sovol sv06 ace MCU error

[hidden tartan]

printer stops mid print and gives this error, im not sure what it means and i have tried factory resetting and clearing out the system storage multipule times

[frosty light]

Is the fan in the large black control box on the left and right running when you turn the printer on or run a print?
(Motherboard box)

[hidden tartan]

I think so?

How come?

[frosty light]

And check all the cables are plugged in all the way by pushing them in (WHILE POWER IS OFF)

Otherwise might be klipper related... 🤔

The mcu \ cpu is the brain of the printer.
If it overheats, you can get errors. (But theres other reasons too)

The thing your trying to print....is it round or circular by any chance?

[hidden tartan]

Sorta round

It's a split keyboard case

[frosty light]

Oh! Ok so really shouldnt be a massive issue.

Used be an issue when you'd send lots of g1 one commands to a weaker mcu (so the solution was to enable arc moves in the slicer to send g2(?) g3 commands (?) instead and thus reduce the amount of processing needed.

[hidden tartan]

should i try a test print first to make sure its not a hardware issue?

i didnt mean to delete that message 😐

anyways, i think i could be a klipper issue because its not connecting from my browser

[frosty light]

I don't there would be much hardware related to the issues except heat and cabling...
But you can try a really high res cylinder without arc moves on maybe? That should hammer the mcu + in theory reliably trigger the message (this is a guess)

Klipper usually has a log file you can pull and look at.

[hidden tartan]

sure but if it is of any relevance here is what im trying to print

you can see its pretty detailed, that might be part of it

[frosty light]

Dactyl manuform?
Yeah but that shouldnt be triggering an error even though.

If you restart the printer, and download the klippy.log (i think) it might say something? (And other with more klipper knowlegde can then help)

[hidden tartan]

dactyl scylla but yes

im trying a benchy just to see if its a gcode issue or a hardware issue,

after that ill check the logs

[hidden tartan]

benchy was flawless, must be a gcode issue

[thorny bear]

https://forum.sovol3d.com/t/shutdown-mid-print-mcu-shutdown-move-queue-overflow/6374/10 maybe this

[hidden tartan]

ill look at this tomorrow, its late here. thanks

[slender skiff]

This post has been closed due to inactivity.

This post has been inactive for over 1 hour and so has been closed. To reopen this post simply send another message.

[hidden tartan]

ok, sorry for the late reply but i have not been at the computer for the past few days so i am just not getting to this

ok, ive sshed into the printer but i do not think the code is the same as the sv08s

yeah, not sure what to do here

[slender skiff]

This post has been closed due to inactivity.

This post has been inactive for over 1 hour and so has been closed. To reopen this post simply send another message.

[lost dew]

thats a local IP, local ones can change day to day

[hidden tartan]

pretty sure its a static ip

[lost dew]

you set it in your router?

[hidden tartan]

well

i have the IP bookmarked and 90% of the time it works

i didnt set it in my router, i think it sets itself automatically

[lost dew]

it does set automaticaly, i guess it set itself to the same thing for a long time, but without a static set from the router it can change

IE you dont use it or a day, some other thing gets the IP and then it cant set the same

and i would expect the UI to load in the first place if the IP was right, regardless of the klipper error

[hidden tartan]

every once in awhile it doesnt load

not really the main issue for me right now, its working flawlessly right now

webcam is working too

[hidden tartan]

im hesitant to try printing it again considering this didnt work and i havent made any other changes

im wondering if there are any gcode optimizations i should be making in orca slicer

[lost dew]

whats the resolution and is arc fitting on in quality/precision?

[hidden tartan]

.16 i think? i didnt change anything related to arc fitting

i mostly use the default settings given

i may aswell just reslice it though, i dont have the project file saved

how would arc fitting benefit me here?

[lost dew]

it wouldnt with klipper

and .16 is fine, even probably rough, it makes the moves larger and easier to parse

.016 would probably also be fine

[hidden tartan]

¯_(ツ)_/¯

i hope this isnt some deeper issue, i do not think its a hardware issue because i printed a benchy flawlessly a few days ago

maybe i should be keeping an eye on the cpu and ram when its printing

[lost dew]

you slice the benchy? also dont think its a gcode issue off that

though dont really know if there is some config issue with the ace that would cause that

[hidden tartan]

i am pretty sure i reset all of the configs not that long ago

my firmware should be up to date aswell

[lost dew]

ah, sovol messed up klipper, its trying to save after every G1 command https://forum.sovol3d.com/t/shutdown-mid-print-mcu-shutdown-move-queue-overflow/6374/10

klipper doesnt really need power loss, and it causes much more errors than it solves

[hidden tartan]

i looked at that before but the code between the sv08 and the sv06 ace is not the same, i could send the gcode_main.py here if its of any use

im not smart enough to know what that file does on its own lol

[lost dew]

is that part from the link not in there?

[hidden tartan]

its not

some parts are similar but this part is not

[lost dew]

any rename_existing or gcode_macro with a G1 in it?

[hidden tartan]

one sec

ill send it here

[lost dew]

not seeing any issues with that myself either

[hidden tartan]

yeah im clueless honestly
