Vulpengine is my game engine written in C/C++. This is a library of common code I use for my projects. All my other projects can be discussed here too since they share this codebase.
The codebase
https://github.com/anthofoxo/vulpengine
(Image link: Doesn't allow to attach the image normally for some reason???)
https://cdn.discordapp.com/attachments/1286757925863424063/1287417422638219331/image.png?ex=66f17868&is=66f026e8&hm=aaef5cf7bc8f109ad3076af85d836c6cbcf92dead3ed3a4b9ac5874d32eb0219&
I don't current have much to show for this atm since its being rebuilt from the ground up. The older codebase dates back years ago and was broken in many ways. Main thing this code rework is the improve abstractions and make apis more consistant and powerful.
main latch
third
bright pivot
third?
main latch
fifth
bright pivot
Finally got an abstraction for buffers, vertex arrays and meshes
bright pivot
I'm revisiting vulkan atm since if I'm going to redo a codebase may as well give it another shot
nimble onyx
No screenshots?
bright pivot
all i got is code sceenies
heres the current code for making the buffers and all that
struct Vec3f32 final {
float x, y;
};
struct Vertex final {
Vec3f32 position;
};
Vertex positions[] = {
{ -0.5f, -0.5f },
{ 0.5f, -0.5f },
{ 0.0f, 0.5f }
};
unsigned int indices[] = { 0, 1, 2 };
vulpengine::experimental::Buffer vertexBuffer = {{
.content = std::as_bytes(std::span(positions)),
.flags = GL_NONE,
.label = "Test vertex buffer"
}};
vulpengine::experimental::Buffer indexBuffer = {{
.content = std::as_bytes(std::span(indices)),
.flags = GL_NONE,
.label = "Test index buffer"
}};
vulpengine::experimental::VertexArray vertexArray = {{
.buffers = std::array {
vulpengine::experimental::VertexArray::BufferInfo {
.buffer = vertexBuffer,
.offset = 0,
.stride = sizeof(Vertex),
.divisor = 0
}
},
.attributes = std::array {
vulpengine::experimental::VertexArray::AttributeInfo {
.size = 2,
.type = GL_FLOAT,
.relativeoffset = offsetof(Vertex, position),
.bindingindex = 0,
}
},
.indexBuffer = vulpengine::experimental::wrap_cref(indexBuffer),
.label = "Test vertex array"
}};
mMesh = {{
.vertexArray = std::move(vertexArray),
.buffers = std::array {
vulpengine::experimental::wrap_rvref(vertexBuffer),
vulpengine::experimental::wrap_rvref(indexBuffer),
},
.mode = GL_TRIANGLES,
.count = 3,
.type = GL_UNSIGNED_INT
}};```some things i had to use weird wrappers which is annoying but this works nicely so far
the next thing i to get shaders abstracted in a nice way
but since we going 4.6 i may introduce runtime compilation or something
drifting roost
all i got is code sceenies
Can we get a triangle though
bright pivot
nothing exciting
drifting roost
It has begun
bright pivot
but next up we toss in the shader stuff and get a mesh in there
bright pivot
and some simple diffuse light, so now we go and implement the new stuff!
also yes im injecting the renderdoc dll into the app at start up, i aint doing shit without renderdoc on hand
bright pivot
custom renderdoc ui, this is so helpful to have
you can even control what shows in the renderdoc overlay
i belive you can do this with directx and vulkan capturing too
bright pivot
im also documenting the engine as i go, its very helpful
bright pivot
made a SUPER basic chunk, obvously from the overdraw, we gotta do that internal culling
main latch
white is good right?
main latch
(I know I was pulling your leg)
bright pivot
main latch
now do cross chunk mesh generation
bright pivot
let me fix the input code lmao
bright pivot
willing to bet it shows all the techiques for optimising voxels ive already seen
main latch
it actually shows nothing it's just memes
bright pivot
:0
main latch
it's zoomer editing so beware
bright pivot
jonnny test editing x.x
main latch
more like max0r editing
bright pivot
fixed the input problems, some weird event ordering issues but took that as a good opportunity to get an event system
bright pivot
a lil something together
chunk borders are already handled, just gotta look into directional face culling
bright pivot
some simple little guis to help, cleaned up the input handing so its feels pretty nice to handle cursor locks and unlocks
Basically the handing on cursor lock atm is like this:
main latch
how do you prevent imgui from registering events with cursor locked
bright pivot
yes
theres config flags for it
// Use this to prevent cursor lock if interacting with guis
ImGui::GetIO().WantCaptureMouse
// Disable imgui inputs when locking the cursor
ImGui::GetIO().ConfigFlags |= ImGuiConfigFlags_NoMouse;
ImGui::GetIO().ConfigFlags |= ImGuiConfigFlags_NoKeyboard;
// Enable imgui inputs when unlocking the cursor
ImGui::GetIO().ConfigFlags &= ~ImGuiConfigFlags_NoMouse;
ImGui::GetIO().ConfigFlags &= ~ImGuiConfigFlags_NoKeyboard;
is WantCaptureMouse an input variable as well?
bright pivot
is `WantCaptureMouse` an input variable as well?
no, it's meant to be a readonly
this lets me keep the uis open but allow the in game camera to work as expected without interacting with them
plus binding it to the alt key makes handling alt+tab very graceful
bright pivot
Got multithreading and chunk generation to work across boundaries vertical slices, we have frustum culling working and culling between chunks, next step is getting stuff ready to generate as you move around, may work on getting threaded work queues and that going too
also had to disable some iterator checks cause otherwise debug in msvc is slow asf (brought launch time from 20s to about 3s)
nimble onyx
get yourself a develop config
#engine-dev message
it's very useful
I've been using it since then and never had to go back to debug and was able to use breakpoints just fine
bright pivot
thats stuff i do most of already, its just that in debug mode in msvc theres very time consuming iterator checks
nimble onyx
very strange that they would take place even with those settings
bright pivot
main issue atm is that its generating everything upfront so you have to wait for it to finish
bright pivot
i specifically stay on debug early on plus changing a single define to fix the slow debug std::vector is plenty fix for me
nimble onyx
hmm your call
I don't really want to go back to a debug build ever unless for some reason breakpoints aren't helping at all and printf isn't an option
bright pivot
i already have 3 configs for stuff like this, im just in debug still since im working around threads which easily get very mad
but once i get all that verified to work as it should yeah, getting out of full debug
i never really considered to call the config develop tho, i just added another based on release and called it dist which fully goes for speed and no debug and i modified release to allow some debugging when needed
im really not looking forward to getting condition variables working though
Generally im not too sure how to go about the work queues, ive just always went on my existing knowlege for it
So my assumption is to spawn a number of threads equal to your cpu thread count. (12 in my case)
And you have a queue of work that the threads pull work off of, and when theres no work available youll use a condition variable to allow the thread to sleep without maxing a core
bright pivot
somehow i managed to get the threading to work correctly
main latch
now do caves
bright pivot
Bigger problem is that there's only 1 block type lmao
main latch
ah you doin that strat
bright pivot
It worked for a bit
main latch
so multiple block types are going to be a pain if you want to keep the binary thingy
which if you want to greedy mesh you probably should
bright pivot
Oh I'm ditching it anyhow
It was just do I had something to work with
Nit entirely sure how block data will be stored in thr end but now it'll just be an offset into a block list
bright pivot
So we gonna pivot away from voxels for a bit and work on loading meshes in a more complete way
Vulpengine (Antho's Weird Graphical Club)
much better
bright pivot
been busy, just doing lots of little things
i also have some neat gifs for here too
demonstrating fitting the shadowbox to a frustum
and just overly funny physics demo
bright pivot
Also looking into ways to improve the shadow maps. If anyone had good resources on that I'd happily use them. Plus I want to clean them up before implementing pcss
All I've done at this point is implement csm and pcf with poisson saples
bright pivot
thank you visual studio, very helpful
bright pivot
took a small break, but added multiple block types, and yes im aware of the weird filtering issue
not very good caves but its a start
drifting roost
how big are your chunks?
bright pivot
I havnt implemented greedy meshing yet
drifting roost
sorry to be so nosy, do you use a sparse datastructure for your chunks? or flat arrays?
bright pivot
It's a flat array
Literally std::array<block type, 32*32*32>
Along thr lines of this
drifting roost
yeah that's what I had
only mine were 64x64x64 😅
how are you able to draw so much? mdi? instancing? just render surfaces with your mesh?
bright pivot
Except the chunk size is a constexpr so it isn't exactly hard coded
I'm not doing anything too fancy rn. Just simple face chunk face culling and frustum culling
drifting roost
nice
I had frustum culling
I didn't do chunk face culling
I was working on occlusion culling when I stopped working on my voxel engine
bright pivot
I'm not sure when I'll bother with occlusion culling tbh
drifting roost
maybe you don't need it
bright pivot
Atm I definitely don't need it
But once there's more stuff underground and that. It would ne nice to have
drifting roost
what are you planning to do with lighting?
bright pivot
The sun/moon will have real-time lighting. And static light sources will just bake light information into the meshes
bright pivot
And I may have it so held light sources are also real-time but that part is to be determined
drifting roost
I had light information in meshes, not real time
bright pivot
I do plan to have voxels be able to be cut down to the individual pixel
bright pivot
As an actual thing. A mechanic in the game
drifting roost
you're going to keep all that information?
bright pivot
Why not. I can easily fit the position data in 6 bytes
And if memory bandwidth is still a problem i can render them separatly
drifting roost
so if I have a flat area of 64x64 and I add idk a thousand little 1pixel dimension structures all over that area, how do you draw that in a performant way?
bright pivot
There's not a great to do that. Plus it's a real unrealistic use case for it
But generally the same rules of greedy meshing and face culling can still apply
drifting roost
you have a really cool project, good luck with it
bright pivot
I'll need it lmao
drifting roost
I know
bright pivot
next step im doing is to dynamically load the block types so i dont have to manually create the atlas and data for it
plans to have this basically entirely modular so the new directory structure will be like this (for now)
game root
+-- executable
+-- mods
+-- textures
| +-- dirt.png
+-- blocks
+-- dirt.yaml
gotta make sure utf8 filenames work cause i dont want those crashes
bright pivot
very good, its all working so its easy asf to add new blocks, i dont gotta manually stitch atlases or manually enter texture offsets anymore
bright pivot
so looking into rock types, im not going to have a generic stone type
specifically rock strata, and having different rock types and rock layers
some examples being sandstone, shale, limestone, slate, granite, andesite etc, etc
bright pivot
alrighty its time to port the shadows over to my voxel stuff
bright pivot
first iteration of shadows
lots of stuff to clean up before even trying to smooth em our
iron cove
Hey this is like my implementation of shadow mapping but probably better for performance
bright pivot
its the bare basics of csm
just some simple tweaking got it looking okayish
looks pretty neat (shadow maps for the view below)
i might use more than 4 cascades but i think this will be plenty usable for now
drifting roost
I just block diffuse and specular, but leave some ambient in shadow areas with attenuation
Well attenuation for point lights
I guess that doesn’t apply to your directional light
bright pivot
ambient occlusion will be the thing that improves the look much better
i do plan to have some lights be realtime so itll still apply at times
bright pivot
I guess that doesn’t apply to your directional light
yeah you dont attenuate directional lights
drifting roost
yeah the ambient occlusion will make a difference
bright pivot
the unfortunate part is that since i plan to have some complex voxel stuff, i dont see it worth putting into the mesh data, so ill likely just go with ssao
iron cove
looks pretty neat (shadow maps for the view below)
May I suggest parallel split shadow mapping?
bright pivot
im not gonna spend more time on shadows rn, its something ill revisit but ill look into that when i go back
also from the quick stuff im looking at it doesnt seem hugely applicable to the scenes im doing
bright pivot
doing just some basic work, gamma correction, and that sorta stuff, nothing visual to really show for it
bright pivot
https://wallisc.github.io/rendering/2021/04/18/Fullscreen-Pass.html
vUv = vec2(gl_VertexID & 2, 1 - ((gl_VertexID << 1) & 2));
gl_Position = vec4(vUv * 2.0 - 1.0, 0.0, 1.0);
documenting this cause its neat, based this one triangle screen thing and made a couple modifications to it to fit opengl better
bright pivot
using this for a simple fxaa effect
bright pivot
simple block picking workin
ill have to implment the algorithm to fix the whole selecting through corner problem but thats easy enough to do
bright pivot
we can build now, primitve asf sundial lmao
iron cove
even responds to the actual position of the mouse on screen, nice
that logic always wastes a lot of my time every time I do it
bright pivot
its pretty easy to do, its a very nice qol feature
iron cove
I always get my order of operations wrong and end up spending like hours debugging it
bright pivot
glm::vec4 clipSpace = glm::vec4(cursor, -1.0f, 1.0f);
glm::vec4 viewSpace = glm::inverse(proj) * clipSpace;
glm::vec4 worldSpace = glm::inverse(view) * glm::vec4(viewSpace.x, viewSpace.y, -1.0f, 0.0f);
return glm::normalize(glm::vec3(worldSpace));
not too hard to do
iron cove
glm::vec4(viewSpace.x, viewSpace.y, -1.0f, 0.0f);
h
bright pivot
tldr, we dont care where it projected to in the viewspace z axis, just point it forward lmao
oh yeah this snippit assumes cursor is already in the -1 to 1 range
bright pivot
bedrock layer
drifting roost
You’re getting so much done so quickly
bright pivot
I'm just getting started baby
bright pivot
some basic world editing features
drifting roost
is your world infinite or bounded?
bright pivot
its gonna be large but not "infinite" making it infinite will pose a lot of challenges with what i want to do with the world building
and a lot of the types of map generation i want to do will require a decent but of pregenerating stuff, unique structures and the like
the final size of the map isnt fixed yet but will likely be 64kx64k or 128kx128k
drifting roost
have you seen vblanco's Project Ascendant thread?
seems like similar goals, only his doesn't have any block/world editing
bright pivot
im putting it in my feed now
tbh ill likely generate the entire map on world creation
but who knows if ill be able to pull that off lmao
but using estimates if the map is 128kx128k the entire map will be 8 TiB which we cannot do
im sure compression will do a ton to help it but im undecided on how exactly worldgen will work
drifting roost
on my voxel engine initially stored all my chunks in sqlite uncompressed, my sql file was 2GB and it was just like 8x8x2 for 64^3 chunks
then I pulled them out and stored them as gzip and they compressed to like 10KiB
bright pivot
i can make a decent amount of guarentees with my data so i could go into specifically on some of it
if i take into account some of the guarentees i know itll have, its like 2 TiB uncompressed
and im sure it can easily get > 50% compression ratio
drifting roost
what size integers are you using for your voxel data?
bright pivot
and thats assuming i make the work that big
atm its just pointers, but i can easily just use a 16bit int for them
drifting roost
I was using uin64s
I stored block type, and lighting data and orientation in that and some extra space
bright pivot
with a 32x32x32 chunk size its guarenteed that if voxels have no special data with them, its impossible to have over 2^16 unique voxels
but taking a more typical case, a chunk is likely to have less than 256 unique voxel types
drifting roost
oh that's interesting, having a chunk map for voxel types
instead of a global voxel map, that's brilliant
so you can have unlimited voxel types basically
bright pivot
in my case it reads in the mod files, stores it in a map, and after it goes through a read only interface
so my block types just look like Block const*
for obvious reasons this isnt great for when writting to files and not great on memory overall
drifting roost
I am unlikely to attempt another voxel engine, as much as I really enjoyed it, I personally don't think it's well suited to me working on my own, it takes a year to build even something remotely playable by someone else, at least at my progression speed
bright pivot
yeah im currently fighting with race conditions, its fun
im not very sure how far ill take this since i hop between projects a lot, but we shall see
drifting roost
you're making really amazing progress in a short time
bright pivot
if (!id.contains(':')) {
// unqualified name, auto qualify
id = std::format("{}:{}", modid, id);
}```and the modding api kinda wacky
but it does function
but the next goals rn is basically to get schematics workingt
the foundations for it are ready to go
bright pivot
looking into ways to help revent data racing in future, i think this is okay?
class ChunkData final {
public:
static constexpr size_t index(glm::ivec3 const& position) {
return position.z * kChunkSize * kChunkSize + position.y * kChunkSize + position.x;
}
Block const* get_block(glm::ivec3 const& position) {
std::shared_lock lck{ mMtx };
return mData[index(position)];
}
void set_block(glm::ivec3 const& position, Block const* block) {
std::unique_lock lck{ mMtx };
mData[index(position)] = block;
}
private:
std::array<Block const*, kChunkSize * kChunkSize * kChunkSize> mData{};
std::shared_mutex mMtx;
};
this should at least protect me from myself lmao
i need to work on how the worker threads do things cause it still can break stuff there
drifting roost
The Game Engine Architecture book covers concurrency strategies in great detail, it's a complex topic and it depends on the nature of your data and goals
a mutex lock may prevent the races but might also result in performance about as good as a single thread
this is a picture from that book that I like
what I did in my voxel engine is lock only to memset the chunk data to copy it for reading or writing and not for the full operation
I was able to spam block edits pretty effectively
bright pivot
Supposedly shared mutex is pretty good about performance
Since you can have shared ownership
Specifically this is to catch the case where I edit data while threads are trying to read data from then
Which is already rare as it is but it's possible to break
But I may consider just copying the block data into the worker threads and remove the shared access
drifting roost
I had a problem where I would miss edits, and the data and what was drawn were no longer aligned and there would be an invisible block
bright pivot
I have a solution to that already but if the edits are too close in the queue there's another race condition that's likely to crash
drifting roost
yeah it only really happened if I spam edited a complex chunk that took longer to mesh than normal
it wouldn't ever happen in a fast release, just on a debug build
I fixed it
bright pivot
The basics of this is if a chunk is edited and it's queued already then ignore it. But the issue comes up if it's already built the data and waiting for upload. The vertex cache has no thread peotection
So if you're uploading as the same chunk begins updating its mesh. Yeah not great things happen
So either I prevent rebuild while it uploads or I copy the vertex data into the upload queue
Another I was considering is using a few atomic booleans to flag the chunks as busy but i don't quite like that option
drifting roost
I kind of like the idea from GEA where you start a job at the beginning of the frame and then before rendering assert that it's done
bright pivot
Only the upload part is single threaded too
And that's by far not the slow part. Is fast enough it can swap stuff and you not notice it
I would love to mess about with context sharing and uploading data on another thread but I'm that's a rabbit hole I'm not wanting to touch rn
and maybe using an atomic GLuint and swapping that or something, but im unsure if this is even worth it in ogl land
bright pivot
So we can take a selection and export the data!
the yaml uncompressed is 1.28KiB and compresses 137 bytes, about a 10% compression ratio which is really good
bright pivot
oh also this is being done so i can use schematics in the world gen instead of manually figuring out the blocks offsets and ids myself
but just so happens to be a very convient way to save and load your builds
bright pivot
ill work in integrating this into world gen and loading back up another time, im gonna start diving into the wonderful world of text rendering
if anyone got some epic fonts i should try it ill do so, for now ima roll with noto-sans
bright pivot
bright pivot
and simple multilang is working alright
iron cove
if anyone got some epic fonts i should try it ill do so, for now ima roll with n...
https://github.com/NovaAssistant/ToyShapeFont
here’s a fun one
iron cove
bright pivot
lovely
something must be a bit wacky with how that ttf is written cause it REALLY does all it can to use any other glyph for those codepoints
cool to see that working tho
bright pivot
aight we now respecting the os content scaling
added a little vector graphic for your crosshair, inverts the colors behind it
and you can easily change the sizing
bright pivot
working on a simple debug panel thing, tldr, this new vector rendering system will be used for the in game stuff, imgui will stick around for prototyping and the more debugging related activities
bright pivot
well both cause yk, shaders required, but geometry, this is using the gui system im working on
drifting roost
mine were geometry but I realized I could just render a single triangle and draw fancy crosshairs on it, and even animate them in fancy ways
bright pivot
just a handful of points in a closed loop
drifting roost
I don't have any hud in my game atm
drifting roost
I guess I don't even have a game atm, just a engine with some learning scenes
it's gonna be a while too
bright pivot
i just hacked together some custom cursor support too
drifting roost
nice
bright pivot
its REALLY ugly rn too x.x
bright pivot
i found a REALLY neat bug lmao
also finally using texture arrays
and the nice bonus, i got an easy 16 byte data saving per block face
bright pivot
vec2(idx % 2, ((idx + 1) / 3) % 2)
yummy lmfao
used to generate my uv coords, so now my vertices only need the layer for the texture
bright pivot
Finally added mip maps and anisotropic filtering
iron cove
something must be a bit wacky with how that ttf is written cause it REALLY does ...
Huh?
I have not had problems with this font
bright pivot
its very possible that i just have a weird bug too
bright pivot
i know this thread is stale, been jumping around a lot
In the near future I'm going to be looking into getting a linux dev environment working
the current state of the project(s), you clone recursivly, using premake5 you generate visual studio or makefiles, follow an extra gen step for linux (one time), and using those it'll cleanly build the platform executable. (yes i know premake5 is a bit dated considering it hasnt had an update in a while, may look into using cmake despite how much i dont like it)
Im used to using visual studio and tempted to get a vscode envieonment working but im not familar with how nice an environment that is.
Does code navigation work well, does it have debuggers etc, etc
livid spear
no worries
threads can always be
i use c++ and c# here on lunix
both can be run and debugged in vscode and rider/clion
i use all three tools depending on my mood
premake also works just fine here, just like cmake based projects
vscode has a neat plugin for the latter as well, makes running and debugging c++ projects even easier imho, no need to manually set any weird build scripts up
code navigation also works 99% of the time just with vs itself
after installing microsoft's c/c++ plugin for vscode
with regards to premake, go boop dragonslayer0351
if you want the bleeding edge 🙂
im sure they have nightly builds too or you just build it from source if you need to
bright pivot
Alright so vscode is perfectly viable for this then. That's good to hear.
I'm on premake5 beta2 or something. I'll look into building it my source. I already build my entire source tree by source anyhow
It's just that beta2 doesn't have an option to specify cpp23. And other weird stuff. I just assumed the project was abandoned. I looked on git and it's still worked on so yeah
So ill likely build myself and just ship it with the code or something but we'll see
livid spear
@solemn bone we have a complaint wrt premake
solemn bone
me too
livid spear
i know nothing about premake, but you do 😛 please help the frog
solemn bone
what's up?
livid spear
solemn bone
Yes, build from source for C++23 🙂
livid spear
ah lol hehe
bright pivot
Is master branch considered stable?
livid spear
are you still maintainer?
livid spear
time to create a new release then
solemn bone
it's a bit of a pita, tbh
bright pivot
It's been ages since beta2
bright pivot
But getting cpp23 would be nice to present passing around weird compiler specific flags. Which build tools are supposed to prevent
livid spear
!remindme 3d remind dargon about premake, he said this weekend
mystic fernBOT
solemn bone
I'll look into building from source.
just go check the latest actions and snag the artifacts for your OS
we do have downloadable artifacts there, if you don't want to build it
bright pivot
I don't mind building. I complete forgot about ci builds lmao
solemn bone
Sounds good. Feel free to ping me directly if you run into issues
bright pivot
Sick
solemn bone
!remindme 3d remind dargon about premake, he said this weekend
I did ask if there is any opposition to cutting a release this weekend. May try to do some issue/PR combing this weekend to see if there are any low hanging fruit worth getting in
livid spear
kewl
bright pivot
I just like premake more than cmake so I wanna keep using it when I can
Also i use lua to script so it's like perfect
Unstable scripting api W
solemn bone
Yeah, I really hate DSLs. Premake feels nice to use
livid spear
i need to give it a serious try one day as well, but im kinda spoiled by the cmake plugin in vscode and cmake support tiself in clion, even vs does support it somewhat decently
bright pivot
The cmake dsl and the fact it's just overly complicated for what needs to happen is what keeps me from using it on my own projects
livid spear
if you only do basic shit its quite tame and rather simple, and when writing an engine and a sandbox to use the engine, its shrimple
solemn bone
There are a few issues that need to get closed before beta3 will be ready, but I'm keeping an eye on those and they are all being worked 🙂
bright pivot
Oh maybe I'll wait on that then
Just ealier my 6k main file finally got the refactor it been deserving
solemn bone
bright pivot
I'm hoping to get it public soon but I have to get the copyrighted assets outta there
bright pivot
SOOO beta3 hasn't happened (been over 2 years since an update) AND I cannot find the build artifacts (Looks like the appveyor builds are 4+ years old and I cannot find anything recent), tried building from source, undefined external symbols(registerModules and builtin_scripts) assume this comes from bootstrap, the ./bootstrap.bat fails with error The system cannot find the batch label specified - VsWhereVisualBootstrap file doesn't work so I cannot follow the build instructions.
livid spear
i thought you do c#?
bright pivot
i thought you do c#?
no, c, c++ and lua
bright pivot
id like premake beta3 but hasnt released and id like to stop hacking support for c++23
bright pivot
or build it from sources for the time being
im trying
the build build fails cause i cant run the bootstrap file fails to run
I assume running this file generates a c file which defines the missing symbols
im building from master, currently at the 1a80408 commit
livid spear
dargon mention nightly builds too
i assume the pipeline will spit out builds, premake.exe etc
bright pivot
so atm either master is unstable, the build instructions are wrong or im just missing something
im stuggling to find any recent ci artifacts is the thing
its all the beta2 builds
ohhh wait a second
okay to the readme ci links are basically dead and unused now, so that mislead me, theres ci in the github actions but im not familiar with it so im digging
talk about the lastest successful build being buried
sooo why is the github action working but my same build steps locally dont
bright pivot
i read the logs, i did the same steps
its just some reason maybe the current master may have a broken bootstrap bat file????
bright pivot
yeah i know! why is the release cycle like this mannn
livid spear
dargon got some homework for tomorrow
bright pivot
this is so weird, the website repo has updated information but the wiki itself doesnt like, seem to reflect it
cloning the wiki locally babbyyy
oh sick, i have these tools installed, i can fix this up real fast locally
livid spear
: )
bright pivot
im getting myself so confused rn for real
so the website is updated
mayhaps that was on of the things needed before for beta3 dropped
bright pivot
oh sick, i have these tools installed, i can fix this up real fast locally
this gives me a reason not to use docusaurus though
dude this setup is so weird i swear
premake-core contains the doc source which makes sense, but the generated files end up in another repo which i guess only exists to host the website itself
all this confusion is gonna end up making me contribute documentation of my own to premake
like how stb_vorbis took literal years to fix a tiny bug that annoyed me so i just did it myself
livid spear
mayhaps you can contribute
bright pivot
okkay lets see if this nightly build correctly does this thing i wanna do
dude a ton of the website just has stubs that just say needs documentation
actually this explains a lot
they edited the bootstrap file recently and it broke (for me at least
maybe this is the failed latest action i saw on the github
the current issue is beta2 cppdialect "C++latest" selects the lastest on visual studio which just works, but in gcc it'll select up to C++17, beta2 doesn't have cpp23 as an option so for gcc i have to specifically pass the compiler flag, looks like this works on newer builds
i dont recon theres a function in premake that tells gives a version number to use a filter on or sometihng to conditionally include premake options
solemn bone
I am still waiting on a few outstanding issues for beta3
https://github.com/premake/premake-core/actions/runs/11672557339
This is the latest master build @bright pivot
Actually, only a single outstanding PR for this. Depending on when we get that in, should be a branch cut for release in the next week or so
bright pivot
https://github.com/premake/premake-core/actions/runs/11672557339
This is the la...
i managed to find it, it was just confusing having travis-ci and appveyor linked on the readme so it just misled me for way too long
solemn bone
It is fixing a relatively large break in the functionality that got introduced, so this is something that has to come in before the next "stable" release
And sounds good
bright pivot
thats fair enough, is there a sort of plan for a release cycle at somepoint, or even a roadmap?
solemn bone
Not sure what the 5.0 (non beta) is, but I just merged in the last PR I needed for 5.0-beta3, so I'll be getting a build out within the next day or so
solemn bone
@bright pivot just wanted to let you know that I'm working on the release now
bright pivot
<@218415631479996417> just wanted to let you know that I'm working on the releas...
yessss
solemn bone
Will take probably a day to get someone to give approval for the commit, but I've got all the PRs I need closed
bright pivot
Will take probably a day to get someone to give approval for the commit, but I'v...
Hype
solemn bone
https://github.com/premake/premake-core/actions/runs/11767240048
These here are representative of the binaries that will be in the release, if you need them now
livid spear
@solemn bone thanks for taking care of this 🙂
maybe Release 5.0.0 could be a thing for january first (or whenever you guys are back from xmas holidays) : >
solemn bone
There are two major blocking issues before 5.0 that need to be taken care of first
livid spear
solemn bone
That's the plan. One of the issues will require community feedback (we will be yeeting our old gnu makefile exporter for the new one)
But, we need to ensure there are no minor things people are using in the older, legacy exporter that need to be ported to the new one
bright pivot
https://github.com/premake/premake-core/actions/runs/11767240048
These here are...
Ooh I'll gladly use them
bright pivot
That's the plan. One of the issues will require community feedback (we will be y...
Oh gmake vs gmake2 ?
I've been using the gmake2 one for ages and never had problems with it
solemn bone
Yeah, gmake is our legacy gnu makefile exporter. gmake2 is what people should be using, but there's a handful of users still on gmake
bright pivot
Oooh that make sense
bright pivot
So im preping to migrate from windows to linux as a dev environment soon and would like to get a vscode setup going, i already use premake and it generates makefiles, the code itself is already fully supports linux
Does anyone know of some good guides i can follow to get this working nicely, in a way where you slone the repo, and the vscode stuff will be there
Being able to debug is a must, as in stepping through, breakpoints etc
the most i know about this is a .vscode directory gets created and you need a couple extensions
im doing my basic google and stack overflow searches but any resources on this would be great
drifting roost
you can sync vscode
bright pivot
Specifically building can be as simple as running make, the specifics about getting vscode to run as a debugger is where i need help
drifting roost
the sync is so good I hate it and turn it off because I don't want my work stuff synced to my home vs code
bright pivot
you can sync vscode
idk what tf this means
bright pivot
this tells be nothing on how to get started
bright pivot
i understand the extensions and all that, but configuring launch and tasks is where im stuck
drifting roost
what are you using now?
bright pivot
premake which generates visual studio files or makefiles, so building the project on linux is as simple as running make which is easy enough to make a task for, im just unaware of how to get vscode to run the binary and attach as a debugger
drifting roost
you know about launch.json?
bright pivot
all i know is that its a file that exists
drifting roost
cntrl + P add configuration
this is really well documented
it works really well imo, but if you're used to Visual Studio 2022, VS code is not an ide, it is a text editor
bright pivot
for vscode on linux all i really need is basic debugging features and a decent intellesense
drifting roost
yeah it does all that
bright pivot
i dont even use a ton of visual studios debugging features
drifting roost
I write zig, but I use the C++ setup
bright pivot
the most in depth i ever used on there are the process memory dumps
drifting roost
and I can debug and step through in vs code
for memory you're going to have to use valgrind or something else
I don't know
why are you switching?
bright pivot
it wasnt anything crazy, its was that rare occasional thing that came in handy
well i plan to get off windows when win10 hits eol
but its also good to be able to build and debug nativilly on linux
building is more or less handled already
drifting roost
I think you can probably set up debugging in minutes if you're already building
bright pivot
its just having trouble finding the binaries and symbols and garbage
drifting roost
ah I'm not sure, maybe someone can help you in #questions
I think though the documentation is pretty good if you haven't read it yet
bright pivot
the main issue i have with the docs i see is that is just assumed you have a one file project which just isnt the case
like this wasnt too hard to get to work
problem matcher!?
ooh the os specific override feature is very nice
okay so this is working, just intelisense doesnt seem to know what the include paths are
so the basics are working on windows at least
oh thats a very weird issue
so the setup isnt great rn but its at least usable
solemn bone
https://github.com/premake/premake-core/releases/tag/v5.0.0-beta3
Beta 3 is live 🙂
bright pivot
The 21st century is real :o
bright pivot
Having some trouble, im just playing around and im trying to draw a volume as a post fx, theres a quad that covers the screen, and the depth testing is weird. Basically my sdf produces a euclidean distance whereas the depth buffer sample isnt. Even after normalizing it, its still just distance to clip plane vs distance to camera origin,
and i cannot figure out for the life of me how to account for this difference
in the vertex shader, i calculate the view vector and the view origin which work fine, i use these in the fragment shader to test against an sdx box which also works, but i want it to respect depth testing
so i sample from the depth buffer and compare which works when directly looking at the object, but as you turn the camera you see the depth values not being right
oh man i hate that
alternative for now, i take the object distance, run it through the pipline operations, perspective device, then use that z value for compare
bright pivot
i fixed all this stuff, just have a little test here
bright pivot
some optimising later things run much faster and generally look better too
iron cove
Where does this fox model come from?
bright pivot
Where does this fox model come from?
No idea. I've just had it on my pc for ages
drifting roost
I have seen it before
Although it could have just been a different fox model
It looks very similar though
bright pivot
this isnt where i originally found it but the same mesh can be found here
https://sketchfab.com/3d-models/lowpoly-fox-01674a892f414c0681afdeb563cc8e13
bright pivot
bright pivot
WHEW
bright pivot
added some params to make them a bit nicer
bright pivot
using blue noise for my random offsets look SO much better than pure random
comparison of the noise textures
bright pivot
got an in engine text editor working
bright pivot
i rewritten my #include stuff. stb_include is no longer a dependency and i have my own implementation
drifting roost
are you using an extension with your GLSL or have some of your preprocessing?
bright pivot
the preprocessing is just done in c++
the glsl extension for include isnt even core in any version so i chose to not bother with it
glsl DOES have a preprocessor, it just doesnt support #include which is what i had to manually do
bright pivot
it does not, not a core glsl feature
bright pivot
cause you use a non standard shader preprocessor
bright pivot
im talking the glsl compiler itself
plug shader source with #include into glCompileShader, it will fail unless you setup the glsl ext for it
drifting roost
right I'm saying I don't need to do any C++ to do that given the glslangValidator does that
but that wouldn't work for you I guess
given you want to edit it there
bright pivot
and i dont want to bother with that since theres no guarentee itll be installed and its one less thing to ship
bright pivot
to be fair my #include preprocessor is only like 20ish lines long
drifting roost
nice
bright pivot
the performance is horrible but shader compilation isnt fast anyways so idc
but the idea now is with this i can associate file paths with the source numbers generated in code, so if an error happens i can have my in engine tooling display the actual glsl file it happened in
its 45 lines oop
also the way i write shaders glslang wouldnt be able to figure out the shader types anyhow
so in most my shaders they begin like this
#version 450 core
#inject
#include "common.glsl
do you use a glsl linter
bright pivot
obviously the version thing is nothing new, the #inject gives the engine the opportunity to throw in whatever defines it wants which it does, and include is obvious enough
bright pivot
do you use a glsl linter
i do not
drifting roost
I have so many problems with typos in my GLSL
linter saves me from so much self-inflicted pain, but it's a skill issue on my side
bright pivot
in my case with the new workflow, the engine will try loading, error happens, and the in engine tooling will highlight the error and you can edit it and hotswap it in
drifting roost
nice
bright pivot
but the same source is used for both vertex and fragment shaders a lot of validating tools have no idea how to handle it
and no tools i know of would know wtf to do with the #inject since thats a runtime generated source
drifting roost
yeah I had that issue in my foundations project since I did my own including also, and couldn't use a linter
I gave all that up just so I could lint and I switched to the offline thing
bright pivot
in some old project here the #inject would also have quality settings too
drifting roost
different use case than yours
bright pivot
so say you disable shadows or something, it can stright up delete it from the glsl source and would run better (after recompilation
drifting roost
nice
bright pivot
but this is all planned to come back, i need a more proper resource management solution to allow me to do this stuff
bright pivot
Idea I could just save the preprocessor output and lint that with validatir
bright pivot
Compilers are encouraged to detect ill-formed programs and issue diagnostic messages,
but are not required to do so for all cases
mann this would solve so many issues if this wasnt a thing in glsl
drifting roost
this is your ingame editor? wow
nimble onyx
what plugin are you using for text highlighting?
also in case it has problems you may want to not apply it immediately XD lower risk of crashing the driver that way
bright pivot
The driver isn't going to crash from anything I'm doing
The editor is my own fork of an ingui project
It's its all such a mess I'm likely to make my own from scratch
the text highlighting is all custom, just regex and a couple other things
tldr im very unhappy with the state of imgui code editors and i plan to make something easy to integrate and use
drifting roost
nice
how do you search?
you wrote your own fuzzysearch?
or are you using something
bright pivot
im using something for that
i will be implementing my own for it so itll be all one thing
im working on improving the fuzzy search rn
bright pivot
improved fuzzy scoring
its a mix of token splitting, regex matching and whole word matching
bright pivot
theres a bug with a widget and i have to manually do this shit
bright pivot
Aight the command palette system now handles global keybinds and fills in the main menu bar for me
bright pivot
ive written the entire command pallete and im very happy with it, im likely gonna release it for use
bright pivot
i cleanup the code its avail in the dev branch for anyone who wants to try it out, only requires cpp23 and imgui
bright pivot
just showing the basic usage of the tools thus far
drifting roost
you should show this off in #showcase this is great stuff
bright pivot
you should show this off in <#390264006402899979> this is great stuff
perhaps once i tidy stuff up
drifting roost
I'm kind of liking hanging out and sharing stuff in #wip instead of having a thread. I still like looking at other people's threads though, I wish more people looked at threads
bright pivot
i just share here, keeps me more focused and those who arent interested just dont follow the thread and simple as that
bright pivot
these are growing rather quick aha aha
bright pivot
Hmmm what to work on today
bright pivot
working on abstracting a bit of a lua layer, gonna allow scripting to happen now, i already have plans on how to safely handle infinite loop cases from the scripting side
bright pivot
experimenting with audio and i have playback and everything working, but now im going about reading back the audio frames to calculate the ppm of the audio frame window,
i now have a LOT more respect for audio tools now
bright pivot
Managed to get this little ppm meter somewhat usable
This is the ppm of the left channel cause lazy
bright pivot
got a more interested song playing, multichannel visual workin
bright pivot
im going insane mannn, finally got an 8 order lpf working
bright pivot
Also custom mesh format is going really well. You can just memcpy the file contents into a buffer. Directly upload and read the metadata. I'm just at a point of deciding what attributes should be supported. How many uv channels? Color channels? Should I bother storing bitangents if normals and tangents are there. Etc etc
bright pivot
we're so back baby
so this is a wip of a little effect applied to in game monitors
im starting a new project and i have an actual goal in mind this time around and im actually very excited for it
im gonna keep the details of that under wraps since the project itself i dont think would cater to this community much but ill still be showing the technical stuff and neat things as they happen
along with this more off topic things will end up in wip as well just as a conversation
bright pivot
with the new mesh format stanford dragon takes ~8.3ms to load (same speed on debug and release), this includes all io operation and the cpu side upload calls
iron cove
got distracted
bright pivot
made this helper template function for using entt dispatcher
makes events pretty nice to hook into
solemn bone
Just wanted to let you know I'll be releasing 5.0-beta4 this weekend
bright pivot
Just wanted to let you know I'll be releasing 5.0-beta4 this weekend
Woah already!? We just got beta3. Anything worth noting here?
solemn bone
Some flag deprecations (they all have replacements), symbolic link support, several new platforms are supported (as well as lots of new CI jobs for automated builds), updated a few dependencies, and fixed a handful of bugs
bright pivot
Awesome!
solemn bone
Will also be removing transparently removing gmake (and renaming gmake2 to gmake) in the next beta (probably mid february 2025)
bright pivot
Sick. I havnt used the old gmake so good
bright pivot
im pretty happy with my little function traits stuff, unusually helpful
bright pivot
Bet!
bright pivot
been messing about with basic multilang support and im very happy with progress so far
i was originally worried about speed of constantly accessing the lua script to read these, but this takes <1us so its a non issue right now
bright pivot
We now taking advantage of renderdoc 1.5 api features
drifting roost
what's happening in that video?
bright pivot
I have a language file open on the right and it's responding to file changes and fmt changes
The idea being you csn easily swap this file and have all the important strings change without recompiling. Multilingual support alresdy is partially working
Itll happily display korean
drifting roost
wow
bright pivot
All configurations data etc will be read and written with lua
It's very nice. I've already put I the security checks to prevent scripts from doing crazy shit
bright pivot
been messing about with basic multilang support and im very happy with progress ...
In order of what's happening.
drifting roost
really cool, should make for a fast dev loop
bright pivot
really cool, should make for a fast dev loop
It does. Hot swapping shaders will happen soon too
bright pivot
so obviously lua is like the most popular scripting language out there, but ive heard webassembly could be good as well
bright pivot
just showing some stuff dont mind me
bright pivot
theres lots of features to get working early, onegreedy meshing gotta come back along with allowing different textures to be used in different locations for the same block
bright pivot
Forgot to mention this is custom text rendering. I'm going to be writing my own gui lib on top of everything here
drifting roost
I need to do that also :/
bright pivot
What part.
There's just some stuff with imgui that'a really annoying and text rendering generally being one of them. Lack of content scale awareness to name a few
drifting roost
I want non-debug ui that's my own
I don't want to use imgui for the game's UI
for debugging imgui is fine
in a hypothetical release if I ever have one I don't even want to include imgui in the executable
I manually manage content scale for imgui fwiw
like for fonts
bright pivot
thats more or less exactly what im working on terms of gui
hence youre already seeing multilang support happen
I also don't like how the glfw imgui backend stright up takes full control of certain things
bright pivot
ayo apparently ive implmented greedy meshing before in an old codebase, TIME TO STEAL FROM MY PAST SELF
who apparently was smarter than me now
drifting roost
are you using barycentric coordinates for your triangle lines?
interesting, usually I just change polygon mode from file to line
bright pivot
it basically does that but just draws an extra time
drifting roost
ah
bright pivot
REALLY old project, not ideal
drifting roost
you can do some shader business with barycentric coordinates to do lines I did that once
adds control flow to the shader though so idk
bright pivot
can easily be guarded with an ifdef though
drifting roost
true
bright pivot
well its like sometimes it just like doesnt greedy mesh anything
and looks like the easy cull method
also the code behind it is AWFUL so erm
honestly may be better to do that from scratch again
oh this shit is fucked up
fixed the bug
bright pivot
managed to port the code over, gotta do a lot of cleanup
bright pivot
are you using barycentric coordinates for your triangle lines?
do tell me how abouts you did this
https://codeflow.org/entries/2012/aug/02/easy-wireframe-display-with-barycentric-coordinates/
i did find this, youve gotta use wayback to get to it but ima read this and see
looks like this can be entirely done in shader without the attrbutes
huh thats wild
drifting roost
this is what I had way back when, I didn't really know anything back then but I had lines like that:
https://github.com/btipling/blockens/commit/1a5b8ebe40e95cc9f95a032913f751a063dc8bc4
this is like 2 or 3 months into learning opengl
bright pivot
wasnt too hard to make it look alright
bright pivot
yeah cause i can easily just not use vertex attributes and waste tons of data on it
pure shader edit which is very nice
so you could just put it in a uniform and call it a day
bright pivot
vBC = vec3(0.0);
vBC[gl_VertexID % 3] = 1.0;
my dumb af way to skip out on vertex attribs
drifting roost
yeah I used attributes
that's better
I didn't even know what gl_VertexID was then
bright pivot
having 3 extra floats per vertex to only sometimes draw triangles seems like a huge waste
drifting roost
barycentric coordinates have a lot of nice uses
bright pivot
i used to use it way back to manually do collision on a heightmap
its actually really nice to not have that z fighting for this
so ill just stick this behind an ifdef and thatll be all i need for it
^ heres the resource i briefly followed to get an idea on wtf i was doing
oh and you can easily change the opacity of the wireframe
always forget how big a difference greedy meshing can made whew
bright pivot
got my multiple fanned stones working, 4 different textures but lil tricks
this screenie can show that better
drifting roost
did your frame time decrease?
bright pivot
its on vsync so i have no idea
ill time this rq, the triangle count went down ~95% so it probaby will be lower frametime
drifting roost
lol nice
bright pivot
Did some measuring, theres no significant impact on frametime
likely cause theres only one chunk here
im very sure there will be bigger impact once i decide to expand the scene here
ive been wanting to make a little built in profiler though so this may be a good place to begin
i feel like i dont really have much worth profiling though
bright pivot
rewriting and updating the greedy mesher to support multiple blocks
bright pivot
bright pivot
bingo, code is readable this time, just gotta refactor so i can put this into a proper loop
drifting roost
looks amazing
bright pivot
tdlr its generic and iterates for each 6 faces, you just need to specify the direction, base mesh and swizzle mask
14855us in debug
1025us in release
not horrible
bright pivot
super basic lighting
the greedy meshing did introduce the small little gaps cause floating point math is perfect, so looking at ways to improve that
either removing t junctions which make generation WAYYY more complex, i could use a simple post fx to check for values like this, or even some antialiasing of some sort could hide this, either way not a super high priority, also looking into method of shadowing and occlusion, mesh based occlusion is more or less out the window since greedy meshing doesnt work nicely with that and will likely use a screenspace solution
bright pivot
new profiler graph started
bright pivot
viscid karma
Well this is very cool!
iron cove
Advice: ALWAYS test chunk render code on negative values
Very easy to end up with incorrect offsets or off by ones with that
bright pivot
Advice: ALWAYS test chunk render code on negative values
This already happens. The bugs related to that are fixed already
bright pivot
Gonna work more on profiling today. When showing percentages of frame times. Should I show the times for last frame or an average over like 30 frames?
drifting roost
I would like to show an average, I haven't gotten to that yet, I just show the last frame times. I want to have a implot too
bright pivot
the stuff is all there to easily show averages, im just not super sure what would be super helpful ykyk
drifting roost
I just like averages because it makes the fps readable instead of updating every frame
solemn bone
Just a heads up that premake v5.0-beta5 is going to release this weekend @bright pivot
bright pivot
Just a heads up that premake v5.0-beta5 is going to release this weekend <@21841...
Hell yeah. I havnt been in need of the new features but I've gotta keep up with it
bright pivot
I just like averages because it makes the fps readable instead of updating every...
Question also is over how many frames to take the average. I was thinking just 30
solemn bone
Hell yeah. I havnt been in need of the new features but I've gotta keep up with ...
Big thing here in this patch is the official deprecation of gmake for gmake2
Scripts using gmake are automatically transitioned to use gmake2 now
bright pivot
ooh right, ive been using gmake2 for ages but thats a nice change
solemn bone
gmake2 is actually renamed to gmake under the hood, but we have an alias pointing gmake2 at gmake so existing scripts will continue to work with warnings to use gmake in your filters and actions 🙂
trying to keep to a roughly ~6 week release cycle
bright pivot
excitment!
drifting roost
Question also is over how many frames to take the average. I was thinking just 3...
sounds ok to me, I was not sure myself I am not doing it yet
bright pivot
also a mechanic im still disapointed about that isnt in any 3d block game is the terraria style painting mechanic
drifting roost
I think that's what Jaker is working on in https://discord.com/channels/318590007881236480/1128020727380054046
a 3d block version of terraria
although not sure what you mean by block painting
I guess you were talking about something more specific
bright pivot
atm im just using a block style for fun, gives me something to mess about with
bright pivot
a lil more work here, red now represents unspecified/unknown time, green is gui draw time, yellow is the buffer swap
a way to group stuff and subdivide the stats are wip
viscid karma
I was gonna suggest showing %lows too for stuttering reasons but the graph kinda takes care of that
bright pivot
Low high and average would probably be good to have
bright pivot
im fucking around with world gen lmao, yes theres simple distance fog
drifting roost
I like distance fog, I may add a really small one to mine that won't fully obscure, just adds some minor distance effect
bright pivot
i only want mine to fully obscure at the far clipping plane
which a simple exp-pow fog plus smoothstep would do perfectly
i do plan to color the fog based on the view vector and sun direction too, makes it nicer imo
also implmented some win32 priority code which helps the frametimes a bit
bright pivot
May look more into the mesh data compression but it isn't a huge slowdown rn so I'm pushing it off as long as I can
bright pivot
Also experimenting with structure gen. I'm unsure if I want infinite world sizes though
bright pivot
looking into multiple rock layers
drifting roost
do you have a Character.cpp?
bright pivot
havnt bothered with that yet, but i could easily throw together some phyics and a character controller within a few hours
all the nessesary peices to do so are in place
i have over 10 rock types planned but figuring out how to generate them in the world is the hard part
theres not going to be a generic stone type, but the rock types suitable for certain things will be tagged as such thus making recipes easier to do
bright pivot
do you have a Character.cpp?
curious, are you looking for a controller controller to borrow?
bright pivot
isnt amazing but its a start
gonna leave this here for now, im gonna look into better ways to handle this sorta generation
drifting roost
curious, are you looking for a controller controller to borrow?
I am more interested in your harfbuzz implementation, I will need a good UI for https://discord.com/channels/318590007881236480/1323084490997895198
Do you rasterize with freetype?
And that generates something you can draw with OpenGL?
bright pivot
I am more interested in your harfbuzz implementation, I will need a good UI for ...
It is not fully supported. It still screws up on a lot of stuff. It uses stb_truetype
I do plan to pull all of this into a standalone gui library but I'll get there
solemn bone
premake5 beta5 is out
bright pivot
also more about the text rendering it rasterizes a glyph cache at runtime and i manually pack a texture atlas with the data
drifting roost
I see
bright pivot
yeeeee
bright pivot
working on some new graphical text rendering effects (will need accesability options to turn off tho
bright pivot
updating the profiling tools a lot, will now show locks, threads, zones etc
bright pivot
Looking into separating out my text and gui rendering along with feature requests. Besides imgui there's no real nice alternatives to rendering ui with an easy to setup library.
What sorta features would we wanna see?
solemn bone
imo, nuklear is also pretty good
bright pivot
imo, nuklear is also pretty good
I can give that a try. Basically I want a gui library that isn't intrusive to your application or backend
Which imgui is intrusive with default backends
solemn bone
oh yeah. i modified the "default" backends intentionally
(which is probably what you should be doing)
bright pivot
Thing is if I'm going to modify the backends. I may as well use a better suited library for closer to final rendering anyways
Esp since imgui has some thread safety issues as well
solemn bone
likely so
bright pivot
Which I did modify thr backends for some time and I couldn't keep up
solemn bone
really, you should only be using imgui for tooling like things. nothing that's exposed to the end "user"
bright pivot
Right. But I'd love to be able to have a debug ui library that's also capable to render the main ui
Like in all honesty is is pretty annoying thst imgui still isn't at all suited to nicer rendering thus you need another ui library anyways
From what I'm seeing nuklear might actuslly be a perfect middle ground
solemn bone
the thing is, it's "good enough" for a lot of use cases. any time you've got special requirements, you're going to need to build your own stuff. this is not an "imgui" only issue
I personally have really liked it in the past. Haven't used it in years, though
bright pivot
The main repo seems archives but there's a promoted active fork still so I'll give it a shot and see how I feel about it
solemn bone
It's not really a fork, they just moved dev to an org instead of a personal account
bright pivot
That's fair enough. Nice to see it's still active though
solemn bone
Definitely. I want to investigate moving back to using it over imgui
bright pivot
As much as I like imgui there's so many little annoyances that get to me
solemn bone
Also, there exists: https://github.com/nicbarker/clay
This one is pretty new
went "viral" on twitter a while back
bright pivot
I saw Clay and really disliked the heavy use of macros
solemn bone
agreed, but the arena based allocation is quite nice
bright pivot
Plus it doesn't seem to be suitable for debug uis
I'll give nuklear a shot. It is nice it more or less just gives you full of how input and rendering work which is very nice
solemn bone
👍
good luck. ping me if you have any useful info to share about your experience with it. i need to work on some ui stuff in my project at some point
bright pivot
I do have some existing stuff to nicely draw stroked shapes so I'll reimppment that for nuklear as well
Also if it's just a single header and it's as easy to build as it sounds. I'm gonna be in love lmao
solemn bone
Last time I used it was when I was working with LWJGL. The bindings there are quite nice
bright pivot
Lwjgl is like the gold standard for java bindings
I remeber when I used to work in java that I quite liked the bindings myself. I just never used nuckler
Except the opengl bindings were a bit weird but workable
bright pivot
im very happy with this so far
drifting roost
Nice. I set up tracy in Rosy, but I haven’t configured any zones or anything beyond the framemark yet 😅
bright pivot
ive written some custom tracy code to automaically profile and instrument lua code with little developer intervention, no more need to manually instrument lua code (mostly)
bright pivot
bright pivot
Got Tracy to track the realloc/free calls lua uses. It's pretty neat
You can actuslly see in thr trace where the gc happens
bright pivot
This sorta stuff making me really wanna make my own allocators cause there's so many new delete calls
drifting roost
I want my own allocators too
bright pivot
I mean these technically are my own allocator cause they hook into tracy but they still got into malloc free
bright pivot
Even pmr would be a big improvement
bright pivot
I now appreciate apis that expose their allocation functions
bright pivot
i can control how the lua gc works :0 you can easily see how much is allocated from a basic lua call and control when and how gc happens
bright pivot
implemented some fxaa, super simple post fx but does the job alright
bright pivot
Ur boi has officially contributed to Tracy
bright pivot
finally took to implementing normal mapping
nimble onyx
Cool barrel, nice and wet just the way I like em
bright pivot
Cool barrel, nice and wet just the way I like em
You rough asf fr
bright pivot
combining normal mapping with low poly lods is actually insane how well you can fake lighting
bright pivot
Original 200k tris
Low poly version 90% triangle reduction from 100k to 10k
Low poly version with normal map (2k x 2k)
iron cove
Yup
bright pivot
i have successfully make my terrain look like a crappy unity project 🧡
nimble onyx
More like a FF 8 FMV upscaled a bit
bright pivot
Idk if that good or not lmfao
bright pivot
Been working on improving the allocation strategy being used for lua, it now makes 0 new/delete/alloc/free/realloc calls
The Lua memory span is now 182.24KiB vs the old 517.51MiB with realloc/free, lua now gets 1MiB of memory
bright pivot
been a hot minute, been look into parallax mapping and finally gotten it to work!
you can see it in action here
bright pivot
took a lil change of direction for a bit, working on reflection and equirectangular skybox support
bright pivot
things looking uppp
bright pivot
been implementing the steamworks api and been going very well
bright pivot
took a break to handle life and all, im back and have been working on a new terrain renderer
bright pivot
bright pivot
trying out some different ideas for sun/sky rendering
would love to do actual atmosphere rendering but i have other priorities rn
bright pivot
finally got around to fixing shadow crawl
nimble onyx
shadow crawling and shimmering is kinda nice though it looks very game-y XD
bright pivot
Game-y yes. Nice though??? Hard disagree lmao
iron cove
What is shadow crawl?
bright pivot
When you move the camera around and the edges of shadows flicker
bright pivot
Here's an example I found on a forum since I'm away from PC rn
iron cove
alright
