UITK for KSP 2

[stuck jasper]

I guess it makes sense to keep the experimental this way so that they stay last if we add new namespaces

[ebon seal]

yeah and people wont be as inclined to use them

[stuck jasper]

oh and (hopefully) last question, why are they internal?

[ebon seal]

cuz they arent suposed to be used in code

[stuck jasper]

I'm guessing the game will still be able to find them since it uses reflection

[ebon seal]

they just expose them to the UIBuilder

yeah

i think the selector is public tho? or not?

[stuck jasper]

nope, also internal

I should probably change that

[ebon seal]

the exposed ones should stay internal to avoid u using them since they are empty classes

yeah change it

[stuck jasper]

and probably make BaseControl abstract

so it can't be instantiated

[ebon seal]

i dont remember why i didnt make it abstract tbh, but sure

[stuck jasper]

alright, package seems to be working fine

[stuck jasper]

ahhhhh what the fuck

I'm slowly going insane trying to make this work in a reasonable way

nevermind lmao, it was because I was loading the assembly with the custom controls before registering the Harmony patch for Shader.Find

[stuck jasper]

Version 1.3 is now released, featuring:

• Configuration of UI scaling
• Selector custom control and support for many native controls hidden in the Builder
• API to disable dragging on an element, and disabled dragging on TextField by default
• UitkForKsp2.Controls Unity package for easy development of UITK UIs - install using Unity Package Manager from the following Git URL: https://github.com/jan-bures/UitkForKsp2.Controls.git

[ebon seal]

huh

@stuck jasper wasn't it possible to have it in the same git?

why the UITKforKsp2.Controls?

also sorry if i woke u up

[stuck jasper]

Having a Unity solution within another C# solution didn't seem like the best idea

[ebon seal]

oh yeah ur using an actual solution, makes sense yea

[stuck jasper]

Instead I made the Unity project, inside it the package, made the package its own Git repo, made it a git submodule of the Unity project, and a submodule of the UitkForKsp2 solution within its own project

[ebon seal]

oh yeah wtf that works greatly

[stuck jasper]

So now I can update the package from the Unity project, push those changes, and then pull them with one command into UitkForKsp2 and press build, and it's done

Seemed like the best way to go about it

[cyan terrace]

who did stuff.

[ebon seal]

@stuck jasper is it a dependecy for uitk?

[stuck jasper]

you know full well "who did stuff", if you wanna say "munix you fucked up, fix the package", just say it lol

[cyan terrace]

munix you fucked up, fix the package

[ebon seal]

https://tenor.com/view/star-citizen-aurora-get-this-man-a-ban-gif-25968972

[stuck jasper]

done, delete the uitkforksp2 folder from your Nuget cache

and restore again

[compact sandal]

seems that 1.3.0 isn't on CKAN yet

[stuck jasper]

no clue why that would happen, it is on SpaceDock

[stuck jasper]

alright, I've finally started work on proper docs for this

and in preparation for that, I'm now preparing a new template type in SpaceWarp.Template for a UI mod

also I moved the relevant repositories from my personal GH profile to an organization:
https://github.com/UitkForKsp2

mostly to be able to use uitkforksp2.github.io for the docs

[hard onyx]

That reminds me, I'm likely going to have to use KSP2Community.github.io/PatchManager for the patch manager docs

[stuck jasper]

yeah, but I think that's fine for the KSP2 Community mods

we could even make a landing page with links to all the docs for the mods there

[stuck jasper]

I moved the assets for UitkForKsp2 from a regular bundle to addressables, that way when a modder installs the Unity package into their project and builds regular bundles, they will no longer get a rogue copy of the kerbalui bundle

plus I also restructured the UitkForKsp2 project to be more similar to how I did LFO, eliminating the need for a separate 3rd repo just for the Unity project

[stuck jasper]

I'm finally done with the UITK template for SpaceWarp.Template, and I think I did a pretty good job with it, but I'll release it tomorrow, since it's almost 6am and I'm dying

[compact sandal]

Is there a specific reason the struct is named "MoveOptions" and not "DragOptions"?

[compact sandal]

Maybe you could also add CenterByDefault to WindowOptions?

[south tendon]

I don't know how many subdomains we can add to kerbal.wiki but a uitk.kerbal.wiki redirect to the docs would be pretty nice imo

[hard onyx]

I mean we own kerbal.wiki as a domain (or at least shadow does)
I dont see how subdomaining it more would be an issue

[stuck jasper]

Yeah, I don't think that's limited in any way

[stuck jasper]

Not particularly, it was actually named DraggingOptions at first, but MoveOptions just sounded better to me

[stuck jasper]

Sure, that's not a bad idea

Though I'll also need to fix these positioning methods, since they only work if you change the geometry of the window after they're called (so for example when display is changed from none to flex)

I can't really think of a use case where you'd want a window to be showing up automatically on game start, instead of being hidden at first, but I'd still like the methods to be more consistent

(actually I can think of one, the SpaceWarp version checker automatically shows up on first launch of the game)

[compact sandal]

What I'm always doing is creating a window when the tray toggle is activated and destroying it when the window is closed. So in essence I always want to show the window when it's created, no? Or I misunderstood what you're saying.

Also, Micro Engineer has a system that saves window(s) state on each open/close and on each window move/drag, so that it can automatically open whenever Flight, Map or OAB scenes are loaded. So whatever user did last before he closed the game, that's what the window state will be when a new session is loaded.

[compact sandal]

To be pedantic about this (sorry 🙂 ), windows can be moved by dragging, but they can also be moved without dragging (some game event or any other user action that makes the window move its position).
What MoveOptions are setting are the dragging parameters - IsMovingEnabled actually determines if a window can be dragged by the user.

[stuck jasper]

I'm not sure how exactly you handle the displaying/hiding of windows, but usually it's done with rootElement.style.display = DisplayStyle.None or DisplayStyle.Flex

While what I mean by creating the window is calling Window.Create

[hard onyx]

(You should add window.Hide and window.Show extension functions to UITKForKSP2 in that case)

[stuck jasper]

Which most mods do somewhere like in OnInitialized, so as soon as the game is loaded

[compact sandal]

I don't hide the window. When it's closed, I destroy it GameObject.Destroy(document);

[stuck jasper]

It makes sense in your use case where you're updating the window every frame

[compact sandal]

DisplayStyle.None/Flex I'm using only for foldouts and some other special cases, but never to hide the entire window

[stuck jasper]

You don't want it to keep updating in the background

[compact sandal]

Exactly

[stuck jasper]

But even then I feel like using something like gameObject.SetActive(true/false) and handling the starting/stopping of the UI updates in OnEnable/OnDisable might be slightly better, because that way the entire UI doesn't have to be recreated each time

Of course, that's just a minor suggestion

I suppose the performance overhead of recreating the UI is not big enough to be noticeable, though

[stuck jasper]

And yeah, this makes sense, though I can't really change it now that it's released, but I'll take it into consideration for 3.0.0

[compact sandal]

I found it much easier to recreate the UI because ME's window geometry can change a lot. Windows can pop in and out frequently and I didn't want to handle each case. And recreation is done only with user action, never in an Update() or similar, so the overhead isn't noticeable.

But in any case, what I'm just trying to convey here is that I have a need for the window to show immediately when it's created. It's (probably) not a problem if you want to change that behavior if I can get that functionality with an additional command I'll run when creating a window.

[stuck jasper]

Oh no I wasn't talking about changing that

If someone wants their window to he hidden when created, they can just use display: hidden as the default style for their root element, or change it from code right as the window is created

But what I meant is that currently when you call Window.Create(), and then call rootElement.CenterByDefault() or rootElement.SetDefaultPosition(), nothing actually happens, the window will be (usually) in the top left corner of the screen

And only when you first change the geometry of the window, it will get centered/positioned

[compact sandal]

Alright, got it, thanks

[stuck jasper]

So for example if the window has display:hidden and you change it to display:flex, it will get positioned correctly, but if it start with display:flex, and you're not manipulating its geometry in any way, then it just stays in the corner

The repositioning is currently done in OnGeometryChanged because the UI may not be fully created in the same tick where you call Window.Create, and if it is created in time but your UI is hidden by default, it still won't work properly, because it can't calculate the center position of the window when the window visually doesn't exist

So I'll need to work around that to somehow trigger OnGeometryChanged when the window is fully created, but its geometry is not being manipulated

[compact sandal]

It probably won't help, but what I've done in Orbital Survey is that I create the window in a SceneController, then add a MainGuiController component. On OnEnable of that component I'm setting up the positioning. Micro Engineer has a different system, HUMANS also different, I'm changing things each time 🙂

[stuck jasper]

actually now I'm looking into the code for the SpaceWarp version checking dialog, and it seems it works there without any workarounds

but for the UITK template I made yesterday, it doesn't work

interesting

var avcDialogUxml = AssetManager.GetAsset<VisualTreeAsset>( $"{SpaceWarpPlugin.ModGuid}/avcdialog/ui/avcdialog/avcdialog.uxml");
var avcDialog = Window.CreateFromUxml(avcDialogUxml, "Space Warp AVC Dialog", ui.transform, true);
var avcDialogController = avcDialog.gameObject.AddComponent<AvcDialogController>();
avcDialogController.Module = VersionChecking.Instance;

// AvcDialogController.Awake:
var document = GetComponent<UIDocument>();
document.EnableLocalization();
var container = document.rootVisualElement;
container[0].CenterByDefault();

vs.

var myFirstWindowUxml = AssetManager.GetAsset<VisualTreeAsset>($"{ModGuid}/SpaceWarpModUI_ui/ui/myfirstwindow/myfirstwindow.uxml");
var windowOptions = new WindowOptions
{
    WindowId = "SpaceWarpModUI_MyFirstWindow",
    Parent = null,
    IsHidingEnabled = true,
    MoveOptions = new MoveOptions
    {
        IsMovingEnabled = true,
        CheckScreenBounds = true
    }
};

var myFirstWindow = Window.Create(windowOptions, myFirstWindowUxml);
var rootElement = myFirstWindow.rootVisualElement;
rootElement.CenterByDefault();

I feel like if the first one centers the window correctly, the second one should as well, but that is not the case

theoretically it could be the document.EnableLocalization(); call in the first snippet that makes it work, actually

since the localization component updates the text of elements

and that probably fires the OnGeometryChanged event

[compact sandal]

In the first case you're calling CenterByDefault for the first element in the root and in the second case on the root itself?

[stuck jasper]

actually it does that in Awake, which should go through before the CenterByDefault method is called

I'm not sure

[stuck jasper]

that's... a good point lmao

I'll try that

I'm blind

yeah that was the issue

[compact sandal]

nice

[stuck jasper]

since the root is the TemplateContainer that doesn't change in size at all

it needs to target the actual root VisualElement

which is its first child

thanks!

[stuck jasper]

and yeah that is a good idea

[stuck jasper]

and now, big sigh, forum thread for this

though I might just wait until I have the documentation ready

[hard onyx]

Just light a fire under your ass by making the forum post like me

[stuck jasper]

lmao I guess it will be one way to motivate me

[dense bison]

So I'm thinking about updating the template uss to make drop downs better match the default game, if you haven't already done that as part of the update

[compact sandal]

If you mean the dropdown tray that pops up when the control is clicked, a while ago I desperately tried to find a selector to hide the big ugly checkmark. My conclusion was that it could only be done from the theme, since that selector is not accessible from individual mod uss files.
So, go for it! It would be nice to have a style that is more appropriate. It would be even better if the theme could somehow expose those selectors so mods could override it with their settings.
To help you out, check this: #🔴mod-dev message

[dense bison]

Yeah, I think I should be able to change the background color to something more like the stock controls at least. The default drop down text that's not part of the drop-down list is also the same color as the background, at least for me, so I wanna fix that too. Right now I've been using html like color codes the override the color, but it feels like a bit of a hack.

[stuck jasper]

Creating a new custom dropdown control is next up on my to-do list for UitkForKsp2

But yeah, the default one could also use some extra styling, I've been kinda putting it off but I really need to add styles for all the controls that are new in 2022.3.5

[dense bison]

Here's my attempt at making the controls a little more consistent with each other and the base game

Dropdown text color fixed too

[hard onyx]

Looks nice

[stuck jasper]

looks great, thanks for doing this!

[dense bison]

By the way, whats the reason for the seperate KerbalUI and UitkForKsp2 uss themes?

[stuck jasper]

well, mostly just for the sake of organization

KerbalUI is the theme for the native controls, and the UitkForKsp2 USS contains styles for custom controls

[dense bison]

Ah, okay. I was curious, since most of the settings were in KerbalUI, but I had to override a setting in UitkForKsp2 in order to get the labels to all line up

[stuck jasper]

oh, that's weird, what was it?

[dense bison]

.unity-popup-field .unity-text-element {
    -unity-text-align: middle-left;
    margin-right: 0;
}

I had to change that -unity-text-align from top-center to middle-left

[stuck jasper]

oh yeah I suppose this was in that file because some controls were experimental in 2020.3.33 and Lux wrote a wrapper for them to be displayed in the UI builder

and so they were technically custom elements and their styles probably ended up in the UitkForKsp2 file

I'll need to do some general refactoring of the stylesheets and controls, it's a mess

and a lot of it is not needed anymore in the new Unity version

plus I wanted to start laying down a framework for the support of multiple different themes, at first simply as a per-window choice for the modders using them, as something like an overrideable USS variable or a class on the root element, and later possibly even as a user-configurable global setting

[dense bison]

I've only tested it in the unity scene, so I don't feel comfortable pushing my changes just yet, but I've forked the repo and made a commit at https://github.com/coldrifting/UitkForKsp2.Controls/, if you're interested in seeing the changes

[stuck jasper]

will do when I get the chance, thanks

[dense bison]

Multiple themes sounds cool, btw

[stuck jasper]

just wanted to clarify some of the choices I made, for example the text boxes are based on this:

[cyan terrace]

omg why

[stuck jasper]

though in hindsight, it would probably be better to do what you did and make the controls look more consistent with each other rather than trying to perfectly match the game

[stuck jasper]

there are a lot of choices made in the game's UI design lol

[cyan terrace]

wait thats in the games ui

[stuck jasper]

yes

[cyan terrace]

@trail stag please fix. I cannot unsee.

[hard onyx]

Eww

[stuck jasper]

another fun one right in the same window is the save button

this is the active (currently clicking on it) state

lmao

[cyan terrace]

thats not good.

[hard onyx]

Thats ... very slughtly off center isnt it or are my eyes playing tricks

[stuck jasper]

not sure, but the disappearing text feels like the bigger problem here lmao

[cyan terrace]

2px out

[hard onyx]

I knew it

[stuck jasper]

lol

[cyan terrace]

I think they should push 0.2.0.0 back a bit for this

[stuck jasper]

[hard onyx]

We should file a bug report

[cyan terrace]

heres the fixed save button

[stuck jasper]

honestly, I think I might put together a whole forum post with feedback regarding all of the UI inconsistencies

it'll probably be more useful than whining here

[hard onyx]

Yeah I can somehow notice the 2px difference

[stuck jasper]

and it's something that's been annoying me since 0.1.0

[cyan terrace]

file

[hard onyx]

Ill be honest that doesnt look much better

The line being skewed i hate

[hard onyx]

Move the x right a bit

[stuck jasper]

I feel like the line should end before the x

yeah

that too

[stuck jasper]

since it signifies the place where text is written, and the x is beyond that point

[cyan terrace]

added some line ends

[hard onyx]

Thr gap between the x and the line end should equal the gap between the x and the border

So either shrink one or grow the other

Thats my opinion tho

[cyan terrace]

its the same

[stuck jasper]

re: inconsistencies

these are all buttons accessible in the VAB

[cyan terrace]

wait you mean 1 sec

[stuck jasper]

and there are many more outside of it

[stuck jasper]

yeah that looks good

[cyan terrace]

this mostly seems like they kept old uis

[hard onyx]

(My last suggestion would be make the x bigger maybe

[stuck jasper]

I wouldn't even say that, it's more like literally every single window they made is made from scratch, independently on all others

[stuck jasper]

can't explain why every single one would have a different style for buttons, for dropdowns, for toggles, etc

like, just make a centralized library of UI controls that you reuse for god's sake

[hard onyx]

Looks nice, just needs a higher res x, which i wont have you do

[hard onyx]

UITK

Just fucking use UITK

[stuck jasper]

but it's also doable in uGUI

even if it's slightly more difficult

[hard onyx]

Ooo

[stuck jasper]

@ Dakota forget what I said about hiring us for modding, just hire me for UI smh

[hard onyx]

But they have access to UITK, and if they want to make it easier, then they should use it

[stuck jasper]

yeah but I don't see that happening

they'd have to start UI from scratch

[hard onyx]

plus we could use their themes and such if they did

[cyan terrace]

maybe I should just go for one of the design roles.

[stuck jasper]

including the supporting systems, not just the UI itself

[compact sandal]

https://discord.com/channels/1039959585949237268/1179932864968671342

[stuck jasper]

to be fair that's more so about the actual UI/UX as a whole functionally, while what I'm more concerned about are the various styles

I don't know how to put it well

(plus it is closed)

[compact sandal]

To the forum then: https://forum.kerbalspaceprogram.com/topic/221025-ui-ux-feedback-megathread/

[dense bison]

I can't remember, does the text box also turn green when you select it? That was the thing that bugged me the most

[stuck jasper]

yeah

that's from the game

[dense bison]

Eww lol

[stuck jasper]

I'm putting together all the references of inconsistencies I can find, and will 1) make a post/thread about it on the forums, 2) use it to try to make a somewhat coherent style for UitkForKsp2

[dense bison]

Great idea

I think my biggest beef with the UI is the non native Scaling of pixel graphics. Hence the mod I'm working on

[stuck jasper]

yeah, it will be awesome to have that

[stuck jasper]

here is what I came up with - basically just dumped it all into Figma, categorized and saved to PDF for easier panning around/zooming

the list is not comprehensive, and many of the styles are replicated among many different UIs

but I did attempt to get at least one of each style of the main types of controls

https://www.figma.com/file/E3sOOr56TNFCL9eEjGBQjA/KSP2-UI-Reference

here's the source

~30 different button types

[stuck jasper]

(and the PDF is already outdated lol, I forgot to check the Wing Shape window and of course it had a differently colored toggle)

well, now that I have this, next up will be taking a look at the KerbalUI theme, and UitkForKsp 3.0

I'll probably do a couple of pre-releases so that people have the time to update their mods, and I can help out with some pull requests during that time, since I'm the asshole who wants to break compatibility, not them

but hopefully 3.x will stick around for a longer time

the current API is not very different from the days of like version 0.4

so it really needs some updates, it definitely hasn't aged and scaled well

it will probably take some time before I get that done, but then, finally the docs

I decided it's useless to write extensive documentation for the current version if I'm going to be changing a lot of stuff

[dense bison]

Sounds great! Better to get radical changes out of the way while the modding community is relatively small anyways IMO

[dense bison]

BTW what resolution did you take those screenshots at? Because if it's not 1080p there's probably gonna be some artifacts. I think I noticed some on one of the PAM toggles.

[compact sandal]

Can you create a new "KerbalUI2" theme and leave "KerbalUI" as is? I'm not keen on updating all my mods tbh

[stuck jasper]

that won't be that easy to do, since to have more concurrent themes, I'd have to create multiple PanelSettings, and an API to control which UI Documents are created in which

what I can do is make the old styles available with some class on the root element, like <VisualElement class="root theme-legacy">...</VisualElement>

is that good enough?

[stuck jasper]

yep, it was 1080p

[hard onyx]

Uhhh theres got to be a better way than multiple panel settings

[stuck jasper]

well, yeah, the alternative I suggested

[hard onyx]

Yeah but in general

[stuck jasper]

themes are inherently linked to PanelSettings

so you can either swap out the theme globally, or make different styles accessible through different classes

or, make more panels

those are the only options I can think of

[hard onyx]

Hmm, could you not basically make the theme nothing, and dynamically apply the USS to a document when its created

Or is there some stuff that has to be in a theme

[stuck jasper]

not really, no, there is no real need for a theme, though I feel like it's nice to have a sensible default

but applying USS dynamically sounds a bit like overkill, when you can just add a class to the root element

[hard onyx]

It doesnt sound like overkill to me tbh but I getcha I suppose

[stuck jasper]

the issue with the dynamic approach is I'm not sure how easy it would be to do, you might have to recursively traverse the document tree and apply the styles to all elements in it

I suppose I can look into it, but I don't think it will be as simple as changing a property on the root element

[hard onyx]

Is there not a stylesheet property on the VisualDocument?

[stuck jasper]

ah yeah you're right, element.styleSheets.Swap(...) might do the trick

good to know, adding support for the user settings of themes should be much easier with that

[hard onyx]

Also, this may have been the cause of the reflektor offsetting issue

[stuck jasper]

I'll take a look at it in UE

nope that's not it, the two objects with UIDocuments are next to each other, and parentUI is null on both

[hard onyx]

Ahh

Was just a theory

[compact sandal]

If you'll stick with your original idea, what would I need to do exactly? Just add a theme-legacy class to the root and that's it?

[stuck jasper]

yeah

the other option is what Cheese suggested, adding some sort of an API to change styles when creating the window in C#

like adding an enum with the existing themes and then adding a parameter to WindowOptions for that

[compact sandal]

That'd be sweet

[stuck jasper]

I'll probably do that, then

[stuck jasper]

@dense bison finally took the time to look at your changes, and the dropdowns look great!

however, this is why I couldn't just style Toggle without adding a class to it, because it is automatically created inside some other controls like the foldout

resulting in this

[dense bison]

Thanks! Ah that's too bad. I was hoping to avoid custom controls

[dense bison]

Fixed the foldout. Are you aware of any other classes that have the toggle?

[stuck jasper]

not aware of anything else

though it might be used for the TreeView/MultiColumnTreeView

if I had to guess

it's hard to test since you have to generate the content of these dynamically

[dense bison]

Hmm, I was messing with treeview a lot before I switched refektor to use a list and I didn't see one anywhere. I think it's only there if you add it

[stuck jasper]

I was guessing because of this page in the docs

[dense bison]

Right, you have to use code to make that though, it doesn't come like that

[stuck jasper]

yeah, that's what I meant by saying it has to be generated dynamically

[dense bison]

In any case, here's the uss for the foldout fix

.unity-foldout > .unity-foldout__toggle > .unity-base-field__input {
    min-width: 100%;
    max-width: 100%;
}

.unity-foldout > .unity-foldout__toggle > .unity-base-field__input > .unity-toggle__checkmark,
.unity-foldout:hover > .unity-foldout__toggle > .unity-base-field__input > .unity-toggle__checkmark,
.unity-foldout:active > .unity-foldout__toggle > .unity-base-field__input > .unity-toggle__checkmark,
.unity-foldout:inactive > .unity-foldout__toggle > .unity-base-field__input > .unity-toggle__checkmark {
    -unity-background-image-tint-color: #d5dfff;
    border-width: 0px;
    background-color: transparent;
    background-image: resource(arrow-right);
    max-width: 24px;
    height: 24px;
}

.unity-foldout:checked > .unity-foldout__toggle > .unity-base-field__input > .unity-toggle__checkmark {
    background-image: resource(arrow-down);
    top: 1px;
    right: 1px;
}

[stuck jasper]

ahh, the arrows are in resources, of course

[dense bison]

Yeah, took me a bit to figure that one out

[stuck jasper]

to be fair it wouldn't work in KSP pre-0.1.5 since it didn't have UITK built-in, so I'm giving myself a free pass

lmao

but it's nice that we have it now, thanks

another thing is I'm not sure whether to make the one we have now the default for the toggle, or the more traditional checkbox one

(they look similar to the radio buttons but they are in fact checkboxes)

[dense bison]

Ah. I think those look a lot like radio buttons, so they probably shouldn't be toggles. I don't think it should be just a checkbox either though. I do like the current one, though I'm not sure if I like how it's offset to one side

I wouldn't mind the PAW toggle either though

That's probably harder to write USS for though

[stuck jasper]

hm?

[dense bison]

I think it's offset to the side in the Mods window on the main menu

Not sure if it is everywhere. I did change it to be centered in the USS i wrote

[stuck jasper]

then it's most likely due to scaling

[dense bison]

Oof. KSP2 scaling strikes again lol

[stuck jasper]

looks ok at 1080p

[stuck jasper]

yeah, the scaling of elements with 1px wide stuff like borders and text is just bad

[dense bison]

1440p

[stuck jasper]

yeaah

that's the issue with trying to display 1.3333px wide borders and paddings

lmao

[dense bison]

makes sense

[stuck jasper]

this is how Unity renders it at 1440p for me

not much better

[dense bison]

Oh yeah, you're right

[stuck jasper]

only looks good in 4K

[dense bison]

Let me see if maybe I can fix that

Yeah, 4K is double pixel scale, so it should be fine

[stuck jasper]

yeah

[dense bison]

By the way, if you change .unity-text-field to .unity-base-text-field you'll also style the float, int, long, and double input fields with the same selector

[stuck jasper]

yep, already did that

[dense bison]

Sweet

[stuck jasper]

Actually could you please send me the full foldout USS? I still seem to be having some issues

first the background was green for one of the visual elements so I fixed that, but still having padding/margin issues and don't feel like investigating right now when you have it correctly

😆

[stuck jasper]

ah, then I see we had a similar idea lol

you have top: -4px; and I "fixed" it with margin-top: -5px;

[dense bison]

Ah, yeah I was trying to make the arrow appear to pivot around the center

[stuck jasper]

how I wish we had something like SCSS for Unity

.unity-foldout {
    background-color: #2e3540;
    border-radius: 6px;
    border-width: 2px;
    border-color: #354051;
    color: #c0c7d5;

    > .unity-foldout__toggle {
        color: #d6e0ff;
        margin: 2px;
        border-radius: 6px;
        padding: 0;

        &:hover {
            background-color: #3f4487;
        }

        &:checked,
        &:active {
            background-color: #4b50b0;
        }

        .unity-text-element {
            padding: 0;
            margin: 2px;
            color: #ffffff;
        }

        // ...
    }
}

something like this would be so much easier to read (and write)

[dense bison]

Yeah css can get ugly real fast

[stuck jasper]

and meanwhile I'm planning to duplicate every single selector to support themes

e.g.

.theme-default .unity-foldout > .unity-foldout__toggle,
.root .unity-foldout.theme-default > .unity-foldout__toggle {
   /* ... */
}

so that there's both a default style for the theme, and a way for windows with other themes to use the controls from other themes

[dense bison]

Crazy idea, but maybe we could generate uss from a template?

[stuck jasper]

hmmm

https://forum.unity.com/threads/editor-scss-importer-library.1233940/

hmmmmmmm

I'm willing to give this a try

[dense bison]

Interesting, nice that there's a package for it

[stuck jasper]

yeah, I like the idea a lot

I'll head to bed now but I'll definitely take a look at it tomorrow

[dense bison]

💤

[stuck jasper]

thanks for all the help by the way!

[dense bison]

NP. It's something I'm interested in, so I def want to help if I can.

[stuck jasper]

woah I just discovered this completely randomly lol

[dense bison]

Oh cool!

[stuck jasper]

might have to add some sort of an indicator to make it obvious

[dense bison]

Oh, forgot that SCSS has variables. Nice.

[stuck jasper]

yeah, though I've been using the native CSS/USS ones with no issues

[dense bison]

Ah, I forgot that default css has that, ha

[stuck jasper]

for example

I definitely want to use them more often, for stuff like common colors, etc.

the stylesheet is a hot mess right now

[dense bison]

Yeah, it's really easy to just add one thing, and then one more thing, etc, and suddenly your central rules aren't as central as you'd like

[stuck jasper]

indeed

another reason why I'm glad I'm doing what's probably going to be almost a full rewrite of both the styles and the code

hindsight is 20/20

[dense bison]

Hey, refactoring is FUN

[stuck jasper]

honestly, it's some of the most fun I have when coding

seeing your old stuff and knowing exactly how you want to improve it is great

[dense bison]

I get so much satisfaction from completing a refactoring and cleaning up the code. It's like cleaning for me

Yeah, this package is great. Looks like you can still edit and have it refresh in real time

[stuck jasper]

Damn, I can hear people outside my apartment leaving for work

That's how I know it's really time for bed lmao

[dense bison]

Oof, you're in europe right? I'm on night shift, so my schedule is already all f'd up

[stuck jasper]

Haha yeah, almost 6am

[dense bison]

Just woke up a few hours ago

[hard onyx]

Damn thats cool

[stuck jasper]

Yeah, I'll try it out in a bit

If it works well, I might start using it for all my UITK projects

USS selectors get stupidly long and ugly really fast

[hard onyx]

Imagine patch manager without the nested selectors

[stuck jasper]

Oh god

[hard onyx]

I dont think it would actually work as you need the variables from outer selectors

[dense bison]

So it's still a bit incomplete, but I've been working on converting the KerbalUI theme to SCSS

Feel free to steal anything from here if you want

[hard onyx]

Thats much nicer lol

[hard onyx]

having variables like that is like please

[dense bison]

By the way from my testing it seems that the SCSS addon doesn't like // comments inside block comments

[hard onyx]

Just always use /* comments */ tbh

[stuck jasper]

this hybrid of USS and SCSS should be called SUSS

[dense bison]

Nice

[stuck jasper]

ahhh this is annoying

I wish USS had @font-face

so that I could define new fonts and then reference them with their name

being unable to do that really sucks when using imports

since I define variables for font assets like $font-regular: url('../../Theme/Fonts/JetBrainsMono/JetBrainsMono-Regular SDF.asset'); in one file, but the variable is only evaluated in the file inside which I import the definitions

so for example having a folder structure like

• Theme
  • Fonts
  • Styles
    • _common.scss ($font-regular definition here)
    • some-folder
      • styles-1.scss
      • subfolder
        • styles-2.scss

I can only use the above definition of $font-regular in styles-1.scss, but not in styles-2.scss, because the path is invalid

I guess I can do absolute paths but jeez

[hard onyx]

You can do the paths based off of Assets/

at least

as the CWD is always the folder above assets

[stuck jasper]

well this is a package

[hard onyx]

Wait nvm then

yeah, absolute paths not gonna work then

[stuck jasper]

I mean packages have absolute paths too

Packages/uitkforksp2.unity/Assets/Theme/Fonts/JetBrainsMono/JetBrainsMono-Regular SDF.asset should work

but it's ugly

lmao

[dense bison]

Yeah, abs paths are kinda gross.

I've been working on the SCSS some more, got progress bars, radio buttons, and cleaned up the scroll bars a bit

[stuck jasper]

plus Rider doesn't like these

but they do work

[dense bison]

Does each theme need it's own folder?

Oh, never mind saw the root folder

[stuck jasper]

I prefer to keep them separated

for now I'm pretty happy with this folder structure

I might even further split controls and containers from native-controls

[dense bison]

Fair, looks good.

I think if a theme had only a single file it would be fine, but otherwise i would def want sep folders

[stuck jasper]

just to have everything nicely organized, instead of having comments for it

lmao

[hard onyx]

Wow just seeing how nice that organization looks using scss, we should've been using it earlier

[stuck jasper]

I mean theoretically all this is doable with just USS

I haven't actually started converting into SCSS yet

[stuck jasper]

(though I definitely will make use of this, thanks)

[dense bison]

NP

Trying out a little tweak with the dropdowns

[hard onyx]

Are you using both the executable and importer package?

[stuck jasper]

yeah

so that anyone who wants to build the project doesn't have to have Sass installed

[hard onyx]

makes sense

[stuck jasper]

[Error  : Unity Log] NullReferenceException while executing 'performed' callbacks of 'MapView/Focus[/Mouse/leftButton,/VirtualMouse/leftButton]'
[Error  : Unity Log] NullReferenceException: Object reference not set to an instance of an object
Stack trace:
KSP.Map.Map3DManeuvers.TryGetParentItemUnderCursor[T] (T& item) (at <483cd9805b7642b5be13e081b9a5d1b4>:0)
KSP.Map.MapCore.OnFocus () (at <483cd9805b7642b5be13e081b9a5d1b4>:0)
KSP.Input.InputActionBinder.Invoke () (at <483cd9805b7642b5be13e081b9a5d1b4>:0)
KSP.Input.InputDefinition.TriggerAction (System.String id) (at <483cd9805b7642b5be13e081b9a5d1b4>:0)
KSP.Input.MapViewInputDefinition.OnFocus (UnityEngine.InputSystem.InputAction+CallbackContext context) (at <483cd9805b7642b5be13e081b9a5d1b4>:0)
UnityEngine.InputSystem.Utilities.DelegateHelpers.InvokeCallbacksSafe[TValue] (UnityEngine.InputSystem.Utilities.CallbackArray`1[System.Action`1[TValue]]& callbacks, TValue argument, System.String callbackName, System.Object context) (at <5b4eda9332d34a6f90f7ed9a858088a9>:0)
UnityEngine.InputSystem.LowLevel.<>c__DisplayClass7_0:<set_onUpdate>b__0(NativeInputUpdateType, NativeInputEventBuffer*)
UnityEngineInternal.Input.NativeInputSystem:NotifyUpdate(NativeInputUpdateType, IntPtr)

[Error  : Unity Log] NullReferenceException while executing 'performed' callbacks of 'MapView/Focus[/Mouse/leftButton,/VirtualMouse/leftButton]'

this is quite annoying though

it's caused by using the input locks

it seems to cause some glitches in interactions with the game's UI, too

haven't noticed anything game-breaking, but it's annoying

but it's weird because the game uses these input locks just like we do

https://www.figma.com/file/sLxntIRNVZMbMAArf1PlL5/UITK-for-KSP-2-Reference

here's the latest reference file by the way

it should have references for all the basic types of controls for all three themes

I don't intend to follow everything exactly as it is in the game (because damn, are some of the choices the game UI makes interesting)

but I feel like the general styles of the controls fit relatively well with each other for each theme

[dense bison]

By the way, while you're working on the stylesheets, can you change the default hover color of lists?

[stuck jasper]

oh yeah, for sure

just for context, the reason why we didn't use ListViews (and so we had no reason to style them) is because in 2020.3.33, their items could only have fixed height, and generally there were quite a few issues with it, with even the Unity devs recommending it just for very large uniform lists of 1000s of items

but it looks like it's much more usable now

[dense bison]

Gotcha. Yeah, I gave up on them on the inspector, but I do like having the highlight for the game object children list

You can fake it with events, but it's not always consistent

[stuck jasper]

it should be possible to just add styles with :hover to almost everything, that's what we do in the SpaceWarp modlist I'm pretty sure

actually let me check before talking lol

[dense bison]

I've been avoiding having to bundle USS stylesheets, since it's easier for me to do stuff in raw C#, and to my knowledge you can't style psuedo states in C#

[stuck jasper]

ah, yeah, gotcha

(well, you can add pseudostate styles in C#, but it will be a pain in the ass)

[dense bison]

Really?

[stuck jasper]

I'm pretty sure I saw something like that when inspecting some element styles with UE, let me check

uhh yeah it's definitely not worth it, you'd probably have to mess with the styleSheets property and manually create the structure that would be normally created when compiling USS into a bundle

[dense bison]

Ha, thanks for checking. Pain in the ass indeed

[hard onyx]

Just create our own runtime scss parser

[stuck jasper]

I mean

there is one already

https://onejs.com/docs/runtimeuss

(it is $70 though)

or $35 now on sale lol

and since Unity uses a fork of ExCSS (https://github.com/TylerBrinks/ExCSS), it should be possible to use that for parsing and then just reverse engineer the structure they use for their stylesheet objects

[dense bison]

I'm already on like side project #4 right now ha

[stuck jasper]

from the example it looks very similar to the USS stylesheet objects

so yeah, theoretically we could in the future add runtime USS parsing, so that USS files don't have to be bundled

but it's very low priority

[dense bison]

I just wish I could use the unity UI Toolkit debugger in the game

[hard onyx]

Aight bet

Project #4 incoming

[stuck jasper]

oh no, now Cheese is going to make this before 0.2.0 drops

[hard onyx]

I havent even gotten outta bed

I think im going to use loading actions, and allow for fonts/images to be loaded using space warps asset manager

[stuck jasper]

oh wait, they have the fork on GitHub https://github.com/Unity-Technologies/ExCSS

[hard onyx]

Well that makes it dead easy dont it

[stuck jasper]

though it's probably not the version they're using now

since the last commit was 3 years ago

but it's a start

[hard onyx]

Ill probably go from the original version to handle my own font parsing and such

I really want a scss parser tho

[stuck jasper]

oh lawd

[hard onyx]

I feel like users would like that better

[stuck jasper]

I suppose extending the ExCSS parser with just minor stuff like nesting would be relatively easy

though I mean, at this point you might be better off to start from the SassyPatching project in Patch Manager

since that almost fully implements SCSS lol

[hard onyx]

Not well
It doesnt allow you to do

:parts {
    > {
    }
}

You have to have * on both sides of that >

[dense bison]

Not sure if this is really a bug, but It looks like if one character is selected and you type that same character in, it won't remove the selection until you type anther character, which gives the impression that the text field isn't updating.

This is on 2.4.0 btw

[stuck jasper]

interesting, that must be a UI Toolkit bug then

[dense bison]

@stuck jasper I don't suppose you figured out that weird offset bug when unhiding another window, did you? Still running into it...

[stuck jasper]

no clue about it, sorry

I tried looking into it and saw the symptoms but I have no idea what causes it

but there has to be something specific to your approach, because I haven't seen the issue in any other mod

[dense bison]

Dang. Thanks for looking into it.

Figured it out!

Set the position of the root visual element to absolute

Maybe that should be done if the window has a drag manipulator by default?

[stuck jasper]

ahh I'm stupid, I literally thought about that being a possible fix earlier

and then completely forgot

[dense bison]

Don't know why I didn't realize sooner, ha

[stuck jasper]

though it still is strange

you're creating new UIDocuments, right?

and they're basically not related in any way

so this shouldn't be happening as far as I'm concerned

[dense bison]

As far as I can tell, they have seperate root gameobjects, which each don't have a parent

sep window ids

[stuck jasper]

yeah, Cheese suggested checking the documents' parent IDs, and they were null

so they shouldn't be affecting each other's transforms

it's strange

[dense bison]

GameObject rootGameObject = new GameObject("_Inspector");
DontDestroyOnLoad(rootGameObject);

GameObject rootGameObjectBrowser = new GameObject("_Inspector_Browser");
DontDestroyOnLoad(rootGameObjectBrowser);

WindowOptions winOptions = new WindowOptions
{
    WindowId = rootGameObject.name,
    Parent = rootGameObject.transform,
    IsHidingEnabled = true,
    DisableGameInputForTextFields = true,
    MoveOptions = new MoveOptions()
    {
        CheckScreenBounds = false,
        IsMovingEnabled = true
    }
};
WindowOptions winOptionsBrowser = winOptions;
winOptionsBrowser.WindowId += "_Browser";
winOptionsBrowser.Parent = rootGameObjectBrowser.transform;

_inspectorWindow = new Inspector();
_browserWindow = new Browser(_inspectorWindow);

var v1 = Window.Create(winOptions, _inspectorWindow);
var v2 = Window.Create(winOptionsBrowser, _browserWindow);

v1.rootVisualElement.style.position = Position.Absolute;
v2.rootVisualElement.style.position = Position.Absolute;

[stuck jasper]

you're basically doing the same thing that SpaceWarp does when creating its windows

and I don't think we've had to use absolute positions anywhere

oh but wait a minute, the one difference is that most other mods create the visual tree from an asset, which places it inside a TemplateContainer

could it be that the TemplateContainer is by default positioned absolutely?

Checking that right now

yep there it is

the TemplateContainer is by default absolutely positioned

so UIs loaded from UXML don't have the issue

[dense bison]

Interesting

[stuck jasper]

but also, I'm updating the API so that UIs loaded from UXML don't have the TemplateContainer as the root, instead having its first child as the root

so that it's consistent across all the ways that you can create a window

I'll add an option which wraps the UI in another root element and makes it absolute, though

so that current UIs don't have to be rebundled, only needing a change on the C# side

though I'm not sure how necessary/useful that will be when a lot of other things will be incompatible anyway

[stuck jasper]

soooo, time to redo the UI reference

lmao

they fixed a lot of the issues I had with the UI

[hard onyx]

@stuck jasper

[stuck jasper]

yeah I've seen this

Actually the semi-transparent background might be really cool for the small theme

also that's two new styles for switches/radios in this update

this and the cheat menu

[hard onyx]

FUCKING ALT F8 DOESN'T WORK FOR ME

It brings up nvidia

fucking hell

[stuck jasper]

[dense bison]

All the styling in my code is getting a bit too much, so I'm thinking about bundling USS. How can I do that?

[stuck jasper]

I would recommend using the UI template from SpaceWarp.Template to get started, it will generate a full C# solution which you don't need since you already have one, but it will also generate the Unity project for you

and you can use that to get started

it will be in src/ProjectName.Unity/ProjectName.Unity

[dense bison]

Ah, found it on github. thanks

[compact sandal]

https://github.com/Micrologist/MicroEngineer/issues/41
@stuck jasper, I've noticed this as well. Could it be because I'm recreating windows on state changes?

[stuck jasper]

I'll look into it

[stuck jasper]

it really shouldn't be caused by destroying and creating the windows

as far as I can tell, that should actually make it more reliable than for example just calling SetActive(false/true)

I went through my code again, went through your code, and so far I have no clue

ah I think I found the issue

it's most likely a bug in the stock game, rather than in UITK or ME

[Error  : Unity Log] NullReferenceException
Stack trace:
UnityEngine.Component.GetComponent[T] () (at <241ca07620644274b99c2f9d1288d0ab>:0)
KSP.Map.Map3DFocusItem.ToggleIconVisibility () (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.InputActionBinder.Invoke () (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.InputDefinition.TriggerAction (System.String id) (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.GlobalInputDefinition.OnToggleUIVisibility (UnityEngine.InputSystem.InputAction+CallbackContext context) (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
UnityEngine.InputSystem.Utilities.DelegateHelpers.InvokeCallbacksSafe[TValue] (UnityEngine.InputSystem.Utilities.CallbackArray`1[System.Action`1[TValue]]& callbacks, TValue argument, System.String callbackName, System.Object context) (at <eec8b0f7e605454fa749d62d287ae90f>:0)
UnityEngine.InputSystem.LowLevel.<>c__DisplayClass7_0:<set_onUpdate>b__0(NativeInputUpdateType, NativeInputEventBuffer*)
UnityEngineInternal.Input.NativeInputSystem:NotifyUpdate(NativeInputUpdateType, IntPtr)

[Error  : Unity Log] NullReferenceException while executing 'performed' callbacks of 'Global/ToggleUIVisibility[/Keyboard/f2]'
[Error  : Unity Log] NullReferenceException
Stack trace:
UnityEngine.Component.GetComponent[T] () (at <241ca07620644274b99c2f9d1288d0ab>:0)
KSP.Map.Map3DFocusItem.ToggleIconVisibility () (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.InputActionBinder.Invoke () (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.InputDefinition.TriggerAction (System.String id) (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
KSP.Input.GlobalInputDefinition.OnToggleUIVisibility (UnityEngine.InputSystem.InputAction+CallbackContext context) (at <dd6137ea2e634c0ba20d8eb5ac23d499>:0)
UnityEngine.InputSystem.Utilities.DelegateHelpers.InvokeCallbacksSafe[TValue] (UnityEngine.InputSystem.Utilities.CallbackArray`1[System.Action`1[TValue]]& callbacks, TValue argument, System.String callbackName, System.Object context) (at <eec8b0f7e605454fa749d62d287ae90f>:0)
UnityEngine.InputSystem.LowLevel.<>c__DisplayClass7_0:<set_onUpdate>b__0(NativeInputUpdateType, NativeInputEventBuffer*)
UnityEngineInternal.Input.NativeInputSystem:NotifyUpdate(NativeInputUpdateType, IntPtr)

[Error  : Unity Log] NullReferenceException while executing 'performed' callbacks of 'Global/ToggleUIVisibility[/Keyboard/f2]'

[hard onyx]

thats the F2 bug that causes the orbit line issue

[stuck jasper]

this exception happens when pressing F2 in the Map View, and it prevents UITK from hiding its windows

[stuck jasper]

ah good to know

[hard onyx]

well rather that bug is a side effect of a deeper bug that causes it

[stuck jasper]

@compact sandal so not much to do about it other than actually fixing the game's bug

which I think Cheese was able to do with a preload patcher?

[compact sandal]

It's strange that it happens only for Micro Engineer. I'm testing with both Micro Engineer and Orbital Survey windows open and it consistently happens only for ME, never for Orbital Survey. And I used almost an identical approach with Orbital Survey. I think there may be something different with ME that's causing this. I'm recreating the UI at each state change, so Flight -> Map -> Flight causes 2 refreshes. That might be messing things up. Might try to ignore state changes for Flight <-> Map to see if that fixes it.

(the reason it's like this is that earlier I had the idea of having different parameters for windows in Flight and Map states, you could have different windows shown, different positions, etc. But I abandoned the idea a while ago)

[silk zealot]

Is there a public tracker like GH Projects for UITK for KSP2? I'd like to contribute adding some more base Widgets if contributions are welcome; I think a standard Window could be helpful for example

Plus I'd really like to find a way to block scrolling (mouse wheel event) to influence Gameplay while scrolling inside a window ;_;

[stuck jasper]

I don't really have anything like that, but I definitely welcome contributions

though, currently UITK is in the process of basically a complete rewrite of both the library and the themes, for the 3.0 update

[silk zealot]

Oh! Awesome ❤️

[stuck jasper]

the current API has had just pretty small (and almost always just additive) updates since like version 0.3.0, which was very experimental

and since then I've mostly just been slapping on more and more code on top of that, to keep backwards compatibility, and the result after many months isn't very nice

and now after the library has actually been picked up by multiple modders, I feel like I have a pretty good idea of how to structure it better and make it more user friendly

all that said, I think right now I'd prefer to wait with contributions until after that big update

[silk zealot]

Seems like great news; I'll be happy to contribute when 3.0 is live so

[stuck jasper]

awesome, thanks!

[silk zealot]

@mystic marsh About your previous message: when this will be fixed in UITK (this lib), it will be automatically fixed in every mod since the UI core is centralized thanks to @stuck jasper

About Japanese and Korean, sure; there are some Pan-CJK fonts, but I'm not an expert here

[mystic marsh]

That's a really good news!

[silk zealot]

@stuck jasper https://fonts.google.com/noto/specimen/Noto+Sans+TC is Pan-CJK so could be a good candidate as a starter fallback font

[mystic marsh]

take a look at this https://fonts.google.com/noto/use#faq , and in-page search for "Which Noto monospace fonts should I use?" there are multiple fonts for different languages

[silk zealot]

Seems perfect, https://fonts.google.com/noto/specimen/Noto+Sans+Mono

[stuck jasper]

awesome

so basically, ideally all these

and that should hopefully cover most of our needs for CJK

[silk zealot]

Hm the version I download as a "global" ttf

[stuck jasper]

the version you linked only seems to support Latin, Cyrillic and Greek alphabets

[silk zealot]

Ah! My bad

Perfect so

[stuck jasper]

for now I would just leave out the pixelated version, and just use these as the fallbacks for all fonts

[silk zealot]

Yes, I'd prefer that too

[mystic marsh]

Note that for Traditional Chinese, there are two variants, HK and TC, not sure if conflicts exist

[stuck jasper]

yeah, I've also noticed, but I have absolutely no clue what the differences are, to be honest

or if they can coexist

the README file seems to suggest that TC is the default Traditional Chinese variant

so I suppose we can use that one

[mystic marsh]

From my search, they can not coexist and the "TC" used in Taiwan is more commonly used.

[stuck jasper]

the forum editor works just fine guys

I tried to make that post three different times before clicking the Post button did anything, and when it did, it wrote out all three of them

[silk zealot]

Hahaha

awesome

[mystic marsh]

I am running the Chinese version of the game, so I can help you test once the update is implemented. It's even better if the forum user "lw0wl" can contribute his translation.

[stuck jasper]

alright, it works fine in Unity

so I'll build a new zip of the mod and send it for testing before I release it

and just for a quick test, also added Cyrillic and Greek

those should be supported by JetBrains Mono, but I just wanted to make sure

oh but I'll probably need to add JB Mono as fallback for the two pixel fonts

[mystic marsh]

great!

unrelated thought: Chinese characters can be too complicated to be pixelized, sometimes it's unreadable when the size is small.

[stuck jasper]

yeah, I was kinda thinking that it might get unreadable at smaller sizes, that's why I went with just the Noto font as a fallback for all of them, instead of finding a pixel font

ahhh I'm running into an annoying issue where I have the same fallbacks set up for all fonts, but the Cyrillic and Greek characters don't work only in one case

and I have no clue why

the fallbacks display correctly in both the middle font and the bottom font, but in the selected label at the top, they don't show up

but all the fonts are set up the same way

[hard onyx]

Is it a weird switch in the doorstop config :p

[stuck jasper]

what is happening

[mystic marsh]

no idea at all. Are labels any different?

[stuck jasper]

nope

well

my only conclusion is that the font basically claims to have those characters, but it doesn't

since it just refuses to fall back on other fonts for them, but it does so for the Asian languages

I think I'll just try to replace it with a different font

I've had a better one (imo) for ages, in my perpetually unfinished AppBar library

so I'll just use that one instead

I feel like it more closely matches the game, anyway

[silk zealot]

seems nice!

[stuck jasper]

I'll leave the old font in the mod for now, to not break mods that already use it, but I'll remove it in 3.0

[stuck jasper]

oof

from 1 MB to 50 MB

with those new fonts

a loooot of characters in them

[hard onyx]

Those scripts have a large amount of glyphs

[stuck jasper]

yeah

[mystic marsh]

just a thought, could fonts be developed into optional sub-mods in the future?

[stuck jasper]

theoretically, yes

though I would have to do some runtime magic to get them to work well with the main UITK library

but it's definitely possible

at least for fallback fonts

[hard onyx]

I dont see how well this would work
Would users be expected to go and find mods because they dont have translations?

[stuck jasper]

not sure how I would handle using them as the main fonts

[hard onyx]

Someone downloads science arkive for example, but doesnt have the chinese font module

How are they expected to know there is a chinese font module?

Is UITK for KSP2 supposed to detect missing glyphs and give a message to the user?

[stuck jasper]

if this was done, I would be for making it so that all the languages supported by the stock game would have fonts in the main library, and then fonts for languages that are modded in (let's say something like Arabic) could be in the standalone mods, along with the game translations

[silk zealot]

We could warn them in UITK/SW, something like if (Language.Current == "Japanes" ... )

[silk zealot]

This is the main issue, since CJK are all supported in the base game

[stuck jasper]

yeah, I definitely wouldn't want to take those fonts out

[hard onyx]

Arabic has many less glyphs than any of those 3 languages

[stuck jasper]

but it could work for extra languages

[hard onyx]

Almost any font would be drastically smaller actually

[stuck jasper]

yeah I don't really mean this as a size saving thing

more like, if someone wants to translate the game into a new language not supported by the fonts, they could add their own fonts as fallbacks

[silk zealot]

wouldn't be possible, as a fallback, to set in the TextPanelSettings the same fonts used by the game itself?

[hard onyx]

The game uses tmpro
The fonts wont have all the glyphs im pretty sure

Thats my understanding at least

[stuck jasper]

yeah, the issue is that the stock game and UITK use two different systems for text

so we can't use the game font assets

that's why I haven't already done that

[silk zealot]

Ah, well, crystal clear now

[silk zealot]

Yes haha now that I think about it, it's obvious

[hard onyx]

If we could use the game fonts, we'd have made them the main fonts im pretty sure

[stuck jasper]

yeaah

[hard onyx]

But the games fonts are paid and we cant really redistribute them

And we cant get them from in game

[stuck jasper]

I did look into converting a TMPro font asset into a TextCore asset in C# and it looked like it would be a nightmare

it is probably possible

but a nightmare

[hard onyx]

It is my understanding that TMPro only generates glyphs for characters that are used

[stuck jasper]

it's the same for TextCore

[silk zealot]

Is it really a problem to bundle the 50mb? UITK is a core library in the end

[stuck jasper]

oh definitely not

[hard onyx]

I'm more annoyed about spacewarp becoming 38 mb, cuz we have to put a small exe in there

a c++ or rust exe wouldve been smaller, and have run under proton tbh

[stuck jasper]

I'm using dynamic atlases, which means that only the few characters that are in my test document are actually in the assets, and the rest of glyphs are generated at runtime from the bundled ttf/otf files

[stuck jasper]

but it would be a pain in the ass to have two different projects in two different dev environments

[hard onyx]

Ehh, rust wouldnt really have been

C++ with clang too, I think

[stuck jasper]

I'd have to install either of these first

[hard onyx]

Setting up MSBuild for that though

[stuck jasper]

so I declare it a pain

[hard onyx]

Hell zig would work too, but its not 1.0

Anyways #🔴space-warp

[chilly thorn]

zig?

i heard zig

[stuck jasper]

oh god he's here

[chilly thorn]

i felt it in the force

[stuck jasper]

hide yo kids hide yo wives

the Ziggler is here

[chilly thorn]

👀

[stuck jasper]

[stuck jasper]

whyyyyyyyyyyy doesn't this work

[silk zealot]

Chinese font refusing to work?

[stuck jasper]

yes

it's in the addressables, it's set as the fallback, and still nothing

this was supposed to be such an easy fix

and it's just one issue after the other

[silk zealot]

oh my god

mhh maybe something wrong in the mods, like TextPanelSettings not updating

?

I can debug ScienceArkive to find the TextPanelSettings and see if the fonts is there

would you mind sending me the UITK plugin?

[stuck jasper]

it's not set in the text panel settings, those seem to require that the fonts be in Resources, which we can't add to the game

[silk zealot]

(If you'd like some help obviously)

[stuck jasper]

each font asset has its own fallback settings instead

that way I can also differentiate between fallbacks for regular and bold fonts

[silk zealot]

Seems good

.. well, if it does work

[stuck jasper]

yeah...

oh what the hell

the fallbacks somehow disappeared from most of the font assets??

inside the editor

Unity wtf are you doing

[silk zealot]

Classical Unity

[stuck jasper]

ok what

now half of it works

is a different font used for those or something? @silk zealot

[silk zealot]

I'll double check, is it possible setting the font in the Visual Editor breaks this link with UITK?

[stuck jasper]

it shouldn't

[stuck jasper]

huh

I wonder if using the USS variables instead of a direct reference would fix it

but that would be weird

[silk zealot]

let me double check

I don't think it's possible because the addressable bundle is ~160kb

[stuck jasper]

here's the latest build by the way

[stuck jasper]

not sure what that means

[silk zealot]

If it's using a different font, it should be bundled here right?

[stuck jasper]

probably not a different one

what I meant was more so whether directly setting the font asset reference instead of using one of the font variables could cause it

[silk zealot]

ahn

so strange

[stuck jasper]

like -unity-font-definition: url('Packages/uitkforksp2.controls/Assets/Fonts/JetBrainsMono/JetBrainsMono-Bold SDF.asset') instead of -unity-font-definition: var(--font-bold)

for example

[silk zealot]

in the uxml it is -unity-font-definition: url('project://database/Packages/uitkforksp2.controls/Assets/Theme/Fonts/JetBrainsMono/JetBrainsMono-Regular%20SDF.asset?fileID=11400000&guid=f5454c9c675002c44a5a7234bd40c390&type=2#JetBrainsMono-Regular SDF');

[stuck jasper]

hm

not sure if USS variables can be used directly in UXML

[silk zealot]

I'll try to swap it

[stuck jasper]

my guess is it would require setting the style from inside a USS file

still, this is one weird issue

[silk zealot]

I'm using the JetBrains Regular font

just to double check

[stuck jasper]

that shouldn't be an issue, all of them have the fallbacks

[silk zealot]

Well, the experiment title works (it's a foldout, USS untouched)
The buttons work too
Instead the places where I set the fonts got some issues

Ah god

trying to use only USS

(Well, playing in japanese is so futuristic anyway)

Akira vibes

[stuck jasper]

lol

[silk zealot]

this sounds not goot

[stuck jasper]

so the issue was what I thought

[silk zealot]

(or is it normal?)

What!

[stuck jasper]

by directly referencing the font asset, it actually gets copied into your bundle

[silk zealot]

gosh

[stuck jasper]

it still takes the actual glyphs from the font that's inside UITK for KSP2

but it has its own asset settings

including the fallbacks

switching to the variables fixed it

another way to fix it would most likely be just updating the UITK package in Unity

after I release it

[silk zealot]

I didn't get this part, so do you mean that just removing it from inlineStyles?

[stuck jasper]

because then you'll have the fallbacks defined

even in your copies

[silk zealot]

Sure

But I'd like to avoid the copies if possible

[stuck jasper]

the culprit here is that I switched from asset bundles to addressables

if I were still using asset bundles, your Unity project would build both the UITK bundle, and your mod's bundle

and your bundle would only reference the assets in the UITK bundle, instead of copying them

I got rid of it exactly for the reason that I didn't like the fact that everyone's projects also automatically build the UITK bundles for no reason

[silk zealot]

But using addressables, by definition, shouldn't Unity omit these font since they are in another addressable bundle?

[stuck jasper]

but it turns out it wasn't for completely no reason

[stuck jasper]

well, I'm pretty sure it would, if you were also using addressables

but I don't think the two systems interact well between each other

[silk zealot]

Ahhn, but I'm using just regular bundles

(Just to talk again about the Unity mess)

[stuck jasper]

I suppose what I could do is switch the UI template to also use addressables instead of regular bundles

at least I think that would fix the issue

but it does make the situation a bit more complex

especially for someone who comes to it with no Unity knowledge

[silk zealot]

Mh yes this is my doubt too

Was wondering if there is some settings to avoid this

[stuck jasper]

if there is, I'm not aware of it

I think they just expect you to use one system or the other, but not a combination of both

[stuck jasper]

and just to get back to this, what I did was unset the inline font asset:

and then added styles like this for all the elements with the custom font

(well I only did it for the one, but you know what I mean)

that's the best temporary fix

here you can see the variables for the various fonts

[silk zealot]

I should admit I used the selector

just because I didn't find this

[stuck jasper]

that's on me, I absolutely need to write the documentation after the rewrite

[silk zealot]

I think we should add it on the wiki

[stuck jasper]

there's just always something else more pressing to do first

[silk zealot]

Haha sure, I could've just asked, you guys are super present

[stuck jasper]

alright, so I think I can push out this UITK update then

[silk zealot]

let me just double check all the UI

2 minutes

if you don't mind

[stuck jasper]

oh sure

(damn you if you manage to find a different bug though 😠 )

[silk zealot]

Hahaha

Can I use the UITK variable freely or do we need an import or something like that?

[stuck jasper]

yeah, you can just use it wherever

since it's defined in the main theme

[silk zealot]

Mh it seems like it is not showing in the builder

.font-pixel-label {
    -unity-font-definition: url(--font-title-big);
}

[stuck jasper]

how about if you add the document to a scene and run it?

oh I see the error

it's var(...) instead of url(...)

[silk zealot]

Oh, lol

I could atleast read the error message

[stuck jasper]

😆

[silk zealot]

perfect

beautiful!

[hard onyx]

Awesome!

What are the ???

[silk zealot]

Discoverables which aren't reached by the player

like Mun Monument

There is a setting to select if you want to see All of them, Only the discovered ones or to show them "Censored"

Spoiler free mode 😄

[mystic marsh]

WOW! Good job guys! Thank you for the effort!

[hard onyx]

Also, someone should tell the person on the forums who is trying to add chinese to spacewarp

[stuck jasper]

Yeah I will

[silk zealot]

Should UIDocument.EnableLocalization(); work on dynamic UI elements, e.g. when you instantiate dynamically an UXML and add it to parent window?

cause I'm getting this

[stuck jasper]

you can call Localize on the DocumentLocalization component when you want to refresh it

but I'm not calling it anytime any UI is updated, no

[silk zealot]

Ah gotcha, thanks

[stuck jasper]

ahh actually not even that will work

because it only updates the elements that are cached in the component

otherwise it would be really expensive to do a full recursive search for all elements that might need localization

[silk zealot]

Better to do it by hand so

[stuck jasper]

you can either call RegisterElement to add a single element, or RegisterDocument to re-cache the whole document

but I feel like in your case, it should be enough to just call EnableLocalization after you set up everything in the window

then it should work fine

[silk zealot]

Seems working fine, thanks!

[hard onyx]

are there stiill plans to use scss?

[stuck jasper]

yep, I already have that implemented in the dev (3.0) branch

and anyone else can use it right now by just installing the two Unity packages

since that's completely independent on UITK for KSP2

[hard onyx]

Ah you do have it in the dev branch

[silk zealot]

@stuck jasper in the end I got a way to make tooltips in a dedicated Window, so I think this could be a nice addition to UITK, since this way there could be only one centralized tooltip manager; plus, consistent U! I designed the tooltip to be very similar to in game ones

It's very generic so it could be enough to expose a VisualElement.AddGameTooltip extension method

https://github.com/Kerbalight/WayfarersWings/blob/main/src/WayfarersWings/UI/Components/TooltipManipulator.cs
https://github.com/Kerbalight/WayfarersWings/blob/main/src/WayfarersWings/UI/TooltipWindowController.cs

[stuck jasper]

nice, thanks!

I'll definitely look at it for inspiration when I get to the UITK update

looks pretty similar to this recommended solution

[silk zealot]

I red exactly that post to implement it 😄

Plus having a central one makes for better animations

[stuck jasper]

though I might try to adapt this one: https://github.com/plyoung/UIElements

I would like to integrate all of these into UITK ideally

and the tooltip here seems to additionally have support for boundary checking, so that it doesn't display off-screen, which I like

[silk zealot]

It's cool, I've seen it, but tooltips are not supported at runtime

atleast it's what written there

[stuck jasper]

that is a custom implementation

[silk zealot]

I didn't dig down

[stuck jasper]

"UIElements does not have tooltip support at runtime. Here's some code to show how you can get it working."

they mean, "natively they're not supported, so I made my own version"

[silk zealot]

Ahhhn

[stuck jasper]

it's quite similar to your implementation, too

just a bit more robust

[silk zealot]

I thought he/she was referring to the library as UIElements

lol

[stuck jasper]

UIElements was the old name before they renamed it to UI Toolkit

[silk zealot]

I didn't remember

too many changes in U world..

[stuck jasper]

indeed 😆

[silk zealot]

Anyway it's perfect

love the popup

[stuck jasper]

yep, pretty sure I can just take the best from this and from your implementation and we'll have basically perfect tooltips

[silk zealot]

For sure, but I don't care about the solutions used, just to contribute you know

[silk zealot]

Hi @munix, I’m fighting with DropdownFields right now, and I’ve discovered the popup drop-down content is shown in another rootElement, owned by Unity, so only “inherited” style sheets in the PanelSettings are applied (for example, KerbalUI is applied), but I cannot override them.

The solution would be to add my style sheet to inherited styles, but the PanelSettings is from the UITK addressable, Do you have any hint on how I could do something like that? Like, editing or cloning the PanelSettings, or duplicate it without loading all the assets

Thanks!

[stuck jasper]

oh boy, here we go again

yeah, we already had this issue a few times before, and yeah, the only way to change this would be to change the main theme that's common for all mods

unless you create a custom panel

which is usually discouraged because more panels = worse performance

this is one of the main reasons why I need to make a custom dropdown element

[silk zealot]

gotcha! I thought something like that

Even if I think probably a base style for dropdowns would be adeguate

plus a wide-dropdown option or something like that to have the dropdown content expand (my problem)

is it possible to define custom controls through UXML or is it necessary to do all of them in code?

[stuck jasper]

well, you can just write the UXML and then control them in your plugin

custom controls basically just encapsule the two

[hard onyx]

Have a dropdown element that can have a list of child elements rather than just text

[stuck jasper]

so that they can be easily reused

[silk zealot]

I'm just lost at where to write the UXML, which file, and how to use it in other uxml templates

[hard onyx]

Btw munix, should I hold off on writing a markdown renderer until uitk for ksp2 3.0

[stuck jasper]

oh well if you want to use it in multiple places, then you probably do need to make a custom control

otherwise you'd just write the UXML directly inside the UXML window where you want the dropdown

[silk zealot]

Yep, that's the reason I though about the custom controls; my doubt is that, e.g., in this unity tutorial (https://docs.unity3d.com/Manual/UIE-slide-toggle.html) they define two visual elements:

VisualElement m_Input;
VisualElement m_Knob;

However they don't ever initialize them, nor create them. How would you do that is a myster to me..

[hard onyx]

m_Input = this.Q(className: BaseField<bool>.inputUssClassName);

[silk zealot]

doesn't Q find the element?

[hard onyx]

Yes

But the custom control is created from the equivalent of a prefav

Prefab

Its instantiated from the uxml, which has the children

[silk zealot]

I'm a bit lost on where this "prefab" is placed

[hard onyx]

You have a uxml document that defines it basically, I think

[stuck jasper]

basically, you put the UXML into your asset bundle, and then in the code, you load it from it

like a regular window UXML

[silk zealot]

Ok and then I'm able to put this custom control directly into my other UXMLs?

[stuck jasper]

you should be able to, with the way the UI template is structured

the same C# gets compiled by both Unity for the editor, and by the main C# solution

[silk zealot]

yep

and the worst question: is there any example about this that you know 😄 ?

[stuck jasper]

SpaceWarp has a custom element, but it is not using the template, so the files are duplicated I'm pretty sure

oh wait actually I think it is using the UI template now

I think I did that conversion already

ok no I didn't

well, partially

but not that part

[silk zealot]

haha

https://github.com/SpaceWarpDev/SpaceWarp/blob/main/src/SpaceWarp.UI/UI/Console/LogEntry.cs

[stuck jasper]

https://github.com/SpaceWarpDev/SpaceWarp/blob/main/src/SpaceWarp.UI/UI/Console/LogEntry.cs

[silk zealot]

I've found this

[stuck jasper]

lmao

[silk zealot]

hahahah

nice 😄

[stuck jasper]

yeah seems like Lux just creates the UXML programmatically

so no .uxml file

[silk zealot]

so the VisualElement should be built programmatically

ok, not a problem

[stuck jasper]

well, you can do it either way

[silk zealot]

since you can just put it into the UXML

and preview it

[stuck jasper]

yeah

but only in play mode, I would assume

not in the UI builder

though honestly I'm not sure

I have nearly 0 experience with custom controls

[silk zealot]

I'd like to try

[stuck jasper]

actually I think it worked in the UI builder

[silk zealot]

(I hope so, since trying to run a UI project where I imported thunderkit for the addressables just crashes my unity editor)

[stuck jasper]

ahh yeah

that's the biggest issue with ThunderKit

[silk zealot]

but

to be sure

is it needed to import ThunderKit if not doing Parts (but still using addressables)

in that case it would be easy to have two projects, like XYZ.Unity and XYZ.UI or something like that

[stuck jasper]

it isn't

if you don't need to use KSP2 Unity Tools

since those depend on KSP2 being imported

[silk zealot]

but I love it to build the bundles

[stuck jasper]

but for just building addressables, it's not necessary

[stuck jasper]

yeah...

it is convenient

[compact sandal]

You can use custom controls inside the UI builder (if that was the question)

[silk zealot]

It's working!

[compact sandal]

Something changed in one of the recent(ish) updates. Game input isn't blocked anymore for textfields, for MicroEngineer and OrbitalSurvey. It is blocked for other mods I've tried, like Science Arkive Wayfarer's Wings and MNC. But I haven't changed anything for MicroEngineer for a while, so it must be something else that's changed.

[stuck jasper]

my guess would be that it's because other mods still use the pre-2.3 API (not using WindowOptions) and that has the disabling on by default

Micro Engineer uses them, but doesn't enable the option for disabling game input on focus

https://github.com/Falki-git/MicroEngineer/blob/8332eb4f35138dad047ea0d2782234ea1d894de3/MicroEngineerProject/MicroEngineer/UI/Controllers/Uxmls.cs#L74-L83

if you want to use the default values and modify those, instead of making the full object from scratch, you can do this instead:

return WindowOptions.Default with
{
    WindowId = windowId,
    IsHidingEnabled = true,
    MoveOptions = new MoveOptions
    {
        IsMovingEnabled = makeDraggable,
        CheckScreenBounds = true
    }
};

[compact sandal]

Ah, is that something new? The DisableGameInputForTextFields I mean. It's strange that I wouldn't use it in the first place

[hard onyx]

with?
Ive never seen this syntax aaa

[stuck jasper]

yes it's really nice

you can use it to copy structs with some modified values

[hard onyx]

That would be really nice to have known a while ago

[stuck jasper]

honestly I don't 100% remember but I probably added it in 2.4

[compact sandal]

It works now, thanks!

[silk zealot]

I'm moving the discussion here @stuck jasper

I was thinking

is it possible someway the "default" values set in Unity for the KerbalPanelSettings, gets "applied" to the in-game UI, so the UIDocuments width/height/transform is changed, then it gets reset by the UITK Manual/Auto switch, but now it's late since dimensions are already computed?

[stuck jasper]

well, switching between auto and manual requires a game restart for everything to properly apply

but then it should be working fine

[silk zealot]

mh

[shut beacon]

this channel is really cool to lear UITK !!

https://www.youtube.com/watch?v=0mYtI21Fmg4&ab_channel=Hj

[stuck jasper]

awesome, thanks for sharing!

[shut beacon]

this is helping me a lot

[hard onyx]

@stuck jasper I made a PR to the unity side

[stuck jasper]

yup, I already merged it

thanks

[hard onyx]

AH I didn't notice, sorry

[compact sandal]

I'm trying to bring MicroEngineer to the newest template version, primary goal to finally decouple unity files from a single unity project into separate mod projects (I blame @ Lux for teaching me this 😆 ).
Anyway, I have some custom controls in the main project that I'd like to move to the unity project. Issue is that inside the controls I'm using some classes from the main project, so I need to add a reference to them. If I try to add a reference to the main project it says that it would create a circular reference (well yeah, makes sense). So how do I actually do that? I could add a reference to the compiled dll from the main project, but there must be a direct way. This is a noob question so I feel there's an obvious answer here 🙂

[stuck jasper]

Well, the ideal way to do it would be not to have any logic code inside UI controls definitions

And instead passing data to them from the controller

[compact sandal]

I'll move the control initialization to the controller then

Alternatives sound too complex and not worthy

[hard onyx]

You generally dont want to reference spacewarp stuff in unity, or youll have to drag in every single spacewarp/bepinex assembly

[compact sandal]

Yeah, I've read about that now. Would have to set up nuget packages that unity doesn't like, so there are workarounds for it.

[shut beacon]

From my side, the K2D2 port will take a little bit longer than expected. I'm still in a long learning curve. Perhaps because I need for to be confident for continuing with it. I really need to master many little ui tricks I was use to have using IMGUI.
My first attemp of UI was really too complex to adapt to add simple feature. coming from Unity editor, Build UI, go back to vscode, Build and see the result on KSP2.

I need to have a better workflow and that's why I need a long preparation of my tools under Unity Editor.

I'm currently creating a set of little UI Component I used to have in previous K2D2 UI. Thiis inlcude :

• tabs with a light on it when Pilot is On
• 3 differents styles and behavior for buttons.
• new toggles and sliders with a better look
• FoldOut
  and Labels, console infos and so on.

Building all this stuff takes a long time.

I'm following that examples given here : https://docs.unity3d.com/2022.3/Documentation/Manual/UIE-slide-toggle.html

[stuck jasper]

I mean, you don't really have to create a custom control for just a toggle

you can just restyle the native toggle

like I did

unless you want to do something really complex

[shut beacon]

Yes of course but i've adjusted so many little things in the k2d2 ui that I want at least to have that level of quality and doing this is a good tutorial for more complex UI like the compass and so on

The tabs of example have level and 2 toggle states. many button in K2D2 ui have this kind of logic I need to reproduce

I could have a first version of K2D2 with UITK quick but it will be harder to continue on it rather than having betters bases. so just to say I take time to create this. it could be used in another projects, making it relatively generic.

I want for example to add animated controllers anywhere it is possible and interesting.
