(advait) Building while pathfinding

[elder peak]

I asked this question a while ago and fullwall told me I'd need to code it myself, so here's my approach so far:

• Make a custom trait
• Make it so that the NPC will navigate normally if it can get to the path via walking
• Make the NPC build (todo) if it cannot get to the path normally

Here's my approach so far:

    @Override
    public void run() {
        new BukkitRunnable() {
            @Override
            public void run() {
                if (!npc.isSpawned()) return;

                try {
                    Location targetLocation = npc.getNavigator().getTargetAsLocation();

                    if (targetLocation != null && npc.getNavigator().canNavigateTo(targetLocation)) {
                        debugMessage("NPC can navigate to " + targetLocation);
                    } else {
                        debugMessage("NPC cannot navigate to " + targetLocation);
                    }


                    // If stuck or unable to see the target, handle obstacles
                    debugMessage("NPC cannot see target location.");
                    handleObstacle();
                } catch (Exception e) {
                    e.printStackTrace();
                }
            }
        }.runTaskTimer(JavaPlugin.getPlugin(Mai.class), 1, 1);

the handleObstacle(); code will be written later to handle the actual building

however, canNavigateTo running every tick is extremely computationally expensive, my server is basically unplayable with that code. is there a more elegant way to do this? i want to make sure im not overcomplicating it

[full comet]

(advait) Building while pathfinding

[full comet]

Hi I'm AutoThreadBot! Don't mind me, I'll just be adding the helper team to this thread so they can see it. A human will get to you soon.

[thin fable]

yes pathfinding checks are expensive so why not give it more delay?

[elder peak]

well if i gave it more delay that'd cause some more issues i'd imagine?

as an example, let's say i want the npc to build towards me and i give the runnable a delay of 10 seconds. that means it'll build one block towards me, not be able to get to me, and then have to wait another 10 seconds before building another block towards me

this plugin https://github.com/notnotnotswipez/TerminatorNPC/blob/master/src/main/java/me/swipez/terminatornpc/trait/TerminatorTrait.java basically checks for every edge case (e.g. when to bridge, when to mine, when to tower) based on the target's location and proximity from the npc, but is that really necessary? is there no simple way to just see if an npc can/can't get to a location without it being computationally expensive?

[thin fable]

just try 10t?

1t is too short

and at least 1t is needed for Citizens to update path

[thin fable]

Someone else asked a question in this forum about this plugin but we don't know so clearly how they use Citizens API

I'll have to go for work, leaving this to someone else or I'd happy to talk about this when I'm free.
20- min to 7 o'clock for UTC+8

[elder peak]

what time is this in est? i've never seen someone give their timezone in utc before 😅

ill look into it while you're busy too ofc

[elder peak]

will give this a shot

the citizens config by default says the pathfinding only gets updated every 1 second, do plugins override that? or do i have to change it in the config as well?

[elder peak]

testing with this code

                    Location targetLocation = npc.getNavigator().getTargetAsLocation();

                    if (targetLocation != null && npc.getNavigator().canNavigateTo(targetLocation)) {
                        debugMessage("NPC can navigate to location.");
                    } else {
                        debugMessage("NPC cannot navigate to location.");
                    }

something super strange i found is that the server basically doesnt lag when the npc can navigate to its location, but as soon as it has no path it lags out. that makes no sense to me, am i missing something? why would it suddenly start lagging when the same function is being called regardless

[heady saddle]

Simple: it's a* pathfinding, if there's no path then it will check more blocks before failing

[elder peak]

so you're saying if i switched it back to legacy mc pathfinding it wouldnt lag?

right now the citizens config (and my code) use the new pathfinder

im not against using the new pathfinder because i believe its better than the old one; is there any way to make it not lag out the server?

this is all very new to me so sorry if some of my questions seem trivial

the issue is when i use the old pathfinding its claiming the npc can still navigate to me when it obviously cant lol

at least... for the most part. man now im really confused lol

[heady saddle]

No, I'm saying that this is how pathfinding algorithms work

You could adjust how many blocks get checked for a path

[elder peak]

well when i switch back to legacy pathfinding it clearly isnt lagging so at the very least i know the type of pathfinding has something to do with it

[elder peak]

my question is why does it say that the npc can navigate to the location when it obviously cant?

and also why it keeps switching between the two, like theres no path there, what is it doing?

[heady saddle]

The pathfinder settings are different between the two

[heady saddle]

You would have to do some debugging, eg path debug or checking the states

[elder peak]

i see, ill lower it in the config first and see if that helps

[heady saddle]

From memory, minecraft will look at 768 blocks before giving up

[elder peak]

alright lowering the values definitely helped but the pathfinding (using newer citizens pathfinding btw) does get significantly worse as you lower said values

wondering if theres a sweet spot

[elder peak]

what do you mean by "checking the states"?

path debug helps btw, its basically showing that whenever the npc has an option of getting closer to me, canNavigateTo is true. but that doesnt make any sense to me, shouldn't canNavigateTo check the entire path holistically? why would citizens think that the path is possible just because the bot can get a little closer?

[elder peak]

going to bump this again, fullwall, is there a reason citizens thinks the npc can navigate to my location when it cant? is there any fix to it i may be missing?

[elder peak]

i remember a while ago you talked about using BlockExaminer to help with this, is that applicable? im not really sure how to use it

[elder peak]

okay, after some further debugging, here is what i found:

                    if (targetLocation != null && navigator.canNavigateTo(targetLocation)) {
                        debugMessage("NPC can navigate to location.");
                        return;
                    } else if (targetLocation == null) {
                        debugMessage("NPC target location is null.");
                        return;
                    }

                    // This is where the code gets spicy
                    debugMessage("NPC cannot navigate to location.");

using this code, it turns out the only two possible cases are "NPC can navigate to location" and "NPC target location is null." there's never a case where the NPC cannot navigate to the location but also has a non-null target location.

my question is... how is that even possible? why is that target location getting nullified whenever theres no path? it clearly remembers where it needs to go because, once a valid path is built, it locks back onto the target

[heady saddle]

it uses the path finder parameters so it may be the distance margin is close enough to stop pathfinding here

[heady saddle]

please dont bump threads

[heady saddle]

I don't have the code where you get the target location. if you use setPath and it can't pathfind then getTargetAsLocation will return null

canNavigateTo does remove existing paths if you're using the minecraft pathfinder

[elder peak]

what ive basically found from testing for the past few hours is that:

• none of the issues above are present when using the a* pathfinder (meaning, if it cant get to the path, canNavigateTo will actually return false)
• using the a* pathfinder (expectedly) is much laggier

is my approach wrong? like, is there a simpler way to do this than constantly checking canNavigateTo in my trait?

[elder peak]

the code to get it is just Location targetLocation = navigator.getTargetAsLocation();

the actual target is just whatever i set it to be, e.g. if i do /npc follow the target will obviously be me, if i do /sentinel addtarget zombie the target will be the nearest zombie etc

the really strange thing though is that when i run this code:

    @CommandAlias("ispathpossible")
    public void runIsPathPossible(Player player) {
        NPC npc = CitizensAPI.getDefaultNPCSelector().getSelected(player);
        if (npc == null) {
            Messages.sendMessage(player, "&cYou have no NPC selected!");
            return;
        }

        long startTime = System.currentTimeMillis();
        boolean canNavigateTo = npc.getNavigator().canNavigateTo(player.getLocation());
        long elapsedTime = (System.currentTimeMillis() - startTime) / 1000;
        Messages.sendMessage(player, "&aResult for path: " + canNavigateTo + " (" + elapsedTime + " sec)");

    }

it always takes 0 seconds to run, it runs instantaneously. but its using the same exact method, why is it only becoming an issue when im doing canNavigateTo in the trait? is it just because its running so often?

[elder peak]

also just to add onto this, even if im like 50 blocks above it would still return true (using the mc pathfinder) so i dont think the distance margin is the issue

for whatever reason the minecraft pathfinder just always thinks the npc can navigate to a location

https://cdn.discordapp.com/attachments/448570857917251615/1319886682417270794/2024-12-20_23-37-14.mp4?ex=676797c3&is=67664643&hm=886c472cb2782772ca1cb4a42dc25ebc529f3d856155fdd6c8b7b804916348d9&

the more i experiment the less sense it makes 💀

[heady saddle]

looks like there was a bug with minecraft navigator canNavigateTo, you should download the latest build

[elder peak]

you're a legend... unfortunately that means i have to update to 1.21.4 now i assume 😭

but also, would that be less laggy than a*? im still a little confused on how theyre different

does the minecraft pathfinder not check as many paths as a* does?

[heady saddle]

you would have to update to 1.21.4 first to check that.

[elder peak]

just did

however

i dont think the fix worked

because this should be saying can't navigate

it occasionally flickers and says cant navigate, thats when the server lags out

[thin fable]

just wondering if it saying so is vanilla behaviour

[elder peak]

like i said before, im not against using a* if there was a way for it to not lag out the server. im just confused on how when i run the command to test a* myself theres no lag but when its ran in the trait method there is lag

[elder peak]

i have a feeling this is the case

because a* is always accurate

at least, from my testing

its mc pathfinding that causes the canNavigateTo issue

[thin fable]

the reason I say so is that, for example, will a zombie cancel its navigation to you even you are 3 blocks higher than it?

ofc not as zombie will just keep walking

[heady saddle]

yes, it's vanilla behavior

[elder peak]

yup, i have a feeling its an issue with mc. even the command is saying it can navigate

[elder peak]

i figured

[heady saddle]

minecraft will ignore air blocks and move the target to the highest ground Y

[elder peak]

so i guess i have to use a*

[thin fable]

and also, it is tough to make canNavigateTo return false for MC navigators

[elder peak]

which is fine i just dont know how to make it not lag, even when i drop the iterations all the way down to 50 its still unplayable

[thin fable]

as that is vanilla MC

[thin fable]

then a spark report pls

[heady saddle]

pathfinding every tick is not recommended for a reason

[thin fable]

!spark

[chrome stirrup]

Info: spark

The "timings" system within Spigot/Paper is incredibly inaccurate for use with Citizens, and cannot be used to diagnose any issues related to Citizens. It notably blames Citizens for a significant amount of entity-related lag (that isn't in any way caused by Citizens).

For accurate timings, you need a Java profiler. There are a variety of profiler options (WarmRoast, YourKit, VisualVM, ...), but the simplest to use on a Spigot server is a plugin named "Spark" that embeds WarmRoast, which you can find here: https://www.spigotmc.org/resources/spark.57242/.

To get a spark report, type /spark profiler start, then replicate lag issues (for no more than about a minute), then /spark profiler stop, and post the link it gives you.

[elder peak]

got it will send rn

[elder peak]

yes but the issue persists when doing it even every few seconds

let me show you right now

im going to set the repeat time in the run function of my trait to 40 ticks (2 seconds)

and run a spark report

https://spark.lucko.me/maR41m9TJB

here

thats running every 2 second at the default iter values in the citizens config

[elder peak]

if i were to run this command even more often than every 2 seconds there'd be no lag

thats what im doing right now actually

and just to prove it, here's my spark report when just spamming the command above multiple times per second: https://spark.lucko.me/k7KBkTBG6r

so something is up, i just dont know what

[thin fable]

might be related to NMS -> OBC object wrapping as so many block state OBC objects are created

unfortunately that's what we can't handle from Bukkit API side, might need some deep dig on this. maybe we shouldn't use Bukkit API for pathfinding?

[elder peak]

i mean we're not using it though for pathfinding i thought? im exclusively using citizens's new pathfinder, is that still part of the bukkit api?

[thin fable]

I think that should be solved on Citizens side

ofc not as Citizens have its own API

I'm just saying about ideas that I have for improving on this

[thin fable]

I can't see anything related to pathfinding in this report.

most of the time in that report is used to wait for next tick

[elder peak]

wdym isnt it right here?

[thin fable]

are we did this currently?

[elder peak]

no, its inside a runnable thats running every 2 seconds

the "runnable" being the overridden run function every custom trait has

[thin fable]

well, weird. the full main report doesn't show about that

[elder peak]

you'll find this interesting, the time elapsed is still saying 0 seconds for calculating the path even in the trait class (code just to make sure im not going crazy)

                    long startTime = System.currentTimeMillis();
                    boolean canNavigate = navigator.canNavigateTo(targetLocation);
                    long elapsedTime = (System.currentTimeMillis() - startTime) / 1000;

                    if (targetLocation != null && canNavigate) {
                        debugMessage("NPC can navigate to location. Target type: " + navigator.getTargetType() + " (" + elapsedTime + " sec)");
                        return;
                    } else if (targetLocation != null && !canNavigate) {
                        debugMessage("NPC cannot navigate to location. Target type: " + navigator.getTargetType() + " (" + elapsedTime + " sec)");
                        return;
                    }

[thin fable]

I understand that. Just want to ask fullwall about how we deal with this

[elder peak]

yeah im wondering too

i mean it surely must be me doing something wrong on my end right? because a* pathfinding has been a thing in citizens for ages and im sure the code uses canNavigateTo multiple times, its not supposed to lag the server out like this

[thin fable]

I think that's not your fault

or... both of us have something went wrong

[elder peak]

im just hella confused on why the first spark report is so much more intensive than the second

[heady saddle]

No

[thin fable]

may you use millis as unit?

[heady saddle]

You haven't provided your actual code

Just snippets

Or your config.yml

[elder peak]

i can provide both

give me a sec

https://gist.github.com/advaitdot/c1078d9b734192402de25b5c49adc2c5

https://gist.github.com/advaitdot/cc555faf82bcd88288a646bc21653348

is there anything else i need to send?

pretty much all the relevant code is in the java file

[elder peak]

i guess that adds some level of detail

still though, 9-10 ms average when the server is lagging

sorry for spamming so many images but i also just wanted to confirm we're on the right build of citizens as well

[neat grotto]

Discord Levels Bot

Level up!

Congratulations @elder peak! You're now at level 5!

[elder peak]

this may actually be one of the most confusing coding problems i've ever seen

[thin fable]

I also have no idea currently

[elder peak]

wondering if fullwall may know whats up, i really dont know

@thin fable i think i found the problem...

the trait runnable doesnt run every 2 seconds, it runs like, 2 million times per second

[thin fable]

wHaT?

[elder peak]

bro i have no idea

how is that even possible

[thin fable]

I was remembered that interesting silly "if" which ran for 1 million times in a sec in somewhat game

[elder peak]

does 40 ticks not equal 2 seconds

[thin fable]

ha

[thin fable]

ofc not

[elder peak]

what is going on

i need fullwall back 😭

[thin fable]

Either fullwall and I can't do anything without spark reports and you latest code

and feel free to use our paste

!pastejava

[chrome stirrup]

Info: pastejava

Help us help you by pasting your Java code to https://paste.denizenscript.com/New/Other?selected=other-java and linking it back here.

[elder peak]

i gave you both already no?

[thin fable]

any updates to them?

[elder peak]

no not at all

except that print statement

i can run again if you want but it would have identical results

i mean we found the issue

the question is why is that even happening

i dont even know what this means

am i overriding something thats making it run every tick?

[thin fable]

traits are ticked for every tick, that works as intended isn't it?

[elder peak]

then whats the point of the runnable

[thin fable]

but the runnable shown in your code is not used by your trait?

oh

yes you created the runnable in trait tick

what the hell

[elder peak]

wait am i not supposed to put a runnable inside of it

[thin fable]

yes

if you put runnable in ticks then you'll get more and more tasks ran on your server

it is impossible to have no lag

[elder peak]

bro why is there even a runnable there

when did i put that there

oh im actually an idiot then

[thin fable]

IDK why you're asking me about your own code

[elder peak]

that means its making a new runnable every tick which repeats itself every 2 seconds

no wonder its lagging

[thin fable]

yes

you created repeat runnables every tick and they never dies

[elder peak]

i swear i saw somewhere you were supposed to put a runnable inside of it idk why 😭

let me remove that then

[thin fable]

you should move it to somewhere like onAttach

and cancel the task onDetach

[elder peak]

im assuming its still going to lag even with it removed though

[thin fable]

hmm I think onSpawn is better to place tasks

[elder peak]

bc its still every tick

ohh

you mean like put the runnable code in onSpawn or somewhere like that

i see

[thin fable]

I recommend onSpawn as it only calls when NPC spawns and navigator should be available for use at this time

[elder peak]

i agree let me test that

[thin fable]

so you don't have duplicate and infinite garbage tasks

[thin fable]

remember to update your plugin on your test server

[elder peak]

yea ofc

[thin fable]

so funny and time-wasting as I've not read your code carefully lol

[elder peak]

works perfectly even when running every 10 ticks

thank you so much i have no idea how i missed that

[thin fable]

lagging is solved so... next question is about MC impl for canNavigateTo, maybe we'll have to leave this to fullwall

[elder peak]

yup, i think fullwall can take a look at that when he wants, assuming it even needs fixing. but personally i think the name is misleading

if that does work as intended i would at the very least change the method name

thanks y'all, going to close this thread but ill definitely be back lol. working on a massive project that uses citizens so im sure ill have more questions

[thin fable]

that's ok! feel free to ask question when you need

you can close this if you're all good
