✅RenoDX: Unreal Engine

[spare bane]

here's 4k nits and 1000 untouched output

ap1 => bt709

4k untonemapped vs 1k untonemapped

[elfin lance]

wow

it actually looks like a sun

[spare bane]

hue shift memes

[elfin lance]

you probably care more about south of midnight vs. the entire gaming community

[spare bane]

pink to yellow from clipping

you'll see why

[bold gulch]

@spare bane what do I call beyond blue's original grain. it's default unity. do i call it grain or noise idk the difference"

  if (CUSTOM_GRAIN_TYPE) {  // film grain
    float2 noise_uv = v1.xy * cb0[28].xy + cb0[28].zw;
    float random = t0.Sample(s0_s, noise_uv).a;
    o0.rgb = renodx::effects::ApplyFilmGrain(
        r1.rgb,
        noise_uv,
        random,
        CUSTOM_GRAIN_STRENGTH * 0.015f,
        1.f);
  } else {
    r0.yz = v1.xy * cb0[28].xy + cb0[28].zw;
    r0.y = t0.Sample(s0_s, r0.yz).w;
    r0.y = r0.y * 2 + -1;
    r0.z = saturate(r0.y * 3.40282347e+38 + 0.5);
    r0.z = r0.z * 2 + -1;
    r0.y = 1 + -abs(r0.y);
    r0.y = sqrt(r0.y);
    r0.y = 1 + -r0.y;
    r0.y = r0.z * r0.y;
    r1.rgb - renodx::color::srgb::EncodeSafe(r1.rgb);
    r0.yzw = r0.yyy * float3(0.00392156886, 0.00392156886, 0.00392156886) + r1.xyz;
    o0.rgb = renodx::color::srgb::DecodeSafe(r0.yzw);
  }```

[elfin lance]

sir, this is unreal engine

[bold gulch]

oh meant to ask in main thread

[elfin lance]

its a joke d.w

[spare bane]

1k untonemapped, 1k rrt, UE tonemapping RRT=>SDR

[elfin lance]

the little floaties in 1k untonemapped look purple too

[spare bane]

they tonemap in ap1

per channel

[elfin lance]

while the second one they seem to become a bit bluer

so good ole aces memes?

[spare bane]

looks like noise/blue-noise, since it layers it on top. grain is sometimes a texture applied on top at least.

[spare bane]

if ap1 is part of aces, then yes

rrt did basically nothing

first mistake is working in ap1

second is per channel

that's also a global desaturation they do

twice

not highlights, global

[elfin lance]

unreal is the gift that keeps on giving

jokes aside, the unreal engine mod as a whole is probably one of the coolest things ever

I remember when you helped me fix my first lutbuilder; I started messing around with a bunch of other games

back when we still had to fix the sample shaders

and now we got this gigachad project

[spare bane]

there's nothing in here to really customize saturation either

it's just the result of using UE's tonemapper

it's not like they had a choice to say "desaturate by x %"

[elfin lance]

and we cant skip it because the color grading is basically fused to it

[spare bane]

https://tenor.com/view/bob-the-builder-gif-21863917

it's just tonemapper params

[elfin lance]

bob the builder

the future is to start compiling lutbuilders through the unreal editor

like silent hill 2

start knocking out entire versions in a few minutes

idk how kosher that is

[spare bane]

nah. too many variations

and custom stuff

[elfin lance]

speaking of the unreal editor

maybe I should go back to silent hill 2

and try to add those lutbuilders to the mod

[spare bane]

if you can get the source. it's only hard compiled here

what ersh did

[elfin lance]

well yea I'd dump them from the game

assuming it lets me

the game has shader precompilation

so fi I'm lucky

I can just search for the hashes in the dump folder

[spare bane]

UE tonemap by luminance + upgradetonemap

old UE upgrade, new UE upgrade

stupid per channel

[elfin lance]

the colors are back!

[spare bane]

because per channel sucks

https://tenor.com/view/snoop-dogg-i-said-it-whats-happenin-gif-11563120

[spare bane]

@bold gulch just replacing per-channel SDR tonemapping to by-luminance in UE

[elfin lance]

I only use it as a 1 click fix for stuff that just feels like a pita otherwise

like in ryza the blue clouds

per channel was the only way I could match them to white/sdr

without griefing everything else

[spare bane]

break time. then time to make it a one liner

[elfin lance]

gl

also I was able to get most .cso files

from silent hil 2

guess I'll fix them up sometime soon ™️

the devkit crashes after ~20s for me in SH2

so I got what I could before it crashed

[spare bane]

#include "./shared.h"

static struct UELutBuilderConfig {
  float3 untonemapped_ap1;
  float3 untonemapped_rrt;
  float3 tonemapped_ap1;
  float3 tonemapped_bt709;
  float3 ungraded_bt709;
  float3 graded_bt709;
} RENODX_UE_CONFIG;

void SetUntonemappedAP1(inout float3 color) {
  RENODX_UE_CONFIG.untonemapped_ap1 = color;
}

void SetUntonemappedRRT(inout float3 color) {
  RENODX_UE_CONFIG.untonemapped_rrt = color;
}

void SetTonemappedAP1(inout float3 color) {
  RENODX_UE_CONFIG.tonemapped_ap1 = color;
}

void SetTonemappedBT709(inout float3 color) {
  RENODX_UE_CONFIG.tonemapped_bt709 = color;
}

void SetUngradedBT709(inout float3 color) {
  RENODX_UE_CONFIG.ungraded_bt709 = color;
}

void SetGradedBT709(inout float3 color) {
  RENODX_UE_CONFIG.graded_bt709 = color;
}

float3 UpgradeToneMapAP1(float3 untonemapped_ap1, float3 tonemapped_bt709) {
  float3 untonemapped_bt709 = renodx::color::bt709::from::AP1(untonemapped_ap1);
  return renodx::draw::ToneMapPass(untonemapped_bt709, tonemapped_bt709);
}

float4 LutBuilderToneMap(float3 untonemapped_ap1, float3 tonemapped_bt709) {
  float3 color = UpgradeToneMapAP1(untonemapped_ap1, tonemapped_bt709);
  color = renodx::draw::RenderIntermediatePass(color);
  color *= 1.f / 1.05f;
  return float4(color, 1);
}

float4 CompleteTonemap() {
  float3 color = UpgradeToneMapAP1(RENODX_UE_CONFIG.untonemapped_ap1, RENODX_UE_CONFIG.graded_bt709);
  color = renodx::draw::RenderIntermediatePass(color);
  color *= 1.f / 1.05f;
  return float4(color, 1.f);
}

float4 CompleteTonemap(float3 graded_bt709) {
  SetGradedBT709(graded_bt709);
  return CompleteTonemap();
}

the more you feed into it, the better

gotta add the special options now, like changing to tonemap by luminance

[elfin lance]

do we still need to find the same colors?

and do the same thng?

I wante do tget started on fixing a few more lutbuilders

but idk if I shoul dwait

[spare bane]

wait a sec

i'll probably regex all of it though

[elfin lance]

its sm6

[spare bane]

i think all the color-based grading has already happened in this part, not sure

when we get untonemapped ap1

[elfin lance]

I'll just wait until you iron some stuff out, this isnt a rush

just a bunch of meme builders I found in silent hill 2's shader precomp

got 10 cs lutbuilders; one of them was already in the addon so I deleted it

if you're going to regex them anyway

here is hlsl -f --use-do-while + .cso

[spare bane]

i think i found a HLSL bug 😕

#include "./shared.h"

// clang-format off
static struct UELutBuilderConfig {
  float3 untonemapped_ap1;
  float untonemapped_ap1_y;
  float3 untonemapped_bt709;
  float3 untonemapped_rrt;
  float3 tonemapped_ap1;
  float3 tonemapped_bt709;
  float3 ungraded_bt709;
  float3 graded_bt709;
} RENODX_UE_CONFIG;
// clang-format on

static bool tonemap_by_luminance = RENODX_TONE_MAP_EXPOSURE != 0.f;

void SetUntonemappedAP1(inout float3 color) {
  float3 new_reference = color;
  RENODX_UE_CONFIG.untonemapped_ap1 = color;
  if (tonemap_by_luminance) {
    RENODX_UE_CONFIG.untonemapped_ap1_y = renodx::color::y::from::AP1(color);
    color = float3(0, 1, 0); // RENODX_UE_CONFIG.untonemapped_ap1_y;
  }
}

void SetUntonemappedRRT(inout float3 color) {
  RENODX_UE_CONFIG.untonemapped_rrt = color;
}

void SetTonemappedAP1(inout float3 color) {
  RENODX_UE_CONFIG.tonemapped_ap1 = color;
}

void SetTonemappedBT709(inout float3 color) {
  RENODX_UE_CONFIG.tonemapped_bt709 = color;
}

void SetUngradedBT709(inout float3 color) {
  RENODX_UE_CONFIG.ungraded_bt709 = color;
}

void SetGradedBT709(inout float3 color) {
  RENODX_UE_CONFIG.graded_bt709 = color;
}

// float3 UpgradeToneMapAP1(float3 untonemapped_ap1, float3 tonemapped_bt709) {
//   float3 untonemapped_bt709 = renodx::color::bt709::from::AP1(untonemapped_ap1);
//   return renodx::draw::ToneMapPass(untonemapped_bt709, tonemapped_bt709);
// }

// float4 LutBuilderToneMap(float3 untonemapped_ap1, float3 tonemapped_bt709) {
//   float3 color = UpgradeToneMapAP1(untonemapped_ap1, tonemapped_bt709);
//   color = renodx::draw::RenderIntermediatePass(color);
//   color *= 1.f / 1.05f;
//   return float4(color, 1);
// }

float4 CompleteTonemap() {
  // RENODX_UE_CONFIG.untonemapped_bt709 = renodx::color::bt709::from::AP1(RENODX_UE_CONFIG.untonemapped_ap1);
  // if (tonemap_by_luminance) {
  //   // convert back
  //   RENODX_UE_CONFIG.graded_bt709 = RENODX_UE_CONFIG.untonemapped_bt709
  //                                   * renodx::math::DivideSafe(
  //                                       renodx::color::y::from::BT709(RENODX_UE_CONFIG.graded_bt709),
  //                                       renodx::color::y::from::BT709(RENODX_UE_CONFIG.untonemapped_bt709));
  // }

  float3 color = renodx::draw::ToneMapPass(RENODX_UE_CONFIG.untonemapped_bt709);  // , RENODX_UE_CONFIG.graded_bt709);
  color = RENODX_UE_CONFIG.untonemapped_ap1;
  color = renodx::draw::RenderIntermediatePass(color);
  color *= 1.f / 1.05f;
  return float4(color, 1.f);
}

float4 CompleteTonemap(float3 graded_bt709) {
  SetGradedBT709(graded_bt709);
  return CompleteTonemap();
}

i set RENODX_UE_CONFIG.untonemapped_ap1 to the original color, i then change the inout variable to be green

when CompleteTonemap() runs, untonemapped_ap1 is green

something something shared references and pointers

[elfin lance]

so are we going to need to find more colors now?

[spare bane]

nah

just testing

[elfin lance]

copy

thought each builder is going to need all this

  float3 untonemapped_ap1;
  float untonemapped_ap1_y;
  float3 untonemapped_bt709;
  float3 untonemapped_rrt;
  float3 tonemapped_ap1;
  float3 tonemapped_bt709;
  float3 ungraded_bt709;
  float3 graded_bt709;

[spare bane]

that's common.hlsl

apparently inout means "make pointer"

but out works

[elfin lance]

ik

but the colors have to come from somewhere

and there where the set functions

[vale yarrow]

where is RENODX_UE_CONFIG coming from? global space

[elfin lance]

btw while you're working on unreal, can we please get a /games/ folder in the root directory -- and move all the per-game mods into it

its going to get really unwieldly soon

[spare bane]

that same file

[vale yarrow]

yeah but is it in global space?

[spare bane]

as you see it, i'm just calling #include "C:\Mods\renodx\src\games\unrealengine\common.hlsl" from the main shader

wait, maybe i was dumb

calling it twice in the main shader

[vale yarrow]

you don't need inout anyways

in or nothing is enough

no wait I am reading it wrong oops

[spare bane]

seems i redeclared untonemapped_ap1 later in code

the system works

screenshotting...

Current UE method, Current + Grading 0, Newer method (UE tonemap by luminance)

waveform matches better with newer method

[elfin lance]

@viscid mirage our dice memes can go in the trash

ty shortfuse

[spare bane]

gotta go try that game with custom tonemapping params

romancing saga2

[elfin lance]

yea

do you have the demo installed

I got the game installed still

[spare bane]

back on fiber

[elfin lance]

so send me a addon64 if you want

[spare bane]

or is the demo gone?

[elfin lance]

no idea

[brave sand]

demo should still be around

[elfin lance]

its been months

[spare bane]

disappeared from my library

but i'm downloading it

[elfin lance]

so

[elfin lance]

do we have to do anything new?

when fixing lutbuilders

or its still find 2 colors and enjoy

[spare bane]

what was float3 untonemapped_ap1 = whatever is SetUntonemappedAP1(r0.xyz);

and was the other thing is o0 = CompleteTonemap(r3.xyz);

so regex will do it fast

you're basically passing the variables to common.hlsl to do work

[elfin lance]

watch out for compute shaders

[elfin lance]

thats what we did before

[spare bane]

no

this is different

[elfin lance]

[spare bane]

you are actually passing an inout

[elfin lance]

like void (float3 poop inout)

[spare bane]

meaning the other hlsl file can manipulate untonemapped_ap1

[elfin lance]

ohh I remember

yea I get it

[spare bane]

void SetUntonemappedAP1(inout float3 color) {
  RENODX_UE_CONFIG.untonemapped_ap1 = color;
  if (RENODX_TONE_MAP_TYPE != 0.f && tonemap_by_luminance) {
    RENODX_UE_CONFIG.untonemapped_ap1_y = renodx::color::y::from::AP1(RENODX_UE_CONFIG.untonemapped_ap1);
    color = RENODX_UE_CONFIG.untonemapped_ap1_y;
  }
}

[elfin lance]

I remember I setup a void with in/inout/out

yea

[spare bane]

meaning, i make it grayscale

i think it's fine, but we'll see

[elfin lance]

my first attempt at my scuffed UE mod

had a void tonemap

with the colors as in/inout/out

because of the duel tonemap setup

[spare bane]

the fast way to make something tonemay by luminance is send it gray

rip RRT red memes

[elfin lance]

if you're interested in colors, use returnal

its super colorful

[spare bane]

the amount of loss is what matters to me

so South of Midnight was good to test with

but now i have to bake in some custom desaturation probably

which isn't horrible

and ap1 hue memes

[elfin lance]

btw do you want to fix these CS lutbuilders since you're already working on unreal engine

or should I do it after you change the stuff up

[elfin lance]

...

btw will these upgradetonemap saturation changes be ported to tonemappass -- so I can get rid of the dice nonsense in other games

[spare bane]

no, because all i'm doing is changing vanilla to render by luminance

i mean

unless....

👨‍🍳

[bold gulch]

https://tenor.com/view/woody-woody-toy-story-sora-kh3-kh-gif-27223516

[tired mulch]

[elfin lance]

[spare bane]

going to sleep on this. something like renodx::draw::GetColored() but less racist

because we need to go back to colored instead of grayscale at some points in the process

r0.xyz = r2.xyz * r2.xyz; // should be colored
r2.xyz = cb0[26].yyy * r2.xyz;
r0.xyz = cb0[26].xxx * r0.xyz + r2.xyz;
r0.xyz = cb0[26].zzz + r0.xyz;
r2.xyz = cb0[42].yzw * r0.xyz; // should be colored
r0.xyz = -r0.xyz * cb0[42].yzw + cb0[43].xyz;
r0.xyz = cb0[43].www * r0.xyz + r2.xyz;
r2.xyz = max(float3(0, 0, 0), r0.xyz);
r2.xyz = log2(r2.xyz);
r2.xyz = cb0[27].yyy * r2.xyz;
r3.xyz = exp2(r2.xyz);

like starfield as well, it wants to sample a lut after tonemapping

[elfin lance]

honestly dont over think it -- like I would've never made the connection if you didnt mention it

[spare bane]

still would be nice to generalize all of what UE does but into renodx::draw

that's what happened before

and why we have renodx::draw

and the special tonemappass one liner

[elfin lance]

I'm talking about the getcolored thing being "racist"

[spare bane]

also, this gives "perfect" hue shifts:

float3 clamped_1k_nits = min(RENODX_UE_CONFIG.untonemapped_bt709, 1000.f / 250.f);
RENODX_UE_CONFIG.untonemapped_bt709 = clamped_1k_nits
                                      * renodx::math::DivideSafe(
                                          renodx::color::y::from::BT709(RENODX_UE_CONFIG.untonemapped_bt709),
                                          renodx::color::y::from::BT709(clamped_1k_nits));

which is straight up what i did in starfield luma

which was clip to 4.f

was going to change : ```diff
if (draw_config.tone_map_hue_shift_method == HUE_SHIFT_METHOD_CLIP) {

•  hue_shifted_color = saturate(color);


•  hue_shifted_color = min(color, HUE_SHIFT_METHOD_MODIFIER);


[elfin lance]

is min really the best way to go about it?

dice displaymaps the color, so it kind of retains info

while min in clamped_1k nits will either return a color or 1k nit white no?

[spare bane]

Dice doesn't hue shift if it's per channel

You need per channel to hue shift

[bold gulch]

what about the hue angle stuff that opendrt uses

is it worthile to implement that

cheaper than oklab I assume

[spare bane]

I think it's ratio. I was also thinking max channel instead of by luminance

[elfin lance]

src/dice.hlsl is per luminance no?

[spare bane]

This scene is really rough. If i shift too early, too much yellow. If I shift too late, green in yellows on the bottom

[elfin lance]

copy

[spare bane]

But if a good scene to experiment

The 4.f was because it looked right clipped to 1K

And aces probably has some clipping involved

[elfin lance]

isnt it built in clipping (in a way)

[spare bane]

Red and green when equal (clipped) is yellow

[elfin lance]

something about how a camera at a certain white point/apterature/exposure would capture a bright object

if its super bright, it gets blown out by the camera

I guess blown out and clipped isnt exactly the same

it was on the unreal filmic tonemapper docs page

[spare bane]

That's per channel blowout

They stumbled into that because it's per channel. High contrast and per channel is going to blowout regardless

Remember that Unreal SDR is not ACES. It's just high contrast per channel that matches and there you go: highlight blowout

All they had to do was increase contrast

[elfin lance]

swore I read on the page that it was "intentional" -- unless they made a bug a feature

Emissive values are now physically correct so that as the emissive power increases the color will become lighter, similarly to how colored lights work in the real world. As color gets tone mapped, if the final color is bright enough to start saturating the film / sensor, it will become white.


...

With a high enough emissive power, the color will start to become white, unlike the legacy tonemapper where values would just become overly saturated causing areas of the material to lose its detail.
...

https://dev.epicgames.com/documentation/en-us/unreal-engine/color-grading-and-the-filmic-tonemapper-in-unreal-engine

but yea thats blowout

but it reads like they wanted to add it intentionally

and its a "feature"

but they're also okay with red eggs becoming completely orange, and blue eggs becoming super pruple -- so idk if I can trust anything on that site

guess I got something to watch later

https://youtu.be/A-wectYNfRQ

[bold gulch]

ya rrt and per channel tonemapping

[elfin lance]

@spare bane I was watching the UE tonemap video, and the UE devs had a desmos link visible in their chrome

https://www.desmos.com/calculator/h8rbdpawxj

idk if you already have that or not

or if its useful for anything

it has the formula for their aces aproximate and all that

[spare bane]

more nerd math

scaling untonemapped back up in bt709 vs scaling in ap1

no grayscale conversion needed yet

An example of why shouldn't chase numbers. Check out the CIE graph.

[spare bane]

oof, this looks kinda perfect, i'm scared

vanilla, luminance+luminance, luminance+per-channel

vanilla, luminance+per-channel

this works

now to fix midtones and shadows to not be per channel

and i think i got it

[raw inlet]

I actually don't completely mind the untonemapped look, but would like to be able to tweak it, but when I enable LUT dumping I'm not getting anything

[spare bane]

might be a compute shader. you should try the devkit then

[raw inlet]

hm, tried disabling drawing on them one by one and couldnt find one that killed the tonemap

[spare bane]

just go from bottom up

or send the trace log

[spare bane]

the game has no lut, so it's 100% custom

[raw inlet]

rip

[spare bane]

log needs to say something like:

11:55:01:918 [43228] | DEBUG | [RenoDX] mods::swapchain::OnCreateResource(counting target, format: r10g10b10a2_unorm, usage: cc4, index: -1, counted: 0) [0/1]
11:55:01:919 [43228] | INFO  | [RenoDX] mods::swapchain::OnCreateResource(Upgrading, flags: 0x0, state: 0x80000000, format: r10g10b10a2_unorm => r16g16b16a16_float, width: 32, height: 32, usage: undefined(cc4), complete: 0)
11:55:01:919 [43228] | INFO  | [RenoDX] mods::swapchain::OnInitResource(tracking 0x00000000667a7720, flags: 0, state: 80000000, width: 32, height: 32, format: r16g16b16a16_float, tag: 1)
11:55:01:919 [43228] | INFO  | [RenoDX] mods::swapchain::OnCreateResourceView(upgrading, found_upgrade: true, expected: true, view type: texture_3d, view format: r10g10b10a2_unorm => r16g16b16a16_float, resource: 0x00000000667a7720, resource width: 32, resource height: 32, resource format: r16g16b16a16_float, resource usage: shader_resource)
11:55:01:919 [43228] | INFO  | [RenoDX] mods::swapchain::OnCreateResourceView(upgrading, found_upgrade: true, expected: true, view type: texture_3d, view format: r10g10b10a2_unorm => r16g16b16a16_float, resource: 0x00000000667a7720, resource width: 32, resource height: 32, resource format: r16g16b16a16_float, resource usage: render_target)

which is upgrade the 10bit 32x32x32 lut to 16bit float

if the word "upgrading" doesn't appear: rip

[raw inlet]

wouldn't it only be upgrading when I'm running the UE addon?

[spare bane]

yes

you can run both

[raw inlet]

ahhhh

I was just running the devkit lol

[spare bane]

though, some times devkit will mention it as a built resource

[raw inlet]

interestingly with the devkit running the tonemap is working

[spare bane]

what shader does it say is replaced in the list

i don't see it in the log

[raw inlet]

Like which ones show up with the addon/original option?

this is the only one that shows a type

rest are all unknown

[lavish ice]

I need some help, guys! I tried the Unreal Engine mod with South of Midnight but the picture is washed out when in-game HDR is turned on. When i turn it off the picture looks way better and the mod seems to work. So do i need to keep in-game HDR off for this mod to work? Thanks in advance!

[spare bane]

vanilla / upgrading+unclampbt709 / luminance+perchannelblend / +blowout50 / ACES

aces deep fried of course. the problem is this game hard depends on the per-channel blowout in the vanilla game

[bold gulch]

did you add an option to do the peak scaling per channel but the other stuff (shadows, contrast, etc) by luminance?

[spare bane]

messing with this as a hue shift option: ```cpp
} else if (draw_config.tone_map_hue_shift_method == HUE_SHIFT_METHOD_PER_CHANNEL_BLEND) {
hue_shifted_color = color; // "hue shift to original color"
tone_map_config.reno_drt_per_channel = true;
tone_map_config.hue_correction_strength = 0.f;
draw_config.tone_map_hue_shift = saturate(draw_config.tone_map_hue_shift * renodx::color::y::from::BT709(color));
}

basically it's per channel, but by luminance hue (untonemapped hue)

er, something is wrong there, but i'm still figuring it out

it's fine for South of Midnight but the SDR needs to blow out in this game

[tired mulch]

didn't we have a separate setting to do lum + lum or lum + per chanel back then and then it was removed

so i guess now it's back but just better?

[spare bane]

this is different

[tired mulch]

oh

[spare bane]

and no. you just have tonemapping after UE grading was done

this is modifying the UE tonemapping

[spare bane]

same logic

  const float3 tonemapped_perceptual = renodx::color::ictcp::from::BT709(color);
  const float3 untonemapped_perceptual = renodx::color::ictcp::from::BT709(RENODX_UE_CONFIG.untonemapped_bt709);

  float untonemapped_chrominance = length(untonemapped_perceptual.yz);
  float tonemapped_chrominance = length(tonemapped_perceptual.yz);
  float chrominance_loss = 1.f - saturate(untonemapped_chrominance / tonemapped_chrominance);
  const float maximum_chrominance_loss = 0.5f;

  float3 new_perceptual = untonemapped_perceptual;
  new_perceptual.yz = untonemapped_perceptual.yz;

  // clamp saturation loss
  float correction = max(tonemapped_chrominance / untonemapped_chrominance, 1.f - maximum_chrominance_loss);
  new_perceptual.yz *= correction;
  float new_chrominance = length(new_perceptual.yz);

  // force restore hue
  new_perceptual.yz = lerp(new_perceptual.yz, tonemapped_perceptual.yz, correction);
  float corrected_chrominance = length(new_perceptual.yz);

  new_perceptual.yz *= renodx::math::DivideSafe(new_chrominance, corrected_chrominance, 1.f);
  new_perceptual.x = tonemapped_perceptual.x;

  color = renodx::color::bt709::from::ICtCp(new_perceptual);

chroma restoration

@bold gulch

[bold gulch]

ictcp?

what about blue

[spare bane]

seemed better with yellow

probalby can swap now

oklab is cursed

oklab vs ictcp

[bold gulch]

make a new lab

isn't oklab not meant for HDR anyway

[spare bane]

now i don't know if i was having trouble with pink because of oklab in general

[spare bane]

with by luminance shadows/midtones

removes the red fog

[paper siren]

I am pretty far into South of Midnight, the flickering with renodx happened in earlier levels but changing settings fixed it but in this level it's not going away

any workarounds for this?

[spare bane]

can't reproduce this

[elfin lance]

[paper siren]

found a way to reproduce it, at least on my machine. Grading strength 0 causes the flicker, setting it any non-zero fixes gets rid of the flickering.

okay, not non-zero , basically changing the grading to any other value changes it, it started happening at 1. Maybe alt-tabbing is causing it, idk

ignore what I said, it's back again and nothing gets rid of it

[spare bane]

yeah, it's something specific to UE, and i'm not sure what it is

[neat pulsar]

maybe; from what I understood ICtCp was made for HDR with wide color gamut in mind; at least on my monitor I never get the "best" look under oklab

[neat pulsar]

haven't found one yet myself; I can toggle settings and it seems stable for a moment and then it picks up again

at first I thought it was something with vrr, then ruled that out. then follwed the path of possible noise and then nothing. I literally watch the CIE graph jump around and it corresponds to the flickering in-game

[paper siren]

Yeah same, but luckily it seems to affect some levels and some are completely fine

[neat pulsar]

my settings are maxed out; trying to see if shadow quality affects it or not; just rando shooting at this point. But yea on the same level early on when traversing the town area at the gas station, it just stopped for like 10 mins no flickering

[paper siren]

Chapter 10, right? Chapter 11 onwards it’s completely fine.

[neat pulsar]

yup; I messed around some more but nothing to it

not sure if it matters, but I am on the game pass version

but it appears it's probably just a texture flicker issue up to that point

[raw inlet]

@spare bane noticed something interesting wrt the gamut clipping - in the pause screen it clips far less
Comparisons are ground truth - reno 100 saturation, sk 200% saturation

also it wasn't running the devkit that got the tonemap working, it was the latest version of the ue addon
So something you changed fixed it ig

[viscid mirage]

ShortFuse fixed the decompilation errors in the lutbuilders

That's probably what changed it

That also fixed the magenta issues in Stray and likely Outer Worlds as well

[thorny kelp]

Is this confirmed? I tested the repo build about a month ago in The Outer Worlds SCE and the magenta hue was still there.

Away from my PC so I can't test.

[spare bane]

I tested the repo build about a month ago

this was days ago

[thorny kelp]

Ahh okay.

[olive flare]

First time using the UE multi game mod. For south of midnight, do we need to do anything else other than dropping the addon in the correct folder? Appreciate adding the game as it doesnt seem to be popular

[unborn verge]

See the UE compatibility list
https://github.com/clshortfuse/renodx/wiki/Mods

[spare bane]

also disable in-game HDR

[viscid mirage]

In case someone needs ShortFuse's regex to fix sm5 lutbuilders (#🧩renodx-dev message)

find
(\s+)if \((cb\d+\[\d+\]\.)(x|y|z|w)+ ([!=]= 0\) \{)
replace
$1[branch]\n$1if (asuint($2$3) $4

find
= (cb\d+\[\d+\]\.)(x|y|z|w)+ \?
replace
= (asuint($1$2) != 0u) ?

[spare bane]

it's SM5 i think only. the sm6 decompilation wouldn't have that issue

[fallow mica]

should add that to wiki

[spare bane]

i'm working on a rewrite where it wouldn't matter, which is just pass the output type variable

[honest elbow]

Has anyone compared using this vs native in hogwarts? ^^

[neat pulsar]

You weren’t able to reproduce the flicker in South of Midnight, correct? @spare bane

[spare bane]

no..

[neat pulsar]

Just making sure. Going to Terry and make some time tonight to see what’s breaking.. it’s an intermittent issue even on the main menu. Reminds me of Watch Dogs 2 flickering

[spare bane]

whatever it is, it's exclusive to UE

[spare bane]

Vanilla / Current / PerChannelCorrection

[tired mulch]

cuhrayzee

in repo soon?

[spare bane]

whoops, that blowout 50, though fine for this game

[spare bane]

probably tomorrow, still testing

[tired mulch]

[spare bane]

Vanilla / Current / PerChannelCorrection

[tired mulch]

looks like a better alternative versus doing 50 lut strength

[spare bane]

Vanilla / Current / PerChannelCorrection

blue smear is more than red smear in per channel

[spare bane]

0x31FE4421 seems modified

like stuff was removed

maybe it's because it samples a lut

i'll do lut stuff later

banisher lut is wrong

[spare bane]

New build up on repo.

[earnest bolt]

btw South of Midnight triggers your screensaver if you idle too long in cutscene, dumb devs 🙂
SK can fix that though

[cobalt marlin]

Oh, like CP77... real dumb indeed

[marble stump]

How are ppl using Reno in Wuwa? I get a ban warning as soon as I launch the game with it and reshade and it closes down

[cobalt marlin]

Is Rocket League known for not playing nice with RenoDX or is there something to do in particular ? I can only get gamma correction & color space to work in it. No unclamping (peak slider works tho), game brightness doesn't do anything and ui brightness affects game brightness

[fallow mica]

rename dxgi.dll to d3d12.dll

dont know if it still works though

[marble stump]

gonna give it a true but not sure if it's safe since I already got warned once xd

[bold gulch]

It’s unreal engine 3 so it’s not supported

[cobalt marlin]

Oh, ok, thanks 🙂

[ashen herald]

Yh UE3 doesn't work with this

XCOM EU / 2 would be nice but those will require custom work

[spare bane]

still works. should use the newer reshade that's pinned in #🧩renodx-dev

[fallow mica]

yeah i always use that one

but i dont play wuwa

[spare bane]

The game didn't boot for me with whatever I had but the latest did.

[raw inlet]

People still use screensavers?

[spare bane]

I use a black/blank one

[raw inlet]

For my oled I just swap to an empty hdmi if I'm not using it

[earnest bolt]

That’s far more effort than screen off on your remote or OLED screensaver

[raw inlet]

turning it off cuts off the display from the pc and I don't like everything resetting when I turn it back on

[earnest bolt]

Screen off does that?

You can set pc to never do that

And combine with black screensaver or screen off on lg remote

[raw inlet]

this is a monitor

black screensaver doesnt help because I want to have the other monitor active

[earnest bolt]

Yes but if you set never turn off display..

You can just screen off lg remote no?

Also why I am fixing your problem lol, there are solutions

[spare bane]

turning off messes with audio, black is good enough for me, but i only use one display

[earnest bolt]

Screen off shouldn’t disconnect display afaik if configured right

[paper siren]

Yeah it doesn’t, at least on my LG oled monitor

[spare bane]

there are custom screensave apps that will only affect one monitor

[paper siren]

The OSD screensaver setting just turns the display black, secondary monitor still remains active

[tired mulch]

just installed new repo

@spare bane trying to do vanilla/old/new comparisons but this is somehow showing up

[spare bane]

what shaders are replaced?

in the log

i found some shaders aren't clamping in vanilla

like true vanilla needs to clamp

[tired mulch]

yeah this is happening on vanilla

reshade.log?

[spare bane]

yeah, i fixed some inaccurate shaders and apparently some games hard rely on the original lut being rgb10a2

meaning clip

i have to add saturate to the shaders

the japanese ones apparently

[tired mulch]

hmm restarted and now im not getting reds anymore

ah nvm

it's there again

[spare bane]

it's just vanilla

or a missing shader

and actually not negative

the game has broken colors and rgb10a2 "fixes" it

we send negative colors and it's fine

so something in vanilla math is broken

[tired mulch]

old/new

ig the old one is blowout restore = 0?

no more pale white

[spare bane]

we're missing a shader in wuwa, i already decompiled it

[rocky harness]

I was actually gonna pop in here and talk about what I assumed was a bug with Renodx and WuWa but I see some talk's already been happening

[tired mulch]

its already in the repo build?

[spare bane]

i'm working on it

[tired mulch]

ah

[spare bane]

@tired mulch try repo now

[tired mulch]

Looks like its not clamped anymore, crazy

hmm okay

The blowout restoration slider doesn't seem to be working

in this new build

changing it from between 0-100 doesnt do anything

[spare bane]

is strength at 100?

check what shaders were replaced

[tired mulch]

yep strength at 100

[spare bane]

what does strength 0 look like?

[tired mulch]

strength 100 / 0

blowout restore doesn't work in either case

[rigid path]

blowout restore is working for me

[tired mulch]

are you using the latest build just now

[rigid path]

yeah just updated

[tired mulch]

weird

[rigid path]

blowout restore 100/0

[spare bane]

depends on the scene

and what it looks like with scene grading strength at 0

[tired mulch]

yeah im in the exact same scene and its not working for me

[spare bane]

the game decides when it wants to rebuild the lut

it's not every frame for some reason

[unique parcel]

poor shorekeeper 😦

Kotorin is using DX11 tho

[tired mulch]

let me try restarting inbetween shots

yeah its not working

[cobalt marlin]

Just gave Chorus a try despite the caveats mentioned on the wiki and it's not that bad I think, but the way some of the sliders affect the gameplay looks are weird. How come this game is so weird for Reno ?

[unborn verge]

Devs probably modified the render somehow

The more customized UE game uses, the less compatible it is with Reno

[cobalt marlin]

With the generic UE build or even custom ones ? Like with this one the highlights controlled by the UI slider, this might not even be addressable by a custom build ?

[unborn verge]

I meant generic RenoUE

Though even making a custom ones can be a pain
afaik modding in HDR in Avowed was a pain

[bold gulch]

If the the highlights are being controlled by the ui slider that means that the game’s lutbuilder is in the mod

[spare bane]

i think that's more DX12 growing pains (Avowed)

[bold gulch]

So you either have to find a shader after the lutbuilder that is clamping or it’s just some upgrade that needs to be enabled

[spare bane]

avowed has a bunch of output shaders, though we have a better decompiler now

[spare bane]

99% sure that means there's no lut builder shader

[spare bane]

you're probably on a different path, the mobile tonemap path, which bypasses aces rrt. custom ue config?

[tired mulch]

My engine ini just has tweals related to draw distance

Although

Using r.KuroTonemapping=0 gets blowout restore working again

[spare bane]

that's the mobile path then

i didn't add support for it

[tired mulch]

I mean adding that line gets blowout restore working not the other way arounf

If i leave the config as is blowout wont work

[spare bane]

what shaders does it say are replaced?

[tired mulch]

Reshade.log?

[spare bane]

yes

[spare bane]

ah the game has a custom lut builder

yeah, it's the mobile path, just different

[tired mulch]

with that line in strength 0 looks way different than strength 100

[spare bane]

@tired mulch try this

yeah the game doesn't use ACES/AP1

also there's a lut

[tired mulch]

hmm seems to be the same issue as before blowout not working

it feels as if some kind of lut is still being applied even at strength 0 vs 100

[spare bane]

yeah, the blowout correction is before the lut

[tired mulch]

strength 0 / strength 100 / strength 0 + kurotonemapping=0 / strength 100 + kurotonemapping=0

[spare bane]

yeah, that's aces probably

though strength 0 of both should be the same

at least in terms of lutbuilder

[tired mulch]

maybe that's the lut thats still applying at strength 0

at least using the line above + strength 0 makes the color look a lot more like aces color

[narrow fern]

How can I enable both RenoDX and MOD at the same time?

When I inject ReShade and then launch the mod using XXMI, only the mod is successfully injected. How can I fix this issue?

[brave sand]

@spare bane do you have any idea on why this happens? highlights on infinity nikki get clipped by what feels like random lol.
happens if i look at things from a different angle or i use a skill.

[spare bane]

Could be a custom output shader that doesn't expect above 1.f values out of the lutbuilder

[spare bane]

If contrast slider being raised still has it clip at game nits, then it's being clipped after sampling the lutbuilder, which points to a second shader after the regular UE output shader, or a custom output shader doing custom things

[brave sand]

there is only ui shaders after the output shader, so it's potentially a custom output shader

[rigid path]

you can simply inject with xxmi by copying reshade64.dll to game directory and putting the path in xxmi

[narrow fern]

Thank you very much, I'll give it a try!

[brave sand]

I figured out the problem, for some reason, the UE output shader isn't alwaysdrawing to the swapchain, conditionally, another set of shaders show up that draws to an RTV that eventually gets drawn to the swapchain, and while those shaders seem to support values above 1.f just fine, I had to add an upgrade to R10G10B10A2_UNORM to fix the clamping.

[spare bane]

I wonder if this could be somewhat related to the flickering, though this seems like it's conditional based on wanting an effect to occur

[narrow fern]

Is there a mod for Wuthering Waves that hides the UID and removes the blur/censorship?

[hearty anchor]

3dmigoto

but it will take a big slice of fps

[hearty anchor]

Am I the only one experiencing crashed on DX12?

[spare bane]

you play with SK, right?

[cobalt marlin]

@14m21s , HDR is broken (red snow )

[tired mulch]

Device hung?

[hearty anchor]

No lost for some reason

[hearty anchor]

Yes sir

[tired mulch]

Lost or removed

[hearty anchor]

dunno lemme check what the log say

[tired mulch]

Are you running ur gpu at stock?

Or any OC

[fallow mica]

lmao

worst hdr of the year confirmed

[tired mulch]

I get some occasional crashes but im not sure its my overclock being unstable or its actually the game

[hearty anchor]

Man i hate that you can't search on mobile

[tired mulch]

Although i think its probably related to r8g8b8 typeless upgrade

[hearty anchor]

I mean I am but I'm pretty darn sure it's stable

I know unreal engine is especially sensitive

[tired mulch]

Play with stock and double check

[hearty anchor]

i guess i can try that

[tardy bear]

Ah, guys

Can your DX12 and RenoDX work well?

I can't do it here

[fallow mica]

which game

[tardy bear]

Especially RTX ray tracing

WuWa

[fallow mica]

idk then

dont play that game

[spare bane]

@tardy bear SK?

[tardy bear]

No, it's Reshade

[spare bane]

so just Reshade and no other mods?

[hearty anchor]

I don't use RTX no

[tardy bear]

RTX ray tracing cannot work with RenoDX

The picture is strange, the light turns red

[spare bane]

works fine for me

i try with dlssfg and rtx

[tardy bear]

God, I need your RenoDX configuration
I may have set the wrong configuration

[spare bane]

clean install, the reshade from #🧩renodx-dev that's pinned but renamed to d3d12.dlland the unreal addon

[tardy bear]

OK，Thanks
I'm going to give it a try now

[spare bane]

i open the Client-Win64-Shipping.exe directly

D:\Epic Games\WutheringWavesj3oFh\Wuthering Waves Game\Client\Binaries\Win64

i'm adding another option for dlssfg in other games, but might work here as well

[spare bane]

oh wow, i was testing the debug build and it was still 225 fps vs 235 unmodded

[tardy bear]

magic

I will do it according to your request

Now it's done,running very well

Praise You

Occasional discoveries

[spare bane]

discoveries?

[tardy bear]

Modified engine

It makes RenoDX work poorly

[spare bane]

i'm not sure what you mean by discoveries

[tardy bear]

Engine.ini

I have added some parameters to this file

This willprevent RenoDX from working well

I deleted the engine.ini file

RenoDX and RTX ray tracing can work

[tardy bear]

go to hell

[spare bane]

@tardy bear you okay there?

[tardy bear]

Very bad

I don't understand

I don't know where went wrong

I have recovered

But it can't run well either

Screen abnormality

This shouldn"t be

I will do it according to your request

Yes, it works very well. RenoDX and RTX very well

I changed the engine.ini,causing the screen to malfunction

I deleted the engine.ini file,

[spare bane]

what options are you trying to get working, i can take a look at getting them to work right

[tardy bear]

but the screen still shows abnormalities]

is this one?

[spare bane]

i mean, what options are you trying in Engine.ini

[tardy bear]

🥲

I can work with RenoDX in DX11 mode with the same parameters

In DX12 mode,itdoes not work

Now there is an additional question

Prior to this, DX12 mode, RenoDX, and RTX could work
After adding some parameters to the engine. ini, the screen became abnormal
Even if the engine. ini file is deleted, the screen still appears abnormal

Magical question

I will delete wuwa and reinstall it

[spare bane]

the ```ini
r.Tonemapper.GrainQuantization=0
r.Tonemapper.Quality=1

options are probably what's affecting it

[tardy bear]

The first time i deleted these two parameters

The screen is still abnormal

Even if the engine. ini file is deleted

The screen is still abnormal

I don't know what the principle is

How do you take screenshots?

Save HDR images and send them here

[spare bane]

Reshade takes screenshots. Go to Setting and change the keyboard key, but by default it's PrntScrn

[tardy bear]

Understood,thank you

Wuwa installation completed

Now I'm going to put it into practice

WUWA completed

I need to make a backup

Next, Reshade is injected into Wuwa

[rigid path]

highly likely that any engine.ini lines which modify post processing cause issues with clamping, I confirmed yesterday that these two settings need to be removed r.Tonemapper.GrainQuantization=0 r.SceneColorFringeQuality=0

[tardy bear]

Okay

The injection is complete, and the renodx-unrealine.addon64 file has also been placed

d3d12.dll

Wuwa Start

RenoDX and RTX work very well

Now I need to modify the screen settings of RenoDX

This RenoDX configuration doesn't work very well

RenoDRT， It can't

[tardy bear]

Are you using RenoDRT?

After RenoDRT recovery, subtle flickering anomalies were still found

Vanilla works very well

[rigid path]

yeah renodrt

are you using frame gen? last time i tried it had some flickering issues but I haven't checked with latest version

[spare bane]

i don't have flickering with frame gen

but when he moves the slider it flickers which is probably related to that flickering issue people reported

[rigid path]

i discovered another issue with this vignette effect

seems to clamp

[fallow mica]

@spare bane tempest rising crashes with addon

and i dont even see the in game hdr option ?

its still in sdr

[tardy bear]

Uh, I turned off frame generation, it works very well.

[fallow mica]

wait it works

[spare bane]

maybe downloading the frame gen dll would help

[fallow mica]

it is working

[rigid path]

yes resource upgrades are turned on

[cobalt marlin]

DF Alex should be made aware of RenoDX, maybe he'll mention it on tomorrow's Direct

[fallow mica]

no the game dont even have native hdr

review code is broken ?

[spare bane]

out dated and they likely could never get it to work

what does strength 0 look like?

also, can you find that snow scene?

[fallow mica]

no it doesnt work

and its doesnt dump the lutbuilder ?

actually the snow scene is just the start of the campaign

[spare bane]

what doesn't work? i'm confused

[fallow mica]

its the ui that exceeds 203 nits so i thought it worked

but it doesnt work actually

and doesnt dump the lutbuilder

[spare bane]

it's custom then

devkit might get you some info

[tardy bear]

engine.ini， I rewrote it
RenoDX and RTX are working very well now.
What a surprise, it's actually a problem with frame generation

[spare bane]

i'm working on fg issues in Avowed, where we downgraded to dlss 3.8.1 to get working, but i don't have flickering issues in this game

[tardy bear]

Anyway

Thank you very much for your help

Praise you all

❤️

[marble stump]

did anyone manage to get reno UE working in lords of the fallen 2 and eternal strands?

both get a black screen with audio for a few sec at the start, and then instantly crash

[spare bane]

eternal strands luts were uploaded by @glossy valve

[fallow mica]

@spare bane

[tired mulch]

FG works fine

even the transformer model

looks like you have something configured incorrectly

[tardy bear]

[fallow mica]

i sent the reshade log can you get some info ?

[spare bane]

no lut builder at all

[fallow mica]

rip

[spare bane]

would need a custom mod

[fallow mica]

im assuming they just removed the broken native hdr after DF told them

[spare bane]

it might not be hard to mod tbh

even if it doesn't use a lutbuilder, it's probably still composited in generic UE style

[fallow mica]

is there a way to tell if it is composited in generic UE style

[spare bane]

using the devkit and analyzing the game

[fallow mica]

actually this game is dx11?

Is there any other ue5 game dx11

[spare bane]

wuwa, no?

has both

[fallow mica]

wuwa is ue4 apparently

quite bizzare that they released a ue5 game with dx11 in 2025

[unborn verge]

He is

[bold gulch]

artifacts in shadows

there's less of it when you lower saturation correction

[spare bane]

I'm assuming out of gamut stuff. Can't tell well on mobile

[bold gulch]

ya

[spare bane]

I noticed how rare it is to get that deep, dark red because of per channel. The saturation correction would bring that back, but there's no gamut compression, so sometimes both ICtCp and oklab can make some strong output gamut colors where clipping just doesn't work.

Had that issue with FF7 remake

[bold gulch]

does just using gamutcompress from ACES not work

[spare bane]

It would work, but you'd have to calculate new thresholds for cyan magenta and yellow I think

It's built for ap0 I think

I could code one. It's probably easier to mirror and curve to 0

I haven't investigated why OKLab is broken though. Might be related

[dire saffron]

Is there a way to make it work properly with Atomic Heart?

[fallow mica]

does contrast slider work

[dire saffron]

yes

[fallow mica]

try up upgrade stuff

under resource upgrades

[dire saffron]

Upgrade B8G8R8A8_TYPELESS seems to work.

[viscid mirage]

cool, pls let us know if you have any issues

@full moss @vagrant thicket Atomic Heart seems to work with the mod now, if you're still interested in playing that

[dire saffron]

The last framegen version flickers, but with 3.8.1 it works.

[pine forum]

any recommended presets for crisis core?

[full moss]

I am, thank you

[honest elbow]

Would like to know this as well, just bought Lords of the Fallen :>

[finite basalt]

doesnt it have native hdr?

or is it just bad cuz its UE5

[fallow mica]

lords of the fallen instant crashes with that addon

[warped lynx]

what do the reshade logs say?

[warped lynx]

basically nothing I guess

[fallow mica]

maybe some anti cheats shit

but i disabled eac

[finite basalt]

oh you can play that game without eac??

[fallow mica]

https://www.nexusmods.com/lordsofthefallen2023/mods/54

[spare bane]

https://www.pcgamingwiki.com/wiki/Lords_of_the_Fallen_(2023)#Disable_Easy_Anticheat

[elfin lance]

the game is super generous

even with EAC off you can still see bloodstains

and get invaded

you just cant co-op or invade others

you can also interact with the online faction stuff

[bold gulch]

how it should be

[elfin lance]

yea I beat the game on launch

played the entire thing EAC off

[kind schooner]

even with EAC on it allows you to do a lot, I am running a no sharpening mod and EAC doesn't care

game needs renodx tho

that hdr is disgusting

[fallow mica]

hdr is dogshit level

more washed out than sdr srgb

they must done some really cursed shit

[finite basalt]

is there messages in the game from other players like dark souls?

[elfin lance]

there are bloodstains, and there is a really cool system

like you follow a ghost of aperson who died

and then you can fight a ghost of them iirc

and get faction currency

wait no you fight the mob that killed them

you follow their ghost, it takes you to the mob that killed them, and you get extra loot for killing the mob

also they might take you to cool places

[ashen herald]

RIP, SK & Reno on Witchfire is kill. I've tried both lazy and plugin loading

Game gets stuck on the starting screen but underneath you can interact with the game

[ashen herald]

No nvm, removed SK and the issue persists

No SK, only reshade with upgrades to stop black screen on start up

[elfin lance]

please always test mods without SK first

if you have an issue, the first thing you should do is install reshade the traditional way as dxgi, and then throw the addon in the game folder -- dont use any other mods

if the bug is still there, well now we can share

[ashen herald]

👍 Utilising shortfuse reshade and the latest UE addon (yesterdays Snapshot), upgraded R10G10B10A2_UNORM

I Set FG to off (just in case it was the cause) which does allow the in game hud to appear when continuing the game but the screen is still black

Intreseting reno doesnt like upscaling

specifically NV stuff

Wonder if its because I upgraded the DLLs, time to check

Narrowed it down to sharpness on my end

setting it to zero, displays the screen correctly 🤔

[elfin lance]

did you upgrade RGB10

Upgrade R10G10B10A2_UNORM

[ashen herald]

Yes

[elfin lance]

try output ratio

not output size

also try bgr8 upgrades

[ashen herald]

without the upgrade the screen would be entirely black

disabling sharpness fixes the problem entirely

[elfin lance]

right they're mandatory

[elfin lance]

might be a custom shader that comes after generic UE stuff

or upgrades

try bgr8 typeless/unorm upgrades

[ashen herald]

lets see

[elfin lance]

also rgb10 to output ratio

[ashen herald]

Tried a few of those upgrades

also verified game files to revert my DLL replacements

issue persists

I dont personally care for the sharpening and everything else works

[elfin lance]

sharpening might be a custom shader then

[ashen herald]

Game looking good with reno and we figured out what the issue was. Can't complain and thank you for the pointers Marat.

[elfin lance]

np. enjoy

[ashen herald]

Would need a few more reports to see if the issue is repeatable on other setups as well

Would be a good idea after to add it on the github as a warning

Darktable UCS causing some issues in UI

https://tenor.com/view/patrick-menacingly-spongebob-standing-there-gif-19452999

[elfin lance]

darktable is weird sometimes, stick to oklab or ictcp

[summer heart]

For Lies of P, the github wiki says this:

What do I upgrade B8G8R8A8_TYPELESS to?

Any size?

[warped lynx]

probably output size

if you're using dlss then you'd use output ratio

[summer heart]

I'm not using DLSS. So I'll try output size then.

[covert dawn]

If I'm using dx11 for mods purpose, should I rename the dll to d3d12?

[honest elbow]

Hmm, how does one even do that? Never seen that? Settings in reshade?

[summer heart]

Press Home (or whatever is your Reshade shortcut), it’ll show the reno setting dialog, change “Simple” settings slider to “Advanced”. Then it’ll show.

[hearty anchor]

should i use the repo build or wuwa one?

for wuwa

and this reshade

[tired mulch]

Whichever one works for you

You can check with lilium hdr analysis

[paper zenith]

Are there any additional steps to use renodx with Wuthering Waves?

Seem to get a crash on the intro (where the game loads). Renamed the dxdgi, but no dice

[paper zenith]

Always get this

[tired mulch]

what version are you using

[tight acorn]

@worldly wind

[worldly wind]

I'm getting into the game, reshade is loading but not the renodx add-on

[dense cliff]

wuwa has early scans for file activity and gets very crashy with graphics dumping. make sure to clear any caches and if you can load in with all renodx features disabled and turn trhem on after the first load screen you should be chilling

[tight acorn]

are you in dx12 mode in the game ?

[worldly wind]

Yes

[tight acorn]

someone has the issue they said the game swapped to dx11 mode randomly

so idk :/

[worldly wind]

Only thing I did was rename the reshade DLL to d3d12.dll

Since that what it says on Github

[dense cliff]

huh I just stumbled on a possibly useless but kind of interesting little exploit here. It seems that if you inject reshade from elsewhere but leave it in the folder as d3d12.dll, infinity nikki doesnt load d3d12 and starts up in d3d11 despite normally not allowing d3d11. it does stall on the loading screen but maybe with cvars it can be made to work. presumably this could apply to some other unreal games as well

[tired mulch]

it might only matter in your case, since i think ur using pak mods

the game never had that issue for me

[dense cliff]

I'm vr modding but the same issues could apply to renodx

[tired mulch]

🤷‍♂️

anyway we can get skin mods in dx12 without getting banned

[paper zenith]

Turns out it was an issue from my side, it's loading correctly now.

[worldly wind]

i still cannot get the addon to load, can you tell me what exactly you did?

[paper zenith]

Do you get a crash when it loads up? Or it's just that the add on does not load?

Mine was crashing at the log in screen, but I tried to inject HDR with SpecialK, and it was still crashing on some other spots.

What I did to fix that was in this order:

1- Delete WuWa and all traces from my drive
2- Download Reshade 6.4.1 with addons (https://reshade.me/#download)
3- Started WuWa, patched it, logged in
4- Installed Reshade, selecting DX12 and the "C:\Program Files\Epic Games\WutheringWavesj3oFh\Wuthering Waves Game\Client\Binaries\Win64" exe path
5- Loaded up WuWa, saw that reshade was being loaded up
6- Dropped the renodx addon on the same path as the reshade
7-Renamed the dxgi.dll to d3d12.dll

After that it loaded every time. It does take a second to any changes you make to the addon to take effect which I thought was weird.

[tired mulch]

Why do you have to do all of that

When u can just inject reshade within SK itself

[paper zenith]

I ended up doing that, but realized I was still crashing, so after fixing the crashing issue (Which was my pc, not reno or sk) I redid the reno steps to see if it solved with only reshade and reno and it did 😅

But yeah, it's easier to do it with SK

[spare bane]

strength 100 vs strength 0, probably whatever is going on here

i thought romancing saga 2 has the harshest difference, but this one is worse

this is what aces/ap1 does to gaming

they were forced to pick the colors on the right to get the colors on the left

@vale yarrow @west stump aces bad

wait a minute, did i just fix the flickering

@grim kernel can you check latest build

renodx::mods::swapchain::expected_constant_buffer_space = 50;

swapchain proxy was never writing cbuffers. it was just carrying over from during render

[west stump]

Sad

Once aces, forever aces.

[spare bane]

@west stump i'm going to confirm that there's no graphical errors here, but could be useful for showcasing why aces is bad

[grim kernel]

can't really check now but that makes sense

[spare bane]

yep, whenever you can, thanks 🙏

[west stump]

So the right is pre tonemapping?

[spare bane]

yeah. scene grade strength 0 just returns untonemapped_bt709 which is the ap1=>bt709 conversion of the ap1 color before passing UE passes it through the ACES RRT and UE's per-channel tonemapper.

[fallow mica]

right looks pretty close to native hdr

[spare bane]

native hdr doesn't have sdr color grading

or sdr luts (technically also sdr color grading)

[fallow mica]

i guess returnal is similar ?

[spare bane]

considering how broken UE hdr is, i should sell a RenoDX UE plugin

UE HDR only works if you throw out the SDR color grading

[earnest bolt]

you should 100% try and get it integrated into the engine

[west stump]

But it still has a form aces.

It just misses the filmic adjustments

[grim kernel]

doing all that through a legit plugin might be pretty tricky i think

they can't actually do everything you'd want

[grim kernel]

didnt play much but it does seem stable now

[vale yarrow]

how is this news? 🤣

[vale yarrow]

you just need another HDR->HDR tone mapper that is not ACES.
not sure if the plugin system can do that.

[spare bane]

maybe if it inverses the steps the shader will do so the net result is what's expected

[thorny kelp]

Tested the latest repo build and The Outer Worlds: Spacer's Choice Edition (DX12) finally has the magenta hue fixed! Hurray! No other issues that I've found so far.

But I've noticed the OG version of the game (DX11) still has an issue where the UI Brightness slider affects the brightness of the in-game lights, and as such max luminance doesn't reach the value set by the Peak Brightness slider:

Game Brightness bottomed-out, UI Brightness maxed:

Both Game and UI Brightness bottomed-out:

Tried dumping LUT shaders, but nothing gets created in the game binary's folder.

[west stump]

lol

that means they'd admit they messed up

NEVER, in a million years.

Human nature 🙂

[earnest bolt]

Hey they finally accepted your Y FOV change

Never say never

[viscid mirage]

have you tried B8G8R8A8_TYPELESS upgrades

[thorny kelp]

Just tried it and that fixed it! But only when set to Any Size. Both Output Ratio and Output Size don't remedy it.

Thanks! I'll update the wiki page for the two games.

[viscid mirage]

just a guess but could it be that the game's not dpi aware

you may need to set this for the win64-shipping exe in the properties

[thorny kelp]

That had already been set.

[viscid mirage]

ah ok, I think that would screw up output size and ratio

[vale yarrow]

that's kinda the point
they do similar stuff in movies too

[spare bane]

it's a bug not a feature. you don't people faces bright orange on camera to get a yellow output

[vale yarrow]

that's true

[spare bane]

i'm basing it on the fact on the forum they say they should either grade entirely in AP1 textures and do all their art in AP1 or "pick" colors that end up looking how they want

just a horrible way to work imo, and does more harm than good

[vale yarrow]

I think colourists basically have to fight the ACES stuff when doing grading

in movies/shows that is

[spare bane]

i was thinking recently that most grading is for film and most film is sdr

we should probably start thinking how netflix productions grade since they're TV and thus HDR first

making an SDR grade is basically the priority in ACES forums

[vale yarrow]

isn't Netflix grading hella cursed?
basically it looks normal with Vivid modes on TVs

[spare bane]

you can probably find horrible examples, but made for film usually means made for cinema, meaning at best 108 nits Dolby Cinema.

https://partnerhelp.netflixstudios.com/hc/en-us/articles/360000591787-Color-Critical-Display-Calibration-Guidelines seems mostly dolby based

[vale yarrow]

the 108 nits DV for cinema does not translate 1:1 to TV grades
it's quite a bit more.
if we go by Dolby math and scale it linearly:
cinema ref white: 48; max white: 108
TV ref white 140; max white: 315

[spare bane]

in aces max white is 48

0.02 for black

[vale yarrow]

ACES HDR cinema?

[thorny kelp]

Sorry, last thing: I'm wondering why this shot looks like the gamma is raised or something? Specifically the shadowed recesses/pockets on the rocks. I can remedy it mostly by raising Flare to around 40-ish, but I'm wondering if this is an issue with the mod or the game or something.

[vale yarrow]

I meant DV HDR cinema

[spare bane]

ACES SDR is 48nits, yeah

haven't look at what changed in 2.0

[vale yarrow]

cinema stuff has stayed the same

[spare bane]

but 1.3 is sdr 48 nits, hdr 15mid/1000 and 15mid/2000 peak

[vale yarrow]

tbh 48 nits in a cinema is plenty bright because of the huge screen

[vale yarrow]

ah ok

well

[spare bane]

ah, p3 108

https://github.com/ampas/aces-core/blob/v1.3.1/transforms/ctl/outputTransform/p3/RRTODT.Academy.P3D65_108nits_7.2nits_ST2084.ctl

[vale yarrow]

P3D65 is not cinema

cinema white point is that ACES D60

[spare bane]

then just 48 https://github.com/ampas/aces-core/blob/v1.3.1/transforms/ctl/odt/p3/ODT.Academy.P3D60_48nits.ctl

2.6 gamma

// This transform is intended for mapping OCES onto a P3 digital cinema
// projector that is calibrated to a D60 white point at 48 cd/m^2. The assumed
// observer adapted white is D60, and the viewing environment is that of a dark
// theater.

[vale yarrow]

yep, that's the cinema "standard"

[spare bane]

they do saturate to 48 nits

[vale yarrow]

there is also this:
https://github.com/ampas/aces-core/blob/v1.3.1/transforms/ctl/odt/p3/ODT.Academy.P3DCI_D60sim_48nits.ctl

[spare bane]

it's actually what i use to scale linearly in renodx

inverse

actually i think i use this: https://github.com/ampas/aces-core/blob/v1.3.1/transforms/ctl/odt/sRGB/ODT.Academy.sRGB_100nits_dim.ctl

[vale yarrow]

here is the ODT for tv grades:
https://github.com/ampas/aces-core/blob/v1.3.1/transforms/ctl/odt/rec709/ODT.Academy.Rec709_100nits_dim.ctl

[spare bane]

it's the same numbers iirc, just stretched and encoded differently

bt709 tv, srgb, and cinema all use the same 48nit config : https://github.com/ampas/aces-core/blob/fc189808208e28019a8c5a27cdb2d50312939232/transforms/ctl/lib/ACESlib.Tonescales.ctl#L251

then just scale based on output

there's also a 4000 nit one

48 / 1000 / 2000 / 4000

[vale yarrow]

even says that this is for DV HDR cinema

[spare bane]

the repo is split between a newer dynamic output and the older fixed one. so i can't remember which math applies how

one of ssts and another is the older method

[vale yarrow]

those are the old ones as I understand it, when the tmo was still somewhat hardcoded

thing's cursed

[spare bane]

Does the math even work though. It's all per channel.

[vale yarrow]

what do you mean?

[spare bane]

Which is probably why they did JMH in aces 2

Let's say I do the grading on a 4000 bit display and do all that math. When I use a srgb transform would it look the same?

(and obviously the inverse)

Curbing Y MAX to 48 is different than to 1000 in per channel

[vale yarrow]

ideally yes, but ACES is not set up for that
maybe that is even a Union thing because someone needs to do that work of doing the individual grades

[spare bane]

I guess the work we're doing of dynamic grading and SDR/HDR match more, uh, complex

I'm just thinking of how many colorists there are that hate HDR and I'm sure a lot of that stems from working per channel and things not scaling at that level

[vale yarrow]

could be

[vale yarrow]

you are forgetting the chroma compression, gamut mapping and gamut compression that are happening

[spare bane]

That's before ssts

They're the same for all odts

[vale yarrow]

the ODT in 2.0 is just this now:

    float AP0_clamped[3] = clamp_AP0_to_AP1(aces, 0., p.ts.forward_limit);

    float JMh[3] = RGB_to_JMh(AP0_clamped, p.input_params);

    float tonemappedJMh[3] = tonemap_and_compress_fwd(JMh, p);

    float compressedJMh[3] = gamut_compress_fwd(tonemappedJMh, p);

    float RGBout[3] = JMh_to_RGB(compressedJMh, p.limit_params);

    return RGBout;

[spare bane]

That's aces 2

But 1.3 was just ymin ymid ymax and output transform

ymin ymid ymax are going to have different hues from mid to max since they're doing per channel

Aces 2 is single channel/value

[vale yarrow]

yeah that thing is cursed lol

[spare bane]

Aces 1 was 4 curves: 0 to min, min to mid, mid to max, max +

Something like that.

[vale yarrow]

yeah 4 curves

[spare bane]

And if min and max were just clip, then it's just a split tonemap system

I think that's slope? Something like that

[vale yarrow]

it says spline? though I am not sure what you mean?

[spare bane]

A variable they called offset something

https://github.com/clshortfuse/renodx/blob/c4490137e9a90b03c0907b77f124ab40dfae1592/src/shaders/aces.hlsl#L378

[vale yarrow]

no idea anymore what that is

[raw inlet]

in kof the health bars and portraits are partially affected by UI brightness, but are also affected by game brightness, saturation etc

[spare bane]

It means they didn't properly separate their render. UI is getting grain and bloom...

[raw inlet]

I don't think it does normally?

[spare bane]

We're patching the internal lut, and normally you don't pass the UI components to the lut. The same shader that samples the lut applies grain and bloom to what is considered "render"

[raw inlet]

well unfortunately no lut is getting dumped

[elfin lance]

@fallow mica grab the lutbuilder if possible, and I'll add it to the UE mod

god damn it forwarded the wrong image

I meant to forward your lords of the fallen 2023 post

[fallow mica]

lotf crashes with the ue addon

[elfin lance]

did you disable

EAC?

[fallow mica]

yeah

instant crashes anyway

[elfin lance]

rip

if you have the game installed still

what verison of UE is it on

right click the game's .exe

it should be in info

it was an early UE5 game; but tehy had a lot of patches

I beat the game on release

[fallow mica]

i wrote the version in my analysis

[elfin lance]

let me find it again

5.1

[fallow mica]

uninstalled unfortunately

[elfin lance]

the reason I asked is because ue 5.3+ seem do to stuff differently

[earnest bolt]

has anyone tried It Takes Two with this?

[spare bane]

testing this now, how far into it is it? might just be NaN

[bold gulch]

15 minutes maybe

[spare bane]

i see it on the first staircase

we've had those blues in starfield as well

when upgradetonemap mismatches i think

[spare bane]

hard luminance mismatch

it's crushed in post tonemap (sdr)

[bold gulch]

Take the y of saturated pre tonemap and post tonemap

Multiply pre by the ratio to roughly line up luminance

[hearty anchor]

Gonna try without uv

dx12

Hmm

No crashes so far

Could it actually be...?

Does reno dx make pcs more unstable 🤔

[spare bane]

yeah, the lift is upgradetonemap in general, just increasing saturation of a bad lift is going to look bad

did find a bug in applyperchannelcorrection

[hearty anchor]

Well i played for a good bit quite sweaty too

No crash

interesting

[spare bane]

hdr takes up more vram, other than that, should be the same

if it's not crashing after all is said and done (eg: booting game, loading an area) then there's nothing more it's likely doing differently

[glossy valve]

I was just gonna send you a pic of RENODX_PER_CHANNEL_BLOWOUT_RESTORATION causing visual bugs only at 1.f

[spare bane]

float chrominance_loss = max(
      renodx::math::DivideSafe(tonemapped_chrominance / untonemapped_chrominance, 1.f),  // eg: 0.25
      blowout_restoration);

this is nonsense

probably should be ```cpp
float chrominance_loss = max(
min(renodx::math::DivideSafe(tonemapped_chrominance, untonemapped_chrominance, 1.f), 1.f),
blowout_restoration);

float3 UpgradeToneMap(float3 color_hdr, float3 color_sdr, float3 post_process_color, float post_process_strength) {
  float ratio = 1.f;

  float y_hdr = renodx::color::y::from::BT709(abs(color_hdr));
  float y_sdr = renodx::color::y::from::BT709(abs(color_sdr));
  float y_post_process = renodx::color::y::from::BT709(abs(post_process_color));

  if (y_hdr < y_sdr) {
    // If substracting (user contrast or paperwhite) scale down instead
    // Should only apply on mismatched HDR
    ratio = y_hdr / y_sdr;
  } else {
    float y_delta = y_hdr - y_sdr;
    y_delta = max(0, y_delta);  // Cleans up NaN
    const float y_new = y_post_process + y_delta;

    const bool y_valid = (y_post_process > 0);  // Cleans up NaN and ignore black
    ratio = y_valid ? (y_new / y_post_process) : 0;
    // ratio *= min(1.f, y_sdr);
  }

  float3 color_scaled = post_process_color * ratio;
+  color_scaled = lerp(post_process_color, color_scaled, saturate(y_hdr));
  // Match hue
  color_scaled = renodx::color::correct::Hue(color_scaled, post_process_color);
  return lerp(color_hdr, color_scaled, post_process_strength);
}

new magic?

basically the problem is hdr is like 0.01 and sdr is 0.00000001

that jacks up black areas because they mismatch
