So, mostly build my box turtle and now on the hardest part... the flashing.
I've followed step by step, when I get the getting the UUID to move onto the next stage, it says 0 uuids, which everything else looks like it's worked.
Voron 2.4 fysetc spider v3, using mellow can expander as already have can set up for toolhead.
Any assistance would be great
final quartz
Yep, now we can keep working on this
AFC Lite should be flashed as long as you followed the instructions given by Isik.
What I wanted to know was which port on the CAN expander you have what plugged into
Becuase it'll matter for terminating the CAN chain
final quartz
So, you have a 120ohm jumper on both your toolhead and on your U2C, right?
dreamy zephyr
Not on the toolhead, should I have one there?
dreamy zephyr
So, you have a 120ohm jumper on both your toolhead and on your U2C, right?
I have just checked and yes there is one on the toolhead
dreamy zephyr
@mild saffron hi, i saw that you assisted someone with similar issue to me.. hoping you could assist?
<@&1304550334839918672>
abstract sierra
As long as it ssays "Download Done" its generally successful
dreamy zephyr
i just cant get the UUID
abstract sierra
There is a known issue with dfu util that displays errors even when successful
dreamy zephyr
to move onto next step
abstract sierra
Dumb question but the switch is on buck,correct?
dreamy zephyr
yeah
abstract sierra
Just checking, it will show up for flashing on USB but not anything else.
abstract sierra
Im just working though possibilites as to why its not showing up,
Can you show me the settings you flashed katapult with please?
dreamy zephyr
Will have to send over later as I've had to pop out. I've even tried flashing with usb. I might even just use usb instead of can
abstract sierra
USB is super EZ tbh lol
Im running mine on USB as I dont have any can in my printer at all
final quartz
I’m running 2 on US … about to set them up as CAN because I have a 3rd to add to the mix…
dreamy zephyr
@sand wasp I believe that you are using the fysetc spider v3 board. Did you have any issues with flashing the afc lite?
sand wasp
<@1157657566239797288> I believe that you are using the fysetc spider v3 board. ...
I have a U2C on the AFC, I couldn’t connect to it from the spider for reasons I don’t know 🤷🏼♂️ the rest of my can works via the Spider fine.
dreamy zephyr
I have a U2C on the AFC, I couldn’t connect to it from the spider for reasons I ...
im using a mellow can expander which is working as i now have my toolhead connected to it and works fine
sand wasp
Yea I dont know why it’s that way, it would probably work at 50k baud but I’ve not tested it
dreamy zephyr
<@&1304550334839918672> anyone who could assist as this is bothering me#
final quartz
I'm reading more on the CAN wiring, since I know fuck all about it lol
But since your query sees neither of you CAN devices now, something is weird
atomic timber
Sorry haven’t been following this but I just flashed my board this morning. Did you use this guide? #isiks-tech-🇺🇸-✈🌎 message
You don’t need usb to flash CAN
final quartz
Okay, so after some reading, remove the 120r from your U2C and put one on the AFC-Lite
dreamy zephyr
i dont have a U2C, my mainboard is fysetc spider v3 with can already on the board
final quartz
Should still have a 120r jumper on it
dreamy zephyr
Sorry haven’t been following this but I just flashed my board this morning. Did ...
yeah been using that but it says to use usb
atomic timber
dreamy zephyr
Should still have a 120r jumper on it
ive looked and cant see one
atomic timber
Follow this exact and share screen shots of the results
dreamy zephyr
Follow this exact and share screen shots of the results
its asking for github username? is this correct?
atomic timber
Screen capture?
dreamy zephyr
thinkg its already installed?
should i be using cd ~/klipper instead of just ~/klipper
atomic timber
just do: cd klipper
dreamy zephyr
my can pin on my board is different to the PB8 PB9, do i leave or change to the ones from my main board
followed word for word and still nothing
my afc lite is only connected to power and can, no usb
atomic timber
my can pin on my board is different to the PB8 PB9, do i leave or change to the ...
Did you leave it?
dreamy zephyr
no changed to my pins
atomic timber
Leave the pins per the instructions
dreamy zephyr
should i be un plugging my main board or will it be fine
atomic timber
Should be fine. Did you flash katapult first or are you going straight to klipper?
dreamy zephyr
i cant flash klipper as i dont have my UUID
atomic timber
Did you press the reset button twice?
dreamy zephyr
Did you press the reset button twice?
yeah, the instructions vary compared to the manual from the github
dreamy zephyr
dont know what im doing wrong
wraith fern
did you try the katapult query? Ive had in not show up using the klipper one before
<@&1304550334839918672> ive tried what i believe is all options, I have checked my wires and all is fine. for some reason i just dont get a UUID, has this been common? will try anything to get this thing working
final quartz
You aren't finding any CAN devices now
atomic timber
Maybe you’ve already tried this. Do you have your can high and low correct?
final quartz
Your toolhead isn't showing either, please make sure the network is terminated correctly
mild saffron
well, the toolhead wont'show if klipper has 'claimed' it/is working.
wraith fern
run
ip -details -statistics link show can0```have to kill klipper, then reset the toolhead board
or mv printer.cfg out of hte way and reboot hte system
dreamy zephyr
have to kill klipper, then reset the toolhead board
or mv printer.cfg out of ht...
I would ideally want to avoid redoing can on my toolhead as that was a night mare too.
What is the best way. Am I better off just using usb
mild saffron
you wouldn't have to touch can on your toolhead
when i say rest, i just mean literally hit the reset button which reboots the board
not 'wipe adn reset'
dreamy zephyr
not 'wipe adn reset'
Is there any way for me to remove clipper from the afc board, I've read something that says if klipper is installed then it won't show the uuid as its claimed. I did manage to flash klipper using usb and think this may be causing the issue
mild saffron
what it means by that is if it's if you have the uuid in the klipper.cfg and it's detected/working
not that if klipper has been flasehd to the board
wraith fern
Run my command above so we can see the can0 network info
dreamy zephyr
run
```
ip -details -statistics link show can0```
wraith fern
i would re-setup the can0 network using esoteric guide. Ideally you want that qlen at 1024
https://canbus.esoterical.online/Getting_Started.html
dreamy zephyr
i would re-setup the can0 network using esoteric guide. Ideally you want that ql...
done that and still the same...
dreamy zephyr
i would re-setup the can0 network using esoteric guide. Ideally you want that ql...
i have a fysetc spider v3 main board which i belive has the 120 resistor fused to the board. i have a mellow can expander which obviously goes from my main board and then has can for my tool head and for my afc lite connected. i have 120 resistor on the toolhead and also on my afc, could this be the issue? do i need to remove one of the 120 ohm
wraith fern
do you have a voltmeter you could test the can lines?
power it off and ohm test the can h/l lines and see if you are getting 60 ohms
dreamy zephyr
power it off and ohm test the can h/l lines and see if you are getting 60 ohms
do i check each line singular
wraith fern
to test across them connect one to h and one to l
wraith fern
k try taking the 120 off the afc and test again
dreamy zephyr
with it off the afc it shows 60
wraith fern
ok boot it up and try that
dreamy zephyr
with out it on
wraith fern
ya you want it at 60 ohms
dreamy zephyr
wish me luck
wraith fern
🤞
abstract sierra
Coule it be something with the expander making it not seeing it as one network perhaps?
abstract sierra
So you added the expanded when you addded the AFC or it has always been there?
dreamy zephyr
added when added afc
but my toolhead still works fine and that is connected to the mellow expander
abstract sierra
Just out of curiosity have you tried putting the resistor on the AFC and not the tool head?
dreamy zephyr
not tried that yet
wraith fern
hes getting 60 ohm on the can lines so should be fine
dreamy zephyr
you think its worth the swap?
wraith fern
can i see your katapult build settings
abstract sierra
Seeing tons of reports of CAN issues with spider v3
wraith fern
i would build and flash katapult first
dreamy zephyr
was just following the instructions in order
shall i reboot and do the katapult first?
wraith fern
dreamy zephyr
abstract sierra
correct me if im wrong, but katapult doesnt need the bootloader offset?
wraith fern
only thing to watch is when you copy the flash command this is what you need to run
sudo dfu-util -a 0 -d 0483:df11 --dfuse-address 0x08000000:leave -D out/canboot.bin```
Set canbus to PB8/PB9yes it does the above image i posted is from isiks guide
dreamy zephyr
only thing to watch is when you copy the flash command this is what you need to ...
my board pins are pd0 / pd1 for the fysetc spider v3
wraith fern
these are the can bus pins on the afc
abstract sierra
my board pins are pd0 / pd1 for the fysetc spider v3
youre flashing the afc tho
dreamy zephyr
ah okay, i thought that was where the afc would look to where its connected on the main board.
abstract sierra
Youre telling it where it should talk to the can network from
dreamy zephyr
okay changed, will see what happens
wraith fern
after you flash that run
python3 ~/katapult/scripts/flashtool.py -i can0 -q
should see a uuid and application: Katapult
dreamy zephyr
do i need to sudo service klipper stop first?
wraith fern
no it wont register to klipper
wraith fern
ok try a full shutdown
Shut down your Pi (sudo shutdown now) and then power off your entire printer then restart and run that again and see if it shows
dreamy zephyr
what just run the 'python3 ~/katapult/scripts/flashtool.py -i can0 -q'
wraith fern
ya after a reboot to see if it shows up
dreamy zephyr
same again
are my only options to use usb instead of can?
this is info from my toolhead on mainsail, shall i change bitrate to 500000 to see if this works?
wraith fern
yes that means you mainboard is likely also 500000. Rebuild katapult with 500000 and flash with this command
sudo dfu-util -R -a 0 -s 0x08000000:force:mass-erase:leave -D ~/katapult/out/katapult.bin -d 0483:df11
done, now reboot?
wraith fern
yup then see if it shows this time
wraith fern
awesome! now just make sure to build the klipper with the 500000 then flash with
python3 ~/katapult/scripts/flashtool.py -i can0 -u youruuid -f ~/klipper/out/klipper.bin
replace youruuid with the d5fa36de5f65
dreamy zephyr
do i need to stop klipper before i flash?
wraith fern
ya
dreamy zephyr
wraith fern
after that run that flashtool query command again and it should say klipper instead of katapult
dreamy zephyr
now need to add the afc add on... will this be easy enough?
wraith fern
ya it has an auto installer that walks you though the install then you just need to go put in this uuid for the afc
wraith fern
no thats the pin for your toolhead sensor
uuid you put in manually into the config after the install is done
wraith fern
do you have a toolhead filament sensor?
wraith fern
ok you will need one either in the toolhead or you can use a small inline one right above the toolhead
https://github.com/ArmoredTurtle/Filatector this one can go inline right above the toolhead.
dreamy zephyr
man would have been sorted, i have a spare d2f switch but dont have any of those ones
dreamy zephyr
https://github.com/ArmoredTurtle/Filatector this one can go inline right above t...
i have stealthburner with CW2, is there a part a i could to put into the toolhead
wraith fern
yes there are a couple versions. are you planning on running a toolhead cutter?
dreamy zephyr
no i was planning to do the snappy hub, however if im changing the toolhead i may as well look into the other
@wraith fern massive thanks for you help. i would have just given up if not for your assistance
wraith fern
Of course. Glad we got it sorted for ya.
