It worked , thanks alot @tulip sleet ๐
#circuitpython-dev
obsidian compass
tulip sleet
yw!
obsidian compass
here it is @tulip sleet , @tidal kiln
tulip sleet
very nice!
tidal kiln
neat!
obsidian compass
thanks, that's pybadge working with adafruit IO over mqtt using airlift featherwing
It's sad can't use the display, neopixel and airlift at the same time
tulip sleet
is it SPI bus contention? are the display and the airlift sharing the same SPI bus?
obsidian compass
I think it's airlift and neopixel
not sure, checking schematic
because I can surely do both display and airlift at the same time, it has to be neopixel right?
tulip sleet
what goes wrong?
obsidian compass
Maybe a shared pin, wait let me share that error
File "neopixel.py", line 91, in __init__
ValueError: D8 in use ```i don't see that it's shared on the schematic.. hmm
tft and regular SPI bus are separate
obsidian compass
What pins are SPI?
tulip sleet
MOSI, MISO, SCK
tidal kiln
are you using pybadger library?
obsidian compass
@tidal kiln to use the display? Yes
tidal kiln
and also creating a separate neopixel object?
tulip sleet
bingo &^^
obsidian compass
Ok lmao
tidal kiln
pybadger lib does that for you
obsidian compass
I feel good and bad ๐
tidal kiln
(for the pybadge neopixels)
tidal kiln
no worries. it happens a lot.
idle owl
That it does.
ionic elk
@tulip sleet sorry for being a git dumb dumb, but I still want to totally nail down what I should do here:
- Should I make my own hierophect/uf2-stm32f fork and submit prs to the adafruit fork, or just clone the adafruit fork and submit directly?
- Say I want to make a commit/PR that changes the drive name to CPYBOOT, which the upstream repo won't want. Will that be skippable in what we send to them?
tulip sleet
@ionic elk 1) the former, so we can review your changes ourselves, and them submit them upstream
- with the right PR's yes, but we try make it so we and they can stay in sync. Worst case there could be compile options.
half sedge
@obsidian compass You seems to do PyBadge+Airlift and dealing with converting color in string to color for displayio... I did this and it is very similar:
https://gist.github.com/dglaude/cc9f7d596c7d976e9c331a9e00e43292
Err that is not for displayIO that is for the neopixel on board.
@obsidian compass I have another piece of code that does web color to color on PyPortal with this:
pyportal.set_background(eval("0x"+value.lstrip("#")))
I don't know if it is pythonic but it works for me.
tulip sleet
@half sedge use int(value.lstrip("#"), 16)
half sedge
@tulip sleet Perfect, thank you.
tulip sleet
eval() has to compile and run the string you pass as Python code, which is quite expensive, and can also be unsafe (malicious code could be passed in)
lone axle
yep, I was going to mention make sure you have a full understanding of what value could contain if you are going to pass it to eval.
idle owl
@tulip sleet @slender iron Any ETA on the next CP release?
half sedge
It is likely that I borrowed this code from... the internet!
slender iron
not that I have planned. something you'd like released?
obsidian compass
Thanks for sharing that @half sedge ๐
idle owl
@slender iron We didn't include the updated Circuit Playground library in the last release. I wondered when it would next be released. Doesn't need its own release. Was simply curious whether there was anything planned. Not a big deal that there isn't.
half sedge
@obsidian compass here is the repo for my PyPortal cheerlight code (without danh fix): https://github.com/dglaude/Fosdem20CircuitPython
obsidian compass
Thanks, I am looking forward to get my hands on a PyPortal soon
slender iron
kk, I don't know what @tulip sleet is thinking. he's been squashing bugs
idle owl
Alright. Thanks.
tulip sleet
@idle owl do you mean 4.x? I started a PR, but decided it was not urgent and we could wait for things to settle
idle owl
@tulip sleet I meant 5.x. But I suppose 4.x as well. I agree with waiting. It was more of a curiosity. I have an updated version of the soundmeter code to PR, but I don't think it relies on the recent updates. So it should be fine with the current version.
bright aspen
@tidal kiln Are you tinkering with busio.SPI? Here are couple of my observations: On Feather M4 Express it currently takes a minimum of 30 us to do an I/O operation. The lock takes twice as long.
half sedge
@gilded cradle do you know the future of displaying on LCD from Blinka?
Should we be able to use a supported I2C or SPI display, connect to a Pi and display on it from Python but with Blinka and CP library?
Are we going to miss DisplayIO?
The idea is to get that 240*240 on a Pi, write code and then move that to the Gizmo for CPX or CPB.
tidal kiln
@bright aspen thanks. i'm not doing anything that low level though.
obsidian compass
@tidal kiln I am kinda lost here finding the API exposed by pybadger library to control on-board neopixels, any idea?
I see a "pixels" property in lib code but not really sure how to use that one
tidal kiln
that's the neopixel instance, so just access it and then use any neopixel API call on it
obsidian compass
trying...
tidal kiln
pybadger = PyBadger()
pybadger.pixels[0] = 0xFF0000
pybadger.pixels[1] = 0x00FF00
pybadger.pixels.fill(0xADAF00)
etc.
obsidian compass
Yes, worked. Thank you!
ionic elk
@tulip sleet ok, current F405 bootloader pattern is it alternates on reset presses between circuitpython and the ARCADE-F4 drive. If I want to match the Atmel behavior, it seems changes will need to be made.
works great otherwise though.
@slender iron & @meager fog you might want to weigh in on this too? I've got a working UF2 bootloader for the Feather F405, but it will need changes to be in line with other feather boot behavior.
idle owl
<@&356864093652516868> Here is the notes document for Mondayโs CircuitPython Weekly meeting. Everyone is encouraged to attend! Please add your hug reports and status updates even if youโll be attending the meeting - itโs super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and Iโll read them off during the meeting. Hope to see you there! https://docs.google.com/document/d/16ssd4xtTLyBV_5dmoOSjXIWLtJrESWVIxJ5BIfoUfYA/edit
gilded cradle
@half sedge pretty much everything I know about it is contained here: https://github.com/adafruit/Adafruit_Blinka/issues/109
Currently it's not there, but I like to see it added this year.
slender iron
thanks @idle owl !
@ionic elk it'd be best if it worked the same way with a double tap to enter the bootloader
ionic elk
@slender iron Ok I'll look into making it do that. What about the drive name? Are you ok with our fork of the uf2 bootloader diverging from upstream so it can by FEATHERBOOT instead of ARCADE-F4?
@stuck elbow I'm recreating your snake game - is refresh_soon deprecated?
tulip sleet
@ionic elk the boot drive name can be board-specific. We load the bootloaders on our boards at the factory so we'd choose that. Worst case is a compile-time option or two board defs. I'd rather not diverge if we don't have to
i got buy-in from the MS group that we would try to keep the uf2-samdx1 repos sync'd, and it would be good to do the same here
ionic elk
Ok that makes sense, you'd just go in and change the config for your local copy at the factory.
no sense worrying about that, good point
slender iron
@ionic elk refresh_soon is removed in 5. you can omit it
slender iron
@gilded cradle https://forums.adafruit.com/viewtopic.php?f=60&t=161551
gilded cradle
Hmm, thanks @slender iron.
slender iron
np, thank you
gilded cradle
I opened an issue on github and let them know
slender iron
thansk
slender iron
any ideas why build sizes would be 200 bytes different between my computer and github actions? It outputs the same version of gcc
onyx hinge
@slender iron 200 bytes is a big difference. I observe small differences from build to build, though, even on the same system. I think it's down to the fact that (sigh) the lto linker involves random numbers for some reason (!?) https://gcc.gnu.org/bugzilla/show_bug.cgi?id=66305
two consecutive builds of metro_m0_express just now gave me: ```5396 bytes free in flash firmware space out of 253696 bytes (247.75kB).
5392 bytes free in flash firmware space out of 253696 bytes (247.75kB).
I think it's that github actions is creating a merge commit
onyx hinge
oh, so it's not even building the same code as you? that could explain 200 bytes easily.
slender iron
ya, believe so
the run is marked as 5e789b3 but in the output HEAD is now at e9860007d Merge 5e789b38504846982a8cd7fa447297a51efc8352 into eb0ef3726f7c5857bcb3b75910ee445767b2af89
bright aspen
@onyx hinge @slender iron Perhaps the 4-byte changes are related to a date/time string?
slender iron
ok, now it is spot on for me
en us is off by 4
I'd believe linker randomness
@bright aspen I don't think we include the build date though the compiler may
tidal kiln
@idle owl want me to merge this and tag a release?
https://github.com/adafruit/Adafruit_CircuitPython_Display_Text/pull/30
slender iron
I think the version string is git commit
Use make V=1, make V=2 or set BUILD_VERBOSE similarly in your environment to increase build verbosity.
Font missing character: รผ 252
Font missing character: ร 220
Font missing character: ร 223
Font missing character: รถ 246
Font missing character: รค 228
0 bytes free in flash firmware space out of 237568 bytes (232.0kB).```nailed it
its -4 on github actions ๐
did tinyusb get bigger?
gonna go for a run. will debug after
idle owl
@tidal kiln Yes please
ionic elk
@tulip sleet for the arduino nano 33 ble, do you know if these lines in board.c will cause breakage if included after the filesystem is inited?
// Errata Nano33BLE - I2C pullup is on SWO line, need to disable TRACE
// was being enabled by nrfx_clock_anomaly_132
CoreDebug->DEMCR = 0;
NRF_CLOCK->TRACECONFIG = 0;
// FIXME: bootloader enables interrupt on COMPARE[0], which we don't handle
// Disable it here to avoid getting stuck when OVERFLOW irq is triggered
nrf_rtc_event_disable(NRF_RTC1, NRF_RTC_INT_COMPARE0_MASK);
nrf_rtc_int_disable(NRF_RTC1, NRF_RTC_INT_COMPARE0_MASK);
@ionic elk does "bootloader" here mean the UF2 bootloader or the Arduino-supplied bootloader?
ionic elk
If you're referring to what I just posted I have no idea, that's nrf port code
tulip sleet
I don't know if the softdevice uses NRF_RTC1 for anything
maybe I just copied that from the Arduino startup code forthe board
ionic elk
do you have one of those on hand? Scott had me move the board_init into main, after the filesystem, and this is the only board that could be affected by the change
everything else is either empty or won't have problems
tulip sleet
I think you could delete the "FIXME: bootloader" lines. I copied those from the Arduino variant.cpp
they aren't relevant to the UF2 bootlaoder
I am more worried about moving board_init() to past the filesystem. On some boards it does some pretty low-level stuff
ionic elk
This isn't related to the bootloader stuff I was talking about earlier, by the way, it's the display thing
onyx hinge
@slender iron I wrote this up and welcome thoughts, but like so many things it's not anywhere near the top of my todo list.
Improving memory usage for labels in displayio:
My idea is to introduce a type GlyphRow whose data fields are basically
uint16_t x, y;
mp_obj_t font;
mp_obj_str_t* content;The first glyph is drawn with its origin at (x,y). Subsequent glyphs have the
x coordinate adjusted by the width of the prior glyph.A row of pixels can be computed efficiently from left to right by just
iterating over the list of characters in the string. If it has to be
drawn from right to left, then you'd also need to keep an "end of string"
and a "total length" pointer (plus extra problems that arise from the memory
storage of unicode in circuitpython being utf-8; this complicates backwards
iteration). Drawing from top to bottom or bottom to top just mean using a
column of pixels at a time but are otherwise like RtL or LtR. I think all
these cases can arise from screen rotations.It doesn't matter whether the glyphs are in one Bitmap or not, they are
fetched from the font object by calling the get_glyph method. No auxiliary
storage is necessary for the string data itself.Multiline text would consist of multiple GlyphLines, and the responsibility
for laying them out would fall to a refined adafruit_display_text. In this
case we might want to allow for str to be qualified with a start and end, so
that there's no slicing of the overall string; or maybe YAGNI.Protocol-izing Group / TileGrid so that GlyphRow can be added is probably a
sensible step to take before introducing a third type that needs to implement
similar operations at the shared-module level.
ionic elk
I looked through every board in circuitpython and it's empty in every single one but this and the i.mx, which scott thought was fine
These are the only boards that had any content in the function:
- capablerobot_usbhub
- feather_mimxrt1011
- feather_mimxrt1062
- imxrt1010_evk
- arduino_nano_33_ble
scott emptied the capable robot one, the i.mxs he says should be ok, so it's really just this nano left.
tulip sleet
@ionic elk, ok then
half sedge
Big Hug to @idle owl for the MLX90640 learn guide and the use of my example. So proud. Also nice picture.
idle owl
Thank you and thanks for the example!
manic glacierBOT
meager fog
we have a smattering of https://www.adafruit.com/product/4500 if someone would like to pick one up
quartz raptorBOT
tulip sleet
@idle owl @slender iron having trouble setting readthedocs url properly: This is right: https://circuitpython.readthedocs.io/projects/ble_apple_media/en/latest/
This is wrong:
https://circuitpython.readthedocs.io/projects/adafruit-circuitpython-ble-heart-rate/en/latest/
adafruit-circuitpython- after projects/ is wrong, but I can't find where this is set (on RTD?, in a file?)
it's not the rtd slug
slender iron
its in the subproject settings
tulip sleet
aha
slender iron
it can be hard to change because those settings tend to crash the server
tulip sleet
yes, I am getting irregular 502's, but I did succeed in making it a subjproject
slender iron
I've had better luck url hacking to avoid the giant list
tulip sleet
snagged it; I"ll bookmark the edit URL as a sample; tnx
slender iron
๐
ionic elk
@slender iron all set
slender iron
k, looking
ionic elk
@slender iron want me to merge or is there anything else we're waiting on?
ionic elk
k
ruby atlas
serene warren
Shop Bot indicates that two hours ago, it was in stock (11).
idle owl
@serene warren There was no notification sent out. 17 were put in stock. There will be more in tomorrow. Keep an eye out here as well - sometimes we post here before that notification goes out.
serene warren
I await with anticipation... Thank you @idle owl
idle owl
You're welcome
slender iron
@tulip sleet I did realize we should add a wait to limit the number of advertisements
tulip sleet
@slender iron that's a good idea. I think what I'm seeing is that the event handlers have a param that is a stale object, either on the stack or in the heap. But I'm not sure that is the case. The event handler list gets reset sometimes but not all the time. Still trying to trace it. The stack traces I am seeing are weird
I might talk to you tomorrow about it
raven canopy
finally!...
redis-server.service loaded active running Advanced key-value store
rosie-rq-worker.service loaded active running RQ Worker For Rosie
note: if you're going to include systemd unit files in a distro package, please have them work out-of-the-box.
rugged blaze
Might want to add that the only valid VT100 commands ( \x1b[K for clear to end of line and \x1bnnnD for move cursor left nnn spaces ) to the doc https://circuitpython.readthedocs.io/en/4.x/shared-bindings/terminalio/Terminal.html
I could not figure out how to put an issue for that into Github. I had to hunt around in the source code to find this out.
lone axle
Would the circuitplayground library be expected to work as-is with the CPX+displayio firmware? I'm having some trouble importing it, but I'm not sure if it's really expected to work
tulip sleet
@lone axle it is frozen in, so it doesn't need to be in your filesystem. Are you getting memory errors?
lone axle
I got an error when I try to import it:
Adafruit CircuitPython 5.0.0-beta.4 on 2020-01-22; Adafruit CircuitPlayground Express with displayio with samd21g18
>>> from adafruit_circuitplayground import cp
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
File "adafruit_circuitplayground/__init__.py", line 29, in <module>
File "adafruit_circuitplayground/express.py", line 49, in <module>
File "adafruit_circuitplayground/circuit_playground_base.py", line 54, in <module>
ImportError: no module named 'gamepad'
but I did include the library in my lib folder
tulip sleet
that is ok, lib/ comes after .frozen in sys.path
but i'll check this
ok, this is a problem; gamepad was added to the lib, is turned off in the build for space reasons. I'll make an issue.
gamepad is a native module
lone axle
I ended up trying an older build as well:
Adafruit CircuitPython 5.0.0-alpha.5 on 2019-11-04; Adafruit CircuitPlayground Express with displayio with samd21g18
on that one I was able to import it without gamepad issue, but I did have to use a slightly different import
slender iron
what is gamepad used for?
lone axle
I peeked for a second and it looked like it was holding the A and B buttons
self.gamepad = gamepad.GamePad(self._a, self._b)
tulip sleet
try this - it's approximately beta 4 with gamepad included
lone axle
This one works. Thank you ๐
slender iron
What do folks think about this as a #circuitpython-dev2020 recap post? ```Wow, 2020 has seen CircuitPython growing even faster than 2019 already. We had many more #CircuitPython2020 responses than last year, 5.0.0 is just around the corner, we have over 200 libraries, over 100 boards and the website just got a face lift! Thank you to every one for helping make that happen.
With #CircuitPython2020 we asked you to post your vision for CircuitPython in 2020 and so many of you posted. Kattni, in particular, pointed out that we should do something similar throughout the year. It is a great idea! So, as you use and explore CircuitPython this year, post your thoughts about the future of CircuitPython with the #circuitpython2020 just as we requested earlier this month. We'll leave the email open and blog your posts as we see them. If you have a specific feature in mind or want to see what we're working on then check out the CircuitPython issues here.
Here is a list of all the posts so far:```
(with pictures and links of course)
lone axle
Weird. The blurb from the bot transposed some of the hex color digits.
umbral dagger
Is the information at https://learn.adafruit.com/circuitpython-essentials/circuitpython-storage still valid for swicth the flash fs to writeable?
lone axle
It was valid last time I tried, but that would have been back in the 3.X days.
onyx hinge
4.x documentation for storage.remount: https://circuitpython.readthedocs.io/en/4.x/shared-bindings/storage/__init__.html
lone axle
Ooooo nifty, disable_concurrent_write_protection
umbral dagger
This is what I have in boot.py:
import digitalio
import storage
switch = digitalio.DigitalInOut(board.D9)
switch.direction = digitalio.Direction.INPUT
switch.pull = digitalio.Pull.UP
# If the switch is pressed CircuitPython can write to the drive
storage.remount('/', switch.value)
Seems either to not get run, or remount isn't working. In code it's always readonly.
Even on a power-on disconnected from USB (battery powered)
lone axle
It does need to be a fresh power up, instead of the reset button iirc so it's good if you are using battery and unplugging / replugging. It might be worth trying to open a txt file and write something to it from inside boot.py and/or turn on or off the built-in LED (if you have one) to figure out if boot.py is running or not.
umbral dagger
Yes. eject, disconnect USB, attach battery based power, and powerup.
I'm using a neopixel as a status indicator, currently it's color is set based on whether or not the fs is readonly. Always comes up readonly.
lone axle
Have you confirmed somehow that switch.value is changing with your physical switch?
solar whale
@umbral dagger have you verified the default state of the the pin? IIRC it will be True at power on if the button is not pressed.
umbral dagger
I've run the same code (not the remount) in the REPL and it reads the pin as expected. So yes.
solar whale
so are you pressing the button at power on or leaving it unpressed?
umbral dagger
Pressing it in hopes of having a writeable fs ๐ฆ
solar whale
waht MCU are you using?
umbral dagger
Beyond that, I've put storage.remount('/', False) in boot.py with the same results.
SAMD51 (Feather M4 Express)
solar whale
and what version of CP?
umbral dagger
Adafruit CircuitPython 5.0.0-beta.4 on 2020-01-22; Adafruit Feather M4 Express with samd51j19
solar whale
ok -- I'll try to reproduce
I just tried it and switch.value is defaulting to True and the drive remains writable by via CIRCUITPY
but grounding D9 -- it comes up as read-only via CIRCUITPY - switch.value is False
so it appears tp work as advertised.
In my case it is connected via USB ....
@umbral dagger I ran your original code ```import board
import digitalio
import storage
switch = digitalio.DigitalInOut(board.D9)
switch.direction = digitalio.Direction.INPUT
switch.pull = digitalio.Pull.UP
If the switch is pressed CircuitPython can write to the drive
storage.remount('/', switch.value)```
umbral dagger
Hmmm... here's my code in code.py: try: with open(settings.LOG_FILE, 'w') as fp: # first, get rid of any previous log fp.write('Log\r\n') system.indicate(colours.RED) import file_handler logger.addHandler(file_handler.FileHandler(settings.LOG_FILE)) except OSError as e: system.indicate(colours.GREEN) print(e) print('Logging to serial')
It always throws [Errno 30] Read-only filesystem
solar whale
with D9 grounded ```Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 5.0.0-beta.4-95-g0b761f60e on 2020-01-30; Adafruit Feather M4 Express with samd51j19
fp = open("junk.txt","w")
fp.write('test\r\n')
6
the did fp.close() opened D9 and rebooted ```jerryneedell@Ubuntu-Macmini:~/projects/feather_m4_express$ cat /media/jerryneedell/CIRCUITPY/junk.txt
test
are you sure your button is "normally open" ?? grasping at straws...
umbral dagger
Yes. The button works fine, reading the button from the REPL works fine.
solar whale
odd...
umbral dagger
With the switch removed and D9 jumpered to ground it still behaves the same.
umbral dagger
@slender iron I added print('D9: {0}'.format(switch.value)) but nothing different in boot_out.txt
umbral dagger
I emptied boou_out.txt, booted on battery power, after that boot_out.txt contains: Adafruit CircuitPython 5.0.0-beta.4 on 2020-01-22; Adafruit Feather M4 Express w ith samd51j19 settings.py output:
slender iron
its always been that way
umbral dagger
What about all the wifi projects that use a settings.py that gets imported
which is what I'm doing
slender iron
isn't it named secrets.py?
slender iron
๐
umbral dagger
renamed it to config.py and things are behaving better. Thanks.
Where's that documented?
settings is a pretty tempting filename for ... um ... well... settings
What about having it be an error to have multiple of competing files (boot.py/settings.py, code.py/main.py/...)
slender iron
one spot is here: https://github.com/adafruit/circuitpython#behavior
I'd be ok removing settings.py as an option
manic glacierBOT
onyx hinge
@slender iron @ruby atlas just saw the review request, will hop on that now.
slender iron
thanks @onyx hinge
lone axle
It would appear there are a few more CLUE boards in inventory in the shop if anyone missed them yesterday and wants one. Probably going to go quick again though I would imagine.
modern wing
Just a friendly note -- clue boards are back in stock ๐ 75 of them....wait, hold on....74. There. 74 are in stock ๐
@lone axle Beat me to it ๐
solar whale
got mine! 70 left
modern wing
Seriously, Clue is what got me to take a look at the Micro:Bit ecosystem. The original Micro:Bit, although perfectly appropriate for the target market, just didn't entice me -- but toss on BLE with a ridiculously sharp IPS screen? Why hello. ๐
lone axle
I loved playing with the microbit, but I did always wish for it to work like the Circuit Python devices where we could put the py file directly onto it rather than having to compile to hex or whatever it was first.
stuck elbow
there is a number of microbit-compatible boards
I have one with esp32 on it and 5x5 neopixel matrix somewhere in my drawer
bpi:bit
modern wing
I nabbed the new octagon robotics chassis. Something about making a BLE Clue with micro:bit-compatible Crickit....
timber mango
Nabbed a Clue a few minutes ago.๐
pearl notch
Hi all. Iโm looking for something fun to show at a Kโ8 science fair tonight with multiple Circuit Playground Bluefruits. @idle owl, you mentioned a project using 4 CPBs. Ideas, anyone?
Some kind of multiplayer game, perhaps.
onyx hinge
I just imagined playing the 'simon' color sequence game but with 4 CPBs that aren't even wired together. not helpful for getting something going for tonight though.
pearl notch
With part of it running on my Mac showing on a large monitor.
I made such a thing for Raspberry Pi with a nice webapp.
Kids played it at the same science fair last year and loved it. Iโm just learning BLE, so this may need to be simple if I am to program it in the next couple of hours.
lone axle
@pearl notch Here are a few projects that are using multiple CPB's, not sure if any of them are specifically 4 though. https://learn.adafruit.com/hide-n-seek-bluefruit-ornament | https://learn.adafruit.com/circuit-playground-bluefruit-neopixel-animation-and-color-remote-control | https://learn.adafruit.com/circuit-playground-bluefruit-quick-draw-duo
pearl notch
Quick Draw Duo might be just the thing. Thanks!
onyx hinge
@lone axle you beat me to the punch, I was about to share the quick draw link
onyx hinge
@tulip sleet what that merged based on it passing Actions, or should I let someone with a board verify the added pins function as expected? I assume Rev C is what is going out as alpha?
lone axle
@pearl notch the Bluefruit Playground iOS (and now Community Edition for Android) also provide a nice way to show off the board. Here is a learn guide for the iOS one (Android works basically the same) https://learn.adafruit.com/bluefruit-playground-app
Doesn't really involve multiple CPB devices though, it's 1 CPB "paired" with the phone at a time
pearl notch
Still, cool to show. Thanks!
I installed โableโ on the Mac, which talks to the examples programs on a CPB.
lone axle
If you end up using the Android one, and run into any issues feel free to ping me in here. I made the Android one and am happy to help if you run into any trouble.
pearl notch
Excellent. Good to know you. Iโm running it on Android.
tulip sleet
@onyx hinge right, rev c is alpha, and that PR will be reviewed by limor.
onyx hinge
okie
pearl notch
Hah! Quick Draw Duo is awesome!
solar whale
looking forward to trying a clue on one of these https://www.adafruit.com/product/4442
idle owl
@onyx hinge I have someone lined up to test the PR you merged.
I'll have them test it anyway. No worries.
onyx hinge
@idle owl Thanks! I hope I didn't step on toes too hard.
modern wing
@solar whale I was thinking of getting one of those myself, but I figured I'd run with Crickit first -- plus that buggy bolts onto the microbit, whereas the Crickit is more easily accessible.
idle owl
@lone axle The VL53L0X PR was merged - please test it anyway once you have the hardware.
@onyx hinge It's on us, we should have commented on the PR.
@lone axle Moving forward, let's make sure we comment on PRs we have plans for.
solar whale
@modern wing but itโs so cute ๐
onyx hinge
@lone axle testing beats just looking at the code onscreen ๐ ๐
modern wing
It is! @solar whale --- and inexpensive since it's all inclusive of the chassis, motors, wheels, etc.
lone axle
@idle owl will do. I'll go through my list tonight and make comments on all of them indicating that I'll be testing soon.
idle owl
Excellent.
Thanks!
@tidal kiln Do you have a minute to talk Micro:Bit/CLUE? I'm doing the pinouts and saw you did the initial guide of the Micro:Bit and thought you might be able to help.
tidal kiln
@idle owl sure
idle owl
@tidal kiln I don't know how to describe the pads. I kind of fudged my way through explaining the edge connector.
same with 3V and GND
idle owl
You didn't get into it much, it was much more of a broad stroke deal
tidal kiln
could just do same? or do you want more detail?
tidal kiln
are you trying to document all the small ones as well?
idle owl
Not yet.
Which is to say not unless Limor asks me to.
I'm unsure whether she wants that level of detail or "Micro:Bit compatible edge connector" is enough to get people started.
tidal kiln
i'd think that would be enough
i probably borrow the more detailed pinout from somewhere:
https://learn.adafruit.com/bbc-micro-bit-lesson-number-0/edge-connector
but could make one for clue if needed
otherwise there's just the 5 big pads, which you can explain more simply
idle owl
right.
idle owl
I guess I wanted a little more than "Can be an input or an output"
but I don't know what they do beyond that.
Never did anything with micro:bit
tidal kiln
i'd have to do some looking around to figure out the other functions for the pins, on clue
idle owl
Eh. I'll deal with it then. I figured if you had some knowledge already, I'd take it
Limor usually fixes up the pinouts pages anyway, but I try to have something for her to work with
tidal kiln
you're wanting something more like "0 - is digital 0, but is also SCL, PWM3, ADC12, LASER_ENABLE_123, etc." ?
idle owl
Maybe? Except it's different for Arduino and CircuitPython I assume. Bleh. Not sure if there's a middle ground somewhere.
tidal kiln
should be the same, maybe different nomenclature
but it all comes down to what the specific pin on the nRF can mux to
tidal kiln
ah. cause "alpha"?
idle owl
yeah., not sure to what extent.
tidal kiln
me either. but possible if something gets rerouted.
idle owl
That feeling when you run an upgrade command and it's doing way more than you expected it to and you're pretty sure your computer is going to explode on the other side. ๐คฆ
my SSL is broken. trying to fix it.
and now it's doing a million other things first.
modern wing
....imagine the same upgrade anxiety, but on an enterprise-class NAS array. You know it shouldn't take that long.
And then it completes....and you give it a side-eye.... "Ok buddy, how'd you drop the ball? What went wrong?"
idle owl
Yep. it removed something I was using. which means my dev environment is probably entirely borked right now.
:sigh:
ModuleNotFoundError: No module named 'pip'
modern wing
I'm sorry, for what it's worth.
modern wing
I found this on stack overflow: sudo apt-get install python3-pip
https://stackoverflow.com/questions/18363022/importerror-no-module-named-pip
idle owl
Also Discord isn't sending messages very quickly.
Aaaaand it didn't just bork the env I was in. It's borked my entire machine.
I'm on mac.
modern wing
And i think it just doubled my message.
idle owl
And it's sending duplicate messages. Lovely.
tidal kiln
FWIW, stolen from arduino nrf core for clue:
D0 is P0.04 (GPIO D0 / AIN2 / UART RX)
D1 is P0.05 (GPIO D1 / AIN3 / UART TX)
D2 is P0.03 (GPIO D2 / AIN4)
I haven't had Time Machine hooked up in a week. So I can't even restore.
A sense of dread is slowly setting in.
ok it looks like maybe pip still exists outside the venv.
I am now both dreading and confused.
It's like it upgraded things inside the venv maybe?.... I thought brew had nothing to do with envs though
raven canopy
venv [temporarily] changes environment variables, so that could have affected brew?
raven canopy
if its inside the venv, any "damage" should be confined there.
raven canopy
does brew have things like apt/pip's list or show? that's a good way to see how/where things are installed...
idle owl
yeah brew list is a thing.
idle owl
@raven canopy New venv is working. so I guess delete the other one and hope everything was contained.
lime trellis
is there a technical reason why CircuitPython_Register library never implemented SPI? I find the library super useful for I2C but don't know if @slender iron saw something that scared him away from finishing off the SPI side of things
raven canopy
smashing the old venv should be fine. but check that things are happy outside of the venvs...
idle owl
@lime trellis It's on the list, we simply haven't gotten to it.
Limor plans to do it eventually.
I'm unaware of a technical reason, but that doesn't mean there isn't one.
idle owl
@lime trellis Sounds great.
lime trellis
another question @idle owl. I have a handful of working-for-my-needs-but-likely-buggy circuitpython libraries on my github. Is there somewhere else I should list them so people can use them? I wouldn't say they're ready for primetime and I don't have the bandwidth to polish them right now
idle owl
You're welcome to submit them to the community bundle, but they'll have to be cookiecuttered and pass CI and so on... Hmm. I'm not sure past that. Ooh. You could file an issue on the CircuitPython repo, add a list of links to it, and then close it. And you can always continue to update it even if it's closed.
Then people searching CircuitPython issues for whether a driver exists or if someone is making it, will find your list.
lime trellis
that's a good idea. maybe there should be a more general list of half-baked drivers that people could contribute to?
idle owl
I'm thinking the same thing. But I'm not sure where it would go. Maybe a .md file on the community bundle.
Have to come up with a non-confusing name for the file/list though.
lime trellis
that'd work... then we could PR to to the .md. would that show up on the googles, though?
idle owl
Eventually, I assume.
lime trellis
I've been following the adafruit nomenclature for my driver repo names. Are you thinking that might make them look too official?
idle owl
I don't know of a way to force it, but I imagine if people search for it enough they'll find it.
As long as it doesn't say Adafruit_ on the beginning, you're welcome to call them CircuitPython_Foo.
lime trellis
cool cool. sounds good. I'll keep an eye out for that list on the community bundle
"works in progress" maybe?
idle owl
yeah that's pretty clear
prime flower
@lime trellis FWIW: I usually notice repos which are unpolished by a note at the top of their README file (sometimes they even have useful checkboxes on there for what's left for someone to pick up, I've contributed to one of those)
lime trellis
yeah good call- I do make sure to have something like this at the top:
prime flower
I like the emoji
example that I was thinking about: https://github.com/tzapu/WiFiManager#wishlist
prime flower
@lime trellis totally unrelated and more related to radio, but have you done any circuitpython work with the SX1262/SX1262?
idle owl
@lime trellis PR away! https://github.com/adafruit/CircuitPython_Community_Bundle/blob/master/works_in_progress.md Also please tweak the wording if you have something better. I tossed that off rather quickly.
lime trellis
@prime flower LITERALLY what got me off on this library organization tangent. I have one sitting in my hand and I'm looking at the datasheet realizing it has the same command structure that I built for the SX1280
prime flower
AH, sweet. Yeah, it uses a different iface from the SX127x
lime trellis
yeah unfortunately :/
prime flower
ttn has a decent amount of discussions (https://www.thethingsnetwork.org/forum/t/sx1262-applications/28685/3) about it. I'm into the < footprint and < power draw
lime trellis
know of a CP driver? haha
prime flower
I could probably look at semtech's reference code, but it's below low priority rn for me
What's higher priority would be doing an abstracted loramanager iface for circuitpython
lime trellis
yeah I met a guy with intimate knowledge of semtech die that told me its crazy they even sell the 127x given the performance of the 126x
prime flower
loramanager(rfm9x) / loramanager(sx1280) then loramanager.send
lime trellis
that would be very handy
ping me when you get the sx1280 part and I'll see if I can help
prime flower
I'll order one up from a tindie seller once CNY is over, havent seen a module yet but I haven't searched hard.
lime trellis
I gotchu! hang on lemme find the repo
I shoehorned it into the hoperf module footprint: https://github.com/maholli/sx1280-breakout
let me know if you want a bare board and I can see if I have any lying around. There's commercial modules as well, but with different footprints grrr
idle owl
@lime trellis tag me on the PR please, so it doesn't get lost.
idle owl
You're welcome
@raven canopy do community bundle PRs show up on my lib PRs list?
Do the Adafruit bundle PRs show up, for that matter?
prime flower
oh sweet thanks maholli, bookmarked
raven canopy
community...hmm. let me look real quick. (i don't think so)
idle owl
@raven canopy If not, can we make that happen?
raven canopy
can do all things... well, maybe most. ๐
idle owl
Well, yeah...
raven canopy
community should be included. let me check list_repos() results real quick...
oh yeah. its not included.... search:Adafruit_CircuitPython isn't going to grab CircuitPython_Community. ๐คฆ
throw up an issue?
lime trellis
PR sent. Thanks again @idle owl . I'll be eagerly watching what people contribute
tulip sleet
@slender iron hi - I am looking at increasing the number of connections, and did a bunch of experiments about the cost of increasing each parameter for sd_ble_cfg_set(). One thing you did is increase hvn_tx_queue_size from 1 to 10, which has a substantial effect on the amount of RAM per conenction (like 5kB). In looking for guidance about this, I see in DevZone that they don't recommend increasing this explicitly but instead increasing the GAP event_length. Do you remember anything about this?
tulip sleet
i did write down what increasing each param costs in terms of bytes, and it will bein the comments
slender iron
@lime trellis I don't know of any technical reason why you couldn't do spi registers
@tulip sleet I wanted to have multiple notifications buffered
if you find it could be tuned better then thats ok
lime trellis
๐
slender iron
I also increased buffer sizes
tulip sleet
you mean there or elsewhere?
slender iron
I think in the init stuff
tulip sleet
i think the implication is that changing the event length will change the hvn_tx_queue_size, but it's not clear
slender iron
to the sd
tulip sleet
yah, I"m in that routine.
tulip sleet
did you see it go too slow
slender iron
I was email back and forth with maureen from nxp/zephyr yesterday picking her brain about it
would love to get off the SD
one thing I'd like to add for the sensor stuff is an optional limit to the number of advertisements
tulip sleet
you bet. They talk about increasing some #define in the SDK headers, but don't really explain what's going on. Anyway, each new connection is about 9kbytes, and adding extra roles costs about 600 to 1k bytes each depending on the role. if i reduce the hvn queue from 10 to 1, then each connection costs about 4k bytes instead of 9k bytes. So that's why I was asking.
i'll keep studying DevZone, etc.
slender iron
I may have run into it when I was playing with stuff
maybe 2 would be best because it'd buy us time to queue a subsequent notification?
tulip sleet
anyway, even with the currrent settings, we can fit 2 more connections in like 56-64kb (instead of the current 32kb for the sd)
slender iron
how many are you going for?
tulip sleet
i don't understand why the event length would affect the queue lenght, but i'll see how changing one and not the other affects the ram allocated
so we need to reserve 1 for workflow. Then we have stuff like HRM + cadence + speed (could be two devices) + talking to music service. That's 5 (4 in use for that, 1 reserved for workflow)
that's a lot, we could peel back one (use a combined cadence+speed sensor)
slender iron
the music service is likely the same as workflow though
if there are a bunch of peripheral connections we'll be at the mercy of the centrals' scheduling
tulip sleet
same connection? I didn't know whether they would be paralllel. and we wnat to bring the music service connection up and down during development, but leave the workflow connection up
slender iron
I'd assume they are both on a phone
tulip sleet
are we central or peripheral for music?
slender iron
peripheral because the phone initiates
tulip sleet
k, got it
slender iron
just like current time service
tulip sleet
so do you think 32kB more is too much? stack is currently 40kB, I think, which is a LOT
could prune that
i don't have a good intuition about this; ideally we set # of connections in boot.py
like you suggesetd, but I'm not gonna do that for 5.0.0
slender iron
how much do we have total?
slender iron
ya, and the imx rt 1011 is 128 with half as TCM
tulip sleet
that is going to be tight for larger programs
slender iron
yup
tulip sleet
high speed but not much ram, not the ideal combo
tulip sleet
yes, so 256kb -64kb for SD = 192kB - 40kB stack = 152kB heap + static RAM
maybe not so bad, and might be 60kB for SD, and stack could be 32kB or 24kB
slender iron
ya, I think that's ok
tulip sleet
i'll do a few more experiments
tulip sleet
that was arbitrary, I assume
tulip sleet
i'll see if they have a recommendation
also I don't know if central_role_count (currently 1) needs to be increased if you talk to multiple periphs or not. but that is only 600 bytes for each increment
ok, tnx for being a sounding board
slender iron
my guess would be yes
seems like its all just config for static allocations of everything
tulip sleet
each periph role increase is 1200-1800 bytes (it's not constant: a little weird); each central role increase is 650-1250. uuid table size is +16 bytes for each uuid (makes sense!) and attribute table size increases by 1k for each multiple of the default.
slender iron
oh! I have something to run by you
I'm debating whether we should use service + characteristic for each sensor value
like the app does now
or do a top level service with varying characteristics + descriptors
tulip sleet
hmmm...
slender iron
the sig version is characteristics + descriptors
tulip sleet
there are fewer objects and classes with fewer services
is it easy to determine if a characteristic is present now? If not i should be
slender iron
you can do hasattr
tulip sleet
could this be a single service with tons of characteristics, is this just for CPB or is it for sensor lab for many kinds of sensors
slender iron
many types of sensors
right, could be a single service with lots of chars
could be bad if it's all in one library
but likely easier to use
and can use our 16 bit service uuid
tulip sleet
yes, and maybe use some of the standard 16-bit uuids for various sensors
but suppose you have two, say accelerometers and want to read from both. how do you distinguish them and know their different characteristics?
tulip sleet
i just mean if they match nicely
slender iron
its not terrible now that I look at it
it depends a bit on whether we can to configure out of band or not
I'm not sure if using the standard buys us interoperability at all
tulip sleet
i don't care about that, really, I just care about smaller uuids
slender iron
I don't think that actually matters
tulip sleet
probably not
tulip sleet
still thinking how we handle duplicate characteristics; i'm not sure there are many real-life examples.
if you had a product with two accelerometers, you would have diff characteristic for each
slender iron
bbq thermometers ๐
tulip sleet
with multiple probes? I should look on the thermoworks webiste
tulip sleet
raven canopy
bbq therms are a win-win test. hardware works? you get yummy food as a reward! ๐
raven canopy
there are all sorts of DIY'd versions out there.
small victories are the best. i'm back to a working dev state on the RPi!
rosie-admin@ubuntu:~$ curl http://127.0.0.1:4812/status -w "%{http_code}\n"
[["Host","127.0.0.1:4812"],["User-Agent","curl/7.65.3"],["Accept","*/*"]]
401
rosie-admin@ubuntu:~$ curl -H "Authorization: Signature foobar" http://127.0.0.1:4812/status -w "%{http_code}\n"
{"busy":false,"job_count":0,"node_name":"ubuntu"}
200
rosie-admin@ubuntu:~$ curl -H "Authorization: Signature foobar" http://127.0.0.1:4812/run-test -X POST -w "%{http_code}\n"
{"message":"Endpoint requires valid json payload."}
406
@slender iron btw these are various DevZone articles on the queue size:
https://devzone.nordicsemi.com/f/nordic-q-a/52372/correct-way-to-config-hvn_tx_queue_size
https://devzone.nordicsemi.com/f/nordic-q-a/35447/increase-hvn_tx_queue_size-to-maximize-throughput https://devzone.nordicsemi.com/f/nordic-q-a/34022/optimizing-throughput-with-multiple-central-links-and-1-peripheral-link
i don't necessarily expect you to read all those ๐
slender iron
I turned on the connect event extension thing too
meager fog
@fading solstice hey mrc - we're doing an audit of the adafruit github members and you're still on there. it seems you're takin' a break from reviews and PRs, so we're going to turn you into a 'external collaborator' for now, but the moment you want to come back as a member let us know and we can re-add you ๐
lime trellis
@tulip sleet I'm struggling to build CP with custom boards since you implemented common.template.ld. I keep getting something like this:
collect2: error: ld returned 1 exit status
actually, it's more commonly this:
/usr/bin/../lib/gcc/arm-none-eabi/7.3.1/../../../../arm-none-eabi/bin/ld:build-pycubedminiv01/common.ld:22: syntax error
collect2: error: ld returned 1 exit status
@lime trellis we are using the gcc 9 release; not sure if that would make a difference here. Make sure you are starting from a clean build. Could you upload the build-.../common.ld file here? That's the expanded template file
yes, upload that common.ld file and I'll take a look
the board files changed a lot for this PR, so try to make your board files match a similar board
mostly they got simpler
lime trellis
yep I have done matching to similar boards. I have this sneaky suspicion that I'm not using a valid CHIP_VARIANT. uploading common.ld now
tulip sleet
@lime trellis The only thing different on that line from other similar files is the 0x00080000/2
that should be ok
is your code in a repo? I could try building it with the latest toolchain
lime trellis
not a public one. hmm let me zip and send it to you?
tulip sleet
ok
lime trellis
@tulip sleet
I appreciate the help. meanwhile I'm going to compare the old .ld file I was using to the common.ld
lime trellis
thank you. I'm thrashing with it as well. Will keep you updated
tulip sleet
@lime trellis it seems to dislike the /2 , which is defined in ports/atmel-samd/mpconfigport.h. I changed it to >> 1 and it worked (but it didn't fit). That was a guess for boards without external flash. You can define your own value for CIRCUITPY_INTERNAL_FLASH_FILESYSTEM_SIZE in your mpconfigboard.h.
it's supposed to handle all C operators, not sure what the issue is
lime trellis
oh wow. I was chasing down an entirely different path ๐คฃ thanks for solving that!
tulip sleet
@lime trellis, no, wait that didn't help; hold on
lime trellis
something is up here... I are you using some sort of regex for the common.template? I added a #define CALIBRATE_CRYSTALLESS and things started overflowing
tulip sleet
it doesn't like / or << , but I changed it to (128*1024) and it worked
you mean it's reporting not enough space?
paste the error
lime trellis
it's reported <0 for everything
tulip sleet
?
tulip sleet
common.template.ld uses Python Template to fill things in
tulip sleet
what is your new mpconfigboard.h?
lime trellis
lots and lots of this:
./mpconfigport.h:184:6: note: in expansion of macro 'CIRCUITPY_INTERNAL_FLASH_FILESYSTEM_START_ADDR'
(CIRCUITPY_INTERNAL_FLASH_FILESYSTEM_START_ADDR - CIRCUITPY_FIRMWARE_START_ADDR)
^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
./mpconfigport.h:211:5: note: in expansion of macro 'CIRCUITPY_FIRMWARE_SIZE'
#if CIRCUITPY_FIRMWARE_SIZE < 0
is the error
tulip sleet
what size did you give for CIRCUITPY_INTERNAL_FLASH_FILESYSTEM_SIZE?
those are sanity checks when one of the values is too big
leaving no room for the firmware
lime trellis
I took out that define to model other boards. this is the mpconfigboard.h:
#define MICROPY_HW_BOARD_NAME "PyCubedMini"
#define MICROPY_HW_MCU_NAME "samd51G19"
#define CIRCUITPY_MCU_FAMILY samd51
#define MICROPY_HW_NEOPIXEL (&pin_PB22)
#define MICROPY_PORT_A (PORT_PA24 | PORT_PA25)
#define MICROPY_PORT_B (0)
#define MICROPY_PORT_C (0)
#define MICROPY_PORT_D (0)
#define CALIBRATE_CRYSTALLESS 1
#define BOARD_HAS_CRYSTAL 0
// #define BOARD_FLASH_SIZE (FLASH_SIZE - 0x4000 - 0x0100000)
#define DEFAULT_I2C_BUS_SCL (&pin_PA16)
#define DEFAULT_I2C_BUS_SDA (&pin_PA17)
#define DEFAULT_SPI_BUS_SCK (&pin_PA09)
#define DEFAULT_SPI_BUS_MOSI (&pin_PA08)
#define DEFAULT_SPI_BUS_MISO (&pin_PA10)
#define IGNORE_PIN_PA24 1
#define IGNORE_PIN_PA25 1
NVMCTRL_ROW_SIZE is not defined for SAMD51's. This is kind of a pathological case. I need to fix mpconfigport.h
manic glacierBOT
tulip sleet
do this:
#define CALIBRATE_CRYSTALLESS (0)
#define CIRCUITPY_INTERNAL_FLASH_FILESYSTEM_SIZE (128*1024)
yep I did something similar and it just finished building
whew!!
do we need to define the NVMCTRL_ROW_SIZE based on internal vs external flash?
tulip sleet
no, the calibrate crystalless stuff stores a calibration value in a bit of internal flash. on SAMD21, NVMCTRL_ROW_SIZE (minimum size that can be erased) is 256 bytes. On SAMD51, it's 8192 bytes, and it's not called that.
lime trellis
ooo gotcha. ha- what an edge case
tulip sleet
I thought there were some other SAMD51 boards that don't have external flash, but there's something different in their builds that is not triggering this
lime trellis
yeah I have no issue building my board with external flash
tulip sleet
yeah, kicksat-sprite should have the /2 problem, i don't see why it's different
lime trellis
I have a couple of other custom boards I haven't submitted PRs for that are working fine.
tulip sleet
oh, maybe the LENGTH in that .ld line is negative after computation
or something like that
building kicksat-sprite now
lime trellis
kicksat-sprite wont have the crystalless edge-case, though,
tulip sleet
@lime trellis ok, the /2 problem IS due to gcc7 vs gcc9 toolchain. I mistakenly was using the gcc7 toolchain and hit the same bug as you. Switching to gcc9, and it works!
https://developer.arm.com/tools-and-software/open-source-software/developer-tools/gnu-toolchain/gnu-rm/downloads ; unpack and put the .../bin directory on your PATH
lime trellis
ah-ha! will do. Thanks for the help Dan
lime trellis
๐
indigo wedge
too bad that there's no native usb, could've been a nice CPY target ๐ https://www.nxp.com/products/wireless/bluetooth-low-energy/qn9090-30t-bluetooth-low-energy-mcu-with-armcortex-m4-cpu-energy-efficiency-analog-and-digital-peripherals-and-nfc-tag-option:QN9090-30?&tid=vanQN9090-30
onyx hinge
good (belated) morning
@slender iron I think we all imagined that there would always be a pretty long interval between needing to load audio DMA buffers, but there's an exception! A wave file's last buffer can be arbitrarily short, so if you loop it the time between loading the DMA of the last buffer to the first looped buffer can be small. In fact, the looping audio sample for the light saber project is a worst case, with just 1 sample in its last buffer. The glitches MAY be more severe or at least more frequent in 5.0 than 4.1, probably due to background tasks only happening once per ms. Any quick thoughts before I go in my own direction to work on it? (I don't know what that direction is yet)
slender iron
@onyx hinge ah! interesting! skip the last bit?
onyx hinge
@slender iron i.e., if number of samples in last block is less than X, just drop it on the floor? That seems implementable. Do you think anybody would notice that the last 1.5ms of their sound isn't played? It could increase popping if it cuts off the last "taper to 0". I could pass down a new flag that says that the sample will be played in looping mode, and only do it when both these things are the case (short block and looping)
tulip sleet
@onyx hinge an alternate fix for this is to tell people to make their looping samples be a multiple of block size. That would solve the problem for this project. The original sample could also be divided up into the largest equal-sized blocks that were possible (i.e. allow the DMA buffers be variable size), but that's a lot of code to solve a problem that might not be that important to solve
onyx hinge
Is "make looping sounds a multiple of 512 samples" (** for simplicity, it could be 128 or 256 depending on details) something makers of audio will get? If so, I'm all for it + some documentation ๐
"... or use audiomixer"
Registers in DMAC CHANNEL[0]:
CHCTRLA: 0x00203B00 Channel n Control A
CHCTRLB: 0x00 Channel n Control B
CHPRILVL: 0x00 Channel n Priority Level
CHEVCTRL: 0x80 Channel n Event Control
CHINTENCLR: 0x00 Channel n Interrupt Enable Clear
CHINTENSET: 0x00 Channel n Interrupt Enable Set
CHINTFLAG: 0x02 Channel n Interrupt Flag Status and Clear
CHSTATUS: 0x00 Channel n Status
``` finally set this up, it's pretty neat. thanks @tulip sleetcan I write to a register this way, or do I have to do it via casting memory addresses?
tulip sleet
i think I checked this and you can only look at registers
learning to make good looping samples is more work than most people realize, to avoid clicks etc. Once they have to learn that make them a certain length is just another editing step, so I don't think that's terrible. If we document "you can loop anything but if you want it to be smooth make it a multiple of this size", I think that's ok
onyx hinge
in this case I think the wave files came directly from archive.org from a liberally licensed sample collection. it was designed to loop, but to be a particular number of samples wrong
(unless someone DID try to design it to be an exact number of samples, but was "off by 1" I suppose...!?)
onyx hinge
๐ฎ and then using the laser cutter at the hackspace. probably dropping back in to hack on WaveFile some more this afternoon.
tulip sleet
@slender iron re
many types of sensors
right, could be a single service with lots of chars
could be bad if it's all in one library
but likely easier to use
and can use our 16 bit service uuid
You could monkey-patch the base service when importing more characteristics
manic glacierBOT
lone sandal
slender iron
@tulip sleet ya, I'm not sure still. will finish up the advertising method first
tulip sleet
@slender iron I could make a release today. I'm still fine-tuning the increased number of connections, but that's the last thing I know of
but maybe we should not release on Friday ๐ ?
slender iron
I'm fine waiting
I don't know of anything super urgent
your fixes are nice and solid
my subclass fix may find some edge cases though
tulip sleet
the only strong reason is if we want to release the HRM guide today
prob fine to wait; we can test the increased connections build against multiple sensors before we release it
slender iron
๐
idle owl
@slender iron @tulip sleet Fresh 5.x CP installs now have an empty lib folder and a "hello world" code.py? Or am I misremembering that.
tulip sleet
they should
idle owl
ok
tulip sleet
but only if there was no CIRCUITPY beforehand. It won't add those files to an existing filesystem
or if you erase_filesystem()
idle owl
Ok. Hmph. Kind of complicates explaining install, but I get it.
Thanks
meh. Glossing over that I guess.
Otherwise it's a lot of "if this is the first time, but only if cp wasn't already installed, but if it's already been installed, or if blah blah."
solar whale
How do you put the UF2 bootloader onto the feather stm32f405?
slender iron
@solar whale I assume the same way you load circuitpython without it
the bootloader that is used currently is in ROM
(iMX RT works the same way)
solar whale
Ok. There is a make flash that calls gdb. I was wondering if a j-link or something was needed.
But It sounds like I can use dfu-util
slender iron
ya, that would be my expectation
solar whale
Thanks. I canโt try until next week anyway. On the road..
slender iron
np ๐
@prime flower @meager fog is there a way to post data to an IO feed with a unique id in case it gets posted twice?
ionic elk
Is there a good image of the Blinka snake I can use for our Boston Circuitpython Meetup?
raven canopy
@ionic elk here is the art pack that Phil shared a long time ago... https://www.dropbox.com/sh/l6tp9ym5nf8h5v9/AAB7r58OXyr0VA82eWsFLhJ0a/blinka?dl=0&subfolder_nav_tracking=1
split urchin
holy crap that's actually really good lol
raven canopy
also, i can confirm that GIMP will open them if you don't have Illustrator available. ๐
stuck elbow
Inkscape
stuck elbow
btw, that blinka in that artpack has a lot of unnecessary nodes
Here is one that is a bit more optimized (but with a thicker outline, for a PCB)
prime flower
@slender iron Each data point has a unique identifier. (https://io.adafruit.com/api/docs/#create-data)
onyx hinge
whee, I think it's time to learn about touchscreen on circuitpython.
prime flower
@slender iron But, you can only specify the 'value' metadata, not the 'identifier', I believe that's assigned on the server side...I'll ask justin
prime flower
ID is assigned by the server
slender iron
@prime flower I'm thinking about having multiple listening nodes that could report the same broadcast message. I can do it by having two feeds for it now
it'd also be cool to report discontinuities in a graph
half sedge
@raven canopy Am I right in saying that all of those logo have been done by Phil? I remember an "Ask an Engineer" where he was talking with Guru from Pimoroni about logo, and I kind of remember Phil was the author of those logo. Is that right?
tulip sleet
there is an in-house artist
raven canopy
hehe. i'm not at all qualified for that answer... ๐
half sedge
So Phil is a fan of logo and did appreciate the one of Guru, but maybe not the author. Thanks.
tulip sleet
He may have roughed it out or did some photoshopping on it, etc. The finals are done by the artist.
oh, wait are you talkign about logos or Logo language??
half sedge
I have a question about old vs new BLE product and CircuitPython product. I am a bit confused. In the past there were BT product with serial interface and AT protocol that were maybe targeted to Arduino kind of board. I am talking about Bluefruit kind of product. And now we have those nRF52840 microprocessor at the center of some CP board.
Talking about Logos/graphics like the blinka.
tulip sleet
logo: ok, I'm not misunderstanding
onyx hinge
https://learn.adafruit.com/adafruit-pyportal/pyportal-circuitpython-setup huh is there a reason the guide calls for adafruit_cursorcontrol? On my pynt, importing it just errors, "No module named 'gamepadshift'".
half sedge
So in the past there was Adafruit BLE friend, the UART version, the SPI version. And that was like Airlift to me.
tulip sleet
there are some products that are basically BLE coprocessors you can talk to over serial or SPI. Then we had an nRF52832 Feather that has an Arduino library for doing BLE. But that chip does not have enough RAM or flash to support CPy adequately, and it doesn't have native USB
half sedge
And there are all those serial encapsulation that were developped to control board, like to transmit button, color, ... (from your phone or from another board).
And that was "replicated" in CircuitPython.
tulip sleet
right, we developed an ad hoc protocol over Nordic UART Service that's implemented in the Bluefruit app
half sedge
So today, the recommendation would be to use nRF52840 if you want to do CircuitPython.
prime flower
@slender iron for feature suggestions, post up over here as you think of them https://forums.adafruit.com/viewtopic.php?f=56&t=139746 and I'll file them on the IO feature tracker
half sedge
I mean there is no point in going for a coprocessor.
tulip sleet
@jeperl I think that may be a copy pasta bug
right, the '840 is hefty enough not to be used just as a co-processor. There are advantages to a co-processor, in terms of task scheduling and simplicity, but we were able to use the nRF libraries which hide the time-slicing going on underneath
onyx hinge
@tulip sleet I'll enter a feedback
half sedge
Thanks @tulip sleet I am not going to talk about Adafruit BLE Friend, and focus my little time to what can be done with the '840 as a core.
It is a bit assymetrical between the Wifi situation that now require a co-processor (while there was ESP32) and BLE that can be done with the '840.
tulip sleet
tnx - the emphasis is on nRF52840 going forward
ESP32 was not a good target for CPy because it doesn't have native USB. It also has a difficult architecture, and it has taken a while for the doc and software to mature.
Next-gen ESP32 has native usb
half sedge
I suggested in the CircuitPython2020 the use if Nina-FW to do BLE. It is the same fw used for wifi, but maybe that does not make sense from a developpement point of view.
tulip sleet
i am not sure if it can be simultaneous wifi and BLE
half sedge
No, it was said to me "not simultaniously".
tulip sleet
it is also a cost q: SAMD51+ESP32 vs just the nRF52840
and board real-estate consideration
half sedge
Yeah, sure.
I think the combo that I like is Feather '840 + Airlift. That could be the central node to connect BLE device to the internet...
tulip sleet
nRF has a next-gen chip they just introduced: https://www.nordicsemi.com/Products/Low-power-short-range-wireless/nRF5340, but things are early for that. It is not super-fast like the new NXP chips
tulip sleet
it uses Zephyr instead of the SoftDevice libraries the earlier chips use
half sedge
Thank you all. I am going to continue focussing on what I know and structuring my talk.
tulip sleet
@half sedge There is a standard serial protocol for BLE coprocessors called HCI. Several different mfrs implement it. Same general idea as Nina
prime flower
I wonder if they're going to support LoRa next, the LoRa stack for Zephyr is good
tulip sleet
but it's a 2.4GHz radio, do people do lora at 2.4G?
prime flower
Ultra-long comms yeah, semtech has a chip for it https://www.semtech.com/products/wireless-rf/24-ghz-transceivers/sx1280
tulip sleet
@timber mango Hope FOSDEM is great! Thank you for speaking about our stuff there.
I just looked at the schedule and didn't realize it was this weekend
half sedge
It's only 20 minutes. ๐ without any in between gap to connect the laptop and everything. So I most likely spend too much time on this. I prefer to manadge expectation. We will see later how good or bad it was. And I have 50 Blinka Stickers to distribute to anybody comming to me with any interest.
idle owl
@stuck elbow I have a quick question for you if you're around.
orchid basin
stuck elbow
@idle owl I am now
idle owl
Hey. If there were to be a Circuit Playground like library for CLUE, would you want the were_pressed feature in it?
stuck elbow
I suppose it would make sense to mimic the micro:bit libraries
idle owl
Is that feature in the micro:bit libs?
stuck elbow
stuck elbow
@idle owl I wonder if it would make sense to organize the library the same way too
idle owl
@stuck elbow Same way as which, the micro:bit lib?
ionic elk
@tulip sleet do you know if this line in a debugger indicates some failure of TinyUSB? tud_cdc_n_connected (itf=itf@entry=0 '\000') at ../../lib/tinyusb/src/device/usbd.h:62
tulip sleet
@ionic elk I don't know if entry=0 is a legitimate value or not, sorry.
idle owl
There's a number of differences. And the main point of this lib is to expose all the sensor capabilities and such.
manic glacierBOT
ionic elk
@gentle bronze do you need to add something to TinyUSB for it to support the STM32F407? It's virtually identical to the F405. nvm you've got an example for it and everything. hmm.
tulip sleet
@gilded cradle are you around? you build working CPy for CLUE, but master is not workign for me (display init problems)
old smelt
Okay - how about a Friday afternoon Hug Report for the whole CP development gang?
I'm currently writing some Arduino code to control a SparkFun Tsunami Super WAV Trigger over and I'm surprised by how arduous I find the process of compiling and loading for every minor tweak!!
Where's my REPL?!!
Thanks for making life easy with CircuitPython!
meager fog
@indigo wedge hihi i brought up a 1011 feather -USB works (ROM bootloader thingy) and JLink finds it
whats my next step ๐
tulip sleet
CircuitPython running on clue with display support; PR soon
indigo wedge
@meager fog Darn, my boards are coming Monday ๐ Depends how much time you have, if you wanna code that kinda works and you wanna tinker then I'd advice to try tinyuf2 https://github.com/arturo182/tinyuf2 otherwise the uf2 branch of tinyusb should just work but it's not pretty https://github.com/arturo182/tinyusb/tree/uf2 (build for feather_mimxrt1011). As for CPY, I haven't tested the Feathers with https://github.com/adafruit/circuitpython/pull/2532 merged so unsure if that works, you can always check out the tree just before that commit and that code should work, you need to make a new board definition for the board cause it uses different pins than my Feather. Or just wait for Monday and I'll do all when I get my boards ๐
lone axle
@pastel panther is it safe to say this issue would apply to the LIS3MDL library as well? https://github.com/adafruit/Adafruit_CircuitPython_LIS2MDL/issues/2
meager fog
@lone axle there would be one example and it would work with any magnetometer/accel combo
the exmaple would not live in this library - it would live in a guide
lone axle
I see, Thank you.
tulip sleet
@idle owl @trim elm @gray mantle et al here should be a working build for CLUE, same as PR above:
trim elm
@tulip sleet It works! Thank you!
tulip sleet
yay!
onyx hinge
early to bed / early to rise / was meant for those old fashioned types / who don't use / CircuitPython
[h/t http://burma-shave.org/jingles/1943/early_to_bed]
lone axle
I am working on some example code for the TFT Gizmo. https://github.com/FoamyGuy/Gizmo_Thermometer_Example. If anyone is interested and has a moment to take a quick look and/or try it out, any feedback is welcome.
river quest
here's the DRAFT of the upcoming โPython for microcontrollersโ newsletter that ships out tuesday at 11am ET via adafruitdaily.com - please send any links, news, events and more via an issue/PR, or @ us or really any thing ๐ we'll get it added! https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2020-02-04-draft.md
short phoenix
Is there any way to wirelessly code onto a feather? Or does it have to all be done by connecting it to a computer
main meteor
I suspect there are ways, even if one of them is just hooking a Bluetooth UART to the serial pins.
onyx hinge
I'm not aware of anything standard in circuitpython for doing it. micropython can do it as part of its "web repl", I hear; but circuitpython doesn't presently have a web repl.
bright aspen
@onyx hinge @slender iron I saw something about dropping samples in looping audio. That can be awful to one of my projects. I want to create some pure tones, so if my buffer has to be a multiple of both the wavelength and 512 memory might seem very small. I did not catch the context, so maybe it doesn't really apply to me or I can avoid the problem.
Oh, that use case does not read from a file.
wanton fiber
trying to port the Blinka implementation for the MCP2221A, i think i've spotted a substantial bug but don't really know how to exercise it from python: https://github.com/adafruit/Adafruit_Blinka/blob/master/src/adafruit_blinka/microcontroller/mcp2221/mcp2221.py
theres no way _i2c_write can send more than 60 bytes, and also it doesnt support repeated-start
(even though it is attempting to be able to send more than 60 bytes)
manic glacierBOT
tulip sleet
@short phoenix @onyx hinge @slender iron developed initial strawman support for editing over BLE in the current version of CircuitPython, and started a very simple app. We have plans to flesh that out in the future.
half sedge
The demo part of my presentation went wrong. I could not connect my laptop to the projection system. And I had to start without my slide.
But I had a lot of positive feedback.
stuck elbow
@half sedge at fosdem?
half sedge
@stuck elbow yes IoT track. There was someone from Samsung doing Augmented reality with MicroPython...
But the demo failed due to WiFi issue...
stuck elbow
that's why I'm a huge fan of cables :P
tidal kiln
@wanton fiber curious about MCP2221A bug you mention in Blinka. please ping me when you can. thanks.
obsidian compass
Folks from CircuitPython's day, Delhi used CPX board to make a USB Rubber Ducky type keystroke injector which can parse basic ducky scripts : https://www.hackster.io/p5g41tmlx/rubber-python-f0d023
idle owl
@half sedge Glad to hear you received a lot of positive feedback! It's good that you persevered through the technical difficulties.
short phoenix
@tulip sleet keep me updated then on that app!
idle owl
Not being as good with RGB hex as I am with tuples, I'm wondering why display_text and ostensibly displayio accept only hex. And whether there's a reason for it, or an easy way to make it take tuples as well.
It apparently also takes byte arrays. This helps me even less. ๐
wanton fiber
what do you consider a tuple? its a trivial exercise to break apart an RGB value (expressed in hex if you choose) to a format of your choice. it would be my pleasure to assist, seeing as im using a board with your name on it at this very instant
or is this a rhetorical complaint
idle owl
๐
onyx hinge
@idle owl It would be nice if more knowledge about neopixel would carry over to displayio Palette. but I think that you can use bytes() with a tuple to get something that you and Palette will both understand
idle owl
Oi, giant emoji
onyx hinge
b'\xff\xff\xff'
It was not a rhetorical complaint. ๐
@wanton fiber Nice about the board.
@onyx hinge Odd but interesting.
I'm trying to add some things to a library and I do not expect a majority of those who will use it to be familiar with hex colors.
But at the moment, that or byte arrays is the only option.
The change would have to go into Palette though as far as I can tell.
So into core CircuitPython.
as display_text uses palette to set the color of the text.
wanton fiber
is it at least 24-bit RGB encoding? 1-byte R, G, B components?
(as opposed to 16-bit 565)
idle owl
The value argument represents a color, and can be from 0x000000 to 0xFFFFFF (to represent an RGB value). Value can be an int, bytes (3 bytes (RGB) or 4 bytes (RGB + pad byte)), or bytearray.```I'm not sure of the answer to that question.
wanton fiber
yeah, 24-bit encoding, is the simpler (more accessible) of the two at least
each component R, G, and B is represented with an entire byte (0x00 - 0xFF) packed together RRGGBB
onyx hinge
@idle owl yes I also think a change in core would be necessary to accept a tuple directly.
idle owl
Which is way outside my wheelhouse.
onyx hinge
and also introduces a dependency for your guide
idle owl
The other dependency is already merged. ๐
onyx hinge
would you feel introducing but not explaining a function to convert (r,g,b) to the hex value?
idle owl
And it wouldn't be the first time I've had code that relied on other things.
Bleh. I guess I'd rather tell people to go google hex colors.
The point is to keep this code super simple.
onyx hinge
there are some very nice lists of hex colors
It's funny how different people run into the same thing at nearly the same time, I tried to use the "color wheel" effect on a displayio palette just yesterday
wanton fiber
thats a fun function to learn how it works ๐
very clever
and equally maddening when it doesnt work
onyx hinge
@idle owl ^^ we can do it in the core with just 2 lines and a little punctuation
so this works for me now label.palette[1] = wheel(w)
afk, it's nice enough out for a walk (60F according to the computer!)
half sedge
@idle owl @onyx hinge About color and palette representation, there is the format expected by displayio and all the format supported by FancyLED.
I have not investigated, but it would be great to make be compatible.
I wanted to build a palette gradiant for displayio using FancyLED. Is that what you are working on?
half sedge
There was one presentation at Fosdem'20 that might be interesting for adafruit: https://fosdem.org/2020/schedule/event/iottinygo/
The demo were impressive and used a lot of Adafruit board, but with running Go code compiled with tinygo.
I remember: (1) a PyBadge (2) a PyPortal (3) a ItsyBitsyM4 into a LED cube ... That last one was impressive because it was driving a lot of LED without a FPGA.
onyx hinge
@idle owl I'll fix the PR so it builds, and then there will be one attached to the "checks" in about 20-25 minutes
idle owl
@onyx hinge Oh right! I forgot about the artifacts. Excellent.
onyx hinge
I think this format is different than what FancyLED uses, which seems to be a custom type with red, green, and blue float values. This works with tuples of integers that are in the range 0..255.
a CRGB.pack() value should be what DisplayIO needs though
onyx hinge
@idle owl https://github.com/adafruit/circuitpython/actions/runs/34002989 is slow to show the build artifacts so I'll attach what I built locally.
idle owl
@onyx hinge Works!
onyx hinge
@idle owl yay, thanks for checking. seems to make pewpewm4 not fit, though, so it'll need further finesseing
finessing ?
idle owl
Apparently. :/
onyx hinge
apparently "finessing". thanks english ๐
main meteor
I'd look at lines 12-13 of secrets.py.
serene warren
Line 8 is about the Pyportal and I have copied and recopied the files.
I copied line 13 right out of the guide with the name issued by referenced OpenWeatherMap site. I even backed up to the original New York, US.
How do I "look" at an MPY file?
crimson ferry
Hopefully it exists somewhere as a .py file and you can look at that. Github for CircuitPython libraries, for example.
serene warren
How should the SD card be formatted? In the Weather Guide
onyx hinge
Normally secrets py will be a file you edit yourself. It needs to be filled with info about your WiFi and adafruit io accounts (and maybe other things depending on the project)
serene warren
Thank you @onyx hinge . I think I have a handle on the secrets file. It worked earlier to log me through my network and all (even initially had the weather for New York, US albeit in a small window on the Titano). It was when I downloaded the new Code.py (295 lines) and ran it that things went south. I'm sure it's on my end, no one else seems to be having issues.
tulip sleet
@slender iron I wrote draft release notes for the next beta so we could release it quickly when we decide we're ready.
onyx hinge
I investigated "shoco" and "smaz" as possible alternatives to huffman encoding of translated strings. Both would add complication to the build process, and (without actually integrating them) it doesn't look as though they would have a memory size savings. "smaz" is tuned only for english and never released its compression catalog making script. "shoco" does have a script that will tune it for your input corpus, but (code + tables) size seems to be clearly bigger than huffman.
e.g., // 10431 bytes worth of translations compressed from huffman, vs 16907 bytes just for the same corpus compressed by "shoco"
main meteor
Good research, but pretty much the expected (if not hoped-for) outcome.
slender iron
@onyx hinge take a look at how jimmo is doing it for micropython: https://github.com/micropython/micropython/pull/5168
Hey all, just a reminder that the meeting is tomorrow, Monday, as usual at 11am Pacific / 2pm Eastern here in the Discord voice channel. Notes doc is here and in a pinned message. We have another US holiday two weeks from tomorrow so expect it to be shifted then as well. <@&356864093652516868> https://docs.google.com/document/d/16ssd4xtTLyBV_5dmoOSjXIWLtJrESWVIxJ5BIfoUfYA/edit
manic glacierBOT
onyx hinge
@slender iron thanks for the link. I independently came up with a dictionary scheme. Mine just uses the 32 most common digrams (best result out of several values I tested on zh_Latn_pinyin) and gets back ~400 bytes flash. I could get it to PR status this week, or I could hold on to it for when we "really need it". let me know what you think
onyx hinge
interesting, it seems that on nRF when a pin is configured as a PWM output but it's not actively being DMA'd, it is left floating rather than being driven with the last PWM duty cycle.
onyx hinge
@idle owl I don't have eagle here, can you make me a pdf or png schematic of the pam8302a breakout board? https://github.com/adafruit/Adafruit-PAM8302-Mono-Amplifier-PCB
idle owl
@onyx hinge Yep.
onyx hinge
I appreciate it!
idle owl
@onyx hinge Good?
onyx hinge
yes thank you!
idle owl
@tulip sleet We did this in the Circuit Playground library for touch: python def _touch(self, i): if not isinstance(self._touches[i], touchio.TouchIn): # First time referenced. Get the pin from the slot for this touch # and replace it with a TouchIn object for the pin. self._touches[i] = touchio.TouchIn(self._touches[i]) self._touches[i].threshold += self._touch_threshold_adjustment return self._touches[i].value
With the list of touch pins in init. Comment in init says it saves a little on RAM. Is there any point in doing it this way in a lib strictly meant for a nRF MCU?
Or should I handle each touch pin in its own method?
There are three.
tulip sleet
you still have to not init them in advance, because you'll grab the pins otherwise. But no, not necessary for nRF
idle owl
Right, init them when they are called.
Is there any reason not to do it that way on nRF?
tulip sleet
no, and it makes it easier to understand if the libraries copy each other's styles.
idle owl
Ok.
tulip sleet
in the long run, there might even be a base class that's common to CP and CLUE
idle owl
Names will be different.
For the touch pins.
There is some crossover though.
Not, I think, enough to justify that though.
But depends on where things go I guess.
tulip sleet
yeah. I would say copy/pasting the code is fine, though, because it's already been debugged
onyx hinge
afk until the meeting
slender iron
@onyx hinge kicad can import eagle files
onyx hinge
@slender iron I'll try that next time
crimson ferry
Is there a resource to get started with WebSerial? Can't find anything in Learn guides or Adafruit Github.
lone axle
@crimson ferry I'm not sure if they've published any yet. There is a decent intro here though: https://codelabs.developers.google.com/codelabs/web-serial/#0
They are using a microbit with espruino firmware to demo it, but should apply to Cicruit Python devices as well I believe
onyx hinge
I don't think so
idle owl
nice
ionic elk
I'm coming down with something this morning so I don't think I can make the meeting ๐คข but I've added my hug reports/status updates for text only
Hopefully will be back up at full speed tomorrow
slender iron
feel better @ionic elk !
idle owl
@tulip sleet I'd like this to go in to the beta if possible as well: https://github.com/adafruit/circuitpython/pull/2574
I'll use it in the CLUE lib if it goes in.
onyx hinge
sterile bronze
lurking, just a general hug for all the great people doing great work
