daxa - opionionated vulkan abstraction (now with autosync!)

[winged tangle]

so what is the main usecase for bar then? I definetly think it makes sense for a descriptor buffer that i have for all my resources

as i only do infrequent tiny uploads to it

[south anchor]

sure

[winged tangle]

ok nice

[south anchor]

most likely thats where the driver was putting it anyway

[winged tangle]

true

for me the extension will probably not to anything really

but i am still gonna try and use it to see

[south anchor]

it cuts out the middleman

you can also pipeline descriptor updates

put your descriptor update into the command buffer

no need to stall the host

pretty neat

[winged tangle]

yea but i just have one mega set

i mean for that its not too intresting

[south anchor]

unless that never changes, you need to update it

[winged tangle]

yea but i can just use a descriptor update call or in the future ill write to the mapped pointer

its only done on resource creation so i dont see why id wanna pipeline it

also with comamnd buffers id need to think about what is going on with multi queue

would i just make a cmd buffer that stores all changes and then is submitted with the next submit in the beginning/

wont i have to tehnically synch on all queues

seems easier to write a mapped ptr to be honest

[south anchor]

sure, do whats easiest

[winged tangle]

already ideas for vuk?

im always intrested in stuff others do to get more perspective

[south anchor]

mmm, maybe

we'll see, vuk supports bindy

maybe this can make bindy extra fast

perhaps thats useful

[winged tangle]

yea

[south anchor]

but doubt its high on the list

[winged tangle]

@soft tapir @pale owl later today fucking around with VK_EXT_descrriptor_buffer and beta drivers?

[pale owl]

Oooh

[winged tangle]

@pale owl @soft tapir @cobalt thistle should i remove non buffer reference buffer access?

you know how you can do daxa_get_buffer(Type, id) ?

do you wanna have that?

(it gives bounds checks for debugging but thats it )

i can keep the syntax

[pale owl]

wat

[winged tangle]

but remove the bounds checks and buffers for simplicity

[pale owl]

ohhhh

[winged tangle]

only allow buffer references

[soft tapir]

I feel like I will only use buffer refs, so I don't really care

[pale owl]

daxa_get_buffer is nice for people mixing HLSL and GLSL, but IDK if that's something we care to support anymore 🤔

[winged tangle]

i can keep it by just faking it. id just look up the buffer address with the id in a table then return that from the function

[pale owl]

lmao

[winged tangle]

then its the same as the other function

ssoooo

i guess i can just remove it

i looked more into the generating sampler function

and its simpler then i thought at least a bit

ill add an incomplete experimental impl

So i ll give TextureRef(2D) another try

daxa_sample(image, sampler, uv)
daxa_shadow_sample(....
daxa_gather(...

[pale owl]

yesss

[cobalt thistle]

I hope it won't break my project

[winged tangle]

i will try to be more backwards compatible haha

[cobalt thistle]

[winged tangle]

i will prob add inline uniform blocks

basically bigger slower push constants

[south anchor]

shove constants

[winged tangle]

ima name it push_big_constant

I will also enable a nvidia extension for bindless images behind the scenes (no api cahnges)

so that i only emulate bindless on amd

then nvidia is truely bindless with no downsides except debugging

[south anchor]

the what now

[winged tangle]

i dont remember the name of the extension

nvidia has an extension for bindless imags in vulkan

that removes one indirection

on nv descriptors are stored in some special memory, and the "vulkan side descriptors" are just uints

so in daxa its uint -> uint -> descriptor -> actual image memory

with the extension its just uint -> descriptor -> actual image memory

[south anchor]

found it

[winged tangle]

what was the name again

[south anchor]

VK_NVX_image_view_handle / GL_NV_bindless_texture

ah rip

can't do separate samplers

weird

[winged tangle]

glsl cope probably

hmmm

[south anchor]

funnily enough, the spirv extension can do it

but not the vulkan ext

[winged tangle]

that is very strange

that is a bummer

welp nv you wont get faster image access after all then

[south anchor]

well look if i am wrong

but thats what i saw

[winged tangle]

wtf is that

i need to pass a device address from an image?

really strange

am im stupit

[winged tangle]

it looks like it should be supported

but maybe glsl cant do it

[south anchor]

ah right, you can't do sampler handle

that still must be std bindless

but thats ok ig

[winged tangle]

yea thats fine imo

I am planning on doing some heavy makro magic

to declare samplers inside shaders

[south anchor]

macro?

[winged tangle]

yea

like

DAXA_DECL_INLINE_SAMPLER(
...
)

not sure if it will work like that

but ill try

[south anchor]

my main man potrick

i have indeed seem macros before

that was not the question 😄

[winged tangle]

ah lol yea i am very unspecific lmao

[south anchor]

what does the macro do

[winged tangle]

it would do nothing in glsl but define some binding to a sampler or just a index that can be used to sample

or just declare a global daxa_SamplerId in the shader

and on cpu it would declare a daxa::SamplerInfo, that is then created and bound by the pipeline compiler

hmhmhm

i think that needs extra magic

makros arent enough

maybe not worth honestly

[south anchor]

i have already figured this one out

do you want a free idea

[winged tangle]

😳

[south anchor]

just this once

[winged tangle]

yes yes

https://tenor.com/view/chris-pratt-rubbing-hands-smile-happy-plan-mischief-gif-11789692

[south anchor]

spirv_decorate

[winged tangle]

oh i completely forgor

we can implement intrinsics in glsl right?

[south anchor]

yes

[winged tangle]

like inline spirv?

[south anchor]

yes

[winged tangle]

ong i will commit crimes now

[south anchor]

then you put a usersemantic decoration

and read it back later with spirv-cross or whatever

[winged tangle]

just to be sure on the power of this

could i implement sampling functions with this "more nicely" then just plain glsl?

or at all?

[south anchor]

hmm?

[winged tangle]

with spirv intrinsics

[south anchor]

no, this is not about that

[winged tangle]

not the decorations

[winged tangle]

so its makred in spirv and i can see it later

with reflection?

[south anchor]

yes

[winged tangle]

i dont get it

ah ok

hmmm

so i manipulate the spirv after the fact myself

intresting

[south anchor]

compatible with hlsl too

[winged tangle]

that is cool

https://android.googlesource.com/platform/external/shaderc/glslang/+/refs/heads/upstream-master/Test/spv.intrinsicsSpirvLiteral.vert

ah wow thats cool stuff

(3) How should we handle separate samplers?

  RESOLVED:  OpenGL 3.3 created separate sampler objects, and provided
  separate binding points in a texture image unit.  When referencing a
  texture image unit with a sampler object bound, the state of that object
  is used; otherwise, sampler state embedded in the texture is used.  In
  either case, each texture image unit consists of a texture/sampler pair,
  and no capability is provided to mix the texture from one unit with
  samplers from another.

i mean if thats the case

ill just give all of the images a dummy sampler

i have gotten offhand info that nvidia might actually already do the right thing with normal descriptor sets

and that extension is mostly for opengl glsl extension compatibility

well meh

i guess that makes sense

ok i wont do it then

seems like the syntax would have been cringe anyways

without changes at least

the handles are also 64 bit

my things are 32 bit with 8 bits reserved for debug

...

Ok other fancy idea

use after free detection on the gpu

[soft tapir]

I know you keep a version of each resource on the CPU but how would you use it to detect after-free use on the GPU?

[winged tangle]

ill put them into a buffer

and compare on gpu

when i see a fail i atomic add on a uint to aquire a index in the failure list

then write it out

[soft tapir]

compare with what? does GPU track it's own version?

[winged tangle]

with a small size of like 127 ids per type

[winged tangle]

all ids have the version

[winged tangle]

my cope grows stronger every day

[next tundra]

https://tenor.com/view/copium-meme-pepe-frog-gif-26117735

[winged tangle]

texture ref lives

it LL be in soon

typed boneless handles with sane sample functions

boneless yes

@covert zephyr I'll show you my baby brainworm glsl file to cope with bindless and glsl when it's done

[covert zephyr]

You shouldn't try to detect use after free

That's job of validation layer

[soft tapir]

Validation layers with bindless(y) thing in daxa are acting very sus

[winged tangle]

only sync validation

so use after free detect should work

[winged tangle]

I will expand the docs even more

@soft tapir @cobalt thistle @pale owl syntax questions, what do you prefer:

• TextureRef(texture2D)

• TextureRef(2D, float)

• TextureRef2D

• Texture2D

• (all the above but with SampledImage instead of Texture prefix)

I am currently for option one with either Texture or SampeldImage

and secondly, on image functions:
do you want overloads for existing glsl functions, or new names, or both?
an example:
vec4 texture(TextureRef(T), SamplerId, vec2 uv)

or vec4 daxa_sample(TextureRef(T), SamperId, vec2 uv)

[soft tapir]

1st and new names

[pale owl]

I'm indifferent

The first appears to be the most verbose, which is kinda cringe

But I don't really care

[winged tangle]

any lurkers pls give optlinions too

[pale owl]

I fixed spelling and capitalization in the docs last night. I didn't actually read too much, so grammar might be weird

[winged tangle]

hmmmmmmmmmmmmm. maybe I can make a Ref(T)

that works for buffers and images

[winged tangle]

thx

hmm maybe hlsl style is nice

Texture2D(f32)

hmmmmmmmmmmmmm

I want more consistent naming

there are mainly two image types in Vulkan and glsl

storage image and sampled image

should I just name them that everywhere?

[winged tangle]

I need help

I hate sytnax

simple and consistent it should be

ideas on names?:
image_sample
image_read
image_write
image_size
image_gather

image_compare_sample (shadow sampling)

image_ prefix on these yay or nay?

I am for destroying the name texture

hmmmmmmmmmmmmmmm

[next tundra]

name for what

i didnt read all the stuff above, are you writing some sort of shading language?

[winged tangle]

just some glsl abstractions

[winged tangle]

names for image handles

and names for reading and writing images

inglsl

[next tundra]

in cpp side?

ah

images as in textures or also as in images

thinking about opengl, where you use images in csisms, and textures/samplers in non-csisms

hmm hlsl has something like RWTexture

hmm im probably also the worst person to give any advise here :S

[winged tangle]

glsl side

I am making my own image handles and functions on top of the glsl ones

so bindless looks better

[winged tangle]

true I'm thinking of making it closer to hlsl

[next tundra]

ah using that thing martty showed you last night?

mmhm hhhm mmhmm

if you used plain hlsl how would you call all these things there, or how does hlsl call those, maybe those names are already suitable out of the box and you could just use them?

otherwise, what might help, if you create a little matrix with all the naming glsl/hlsl/metal/andfriends call them and either pick what you like or decide on an existing one which makes most sense already, otherwise maybe seeing all those next to each other you can come up with something different more suitable to your current problem

[winged tangle]

hlsl has member functions for structs

with would be cool

but glsk doesn't have those

[winged tangle]

I will

good point that makes more sense

[next tundra]

wort case is you invent a new shading language from scratch 🙂

[winged tangle]

yea lol

[next tundra]

and waste 10 years of your life on that first

like gobi 🙂

[winged tangle]

fuck

nah I'll stay on glsk cope

I'll work on that maybe later today or tomorrow, give a table of options

[next tundra]

generating glsl is not an option?

[winged tangle]

generalizing?

ok let me actually write down the problems I have with current day and glsl in increasing importance:

• it is strange that there are the names textureXY and imageXY. I would prefer more consistent naming.

• the texture accessing functions are strangely named in glsl. An example is the texture() function. I would prefer more descriptive names like sample_image.

• the glsl handles are not opaque and can not be returned from functions, stored in structs or put in local variables.

• to cope with the previous point Daxa uses IDs for images and samplers. The problem with that is that the IDs don't have type information (for example if it is 2d or integer/float), so when using them the user needs to always specify the accessing type like image2D.

• accessing images via current daxa IDs is ugly.
  an example how one samples a day image currently:

vec4 value = texture(
  sampler2d(
    daxa_get_texture(image_id),
    daxa_get_sampler(sampler_id)
  ),
  uv);

I would prefer this:

vec4 value = sample_image(image, sampler, uv);

I can do all impl details I only need to know what ppl would like the most syntax wise

I'll propose more options for image handles and sampling /read/write functions

[soft tapir]

Can we encode some of the image information into the handle (similar to how version is encoded)?

[winged tangle]

yes

that works

as I said I can do all the impl details

it's all about names now

[soft tapir]

So image_sample is basically glsl texture and image_read/write would be load/saveImage?

Mby image_load(store)_texel would work also

Dam naming is hard

[cobalt thistle]

The best would be Texture2D and second TextureRef2D

[winged tangle]

so you don't like the () syntax?

ok

[winged tangle]

yea

[cobalt thistle]

If it would be the () I would make #define Texture2D on it

[winged tangle]

I see

I honestly liked TextureRef(glsl type)

because then the user can just look up the glsl type that he wants

instead of searching in the daxa wiki

[winged tangle]

that makes me wonder what you think about BufferRef(type)

would you also prefer something else?

[next tundra]

hmmmmmmmmmmmmmmm

the Ref in TextureRef sounds odd to me

[winged tangle]

yes

[cobalt thistle]

It's okay. I dont with else it would be replaced

[winged tangle]

it would be consistent with buffer ref tho

[cobalt thistle]

Honestly sounding to make own shader lang

[next tundra]

BufferRef is a thing in hlsl?

[winged tangle]

no

it's something I created

[next tundra]

ah

[winged tangle]

it's a makeo

Makro

[next tundra]

i dont think those Ref's make sense in a shader language

naming wise

because, what would be semantically different between Texture(foo) and TextureRef(foo)?

same for buffer/bufferref too i suppose

[winged tangle]

it is derived from the glsl extension called buffer reference

but you have a point

it does not make sense to nessexwrily name the textures fmref cause eof that

would only do it for consistency

[next tundra]

fair

[winged tangle]

but tbf

it should be the other way around maybe

Texture(..) and Buffer(..) seem nicer actually

[next tundra]

i concur

or ReadTexture ReadBuffer

and if you want to write to them you WriteTexture and WriteBuffer ;d

jk 😉

Texture() Buffer() make sense

or Load() for both

or LoadSampled/LoadUnsampled

[winged tangle]

aaah bascal case idk

I'll o snake case for functions I think

ppl will hurt me if I do Microsoft style I think lol

[next tundra]

ah loadSampled hmm load_sampled

[winged tangle]

yeeees

[next tundra]

people should shut the fuck up tbh

[winged tangle]

good I like

[next tundra]

pascal case is clearly superior

[winged tangle]

[next tundra]

any should be fine, as long as its consistent

[winged tangle]

yea

agree

[soft tapir]

I like image_read(write)_sampled and _unsamoled

Seems very consistent to me

[winged tangle]

unsamoled

[soft tapir]

Shut

Oled good technology dunno what you on about

Ahh but you can't write sampled image

Hmmm

[winged tangle]

currently looks like it will be:

RWBuffer(type)
Buffer(type)
RWimageXY
AtomicRWImageXY
ImageXY

and access functions
image_(sample/gather/read/write/atomics...)(image,...)

now

I am only conflicted about SampledImage

should we have that?

because Image could either be a read-only storage image or a sampled image

I personally don't see the need for a read-only storage image except to reduce pipe barriers and layout transitions

[next tundra]

i also kinda like the RWisms from hlsl

hmmm

would making a few prototypes make sense then if you are not sure

and see how it feels, if its shit we find something else

[winged tangle]

hmmmmmm

nah

fuck read-only storage images

probably won't do anythigb

hlsl doesn't even have it

[next tundra]

ROimage 😉

[winged tangle]

looool

I have that rn

but that seems sus

[next tundra]

as long as you dont call your shit ipotric

the i/l thing at the beginning 🙂

ill just call you ingo from now on

[winged tangle]

lpotrick::Image

[next tundra]

ingo::image

hang on a second

you do know about ingo's Ringlokschuppen neh?

[winged tangle]

uuuhh

[next tundra]

: )

nvm

[winged tangle]

@pale owl

[pale owl]

I like it

[winged tangle]

pog

[next tundra]

gabe just cba to deal with any of it 🙂 since they are busy getting wayland support to work ahem

[winged tangle]

It works

[winged tangle]

Wayland support is in

hmm did I forget to mention?

[next tundra]

ah no, im just dumb

we tried it the other day, and found out that my hardware is just not capable to run vk

[winged tangle]

sea

yea

sad

[next tundra]

all good, soon its no problem anymore

[winged tangle]

it will be Image2Df32 probably

shortage image will be RWImage2Df32

[soft tapir]

Shortage image

That some terminus technicus?

[winged tangle]

storage

read write images

general layout

[soft tapir]

I'm messing with you

[winged tangle]

I am gonna mess you up sakyyyy

first and stone

I will make you read my makros

[next tundra]

RWTexture<float4> :>

[soft tapir]

🙏🙏

[next tundra]

read_and_writable_texture_for_many_floats 4 channels
read_and_writable_texture_for_several_floats 3 channels
read_and_writable_texture_for_few_floats 2 channels
read_and_writable_texture_for_one_float 1 channel

[soft tapir]

read_and_writable_texture_for_many_floatsises

Deccer has the best naming around I swear to God

[next tundra]

i try

[winged tangle]

I will have the format abstracted(except for float/integer/unsigned) as those are shouldn't be casted

[winged tangle]

@cobalt thistle

[winged tangle]

I also added defines to selectively enable the generation of function overloads. So if someone doesnt want them, they can just not enable them and have faster compiles:

* DAXA_ENABLE_IMAGE_OVERLOADS_BASIC
* DAXA_ENABLE_IMAGE_OVERLOADS_ATOMIC
* DAXA_ENABLE_IMAGE_OVERLOADS_64BIT
* DAXA_ENABLE_IMAGE_OVERLOADS_MULTISAMPLE
* DAXA_ENABLE_SHADER_NO_NAMESPACE
* DAXA_ENABLE_SHADER_NO_NAMESPACE_PRIMITIVES

[next tundra]

enable no namespace sounds a bit funky

double negationesque

[winged tangle]

yea lol

[next tundra]

whats the default?

maybe from that a name for that thing can be inferred

[winged tangle]

the default for all of them is 0

you can set them to 1

and the default for namespaces is that all things have the daxa_ prefix

[next tundra]

i dont mean thair default vlaue value

[winged tangle]

should it be named DAXA_USING_NAMESPACE ?

[next tundra]

but what the semantical default is

[winged tangle]

all things are prefixed

[next tundra]

ie namespaces are on by default or not

[winged tangle]

yes

[next tundra]

then name the thing DAXA_DISABLE_SHADER_NAMESPACE rather than DAXA_ENABLE_SHADER_NO_NAMESPACE

[winged tangle]

glsl has no real namespaces so i just prefix a daxa_ on all things and the no namespace thingy just adds defined

[winged tangle]

ok

[next tundra]

ye whatever it is in the end

but now intent is more obvious

[winged tangle]

i could also name it DAXA_ENABLE_NAMESPACE

and set default to 1

[next tundra]

that could work too

check the other names for double negations too 🙂

[winged tangle]

yea

[cobalt thistle]

Clinically insane human being

[next tundra]

speaking of 👆

where is your entry in #1019722539116802068

[winged tangle]

fr lukas

[cobalt thistle]

After gym I will post

[winged tangle]

https://github.com/Ipotrick/Daxa/wiki/Shader-Integration

@next tundra does that make sense (except for typos and broken grammar)?

also @soft tapir @cobalt thistle ^ new shader integration

naming poll:
BufferRef(BUFFER_TYPE) or Buffer(BUFFER_TYPE)

[next tundra]

hmmmmmmmmmm

re the last question, im in favour of Buffer(type) rather than BufferRef (i still dont see the point of calling something ref in a shader, but i also dont know shaderisms at all tbh)

[winged tangle]

yea i am at buffer rn

[next tundra]

re the link... i suppose DAXA_SAMPLED_IMAGE_BINDING is an example only?

[winged tangle]

just sanity checking

[winged tangle]

yes

[next tundra]

is that a name somebody would use in their program somewhere?

[winged tangle]

no

[next tundra]

kkk then nevermind my question

[winged tangle]

its integrated to main now

[winged tangle]

daxa will get a samples overhaul

[next tundra]

how it handles samples or you mean examples?

[winged tangle]

examples

[next tundra]

https://tenor.com/view/covid-shot-covid-test-covid-vaccine-covid-gif-21506172

[winged tangle]

https://tenor.com/view/chill-out-gif-18289995

[next tundra]

couldnt dinf anything better "samples" related 😄

[winged tangle]

it will take time

i wanna work on my meshlet thingy first

[winged tangle]

I love daxa

struct Mesh
{
    daxa_f32vec3 obb_min;
    daxa_f32vec3 obb_max;
    daxa_BufferId mesh_buffer;
    daxa_u32 meshlet_count;
    daxa_Buffer(MeshletArray) meshlets;
    daxa_Buffer(MicroIndexArray) micro_indices;
    daxa_Buffer(IndirectVertexArray) indirect_vertices;
    daxa_Buffer(Vec3Array) vertex_positions;
};

I love buffer device address. I just allocate a whole mesh into one buffer and then store bda's to the parts that store the relevant data.
And daxa is so nice to translate this to a c++ struct i can init on host.

[winged tangle]

updated buffer ptr syntax

[winged tangle]

@next tundra can i post a link to a daxa discord here?

[next tundra]

sure

and then you could pin it

[winged tangle]

https://discord.gg/WDzCUKfA

[winged tangle]

resurection

perma link https://discord.gg/2u8JnVd7zF

[winged tangle]

Daxa is getting a tutorial showcasing the api on a basic level

its also a bigger sample in multiple steps

[winged tangle]

I started work on conditional based permutations and persistent resource synch

i already have permutations implemented via conditional scopes in recording

but no i will also support just in time generated synch between executions of the task graph

as i now have conditionals the previous frame access can change

even worse, these accesses can fragment and change over time, so i must track last executions last access states. So this synch must be generated just in time every execution

but that is only the case for any resource that is persistent

I will also add just in time static permutation compilatiuon

as currently i just generate 2^(conditionals-1) permutations on startup

with jit compilation it would only compile permutations that are actually encountered

All this will allow daxa task list to cache (or even fully precalculate) synchronization information as much as possible between executions and allows it to be more efficient then pure just in time re optimizing synchronization

@south anchor for the brainworm enjoyment

[south anchor]

now this is nice stuff

i wonder how dynamic real usecases are, do you have any examples?

[winged tangle]

one of the most common examples would be to have a first frame permutation to run some initialization code

another would be to turn off code for culled features, for example no water visible in current view

but it can be taken even further, making it describe all rendering

so on startup of an app you are in a menu for example

then you have a permutation to init rendering

and then a permutation for rendering after entering the game

[south anchor]

mmm, but what is the benefit of that

[winged tangle]

state would be traxken brtween executions, so it can insert correct barriers hwne usage changes between executions

and as the one task lisy holds most of what is going on it can do all synch correctly for persistent resources

[winged tangle]

Technically i should probably also track buffer access stages to synchroniza on that between frames right? That seems kinda unnessecary even tho its needed right?

[south anchor]

look at what vuk futures are then

[winged tangle]

do you have a good sample that shows how its used?

[south anchor]

try example 8

[winged tangle]

is a gpu future tracking the state of a resource? to keep it around for multiple frames for example?

i think i am too dumb to understand xD

[south anchor]

yeah

its automation of initial and final state

point being that you don't need to have a single compilation

[winged tangle]

yea good point

[winged tangle]

after all

this is just research for my own understanding really

i do think that task list is a nice api i want to use

but i wont know if the ideas i have will be good and nice to use in the end

i routinely remove things i dont like after a while

backwards compatibility is low prio in daxa

[south anchor]

yeah, i am not saying don't do it

just my 2c

[winged tangle]

tracked image subressourve manipulation can be really complex

[south anchor]

ye, esp with multi queue

[winged tangle]

probably the most bug prone loops i have ever written

[winged tangle]

intrestingly a few of the changes increase the time to build a task list unexpectedly

i will start to optimize the compilation

[winged tangle]

i actually found a few bugs while redoing layout initialization

[winged tangle]

daxa is now available in vcpkg

https://tenor.com/view/troll-face-creepy-smile-gif-18297390

[winged tangle]

jit compiler to synch between permutations done

just needs testing now

I also fixed initial access for ressources with @soft tapir

[winged tangle]

daxa s wiki got a facelift

its actually passable now

we also added a small tutorial with sample code

[haughty whale]

daxa on shader objects when

[winged tangle]

Soon

ish

[winged tangle]

daxa is getting rpsl for poor people

shaders declare what resources they use and task list will sync and bind automatically

[winged tangle]

inline shader code that can be also included in cpu code

generates a c++ container that task list eats on task construction

and a shader side struct that is used by the shader directly

i am considering adding explicit uniform buffer binding

this way i wouldnt need to put this into a push constant

even easier

[winged tangle]

Can we have rpsl?
We have rpsl at home:

a thing that is annoying here that will get fixed soon, is that the things are passed in the push constant

i will implement opten gl style buffer bindings, so that task list can hide that as well

in the end this saves a ton of code in one of my projects

what can also still be improved is that this must be in inl files

optimally we can declare uses in shaders alone and without the access code

that would just be autogenerated from glsl type + stage

[south anchor]

why do you do codegen instead of just reading info from the spirv?

[winged tangle]

i want to keep using my bindless handles

and they are just fancy bitfields

i can also pack in whatever info i want into this now

dont need to be restricted to spirv reflection information but anything

[south anchor]

i don't follow

[winged tangle]

My declared resources are not visible in the spirv

i only have my mega set bound

[south anchor]

yes, you can just put nonsemantic data into spirv

i already told you this

[winged tangle]

Also if you look at this, this is per task information. So what i want to do is have one shared file for all pipelines in that task as a whole. Declare all uses across the pipelines as thats fine within a task. Then i can simple fill one uniform buffer with the ids at runtime and bind it. The pipelines all then use the ids from there

[winged tangle]

i forgor

maybe an isoteric idea to have many pipelines in a task but i already have some tasks that do that

the code generation is also just more consistent with the rest of daxa

as i use that a lot already

[south anchor]

as you prefer

[winged tangle]

big downside to my design is that its cpu compile time constant

so when i hot reload it wont know the update

if i put it in the spirv

i could rerecord the tasklist and have hit reload add task uses at runtime

that would be amazing

https://tenor.com/view/trade-offer-dungeons-and-fakultet-gif-24324825

i think i will have two options for this

one is the cpu compile time inl file version

and the other is in shader option

[winged tangle]

daxa basically emulates descriptor buffer now

[winged tangle]

i have sinned

daxa has bindy now

but only for uniform buffers

not shown here

but used by task list to remove more code and make it even simpler

in daxa i can use them kinda like descriptor buffers and descriptor sets now

just in a cursed daxa way

[winged tangle]

i love codegen with makros

i love codegen with makros

i am sane

i am sane

[next tundra]

[winged tangle]

I AM SANE

[winged tangle]

Ok

finalizing the sync api in daxa now:
We can now create persistent resources that live outside of tasklists.
One can simply mention these in any task list.
The jit sync will then correctly attach their state to the first and last use of uses inside a task list at runtime.

this makes it so that you can use persistent resources in any combination at any time in any tasklist.

the taskl lists could even be completely statically compiled and choosen from per situation without conditionals

You can rerecord every frame, reuse task lists every frame or any combination, this also works with conditionals

all due to the jit

it just works

[winged tangle]

Importantly it will ONLY jit sync to the FIRST mentioned use of the persistent resource in a task list. the rest is statically compiled sync and can be reused

all in-tasklist resources are transient and will use aliasing allocations to reduce memory footprint

the aliasing imo only makes sense to optimise within a tasklist

[soft tapir]

I think it's impossible to alias outside task lists

because you have no guarantee that two tasks lists will not execute at the same time on the GPU

they can have arbitrary overlap

[winged tangle]

@south anchor https://github.com/Ipotrick/Daxa/blob/5a002846f75490ea43518f12dbb91bc6b353bfc1/include/daxa/types.hpp#L203
I had to change how i work with alignas again

but this template cope makes it work

and so far its non breaking backwards compatible with all projects that use daxa

[south anchor]

jimbus

[winged tangle]

But these work very well from what i see

[south anchor]

quite the wall

[winged tangle]

i have to rewrite the shader integration wiki

[south anchor]

but if it works

[winged tangle]

it was born from immense cope

but i like it now

[winged tangle]

saky and i are redoing task list api

cleanup and big upgrade

[soft tapir]

I think we actually came up with something which does very little if any compromises in the front end and maps super nice to the back end

[winged tangle]

yea

i like the current compromise a lot

i think its very easy to use and understand

and hard to misuse if we get validation right

and still super flexible and fast

[winged tangle]

100 daxa stars

[finite nova]

🎉

its daxin' time

[soft tapir]

Transient resource aliasing is in the works

Also Patrick is adding much better validation messages so that we catch as many user errors as possible

[winged tangle]

man writing validation code is a lot of work

Also rewriting the old crusty validation messages in daxa will take some time

[haughty whale]

writing your own validation :slippy:

have you considered just slapping bunch of asserts on things people actually often run into

[winged tangle]

hmm

its not that many checks

[soft tapir]

That's wgat I do every time I run into user error

Me being the user

🙃

[winged tangle]

i think i found a really nice new interface for tasks

its definetly much better for the things i use task list for

[winged tangle]

struct MipInput
{
    daxa::TaskInputImage lower_mip = {{.access = daxa::TaskImageAccess::TRANSFER_READ}};
    daxa::TaskInputImage higher_mip = {{.access = daxa::TaskImageAccess::TRANSFER_WRITE}};
    daxa::TaskParam<f32> value = 3;
} input;

input.lower_mip.id = task_render_image;
input.lower_mip.slice.base_mip_level = i;
input.value = 3213;

input.higher_mip.id = task_render_image;
input.higher_mip.slice.base_mip_level = i + 1;

new_task_list.add_task(daxa::TaskInfo<MipInput>{
    .task_input = input,
    .task = [=] (daxa::TaskInterface<MipInput> const & ti)
    {
        auto cmd_list = ti.get_command_list();
        f32 value = ti->value;
        cmd_list.blit_image_to_image({
            .src_image = ti->lower_mip.image(),
            .dst_image = ti->higher_mip.image(),
            .src_slice = {
                .image_aspect = ti->lower_mip.slice.image_aspect,
                .mip_level = i,
                .base_array_layer = 0,
                .layer_count = 1,
            },
            .src_offsets = {{{0, 0, 0}, {mip_size[0], mip_size[1], mip_size[2]}}},
            .dst_slice = {
                .image_aspect = ti->higher_mip.slice.image_aspect,
                .mip_level = i + 1,
                .base_array_layer = 0,
                .layer_count = 1,
            },
            .dst_offsets = {{{0, 0, 0}, {next_mip_size[0], next_mip_size[1], next_mip_size[2]}}},
            .filter = daxa::Filter::LINEAR,
        });
    },
    .name = "mip_level_" + std::to_string(i),
});
mip_size = next_mip_size;

example code with mipmapping

[winged tangle]

@wicked loom if you wre still intrested

@haughty whale this could also be done in c with some minor tweaks i think

[winged tangle]

// New fancy syntax!
struct ClearSwapchainIn
{
    daxa::TaskInputImage swapchain = {{.access = daxa::TaskImageAccess::TRANSFER_WRITE}};
} input;
input.swapchain.id = task_swapchain_image;
new_task_list.add_task(daxa::TaskInfo<ClearSwapchainIn>{
    .task_input = input,
    .task = [](daxa::TaskInterface<ClearSwapchainIn> const & ti)
    {
        auto cmd_list = ti.get_command_list();
        cmd_list.clear_image({
            .dst_image_layout = daxa::ImageLayout::TRANSFER_DST_OPTIMAL,
            .clear_value = {std::array<f32, 4>{1, 0, 1, 1}},
            .dst_image = ti->swapchain.image(),
        });
    },
    .name = "clear swapchain",
});
// Inline syntax still works!
new_task_list.add_task(daxa::TaskInfo<>{
    .task_input = {
        daxa::TaskInputImage{{.id = task_render_image, .access = daxa::TaskImageAccess::TRANSFER_READ, .slice = daxa::ImageMipArraySlice{.level_count = 5}}},
        daxa::TaskInputImage{{.id = task_swapchain_image, .access = daxa::TaskImageAccess::TRANSFER_WRITE}},
    },
    .task = [this](daxa::TaskInterface<> const & ti)
    {
        daxa::ImageId render_img = ti.input_as<daxa::TaskInputImage>(0).image();
        daxa::ImageId swapchain_img = ti.input_as<daxa::TaskInputImage>(1).image();
        // alternatively, the task ids can still be used like before. It is jus a shorter syntax now:
        daxa::ImageId render_img_alt = ti.image(task_render_image);
        daxa::ImageId swapchain_img_alt = ti.image(task_swapchain_image);
        this->blit_image_to_swapchain(cmd_list, render_img, swapchain_img);
    },
    .name = "blit to swapchain",
});

i love this

[south anchor]

it is better

[winged tangle]

i am settling on this now

this is fixing all problems i had so far

[south anchor]

you wanna see the future vuk syntax?

[winged tangle]

yes

[south anchor]

// deferred shading RG
auto build_gbuffer_pass = vuk::make_pass(
                  "05_deferred_MRT",
                  [uboVP](vuk::CommandBuffer& command_buffer,
                          vuk::IA<vuk::eColorWrite, decltype([]() {})> position,
                          vuk::IA<vuk::eColorWrite, decltype([]() {})> normal,
                          vuk::IA<vuk::eColorWrite, decltype([]() {})> color,
                          vuk::IA<vuk::eDepthStencilRW, decltype([]() {})> depth_rt) {
                                  command_buffer.set_viewport(0, vuk::Rect2D::framebuffer())
                          .set_scissor(0, vuk::Rect2D::framebuffer())
                          .set_rasterization(vuk::PipelineRasterizationStateCreateInfo{}) // Set the default rasterization state
                          // Set the depth/stencil state
                          .set_depth_stencil(vuk::PipelineDepthStencilStateCreateInfo{
                              .depthTestEnable = true,
                              .depthWriteEnable = true,
                              .depthCompareOp = vuk::CompareOp::eLessOrEqual,
                          })
                          .set_color_blend(position, {})
                          .set_color_blend(normal, {})
                          .set_color_blend(color, {});
// .... more cbuf recording
});
auto shading_pass = vuk::make_pass(...);
auto position_image = vuk::declare_ia("05_position");
position_image->format = vuk::Format::eR16G16B16A16Sfloat;
position_image->sample_count = vuk::Samples::e1;
position_image = vuk::clear(position_image, vuk::ClearColor{ 1.f, 0.f, 0.f, 0.f });
// ... more stuff
auto gbuffer = build_gbuffer_pass(std::move(position_image), std::move(normal_image), std::move(color_image), std::move(depth_img));
auto result = std::apply(shading_pass, std::tuple_cat(std::make_tuple(target), gbuffer));
return result;

[winged tangle]

how do you analyse the use fields

the vuk::IA parameters

[winged tangle]

i like this

[south anchor]

i like it too

[south anchor]

TMP

i just need to work on it more

its not final syntax yet, some things are still rough on the edges

[winged tangle]

i see

[winged tangle]

struct MipMapTask
{
    struct Uses
    {
        ImageTransferRead<> lower_mip{};
        ImageTransferWrite<> higher_mip{};
    } uses = {};
    std::string name = "mip map";

    u32 mip = {};
    std::array<i32, 3> mip_size = {};
    std::array<i32, 3> next_mip_size = {};

    void callback(daxa::TaskInterface const & ti)
    {
        auto cmd_list = ti.get_command_list();

        [[maybe_unused]] auto const lower_mip_view = uses.lower_mip.view();
        [[maybe_unused]] auto const higher_mip_view = uses.higher_mip.view();
        cmd_list.blit_image_to_image({
            .src_image = uses.lower_mip.image(),
            .dst_image = uses.higher_mip.image(),
            .src_slice = {
                .image_aspect = uses.lower_mip.handle.slice.image_aspect,
                .mip_level = mip,
                .base_array_layer = 0,
                .layer_count = 1,
            },
            .src_offsets = {{{0, 0, 0}, {mip_size[0], mip_size[1], mip_size[2]}}},
            .dst_slice = {
                .image_aspect = uses.higher_mip.handle.slice.image_aspect,
                .mip_level = mip + 1,
                .base_array_layer = 0,
                .layer_count = 1,
            },
            .dst_offsets = {{{0, 0, 0}, {next_mip_size[0], next_mip_size[1], next_mip_size[2]}}},
            .filter = daxa::Filter::LINEAR,
        });
    }
};

daxa::TaskImageHandle lower_mip = task_render_image.handle().subslice({.base_mip_level = i});

new_task_list.add_task(MipMapTask{
    .uses = {
        .lower_mip = lower_mip,
        .higher_mip = task_render_image.handle().subslice({.base_mip_level = i+1}),
    },
    .name = std::string("mip map ") + std::to_string(i),
    .mip = i,
    .mip_size = mip_size,
    .next_mip_size = next_mip_size,
});

I did another iteration

i now reflect this struct for tasks

only strangeness is that uses need to be in a locally declared field called uses that must only contain uses.

makes a lot of tiny things more clear

[winged tangle]

I also made handles take a slice. Now handles uniquely identify uses

making this syntax possible as well:

new_task_list.add_task({
    .uses = {
        BufferHostTransferWrite{task_mipmapping_gpu_input_buffer},
    },
    .task = [this](daxa::TaskInterface const & ti)
    {
        auto cmd_list = ti.get_command_list();
        update_gpu_input(cmd_list, ti.uses[task_mipmapping_gpu_input_buffer].buffer());
    },
    .name = "Input Transfer",
});

much, much better

[winged tangle]

im actually completely happy with this now

[winged tangle]

i love daxa

I just fixed some things and now transient memory allocations work nicely with the task graph. ez aliased scratch memory for days.

3 lines and i have my buffer ready

[astral fulcrum]

Epic

[winged tangle]

its really nice rn because i have everything indirect, meaning i need a ton of tiny buffers just containing indirect command info

now i can just create them super ez inbluck

    auto upsweep0_command_buffer = info.task_list.create_transient_buffer({
        .size = sizeof(DispatchIndirectStruct),
        .name = "prefix sum upsweep0_command_buffer",
    });
    auto upsweep1_command_buffer = info.task_list.create_transient_buffer({
        .size = sizeof(DispatchIndirectStruct),
        .name = "prefix sum upsweep1_command_buffer",
    });
    auto downsweep_command_buffer = info.task_list.create_transient_buffer({
        .size = sizeof(DispatchIndirectStruct),
        .name = "prefix sum downsweep_command_buffer",
    });
    info.task_list.add_task(PrefixSumCommandWrite{
        {.uses={
            .u_value_count = info.value_count,
            .u_upsweep_command0 = upsweep0_command_buffer,
            .u_upsweep_command1 = upsweep1_command_buffer,
            .u_downsweep_command = downsweep_command_buffer,
        }},
        .context = info.context,
        .push = {info.value_count_uint_offset}
    });

i have set myself a minimum time i wanna spend on my projects now

its really fun and i just always get lazy and stop for no good reason

[haughty whale]

when are you making a game

[winged tangle]

😦 comany says nono

😈 i have a good excuse

i guess they wont care about anything small tho actually

[astral fulcrum]

have you thought about writing automated tests for daxa

[placid cloak]

You should also write some Rustdoc and MdBook style docs

[winged tangle]

automated tests

No i have not actually. should be easy to set up but i havent come around to it.

mdbook style might be cool

[astral fulcrum]

rustdoc is good

[winged tangle]

md sounds nice, is it actually md, cause the current eocs are all md files already

[sick pilot]

I wonder how daxa handles updating descriptor sets for things like sampler arrays. Does it track it in any way to make it safe?

[hoary zephyr]

ooh daxa supports autosync??

that's intruiging

[sick pilot]

No idea

[sick pilot]

I'm talking about the case of VK_DESCRIPTOR_BINDING_UPDATE_AFTER_BIND_BIT, or more generally I'm wondering how descriptor sets updates for bindless stuff are handled

[cobalt thistle]

there is only one descriptor set which holds everything

[cobalt thistle]

they update the specific index

[sick pilot]

And is it up to the user to not change anything which is dynamically accessed?

[cobalt thistle]

user doesnt have access to this

[sick pilot]

Uhm

[cobalt thistle]

buffers and images are hidden by handle which is just index

[sick pilot]

Ah I see

Thank you!

[cobalt thistle]

you are welcome

@winged tangle good news I give up and will learn task graph

[winged tangle]

yes

[winged tangle]

daxa has a storage image, sampled image and sampler descriptor array

it enables all the descriptor indexing extensions

it kinda makes it just some fancy block of data you can update however. I plan to replace the pool with a descriptor buffer in order to ipdate the descriptors even more efficiently by just writing the mapped host ptr of the descriptir buffer instead of doing descriptor writes. Descriptor set writes can be very expensive

not that it matters much for daya honestly

its ultra fast already but speed addiction hits always

[winged tangle]

😈finally

take a look at the tutorial wiki page

it shows simple use

[cobalt thistle]

Already reading it 🫡

[winged tangle]

daya task graph is quite fleshed out now. it is really nice to use. kinda like vuks rendergraphs but with my own tradeoffs

[winged tangle]

ascend

you will love it

[cobalt thistle]

I dont understand this thing. You can have multiple buffers in on task buffer?

[hoary zephyr]

Awesome

[winged tangle]

you *can

its quite esoterical

whej you have a task that mipmaps N images

it is nice

sometimes you have a collection of resources with the same sync needs. One tbuffer or timager can represent them

[cobalt thistle]

it could be useful for tripple buffering

[winged tangle]

this also allows you to change the count at runtime

ik out for a few hours

rammstein concert started

[cobalt thistle]

okay 👍

[sick pilot]

Descriptor buffer doesn't have that much coverage though right? So you still need the fallback

[hoary zephyr]

Holy based vulkan dev

[winged tangle]

its some prelude they come in a few minutes

[cobalt thistle]

coverage is fine its nvidia gtx 745+ and amd rx580+

[winged tangle]

its just slow driver updates. it will likely be 99% covered

[sick pilot]

BTW I wonder how db compares to updating descriptor sets in radv since all it has to do to update descriptor sets in principle is memcpy but for smaller descriptors it just manually writes stuff without even calling memcpy. So it'd kind of micro optimized. That'd be a question for pixel I guess

[sick pilot]

Ah nice

[winged tangle]

you can switch underlying resources between executions of task graphs . generally you can reuse completed task graphs very well.

[cobalt thistle]

thats some real

[winged tangle]

api calls have a general overhead due to indirection. mapped mem writes to descriptir buffers will lokely always stomp it

[sick pilot]

Is it known whether nvidia "likes it"? From what I know updating descriptor sets on nvidia is not as simple as writing memory

[sick pilot]

Makes sense I guess

[winged tangle]

nvidia likes it

[sick pilot]

Great

[winged tangle]

its a bit dumb how it works on nv

could be better but its still good

[sick pilot]

Do you know how it works?

Though maybe not a discussion doe this channel

Thanks guys

[cobalt thistle]

my only problem how task graph handles when you switch pipeline as in task callback. You can get the task and update the pipeline or you have to rebuild the whole task graph again?

[winged tangle]

you can just switch the pipeline in the callback at any time

as long as you mention all used stuff that needs sync in the task you are fine

[cobalt thistle]

hmmm. I dont see how would you do it code wise.

[winged tangle]

inside the callback

you would have a pointer captured to the pipelines and the data needed to decide what pipeline to use

[cobalt thistle]

oh alright. I see now

[winged tangle]

you should try it some time

join the cult

[hoary zephyr]

I very much would but rust owo

[winged tangle]

[sick pilot]

Yeah

Same for me

[winged tangle]

we are planning a prototype of a c api and rust bindings

i wont promise anything

but maybe(tm)

[sick pilot]

That's nice

[lavish talon]

You promised me some naniteisms though

hurry up so I can copy you

[winged tangle]

i will i will

i need to unlazy tho

[soft tapir]

there is no learning

it's all super simple

(except for the tl bugs)

[winged tangle]

you arent supposed to mention those

[soft tapir]

😈

I found a way to workaround renderdoc ruining the immages btw

we need to add that

[hoary zephyr]

If you manage to make it rusty enough (strong use of type / trait system) then that will be very nice

[soft tapir]

I'll add it tommorow

each task is in it's own batch

Renderdoc is okay with that - for some reason once some tasks are in the same batch it ruins all the texture views

[sick pilot]

So once you go full bindless how do you do the virtual to real resource translation in the task graph? It's just integers you are sending to shaders right? Does daxa send them for you?

[soft tapir]

I don't follow

you pass them as BDA to the shader (in a push constant or in any other way you like)

You have TaskBuffers which contain one or more real buffers

daxa has functions to extract the real buffer ids from the task buffers and for translating the real buffer ids to BDA

[sick pilot]

Ah, so it's up to you to send those to the shader then 🤔

Guess I'll give the code a read

[soft tapir]

if you use the macro task graph api it sends them for you in a uniform buffer

@winged tangle is this on the wiki yet?

[winged tangle]

task graph fills a uniform buffer with all task args

[sick pilot]

I see

Thank you again guys

[winged tangle]

any used images get a view created for the specific use, its view id is put into the buffer

any buffer gets its device address put into the uniform buffer

ypu can alternatively also access them yourself in the task callback.
The wiki shows how to do this already

[soft tapir]

now use it! 😈

[winged tangle]

how task list puts your things in a uniform buffer is not explained yet really but i will add that tomorrow

[sick pilot]

My codebase is in rust 😭
I'm doing open source espionage to hopefully contribute proper support for bindless in Phobos

[winged tangle]

but yes, essentially its all integers then

[soft tapir]

so many rust ppl damn

[winged tangle]

a spy

i think there is more rust daxa demand then c++ daxa demand at this point

[soft tapir]

https://tenor.com/view/sad-frown-rain-cat-gif-17035614

[sick pilot]

Fr?

[soft tapir]

A lot of ppl ask for rust yeah

[winged tangle]

rust is growing really fast in graphics

[sick pilot]

That's nice

When I started there wasn't much

[winged tangle]

its still not much tbf

[sick pilot]

Yeah

But there is something

[winged tangle]

its just a lot of young ppl going for rust

so in 10 y it will be goodish i would think

[sick pilot]

Sooner thanks to my espionage

[winged tangle]

@sick pilot a thing that was a bit tricky was to get the ressource table threadsafe*

you can read without locks, assuming you never use after free which is checked tho (thid check is just a debug thing and can die to race conditions so you still cant just rely on it but it kinda mostly finds errors most of the time)

[hoary zephyr]

Yea considering there's only like 1-2 main libraries used for graphics it's not mature at all

It's growing though so that's a nice thing

[sick pilot]

Ah, something to take a closer look at I guess. Thanks!

[winged tangle]

it is a bit overengineered actually. It cuts up a big array onto page sections. Then only keeps allocations of these sections

idk if i like that still as i prefer simplicity even if that would mean using more memory

hmmm

i think its ok as the objects are kinda big

descriptors are very small usually so i dont care that they are fixed

i need to reevaluate this a little

its very battle tested tho so i believe it doesnt really have bugs

im thinking out loud

🔊

[hoary zephyr]

Thinking out loud kinda helps tbh because if I say something dumb I instantly realize it

[winged tangle]

yea

[soft tapir]

Me too because Patrick reacts with "😐"

[cobalt thistle]

Hopefully it will solve some issues

[sick pilot]

So can you read it locklessly because you can just copy a page and then replace the whole thing when it is written?

[winged tangle]

destroying all confidence with a single emoji

infinite might

[sick pilot]

I wrote lucklessly insteaof of locklessly

[winged tangle]

loool

[winged tangle]

when i add a new page all other pages are independent from that

as opposed to a growing vector

this gives me pointer stability

addresses wont change

if i grow by adding more pages

[sick pilot]

Right, I was thinking about the case in which you replace an entry but I suppose that falls within the case of use after free which as you said is not something you actually need to worry about

That's really nice thx

[winged tangle]

well

you can always check the version

this way you can detect use after free

and version cna be atomic

so that wont need sync

[sick pilot]

I noticed you've got those 8bits for thr version

[winged tangle]

yea its super tiny

for rust i would maybe go for 32

but it happens thaz nv only allows up to 1 million images per app

so thats 20 bits

[sick pilot]

Oh lol

[winged tangle]

so i use 8 for version

[sick pilot]

Yeah makes sense

[winged tangle]

32 bit version woudl make it MUCH more robust

but also make it take more space in buffers

i copied this pattern from entt

very good lib can steal tons of data oriented patterns from it

[sick pilot]

Came across it ad well, it's kinda like generational references

[finite nova]

Yo how is daxa rt going?

[astral fulcrum]

Danny changing vk libs more often than I shower

[finite nova]

I’m just curious as daxa is more matured. No way I’m gonna jump from rust I’m too 🦀’d

[astral fulcrum]

🦀

[soft tapir]

Danny asking the real questions

"it's planned"

There just is a lot of small fixes and stuff higher on the priority list

[winged tangle]

i was thinking of using md book for docs

everything daxa has rn is already in md files

[winged tangle]

daxa c api coming

for the rust and zig ppl

[winged tangle]

im working on making the c api able to be theoretically safe rust when wrapped

so it aligns will all the ownership and sharing bingus

its growing

[cobalt thistle]

🤰

[winged tangle]

Yo

daxa runs on mac now

@pale owl does the magic

[pale owl]

***** MASSIVE ASTERISKS

shaders with daxa.glsl don't seem to compile in moltenvk yet

[hoary zephyr]

vulkan-portability I assume?

I thought that moltenvk was not vulkan-spec complient hm

[winged tangle]

its very spotty

we will see how it works out

but we already ran daxa code on a mac

just some smaller tests

[hoary zephyr]

Ooh I see I see

[winged tangle]

the c api turns out quite nice actually

maybe i can bully nano into trying it out

[hoary zephyr]

Lol

[pale owl]

C API allowing for Rust bindings for those who like Rust

😈

[winged tangle]

😈 we are in business \

to be clear it wont just be poopy c bindings

i ll wrap it all in sexy rust

🦀

[pale owl]

"I" as in all the Rust lovers in my discord (exso, brynn, etc.)

[winged tangle]

right

[winged tangle]

😈

[winged tangle]

daxa team grew

[winged tangle]

damn rewrites are lots of work

daxa is fat as hell

[winged tangle]

i expect c api and c++ changes to be done next week fr

then rust api sunday

[winged tangle]

brynn kindly took over the work for daxa rust, so the work will probably be done even sooner.

[winged tangle]

This is what i cooked @harsh yew

[harsh yew]

yeah.. I'm not reading that 😄

[winged tangle]

lol

[harsh yew]

My template-foo lacks

[winged tangle]

mine too

it broke my head to get this to work

    inline void CompileTestVariant()
    {
        Variant<u32, f32> v;
        Variant<f32,i16,u8> v1 = u8(1);
        v1.set(3.4f);

        if (auto ptr = v1.get_if<f32>())
        {
            *ptr = 1.0f;
        }
        else if (auto ptr = v1.get_if<i16>())
        {
            *ptr = 5;
        }
        v1 = NullVariant{};
        if (!v1.has_value())
        {
            v1 = i16(3);
        }
    }

The use is nice tho

also build in null thingy

[harsh yew]

if constexpr (variant.index() == 0)
{
  return variant[0];
}
...

gotta have that constexpr support in there

[winged tangle]

intresting

[harsh yew]

or in this case its literally
variant[variant.index()] which is a compile-time get of the value

[winged tangle]

yea

meh

i ll keep it simple for now

no need to bloat it more

[winged tangle]

due to changes i make looking at better error handling for the c and rust api i find new solutions to the c++ api as well

its a whole revamp basically and i get rid of some fat c++ stl headers which is always very very nice

[pale owl]

themperror is an amazing name

[winged tangle]

true

[winged tangle]

its very interesting to explore design options to make zhe c api do most of the work and still allow for a convenient small safe rust wrapper

[winged tangle]

@harsh yew https://github.com/Ipotrick/Daxa/blob/1032f844907b9f71147b7ad9ce7cdaa8d3235343/include/daxa/types.hpp#L331C31-L331C31

gabe rewrote it by de bloating another impl

[winged tangle]

ah i lov working on daxa

the c api thing gave us so many problems

that i had to rewrite it multiple times

but i also had to rewrite the implementation which is actually great

Daxa now never internally errors or throws it returns error codes instead.

making rust wrapper possible

[winged tangle]

finding solutions to these problems was epic fun

for example the c api does intenral ref counting similar to vma. The ref counter is exposed, so the c++ and rust wrapper can write super slim wrappers as the c api does all the lifetime stuff

this also means that the c ptrs can be tricially casted to the rust and c++ type

which makes the passthrou and wrappers MUCH simpler and cleaner

and the c++ api will have interop with raw vulkan and the c api now

which is also awsome as that was a big missing part

i love how simple this is in the end on the user side

[winged tangle]

this also means that (as daxa internally ref counts now), that the user doesnt need to care about dependencies at al anymore. for example killing an image before an image view is fine the image vie keeps it alive now

it half assed ref counted ebfore but only outside, which made no sense but i didnt realize that before

so the c api makes the c++ api actually safer and easier to use in the end which is surprising to me

Before i started i dredded the idea of the c api for rust.
But now i love it

[south anchor]

well.. you have now forced refcounting bc the c interface is too anemic to support anything safe

that is not to say you can't make the decision to refcount

but the argument you make is Stockholm syndrome at best

[winged tangle]

i dont follow

[winged tangle]

the interface did refcounting before. Extending it to internal counting for dependencies is only natural

i have no clue what you mean with Stockholm syndrome here.

[south anchor]

i mean that c apis are shit

[winged tangle]

i agree

[south anchor]

refcounting is one thing, but being forced to refcount bc c apis are shit

nothing to celebrate

[winged tangle]

well

idk about that. I think what i tried to say here is that i relalized i can do the internal refcounting allso in the c api which makes less redundant code in the c++ and rust wrapper

also makes the c api simpler to use

"have to do it" i mean i dont have to but it makes life better for me

[south anchor]

thats orthogonal, i don't have an issue for designing it with refcounting

[winged tangle]

hm

ok then i missunderstood

[south anchor]

i personally don't like it, but w/e

what i don't like is having to limit oneself to the stone age due to c

[winged tangle]

oh yea that caused a ton of problems

i had to rewrite some containers like optional and variant so ihave stable c abi

but it was a very cool challange in design

was very fun to get it to work

[winged tangle]

this is the wrost part by far

the rest of the changes were nice imo. Thinking of the c api made me realize general improvements that i could apply everywhere 😄

new perspectives always give new ideas

i actually really like c apis in many cases

i love how simple they are

i often say the best c++ libraries are c libraries

I see what you mean with stockholm syndrome now but i like it 😈 . Maybe im crazy

there is a little c-bro growing inside me

[south anchor]

just keep it in check, otherwise you might go bald

[winged tangle]

c++ already does that to me

[sick pilot]

Is there anything a c api disallows? I mean the c api is not something you use directly

[sick pilot]

Are big resources ref counted? Like if you allocate a buffer, do you have a way of deallocating it, say from another thread, and in general a way of knowing for sure it has been deallocated?

[soft tapir]

Destruction of persistent resources, such as persistent buffers or images is user responsibility but DAXA still notifies the user when he fails to do that

Other objects such as device etc are refcounted though

[sick pilot]

Nice that's great

Makes perfect sense

[winged tangle]

yes

[sick pilot]

Yes to which question lol

[winged tangle]

i like to believe that the c api is actually quite usable on its own too now

[winged tangle]

both

[sick pilot]

Mmm how

[winged tangle]

i missread

the second one is semi knowable

you can enable a flag

that makes daxa error if you for example delete an image that is used by an image view

but per default it will just keep it alive

the only exception right now are images buffers samplers in regard to device. zhe device must always outlive all its images buffers and samplers

well change that for rust

and later also c++ to be consistent

[winged tangle]

the ref count methods return the prev value on decrement so you can chevk on it beeing 1

then its destroyed for sure

coherent explanation:

• every resource has a ref counter
• per default every* resource is internally refcounted. For example an image view keeps its image alive, a semaphore keeps device alive etc.
• currently there is an inconsistency with images, buffers, image views and samplers. Those MUST be destroyed before their device!
• this will be changed in the future for better consistency.
• all other resources can outlive their parent, they will scilently keep it alive via the refcounter
• in the c api, you get one pointer to a resource with ref count of one. In the c api from the user side its basically manual memory management.
• but internally ofc its still ref counted, so the user doesnt need to worry about the dependencies or resources, eg device -> semaphore, image -> image view which makes the c api much easier to use.
• this also makes the c++ and rust wrapper much simpler, they dont have to care about dependencies.
• there is an optional flag that will ERROR if you destroy the user handle with other internal references still beeing in place, for example killing a device before a semaphore will error then.
• in c++ you can also use the c api flawlessly which gives you access to manual management if you wish. The default containers are automatically ref counted tho. And this is relatively safe as the internal ref counting is still in effect!!
• essentially in c++ you can choose between externally refcounted or manually managed + choose if the internal ref count acts as an error check or lifetime extender.
• overall this makes daxa much easier to use as internal errors due to broken dependencies are much rarer.
• in rust everything is ref counted to ensure safety.
• overall ref counting in this style has no real perf impact and makes it much easier to use. The optional flag to error on unordered destruction also makes for peace in mind if you wish to be in full control and check for errors.

@sick pilot sorry for the mumbling before, this explanation should make it clear 😄

So to answer your second question,

there is an optional flag that will ERROR if you destroy the user handle with other internal references still beeing in place, for example killing a device before a semaphore will error then.
With this flag you can be sure of the destruction order.

[sick pilot]

Mmm I see thanks.
With vulkano you are always forced to use Arc for pretty much anything. I didn't like this because it meant I lost any concept of ownership. Things like threads for deallocations would become harder and it was easy to keep something alive by mistake because easily get scattered everywhere.

[winged tangle]

some parts are not ref counted in the rust api

for example command list is not

makes no sense to ref count it in rust

but in rust you dont have a choice if you want it safe

the dependencies are not managable without massive constrains otherwise

actually maybe im wrong

how would you like it pac

[sick pilot]

I'm biased because I would be based on just one bad experience, my opinion is that safety is an open problem in graphics and trying to solve it shouldn't get in the way of a flexibility.

[winged tangle]

i dont think that makes sense in the context of rust

[sick pilot]

Though it is a very biased opinion

What do you mean?

[winged tangle]

well in rust one should always try to use safe wrappers for eveythign as much as possible

[sick pilot]

Yeah ik

[winged tangle]

otherwise the language is needlessly restrictive

but i think the mode where daxa errors if you dont delete in right order might be cool then

still safe

but you know whats going on

[sick pilot]

But like, an engine is not just a renderer, even if all of the renderer is unsafe there is much to be gained in the rest of the codebase. Anyway yeah that sound good

[winged tangle]

👍

[sick pilot]

The reason I say that is, if you force Arc on "big resources", then basically deallocating them too late is as dangerous as deallocating them too soon

[winged tangle]

yea i agree

[sick pilot]

Which like, in general is totally not true for security

So many rust things are designed around that and I've come to the conclusion those things just don't apply to graphics

[winged tangle]

i dont really agree

rust safety is more about correctness
