#circuitpython-dev
onyx hinge
onyx hinge
Howdy folks and particularly <@&356864093652516868> -- we'll be having the meeting in about 65 minutes from now! Please take this time to add any notes to the notes doc: https://docs.google.com/document/d/1S1W7c3Rq2PIV4TVrRahtz3Em5cfJpEEPi6sSyW_mk5U/edit?usp=sharing
tulip sleet
@lone axle all these "unpin sphnix" PR's -- it's tested, is that right, so you are just looking for approvals?
for a non-controversial change, you could merge without approval
slender iron
I was just starting to approve and merge them
tulip sleet
assuming you have the privs
lone axle
<@382939733107408897> all these "unpin sphnix" PR's -- it's tested, is that righ...
That is correct, they're tested. It's the same change that I pushed with Adabot patch, it's just that these repos had different configuration and couldn't push automatically like the others.
lone axle
assuming you have the privs
I don't have privilage for it on these ones. Merge button is disabled saying it needs an Approval, and the approv button is disabled for me saying PR author cannot approve.
I am saving a list of the repos that were like this though. In the long run I think it would be great to have their permission configuration changed to match the rest of the others so that the patches can apply to all of them without the manual PR ones.
There are 6 more that I'll finish up after the meeting, I set it down for lunch before the meeting.
turbid radish
Please tell folks about the newsletter - it's free top subscribe, no ads or spam
to
midnight ember
a lot of new PR authors, very nice to see. 🙌
solar whale
👋
gilded cradle
You're welcome
silver tapir
The HEIF encoder is a bit complex, but it would be a nice alternative format. Jpeg is a bit old :p
(but it's kinda like vfat, it will never die...)
slender iron
could be a beta too
I definitely think a release this week would be good
I think the idf update and the web workflow changes are unreleased
tulip sleet
i certainly can do one sooner rather than later.
slender iron
thank you!
tulip sleet
I will merge from 8.2.x and maybe update frozen
lone axle
ability to update WIFI credentials via on-display controls would be awesome!
slender iron
midnight ember
That's a neat project DGlaude! Would like to see a demo of that.
midnight ember
ability to update WIFI credentials via on-display controls would be awesome!
I am willing to accept help. There aren't many touchscreen related projects to pull inspiration from. Most of them are for the Pyportal but I don't have a Pyportal.
tulip sleet
@mortal kernel do you still have a Ventura machine you could make comparison traces on? I saw delayed writes of some kind when using the initial cluster-number-only traces, but it was not clear if the "delays" were unrelated to the original write transaction or not. Thanks.
midnight ember
Been seeing a lot of Mac related questions in discord lately, seems like a big problem. Good luck to the Devs!
mortal kernel
<@849815081251766292> do you still have a Ventura machine you could make compari...
I've got a pre-Ventura machine available. The issue has a pointer to my trace code. I can refine it into a pull. How would like that to look?
tulip sleet
I've got a pre-Ventura machine available. The issue has a pointer to my trace co...
it's on my short list to look at your fork, hope to do that today or tonight
midnight ember
@gilded cradle All your efforts with the Qualia library is greatly appreciated. There are a lot of new displays and they keep coming out with new ones.
silver tapir
Please sidetrack :p
midnight ember
ESP BLE 🙌
gilded cradle
Thanks @midnight ember
mortal kernel
it's on my short list to look at your fork, hope to do that today or tonight
Cool. The MacOS version I have available is Big Sur, 11.7.8. Hope that's OK.
midnight ember
Take care of your mom. ❤️ Been praying for you and your family.
Welcome @short tendon ! First meeting.
tulip sleet
Cool. The MacOS version I have available is Big Sur, 11.7.8. Hope that's OK.
i could run your same tests on a Ventura machine. I have an Intel Macbook Air that can't go to Sonoma anyway. (It's actually rolled back further at the moment due to us trying to figure out when FTDI and CP21xx drivers were added.)
could you put your exact tests in the issue? or could be in the PR, though I'm not sure where, maybe tests/circuitpython-manual
mortal kernel
could you put your exact tests in the issue? or could be in the PR, though I'm n...
Not sure what you mean. The test is just a one-liner in terminal that writes a one block file of random data.
It's in the issue.
tulip sleet
ah ok, I saw that line. I thought you were maybe copying files of various sizes
i had some multi-file copies that generated cp errors
mortal kernel
Multi-file copies are good for hitting secondary effects, but tend to muddy diagnosis.
tulip sleet
I am going to blog the issue in the Adafruit blog and also point to the current "best" workaround (czei's remount script). Will also post on Mastodon. This is all to increase exposure, and also make more people aware and maybe report it.
mortal kernel
iOS results so far are a relief. The >8MB results are disappointing because my fake FAT16 won't be a viable workaround.
midnight ember
tulip sleet
iOS results so far are a relief. The >8MB results are disappointing because my f...
do iOS internals track macOS closely or vice versa? Do you think this might might be an external "flush" process that has been turned off or adjusted?
wraith crow
There is a private _free_socket https://github.com/adafruit/circuitpython/issues/6502
midnight ember
I used that and it did work
slender iron
sockets also have finalizers
gilded cradle
Thanks for hosting Jeff
midnight ember
but moving the session outside the while true loop made the biggest difference and _free_socket became unneeded at that point.
mortal kernel
do iOS internals track macOS closely or vice versa? Do you think this might migh...
Although they are separate development "trains" they do merge selectively. I'm leaning toward a bug in auto-mounting on Sonoma.
lone axle
Thanks for running the meeting Jeff. Hope everyone has a nice week!
midnight ember
Thank you for hosting Jepler 🤗
onyx hinge
👋
do good work everybody
I think the other part of "make gc 'do the work' of collecting unused sockets" would be that a failed socket() call that returns the equivalent of an EMFILE error would gc.collect() and try a second time before failing for real
midnight ember
oh i had them spread all over the place 😅 because of the early 8.0beta with leaked sockets issue which was eventually fixed. so i thought by 8.2.8 that would have been cleaned up, so i removed them all, and it appears it wasn't... at least not with the way I was attempting to iterate through sessions.
@short tendon fyi that multi API script hasn't worked in a while. last time i updated it was before Twitter removed API access. most of those API's likely no longer work. part of updating the API examples to be 9.0 ready is going back through them all to ensure they work. Like the Twitch API example I found was broken so I'm sure there will be more.
onyx hinge
Here is the notes document for next Monday’s CircuitPython Weekly Meeting. It is at the normal time of 11am Pacific / 2pm US Eastern here on Discord. Add your hug reports and status updates to the document before the meeting. If you are unable to attend but would still like to contribute, feel free to add your notes and we’ll read them off during the meeting. Hope to see you there! <@&356864093652516868> https://docs.google.com/document/d/1jtCjgV5NExzjBZxgPpE8dY_D42g4DAJv6w24TaARTRw/edit?usp=sharing
empty salmon
I wanted to circle back on a question I posted recently regarding USB VID:PID
(I would link it but as mentioned, it’s very difficult to find ‘human’ content in this channel)
I am designing an education board which will ship with CircuitPython and which uses the RP2040. The Adafruit guide indicates people in my situation need to contact the appropriate manufacturer for getting an assigned PID.
I reached out to Raspberry Pi (via their online form) on Thursday and was granted a PID today.
… so the process works 👍🏼🤩
short tendon
<@1152454697614069811> fyi that multi API script hasn't worked in a while. last...
That's okay. I know tons of API endpoints. Any that fail I'll just update to use something random
slender iron
anyone worried about me requiring a directory exist and be empty for a mount point?
that way it'll be listed when listing the parent directory
stuck elbow
that's how posix does it, except for being empty
slender iron
if it isn't empty then the files aren't listed when something else is mounted right?
mortal kernel
if it isn't empty then the files aren't listed when something else is mounted ri...
Usually a mount will hide any files in the mount point directory.
slender iron
👍
mortal kernel
Linux has a "union" mount that can be used with pseudo filesystems with a notion of upper and lower directories, but I've never used it.
slender iron
I haven't either
onyx hinge
@tulip sleet it's possible that the USB descriptor configuration stuff can be made somewhat less complicated now that we have host_malloc...
the core C code that is
tulip sleet
<@329766224093249548> it's possible that the USB descriptor configuration stuff ...
Scott already simplified (removed) the hoisting onto the stack and back after boot.py. But yes, it could use dynamic allocation. It can be revisited in the longer term. Too many other things to work on right now.
gilded cradle
@onyx hinge I have some questions regarding the 3.7" 240x960 bar display. Is that one you got working?
onyx hinge
@gilded cradle I don't remember. I can go look at what I have. I think one of them was 240x960, that sounds familiar.
gilded cradle
Ok thanks, I can't get the overscan_left + width to be > 320, but timing says it should be 360.
So last 40 pixels are cut off
onyx hinge
I have a screen marked "HWTL31601G02-04" but it's about 3.3" and I have a screen marked "BL-HD458002" but it's about 4.8" -- so I may not have that one
gilded cradle
The 4.8" one is actually 4.58", hence the hd458 and I got that working. The one I have that is causing trouble is marked HD371001C40.
So it doesn't sound like you have it.
onyx hinge
what i have
gilded cradle
Ok, I think the TL032 one is already done as well.
I'll check with limor and see if she has some arduino code or something I can go off of. Thanks @onyx hinge.
onyx hinge
@gilded cradle this product? https://www.adafruit.com/product/5799
gilded cradle
yeah
onyx hinge
pretty sure I don't have one. should I order one?
gilded cradle
pretty sure I don't have one. should I order one?
If you want, but I'm pretty sure I'll figure it out before it gets to you.
onyx hinge
I hope so too
gilded cradle
🙂
tidal kiln
does busio.I2C/SPI/UART.unlock() ever throw an exception?
tulip sleet
does `busio.I2C/SPI/UART.unlock()` ever throw an exception?
it only would if the object were deinited
also there is no lock/unlock or UART, since it's not a shared bus
tidal kiln
oops. yah. was just naming all the busio things.
tidal kiln
and that's a generic behavior, right? (attempting to use a deinitd object)
tulip sleet
right, those classes check all over the place for deinited objets
tidal kiln
for more context, asking in relation to this issue:
https://github.com/adafruit/Adafruit_Blinka/issues/748
tidal kiln
but Blinka should try to match
tulip sleet
yes
tulip sleet
I think we wanted to make unlock() be idempotent. So, yes, Blinka should not complain.
tulip sleet
let me check Espressif, because it uses a semaphore
tidal kiln
cool. thanks. so fix for Blinka should be trivial.
tulip sleet
i think so
onyx hinge
thanks for the merges dan
Jpeg decoding is not quite right
but it's clearly something!
devout jolt
Jpeg decoding is not quite right
Ship it! 😄
onyx hinge
Now it's perfect
manic glacierBOT
Something's wrong with the doc build; I'll get that sorted soon.
Testing file:
Testing code:
import jpegio
import displayio
import adafruit_pycamera
import numpy
cam = adafruit_pycamera.PyCamera()
j = jpegio.JpegDecoder()
with open("test.jpg", "rb") as f: b = f.read()
w, h = j.decode(b, None)
print(w, h)
bm = displayio.Bitmap(w, h, 65535)
j.decode(b, bm)
arr = ulab.nu...jpegio sounds like arpeggio
slender iron
@onyx hinge I have a Q about background tasks when you have a chance. On reset, the whole callback structure is cleared to zero. The webworkflow only sets it function once so if it is queued during a reset, then it stops working
Should I change it to only clear next?
or have web workflow set func again?
seems to me that any CB off the python heap should be untouched
onyx hinge
@slender iron trying to piece together my train of thought. is this background_callback_reset?
onyx hinge
and changing it for heap vs non-heap objects was at 64460107531ee110c809edec7823a557e1455b49
slender iron
yup
onyx hinge
jepler@bert:~/src/circuitpython$ git grep '^static background_callback_t'
ports/cxd56/supervisor/port.c:static background_callback_t callback;
supervisor/shared/status_bar.c:static background_callback_t status_bar_background_cb;
supervisor/shared/tick.c:static background_callback_t tick_callback;
supervisor/shared/usb/usb.c:static background_callback_t usb_callback;
supervisor/shared/workflow.c:static background_callback_t workflow_background_cb = {NULL, NULL};
```Here are the non-heap background_callback objects I can spot easilyso this could be affecting a number of things
slender iron
haha, I was just going to look at that
onyx hinge
So background_callback_reset should .. reset all GC-based ones but leave all non-GC based ones?
slender iron
ya, I think so
onyx hinge
is the memset just in the wrong spot?
slender iron
I assume a non-heap one will use a non-heap function and data
onyx hinge
diff --git a/supervisor/shared/background_callback.c b/supervisor/shared/background_callback.c
index cceda7d413..68a174e806 100644
--- a/supervisor/shared/background_callback.c
+++ b/supervisor/shared/background_callback.c
@@ -130,7 +130,5 @@ void background_callback_reset() {
*previous_next = cb;
previous_next = &cb->next;
- cb->next = NULL;
new_tail = cb;
- } else {
memset(cb, 0, sizeof(*cb));
}
why would we need the memset at all?
onyx hinge
I'm not sure; it was part of the original design is all.
it helps make things GC'able but this is only called when zapping the heap
(right?)
onyx hinge
well test with -memset too and see how it goes? audio and keypad would be good to check, one or the other
onyx hinge
could check if the callback's data is heap and clear that too
diff --git a/supervisor/shared/background_callback.c b/supervisor/shared/background_callback.c
index cceda7d413..99170d6015 100644
--- a/supervisor/shared/background_callback.c
+++ b/supervisor/shared/background_callback.c
@@ -118,5 +118,5 @@ void background_callback_end_critical_section() {
-// Filter out queued callbacks if they are allocated on the heap.
+// Filter out queued callbacks before tearing down the heap
void background_callback_reset() {
background_callback_t *new_head = NULL;
@@ -127,11 +127,9 @@ void background_callback_reset() {
while (cb) {
background_callback_t *next = cb->next;
- if (gc_ptr_on_heap((void *)cb)) {
+ // unlink any callback that is either on the heap itself, or refers to heap data
+ if (gc_ptr_on_heap((void *)cb) || gc_ptr_on_heap((void*)cb->data)) {
*previous_next = cb;
previous_next = &cb->next;
- cb->next = NULL;
new_tail = cb;
- } else {
- memset(cb, 0, sizeof(*cb));
}
cb = next;
Yup, that's what I'm thinking
onyx hinge
oh but in case you unlink a callback that is off-heap, but its data is on heap you DO need to clear .. something
you need to clear prev? ```c
void PLACE_IN_ITCM(background_callback_add_core)(background_callback_t * cb) {
CALLBACK_CRITICAL_BEGIN;
if (cb->prev || callback_head == cb) {
I'd assume the owner of it would reset the data
onyx hinge
diff --git a/supervisor/shared/background_callback.c b/supervisor/shared/background_callback.c
index cceda7d413..07d4461a7c 100644
--- a/supervisor/shared/background_callback.c
+++ b/supervisor/shared/background_callback.c
@@ -118,5 +118,5 @@ void background_callback_end_critical_section() {
-// Filter out queued callbacks if they are allocated on the heap.
+// Filter out queued callbacks before tearing down the heap
void background_callback_reset() {
background_callback_t *new_head = NULL;
@@ -127,11 +127,10 @@ void background_callback_reset() {
while (cb) {
background_callback_t *next = cb->next;
- if (gc_ptr_on_heap((void *)cb)) {
+ // unlink any callback that is either on the heap itself, or refers to heap data
+ if (gc_ptr_on_heap((void *)cb) || gc_ptr_on_heap((void*)cb->data)) {
*previous_next = cb;
previous_next = &cb->next;
- cb->next = NULL;
+ cb->prev = NULL; // invariant for un-queued callbacks
new_tail = cb;
- } else {
- memset(cb, 0, sizeof(*cb));
}
cb = next;
are you going to test with it? if that doesn't work we should probably go to video and see what we can figure out together. I'll be around for a couple hours.
slender iron
ya, I'll test this. I think it'll work
onyx hinge
now I'm looing at previous_next = &cb->next next to cb->next = NULL and I'm not sure this is a correct 'remove from linked list' operation.
I need pictures or something
slender iron
ya, I think the old code completely cleared it
well, maybe not. new_head is set via previous_next
I'm right there with you
// Unlink any callbacks that are allocated on the python heap or if they
// reference data on the python heap. The python heap will be disappear
// soon after this.
if (gc_ptr_on_heap((void *)cb) || gc_ptr_on_heap(cb->data)) {
cb->next = NULL;
cb->prev = NULL; // Used to indicate a callback isn't queued.
} else {
*previous_next = cb;
previous_next = &cb->next;
new_tail = cb;
}
// Filter out queued callbacks that refer to GC heap before tearing down the heap
void background_callback_reset() {
CALLBACK_CRITICAL_BEGIN;
background_callback_t *cb = (background_callback_t *)callback_head;
callback_head = NULL;
callback_tail = NULL;
while (cb) {
background_callback_t *next = cb->next;
// Set 'not on queue' invariant
cb->next = cb->prev = NULL;
if (!gc_ptr_on_heap((void *)cb) && gc_ptr_on_heap((void*)cb->data)) {
// This background task was queued and not on the GC heap,
// so re-enqueue it
background_callback_add_core(cb);
}
cb = next;
}
// Flag shouldn't be set here, but clear it anyway
in_background_callback = false;
CALLBACK_CRITICAL_END;
}
no that's not so good because background_callback_add_core also sets/clears CALLBACK_CRITICAL_END and has the side effect of calling port_wake_main_task
callback_add_core2? 🤣
slender iron
*previous_next = cb;
previous_next = &cb->next;
cb->prev = new_tail;
new_tail = cb;
- set next of the previous cb 2. set our next to be set 3. set our prev to the old tail 4. now we're the tail
thorny jay
That's a neat project DGlaude! Would like to see a demo of that.
Thanks to @onyx hinge for reading my notes, I felt I made it long and complicate but he did read that great.
DJDevon3: As already hinted here, I don't plan to go on Show and Tell with my doorbell project, because it end at 2AM (my time)... and pressing the doorbell button will wake up everybody (also I have 4 Pavlov's dogs that go check the entrance door when they hear the old doorbell).
Picture 1: This is my bodge wire job (the blob is some UV nail gel to secure the cable).
Picture 2: This is the central relay that open/close 4 separated circuit at the press of the main doorbell button, that way I can work various solutions with the peace of mind that some sound will be produced even if my code crash.
onyx hinge
background_callback_add_core wants to add at the end of the list, so that a callback that pathologically re-adds itself still progresses. I don't know that the order is important during reset.
@thorny jay UV nail gel has many uses indeed
https://circuitpython--8696.org.readthedocs.build/en/8696/shared-bindings/jpegio/index.html TIL that for pull request builds, readthedocs uses an entire temporary domain name!
gilded cradle
@onyx hinge after looking into the settings for that display, I think there is a bug somewhere, so maybe you should pick one up after all.
onyx hinge
@gilded cradle OK, I will. can you put what you know so far into an issue please?
gilded cradle
Sure. In CircuitPython?
onyx hinge
yes
gilded cradle
Ok, will do.
slender iron
@gilded cradle any data you'd like in the directory listing json? I'm changing it to include whether it is writable and free space
manic glacierBOT
gilded cradle
<@478616919721771019> any data you'd like in the directory listing json? I'm cha...
I presume you mean web workflow. Maybe something like number of files and folders. Perhaps total size.
slender iron
hrm, total number of files may be hard. total size is easy
onyx hinge
@gilded cradle let's eliminate overscan_left. what if you simply specify a framebuffer of 360 pixels wide?
gilded cradle
I tried that. Same result.
onyx hinge
what if you ask for 368 pixels?
and if that doesn't work, what about 384. I am wondering if there's a required "pixels are a multiple of N", where N might be 16 or 32.
onyx hinge
does that get you a stable display?
onyx hinge
cool. displayio will still think the width is too much, so I'll have to do .. something.
I can't find where in the esp-idf source code this "multiple of 16" error is actually being raised.
gilded cradle
I'll have to see if I can find something like that.
manic glacierBOT
example of wiring an encoder with circuitpython (this one also wires the "press in to click" function available on some encoders)
slender iron
I think we're defaulting new ESP file systems to extended
and not preventing their use with dual bank afterwards
onyx hinge
@gilded cradle adafruit_qualia_s3_rgb666/firmware.uf2 locally built from the code in https://github.com/adafruit/circuitpython/pull/8698 if you want to try it .. but I'll be AFK for the rest of the evening
slender iron
We are checking for extended with dualbank
its in shared-bindings
(I expected common-hal)
gilded cradle
Thanks @onyx hinge
onyx hinge
I'll actually try it tomorrow and get it fixed for real @gilded cradle
gilded cradle
Thanks @onyx hinge
manic glacierBOT
lone sandalBOT
onyx hinge
@gilded cradle I still don't have that display 'in hand' but I double-checked that I don't get an exception when setting up a display with ```
"width": 240,
"overscan_left": 120,
"height": 960,
I actually did grab the artifact when I tested, but I'll try again in case I did something wrong.
onyx hinge
OK.
FWIW if a is an int, then a / 16 in C is a lot like a // 16 in Python: it doesn't result in a float like a / 16 does in Python or Javascript.
gilded cradle
Ah ok. Well, tried again and it's working this time, so I'm not sure what happened the first time.
@onyx hinge ^
onyx hinge
woohoo thank you for re-testing!
gilded cradle
yw
onyx hinge
@gilded cradle so the bars show correctly and the displayio width of the panel is what it should be?
gilded cradle
Let me verify...
onyx hinge
(it prints a width of 240 here)
gilded cradle
yes
onyx hinge
thank you! your notes and testing were helpful
gilded cradle
Awesome. Thanks for fixing so quickly.
tulip sleet
@slender iron @onyx hinge I am making an 8.2.9 release. Anything to backport from main? I don't think so.
slender iron
not that I can think of
onyx hinge
nothing on my mind
slender iron
web workflow issues are improved on 9
onyx hinge
if you're doing a 9 release I wouldn't mind getitng the jpeg decoder in 🙂 I just marked it ready for review.
tulip sleet
I will do a 9 release soon. I was just going to ask about those pending PR's.
orchid basinBOT
slender iron
@onyx hinge I just replied on the flipper zero board def
0x400x is IDF defaults and are probably wrong for circuitpython
onyx hinge
oh dang, I thought it was OK to go in. I'm sorry.
slender iron
I know, we overlapped
tulip sleet
We can put it in as is and ask that they change it. Not sure it's worth reverting.
crimson ferry
does CP 9 now have everything from CP 8?
tulip sleet
no, i have to merge up
onyx hinge
@lone axle not sure who I should ask, but my addition of the pycamera library to the bundle seems to have gone wrong. My library got moved to the end of its list and with no description; the files in it don't seem to be in the bundle. https://github.com/adafruit/Adafruit_CircuitPython_Bundle/commit/f0a9f54ebbaf2d79b2d66f48155bbc6a01f01089
and something happened to another module but that's my fault and I know why ..
is it because I was missing ".git" on the URL?
lone axle
<@382939733107408897> not sure who I should ask, but my addition of the pycamera...
very odd, I don't think I've ever seen the automatic adabot update do anything like that before
lone axle
is it because I was missing ".git" on the URL?
Ahhh, yeah I think that is a good theory. The rest of them all do end in .git. Something could be receving an HTML page as a response when it's expcting some kind of git data.
onyx hinge
@lone axle I took the liberty of requesting your review
manic glacierBOT
The full code isn't updated for the new directory listing yet. The developer tools in your browser may have more info.
I'm not sure what to look for but the developer tools console simply displayed a couple status messages:
Load different workflow index.js:37
Initializing File Transfer Client... index.js:37
exceptions know the line numbers where they're generated, but in general... is the runtime self-aware about what line number is executing? it would be super-handy for safemode to document where it went bad
mortal kernel
exceptions know the line numbers where they're generated, but in general... is t...
Something that might be useful would be a "trace-back buffer". This would be a modestly-sized array that is treated as a ring buffer by the runtime, recording each line number as it is executed.
tulip sleet
exceptions know the line numbers where they're generated, but in general... is t...
The line number info is stored at least some of the time. It's suppressed by mpy-cross -O3.
crimson ferry
is it worth an issue for enhancement? are there other non-exception circumstances besides safemode when execution stops and the runtime would still be intact?
manic glacierBOT
tulip sleet
is it worth an issue for enhancement? are there other non-exception circumstance...
it's possible, yes. Related issue: https://github.com/adafruit/circuitpython/issues/1054. But reset_into_safe_mode() really needs to retrieve the info and then stash it somewhere it so we can recover it after a hard reset. Feel free to open an issue!
meager fog
@gilded cradle can you help @crude blaze with some questions on the tinydrm/fbtft overlay
gilded cradle
<@478616919721771019> can you help <@375455651050160130> with some questions on ...
Sure
crude blaze
hey @gilded cradle
Limor mentioned you had already created an overlay using the tinydrm ili9341 driver?
crude blaze
ok nvm actually looks like its already working 🙂
ah nope it was a lie, its actually loading the fb driver
crude blaze
with the tinydrm drivers available it seems to give me a white screen/does not init the controller for some reason
gilded cradle
hey <@478616919721771019>
Limor mentioned you had already created an overlay us...
Hi @crude blaze. I had not created a tinyDRM overlay. I had previously worked on an installer script that installed a MIPI driver that somebody else had made here https://github.com/adafruit/Raspberry-Pi-Installer-Scripts/blob/main/adafruit-pitft-mipi.py and there was talk of somebody having already created tinyDRM drivers here https://github.com/raspberrypi/bookworm-feedback/issues/130
crude blaze
ah I see! thanks for the links, will take a look
gilded cradle
ah I see! thanks for the links, will take a look
you're welcome
empty salmon
Destroy display[0] or Not?
I see several CircuitPython boards with an integrated display. They create their display in board_init() and it’s available as board.DISPLAY within CircuitPython.
Some firmware also has board_deinit() which will release the display if the user code calls displayio.release_displays().
Most CircuitPython tutorials (and troubleshooting suggestions) recommend calling displayio.release_displays() early in their code.
The problem is there appears to be no way to re-initialize the integrated display without power cycling the board.
- Is there a way for a board to re-initialize the integrated display?
- Should boards with integrated displays ignore
board_deinit()?
stuck elbow
you can re-initialize it by using the python libraries for the given displays
the only reason you would call release_displays on a board with a built-in display is if you wanted to initialize it with your own code
empty salmon
The problem I see (and have encountered) is that tutorials often say to release_displays and then the user has no clue why their code stops working with the integrated display.
A search of this discord amplifies this issue. It has been confusing and troublesome for both board developers and end-user CircuitPython coders.
stuck elbow
you call release_displays as part of initializing a display in python
for boards with built-in displays you don't do it
because you never initialize the display in your code
empty salmon
I understand the logic.
I’m saying, the situation causes problems for both board developers and end-users.
Unless there is a valid reason, it would seem - at initial blush - that the board should not deinit the integrated display.
stuck elbow
how would you reinitialize the display then?
empty salmon
if the integrated display is not de-initialized then it would always be available as board.DISPLAY
stuck elbow
I will give you an example. I have a tile-and-sprite engine called Stage that I use for games. It's much simpler than displayio (and faster thanks to that), and it doesn't have software rotation of displays. For the MeowBit, the board_init initializes the display up-side-down, and uses displayio's software rotation to make it look right. In the mewobit port of Stage, the initialization file releases the displays, and initializes the display with correct orientation, so that Stage works correctly. If your change was added, this would no longer work.
There may be other reasons why people might need to use a python library for a built-in display.
besides, having a command that does nothing would only be more confusing in the long run
empty salmon
Rotation is an interesting point as it is “usage” specific. This would also be true for any other parameters which are only available during initialization. (BTW: some initialization parameters would benefit form being available after initialization but that becomes a whole other topic).
stuck elbow
it's not just rotation
there are framebuffer-based display drivers that don't use displayio
empty salmon
The only current path may be to have a re-init capability of the integrated display.
stuck elbow
you might want to use gifio directly, skipping displayio
there is a lot of reasons why you might want to disable displayio
empty salmon
Yes. Which is why there should be an intuitive documented way for a user to get back board.DISPLAY
currently, there is not user-friendly message and no codeable solution
stuck elbow
the board_init is not just for displays
empty salmon
I understand. I’m saying, if the end user has a well documented coding method which can make board.DISPLAY stop working, it seems intuitive there should be a coding method for getting it back.
The problem is rooted in the prolific advice to use displayio.remove_displays() as a catchall troubleshooting step.
stuck elbow
prolific?
you only ever use release_displays when you are initializing a display, and then you have a method of gettingit back right there
literally on the next line
empty salmon
If you search in this discord and on the web, there are many many posts advising end users to call release_displays() as a step.
stuck elbow
and I bet chatgpt is also giving all sort of stupid advice
empty salmon
It may be be bad advice but it’s broadly mentioned
The advice is in many adafruit learning guides … and without guidance on “when not to do it”.
stuck elbow
can't control that
do you have an example of a learn guide that advises to call release_displays without initializing the display?
we should probably fix those
empty salmon
That is not what I said. I was saying there are guides that give examples and it’s easy to mix when the guide is talking about an integrated display vs an external one.
stuck elbow
any advice taken out of context is always going to be bad
empty salmon
Again, the issue is not calling release_display and then initializing explicitly. It’s calling release_display and having no intuitive way to get board.DISLAY back.
stuck elbow
okay, let's consider a hypothetical scenario
empty salmon
We need to decide the persona of the majority of CircuitPython developers.
_ I’ll pick this up shortly. I need to walk the dog_
stuck elbow
A user of a board with a built in display has some kind of problem, and to solve it, they randomly try to copy-paste pieces of code they find in different guides. Eventually they find the mention of release_displays and add it to their code. Their display stops working, so they try to find a way to get it working again. Now, there are two possibilities: right now, there is no such way, so they just remove the release_displays call and try other things to fix their problem. With your proposed change, they find the function to call to get the display back, and add it to their code somewhere after release_displays. Their code is now even worse than it was.
empty salmon
I believe the differences of our viewpoint comes down to the persona of the target end-user. Novice users find the current behavior of release_displays() on an integrated display to be confusing while more advanced users find it adds flexibility.
onyx hinge
@empty salmon I agree there is probably room for improvement here. This is something that core devs are looking at and may change for version 9: https://github.com/adafruit/circuitpython/issues/8675
Part of what we're looking at doing is something like
Instead, we can add an explicit supervisor.runtime.display = that allows for setting a single display to preserve outside the VM and use for the terminal
based on the discussion I was a part of, it's not clear to me whether that'd complement or replace board.DISPLAY.
If you wanted to organize your thoughts and add them to that issue it would be totally appropriate. Thanks!
empty salmon
Thanks @onyx hinge - I read that issue and will set aside some time to assemble a coherent comment.
lone sandalBOT
slender iron
<@401870246157484033> I agree there is probably room for improvement here. This ...
I wasn't thinking we'd do it for 9. But I would like to do it to get rid of release_displays.
onyx hinge
I wasn't thinking we'd do it for 9. But I would like to do it to get rid of rele...
@slender iron oh oops, sorry for putting words in your mouth about that. The milestone info is correct and I just .. ignored it.
slender iron
np
manic glacierBOT
I don't see any failed calls... The 9 second delay was me entering the CircuitPython password
tulip sleet
@slender iron what is left to merge that you would like in alpha.6 (or beta.0)? @onyx hinge jpegdecoder is still in process, right?
not necessarily going to do this now, but I could do it by tomw
tulip sleet
I thought the output was still a bit buggy, as noted internally?
slender iron
maybe alpha because I'm changing how storage.mount works in my wip SD card pr
the PR is marked as ready
tulip sleet
yes, I'm thinking there are still some evolving and not-yet-added things
thorny jay
I worry a little bit that we could be forgetting #CircuitPython2024 (not that I have any clue what I could write there) ... or is it a blogpost that @slender iron does on the first of January?
slender iron
I intend on doing it.
We did just get the email setup
good to have a reminder though
onyx hinge
I thought the output was still a bit buggy, as noted internally?
No that was quickly fixed
I think it's ready but the api needs review
onyx hinge
which I see scott was kind enough to provide, thanks!
onyx hinge
word is to just go with tjpg decoder for now. I'll try enabling jpegio more widely, then turn it back off where it doesn't fit, and finally set the PR as ready for review again. so, maybe not for this release dan is planning to do.
stuck elbow
I wonder if it would make sense, once this lands, to add jpg support to image_load using jpegio, if it exists
I know you can use jpegio directly, but having a simple wrapper in image_load would give a consistent interface
plus, image_load can autodetect file type
onyx hinge
that sounds very possible to me, not that I am super familiar with image_load
digital shoreBOT
adafruit
orchid basinBOT
manic glacierBOT
orchid basinBOT
orchid basinBOT
manic glacierBOT
pulsar sleet
I am trying to recompile circuit python so I can see when circuit python allocate memory and when trying to compile i get this error
│ /mnt/e/circuitpython/ports/atmel-samd/../../tools/gen_nvm_devices.py:9 in main │
│ │
│ 6 │
│ 7 │
│ 8 def main(input_template: pathlib.Path, output_path: pathlib.Path): │
│ ❱ 9 │ flashes = cascadetoml.filter_toml(pathlib.Path("../../data/nvm.toml"), []) │
│ 10 │ │
│ 11 │ template = Template(input_template.read_text()) │
│ 12 │
│ │
│ ╭─────────────────────────────────────── locals ───────────────────────────────────────╮ │
│ │ input_template = PosixPath('../../supervisor/shared/external_flash/devices.h.jinja') │ │
│ │ output_path = PosixPath('build-matrixportal_m4/genhdr/devices.h') │ │
│ ╰──────────────────────────────────────────────────────────────────────────────────────╯ │
│ │
│ /home/carson/.local/lib/python3.10/site-packages/cascadetoml.py:163 in filter_toml │
│ │
│ 160 │ acceptable values for the given keys.""" │
│ 161 │ root_toml = root / ".cascade.toml" │
│ 162 │ if not root_toml.exists(): │
│ ❱ 163 │ │ raise ValueError("Missing root .cascade.toml") │
│ 164 │ │
│ 165 │ template = list(root.glob("*.template.toml")) │
│ 166 │ if not template or len(template) > 1: │
│ │
│ ╭────────────────────────── locals ──────────────────────────╮ │
│ │ filters = [] │ │
│ │ root = PosixPath('../../data/nvm.toml') │ │
│ │ root_toml = PosixPath('../../data/nvm.toml/.cascade.toml') │ │
│ ╰────────────────────────────────────────────────────────────╯ │
╰──────────────────────────────────────────────────────────────────────────────────────────────────╯```
The command I am running is `circuitpython/ports/atmel-samd$ make BOARD=matrixportal_m4`which version of gcc are you using?
pulsar sleet
11.4.0
stuck elbow
and did you run make fetch-port-submodules?
pulsar sleet
no I forgot
manic glacierBOT
pulsar sleet
Can I compile circuit python in wsl or should I switch to linux (i dual boot)
blissful pollen
Can I compile circuit python in wsl or should I switch to linux (i dual boot)
I use WSL so it works, though a bit trickier to map ports to WSL then in native linux
pulsar sleet
Ok. I was wondering because I tried to compile and it took forever but I restarted the command and its working
is this normal
blissful pollen
The errors are not normal
pulsar sleet
internal screaming intensifies
what is boot2.elf
I am running with verbose mode (make -j BOARD=adafruit_kb2040 V="steps commands rules")
midnight ember
I've been able to make builds with WSL but the python pathing can be tricky to setup.
short tendon
Best practice for WSL: treat it like it's own OS. if you try to share entire projects across it doesn't really work. But if you just want to copy the build/final files across, it works like a champ.
manic glacierBOT
pulsar sleet
probably should have asked this before I downloaded the circuit python source but is there a debug build I can just download. I know there is a flag that can be set to log allocations
onyx hinge
probably should have asked this before I downloaded the circuit python source bu...
no, we have too many builds already to offer debug builds.
pulsar sleet
How do I enable build flags. I found a flag called MICROPY_DEBUG_VERBOSE and setting it in py/mpconfig.h does nothing and setting it in ports/raspberrypi/boards/adafruit_kb2040/mpconfigboard.h causes errors (I wrote it to try to set the flag even if its set so these errors show that I would already be set and my config wouldn't matter)
pulsar sleet
I think I figured it out. There is a file called py/circuitpy_mpconfig.h that I had to configure
mortal kernel
How do I enable build flags. I found a flag called `MICROPY_DEBUG_VERBOSE` and s...
You can pass DEBUG=1 into make like so: make BOARD=my_board DEBUG=1 -j8
Also, it's often handy to have REPL plus messages on a UART port, so add these lines (adjusting the pins as necessary) to your board's mpconfigboard.h:
#define CIRCUITPY_CONSOLE_UART_RX (&pin_GPIO1)
#define CIRCUITPY_CONSOLE_UART_TX (&pin_GPIO0)
Finally, you can tweak your optimization flags in your ports Makefile like this (RP2 example):
#Debugging/Optimization
ifeq ($(DEBUG), 1)
CFLAGS += -ggdb3 -Og
# No LTO because we may place some functions in RAM instead of flash.
Giving you a friendlier debug build for use with GDB.
pulsar sleet
You can pass `DEBUG=1` into `make` like so: `make BOARD=my_board DEBUG=1 -j8`
Al...
thank you
so this is would make a build that prints debug messages and when something allocates memory make -j BOARD=adafruit_kb2040 DEBUG=1
pulsar sleet
Ok. I am asking about compile flag things because here https://github.com/adafruit/circuitpython/blob/7715ff09cc663b80403f8907fe90c00fd89c9706/py/malloc.c#L85 it looks like m_alloc will print messages when something allocates memory but I want to know where I enable the flag thing. I tried to set it in py/circuitpy_mpconfig.h and I set MICROPY_MALLOC_USES_ALLOCATED_SIZE to 1 because it is needed but but then I am getting errors.
Here is the log
mortal kernel
Ok. I am asking about compile flag things because here https://github.com/adafru...
Try modifying py/malloc.c adding a line like (for extra points you can make it conditional on DEBUG):
#define DEBUG_printf(...) mp_printf(&mp_plat_print, __VA_ARGS__)
Not all of the debug stuff you'll find in the source is current or working, so you'll have to roll your own.
pulsar sleet
it looks like DEBUG_printf gets define when a flag is set. How could I check is DEBUG is set in the make command
do I do something like #if DEBUG
mortal kernel
it looks like `DEBUG_printf` gets define when a flag is set. How could I check i...
See my previous message. Just stuff that into py/malloc.c after line 40 and you may get what you want. As far as chasing down macros and flags, you'll need to use something like VS Code with its powerful search facilities.
pulsar sleet
I tried to compile circuit python for the matrix portal m4 but I get a error saying that build-matrixportal_m4/firmware.elf section '.text' will not fit in region 'FLASH_FIRMWARE'
spare jacinth
sounds like: you dont have enough flash for all the code 😅
pulsar sleet
the only changes I made is
-#define DEBUG_printf DEBUG_printf
+#if MICROPY_DEBUG_VERBOSE || defined(DEBUG) // print debugging info
+#define DEBUG_printf(...) mp_printf(&mp_plat_print, __VA_ARGS__)``` in py/malloc.c
and
```- CFLAGS += -ggdb3 -Og -Os
+ CFLAGS += -ggdb3 -Og -Os -D DEBUG``` in ports/atmel-samd/MakefileThat port already takes up all available flash, so adding just a few debug strings pushes it over the edge. Upgrading your toolchain to GCC 13.2 can claw you back a few bytes. See here: https://developer.arm.com/downloads/-/arm-gnu-toolchain-downloads. You can also try narrowing the scope of your debug messaging. Finally, you can also see if there are any features you don't use that you can throw over the side. Each has its own flag like CIRCUITPY_PIXELBUF that you can set to 0 in the port or board mpconfigboard.mk.
pulsar sleet
Ok thank
mortal kernel
Ok thank
One more thing to try, if you're not using GDB then drop the -ggdb3 and -Og flags.
mortal kernel
Would the compiled version work without adding `DEBUG=1` to the make command
It should, that's what gets shipped.
pulsar sleet
I get the same errors when removing it so
mortal kernel
I get the same errors when removing it so
What version of CP have you checked out? What version of GCC are you using?
pulsar sleet
gcc (Debian 12.2.0-14) 12.2.0```
And I downloaded the latesd version of cp so I think 9.0.0If you cloned the repo and didn't do a git checkout then you have main which is 9.0.0. You'll need the updated toolchain (gcc 13.2) I noted earlier to do a build that fits.
pulsar sleet
how do I install gcc 13.2
tulip sleet
@pulsar sleet I do not think you are going to find out as much as you want by turning on debugging and allocation logging. There are many allocations that will be mysterious. I would suggest instead that you start with a minimal version of the Python program, and then add features one at a time.
(this is from some previous discussion in #help-with-circuitpython )
pulsar sleet
I know. I need a way to see how big a object is in memory but I don't know how and I don't want to mess around with circuit python's code that much
mortal kernel
how do I install gcc 13.2
Dan's likely right. But, it is informative to learn the ins and outs of CP building. The toolchain instructions are available where you find the download.
tulip sleet
there are allocations that are made for compiled code and for internal use that are not part of any Python object
I agree we could add sys.getsizeof()
tulip sleet
how do I install gcc 13.2
https://developer.arm.com/downloads/-/arm-gnu-toolchain-downloads and then add the bin directory of that to your path, before other things
onyx hinge
note that there are two parts of "getsizeof": enabling the built-in but also implementing MP_UNARY_OP_SIZEOF for relevant types. For instance, getsizeof(a bitmap object) will fail because this is not implemented; this is true for probably ANY type we have added to micropython: ```>>> import displayio
b = displayio.Bitmap(320,200,65535)
import sys
sys.getsizeof(b)
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
TypeError: unsupported type for sizeof: 'Bitmap'
uheap.info() might be easier
stuck elbow
what if you wrap it in memoryview?
onyx hinge
TypeError: unsupported type for __sizeof__: 'memoryview'
stuck elbow
boo
onyx hinge
if implemented the sizeof a memoryview would be small, behavior on standard python is to not count the referred-to memory: ```>>> b = b"x" * 1024
sys.getsizeof(b)
1057
sys.getsizeof(memoryview(b))
184
(python 3.11)
pulsar sleet
I install gcc13 and now I get this error
@pulsar sleet here is build of CIrcuitPython 8.2.x for the MatrixPortal M4 with uheap enabled. I had to do a bit of fiddling to get it to compile. However, I repeat that this is not going to tell you as much as you want to know, because native objects have internal allocations that don't necessarily show up here, as jepler mentioned.
Adafruit CircuitPython 8.2.8-7-gc5c7d110df-dirty on 2023-12-10; Adafruit Matrix Portal M4 with samd51j19
>>>
>>>
>>> b = bytearray(100)
>>> import uheap
>>> uheap.info(b)
Array of size: 112
128
>>>
Thank you soo much
tulip sleet
I install gcc13 and now I get this error
```ytecode stream in file 'build-matrix...
you need to do a clean build if you switch compilers
pulsar sleet
I am getting space issue again. I disabled some stuff but then trying to build with DEBUG disabled should be smaller than a standered build but its not
All I did was disable
MICROPY_PY_BUILTINS_HELP
MICROPY_PY_BUILTINS_HELP_MODULES
MICROPY_PY_BUILTINS_INPUT
MICROPY_PY_BUILTINS_MEMORYVIEW
MICROPY_REPL_AUTO_INDENT
MICROPY_REPL_AUTO_INDENT ``` and I disabled SPI and I2C by commenting out the lines that those pins are definedbuilding without DEBUG worked after clearing the build foulder
mortal kernel
I am getting space issue again. I disabled some stuff but then trying to build w...
You're getting off into the weeds. Let's go back to the beginning. What is it that you are trying to figure out?
pulsar sleet
Printing when allocations happen. My issue is that adding a print function that would print the text takes up too much space
mortal kernel
Printing when allocations happen. My issue is that adding a print function that ...
I'll be back later if you're still stuck. The dinner bell just rang.
pulsar sleet
Ok
I am trying to compile Circuit python but I am getting this error
../../py/objarray.c:70:17: error: 'array_decode' declared 'static' but never defined [-Werror=unused-function]
70 | STATIC mp_obj_t array_decode(size_t n_args, const mp_obj_t *args);
|``` Is `STATIC` equal to the C `static`Figured it out. I needed to reenable bytearrays
short tendon
Question (on my path to write out some changes to requests and sockets):
Would it make sense to rename adafruit_esp32spi/adafruit_esp32spi_socket.py to adafruit_esp32spi/adafruit_esp32spi_socketpool.py and then import the latter in the former? Since it's really a fake pool?
pulsar sleet
for some reason when I downloaded the github for circuit python this file had asf_assert instead of assert on line 98 and 75
define ASSERT_IMPL(condition, file, line) **asf_assert**((condition), file, line)
void **asf_assert**(const bool condition, const char *const file, const int line);
```
should I replace asf_assert with just assert. It only happens in the utils_assert.h files
main furnace
Trying to use NeoKey1x4 with QTPY_M0 but not enough memory. Maybe I can use a custom build if I remove unused features.
lone axle
I've compiled together the list of everything that shook out from the Adabot patch and subsequent release sweep that I don't think I have access to solve. 1 with a pypi token issue, 1 with a GH token issue perhaps the same thing as a different one that Jeff found the settings fix for. And then the list of repos that had additional branch protections which prevented the adabot patch from comitting directly.
There were a few other failures sprinkled in that I have loaded up to look into further today but upon first glance they all looked unrelated to repo settings so I'm hopeful that I'll have the means to get the sorted out.
lone axle
Does anyone know of a way to force pre-commit to wipe and re-install it's dependencies? Or show me what version it's using for it's tests (version of pylint specifically) I've run into a situation where running pre-commit locally is having a different result then what happens when it runs in the github actions. I noticed the pre-commit config file specifies pylint rev: v2.17.4 so I manually installed that and confirmed if I run it directly on the files I do get the same error messages as the actions container with it.
But if I just run pre-commit run -a locally it's still passing and not having that same error. Which leads me to conclude it's using a different version than the one now installed in the venv all this is running in, and also seems to be a different version from the one specified by the pre commit config file since it has different results when run directly on the same files. Unless there is some other thing that could account for that difference?
pre-commit clean turned out to the be answer to wipe and re-install everything and that has worked to get me in sync with behavior from actions 🎉
tulip sleet
for some reason when I downloaded the github for circuit python [this file](http...
There is something wrong with your build. This should not be necessary. If you are trying to do a build, just follow the instructions in the Building CircuitPython guide to the letter, first.
tulip sleet
for some reason when I downloaded the github for circuit python [this file](http...
The program you are trying to make fit is just not going to fit in its present form. That is why we wrote it only for the Matrix Portal S3. I do not think the information you are trying to print out is going to be that helpful in shrinking that program.
@lone axle requests.get() should not require the timeout argument. What is the pylint error you are getting? Let's not change the code, let's change the check
lone axle
<@382939733107408897> requests.get() should not require the timeout argument. Wh...
I happen to have this link handy which is the same error in a different library: https://github.com/adafruit/Adafruit_CircuitPython_BLE_BroadcastNet/actions/runs/7152642898/job/19478188549#step:2:842
This is the pylint reference for it: https://pylint.pycqa.org/en/latest/user_guide/messages/warning/missing-timeout.html. I'll get the link for the original failing check in adabot.
onyx hinge
that's a rather opinionated diagnostic.
lone axle
Here are the failures from the adabot repo that prompted me to add timeout: https://github.com/adafruit/adabot/actions/runs/7169513926/job/19520092586#step:7:37
I'm not sure if this is a new pylint check or what changed but I don't think it used to flag the same way?
tulip sleet
I think it is new. It makes sense that a timeout is a good idea. I'd suggest making a constant maybe instead of using using 30
onyx hinge
Error: examples/ble_broadcastnet_blinka_bridge.py:18:11: W3101: Missing timeout argument for method 'requests.post' can cause your program to hang indefinitely (missing-timeout)
It's not incorrect in the sense that calling a function without a required keyword arg is .. pylint just thinks it's bad practice not to specify this optional keyword arg.
tulip sleet
it was added in pylint 2.15.x
lone axle
I think it is new. It makes sense that a timeout is a good idea. I'd suggest mak...
In the adabot repo example would that be 1 constant in each file that makes requests? or just a single one inside __init__ or somewhere that it can be imported from the different files?
tulip sleet
In the adabot repo example would that be 1 constant in each file that makes requ...
maybe it would be easier to create a helper function that calls requests.get() with a fixed timeout (or make it an optional arg). Basically make the default value of timeout be something else besides None
that would be a lot less verbose
lone axle
I can do that, although it feels a bit akward to add that to adabot specifically though, would we create the same wrapper in other libraries that use requests?
tulip sleet
i am surprised requests.get() has no default timeout
this seems like a larger thing. lemme look at issues in the requests library
tulip sleet
I can do that, although it feels a bit akward to add that to adabot specifically...
This is has been an issue in requests for a long time. main issue is https://github.com/psf/requests/issues/5789. Ideally one would want to set a default timeout, but it seems to be not so simple.
I think it would be fine for now to provide something like from adabot import REQUEST_TIMEOUT and do timeout=REQUEST_TIMEOUT everywhere, so that you can change it if 30 seems too long or to short
maybe REQUESTS_TIMEOUT with an S
lone axle
Sounds good. I'll add that change to the adabot PR and take a similar approach with other libraries I run accross with the same error raised by pylint.
I have run into a seperate question around actions / infrastructure now as well. In our workflow file (gh release) we have something this:
upload-url: ${{ github.event.release.upload_url }}
What is github.event.release.upload_url or how does it get populated? I have a case where it seems that is being empty or null and then the thing it's passed to fails because it's a required argument. I'll do some digging in the actions docs.
manic glacierBOT
lone axle
Thank you!
tulip sleet
i use other things from this API to find out stuff about the PR, etc.
lone axle
Does anyone recall any history on https://github.com/adafruit/Adafruit_CircuitPython_Register_SPI ? It's readme contains instructions for installing with circup install register_spi but it appears it was never added to the library bundle so that doesn't work ATM. Should it get added to the bundle or perhaps have it's readme adjusted?
onyx hinge
Does anyone recall any history on https://github.com/adafruit/Adafruit_CircuitPy...
I don't know what the development status of that is. I see you did the 1.0.0 release -- did you consider it complete and ready to use, just forget to add it to the bundle?
lone axle
I don't know what the development status of that is. I see you did the 1.0.0 rel...
Good question, I do not recall to be honest what I was thinking when it I released it. Forgot that I had done that. My best guess is that I just saw it in the list on the contributing page under library infrastructure and released to get it out of that. But it does appear I may have jumped the gun on it. There is an issue on that repo that was discussing anything further needed to be ready but it didn't get much traction. https://github.com/adafruit/Adafruit_CircuitPython_Register_SPI/issues/1
I don't know if "un-release" is a thing that can happen but if so perhaps that would be appropriate for this library.
tulip sleet
I don't know if "un-release" is a thing that can happen but if so perhaps that w...
since it is not in the bundle I would say don't worry about it. It is possible to delete releases and their associated tags, if you would like to do that.
lone axle
<@&356864093652516868> The weekly meeting will take place here on discord 1 hour from now at 2pm Eastern / 11am Pacific US. The notes doc is here: https://docs.google.com/document/d/1jtCjgV5NExzjBZxgPpE8dY_D42g4DAJv6w24TaARTRw/edit?usp=sharing for anyone that would like to fill in Hug reports and Status updates. We look forward to hearing from folks during the meeting!
onyx hinge
@lone axle discord is taking steps to make links to uploaded files expire, so I replaced your link with a copy of the file I uploaded as a github gist.
lone axle
Thank you, I initially tried attaching it directly to the doc but it turns out that isn't possible.
orchid basinBOT
onyx hinge
@lone axle I could grab the library section if you want a break during state of circuitpython
manic glacierBOT
onyx hinge
OV5640 Register Datasheet https://cdn-learn.adafruit.com/assets/assets/000/118/994/original/OV5640_datasheet.pdf?1677598686
slender iron
it is segmented eink which is weird
onyx hinge
oh very interesting!
tidal kiln
oh yah. huge hug to @danh for dealing with this macos stuff.
onyx hinge
I hope it wasn't at 2AM
thorny jay
Sorry I was editing while you were reading.
lone axle
No worries
midnight ember
I replicated the displayio issue on my own esp32s3 rev tft feather and confirmed the bug on 8.2.9 with the latest 8.x bundle.
Jepler and Melissa doing wizardry this week
thorny jay
I hope it wasn't at 2AM
I had it late (22H00) and early (8H00) but since it is only the music, it may have run during the night without anybody noticing. 🙂
It could be the wind, or "electricity in the air"... I need to measure the minimum time a human close the circuit when pressing the doorbell button, and use that timer for debouncing so that a 1 is only a 1 if it is a 1 for at least x milliseconds.
midnight ember
Neradoc's keyboard layouts for different languages has been an invaluable asset to point people at.
lone axle
If I understand right that'd make those fonts installable via circup which would be very convenient as well!
thorny jay
Fontz: I usually cherry pick in the Learn Guide repo for font to use in my projects. 🙂
midnight ember
The amount of detail with resin surpasses FDM 3D printing but the chemicals...
thorny jay
Fontz: I usually cherry pick in the Learn Guide repo for font to use in my proje...
The 8x5.bin frequently missing is a pain.
gilded cradle
@onyx hinge In the summer, you have to deal with direct sunlight prematurely curing the resin
midnight ember
amazing update Jepler!
onyx hinge
midnight ember
Appeciate all your work Melissa doing great things!
gilded cradle
Thanks
midnight ember
❤️ Sending you good vibes Scott. God bless you and your family.
thorny jay
No that code was after the book.
Maybe next book will contain CP stuff, that would be great. 🙂
slender iron
thanks for hosting!
onyx hinge
@tulip sleet did someone do a merge of 8.x to main recently? I think we talked about that being a good idea to do
tulip sleet
<@329766224093249548> did someone do a merge of 8.x to main recently? I think we...
I did do that: https://github.com/adafruit/circuitpython/pull/8702
onyx hinge
aha great
lone axle
Here is the notes document for next Monday’s CircuitPython Weekly Meeting. It is at the normal time of 11am Pacific / 2pm US Eastern here on Discord. Add your hug reports and status updates to the document before the meeting. If you are unable to attend but would still like to contribute, feel free to add your notes and we’ll read them off during the meeting. Hope to see you there! <@&356864093652516868> https://docs.google.com/document/d/1Jzrzv6IAmRjEdOTQcFm_VghdlLhwG3r-AJlZBHTid68/edit?usp=sharing
devout jolt
Thank you @tulip sleet for MacOS USB serial chip testing Playground page! It always feels like a roulette "will this board show up?"
tulip sleet
Thank you <@329766224093249548> for MacOS USB serial chip testing Playground pag...
You're welcome! I never found this written down in any Apple documentation, but maybe I was looking in the wrong place.
But the doc is pretty terrible about describing things like this.
devout jolt
You're welcome! I never found this written down in any Apple documentation, but ...
No, you found what's there. I've been dealing with MacOS X USB for 15 years and nothing is publicly documented
btw, if you don't have a copy of the great "USB Prober" for MacOS, I've a copy of it stashed here: https://github.com/todbot/hidapitester/releases/tag/0.1
tulip sleet
btw, if you don't have a copy of the great "USB Prober" for MacOS, I've a copy ...
👍 i have used that, but not on mac OS. I have the repo bookmarked!
devout jolt
👍 i have used that, but not on mac OS. I have the repo bookmarked!
"USB Prober" is one of the only USB diagnostic tools Apple ever made. And stopped supporting it in 2014 I think. But it still works!
pulsar sleet
I finally got circuit python to compile with allocations printing. The bulk of the size being used was from just the DEBUG flag. Compiling with the debug stuff on without needing the DEBUG flag worked
tulip sleet
@lone axle @onyx hinge I fixed everything here: <https://gist.github.com/jepler/64b302125bce317ad93e108aa796984f28
lone axle
Thank you!
orchid basinBOT
orchid basinBOT
manic glacierBOT
keen eagle
macOS Sonoma 14.2 actual release is out today, confirmed it still has the same issues with small FAT drives
onyx hinge
thank you @tulip sleet
manic glacierBOT
orchid basinBOT
tulip sleet
Notable since alpha.5: jpegio, synthio enhancements, update to Espress ESP-IDF v5.1.2
crimson ferry
When (web workflow) auto-connect is enabled, is it expected for "auto-connect " to be printed to the console when attempting to manually connect? It will do that endlessly (no exception) and need a restart to connect again.
onyx hinge
The meeting calendar has been updated with the 2024 meeting dates, including January 2, 2024. The 2022 events have been removed.
manic glacierBOT
onyx hinge
@gilded cradle so far it looks like support for jpeg images was limited to the pyportal library, not the portalbase library. is there a reason for that, or is it just how things ended up? I am asking because I wondered if the existing code could be made to transparently switch to using jpegio to decode a jpeg image locally.
gilded cradle
@onyx hinge I'll take a look. Not sure the reason. Perhaps it was added by a user.
onyx hinge
@gilded cradle OK, let me know -- if it makes sense to do, I can probably take on the work since I want to change it anyway.
gilded cradle
<@478616919721771019> OK, let me know -- if it makes sense to do, I can probably...
Do you know where it's added in the lib?
gilded cradle
adafruit_pyportal/network.py
Do you mean the general image handling?
gilded cradle
<@478616919721771019> OK, let me know -- if it makes sense to do, I can probably...
Ok, I kinda remember that now. I think it handled png, gif, and jpg
onyx hinge
the goal would be to have something similar to https://learn.adafruit.com/pyportal-nasa-image-of-the-day-viewer/code-pyportal-nasa-image-viewer work on a qualia, and use jpegio locally to decode the image if it's possible..
gilded cradle
the goal would be to have something similar to https://learn.adafruit.com/pyport...
Yeah, I think just making sure it's a jpeg and not another kind of image and that should be fine. Go ahead and work on it if you'd like.
onyx hinge
Yeah, I think just making sure it's a jpeg and not another kind of image and tha...
thank you. can I tag you on an eventual pull request?
gilded cradle
thank you. can I tag you on an eventual pull request?
sure
slender iron
When (web workflow) auto-connect is enabled, is it expected for "auto-connect " ...
no, that sounds like a bug
gilded cradle
@crude blaze I just wanted to check in and see if you ran into anything you had questions about with the Raspberry Pi stuff.
onyx hinge
@tulip sleet @lone axle yesterday I made a release of pycamera https://github.com/adafruit/Adafruit_CircuitPython_PyCamera/releases/tag/0.0.2 but last night adabot didn't release the a bundle https://github.com/adafruit/adabot/actions/runs/7190944054/job/19584889856 -- do either of you know what I missed that might have prevented it from being picked up? Wed, 13 Dec 2023 05:06:18 GMT Adafruit_CircuitPython_Bundle Wed, 13 Dec 2023 05:06:19 GMT Everything is already released.
lone axle
<@329766224093249548> <@382939733107408897> yesterday I made a release of pycame...
I'm not exactly sure how it normally gets triggered but it looks like the release action hasn't triggered since 12/10 https://github.com/adafruit/Adafruit_CircuitPython_Bundle/actions/workflows/release.yml
onyx hinge
my vague understanding was that the adabot action I linked to 2nd is supposed to cause the release to be made but I don't know.
lone axle
it looks like there could be logic in adabot.circuitpython_bundle
tulip sleet
<@329766224093249548> <@382939733107408897> yesterday I made a release of pycame...
The 0.0.1 and 0.0.2 pycamera releases have the same commit SHA!
onyx hinge
oh!
I wonder how the release note got generated saying there was a bunch of stuff in it then
it still needs to see the bundle re-released, because it needs changes from circuitpyhton-build-tools. so many interconnected pieces.
tulip sleet
really weird because the Asset files are quite different sizes
crude blaze
<@375455651050160130> I just wanted to check in and see if you ran into anything...
I've gotten pretty far!
Managed to get the tinydrm driver working 🙂
Currently working on a kernel patch for the TSC2007 to give that support for the usual touchscreen properties (missing stuff like swap and invert atm)
turns out all that was missing was to invert the reset GPIO, the default behaviour is just the opposite to how it worked in fbtft
lone axle
Out of curiousity what order does boot.py and the web workflow initialization occur in? If boot.py contained code that added or removed the web workflow configurations from settings.toml would the modified configuration be used when webworkflow is initialized? Or web workflow init happen prior so it won't know about the changes?
mortal kernel
@danh Am I handling #8718 correctly? I could patch the CYW43 driver, but I don't think we want to maintain a CP fork.
tulip sleet
@danh Am I handling #8718 correctly? I could patch the CYW43 driver, but I don't...
we have a fork of the driver already: https://github.com/adafruit/cyw43-driver. It hasn't been kept up to date because we switched back to the georgerobotics one. It could be sync'd up and then a branch for these fixes could be made.
Ideally I think a PR to the georgerobotics upstream version is the right thing. The q is how fast it would be acted on.
mortal kernel
we have a fork of the driver already: <https://github.com/adafruit/cyw43-driver>...
I've opened issue https://github.com/georgerobotics/cyw43-driver/issues/106 against the driver. I've not been seeing any response to an earlier issue I opened several weeks ago.
crimson ferry
I'll test on micropython if I get some time. 8.2.9 with #8590 allows turning AP on and off repeatedly. AP shows up and devices can connect to it on subsequent re-start_ap()s.
mortal kernel
we have a fork of the driver already: <https://github.com/adafruit/cyw43-driver>...
I'm thinking that if we get close to 9.0.0 release and it's still not resolved we should consider the fork.
mortal kernel
I'll test on micropython if I get some time. 8.2.9 with #8590 allows turning AP ...
It's not really fixed in 8.2.9, we just were not testing its status. Internally the CYW43 driver thinks the link is down due to internally clobbered state, so the AP won't actually work.
mortal kernel
I can try some sockets over that connection
Please do. I'm basing what I'm saying on my reading of the code not on actual testing.
crimson ferry
I'm bad at reading code, so I have to test to know what's happening 😉
mortal kernel
I'm bad at reading code, so I have to test to know what's happening 😉
I'm bad at both.
stuck elbow
I'm bad at both.
aren't we all? https://cdn.fosstodon.org/media_attachments/files/111/575/122/297/099/172/original/e7367f93466e74b0.png
empty salmon
@stuck elbow - getting a little closer.
setting #define CIRCUITPY_REPL_LOGO 0 in pmconfigboard.h and setting CIRCUITPY_TERMINALIO = 0 in mpconfigboard.mk` will prevent the REPL text and the log from appearing on the ePaper but the display still is "refreshed" when REPL is activated (as in the case of an error, using CTRL-C, or when code.py ends).
I need to figure out how to prevent the "refresh to blank" in those cases.
stuck elbow
<@351136009922019331> - getting a little closer.
setting `#define CIRCUITPY_REP...
I think the refresh is built into the epaperdisplay code
on deinit
empty salmon
but I thought dinit only gets called with release_displays() ?
empty salmon
but if I had used the display (eg I actaull created group(s) and tile(s) and did a display refresh), then 'end fo program' does not refresh the epaper.
stuck elbow
maybe it's some kind of a special case in there
look at the reset_displays function maybe
empty salmon
... reading code now
crimson ferry
@mortal kernel CP 8.2.9 on Pico W ...started and stopped AP 5 times to get things rolling, then started it a 6th time and started a UDP server ...an ESP32-S3 station can connect and they can send and receive UDP packets to each other
mortal kernel
<@849815081251766292> CP 8.2.9 on Pico W ...started and stopped AP 5 times to ge...
Thanks for giving it a try. I'll take a closer look at the code and see if I can find anything that won't work. If the code checks out, I'll submit a pull that ignores the link down indication from the driver as a workaround.
onyx hinge
My change caused the bundle to fail building. I will fix it asap. We may want to remove the latest release from GitHub as I think it is broken and won't let circup work
Sorry
tulip sleet
My change caused the bundle to fail building. I will fix it asap. We may want t...
ok, let's remove the bundle. it is today's date?
I think it is also on S3. I will remove it there.
tulip sleet
I'm thinking that if we get close to 9.0.0 release and it's still not resolved w...
If you have a good PR to submit to george-robotics, that will probably get attention faster. Would it be upward compatible?
onyx hinge
This one. I'm mobile so I don't want to rush to do something
I need to update and release circuitpthon build tools for it to work to release. I'm not sure why the ci of c-b-t succeeded.
mortal kernel
<@849815081251766292> CP 8.2.9 on Pico W ...started and stopped AP 5 times to ge...
Could you try IP data packets? It looks like those might get dropped.
tulip sleet
I need to update and release circuitpthon build tools for it to work to release....
circup was unable to download the bundle, and complained, but my recent fixes make it proceed with an older bundle. I'll go ahead and remove it, since it's clearly not functionala
onyx hinge
circup was unable to download the bundle, and complained, but my recent fixes ma...
Thank you!
crimson ferry
Could you try IP data packets? It looks like those might get dropped.
like TCP? ping works (or at least gets a result of 0.0 ms)
mortal kernel
If you have a good PR to submit to george-robotics, that will probably get atten...
Can do. After some testing, of course.
tulip sleet
Thank you!
the bundle json was never uploaded to https://adafruit-circuit-python.s3.amazonaws.com/index.html?prefix=bundles/adafruit/ so nothing to delete there
tulip sleet
Can do. After some testing, of course.
thanks!
mortal kernel
like TCP? ping works (_or at least gets a result of 0.0 ms_)
Specifically, the soft spot I'm seeing is the data in the packet gets dropped by cyw43_cb_process_ethernet when the flag NETIF_FLAG_LINK_UP is off. The zero ms result could be a symptom of that.
Also, the bad flag affects ARP/IGMP/MLD/RS reports.
crimson ferry
ok, i need to think about how to test that (don't know much about that level and need a computer I can take off the network without disrupting other things)
mortal kernel
ok, i need to think about how to test that (don't know much about that level and...
I'm going to need to make a similar setup here, too. I'll be using a spare RP4 with WireShark. But first, my walk!
manic glacierBOT
crimson ferry
@mortal kernel I can connect to the AP from a mac laptop, but oddly, I don't get an IP address like I do on the ESP32-S3, so can't do anything with it, weird that the DHCP server would work for one but not the other nope, strike that, it must have disconnected --> I get ping times from the Mac, arp -a finds the PicoW
mortal kernel
<@849815081251766292> ~~I can connect to the AP from a mac laptop, but oddly, I ...
Here's the code that I'm most concerned about:
void cyw43_cb_process_ethernet(void *cb_data, int itf, size_t len, const uint8_t *buf) {
cyw43_t *self = cb_data;
struct netif *netif = &self->netif[itf];
#if CYW43_NETUTILS
if (self->trace_flags) {
cyw43_ethernet_trace(self, netif, len, buf, NETUTILS_TRACE_NEWLINE);
}
#endif
if (netif->flags & NETIF_FLAG_LINK_UP) {
struct pbuf *p = pbuf_alloc(PBUF_RAW, len, PBUF_POOL);
if (p != NULL) {
pbuf_take(p, buf, len);
if (netif->input(p, netif) != ERR_OK) {
pbuf_free(p);
}
CYW43_STAT_INC(PACKET_IN_COUNT);
}
}
}
It looks like it will not run pbuf_take so the buffer passed in as buf will get nothing.
And no error indication.
gilded cradle
I've gotten pretty far!
Managed to get the tinydrm driver working 🙂
Currently w...
Awesome. I'm excited to see it. Soon we can get the installer scripts updated.
mortal kernel
@crimson ferry I have a 9.0.0 alpha build that fixes the race condition in cyw43-driver. It passes your test (repeatedly starting and stopping the AP) and I was hoping you would give it a more thorough testing. I'm not sure of the best way to get you the build artifact.
manic glacierBOT
slender iron
Out of curiousity what order does `boot.py` and the web workflow initialization ...
My intent is for boot.py to run before workflows are started.
lone axle
Nice, Thank you!
I'm thinking about a mechanism that uses a physical switch or button to enable / disable the webworkflow, kind of how the examples for mounting storage as writeable encourage users to set it up.
stuck elbow
and writinng stuff in boot.py is easy, because you can remount the drive ro afterwards
crimson ferry
@mortal kernel if it’s in your personal repo, I think you can just drop the UF2 here
I’m tied up for a few hours, but would be happy to test it when I’m done
mortal kernel
I’m tied up for a few hours, but would be happy to test it when I’m done
Thank you! Here's the patched UF2.
onyx hinge
@tulip sleet can I have a moment of your time to review https://github.com/adafruit/circuitpython-build-tools/pull/104 ?
tulip sleet
<@329766224093249548> can I have a moment of your time to review https://github....
sure
onyx hinge
thank you
tidal kiln
this BMP was generated via the AIO image-formatter service
but for some reason can not set the white to transparent
opening and resaving the BMP in gimp creates this BMP
which works as expected
wondering why its not working, why the BMPs are different, etc.
test code:
import displayio
from adafruit_pyportal import PyPortal
pp = PyPortal()
odb = displayio.OnDiskBitmap("/radar_orig.bmp")
odb.pixel_shader.make_transparent(0xFFFFFF)
tg = displayio.TileGrid(odb, pixel_shader=odb.pixel_shader)
pp.splash.append(tg)
@mortal kernel UF2 tests out with the same test as earlier with successful results like 8.2.8:
• esp32-s3 can connect to PicoW AP, receive DHCP address, and exchange UDP packets
• macOS can connect to PicoW AP, receive DHCP address, ping, arp-a
I'll try a more aggressive test of station + AP and report back
mortal kernel
<@849815081251766292> UF2 tests out with the same test as earlier with successfu...
Thanks a million! I've been testing here too with no failures. Looks like it might be a keeper.
crimson ferry
@mortal kernel ran loops of every combination and sequence of start/stop_station/ap ...everything looks good 🙂
mortal kernel
<@849815081251766292> ran loops of every combination and sequence of start/stop_...
I'll submit a pull to cyw43-driver. Make that two pulls, there's a second bug I hit earlier that keeps its latest release from building in 9.0.0 alpha. Thanks again for the testing.
crimson ferry
thanks for getting it ship-shape!
mortal kernel
NP. I love a good bug.
crimson ferry
did it become clear why 8590 worked on 8.2.x despite the bugs, and 8326 worked initially on main then broke?
mortal kernel
did it become clear why 8590 worked on 8.2.x despite the bugs, and 8326 worked i...
8590 worked because it did not test the state of the link as reported by cyw43-driver and cyw43-driver doesn't check its internal state consistently so we lucked out.
The places where it does check we don't seem to hit in CP.
Did 8326 ever work for the AP restart case?
crimson ferry
no, you're right, it was an independent fix for simultaneous station + ap, and stopping AP (once)
mortal kernel
Good, I think we've got all the cases explained then.
Does having to wait for cyw43-driver cause you any problems?
crimson ferry
Does having to wait for `cyw43-driver` cause you any problems?
nope, I can keep using 8.2.x for restart AP, and stick with main for other alpha stuff
thorny jay
Does anybody has an hint on how to flash the C6 I acquired from Adafruit in January 2023 ( https://www.adafruit.com/product/5672 ) with this https://circuitpython.org/board/espressif_esp32c6_devkitc_1_n8/ ?
thorny jay
Does anybody has an hint on how to flash the C6 I acquired from Adafruit in Janu...
First I need to figure out if I should use the UART port or the USB port (UART seems to work). Then https://adafruit.github.io/Adafruit_WebSerial_ESPTool/ complain that it does not know the chip: Error: Unknown Chip: Hex: 0x2ce0806f Number: 752910447 (it is the build in CP2102N USB to UART bridge).
Then I need to figure out if I should flash from 0x000 or from 0x1000 like with this tool: https://espressif.github.io/esptool-js/
I am a bit lost, I am not sure if it already work and what to expect from each port... REPL? Mass storage (is it supported)? Should I use BLE workflow?
manic glacierBOT
tulip sleet
First I need to figure out if I should use the UART port or the USB port (UART s...
have you tried using a recent version of esptool.py instead of the web serial tool? I think the "Unknown Chip" error is the chip ID for the C6. The WebSerial tool probably needs to be updated to know about the C6 chip ID.
hmm, well, it appears there is a chip ID for C6 in the current WebSerial code.
The C6 has a limited USB port. I think you should try the USB port, not the UART port. But you may need to get the board into boto mode.
i found my C6 in the back of a shelf and will take a look
thorny jay
The C6 has a limited USB port. I think you should try the USB port, not the UART...
Thanks, I will try again... at one time I had the RGB LED flashing green, that could be Circuit Python telling me that the "Hello World" program ended successfully, but I did not find a REPL to confirm, not a mass storage.
I used the UART port, because that was the only place I could get a stable Serial... I was able to format and flash with some web tool.
I went using the boot button as I do on other ESP32.
tulip sleet
Thanks, I will try again... at one time I had the RGB LED flashing green, that c...
I am able to get it talking on either port. However, the board I have seems to be a dev sample. I bought it in Jan 2023:
$ esptool.py -p /dev/ttyACM0 chip_id
esptool.py v4.6.2
Serial port /dev/ttyACM0
Connecting...
Detecting chip type... ESP32-C6
Chip is ESP32-C6 (QFN40) (revision v0.0)
Features: WiFi 6, BT 5, IEEE802.15.4
Crystal is 40MHz
MAC: 60:55:f9:00:00:f6:98:a4
BASE MAC: 60:55:f9:f6:98:a4
MAC_EXT: 00:00
Uploading stub...
Running stub...
Stub running...
Warning: ESP32-C6 has no Chip ID. Reading MAC instead.
MAC: 60:55:f9:00:00:f6:98:a4
BASE MAC: 60:55:f9:f6:98:a4
MAC_EXT: 00:00
Hard resetting via RTS pin...
if you use esptools.py, do you also see (revision v0.0). and Warning: ESP32-C6 has no Chip ID. Reading MAC instead.?
thorny jay
I am able to get it talking on either port. However, the board I have seems to b...
Same board acquired on 25 Jan 2023. 🙂
tulip sleet
So I think the webserial tool is for a more recent version that maybe reports a proper chip id. So try uploading with esptool.py instead
thorny jay
So I think the webserial tool is for a more recent version that maybe reports a ...
Will try that, it seems that I need to boot my Linux because I did not install that on my Windows Desktop. I'll report in a few hours. 😦
tulip sleet
you should be able to pip install esptool on Windows
assuming you have Python isntall
thorny jay
I am able to get it talking on either port. However, the board I have seems to b...
esptool.py v4.3
Serial port /dev/ttyUSB0
Connecting....
Detecting chip type... ESP32-C6
Chip is ESP32-C6 (revision v0.0)
Features: WiFi 6, BT 5
Crystal is 40MHz
MAC: 60:55:f9:f6:94:d8
Uploading stub...
Running stub...
Stub running...
WARNING: Failed to communicate with the flash chip, read/write operations will fail. Try checking the chip connections or removing any other hardware connected to IOs.
Warning: ESP32-C6 has no Chip ID. Reading MAC instead.
MAC: 60:55:f9:f6:94:d8
Hard resetting via RTS pin...```So I have CP working on my C6... my C6 is not saying EEE802.15.4 and has trouble communicating with the flash. But I can erase the flash, and push CP to it with esptool.py. I did the flashing on UART on /dev/ttyUSB0 but to get the REPL I need to use the USB port that is /dev/ttyACM0 . The thing is that I don't see the mass storage, and I did not succeed with PyLeap to get the BLE workflow working. So right now it is a bit like working on an ESP32 or with MicroPython. But I am fine and happy to have it running CP. Thank you very much. 🙂 ```$ tio /dev/ttyACM0
[tio 17:28:19] tio v1.32
[tio 17:28:19] Press ctrl-t q to quit
[tio 17:28:19] Connected
Auto-reload is on. Simply save files over USB to run them or enter REPL to disable.
Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 9.0.0-alpha.6 on 2023-12-12; ESP32-C6-DevKitC-1-N8 with ESP32C6```
tulip sleet
So I have CP working on my C6... my C6 is not saying EEE802.15.4 and has trouble...
you cannot see the mass storage: the USB port is only serial -- it is a limited hardware implementation. This is not a great board for general CPy dev. It is like the ESP32 or C3
I don't see the flash chip problem on mine. That is strange
it may simply be defective. Did you buy it from us?
thorny jay
That explain a lot, that and plugging on the USB where there is no REPL. I got it from Adafruit, but never touched it because I did not read the warning saying: Please note: There is minimal support for this dev board. For example, as of the time of this writing, there is no Arduino or CircuitPython support - only ESP IDF! Please purchase if you're doing development with the C6, and OK with stuff not working 100% out of the box.
It is only a few days ago that I saw the board on circuitpython.org/download and I said to myself: "Hey, don't you have that in a box taking dust?" 😉
Actually, the product page could be updated since CP support is coming...
tulip sleet
there have been revisions to this dev board since we started selling it, but I don't know if we are still selling the original stock
thorny jay
Also https://espressif.github.io/esptool-js/ is working with it, but not the version by Melissa on https://adafruit.github.io/Adafruit_WebSerial_ESPTool/ so maybe just matter of whitelisting something. But since there is esptool.py, that's fine.
tulip sleet
your esptool is v4.3, update via pip and see if it does better about seeing the flash chip
I checked stock and it is still the original version
manic glacierBOT
thorny jay
your esptool is v4.3, update via pip and see if it does better about seeing the ...
Sorry, I had to fight with pip and esptool.py (remove it and re-install it). So now my C6 is in perfect condition and as good as yours. I just need to work around the chip limitation and find a use for it. At least I will be able to test CP release from time to time and report issues. : $ esptool.py -p /dev/ttyACM0 chip_id esptool.py v4.7.0 Serial port /dev/ttyACM0 Connecting... Detecting chip type... ESP32-C6 Chip is ESP32-C6 (QFN40) (revision v0.0) Features: WiFi 6, BT 5, IEEE802.15.4 Crystal is 40MHz MAC: 60:55:f9:00:00:f6:94:d8 BASE MAC: 60:55:f9:f6:94:d8 MAC_EXT: 00:00 Uploading stub... Running stub... Stub running... Warning: ESP32-C6 has no Chip ID. Reading MAC instead. MAC: 60:55:f9:00:00:f6:94:d8 BASE MAC: 60:55:f9:f6:94:d8 MAC_EXT: 00:00 Hard resetting via RTS pin...
tulip sleet
Sorry, I had to fight with pip and esptool.py (remove it and re-install it). So ...
excellent
slender iron
@thorny jay BLE workflow isn't on ESP chips yet. Web workflow should work on c6 though. Only the h2 doesn't have wifi.
thorny jay
<@681528999520108564> BLE workflow isn't on ESP chips yet. Web workflow should w...
Thanks, I have the web workflow working.
Maybe we need a workflow matrix (and a way to maintain that):
- Serial (no mass storage)
- Keyboard (USB Host)
- CIRCUITPY (traditional)
- Web workflow
- BLE workflow
empty salmon
What is the downside to freezing modules in the CircuitPython firmware?
tulip sleet
Takes firmware space. Frozen modules can become obsolete and have to be overridden, so users have to understand sys.path.
empty salmon
Thanks @tulip sleet. I am assuming the modules are up-to-date as the CircuitPython version itself - e.g. if someone has CircuitPython 8.2.9 then the frozen modules are current as of that release.
Of course, users may not be quick to update to the latest CircuitPython version. And modules can receive bug fixes more often than CircuitPython releases.
Also, I really appreciate the contributors. They are quick to help with answers 👍🏼👍🏼
tulip sleet
Thanks <@329766224093249548>. I am assuming the modules are up-to-date as the Ci...
No, we don't update the frozen modules on stable releases every time. Sometimes there are major changes, and we don't have the mechanisms for thoroughly testing the frozen modules. 8.2.9 has not had its frozen modules updated in a while. Generally for a stable release, we will update modules that we know have a bug that needs fixing.
We update more often on the alpha/beta releases.
empty salmon
Oh. Good detail to know. I was not aware.
tulip sleet
it's based on support experience, and a few things that went wrong. We are not hesitant to make new releases: it's not a lot of work to make a new releases, and there are plenty of integers. But we don't want to make a stable release that is a regression.
empty salmon
Really appreciate the insights
tulip sleet
yw!
pulsar sleet
How does circuit python handle memory. Are object placed one after another or is there blocks that small objects go in
like blocks of memory for smaller objects
stuck elbow
How does circuit python handle memory. Are object placed one after another or is...
one after the other, with long-lived objects placed at the other end
pulsar sleet
Ok thanks
stuck elbow
there really isn't enough memory to do many of the smart tricks that big python does
pulsar sleet
what is the pallette object in displayio. Is it just a set of colors. If it is then could I just make one and use that on a whole bunch of OnDiskBitmaps. All my bitmaps are 256 colors
blissful pollen
what is the `pallette` object in displayio. Is it just a set of colors. If it is...
Exactly. For example if pallette color 1 is 0xff2255. If that mapping holds for all bitmaps you can share
pulsar sleet
Ok thank you. I need this because I have memory issues and ~6 bitmaps all having 4096 byte (256 colors * sizeof(_displayio_color_t)) pallettes does not help
pulsar sleet
I tried to make the palette get allocated once and reused. I didn't get a error and my memory errors were fixed (so far) but the colors are sometimes messed up a bit. All the bitmaps are 256 indexed colors. What I did is in OnDiskBitmap.c I defined a pointer that then when creating the palette I check if the palette is NULL and if it is then I would allocate space for the palette and construct the object. I will upload my modified OnDiskBitmap.c file and a image
the logos are supposed to be this
pulsar sleet
here is my code
devout jolt
I tried to make the palette get allocated once and reused. I didn't get a error ...
You may want to move this to #help-with-circuitpython as this isn't a dev issue. LEDs act different than screens so you'll usually need to process the images to look more correct. Here's one article about doing that: https://learn.adafruit.com/image-correction-for-rgb-led-matrices?view=all Also Liz has some specifc tips for team logos here: https://learn.adafruit.com/led-matrix-sports-scoreboard/prep-the-team-logos
pulsar sleet
You may want to move this to <#537365702651150357> as this isn't a dev issue. L...
I used the code in that article to generate the images. The images were fine until I modified the ondiskbitmap file
devout jolt
I used the code in that article to generate the images. The images were fine unt...
Not sure what you mean, what's the difference between "file" and "images"? But most logos are designed to work very small number of colors. When I'm making BMPs I usually try for 2, 8 or 64 colors (when converting using ImageMagick's -type palette -colors 64 options). It helps keep the palette sizes down in CircuitPython
pulsar sleet
I modified the ondiskbitmap file in circuit pythons source and that Is the cause of my errors. I used the script to download images that was provided in the article and they worked until I modified the OnDiskBitmap.c file
devout jolt
I modified the ondiskbitmap file in circuit pythons source and that Is the cause...
ah got it
stuck elbow
It does look like my palettes are different
maybe there is an option to not remove unused colors?
you can also convert them manually in gimp
pulsar sleet
maybe there is an option to not remove unused colors?
What do you mean. I think the palette gets generated when saving the image using colors the image uses
stuck elbow
What do you mean. I think the palette gets generated when saving the image using...
you can tell it to use a predefined palette, at least you can in gimp
another manual thing you could do, is to put both images on one image, side by side, convert that to 256 colors, and then clip back each one to the individual image, but without touching the palette
devout jolt
another manual thing you could do, is to put both images on one image, side by s...
yes, this is what I've done since I do most of my BMP processing on the commandline and couldn't figure out how to tell ImageMagick to use one palette for all the images 🙂
celest marsh
hmm, I'm thinking I need to install the requirements for Python3 in order to build CP in a pipenv - i'm getting errors about dependency conflicts
running on macOS Sonoma with Python 3.11.6
pulsar sleet
another manual thing you could do, is to put both images on one image, side by s...
How can I do this?
celest marsh
oh yea, pipenv was definitely the path forward
celest marsh
woo - doing my first board make on my mac
looking forward to diving into new things
done - successful build of the grandcentral_m4_express
and, ugh, that board is at the other place 🤦♂️
guess I'm testing it out later :)
devout jolt
How can I do this?
If using ImageMagick on the commandline, I do stuff like this:
# take two images, make one image of them side-by-side
montage -mode concatenate -tile x1 img1.gif img2.gif img-all.png
# take that image, compress it to BMP3 with reduced colorspace
convert img-all.png -type palette -colors 64 -compress None BMP3:imgall_for_cirpy.bmp
And then I use CircuitPython TileGrid on the combined image to select which of the images I want:
bitmap = displayio.OnDiskBitmap(open("imgall_for_cirpy.bmp", "rb"))
palette = bitmap.pixel_shader
imgall = displayio.TileGrid(bitmap, pixel_shader=palette,
width = 1, height = 1,
tile_width = 64, tile_height = 64) # assumes each image is 64x64
# ... pick an image
imgall[0] = 0 # pick first image
imgall[0] = 1 # pick second image
Opened up my draft pull request on first steps towards a unified socket handler here: https://github.com/adafruit/Adafruit_CircuitPython_Requests/pull/146
Would love any feedback if this is something I can continue to push through.
pulsar sleet
That would be a lot easier but I figured it out. I used image magick to combine the images then split them localy on my pc. Then I renamed the files to the team names with a python script that didn't do everything perfectly so
pulsar sleet
I am still having color issue but they are worse. The palettes on the images are the same
ashen whale
@atomic summit (or @ anyone who might know) I'm building a KMK split keyboard with a couple of FeatherS3s and only now just found that BLE isn't fully working, with ESP-32 S3 apparently? Is it clear what does and doesn't work and what sort of effort is still needed to get it done?
stuck elbow
<@195765176035835904> (or @ anyone who might know) I'm building a KMK split keyb...
a keyboard won't work
ashen whale
And are there workarounds of any sort?
stuck elbow
you can use zmk or qmk instead
though I'm not sure they have the support for s3
generally esp32 boards are very power hungry, so not many people want to use them for keyboards
ashen whale
On ZMK, there should be support in Zephyr, but not directly in ZMK. I don't think there is in QMK.
I understand the power hungry aspect, sure.
stuck elbow
most people fall back to nrf52
stuck elbow
let me find the issue for you
ashen whale
thanks
ashen whale
Ah, well, looks like espressif fixed dynamic services on their end so it may be coming to CP.
stuck elbow
what works right now is advertising
stuck elbow
Ah, well, looks like espressif fixed dynamic services on their end so it may be ...
yes, but it's not planned right now by Adafruit, so unless someone else works on it, it may take a while
there are always too many things to work on
ashen whale
Ah well, rats. I know, they're spread thin.
stuck elbow
I have a keyboard that waits for ble support myself: https://hackaday.io/project/184163-vegemite-sandwich-keyboard
ashen whale
Oh, yes, I saw that just the other day! Cool kit!
stuck elbow
works as wired so far
ashen whale
That's probably what I'll do.
stuck elbow
I suppose I could make it work with espnow and a dongle
ashen whale
I'll build it, get it working in KMK with all the other bits, then when BLE arrives on S3 (and is better implemented in KMK), hook up the batteries.
So the dongle woudl be a USB device on the computer and the halves would chat to it via espnow?
stuck elbow
yeah
ashen whale
Not a bad idea... So espnow could just relay the hid reports? But for the halves to stay synched they'd need to talk to each other, too. Could have KMK on all three devices and a espnow transport.
Or keep the halves connected and just send reports.
midnight ember
Spent part of my morning rewiring the TFT featherwing to have backlight pwm capability. The only place I've seen this documented is in the adafruit forums.
Started my circuit python journey with an NRF52840 board which the LITE mod was designed to work for. I've seen no documentation about requiring to change that pin location to work with an ESP32-S2 or S3.
Unsure if anyone wants to document this with the TFT Featherwing V1 or V2
There are power draw implications for screen dimming that I feel like should be documented for those attempting to put the power hungry TFT to sleep until touched.
manic glacierBOT
