#circuitpython-dev
jaunty juniper
@tulip sleet am I understanding correctly that keypad doesn't have a mechanism to report the current (or last known) status of a key ? (like a .value)
tulip sleet
That is correct, but you can derive it from the events. It is stored internally, and originally I made it accessible, but then removed it after discussions with Scott, some of which are in the PR
crimson ferry
In the ESP32-S2 case, is the WATCHDOG ResetReason an indication of a bug in the IDF, or can it also arise from other areas of CircuitPython?
solar whale
@onyx hinge I just did a build for esp32s2 and noticed that help('modules') shows qrio twice. Is this "issue-worhty" ?```
Auto-reload is on. Simply save files over USB to run them or enter REPL to disable.
Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 7.0.0-alpha.6-57-g498755af0 on 2021-08-15; Saola 1 w/Wrover with ESP32S2
help('modules')
main collections micropython ssl
_bleio countio msgpack storage
_pixelbuf digitalio neopixel_write struct
adafruit_bus_device displayio onewireio supervisor
adafruit_pixelbuf dualbank os synthio
alarm errno ps2io sys
analogio espidf pulseio terminalio
array fontio pwmio time
array framebufferio qrio touchio
audiobusio frequencyio qrio traceback
audiocore gc rainbowio ulab
audiomixer getpass random usb_cdc
binascii imagecapture re usb_hid
bitbangio io rgbmatrix usb_midi
bitmaptools ipaddress rotaryio vectorio
board json rtc watchdog
builtins keypad sdcardio wifi
busio math sharpdisplay
canio microcontroller socketpool
Plus any modules on the filesystem
hmm - so is array
onyx hinge
Yeah I have an idea what's going on so tag me
manic glacierBOT
manic glacierBOT
manic glacierBOT
ornate breach
I havenโt run pre-commit in a while, I didnโt realize I was missing some new tools for it lol
manic glacierBOT
ornate breach
Should adding a new board cause a chance to locale/circuitpython.pot ?
storm minnow
I dunno why, but "circuitpython.pot" made me imagine Blinka coming out of a pot with petals on its head like a flower
ornate breach
i don't remember it every changing that so it i'm not sure that's right
ornate breach
created a draft so i can figure this out
blissful pollen
Should adding a new board cause a chance to locale/circuitpython.pot ?
Generally I don't think so but if you ran make translate and it picked up a translation that hasn't been merged to main branch yet it could show up. Pretty sure I've seen that
ornate breach
Generally I don't think so but if you ran make translate and it picked up a tran...
mind looking to see if that's the case?
i just ran pre-commit on it so... i have no idea why it would have changed
i've got to clean up the pr too
the files sorrry ๐
blissful pollen
i'll take a look not sure if i'll be able to say for certain
ornate breach
it looks like it got rearranged some how
tulip sleet
Before you add the board, get your branch or main up to date w/r/t circtuipython/main
If a new message has been added since your branch, you might be out of date, and if you also changed the translations for some reason, there will be a merge conflict
ornate breach
i did it off a clean fork from a few days ago
and the "able to merge" message was green
but i'll rebase github main, rebase that into my branch to see if that removes that file
tulip sleet
adding a board does not affect the translations
ornate breach
i didn't run anything on translations
fetchings and merging github main, fetching that and rebasing locally, and then rebasing my branch off main shows nothing new to commit
tulip sleet
maybe just save your changes out of the repo, delete the branch, reclone and make a new branch
ornate breach
fixed it
i removed it, and then pasted off of adafruit main into it
so now it only shows changes to my files and build.yml
supple gale
I was just looking at this (too late i know) and am wondering where the USB VID and PID come from. I can't trace back 0x612B anywhere. Perhaps I'm not looking in the right spots. I'm looking at the pdf https://www.usb.org/sites/default/files/vendor_ids072121_0.pdf which should be the complete list. Is there a newer one somewhere? Thanks.
ornate breach
that should be the newest one
lone axle
Is it possible in shared-bindings or elsewhere in core code to ensure the type of an argument? If a function is expecting to receive a Bitmap is it possible for it to validate that the object passed is actually a Bitmap?
onyx hinge
@lone axle yes! ```c
mp_obj_t mp_arg_validate_type(mp_obj_t obj, const mp_obj_type_t *type, qstr arg_name) {
if (!mp_obj_is_type(obj, type)) {
mp_raise_TypeError_varg(translate("%q must of type %q"), arg_name, type->name);
}
return obj;
}
perfect, thank you!
lone axle
it seems like Bitmap color value indexes are enforced up to a larger power of 2 than the actual value_count argument passed in the constructor.
I think I would expect this to raise an error:
bitmap_test = displayio.Bitmap(2, 2, 5)
bitmap_test[0,0] = 15
But it does actually execute with no error. Only once you attempt to set the pixel to 16 does it end up raising a ValueError
Is this behavior known / expected? or is this issue worthy? or at least worth some mention in the docstrings?
lone sandal
slender iron
No plans. I don't think its a simple addition because there isn't a soft device for it afaik. Instead, nordic has moved to zephyr. Please file an issue at least so we can track it. I don't believe we have one for it yet
turbid radish
?serverinfo
digital shoreBOT
adafruit
analog bridge
looks like the docs build is failing for some reason unrelated to the PR ๐
https://github.com/adafruit/circuitpython/actions/workflows/build.yml
onyx hinge
<@&356864093652516868> hope to see you in about an hour for the weekly meeting! Add your notes to the doc, and write in if we need to read your notes for you. I'll be the host today.
onyx hinge
https://docs.google.com/document/d/1m31PDWUWCA7AbFN6D0ht7K4TNlqe9_PwM_3qDV3Ng4o/edit?usp=sharing โ in case you need the meeting document link
tulip sleet
it seems like Bitmap color value indexes are enforced up to a larger power of 2 ...
Go ahead and open an issue about this, so it won't get lost.
modern wing
Happily lurking, y'all have a most excellent meeting.
turbid radish
lurking
blissful pollen
lurking but just had a work call, I should be back for 1:30 for in the weeds topic I put hopefully
modern wing
๐๏ธ bang bang bang....you're not recording, are you?
turbid radish
๐๏ธ โ
idle owl
@solar whale Arbitrary thing that Jeff ran into with the QR scanning.... if the QR code is at all curved, e.g. on a sheet of printer paper that you're holding in your hand not perfectly flat, it has all kinds of trouble with the scanning. So... FYI. Make sure your QR codes are flat.
onyx hinge
picks up, plays with macropad
solar whale
Thanks -- they also have to be big enough! I've had issues with small ones.
blissful pollen
<@!343570430042308609> Arbitrary thing that Jeff ran into with the QR scanning.....
Good info on the QR curvature. That's actually affecting something I'm doing at work now so good to know.
idle owl
Good info on the QR curvature. That's actually affecting something I'm doing at ...
Oh good! Glad to help.
modern wing
Another excellent meeting in the bag ๐
ember iris
Is there a link to the qr code demo?
onyx hinge
solar whale
ember iris
<@!459119350851567626> https://learn.adafruit.com/scan-qr-codes-with-circuitpyth...
How much space is left on the chip after the demo is running on it? It might be possible to do a transformation on the qr code boundaries to adjust for curves on paper
modern wing
That reminds me of the pyramid complexes outside Mexico City, strangely enough ๐
solar whale
Sorry -- not sure -- @onyx hinge might know.
gilded cradle
Later
onyx hinge
@ember iris the library does a correction for perspective but doesn't try to do any non-affine correction (whether for a curved piece of paper or something like barrel distortion of the sensor image), as far as I understood it. I don't plan to write that kind of image processing for it, it's beyond my paygrade.
on the esp32s2 there is plenty enough RAM for another copy of the image bitmap, however
ember iris
I might poke around on it to see if I can get it working on curved papers. I probably wont get it going anytime soon, but I'm thinking about it now and will have to give it a shot
onyx hinge
awesome! you might want to contribute it to the library we incorporated, quirc.
ember iris
Sweet! I'm still working when I can on the sgp40 sensor, but an extra project ought to help me refocus when I get too bogged down
onyx hinge
MicroPython 7.0.0-alpha.5-106-g8e201d519-dirty on 2021-08-06; linux version
Use Ctrl-D to exit, Ctrl-E for paste mode
>>> v = (1<<128)
>>> u = v + 1 - v
>>> u == 1
True
>>> u is 1
False
``` it's also true in circuitpython that you can get two integers that are `==` but not `is`. Just had to satisfy myself of that.@onyx hinge you are assuming I know more about MP_REGISTER_MODULE than I do. if you think it's better than I'm ok switching to it
onyx hinge
@slender iron OK, fair enough ๐
Here is the notes document for Mondayโs CircuitPython Weekly meeting. It is at the normal time of 11am Pacific / 2pm Eastern here on Discord. Everyone is encouraged to attend! Please add your hug reports and status updates even if youโll be attending the meeting - itโs super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and weโll read them off during the meeting. Hope to see you there! <@&356864093652516868> https://docs.google.com/document/d/10fzYN9LFHmhD-v47O-HZw6WN8us9PmUtQTcjUbbHxEU/edit?usp=sharing
onyx hinge
I discovered last week that you can convert the PWR USB connector of the Kaluga to the CircuitPython USB connector! It's awesome. You just have to bridge those two pairs of pads, to connect the D+/D- through to the right ESP32-S2 pins
onyx hinge
solar whale
@onyx hinge hmm -- cool --- I will give that a try -- so that make s it connect to D19/D20??
onyx hinge
right
solar whale
very nice -- Thanks.
onyx hinge
They're not designed as solder jumpers so I used fine wire. Smaller soldering than I like to do on a regular basis.
solar whale
I'll likely do the same.
solar whale
I've looked at the schematic but never appreciated what it was implying!!
cunning crypt
No pride in how it looks but it does work
What does it matter if it looks terrible, if it works and few will see it?
onyx hinge
@cunning crypt a healthy attitude, thanks
solar whale
looks adorable to me...
ornate breach
Thanks Scott ๐
slender iron
Thanks Scott ๐
This makes a good point about trademark if you haven't gotten yours already: http://www.ladyada.net/library/openhardware/license.html
ornate breach
Yeah, I need to invest in that for my various boards
idle owl
@onyx hinge Can you send me the compatible MP3 file, or some compatible files if you have multiples?
@onyx hinge Also, is this pretty much the same thing as how it would work for MacroPad? I'm unclear on it because you're saying you don't want to recreate it every time, but if you're calling that in the loop, wouldn't it get recreated on every time through the loop? https://github.com/adafruit/Adafruit_CircuitPython_CircuitPlayground/blob/e0fecb6c73f11c31cfc2a9c0e9ce9805b8fb1cf1/adafruit_circuitplayground/bluefruit.py#L137
onyx hinge
yeah I guess that code does re-create it
idle owl
I'm unsure how to write it so it only creates the thing on instantiation and allows for reuse in the loop.
onyx hinge
compatible mp3 files .. well, I mostly used copyrighted music so that's not great to share. iirc you can save mp3 files from audacity with the bitrate of your choice, so maybe try that.
idle owl
compatible mp3 files .. well, I mostly used copyrighted music so that's not grea...
I mean for testing. I'll sort something out for the guide.
onyx hinge
maybe don't worry about the memory use problem for adding it to macropad. if it's OK that's simplest, if not we can fix it without changing the API
idle owl
maybe don't worry about the memory use problem for adding it to macropad. if it...
Ok
What are the compatible bitrates, then? If I need to make my own?
onyx hinge
I DM'd you some
idle owl
Cheers.
idle owl
@onyx hinge Ok, so, to clarify then, the way I did it in the CircuitPlayground library will work for MacroPad then?
onyx hinge
@idle owl yes, if the CP version is working
idle owl
Ok I'll give it a try.
idle owl
@onyx hinge Ok, so, maybe it's how I did it, or maybe it's the file, but when I play a wav file, it fails to the else: raise ValueError("File must be wav or mp3"), and when I play a seriously shortened version of the MP3 you sent (shortened via audacity), it plays it and then hangs, the LED on the key stays on and nothing works until I reset or reload via REPL.
So I broke all file playback apparently.
I realised it didn't need to be separate like the CircuitPlayground version, which is separate because both boards don't support MP3 playback.
So it's all in one def.
I think I'll pick this up tomorrow.
I feel like it's something silly, and I'm probably simply missing it.
onyx hinge
that doesn't sound good. If you can't tease out a reason for that happening, we can look together.
it could always be a core bug, you never know
idle owl
I'll ping you tomorrow after I look at it with fresh eyes, if I can't sort it out. Thanks.
cunning crypt
I'll ping you tomorrow after I look at it with fresh eyes, if I can't sort it ou...
When I read fresh eyes, I immediately thought "Oh, what store do you get those from?"
More seriously though, I agree. Sometimes we just get 'stuck' on something, get frustrated, and then come back to it and go "Huh, well. That's not that bad."
ember iris
When I read fresh eyes, I immediately thought "Oh, what store do you get those f...
For real, one of the best things I learned during my college experience was how valuable walking away from a problem is. It's crazy how helpful it is
cunning crypt
For real, one of the best things I learned during my college experience was how ...
It's so good! Even just a few minute break to just... not worry about it is fantastic. Or, on larger projects, just move to another section of the project and come back later
ember iris
Walk away, grab water, take a moment to watch a bird or a plant in the wind, or even the clouds, and refocus when you're ready. It's the best. I need to remember how helpful it is because I don't walk away from problems often enough
kind river
No plans. I don't think its a simple addition because there isn't a soft device ...
Will do. After digging through the nRFX drivers in the nRF52 port, it looks like a "bare metal" port might be possible if you added a RPMSG library for the HCI comms to the network core. Zephyr/NCS would be the way to go though, so looks like this will be dependent on a Zephyr port.
slender iron
@kind river You may want to look into the devices/ble_hci folder as a way to do the host side from within CP. Then we can load whatever we need for the controller on the second core
kind river
<@!177230548236763136> You may want to look into the `devices/ble_hci` folder as...
Yeah, the further I dig the more it seems like a bare metal + rpmsg hci port might actually be easier than porting to zephyr.
devout jolt
Hi filesystem-knowing circuitpython-devs, would it even be conceivable to do a read-write sub-mount of the CIRCUITPY filesystem? This sub-mount is read-write to code.py and read-only to the USB host while keeping the rest of "/" writable by the USB host? e.g. storage.remount("/foo", readonly=False) would let CircuitPython write, but allow code.py changes. This would enable two-way "communication" through the filesystem
slender iron
@devout jolt that would require a second partition and file system. I've pushed back against that because I never manage to have enough space in each partition
devout jolt
<@!352910176736772096> that would require a second partition and file system. I'...
I figured it was something like that. And makes sense
jaunty juniper
many boards have 8MB now (from ESPs to Adafruits 2040 boards), maybe we could look into some option on those ?
manic glacierBOT
slender iron
I'm skeptical you'll find a good default option. probably more likely want to create a way to opt into it
jaunty juniper
maybe as an advanced option to erase_filesystem() or something
ornate breach
Remind me if Iโm wrong (I might be) there is a character length to the company and board name that is printed to boot.txt and repl when you hit enter?
jaunty juniper
do you mean a limit ?
ornate breach
Well, on the boot.txt for my Bread 2040 board it only displays my company name not the board name
So it says the CP version followed by โOak Development Technologies with rp2040โ
jaunty juniper
the string is #define MICROPY_FULL_VERSION_INFO ("Adafruit CircuitPython " MICROPY_GIT_TAG " on " MICROPY_BUILD_DATE "; " MICROPY_HW_BOARD_NAME " with " MICROPY_HW_MCU_NAME)
hmm I don't know ๐คท
ornate breach
i probably messed up the config when i did it earlier
yeah, i think i did it wrong the first time
manic glacierBOT
idle owl
@onyx hinge Ok, I'm calling you in. It's still doing the same thing as yesterday. wav file plays once, and fails to the ValueError, MP3 file plays once and then hangs (key LED stays lit, nothing else responds, nothing shows up in serial console), can continue with a serial console reload.
I tried moving some things around in the code, but it didn't fix it. Didn't think it would but it was worth a try.
onyx hinge
@idle owl OK, can you send me the code you're using?
idle owl
Yes.
idle owl
<@!330227457296957440> OK, can you send me the code you're using?
Do you want my CIRCUITPY zipped too?
I'll do that.
There's cruft, but eh.
onyx hinge
umm sure
idle owl
@onyx hinge
Includes latest lib.
which is where the MP3 code is, obvs.
Code is for MacroPad.
onyx hinge
yup, the device I've got here is a macropad
I'm starting with my very simple code and adding a print "done playing" when it's done playing
onyx hinge
because I think I did not test that, I would always just work by making the code reload when I wanted to go again
idle owl
after the while audio.playing: pass?
onyx hinge
import audiopwmio
import audiomp3
import board
import digitalio
shutdown = digitalio.DigitalInOut(board.SPEAKER_SHUTDOWN)
shutdown.switch_to_output(True)
speaker = audiopwmio.PWMAudioOut(board.SPEAKER)
decoder = audiomp3.MP3Decoder(open("/alot-64.mp3", "rb"))
speaker.play(decoder)
speaker.stop()
speaker.play(decoder)
while speaker.playing:
pass
print("done playing")
``` here's my test code, it's not using libraries or anything.but now I have to listen to this whole song, why did I pick such a long "sample" ๐
idle owl
There's a short clip of it in the zip
I used audacity and cut most of it out. The clip is entirely arbitrary.
Mine never gets to the print.
I wonder if it didn't really cut out the rest of the song.
the file size sure says it did cut it properly.
onyx hinge
I see the same thing in my local test program, it doesn't reach 'done playing', but continues in the while loop.
onyx hinge
it doesn't seem to affect wav files, and it does affect the full-duration alot-16.mp3. I'll debug it, but you can toss in an issue in the core in the meantime.
tulip sleet
@onyx hinge there is now a flag in the RP2040 audio_dma.c code: dma->playing_in_progress. The DMA filling code detects that playing is done by getting a GET_BUFFER_DONE status from audiosample_get_buffer AND the buffer length should be set to zero.
I think it did not used to check the buffer length
so the MP3 code should make sure to set the buffer length to zero
onyx hinge
@tulip sleet OK I'll check what the code does .. I think it doesn't set the buffer length to zero
tulip sleet
It actually asks for a buffer twice. The first time it should return the actual buffer length and report DONE. The second time there will be nothing to read and it should report DONE and set the length to zero.
@onyx hinge ^
this is a bit tricky, but it's because I get a final interrupt when the last buffer has played, and only then do I know that it's done. Maybe I should have a last_buffer_being_played flag.
i should check whether mixer does this too.
onyx hinge
mixer is never really done playing, I don't think
tulip sleet
eek
onyx hinge
OK, by inserting some sets of *buffer_size to 0 it does now set .playing to false after awhile. I will have to read back over your explanation to know whether what I'm doing is causing the last mp3 frame to be dropped or not.
tulip sleet
don't set buffer_size to 0 on the last buffer; make it the true size (which it should be already). It's just if you're called and you see there is nothing to play, make sure it's set to zero.
onyx hinge
I don't think I know which buffer is the last buffer
tulip sleet
would you know whethere there is nothing left to decode?
onyx hinge
../../shared-module/audiomp3/MP3Decoder.c:370: MORE_DATA buffer_length=2304
../../shared-module/audiomp3/MP3Decoder.c:370: MORE_DATA buffer_length=2304
../../shared-module/audiomp3/MP3Decoder.c:349: DONE buffer_length=0
../../shared-module/audiomp3/MP3Decoder.c:349: DONE buffer_length=0
``` here are the successive return values of the get buffer function as instrumented, after I bug-fixedthe third one probalby shouldn't be zero
but you should expect to see DONE returned twice
onyx hinge
Both of those are the same condition, there was no "sync word" left in the mp3 file, indicating the start of the next chunk of mp3 data
tulip sleet
ah, ok
I think it will not cut off, then, but you can test that aurally
unless the decoding is more than one buffer's worth
onyx hinge
../../shared-module/audiomp3/MP3Decoder.c:364: DONE buffer_length=2304
../../shared-module/audiomp3/MP3Decoder.c:349: DONE buffer_length=0
../../shared-module/audiomp3/MP3Decoder.c:349: DONE buffer_length=0
``` is this better? It may cause a bit more disk access.is there really no more data after the 2304? If so then there's not an issue
and the first way should be ok?
onyx hinge
OK
tulip sleet
I was just worried it was saying DONE before all the data was actually read
onyx hinge
there's always an integer number of complete 2304-byte frames in an mp3 file
tulip sleet
the decoded data is always 2304 bytes?
tulip sleet
strange number
onyx hinge
So's 525 or 1080 but nobody talks about it
During encoding, 576 time-domain samples are taken and are transformed to 576 frequency-domain samples.[clarification needed] If there is a transient, 192 samples are taken instead of 576. This is done to limit the temporal spread of quantization noise accompanying the transient (see psychoacoustics). Frequency resolution is limited by the small long block window size, which decreases coding efficiency.[66] Time resolution can be too low for highly transient signals and may cause smearing of percussive sounds.[66]
so maybe there could be 4*192 sometimes? I don't recall having seen it
I'm happy someone gets jokes about obsolete technology
tulip sleet
audiomixer_mixer_get_buffer() always returns GET_BUFFER_MORE_DATA; hmm, but get_playing will tell if any voice has finished playing. Maybe audiomixer_mixer_get_buffer() should check for that and say it's done.
onyx hinge
@idle owl see here's why it's great that someone besides me tried to use mp3 playback. because my testing was embarassingly incomplete. Thanks so much for doing that, and I'm sorry that in the meantime you felt like you must be doing something wrong.
idle owl
<@!330227457296957440> see here's why it's great that someone besides me tried t...
No worries. It's that much more satisfying finding out it's not me after thinking it was me.
tulip sleet
did you write mixer?
onyx hinge
@tulip sleet when I implemented the mp3 soundboard for neotrellis, I liked that the audiomixer kept playing forever. All I had to do was concern myself with which track was available to play the next sample when it was pressed, but I didn't have to decide whether to restart playing the audiomixer itself..
no, I helped get it over the finish line but sommersoft worked on it in the middle, and somebody else started it
tulip sleet
if you call stop explicitly, it will work, and get_playing does do a stop as a side effect
onyx hinge
a mixer with no channels playing outputs "no-sound" forever and that's fine
tulip sleet
so maybe that's ok, as a use case, though we should probably document it
onyx hinge
there may be hiss you'd prefer to avoid especially with pwm, I guess..
tulip sleet
the stop will shut down the PWM and stop the hiss. I think we need to add the speaker/amp enable pin to the next rev of the API
like Limor said, we need to see how other people do ti
onyx hinge
an alternative design would be that the mixer would default stop if no voices were playing; if started with no voices, it would play 1 buffer of silence. So if you 'play' the mixer with looping=True it would work like now, but if you want it to stop when nothing's playing (so you can shut down the amplifier or whatever) and manage it yourself you'd just omit looping=True
tulip sleet
bool common_hal_audiopwmio_pwmaudioout_get_playing(audiopwmio_pwmaudioout_obj_t *self) {
bool playing = audio_dma_get_playing(&self->dma);
if (!playing && self->pacing_timer < NUM_DMA_TIMERS) {
common_hal_audiopwmio_pwmaudioout_stop(self);
}
I won't change mixer now, but I think most programs will work ok, due to the side effect when checking
onyx hinge
that may have the debug prints in it, hold on..
well, if it spews to the display and makes everything sound BAD just displayio.release_displays()
idle owl
Prints included, yes.
But it stops at the end of playing, and I can still use things!
Now I need help figuring out why the wav playback fails to the else: ValueError() every time it's done. ๐
onyx hinge
this one should be without debug prints
@idle owl let's see the full code for the play function, maybe something will leap out at me
onyx hinge
- if file_name.lower().endswith(".mp3"):
+ else if file_name.lower().endswith(".mp3"):
you have if/if/else
idle owl
Oh that matters?
ok
Testing
Thank you!!!
I swear I've done it before with if/it/else and it was fine
onyx hinge
do you wanna think about why it matters for a second?
onyx hinge
oh I am bad at python
idle owl
๐ You are very much not.
onyx hinge
873 self._speaker_enable.value = True
874 if file_name.lower().endswith(".wav"):
875 with audiopwmio.PWMAudioOut(board.SPEAKER) as audio: # pylint: disable=not-callable
876 wavefile = audiocore.WaveFile(open(file_name, "rb"))
877 audio.play(wavefile)
878 while audio.playing:
879 pass
880 if file_name.lower().endswith(".mp3"):
881 else if file_name.lower().endswith(".mp3"):
882 with audiopwmio.PWMAudioOut(board.SPEAKER) as audio: # pylint: disable=not-callable
The key is to understand where CircuitPython will go next after the while loop at line 878/879 is done...
878 while audio.playing:
879 pass
880 print("what if there is a print statement here?")
881 if file_name.lower().endswith(".mp3"):
``` you might also want to think about what happens if the next line is something other than `if`hmm.
onyx hinge
878 while audio.playing:
879 pass
880 return
881 if file_name.lower().endswith(".mp3"):
``` or what effect adding this could haveThis PyCharm is complaining about already.
cunning crypt
oh I am bad at python
Python is pretty much all I use, and I still do else if far too often...
onyx hinge
oh I didn't fix the "else if" yet in those samples as pasted, or is it sad about something besides that?
onyx hinge
Python is pretty much all I use, and I still do `else if` far too often...
I blame my editor; it doesn't show "else if" in bright error-red
cunning crypt
oh I didn't fix the "else if" yet in those samples as pasted, or is it sad about...
It'll yell about bad syntax I think
idle owl
It's sad about the print at the same level as the if/elif between the if and the elif.
cunning crypt
I blame my editor; it doesn't show "else if" in bright error-red
Same here, it just shows it as fine and goes on it's merry way
idle owl
Not your extra else if.
onyx hinge
oh, oh, my examples were still bad then
I meant to go back to the if/if/else version, and think about what if/print/if would do
idle owl
oh
onyx hinge
def describe_number(x):
print(f"x is {x}")
if x < 100:
print("x is pretty small")
if x < 10:
print("x is really small!")
else:
print("x is big!")
print()
describe_number(5)
describe_number(50)
describe_number(500)
``` another fresh example that I actually tried before pasting in, your problem is like the reason that this prints the wrong things for 50..though it's still not a great example, because just changing an if to an elif is still wrong.
so all these words later, did anything help make the problem / solution click for you?
idle owl
Not entirely, if I'm being honest. But it's ok.
onyx hinge
fair
idle owl
I guess I should add an MP3 example to use in the guide.
onyx hinge
@slender iron @tulip sleet looking at the way mp3s and wavefiles work, and recalling how we changed ondiskbitmap to take the filename instead of the open file .. I wonder if we should do it for mp3 and wave before beta.
tulip sleet
that is an interesting idea. I was wondering what would happen if I closed the open() .
on the other hand, in python I think many things take file-like objects for duck-typing purposes
so I'm not sure I would do this now without further cogitation
taking something that obeys a protocol can be more convenient. e.g. "has .value (like a DigitalInOut instead of passing a pin). I considered that for keypad, so I might pass in TouchIns, but it's not so easy to validate a duck-typed arg, esp in C
onyx hinge
@tulip sleet that's true, we also have talked about wanting to stream mp3s from wifi someday, and this would make that harder
slender iron
fyi I'll be around later. going to pick up the car now before the beagle arrives
solar whale
@onyx hinge Let me know if you have a few minutes to chat about an issue I am having with the webcam on the Saola -- it may be easier to explain over voice. No rush.
The problem involves AIO not displaying updated images. I was wondering if you have seen similar behavior -- It works fine on the Kaluga though but when I use the saolo, it often see the new image arrive, but AIO seems to ignore it. It is very intermittent.
idle owl
@gilded cradle Any chance you could help me out with an Arduino issue?
I think it might be at the library level and I don't know it well enough to be certain. I don't know your Arduino skill level though.
gilded cradle
Sure
idle owl
Ok, so the MCP9601 is a new breakout. It's basically a MCP9600 except for the device ID.
I'm trying to get the simpletest code to run on it, and it's failing immediately saying it can't find the sensor.
The I2C address is right
gilded cradle
Ok, just a moment...
idle owl
Here's the lib: https://github.com/adafruit/Adafruit_MCP9600 and the code fails here even if I change line 8 to Adafruit_MCP9601: https://github.com/adafruit/Adafruit_MCP9600/blob/f9b5dae333882b9770742922f9c712f89d747afe/examples/mcp9600_test/mcp9600_test.ino#L20
gilded cradle
I was just checking if I had one. I don't.
idle owl
Yeah they're super new and went out of stock quickly.
I thought mine was broken, and was concerned because I couldn't get another one. But it works in CircuitPython.
Am I not understanding how I need to update the code to work with the 9601?
Because I definitely don't understand subclassing in Arduino.
gilded cradle
Have you done an i2c scan to verify your device matches the expected one?
idle owl
I don't know how to do that in Arduino. That was my thought too, but I don't have that code.
gilded cradle
You can do it in CP
gilded cradle
Device id should be the same regardless
idle owl
There's a weird thing with the CP I2C scan though
it only shows the address once after being plugged in
gilded cradle
oh?
idle owl
then shows nothing.
gilded cradle
That's odd
idle owl
I tried to figure this out the other day, and never did. The code runs just fine.
But the I2C scan only shows an address on the first run.
After physically plugging it in.
gilded cradle
oh, so just an issue with scanning
gilded cradle
Ok, who knows. If the code works, that's promising.
idle owl
I simply have no idea why the Arduino code isn't working. ๐
gilded cradle
Wait, you said default i2c is 0x67?
gilded cradle
Huh, this says 0x40: https://github.com/adafruit/Adafruit_MCP9600/blob/f9b5dae333882b9770742922f9c712f89d747afe/Adafruit_MCP9600.cpp#L32
uneven mango
I found a bug in circup when installing the Pimoroni LTR559 library. Should I create an issue first, then a PR, or just the PR?
idle owl
I found a bug in circup when installing the Pimoroni LTR559 library. Should I c...
Either way works! If you already have a fix, PR is just fine.
idle owl
Huh, this says 0x40: https://github.com/adafruit/Adafruit_MCP9600/blob/f9b5dae33...
Device ID and I2C address are separate
Separate registers.
gilded cradle
Oh, ok. Nevermind. Let me poke around some more.
idle owl
Thank you
uneven mango
Either way works! If you already have a fix, PR is just fine.
thanks.
gilded cradle
Are both MCP9600 and MCP9601 same I2C?
gilded cradle
Ok, let me look again
idle owl
The Arduino lib defaults to the same address anyway
gilded cradle
Ok, the i2c scanning and it not finding the device may be related.
idle owl
Or wait
still checking
Yes. I2C default address is the same
Also I tried unplugged it and plugging it back in and it still didn't find it.
which made the I2C scan find it in CircuitPython.
gilded cradle
From what I can tell looking at the code, it sounds like you did it right. Maybe ladyada has some ideas?
idle owl
OK, I wanted to make sure I hadn't missed something obvious before bugging her.
Thanks for looking into it with me!
gilded cradle
No worries. You're welcome.
idle owl
@tulip sleet @onyx hinge Do either of you know who setup the Reuse licensing stuff on the libraries? I can't use the license I need to on some files, and I'm not sure what I'm even looking for to see if I can add it or something.
onyx hinge
<@!426200547024961539> Let me know if you have a few minutes to chat about an is...
sorry, no, I haven't been seeing anything like that
onyx hinge
@idle owl I didn't put it in place, but I can try to help you use it. what's up?
idle owl
<@!330227457296957440> I didn't put it in place, but I can try to help you use i...
I need CC BY-SA 4.0 for some files, and apparently it's not allowed.
* Bad licenses: CC BY-SA 4.0
* Deprecated licenses:
* Licenses without file extension:
* Missing licenses: CC BY-SA 4.0
* Unused licenses:
* Used licenses: CC-BY-4.0, MIT, Unlicense
* Read errors: 0
* Files with copyright information: 35 / 35
* Files with license information: 35 / 35
Unfortunately, your project is not compliant with version 3.0 of the REUSE Specification :-(```Hmm wait
maybe it's the format now that I read it again.
Let me try to add some more dashes.
onyx hinge
idle owl
That didn't work. Still says "missing".
onyx hinge
this is the canonical list apparently
idle owl
It's listed.
onyx hinge
"CC-BY-SA-4.0" ?
onyx hinge
also there's a difference between bad and missing, it's a different step to fix a missing license
idle owl
* Deprecated licenses:
* Licenses without file extension:
* Missing licenses: CC-BY-SA-4.0
* Unused licenses:
* Used licenses: CC-BY-4.0, MIT, Unlicense
* Read errors: 0
* Files with copyright information: 35 / 35
* Files with license information: 35 / 35```Right. Hmm.
onyx hinge
yay you got closer to the solution
now you can "reuse download --all" the new license file
& add with git add
onyx hinge
yes with pip
idle owl
hm
I found the individual file after digging.
And added that.
It passes now. Thank you so much @onyx hinge !
onyx hinge
hooray!
onyx hinge
on it
onyx hinge
@idle owl works great, but I had some minor feedback
idle owl
<@!330227457296957440> works great, but I had some minor feedback
I was replying so quickly it replied to the wrong comment. I addressed the feedback! Thanks for taking a look!
slender iron
anyone with a funhouse want to look at https://github.com/adafruit/circuitpython/issues/5159?
tulip sleet
I was going to try that with some other ESP32-S2 board too. I have a lot of issue assignments so I didn't pick it up immediately ๐
slender iron
kk ๐
onyx hinge
still spinning my wheels on this other esp32s2 watchdog-biting bug ๐
ornate breach
anyone with a funhouse want to look at <https://github.com/adafruit/circuitpytho...
It almost seems like a hardware issue in a way. I might see if I can log a similar behavior with my ESP32-s2 with a few I2C devices hooked up.
onyx hinge
Tomorrow I'll switch issues for sure if I don't have a breakthrough within the hour today
idle owl
you'll probably figure it out after you switch ๐
I was hoping that would happen this morning for me, but Jeff had to figure out my problem ๐
I won't be able to return the favor, sadly.
slender iron
I value all the testing, reviews and guides you do
solar whale
sorry, no, I haven't been seeing anything like that
Thanks -- I'll keep investigating....
idle owl
@onyx hinge OK, I think I'm to the point where I need some pointers for this MP3 guide. If you'd rather I wait until tomorrow for the bits that need your knowledge, that's absolutely fine. I can fill in other bits until then.
onyx hinge
@idle owl let's wait if that's OK
idle owl
<@!330227457296957440> let's wait if that's OK
Yep! I'll ping you tomorrow and we can coordinate.
onyx hinge
@analog bridge if you're around, can you tell me about why you chose to modify parse_compile_execute to implement atexit? The reasons for the choice are not obvious to me.
if you don't jump in with an answer I'll leave the question in the review request.
steel shell
New to CircuitPython here. I was wondering if it's possible to use other python libraries like pandas or matplotlib to do data analysis with data collected from sensors that have CircuitPython installed on it?
tulip sleet
New to CircuitPython here. I was wondering if it's possible to use other python ...
let's continue this conversation in #help-with-circuitpython . This is more a development channel.
ornate breach
Hey @slender iron I tested to see if I got the same I2C errors on my ESP32-S2 pixel wing that was reported with the funhouse and I donโt have any issues with more than one I2C device. Itโs possible itโs isolated to that board specifically.
Iโm using the longer I2C Stemma connectors too
onyx hinge
@blissful pollen Disable something else on that board, such as ulab or audiopwmio -- look at the non-flash version to see what we've already had to disable.
blissful pollen
<@!228322543507865601> Disable something else on that board, such as ulab or aud...
Thanks will do! I didn't want to disable something that was needed for that board
onyx hinge
You have my permission, for what that's worth.
manic glacierBOT
slender iron
@tulip sleet here is zephyr currently proposed pinctrl api: https://github.com/zephyrproject-rtos/zephyr/pull/37572
crimson ferry
trying to isolate a few intermittent esp32s2 lock-ups (code stops, serial dead, but CIRCUITPY sometimes still active)... does microcontroller.ResetReason.WATCHDOGarise from core code (idf) watchdog, watchdog python code, or both?
I just learned about the watchdog module today and added it to a couple of units, but was definitely seeing that reset reason before with no watchdog code
jaunty juniper
@lone axle I noticed the displayio_annotation module is named circuitpython-displayio-annotation on pypi, as opposed to adafruit modules that put the -circuitpython- in the middle, making circup unable to install it from a requirements file containing pypi names.
analog bridge
trying to isolate a few intermittent esp32s2 lock-ups (code stops, serial dead, ...
it should be both
crimson ferry
does the core have its own watchdog timer, or is it catching the idf WDT, or both?
analog bridge
the core doesn't have a watchdog... the idf might have it internally.
ornate breach
trying to isolate a few intermittent esp32s2 lock-ups (code stops, serial dead, ...
Is this related to the โdropping circuitpy in save or adding library to lib folderโ ?
crimson ferry
the core doesn't have a watchdog... the idf might have it internally.
thanks. I do get that reason sometimes, but lock-ups other times, so just trying to sort the venn diagram of what it catches
crimson ferry
@ornate breach I'm not sure... when I see lock-ups they are typically on unattended devices
ornate breach
I was experiencing yesterday where code would randomly just stop running on my PixelWing
And also dealing with the issue of dropping circuitpy drive if I save code.py or add anything to the lib folder
Running 7 beta 6
ornate breach
It was a build from two days ago
I sent that board off to someone who was interested in trying it out. Iโm building another this evening and Iโll do a clean build
crimson ferry
I was disabling auto-reload between alpha6 and this PR 3 days ago https://github.com/adafruit/circuitpython/pull/5152
ornate breach
The randomly stopping of code was intermittent
It would run for 30 seconds to up to 10 minutes and it would just stop running
Had to hit reset to restart
crimson ferry
I'm guessing get_previous_traceback() was None
ornate breach
Yeah, from what I could tell
It would nuke CIRCUITPY when it stopped as well
Iโll look over the behavior again this evening when I build up another PixelWing
lone axle
<@!382939733107408897> I noticed the `displayio_annotation` module is named `cir...
nice catch thank you. When I have some time I'll dig into it a bit and see if we can tweak circup to be able to work with that naming scheme as well. If I understand correctly the only way to fix without a change to circup would be add some word to the beginning of the pypi name, but I'm not sure what we would add circuitpython-circuitpython-[library name] feels a bit too redundant.
lone axle
or maybe that wouldn't be a fix anyway actually. I haven't looked in the code yet. Possibly the "adafruit" is hardcoded.
jaunty juniper
nice catch thank you. When I have some time I'll dig into it a bit and see if we...
I have been working on switching circup to using the json file to find dependencies (and version numbers), that would allow a reverse search with the real pypi name
jaunty juniper
but that still requires a lot of work (at least rebase since I first looked into it a few months ago, and fix a bunch of tests)
oh but the pypi name in the json file is incorrect right now: setup.py says circuitpython-displayio-annotation but the json file says "pypi_name": "circuitpython-org-displayio-annotation",
lone axle
oh but the pypi name in the json file is incorrect right now: setup.py says `cir...
Do you know if there would be an expectation for what would be the PyPi name to work (if included in a requirements file) even if the library itself is not released on PyPi due to not being compatible with Blinka currently? I know some of the widget libraries will be in that boat.
jaunty juniper
Do you know if there would be an expectation for what would be the PyPi name to ...
currently, either make the pypi name the same as the module name or stick a -circuitpython- somewhere in the middle.
The rules are tailored to the format used by Adafruit modules: company-circuitpython-driver-or-helper becomes company_driver_or_helper, anything that doesn't contain circuitpython is unchanged.
tulip sleet
anyone disagree that we should have unicode filename support on all boards?
No, it sounds like a fine idea, assuming it's compatible with the FAT support on all the OS's.
slender iron
I think it's just the fatfs api. the fatfs on disk is two bytes per character
In the FAT filesystems with LFN extention, also + , ; = [ ], white space and extended characters U+000080 to U+10FFFF are legal for the object name
I'll need to squeeze some builds then
what do we think about figure out how to link the -Os stdlib?
tulip sleet
i looked at this a bit; I think it didn't look too bad, but I didn't look in detail at how to specify the lib path. I don't think we want to build it ourselves; we could take it from the arch build, and then we need to put it on S3 or something like that
tulip sleet
I'd get the matching version down to the bug level n.n.x, make x match, if that's easy. And I think we don't use it if its version doesn't match the current compiler version
Your own circumstance is unusual, since you're not using the ARM download. So if it's easy you could test with this, else i could test
slender iron
kk, I can look into this @tulip sleet. diving into usb atm
tulip sleet
i can look too, if you are busy. Let me know if you start to work on it. I am looking at samd audio atm
crimson ferry
Is there a concise description somewhere of the priorities within the core, for interrupts, watchdog, serial, usb, etc.?
slender iron
i can look too, if you are busy. Let me know if you start to work on it. I am lo...
kk, won't get to it today but maybe tomorrow
slender iron
Is there a concise description somewhere of the priorities within the core, for ...
what do you mean by priorities?
crimson ferry
I assume code isn't purely sequential, that there are interrupts and context switches, events, etc. Maybe that's wrong.
slender iron
you are correct
slender iron
interrupts can interrupt things
and on esp32s2 there is freertos as well
tinyusb runs in its own task separately from cp
crimson ferry
something is not being caught by watchdog, that's my current question, but I also seem to recall discussion some time ago about relative priorities of serial, control-C, etc
could have pre-dated TinyUSB, or was more of a question of precedence of TinyUSB vs. the rest
slender iron
watchdogs typically reset the whole cpu
crimson ferry
do our interrupts have priorities amongst themselves?
slender iron
yes, interrupts can have priorities. I know more about arm priorities than xtensa ones
crimson ferry
thanks, that gives me a little context, I'll poke around more in the code
Ideally I'd like my code to run forever (I do have some 6.x devices in remote places that I never need to touch), but absent that, I'd like ways to catch anything that may happen, reload (or reset if necessary), and supply debug info to the next iteration
slender iron
ya, it's a tall order because it is whack-a-mole
blissful pollen
The best way I found for long running is using the watchdog timer. You could have a global try/catch block and write that info somewhere and let it timeout for the watchdog to restart things
crimson ferry
thanks, I haven't resorted to a global try/except yet, but watchdog isn't catching my current lock-up situation, not sure what else to do... get_previous_traceback() is None, so that's no help
blissful pollen
strange though i have seen rare cases of it, but even if it drops to the REPL it should trigger the watchdog I believe
manic glacierBOT
idle owl
@tulip sleet Do we have an ETA for the next release of CircuitPython? This guide will kind of rely on that MP3 playback fix. I still need some hardware to do the second part of it, so it's partially on hold anyway, but I wanted to know what the plan was if there is any.
tulip sleet
i can do one at any time. What is the target for the guide? I was thinking of waiting until Scott debugged the i.MX USB issue (USB is not working at all on those boards), but I don't think he's found the cause of it. But he's working on it right now.
idle owl
i can do one at any time. What is the target for the guide? I was thinking of wa...
Let me ask Limor whether she intends to make it live without the page I don't have hardware for, or if she wants to wait. Because she's got me waiting on ordering until another thing goes into the shop, so it might even be next week if she wants that page in to make it live. If not, then the Overview and MacroPad pages will be done probably tomorrow. So let me find out what her plan is for this. I don't think it's really a rush job, people aren't clamoring for it, it's simply something we should document.
prime flower
The best way I found for long running is using the watchdog timer. You could hav...
agreed - especially for networking-based tasks
idle owl
@onyx hinge Let me know if there's a good time to talk MP3 limitations today.
onyx hinge
kattni
idle owl
me
idle owl
Ok, so the blurb in the Essentials guide now applies to SAMD51 and nRF, yes?
onyx hinge
yes
onyx hinge
for pico I'd say stick with rates 64kbit/s and under
for all of them, doing things like updating the display or having intense flash activity like reading and writing files can make them give distorted sounds or noise
I am sure you experienced this with pico
onyx hinge
macropad?
idle owl
That's the hardware I'm waiting to order.
Oh yeah played on MacroPad
All I did was play when a key was pressed though
onyx hinge
I was incorrectly equating the pico name with rp2040, my apologies
idle owl
Ah fair enough
this guide includes Pico so it made sense to me
@onyx hinge What about sample rates for RP2040?
tulip sleet
i would expect similar issues, but one could test; there's nothing magical about the RP2040 that would prevent those issues. I heard glitches when writing files, for instance
idle owl
Also, are mono and stereo both fine for RP2040?
onyx hinge
alot-32.mp3: MPEG ADTS, layer III, v2, 32 kbps, 16 kHz, JntStereo
alot-64.mp3: MPEG ADTS, layer III, v2, 64 kbps, 24 kHz, JntStereo
``` those files I shared with you are 8 / 16 / 24kHz sample rate and stereoOk
onyx hinge
I am not sure if it downmixes or plays just one channel though
so, like, if you're listening to the white album on your macropad you may be disappointed
onyx hinge
ikr
tulip sleet
there's no channel mixing in the RP2040 audio code
without explicitly using the mixer
onyx hinge
yeah so I bet you just hear the left channel
the mixer can't do left/right channel mixing, I don't think
tulip sleet
ok, I didn't even know that
idle owl
You mention the SAMD51 DAC output, but not the nRF. Is there info on the nRF DAC output that's worth including?
Or is that irrelevant on nRF boards
tulip sleet
i was testing some (non-MP3) stereo files yesterday and it played just one channel, but it did work.
idle owl
Also, we have SAMD51 (21 notwithstanding), nRF, RP2040...... What else? ESP32-S2. Does that support MP3? And if so, with what limitations?
idle owl
Appears FunHouse does not have mp3 module.
onyx hinge
https://circuitpython.readthedocs.io/en/latest/shared-bindings/audiomp3/ yeah it seems to be limited to ARM-family microcontrollers
which is everything but esp32 and fomu
idle owl
Ok
@onyx hinge ```For SAMD51 boards:
CircuitPython supports any MP3 file you like. Mono and stereo files from 32kbit/s to 128kbit/s work, with sample rates from 16kHz to 44.1kHz. The DAC output on the SAMD51 is 12-bit so there's not much point in using higher bitrates. Be aware, doing things like updating a display, or having intense flash activity like reading and writing files can result in distorted sounds or noise during playback.
For nRF boards:
CircuitPython supports any MP3 file you like. Mono and stereo files from 32kbit/s to 128kbit/s work, with sample rates from 16kHz to 44.1kHz. The DAC output on the SAMD51 is 12-bit so there's not much point in using higher bitrates. Be aware, doing things like updating a display, or having intense flash activity like reading and writing files can result in distorted sounds or noise during playback.
For RP2040 boards:
CircuitPython supports certain MP3 files. For RP2040, mono and stereo are both supported, and you should stick with files less than 64kbit/s, with sample rates from 8kHz to 24kHz. Be aware, doing things like updating a display, or having intense flash activity like reading and writing files can result in distorted sounds or noise during playback.```
Anything need fixing or worth including?
onyx hinge
"The DAC output on the SAMD51 is 12-bit" doesn't belong in the nRF section
idle owl
Oh I thought I deleted it.
onyx hinge
nRF is a PWM output with approximately 8 bits
idle owl
Oh wait I was asking earlier what I should put there for nRF
So I didn't delete it because I wasn't sure if it should be replaced.
onyx hinge
aha
tulip sleet
nrf also has I2S
onyx hinge
"The nRF has a PWM output with approximately 8 bits, so there's not much point in using high bitrates."
I think all 3 of those have i2s available, it's true
idle owl
Got the update, thanks.
tulip sleet
but the builtin speakers use PWM or DAC
idle owl
hmm.
onyx hinge
if using i2s you still need to stay within the rates the board can handle but you get a much better DAC
idle owl
And I2S works with MP3?
If it's supported across the board, then it can be hardcoded into the template.
onyx hinge
yes, i2s works with mp3
onyx hinge
"These microcontrollers also support I2S, which allows use of a higher quality external DAC. The sample rates and bit rates are still limited to those shown above, but the audio quality can be substantially better."
idle owl
Thank you
@onyx hinge Is there something to say about the output on the RP2040? Similar to the "nrf has a PWM that's 8 bits etc etc" line in the other two sections.
onyx hinge
hum, I don't know that off the top of my head
idle owl
Ok
onyx hinge
if dan doesn't know, scott will
tulip sleet
the rp2040 uses 10 bits for the PWM. I'm not sure the nrf uses 8 bits
idle owl
Thank you
onyx hinge
the nrf is "it's complicated, but around 8 bits"
tulip sleet
the RP2040 can use a really high carrier freq, so we can get 10
idle owl
Nice. I left "approximately" in the nRF section.
TFW I manage to remember the exact phrase Jeff used right after posting a code snippet I needed so I found it in searching on the first try
Oi, everything is taking forever. I might need to reboot. Bleh.
Speaking of Jeff's code... why is this like this, @onyx hinge ? py speaker.play(decoder) speaker.stop() speaker.play(decoder)
idle owl
On it
Seems to work the same. Code reloaded in the middle of playing and some loud sharp sounds startled me quite thoroughly, but I don't think it was related to removing the first two lines.
So the SPEAKER_SHUTDOWN bit is only necessary on boards with a built-in speaker, and that pin, correct? The pseudo-code starter example for this is going to be gnarly.
Since this template is supposed to work with whatever board.
onyx hinge
atmel-samd/boards/circuitplayground_express/pins.c: { MP_ROM_QSTR(MP_QSTR_SPEAKER_ENABLE), MP_ROM_PTR(&pin_PA30) }, we also have SPEAKER_ENABLE and ```c
atmel-samd/boards/cp32-m4/pins.c: { MP_OBJ_NEW_QSTR(MP_QSTR_SPEAKER_P), MP_ROM_PTR(&pin_PA02) },
atmel-samd/boards/cp32-m4/pins.c: { MP_OBJ_NEW_QSTR(MP_QSTR_SPEAKER_N), MP_ROM_PTR(&pin_PA05) },
Express is irrelevant, it's not supported, I thought.
Yeah speaker_enable is on CPB though
So, one section for MacroPad, one section for CPB, and one section for generic RP2040/nRF that requires external speaker, and one section for generic SAMD51 that requires an external speaker...
CLUE is nRF with built in speaker.
blergh.
No shutdown or enable pin.
manic glacierBOT
tulip sleet
@idle owl macropad is the only one where it's called SPEAKER_SHUTDOWN; all the other call it SPEAKER_ENABLE
I was wondering if we should add the other name. I think some may be inverted, some not, but I haven't checked.
idle owl
I was wondering if we should add the other name. I think some may be inverted, s...
Yeah I think that is the case.
onyx hinge
shutdown.switch_to_output(True)
```on macropad I had to set the pin to True even though it was called SHUTDOWN so I don't know about the polarity generallyanother one of these inverted shutdowns o_O
tulip sleet
macropad is really SPEAKER_SHUTDOWN_INVERT (active low to shutdown); so it even more should be called SPEAKER_ENABLE
idle owl
ugh.
um.
Do we break things and fix it?
MacroPad library might be the only thing it breaks.
tulip sleet
we can add SPEAKER_ENABLE as an alias
idle owl
Won't that be confusing to have both?
tulip sleet
and use that preferentially from now on. When 7 comes out we can change the guides
idle owl
Since they're kind of the opposite...
tulip sleet
when 8 comes out we drop SPEAKER_SHUTODWN
tulip sleet
we can discuss that
it was added here: https://github.com/adafruit/circuitpython/pull/4864
onyx hinge
macropad isn't in a released version so can we just break it?
(but 7.alpha is on everyone's device in the field)
idle owl
I want that to be the case, but I also see Dan's point in doing it incrementally.
tulip sleet
we can ask at 6pm, or just open a PR and ping limor
idle owl
Oops. ๐ git pull adafruit pain fatal: couldn't find remote ref pain
ornate breach
Oops. ๐ ```git pull adafruit pain
fatal: couldn't find remote ref pain```
At least it didnโt find pain, might be concerning if it did ๐๐
idle owl
Right?
tulip sleet
we could also alias the SPEAKER_ENABLE pins as SPEAKER_ENABLED_INVERTED if they enable the speaker when pulled low. I don't know if that 's true or not for any of them
idle owl
@tulip sleet Should I put a comment in pins.c about adding SPEAKER_ENABLE or just explain in the PR?
tulip sleet
I would add a comment since it's confusing to read: SPEAKER_SHUTDOWN is deprecated and will be removed later
idle owl
Ok that's what I thought, which is why I asked.
Now for the stupid question.... how do I do a comment in C? // or something?
tulip sleet
my rule of thumb is that if something is going to scratch their head about something, add a comment
idle owl
I agree entirely
tulip sleet
yah //
idle owl
nice.
Woah.
I've never seen this before. ```Translations.............................................................Failed
- hook id: translations
- files were modified by this hook
find extmod lib main.c ports/atmel-samd ports/cxd56 ports/esp32s2 ports/mimxrt10xx ports/nrf ports/raspberrypi ports/stm py shared-bindings shared-module supervisor -type d ( -path "ports//build-" -o -path "ports//build" -o -path ports/atmel-samd/asf4 -o -path ports/cxd56/spresense-exported-sdk -o -path ports/esp32s2/esp-idf -o -path ports/mimxrt10xx/sdk -o -path ports/raspberrypi/sdk -o -path ports/stm/st_driver -o -path lib/tinyusb -o -path lib/lwip -o -path extmod/ulab/circuitpython -o -path extmod/ulab/micropython ) -prune -o -type f ( -iname ".c" -o -iname ".h" ) -print | (LC_ALL=C sort) | xgettext -f- -L C -s --add-location=file --keyword=translate --keyword=MP_ERROR_TEXT -o circuitpython.pot.tmp -p locale
python3 tools/check_translations.py locale/circuitpython.pot.tmp locale/circuitpython.pot; status=$?; rm -f locale/circuitpython.pot.tmp; exit $status
Traceback (most recent call last):
File "/Volumes/circuitpython.git/circuitpython/tools/check_translations.py", line 10, in <module>
import polib
ModuleNotFoundError: No module named 'polib'
make: *** [check-translate] Error 1
find extmod lib main.c ports/atmel-samd ports/cxd56 ports/esp32s2 ports/mimxrt10xx ports/nrf ports/raspberrypi ports/stm py shared-bindings shared-module supervisor -type d ( -path "ports//build-" -o -path "ports//build" -o -path ports/atmel-samd/asf4 -o -path ports/cxd56/spresense-exported-sdk -o -path ports/esp32s2/esp-idf -o -path ports/mimxrt10xx/sdk -o -path ports/raspberrypi/sdk -o -path ports/stm/st_driver -o -path lib/tinyusb -o -path lib/lwip -o -path extmod/ulab/circuitpython -o -path extmod/ulab/micropython ) -prune -o -type f ( -iname ".c" -o -iname ".h" ) -print | (LC_ALL=C sort) | xgettext -f- -L C -s --add-location=file --keyword=translate --keyword=MP_ERROR_TEXT -o - | sed -e '/"POT-Creation-Date: /d' > locale/circuitpython.pot```
Er, begins with Translations......Failed, but apparently although it's highlighted, it did not copy.
What step did I miss somewhere along the line?
tulip sleet
brew install gettext; break link gettext --force
idle owl
Thank you
idle owl
I just realised I wasn't in my venv.
That might be the problem.
That was it.
Passed this time.
Hmm. It modified this though: modified: locale/circuitpython.pot
As in that's showing up in my git status now.
Am I supposed to add that to my PR, or is that similar to submodule update failures that show up as unstaged files?
tulip sleet
it should not change that. Why don't you git restore that and run a clean build again
idle owl
I did pulls and all that before doing this....
I'll back out to main, pull again, and make a new branch.
It's only one line of code and a comment I updated. I can paste it back into the file.
tulip sleet
one of us should check the other SPEAKER_ENABLE boards
to see about SPEAKER_ENABLE_INVERTED
idle owl
From github.com:adafruit/circuitpython
* branch main -> FETCH_HEAD
Already up to date.```Is there something like git submodule update etc that you're supposed to run to get translation stuff updated?
tulip sleet
make translate at the top level, but you should not need to do that. Are you doing this on your fork?
idle owl
I have that aliased, so I don't remember the whole command.
I have my fork setup as a remote, I pushed to it from updated main before making my branch.
tulip sleet
is your fork origin?
idle owl
No, it's kattni and Adafruit's is adafruit.
tulip sleet
git fetch adafruit; git checkout kattni/main; git merge --ff-only adafruit/main
(I don't usually bother with -ff-only, but it should only be doing a fast-forward
tulip sleet
so just do a build again, it should not change circuitpython.pot
also do the gitsubupdate
idle owl
I didn't even build. I only commited.
tulip sleet
because tinyusb was just updated
idle owl
Ok, I'll do it again, but I did it earlier.
Yeah nothing happened running it.
Bunch happened earlier.
Ok it worked this time, nothing else modified.
This whole thing can be so finicky and bonkers sometimes. ๐
tulip sleet
agree with that
manic glacierBOT
idle owl
@tulip sleet Is this a valid description for the PR?
The current pin label SPEAKER_SHUTDOWN is confusing because the pin enables the speaker, it does not shut it off. So in code, when using the pin, you currently set SPEAKER_SHUTDOWN to True to enable the speaker, and this is not intuitive.
Or say it's confusing.
I like that better.
Or am I misunderstanding how it works. Is why I'm asking.
tulip sleet
it does enable/shutdown the speaker, and it's true it's inverted if its name is SHUTDOWN. It should be SHUTDOWN_INVERTED or ENABLE. But mainly it isn't consistent with the speaker control pin on other boards. If they are not consistent wrt inverted or not, we need to fix those too. I will take a look at the other boards in a bit
idle owl
Hmm, I'll hold off on this PR then.
tulip sleet
they should all have the prefix of SPEAKER_ENABLE.... That means if it's True, the speaker is enabled. If it happens to be the other way around (low to enable), then the name should ideally be SPEAKER_ENABLE_INVERTED.
idle owl
Ok, I like that.
idle owl
@tulip sleet Ok, I can take a look at the other boards tomorrow to figure out what should be what, and include it in the same PR to make everything consistent.
tulip sleet
if you want I will do that, not a big deal
idle owl
I will probably ask for verification from you that I'm on the right track though.
tulip sleet
we can both do it; i'll get you a list
idle owl
OK, sounds good. I think it's good for me to go over it since I don't want to lose schematic and core PR skills. Which I do when I have no reason to deal with either for long periods of time. ๐
@tulip sleet Here's what I got for SPEAKER_ENABLE: ports/atmel-samd/boards/circuitplayground_express/pins.c ports/atmel-samd/boards/circuitplayground_express_crickit/pins.c ports/atmel-samd/boards/circuitplayground_express_displayio/pins.c ports/atmel-samd/boards/hallowing_m4_express/pins.c ports/atmel-samd/boards/monster_m4sk/pins.c ports/atmel-samd/boards/pybadge/pins.c ports/atmel-samd/boards/pygamer/pins.c ports/atmel-samd/boards/pyportal/pins.c ports/atmel-samd/boards/pyportal_titano/pins.c ports/esp32s2/boards/adafruit_magtag_2.9_grayscale/pins.c ports/nrf/boards/circuitplayground_bluefruit/pins.c ports/nrf/boards/hiibot_bluefi/pins.c ports/raspberrypi/boards/adafruit_macropad_rp2040/pins.c
So basically we want to verify that none of them are inverted pins? Where they have to be set to False to turn on in the end?
tulip sleet
exacto
tulip sleet
๐ฝ๏ธ
idle owl
We have leftover grass fed ribeye. Huge slab of steak from a fancy restaurant. We had a really nice dinner last night.
tulip sleet
sounds delish
@slender iron great progress on the highspeed USB, but why did it used to work?? until the dynamic USB came in, not sure I understand that; there are larger buffers specified in the compilation but maybe not for events
tulip sleet
traces with working version might be interesting
slender iron
@tulip sleet I did get one working trace from before. it did have one failed enumeration before going onwards
I still haven't figured it out. It's weird that it's getting into a state where the OUT packets are naked for two seconds
tulip sleet
interesting, so it sounds like it was marginal previously; I don't know why there might be timing differences but there could be
One thing I notice on Linux is that when a board enumerates (any board), Linux USB seems to grind to a halt temporarily. I.e.g I am typing the equivalent of tio in a terminal after a reboot and the echoing is delayed. That seems very odd to me, as if the Linux driver is locking itself while enumerating
slender iron
ya, maybe. one idea I had was to ensure we always queue the background correctly
will keep looking tomorrow
time to start dinner while I watch aae
tulip sleet
good luck!
crimson ferry
@idle owl at your leisure, perhaps of interest, there are other similar power control pins:
SHUTDOWNs:
ports/atmel-samd/boards/openbook_m4/pins.c: { MP_OBJ_NEW_QSTR(MP_QSTR_MIC_SHUTDOWN), MP_ROM_PTR(&pin_PB31) },
ports/raspberrypi/boards/adafruit_macropad_rp2040/pins.c: { MP_ROM_QSTR(MP_QSTR_SPEAKER_SHUTDOWN), MP_ROM_PTR(&pin_GPIO14) },
Non-Speaker ENABLEs:
ports/atmel-samd/boards/dynossat_edu_eps/pins.c: { MP_ROM_QSTR(MP_QSTR_SAT_PWR_ENABLE), MP_ROM_PTR(&pin_PA10) },
ports/atmel-samd/boards/robohatmm1_m4/pins.c: { MP_ROM_QSTR(MP_QSTR_POWER_ENABLE), MP_ROM_PTR(&pin_PA27) },
ports/atmel-samd/boards/feather_m4_can/pins.c: { MP_ROM_QSTR(MP_QSTR_BOOST_ENABLE), MP_ROM_PTR(&pin_PB13) },
ports/mimxrt10xx/boards/imxrt1060_evk/pins.c: { MP_ROM_QSTR(MP_QSTR_LCD_ENABLE), MP_ROM_PTR(&pin_GPIO_B0_01) },
ports/nrf/boards/teknikio_bluebird/pins.c: { MP_ROM_QSTR(MP_QSTR_LIGHT_ENABLE), MP_ROM_PTR(&pin_P0_30) },
ports/nrf/boards/TG-Watch/pins.c: { MP_ROM_QSTR(MP_QSTR_HAPTIC_ENABLE), MP_ROM_PTR(&pin_P1_06) },
ports/nrf/boards/particle_boron/pins.c: { MP_ROM_QSTR(MP_QSTR_UBLOX_POWER_ENABLE), MP_ROM_PTR(&pin_P0_25) },
ports/nrf/boards/microbit_v2/pins.c: { MP_ROM_QSTR(MP_QSTR_MICROPHONE_ENABLE), MP_ROM_PTR(&pin_P0_20) },
Other aux power controls, e.g.:
ports/esp32s2/boards/unexpectedmaker_feathers2/pins.c { MP_ROM_QSTR(MP_QSTR_LDO2), MP_ROM_PTR(&pin_GPIO21) }, // Second LDO Enable control
There are numerous NEOPIXEL_POWER and other *POWER* names (polarity not necessarily correct on any of these), and other non-standard names we'll probably have to find serendipitously.
Of note is that some aux power pins control more than one peripheral.
crimson ferry
got the two new Stemma QT RTC modules and rediscovered @onyx hinge's timeless post on telling the difference https://emergent.unpythonic.net/01594912346 ๐
onyx hinge
@crimson ferry ah the best kind of help .. I can give it even while sound asleep.
idle owl
<@!330227457296957440> at your leisure, perhaps of interest, there are other sim...
Thanks, anecdata! Appreciate you looking into this. We'll keep it in mind moving forward, for now, I think the plan is to do the SPEAKER pins properly. I do agree the NEOPIXEL_POWER pins should likely also be looked at because they're relatively ubiquitous, and I'd rather have a non-confusing standard for something folks are constantly using, but we'd have to be careful with that since people would already be using it.
@tulip sleet Ok, caught up on messages and dealing with Discord admin stuff. Going to start in on the SPEAKER_ENABLE situation.
idle owl
Thanks yet again to @onyx hinge for the git ls-files command. Finding that list of pins was super quick.
idle owl
@tulip sleet so, I'm not sure what I'm looking for in the schematic to tell me whether it's inverted. Circuit Playground Express and Bluefruit are not inverted because the CircuitPlayground library sets it to False to turn it off, and True to turn it on, so they're both consistent with SPEAKER_ENABLE. I'm looking at the CPX schematic. Basically, I'm saying, other than getting out each of the boards and testing them with code, or finding an example that already uses the speaker, I'm not sure how to figure this out.
@gilded cradle Do you have a Pi4 set up somewhere not in a case? Or I guess one not setup and an extra SD card sitting around? I put mine in a case before putting the SD card in, and it feels like the card is sticking out more than it should, and I have no frame of reference to know, so I was hoping someone could get a pic from the bottom of a Pi4 with an SD card in it.
tulip sleet
The PAM8301 amp has a /SD pin, ("ShutDown"). the / prefix usually means that it's active low (ideally there would be an overbar over the SD, but the / substitute for that
you can see it's pulled up normally, due to R10, so it's normally on.
idle owl
Oh I didn't even make the connection between those two bits
tulip sleet
so if a board uses the PAM8301, then it's the same
tulip sleet
the pullup, you mean?
idle owl
Yeah
orchid basinBOT
tulip sleet
yeah, you have to match up the names. That's kind of an artifact of these CAD schematics. Connecting lines are often implied by names
idle owl
Right, I understand that, but I straight up missed it here.
Didn't think to look for a disconnected pullup
heh
tulip sleet
i was confused by that when I first started looking at them. I expected everything to be connected
gilded cradle
<@!478616919721771019> Do you have a Pi4 set up somewhere not in a case? Or I gu...
Yeah, did you want a pic of what it looks like with an SD card?
idle owl
Yeah, did you want a pic of what it looks like with an SD card?
Yes please.
I think it's probably fine, but I can't compare it to the slot because the slot is covered
onyx hinge
it does stick well past the edge of the board when inserted
gilded cradle
Yeah, that's the right amount
idle owl
Ok then maybe it's fine
onyx hinge
does it boot? or are you trying to diagnose why it doesn't start?
idle owl
Hard to see the edge of the board in this case too
No I hadn't gotten that far. It seemed more sticking out than other Pis
so I asked first
gilded cradle
People often complain about breaking the card in half cause it sticks out
onyx hinge
Oh I assumed it was because I was an oaf ๐
gilded cradle
I've ripped the socket partially off the board myself
idle owl
Wow.
gilded cradle
I ended up epoxying it back on
