Finite State Machine Implementations

[severe kindle]

As an exercise I wrote out 3 broad categories of ways I can see someone handling a FSM.

1. match statement
2. dictionary or array
3. polymorphism with states as objects

I am curious if there are other strategies not listed here, or which of these patterns people feel are generally better?

[stray comet]

I always will prefer ENUM vs String to check the status, because the String isn't checkable from the builder process, but the ENUM it is! 😉

Also for the "polymorphism" method, I'll prefer write a static base class with an empty method, and inherit a new static class for any new status (implementing the right method).

PS: using static classes, you haven't the need to create a new object to use a new status!

[glad niche]

If I did
enum {CONST1, CONST2, etc}
how/when do I assign values to them? or I don't?

[stray comet]

Take a look here (at the "Enum" section)... https://docs.godotengine.org/en/stable/tutorials/scripting/gdscript/gdscript_basics.html#enums

[glad niche]

Yeah I just did, thanks

[stray comet]

You are welcome 👍

[dawn bobcat]

Thanks

Good reference for me as well

[stray comet]

Happy to can help 👍

[dawn bobcat]

[ember prism]

Very nice! Lately, I've been a fan of shaggydev's advanced state machine https://youtu.be/DPxIMVC0oZA?si=vu8hsPc3sK9eHHPw (source code link in the description -- its for Godot 3, but it's just a skeleton so it's easy to port). I've used variations of it for a few projects now. At first, it seemed unnecessarily complicated with all the inheritance and export variables, but I've found I actually spend way less time on both setup and debugging than simpler state machine implementations I've used.

[stray comet]

Thank you, I'll take a look.

[exotic sky]

It depends on the complexity of the project. I think a good solution for an advanced state machine is something like this: https://gitlab.com/atnb/xsm

[dawn bobcat]

I'll take a look

[tight fossil]

I've made one based on Resources recently. Has the charm of being expanded on without having to touch code.

[stray comet]

Really interesting, can you Expose the idea?

[tight fossil]

Basically, I create 3 Resources:

• State
• Condition
• Transition

State is basically just a Resource with a text var that contains the name of the state. But of course you can expand on it, add variables with values for that state, for example.

Condition could be empty, as it's mainly the name of the resource itself that's interesting, but the way I've built it, I added a text var with a name, so I could push a condition to the state machine by name, not just by having a reference to the resource, so then I compare the condition text rather than the condition itself.

Transitions are a resource that combine the 2 above:

• from: State
• condition: Condition
• to: State

The state machine itself has an export Array[State] and an export Array[Transition]. I can create my states, conditions and transitions either directly in the inspector or save them locally then drag them into the arrays. I then send either a Condition or a string to the state machine and it looks through its list to see if it has a matching pair of from and condition, then it executes the transition and emits signals based on that. I use 3 signals for that: StartState, RunState, EndState, so I can have a bit of setup and cleanup, when necessary.

I can show you the project if you like, once I'm back at my home pc.

[glad niche]

ok show me too ?

[ember prism]

Interesting! I use resources for things like physics variables, which vary by state, but haven't tried using resources to manage the switching logic. Seems like it provides a nice standardized way of managing external communications

[stray comet]

Yes please, a demo project. 😉

[tight fossil]

Cleaned up a bit and uploaded it. If you have questions, ask away.
https://github.com/pkiesshauer/GodotResourceFSM

@stray comet @ember prism @glad niche

[stray comet]

Thanks a lot 🙂

[glad niche]

can you explain ?

how can I use this ?

[tight fossil]

I've added an example scene, have you looked into it?

[glad niche]

yes I did

I looked at the code

[tight fossil]

Well, the example scene uses the PlayerFSM.tres, a finite state machine that's created using the conditions, states and transitions created in the folder. The buttons push a condition to the FSM, the label listens to the change of the state and displays the state name.
You can use this kind of setup to communicate the states of a larger system between the components of that system.
How you use it eventually would be dependent on what kind of problem you're trying to solve.

[severe kindle]

Not to necro this post but I just realized this is probably an even easier method for handling state delegation if you want to stick to using a single script, rather than splitting it up into a bunch of different classes and stuff

All the array/dictionary stuff is pointless if you're just using callables anyways
