I'm still on the repo one
#RenoDX: Wuthering Waves
misty brook
autumn jetty
I play with ktm on, and screen grading strength 0
peak geyser
Who has the good KTM=off settings for Reno??
subtle warren
Guys, do I enable dump LUT shaders on renodx?
peak geyser
This is with 50/50/50 in game, right?
subtle warren
Ah ok
subtle warren
Did you guys notice when landing final blows while attacking? The hdr breaks for a little second
no
wait wdym?
@tough ember
Okay hold on
frank heart
https://tenor.com/view/another-one-and-another-one-gif-13250129
it's gonna happen
again
and again
and again
@autumn jetty mind pinning this #1383049193186136216 message
subtle warren
@autumn jetty
subtle warren
kuro off and yea i raised them a little
these are spiwar settings
raised them a little
peak geyser
60?
subtle warren
Yup
frank heart
i dont use these anymore
subtle warren
i dont use these anymore
what do you use now?
subtle warren
def better! but shadows need to be raised a little, maybe its bc im on qd oled
@frank heart
frank heart
sounds like your display is shadow crushed
it being QD OLED is unrelated
this is also the exact same shadow amount as the last preset
subtle warren
this is also the exact same shadow amount as the last preset
Then what's up this time?
Why my shadows are so crushed?
frank heart
thats your problem
frank heart
look at the settings before
60 highlights 50 shadows 60 contrast
look at the settings i linked
60 highlights 50 shadows 60 contrast
if your display is crushing
just raise shadow to compensate
subtle warren
I put shadow at 60
visual sand
Oh wow that was fast
frank heart
looks like its broken
clamping
kurotonemapping strength 0 makes the game unclamp again
cosmic hearth
Kuro Games Tonemapping
How should I test it
Just now, I manipulated it, but there was no response and it didn't work
Do I need to turn off kuro tone mapping?
cosmic hearth
OK
astral night
i'll bring it up at the next meeting of the council
i forwarded to admin/mod chat.
we'll debate and holler over it
basically comes down to finding a reliable bot
we have two already
empty coralBOT
The == prefix is a shortcut for the =calc command.
For information on how to use the bot, type =help.
For information on how to use the =calc, command, type =help calc.
Parse error
On line 1 at position 1
=help
^
Parse error
On line 1 at position 1
=help calc
^
frank heart
Think you might have got it if u fix the clamping situation when strength is past a certain threshold
astral night
beware piecewise, be sure to plot them and not go by visuals alone
frank heart
kk
astral night
basically by hand, unforunately
i think it's a common format it supports, maybe latex?
outer jackal
where to get renodx wuwa?
astral night
i essentially use long variable names v_blahblah
we're not animals, we use maths and stuff
3d desmos is even cooler https://www.desmos.com/3d/lphbx1ecxx
cosmic hearth
🥵
subtle warren
@frank heart bro, I tried to load à shader on special K but it says failed to compile
any idea
?
peak geyser
A shader??
subtle warren
A shader??
An effect
peak geyser
I've had that happen before. But it just fixed itself with a game restart.
subtle warren
Yeah but not mine idk why
peak geyser
idk. I've never had one error out on me. Unless it just wasn't compatible with a particular game.
Maybe google the issue in a general sense. Don't mention WuWa.
subtle warren
Any way to use rcas on wuwa with special K?
astral night
both
i mean
it should only relate to tonemapping though
float3 color_untonemapped,
float3 color_tonemapped,
float3 color_tonemapped_graded,
basically it takes computes the delta of untonemapped / tonemapped and applies that delta to tonemapped_graded
midgray has to be adjusted but that's it
tonemapped means "goes to sdr"
contrast and brightness and bloom aren't tonemapping
so if it does extra exposure, or contrast, or adds on bloom, then it's still in HDR state (untonemapped)
the problem is when it compresses down to 1 (SDR)
you basically want it before it goes to sdr
so last time
UpgradeToneMap can be understood as "let's upgrade their sdr tonemapping to an hdr one"
or basically strip the SDRifying of the tonemapper, but still retain whatever is does it with colors
including if it uses a SDR lut on the SDR tonemap
so imagine
- render output
- render output + bloom (untonemapped)
- tonemap to sdr
- apply SDR contrast
- apply SDR LUT color filter
- apply grayscale
- output sdr (tonemapped_sdr_graded)
You'll have to construct your own neutral SDR tonemap from untonemapped, for example, ToneMapPass uses a generic, reinhard-based neutral SDR tonemap.
basically that means whatever is different between neutral sdr tonemap and the game's final sdr output is just the "look" which we try to apply back to untonemapped
LUT in this case is coloring, contrast, brightness, saturation etc
it makes a bit more sense if you pick apart ToneMapPass
because it says
float3 ComputeUntonemappedGraded(float3 untonemapped, float3 graded_sdr_color, float3 neutral_sdr_color, Config config) {
[branch]
if (config.color_grade_strength == 0) {
return untonemapped;
} else {
if (config.per_channel_blowout_restoration != 0.f
|| config.per_channel_hue_correction != 0.f
|| config.per_channel_chrominance_correction != 0.f) {
graded_sdr_color = ApplyPerChannelCorrection(
untonemapped,
graded_sdr_color,
config.per_channel_blowout_restoration,
config.per_channel_hue_correction,
config.per_channel_chrominance_correction);
}
return renodx::tonemap::UpgradeToneMap(
untonemapped,
neutral_sdr_color,
graded_sdr_color,
config.color_grade_strength,
config.tone_map_pass_autocorrection);
}
}
ComputeUntonemappedGraded is just UpgradeToneMap
but the intent is more obvious in terms of function naming
it depends on the intent really. upgradetonemap is pretty versatile, it doesn't technically have to be hdr/sdr
yeah, upgradetonemap we use even for untonemapped and ACES 1000, because it's just a delta computing system
but tonemappass itself has extra code to compute a neutral SDR for you
via this
float3 ComputeUntonemappedGraded(float3 untonemapped, float3 graded_sdr_color, Config config) {
[branch]
if (config.color_grade_strength == 0) {
return untonemapped;
} else {
return ComputeUntonemappedGraded(
untonemapped,
graded_sdr_color,
renodx::tonemap::renodrt::NeutralSDR(untonemapped),
config);
}
}
neutral sdr is basically like, the most generic least opiniated tonemap you can get, which is reinhard. ToneMapPass/ComputeUntonemappedGraded still heavily expects that the SDR tonemap has some familiarity to with reinhard it
if the SDR tonemap is insane, then upgradetonemap might not work
you don't have to do tonemap if you replace the vanilla tonemapper though
we used to build replacements for vanilla tonemappers by hand and building our own renodrt profiles
er, do the multiparameter tonemappass/upgradetonemap
what tonemappass does is applies contrast and style just like the sdr tonemap (eg: uncharted2) does, and applies that to untonemapped. then it calls a for a neutral tonemap (renodrt-reinhard) with everything 50, meaning do near nothing
instead you can try to build a replacement tonemapper (eg: for uncharted2) with the renodrt parameters, which is a scalable, varialbe peak tonemapper (can be sdr or hdr)
that's what i mean by matching
batmanak has that evolution
where we matched their uncharted2 for a while and then just ended up with tonemappass
float renoDRTContrast = 1.12f;
float renoDRTFlare = lerp(0, 0.10, pow(RENODX_TONE_MAP_FLARE, 10.f));
float renoDRTShadows = 1.f;
float renoDRTBlowout = RENODX_TONE_MAP_BLOWOUT;
float renoDRTHighlights = 1.02f;
float RenoDRTSaturation = 1.1f;
upgradetonemap is "i don't want to manually try to match their tonemapper, just compute the delta from a neutral tonemap"
the other is "i'm going to replace their sdr-only tonemapper with renodrt using custom numbers and it'll be a scalable tonemapper"
when the game has variable tonemapping over cbuffers, or a baked LUT that tonemaps (a black box), then computing a delta is your best option
when it's a fixed tonemapper, then just throw out theirs and match it for best results
or just get lazy and tonemappass anyway
if you replace their tonemapper, you don't need an SDR reference
though that also depends if the game has SDR effects
for example in zelda, i just threw out their tonemapper and just made my own
which ends being close enough
frank heart
Based
astral night
the only use i had for the vanilla tonemap was how it messed with midgray
so i pass midgray (0.18) to their tonemapper and what comes out is how much i have to adjust untonemap's midgray
yeah, zelda's clips and crushes
musa was showing hitman and he throw out their tonemapper, i'm sure
maybe just use it for midgray
float vanilla_mid_gray =
HejlDawsonCustom(0.18f, fp_c1_1._m0[0].x, fp_c1_1._m0[0].y); // 0.225f
HejlDawsonCustom being the vanilla tonemapper
i pass 0.18 to get what vanilla would have done with midgray
some rely on the tonemapper to also adjust midgray as well
sign of bad tonemappers, imo
yeah, though that also brings in the complexity of tonemappers that heavily hue shift because they're per channel
which is also why tonemappass has ApplyPerChannelCorrection
because the neutral tonemapper doesn't modify the color of things, but vanilla's tonemapper might do wild things with hues
frank heart
thats one of the sliders exposed right
astral night
and then they rely on their broken tonemapper by inversely breaking their textures so the output is correct (eg: they hardcode flames to be pink in textures so their tonemapper breaks it into the yellow they want)
frank heart
Per channel correction
astral night
scene grading is color_grade_strength, so if you remove the sdr reference it's just a neutral tonemap. and if sdr did basically nothing to image (rare) then you're just showing untonemapped with neutral a tonemap
if (config.color_grade_strength == 0) {
return untonemapped;
} else {
then the sdr_color doesn't have per channel hue shifts, or enough to notice
the more contrast a per channel tonemapper has, exponentially the more it shifts and blows out
a pretty tame per channel tonemapper will shift less
it's a nightmare to work with per channel, i don't get how devs do it. colors change because contrast changes and then you have to redo your textures
which is why all UE games end up looking the same, because the textures and texture sets they use are all built for one specific tonemapped look
i think kurotonemapping is in the output shaders, but i never checked
there's like 3 different tonemapping branches in there
frank heart
i think kurotonemapping is in the output shaders, but i never checked
Its in the output shader yeah
astral night
i think it does both theirs and then ue as well
because the output shader still samples the LUTBuilder, which houses the filmic tonemapper
frank heart
Shortfuse is probably right
Cause the kurotonemapping sliders u make
Still work
With kurotonemapping off
astral night
if (RENODX_TONE_MAP_TYPE != 0.f) {
r0.xyz = max(0, r0.xyz);
r0.xyz = renodx::tonemap::UpgradeToneMap(
untonemapped,
renodx::tonemap::renodrt::NeutralSDR(r0.xyz), // Intentional
r0.xyz, 1.f);
}
r0.xyz = float3(0.00266771927, 0.00266771927, 0.00266771927) + r0.xyz;
r0.xyz = log2(r0.xyz);
r0.xyz = saturate(r0.xyz * float3(0.0714285746, 0.0714285746, 0.0714285746) + float3(0.610726953, 0.610726953, 0.610726953));
r0.xyz = r0.xyz * float3(0.96875, 0.96875, 0.96875) + float3(0.015625, 0.015625, 0.015625);
r0.xyz = t2.Sample(s2_s, r0.xyz).xyz; // SAMPLE LUT BUILDER
r0.xyz = float3(1.04999995, 1.04999995, 1.04999995) * r0.xyz;
the game actually sends SDR to get tonemapped again
it double tonemaps
frank heart
🤣
I guess if you turn kurotonemapping off theres no more double tonemapping and thats why all the per channel correction sliders start working again?
astral night
i guess i don't per channel fix their kurotonemapping
probably should
would be before ```cpp
r0.xyz = renodx::tonemap::UpgradeToneMap(
untonemapped,
renodx::tonemap::renodrt::NeutralSDR(r0.xyz), // Intentional
r0.xyz, 1.f);
like it is in tonemappass if (config.per_channel_blowout_restoration != 0.f
|| config.per_channel_hue_correction != 0.f
|| config.per_channel_chrominance_correction != 0.f) {
graded_sdr_color = ApplyPerChannelCorrection(
untonemapped,
graded_sdr_color,
config.per_channel_blowout_restoration,
config.per_channel_hue_correction,
config.per_channel_chrominance_correction);
}
return renodx::tonemap::UpgradeToneMap(
untonemapped,
neutral_sdr_color,
graded_sdr_color,
config.color_grade_strength,
config.tone_map_pass_autocorrection);
nah
that's some generic UE debug pq thing that no game uses
that's usually the last cbuffer in UE
so they added 3 more cbuffers that end up being yzw
basically generic UE stops at cb0[86].x
then they added 3 new floats
yeah
@hard cedar has a UE4 game that has the cbuffer names, but you can also compare with output shaders from UE5
float LUTSize : packoffset(c047.x);
float InvLUTSize : packoffset(c047.y);
float LUTScale : packoffset(c047.z);
float LUTOffset : packoffset(c047.w);
float EditorNITLevel : packoffset(c048.x);
float BackbufferQuantizationDithering : packoffset(c048.y);
uint bOutputInHDR : packoffset(c048.z);
from oblivion
but bOutputInHDR isn't what you think. it's a UE design editor thing
yeah, they should have done it in the lut, for efficiency, which is how it's designed
in a general sense you don't have to do any of this for a normal UE game
it's because they modified it that it's weird
but yeah, the output shaders should have per channel correction. because that should be applied on any per-channel tonemap
basically if they don't apply the math to all channels equally, it's going to hue shift and gain/lose saturation
if a game does color *= ComputeOtherNumber(color.rgb) it's fine
because that's just exposure, technically. different exposure at different parts of the output curve
w?
color.xyz = color.rgb
colors are expressed in red,green,blue channels
doing math differently for each channel means per-channel
doing the same for all channels equally, thus is not per-channel (and not subject to hue and saturation changes)
so if you take all 3 channels and multiply it by the same number you're basically working with its luminance (not hue or saturation)
it is all per-channel
it's not that the function is different for each channel
it's that there's no singular uniform number being applied to each channel
r2.xyz = float3(-0.195050001, -0.195050001, -0.195050001) + r0.xyz;
r2.xyz = float3(-0.163980007, -0.163980007, -0.163980007) / r2.xyz;
this is per channel
r0.xyz here is untonemapped, the original color
so it's -0.16398 / (untonemapped.rgb - 0.19505)
already it's per value in each channel it'll result in a new number that's isn't proportional anymore
so channels move indepedently, instead of all three at the same time
it's a rough example, but 99% of the time, the moment you see addition and subtraction it's per-channel
a by-luminance system would multiply one number to all 3 channels. honestly rare
but you can see renodrt since it has a by channel and a by luminance branch
for example, let's say i wanted 2x reinhard for a color: rgb(0,2,5).
per channel would be rgb( 0/(0+1), 2/(2+1), 5/(5+1) )
by luminance would be rgb( 0 * lum/(lum+1), 2 * lum/(lum+1), 5 * lum/(lum+1))
which is the same as saying rgb(0,2,5) * lum/(lum+1)
which is the same as saying float3(0,2,5) * lum/(lum + 1)
running per channel in different color spaces (bt709 and bt2020) would result in different colors
by luminance doesn't really
UE does per channel in AP1 color space
by luminance, as the name implies, is the same color, just darker/brighter
per channel is basically random (not really, but for illustration)
per channel is basically a hack, to be honest
doesn't have much foundation on much science, except some vague concept on that's how film works, and "looking nice"
"it's a feature not a bug"
legit what the article that pushed it says
Finally, another common change I see is to apply the filmic curve to luminance only. I disagree with this practice, but there are good reasons to do it. The filmic curve will add saturation to your shadows and remove saturation from your highlights. It is an open question whether this behavior is a bug or a feature.
[...]
However if we had applied the filmic curve to each channel individually, we would have a value of (R=0,G=0.8,B=0.95) which preserves detail in the highlights. As we get closer to white, we WANT to reduce the saturation. A tone cuve that gradually removes saturation from highlights as they become overexposed is a feature, not a bug (IMO).
http://filmicworlds.com/blog/filmic-tonemapping-with-piecewise-power-curves/
frank heart
is that the guy who brought us red shadows under character faces
astral night
yes
he built the uncharted2 tonemapper
and UE4 is based on UC2 tonemapper
in the way he used per channel, it applies color ratios exponentially, which means more color contrast in shaders, and less color contrast in highlights (which ends up being white). completely disregards the hue shifting element and the need to make custom textures for a custom tonemapper
what renodrt does is handle highlight saturation completely separately to by luminance (blowout)
what ACESv2 does is use reinhard but against perceptual luminance, not mathematical luminance
frank heart
that should still be better than ACESv1 right
astral night
yeah
i'm a bit hesitant to dump (use) all of the chrominance systems of ictcp an oklab, so for now i'm just using sticking with the reinhard math as it's meant to be used (mathematical luminance)
i'm using ictcp and oklab for some minor perceptual hue stuff, but it's barely noticeable. i do both chrominance (saturation) with oklab and ictcp, but i don't really use the lightness/intensity system. there's a combination of lightness/intensity + chrominance that i'm not sure how i'll want to use yet
for now the hacky blowout slider works well enough
autumn jetty
Any way to use rcas on wuwa with special K?
use optiscaler
load the optiscaler dll/asi as an SK plugin and it should work
autumn jetty
It smells good from here
hard cedar
<@664732951724032001> has a UE4 game that has the cbuffer names, but you can als...
@astral night @tough ember the game with named cbuffers is Like a Dragon: Ishin! -- it might be on gamepass
also the pull request for the lutbuilders has been up for a week -.- they've been tested and work
astral night
i'm asking for the output shader
hard cedar
I dont have the game downloaded
a dude just sent me lutbuilders
and I fixed them
and he tested it
I can download it if you're interested
astral night
it's just to see the output shader decompiled with cbuffer names
hard cedar
copy
its downloading; its like 60gb so give it a few min
thats for #1321685184852135967
I added lutbuilders for 2 games, and waiting for shortfuse to merge
almost there
@tough ember @astral night
thats a lot of inputs
ue 4.27 "generic"
visual sand
Is this for KTM?
hard cedar
pretty trippy to see these shaders with names lol
astral night
i'm getting ```cpp
float DefaultEyeExposure : packoffset(c65.y);
float4 BloomDirtMaskTint : packoffset(c66);
float4 LensPrincipalPointOffsetScale : packoffset(c67);
float4 LensPrincipalPointOffsetScaleInverse : packoffset(c68);
float SwitchVerticalAxis : packoffset(c69);
float4 ChromaticAberrationParams : packoffset(c70);
float FringeIntensity : packoffset(c71);
float4 BufferSizeAndInvSize : packoffset(c72);
float4 DofBlurSizeAndInvSize : packoffset(c73);
float4 OverlayColor : packoffset(c74);
float SRGBAwareTarget : packoffset(c75);
came laternah, order is different in this game
astral night
yeah, has bOutputInHDR but it's not the last cbuffer
in ue5 it is
and most ue4
so the game is likely custom and reshuffled cbuffers
hard cedar
ah
hard cedar
all ue4 output shaders have that "ishdr" branch
on a side note the game looks really nice with reno unreal; I played it with SK HDR when it came out
astral night
no, it's just for UE Editor
hard cedar
yea I dont think the output shader hdr stuff ever actually runs
btw is there something wrong with my lutbuilder PR -- I'm not really in a rush to get it merged; just curious
whenever I see lutbuilders sit around for a while; I think I did something wrong lol
astral night
bool IsPostProcessingOutputInHDR()
{
static const auto CVarDumpFramesAsHDR = IConsoleManager::Get().FindTConsoleVariableDataInt(TEXT("r.BufferVisualizationDumpFramesAsHDR"));
return CVarDumpFramesAsHDR->GetValueOnRenderThread() != 0 || GetHighResScreenshotConfig().bCaptureHDR;
}
editor stuff
i'm sure UE team will get right on that
Oct 2015
hard cedar
I wonder what happened to pumbo's PR
he wanted to fix the srgb missmatch
and needed comparison photos of 2.2 sdr in a hdr container
vs. missmatched native UE hdr
modest jewel
Any way to use rcas on wuwa with special K?
not with SK either with optiscaler or reshade
but you can add either as SK plugin
visual sand
Stupid question but: This will still work even without a proper HDR Screen yeah?
frank heart
you can do it without an HDR screen
just put peak/game/UI to 80 nits
i dont see any reason to though because it hits performance
visual sand
Cause I’ll be using my laptop for the next while and it doesn’t have HDR
frank heart
You'll be better off playing without the mod
subtle warren
not with SK either with optiscaler or reshade
Yea already done ir!
frank heart
with current build?
per channel waveform is that with the new lilium shaders
so you want me to change which sliders specifically
the sliders you added with the scene grading strength 0?
with ktm off they work fine and well
these all work when kurotonemapping off
one second
im topping up 💀
frank heart
?
did an update change something
this does not look like the
kurotonemapping off i know
one second
i've got like 20 renodx builds saved
let me check
nvm lol
I was editing the variable on an engine.ini that i saved somewhere else
not one that the game actually loaded
@tough ember cheers
The blowout restore one is weird, on this scene specifically it turns saturated and then desaturated again
@astral night does that look like the intended behavior for blowout restore?
it becomes more saturated and then gets less saturated as you reach closer to 100 for some reason
at night
patent blade
I think this is too bright on skin, what am I doing wrong?
frank heart
welp drop and hopefully someone can test, i gotta go soon
autumn jetty
I can test BUT with ktm on
frank heart
I can test BUT with ktm on <:pepeToast:1309186285243469824>
thats what we're testing for
KTM on all teh effects disabled/ set to 0 should be the same as off
astral night
yes, enable descriptor tracking in the devkit
snapshot will show it
you have to restart devkit if you enable it
civic path
should you use this preset if not disabling the kuro tone mapper?
astral night
Dx12, probably
frank heart
cosmic hearth
visual sand
Heyyyy
cosmic hearth
oh！！！！！！
I find it difficult indeed
Is this my problem
just a moment
I need to reset the engine. ini file
OK
Unchanged renoDX
It looks like the filter has been lost
Compared to before, it is not as thick or very saturated
The special effects colors have almost been redesigned
Well, it also has previous issues
Attack or fall, the screen will briefly darken
I think this should be my problem
This may be a defect in the monitor
It is a MiniLcd monitor, and the output color depth is only 8 and shakes 10
wait a moment
I will record and send it to you for viewing
Strength 100 It has a strange color
When it is 0, the color is correct
Wuthering Waves
Bloom
Its function is quite different from what I imagined
When I pulled its value to 0, the light diffused and the character's color changed
to be honest
It seems that the SDR here is not displaying correctly
I find it difficult to understand whether the settings I set in RenoDX are what I expected
Bloom's functionality may be correct
cosmic hearth
KuroTonemapping
Its job, it works
Its effect looks like
Lowering or increasing the brightness of the game screen results in different color saturation levels when the values change
！
spiwar， there he is
You can leave it to him for testing
frank heart
@tough ember i assume it still changes something even with kurotonemapping off?
yeah i asked because its still doing something
green tint shift
at scene grading strength 100
thats the color issue
you're talking about?
oh
this build removed the bloom slider?
no
i dont care about it
cosmic hearth
frank heart
definitely some wrong interactions somewhere
with this strong green shift
ah
blowout restore
one second
cosmic hearth
frank heart
cosmic hearth
I don't know
This is UI
frank heart
you might also be having issues
with blue shadows
I can alread notice it from the login screen
frank heart
kinda hard to difficult to understand that through the language barrier
cosmic hearth
YES
frank heart
yes but it's not the shader
you might have broken something
one second
yeah
should not be any missing shader
because this is repo result
no blue tint on shadow and UI brightness is non-reactive
well
youtube
clean reference with no UI
cosmic hearth
All are SDR images, RenoDX is not enabled
They are 12:00 noon and 9:00 pm respectively
autumn jetty
not just pale, the pink hue in the skin is weird too
autumn jetty
I mean the skin is pink tinted and pale 😄
nocturne lava
We appreciate your efforts lol
hard cedar
@tough ember what was kurotonemapping doing color wise?
I thought wuwa was just a standard lutbuilder + sample shader UE game
hard cedar
send code if you dont mind
so kurotonemapping is just a branch in the output shader?
the lutbuilder doesnt sample colors (I guess it might sample sdr luts)
a color gets processed by a lut
in the sample/output shader
think of a lut as jus ta block of hlsl code
and you "#include" it in other shaders
so instead of
color = untonemapped;
color = 500_lines_of_code(color)
tonemapped = color
its
color = untonemapped;
color = lut::sample(lut)
tonemapped = color;
hard cedar
pog
umbral granite
Was wondering if anyone else tested MFG?
Sl. files can be manually replaced to versions that support MFG
Set driver forced MFG for the game but that didn't work, nor did the global driver one
Ofc FG / Reno flicker but I'm planning to come back when the future maybe FG fix for flickering is out
frank heart
Was wondering if anyone else tested MFG?
i think it works but obviously reno wont work with it
nocturne lava
The driver override will change it to 3x or 4x for me but Reno doesn't hdr the mfg frames
astral night
MFG worked fine for me with WuWa
4x
but that was months ago i last tested
60 => 240
frank heart
I was playing this full screen
and I thought there was some clamping going
but no
it's so bright it triggered my C2's ABL
patent blade
Which version of .addon64 should I use, the latest on github? I heard there’s some color issues.
peak geyser
Which version of .addon64 should I use, the latest on github? I heard there’s so...
Latest version is like 95% correct I believe.
subtle warren
Latest version is like 95% correct I believe.
Is it the repo one?
peak geyser
You use this one
subtle warren
Maybe that's the reason my my blacks look too dark with value 0
subtle warren
You use this one
I'm currently using this one
peak geyser
I'm currently using this one
Yeah, I always get it off the Github.
I think the one you got is for developing Reno for games as it's talking about dumbing game info and such.
Use THIS link and download the Unreal Engine snapshot.
https://github.com/clshortfuse/renodx/wiki/Mods
astral night
Use THIS link and download the Unreal Engine snapshot.
https://github.com/clshor...
the top post in the UE is the same snapshot fyi
peak geyser
the top post in the UE is the same snapshot fyi
Fair enough. ^^
Github just seemed like the most reliable source as I know a lot of experimental versions float around on here. XD
nocturne lava
oh whoops lol
and yeah I noticed that
Hmm I think the sun might've shifted a little there
it is
it does feel a little bloomier but it's not the worst thing
the lighting shifted a bit
this game is so damn pretty lol
Ah that could be?
the fog seems to pick up more saturation too
or maybe it's just moving between my screenshots lol
yeah, so far it doesn't look bad though
feels like it highlights some of the rtgi a bit more
but maybe it's just playing tricks on me
the red banners in septimont have a bit of a different look with aces too
I think skin feels a bit more natural with aces
oh the sun shifted a lot there
wait this time shorekeeper got bored on me
oh hmm
my game color settings are not vanilla
I wonder if that's affecting this
I had 30 brightness, 55 saturation, 50 contrast
pretty big difference on the rocks here
I went back to 50/50/50 here but yes they do
reno ui brightness doesn't seem to
frank heart
Whats the options here
nocturne lava
100/100/100 and 0/0/0 lol
nocturne lava
Whats the options here
which options? the above shots for the ingame brightness/saturation/contrast I had 30/55/50 until the second shorekeeper one, and then I had 50/50/50
frank heart
No the tonemapper options
The images austin posted the settings menu
Look almost exactly the same
Whats the 100/100/100 then
nocturne lava
The images austin posted the settings menu
oh, sorry, yeah that's aces and ktm swapped, you can see in the settings
nocturne lava
nocturne lava
These
those two shots in particular were just the in-game options, with aces both
mostly to confirm they were doing something
frank heart
Ah the in game settings have always been fine
nocturne lava
no problem thanks for your work on this game!
frank heart
@tough ember can you lock vanilla
to always use kurotonemapping
better for comparisons tbh
since its true vanilla
yeah
i'l prob make a showcase video
once this is all
said and done
not necessary but would be nice for vanilla to be pretty much game vanilla, kurotonemapping and all
nocturne lava
yeah that would make comparisons a lot more authentic
frank heart
yeah
grey out the tonemapper selection as well
like how the custom color grading locks out
nocturne lava
the in-game adjustments do have a lot more severe effect on vanilla than on reno though lol
woo!
okay awesome
I will although I gotta sleep soon
if I can sleep after looking at these bright images
frank heart
probably wont be able so save aces
nocturne lava
the color shadows feel a bit brighter on aces
nocturne lava
the red banners in septimont have a bit of a different look with aces too
you can really see it in the reds here
nocturne lava
I'm going to pass out, too tired rip
frank heart
aces has too much shadow tint
nocturne lava
gn and thanks for the uploads, I'll check back tomorrow
nocturne lava
linear has some weird spots
frank heart
can't unsee that shadows tint
once you've seen it
it only makes the shadow darker
it wont fix the red tint underneath
I'm going to try to to a grade with filmic
but like
im pretty set on linear atp
frank heart
huh
is that what you think they are?
I thought u put those in manually
but if it's the in-game one
then KTM 1 = genshin impact
KTM 2 = death stranding
its the actual name
used by the game
according to game files
; 0 = Off, 1 = Genshin, 2 = Death Stranding, 3 = Kuro (Default)
; Yes, those are the information Kuro used for the tonemapping command lol
its in the game files
people just dig it up
Ctrl +F genshin
no
not in this server
well
personally a lot of it I think is placebo too :kek:
the performance related ones
the ones that does change performance will reduce the visual quality
inspiration™
they have a server at the top of that google docs link if ur interested
im in there just to spread the good word about HDR
also
u might have mssed up
a change somewhere
blowout restoration worked in your previous build
now its not working
when using any of the three tonemapper types except linear
hmm
imma go back to linear then
linear FTW
i think u should
would be really funny
and sitll accurate
since thats how they actually call them internally
🤣
Damn
Lets do that
The grain isnt very noticeable anyways
Ah
Both builds?
frank heart
prob gonna stick with linear/off
color temp diff aside
the way you lose details off the leaves when you use any of the kuro tonemappers
goated update though
since we can do 1:1 comparisons between kuro on/off now
wdym better neutral sdr
ah ok
looking forward to that
practice work for when wuthering waves 3.0 breaks the mod again
U can drop the mod here for someone i gotta go
patent blade
Is editing engine.ini with kuro=0 necessary? since this new build has switch for kuro on/off
raven wedge
Why it doesn't go past bt.709 color set?
frank heart
game dont have to go past 709 to be HDR...
if you want oversaturated colors you're welcome to
crank up the saturation sliders
raven wedge
I just deleted localstorage.db
For some reason
But I use xxmi launcher with dll injector
frank heart
that looks normal
raven wedge
Restarting the game doesn't help
frank heart
nah, looks clipped
i meant the reshade detected back buffer
astral night
try without the other mods and launchers
frank heart
hdr10 looks correct
frank heart
Restarting the game doesn't help
- engine.ini tweaks
- you used global filter
- you're using FSR
any engine ini tweaks
that changes vignette
or upscaling
also has a chance to break this
raven wedge
Yup, that was FSR, buy why gains are so neglegible?
raven wedge
Damn, when you boost in flight it goes back to 203
frank heart
Damn, when you boost in flight it goes back to 203
yeah, read the pinned message
pastel pond
im having the same issue as @raven wedge tried literally everything to solve it
came to the conclusion "prob becase i have an amd gpu"
frank heart
Works fine on my amd igpu
astral night
im having the same issue as <@456226577798135808> tried literally everything to...
this is your first comment here, so, no. not "literally everything"
share a picture of engine.ini and the advanced mode page
as spiwar said
pastel pond
yea it is my first comment doesnt mean i haven been lurking into it, as well as having help from a friend that dwells more into it than me
pastel pond
ill sahre an img of the engine.ini as soon as i get a chace,
fsr is off
astral night
it's extremely more likely something is misconfigured/conflicting that being the person to discover a completely new bug that no one else has ever encountered
frank heart
Any secondary scaling like screen percentage will also break it
Just people getting clamping to 203 issues not related to ur build
Most likely user error
raven wedge
Picture of renodx settings page in advanced mode
frank heart
Did the mod set r8g8b8 typeless to output size for you
Or did you just manually set that up
frank heart
Ah
astral night
which one of the engine.ini settings messes with the shaders is the question
frank heart
Best to just reset engine.ini to stock
raven wedge
ok, one sec
frank heart
any of these can break it
things related to draw distance, shadow resolution won't
raven wedge
I don't have any of those
frank heart
just best to reset engine.ini so we know for sure
astral night
just back it up, and if fixes, then it's going one by one to figure out which one is it
wutheringwaves has non-stock UE custom output shaders, so ini variations change the output shader
alternative is to share the engine.ini and see if somebody wants to apply and dump the missing custom shader
pastel pond
frank heart
https://cloud.ferrahome.com/s/peqNsqttGDpBAWJ/download/Client-Win64-Shipping_OP8...
where are you in the game
map position
since you're on AMD
FSR off yet?
raven wedge
Same
raven wedge
FSR off yet?
Yup
pastel pond
let me try , last time it wasnt working either but who knows, i have run into many silly bugs here and there ( i was using just sk hdr but renodx just looks so much better
frank heart
if you've used SK HDR before
pastel pond
oh yea i reset everything , evenr reinstalled the game LOL
frank heart
SK might take priority
in upgrading the SDR swapchain
and fuck up reno
so reset SK settings
astral night
reshade as d3d12.dll works, you don't need SK
frank heart
yeah, if you're using SK, try using D3D12 instead
pastel pond
opening without sk gives me the same result
raven wedge
can you send your reshade.log file?
astral night
you're on dx11
raven wedge
Whot
astral night
20:27:13:181 [20132] | DEBUG | [RenoDX] utils::resource::OnInitDevice(Hooking device: 593709920, api: d3d11)
it's dx11 not dx12
astral night
i don't think i tested dx11
pastel pond
yea ran it thro there
astral night
i mean, might work
frank heart
should work, i've got it on my iGPU for performance reasons
DX11 and AMD
💀
yeah
bloom slider works
astral night
also rip performance with so many fx shaders
pastel pond
astral night
https://cloud.ferrahome.com/s/jerKQsgSBJznjQP/download/Client-Win64-Shipping_n9n...
yeah, capped by output shader
though
is the UI above 203?
warped obsidian
wait what is this?
this is just the latest release right?
astral night
UI tends to go above 203 unless you have some reshade fx that caps to sdr
frank heart
make sure to delete localstorage.db or whatever its loading the settings from
raven wedge
Oh wow, xxmi probably need dx11 for mod loading
warped obsidian
the test release?
that needs more than just that file
frank heart
Oh wow, xxmi probably need dx11 for mod loading
3dmigoto doesn;t support dx12
astral night
dx11 might have a different output shader
raven wedge
3dmigoto doesn;t support dx12
bruuuuuuuuuuuh
warped obsidian
😄
astral night
bruuuuuuuuuuuh
dx12 support isn't free. it's a pain in the ass
pastel pond
is the UI above 203?
ui is at 137
frank heart
i can pull the game up on my laptop right now
astral night
when capping from output shader the UI still breaks through.
if even the UI is capped then something else is going on (FSR/DLSS, XESS, SK, reshade fx, etc)
pastel pond
after reisntalling the game ( fsr was on ) i was having the issue that chanigng the ui brightness would change everything else, but after turning fsr off it only touches the ui
frank heart
fsr or screenpercentage will break
probably adds an output shader
DLSS (or FSR2 via optiscaler) won't
astral night
eh, might just be faster to go the "long way", load up the devkit, take snapshot and dump the missing shader
frank heart
im glad someone found out the global filter issue
astral night
should add some instruction saying how to dump shaders with devkit
astral night
im glad someone found out the global filter issue
honestly should just patch the shader
pastel pond
ok , will do that, thanks for the help in advance
astral night
in Oblivion Remastered i disabled the game's screen brightness shader
more custom stuff that just interfered (and useless since we have a brightness slider)
astral night
Works fine on AMD and dx11 (and SK, and Optiscaler)
AMD gpu? or CPU?
pastel pond
btw idk if this helps but increasing the game brightness increeases it higher than 203~ nits but no peaks
frank heart
AMD gpu? or CPU?
amd iGPU
astral night
we're going to need the devkit dump, which may not even work with the WuWa build you're using. unless @tough ember rebased to latest
raven wedge
Well, now it's like this
raven wedge
can you take a HDR screenshot
How?
raven wedge
astral night
(oh i misread bub, rip wolverine joke)
pastel pond
ok, donwloading it thanks
raven wedge
are you using d3d12 method
?
frank heart
how are you injecthing the mod
astral night
it's floating around 203, not but capped to 203
eh, that's also ui
jack up contrast to see if it's clipped
raven wedge
how are you injecthing the mod
Right now it's renamed reshade64.dll
astral night
renamed to...?
pastel pond
on the dev kit, > take a snapshot and then?
frank heart
yes
wait a second\
(?)
the game is dull by default by your words and you're bringing the brightness down?
can you reset to defaults
take a picture with the game in vanilla
and then with renoDRT
those small sparkle there don't look like you're clamping, looks more like you made the game intentionally dull
raven wedge
can you reset to defaults
Here is default
frank heart
i dont care about the waveform
astral night
set contrast to 100 for testing
raven wedge
Now, what I need to press in devkit?
astral night
snapshot on the top left, then the second tab on the navbar
pastel pond
raven wedge
snapshot on the top left, then the second tab on the navbar
auto dump?
astral night
click on draw on the ones after 0x271e
frank heart
if any of these draws
make the screen black
and not just
turn off the UI
yeah
i am pretty sure they're all UI though
astral night
yeah the Draw button is a toggle, it'll turn gray to show the draw has been disabled. ideally it's just UI stuff, but if one of them isn't UI you'll know by it either going black
yeah, don't be confusing
you don't have 0x03354fcd
raven wedge
pastel pond
yea ui stuff is not visible
frank heart
huh?
astral night
yea ui stuff is not visible
screenshot of what you have now?
astral night
https://cloud.ferrahome.com/s/bdkosGqHTJJeAKw/download/Discord_zrYE4GWQ5h.jpg
can you show me a picture of your effects tab?
frank heart
https://cloud.ferrahome.com/s/bdkosGqHTJJeAKw/download/Discord_zrYE4GWQ5h.jpg
have you closed the game, deleted your localstorage.db and restart the game...
pastel pond
yes i have
pastel pond
One sec power went off lol
astral night
https://cloud.ferrahome.com/s/bdkosGqHTJJeAKw/download/Discord_zrYE4GWQ5h.jpg
can't make out the shader hashes, jpg bad
frank heart
which shader is this?
astral night
idk what f680628f is
pastel pond
Got to wait for power to come back...
astral night
i don't have that shader... is that yours @tough ember
astral night
ah 00
raven wedge
devkit needs search in it
frank heart
i went to the same location @pastel pond shared
frank heart
why can't you just press on the dump button right there
raven wedge
why can't you just press on the dump button right there
I just pressed and nothing happened
No
frank heart
then why did you paste them over here 😭
frank heart
yes?
we're not asking you to search for a known shader
if it's known then someone already patched it
I'll turn on global filters and see if I can find that shader
lol
pastel pond
Still waiting for power... Once it's back I'll toggle the sahder wino pointed
frank heart
you just need to enter the
global filters menu
for the game to break
don't even needd to change anything
hello clamping my old friend
@astral night if the image freezes instead of going black does that count
astral night
100% counts
raven wedge
well, none of those makes screen go black
frank heart
astral night
so 99% counts
frank heart
This one makes everything dimmer
only one that makes the screen goes black
astral night
well, affects the whole screen is important too
raven wedge
astral night
ui is just sections
raven wedge
Damn
astral night
a shader that modifies the whole screen can cap
a shader that just draws ui sections is meh
also, i'm pretty sure we're testing with like every option on in the game
even game UI options like idk, sharpening, vignette, CA can introduce new shaders
pastel pond
ok back at it,
astral night
though the shader isn't new
astral night
how do you have a ui.... hmm
if you removed the draw calls where's that UI coming from
astral night
oh youdid, i'm blind
frank heart
once you start getting into the shaders that disables geometry or 2d textures
is it too far
astral night
you don't have to go before lutbuilder
raven wedge
only one that makes the screen goes black
And UI is still visible?
astral night
@raven wedge you need to scroll to the bottom where last snapshot number appears
astral night
eg
pastel pond
frank heart
guys the file is in your game folder
frank heart
astral night
the disasembly is useless, not sure why you guys keep pasting it
astral night
<@456226577798135808> you need to scroll to the bottom where last snapshot numbe...
@raven wedge
astral night
For e v e r y t h i n g
yeah, no chat on github
astral night
i need the picture
raven wedge
i need the picture
astral night
astral night
if you disabled the draw and the game is capped the shader isn't capping the image
astral night
yeah, 0x1d1c270c0 is the last shader to draw the game
we have that shader
he just sent it
pastel pond
yea it is 0xf600 not 680
raven wedge
Where is it?
misty brook
The wuwa in game bloom sucks ass even with engine ini edit it's wayy too strong 🗿
raven wedge
I don't have anything enabled
frank heart
i've got one that turns black, but it's before the lutbuilder
misty brook
Okay, any config changes I need to make?
pastel pond
im not using any shaders only enabled the hdr analysis
astral night
okay, forget the devkit, it's not a shader problem. have they tried contrast like 100?
pastel pond
well effects
frank heart
yeah guys
misty brook
I'm still using what spiwar sent me a month or two ago
frank heart
- Turn on contrast up to 100
- take one picture with vanilla
- take another with renoDRT
take an HDR screenshot please
astral night
crank up exposure and contrast to max
if it goes over Game Brightness, then it's working
raven wedge
vanilla
astral night
uh
raven wedge
Reno
