Exterior wall has gaps

[fossil stone]

Hi

Something like the model shouldn't be that extreme. I've had the problem for a while now that the outer wall isn't printed all the way through.

This time I set the arrangement of the walls to outside/inside, which makes the problem even bigger. It would be really helpful to know which setting is responsible for this.

Temp Filament 210
Bed 65
Filament is calibrated
PA value 0.25

The rest of the settings are as in the pictures.

I'm really confused as to why this is happening

[spiral chasm]

PA is 0.25?!? Or is that supposed to be 0.025?

[fossil stone]

Yes PA is 0.25

[spiral chasm]

Is your printer a direct-drive extruder?

[fossil stone]

Is an Anycubic Kobra go, with Micro Swiss Bowden Extruder and E3D Revo Cr Hotend, pid calibration is also done

[fossil stone]

I reduced the speed from 75 mm/s to 50 mm/s, determined a new PA value of 0.32 and activated the small area flow compensation, now it looks better

[pearl egret]

You can also try extrusion rate smoothing in your case as it helps a lot with Bowden style printers

[fossil stone]

Ok you mean this https://github.com/SoftFever/OrcaSlicer/wiki/extrusion-rate-smoothing How does it all work exactly?

[pearl egret]

It gradually ramps print speed when going from slow to fast and fast to slow print segments. Set the ERS value to something like 50-70 and post a picture of your print speed preview 😉

[livid delta]

not surprising me, my first printer is also a bowden type, linear advance is 0.35

[fossil stone]

Ok I'll try it out thanks

[jovial stream]

@fossil stone ziemlich verwirrend diese deutschen menüs. 😀

[fossil stone]

welche deutschen menüs?

[jovial stream]

@fossil stone die von orca slicer, die meisten Leute Können jah kein deutsch lesen, deswegen verwirrend. 😀
