How to deal with pattern matching when procedurally generating chunks

[stone sigil]

Hi everyone,

I'm not sure if this should go here, but as I still consider myself as a beginner, I will open a post here.
I'm trying to procedurally generate a 2D terrain with a tilemap, I successfully done it with a simple tileset (with chunks), but now I want to introduce my own tileset which has terrain options for auto placing specific tiles when I place a type of tile.
I can clearly see big freezes when I'm trying this (below in my code), where I just generate the final tiles at the end of each chunk generation. Do you know how should I implement it, so it's correctly optimal ?

Thank you !

We can't send pieces of code ?

So the part of code where I generate my chunk (assuming I'm generating it when it's necessary):

func generate_chunk(chunk_pos : Vector2i) -> void:

    var tiles : Dictionary = {"dirt":[], "water":[], "grass":[]}

    for y in range(width):
        for x in range(height):
            var noise_pos : Vector2 = Vector2i(x, y) + chunk_pos * 32
            var noise_val : float = abs(noise.get_noise_2d(noise_pos.x, noise_pos.y))
            if noise_val < 0.1:
                tiles["water"].append(chunk_pos * 32 + Vector2i(x, y))
            elif noise_val < 0.15:
                tiles["dirt"].append(chunk_pos * 32 + Vector2i(x, y))
            else:
                tiles["grass"].append(chunk_pos * 32 + Vector2i(x, y))

    groundLayer.set_cells_terrain_connect(tiles["dirt"],0,0)
    groundLayer.set_cells_terrain_connect(tiles["grass"],0,1)
    groundLayer.set_cells_terrain_connect(tiles["water"],0,2)

And this is how chunk generation is handled each frame :

func _process(delta : float) -> void:
    var cam_pos : Vector2i = camera.position / (32 * 16)
    var chunk_loaded : Array = []

    for i in range(-3, 4):
        for j in range(-2, 3):
            if Vector2i(i, j) + cam_pos not in chunks.keys():
                generate_chunk(Vector2i(i, j) + cam_pos)
                chunks[Vector2i(i, j) + cam_pos] = Chunk.new(Vector2i(i, j) + cam_pos)
            chunk_loaded.append(Vector2i(i, j) + cam_pos)

    for key in chunks.keys():
        if key not in chunk_loaded:
            remove_chunk(chunks[key])
            chunks.erase(key)

[tribal spear]

Haven't used it myself but have seen this recommended often when it comes to those issues
https://github.com/Portponky/better-terrain

[stone sigil]

So I'm using it and I still get lags, because I use BetterTerrain.update_terrain_something to update the tiles in a specific area (here for each chunk). But it's still laggy, I'm pretty sure I'm doing it wrong.

[torpid moon]

You probably shouldn't call it often, if that's what you're doing.
If you're doing this in a large area, do it during a loading screen. That is what those are for.

[tribal spear]

I recommend reading through the plugins documentation, open and closed issues and if you still dont have a clue open a new issue.
The plugin dev seems a likely person to get a good answer from

[stone sigil]

I can't, as the chunk are generated based on where the player is.

[stone sigil]

I don't think it's necessary, it's not a bug or missconception, just maybe I don't do it the right way.

[torpid moon]

Assuming you're only doing the necessary updates. The next thing to try is to space the updates accross frames.

[stone sigil]

wdym ?

[torpid moon]

Like, in the loop that places the tiles.
Make it stop after X time passes, then resume the next frame.

It is a bit risky, but you can synch it up with signals like get_tree().physics_frame

[stone sigil]

I never heard about this method, before that I wasn't using a game engine for my game, so I implemented myself the pattern matching system based on the saved datas from Tiled, it wasn't laggy when I generated a chunk, Idk how they do it. 🤔

[torpid moon]

There's quite the difference between just moving a couple numbers and strings around vs all the work an engine puts on top. Like the rendering.

Optimization is almost always complicated.

There's probably some tutorials online on how to handle chunking of data more performantly.

[stone sigil]

yes, for me to see 0.5s of freeze, it seems a bit weird, without terrain connection, the game is perfectly fine, maybe I need to turn myself to threads ?

[tribal spear]

some of the meganodes in godot cant really run on a thread, or at least not efficiently. Iirc TileMap is - or was - one of them but the better terrain plugin offered this functionality.

[stone sigil]

I just need to find someoe who procedurally generated infinite 2D map, using terrain to connect their tiles.

[harsh meteor]

Have you profiled your code? I understand the slowdown is coming from tilemap stuff, but you shouldn't be speculating what precisely is causing the slowdown

[stone sigil]

I'm not speculating

If you comment the part where I connect the tiles (outside the loop), it runs normally

A bit strange that nobody ever complained about performance problems when connecting tiles 🤔

[harsh meteor]

There's been plenty of complaints, don't worry. I believe that set_cells_terrain_connect is the problem part, although I suggest using the profiler next time, not just commenting code/evaluating freeze.

Personally, I use BetterTerrain, and it's significantly better than default godot implementation. It has a threaded terrain update method as well, I suggest you look at that.

Aside from that, your options are either: not using terrain and having a custom tile solver or using gdextension to make a faster c++ implementation. There is a BetterTerrain gdextension version, but it hasn't been updated in a bit, and won't work with tilemaplayers
