#circuitpython-dev
slender iron
@onyx hinge for tomorrow when you have time: https://github.com/tannewt/circuitpython/tree/merge_1.13 I'll check in tomorrow before I pick up anything. Note running the tests is a different command because of unix build changes. make VARIANT=coverage test_full
from ports/unix
crimson ferry
sys.print_exception() has disappeared from 7.0.0-* ?
analog bridge
that is the result of 1.12 merge
jaunty juniper
yep, disappeared in 1.12 merge, probably not intentionnally
we might want to move it from sys though since it's not C Python
(and 7.0s are for breaking changes)
slender iron
`sys.print_exception()` has disappeared from 7.0.0-* ?
yup, I disabled it because it doesn't match CPython. we could add a traceback module instead with it
I think that's where it is in CPython
jaunty juniper
I believe it's not really in C Python, I guess the closest would be traceback.print_exc(), but nothing here just takes an exception, it's more convoluted
format_exc might be better, to get a string
hollow token
@jaunty juniper it is, https://docs.python.org/3/library/traceback.html#traceback.print_exception
jaunty juniper
no it's not, this takes a bunch of things and does not provide the simple API of sys.print_exception
hollow token
In function its closer to print_exc()
but as the Python doc explains, print_exc() is only really a macro to print_exception(*sys.exc_info(), limit, file, chain)
sys.print_exception() was probably there because mpy or circpy didn't have traceback
jaunty juniper
I've seen sys.print_exception used to get the stack trace without halting the code, and to log the exceptions to a file basically, both useful on a microcontroller
hollow token
having traceback is actually pretty useful overall
you can still do that with traceback
jaunty juniper
I don't want to see it disappear in favor of a module that will take more space and in particular not fit on small boards
hollow token
errrr, are you sure about that? https://github.com/python/cpython/blob/3.9/Lib/traceback.py
even in its uncompressed form in CPython, its only 23KB
even if you made utraceback as a version, you're still not going to take extra space than before
(aka, strip functions you don't care about (there is a LOT of format funcs in that lib) it isn't going to make builds bigger in memory than before)
tulip sleet
@arctic hamlet In CircuitPython 7, we're adding some things that are overflowing your CS11. I am getting things to fit by turning off longints. Also note there is now a native sdcardio implementation that can substitute for the Python-based SD card library.
It appears you have discontinued the CS11 anyway?
do you have strong requirements for longints?
@paper sedge I sent you a message yesterday via contact form about removing some things from the CircuitBrains Basic build. I may be able to remove less than I thought. Removing async/await and re may do it.
@arctic hamlet similar q for CC03
paper sedge
Hi @tulip sleet. Thanks for the update. Sorry I hadn’t replied yet. Do you happen to know what Adafruit is going to do with their SAMD21 board definitions?
tulip sleet
we are going to make them fit :). CPX is a special case, but Feather M0, Metro M0, etc. will all be similar.
Current settings I am testing:
CIRCUITPY_AUDIOMIXER ?= 0
CIRCUITPY_BINASCII ?= 0
CIRCUITPY_AUDIOMP3 ?= 0
CIRCUITPY_BLEIO_HCI = 0
CIRCUITPY_BUILTINS_POW3 ?= 0
CIRCUITPY_COMPUTED_GOTO_SAVE_SPACE ?= 1
CIRCUITPY_COUNTIO ?= 0
# Not enough RAM for framebuffers
CIRCUITPY_FRAMEBUFFERIO ?= 0
CIRCUITPY_FREQUENCYIO ?= 0
CIRCUITPY_I2CPERIPHERAL ?= 0
CIRCUITPY_JSON ?= 0
CIRCUITPY_MSGPACK ?= 0
CIRCUITPY_RE ?= 0
CIRCUITPY_SDCARDIO ?= 0
CIRCUITPY_SYNTHIO ?= 0
CIRCUITPY_TOUCHIO_USE_NATIVE ?= 1
CIRCUITPY_ULAB = 0
MICROPY_PY_ASYNC_AWAIT = 0
for boards with external flash. displayio will be ON, but probably not vectorio (addition to displayio)
countio could go either way
the main addition for CircuitPython 7 in terms of space taken is dynamic USB descriptors so you can turn devices on and off and supply your own HID report descriptors (custom gamepads, etc.)
paper sedge
Thanks. I am pretty sure I am on my last run of these boards. They aren’t selling well anymore, likely due to market shifts like the RPI2040. I am good with whatever is decided for the Adafruit M0 line.
tulip sleet
got it; we can always tweak the definitions for you later; the RP2040 is a big (and ultimately good) disruption. We always felt the SAMD21 boards were a stepping stone due to limited RAM and flash, but are not planning to drop them or anything like that.
paper sedge
Totally agree of the 2040 being a good direction. My board is a bit of a different case because it’s more of an intermediate board that you typically would design a mounting PCB around. It’s a tough sell at the price point required for small volume production. The only thing constant in life is change. 😀
tulip sleet
if you can get RP2040's and build a tiny castellated board, it sounds like it would go over well
good luck with your product line!
paper sedge
Thank you!
idle owl
@tulip sleet Are you around for a question about the HID thread?
tulip sleet
yup
idle owl
Limor said "make a note on the Pico HID guides and the HID template", but I'm unclear on what I'm supposed to be making a note of? That multi-media keys are sent using ConsumerControl? Or.. am I missing something.
tulip sleet
I think, to make the point that certain keys on a regular keyboard are not necessarily sending regular keycode values, but might be sending consumer control values on a separate consumer control device.
In CircuitPython, this means sending Keycodes values via a Keyboard, and sending ConsumerControlCode values via a ConsumerControl.
So if you have a stock HID keyboard example, maybe it should also include ConsumerControl, instead of just Keybaord, to make people aware they may need to do both. E.g. include sending an "A", and also "mute", or something like that.
idle owl
Hmm ok.
tulip sleet
maybe an augmented example is not necessary, but just add some text that some keys on a keyboard that a person might want to emulate are not actually regular keyboard keys, but consumer control keys. The person in that issue was not aware of that. Or maybe just have a section about "Consumer Control", and how it's used for "multimedia keys", and they don't require focus. It's hard to explain, I agree. People think that the keys on their keyboard are just keys that send codes like any other key, but in fact something quite different is going on.
idle owl
I'm adding a paragraph or two to the only Pico HID guide I can find now.
tulip sleet
it's not Pico only at all, it's any use of HID.
it's just that everyone and their sibling is using Pico to build keyboards 🙂
idle owl
Right, which is why I was a little confused at the specificity of the request. But yeah.
I'll include the note in my HID template when I do it.
tulip sleet
sounds good
onyx hinge
@slender iron making good progress on test failures, will push something soon.
past the first set of tests, but there are more failures with "--emit native"
async and native don't mix
idle owl
@tulip sleet ```USB Keyboards versus CircuitPython HID Keyboards
Certain keys you might want to emulate from your standard existing keyboard, such as multi-media (volume, play/pause, etc.) keys, are not actually regular keyboard keys. They are consumer control keys. All keys on a standard USB keyboard are not necessarily sending regular keycode values, but instead may be sending consumer control values on a separate consumer control device. In CircuitPython this is the difference between sending Keycode values via a Keyboard, and sending ConsumerControlCode values via a ConsumerControl. Therefore, if, in CircuitPython, you intend to send, for example, a "mute" command in your HID example, you should use ConsumerControl instead of an equivalent keyboard key based on your standard existing keyboard.
Consumer control keys, such as multi-media keys, do not require "focus" to function. For example, sending a VOLUME_DECREMENT consumer control command will decrease the volume regardless of what application is currently focused.```
Eh?
Some of that is code formatted in Learn.
oops last part has grammar issues.
tulip sleet
Quite clear, I think/hope. Last sentence maybe "regardless of which window currently has keyboard focus"
tulip sleet
all this talk about "focus": I am not sure many people know the technical terms, but they just know "I have to click here before I type", but I'm not sure we can educate them on that right now
blissful pollen
The writeup makes sense to me and until 60 seconds ago I did not know anything about consumer control keys and how they work in USB
idle owl
Heh, thanks Mark.
idle owl
all this talk about "focus": I am not sure many people know the technical terms,...
Hopefully that's enough for now.
tulip sleet
i was completely surprised by it too, when I was looking at the HID descriptors for a regular keyboard: "hey, what's all this extra stuff??"
There's "sys control" too, which is for power keys, etc., but no one seems interested in those
i think we could use a whole USB guide when dynamic descriptors go in, with more or several pages on HID devices
slender iron
I don't want to see it disappear in favor of a module that will take more space ...
It should have never appeared. Our policy is to not have any non-CPython functions on CPython modules
jaunty juniper
It should have never appeared. Our policy is to not have any non-CPython functio...
yes, but the traceback module is a more complicated way to do it, so I prefer it to be moved to a non C Python module rather than removed
slender iron
that's fine with me
jaunty juniper
I just fear another situation where "you can't do it on M0"
slender iron
but if it's not much more difficult I'd rather match CPython
jaunty juniper
and maybe it's not, I might not just understand the traceback module
analog bridge
I did a build implementing traceback.print_exception and its 80 bytes for S2
@slender iron want to see a PR?
slender iron
sure! thank you
idle owl
So, even though the button on a QT Py RP2040 is controllable in code with CircuitPython, I can't use it in boot.py to trigger storage.remount() because if I'm holding down the boot button on reset, it will go into the bootloader. Right? Sanity check on that please?
I can use the button on a CPX though, I think.
tulip sleet
So, even though the button on a QT Py RP2040 is controllable in code with Circui...
right, you make a delay, and then check the button, but you'd have to explain that
idle owl
right, you make a delay, and then check the button, but you'd have to explain th...
So tying a pin to ground would be a better option.
idle owl
more straightfoward
Thanks. That's what I'm going for.
jaunty juniper
will the QT PY 2040 be updated to light up the neopixel yellow for safe mode ?
slender iron
all of the LED flashing will be changing soon hopefully
it should apply to the RP2040 though
jaunty juniper
I don't think you intend to change wait_for_safe_mode_reset() as part of that ?
slender iron
nope. I think the startup LED colors will be the same
onyx hinge
@slender iron I think I have a good lead on the native+async problems
slender iron
nice!
slender iron
@crimson ferry want to do anything else on your AP PR?
crimson ferry
@slender iron There's always more scope, but I think it's at a good place with core features.
idle owl
How can I determine how much space is left for files on CIRCUITPY using command line? Using Finder is returning the same number no matter what, I don't think it's right.
tulip sleet
I don't think there's a way. did you empty the trash?
idle owl
Two different boards gave the same number.
Disk Utility is giving me a more accurate picture.
So now my original question: is 40KB very much space for a temperature logging file in CircuitPython, or would that fill up really fast?
tulip sleet
how much are you writing for each log entry?
and how often?
do you need to write a timestamp?
idle owl
This code doesn't timestamp it. Only records the temp, on one line, every second.
I'm looking at NeoTrinkey as the smallest example here. Basically I'm trying to decide whether it is possible to use the NeoPixel for the blink codes on boards without a little red LED, or if that would take up too much space.
tulip sleet
so 5-10 bytes per second. 300-600 bytes per minute 18k-36k bytes per hour
I wouldn't log every second
idle owl
Ok, so drop logging time.
So basically every second I add to logging time, adds an hour to how long it would last?
ish
wait no
I'm mathing wrong.
tulip sleet
if you sampled every 10 seconds, then 1.8-3.6kb per hour
idle owl
Ok so no I did the maths right.
Alrighty. So 10 seconds gets over 10 hours. I suppose that'll work.
Better than wiring up an external LED to make a data logger.
Which is what I'm trying to avoid here.
tulip sleet
depends on how many digits of accuracy you want. If just 3 digits, then more like 5 bytes per entry
tulip sleet
writing every second may wear out the flash also, so 10-30 seconds is a better example
idle owl
Duly noted.
So glad I wrote this code ever so long ago: while True: cpx.pixels[0] = (abs(cpx.pixels[0][0] - 255), 0, 0) time.sleep(0.5) It's the NeoPixel equivalent of led.value = not led.value.
If I remember correctly anyway.
onyx hinge
@slender iron okay, that PR's updated so that all the tests pass. the workflow doesn't run on github because I'm a first-time contributor to your repo...
manic glacierBOT
slender iron
<@!252717193496756235> okay, that PR's updated so that all the tests pass. the ...
thanks!
idle owl
Realising blinking an LED every 10 seconds in that fashion isn't really all that useful. On for 10 seconds, off for 10 seconds... hmph.
tulip sleet
blink for one second every ten seconds?
idle owl
Yeah that would be idea.
I am currently trying to wrap my brain around the logic necessary to do that.
I'm sure it's simple, but I'm missing something.
Need to write the file every 10 seconds, and blink the LED for 1 second, every 10. Need monotonic() maybe?
That's the only way I know how to do it is to use monotonic().
jaunty juniper
you can blink 1 second and sleep(9) but you'll drift due to overhead, not that monotonic won't anyway
idle owl
Be back in a few, prepping lunch.
onyx hinge
I didn't even know we built latex/pdf documentation -- that's where the actions in my repo failed.
/home/runner/work/circuitpython/circuitpython/CONTRIBUTING.md:8: WARNING: None:any reference target not found: CODE_OF_CONDUCT
idle owl
you can blink 1 second and sleep(9) but you'll drift due to overhead, not that m...
Drift is fine, this isn't meant to be precise. But I'm not following how that would work. Trying something like what you're suggesting and it's not doing what I need it to.
jaunty juniper
ah sorry, I might have misunderstood what you wanted to do
idle owl
No worries, I sort of thought it might work as well.
I'm trying to do two things in a loop. One thing every 10 seconds, and the other thing for 1 second, every 10 seconds.
jaunty juniper
not synchronous with each other ?
idle owl
So, let's say, print to the serial console once every 10 seconds, and blink the LED for 1 second every time I print.
Synchronous.
Not perfectly because print doesn't take 1 second, but you get the idea.
orchid basinBOT
tulip sleet
@idle owl, turn LED on, sleep 1 sec, turn LED off, sleep for 9 seconds, read and log temp, loop around
idle owl
Oh. I need to separate out the LED code. Ok. That makes more sense.
idle owl
<@330227457296957440>, turn LED on, sleep 1 sec, turn LED off, sleep for 9 secon...
I knew it was something simple I was missing. 🤦♀️ Thank you.
tulip sleet
np 🙂
idle owl
Easier to explain than my fancy neopixel = not neopixel code anyway.
orchid basinBOT
tulip sleet
maybe blink 1 sec, read/log temp, sleep 9 seconds, so the logging is close to the blinking
idle owl
I wrote a simple print/blink thing and it seems to be pretty close. But yeah I'll reorder it.
pixel.fill((255, 0, 0))
time.sleep(1)
pixel.fill((0, 0, 0))
time.sleep(9)
print("Test")```Puts them kind of together because end and beginning of loop...This is better. while True: pixel.fill((255, 0, 0)) print("Test") time.sleep(1) pixel.fill((0, 0, 0)) time.sleep(9)
except might be a problem if the write takes longer then 1 second.
Can put write first.
idle owl
Did this ever work? It gives the pin a Pull.UP but we say to connect it to ground.... Is that right? Because giving A0 on QT Py RP2040 a pull up, and connecting A0 to GND returns False and connecting it to 3.3V returns True.
Wait.
I think I just confused myself with the readonly thing 😆
OK, I confused myself because it wasn't really tied to ground, the wire apparently wasn't quite connecting. So I thought everything was backwards.
False alarm.
Oooh I almost wasted a ton of time troubleshooting that buggy pin definition on the Itsy RP2040 that I fixed. Apparently had only updated one of my two Itsy's. Oi.
Also destroyed my USB on that board reset. Had to unplug my hub from the wall and plug it back in to bring my keyboard back up.
jaunty juniper
sometimes with a rp2040 board on my Mac, after going to bootloader I have to switch USB port or the CIRCUITPY drive doesn't come up. It's very elusive and I have like 2 powered USB hubs in cascade, so who knows what's up with that...
crimson ferry
I have a dumb question... in the context of the dynamic USB descriptors, is CDC Data in CircuitPython the serial output, and that's distinct somehow from the REPL in USB?
tulip sleet
I have a dumb question... in the context of the dynamic USB descriptors, is CDC ...
there will be cdc data and cdc console; the latter is the REPL and the normal destination for print(), etc. aka sys.stdin and sys.stdout. However, if you access it through usb_hid.console, it is a binary stream ,as opposed to through print() or input(), where it's a text stream
tulip sleet
sometimes with a rp2040 board on my Mac, after going to bootloader I have to swi...
i have also seen that sometimes i have to power cycle or just reset to get the drive back. Which OS is this on?
jaunty juniper
it's Catalina
crimson ferry
that's all cdc console, right? is cdc data something in use in CircuitPython currently?
tulip sleet
cdc data was availaable in 6.2.0-beta.2 or 3 but then turned off afterwards because it confused Mu
it's coming back in 7.0.0 but will be turned off by default. Also now Mu knows how to identify a particular CDC as console/repl
crimson ferry
I had the impression (perhaps mistaken) that was a secondary console that was turned on then off, is data characteristically different than console?
idle owl
I'm having issues with more than one board on Catalina. Absolutely cannot get two to show up at the same time. I have to get to the files via command line.
In Finder, I mean.
If I want to use Finder to copy files, I have to unplug one board, and then reset the other board to get it to show up.
They both mount fine, and are accessible via command line.
tulip sleet
I had the impression (perhaps mistaken) that was a secondary console that was tu...
not sure what you mean by "characteristically". It's a completey separate channel, so on Windows, COM5 might be the console/repl, COM6 might be data. Nothing is sent to data except by you, so there's no interfering data like console messages or repl prompts, etc.
crimson ferry
sorry I'm being obtuse about this... so console is really a subset of data that we use in special ways?
@idle owl do you use column view? sometimes I won't see a volume in the left naviugation pane, but it will show up if I navigate the columns to find it
tulip sleet
they are both USB serial (CDC) devices. until 6.2.0-beta.3 or whatever there was only one, which was used for the REPL
idle owl
<@!330227457296957440> do you use column view? sometimes I won't see a volume in...
I do not. I'll try that next time.
tulip sleet
now we have an optional second one, which is in addition to the REPL
i'm not sure what you mean by subset
until usb_cdc existed, there was just text stream access to the REPL connection via input(), print() or sys.stdin and sys.stdout
jaunty juniper
oh, I make the removable drives show up on the desktop, I forgot that's an option
tulip sleet
now you can also access the same stream (as a binary stream, not text) using usb_hid.console.
idle owl
oh, I make the removable drives show up on the desktop, I forgot that's an optio...
Ugh, I don't. I get annoyed by that.
tulip sleet
if you enable usb_hid.data, then you have a separate bidirectional stream that you can use however you want, that shows up as a separate COMxx or /dev/tty...
ionic elk
Is there any case where we actually use exit_code != 0 to exit the for loop in main and hit mp_deinit? Or is that just legacy handling?
tulip sleet
I think you can do sys.exit(1), etc
ionic elk
is there a point to doing so, though?
crimson ferry
thanks for the deep dive, Dan!
tulip sleet
i'll probably write a guide 🙂
ionic elk
mp_deinit doesn't appear to do a lot, just MP_THREAD_GIL_EXIT, which is just some kinda mutex thing?
tulip sleet
is there a point to doing so, though?
maybe not, but in the future, there might be, to indicate some error condition
jaunty juniper
@tulip sleet you can read console as binary, but receiving 0x03 will still ctrl-C the program right ?
tulip sleet
i mean, in regular python sys.exit() returns an integer to the shell. We don't have a shell to take that, but you could imagine somehow passing that error code back
ionic elk
it'll hit the end of main, right? Is that even defined the same for ARM vs XTENSA etc?
tulip sleet
<@329766224093249548> you can read `console` as binary, but receiving 0x03 will ...
right, because the repl stream is still reading it. It's just another connection to the same stream
tulip sleet
it'll hit the end of main, right? Is that even defined the same for ARM vs XTENS...
i don't think we would necessarily cause main() to exit, it could be handled by supervisor, which kind of takes the place of the shell
but right now, no, it's not interesting, but I wouldn't take it out; it's latent support for doing something.
ionic elk
Ok, good to know. Thanks!
was just curious whether something sneaky was happening there.
I do kind of wonder what happens with the return 0; from main though, I'd have to look at the C runtime
It could be defined differently between ports.
tulip sleet
It could be defined differently between ports.
yeah, just looking, main() gets called from the reset handler in mimxrt, but I don't see other ports calling main(). However, there is something that calls main in the guts of the arm-none-eabi runtime
ionic elk
or the xtensa one, in the ESP case, which might be different.
I could put in a comment saying the behavior is undefined, maybe?
onyx hinge
@slender iron can you help me with github privs? I don't have access to the settings tab of https://github.com/circuitpython/CircuitPython_Library_Screenshot_Maker
slender iron
@onyx hinge added you as a maintainer
onyx hinge
<@!426200547024961539> added you as a maintainer
thanks!
idle owl
@lone axle Have you started on the CircuitPython Essentials storage page update yet?
idle owl
@lone axle I'm asking because I started working on the Template, and you may want to check it out because I'm trying to include the bits that I wanted included in the current one. And if you started on it, I wanted to look at what you have. If you haven't, you can check out what I have as I work on it.
lone axle
<@!382939733107408897> Have you started on the CircuitPython Essentials storage ...
Not yet, it's on my docket for tonight though.
idle owl
@lone axle Alright, remind me to send you a link to the template before you start working on it tonight then. We'll see how far I get. Templates are a little weird to look at, but you'll get the idea.
lone axle
Will do.
onyx hinge
@slender iron thanks, I was able to make sure actions was enabled in that repo (I think it was all along but if a PR has workflows but the main branch doesn't, github doesn't bother running them in the PR)
idle owl
Are microcontroller.cpu.temperature values affected by ambient temp? As in, could you track changes in ambient temperature by running a basic board-only temperature logger for a period of time, or do the temperatures of the MCUs stay pretty consistent regardless of ambient temperatures? I've never run one long enough to have any idea.
Trying to figure out whether it's worth telling folks "You can plug this in anywhere you have USB power and track the temperature" or whether there's no point because tracking CPU temp in random places isn't useful.
blissful pollen
Are `microcontroller.cpu.temperature` values affected by ambient temp? As in, co...
The CPU temp can change based on ambient temperature but it will still register higher (usually) then ambient and CPU workload can also affect it. If the CPU workload is pretty even and has reached a consistent temp, then the ambient temperature may be detected by changes, but it would be a relative measure. Hope this makes some sense
idle owl
The CPU temp can change based on ambient temperature but it will still register ...
That makes exact sense. That's exactly what I was thinking, but wanted a sanity check.
Basically it's running the data logger code, and that's it. So if you set it and forget it until it fills up, it should be stable.
Thanks, Mark!
blissful pollen
Welcome!
idle owl
@blissful pollen The temperature is not the ambient temperature; it is the temperature inside the microcontroller, which will typically be higher than ambient temperature. However, running only this code, once the microcontroller temperature stabilises, it should at least be consistent, and therefore usable for tracking changes in ambient temperature. Changes is in italics.
Clear enough?
blissful pollen
reads clear to me
idle owl
Great, thank you.
slender iron
@onyx hinge I'm gonna merge in your fixes and keep going with it
I'm not going to amend that starting commit anymore
onyx hinge
@slender iron thanks, let me know if/when you have more for me to look at.
slender iron
👍
idle owl
What is it called in Python when you get an error? Is CircuitPython "returning" the error? "Receiving" the error sounds wrong, but returning seems dubious as well.
"throwing" seems familiar?
But also seems more casual.
mental nexus
I think the Python term is “raise”
idle owl
Yes!
idle owl
I think the Python term is “raise”
That is it. Thank you.
jaunty juniper
throwing is used in other programming languages, python raises an exception
Swift throws an error
manic glacierBOT
idle owl
Woah. I just erased my CIRCUITPY filesystem, and now it's NO_NAME. By hitting reset, and then hitting reset again in an attempt to get into safe mode.
I can still get to the serial console.
Hey I was able to reproduce it
idle owl
I think it's if I hit reset when the status LED is blue. Because it took a few tries this time.
I do not have a boot.py on this.
It's currently called storage_boot.py. and doesn't have valid pin names in it.
tulip sleet
that is before boot.py runs, but maybe you caught the USB just trying to set up the MSC device
idle owl
Hmm.
Related question: how do I get into safe mode or is that not a thing you can manually trigger anymore?
tulip sleet
do you see it yellow for 700ms? It's during that time you can do it
idle owl
No, I don't see it yellow, that's when I thought I was suppose to do it.
tulip sleet
me too...
tulip sleet
there could be something different about the startup on RP2040
but I don't know off the bat. That may be a Scott q
idle owl
Being able to destroy your filesystem by hitting reset in the wrong rhythm seems worth dealing with.
storage.erase_filesystem() gets me CIRCUITPY back.
tulip sleet
i keep trying to think of a better way to indicate getting into safe mode, but we need yet another button, or maybe support for triple-click in the bootloader
idle owl
Can't seem to do it again with no code running. Let me add a code.py with something more substantial than hello world in it.
Still not doing it. Was it somehow trying to run the code in storage_boot.py? Trying with that.
idle owl
It's not a valid file, there's no pin names in it or whatever, it's a template file.
but it turns blue, I hit reset, and it blasts the board.
manic glacierBOT
jaunty juniper
ah I though I understood a thing but I misread >_>
idle owl
idle owl
@jaunty juniper Oh thanks.
jaunty juniper
does it have a 700ms delay on boot ?
idle owl
I have no way to measure that 😄
jaunty juniper
true
the difference might be visible if you light the neopixel in code.py, compared to the pico (which doesn't have the delay due to no status LED)
tulip sleet
it shouldn't do that, but if you reset before boot.py was completely written, that might happen (though it's very rare on the Mac)
tulip sleet
In Linux, you can run the sync command, which forces stuiff out. It might exist on MacOS too
jaunty juniper
any other file disappear ?
idle owl
I mean, it persists through a normal reset. But If I click reset again when the LED is blue, deletes boot.py.
idle owl
It also resets code.py to it's initial state.
I added a test print into code.py, and it's gone.
So basically, add some code and a boot.py file, click reset, NeoPixel turns blue, click reset again, CIRCUITPY is back to it's initial state.
ionic elk
Anybody have a PyPortal who could give the run_reason PR a shot? We're having trouble pinning down a weird overwrite of the "STARTUP" with "AUTORELOAD" reason on that board.
crimson ferry
are the artifacts unavailable while it's re-building?
lone axle
@idle owl I will be getting going on the storage clarifications shortly if you want to send me that page to take a look at.
idle owl
I'll DM you the link.
idle owl
<@!330227457296957440> I will be getting going on the storage clarifications sho...
I think the only other point not covered on that page is explicitly explaining the CPX switch. Because that page is written for using a pin, and there will be a separate one for using the switch.
lone axle
okie doke, TIL...
idle owl
@lone axle Explains why I couldn't get to it on this board. Basically you'd be stuck listing all the boards it works for, etc. So, forget it. Means you could be able to get pretty much everything you need from the template.
Makes it easier!
idle owl
@tulip sleet I am reproducing this weird deleting boot.py issue. Should I file an issue at this point? Is this a bug or is it me?
tulip sleet
sure, document the recipe to get it; it may ultimately be something else but it's good to write it down; i don't think it's necessarily you
lone axle
I will get it worked into the hidden page and note which direction the switch is for each setting.
idle owl
I will get it worked into the hidden page and note which direction the switch is...
Perfect. Thank you.
ionic elk
@slender iron do you want to review the run reason thing or should I go ahead and merge? Green light from Anecdata
slender iron
no need to wait for me
ionic elk
k
frozen flume
Does Circuitpython supports 32MB of flash? I know there is a 16MB csv file with the partition, but I'm wondering if I can modify that to support 32MB?
ionic elk
Also, is the "squash and merge" feature on Github new? That seems handy
We don't have it turned on though
slender iron
Does Circuitpython supports 32MB of flash? I know there is a 16MB csv file with ...
on what board? usually the port has a limit
frozen flume
on what board? usually the port has a limit
Is for my new board the ATMegaZero. We are shipping it with 32MB flash with the ESP32-S2, but I know that their firmware is limiting it to 16MB
slender iron
Also, is the "squash and merge" feature on Github new? That seems handy
We don't squash because that rewrites history and makes it hard if folks reuse their local branch
ionic elk
Hmm, gotcha
tulip sleet
Is for my new board the ATMegaZero. We are shipping it with 32MB flash with the ...
the only q is whether CIRCUITPY rolls over smoothly to FAT16 from FAT12 when you get to 16MB (actually it depends on sector size and # of sectors, but it's usually 16MB). The underlying code is supposed to handle FAT16, but I'm not sure it's been exercised.
(welll, maybe that's not the only q, but it's the q i have)
if it doesn't work we will want to fix it
frozen flume
Is there a way I can test that out to see if it would handle it?
tulip sleet
you could just specify the new flash chip and then try a build. I think the CIRCUITPY size is just what's left over after everything else, though I'm not sure. I didn't do that part.
worst case is at first the size will need to be limited until any issue about it gets fixed
@slender iron can you think of any other gotchas?
frozen flume
Right now I'm running the board fine with 16MB out of the 32MB
but, i'm not taking full advantage of the extra space
tulip sleet
so are you pretending the chip is the 16MB part number, or did you just set a limit somewhere?
onyx hinge
@slender iron those test failures are weird. Python 3.8 prints these SyntaxWarnings, CP/MP never have. Python 3.7 and below didn't. So I get a pass locally since I have 3.7. But we aren't NEWLY using 3.8 for CI. If you look at a build of main in the CI, you can see that the SyntaxWarnings are shown as part of the output, not "what is being compared"... weird.
frozen flume
so are you pretending the chip is the 16MB part number, or did you just set a li...
The board has this memory chip in it. https://www.mouser.com/ProductDetail/Winbond/W25Q256JVEIQ-TR?qs=qSfuJ%252Bfl%2Fd4d16629NnShw%3D%3D. When I created the board definition I used the 16MB partition because I couldn't find any 32MB example.
slender iron
<@252717193496756235> can you think of any other gotchas?
ya definitely. it does matter how big the memory mapped space can be
slender iron
<@!252717193496756235> those test failures are weird. Python 3.8 prints these S...
ok, I think I'm on 3.9 locally but I know what to ignore
frozen flume
This is the board I'm referring to BTW: https://cdn.shopify.com/s/files/1/0489/4720/0154/files/F4A1C54A-64C3-4A28-9D8E-7C9D2EA92C1B.jpg?v=1619533357
I would love to take advantage of the 32MB since I'm planning to ship it with CircuitPython
slender iron
(I can reply better after show and tell)
looks like it depends on the idf
only 10.5MB are supported through the memory mapped cache
but the datasheet says up to 1GB is supported
frozen flume
right
which is why we went with 32MB since that was the biggest chip we could fit in this board
slender iron
this is where CP calls into the IDF: https://github.com/adafruit/circuitpython/blob/main/ports/esp32s2/supervisor/internal_flash.c
frozen flume
I also just noticed that CircuitPython doesn't have the partition I was referring to. I got confused with the arduino approach.
How can I verify if it's reading the memory size correctly? Sorry I'm not super savvy with this yet. 🙂
slender iron
the drive should be 28MB when working I think. 3MB are used for CP
you'll want to change CIRCUITPY_ESP_FLASH_SIZE=16MB and add a 32MB partitions.csv file into esp-idf-config
frozen flume
you'll want to change CIRCUITPY_ESP_FLASH_SIZE=16MB and add a 32MB partitions.cs...
Which values can I change here for the 32MB? this is copy from the 16MB partition csv file.
slender iron
the userfs size
frozen flume
Thanks, let me try that
slender iron
<@!252717193496756235> those test failures are weird. Python 3.8 prints these S...
I did change the stderr capture I think
onyx hinge
@slender iron it could be that, maybe I just didn't see it in the diff
we could also add to the python3 commandline the flag to turn off all warnings if we knew what it was
-Wignore
frozen flume
the userfs size
I was running the make script and got this error after updating to 32MB. esptool elf2image: error: argument --flash_size/-fs: 32MB is not a known flash size. Known sizes: 512KB, 256KB, 1MB, 2MB, 4MB, 2MB-c1, 4MB-c1, 8MB, 16MB
slender iron
that looks like an idf issue, not a CP one
onyx hinge
it appears it may have been added in esptool, but it requires a newer one than is in the esp-idf version we use -- https://github.com/espressif/esptool/commit/bb9a93b9d7170aa1ad015df881f2c881a81dada1 (march 25)
huh either feb 16 or mar 25 🙂
onyx hinge
https://github.com/adafruit/circuitpython/pull/4195 seems to be the latest place we've discussed updating esp-idf. It might be worth revisiting for main branch / 7.0 because the trade-offs are different than when we were trying to stabilize 6.2.0 for release.
frozen flume
I'm trying to use that branch from that PR for testing the new idf but I keep getting some errors when running the make script. fatal error: soc/gpio_periph.h: No such file or directory
#include "soc/gpio_periph.h"
^~~~~~~~~~~~~~~~~~~
wait, I forgot to run git submodule update.
Testing again, hopefully it works
@slender iron Ok, I'm almost there. Just got this new partition error. esp32s2/esp-idf-config/partitions-32MB.csv' occupy 4.3MB of flash (4549568 bytes) which does not fit in configured flash size 2MB. Change the flash size in menuconfig under the 'Serial Flasher Config' menu.
I gave the value of user_fs, data, fat, 0x450000, 27584, for 32MB
I semi guess that number of google conversion of MB to KB
slender iron
take a look at the other files in the board directory
theres is probably something else there
frozen flume
I haven't seen any 32MB version yet
lone axle
@idle owl for whenever you dive in today: I have the unpublished page here https://learn.adafruit.com/admin/guides/1954/editor/22213 with the new wording from your template plus a note explaining which way the switch on the CPX / CPB belongs for each setting.
jaunty juniper
oh the mpy-cross page has the same multiple pages issue as the adabot stats, with the windows versions being pushed to the bottom https://adafruit-circuit-python.s3.amazonaws.com/index.html?prefix=bin/mpy-cross/
supple goblet
I'm cross-asking this here (already asked in the UnexpectedMaker Discord): I'm running the same code on a Feather S2 and Feather M4 Express but the M4 is a lot faster (RGB matrix, running at 7 FPS with the S2 vs 12 FPS with the M3). On paper, this shouldn't be the case and the S2 should outperform the M4 by being almost twice as fast.
Same results on Circuitpython 6.2 release and 7.0.0-alpha1.
mental nexus
On the S2 the RAM and flash are off board so are slower to access. Maybe that counteracts the processor speed.
supple goblet
Hmm that does makes sense. My application is very memory heavy and I'm doing a lot of matrix calculations. Unfortunately I have nothing as optimized as numpy 😄
still zephyr
Hmm that does makes sense. My application is very memory heavy and I'm doing a l...
is this MP or CircuitPython?
supple goblet
is this MP or CircuitPython?
Circuitpython 6.2 release and 7.0.0-alpha1.
There is no pre-built MP binary available yet as far as i know
serene briar
I'm cross-asking this here (already asked in the UnexpectedMaker Discord): I'm r...
The speed in MHz is not everything when comparing the speed of chips
still zephyr
Sorry I was talking about the bumpy party you could use Ulab
serene briar
The cpu architecture can impact cpu performance as well
supple goblet
The speed in MHz is not everything when comparing the speed of chips
Absolutely. But with double MHz speed I would have expected... well at least comparable code speed.
supple goblet
Sorry I was talking about the bumpy party you could use Ulab
how did i not know about that! That might help!
Thanks!
still zephyr
No problem 🙂
still zephyr
how did i not know about that! That might help!
It will for sure
serene briar
Absolutely. But with double MHz speed I would have expected... well at least com...
My guess is both the memory access and differences in cpu architecture will be impacting. That being said I don’t have that much knowledge on the lx7 core the esp32s2 uses.
supple goblet
Already gained ~20% speed replacing pow() with **...
serene briar
Definitely give ulab a try, it’s not as good as fully cpython numpy but offers much better performance than plain circuitpython.
onyx hinge
oh the mpy-cross page has the same multiple pages issue as the adabot stats, wit...
@tulip sleet can you help out with this?
supple goblet
On the M4 i was RAM constrained so i had to split up image sprites into single bitmaps. Might try to revert to sprites and use the additional RAM, vs. having to read a BMP file for every frame.
tulip sleet
<@!329766224093249548> can you help out with this?
sure, thanks, I will just clean most of the versions. @jaunty juniper
jaunty juniper
@tulip sleet now that micropython 1.12 and #4713 are merged in, I believe the mpy format is stable for the time being ? Could then an alpha 2 release be made to upgrade the 7.x bundle to the latest mpy format going forward ?
tulip sleet
Let's double-check with @slender iron about the mpy format, but yes, I can make a release. The dynamic USB PR is close to done, so when that's in, I can make a release in the next few days.
solar whale
@onyx hinge just tried the new mpy-cross on a pirkey_m0 (converted adafruit_dotstar and adafruit_pypixelbuf) worked fine!
manic glacierBOT
idle owl
<@!330227457296957440> for whenever you dive in today: I have the unpublished pa...
Cheers, looking now.
onyx hinge
@slender iron I tossed in a PR to fix what I think were the last two failing builds.
for some reason it's still requiring approval to run in your repo... huh.
idle owl
@lone axle Ok I made a couple of tiny changes, but overall it's good to go. Feel free to integrate it whenever you get a chance. Love the page name 😄
lone axle
😄 I'll work on moving it over tonight. Thank you.
idle owl
@tulip sleet The ability to turn off the REPL and CIRCUITPY is already in main?
Want to know if I should include a warning in this section about using the REPL to recover a read-only fileysystem about how if you turned off the REPL, it won't work.
onyx hinge
@idle owl not yet
simple pulsar
Absolutely. But with double MHz speed I would have expected... well at least com...
I did some basic benchmarking a while ago when I saw some odd-looking performance numbers in HackSpace. Your code sounds more like a real world application. In https://forums.adafruit.com/viewtopic.php?f=60&t=170425if you're interested
idle owl
<@!330227457296957440> not yet
Thanks.
still zephyr
@slender iron it is possible to create a group of reviewers for the circuitpython.org? similar to the librarians in the libraries? thanks
idle owl
Hmm. Is there a way to differentiate between ValueErrors if they don't have an Errno? I'm trying to write a script that tells me what pins have touch capabilities, and ValueError is returned on invalid pins, and also on valid pins without a pulldown.
The PWM/SPI/UART/I2C scripts simply use ValueError to determine invalid pins. But that isn't working here.
Or is there some other way to know what pins work with touchio.
slender iron
Let's double-check with <@252717193496756235> about the mpy format, but yes, I c...
I want to take a peek at 1.14 first. I think it might be pretty quick to do
slender iron
<@!252717193496756235> it is possible to create a group of reviewers for the cir...
Ya, I think we could have a librarians team there too. (or just use the graphics team)
@tulip sleet for the mijia sensor did you find someone who determined how to change the display from C to F?
without the app
haha, got it
I'm such a "hacker"
sent 1 to the the Temperature uint characteristic
idle owl
🎉
Touch (no pulldown) on: D7
Touch (no pulldown) on: D9
No touch on: LED
Touch (no pulldown) on: MISO
Touch (no pulldown) on: MOSI
Touch (no pulldown) on: NEOPIXEL
No touch on: NEOPIXEL_POWER
No touch on: RX
Touch (no pulldown) on: SCK
Touch (no pulldown) on: SCL
Touch (no pulldown) on: SDA
No touch on: TX```Script works. It's aware of the pulldown or not situation. code.py output: Touch on: A0 Touch on: A1 Touch (no pulldown) on: A2 Touch (no pulldown) on: A3 Touch (no pulldown) on: D0 Touch (no pulldown) on: D1 Touch (no pulldown) on: D10 Touch (no pulldown) on: D11 Touch (no pulldown) on: D12 Touch (no pulldown) on: D13 Touch (no pulldown) on: D24 Touch (no pulldown) on: D25 Touch (no pulldown) on: D4 Touch (no pulldown) on: D5 Touch (no pulldown) on: D6 Touch (no pulldown) on: D9 No touch on: LED
tulip sleet
<@!329766224093249548> for the mijia sensor did you find someone who determined ...
wanna pr? 🙂
tulip sleet
<@!329766224093249548> The ability to turn off the REPL and CIRCUITPY is already...
Scott just has to do a final review on the PR.
idle owl
Scott just has to do a final review on the PR.
I'll add the warning, then. Might be a little confusing for a bit, but better to have it.
tulip sleet
on reflection, do you think if we just make one "SOS" build per board, it should be an eraser, or simply drop you into safe mode, where you can erase/reformat via the REPL or rename boot.py via CIRCUITPY
idle owl
I thought safe mode didn't work on everything.
Or is it the rest to safe mode that doesn't.
tulip sleet
i think it's reset to safe mode. I will just make sure I can make an "immediate safe mode" RP2040 build
tulip sleet
i know what you mean; I had to clean my desk over the weekend. It had about three layers of projects and other cruft
blissful pollen
I'm glad to hear having a pile of random circuit boards on my desk isn't unusual
crimson ferry
I just had to move my office, which unfortunately meant dismantling about three layers of long-term "experiments" 😦
idle owl
My desk is actually uncharacteristically clean at the moment. I mean, it's cluttered, but I can still see desk. Here anyway. My other desk is a mess.
ionic elk
I feel like the Espruino Pico has the most misleading possible name for a devboard now. It's not an ESP32, it isn't from Arduino, and it's not a Pico.
or confusing, rather. It's not like it's their fault.
still zephyr
I'm glad to hear having a pile of random circuit boards on my desk isn't unusual
By the way Mark, how come only the people and Show and Tell could have one of your boards? 🤔 😋
blissful pollen
By the way Mark, how come only the people and Show and Tell could have one of yo...
Ha just was my thought cause they're showing and telling something! But if contributors to CP wanted one that could be arranged - if I can find a replacement IMU
blissful pollen
Remind me if I forget, I plan to check for a replacement chip soon but I'd send you one for sure
still zephyr
Thank you very much 🙂
slender iron
@onyx hinge gonna get back to this? https://github.com/adafruit/circuitpython/pull/4607
tulip sleet
@idle owl (if you have time) do you have an M1 Mac? I couldn't remember if you mentioned that. I have one thing for you or someone to try
gloomy shuttle
What would need to be done to use u2if with adafruit RP2040 boards? Would a similar pull request as this one need to be done but with a new board and pin definition? https://github.com/adafruit/Adafruit_Blinka/pull/449/files
slender iron
I think @tidal kiln would know @gloomy shuttle
tidal kiln
yes. that PR, plus one like this:
https://github.com/adafruit/Adafruit_Python_PlatformDetect/pull/152
but the bigger task would be to update the u2if firmware with builds for those boards
this is all planned to be done eventually
for feather/itsy/qtpy 2040's
gloomy shuttle
this is all planned to be done eventually
Thank you and that is good to know! That u2if on the pico really saved me a lot of hassle on a test project I am working on. It will be really nice with the adafruit rp2040 boards, stemma qt connector, and the new see saw rotary encoders.
tidal kiln
cool. yep. that's the hope. it'll be a bit of work, so no known timelines.
glad you found the blinka/pico-u2if combo useful
that u2if firmware is the real magic
idle owl
<@330227457296957440> (if you have time) do you have an M1 Mac? I couldn't remem...
I don't have one.
tulip sleet
ok, np, tnx
manic glacierBOT
blissful pollen
Random thought: I know there has been questions about running items on the second RP2040 core, I wonder if the native MPY change being merged in would be a good way to target something like running code on the second core.
(cavet I haven't had a chance to look or examine the code related to the native MPYs yet)
ember iris
That's a nicer number
ionic elk
Does anyone have tips on how to load onto a RP2040 and restart it without the Jlink needing to be disconnected and reconnected? After I load, I always get ISR hardfaults, or a deadbeef report, or any number of things and always have to restart GDB or even hard power cycle
fossil gorge
<@330227457296957440> (if you have time) do you have an M1 Mac? I couldn't remem...
I've got an M1, and happy to help out if you need something tested
idle owl
@fossil gorge Is it still limited to 1 external display?
fossil gorge
Not sure. I'll give it a go and find out
idle owl
I haven't looked recently. That was a dealbreaker for me.
Oh. That also works 😄
@fossil gorge The thing Dan wanted tested. He wants to know what prints out when you do the following: ```# unplug all CircuitPython boards
$ pip3 install adafruit-board-toolkit
$ python3
import adafruit_board_toolkit.circuitpython_serial
print(adafruit_board_toolkit.circuitpython_serial.comports())
now plug in a CircuitPython board and wait for CIRCUITPY to appear
print(adafruit_board_toolkit.circuitpython_serial.comports())
print(adafruit_board_toolkit.circuitpython_serial.repl_comports())```
onyx hinge
@slender iron I don't think I can "finish" it to the point where we're at zero diagnostcs right now (so much stuff to do!), so we can't enable -Werror=missing-prototypes. It might be better to vet the changes that are in that PR and if possible merge it as is, vs letting it languish.
slender iron
that's fine with me
fossil gorge
I haven't looked recently. That was a dealbreaker for me.
So, as far as my Macbook Air goes, so far, only 1 display - more if you count mirroring the external display (I don't)
idle owl
So, as far as my Macbook Air goes, so far, only 1 display - more if you count mi...
Neither do I. Thanks for checking.
fossil gorge
<@!361158808501747735> The thing Dan wanted tested. He wants to know what prints...
Will give that a try and report back
idle owl
There appear to be workarounds that require extra hardware to run more than one display. Apple supposedly said they'd include native support in a future Big Sur update. I apparently will still be waiting.
fossil gorge
Probably with something from DisplayLink. Works well in a pinch, but it's a lot of CPU work for the external display
fossil gorge
<@!361158808501747735> The thing Dan wanted tested. He wants to know what prints...
Because I has teh smartz, I'm guessing that would be with a CP7 image, right?
Sorry, meant to tag @tulip sleet about that question
idle owl
Oh I have no idea. Heh yeah, I was going to say. Ask Dan 😄
tulip sleet
hi, no it has nothing to do with CP7. Just try it with any old board 5.x or later, probably. I'm testing some CPython code that figures out the USB devices connected to the Mac.
fossil gorge
hi, no it has nothing to do with CP7. Just try it with any old board 5.x or lat...
❯ python3
Python 3.8.9 (default, Apr 4 2021, 15:10:29)
[Clang 12.0.0 (clang-1200.0.32.29)] on darwin
Type "help", "copyright", "credits" or "license" for more information.
>>> import adafruit_board_toolkit.circuitpython_serial
>>> print(adafruit_board_toolkit.circuitpython_serial.comports())
()
>>> print(adafruit_board_toolkit.circuitpython_serial.comports())
()
>>> print(adafruit_board_toolkit.circuitpython_serial.repl_comports())
()
>>> ^D
This is the first try, with a USB-A to USB-C adapter on the computer side
Just realized I have a USB-C to USB-C, so will try that "natively"
Same result
Tried 2 different boards as well, just in case
tulip sleet
```text
❯ python3
Python 3.8.9 (default, Apr 4 2021, 15:10:29)
[Clang 12.0.0 (c...
thanks, that's bad, it doesn't appear to work on M1
orchid basinBOT
tulip sleet
@fossil gorge could you also try this:
$ pip3 install --upgrade pyserial
$ python3
>>> import serial.tools.list_ports
>>> print(serial.tools.list_ports.comports())
without and with a CPy board plugged in
thanks!
this tries the original code from pyserial to see if it can list the ports
idle owl
@tulip sleet Editing a message to add a username only makes it highlighted, it doesn't tag the person.
manic glacierBOT
fossil gorge
<@!361158808501747735> could you also try this:
```
$ pip3 install --upgrade py...
❯ python3
Python 3.8.9 (default, Apr 4 2021, 15:10:29)
[Clang 12.0.0 (clang-1200.0.32.29)] on darwin
Type "help", "copyright", "credits" or "license" for more information.
>>> import serial.tools.list_ports
>>> print(serial.tools.list_ports.comports())
[<serial.tools.list_ports_common.ListPortInfo object at 0x102ede0a0>, <serial.tools.list_ports_common.ListPortInfo object at 0x1029f9610>, <serial.tools.list_ports_common.ListPortInfo object at 0x102faf340>, <serial.tools.list_ports_common.ListPortInfo object at 0x102efeee0>]
>>>
is that with or without the board(s)?
the list should add one more port when a board is plugged in
fossil gorge
Without boards
tulip sleet
so now if you plug in a board, let's see if there are five ports
just repeat the same print()
@jaunty juniper I was going to ping you later about this
jaunty juniper
I don't have a M1 😕
fossil gorge
just repeat the same print()
>>> print(serial.tools.list_ports.comports())
[<serial.tools.list_ports_common.ListPortInfo object at 0x102faf190>, <serial.tools.list_ports_common.ListPortInfo object at 0x102ec4fd0>, <serial.tools.list_ports_common.ListPortInfo object at 0x10298ee50>, <serial.tools.list_ports_common.ListPortInfo object at 0x10298e9a0>, <serial.tools.list_ports_common.ListPortInfo object at 0x10298ebb0>]
>>>
So 5 indeed
tulip sleet
ok, that's what I expect. I just tried it on Big Sur 11.3 on a non-M1 mac, and it's working. will upgrade to 11.3.1 in a bit
thankyouverymcuh
fossil gorge
Sure thing!
Just realized I was/am on 11.2.3, but 11.3.1 is anxiously awaiting my "ok" to upgrade
tulip sleet
if you could repeat the adafruit_board_toolkit testing after the upgrade, that would be great, thanks
fossil gorge
Sure thing
tulip sleet
@slender iron I am going through the 1.13 files
slender iron
ok, looks like Jeff is too
blissful pollen
If someone knows offhand what's the extmod directory for? (glancing at the 1.13 changes and see lots there)
tulip sleet
extmod is where micropython puts a lot of its native modules, what we have in shared-bindings and shared-module and common-hal
blissful pollen
ah okay that makes sense, thanks. So what is there can be brought in with an import just like something in shared-bindings
tulip sleet
they don't separate the Python API impl from the functional impl
onyx hinge
@slender iron https://gist.github.com/5a88cfdb0f24132fe7950027e56d1591
[fixes the one test failure I saw locally with the native emitter]
fossil gorge
if you could repeat the adafruit_board_toolkit testing after the upgrade, that w...
Output after upgrading to macOS 11.3.1
❯ python3
Python 3.8.9 (default, Apr 4 2021, 15:10:29)
[Clang 12.0.0 (clang-1200.0.32.29)] on darwin
Type "help", "copyright", "credits" or "license" for more information.
>>> import adafruit_board_toolkit.circuitpython_serial
>>> print(adafruit_board_toolkit.circuitpython_serial.comports())
()
>>> print(adafruit_board_toolkit.circuitpython_serial.comports())
()
>>> print(adafruit_board_toolkit.circuitpython_serial.repl_comports())
()
>>> import serial.tools.list_ports
>>> print(serial.tools.list_ports.comports())
[<serial.tools.list_ports_common.ListPortInfo object at 0x104efee50>, <serial.tools.list_ports_common.ListPortInfo object at 0x104efe9a0>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517cd00>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517c670>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517c610>]
>>>
# after unplugging board
>>> print(serial.tools.list_ports.comports())
[<serial.tools.list_ports_common.ListPortInfo object at 0x104efe9a0>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517c5e0>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517cd00>, <serial.tools.list_ports_common.ListPortInfo object at 0x10517c610>]
>>>
Hi, is this aspect of f strings supposed to work ```>>> val = 1.2345
digits = 2
f"{val:.{digits}f}"
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
KeyError: digits
it works in CPython 3.6, but the impl in CPy/MPy must be incomplete
@fossil gorge thanks; @jaunty juniper this is mysterious. The stock list_ports() is working.
jaunty juniper
and just on M1 ?
tulip sleet
yes
there was this old fix, but it's already done: https://github.com/pyserial/pyserial/issues/545
i just retested on 11.3.1 on non-M1 and it's fine
the weird difference is that your patch is an adaptation of what is in pyserial 3.5, which is what seems to be working above but not in adafruit_board_toolkit; i copied your PR into there
perhaps I made a mistake of some kind, though it works on non-M1
jaunty juniper
it just changes the interface property
tulip sleet
right, so I don't understand why it's not finding the ports at all
jaunty juniper
hey @hugo could you test this ?
pip3 install discotool-for-microcontrollers
discotool
it must be because the interface names are not coming back, because I do filter on them:
return tuple(
port
for port in ports
if port.interface
and port.interface.startswith(
tuple((prefix + " CDC" for prefix in INTERFACE_PREFIXES))
)
)
ah right
tulip sleet
actually that is post 1.0.1, and hasn't been released yet. IT's even simpler:
return tuple(
port
for port in ports
if port.interface and port.interface.startswith("CircuitPython CDC")
)
so my guess is that port.interface is not working
we should see whether list_tools is returning anything for interface, even if it's wrong
jaunty juniper
[(port.interface,port.device) for port in serial.tools.list_ports.comports()]
something like that
I'm curious what system_profiler -json SPUSBDataType gives too
tulip sleet
if @fossil gorge is willing to test further with @jaunty juniper , thanks! You know a lot more about this.
or if you have a nearby friend with an M1 Mac...
fossil gorge
if <@!361158808501747735> is willing to test further with <@!199811382793863168>...
I certainly am!
fossil gorge
hey @hugo could you test this ?
```py
pip3 install discotool-for-microcontroller...
With or without board plugged in? Or does it matter?
jaunty juniper
with
fossil gorge
Just in case...
# Without device...
❯ discotool
No device found.
## Plugged in device
Projects/CircuitPython/Tests via 🐍 v3.8.9 (.venv)
❯ discotool
- Feather RP2040 ---------------------------------------------------------------------------------------------------------------
Adafruit [SN:545473038350B304]
/dev/cu.usbmodem1101 ()
thanks
jaunty juniper
I think I'll need the output of ioreg -l on an M1 with a connected board to understand what I should be looking for
tulip sleet
I think I'll need the output of `ioreg -l` on an M1 with a connected board to un...
I'm asking a staff member
still zephyr
Danh and Neradoc Thanks for the help earlier, I was able to test the sensor and verify my PR.
tulip sleet
good night, this will be a process, thanks
@jaunty juniper you don't need to be tempted 🙂
fossil gorge
I think I'll need the output of `ioreg -l` on an M1 with a connected board to un...
Hopefully that helps 🙂
(in the morning, ofc)
jaunty juniper
is that with a board connected ?
@fossil gorge can you run this script (with pyserial installed) ?
https://gist.github.com/Neradoc/e718ee1db78549e510dfd03da2eed7d9
fossil gorge
One of each
I think that broke Gist
Those are the directly piped output, with each
❯ python3 pyserial_list_ports_osx.py
----------------------------------------------------------------------
/dev/cu.Bluetooth-Incoming-Port: n/a [n/a]
/dev/cu.HugoDahlsAirPods-Wirele: n/a [n/a]
/dev/cu.debug-console: n/a [n/a]
/dev/cu.usbmodem1101: Feather RP2040 [USB VID:PID=239A:80F2 SER=545473038350B304 LOCATION=1-1]
/dev/cu.wlan-debug: n/a [n/a]
I need to get to bed, but happy to help out more in the morning
jaunty juniper
yeah me too, good night
fossil gorge
G'night 🌜
manic glacierBOT
manic glacierBOT
lone axle
@still zephyr if you are up for doing another one of the changes from busio to board, I found this one that needs a PR for its example code: https://github.com/adafruit/Adafruit_Learning_System_Guides/blob/master/Data_Logging_with_Feather_and_CircuitPython/DataLogger.py
onyx hinge
@slender iron curious if you have any insight into why we need to clear out more stack entries than micropython .. I think we've seen it twice now. ```python
- [0, 1, 2, 3] # use up Python stack so f is really gone
- [0, 1, 2, 3, 4, 5] # use up Python stack so f is really gone``` https://gist.github.com/5a88cfdb0f24132fe7950027e56d1591
you figured it out the first time, I just copied
FWIW I ran out of juice reviewing the changes in that merge PR
jaunty juniper
I think I figured out... something... can somebody run me this on an M1 mac WITH a Circuitpython board connected ? The goal is to have the interface of the board being Circuitpython CDC Data (or at least not empty)
https://gist.githubusercontent.com/Neradoc/e718ee1db78549e510dfd03da2eed7d9/raw/6b93e0643bc04b05e795e6adeb16c2fba5a11a31/pyserial_list_ports_osx.py
jaunty juniper
I think I figured out... something... can somebody run me this on an M1 mac WITH...
@fossil gorge if you are available ☝️
fossil gorge
Sure thing. Will give it a go in just a sec
jaunty juniper
thank you very much
fossil gorge
I think you're right, @jaunty juniper!
❯ python3 pyserial_list_ports_osx.py
cu.Bluetooth-Incoming-Port
name: None
interface: None
device: /dev/cu.Bluetooth-Incoming-Port
cu.HugoDahlsAirPods-Wirele
name: None
interface: None
device: /dev/cu.HugoDahlsAirPods-Wirele
cu.debug-console
name: None
interface: None
device: /dev/cu.debug-console
Feather RP2040 - CircuitPython CDC data
name: Feather RP2040
interface: CircuitPython CDC data
device: /dev/cu.usbmodem1101
cu.wlan-debug
name: None
interface: None
device: /dev/cu.wlan-debug
So not only not empty, but also has the "CircuitPython CDC data" present. though "Data" is actually lowercase "data".
fossil gorge
You're most welcome!
solar whale
HAs there been a basic change to using usb_hid? I'm getting USB Busy errors with code that worked before the recent updates.
idle owl
@tough flax Hey, Bill! I have a quick question. Is it alright with you if I use the STEMMA connector from your Feather RP2040 pinout for our own pinout diagrams? I need to modify it to match our pin labels, but I'd like to use the connector bit if it's ok with you.
slender iron
<@!252717193496756235> curious if you have any insight into why we need to clear...
I forget what function it was but we basically added some more C functionality that caused the C stack to be larger. If a pointer value remains in the stack area (even if unused) it won't be collected and finalized by the gc.collect()
it's just a fragile test
manic glacierBOT
still zephyr
<@!607375730610798634> if you are up for doing another one of the changes from b...
Yes, , I am up to it. would take a look and change the references and go through that library with the other new changes. thanks
orchid basinBOT
tough flax
<@!286539914793844739> Hey, Bill! I have a quick question. Is it alright with yo...
Of course. I made that for adafruit. Do what you’d like with it
idle owl
Of course. I made that for adafruit. Do what you’d like with it
Cheers! Appreciate it.
idle owl
@still zephyr I noticed this list says 41. But if you check the .gitmodules file, submodule appears 43 times, implying 43 libraries. Any idea why there's a discrepancy? https://github.com/adafruit/CircuitPython_Community_Bundle/blob/master/circuitpython_community_library_list.md
still zephyr
There are two libraries included after the list was made, schedule and morse_code,
The list was created as a test that the code works but is not live
idle owl
Ah ok
Cheers
I'll stick with my method of searching for submodule in the .gitmodules file. It's worked for a long time. 😄
onyx hinge
@slender iron any more merge test failures for me to look at?
still zephyr
:), we could revisit once all the bundles and community repos are defined
idle owl
:), we could revisit once all the bundles and community repos are defined
That's the plan.
slender iron
nope. I did 1.14 and 1.15 yesterday too. could use reviews for them though
onyx hinge
1.13 is still failing on esp32-s2 builds?
manic glacierBOT
slender iron
1.13 is still failing on esp32-s2 builds?
just pushed a fix. the AP PR had added more const_none_obj things
still zephyr
@idle owl do you think there is any way, that we could make a note for first time contributors, when they submit a PR in Github?, There is a section in the readme.md in how to contribute. But this link points to the Creating and sharing a CircuitPython library learning Guide in , and is not until further in that reading that the Pylint and Black is mentioned. Also I think, that we should include the design guidelines somewhere as normally people include code to the library and not build a library. This is related to this PR. https://github.com/adafruit/Adafruit_CircuitPython_MCP4728/pull/10
idle owl
<@!330227457296957440> do you think there is any way, that we could make a note ...
What kind of note specifically?
still zephyr
See the Pylint and black Learning Guide, and the design guidelines in the circuitpython repo?
idle owl
And I don't think we can do a thing that is specific to first time contributors. I'd have to look into that. I think it's everyone or no one.
manic glacierBOT
still zephyr
And I don't think we can do a thing that is specific to first time contributors....
Thanks, for looking into that
idle owl
Thanks, for looking into that
I'm not finding anything. If we're going to include a note, it would be a PR template that would appear to everyone.
As far as I can tell.
still zephyr
I saw that we have that kind of template in the learning guides, I think would be good, but others opinion are welcome 🙂
idle owl
We have them on CircuitPython now as well. I kind of don't like them because you get folks who see text in the PR, and don't delete it or fill anything in because there's already something there. But I guess it' a matter of education.
I need to see whether enabling templates is something we can automate because 270 repos is a lot to manually do that on.
still zephyr
or maybe if we could have a template for reviewers that could help also and avoid the spam in the notes
that everyone uses and we just copy as a first note
idle owl
Looks like we can automate it.
still zephyr
oh nice 🙂
idle owl
It's simply a file in the .github directory. That's Adabot's jam.
onyx hinge
@slender iron should we consider transitioning from translate() to MP_ERROR_TEXT generally? or just in files that are shared with mp?
still zephyr
It's simply a file in the `.github` directory. That's Adabot's jam.
oh no , ... suddenly I feel fear with the Adabot mention 😬
slender iron
I just did the shared ones. we use it for more than error text so I didn't want to overuse it
idle owl
oh no , ... suddenly I feel fear with the Adabot mention 😬
Adabot is your friend 🙂
misty garnet
I didn't think f-strings worked at all in CP
still zephyr
Adabot is your friend 🙂
😆 well... not sure about that
idle owl
I didn't think f-strings worked at all in CP
I thought we added support at some point.
misty garnet
a=2; print(f'{a}') gives me an invalid syntax error
idle owl
I could be conflating it with a discussion about adding support.
versus actually adding it.
misty garnet
ah
idle owl
Scott, Dan or Jeff might know.
idle owl
It shouldn't be port specific.
still zephyr
maybe...
onyx hinge
It is, unfortunately. It's turned on by .... checks
idle owl
Oh. Interesting.
still zephyr
oh no....
misty garnet
I'm on CP7 on QtPy M0, so maybe I don't have the right flag set
onyx hinge
It's turned on/off by MICROPY_CPYTHON_COMPAT which is turned off for small boards like most (all?) samd21
misty garnet
that would explain it
still zephyr
So we need to avoid them in the examples as they do not work all across the board jeff?
onyx hinge
Yeah you need to do other things like "...".format() for code that will work on all CP boards
idle owl
I would say that is correct. Unless you are explicitly clear that the example is meant for a specific board. Even then, it's not a good idea.
onyx hinge
The "m" in "mpy" stands for "coMpiled"
solar whale
somehow "f-strings" sounds like something you would get banned for using....
misty garnet
heh
onyx hinge
the "ſ" stands for subſtitution
solar whale
It's that "early-american" form - congreff
jaunty juniper
personally I'm conflicted on f-strings, people seem to think they are great, but how do you translate an f-string ? you can translate "Speed: {}" into "Vitesse: {}" and .format it but where and how do you translate f"Speed: {speed_value}" ?
onyx hinge
I agree, f-strings and localization don't seem to mix
perhaps some future version of Python will provide for a kind of extended literals that can permit both localization and formatting, so that e.g., f_"Speed: {speed_value}" does a gettext() call and then a format() call. C++ has added such user-defined string literals that can expand into magical things.
the f-string PEP doesn't seem to have discussed how it interacts with localization. https://www.python.org/dev/peps/pep-0498/
jaunty juniper
likewise I believe Swift has an approach that allows for localisation but I don't remember the details
onyx hinge
@lapis hemlock once 1.13 is merged in, I think ulab may be able to drop the workaround for cicuitpython not having rich comparisons!
still zephyr
@idle owl or @onyx hinge I would include this note in the design guideline, please let me know if I need to rephrase it. thanks
When using print statements you should use the " ".format() format, as there are particular boards that are not capable to use f-strings.
onyx hinge
@still zephyr sounds good (missing an e of "are particular")
still zephyr
Thanks, I will correct that
manic glacierBOT
jaunty juniper
hey @fossil gorge are you ready to live on the edge ? Would you risk installing the latest on a board and enable the second serial, and run the serial test script on M1 ? https://gist.github.com/Neradoc/e718ee1db78549e510dfd03da2eed7d9 there's a bug if you don't disable hid (at least on QT PY), so you would put that in boot.py
import usb_hid
usb_hid.disable()
import usb_cdc
usb_cdc.enable(console=True, data=True)
Live on the edge and back away from this freefall? :D
I'll give it a try as soon as I get back home. Should be about 30 minutes
jaunty juniper
thank you 👍
fossil gorge
hey <@!361158808501747735> are you ready to live on the edge ? Would you risk in...
This is without the "boot.py" file (using a Feather RP2040)
❯ python3 pyserial_list_ports_osx.2.py
/dev/cu.Bluetooth-Incoming-Port: n/a [n/a]
/dev/cu.HugoDahlsAirPods-Wirele: n/a [n/a]
/dev/cu.debug-console: n/a [n/a]
/dev/cu.usbmodem1101: Feather RP2040 - CircuitPython usb_midi.ports[0] [USB VID:PID=239A:80F2 SER=4545373038053B40 LOCATION=1-1]
/dev/cu.wlan-debug: n/a [n/a]
Should I try with the boot.py file as well?
jaunty juniper
yes, but I think I'll want the output of ioreg -l like last time too
fossil gorge
Ok. I'll run those and let you know what comes up
jaunty juniper
cause there it's saying "usb_midi.ports[0]" and that is super weird
fossil gorge
Here's the pyserial_list_ports.py
❯ python3 pyserial_list_ports_osx.2.py
/dev/cu.Bluetooth-Incoming-Port: n/a [n/a]
/dev/cu.HugoDahlsAirPods-Wirele: n/a [n/a]
/dev/cu.debug-console: n/a [n/a]
/dev/cu.usbmodem1101: Feather RP2040 - CircuitPython CDC data [USB VID:PID=239A:80F2 SER=4545373038053B40 LOCATION=1-1]
/dev/cu.usbmodem1103: Feather RP2040 - CircuitPython CDC2 data [USB VID:PID=239A:80F2 SER=4545373038053B40 LOCATION=1-1]
/dev/cu.wlan-debug: n/a [n/a]
For @jaunty juniper - ioreg output
jaunty juniper
ah that's not a M1 issue
good to know
thanks, I believe that means my code works and I can PR for now, but there are more issues with 7.x
fossil gorge
Awesome! Good job getting it sorted out! 🙂
manic glacierBOT
solar whale
So far -- post merge of MP1.13 my rp2040 pico and esp32s2 funhouse are still working !! Well done!
blissful pollen
So far -- post merge of MP1.13 my rp2040 pico and esp32s2 funhouse are still wor...
No really CP related (I think) but do you know if your funhouse temperature reading seems a lot higher then what it actually is? Mine is saying 33C and I'm not where near that
solar whale
Yes - the onboard temps are way high due to heating of the board 😦 - I use an external I2C (STEMMA) temperature sensor
blissful pollen
okay thanks just wanted to make sure that was normal
pearl tapir
any idea with mocking hardware in **all **circuitpython libraryies that supports development of software/program and debugging outside the hardware..? (for ex: in ubuntu)
Example : adafruit_mcp4725 and adafruit_tca9548a in https://github.com/codenio/virtual-pi
still zephyr
any idea with mocking hardware in **all **circuitpython libraryies that support...
do not know, hey those DAC look familiar 😬
lone sandal
manic glacierBOT
manic glacierBOT
pearl tapir
do not know, hey those DAC look familiar 😬
I had the following requirement :
I had to develeope an GUI that controls several DACs using Circuit Python libraries. As developement inside RPi becomes difficult (or if you dont have one yet) and ubuntu had no GPIO support, I started with Mocking GPIO and then Mocked all essential breakout boards (MCP4725 and TCA9548A). Post Developement in ubuntu it was a seamless switch. It uses virtual libraries when executed outside RPi and actual Hardware inside RPi.
Adding such mock/virtual hardware in respective circuit python libraries could accelerate software/program developement even in absence on actual hardware. It helps to decouple the hardware dependencies during developement and enhances debugging.
It resembles : Local developement and deployment in production
Thoughts and Comments..?
thorny jay
I had the following requirement :
I had to develeope an GUI that controls sever...
T&C: I guess you could have use some Blinka layer, or create a fake Blinka layer that only print and does not do anything. That way you have a compatible interface that work on Pi and MCU and many other SBC.
manic glacierBOT
manic glacierBOT
still zephyr
I had the following requirement :
I had to develeope an GUI that controls sever...
Same questions as David, do Blinka is included, also it would worth a look to https://github.com/adafruit/Adafruit_Blinka_Displayio. I am interested in the graphical aspect, do this does something similar to Raspberry Pi GPIO Emulator? but very interesting.
hearty forge
I had the following requirement :
I had to develeope an GUI that controls sever...
a concrete "fake" implementation for use on non microcontrollers would be interesting. I was randomly googling ideas this morning, and started thinking about circuitpython in Jupyter Notebooks, and borrowing some of the components that have been developed for the wokwi arduino simulator 🙂
Is it possible to modify a uf2 (existing or by regenerating) so that a newly flashed CP device will have pre-packaged files on the CIRCUITPYTHON drive? e.g. I'd like to add a custom code.py, a back-up copy of this, and possibly one or two of the standard libraries. (I don't want to freeze them - want to include them as a concrete example of where the files should be copied to.)
hearty forge
@still zephyr thanks- but I think that's for connecting a notebook to a CP device and using Jupyter as a sort of REPL frontend. I was thinking more of a virtual CP that could eg be used with google colab, no CP hardware at all.
hollow token
https://github.com/adafruit/circuitpython_jupyter_kernel. <:blinka:3423840864441...
I think, as goal from this discussion, would be being able to unit test CircuitPython code, without having to have a device farm
eg, create a device simulator or pseudo-device library, that simulated states to test code
still zephyr
I think, as goal from this discussion, would be being able to unit test CircuitP...
Interesting 🤔 . yes being able to test CP is a good thing.
hollow token
I do this on my own projects as well. https://coveralls.io/github/Red-M/RedSSH?branch=master
Understanding coverage and how much of your code is actually able to be used is also good.
manic glacierBOT
manic glacierBOT
hollow token
Yay! I have a few MCP23S17 in my hands :)
manic glacierBOT
solar whale
@tulip sleet I am pretty well baffled by PR 4734 -- I added more to the comments -- I now have a trigger for the issue on a CPX or prikey_m0 -- No idea why, though... I have to go off for awhile and will resume troubleshooting later. I have no objection to merging pr 4734 and working on this as new issue. Whatever you think best.
solar whale
Perhaps this would be a good topic for "in the weeds" today.
solar whale
@prime flower can you possibly comment on this https://forums.adafruit.com/viewtopic.php?f=57&t=179044 -- Is there any chance that the FONA library will support the LTE module on the Particle BORON?
daring ridge
Hi - I'm getting ready to make some updates to circuitpython-org repo and submit a PR - but want to test before submitting. Can anyone confirm that the instructions in the README.md are up to date with the software versions needed? Specifically, the section: To test your changes local: ... 6 short steps.
I did attempt to do so directly on my Mac using the software versions specified, but it failed to generate and launch the jekyll server to test with. So I'm setting up a Debian VM which the instructions indicate is used for this. The Debian Stretch system indicated and Ruby versions appear to be pretty old, though, so just wanted to verify.
manic glacierBOT
ionic elk
@tulip sleet when you're back in town: I think the best plan for sleep is
a) merge STM32 Alarms (do we need someone to help test this?)
b) I merge main into the API revisions and spruce up STM32 and NRF accordingly
c) merge API revisions in #4606
d) RP2040 Alarms PR can be submitted/reviewed, since it is built on #4606
prime flower
<@!311339734339289090> can you possibly comment on this <https://forums.adafruit...
No, wont be supported because the boron has an entirely different module than the FONA
When adafruit makes a LTE fona breakout, that'll get an official Adafruit_CircuitPython_ library. No guarantees whether an updated breakout will use the same modem as Particle or not.
solar whale
@prime flower Thanks -- would you be able to comment in the Forum post -- to give an "official" Adfruit response.
prime flower
Yeah sec.
solar whale
Thanks!
prime flower
Thanks!
https://forums.adafruit.com/viewtopic.php?f=57&t=179044&p=871641#p871641 < thanks for pinging me on this one Jerry
fossil gorge
Hi - I'm getting ready to make some updates to circuitpython-org repo and submit...
Hey @daring ridge! I'm looking over the README now, and comparing it with the GitHub action that runs for deployment. It looks like they're fairly similar, with these variations or details
- GitHub action is run on the "ubuntu-latest" image - probably 20.04 which is LTS
- The specific version of Ruby used is 2.7, not 2.5. Don't know if it makes a differences
- The commands run to install bundler and build are:
# Install bundler, and run
gem install bundler:1.17.3
bundle install --full-index
# Build site with jekyll
bundle exec jekyll build -d build
turbid radish
?serverinfo
digital shoreBOT
adafruit
idle owl
Hi - I'm getting ready to make some updates to circuitpython-org repo and submit...
It should work on MacOS, as far as I know. But I haven't specifically run it, so I'm not certain.
@tough flax Limor and PhilB put together a semi-automated generator, here: https://github.com/adafruit/PrettyPins I nabbed the connector to include in a file that I can pull from as needed with lines that match the spread of the pin labels.
daring ridge
Hey <@!702323484730065018>! I'm looking over the README now, and comparing it wi...
@fossil gorge , thank you very much, that is extremely helpful! I'll give that a whirl.
daring ridge
It should work on MacOS, as far as I know. But I haven't specifically run it, so...
@idle owl , thank you also. I tried on MacOS using the versions specified, but it failed late with an invalid ascii character during processing. I didn't dig too deep, though, perhaps it will work with the later version(s) that @fossil gorge found in the GitHub actions. Thanks!
daring ridge
@fossil gorge and @idle owl , I got it working directly on MacOS - thanks to both of you.
I still had to edit a couple of files to remove a non-US-ASCII character to get the generation to complete, but it shouldn't affect my update - this is extremely helpful. Thanks again to both of you!
idle owl
<@!361158808501747735> and <@!330227457296957440> , I got it working directly on...
You're welcome! Glad to hear it. Thanks for contributing!
fossil gorge
<@!361158808501747735> and <@!330227457296957440> , I got it working directly on...
Glad you got it going! Out of curiosity, which characters did you have to remove, and from where? (if you have those handy)
daring ridge
Glad you got it going! Out of curiosity, which characters did you have to remove...
These two:
circuitpython-org/vendor/bundle/ruby/2.7.0/gems/jekyll-theme-primer-0.5.4/_sass/primer-support/lib/mixins/typography.scss:43: Invalid US-ASCII character "\xE2" (Sass::SyntaxError)
and
circuitpython-org/vendor/bundle/ruby/2.7.0/gems/jekyll-sass-converter-1.5.2/lib/jekyll/converters/scss.rb:123:in `rescue in convert': Invalid US-ASCII character "\xE2" on line 5 (Jekyll::Converters::Scss::SyntaxError)
fossil gorge
These two:
circuitpython-org/vendor/bundle/ruby/2.7.0/gems/jekyll-theme-primer-...
Wow, so that's within the jekyll gems. eeenterestink
daring ridge
Wow, so that's within the jekyll gems. eeenterestink
It's this sequence in all the occurances:
// Heading sizes - mobile
// h4<E2><80><94>h6 remain the same size on both mobile & desktop
fossil gorge
Thanks for sharing that @daring ridge. Will be on the lookout for those. Was that in macOS, the Debian VM, or elsewhere?
daring ridge
Thanks for sharing that <@!702323484730065018>. Will be on the lookout for those...
That was Mac OS using Ruby 2.7. I did gem install bundler:1.17.3, but I think it used 2.1.4:
[bsd@yyz]:/bsd- bundler -v
Bundler version 2.1.4
[bsd@yyz]:/bsd-
So that may be the problem ...
fossil gorge
Peculiar. Seems like another rabbit hole to dive into and sidetrack other things soon! 🙂
Again, I appreciate you providing that information and level of detail! 🙂
daring ridge
Peculiar. Seems like another rabbit hole to dive into and sidetrack other things...
No problem at all! 🙂
jaunty juniper
say @idle owl you might be already working on that amongst your guides rework, but somebody this weekend mentioned that page, that uses D13 as default pin for blink (instead of maybe board.LED), the person was using a pico and came asking about it https://learn.adafruit.com/welcome-to-circuitpython/creating-and-editing-code
idle owl
say <@!330227457296957440> you might be already working on that amongst your gui...
It's not in my rework, no. But it can be updated to board.LED. Not all boards have board.LED yet, that is part of my rework. As I get to their guides, I will be updating boards in batches. I have a list. The Pico guide has https://learn.adafruit.com/getting-started-with-raspberry-pi-pico-circuitpython/blinky-and-a-button which uses board.LED.
idle owl
say <@!330227457296957440> you might be already working on that amongst your gui...
Updated. Now we'll get feedback from folks using the board without board.LED. 😄
jaunty juniper
if mentions the QT PY, D17 for the Clue and BLUE_LED for the itsybitsy nrf52, maybe a general warning saying if it doesn't blink to look at the specific board's guide pinout to check the LED pin would guide people to where to look
it's hard to know what will help people the most 🤷
idle owl
I took the time to narrow down the list to Adafruit boards, and I think I'll update them today or tomorrow. Alleviate the issue at the source.
There are 38 boards. Shouldn't be too bad. 🙄
jaunty juniper
it was someone who decided to read the whole "Welcome to CircuitPython" guide to familiarize themselves with it
idle owl
There are more of those folks than you'd think.
That's the problem with including troubleshooting and other things that may not apply to every board. Some folks try to do all of it.
We do what we can to make it clear when things won't work. And we adapt where necessary.
That's where the templates will be super helpful - they're tailored to each board, so there's no warning about QT Py on a Pico page, etc. Though Pico won't get them because it's not an Adafruit board.
pearl tapir
we could either modifiy VPi to make it more generic or We could start some virtualisation library from stracth. @still zephyr @thorny jay your thoughts..?
ivory yew
if someone would be so kind to merge this: https://github.com/adafruit/circuitpython/pull/4735
I seem to have lost my merge rights. (but that is okay)
idle owl
if someone would be so kind to merge this: https://github.com/adafruit/circuitpy...
Done, and I'll look into your status.
This afternoon.
idle owl
Thanks, <@!330227457296957440>
Odd. I'll dig into it later. But you still have write access to the CP repo.
ivory yew
Yeah it was weird - it said I had write access so I could approve it, but that I couldn't merge because the branch was protected. 🤷♀️
still zephyr
we could either modifiy VPi to make it more generic or We could start some virtu...
oh no, no scratch for me, I like REUSE as much as possible, but a least link it with Blinka somehow 🤔
@pearl tapir Thanks for you answer in the issue https://github.com/adafruit/Adafruit_CircuitPython_VL53L0X/issues/27
idle owl
<@&356864093652516868> Meeting in little over 30 minutes. If you're participating, please update the notes doc with your Hug Reports and Status updates. Thanks! https://docs.google.com/document/d/1R2Qq9dAKqrAh0wFuu1-X7r9HgPJf1bgLz45fklJHmfo/edit?usp=sharing
modern wing
Good afternoon all you wonderful people ☕
drowsy geyser
silver tapir
That's better than print() debugging 🙂
modern wing
That's the new hot item -- celebrities doing computer sound effects. Next up, Morgan Freeman doing the Windows XP logon sound.
onyx hinge
MicroPython 7.0.0-alpha.1-709-g256fcd6cc-dirty on 2021-05-10; linux version
Use Ctrl-D to exit, Ctrl-E for paste mode
>>> from ulab import numpy as np
>>> np.arange(1, 24) > 7
array([False, False, False, ..., True, True, True], dtype=bool)
``` ooh the rich comparison stuff works in current circuitpython. It didn't work earlier, because we needed update from micropython to enable it
errant grail
Just listening today.
onyx hinge
calendar links are in the notes document
errant grail
"lurking" is such a dark term
slender iron
hears jaws music
storm minnow
lurk lurk
jaunty juniper
it's a common term on live streams and forums
with no particular negative implication
old smelt
lurking
modern wing
_hears jaws music_
All thanks to John Williams. 🎼
onyx hinge
Since May 1, we have the following file and line modifications stats in circuitpython: 1129 files changed, 68239 insertions(+), 22170 deletions(-) -- big numbers, because they count all the micropython changes we've been bringing in.
solar whale
Is .mpy stable now through 1.15?
onyx hinge
@solar whale yes we think/hope so
jaunty juniper
I believe it is, there is nothing about it in the update notes for Micropython 13-14-15 that I could see
slender iron
yup, post the M -> C change
jaunty juniper
we'll need a new alpha release to get the 7.x bundle to compile the latest mpy version
onyx hinge
Yes, let's do that
solar whale
I've done a few quick conversions with no issues.
slender iron
same
lone axle
yep
jaunty juniper
that's a question by the way, should displayio.release_displays() release the board.DISPLAY ? And if so is there a way to reinit it from python code ?
slender iron
I think it should. you can reinit using the python driver but it's not simple
(one may want to change the init of the built in display)
manic glacierBOT
onyx hinge
I'm sad I missed the precision timing discussion. can someone give me a link back to the discussion for later?
slender iron
that was from @still zephyr's hug report
onyx hinge
I assume they had discussed it here on discord, I'd read back if I could find the messages
slender iron
I read through most of discord and didn't see it. may have been an issue
(I'm not through my email)
onyx hinge
OK, I archive most of my github email without reading it 😕
slender iron
I'll let you know if I come across it later
