slender iron
#

you could reference micropython too

#

are you wanting to learn to port or are you wedded to that board specifically?

manic glacierBOT
manic glacierBOT
#
kvc0
[adafruit/circuitpython] New comment on issue #7883: Fix \`abs\(\)\` warning in \`vectorio/Circle\.c\`

That abs on radius should definitely be removed. Thanks for noticing!

x&y math should have abs(). Circles are placed by their center point, so the math only needs to be concerned with the 1st quadrant. The other 3 are symmetrically mirrored with positive math. You could factor out the abs by doing signed math up to the end, but I think you might have to store 1 more variable if you did so. Dubious that it would read any better :-)

manic glacierBOT
manic glacierBOT
jaunty juniper
#

oh no ! All the cookiecutter libraries are impacted by the jQuery issue !!!

mystic flume
#

I'm having some issues around circuitpython hanging when using displayio. My current circuit uses an external SH1106 display, which is powered on and off using a separate controllable voltage regulator. I need to do this to limit power drain in deep sleep. The I2C rails are also connected to this switched power supply. My problem arises when the program ends - the power supply is turned off, but then I think circuitpython tries to display blinka (or an error message if there is a crash). This causes circuitpython to hang, and I am unable to connect via USB. I can see my laptop recognises that the USB device has stopped responding and eventually disconnects it. Access to the flash drive also stops working at this point

#

If I leave the display powered on then everything works fine. I've tried CIRCUITPYTHON_TERMINALIO=0 in the makefile - but still get the same problem

slender iron
#

@mystic flume call release_displays() before sleeping

mystic flume
#

I think it would be really useful to have an option to stop any terminal (and blinka) output to the display, either as an option in boot.py or when creating the displat

#

It's more of an issue during development, my device keeps freezing during testing if I get an exception

jaunty juniper
#

you could use atexit to release the display ?

mystic flume
#

@jaunty juniper I was just thinking that!

jaunty juniper
#

(as a workaround)

mystic flume
#

I'll give it a go

#

Ah - that works

#

Thanks folks

slender iron
#

generally freezes are loops that should be checking for interrupted state 🙂

#

a debugger can help find them

#

though most of those loops will keep usb alive

mystic flume
#

I'm still getting an error on soft reboot saying pin D8 is in use after release_displays is called

jaunty juniper
#

which is what ? The SCL pin ?

mystic flume
#

Sorry yes

slender iron
#

looks like I2CDisplay doesn't clear the never_reset properly

mystic flume
#

I've found that deiniting the i2c bus in an atexit call fixes this bug

slender iron
#

which will prevent it from being reset automatically

#

👍 that'll work

#

explicit deinit overrides never_reset

mystic flume
#

Yep - that works well enough for me now

#

Thank you all for your help - I can get back to my nerding now!

manic glacierBOT
#
dorinclisu
[adafruit/circuitpython] Issue opened: #7885 Using plain terminalio with displayio \- ValueError: Tile index out of bounds

CircuitPython version

Adafruit CircuitPython 8.0.5 on 2023-03-31; Raspberry Pi Pico with rp2040

Code/REPL

import displayio
import board
import busio
import terminalio

from adafruit_st7735r import ST7735R


displayio.release_displays()
tft_spi = busio.SPI(clock=board.GP18, MOSI=board.GP19)
tft_cs = board.GP17
tft_dc = board.GP16
tft_reset = board.GP20

displayio.release_displays()
tft_bus = displayio.FourWire(tft_spi, command=tft_dc, chip_sel...
#
anecdata
[adafruit/circuitpython] New comment on issue #7885: Using plain terminalio with displayio \- ValueError: Tile index out of bounds

I'm able to do it this way:

import sys
import board
import displayio
import terminalio

display = board.DISPLAY  # or equivalent external display library

splash = displayio.Group()

fontx, fonty = terminalio.FONT.get_bounding_box()
term_palette = displayio.Palette(2)
term_palette[0] = 0x000000
term_palette[1] = 0xffffff
logbox = displayio.TileGrid(terminalio.FONT.bitmap,
                            x=0,
                            y=0,
                            widt...
#
kvc0
[adafruit/circuitpython] New comment on issue #7883: Fix \`abs\(\)\` warning in \`vectorio/Circle\.c\`

@dhalbert widening. So that circles at 256 < x or 256 < y can still be handled. I have some Adafruit displays with more pixels than that ;-)

If you multiply 257 * 257 int16's what do you get? :-) On the other hand, if you widen to int32, you can support nearly every positive position of int16 x and y. Ideally we'd widen to uint32 instead though because (2^15)^2 * 2 is 2^31, and that's 1 greater than 2^31 - 1! But it fits no sweat in 2^32. Int16.minval x and y will position at 0 I think. So v...

jaunty juniper
#

@slender iron I think I got the jquery issue wrong, though I'm not sure that I understand what is going on. There was something about the version of the theme being invisibly forced on older libraries or something ? I believe @lone axle would know about that.
The issue is that right now, none of the Adafruit libraries that I looked at have a working bottom left panel.

slender iron
#

I haven't been following it so I'm not sure what the right thing to do is

manic glacierBOT
turbid radish
brazen hatch
#

Uhh. Why are we returning 3.3 on rp2 when on esp we return None?

#

Isn't it a horrible idea presenting a fake value?

slender iron
#

are you using it?

brazen hatch
#

Not really..

slender iron
#

its probably a mistake

brazen hatch
#

Shall I None it in my ttgo pr?

slender iron
#

sure, that's fine

manic glacierBOT
still zephyr
#

@slender iron Question for the DVI PR, Testing now, would adding elements to a displayio.group would have any effect in the display dimensions?

slender iron
manic glacierBOT
#
kvc0
[adafruit/circuitpython] New comment on issue #7883: Fix \`abs\(\)\` warning in \`vectorio/Circle\.c\`

So I personally prefer to be explicit when bit width matters... I always forget what the rules are for implicit widening within a math expression :-( and whether I'm on an 8, 16, 32 or 64 bit pointer machine :-(, so it helps me read it. Maybe it's helpful to other people reading it to be explicit also? It's otherwise implicitly dependent on the size of int (or ptr, again I'm not sure, and being explicit makes me sure).

Also, I notice that below even after abs() we're using int16_t. On ar...

still zephyr
# slender iron it shouldn't

mmmm, will investigate some more then... Having different behaviour that I normally do in a pyportal in some of my libraries. Will try to see what is hapenning. Thanks for the info 🙂

slender iron
#

kk, sounds good. definitely could be a bug

still zephyr
#

kk will try to reduce it to simple code if so, and comment in the PR is so (y)

slender iron
#

thanks!

thorny jay
#

I am discovering Feather DVI. I took the latest image but is it know issue that the first character is missing in the REPL?

slender iron
#

I haven't seen that

thorny jay
#

It does not seems to be my screen, but I will try another one.

thorny jay
# slender iron I haven't seen that

It is my screen (actually an LG beamer) and I have other doing that.
On my big LG OLED there is a similar issue, that look like "overscan".
(overscan will typically eat the screen boarder for a full HD source, I have never seen that acting on low res signal)
However, there is a "Analyse Signal" mode that when enabled will display everything correctly.

#

Maybe one thing "special" about most TV/Screen at home is that over here in Belgium we are 50Hz (also PAL). But our TVs, expecially with DVI input should be able to display a 60Hz signal without problem.
So I am curious about other positive or negative report and from where they are coming.

edgy edge
slender iron
#

this made my jaw drop

#

after getting poor search results

edgy edge
manic glacierBOT
#
bill88t
[adafruit/circuitpython] Issue opened: #7887 ESP32 ability to disable serial

As I am doing the t-energy port, I discovered that as the battery discharges the serial chip spams KeyboardInterrupt's to the serial console.
It wouldn't be an issue since I could just configure the usb_cdc console to disable serial.
But that is impossible on esp32 since there is no usb_cdc.

This board hates me.

This could alternatively be solved by #7857, as non-interrupting data can be ignored.

thorny jay
manic glacierBOT
slender iron
#

it's closer to 16x9

lone axle
#

@tulip sleet for the warnings about vectorio Circle. Did you have to do anything specific in the make command to get those to be shown? I'm trying out builds of a few different ports, but not seeing that warning when I build from current main.

tulip sleet
lone axle
#

Thank you, I'll try it out on that new port.

manic glacierBOT
#
stonehippo
[adafruit/circuitpython] Pull request opened: #7889 Added notes re the RTL8720D pins

The Wio Terminal includes a RealTek RTL8720D as a companion to the main chip to provide WiFi and Bluetooth capabilities via eRPC over a UART connection. The WIO Terminal schematic labels some pins as the RXD/TXD for the UART, and that was captured in the board definition for CircuitPython. However, these pins may be used for logging in another mode, but they are not the main pins used to communicate with the RTL chip. The correct configuration is RX on PC24/pad 2 and TX on PB24/pad 0 of SERCO...

#
FoamyGuy
[adafruit/circuitpython] Pull request opened: #7890 remove abs\(\) from radius

Attempt to resolve #7883

This removes the unnecessary absolute value call from radius variable.

Honestly I don't quite follow the rest of the conversation about x and y calculations and casting. If there are other proposed changes that need to be tested out I'm happy to try those if someone can point me more specifically to what the code would look like.

manic glacierBOT
#
tannewt
[adafruit/circuitpython] Pull request opened: #7891 Add address\_little\_endian and fix display memory reuse

Add address_little_endian for epaper displays with little endian
(low byte first) addresses.

Also clears allocated display and display bus memory so it has a
known state. The acep member wasn't always set so it varied
accidentally.

Fixes https://github.com/adafruit/circuitpython/issues/7560. May fix https://github.com/adafruit/circuitpython/issues/7778. Fixes https://github.com/adafruit/circuitpython/issues/5119.

manic glacierBOT
#
jposada202020
[adafruit/circuitpython] New comment on pull request #7880: Add PicoDVI support

As discussed in Discord.. I think I reduced the code as much as I can... hopefully

Tested in
Adafruit CircuitPython 8.1.0-beta.1-36-g7d02bff6b on 2023-04-20; Adafruit Feather RP2040 DVI with rp2040

Problem


import board
import displayio
from bitmaptools import draw_line
display = board.DISPLAY
group = displayio.Group()

palette = displayio.Palette(1)
palette[0] = 0xFFFFFF

a2 = displayio.Group(x=0, y=0, scale=1)
a2bitmap = displayio.Bitmap(300, 300, 2)
tile...
still zephyr
#

@slender iron ^^

#

Got a ValueError: width must be 1-32767 loading a bitmap_font in the DVI too, but I need to reduce the code to a minimum. and verify that is not the library.

manic glacierBOT
slender iron
#

@still zephyr please file a new issue. They are easier to keep track of

#

the default display will be 320x240 when in color mode

manic glacierBOT
#
Neradoc
[adafruit/circuitpython] New comment on issue #7875: Web Workflow CORS implementation too restrictive

I would say the device/server side is fixed if CORS support is desired (What problem is it solving??? Example, please).

Here is how I understand this:

The first implementations of tools using the web workflow were code.circuitpython.org trying to load API endpoints from the circuitpython.local web workflow. This would cause the browser to send a CORS preflight request to the board, so that request had to be allowed to go through, but not from any address for security reasons. I was my...

manic glacierBOT
#
FoamyGuy
[adafruit/circuitpython] Pull request opened: #7892 add minimum validation for tilegrid size in terminalio\.Terminal

Attempts to resolve #7885

This PR adds minimum size validation that enforces the TileGrid being no smaller than 2x2, which is arguably still too small to be practically useful. Perhaps a higher limit would be appropriate?

If there is a desire to allow 1xN sized TileGrids the logic in this will have to get reworked.

Also something for consideration would be adding an example to the docs of terminalio module that illustrate how to use it. As noted in the issue there isn't currently any...

manic glacierBOT
manic glacierBOT
#
jposada202020
[adafruit/circuitpython] Issue opened: #7894 RP2040 DVI Zooming bitmap

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.1-36-g7d02bff6b on 2023-04-20; Adafruit Feather RP2040 DVI with rp2040

Code/REPL

import board
import displayio
from bitmaptools import draw_line
display = board.DISPLAY
group = displayio.Group()

palette = displayio.Palette(1)
palette[0] = 0xFFFFFF

a2 = displayio.Group(x=0, y=0, scale=1)
a2bitmap = displayio.Bitmap(300, 300, 2)
tile2 = displayio.TileGrid(a2bitmap, pixel_shader=palette, x=0,...
lone sandalBOT
manic glacierBOT
manic glacierBOT
manic glacierBOT
#
dglaude
[adafruit/circuitpython] New comment on issue #7894: RP2040 DVI Zooming bitmap

First thank you for your piece of code, I could not have progress without reading your code.

I changed a few things to let you check your screen rendering.
First I make the bitmap exactly the size of the DISPLAY.
a2bitmap = displayio.Bitmap(display.width, display.height, 2)

Then I draw a boarder one pixel inside.
Finally I use a sleep loop to stay in the program and not exit in the REPL.

`import time

import board
import displayio
from bitmaptools import draw_line
display =...

thorny jay
#

Just checking about the Feather RP2040 DVI.
If I take the FeatherWing AirLift, do I have almost automatically most of the PyPortal project ready to be put on the big screen?
What is missing:

  • Light sensor
  • Touch screen
  • M0+ rather M4
  • Less colour(?)
    Is anybody planning to create a glue library that will make porting PyPortal code to such a setup?
manic glacierBOT
manic glacierBOT
#
Neradoc
[adafruit/circuitpython] Issue opened: #7896 Bottom panel missing in libraries docs\. \(jquery missing\)

Similar to #7799 most Adafruit libraries have a jquery error that makes the bottom left panel non-working in the RTD docs. It seems that new libraries from the past weeks are not affected (I added a library to RTD last week without the issue).

As mentioned in that PR: it seems that jquery gets "loaded/injected" into the page after the page finishes loading, so it doesn't work when it's used the first time in the page. The fix forces jquery to be included earlier in the page. I looked at ad...

manic glacierBOT
crimson ferry
#

os.getenv('WIFI_SSID') & os.getenv('WIFI_PASSWORD') seems to be a de facto standard for connecting to native wifi without assuming that Web Workflow auto-connect is enabled (via CIRUITPY_WIFI_SSID & CIRCUITPY_WIFI_PASSWORD). Is this documented somewhere? Do we intend for all example code to migrate from secrets.py to this?

manic glacierBOT
wraith crow
#

Is the documentation on doc.circuitpython.org generated directly from the "//|" lines in the code? i.e. If I find a documentation error, is a PR changing the matching text in the module all that's needed?

jaunty juniper
#

yep

manic glacierBOT
#
dglaude
[adafruit/circuitpython] Issue opened: #7898 Cannot use adafruit\_framebuf to draw on picodvi\.Framebuffer \(multiple issues\)

CircuitPython version

8.1.0-beta.1-39-gd078bc3ae

Code/REPL

#Trying to draw in the framebuffer using adafruit_framebuf

import displayio
displayio.release_displays()

import time
import board
import picodvi
import framebufferio

w=640
h=480

fb = picodvi.Framebuffer(
    width=w, height=h, color_depth=1,
    clk_dp=board.CKP, clk_dn=board.CKN,
    red_dp=board.D0P, red_dn=board.D0N,
    green_dp=board.D1P, green_dn=board.D1N,
    blue_dp=bo...
thorny jay
#

Hi, the issue above is a bit convoluted... I have been trying to change resolution of the DVI output, and found no example code. I was successful in that.
Then I have been trying hard to draw directly in the framebuffer and try to figure out the proper way to do that... and that is where I failed so far. So it is more like a call for help.

#

I don't know what I am doing... but it is really fun.
Now is time to sleep. 💤

brazen hatch
#

Meanwhile me here porting circuitpython back to esp8266 as support was dropped all the way back in 3.x.
I want to see what happens.

thorny jay
brazen hatch
#

Well, I'm just playing around. This stuff isn't goin in main anyways, so why not.

#

I don't care if it doesnt do ssl. I want to see it do web workflow for the memes.

#

Also isn't esp8266ex a newer chip? Mine's produced in '21.
I could be wrong but eh.

spiral elk
#

My remote temp sensors still are esp8266/micropython/webrepl.

#

And modern micropython can still be wedged in an 8266 and its probably no worse than a SAMD21 in terms of capability.

manic glacierBOT
manic glacierBOT
brazen hatch
manic glacierBOT
jaunty juniper
#

ugh git/github can't auto merge adding a submodule if another module was added in the mean time 🤦

proven garnet
jaunty juniper
#

maybe I can a cheat by manually placing the new module somewhere else than at the end in the .gitmodule file 🤔

#

oh yeah that worked

onyx hinge
#

@ember iris I figured out the sphinx problem, it was a problem further down in the file (relative to the line 11 that the error kept citing) with a stray :!

manic glacierBOT
#
jepler
[adafruit/circuitpython] New comment on pull request #7862: Synthio envelope

This is updated! Now an envelope can be used similar to this, from my testing code:

envelope = synthio.Envelope(
    attack_time=0.1, decay_time=0.05, release_time=0.2, attack_level=1, sustain_level=0.8
)
melody = synthio.MidiTrack(
    b"\0\x90H\0*\x80H\0\6\x90J\0*\x80J\0\6\x90L\0*\x80L\0\6\x90J\0"
    + b"*\x80J\0\6\x90H\0*\x80H\0\6\x90J\0*\x80J\0\6\x90L\0T\x80L\0"
    + b"\x0c\x90H\0T\x80H\0\x0c\x90H\0T\x80H\0",
    tempo=240,
    sample_rate=48000,
    waveform=sine,
    ...
ember iris
turbid radish
#

Have you some CircuitPython/MicroPython/Python news?? Please send links to cpnews-at-adafruit-dot-com for newsletter consideration. Thanks!!

manic glacierBOT
#
jdswope
[adafruit/circuitpython] Issue opened: #7901 ItsyBitsy M4 Express Deep Sleep with External Wake

CircuitPython version

Adafruit CircuitPython 8.0.5; 04/23/2032 ItsyBitsy M4 Express

Code/REPL

import gc
import board
import adafruit_ssd1306
import adafruit_tca9548a
import alarm
import time
import digitalio

gc.collect()  # Garbage Collector to free up residual space

# Create the TCA9548A object and give it the I2C bus
tca = adafruit_tca9548a.TCA9548A(board.I2C())

led = digitalio.DigitalInOut(board.LED)
led.direction = digitalio.Direction.O...
#
jdswope
[adafruit/circuitpython] Issue opened: #7902 ItsyBitsy M4 Express deep sleep with external wakeup

CircuitPython version

Adafruit CircuitPython 8.0.5; 4/23/2023 using IstyBitsy M4 Express

Code/REPL

import gc
import board
import adafruit_ssd1306
import adafruit_tca9548a
import alarm
import time
import digitalio

gc.collect()  # Garbage Collector to free up residual space

# Create the TCA9548A object and give it the I2C bus
tca = adafruit_tca9548a.TCA9548A(board.I2C())

led = digitalio.DigitalInOut(board.LED)
led.direction = digitalio.Direct...
manic glacierBOT
#
anecdata
[adafruit/circuitpython] Issue opened: #7903 ESP\-NOW error 0x306a if channel is not 1

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.0-80-g22636e056 on 2023-03-29; Adafruit Feather ESP32-S2 TFT with ESP32S2

Code/REPL

Code and initial testing commentary here (also some on Discord):
https://gist.github.com/anecdata/f46a1d07add5fc60cfbcf42dc7be6528

Behavior

The most limiting issue right now I think is that if peer channel is set to anything except 0 (default; becomes channel 1) or 1, send will result in `espidf.IDFError...

orchid basinBOT
tulip sleet
#

that is the only Learn Guide that uses the library.

lone axle
lone axle
tulip sleet
turbid radish
#

The PoM Newsletter is ready to crib for the Discord Notes

manic glacierBOT
slender iron
manic glacierBOT
manic glacierBOT
orchid basinBOT
manic glacierBOT
#
Neradoc
[adafruit/circuitpython] New comment on issue #7875: Web Workflow CORS implementation too restrictive

Have you tested with the absolute newest ?
#7876 fixes the code limiting all access to the internally known names.

The OPTIONS request here is likely to be the one made by the web workflow page to get the list of allowed actions, to know if the drive is writeable (it tests the presence of DELETE in Access-Control-Allow-Methods).

https://github.com/adafruit/circuitpython/blob/adfb9b196bfa328b183df2412cf9bde7f9e397db/supervisor/shared/web_workflow/static/directory.js#L46-L53

Note ...

slender iron
lone axle
#

That thing looks awesome!! The LED animations when touched are a really nice touch.

tulip sleet
#

i can read libraries and/or blinka

lone axle
#

I can take the other.

midnight ember
#

20 authors, is that a new record? that's a lot of new contributors.

onyx hinge
#

Hi all! sorry for typing out of turn .. we are at circuitpython sprints day 1 and the number of people here is amazing. all of us here are working to get everybody going, whether that's extending the open spaces and letting them learn on circuitplayground expresses, or starting to work on issues in the libraries. Group hug from us here at pycon!

#

we had planned to come by at least in an audio capacity but it's just a bit crazy 🙂

tulip sleet
#

i will paste this in -- thanks!

midnight ember
#

apparently my mic isn't working

#

exactly as i would have said it 🤗

slender iron
#

😄

midnight ember
#

That might be JohnG?

tulip sleet
#

[From Boston Python slack events channel]
@Scott Gustafson
will give us an introduction to running Python on microcontrollers using CircuitPython. He showed us a sneak peek of some of the content in the discussion at after the last meeting of the #study-group and a good time was had by all, hope you can make it!
https://www.meetup.com/bostonpython/events/293092896

Meetup
Presentation Night: Introduction to CircuitPython on Hardware, Thu,...

Introduction to CircuitPython on Hardware

An introduction to running CircuitPython on micro-controllers. From blinking a LED to building a web sever. Scott will cover

midnight ember
#

frequency for overclocking?

lone axle
#

I think underclocking was the use-case they mentioned in the PR. To save power.

midnight ember
#

iMX + synthio will be amazing.

#

I don't even understand asyncio, Neradoc got that working I have no clue how it works 😛

#

my mic is working on windows, role change?

#

yup, discord reset the input device messing with the fpv camera stuff

#

OnDiskGif palette is that new?

lone axle
#

Yes, prior to the PR OnDiskGif had to use ColorConverter. The new PR adds support for using Palette instead.

thorny jay
midnight ember
#

That's all beyond my understanding. It worked so that's how it shipped.

lone axle
crimson ferry
#

@thorny jay the example in Dan's guide is really good, that structure goes a long way

midnight ember
#

Seems like a question for Kattni?

turbid radish
#

The guide that defines SPDX has a link to all valid codes

still zephyr
#

If my memory is correct we added one license for display_text, Ill take a look

thorny jay
#

I think the problem is with all the non GPL licence. 🙂

lone axle
#

😸

midnight ember
#

😾 lemme outside

austere acorn
still zephyr
#

Foamyguay we added OFL to the licenses directory for in display_text.. so we could add the BSD one too

silver tapir
#

ty all.

thorny jay
#

Thanks

still zephyr
#

thank you

midnight ember
#

Thank you for hosting @slender iron

#

Circuit Python to HDMI

thorny jay
#

@slender iron I was trying to draw circle or turn on pixel on the DVI. The piece of code I had was creating a bitmap, using bitmaptools to draw, then display the bitmap with displayio. Adafruit_framebuf did seems like the way to go to avoid consuming twice the memory. But I have no clue how to make that work, maybe some typing secret that I don't master in python.

#

I am maybe also interested in some ulab magic where the framebuffer would be an array and you could do math to compute the next frame... but this is way above my head anyway.

slender iron
#

Here is the notes document for next Monday’s CircuitPython Weekly meeting. It is at the normal time of 11am Pacific / 2pm Eastern here on Discord. Everyone is encouraged to attend! Please add your hug reports and status updates even if you’ll be attending the meeting - it’s super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and we’ll read them off during the meeting. Hope to see you there! <@&356864093652516868> https://docs.google.com/document/d/1JbwTjyVDqmIo2do9EDXZkUYYMgTv97QTfM2nBxRK3HM/edit?usp=sharing

slender iron
slender iron
#

I bet we could reuse the bitmap code to write to the framebuffer bitmap

thorny jay
blissful pollen
#

A FB really is just a bitmap. That's pretty much how I'm using it go OnDiskGif

thorny jay
slender iron
manic glacierBOT
steady garden
slender iron
steady garden
#

ok I have ~4 questions. 1. the GPS class has two competing(?) attributes, self.horizontal_dilution and self.hdop. As far as I can tell, they come from different parts of the message or different protocols. Is what I've done enough to disambiguate them?

slender iron
#

I think the GSA vs GGA annotation makes sense

steady garden
#

cool, ok. q2: attributes true_track and mag_track are unused. do you know what they are?

slender iron
#

I don't know what happened to that code

steady garden
#

hmm ok. is it worth defining them do you think? If the relevant code is gone, I'm tempted to take them out

#

otoh, might be nice to have if someone comes back to reimplement the missing stuff

slender iron
#

I'd remove them if not set but its worth figuring out when they were removed and why

steady garden
#

ok, I'll do some research

slender iron
#

thanks!

steady garden
#

q3: after a bit of googling, I'm sort of sure that sat_prns is "Satellite pseudorandom noise code". is that right?

slender iron
#

that I don't know

steady garden
#

ok, I think that's it, the two unused vars are in the same boat

#

can I tag you on this PR when it's ready for review?

slender iron
#

sure though I think you understand it better than I do now

steady garden
#

haha ok. well much appreciated!

slender iron
#

I'm ok documenting them as something and having folks correct if needed

#

I'm only around another hour or two but can look tomorrow if needed

steady garden
#

sure, no real deadline on this

manic glacierBOT
#
jposada202020
[adafruit/circuitpython] Issue opened: #7904 displayio\.bitmap "Space" characther given ValueError

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.0-62-g4986ad6d6-dirty on 2023-03-30; Adafruit PyPortal Titano with samd51j20

and

Adafruit CircuitPython 8.1.0-beta.1-36-g7d02bff6b on 2023-04-20; Adafruit Feather RP2040 DVI with rp2040

Code/REPL

import board
import displayio
from adafruit_bitmap_font import bitmap_font
from adafruit_display_text import label, bitmap_label

display = board.DISPLAY
main_group = displayio.Group()
MEDIUM_FONT...
manic glacierBOT
manic glacierBOT
#
casainho
[adafruit/circuitpython] Issue opened: #7905 Web workflow: main\.py will not run if the configured wifi network is not available at boot

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.1, board ESP32-S3-DevKitC-1-N8R2.

If I do microcontroller.reset() on safemode.py, as soon the configured wifi network is available, the, main.py will then run.

NOTE: this issue did not happen to me on CircuitPython 7.xx.

Code/REPL

import board
import time
import supervisor
import simpleio
import asyncio
import ebike_data
import vesc
import m365_dashboard
import simpleio

import supervis...
manic glacierBOT
#
anecdata
[adafruit/circuitpython] Issue opened: #7906 Pico W sometimes won't start AP immediately after stopping Station

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.1-46-gb5a26c7f9 on 2023-04-24; Raspberry Pi Pico W with rp2040

Code/REPL

import os
import traceback
import microcontroller
import supervisor

time.sleep(3)

while True:
    try:
        print(f"starting station...", end=" ")
        wifi.radio.start_station()
        while not wifi.radio.connected:
            wifi.radio.connect(os.getenv("WIFI_SSID"), os.getenv("WIFI_PASSWORD"))
         ...
manic glacierBOT
manic glacierBOT
proven garnet
#

Following up on the meeting I must have the incorrect Scott for the Boston meetup 🤣

#

Ah, I do

#

Well, still exciting!

manic glacierBOT
#
JiapengLi
[adafruit/circuitpython] New comment on pull request #7844: Add YD\_ESP32\_S3

@bill88t I would like to change it to use qio, after change from dio to qio, the board fails booting, do you have any expierence?

diff --git a/ports/espressif/boards/yd_esp32_s3_n16r8/mpconfigboard.mk b/ports/espressif/boards/yd_esp32_s3_n16r8/mpconfigboard.mk
index 2120ba97c..d2c477951 100644
--- a/ports/espressif/boards/yd_esp32_s3_n16r8/mpconfigboard.mk
+++ b/ports/espressif/boards/yd_esp32_s3_n16r8/mpconfigboard.mk
@@ -5,9 +5,11 @@ USB_MANUFACTURER = "VCC-GND"

 IDF_T...
manic glacierBOT
brazen hatch
#

Does anybody know how make flash is supposed to work?

lone sandalBOT
manic glacierBOT
wraith crow
brazen hatch
#

I mean, if we need to add the params.. It's as good as an alias.

wraith crow
#

No you don't need to add the address/reset/etc parameters, just the port

brazen hatch
# manic glacier

Oh, ok then.
Bcz there is this.
And I really have never used automatic flashing.
I only used my aliases which did it with auto settings.

manic glacierBOT
manic glacierBOT
#
bill88t
[adafruit/circuitpython] New comment on pull request #7844: Add YD\_ESP32\_S3

Flashing with:
esptool.py --chip esp32s3 -b 2000000 -p /dev/ttyACM0 write_flash --verify -fm dio -ff 80m 0x0 build-yd_esp32_s3_n16r8/firmware.bin works.
Flashing with: esptool.py --chip esp32s3 -b 2000000 -p /dev/ttyACM0 write_flash --verify -fm qio -ff 80m 0x0 build-yd_esp32_s3_n16r8/firmware.bin does not work. It doesn't boot.

ESP-ROM:esp32s3-20210327
Build:Mar 27 2021
rst:0x7 (TG0WDT_SYS_RST),boot:0x8 (SPI_FAST_FLASH_BOOT)
Saved PC:0x400454d5
SPIWP:0xee
mode:QIO, clock d...
manic glacierBOT
#
andywarburton
[adafruit/circuitpython] Issue opened: #7907 Crash into the HardFault\_Handler\.

CircuitPython version

Adafruit CircuitPython 7.2.0 on 2022-02-24; FeatherS2 with ESP32S2
Board ID:unexpectedmaker_feathers2

Code/REPL

[13:52:08.944] Disconnected
[13:52:09.951] Warning: Could not open tty device (No such file or directory)
[13:52:09.951] Waiting for tty device..
[13:52:11.976] Connected
You are in safe mode because:
CircuitPython core code crashed hard. Whoops!
Crash into the HardFault_Handler.
Please file an issue with the contents...
#
bill88t
[adafruit/circuitpython] New comment on pull request #7844: Add YD\_ESP32\_S3

Oh wait, your's can't boot either.

I would like to change it to use qio, after change from dio to qio, the board fails booting.

I initially though yours did.
I have no idea honestly. But it certainly seems like our flash modules won't work with qio or qout.
For further discussion please open a new issue and ping me at it.

Some additional info I found while researching this issue:
https://docs.espressif.com/projects/esptool/en/latest/esp32s3/advanced-topics/spi-flash-modes.html...

manic glacierBOT
manic glacierBOT
tulip sleet
manic glacierBOT
midnight ember
#

That was honestly funny. Scott, "Apparently I'm going to Boston". 🙂

manic glacierBOT
manic glacierBOT
#
dhalbert
[adafruit/circuitpython] New comment on pull request #7877: Add Adafruit Feather RP2040 Prop\-Maker

@ladyada

Proto board tested completely:

  • Tested all pins are mapped correctly, checking that they can drive an LED.
  • Tested external neopixel capability.
  • Tested external power switching on/off.
  • Tested I2S amp by playing an MP3.
  • Tested EXTERNAL_BUTTON as an input.
  • Tested STEMMA I2C with a BNO055
  • Tested accelerometer, including tap detection via interrupt pin, and tested state of interrupt pin
  • Tested battery power capability

I2S_MOD is called out in the schematic,...

stuck elbow
#

I mean how many scotts can there be

#

they are highlanders after all

midnight ember
#

Plenty of Scotts, there can be only 1 Tannewt

thorny jay
proven garnet
#

Glad my totally intended joke and not at all reading comprehension error was funny!

manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #7907: Crash into the HardFault\_Handler\.

Helping beta test this one on the UM FeatherS2 with AndyWrburton.

Adafruit CircuitPython 8.0.5 on 2023-03-31; FeatherS2 with ESP32S2
Board ID:unexpectedmaker_feathers2

Closest I can come is AdafruitIO with a DPS310 temp sensor. Your motor driver, other specific sensors, and home assistant broker I can't replicate on my setup.

I can say I had this same issue with the UM FeatherS3, it wasn't specific to the S2 or UM boards as I had the same issue with the Adafruit S3 in 7.3 a...

slender iron
#

almost was icantwait which would have been cool too

#

but I think someone had it on twitter already

manic glacierBOT
manic glacierBOT
manic glacierBOT
manic glacierBOT
#
todbot
[adafruit/circuitpython] Issue opened: #7911 DVI resolution is actually 320x240, not 640x480

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.1-48-gabb0d5e62 on 2023-04-24; Adafruit Feather RP2040 DVI with rp2040

Code/REPL

import board
display = board.DISPLAY
print("display width, height:", display.width, display.height)

Behavior

Prints out:

code.py output:
display width, height: 320 240

Description

I am not sure that 640x480 is actually possible. Most all the PicoDVI examples I've seen have been 320x240.

###...

midnight ember
#

Randomly decided to take a look into first good issues. I was like hey maybe I'll give type annotations a shot again. Almost every issue I looked at already has a PR submitted from hours ago. Almost feels like Hacktober Fest with all the random contributors. The PyCon sprints are obviously having a good impact and I hope everyone is having fun! People are knocking out type annotations over 570 days old. Reviewers, you've got your work cut out for you this week for sure. Can't wait to hear all about it in next weeks meeting.

rough rapids
#

Speaking from the sprints, we're having a blast. There were probably 20 people in the room today and the hosts are taking great care of us 😁

manic glacierBOT
manic glacierBOT
manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #7907: Crash into the HardFault\_Handler\.

My attempt failed at the 13 hour mark because it doesn't have a graceful failure try/except if the broker doesn't respond apparently. This is my first time ever using mqtt so I don't have a snippet for that part. It's mostly using the default AdafruitIO example. Circuit Python really needs to include try/except error handling with all examples for anything MQTT or Requests related. Looks like mine failed inside io.loop() and I think that's something the library itself handles.

Trac...
manic glacierBOT
#
dglaude
[adafruit/circuitpython] New comment on issue #7911: DVI resolution is actually 320x240, not 640x480

Hi,

I suggest you look at the code in this issue for a way to get a 640x480x2 display:
https://github.com/adafruit/circuitpython/issues/7898
(just ignore the afb and the circle, but the rest of the code should work)

I confirm most resolution and number of colours do fail on the Memory side.
But I manadged to go in "High Res" mode and that was my only goal.
And is why I wanted to write to the framebuffer to avoid alocating any extra bit of memory.

I also confirm that having width ...

manic glacierBOT
#
dglaude
[adafruit/circuitpython] New comment on issue #7911: DVI resolution is actually 320x240, not 640x480

I have put together a demo or high-resolution DVI output.

It create a bitmap as big as the frame buffer, so it is very inefficient.

This works for 640x480 black and white.
It seems ok in 800x480 too.
But it fail if you want to go grey scale with 2 bits per pixel.

Also, most "turtle" attempt will fail as turtle reserve a frame buffer (I guess).

So either we get an addressable frame buffer from picodvi and can reuse that.
Or you have to draw with object in displayio, but don't ex...

orchid basinBOT
#
Neradoc
[adafruit/circuitpython-org] New comment on issue #1188: Hidden board adafruit\_feather\_rp2040\_usb\_host

Hi, build artifacts from merged PRs are uploaded to Amazon S3 with the board ID, which is the name of the board directory in the Circuitpython repository, and the path in the URL used on circuitpython.org. That is the S3 link you mention.
The board list on circuitpython.org is only updated when there's a release, unless a board is added manually in which case it will be listed at the end, with no release but a link to "Absolute newest" (which might not work if there is no finished build yet).

manic glacierBOT
#
markbarna
[adafruit/circuitpython] Issue opened: #7912 Distortion with Two Adafruit 64x32 RGB LED Matrix

CircuitPython version

Adafruit CircuitPython 8.3.3 on MatrixPortal M4

Code/REPL

# SPDX-FileCopyrightText: 2020 Jeff Epler for Adafruit Industries
#
# SPDX-License-Identifier: MIT

# This example implements a simple two line scroller using
# Adafruit_CircuitPython_Display_Text. Each line has its own color
# and it is possible to modify the example to use other fonts and non-standard
# characters.

import adafruit_display_text.label
import board
im...
still zephyr
rough rapids
manic glacierBOT
crimson ferry
#

Why on Pico [W] can I set supervisor.runtime.next_stack_limit to something over 100KB, but ESP32-S2 N4R2 (QT Py) gets AttributeError: can't set attribute 'next_stack_limit'?

#

Pico [W] default stack limit is 24576, but ESP32-S2 QT Py (much more RAM) default is 16896.

slender iron
#

@crimson ferry esp inherits stack sizes from the idf

#

rp2 manages it ourselves

crimson ferry
#

esp stack is fixed always, even with CIRCUITPY_RESERVED_PSRAM=?

slender iron
#

ya. reserved psram adds psram to the idf heap

crimson ferry
#

idf must manage b/c C stack always comes from on-chip memory that has to get shared / traded-off with esp-idf memory?

slender iron
#

it manages it because of freertos

#

I think it can place them anywhere

crimson ferry
#

thanks adds deep dive into esp memory onto bucket list 🙂

slender iron
#

I don't know much about it

#

the idf starts a main task for CP

#

and the IDF sets the size of the main task stack

crimson ferry
#

and that's probably before we start to mess with PSRAM

#

a couple of people have been asking about pystack and recursion limits, so I was trying to understand the constraints better

slender iron
#

ya, its weird

#

they'll give different error. pystack exhausted vs recursion depth

#

pystack prevents large function frame allocations to the heap

rough rapids
#

hey folks, just for giggles I decided to see if I could build CP for the Feather ESP32-S2 Reverse w/ TFT I ordered. I've been following the instructions at https://learn.adafruit.com/building-circuitpython (I'm on Ubuntu 22.04) and it's been going smoothly up until the actual C compilation step. It looks like it's complaining at not finding ninja - is that a build system requirement now or something I just forgot to config to not use?

Adafruit Learning System
Building CircuitPython

How to build CircuitPython yourself on different platforms

slender iron
#

so you will need it

rough rapids
slender iron
#

np

manic glacierBOT
manic glacierBOT
#
tannewt
[adafruit/circuitpython] New comment on issue #7911: DVI resolution is actually 320x240, not 640x480

Trying to create a duplicate of board.DISPLAY using picodvi.Framebuffer yields "invalid height" when trying to do 320x240x8 or "MemoryError: memory allocation failed" when trying to do 640x480x2 or 640x480x4.

Please post this code. x4 isn't supported.

These are the supported arguments and the resulting framebuffer. The larger versions will be hard to allocate from within CP but may be possible from board_init().

Grayscale:

  • 640x480x1 -> 640x480x1
  • 800x480x1 -> 800x480x1...
rough rapids
#

now to watch as the build completely destroys this poor little Pentium Silver

slender iron
#

lap warmer

manic glacierBOT
rough rapids
#

Wrote 2614784 bytes to build-adafruit_feather_esp32s2_reverse_tft/firmware.uf2 🎉

manic glacierBOT
slender iron
#

@devout jolt I'm not sure why you are confused

#

the object's height and width don't match the given parameters

devout jolt
slender iron
#

it is outputting 640x480

#

but that's not the framebuffer size

#

color framebuffers are halved

devout jolt
#

why does display.width print out 320? the code clearly says 640

#

The display looks like a 320x240 display

slender iron
#

it looks like that because color pixels are doubled horizontally and vertically when transmitted to the display

#

grayscale isn't

manic glacierBOT
devout jolt
#

okay so logically (to CircuitPython users), color display is 320x240, even though they pass in 640x480 to picodvi.FrameBuffer but physically the output is 640x480

slender iron
#

right

#

the signal to the monitor is 640x480

manic glacierBOT
#
todbot
[adafruit/circuitpython] New comment on issue #7911: DVI resolution is actually 320x240, not 640x480

Okay, after conversation with @tannewt in Discord, I see the problem. While you must construct picodvi.Framebuffer() with a 640x480 argument or using board.DISPLAY, the resulting display is reported as 320x240 to CircuitPython code, the actual monitor is driven at 640x480 with pixels doubled in both dimensions

I would still classify this as a bug. Shouldn't display.width and picodvi.Framebuffer(width=) have the same value?

As an explicit example using the Feather RP2400 DVI...

grand stag
#

is the contextlib stdlib pkg supported in CircuitPython? so I can do

from contextlib import suppress

with suppress(ImportError):
  from typing import List, Tuple
tulip sleet
grand stag
manic glacierBOT
#
anecdata
[adafruit/circuitpython] New branch created: anecdata\-patch\-1
orchid basinBOT
manic glacierBOT
slender iron
crimson ferry
#

Dan, I get confused in cases like this... you made the commit with wording change, but GitHub still says changes requested... do I need to take some action?

tulip sleet
manic glacierBOT
crimson ferry
tulip sleet
#

@crimson ferry thanks for the very quick PR

#

@analog bridge I had to mess with the circuitpython branch protection rule temporarily when I was undoing the older silabs PR. I may not have put everything back. Should this be checked?

#

The question comes up because a PR was made via the GitHub web UI, and I noticed that additional pushed commits are not stopping the older GItHub Actions CI runs for the obsoleted commits. But maybe this is unrelated.

manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #7907: Crash into the HardFault\_Handler\.

If we can get the UM FeatherS2 running for about 72 hours total I think we can close this and hand everything over to #7490. @tannewt tagging this issue means it's already referenced as additional data for their uses over in #7490.

I wasn't sure if the IDF issue was still a thing so I didn't bring it up. Best scenario for this one is to hit 72 hours (fingers crossed), close it, and hand our findings over to #7490.

7.3.3 in part...

manic glacierBOT
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] Pull request opened: #7915 Add Pimoroni Pico dv Demo Base \(pico & pico w\)

I'm submitting this as a Draft because WiFi on the Pico W version doesn't work. When the board boots, Web Workflow hasn't started and the board will crash into safe mode if you attempt the following:

import wifi
wifi.radio.connect(ssid,passwd)

The standard Pico version of the Demo Base I've tested and the built in SD card slot, I2S DAC and DVI out all seem to work great.

I've contacted Pimoroni and they've been very helpful with naming recommendations and obtaining the V...

manic glacierBOT
manic glacierBOT
#
dhalbert
[adafruit/circuitpython] New tag created: 8\.1\.0\-beta\.2
orchid basinBOT
manic glacierBOT
orchid basinBOT
tulip sleet
manic glacierBOT
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on pull request #7915: Add Pimoroni Pico dv Demo Base \(pico & pico w\)

I took the board_init function and the associated includes out of pimoroni_pico_dv_base_w/board.c and the crashes went away. I then ran the following script:

import displayio
displayio.release_displays()

import time
import board
import picodvi
import framebufferio
from bitmaptools import draw_line

w=640
h=480
cd=1

fb = picodvi.Framebuffer(
    width=w, height=h, color_depth=cd,
    clk_dp=board.CKP, clk_dn=board.CKN,
    red_dp=board.D0P, red_dn=board.D0...
meager shell
#

I'm trying to add CIRCUITPY_ROTARYIO to a circuitpython build by editing the mpconfigboard.mk file. I can successfully build and flash but no module named 'rotaryio' and I don't see rotaryio when I run help('modules'). The board I build for is lolin_c3_mini. I also have seeed_xiao_esp32c3. I'm wondering if the esp32-c3 is able to support rotaryio

meager shell
manic glacierBOT
jaunty juniper
manic glacierBOT
manic glacierBOT
#
paulrodgers
[adafruit/circuitpython] Issue opened: #7917 hit a whoopsi with character lcd

CircuitPython version

boot_out:
Adafruit CircuitPython 8.0.5 on 2023-03-31; Adafruit Feather M0 RFM9x with samd21g18
Board ID:feather_m0_rfm9x
UID:09BDE3414E37505120202050052009FF

Code/REPL

import time
import board
import adafruit_character_lcd.character_lcd_i2c as clcd

i2c = board.I2C()  # uses board.SCL and board.SDA
lcd = clcd(i2c, 40, 4)

lcd.message = "Hello, world!"
time.sleep(5)
lcd.clear()

Behavior

get the whoops response in ...

#
dhalbert
[adafruit/circuitpython] New comment on issue #7917: hit a whoopsi with character lcd

The common backpacks use a PCF8574, which is not supported by the Adafruit library. However, it should not normally crash for software reasons.

Are you powering the display and backpack with 5V? If so there may be 5V on the I2C pins from the pull-up resistors. This may cause a hardware issue with the Feather M0.

Do you have a link for the display and backpack, or if not, photos? How is it wired? How was it wired with the RPi, and do you have a link to that software?

#
paulrodgers
[adafruit/circuitpython] New comment on issue #7917: hit a whoopsi with character lcd

yes, its powered off 5v, e same USB power that runs the feather
I hear you saying that the backpack needs to talk to the feather at 3.3v on the I2C

makes sense, so If I unplug the I2C at the feather end it should no longer crash
will not work, but no crash. but thats not what happens, same result

BTW fantastically fast response, I was expecting tmw morning earliest

if I just get a new adafruit backpack will that run at 3.3v?

#
dhalbert
[adafruit/circuitpython] New comment on issue #7917: hit a whoopsi with character lcd

This is the latest version of our backpack: https://www.adafruit.com/product/292. The LCD needs 5v for proper contrast, but this new backpack upconverts the 3.3V to 5V. It will probably work with your display, but it's possible it wouldn't. We'd to know more about the display to check on that.

If you disconnect the I2C, you will get an error that there is no I2C connected (it will mention missing pullups).

This appears to be more of a support issue than a CircuitPython bug. I'm going to...

manic glacierBOT
meager shell
manic glacierBOT
#
gree303
[adafruit/circuitpython] New comment on issue #5461: USB HID Report \- USB Busy

@JaggerJo + @hdo
would you mind sharing some details on how to implement your solution?
I'm having a hard time; tried all sort of solutions via Arduino to get absolute position without success on a Qt Py ESP32-S2 nor Nano 33 iot.

Does this work with CuircuitPython 8.x too?
If not; does it support 7.3?

It would help me a lot if you could just point out the procedure roughly.
Thank you very much

spare jacinth
#

is there some sort of "TODO list" to take a look at? i have a little experience with embedded C and been coding in Python for a few years (no idea about the layer connecting both things tho), i would like to contribute on something if i feel like im capable of doing so:

  • rather basic stuff, given my lack of knowledge/familiarity with the ecosystem
  • cross-platform code, as the only hardware i can test with is RP2040
manic glacierBOT
jaunty juniper
midnight ember
#

CircuitPython.org collates the github issues into a nice format for browsing and picking one out to tackle.

#

Check the open PR's for an issue first to make sure someone hasn't already committed a fix waiting for review.

spare jacinth
# midnight ember <@168269895988019200> https://circuitpython.org/contributing/open-issues?label=g...

that's definitely easier to go through 👌
took a look at one or two of them which were recently solved (PyCon), seems like the page updates every once in a while and last changes aren't there, completely understandable...

however i was taking a look at this as i have some of those registers... it was solved by the issue's author with a PR, but isn't closed https://github.com/adafruit/Adafruit_CircuitPython_74HC595/issues/21, perhaps some admin can do it ;)

tulip sleet
midnight ember
#

sometimes PR's aren't closed for a variety of reasons including requiring some 3rd party sub-module to be updated first. all PR's are reviewed first so it does take time for a reviewer to manually go through and confirm the fix. for events like Hacktober Fest and PyCon there's usually a team of reviewers at the ready to review PR's for special events.

spare jacinth
midnight ember
#

yeah have to click through, look at the issue in Github, and see. I think the CircuitPython list is updated once per day.

#

which is usually plenty, but for sprints I can see how wanting it updated every 10 minutes or so would be more helpful.

onyx hinge
#

Thanks for your help!

#

If the page is seriously out of date then somebody will need to take a look

midnight ember
#

Hope everyone is having fun out there @onyx hinge Some really good feedback about the sprints so far. ❤️

onyx hinge
#

@midnight ember I had a blast however today is my travel day, getting home this evening

#

So many folks interested in learning or improving circuitpython

spare jacinth
# onyx hinge If the page is seriously out of date then somebody will need to take a look

the ones i've seen were closed at most some hours ago, and some others are being worked on (PRs openned) during PyCon, so not something i would say needs to be checked/improved in any way (having a completely up to date page will take a hit on performance and outisde events its not needed)

however i will try and find other stuff that is solved but the issue isn't updated accordingly, and perhaps find something i can PR myself

manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #7907: Crash into the HardFault\_Handler\.

Apparently try/except around the io.loop() doesn't help it fail gracefully.

try:
        io.loop()
    except (ValueError, RuntimeError) as e:
        print("MQTTException: \n", e)
        time.sleep(60)
        continue

Monotonic:  173387.0
Monotonic Hours:  48.1629
Publishing 86.0045 to DemoFeed.
Traceback (most recent call last):
  File "code.py", line 119, in <module>
  File "adafruit_io/adafruit_io.py", line 239, in loop
  File "adafruit_minimqtt/adafruit_...
spare jacinth
# spare jacinth the ones i've seen were closed at most some hours ago, and some others are being...

Issues that could be closed
https://github.com/adafruit/Adafruit_CircuitPython_BLE_File_Transfer/issues/15 (PR mentioned the issue, shows at the bottom) CLOSED
https://github.com/adafruit/Adafruit_CircuitPython_MacroPad/issues/30 be fixed by https://github.com/adafruit/Adafruit_CircuitPython_MacroPad/pull/36
https://github.com/adafruit/Adafruit_CircuitPython_PN532/issues/48 fixed byhttps://github.com/adafruit/Adafruit_CircuitPython_PN532/pull/64 CLOSED
https://github.com/adafruit/Adafruit_CircuitPython_RSA/pull/19 fixed by https://github.com/adafruit/Adafruit_CircuitPython_RSA/pull/27 CLOSED
https://github.com/adafruit/Adafruit_CircuitPython_TCS34725/pull/37 fixed by https://github.com/adafruit/Adafruit_CircuitPython_TCS34725/pull/16 ? got confused jumping through a couple of issues/PRs tbh CLOSED

===
Would this one only need a PR copy-pasting the file linked on a comment? https://github.com/adafruit/Adafruit_CircuitPython_MAX7219/issues/36

Will be updating if i find something else (or if im told any of those gets closed)

Note: Perhaps the PR's left some func un-annotated, im not checking that 🙃

Update: Went through the full list already, more stuff tomorrow (maybe)

still zephyr
spare jacinth
manic glacierBOT
still zephyr
#

@spare jacinth for the TCS library, We did some test and validation for the raw color, at the end we kind of agree that the PR from FR where not longer required as we included better explanations in the simple_test and in the library. Ill take a look after dinner to the MAX7219. Thanks again for your help

spare jacinth
still zephyr
#

@spare jacinth regarding MAX7219, I think the FlantasticDan's idea is good, not sure why they did not make a PR, but we could make one and link the issue. And then, the solution could be discussed in the PR.

rough rapids
manic glacierBOT
midnight ember
#

Don't think I need to continue with the UM FeatherS2 wifi/mqtt stability test. 53 hours in, feed update every 10 seconds, approximately 19,000 transactions to AdafruitIO over 2 1/2 days... not a single error let alone a hard fault.

#
Monotonic:  193109.0
Monotonic Hours:  53.6413
```I'm satisfied with the board uptime at this point but I did say 72 hours so will just let it ride.  Hope that helps you devs somehow.  I'm sure UM will be very happy to hear about the stability.
#

I will be doing the same test to the UM FeatherS3 next.

lone sandalBOT
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on pull request #7915: Add Pimoroni Pico dv Demo Base \(pico & pico w\)

The only possibly useful observation I've made from todays poking at this is that when Web Workflow attempts to connect to the AP using common_hal_wifi_radio_connect it fails with a timeout (WIFI_RADIO_ERROR_UNSPECIFIED) after calling cyw43_arch_wifi_connect_async. However, attempting to execute wifi.radio.connect('ssid','password') from the REPL immediately crashes apparently without entering the common_hal_wifi_radio_connect module.

analog bridge
analog bridge
manic glacierBOT
#
regicidalplutophage
[adafruit/circuitpython] Issue opened: #7919 Improvements to keypad library

Some feature I find missing from keypad library:

  • There's no way to use normally closed seitches without external pullups.
    In keypad.Keys if pull=True, the pin is always pulled to the opposite of value_when_pressed which prevents the use on normally closed switches without external pullups.
    Allow the use of normally open switches here and in the keypad.KeyMatrix;
  • Add support for SPI bus to be used for keypad.ShiftRegisterKeys;
  • Add support for more con...
tulip sleet
tulip sleet
#

thanks!

manic glacierBOT
manic glacierBOT
proven garnet
#

Early hug report to all the PyCon sprinters again, y'all have been awesome and these PRs are wonderful 🥹

manic glacierBOT
analog bridge
# tulip sleet <https://github.com/adafruit/circuitpython/pull/7914>; see the `anecdata-patch-1...

Half of the CI runs were due to push events as the anecdata-patch-1 branch was created on adafruit/circuitpython.
Unlike the runs triggered by pull_request event, the runs triggered by push event aren't configured to auto-cancel.
You can see this when filtering the runs like so:
push - https://github.com/adafruit/circuitpython/actions/workflows/build.yml?query=branch%3Aanecdata-patch-1+event%3Apush
pull_request - https://github.com/adafruit/circuitpython/actions/workflows/build.yml?query=branch%3Aanecdata-patch-1+event%3Apull_request

manic glacierBOT
tulip sleet
#
on:
  push:
  pull_request:
  release:
    types: [published]

concurrency:
  group: ${{ github.workflow }}-${{ github.head_ref || github.run_id }}
  cancel-in-progress: true
manic glacierBOT
#
DavePutz
[adafruit/circuitpython] New comment on issue #7365: exit\_and\_deep\_sleep\_until\_alarms not working on rp2040

Testing with Adafruit CircuitPython 8.1.0-beta.2 on 2023-04-26; Raspberry Pi Pico W with rp2040
If I remove the pin_alarm the time_alarm works consistently.
With the pin_alarm enabled I see wildly inconsistent results (even though nothing was connected to the pin);
sometimes with the alarm getting called constantly, and sometimes including a hard crash:

Auto-reload is on. Simply save files over USB to run them or enter REPL to disable.
code.py output:
Waking up
Auto-reload is off....
manic glacierBOT
manic glacierBOT
#
dhalbert
[adafruit/circuitpython] Pull request review submitted: #7921 Add additional iMX RT support

Glad you got these working. A few minor things.

I think it would be better to call these boards nxp_mimx... instead of just mimx.... I know the first one was not named that. I would really like to see the manufacturer included in the board name. I know we haven't been consistent, and it's going to be a job to rename them all. So if you don't want to do it now and we do it in a big bang later, that's OK.

onyx hinge
#

so the sck vs dqs change is unrelated to the bump in flash speed @slender iron ?

slender iron
#

@onyx hinge ya, though I think we do need a loopback from a pad to be faster

#

instead of looping back internal to the peripheral

tulip sleet
slender iron
#

maybe we do it with 9.0 and do all ports then too

tulip sleet
#

yah, that's what I was thinking, so a few more boards named in old style now doesn't make much difference, and we may as well keep all the mimxrt evk's the same for now

onyx hinge
#

$ ./s3rename 's/data_(?P<year>[0-9]{4})-(?P<month>[0-9]{2})-(?P<day>[0-9]{2}).txt/year=$year\/month=$month\/day=$day\/data_$year-$month-$day.txt/g' s3://s3rename-test-bucket/datatest

#

and it probably causes a very large number of API calls too

manic glacierBOT
midnight ember
#

Onto the UM FeatherS3

#

@tulip sleet It does seem like the MMQTTException was never being caught properly by my try/except attempt. I was catching OSError and RuntimeError's np. I have no idea if rolling it into RuntimeError is a good idea or not, that's way above my level of understanding, that's up to you devs. I only know how to use them to get around scripts from crashing which is important for online retrying stuff. Using MMQTTException did not work as I expected it to like OSError and RuntimeError exception handling.

#

It's a minor issue but one that did stop my online script in its tracks multiple times instead of automatically retrying its way around it. Probably my fault for using it incorrectly around the entire io.loop() instead of the individual def functions.

manic glacierBOT
brazen hatch
#

I mean, as a worst case scenario, could you not place a except: below all others if you want to always catch it?

#

Or if you wanna know what it was except Exception as err: print(str(err))

tulip sleet
midnight ember
#

Will probably do that, it didn't behave as I expected it would the same as OSError or RuntimeError would. I'm used to those with the requests library. Would be good to have error handling act the same for anything online/wifi related.

#

or maybe I'm just doing it wrong. will have to add a catch all at the bottom, thanks bill88t and danh. 👍

jaunty juniper
#

I don't know what the best exception hierarchy is, but I would say you want to catch a MQTTException when using the MQTT library ?

midnight ember
#

yeah after thinking about it if it fails inside the io.loop() I don't think it'll get to the bottom.

#
try:
        io.loop()
    except (OSError, RuntimeError, MMQTTException) as e:
        print("MQTTException: \n", e)
        time.sleep(300)
        continue

    if (time.monotonic() - last) >= polling_rate:
        value = temperature * 1.8 + 32
        print("")
        print("Monotonic: ", time.monotonic())
        print("Monotonic Hours: ", time.monotonic()/60/60)
        print("Publishing {0} to DemoFeed.".format(value))
        io.publish("DemoFeed", value)
        last = time.monotonic()
#

vs

#
try:
        io.loop()

        if (time.monotonic() - last) >= polling_rate:
            value = temperature * 1.8 + 32
            print("")
            print("Monotonic: ", time.monotonic())
            print("Monotonic Hours: ", time.monotonic()/60/60)
            print("Publishing {0} to DemoFeed.".format(value))
            io.publish("DemoFeed", value)
            last = time.monotonic()

    except (OSError, RuntimeError, Exception) as e:
        print("------------------------------Error: \n", e)
        time.sleep(300)
        continue
#

Most of the issues I have with it fail inside the io.loop() with an MMQTTException. Tried adding that to the except but it doesn't seem to be recognized as a valid error handler. Double checked the spelling, seems right.

#

It does recognize Exception in the bottom example but pretty sure it'll never get there if it fails inside io.loop()

tulip sleet
midnight ember
#

ah

#

which only uses OSError and RuntimeError which are not imported because they're built-in?

tulip sleet
midnight ember
#

🤦‍♂️ should i close that issue?

tulip sleet
#

I don't understand -- the weather station script doesn't use MQTT at all, is that right?

midnight ember
#

correct, uses adafruit_requests

#

I was expecting the error handling for mmqtt to be like adafruit_requests

#

seems like MMQTT has it's own built in error handling. i didn't realize error handling could be built into a library like that.

tulip sleet
#

the API of MiniMQTT is based (somewhat?) on some other libraries, but I don't know them at all, and don't know if they have unique exceptions. ... But your issue says you can't continue after the exception. That is a separate issue, unrelated to the class of the exception. In other words, is the exception recoverable or not? That's what you're asking for, is that right?

#

that isn't related to what the superclass is

#

just whether it's easy to catch

midnight ember
#

yes but I was using it wrong as you pointed out without the correct import

#

will likely work as intended now

tulip sleet
#

oh, you mean you got a compile error?

midnight ember
#

i think this is user error

crimson ferry
#

I just updated a couple of boards. FunHouse is having frequent safe modes, but same code on QT Py ESP32-S2 does not. Probably some onboard I2C thing? There should be no other material differences... an S2 is an S2.

tulip sleet
crimson ferry
#

thanks, I'll try that

tulip sleet
tulip sleet
#

is it a hard fault or something else?

crimson ferry
#

HARD_FAULT, yes

tulip sleet
#

did you update from beta.1 to beta.2? Some stack stuff was changed

#

you might try a manual bisect with the non-labeled builds

#

i have to go chop onions

crimson ferry
#

some random random 8.1.0-alpha to 8.1.0-beta.2, I'll bisect if flash-from-scratch doesn't work

jaunty juniper
#

a FunHouse freshly erased with a 4-days old build running a httpserver that does nothing (as in, I don't connect to it) hard faults into safe mode after a certain amount of time, I have not had time to dig into that, it used to happen months ago and I don't know if it ever stopped

manic glacierBOT
crimson ferry
#

after bootloader update and storage.erase_filesystem(), it's still hardfaulting. so on to next steps

manic glacierBOT
manic glacierBOT
manic glacierBOT
jaunty juniper
crimson ferry
#

Mine crashed just once so far, 20 minutes in, but not again in the past hour. It was crashing several times an hour before the cleanse. More data needed.

#

(on the 8.1.0-alpha, it went into safemode last a month ago, but for WATCHDOG - probably some network hang)

manic glacierBOT
manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #6765: microcontroller\.on\_next\_reset\(microcontroller\.RunMode\.BOOTLOADER\) not working on S3 TFT

Worth noting that I tried this NOT in REPL but in my script. Took about 2 hours to get out of it. You'd think that using python esptool to erase_flash would defeat it but it didn't. Only way out was to quickly load the QT Py S3 Factory Reset (even though I'm on a UM FeatherS3 because it's just too big to go through fast enough). Surprisingly the UM FeatherS3 is happy to live as a QT Py S3. Once the QT Py boot showed up I was able to reflash everything back as the UM FeatherS3.

impo...
manic glacierBOT
#
dhalbert
[adafruit/circuitpython] Pull request review dismissed: #7921 Add additional iMX RT support

Glad you got these working. A few minor things.

I think it would be better to call these boards nxp_mimx... instead of just mimx.... I know the first one was not named that. I would really like to see the manufacturer included in the board name. I know we haven't been consistent, and it's going to be a job to rename them all. So if you don't want to do it now and we do it in a big bang later, that's OK.

manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on pull request #7922: Take in framebuffer resolution, not output res

I ran this on the Adafruit Feather RP2040 dvi and it seemed to work fine. I displayed a gif from desktop and an example turtle script without issue.

I was hoping I might stumble on a clue as to why the DVI+PicoW build is giving me trouble but other than learning that a color depth of 1 requires a widthxheight of 640x480 and a color depth of 8 requires 320x240 when creating a picodvi.framebuffer (either in C or python) I don't think I'm any closer.

manic glacierBOT
#
jposada202020
[adafruit/circuitpython] Issue opened: #7923 ESP32\-S3 TFT could not work with the HTU31D sensor

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.2 on 2023-04-26; Adafruit Feather ESP32-S3 TFT with ESP32S3

Code/REPL

import time
import board
import adafruit_htu31d

i2c = board.I2C()  # uses board.SCL and board.SDA
htu = adafruit_htu31d.HTU31D(i2c)

while True:

    temperature, relative_humidity = htu.measurements
    print("Temperature: %0.1f C" % temperature)
    print("Humidity: %0.1f %%" % relative_humidity)
    print("")

    t...
manic glacierBOT
manic glacierBOT
manic glacierBOT
#
markbarna
[adafruit/circuitpython] New comment on issue #7912: Distortion with Two Adafruit 64x32 RGB LED Matrix

I don't have a matrix portal. I have 2 panels, RGB Matrix Featherwing, and M4 Express. Would that be close enough to help beta test this issue?

@DJDevon3 , is the code block that I posted unable on your setup? I'm not sure if the hardware is similar enough. That being said, Adafruit is sending me a replacement MatrixPortal so once it arrives, I'll post an update as to whether this issue was due to hardware.

manic glacierBOT
manic glacierBOT
#
dglaude
[adafruit/circuitpython] New comment on pull request #7922: Take in framebuffer resolution, not output res

I tested all the combo I had in mind with the artifact for the Feather RP2040 DVI from this PR, and I get the result in the code comment.

I am not super fan of the error "# ValueError: Invalid width" but at least those 3 give the same value:
print("input: ", w, h, cd)
print("board: ", board.DISPLAY.width, board.DISPLAY.height)
print("disp: ", display.width, display.height)

Regards

import displayio
displayio.release_displays()

import time
import board
import picodvi
im...
manic glacierBOT
last shale
#

Hi all, we are running into an issue where all USB comms on our 2040 suddenly die: the removable disk unmounts and both cdc interfaces disconnect. It appears the uC may still be running, although it is hard to confirm without serial comms.
The issue seems to be somewhat sporadic and difficult to reproduce.
In order to reconnect, we have to power cycle the uC.

Hardware: 2040 on a custom PCB, running 8.0.5

Is there any debugging tool you could recommend to trace the cause of this issue? Thanks!

manic glacierBOT
#
devansau
[adafruit/circuitpython] Issue opened: #7925 CircuitPython core code crashed hard\. Whoops\!

CircuitPython version

adafruit CircuitPython 8.0.3 on 2023-02-23; FeatherS2 with ESP32S2

Code/REPL

#
#   Motor
#
#   connects to WIFI and MQTT broker as specified in the screts file
#   main loop gets sensor  data from MQTT
#
# imports for the board
import gc
import board
import adafruit_dotstar
import time

# imports for WIFI and MQTT
import ssl
import socketpool
import wifi
import adafruit_minimqtt.adafruit_minimqtt as MQTT

# impport th...
brazen hatch
#

Load up a DEBUG=1 firmware and you are off to the races.

crimson ferry
#

odd new behavior... PicoW (8.1.0-beta.2) running adafruit_httpserver starts repeatedly getting

[CYW43] STALL(0;233-233): timeout
[CYW43] do_ioctl(0, 262, 9): timeout
[CYW43] STALL(0;233-233): timeout
[CYW43] do_ioctl(2, 263, 16): timeout

(I don't know which is the chicken and which is the egg)
then, even control-C to the REPL continues to repeatedly get:

[CYW43] send_ethernet failed: -1
[CYW43] STALL(0;233-233): timeout
[CYW43] send_ethernet failed: -1
[CYW43] STALL(0;233-233): timeout

reset fixes it, if there was a way to test for it code could auto-recover

onyx hinge
#
lib/cyw43-driver/src/cyw43_ll.c
661:        CYW43_DEBUG("[CYW43;%u] STALL(%u;%u-%u)\n", (int)cyw43_hal_ticks_ms(), self->wlan_flow_control, self->wwd_sdpcm_packet_transmit_sequence_number, self->wwd_sdpcm_last_bus_data_credit);
```here's where the STALL message comes from, in one of the submodules. dunno anything beyond that, but I haven't done much wifi and no httpserver lately
onyx hinge
#

@crimson ferry are you reading the voltage on GP29? our protection around that may not be adequate. https://forums.raspberrypi.com/viewtopic.php?t=339994 https://github.com/raspberrypi/pico-sdk/issues/1222
we may need to add cyw_thread_enter/exit calls down in our function common_hal_analogio_analogin_get_value:

You only need to wrap calls to the shared pins between cyw43_thread_enter() and cyw43_thread_exit() and make sure there is no other wifi activity ongoing like an HTTP call.

GitHub
Unable to measure VSYS/ADC3/GPIO29 with WIFI · Issue #1222 · raspbe...

I have a setup with Pico W + pimoroni lipo shim. I am trying to run it on batteries, measure some sensors and submit the data via wifi. I am also trying to check battery status from time to time to...

last shale
crimson ferry
#

@onyx hinge Not checking temp, just very simple web server. I’m guessing something random got things into a bad state. I’ll double-check the code when i get back later.

manic glacierBOT
crimson ferry
tulip sleet
knotty trail
#

Question - I am making a CircuitPython compatible board that I plan on selling.

I am currently creating the port for it. I see that there is a USB_VID and a USB_PID

I am not sure what I would put for those. Doing a vendor lookup, I see that Adafruit has their own VID, so I don't want to use that one.

Do I just omit/comment out? Do I put a random one?

#

I see that online, it costs several thousands to get a USB Vendor ID. This is just something I plan on selling a few of, so I really don't want to buy a Vendor ID

blissful pollen
knotty trail
#

Thanks!

blissful pollen
#

It is aimed at open source hardware though just FYI

onyx hinge
#

Yes, you will not receive a PID from pid.codes unless the board design is open source.

open wren
#

hi, I am looking similar to this(https://github.com/brainelectronics/micropython-winbond) in Circuitpython. Actually I want to interface an external W25 4MB external flash with Raspberry Pi Pico board and use this an expended storage. I am ok if this additional 4 MB will not ahowup in my windows drive, but still i want to store some CSV file and read it.

GitHub
GitHub - brainelectronics/micropython-winbond: Micropython library ...

Micropython library to interact with Winbond Flash chips - GitHub - brainelectronics/micropython-winbond: Micropython library to interact with Winbond Flash chips

manic glacierBOT
onyx hinge
#

@open wren it should be possible. CircuitPython also can 'mount' a filesystem from a block device implemented in Python code. You can look at adafruit_sdcard from https://github.com/adafruit/Adafruit_CircuitPython_SD to see how that looks. I think the critical methods are readblocks, writeblocks and capacity. You'd substitute an implementation of these methods suitable for the W25 chip, probably using adafruit_bus_device as the abstraction for talking to an SPI bus.

Further discussion may be more appropriate #help-with-circuitpython

GitHub
GitHub - adafruit/Adafruit_CircuitPython_SD: SD card drivers for Ad...

SD card drivers for Adafruit CircuitPython. Contribute to adafruit/Adafruit_CircuitPython_SD development by creating an account on GitHub.

open wren
#

thanks @onyx hinge . I will try it once

onyx hinge
#

<@&356864093652516868> hey y'all! It's my pleasure to invite you to our weekly CircuitPython meeting today at the usual time of 2PM ET / 11AM ET, or a bit over 2 hours from now. If you have notes, please add them to the notes document https://docs.google.com/document/d/1JbwTjyVDqmIo2do9EDXZkUYYMgTv97QTfM2nBxRK3HM/edit?usp=sharing and if you need me to read them please note that too, by writing a note like "(no mic)", "(missing meeting)" etc after your name. If you just feel like listening in, that's great too, and we're happy to have you. The meeting is recorded, and the recording will be released on YouTube and other streaming & podcast services under a Creative Commons license which allows re-use.

If you want reminders like this, or you want to speak in the meeting, ask any admin or community moderator to add you to the "circuitpythonistas" role. It's free an entails no obligation!

Google Docs
CircuitPython Weekly Meeting for May 1, 2023

CircuitPython Weekly Meeting for Welcome to the CircuitPython Weekly meeting notes! Feel free to add your Hug Reports and Status Updates early. During the meeting, we go through them as a round robin sorted by username. If you can’t make the meeting and would still like to participate, add y...

turbid radish
#

The newsletter is ready in GitHub to crib from for the meeting

onyx hinge
thorny jay
#

Skipping the meeting without notes. Group hug and the only thing I did is playing with Feather RP2040 DVI (in CP) and USB-Host (Intelikey).

lone axle
#

I noticed the contributing page on circuitpython.org has got days that are off by 2-3 days from realtime. Investigating a bit I made a build of circuitpython-org locally from main and in the local version the days are 2 days "newer" i.e. a line showing Open 2 Days on circuitpython.org live site shows Open 4 Days on the local one.

It looks like the final action to build the site after fetching data failed to run fully the most recent attempt that it made: https://github.com/adafruit/circuitpython-org/actions/runs/4850291876/jobs/8643070977

Is this one of the actions that we can just use the re-run functionality with? Or does it need something different, or to just wait a day and see if it suceeds tomorrow.

tulip sleet
tulip sleet
#

Actions has been a bit more flaky than usual the past few days. I've often had to re-run 2-4 failed jobs after a circuitpython PR merge

manic glacierBOT
#
jposada202020
[adafruit/circuitpython] New comment on issue #7923: ESP32\-S3 TFT could not work with the HTU31D sensor

@dhalbert works fine with the S2 :)

Adafruit CircuitPython 8.1.0-beta.2 on 2023-04-26; Adafruit Feather ESP32-S2 TFT with ESP32S2
>>> import t2
Temperature: 21.0 C
Humidity: 54.7 %

Temperature: 20.9 C
Humidity: 54.7 %

Temperature: 20.9 C
Humidity: 54.7 %

Temperature: 21.0 C
Humidity: 54.8 %

Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
  File "t2.py", line 15, in <module>
KeyboardInterrupt:
#
CedarGroveStudios
[adafruit/circuitpython] New comment on issue #7871: ESP32\-S2 A0 DAC truncates and reverses value below mid\-point

shouldn’t the output capability be disabled within CircuitPython?

if you added a pull-down of the same value, is the current drive enough to override the balanced pull-up/pull-down?

Certainly should be documented.

I'll check on the guides, and we can add it to a **Limitations:** section in RTD.

That’s an interesting idea. Adding an offsetting pull-down could reveal more about the buffer but would defeat the purpose of having the pull-up. I’m inclined to chalk i...

manic glacierBOT
onyx hinge
#

We're wrapping up our internal meeting and then I need to take a few moments to get ready for the discord meeting, so things will get going a bit late

#

thanks for your patience!

tulip sleet
#

@onyx hinge your mic volume was pretty high during the meeting, so let's check it here too

onyx hinge
#

OK

#

OBS is not starting for me at all. rebooting.

turbid radish
#

Heya!

gilded cradle
#

Hello

turbid radish
#

it's fine

gilded cradle
#

I'm text only today

manic glacierBOT
#
CedarGroveStudios
[adafruit/circuitpython] New comment on issue #7871: ESP32\-S2 A0 DAC truncates and reverses value below mid\-point

You could have a switchable pull-down by using a pin: external resistor you ground or not, or attach another input. But that's getting into the weeds.

I have no idea why they decided to add a pull-up on that pin and sacrifice the analog functionality -- it's weird.

If we assume that the pull-up resistor is impacting the DAC, adding an external resistance or source current to the pin would introduce other non-linearity effects and temperature issues. Designers take the DAC accuracy...

midnight ember
#

A wizard is never late, nor early, they arrive precisely when they mean to.

gilded cradle
#

I'm text only today, so please read.

#

Still unpacking and can't find my microphone cord.

idle owl
#

No worries! I've got it. 🙂

gilded cradle
#

Thanks

idle owl
#

@gilded cradle I do have a request, can you type out your quick explanation involving "is our CP compatibility layer"? I think I remember the whole thing, but I'd prefer to get it right. Everything else I don't need any assistance with.

#

Add it to the notes doc next to the title please 🙂

gilded cradle
idle owl
#

Thank you so much!

royal rover
#

Time stamps

gilded cradle
turbid radish
#

My pleasure (and blood, sweat, & tears)

lone axle
midnight ember
#

Adafruit's CircuitPython Newsletter is 🔥 Thanks @turbid radish

#

wow, that's gotta be a record blinka_cooking

#

will no timestamps be an issue for the host?

#

nvm

#

There are so many new contributors there's no way to thank them individually like they normally do.

manic glacierBOT
midnight ember
#

PyCon sounds like a great time.

#

I have so many improper animated gifs in mind for all the synthio envelope talk... just awesomeness.

slender iron
midnight ember
#

An actual Xerox PC? Can't wait to read about that.

#

Didn't know it was blocking, looking forward to seeing you work on that.

gilded cradle
#

Still going through notifications. Currently still have >1000 to go through.

idle owl
#

@proven garnet 🎉

#

Congratulations!!!!!!

midnight ember
#

Awww ❤️

shadow vigil
slender iron
#

I assume they got engaged.

proven garnet
#

Thank you! And yes, that was it. 😁

#

Not present today, but thank you everyone!

blissful pollen
#

Congrats @proven garnet !

still zephyr
#

Congratulations @proven garnet

errant grail
#

Thanks!

midnight ember
#

Thank you for hosting @onyx hinge

ember iris
#

@proven garnet Congrats!!! That's delightful news!

gilded cradle
#

Thanks everyone and thanks @onyx hinge for reading my notes.

onyx hinge
#

@proven garnet congrats!

turbid radish
#

ok

ember iris
#

thanks all, have a great week!

gilded cradle
#

Congrats @proven garnet

lone axle
#

Thanks for hosting Jeff!

proven garnet
#

Thank you everyone! Thanks @onyx hinge for reading my notes!

minor plume
#

Thanks, everyone!

midnight ember
#

Thank you Jepler & Kattni for sharing your experience at Pycon. It was interesting on this end too seeing so many type annotations come out of nowhere.

idle owl
midnight ember
#

Wanted to ask why didn't we have a coordinated sprint like we did for Hacktoberfest?

idle owl
midnight ember
#

lol

#

you know what i mean, here on discord.

#

fear of overwhelming reviewers?

#

because that would definitely be a valid reason from the action i saw happening.

idle owl
#

A lot goes into an in-person sprint. We had the folks doing reviews and helping out coordinated here, but involving the remote community would have added quite a lot more to the situation. That said! I'll add this to my notes for next year. Perhaps someone like you 😉 could help coordinate the Discord end of things to help out!

midnight ember
#

haha umm I am definitely not the right person for that one.

idle owl
still zephyr
idle owl
slender iron
#

I briefly looked into making objects identical across boards

onyx hinge
#

that is an interesting idea @slender iron

slender iron
#

the tricky part is knowing later which ones you need

onyx hinge
#

It's probably all tricky parts 🙂

#

Here is the notes document for next Monday’s CircuitPython Weekly meeting. It is at the normal time of 11am Pacific / 2pm Eastern here on Discord. Everyone is encouraged to attend! Please add your hug reports and status updates even if you’ll be attending the meeting - it’s super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and we’ll read them off during the meeting. Hope to see you there! <@&356864093652516868>
https://docs.google.com/document/d/1y5tGjTm1zDpbaSjTIQLytXE_Eg4mmfI4kf95AclnJ2Q/edit?usp=sharing

Google Docs
CircuitPython Weekly Meeting for May 8, 2023

CircuitPython Weekly Meeting for Welcome to the CircuitPython Weekly meeting notes! Feel free to add your Hug Reports and Status Updates early. During the meeting, we go through them as a round robin sorted by username. If you can’t make the meeting and would still like to participate, add y...

onyx hinge
slender iron
#

I also wondered if we could just switch to C strings

onyx hinge
#

@slender iron just confirming, are you running the next meeting? it's what our internal calendar says but also I thought I saw that you ran last week's

slender iron
#

I can do it again. That's fine

onyx hinge
#

the doc says it for now, anyway

#

thanks

slender iron
#

One of them might have been a kattni slot

#

I'm ok with the practice. I'm rusty

onyx hinge
#

appreciate it

slender iron
#

np

#

I'm in "run the meeting" debt anyway

onyx hinge
#

I'm not keeping score though it sure is nice now that you're back in the rotation!

slender iron
#

🙂

#

I'd love to figure out this qstr thing at some point

#

it'd be nice to share compiles across boards better

manic glacierBOT
#
todbot
[adafruit/circuitpython] New comment on pull request #7862: Synthio envelope

Hi @jepler!
I finally got around to trying this out. Very cool! Much easier to change envelope rates based on incoming note playing, and we can now make some pretty expressive synths.

A few observations:

  • The synthio.Envelope is "global" to the synth, so the amplitude envelope of currently playing notes gets replaced by notes with a different envelope (e.g. play gentle, then play hard, hard notes' env replace gentle notes' env). It would be nice to have per-note envelope state, but ...
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on pull request #7922: Take in framebuffer resolution, not output res

I also tested with the above code and it worked as expected. I did notice one peculiarity, If you set the framebuffer to any of the sizes greater than 320x240, pressing ctrl-D and then attempting to run the code with another framebuffer size greater than 320x240 but different than the one you just used caused a memory error. Pressing ctrl-D again, after getting the memory error and pasting in the same code that just gave you the error then succeeds.

manic glacierBOT
#
hiredman
[adafruit/circuitpython] New comment on issue #5318: nRF: deep sleep increases power usage

I've recently run into this as well. Thought I would get my act together and use deepsleep, and it would give me a nice battery life boost in some ItsyBitsy nRF52840 Express based projects. Then I saw this report and ran some experiments. I get 1.5x to 2x the battery life just using time.sleep+supervisor.reload vs alarm.exit_and_deep_sleep_until_alarms.

I poked around a little looking at https://github.com/adafruit/circuitpython/tree/main/ports/nrf but have no idea where to start. A real b...

manic glacierBOT
#
jepler
[adafruit/circuitpython] New comment on pull request #7862: Synthio envelope
  • The synthio.Envelope is "global" to the synth, so the amplitude envelope of currently playing notes gets replaced by notes with a different envelope (e.g. play gentle, then play hard, hard notes' env replace gentle notes' env). It would be nice to have per-note envelope state, but that may be asking too much. :)

I want to tackle that in the next round of improvements, so that a note can be associate with an envelope rather than having just one envelope for the whole Synthesizer obje...

slender iron
#

@onyx hinge have you looked at pico-8 for synth inspiration?

onyx hinge
#

I wish I had done more of a 'survey' up front. this started out as looking for a quick win improving the audio synthesis, then I got more free reign (time) than I expected to improve on it. but it means it's a big pile of NIH and I don't know much about what is out there.

slender iron
#

🙂 understandable. I was just looking at it for the edit/run cycle it has. (escape toggles between editor and console)

onyx hinge
#

I'll review that PR you asked me about tomorrow, but ping me if I fail

slender iron
#

kk, np

manic glacierBOT
#
dglaude
[adafruit/circuitpython] New comment on pull request #7922: Take in framebuffer resolution, not output res

I am fine with "Invalid color_depth" or anything, really.

I had the same memory issue (I guess)... this is why I have that count-down.
For each test I started from power on, that is the time I needed to get to the console in time to see the message.

I did not try to understand the random memory allocation issue... could it be that the REPL use the DVI output and block reuse? I don't know much how ^D interact with memory management.

I was thinking the allocation error were due to som...

knotty trail
#

Let’s say I go into production with a circuitpython compatible board. How do I batch program hundreds of boards?

blissful pollen
knotty trail
#

Interesting. I’ll have to look into that. Thanks!

stuck elbow
#

I usually just give the firmware to my fab and let them flash it as a part of their testing procedure

jaunty juniper
#

there are some guides on testers and recently ladyada has been switching from teensy to pico for that (using pio USB host for USB test and programming)
Unexpected Maker has a discord and youtube channel where he talks about his production process (he ships his boards with CP installed)

thorny jay
#

In fact, I would not even know how to do that from a Linux machine, I guess it would involve discotool.

jaunty juniper
#

yeah I was thinking of that too. For a classroom I would think a computer is enough, kattni has code to do that, I have an example in the discotool repo that's geared towards that. But I could see using a handful of USB feathers, you plug the device, wait for the LED to turn green, go to the next one, do 5 in parallel...

manic glacierBOT
manic glacierBOT
#
chilipeppr
[adafruit/circuitpython] Issue opened: #7926 CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

CircuitPython version

When running this simple code that creates several async/await tasks that run in parallel, CircuitPython will HARD_FAULT randomly roughly every several hours.

I have tested this on CircuitPython 8.0.5 and 8.1.0 and they both act similarly.

Code/REPL

# main_test_why_circuitpython_hardfaults.py
# This file will just run a simple asyncio infinite loop to see if that causes
# a hard fault after 24 hours.

import asyncio
import time...
lone sandalBOT
orchid basinBOT
orchid basinBOT
manic glacierBOT
#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

Yes.

On Tue, May 2, 2023 at 10:20 AM anecdata @.***> wrote:

Wemos S2 Mini?

—
Reply to this email directly, view it on GitHub
https://github.com/adafruit/circuitpython/issues/7926#issuecomment-1531666182,
or unsubscribe
https://github.com/notifications/unsubscribe-auth/AB4J23IG7DGU33NNYXHT5NTXEEQ5FANCNFSM6AAAAAAXTAC3WM
.
You are receiving this because you authored the thread.Message ID:
@.***>

orchid basinBOT
manic glacierBOT
manic glacierBOT
#
jepler
[adafruit/circuitpython] New comment on issue #7912: Distortion with Two Adafruit 64x32 RGB LED Matrix

OK I've gotten my project out of storage.

I'm using two of the 64x32 LED displays, a matrixportal, and a 4V 2A power supply

The power supply reads 5.18V no load and 5.10V while running the code with display on.

I have previously installed a 220µF capacitor on the power input, but I do not know if this is important.

The display looks right with the following versions: 7.3.1 (was previously loaded), 8.0.5, 8.1.0-beta.2

The display initiali...

slender iron
#

anyone tried (and failed) to load the most recent builds onto rp2040?

tall tide
manic glacierBOT
#
hiredman
[adafruit/circuitpython] New comment on issue #5318: nRF: deep sleep increases power usage

wild guess:
https://github.com/adafruit/circuitpython/blob/488dca565f700f40358eb3a6e50f1eb561f541c2/ports/nrf/supervisor/port.c#L356-L397 appears to skip sleeping if there are any background callbacks, and I don't see anything in the loop here https://github.com/adafruit/circuitpython/blob/488dca565f700f40358eb3a6e50f1eb561f541c2/ports/nrf/common-hal/alarm/__init__.c#L182 that immediately looks like it is processing background callbacks.
So maybe there is a background callback (dunno anyth...

random junco
idle owl
#

OK, I'm trying to use wifi.radio.ping. And I've tried every format that makes any sense for the IP to ping, and nothing is working. How is this supposed to work? There are no details in the documentation.

manic glacierBOT
#
BlitzCityDIY
[adafruit/circuitpython] New branch created: thinkink\_update
jaunty juniper
idle owl
#

bytes or a string formatted address.

#

Oh, hmm ok.

#

Thanks @jaunty juniper.

#

Ok, that worked. Now I understand why the docs are what they are for ping. Learned two things here. Appreciate it.

jaunty juniper
idle owl
#

Ohhhhhhhhhh. Interesting. I assumed it simply wasn't supported.

#

Thanks!

#

I found a domain that would work though.

manic glacierBOT
orchid basinBOT
idle owl
#

Oooof. When using settings.toml, wifi.radio.connect throws completely useless errors. I modified the SSID to be wrong for the purpose of throwing an error, and I get Unknown failure 15 and, once, Unknown failure 4. Is this by design, or some limitation? I would think, at least for SSID or password mismatches specifically, it could provide a clearer error.

orchid basinBOT
manic glacierBOT
manic glacierBOT
slender iron
crimson ferry
idle owl
#

Hmm.

crimson ferry
#

you can blame me for adding those cryptic numbers to "Unknown failure" :p

idle owl
#

I wonder if there's a way to specifically tell you if your SSID or password are wrong, a least.

crimson ferry
#

tannewt is right, the error you actually get back could be one of a few, depending on where in the wifi connect / disconnect process it fails

#

not always indicative of what really happened (sometimes there are a series of error codes, and the one of the moment gets reported)

idle owl
#

Ah.

#

Welp. It was worth asking.

crimson ferry
#

it's a good problem to try to solve

orchid basinBOT
manic glacierBOT
onyx hinge
#

"get the latest commit with checks" failed with "IndexError: list index out of range" so nothing else ran...

#

I'll try 're-run jobs'

manic glacierBOT
#
jepler
[adafruit/circuitpython] New comment on pull request #7862: Synthio envelope

@microdev1 this is failing in a weird way:

Run python3 -u ci_changes_per_commit.py
Traceback (most recent call last):
  File "/home/runner/work/circuitpython/circuitpython/tools/ci_changes_per_commit.py", line 239, in <module>
    main()
  File "/home/runner/work/circuitpython/circuitpython/tools/ci_changes_per_commit.py", line 228, in main
    check_runs = get_bad_check_runs(query_check_runs)
                 ^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^^
  File "/home/runner/work/circuit...
manic glacierBOT
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

I increased the number of asyncio tasks to 30 and started your test program on a UM Feather S2 and an Adafruit Feather ESP32-S2 about 13 hours ago. They haven't crashed yet but I'll let them run over night. I'm assuming that adding the extra tasks didn't mess the test up. Unfortunately, I don't have a Wemos S2 Mini to test on, hopefully it's not hardware or port specific.

I did notice that the Lolin S2 boards are among the relatively few S2 boards that have CIRCUITPY_ESP_FLASH_FREQ set to...

#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

I was actually using a Lolin S2 Mini, not a Wemos S2 Mini, but aren't they basically the same thing?

I've been running this even further since I posted and I did get a HARD_FAULT again a couple hours ago. Here's my log below. I also seem to sometimes get the WATCHDOG as well as a reason for a reboot. So my period between HARD_FAULTs is about 22 hours.

I'm building a Marble Run for the local school's STEM lab to inspire the kids and this thing needs to run 24x7 so the kids can hit the bu...

orchid basinBOT
#
lboue
[adafruit/circuitpython-org] New comment on pull request #1192: Add process to Flash Circuitpython to the board

Hello @RetiredWizard:

  1. Can I have confirmation of the addresses to use to flash the binary?
  2. I propose to add some notes to help users:

Method 2 - Simplicity Commander

You can use Simplicity Commander: A tool that contains a scriptable command line, allows the user to flash their application.

  1. Download Simplicity Commander
  2. Extract Simplicity Commander directory from the zip file.
  3. Go to Simplicity Commande...
lone sandalBOT
manic glacierBOT
manic glacierBOT
#
jepler
[adafruit/circuitpython] Issue opened: #7928 circuitpython\-stubs uses deprecated way to build \(pep517\)

CircuitPython version

main

Code/REPL

make html

Behavior

/home/jepler/.local/lib/python3.9/site-packages/setuptools/__init__.py:84: _DeprecatedInstaller: setuptools.installer and fetch_build_eggs are deprecated.
!!

        ********************************************************************************
        Requirements should be satisfied by a PEP 517 installer.
        If you are using pip, you can try `pip install --use-pep517`.
...
onyx hinge
#

@candid sun @split ocean @devout jolt I'm working on the next thing after ADSR. I would like feedback on this API. ```py
class Note:
def init(
self,
frequency: float,
amplitude: float = 1.0,
waveform: Optional[ReadableBuffer] = None,
envelope: Optional[Envelope] = None,
tremolo_depth: float = 0.0,
tremolo_rate: float = 0.0,
vibrato_depth: float = 0.0,
vibrato_rate: float = 0.0,
) -> None:
"""Construct a Note object, with a frequency in Hz, and optional amplitude (volume), waveform, envelope, tremolo (volume change) and vibrato (frequency change).

    If waveform or envelope are `None` the synthesizer object's default waveform or envelope are used.

    If the same Note object is played on multiple Synthesizer objects, the result is undefined.
    """
frequency: float
"""The base frequency of the note, in Hz."""
amplitude: float
"""The base amplitude of the note, from 0 to 1"""
tremolo_depth: float
"""The tremolo depth of the note, from 0 to 1"""
tremolo_rate: float
"""The tremolo rate of the note, in Hz."""
vibrato_depth: float
"""The vibrato depth of the note, from 0 to 1"""
vibrato_rate: float
"""The vibrato rate of the note, in Hz."""
waveform: Optional[ReadableBuffer]
"""The waveform of this note. Setting the waveform to a buffer of a different size resets the note's phase."""
envelope: Envelope
"""The envelope of this note"""

NoteSequence = Sequence[Union[int, Note]]
"""A sequence of notes, which can each be integer MIDI notes or Note objects"""

Each place a `Synthesizer` could take an integer MIDI note number, it will also accept a `Note` object. The `Note` object can also be dynamically changed while playing, such as by changing the base `Note.frequency` to do a sweep. Notes can have different waveforms and envelopes, so each note can have its own distinct sound.

It's largely coded, but not yet tested on hardware. Also it'll require some re-work after I make the changes requested on the ADSR PR. But this is what's next, and I welcome your feedback (and anyone else who's interested)
manic glacierBOT
#
casainho
[adafruit/circuitpython] Issue opened: #7929 Webworkflow code editor not working

CircuitPython version

Adafruit CircuitPyhton 8.1.0-beta.2, ESP32-S3-DevKitC-1-N8R2 board.

Code/REPL

pass

Behavior

http://cpy-2b4f34.local/code/ don't load the code editor. Some weeks ago it was working perfectly for me.

Description

I tested to change the CIRCUITPY_WEB_API_PORT.

I tested in two different ESP32-S3 as also in one ESP32-S2, that always worked well for me.

I also tested on a different wifi network, with only my PC and the ...

orchid basinBOT
#
RetiredWizard
[adafruit/circuitpython-org] New comment on pull request #1192: Add process to Flash Circuitpython to the board

That looks correct, however I'm running the Windows install which would probably be launched from an icon rather than the command line.

Here are a couple other approaches that I thought might work, but really as long as the link and reference to Simplicity Commander is included I think they're all good:

Method 2 - Simplicity Commander

You can use Simplicity Commander, A tool that contains a scriptable command line, allo...

candid sun
#

super cool @onyx hinge ! i really like being able to dynamically change the attributes. i'm envisioning tying the values to sensors

manic glacierBOT
#
DJDevon3
[adafruit/circuitpython] New comment on issue #7925: CircuitPython core code crashed hard\. Whoops\!

I actually have a pan/tilt servo kit. Can help test this on latest beta release sometime this week on the UM Feather S2 with motor featherwing.

The UM FeatherS2 has a special featherS2.py that is created upon initial install with many pre-defined functions. I'm not sure if they're required or just helpers but in all of my uses I've always included it in my code.py

def enable_LDO2(state):
    """Set the power for the second on-board LDO to allow no current draw when not needed."...
#
jepler
[adafruit/circuitpython] New review comment on pull request #7862: Synthio envelope

OK, I'll use those as defaults. It's not as bad as I was worried it would be to allow default values. After the next update, it'll work like this:

>>> synthio.Envelope()
Envelope(attack_time=0.1, decay_time=0.05, release_time=0.2, attack_level=1.0, sustain_level=0.8)
>>> synthio.Envelope(decay_time=7)
Envelope(attack_time=0.1, decay_time=7, release_time=0.2, attack_level=1.0, sustain_level=0.8)
>>> synthio.Envelope(7)
Traceback (most recent call last):
  File "<stdin>", line 1, ...
orchid basinBOT
manic glacierBOT
#
jepler
[adafruit/circuitpython] New comment on issue #5707: synthio\.MidiTrack produces single note/beep only

If you're still having a problem with this, I recommend trying to play the MidiTrack through an AudioMixer.

The reason is that the MidiTrack produces audio buffers of varying sizes, including very small sizes for short notes. (in older versions it also produced extremely large buffers for long-held notes, but now it has a certain upper limit buffer size)

Some of our audio out implementations handle this small audio buffers poorly and get confused because with a small buffer the next aud...

manic glacierBOT
manic glacierBOT
manic glacierBOT
manic glacierBOT
manic glacierBOT
slender iron
manic glacierBOT
manic glacierBOT
idle owl
#

RP2040 can do light sleep in CircuitPython, right?

#

IIRC, it doesn't do deep sleep.

manic glacierBOT
onyx hinge
#

@devout jolt can you remind me what website(?) you were using for all those single-cycle waveforms? I'm after a windchime-style waveform for this demo.

lone sandalBOT
mystic flume
#

I've been playing with the Seeed XIAO nrf52840; this device will need to be turned off for long periods without draining the battery. I'd been hoping to get micro-amp current draw as per the Seeed website - but instead I seem to be getting about 2.5mA. Looks like CP doesn't actually use the deep sleep function of the processor, but just does a light sleep and then a reset. Is there a reason for this? I've got uctypes working on my build of CP so I can poke the various registers and enable deep sleep myself - anything I need to be careful of with this?

onyx hinge
manic glacierBOT
#
jedgarpark
[adafruit/circuitpython] Issue opened: #7930 USB MIDI in messages not received on Metro M7

CircuitPython version

Adafruit CircuitPython 8.1.0-beta.1-50-ge928554a9 on 2023-04-25; Metro MIMXRT1011 with IMXRT1011DAE5A
Board ID:metro_m7_1011

Code/REPL

import time
import board, analogio
import busio
import audiobusio, audiomixer
import synthio
import ulab.numpy as np
import usb_midi
import adafruit_midi
from adafruit_midi.note_on import NoteOn
from adafruit_midi.note_off import NoteOff
from adafruit_midi.control_change import ControlChange
...
#
todbot
[adafruit/circuitpython] New comment on issue #7930: USB MIDI in messages not received on Metro M7

Yep, verified that usb_midi worked in 8.0.5 but does not work in 8.1.0-beta.2 and up
The simpler test code I was using was:

import usb_midi
import adafruit_midi
from adafruit_midi.note_on import NoteOn
from adafruit_midi.note_off import NoteOff

midi = adafruit_midi.MIDI(midi_in=usb_midi.ports[0] )

while True:
    msg = midi.receive()
    if isinstance(msg, NoteOn) and msg.velocity != 0:
        print("note on", msg.note, msg.velocity)
    elif isinstance(msg,NoteOff) o...
devout jolt
onyx hinge
#

Thanks @devout jolt -- do you know one that sounds like a bell?

devout jolt
#

The granular ones are probably most bell-like

onyx hinge
#

ooh cool! I ported desktop python's wave file reader to CP so I can just put the wav files directly

devout jolt
#

oh nice

manic glacierBOT
onyx hinge
devout jolt
#

nice. thanks!

onyx hinge
#

I hope to find time to package it maybe as a community bundle item

#

bbl

#

btw as I try to put together this demo I see more what you are saying about the loudness of 1 voice vs multiple voices but I still don't know what to do about it 😕 if someone wants 1 voice at a time they don't want it 1/12 of total possible loudness.

devout jolt
devout jolt
onyx hinge
#

oh hey I'm caught up to 2000? rad

devout jolt
#

ahahah it's very impressive. "wavetable synthesis" was the holy grail back then and we get it sort of for free

manic glacierBOT
onyx hinge
#

I think that one part of it is the RMS level of a sum of a bunch of sine waves of different frequencies is less than the sum of their amplitudes, because half the time they cancel each other out; so that's why 12 notes sounds a lot lower volume than 1

#

when either one is "allowed" to get to +-32768 as the sum of all the waveforms

devout jolt
#

i.e. (sig1 + sig2 + sig3 +sig4)/4 and not thinking much harder than that about it

manic glacierBOT
manic glacierBOT
manic glacierBOT
#
furbrain
[adafruit/circuitpython] New comment on issue #5318: nRF: deep sleep increases power usage

@hiredman I don't suppose you are connecting to the REPL via bluetooth?

I've tried using uctypes to "manually" set up a pin alarm and deep sleep - and that seems to work really nicely, current consumption drops down to about 20uA as per my (fairly cheap) multimeter.

  pin_no = get_pin_no(hardware.BUTTON_A)
  if pin_no >= 32:
      gpio_base_addr = 0x50000300
      pin_no %= 32
  else:
      gpio_base_addr = 0x50000000
  pin_cnf_addr = gpio_base_addr + 0x700 + pin_no * 4
...
blissful pollen
#

Has anyone had success getting code.circuitpython.org to connect via BLE? I've been trying to an nRF52840 and my own nRF board and after selecting the device I never get the option to Bond to it and while a subsequent connect shows it is paired, no functionality works

manic glacierBOT
#
markbarna
[adafruit/circuitpython] New comment on issue #7912: Distortion with Two Adafruit 64x32 RGB LED Matrix

Thank you for looking at it. I received a replacement MatrixPortal so will
try using that one to run the same code and will post an update.

On Tue, May 2, 2023 at 12:57 PM Jeff Epler @.***> wrote:

OK I've gotten my project out of storage.

I'm using two of the 64x32 LED displays, a matrixportal, and a 4V 2A
power supply https://www.adafruit.com/product/1466

The power supply reads 5.18V no load and 5.10V while running the code with
display on.

I have previously insta...

knotty trail
#

How do I use MP_QSTRs? Where are they defined?

I want to create a custom pin name for one of the features on my board and I want to know where I can add the strings. I assume they are constants defined in another file somewhere?

jaunty juniper
#

note that you have to make BOARD=... clean of you change them

manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

I had a bit of a glitch overnight last night which killed my terminal sessions, so from yesterday's test runs all I know is that neither board crashed after about 13 hours.

I started the tests up again this morning but this time, I loaded the Lolin S2 mini firmware up on one of the boards first. The test program has been running again for about 13 hours. I'll check them again in the morning and hopefully at least one of them will have hard faulted.

#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

Sounds good. Yeah, I left mine running today again too, but I actually had
accidentally left it in the REPL, so missed out on my test today as well.

On Wed, May 3, 2023 at 9:51 PM RetiredWizard @.***>
wrote:

I had a bit of a glitch overnight last night which killed my terminal
sessions, so from yesterday's test runs all I know is that neither board
crashed after about 13 hours.

I started the tests up again this morning but this time, I loaded the
Lolin S2 mini firmware up ...

midnight ember
#

Because it's almost 3 am I'm not going to ping you in a reply. Has anyone had success getting code.circuitpython.org to connect via BLE? I've been trying to an nRF52840 and my own nRF board and after selecting the device I never get the option to Bond to it and while a subsequent connect shows it is paired, no functionality works

#

Yes I've had this happen ever since the web flasher and web serial in chrome became a thing with every type of board. It's more likely to fail when it says paired next to it than when it doesn't. I have no idea what paired means (serial communication i think). It's not just the NRF, this definitely affects ESP boards as well.

#

You can use esptool in python to get around the issue of it locking down the serial bus quite easily with ESP32's using erase_flash then reflash with a bin. It's not as easy if you run into it with the NRF52840.

thorny jay
#

3AM? 🙂

manic glacierBOT
manic glacierBOT
#
ishahak
[adafruit/circuitpython] Issue opened: #7931 Wifi access point: setting subnet parameters

When starting a wifi access-point with this code:

import wifi
wifi.radio.start_ap(ssid=ssid, password=pw, channel=chn)

It will always use same local IP for the network it creates: 192.168.4.X
This prevents us from generating several networks with several boards.

Can you please allow setting the third part of the IP for a custom value?

This was also raised here: https://forums.adafruit.com/viewtopic.php?t=201121

manic glacierBOT
#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

Had a HARD_FAULT again last night.

The timestamp is odd. Safemode got hit at 3:33AM. Then it rebooted into normal mode which should be about 10 seconds later, but the clock says 3:27AM. I do the RTC lookup when booting in normal mode, so it just makes me think the clock runs fast on the ESP32. Is it possible a fast clock throws stuff off over time and that's what causes a hard fault?

From safemode.py. Kill switch off. 2023-05-04 03:33:58, supervisor.RunReason.STARTUP, microcontrol...
onyx hinge
#

@slender iron [up early?] quick gut check question -- I have ported the cpython library for reading wave files to CP (nearly trivial). it seems useful for reading single-cycle waveforms for synthio. should i package it as an adafruit circuitpython library, or put it in the community bundle? I anticipate it'd be used in a synthio guide which tends to make me think adafruit.

manic glacierBOT
#
Schmeckinger
[adafruit/circuitpython] Issue opened: #7932 CircuitPython 8\.x bootloops on ESP\-C3\-32S \(2M\)

CircuitPython version

Broken:
CircuitPython 8.0.5, CircuitPython 8.1.0-beta.2 for ESP-C3-32S (2M)
Working:
Adafruit CircuitPython 7.3.3 on 2022-08-29; AITHinker ESP32-C3S_Kit_2M with ESP32-C3

Code/REPL

ESP-ROM:esp32c3-api1-20210207
Build:Feb  7 2021
rst:0x1 (POWERON),boot:0xd (SPI_FAST_FLASH_BOOT)
SPIWP:0xee
mode:DIO, clock div:2
load:0x3fcd5810,len:0x24
load:0x403cc710,len:0x668
load:0x403ce710,len:0x2218
entry 0x403cc710
Serial console setup
...
manic glacierBOT
#
jepler
[adafruit/circuitpython] Pull request opened: #7933 synthio: add 'Note' with arbitrary frequency and more

Here's the doc for the new class, which can be used where integer note numbers were used before:

class Note:
    def __init__(
        self,
        frequency: float,
        amplitude: float = 1.0,
        waveform: Optional[ReadableBuffer] = None,
        envelope: Optional[Envelope] = None,
        tremolo_depth: float = 0.0,
        tremolo_rate: float = 0.0,
        vibrato_depth: float = 0.0,
        vibrato_rate: float = 0.0,
    ) -> None:
        """Construct a No...
manic glacierBOT
manic glacierBOT
#
RetiredWizard
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

No luck for me, 25 hours, 2 boards, 30 asyncio loops and no faults yet. I'll keep them running but I'm wondering if it's something with the specific board. Do you have just one of the Lolin boards?

I've gone ahead and ordered one which should be here in about 10 days but I also seem to remember that there was an issue with different manufacturers of these boards using different parts that behaved differently. Hopefully I've just been lucky and I'll be able to reproduce this on one of these...

#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

I have tested this on 2 different Lolin S2 Mini's and same issue, but I
could try this on other ESP32's now that you mention it could be specific
to the version of the chip they used.

On Thu, May 4, 2023 at 10:16 AM RetiredWizard @.***>
wrote:

No luck for me, 25 hours, 2 boards, 30 asyncio loops and no faults yet.
I'll keep them running but I'm wondering if it's something with the
specific board. Do you have just one of the Lolin boards?

I've gone ahead and ordered one which...

#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

Do you think it has anything to do with me activating the display?

On Thu, May 4, 2023 at 10:17 AM John Lauer @.***> wrote:

I have tested this on 2 different Lolin S2 Mini's and same issue, but I
could try this on other ESP32's now that you mention it could be specific
to the version of the chip they used.

On Thu, May 4, 2023 at 10:16 AM RetiredWizard @.***>
wrote:

No luck for me, 25 hours, 2 boards, 30 asyncio loops and no faults yet.
I'll keep them running ...

#
chilipeppr
[adafruit/circuitpython] New comment on issue #7926: CircuitPython HARD FAULTs crashes hard after several hours from async/await loops

I do have the display regurgitating the standard output, so code would be
executing in those display classes. I just commented out that part of the
code so I'm ONLY testing the async tasks. If this doesn't crash on me then
it would have to be the display causing this. If it does crash, one other
idea is that I am using the Web Workflow to see the serial output. Perhaps
it's the Wifi classes causing it.

As for powering the board, I'm just using a normal USB-C wall wart for a
Raspberry Pi that...

blissful pollen
#

Is there someplace to file issues with code.CircuitPython.org? Or to report issues too? I lack a ton of web knowledge so not sure how much help I can be looking into it but could try.

manic glacierBOT
manic glacierBOT
slender iron
slender iron
manic glacierBOT
lavish saffron
#

The adafruit_wiznet5k_wsgiserver.py module in the adafruit_wiznet5k Ethernet driver implements a WSGIServer class. This class relies on a mixture of calls to deprecated, non-standard socket.socket methods and direct calls to the hardware via WIZNET5K methods. It is difficult to maintain. Rather than expend a lot of effort on refactoring this module to use only standard socket.socket calls, does the adafruit_httpserver provide the same functionality as adafruit_wiznet5k_wsgiserver.py, could it be used instead?

manic glacierBOT
jaunty juniper
orchid basinBOT
lavish saffron
jaunty juniper
#

yeah I implemented readline() because the point was to make it work the other way too, so that native wifi sockets could be used with libraries that were written for ESP32SPI (originally it was written for my uwebsockets port, which assumes native wifi)

#

and yeah I would say it provides more functionalities at this point

manic glacierBOT
jaunty juniper
#

not sure how it compares in memory use though, as it's getting bigger

lavish saffron
willow totem
#

Okay, someone save me...
I get an error when I log some debug data:
This is the code:

print(type(result))
print(str(result))

log.debug("I2cConnection received raw: {}".format(self._data_to_log_string(result)))

and the data_to_log_string is:

        if type(data) is bytes:
            return "[{}]".format(", ".join(
                ["0x%.2X" % i for i in bytearray(data)]))
        else:
            return str(data)

and the console output with print statements and error:

<class 'bytearray'>
bytearray(b'\x04\x07\x95\x04}\xb6\x04\xb6\x1b\x04\xd0\x06\x12\xcb\x9b\x13~%\x04LB\x7f\xff\x8f')
Traceback (most recent call last):
  File "code.py", line 336, in <module>
  File "/lib/sensirion_i2c_sen5x/device.py", line 242, in read_measured_values
  File "/lib/sensirion_i2c_driver/device.py", line 61, in execute
  File "/lib/sensirion_i2c_driver/connection.py", line 116, in execute
  File "/lib/sensirion_i2c_driver/connection.py", line 153, in _transceive
  File "/lib/adafruit_logging.py", line 380, in debug
  File "/lib/adafruit_logging.py", line 327, in _log
TypeError: not enough arguments for format string

and adafruit log function:

    def _log(self, level: int, msg: str, *args) -> None:
        record = _logRecordFactory(self.name, level, msg % args, args)
        self.handle(record)
manic glacierBOT
slender iron
#

@willow totem % format needs the right hand side to be a tuple

#

so you need (i,)

proven garnet
#

Since GitHub mentioned it today, reminder that Node 12 will be depreciated in two weeks on GitHub CI!

#

I believe almost of the CircuitPython infrastructure is safe (not too sure about the core though), but please feel free to ping me if something doesn't work starting on the 18th if that is a problem anywhere!

stuck elbow
#

the problem is that the priority of operators is not intuitive there, he needs parens

willow totem
# slender iron so you need `(i,)`

brilliant, thank you. I was trying to avoid changing more of the main i2c driver logging code, i.e. I can get it to work changing "{}".format to "%s" which allows the code to work, but changes one log method in connection.py and I was curious why it was necessary for adafruit logging but not python logging.

stuck elbow
#

[("0x%.2X" % i) for i in bytearray(data)]))

willow totem
#

works on right, crashes on left

jaunty juniper
#

what are you doing with platform detect ?

#

what board is that on ?

willow totem
#

checking if any_embedded_linux to use the sensirion linuxi2ctranceiver.py and a circuitpython version if not, plus logging swap

rough rapids
#

@willow totem it can sometimes be useful to split lines like those up to make them easier to read, too. i.e.

        if type(data) is bytes:
            bytestrings = ["0x%.2X" % i for i in bytearray(data)]
            return "[{}]".format(", ".join(bytestrings))
        else:
            return str(data)
manic glacierBOT
willow totem
#

this is the python i2c driver (base driver), and the sen5x driver on top, both forked from sensirion and then modded for ciruitpython
https://github.com/tyeth/python-i2c-driver/tree/circuitpython-busio-i2cdevice
https://github.com/tyeth/circuitpython-i2c-sen5x/tree/circuitpython-fix

GitHub
GitHub - tyeth/python-i2c-driver at circuitpython-busio-i2cdevice

Python package of a common I2C driver. Contribute to tyeth/python-i2c-driver development by creating an account on GitHub.

GitHub
GitHub - tyeth/circuitpython-i2c-sen5x at circuitpython-fix

Python I2C sensor driver for Sensirion's SEN54, SEN55 and SEN50 sensors - GitHub - tyeth/circuitpython-i2c-sen5x at circuitpython-fix

jaunty juniper
#

yeah what is happening is that _transceive is calling logging.debug() without additional arguments

stuck elbow
jaunty juniper
#

and that is not supported by the adafruit library

willow totem
manic glacierBOT
willow totem
#

(im not great at python, c# guy but dnagerous in all languages)

jaunty juniper
#

I'm not sure honnestly

willow totem
#

it's curious, and I really don't get why the %s version works but the other doesnt

jaunty juniper
#

it says TypeError: not enough arguments for format string
and that would mean something like:

>>> "%d" % ()
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
TypeError: not enough arguments for format string
#

but you don't pass a format string with % in it I don't think

willow totem
#

no, use {}

#

or fstring with %s

#

or frm what ive observed anyway
