Thread for work on planet rendering divorced of other parts of the architecture for the moment

dusky crane May 2, 2024, 1:53 AM

#

i assume this channel is for this

#

heres a moonlike thing i whipped together in 30 minutes

dusky crane May 2, 2024, 2:19 AM

#

Someone asked me to give this one lava i think

#

looks neat

#

wicked plinth May 2, 2024, 7:26 AM

#

hell yeah that was me

#

look anwesome

blissful saffron May 2, 2024, 8:00 AM

#

Did you use blender? Looks very nice

sleek lion May 2, 2024, 9:47 AM

#

For general art (3D models, texturing), I made the separate #🟡game-art channel btw

#

This is probably more so for the graphical programming side of things

lethal flicker May 2, 2024, 2:24 PM

#

Doing some math

loud maple May 2, 2024, 2:27 PM

#

No sure if this is the right section, but do we have an idea of how we want to generate the planets? such as PQS or some other system? I saw something like PQS somewhere but with triangles instead of squares that looked pretty cool

lethal flicker May 2, 2024, 2:27 PM

#

I'm trying to figure out how to at least draw a quad sphere for the moment, not even a procedural lod kinda one yet

lethal flicker May 2, 2024, 2:48 PM

#

#

That wasn't it

#

First things first, the poles are wrong

#

the south poles normals are reversed for example

loud maple May 2, 2024, 2:51 PM

#

Uh oh, don't create the sims by accident

lethal flicker May 2, 2024, 2:51 PM

#

lmao

#

I won't

#

aaa, south poles normals are still reveresed

#

#

Less thick lines

lethal flicker May 2, 2024, 3:36 PM

#

Oh my fucking god

#

I'm implenting a subdivision algorithm from wikipedia

lethal flicker May 2, 2024, 3:53 PM

#

https://en.wikipedia.org/wiki/Catmull–Clark_subdivision_surface

Catmull–Clark subdivision surface

The Catmull–Clark algorithm is a technique used in 3D computer graphics to create curved surfaces by using subdivision surface modeling. It was devised by Edwin Catmull and Jim Clark in 1978 as a generalization of bi-cubic uniform B-spline surfaces to arbitrary topology.
In 2005, Edwin Catmull, together with Tony DeRose and Jos Stam, received an...

#

This is the algorithm I'm implementing

#

I ... think I'd rather have a mesh manipulation library than deal with implementing this part manually

#

though ... hmmm

#

because it's the final 2 steps that are going to be the most painful

#

Or I could go about this a better way

#

Gonna try and port this unity tutorial to godot
https://catlikecoding.com/unity/tutorials/procedural-meshes/

Unity Pseudorandom Noise Tutorials

A series about generating procedural meshes in Unity.

lethal flicker May 2, 2024, 4:40 PM

#

I feel like I'm banging my head on the wall on something I conceptually do understand. as in what a cube sphere is

#

I think I need to draw some stuff on paper

lethal flicker May 2, 2024, 6:12 PM

#

Seem to be getting a reversed winding order here

#

Fixed

#

Box

lethal flicker May 2, 2024, 6:45 PM

#

Round box

lethal flicker May 2, 2024, 7:01 PM

#

I did something wrong

wicked plinth May 2, 2024, 7:01 PM

#

perfect sphere in a 10D curved spacetime

lethal flicker May 2, 2024, 7:02 PM

#

Anyways, quad sphere

wicked plinth May 2, 2024, 7:02 PM

#

sheesh

lethal flicker May 2, 2024, 7:02 PM

#

hmm?

wicked plinth May 2, 2024, 7:02 PM

#

it's clean

#

nice job !

lethal flicker May 2, 2024, 7:02 PM

#

thank you!

#

next up, at some point will be subdividing areas to have more resolution depending on where the camera is

wicked plinth May 2, 2024, 7:03 PM

#

isn't that just LOD

#

am I missing something ?

lethal flicker May 2, 2024, 7:03 PM

#

yeah, but consider this sphere is going to be like 50 kilometers wide or something

#

so the LOD needs to be procedural on the mesh

#

the entire mesh can't be LOD'd

wicked plinth May 2, 2024, 7:04 PM

#

aaah

#

gotcha

lethal flicker May 2, 2024, 7:07 PM

#

You know whats going to be even more fun....
Porting this over to GD Extension at some point

#

did not uv map that correctly

lethal flicker May 3, 2024, 5:44 PM

#

I think my brain has finally cooked up an algorithm

midnight sand May 3, 2024, 5:56 PM

#

This (planet renderer) is something I've actually made before

#

If you want help

lethal flicker May 3, 2024, 6:05 PM

#

That'd be really great

#

I am cooking up something

#

I mostly had to wrap my mind around things such as winding order and how to not have gaps

lethal flicker May 3, 2024, 8:02 PM

#

Aaaaa

#

I was going to work on some proof of concept stuff

#

but gestures vaguely

#

my feels are being hit hard rn

lethal flicker May 4, 2024, 1:49 PM

#

Alright

#

time to work on first a quadtree

#

then a cubic quadtree

barren birch May 5, 2024, 8:38 AM

#

lethal flicker did not uv map that correctly

Classic UV moment

lethal flicker May 5, 2024, 10:44 AM

#

Yeah i know the issue

#

I didnt put 0 on the edge of one of the surfaces

loud maple May 5, 2024, 3:58 PM

#

Messing around with Icospheres. Probably not as practical as Quadspheres, but they look pretty cool

lethal flicker May 6, 2024, 10:36 AM

#

https://onrendering.com/data/papers/cbt/ConcurrentBinaryTrees.pdf

#

This is the approach ksp2 was .... planning ... on using

lethal flicker May 6, 2024, 12:28 PM

#

Hmmmm

#

that's an issue

#

in terms of vertex placement

lethal flicker May 6, 2024, 12:58 PM

#

I'm still missing a ton of vertices here

#

how the fuck does 8 become 9

#

More off by one errors yay

lethal flicker May 6, 2024, 2:54 PM

#

The issue I'm having with quad spheres and icospheres conceptually is making sure there aren't any holes

#

I think I want to test something else out for the moment

#

Like I did it on a plane

#

But I need it on a cube sphere

#

Or just on a sphere

#

And I need it to be a lot more efficient im pretty sure

sleek lion May 6, 2024, 3:01 PM

#

we believe in you, our fearless leader

#

https://tenor.com/view/spongebob-worship-worshipping-now-bowing-gif-12297363

Tenor

#

(in the meantime I'm reading up as much as I can on DOTS)

lethal flicker May 6, 2024, 3:04 PM

#

3d mesh stuff is something I dont really have experience with is all

midnight sand May 6, 2024, 6:57 PM

#

Made a quick multithreaded LOD planet renderer in Godot to check I remembered how

lethal flicker May 6, 2024, 7:00 PM

#

midnight sand Made a quick multithreaded LOD planet renderer in Godot to check I remembered ho...

Okay I might just offload this to you lmao
If thats alright

#

Cuz like ive been strugglingg

midnight sand May 6, 2024, 7:01 PM

#

I can probably make a similar thing in Unity (but Godot is my preferred engine, and I'll likely make my opwn space game anyway)

lethal flicker May 6, 2024, 7:01 PM

#

We also might be using unity cuz ECS

lethal flicker May 6, 2024, 7:11 PM

#

midnight sand I can probably make a similar thing in Unity (but Godot is my preferred engine, ...

Ah, fair enough

#

I think I just need help understanding what to do here, I have gotten a simple quad tree system done (that also isn't the common way to do a quad tree)

indigo gyro May 7, 2024, 4:37 AM

#

Why not procedural based on a hexadecimal sphere (with some pentagons to even it out?)

midnight sand May 7, 2024, 4:41 AM

#

Why would that be better than a tetrahedron, icosahedron, or cube, which only have one type of face and that can be subdivided into themselves?

indigo gyro May 7, 2024, 4:48 AM

#

Hmmm… my thinking was you could make the planet out of tiles (each tile is a certain size and then people can model various tiles with fix side heights) then a planet could be procedurally generated from a tile sets so you’d have a new adventure planet each visit, but not overwhelming to the n-th degree of individually modelling each planet.
