Does gltfpack set a flag

[wicked notch]

It's kind of naive, I just see if the glTF has basisu images in it.

Ideally I'd want to set a flag somere in the extras section

https://github.com/LVSTRI/Iris/blob/master/src/texture.cpp#L28
https://github.com/LVSTRI/Iris/blob/master/src/model.cpp#L65
This is the implementation by the way

Feel free to steal as I have stolen from others

[frank sail]

I've never seen std::type_identity before
auto* ktx = std::type_identity_t<ktxTexture2*>();

apparently it's useful for implicit type conversions to the template type

[wicked notch]

My reasoning for using that is I don't like declaring the type on the left

[frank sail]

uh

[wicked notch]

Call me crazy, I deserve it

[frank sail]

you can just write auto* ktx = ktxTexture2*{};

nvm

you have to write it like (int*){}

er

(ktxTexture2*){}

[wicked notch]

Interesting.

[frank sail]

damn, libktx looks super easy to use

[wicked notch]

I guess my life is a lie then

[frank sail]

for value types, you can indeed write auto foo = Foo{}; (or Foo()), which I do a lot

I guess pointer syntax is brain damaged, so you can't write it exactly like those

[wicked notch]

Truer words have never been spoketh

[frank sail]

I learn something new about C++ every time I read your code

what's the advantage of defining swap for a custom type instead of just defining a move constructor and move assignment operator?

[wicked notch]

I don't understand it fully either, but apparently it avoids repetition and favors ADL

[frank sail]

my move semantics are cursed, lemme show you

[wicked notch]

It's called the copy-and-swap idiom

[frank sail]

  Buffer::Buffer(Buffer&& old) noexcept
    : size_(std::exchange(old.size_, 0)),
      storageFlags_(std::exchange(old.storageFlags_, BufferStorageFlag::NONE)),
      id_(std::exchange(old.id_, 0)),
      mappedMemory_(std::exchange(old.mappedMemory_, nullptr))
  {
  }

  Buffer& Buffer::operator=(Buffer&& old) noexcept
  {
    if (&old == this)
      return *this;
    this->~Buffer();
    return *new (this) Buffer(std::move(old));
  }

[wicked notch]

I always flinch when I see a placement new

for some reason

[frank sail]

I did some epic spec reading with others to ensure this is actually legal code

iirc there is an edge case with this pattern when you have a pointer to a subobject of the object that gets destroyed

where the spec isn't clear on whether it's UB

but no one should (or can) be making pointers to members of Buffer, so it's fine here

[wicked notch]

Reject the spec, embrace "it works on my machine"

[frank sail]

anyways, the whole point of this is to reduce duplication in favor of spooky placement new

60% of the time, it works every time

[wicked notch]

I'll keep my "swap" thanks

[frank sail]

you need move semantics anyways, no?

swapping isn't the only reason I need em

idk, this is #bikeshed-😇 material

[wicked notch]

If I didn't misunderstand that idiom, copy-and-swap works in all cases

Because you define only one copy assignment op, taking self by value

and you just swap that with *this

[frank sail]

yeah, it seems to work

[wicked notch]

If you pass anything that's not an xvalue or rvalue it copies it

otherwise, move constructed

Then you swap it with either the copied state, or "unspecified" state (depending always on whether you move or not) which agrees to move semantics

I don't know where ADL comes into play but I never understood ADL

Or anything about C++'s overloading resolution rules

[frank sail]

yeah, they're absurdly complex

all I know is that it enables this construct
endl(std::cout);

oh, it also lets you do this

    std::string a{"hello"};
    std::string b{"world"};
    swap(a, b);

which means you don't have to force a particular version of swap, if your thing happens to define it in its namespace/class/whatever

std::swap means you will get something slightly less optimal than if you implemented your own swap, since it always move-constructs a temporary instead of just swapping each member

maybe once they add reflection, we can finally have an optimal std::swap

[wicked notch]

Good morning friends

Today I discovered that cutting electricity for half a day is legal in this country

Can't really do anything about it if it's an issue in the electrical distribution network.

Anyways now that we have Indirect Drawing and Shadows figured out, I will now ponder where to go next.

Possible candidates are OIT and Frustum Culling

OIT is really interesting because it uses Linked Lists on the GPU which to me is fairly wild.

[frank sail]

that's just one possible implementation of OIT

if you want the state of the art, you probably want one of these (second one requires RoVs which aren't on AMD)
http://momentsingraphics.de/MissingTMBOITCode.html
https://www.intel.com/content/www/us/en/developer/articles/technical/oit-approximation-with-pixel-synchronization.html

[wicked notch]

But no linked lists 😦

Are there other things things that use GPU Linked Lists, I'm very curious to try them

[frank sail]

linked lists generally aren't what you want to be doing on the GPU 😄

[frank sail]

may I suggest occlusion culling

all done in a compoot shader

well, there's raster occlusion culling, which uses the frogment shader

[wicked notch]

Occlusion culling in compute hmm.

[frank sail]

look up "hi-z occlusion culling"

it's a bit more complex than raster occlusion culling

you can use both at the same time if you wish

[wicked notch]

Alright I have pondered enough, it's time to setup frustum + occlusion culling

[wispy spear]

so, how did you compress sponza

did you just run compressonator with some flags?

and it produced ktx2 files out of png?

[wicked notch]

I ended up not using Compressonator as it was far too overkill for my purposes, instead gltfpack is very automagic

gltfpack -i .\bistro\bistro.gltf -o .\compressed\bistro\bistro.glb -tc -tq 10 -vpf -kn -km -ke -noq```

I just had to run this and boom: everything is compressed

[wispy spear]

ah neat

[wicked notch]

Somehow I always manage to forget GPUs are parallel machines

Hmm I still get occasional flickering for some reason?

Even though this was most likely the issue, there is still flickering once every second or so, randomly

Shader is just this:

void main() {
    uint index = gl_GlobalInvocationID.x;
    if (index == 0) {
        for (uint i = 0; i < u_draw_count; ++i) {
            draw_count[i] = 0;
        }
    }
    barrier();
    if (index < u_object_count) {
        const object_info_t object = objects[index];
        const mat4 local_transform = local_transforms[object.local_transform];
        const mat4 global_transform = global_transforms[object.global_transform];
        const mat4 model = global_transform * local_transform;
        if (is_object_visible(object, model)) {
            const uint slot = atomicAdd(draw_count[object.group_index], 1);
            indirect_commands[slot + object.group_offset] = object.command;
            object_shift[slot + object.group_offset].object_id = index;
        }
    }
}

(is_object_visible always returns true for now)

[frank sail]

do you call glMemoryBarrier in your host code

[wicked notch]

I have no idea what that is (so no)

[frank sail]

it's necessary to make your program correct

[wicked notch]

Interesting, I'll read up on that

[frank sail]

it ensures incoherent reads and writes (SSBO and image stores from shaders) are visible/completed to future operations

so if you write some indirect commands in a shader, then do glMultiDrawElementsIndirect, you need glMemoryBarrier(GL_COMMAND_BARRIER_BIT); between them

otherwise the driver cannot see that the MDI command depends on the dispatch and issue the corresponding synchronization and cache flush/invalidation

[wicked notch]

I see

So just like CPUs atomics then

I assume "visible" and "available" mean the same thing (I mean, not that visible == available, just that visible/available on the CPU are the same on the GPU)?

[frank sail]

glMakeVisible and glMakeAvailable

(jk those don't exist)

[wicked notch]

It's basically a cache flush

[frank sail]

there is just one concept of memory visibility in opengl

btw, DX11 doesn't have this, so the driver has to issue conservative barriers between every pass that does incoherent writes

which means you can't mess up sync, but you also cannot get maximum perf

anyways, flickering like what you have is typically a symptom of a synchronization issue

you can check it by inserting glFinish or glMemoryBarrier(GL_ALL_BARRIER_BITS) after every draw/dispatch that does SSBO/image writes

[wicked notch]

Very interesting

Why does cache become incoherent on the GPU itself though?

Like, the GPU is feeding itself data, how does it fail to maintain coherency?

Oh it's probably because each GPU SM has its own cache and any workgroup writing data is not guaranteed to be the same reading it?

[frank sail]

GPU cache coherency protocols are very basic compared to CPU ones

and often rely on manual flushes and sync

idk all the details though

[wicked notch]

So hold on a sec

I also do a depth reduce and setup shadow cascades in compute

...Am I supposed to insert barriers here too?

[frank sail]

prob

[wicked notch]

But it's been working fine up until now with no errors from the debug callback

[frank sail]

any time you want a write to be visible or a read to have finished before the next pass that consumes the memory, you need a barrier

[wicked notch]

So this:

depth_reduce_init_shader.bind();
offscreen_attachment[1].bind_texture(0);
depth_reduce_attachments[0].bind_image_texture(0, 0, false, 0, GL_WRITE_ONLY);
camera_buffer.bind_base(1);
glDispatchCompute(depth_reduce_wgc[0].x, depth_reduce_wgc[0].y, 1);

depth_reduce_shader.bind();
for (auto i = 1; i < depth_reduce_wgc.size(); i++) {
    depth_reduce_attachments[i - 1].bind_image_texture(0, 0, false, 0, GL_READ_ONLY);
    depth_reduce_attachments[i].bind_image_texture(1, 0, false, 0, GL_WRITE_ONLY);
    glDispatchCompute(depth_reduce_wgc[i].x, depth_reduce_wgc[i].y, 1);
}```
becomes this:
```cpp
...
glDispatchCompute(depth_reduce_wgc[0].x, depth_reduce_wgc[0].y, 1);
glMemoryBarrier();
depth_reduce_shader.bind();
for (auto i = 1; i < depth_reduce_wgc.size(); i++) {
    ...
    glDispatchCompute(depth_reduce_wgc[i].x, depth_reduce_wgc[i].y, 1);
    glMemoryBarrier();
}```?

[frank sail]

ye

[wicked notch]

Hmm I also read from the depth's sampler though, do I need a barrier here too 🤔

Before the first dispatch, I mean

[frank sail]

wdym before the first dispatch

like in some draw?

[wicked notch]

The first dispatch here, reads from a framebuffer attachment (the depth attachment, written to by a Z-prepass)

Should I do glMemoryBarrier(GL_FRAMEBUFFER_BARRIER_BIT);?

The spec isn't very clear on the rules.

[frank sail]

SHADER_IMAGE_ACCESS_BARRIER_BIT: Memory accesses using shader built-in image load, store, and atomic functions issued after the barrier will reflect data written by shaders prior to the barrier. Additionally, image stores and atomics issued after the barrier will not execute until all memory accesses (e.g., loads, stores, texture fetches, vertex fetches) initiated prior to the barrier complete.

btw, the ref pages do not mention this critical information for some of the barrier bits, so you best refer to the spec

https://github.com/KhronosGroup/OpenGL-Refpages/issues/128

[wicked notch]

Hm

Interesting

[frank sail]

I guess that is to say that you need a barrier before the first dispatch as well

[wicked notch]

By the way

We might have a situation

Using glFinish(); I still see occasional flickering

[frank sail]

spoopy

idk if glFinish technically makes writes visible, so maybe don't use that

or use glFinish+glMemoryBarrier if you're super paranoid 😄

[wicked notch]

Uhhh

glMemoryBarrier(GL_ALL_BARRIER_BITS);
glFinish();``` still flickers

oh no

[frank sail]

where did you put it

[wicked notch]

After the dispatch that writes indirect commands

[frank sail]

damn

maybe there is a race within that shader. Lemme look at it again

shader looks okay

[wicked notch]

I pushed this broken stuff

https://github.com/LVSTRI/Iris/blob/master/shaders/5.0/generic_cull.comp

[frank sail]

I thought atomics could only be done on variables that were neither readonly nor writeonly

[wicked notch]

Compiler doesn't really complain but you are right lol

It doesn't really make sense for it to be writeonly

Same flickering though

[frank sail]

I guess try debugging with nsight

or somehow simplifying the shader (e.g., removing the atomic and just using the global invocation id, if possible)

wait

Can you explain the loop at the beginning of your shader

[wicked notch]

Since the shader increments the draw_count, I need a way to reset it between invocations

So that it doesn't grow to infinity and beyond

[frank sail]

What do you expect barrier() to do

[wicked notch]

Make all other threads wait for the first thread to finish initializing draw_count?

[frank sail]

Did you know that barrier only synchronizes threads within a single workgroup

i.e., it is not global sync

so the code is probably wrong if you have more than one wg

[wicked notch]

me:

[frank sail]

Try clearing the buffer with this
https://registry.khronos.org/OpenGL-Refpages/gl4/html/glClearBufferSubData.xhtml

[wicked notch]

Yeah...

no more flickering

How many more absolutely vital pieces of information am I missing I wonder

[frank sail]

just read the whole gl and glsl specs before continuing

[wicked notch]

Took a whole day just to setup Frustum Culling

Very promising dare I say

[frank sail]

usually takes me a lot longer than that 🙂

[wispy spear]

and me ^3 that

[wicked notch]

Alright that's a wrap, tomorrow we'll have actual frustum culling (and possibly even occlusion)

[wicked notch]

By the way I only just realized that gltfpack merges primitives if they have the same node and material

Thankfully it's open source so I could simply add a flag and build from source

[wicked notch]

bool intersect_aabb_plane(in aabb_t aabb, in vec4 plane) {
    const vec3 normal = plane.xyz;
    const vec3 size = aabb.size.xyz;
    const vec3 center = aabb.center.xyz;
    const float radius = dot(size, abs(normal));
    return -radius <= dot(normal, center) - plane.w;
}

bool is_object_visible(in object_info_t object, in mat4 model) {
    const aabb_t aabb = object.aabb;
    const vec3 world_aabb_max = vec3(model * vec4(aabb.max.xyz, 1.0));
    const vec3 world_aabb_min = vec3(model * vec4(aabb.min.xyz, 1.0));
    const vec3 world_aabb_center = (world_aabb_max + world_aabb_min) / 2.0;
    const vec3 world_aabb_extents = world_aabb_max - world_aabb_center;

    const aabb_t global_aabb = aabb_t(
        vec4(world_aabb_min, 0.0),
        vec4(world_aabb_max, 0.0),
        vec4(world_aabb_center, 0.0),
        vec4(world_aabb_extents, 0.0));
    for (int i = 0; i < 6; ++i) {
        if (!intersect_aabb_plane(global_aabb, frustum.planes[i])) {
            return false;
        }
    }

    return true;
}``` It was disappointingly trivial to implement...

Learning about AABBs with mouse picking was worth it

[wicked notch]

Is it worth doing this for shadow maps too? 🤔

[wicked notch]

Hmm, frustum culling shadow cascades doesn't really work sadly, I need more tolerance I guess?

[wicked notch]

Turns out my intuition for culling shadow lights was completely off

I'm now following this scary looking paper: https://arisilvennoinen.github.io/Publications/Shadow_Caster_Culling_for_Efficient_Shadow_Mapping.pdf but it's probably better if I do occlusion culling first

[wicked notch]

CHC++ Uses hardware occlusion queries, but from what I'm reading they are fairly inefficient due to CPU stalling, can conditional rendering fix this?

Maybe HiZ culling is the way to go?

[frank sail]

Ye

Hardware occlusion queries aren't great these days since you can just write to a buffer now

[wicked notch]

But how do you do occlusion culling for shadows?

HiZ requires depth

But shadows are depth

[frank sail]

uh

you do it the exact same way as usual

[wicked notch]

https://tenor.com/view/favorite-facts-equations-math-confused-gif-15404559

[frank sail]

here's a classic algorithm:

1. Render objects that were marked visible to depth
2. Perform occlusion culling against depth, marking visible objects

if you do it all on the GPU, there is just one frame of latency between an object being marked visible, and actually being drawn

But you can add a third step to remove that latency

By simply drawing the objects whose visibility changed from 0 to 1 this frame

[wicked notch]

I uh

How do you do step 2 without rendering all objects

You need the depth of every object to check whether the object is visible or not?

[frank sail]

Step 2 depends on the implementation

For hi-z, it means performing the test for every object's bounding volume

For raster occlusion culling, it means drawing the bounding volume for every object (which is hopefully substantially cheaper than actually drawing every object)

Raster is cool because it's so shrimple

Here's a sample that implements it
https://github.com/JuanDiegoMontoya/Fwog/blob/main/example/05_gpu_driven.cpp

[wicked notch]

Wow you actually render cubes

Incredible

It's not like you told me already

...if I'm dumb

[wispy spear]

thats a cute pic

[wicked notch]

Shadow frustum culling for some unknown reason does not work

Isn't it the same exact thing? As frustum culling for perspective projections I mean.

Even though I explicitly disable near plane culling, it looks like it's doing it anyways...?

I think

Nevermind I don't

[frank sail]

The only difference is where your planes are

[wicked notch]

Ight it works now

[wicked notch]

bug was actually pretty obvious, you get one LVSTRI point if you spot it

Actually nevermind, that was just placebo, I'm not culling anything now

I actually have no idea now 🤔

bool is_aabb_inside_plane(in aabb_t aabb, in mat4 model, in vec4 plane) {
    const vec3 normal = plane.xyz;
    const vec3 extent = aabb.extent.xyz;
    const vec3 center = aabb.center.xyz;
    const float radius = dot(extent, abs(normal));
    return -radius <= (dot(normal, center) - plane.w);
}

bool is_object_visible(in object_info_t object, in mat4 model) {
    const aabb_t aabb = object.aabb;
    const vec3 world_aabb_min = vec3(model * vec4(aabb.min.xyz, 1.0));
    const vec3 world_aabb_max = vec3(model * vec4(aabb.max.xyz, 1.0));
    const vec3 world_aabb_center = vec3(model * vec4(aabb.center.xyz, 1.0));
    const vec3 right = vec3(model[0]) * aabb.extent.x;
    const vec3 up = vec3(model[1]) * aabb.extent.y;
    const vec3 forward = vec3(-model[2]) * aabb.extent.z;

    const vec3 world_extent = vec3(
        abs(dot(vec3(1, 0, 0), right)) +
        abs(dot(vec3(1, 0, 0), up)) +
        abs(dot(vec3(1, 0, 0), forward)),

        abs(dot(vec3(0, 1, 0), right)) +
        abs(dot(vec3(0, 1, 0), up)) +
        abs(dot(vec3(0, 1, 0), forward)),

        abs(dot(vec3(0, 0, 1), right)) +
        abs(dot(vec3(0, 0, 1), up)) +
        abs(dot(vec3(0, 0, 1), forward)));

    const aabb_t world_aabb = aabb_t(
        vec4(world_aabb_min, 1.0),
        vec4(world_aabb_max, 1.0),
        vec4(world_aabb_center, 1.0),
        vec4(world_extent, 1.0));
    const uint planes = bool(u_disable_near_culling) ? 5 : 6;
    for (uint i = 0; i < planes; ++i) {
        if (!is_aabb_inside_plane(world_aabb, model, frustum.planes[i])) {
            return false;
        }
    }

    return true;
}
``` This should be fine?

I mean, it works perfectly fine for a perspective projection, why not for shadows?

it's just culling completely visible objects for some unknown reason?

They aren't even z < 0

It's only the first cascade as well...

I'm lighting the Jaker beacon

https://tenor.com/view/wongwingchun58-gif-15613675

[frank sail]

ask chatgpt what's wrong with your code

[wicked notch]

Why would you even suggest that

[frank sail]

cuz I'm a lazy bastard

[frank sail]

ngl I actually asked chatgpt, but I can't tell if it's answer is correct

probably because I don't understand 100% of the math in the original code

maybe it'll help if you walk me through the math, style 😄

btw, is_aabb_inside_plane has an unused parameter

and arguably is_object_visible should take an aabb_t instead of an object_info_t, if all you need from it is the AABB

[wicked notch]

Yeah that's me checking various things

Anyways the math is as follows:

• Translate AABB's center to world space model * vec4(center, 1)
• Translate and correct AABB's extents (should account for rotations and scales, we use the first 3 columns of the model matrix to correct this)
• Check if the AABB is on or inside all 6 planes (or 5 if near culling is disabled, last plane is the near plane), we basically take the signed distance from the plane's origin to the center of the AABB and check if it's within radius or more

dot(normal, center) gives whether the point is inside or outside the plane

Is there any way I can debug a compute shader?

[frank sail]

no 😦

well, not in gl

[wicked notch]

Out of pure curiosity, what did answer?

[frank sail]

It said something about the computation for world_extent being wrong

[wicked notch]

I have discovered

A thing

Actually multiple things.

First off my signs are completely broken.

[wispy spear]

https://tenor.com/view/signs-gif-13324315

[wicked notch]

Second, distances from the plane origins are garbage

Third.

I have no idea how to fix all this

Therefore I'll grab a man's best friends: pen and paper, and write down stuff.

[frank sail]

how dare you disrespect man's true best friend

[wicked notch]

True, pen and paper are actually a man's oldest friend.

A tool as old as time

[wicked notch]

With inverse(view)
[0] = {iris::plane_t} {normal=[0.609994292 0 0.792405844], distance=-4.57495737}
[1] = {iris::plane_t} {normal=[0.609994292 0 -0.792405844], distance=-4.57495737}
[2] = {iris::plane_t} {normal=[0.5 0.866025447 0], distance=-2.88397455}
[3] = {iris::plane_t} {normal=[0.5 -0.866025447 -0], distance=-4.61602545}
[4] = {iris::plane_t} {normal=[-1 -0 -0], distance=-504.5}
[5] = {iris::plane_t} {normal=[1 0 0], distance=-7.4000001}

With inverse(pv)
[0] = {iris::plane_t} {normal=[-0.609995067 0 0.792405247], distance=-4.57496309}
[1] = {iris::plane_t} {normal=[-0.609995067 0 -0.792405247], distance=-4.57496309}
[2] = {iris::plane_t} {normal=[-0.500000775 0.86602503 0], distance=-4.61603069}
[3] = {iris::plane_t} {normal=[-0.500000775 -0.86602503 0], distance=-2.88398075}
[4] = {iris::plane_t} {normal=[1 0 0], distance=-504.5}
[5] = {iris::plane_t} {normal=[-1 0 0], distance=-7.4000001}

Why god

[wicked notch]

I fixed the thing

I finally achieved inner peace.

@ derhass helped me a lot, honorable mention here.

[wicked notch]

Alright

Now occlusion culling

Wish me luck

[wispy spear]

good luck

[wicked notch]

Hmm, the "first frame" is very important in raster occlusion culling apparently, but I still don't understand the "core loop" very well

If the first frame I perform no occlusion culling, the next frame I am supposed to mark all objects that were visible the previous frame and render them?

What about changes though? Reprojection of the depth buffer?

[wispy spear]

you can run a frame before the gameloop starts

[wicked notch]

And I guess any time I can't reliably reproject 😅

[frank sail]

you don't need to reproject anything

[wicked notch]

[frank sail]

reprojection is for if you want to reuse an old depth buffer for new object positions

but you don't have to do that

[wicked notch]

Hmm.

https://tenor.com/view/pondering-pondering-my-orb-my-orb-orb-pondering-my-pondering-my-orb-orb-gif-24060364

[frank sail]

I described some methods above that don't require reprojection

[wispy spear]

a dogjiff.gif also doesnt require reprojection

[frank sail]

I suppose the core idea is that, instead of reprojecting, you use the object visibility from last frame instead

Also, the first frame isn't a special case when you do this

[wicked notch]

Yes, I see

Something like this I suppose

[frank sail]

yus

[wicked notch]

How do I know if an object is completely occluded though...

No samples pass the depth test? Doesn't that require an occlusion query 🤔

Oh wait that's what early Z is for right?

[frank sail]

early z + ssbo write in fs

[wicked notch]

If no samples pass the depth test then there will be no writes?

Crazy

Huge

[frank sail]

yep

quite epic indeed

https://github.com/JuanDiegoMontoya/Fwog/blob/main/example/shaders/gpu_driven/CullVisibility.frag.glsl

[wicked notch]

I can feel more brain expansion

[frank sail]

technically that code is UB btw

since there is a race if there are multiple fragments

[wicked notch]

atomicCompareExchange?

Or whatever it's called in GLSL

[frank sail]

atomicExchange

[wicked notch]

atomicCompSwap

[frank sail]

either one works

[wicked notch]

atomicCompSwap(data[draw_id].is_visible, 0, 1)

So that you only do this once

efishenshy

[frank sail]

writing the same value from multiple threads is technically UB according to the spec, but works on actual hw

[wicked notch]

Yeah makes sense, there's no reason why it wouldn't

[frank sail]

I imagine it's faster than atomics since you don't have to serialize access to the memory controller

[wicked notch]

Now what vertices do I feed the GPU?

Hmm

I suppose I could first do frustum culling, get the number of visible objects there, then build another indirect buffer with instanceCount = number of objects in frustum and draw cubes?

``` I don't really understand this...

[frank sail]

a cube lol

Cube hack
https://github.com/JuanDiegoMontoya/Fwog/blob/main/example/shaders/gpu_driven/BoundingBox.vert.glsl

The comment says 24 vertices, but I think it's actually 14

[wicked notch]

1e-1

What

-1.0?

[frank sail]

lmao

I must've been testing different epsilon values

[wicked notch]

Oh god this is going to be a mess isn't it

If I want to do occlusion culling for shadows too, that is

Each cascade gets its own indirect buffer...

[frank sail]

it shouldn't be too bad if you abstract it properly

[wicked notch]

This piece of code is copy-pasted 5 times

Uhh

I have these two buffer bindings here:

layout (std430, binding = 7) restrict buffer b_occlusion_draw_count {
    uint occlusion_draw_count;
};

layout (std430, binding = 8) writeonly restrict buffer b_occlusion_indirect_command {
    indirect_command_t occlusion_command;
};```

Because I need atomics basically

Is there any way I can avoid creating a whole SSBO for a single uint?

[wispy spear]

you could just use a glUniform1ui

[proven laurel]

^

[wispy spear]

what happened to your foo_t naming convention

[wicked notch]

Hmm but I'd still need to bind this buffer to GL_PARAMETER_BUFFER

[wicked notch]

I changed it, it didn't make much sense for buffers and uniforms and stuff

[wispy spear]

are you doing glMDICount?

[wicked notch]

Yes

[proven laurel]

isn't there GL_DRAW_INDIRECT_BUFFER? or does that not work with MDI?

[wicked notch]

Yes but you also need to bind a buffer to tell GL how many indirect commands to consume, that's bound to GL_PARAMETER_BUFFER

[wispy spear]

those are 2 buffers

[proven laurel]

oh lol

[wispy spear]

ye you need two

just looksied in the spec

[proven laurel]

the buffer types are weird

[proven laurel]

this is effectively a counter buffer

[wicked notch]

Naming couldn't be worse yes

[wispy spear]

May Fiffths

almost to the day 🙂

[proven laurel]

75% of the problems people have when learning gl would be solved with better names

anyhow, doing hi-z culling here?

[wicked notch]

Raster based, because it's more 🦐le

[proven laurel]

https://tenor.com/view/shrimp-as-that-clash-royale-hee-hee-hee-haw-gif-25054781

[wicked notch]

I'm currently taking the output of the frustum culling pass to draw only the AABBs that are in frustum

[proven laurel]

oh you mean like

that opengl occlusion thing?

[wicked notch]

Sorry, which thing?

[proven laurel]

was thinking about the conditional rendering occlusion stuff opengl has

but pretty sure the perf of that ain't that great

[wicked notch]

Ah no, the idea is to rasterize AABBs and check visibility with early Z

So you basically leverage early Z to write into an SSBO the visibility of any object

[proven laurel]

right

[wicked notch]

Then you just write indirect commands that pass this test (if they managed to pass frustum culling first that is)

[wicked notch]

Jaker, why is your depth write disabled when rendering visible bounding boxes?

Ah I see.

[wicked notch]

Do we use last frame's depth buffer as well hmm

"This pass comes after the scene pass because it relies on a depth buffer to have already been created" do we really need this though?

[frank sail]

noooooo

[frank sail]

yes, otherwise you're testing occlusion against an empty depth buffer

[wicked notch]

But what about this

[frank sail]

which part

[wicked notch]

It's a bullet point but it's all the same technique

[frank sail]

the temporal coherence just means that object visibility will be almost the same from frame to frame

objects visible last frame are probably visible this frame, etc

[wicked notch]

So rip shadow mapping occlusion culling?

If the depth buffer already needs to be created then we can't really cull anything can we?

Unless it's acceptable for shadow mapping culling to just use last frames' depth?

[frank sail]

it should work for shadows, even if the frustum changes every frame

I think you have some confusion about exactly what data is taken from the last frame

[wicked notch]

I'm very bad at tracking resources

But I think just depth?

Uh

Not sure

[frank sail]

lemme go through it again

0. clear depth buffer
1. render visible objects
2. render bounding boxes for occlusion testing
3. render objects whose visibility changed from 0 to 1 this frame (optional step to prevent one frame of pop-in when objects become visible)

the visibility info from step 2 is used in step 1 of the next frame

visibility=draw commands or whatever

[wicked notch]

🐸 💡

Got it, thanks

[frank sail]

the thingy with reprojection basically uses the last frame's depth buffer, and swaps occlusion testing and object rendering (so u test first)

which I guess is more intuitive lol

the problem is that reprojection is not perfect and leads to arguably worse artifacts (false occlusion) compared to one frame of lag (which, again, can be mitigated by step 3 above)

[wicked notch]

About step 3

Can I just do this:

void main() {
    const uint prev = visibility[i_object_id] & 0x1;
    visibility[i_object_id] = (prev << 1u) | 1;
}```

[frank sail]

uh

why the long shift

[wicked notch]

Yeah, it's useless

[frank sail]

red herring smh

[wicked notch]

Does this work as in last = curr?

Idea is bit 1 is last and bit 0 is curr

[frank sail]

Tbh I'd use an if statement just to make it obvious 😄

[wicked notch]

To keep track of change

[frank sail]

if (lastFrameVisibility[obj_id] == 0)
{
objectsThatNeedToBeDrawnThisFrame[obj_id] = 1;
}
thisFrameVisibility[obj_id] = 1;

you can certainly reduce the number of buffers needed here

[wicked notch]

Yeah, I'll just make it work first

On my way copy pasting 5 times the same snippet (again)

[frank sail]

hehe

[wicked notch]

Actually screw that, I don't even know if it works only for objects in my perspective

Let's just test primary camera perspective first

It didn't work 😦

Wait I didn't bind the shader

It worksn't

Ah my shift is wrong

Goddamnit

[wispy spear]

[wicked notch]

It's "working" but it doesn't seem to cull anything more than frustum culling did

[frank sail]

Make a debug mode that draws the bounding boxes to the screen

[wicked notch]

Alright, occlusion culling works

Except it's slower than... a depth prepass?

[wicked notch]

HiZ is looking more and more appealing... there are loads of issues with ROC apparently

Well, it's to be expected when dealing with bounding boxes, I wish ROC was a bit more conservative though

[frank sail]

like what

[wicked notch]

I don't know the exact reason, but some flickering can be observed if you are inside an AABB

Sometimes not even just flickering, you get the object seemingly transparent due to its visibility changing every frame

Here for example

I am using your Fwog because I nuked ROC

[frank sail]

ah

that artifact happens when an object occludes its own bounding box

[wicked notch]

Hmm

[frank sail]

a shrimple way to mitigate it is to always draw the object if the camera is very close to its bounding box

[wicked notch]

Makes sense, what about this?

The object is not very close to the camera here, perhaps some offset could be applied to the AABB's position?

[frank sail]

I can't see the aabb of the object in question

[wicked notch]

Well... we are inside it

[frank sail]

all it takes for the artifact to appear is for the camera to be inside the aabb and to not be looking at any other side of the object

I wonder if you can use clip planes for this

[wicked notch]

Hmm

I already have frustum planes from frustum culling

I would shrimply have to invert the condition

[frank sail]

Tbh it's easier to just draw the thingy if you're inside the aabb

[wicked notch]

Yeah

But that kills occlusion culling basically

[frank sail]

ideally, you wouldn't have objects with giant bounding boxes like that

[wicked notch]

Many scenes merge primitives so their bounding boxes are huge

I de-nuked ROC

Ah by the way, I can't find any documentation about NSight's profiler magic words

[frank sail]

you'd get much finer culling if you used it on meshlets

[wicked notch]

How the hell do I read this

What is PES+VPC

[frank sail]

https://developer.nvidia.com/blog/the-peak-performance-analysis-method-for-optimizing-any-gpu-workload/

vpc = viewport culling

idk what pes is

[wicked notch]

Also PCIe throughput is reporting 16GB/s, should I be worried about that?

They only happen at the end of shadow map draws

[frank sail]

Are you uploading something 🤔

Or maybe some buffer is in host memory

[wicked notch]

Actually... yes lol

I was rewriting the whole texture buffer, object buffer, indirect buffer for each call to "perform_frustum_cull"

Truly incredible

[frank sail]

Zoo wee mama

[wicked notch]

Looks like checking if you are inside the AABB works fine

Or rather, I have not found any more artifacts yet.

[wicked notch]

By the way what's this

[frank sail]

meshlets are little baby meshes

like 64-128 verts each

might be too fine though, since each aabb is like 14-24 verts

Meshoptimizer can emit meshlets

They are typically used with mesh shaders

[wicked notch]

This is super interesting holy

Apparently it's a whole new rendering paradigm?

Gone are vertex -> geometry -> raster?

[frank sail]

everything before fs is replaced by task and mesh shaders

it's pretty low level

[wicked notch]

No worries, it'll only be a very small detour

How do you enable extensions?

[frank sail]

they are automatically enabled

you just have to check that your implementation supports it

[wicked notch]

https://tenor.com/view/20-twenty-minutes-rick-and-morty-gif-12928450

[wicked notch]

very good

[frank sail]

Like this
https://github.com/JuanDiegoMontoya/Fwog/blob/main/src/Context.cpp#L122

[wicked notch]

Old: model_t
New: meshlet_group_t

To be honest I'm not understanding much, if anything at all

The task shader is optional apparently, which is great for me, one less thing to worry about

[frank sail]

you use task shaders to cull meshlets, basically

[wispy spear]

are you switching to vk already?

[wicked notch]

No way

[frank sail]

just using the cursed gl nv meme shader ext

[wicked notch]

I'll stay on GL for a long time

Why is it cursed?

[wispy spear]

ah

[frank sail]

cursed because probably no one uses it 🐸

[wicked notch]

I know everyone's given up on GL, but I have not

I couldn't help but see there's no AMD version of this mesh shader extension

[frank sail]

yup

you only get cross platform meme shading on nv

I mean vk lol

[proven laurel]

meme shading lol

[wispy spear]

who cares about AMD and INTEL anyway

[frank sail]

AMD (pejorative)

[wispy spear]

heh

[wicked notch]

auto meshlet_triangles = std::vector<uint32>(max_meshlets * max_triangles * 3);``` I stared at that 3 for a solid minute

Before remembering: "Wait a minute, a triangle has 3 points"

Incredible.

[wispy spear]

tis a multi tringle

one per universe

[frank sail]

smh

struct Tringle
{
  uint32_t verticeeeez[3];
};

std :: vector < Tringle >(max_meshlets * max_triangles);

[wicked notch]

https://tenor.com/view/demo-man-going-in-circles-eye-illuminati-triangle-gif-26507108

struct meshlet_t {
    uint32 vertex_offset = 0;
    uint32 vertex_count = 0;
    uint32 triangle_offset = 0;
    uint32 triangle_count = 0;

    // this indices into meshlet_group_t::vertices
    std::vector<uint32> vertices;
    // gl_PrimitiveIndicesNV I guess
    std::vector<uint8> triangles;
};

struct meshlet_group_t {
    std::vector<meshlet_t> meshlets;
    std::vector<vertex_format_t> vertices;
    std::vector<uint32> indices;
};``` I have no idea what I'm doing ![KEKW](https://cdn.discordapp.com/emojis/666849321462792234.webp?size=128 "KEKW")

[frank sail]

are you copying a sample from somewhere

also, I N D I R E C T I O N

[wicked notch]

I'm relying on meshoptimizer's documentation which is not much

constexpr auto max_vertices = 64u;
constexpr auto max_triangles = 124u;
constexpr auto cone_weight = 0.0f;
const auto max_meshlets = meshopt_buildMeshletsBound(indices.size(), max_vertices, max_triangles);
auto meshlets = std::vector<meshopt_Meshlet>(max_meshlets);
auto meshlet_vertices = std::vector<uint32>(max_meshlets * max_vertices);
auto meshlet_triangles = std::vector<uint8>(max_meshlets * max_triangles * 3);
const auto meshlet_count = meshopt_buildMeshlets(
    meshlets.data(),
    meshlet_vertices.data(),
    meshlet_triangles.data(),
    indices.data(),
    indices.size(),
    (const float32*)vertices.data(),
    vertices.size(),
    sizeof(vertex_format_t),
    max_vertices,
    max_triangles,
    cone_weight);

auto& last_meshlet = meshlets[meshlet_count - 1];
meshlet_vertices.resize(last_meshlet.vertex_offset + last_meshlet.vertex_count);
meshlet_triangles.resize(last_meshlet.triangle_offset + ((last_meshlet.triangle_count * 3 + 3) & ~3));
meshlets.resize(meshlet_count);``` This "works"

i.e: it doesn't crash

[frank sail]

oh jeez

[wicked notch]

I guess the "triangles" are indices into the meshlet itself?

[frank sail]

I guess cone_weight is some value to influence how faces are grouped w.r.t. their normal

idk, we're all guessing

[wicked notch]

It's something regarding cone based culling but I dunno

"cone_weight should be left as 0 if cluster cone culling is not used, and set to a value between 0 and 1 to balance cone culling efficiency with other forms of culling like frustum or occlusion culling."
Whatever this means

[frank sail]

yeah, ultimately you would use it to make normal-based culling better

but optimizing for that too much means you might group far apart vertices together, making frustum and occlusion culling worse

[wicked notch]

What I would really like to know right now is whatever the hell gl_PrimitiveIndicesNV is

Since it's a uint8 and NVIDIA only allows up to 256 - 1 triangles in a meshlet I suppose they are indices that index into the meshlet vertices?

i.e: gl_MeshVerticesNV

[frank sail]

When each mesh shader work group completes, it emits an output mesh
    consisting of
...
  * an array of vertex index values written to the built-in output array
      gl_PrimitiveIndicesNV, where each output primitive has a set of one,
      two, or three indices that identify the output vertices in the mesh used
      to form the primitive.

[wicked notch]

So... yes?

gl_PrimitiveIndicesNV are indices for gl_MeshVerticesNV?

I'll just assume yes for now

I'll know if I'm wrong because I will see funny triangles (or none at all)

[frank sail]

where did you see gl_MeshVerticesNV

[wicked notch]

https://developer.nvidia.com/blog/introduction-turing-mesh-shaders/

[frank sail]

I don't see it in the spec

https://registry.khronos.org/OpenGL/extensions/NV/NV_mesh_shader.txt

[wicked notch]

out gl_MeshPerVertexNV {
     vec4  gl_Position;
     float gl_PointSize;
     float gl_ClipDistance[];
     float gl_CullDistance[];
  } gl_MeshVerticesNV[];```

It's this thing apparently

[wispy spear]

hmm the roblox guy, the same guy who made meshoptimizer, forgor his name atm, has a video series of meshletisms going iirc

its vulkan, but still

[wicked notch]

I'll look it up one sec

I have to figure out if I need the original index buffer or not

I'm 80% sure I don't

[wispy spear]

https://www.youtube.com/watch?v=BR2my8OE1Sc&list=PL0JVLUVCkk-l7CWCn3-cdftR0oajugYvd

i think it was towards the end, meshlet culling

[wicked notch]

fun fact, sponza subdivides in 3515 meshlets

(Assuming I didn't break any laws of physics)

[wicked notch]

We are back to the origins once more.

For the third time

Jaker, could you translate into (comprehensible) english what the first parameter of glDrawMeshTasksNV does?

Wait it's simply an offset int gl_WorkGroupID.x

Why would I ever need this

[frank sail]

if you want to draw a subset of meshlets

[wicked notch]

Hmm

I lately type "hmm" a lot, I should make an emoji 🐸 🤔

frog_think

[frank sail]

consider it a convenience parameter, like how dispatches are 3D

[frank sail]

🇭🇲 🇲🇲

[wicked notch]

Yeah, that's fair.

deccer if you please.

Oh shit this is garbage, one second

[frank sail]

#1027528776717975592

reminds me of this frog_shush I made

the hand needs an outline though

[wicked notch]

Yeah, I'll do it 'morrow.

I would like to see sponza before I sleepy

[wicked notch]

Uh

------------
Internal error: assembly compile error for mesh shader at offset 30836:
-- error message --
line 1003, column 8:  error: unknown opcode modifier
-- internal assembly text --
!!NVmp5.0
OPTION NV_internal;
OPTION NV_shader_storage_buffer;
OPTION NV_bindless_texture;
GROUP_SIZE 1;
PRIMITIVE_TYPE TRIANGLES;
PRIMITIVES_OUT 124;
VERTICES_OUT 64;
# cgc version 3.4.0001, build date Apr 13 2023
# command line args:
#vendor NVIDIA Corporation
#version 3.4.0.1 COP Build Date Apr 13 2023
#profile gp5mp
#program main
#semantic b_transform_buffer : SBO_BUFFER[0]
#semantic b_meshlet_buffer : SBO_BUFFER[1]
#semantic b_vertex_buffer : SBO_BUFFER[2]
#semantic pv
#semantic meshlet.5 : __LOCAL
#var uint3 gl_WorkGroupID : $vin.CTAID : CTAID[0] : -1 : 1
#var float4 gl_MeshVerticesNV[0].gl_Position : $vout.POSITION : HPOS[32] : -1 : 1
#var float gl_MeshVerticesNV[0].gl_PointSize : $vout.PSIZE :  : -1 : 0
#var float gl_MeshVerticesNV[0].gl_ClipDistance[0] :  :  : -1 : 0
#var float gl_MeshVerticesNV[0].gl_Cul

I managed to crash NVIDIA's internal shader compiler

[frank sail]

oof

[wicked notch]

Removing this:

layout (location = 0) in flat uint o_meshlet_id;``` fixes it

Ah I see

layout (location = 0) out t_per_vertex {
    uint meshlet_id;
} o_per_vertex[];```

Where the hell do I put the flat

lol

out flat t_per_vertex doesn't work

[frank sail]

idk

you probably can't

[wicked notch]

....how do I send flat attributes to the frag shader?

[frank sail]

you can write the same value three times

ez flat

[wicked notch]

It's per vertex not per primitive sadly

[frank sail]

and from the mesh shader, it should be easy

You have access to the whole meshlet in the mesh shader, no?

You should be able to do whatever you want with a little creativity

[wicked notch]

So far my creativity has caused the NVIDIA internal compiler to crash 4 times

I figured it out btw

layout (location = 0) out t_per_vertex {
    flat uint meshlet_id;
} o_per_vertex[];``` this is legal apparently

The spec says it's not

But NVIDIA is NVIDIA I guess

What do you mean nsight does not support debugging their own fucking extension

Only D3D12 Mesh Shaders are supported in NSight apparently..

[wicked notch]

At least deccer's cubes work

But I'll leave it like this

There's no way I can continue with mesh shading if I can't even debug...

Pretty sad

[wicked notch]

I once again forgor a triangle has 3 vertices

pog

Now I just have to figure out why everything borks when there's more than one meshlet group

While I figure that out, here's good froge

[frank sail]

frogchamp

[wicked notch]

83796 meshlets and 5942 meshlet groups (or if you are old fashioned "meshes" 😄)

Occupancy is dead though

I'm hitting the memory limit 11 times out of 10

#version 460 core
#extension GL_NV_mesh_shader : require

struct meshlet_t {
    uint triangle_count;
    uint vertex_count;
    uint vertex_offset;
    uint[64] vertices;
    uint[384] triangles;
    uint mesh_index;
};

struct vertex_format_t {
    vec4 position;
    vec4 normal;
    vec4 uv;
    vec4 tangent;
};

layout (local_size_x = 1) in;

layout (triangles, max_vertices = 64, max_primitives = 124) out;

layout (location = 0) out t_per_vertex {
    flat uint meshlet_id;
} o_per_vertex[];

layout (location = 0) uniform mat4 pv;

layout (std430, binding = 0) readonly restrict buffer b_transform_buffer {
    mat4[] transforms;
};

layout (std430, binding = 1) readonly restrict buffer b_meshlet_buffer {
    meshlet_t[] meshlets;
};

layout (std430, binding = 2) readonly restrict buffer b_vertex_buffer {
    vertex_format_t[] vertices;
};

void main() {
    const uint workgroup_index = gl_WorkGroupID.x;
    const meshlet_t meshlet = meshlets[workgroup_index];
    const mat4 transform = transforms[meshlet.mesh_index];

    for (uint i = 0; i < meshlet.vertex_count; ++i) {
        const vertex_format_t vertex = vertices[meshlet.vertex_offset + meshlet.vertices[i]];
        gl_MeshVerticesNV[i].gl_Position = pv * transform * vec4(vertex.position.xyz, 1.0);
        o_per_vertex[i].meshlet_id = workgroup_index;
    }

    const uint index_count = meshlet.triangle_count;
    gl_PrimitiveCountNV = index_count;
    for (uint i = 0; i < index_count * 3; ++i) {
        gl_PrimitiveIndicesNV[i] = meshlet.triangles[i];
    }
}
``` Backup

[finite yacht]

i think perprimitiveNV qualifier is what you want

[wicked notch]

Interesting, I'll check it out

I think this struct is the culprit by the way:

struct meshlet_t {
    uint triangle_count;
    uint vertex_count;
    uint vertex_offset;
    uint[64] vertices;
    uint[384] triangles;
    uint mesh_index;
};```

Each thread loading 2KiB of data isn't ideal I think

[finite yacht]

the bad occupancy you mean? Thats probably because the layout (local_size_x = 1) in; so its only using 1/subgroupSize of the hardware

[wicked notch]

Ah yeah I changed that, I now use 32

Occupancy is still horrible, though better by a factor of 2

[finite yacht]

btw didnt you start learning opengl only a few months ago how can you already be messing with mesh shaders and shit thats crazy

[wicked notch]

I just copied the nvidia sample

Also jaker helped me translate the spec into human language

[frank sail]

pretty sure I was doing learnopengl shit a couple months in

[wicked notch]

I am still doing that by the way, I implemented normal mapping on the way

[frank sail]

I didn't have this server when I started tho

[wicked notch]

Yeah, this server is a gold mine

[frank sail]

what's funny is that I recently submitted a bug report to nvidia and got a reply basically telling me to rtfm

#1019779751600205955 message

[cunning atlas]

this thread singlehandedly making me question what I've been spending my time on

[frank sail]

I haven't done a bunch of the things lvstri is doing here

the shadows are way cooler already

and I haven't even touched mesh shaders

[wicked notch]

You gave me the filtering algorithm though

[cunning atlas]

yeah they look great :3

probably look back through this thread when I go back to making my shadows look better

[wicked notch]

I also spent a solid week fixing bugs in my shadows

[cunning atlas]

and look how it paid off 😉

[wicked notch]

Everything regarding shadows is here btw: https://github.com/LVSTRI/Iris/blob/master/shaders/5.0/setup_shadows.comp

While filtering is here: https://github.com/LVSTRI/Iris/blob/master/shaders/5.0/main.frag#L100

[cunning atlas]

ty, I've saved those links for later to have a browse

although with what I'm currently doing I don't care about shadows too much

but i'll definitely take a look after

[wicked notch]

I somewhat fixed the occupancy by putting everything in buffers, but it's still limited because there's too much data in each thread?

[wicked notch]

What the hell is a subgroupBallot and subgroupVote

We're electing the next US president?

Ah, GL_KHR_shader_subgroup isn't even supported in OpenGL

There is no apparent way of scheduling work to the mesh shader from the task shader that allows culling in OpenGL without KHR_shader_subgroup

I guess this is as far as we go huh...

Pretty sad, I was having a ton of fun even without a debugger

Final image with Mesh Shaders, 32 threads per workgroup, 32 vertices MAX (1 to 1), 124 primitives MAX, 174777 meshlets

It's time to go back to our origins, with good ol' vertex shaders.

[finite yacht]

they are supported. NVIDIA, AMD and Intel have them in OpenGL. Just not core which is sad

[wicked notch]

I see, then they are buried under the second page result of google, because first page is Vulkan only

[proven laurel]

I don't think the next core opengl version will come for a long time lol

[wicked notch]

I'm sure it'll come within the heat death of the universe

[finite yacht]

actually one type of subgroup operations is core (since 4.6) : ARB_shader_group_vote

[wicked notch]

Interesting, I'll eventually come back to mesh shaders, maybe I'll figure these out.

[wicked notch]

Hi-Z time!

[frank sail]

what

[wicked notch]

Nevermind that, you can do culling with GL, I just refused to go past the first few google hits lol

I also didn't bother to look at how ballotThreadNV actually worked, turns out it's extremely useful

[frank sail]

https://www.khronos.org/blog/vulkan-subgroup-tutorial

[wicked notch]

Yes indeed, unfortunately it's very different from the NV one.

That said, GPUs are scary.

[frank sail]

gpus are epiiiiiiic

[wicked notch]

GPUs are trying to take over the world, they can already feed themselves data to work with.

With task shaders they can even dispatch work to themselves

[finite yacht]

KHR_shader_subgroup_ballot is a superset of ARB_shader_ballot which is basically NV_shader_thread_group

[wispy spear]

if this continues, lustri is publishing some api more capable than vulkan, soon

you read it here first

[wicked notch]

I doubt that, but I may or may not try to hack bindless textures into RenderDoc.

It's really a pain having to disable textures everytime I want to debug with it.

[wispy spear]

yes please 😄

that also reminds me i wanted to readd a texturearray path for that reason to my shit

[frank sail]

you'd be a 🦵end if you did it

it's probably not easy to implement if baldurk has refused to do it a million times already

hmm, maybe you can still hack a non-complete, non-performant version in somehow

[wispy spear]

jaker and i are worthy guinea pigs

[wicked notch]

How do I know the size of the mips in a texture created with glTextureStorage2D(..., mips)? 🤔

If the base level is 1024x768, what's level 1?

[frank sail]

The spec says how they're created

But basically it's just max(1, floor(res / 2)) for each level

[wicked notch]

Very nice

So if I specify floor(log2(max(w, h))) + 1 mips I'll have
0 -> 1024x768
1 -> 512x384
...
9 -> 2x1
10 -> 1x1

[frank sail]

yeah, probably

[wicked notch]

I worry about the probably, but it'll be fine

[frank sail]

I almost always mince my statements so I can't be wrong

[wispy spear]

not curry?

[frank sail]

that comes later

[wicked notch]

Anything that combines textureGather and textureLod?

[wispy spear]

textureGatherLod

jk

[wicked notch]

https://tenor.com/view/lies-the-batman-liar-you-lie-dont-lie-to-me-gif-23486294

[finite yacht]

interesting AMD has an extension just for that

[wicked notch]

There is this stupid edge that doesn't go away

#version 460 core

layout (local_size_x = 16, local_size_y = 16, local_size_z = 1) in;

layout (location = 0) uniform uint u_level;

layout (binding = 0) uniform sampler2D u_in_depth;
layout (binding = 1, r32f) uniform writeonly image2D u_out_depth;


void main() {
    const uvec2 coord = gl_GlobalInvocationID.xy;
    const ivec2 size = imageSize(u_out_depth);
    if (all(lessThan(coord, size))) {
        const vec4 depth = vec4(
            textureLod(u_in_depth, ((vec2(coord) + vec2(0.0, 0.0) + 0.5) / vec2(size)), u_level).r,
            textureLod(u_in_depth, ((vec2(coord) + vec2(1.0, 0.0) + 0.5) / vec2(size)), u_level).r,
            textureLod(u_in_depth, ((vec2(coord) + vec2(0.0, 1.0) + 0.5) / vec2(size)), u_level).r,
            textureLod(u_in_depth, ((vec2(coord) + vec2(1.0, 1.0) + 0.5) / vec2(size)), u_level).r);
        imageStore(u_out_depth, ivec2(coord), vec4(max(max(depth.x, depth.y), max(depth.z, depth.w))));
    }
}``` What's wrong here?

[wispy spear]

hmm wrong addressmode perhaps in your u_in_depth?

clamp_to_edge vs clamp_to_border?

(i am just talking out of my ass here)

[wicked notch]

Yeah it's clamp_to_edge

[wispy spear]

what if you clamp to border and bordercolly to black?

[wicked notch]

Wait hold on, I'm an idiot.

Only the first mip is clamp_to_edge

Lovely, it works now

[wicked notch]

Hmm, HiZ culling has the opposite problem as ROC

It's not very conservative

Mayhaps I have some errors in my implementation.

[wispy spear]

what was ROC again?

[wicked notch]

Raster Occlusion Culling

[wispy spear]

never heard that before

[frank sail]

Wot

[wicked notch]

That doesn't make a lot of sense yes, I meant to say "only the original depth buffer is clamp to edge, the actual hiz mip chain was clamp to border"

I should probably start using sampler objects.

[frank sail]

Sampler objects are bae

[wicked notch]

Hmm HiZ is super fast

By a factor of 2 at least

Still broken though

It's possible that D3D/Vulkan conventions are biasing this article

[frank sail]

try glClipControl to change the depth range, then call the corresponding glm function to generate a new projection

[wicked notch]

I'd have to change all my 60 shaders to use [0;1] instead of [-1;1]

But honestly it's worth it, I don't know who the hell thought -1,1 depth was a good idea, I hope he's repenting

[wicked notch]

Finally, I switched to a sane(r) NDC system

No more depth [-1,1] bullshit. (HiZ is still broken though )

[wicked notch]

Hmm these are the AABB's uvs that HiZ is seeing, I'm not sure I see anything wrong with them

Maybe the scale?

[wispy spear]

https://tenor.com/view/baby-scale-omg-shookt-surprised-gif-9356799

[wicked notch]

I am failing to understand HiZ

And the funny part is I don't know why I'm failing at understading it, it's quite straightforward.

I'll start again from square 0, building the HiZ mip chain

[frank sail]

are you failing to understand HiZ as a whole, or just a particular bit of its implementation?

[wicked notch]

I don't know, I feel like I understand it, but when I try and apply "fixes" that I think are causing me problems, everything breaks (or nothing changes at all).

Also:

const mat4 pv = u_cascade_layer == -1 ? camera.pv : cascades[u_cascade_layer].pv;
// project AABB in clip space
vec4 ndc_corner = pv * model * vec4(aabb_corners[i], 1.0);
ndc_corner.z = max(ndc_corner.z, 0.0);
ndc_corner /= ndc_corner.w;``` Why the hell we max out ndc's Z before perspective div is a mystery

[wispy spear]

when you say "i dont know" you need to say it like jimmy yang in his chinese accent... "oh.... i dont knoow"

[frank sail]

then why do you have it

[wicked notch]

https://interplayoflight.wordpress.com/2017/11/15/experiments-in-gpu-based-occlusion-culling/

His fault

I mean, it makes sense to do that, just not before perspective division

We don't care about objects behind the near plane after all.

[frank sail]

does it even matter if you do the clamp before or after perspective division

the eventual value will be 0 either way

[wicked notch]

I guess

I'm grasping at straws here

ROC was much easier

[frank sail]

ASUS ROC (Republic of Camers)

[wicked notch]

Alright enough complaining, I'll get to work seriously now

Ah just one thing, could you find some HiZ samples for me? I can't find anything other than Niagara and the one linked above

I'd like to see some common ground, hopefully

[frank sail]

vkguide.dev has one

[frank sail]

I like this variable name
NoofInstances

N o o f

[wicked notch]

Is there anything equivalent to VK_STRUCTURE_TYPE_SAMPLER_REDUCTION_MODE_CREATE_INFO_EXT in OpenGL?

Looks like vkguide is using it as a foolproof way of reducing a depth image

Also that's one long struct name lol

[frank sail]

no

[wicked notch]

https://tenor.com/view/crying-emoji-gif-21922016

[frank sail]

it's not hard to implement yourself, it'll just perform worse since you have to explicitly take four shrimples

[wicked notch]

I am gigastupid then

Can't seem to implement a proper depth reduction

[wispy spear]

just go straight to whatever you want to call your gpu architecture + api which will be the successor of vk

where xxReduceDepth() is a thing

[wicked notch]

:(

[frank sail]

it's ez pz
return 0;

or return 1; if you don't have reverse depth

[wicked notch]

How

In god's holy name

is level 9

lower than level 10

How does this even happen

[frank sail]

isn't that expected behavior

the final mip should be really deep since it's the deepest of all pixels

[wicked notch]

Well yes, it would be

except I omitted one crucial detail

level 8 is also higher than level 9

Which is absolutely bonkers

[frank sail]

maybe you don't handle reducing odd resolutions correctly

you have to do something special for those iirc

[wicked notch]

yes

Which is why I made this:

static auto previous_power_two(iris::uint32 v) noexcept -> iris::uint32 {
    auto r = 1;
    while (r < v) {
        r <<= 1;
    }
    return r >> 1;
}```

[wicked notch]

Mip chain is fully working now

Onto figuring out the dumb algorithm

[wicked notch]

This is very frustrating.

I'll stop for now

[wicked notch]

Here projectSphere seems to take a world space sphere, but that doesn't seem right does it? https://github.com/zeux/niagara/blob/4e3e21440e4b7d0699bcc5d46f2efbe1e0050946/src/shaders/drawcull.comp.glsl#L82

[frank sail]

DX12 equivalent if you're curious
https://github.com/microsoft/DirectX-Specs/blob/master/d3d/MeshShader.md#primitive-attributes

[wicked notch]

Good morning friends.

Day 2 of debugging HiZ, hopefully I'll have a clue what's going on by today

[frank sail]

did it come to you in your dreams

[wicked notch]

Sadly not

By the way, if you know how this works, could you give me a hint?

[frank sail]

idk, never implemented it

I mean, I know how it works conceptually

do depth reduction, project object bounds (AABBs or spheres), gather some texels, etc.

[wicked notch]

Could you find the original SIGGRAPH slides or the original paper? I can't seem to find it lol

[frank sail]

I'll try

I failed

[wicked notch]

I see you don't go past google hit #5 too

[frank sail]

is there something fundamental about hi-z culling that you're unsure about?

[wicked notch]

A bit of this

This is deccer cubes

™️

These are the screen space bounding rectangles that HiZ is seeing

Now, suppose the red cube is huge, except there's a hole in the middle that allows you to see the purple and green cubes

Would they get culled because the bounding box's depth is lower than in the HiZ's?

[frank sail]

shouldn't be a problem

the bounding boxes cannot occlude other bounding boxes

they are simply a conservative testing volume

which you test against the depth buffer

[wicked notch]

So the bounding rects simply serve as an "index" against the HiZ chain?

[frank sail]

they serve the same purpose as the bounding volumes in ROC

a volume that conservatively encapsulates an object which, if visible, is an indication that the object itself is probably visible as well

hi-z and ROC are really just different ways of testing the bounding volumes against the depth buffer

[wicked notch]

Ah I was going with the opposite (and wrong) intuition: if the volume is NOT visible then the object is culled

[frank sail]

that is correct though

if the conservative bounding volume isn't visible, then the object itself definitely isn't

[wicked notch]

Hmm I see

[frank sail]

but if the bounding volume is visible, then the object is only probably visible (because the bounding volume is conservative)

[wicked notch]

Alright

Thanks a lot for the additional insight

[wicked notch]

I think I'm getting close to solving it.

I only need to figure out the projectSphere's weird projection thing

[wicked notch]

Heh

Hahah

Aahahahha

[frank sail]

[wicked notch]

I would like to order one death please

You would think.

As a human person

That GL_NEAREST takes the closest pixel to the UV coordinates specified in textureLod

[wispy spear]

GL_CLOSEST does

[frank sail]

It just truncates 🙂

[wicked notch]

Except if you have mips

You need GL_NEAREST_MIPMAP_NEAREST

[wispy spear]

badumm tsss

[frank sail]

ah

because gl is so unhinged that you have to specify min and mip in the same parameter

otherwise you implicitly disable mips

[wispy spear]

wouldntvedve happend with the right abstraction

[frank sail]

fwog user #2???

[wicked notch]

I want to say this was a good experience

[wispy spear]

OpenGL is like a diving in some closed mines experience

[wicked notch]

But this really wasn't, I just hope OpenGL doesn't fail me again...

[wispy spear]

crystal clear water everywhere, but as soon as you dive and cause a wave shock, shit is going to hit the fan

[frank sail]

or maybe it's lvstri's evil villain Vulkan backstory

[wispy spear]

haha

[wicked notch]

By the way, in the few months I have only had a few dozen debug messages

[wispy spear]

there are usually not many anyway

[wicked notch]

Not once has the debug message callback come to my help like "hey, you might want to do GL_NEAREST_MIPMAP_NEAREST"

[frank sail]

Did you ever enable the synchronous thingy

[wicked notch]

Yes since you told me

[wispy spear]

glValidationLayer :C

[wicked notch]

Haven't had the chance to use it though, since literally not a single message has happened

[frank sail]

Well it's not an api error to do that methinks

[wicked notch]

It should be

fucking hell

Don't just implicitly disable shit

[wispy spear]

if the api would have known what you wanted to achieve

[wicked notch]

Right, I just don't think implicitly disabling mips is not a good way of handling this

Give me literally any message, don't just do stuff silently

[wispy spear]

dont be so hard on neither of you (you and OpenGL)

the latter will have more opportunities to bite you in the butt

[wicked notch]

I can only imagine

By the way

Here's how I diagnosed this

[wispy spear]

pengu jaker and i were thinking/toying with some glValidation layer thing a while ago, but its super dead

[wicked notch]

Blue is mip level, red is value sampled from the uvs of that level

[wispy spear]

that thing could/should/might have picked that one up

[wicked notch]

I checked level 9, and the mip was just 1.0

So thank you, OpenGL.

I'm sure this would not have happened with any saner API .

But it is what it is..

At least I have occlusion culling now

Actually, I have 4 different fully functional algorithms of doing occlusion culling

[wispy spear]

noice

[wicked notch]

Because yes, I rewrote the entire algorithm 4 times, in different ways

And they all work perfectly fine

Now, onto removing the over 500 lines of code purely for debugging purposes

After this I think I'll be taking a big chamomile cup

I'm kind of irritated.

[frank sail]

You're using the wrong API then, my friend

[wispy spear]

https://github.com/GraphicsProgramming/gl-validation-layer is the thing i was talking about

[wicked notch]

I came back.

[wicked notch]

I checked this out too, but it looks like it's abandoned?

😦

[frank sail]

It's merely taking a nap

[wicked notch]

I do think sometimes that I could "just" switch to Vulkan, "just" use meshlets, "just" use meshlet culling which is super accurate and all the bleeding edge features you can name

Except the "just"

[wicked notch]

I saw some Vulkan code today as a result of trying to figure out why HiZ was not working and it's very thicc

I don't really want to give up the convenience of GL yet.

[frank sail]

Maybe you could do vkguide as a side-side project

[wicked notch]

The unhingedness does not outweigh the convenience (yet)

[wispy spear]

ja its kind dead 😦

[frank sail]

You could always use a nice gl wrapper ahem (ignore broken docs build)
https://github.com/JuanDiegoMontoya/Fwog

[wispy spear]

or switch to c# and use my experiment 😛

[wicked notch]

At least I know I'm not alone fighting the non-existant debugging messages

[frank sail]

But we accept contributors

[wicked notch]

Anyways I have now calmed down and I'm not mad anymore at GL

I want to do something smol next.

Anti-Aliasing

[frank sail]

Do something easy like cutting edge TAA

[wicked notch]

Except I won't implement TAA myself, I'll just use FSR2 since it's open source (Thank you Jaker)

[frank sail]

One small issue

Only Vulkan and dx12 backend are provided

So you'd have to make a gl one

[wicked notch]

Why do I get the feeling it's not... small

Yeah

You work at AMD right? Just make an OpenGL version duh

[frank sail]

I can make one in my personal time

But there won't be an official one

[wicked notch]

Sad

[frank sail]

If you want, I can start working on it. I've been needing an excuse to do it

[wicked notch]

What do you mean it's not supported on OpenGL by the way? Isn't it just a spatio-temporal upscaling algorithm?

Like, why does it require Vulkan or DX12?

[frank sail]

It's not just a shader you invoke. Fsr2 also needs a bunch of internal resources and stuff

[wicked notch]

Hmm

How hard is it to port to OpenGL?

[wispy spear]

from 1 to 10? 9.2 id say

[frank sail]

https://github.com/GPUOpen-Effects/FidelityFX-FSR2/blob/master/src/ffx-fsr2-api/vk/ffx_fsr2_vk.cpp

[frank sail]

Probably not super hard, provided you understand the requirements

[wicked notch]

...Translating Vulkan code (which I have 0 idea about) to OpenGL code (which I have at most 1 idea about) isn't exactly in my skillset

[frank sail]

I am unironically willing to try it

I need to better understand fsr2 for my job anyways

[wispy spear]

after the volume clustered renderer~~?~~!

Jaker:

https://tenor.com/view/dredd-i-knew-youd-say-that-stallone-gif-23229845

[wicked notch]

?????

I don't really handle transparency for now so I'm safe from this thing?

[wicked notch]

Ah yes

Lines

Yeah ok, I don't understand shit

Hmm where to go next I wonder

[frank sail]

FXAA

[wicked notch]

FXAA sounds good

[frank sail]

SMAA is like improved FXAA if you're willing to suffer through a much more complicated implementation

[cunning atlas]

you got it figured out at least, you've been doing great things

[wispy spear]

did you know Iris is also a female firstname in germany

not just the eye part

[frank sail]

eyeris

[wicked notch]

I hope I don't bring shame to any women in Germany bearing that name with my shitty OpenGL stuff then

[wispy spear]

haha

na, dont worry

[wicked notch]

Lovely edges

[wispy spear]

oi that looks cool

[frank sail]

@wicked notch are you following the catlike coding tutorial (I think that was the one I used)

[wicked notch]

I'm using
https://developer.download.nvidia.com/assets/gamedev/files/sdk/11/FXAA_WhitePaper.pdf and
http://blog.simonrodriguez.fr/articles/2016/07/implementing_fxaa.html

[frank sail]

ah

[wispy spear]

+1 for sorting your messages for better readabliktliblity

[frank sail]

the second link only implements half of FXAA btw

it doesn't do the end-of-edge search, which is pretty important for reducing geometric aliasing

[wicked notch]

I see, I'll try catlike coding then

[frank sail]

ye
https://catlikecoding.com/unity/tutorials/advanced-rendering/fxaa/

[wicked notch]

The paper should implement everything anyways?

[frank sail]

yeah

lol

[twin bough]

How many aa techniques are there anyway

[wicked notch]

Too many

[wicked notch]

2 hour wait for a haircut but we got it done

Time to finish FXAA

[wicked notch]

Visualizing AABBs when in FXAA debug mode is kinda weird

[wicked notch]

It's not very... anti-aliased.

The AABB debug lines are pretty smooth though

[wispy spear]

looks smoof to me

[wicked notch]

Yeah it's definitely better

[wispy spear]

this scene is probably also not a good scene to show off antialiasing

[wicked notch]

I've been trying to find new scenes, no luck unfortuantely 😦

[wispy spear]

the directxsamples might have one with 2 telefone poles and a wire

[wicked notch]

The tree in bistro gets blurred a lot lol

[wicked notch]

I'll download that

[wispy spear]

ah bistro also has those lights hanging across on wire

[wicked notch]

These DirectX samples made me remember how attracted I am to Mesh Shaders

They are so good

Anyways testing scene right now

[wicked notch]

After a bit more testing I found that FXAA was indeed working..

It's just.. well, not very good

[wicked notch]

Do I do TAA or do I not do TAA...

[finite yacht]

Do it!

[wicked notch]

I'll try asking my orb (the magic 8 ball)

Looks like I will do TAA

[frank sail]

Sweet

all I ask is that you use a TAA impl that relies on a single frame of history

[wicked notch]

No temporal accumulation?

[frank sail]

I mean something different

some old TAA impls have like 5 frames of history that they reproject and test against

but modern impls use the last frame only, since it's faster and more stable

[wicked notch]

Interesting

[frank sail]

https://developer.download.nvidia.com/gameworks/events/GDC2016/msalvi_temporal_supersampling.pdf

[wicked notch]

It's always either Marco Salvi or Akenine-Moller

[frank sail]

oh hi marc(o)

[wicked notch]

They wrote 90% of the papers

[wicked notch]

I went with ROC in the end

HiZ is too damn conservative for my tastes

Anyways TAA, I think I get the gist of the algorithm but there's still some parts I can't figure out quite well cough neighborhood clipping

But we'll deal with that later.

[finite yacht]

never tried but I think for ROC GL_NV_representative_fragment_test can be useful

could be worth a try you just need to do glEnable(REPRESENTATIVE_FRAGMENT_TEST_NV)

[wicked notch]

I'll try it right now since it seems easy enough

Ah it's a performance thing, let's see..

Damn, this actually reduced my frametimes by 1ms lol

Unfortunately it's NV only..

[finite yacht]

yeah. Just test if its available before enabling it ez

i am suprised it makes such a big difference. Wouldnt expect drawing a few aabbs and writing to ssbo to be that expensive
