Tables

[wary knot]

what's more important there is showing that a cell is spanning two columns

but i mean, the most important takeaway here is that we need an example showing how to remove vertical lines

[upbeat pine]

wait, so h/vline have the highest priority?

[wary knot]

yes

[upbeat pine]

I thought they have the medium priority.

[wary knot]

👆

[upbeat pine]

Yeah, but what was the argument for this again?

[wary knot]

you cant add hlines / vlines in templates

[upbeat pine]

which templates?

[wary knot]

#set table(...)

and #set table.cell(...)

so it's natural that the thing which the user has to explicitly specify at call site will have more priority over things which can be overridden globally

[upbeat pine]

So you are saying that #set table.hline(...) doesn't exist?

[wary knot]

it does

but you have to place the hline for it to have any effect

if your table has no hlines that doesnt change anything

whereas #set table.cell(...) and #set table(...) will affect all tables regardless of what you use

[upbeat pine]

It would be cool if you can disable only horizontal lines with the set rule. Which means that the table's rules are affecting vlines and hlines.

I even think now that it is a better approach.

[wary knot]

but you can

the thing is that vlines and hlines changed their semantics from what we had thought initially

initially we had defined vline and hline to be any vertical or horizontal line in the table

so indeed hline and vline would have low priority because they're just a basic thing

but after our call we decided that hlines and vlines are only user overrides

the "basic lines" in the table are really just cell strokes

so #table(stroke: ...) sets cell strokes

[upbeat pine]

oh, right.

[wary knot]

and so if you want to disable horizontal lines , you can write #table(stroke: (y: none)) for instance

[upbeat pine]

...

[wary knot]

it disables the line above and below the cell

equivalent to (top: none, bottom: none)

[upbeat pine]

I don't know what to say. I'm just impressed.

It's like writing set rule for v/hlines, but in the same place, just chaning x/y.

truly genius. It is much more convenient, but you need to write table/stroke/y/...,x/...

But are those lines override the cell's stroke or create new lines on top?

I think this also was discussed...

[wary knot]

it overrides the cell's stroke property

if it doesnt define its own

[upbeat pine]

if cell doesn't define its own stroke?

[wary knot]

yeah

[upbeat pine]

what does "define" mean?

[wary knot]

table.cell(stroke: red)[a]

[upbeat pine]

define define

[wary knot]

think of #grid(stroke: blue, stuff) as

#[ #set grid.cell(stroke: blue) #grid(...) ]

[upbeat pine]

So if you use this, then it will actually have a higher priority than the hline?

[wary knot]

no

cuz theres no hline

unless you place one

then it will have higher priority

[upbeat pine]

there is, because we are talking about placing them

[wary knot]

if you place one then the hline has higher priority

[upbeat pine]

so hline overrides cell's stroke if cell doesn't override its own stroke. But if the cell does override its own stroke, then hline will still have a higher priority.

[wary knot]

no

sorry i misunderstood what you had said

[upbeat pine]

that's how I interpreted your words.

[wary knot]

i meant that #grid(stroke: ...) sets the cell's stroke field

unless you set it manually, then it doesnt

and regardless of that

grid.hline and grid.vline will appear on top

[upbeat pine]

#table(
  columns: 3,
  [], [], table.cell(stroke: green)[hey],
  table.hline(stroke: red),
  table.cell(stroke: green)[hey], [], [],
)

Indeed...

So, I'm guessing that for simple tables if you don't want to override, you just add start/end. And for complex tables you are on your own, probably have a complex show rule for everything as well.

I don't usually change hlines, but it is something that I will need to experience myself to know if it's good or bad.

I feel like begin/end is a more iconic duo and h/vline should use it instead of start/end. Because normally it's start/stop.

[wary knot]

it's analogous to the line parameters

[upbeat pine]

indeed

https://staging.typst.app/docs/reference/model/table/#definitions-hline-stroke:

The line's stroke.

Specifying none interrupts previous hlines placed across this line's range, but does not affect per-cell stroke or vlines.
What does interrupts previous hlines mean? It does affect per-cell stroke:

#table(
  columns: 3,
  [], [], table.cell(stroke: green)[hey],
  table.hline(stroke: none),
  table.cell(stroke: green)[hey], [], [],
)

[wary knot]

oh yea good catch

laurenz asked me to change that i think but i forgot to update the docs

[upbeat pine]

which metadata?

[wary knot]

i assume that was intentionally unspecified as it wasnt implemented yet

but in general, something that indicates what the header of your table is

[upbeat pine]

And what difference will it make? For clarity?

[wary knot]

for accessibility

[upbeat pine]

I know that

[wary knot]

so maybe a screen reader will say "table header"

well we cant really reason about it as it doesnt exist

it's just a vague suggestion to use it whenever something of the sort is added

I assume martin had PDF-A in mind when he wrote that

or something like that

[upbeat pine]

it isn't implemented, but it must exist already, otherwise this whole vague stuff is useless.

[wary knot]

why is it useless?

it's just encouraging people to future-proof their stuff

pretty normal

[upbeat pine]

if the thing doesn't exist, then there is no point in planning to add it.

[wary knot]

why not?

[upbeat pine]

Because we don't know what will happen in the future. otherwise we need to predict 100 stuff that might be created and then added in the typst.

[wary knot]

that sounds like a strawman though

it's not saying to prepare yourself against 100 unpredictable stuff

it's saying to prepare yourself against one specific thing which is planned and will be added

[upbeat pine]

I thought there is some kind of standard, but if it's nothing, then our standards are bad, this should've been existed for a long time.

[wary knot]

there is

i mean there are PDF standards

it's probably just gonna use one of them

i just cant tell you cuz i dont speak PDF

so the info i have is very limited

[wary knot]

it didnt exist before cuz table headers didnt either

now that they do, we can begin to consider implementing this

anyway

[upbeat pine]

planned and will be added to the standard?

[wary knot]

i cant give much more info

[wary knot]

no, the standards already exist, typst will just conform to them

also for example, when html export becomes a thing

a table header would be exported as <thead>

[upbeat pine]

no, the standards already exist, typst will just conform to them
so the "something that indicates what the header of your table is" does exist after all. But you've said that it doesn't exist just a moment ago.

[wary knot]

with "it" i meant the typst implementation

anyway, this answer explains it better https://stackoverflow.com/a/53598697

[upbeat pine]

how fragile the language is sometimes...

telepathy when?

do you really can't combine them?

[wary knot]

#show table.cell.where(x: 0).or(table.cell.where(y: 0)): strong

that's the only way

[upbeat pine]

sad

[wary knot]

well, or

#show table.cell: it => {
  if it.x == 0 or it.y == 0 {
     strong(it)
  } else {
     it
  }
}

[upbeat pine]

I guess the only way is to add new syntax where(x: 0 or y: 0) or make where(x: 0).or(where(y: 0)).

so basically tell typst to use where for the same thing as in the first time.

Wait, if you import cell, do you do #show cell.where().or(cell.where())?

[wary knot]

sure

[upbeat pine]

well, this is much better.

No other table cells may be placed after the footer.
even if you specify the cell's position as above the footer?

[wary knot]

in that case it's fine

[upbeat pine]

mMm

[upbeat pine]

so, are you on it?

[wary knot]

done

[upbeat pine]

now it makes all sense.

[upbeat pine]

I wanted to move out euro to make the table extra cool, but apparently I can't even do that properly:

// #set table.cell(stroke: green) // works
#set table.cell(inset: (right: 0pt)) // works
#show table.cell: it => {
  // set table.cell(stroke: green) // doesn't work
  if it.x > 0 and it.y > 0 {
    set table.cell(inset: (right: 0pt)) // doesn't work
    // set table.cell(inset: 0pt) // doesn't work
    align(it.align, box(it) + box(inset: it.inset + (left: 0pt, right: 5pt))[#sym.space€])
  } else { it }
}

#table(
  fill: (col, _) =>
    if calc.odd(col) { luma(240) }
    else { white },
  align: (col, row) =>
    if row == 0 { center }
    else if col == 0 { left }
    else { right },
  columns: 4,
  [], [*Q1*], [*Q2*], [*Q3*],
  [Revenue:], [1000], [2000], [3000],
  [Expenses:], [500], [1000], [1500],
  [Profit:], [500], [1000], [1500],
)

Why is the local set rule doesn't work? it is illegal, isn't it?

Also normal space is ignored there, so instead of becoming extra cool, it becomes extra ugly.

[wary knot]

See the changelog on styling

[upbeat pine]

It doesn't answer the first question.

moreover, I need to know how to overcome this limitation to achieve the goal, which is pretty reasonable, but hacky nevertheless.

If I was able to modify the it.body, then it would all be fine, but I can't.

[wary knot]

#let eurotable(columns: auto, euro-cols: none, table-func: table, ..args) = {
  if type(euro-cols) == int {
    euro-cols = (euro-cols,)
  }
  assert(euro-cols == none or type(euro-cols) == array and euro-cols.all(x => type(x) == int))
  let cells = args.pos()
  let opts = args.named()
  let c = if type(columns) == int {
    calc.max(columns, 1)
  } else if type(columns) == array {
    calc.max(columns.len(), 1)
  } else {
    1
  }

  cells = cells.enumerate().map(((i, cell)) => {
    let cell-func = if type(c) == content { c.func() } else { none }
    let cell-x = if cell-func == table-func.cell and cell.x != auto { cell.x } else { calc.rem(i, c) }
    let cell-y = if cell-func == table-func.cell and cell.y != auto { cell.y } else { calc.floor(i / c) }
    if euro-cols != none and cell-func not in (table-func.footer, table-func.header, table-func.hline, table-func.vline) and cell-x in euro-cols and cell-y > 0 {
      let fields
      let body
      let label
      let cell = if cell-func == table-func.cell {
        fields = cell.fields()
        body = if "body" in fields { fields.remove("body") }
        label = if "label" in fields { fields.remove("label") }
      } else {
        fields = (:)
        body = cell
        label = none
      }
      [#table-func.cell([#body €], ..fields) #label]
    } else {
      cell
    }
  })

  table-func(..cells, ..opts, columns: columns)
}

#eurotable(
  euro-cols: (1, 3),
  fill: (col, _) =>
    if calc.odd(col) { luma(240) }
    else { white },
  align: (col, row) =>
    if row == 0 { center }
    else if col == 0 { left }
    else { right },
  columns: 4,
  [], [*Q1*], [*Q2*], [*Q3*],
  [Revenue:], [1000], [2000], [3000],
  [Expenses:], [500], [1000], [1500],
  [Profit:], [500], [1000], [1500],
)

[upbeat pine]

you can't mutate read-only variables.

[wary knot]

wut?

[wary knot]

What's the problem

?

[upbeat pine]

missing let euro-cols = euro-cols

[wary knot]

does it error if you run the code?

[upbeat pine]

if you change the type of the argument when you call the function

[wary knot]

Does it error then?

[upbeat pine]

Pretty sure it would.

[wary knot]

There's only one way to find out

Haha

But in principle it shouldn't

You aren't attempting to mutate an external variable

Euro-cols is an internal variable

You would have an error if it were an array and you tried to append to it

But here we're replacing its contents entirely

[upbeat pine]

hmm, strange. did all my previous errors were due to a different use case...

[upbeat pine]

This is truly a work of art, but not only changed the table name, but also there are new arguments. typst-lsp wouldn't handle it. I want table. Native one.

So you basically reconstructed the table cell from its pieces into a new table cell, which I wanted to do, but in show rule this will fail due to recursion.

I assume, since you've made a big-ass function instead, there is no way to do it properly with a single show rule.

[wary knot]

i think one possible idea to make table styling easier could be to synthesize table properties

e.g. replace the (auto, auto) columns by (1pt, 2pt)

even table.children could theoretically be synthesized

but in practice i feel like that would be harder to get right

[upbeat pine]

is this related to the not working show set thing?

[wary knot]

no

it's just a feature idea

being able to show table and have access to the final sizes of columns and rows

[upbeat pine]

And now you can't?

[wary knot]

no, table fields in show rules will be almost exactly as you specified them

columns will be changed from 2 to (auto, auto) for example

but not much more than that

[upbeat pine]

yeah, shame

[wary knot]

also

i found a good use case for a fit parameter for cells, to have them not affect auto rows

#1216694065626746951 message

basically being able to have some line as large as the adjacent content, like block(stroke: ...) but with more flexibility

so you'd be able to have anything as large as adjacent content

while it would be very quick to implement that, theres of course no time to add it to this release, so we can discuss for 0.12

personally i think it'd bring value, much like fit-spans in tablex, but I'm open to hearing other opinions about such a feature

[wary knot]

ok i just implemented it

looks cool

basically easier way to make stuff have the same height as other stuff

without having to measure()

or same width

well the grid does measure internally but you dont need to know that

[wary knot]

anyway but that'll be for 0.12 so i don't wanna give it too much importance
I might open a draft PR later just in case

[wary knot]

Okay

@robust viper i found a bug (or, at least, inconsistency) in tables

TL;DR:
#table(
rows: 2em,
block(width: 2em, height: 100%, fill: red)
)

Produces a small block,

But wrapping it in a rowspan: 2 table cell causes it to go all the way to the end of the page

[robust viper]

Luckily not a regression though

[wary knot]

That's true, though it's worth considering

Basically I'm just using the region full from the first region the rowspan appears in, ideally i should change that :p

[robust viper]

the rowspan behaviour seems more correct

ah no

nevermind

didn't see the rows: 2em

[wary knot]

yeah

In theory it's a quick fix, we just need to determine the criteria for using or not the first region full

Maybe spans auto row = yes, doesn't = no?

[robust viper]

seems sensible

[wary knot]

I think unbreakable cell = no as well for consistency

As an unfortunate consequence of measuring with infinite height, an unbreakable auto row won't pick up 100% properly

So yeah

Anyway

I'll take a look at this in a few hours, once I'm at my PC

Should just be a simple "if" in layout_rowspan

[bold bluff]

I really like the tables.

#let spin(word,origin,length) = {
  return (
    table.cell(colspan:length,x:origin.x,y:origin.y)[#word],
    table.cell(rowspan:length,x:origin.x+length,y:origin.y,rotate(90deg,reflow:true)[#word]),
    table.cell(colspan:length,x:origin.x + 1,y:origin.y+length,align:right,rotate(180deg,reflow:true)[#word]),
    table.cell(rowspan:length,x:origin.x,y:origin.y + 1,align:bottom,rotate(270deg,reflow:true)[#word])
  )
}

#table(columns:8,
  ..spin([TABLES],(x:0,y:0),7),
  ..spin([TABLES],(x:1,y:1),5),
  ..spin([TABLES],(x:2,y:2),3),
  table.cell(rowspan: 2,colspan: 2,x:3,y:3,align: center+horizon)[#emoji.star]
)

[pulsar sedge]

An error occurred:

Error: function `table` does not contain field `cell`
    ╭─[/main.typ:10:11]
    │
 10 │     table.cell(colspan:length,x:origin.x,y:origin.y)[#word],
    │           ────
    │
────╯

[bold bluff]

They work good even when nesting.

[upbeat pine]

I don't understand what is happening, but this is impressive.

[wary knot]

Someone just ran into this: #1217143831926145154 message
Seems like there's a use case here

I'll be working on this soon, just got home

It's kinda funny how many bugs I find out by just reflecting about things lol

[wary knot]

In particular i was thinking about the feature i mentioned above, of having cells fit within auto rows without expanding them

And then i thought well i wonder if there would be any problems in implementing this on rowspans

And then i thought ... Wait ... Lol

Anyway , but even then, I'm happy that we haven't rlly been facing any major bugs

Even though lots of complex stuff has been added

So yay

[wary knot]

forgot to comment on this but lol, very epic
nice to see that you're enjoying the new tables 😎

[bold bluff]

so i found a weird thing here i get an error if i have less than 15 columns:

#table(columns:15,
..range(0,10).map(y => {
range(0,10).map(x=>{if calc.rem(x,2) == calc.rem(y,2) {table.cell(rowspan:2,x:x,y:y,[#x])}else {} })
}).flatten()
)

[wary knot]

and whats that error?

[bold bluff]

attempted to place a second cell at column 9 row 1.

ehh it changes depending on the number of columns..

[wary knot]

the hint is very helpful

i suggest reading it

🙂

as explained here

you're placing cells with manual positioning followed by one cell with automatic positioning (from the else {}) followed by more cells with manual positioning

so the latter cells wont be aware of that one cell with automatic positioning

and can potentially try to overlap with it

[bold bluff]

ohh ehh. thats not smart on my part. but it makes sense.

does none count as a cell?

[wary knot]

anything in the table is a cell

none is converted to [] which is later converted to table.cell[]

with all arguments set to their default values

solutions:

1. manual positioning in all cells
2. place all manually positioned cells before automatically positioned cells

3. use flat_map instead of map

[bold bluff]

flat_map 🙂

[wary knot]

actually you dont need to flat_map since you already flatten

so you can do the following

if stuff { (table.cell(...), ) } else { () }

array of size 1 vs array of size 0

the latter wont create a cell

[bold bluff]

ohhhh. so () is more none than none is. this is very helpful.

[wary knot]

well

the thing is that you're using flatten

and flatten will replace all arrays by the items inside them

recursively

[bold bluff]

yeah i was trying to filter but i was too noob.

[wary knot]

so it will convert ( (...), (...), (...) ) to (..., ..., ...) and then the arrays inside those to their items

but () has no items

so

it's just ignored

[timber bronze]

Hi. I did not follow the table changes very closely, so I assume this is a known limitation, but is there a way to style table headers? For example, I would like to do the following:

#show table.header: set text(weight: "bold")

But this does not work.
I'm sorry if this was already answered, I was unable to find recent information about that.

[wary knot]

Yeah it's known

Unfortunately won't happen for the next version

[wary knot]

Though

I'd suggest opening an issue on it

Just so i don't forget

🙂

[timber bronze]

I'll do that

[wary knot]

(feel free to ping me there)

[wary knot]

Yeah that'll work for the simplest use cases (though not for arbitrary headers)

[timber bronze]

Yeah I will use this solution in the mean time, but it's not perfect

[upbeat pine]

I saw at least one or more examples of how the table headers were bolded in the docs. I think there are another ones too.

[wary knot]

The table header element can occupy more than one row

And you can't rlly know how many rows it occupies without access to internals ATM

But I guess you can hack something on #show table like I did for the euro column

Either way ideally you'd use #show table.header: ... And it'd just work

At least show-set

normal show won't work cuz headers don't actually exist

They're an illusion of the senses

Mere mortals do not understand the complex power living therein

[timber bronze]

Done! https://github.com/typst/typst/issues/3640

[wary knot]

Ty ❤️

Btw @robust viper
Just wanted to mention that the last case in the draft PR i opened is more of a consequence of the workarounds needed to make the rather "exotic" case of breakable rowspans over unbreakable auto rows "work"

Presently, they are measured with infinite height at the region of the auto row, but this isn't really the best thing

So I'll just apply a workaround to make the case listed in the PR work for now (if the unbreakable auto row occurs at the first region of the rowspan, and the rowspan only occupies one region, we also layout the rowspan with infinite height), and in future versions we can study if there's a better way around this weirdness (maybe a way to not have to use infinite full height for the rowspan if it's breakable after all)

Don't really wanna delay anything so i think this will be the best way forward, I doubt this will be a common case anyway, just don't want users to think tables are broken :p

[wary knot]

(for clarification on the problem, check the last page of the updated test in the PR - one of the cells overflows)

[wary knot]

actually, can it be a problem to have full height be infinite but remaining height be finite? 🤔

i guess that's normally weird

haha

?r ```
#import "@preview/tablex:0.0.8": *

#tablex(
[hi] + block(height: 100%, width: 2em, fill: red)
)

[wary knot]

okay tablex has a similar problem

lol

the main thing is that 100% and ratios / relative lengths using ratios in general mean different things when measuring and when laying out, within the context of unbreakable auto rows

anyway

i think we can more or less accept at that unbreakable auto rows - a totally new feature - are more of an experimental thing and just move along

i'll undraft the PR soon

[azure berry]

@wary knot i previously had a table without any content to show a caro grid as background for my worksheets. With the new table implementation i need to add content with ..("",) * rows_count * cols_count that the table is shown. Otherwise it won't print anything. Is this intended behavior?

[wary knot]

i believe it should be enough to write table.cell(y: rows_count - 1)[]

in principle we didnt make any sort of explicit decision on that matter

are you sure it wasnt already like that?

[azure berry]

#let caro(rows, cols:auto) = {
  layout(size => {
    let cols = if( cols == auto ){ int(size.width.cm() / 0.5) } else { cols }
    table(
      columns: (0.5cm,) * cols,
      rows: (0.5cm,) * rows,
      stroke: 0.3pt + luma(140),
    )
  })
}

this was my previous function and it did work.

Now i added the line mentioned above, then it works again

Your solution works as well.

I guess your solution might be a bit better, performance wise?

[wary knot]

yours would be equivalent , normally

ok i tested in #bot-corner and it seems the previous behavior wasnt very reliable

ill see what i can do

[azure berry]

Anyway, i would have expected if i define a certain amount of rows, that they will all be printed, even if no content is available.

But the current solution is fine for me as well. 😉

[wary knot]

okay

I see what changed that caused this

to be honest im not rlly sure what would be the best thing to do here

for one, it does make sense for it to respect the rows you specified

but for another, specifying more rows than we were given is useful for templates for e.g.

being able to specify the sizes of rows if they are actually used

still, restoring this behavior would likely be quick to do

and probably should be done to avoid breaking changes like in your case

although something will certainly change since now you will have actual cells in those rows

they wont be truly empty anymore

but thats probably an acceptable compromise

either way, thanks for letting me know

[wary knot]

PR opened: https://github.com/typst/typst/pull/3644

thanks for reporting 🙂

[robust viper]

@wary knot I checked the PNG files and if a new test is added to a reference at the bottom, most of the binary contents are the same, which should allow git to do a binary delta-coding. As long as the image's width doesn't change and PNG keeps using the same encoding strategy, that means sort of efficient diffs might be possible. This relieves some of the pressure regarding reference images because otherwise just the most recent bug fix PR would have been 240KB added stuff. Still, switching to a hash-based test runner is one of my top priorities for after 0.11.

[trail oar]

Maybe we can also use this opportunity to add pdf and svg Tests?

But we would need to make it easy to update new ref images and view the difference

[robust viper]

That was also my thinking

[robust viper]

And that is indeed the main challenge

I'll open a new forge, give me a minute

[midnight heron]

I am generating a few options for table strokes for the docs guide. It occurred to me that we maybe want to allow set operations on strokes. I got the idea when I talked about the example with Laurenz and he was like I'd do the union between this one and that one. With set operations, packages or the core could export a few strokes which the user could then match to their desire. @wary knot do you think that would be a good feature for the compiler? https://github.com/typst/typst/issues/3636 may also be relevant (cc @runic oasis)

For comparison, here are all the table stroke functions I wrote for this demo:

#let af(x, y) = (
  left: if x > 0 { 0pt } else { 1pt },
  right: 1pt,
  top: if y == 0 { 1pt } else { 0pt },
  bottom: 1pt
)
#let nf(x, y) = (
  left: if x > 0 { 1pt },
  right: 0pt,
  top: if y > 0 { 1pt },
  bottom: 0pt
)

#let vertical-vf = (x: 1pt, y: none)
#let vertical-nf(x, _) = if x > 0 { (left: 1pt) }
#let vertical-af(_, y) = (
  x: 1pt,
  top: if y == 0 { 1pt } else { 0pt },
  bottom: 1pt
)
#let horizontal-hf = (y: 1pt, x: none)
#let horizontal-nf(_, y) = (top: if y > 0 { 1pt })
#let horizontal-af(x, _) = (
  y: 1pt,
  left: if x == 0 { 1pt } else { 0pt },
  right: 1pt,
)

#let flb-af(x, y) = (
  left: if x == 0 { 1pt } else { 0pt },
  right: 1pt,
  top: if y <= 1 { 1pt } else { 0pt },
  bottom: 1pt,
)
#let flb-nf(_, y) = (
  bottom: if y == 0 { 1pt },
)

#let flbh-af(x, y) = (
  left: if x == 0 or y == 0 { 1pt } else { 0pt },
  right: 1pt,
  top: if y <= 1 { 1pt } else { 0pt },
  bottom: 1pt,
)
#let flbh-nf(x, y) = (
  left: if x > 0 and y == 0 { 1pt } else { 0pt },
  bottom: if y == 0 { 1pt },
)

#let flb-h-af(x, y) = (
  left: if x == 0 or y > 0 { 1pt } else { 0pt },
  right: 1pt,
  top: if y <= 1 { 1pt } else { 0pt },
  bottom: 1pt,
)
#let flb-h-nf(x, y) = (
  left: if x > 0 and y > 0 { 1pt } else { 0pt },
  bottom: if y == 0 { 1pt },
)
#let flbh-h-af(x, y) = (
  x: 1pt,
  top: if y < 2 { 1pt } else { 0pt },
  bottom: 1pt,
)
#let flbh-h-nf(x, y) = (
  left: if x > 0 { 1pt } else { 0pt },
  bottom: if y == 0 { 1pt },
)

[wary knot]

Got it

I'll leave my thoughts in the forge thread later

[wary knot]

Well, you can already union by just appending the lines at the correct positions

As in ..lines

I'm not rlly sure what you would use the other set operations for, a use case would be best to evaluate that imo

[robust viper]

That forces you to adjust the table itself though. This was more about simplifying stroke configuration in global styling.

[pallid surge]

Not sure if it is ready yet, but the documentation for the first shown table is wrong here: https://staging.typst.app/docs/reference/model/table/#definitions-cell (code != image)

[wary knot]

Well... Maybe we need to make #set table(line1, line2, line3) work 😎

Lol but yeah i see what you mean

Though in principle it sounds a bit intrusive or possibly inconsistent to modify all tables like that

Or at least you'd still have to predict the size of the table

So it sounds more practical to make table generator functions than to use show / set rules

[wary knot]

Yeah I've commented on this before

Personally I'm in favor of changing that somehow, either changing the example or having something simple enough to be able to include all of the code

[robust viper]

I'd prefer simplifying the example then

Because the current code is too noisy

[wary knot]

Sounds fair to me

We could use headers to demonstrate colspan

And just have a very simple table like that

[wary knot]

Alright, there's one more thing i wanna fix

Though it's not urgent

So I'll work on it today but it's not a blocker if I don't finish it in time

But basically the footer thing where we move to the next row after the latest auto cell isn't really that smart, since it's possible that the next row will also be occupied
Ideally we'd skip until we found a suitable position for the footer

i.e.

#table( columns: 2, table.cell(rowspan: 2)[a], table.cell(rowspan: 2)[b], table.footer() )

will error cuz it will try to place the footer at the second row instead of the third

But anyway it's not that bad, i think adding a single auto cell to the footer makes the error go away so

This mostly just affects lines and stuff really

[wary knot]

ok ive fixed it in the new PR

the problem wasnt exclusive to empty footers, so it was worth a fix

anyway , hopefully this will be the last PR with adjustments and stuff before 0.11

:p

because there surely are no more bugs!!! 😄

[exotic leaf]

Is it desired that the header is affected by row-gutter?

#set page(width: 15cm, height: auto, margin: 1cm)

#table(
  columns: (1fr, 1fr, 1fr),
  stroke: none,
  row-gutter: 0.25cm,
  table.hline(stroke: 2pt),
  table.header([Header 1], [Header 2], [Header 3]),
  table.hline(),
  [Cell 1A],
  [Cell 2A],
  [Cell 2A],
  [Cell 1B],
  [Cell 2B],
  [Cell 2B],
  [Cell 1C],
  [Cell 2C],
  [Cell 2C],
  table.hline(stroke: 2pt),
)
Table with `row-gutter` set to `0.25cm`

#v(1cm)

#table(
  columns: (1fr, 1fr, 1fr),
  stroke: none,
  table.hline(stroke: 2pt),
  table.header([Header 1], [Header 2], [Header 3]),
  table.hline(),
  [Cell 1A],
  [Cell 2A],
  [Cell 2A],
  [Cell 1B],
  [Cell 2B],
  [Cell 2B],
  [Cell 1C],
  [Cell 2C],
  [Cell 2C],
  table.hline(stroke: 2pt),
)
Table with default `row-gutter`

[wary knot]

Yes, for consistency

You can remove the row-gutter below the header by setting it to 0pt

row-gutter: (0pt, 0.25cm)

Of note, what you have there is a line above the row below the header and not a line in the header itself

For that you'd need to use position: bottom on a line above the last row of the header

Cuz when there's gutter you have two possible positions for a hline: above and below a row (read the docs on hline.position for more info)

[exotic leaf]

Ok, thanks for the quick response. Is there a possibility to remove the little inset left of the first column?

[wary knot]

try inset: (x: 0pt)

On the table

[exotic leaf]

Thank you, this works

[midnight heron]

There sure is a lot to document about tables -- the section on strokes in the WIP table guide alone fills almost 8 screens on my computer!

[grand haven]

You have more than 8 monitors? 🙃

[midnight heron]

I'm a bit of a Wall Street Trader myself

https://tenor.com/view/matrix-the-gif-24707533

Me on my Bloomberg Terminal

[wary knot]

Wow lol

We should probably try to keep it as concise as possible, don't want people to just look at the sheer length of the guide and retreat 😅

But I think a clarification at the beginning that the guide covers various use cases and they should look for their use case could be helpful

[wary knot]

oh hey

just saw the guide was merged

I'll take a quick look if y'all don't mind

I'll let you know if I have any comments

[robust viper]

I'm currently preparing the release, so I'm afraid comments won't make it in anymore. :/ But I reviewed and edited the guide carefully, so I think it should be okay.

[wary knot]

ah okay

no problem

I see now that there were indeed a few iterations

I'll trust you 🫡

[robust viper]

It's also very comprehensive, so it would likely take you a while to review

[wary knot]

fair enough, didnt realize we were so close to release haha

anyway , just keep it up then 👍

changing the topic a bit, overall I think the pre-release was very successful

we did indeed find and squash some important bugs so that's cool

[vernal herald]

so many bugs were captured..

[wary knot]

yep

[robust viper]

yeah indeed

[potent talon]

The guide is super nice ! I haven’t played with it but it looks like we can set booktabs-like for all document ? If so, that would be a nice example in the doc

[wary knot]

Do you have a picture of the style you're looking for?

(Just for reference 🙂 )

[potent talon]

https://nickhigham.files.wordpress.com/2019/11/table_ex2-1.jpg?w=863

I’ve stealed somewhere this setup used here https://typst.app/project/pF-FdwYCg-fO6GcrAV9-DK (sorry am on mobile cannot get a MWI)

[wary knot]

Ah

There was an example on this in this thread

Discord mobile is horrible for threads so I can't search lol

[potent talon]

#let toprule = hlinex(stroke: (thickness: 0.08em))
#let bottomrule = toprule
#let midrule = hlinex(stroke: (thickness: 0.05em))

#figure(
gridx(
columns: 2,
[Catégorie], [Métrique],
toprule,
[Échantillon], [Concentration ADN],
midrule,
[], [Quantification de la librairie],
bottomrule
))

Something like this

[wary knot]

Yeah it's possible

[wary knot]

Here you'd basically have a rowspan of 2 at the top left, then a colspan of 3 with the tol = thing, and another colspan of 3
The rest would be normal cells

Regarding lines, you'd have three table.hline() calls, at the top , middle and bottom

And the two colspans of 3 would have “stroke: (bottom: 0.5pt + black)”

The global table stroke would be set to none

[potent talon]

I’m only interested in the hlines (toprule, midrule and bottomrule defined above) 🙂

[potent talon]

That’s what I thought from the doc but haven’t got access to internet to test it yet. That would be great 🙂

[wary knot]

for the spacing between columns, you can use column-gutter

Here the choice of table.hline vs stroke: (top: ...) matters

Hlines can cross gutter , while stroke goes around cells, so it can't

[potent talon]

Interesting

[upbeat pine]

...
#let colspan(n, ..args) = table.cell(colspan: n, ..args)
...
#table(
  ...
  table.header(
    [Team member], [Monday], [Tuesday], [Wednesday], [Thursday], [Friday]
  ),
  [Evelyn Archer], colspan(2, ofi), colspan(2, rem), ofi,
  [Lila Montgomery], colspan(5, lea),
  [Nolan Pearce], rem, colspan(2, ofi), rem, ofi,
)

lt was such a great example to import cell or even better: a custom function that will shrink down horizontal space even further.

[wary knot]

i think it's fine

^

there's an example which mentions importing so i think thats enough

[upbeat pine]

importing still wouldn't be short enough to make 1 row per line.

this is redundant.

My gut would say "get x n times", so I would've written 5 the last. That's how I write everything, and I think that is how others also write.

[wary knot]

well...

im sorry but we're being way too nitpicky at this point :p

to be honest im probably not gonna look at these docs again (with the eyes of a reviewer at least) for a good several days

let's rejoice , for the release has come forth

🚀

[upbeat pine]

If you have placed your table inside of a figure, it becomes unable to break across pages by default. However, you can change this behavior. Let's take a look:
this brings the question: why is figure's block is not breakable by default? is block globally not breakable?

[upbeat pine]

I expected the last part to be "ever".

[wary knot]

this wouldnt be desirable for most figure kinds

the idea is to display some stuff with a caption right below it

so most of the time you don't want it to span a pagebreak

[wary knot]

well, i wouldnt be saying the truth then :p

[upbeat pine]

I expected the last part to be "ever", judging how the sentence is started.

[upbeat pine]

I can nitpick while being happy that the new version has released.

[upbeat pine]

bruh, I thought I didn't send the message, but only now realized that I did. All because Ctrl+W closed the damn tab again..

[upbeat pine]

ohh, because it can break apart the body and the caption?

oh, no, the proprietary software from micro and soft mentioned. A sad reality...

Why would you complicate the example with unnecessary destruction when you can slice 2 instead?

...slice(2)...
let (year, count) = m

[wary knot]

m isn't the one being sliced here though

[upbeat pine]

m is literally the result of the slice.

[wary knot]

no

this isn't Rust lol

slice doesnt return Option<T>

to put it more clearly: moore is a list of lists

you removed one list

the header

[upbeat pine]

Typst differentiates between grids that are for layout and presentational purposes only and tables, in which the arrangement of the cells itself conveys information.
I wanted to say that double "and" isn't a good thing, and I tripped over this sentence as an example of why it is bad.

[upbeat pine]

ahhhhh, I thought it removed the first column...

yeah, then it's fine.

[upbeat pine]

I didn't get the reference (no, this isn't a pun, unfortunately).

[wary knot]

lol

i thought you were confusing .map with Option::map or smth

since m is clearly not the list itself

but an element in it

but yeah i mean it happens

[upbeat pine]

option map??? whaat? haha Have I missed something in the basics?

[wary knot]

huh

like Some(5).map(|x| x + 1) // Some(6)

[upbeat pine]

Ohh, riiight.

I already forgot that you can do this.

[wary knot]

ye but anyway, does the text mention that it's skipping a header? If not, it should, sure

[upbeat pine]

I only have a strong connection with map being applied on list only

[upbeat pine]

In this example, we first drop the header row from the data since we are adding our own.

Phew, finally finished half-skimming through the guide. It's great but veeeeeeeery long. I already asked a bunch of time "where is the end?" and "it's still going?!"

I already remembered that it contains a bunch of nice snippets for different styling of a table. Good stuff. Now I or (more realistically) other user wouldn't have to be smart by making those conditional strokes/fills. Just copy and use it.

[robust viper]

It is very long indeed, but it's also not necessarily meant to be read in full. You can just skip to the relevant section when you need the thing it explains.

[upbeat pine]

It literally has guide in the name. afaik the guides are for guiding the newcomers or something, so if I'm not mistaking you are supposed to read it full.

[grand haven]

Guide can mean many things.

[vernal herald]

A User Guide isn't supposed to be read in full prior to usage.

example: https://pandoc.org/MANUAL.html. I've rarely met folks who've read this beautiful thing in full, yet all use pandoc.

[upbeat pine]

yeah, here you are right.

I mean it's small enough to be manageable to read in one sitting, so... yeah.. but not really.

[plucky haven]

@robust viper Are thumbnails on packages.typst.org public? For example, https://packages.typst.org/preview/thumbnails/charged-ieee-0.1.0-small.webp .

[upbeat pine]

This should probably go into #contributors.

[robust viper]

wdym with public?

[plucky haven]

sorry, I posted to the wrong channel.

[upbeat pine]

Ah, yes, finally I can add

#let table(..args) = table-old(
  ..args.named(),
  ..args.pos().map(x => if type(x) in (int, float) [#x] else { x }),
)

to the native tables and add pass numbers to it.

[dark wasp]

can't you just use ..args.pos().map(x => [#x])?

it should be equivalent, no?

[upbeat pine]

positional would be also table.cell etc.

[dark wasp]

oh, right

[upbeat pine]

The problem with that is now all the table.* things are broken and I either have to import them or use table-old.* instead. Not ideal...

[wary knot]

yea i'd suggest giving it a different name

[upbeat pine]

This will kill field autocompletion.

[dark wasp]

you can define a number of named arguments yourself: #let num-table(columns: auto, column-gutter: auto, ..args)

[upbeat pine]

Well then it wouldn't be as neat as it is now, now would it? Plus the descriptions will be gone. And I would have to have this massive snippet saved somewhere, because there is no way I can recreate it from scratch and remember all the fields from my memory, unlike the example I showed. Actually, this is a good point, I should add a snippet for it.

[dark wasp]

honestly, I would consider the auto completions where there is an overriding let table a bug

[upbeat pine]

true

until we can make a full-fledged copy will all the fields, description etc. while having a different function name, this is the only hack we have. So, waiting for the typed parameters + doc comments.

[bold bluff]

I did a box split:

Thanks! @wary knot

[wary knot]

Ooooh nice

Send this to #1175784402333212733

[upbeat pine]

If kinda tall cell doesn't fit on the page will it be fully placed on the next page or only partially?

Because it does the second option and repeating header is inserted in between the cell's content. I think that's a bug.

[upbeat pine]

The "keep caption with table" hack when overriding a figure show rule for table was causing that. But removing figure, it still happens.

#let leading = 1.5em
#let leading = leading - 0.75em // "Close enough normalization"
#set page(margin: (left: 3cm, right: 1cm, y: 2cm))
#set block(spacing: leading)
#set par(leading: leading)
#set text(size: 14pt, lang: "ru")

#import table: hline, header
#let head(text, stroke: 0pt) = (strong[#text:], hline(stroke: stroke), [], [],)

#v(22cm)
#table(
  columns: (9cm, 2.5cm, 1.5cm),
  align: (x, y) => if y > 0 and x == 0 { left } else { center + horizon },
  header([Наименование], [Число элементов данных], [Ранг]),
  ..head[Внутренние логические файлы],
  [
    + Таблица "Доверенности"
    + Таблица "Доверенные лица"
    + Таблица "Организации"
    + Таблица "Материалы"
  ],
  [
    10--15

    < 10

    < 10

    < 10
  ],
)

Not only does the second header add itself in the middle of the cell/row, but it doesn't add the hline for itself, like it always should.

[wary knot]

You added an empty hline above the cell being split

It overrides the cell stroke below the header

You can add an hline below the header if you'd prefer for it to win

[wary knot]

It's intended.

You can use table.cell(breakable: false) if you would like for it to not be broken apart

[upbeat pine]

I would've never thought of that. Strange, but it works and that at least fixes half of the problem.

[wary knot]

Well we were trying to conciliate multiple requirements here so it was a bit hard

We want hlines to win but we want headers to have priority

So we made header strokes have priority over cell strokes , but not over hlines

[upbeat pine]

Yeah, that fixes the second half.

[wary knot]

But header hline will always appear

[upbeat pine]

Well, at least now I know how to deal with such problem. Thanks.

[wary knot]

np

[upbeat pine]

Feels like a bug:

?r

#let colspan(n, body) = table.cell(colspan: n, body)

#show table.cell.where(y: 0): set table.cell(align: center)
#show table.cell.where(y: 0): it => {
  show table.header: set table.cell(align: center)
  it
}
// #show table.cell.where(colspan: 2): set table.cell(align: center)
// #show table.cell.where(colspan: 2): it => {
//   show table.header: set table.cell(align: center)
//   it
// }
#figure(table(
  align: (left + horizon, left, center, center, center),
  columns: (2.5fr, 1fr, auto, auto, auto),
  table.header(colspan(2)[A], [B], [C], [D]),
  [],
  [],
  [],
  [],
))

[upbeat pine]

how to center content of a *spanned cell? not inline

[wary knot]

You can't use show set with table cells or headers or footers or lines

I'm extremely aware of that already, don't worry haha

At most you could use normal show rules with an #align or smth

[upbeat pine]

bruh, not the "normal show rules". they are the plague that makes the document fall apart really quickly with heavy customizations.

there is also breakable stuff, that might get affected.

[wary knot]

I'm just sayin' pal

That's the best you can do rn

Otherwise there isn't much you can do

[upbeat pine]

me too

[wary knot]

Fair

We are engaging in simultaneous human communication

The truth is that we live in a society

[upbeat pine]

we live in a society

[upbeat pine]

    align: (x, y) => if y == 0 { center } else {
      (left + horizon, left, center, center, center).at(x)
    },

[turbid granite]

Thought I'd share this comment I ran into about table limitations in LaTeX, I think it might be possible in Typst, but not sure about the status with multi-column support:

https://dercuano.github.io/notes/general-purpose-layout-syntax.html#addtoc_14

This combination of things in LaTeX is annoyingly apparently impossible: multiple-column mode; tables spanning multiple pages/columns; groups of rows within said table which should not be broken apart --- oh, and header rows on the said table which repeat after every column/page break.

(more in the link)

[wary knot]

Not sure, an example would be nice

Text felt a bit dense, or maybe it was 2 am and I was too tired

😅

But if you mean #columns(2) then that should be possible and work

Groups of rows - that one we don't have yet

[wary knot]

https://github.com/typst/typst/issues/4023

now this one is interesting

i have like zero idea how this could happen

😂

[upbeat pine]

Wow, this is the best error ever:

failed to format citation (this is a bug)

But that means that someone already predicted this.

Oh... there is only one place with that:

╰─ hg 'this is a bug'
crates/typst/src/model/cite.rs
162:            .unwrap_or_else(|| bail!(span, "failed to format citation (this is a bug)"))

[wary knot]

yeah uh

it only happens when the header is repeated

or footer

i also tested querying a labelled header inside a header or footer and it worked, so introspection isnt broken, at least not fully

something weird happened with citations

no idea how

well ive nailed it down further, only happens on the first page of a repeated header

on the following pages it's ok

[bold bluff]

I mean it’s uncommon to put labeled or reference things inside the head or footer so maybe that’s a issue , but I don’t know

[wary knot]

it isnt common yeah

but theres definitely something wrong somewhere

probably some very cursed detail i overlooked

[bold bluff]

When you repeat items across pages is the first one the real McCoy and the rest just visual duplicate or would the reference be repeated?

[wary knot]

nah we layout multiple times

admittedly a bit inefficient but im not sure theres another way due to contextual stuf

i also made a few more discoveries

using 1fr rows for the header or footer also fixes it

and auto row makes the footer error on the first page but not on the rest (just like the header)

but fixed-size row for footer makes it not error at all, while header still errors

so. very interesting

[bold bluff]

So if I was to put a reference in the header <mylabel> that would probably cause problems if it had more than one copy

[wary knot]

i also broke the compiler somehow lol

it's loading forever

i typed rows: (1%, 2em)

lol

hmm interesting

[bold bluff]

I mean it’s suddenly dumping on you. Not cool

[wary knot]

ok for some reason rows: (1%, 2em) makes the compiler go insane

lol

actually it has a memory leak and dies

no idea what's that one lol

[bold bluff]

I’m assuming non relative sizes don’t cause issue

[wary knot]

technically they're all relative

but i assume you mean non-ratio

[turbid granite]

I am loving these updates. This is so cursed

[wary knot]

welcome to debugging hell

😂

i still dont have any idea what this could be

and especially why it only happens at the first page of the table

[upbeat pine]

Time for some more bug reporting

[plucky haven]

Did we discuss about grid for mat?

#contributors message

I saw the mat added augment. I didn't like it as it is too specific for concrete cases. It seems just a grid.vline or grid.hline.

[upbeat pine]

I think it is just an oversimplified version of those two. I also didn't like it, and AFAIK you can only change stroke for all of them at once.

[velvet garnet]

Found a nice workaround for this until the show set rule is fixed for table headers:

I usually have a wrapper function to style my tables, so I pass in a value for header-rows and do...

let selectors = for i in range(1, header-rows) {(table.cell.where(y: i),)}
show table.cell.where(y: 0).or(..selectors): strong

The for loop builds an array of selectors to pass to the or() method. Would need to wrap the styling function in an if statement to cover the case where you might have no header.

You could instead pass the header in as a named argument and actually work out the number of rows automagically, but find this way works OK for me.

[upbeat pine]

?r

#let header-rows = 5
#show: doc => {
  show: it => {
    let selectors = range(header-rows).map(i => table.cell.where(y: i))
    if selectors.len() == 0 { return it }
    show selector.or(..selectors): strong
    it
  }
  doc
}
#table(..([h],) * header-rows, [a])

[bold bluff]

I found a odd thing

?render

#table(
  columns: (3.47em, 7.88em, 5.42em, 13.22em, 5.42em),
  rows: (8.05em, 4.06em, 5em, 11.23em),
  stroke: 1pt,
    table.cell(
      box(
        width: 3.47em,
        height: -2pt + 5em,
        inset: 0pt,
        clip: true,
        align(
          center + bottom,
          box(inset: 0.2em, [H]),
        ),
      ),
      x: 0,
      y: 2,
      colspan: 1,
      rowspan: 2,
      fill: black,
      inset: 2pt,
      stroke: 0.5pt + luma(0%),
    ),
)

[bold bluff]

The "H" although it is told to be aligned to the bottom kind of floats in the middle.

it might me my fault. cause the height seems weird.

[frail mortar]

It's aligned with respect to the box which is only as high as the 3rd row

[bold bluff]

Yes. yes it is. 🙂 🙂 :0 🙂

?render

#table(
  columns: (3.47em, 7.88em, 5.42em, 13.22em, 5.42em),
  rows: (8.05em, 4.06em, 5em, 11.23em),
  stroke: 1pt,
    table.cell(
      align(
          center + bottom,
        box(
          width: 3.47em,
          height: -2pt + 5em,
          inset: 0pt,
          clip: true,
          box(inset: 0.2em, [H]),
        ),
      ),
      x: 0,
      y: 2,
      colspan: 1,
      rowspan: 2,
      fill: none,
      inset: 2pt,
      stroke: 0.5pt + luma(0%),
    ),
)

[bold bluff]

That should fix it right?

Nm it only still affects the box stuff.. boy what a day.

[grand haven]

https://github.com/typst/typst/issues/4707 I created a feature request for my question in #quick-questions

[robust viper]

sadly the grid ends immediately so it doesn't repeat

I think without introspection trickery its difficult

but with introspection it's possible I think

[grand haven]

Probably possible, but more effort than I'm willing to put it in right now for just a referee report :p

[robust viper]

just gotta nerd snipe someone into doing it for you ^^

[grand haven]

I just noticed something else. Is this a bug?

?render ```
#set page(width: auto,height: 2cm)
#table(
columns: 2,
stroke: none,
table.cell(rowspan: 3)[A],[B],[C],[D],table.hline()
)

[grand haven]

or, maybe not a bug, but not always desirable

[robust viper]

cc @wary knot

[wary knot]

whats wrong here?

[grand haven]

The hline shouldn't appear on the first page

[wary knot]

if i recall correctly it's how it works, the last hline is repeated on every page

[grand haven]

the last hline in every table you mean?

[wary knot]

yes

using cell stroke instead of hline could even it out in terms of priority

cuz hlines are always top priority

but i dont remember the full semantics for conflict between the repeating stroke and previous strokes, i think a previous stroke wins if it's higher priority, but not if it's <=

[upbeat pine]

FYI, I had a hard time reading this until I formatted the code (too much cramped to a single line). It's better to do that, if you have a chance.

#set page(width: auto, height: 2cm)
#table(
  columns: 2,
  stroke: none,
  table.cell(rowspan: 3)[A],
  [B],
  [C],
  [D],
  table.hline(),
)

[grand haven]

@wary knot okay there's definitely something weird

?r ```
#set page(width: auto,height: 2cm)
#table(
columns: 2,
stroke: none,
table.cell(rowspan: 3)[A],[B],[C],[D],table.hline()
)

[grand haven]

?r ```
#set page(width: auto,height: 2cm)
#table(
columns: 2,
stroke: none,
table.cell(rowspan: 3)[A],[B],[C],[D],table.hline(),[E],[F]
)

[grand haven]

So this matches what you said about the last hline

[wary knot]

looks correct to me

the idea is to allow proper borders around tables

it makes more sense when you include the other lines that repeat too (top, left, right)

w/ that said, we could consider having some way to opt out from this behavior

but it was quite hard to find a good enough API for all use cases :p

[grand haven]

yeah but I have situations where this doesn't act this way

struggling to find a mwe

[wary knot]

it all depends on table stroke vs cell stroke vs v/hline

typst computes priority at each cell border

[grand haven]

See the example in https://github.com/typst/typst/issues/4707

I have no strokes, only an hline after the header and between each page

there should be no line at the bottom of the first page in the picture

[wary knot]

i cant tell without the code

[grand haven]

I know, that's why I wanted to find an mwe

[wary knot]

but in principle if theres any stroke at the bottom it will repeat

period

w/ that said, it can be overridden if it's lower priority in previous pages

[grand haven]

There's only a stroke on the leftmost cell

[wary knot]

are you sure? theres stroke on all cells at the bottom

im not talking about per-cell stroke, but any kind of stroke

including stroke: something in the table

[grand haven]

@wary knot okay I finally figured it out. I'm just too sleepy. It was truly just the repeating last hline in the table

But I'd like to disable that behavior

There's no special significance to it in my case

Shouldn't the table.footer be used for what you're talking about?

[wary knot]

no, it's for borders

it's similar to blocks with stroke, except that you can control the lines more precisely than just a single line crossing the whole bottom of the table

[wary knot]

you can open a feature request for that , we can try to reach some api for this

[grand haven]

my point was that there's some special significance to the last line in a table, and to me that sounds like something that should be related to the footer instead

[wary knot]

footers are more about repeating cells , this is a separate concept, it's more of a style choice than anything

an issue would be good to collect other people's opinions so we can know which api works best

[lone nova]

I understand that tables in Typst don't work well with rotated text, right?

Even if you set reflow: true, it just causes the text to overlap the cell borders and go beyond them.

[grand haven]

That sounds like a bug

https://github.com/typst/typst/pull/4462

probably works on main @lone nova

[lone nova]

Nope, I'm already on main 🙂

?r

#set page(width: 50mm, height: 70mm, margin: 0.5cm)
#set text(size: 10pt);

#table(
  columns: 2,
  gutter: 5pt,
  table.header(
    table.cell(colspan: 2, text(size: 1.5em)[*Some name*]),
  ),

  rotate(-90deg, reflow: true, text(size: 1.1em)[Religion]),
  rotate(-90deg, reflow: true)[#lorem(15)],
)

[grand haven]

Okay so then I don't know, but it's unlikely to be specific to tables. What happens in a rect?

[lone nova]

It seems to be table specific.

[upbeat pine]

You have to use ?r separately from your message.

[lone nova]

?r

#set page(width: 70mm, height: 70mm, margin: 0.5cm)
#set text(size: 10pt);

#stack(
  dir: ltr,
  rect(rotate(-90deg, reflow: true)[#lorem(25)]),
  rect(height: 50mm, rotate(-90deg, reflow: true)[#lorem(25)])
)

[grand haven]

No

?render ```
#set page("a10")
#rect(rotate(33deg, reflow: true,[Religion]))

[grand haven]

though I can't reproduce the last example on main

the table I can

@wary knot table shenanigans?

[wary knot]

idk what reflow is doing here to be honest, but table does depend on measure() internally, to some extent

it first measures width and then measures with fixed available width to figure out the height

assuming auto columns and rows

[grand haven]

I guess they should create an issue

[timber bronze]

What does setting gutters to auto mean? This is not explained in the doc, and auto for Sizing usually means "fit the element's content", but for gutters there is no content.

As noted in #3959 (comment), auto on {column,row}-gutter does not mean "inherit the value from gutter".

[robust viper]

It just the same type as normal sizings. So in this case it is the same as 0pt.

[timber bronze]

Does this mean auto always resolves to 0pt for grid gutters? Then, wouldn't it be better to use auto on {column,row}-gutter to inherit the value from gutter, and not support auto on gutter?

And what's the point of being able to pass an integer n as a shorthand for n * (auto, ), which, if I understand well, is the same as simply auto, i.e., 0pt?

[robust viper]

There isn't really a point. It's really just that both use the TrackSizing type in Rust.

[wary knot]

I considered outright removing it during the table rework, but it felt equally pointless to do so

¯_(ツ)_/¯

It may interact a bit weirdly with rowspans, but i remember i at least considered that case

[timber bronze]

Ok. I'll try to see if I can change that

[wary knot]

I think we shouldn't worry too much about it unless there's a nasty bug related to it

[timber bronze]

It's not great user experience in my opinion, and would let us close #3959 (which is not a bug, but still)

?r

#table(
  columns: 2 * (1cm, ),
  gutter: auto,

  [hey], [ho],
  table.cell(colspan: 2)[spaaaaaaaaaanned],
)

[timber bronze]

I guess this is a case where row-gutter: auto makes sense, but this requires more work than just not allowing auto for gutter

[robust viper]

I don't really see the point of having auto on column-gutter inherit from gutter. What would be the use case for that?

[timber bronze]

I think it makes it easier to understand for the user, for two reasons:

• This is how a user would have to implement a shorthand-like argument in a custom function (without using argument sinks).
• It would improve the documentation (see the aforementioned issue).

[heady tide]

I’m curious whether you think adding a gutter option to table.hline (and to table.vline) is worthwhile; after all, you could always adjust the gutters of the table itself instead

[wary knot]

conceptually, i think some way to configure a particular gutter around some row would make more sense than attaching it to table lines, cuz in practice theres no relation between gutters and lines

in particular ive had the idea in the back of my mind for a while now of having some sort of table.row or table.rows primitive to configure a row / group of rows on the spot

but at least for me thats gonna be lower priority , there are other table things i want to do first

like i'd love to get the multiple headers idea going at some point

worth clarifying that none of this would come for 0.12 though, just some thoughts for the future

[upbeat pine]

||I can't forward without somehow making an old thread recent... so stupid||

Instead of this:

#show table.cell.where(y: 0): strong
#table(
  columns: 2,
  align: (_, y) => if y == 0 { center } else { left },
  table.header[Имя][Роль],
  ...
)

You would simply do this:

#show table.header: set align(center)
#show table.header: set text(weight: "bold")
// #show table.header: strong
#table(
  columns: 2,
  align: left,
  table.header[Имя][Роль],
  ...
)

[wary knot]

there is nothing blocking it other than https://github.com/typst/typst/issues/3640

until that's fixed it's a no go

[upbeat pine]

okey-dokey

My main concern is will Typst allow this, since, IIUC, the intended way is to use alignment callback in the table constructor.

[wary knot]

it wouldnt be too different from #show table.cell: set align(...), which generally doesnt look very good

[upbeat pine]

btw, does this snippet work?

I haven't tested that.

[wary knot]

table.header is never laid out as an element, so show-set doesnt have an effect

as well as just show

[upbeat pine]

This is what I wanted to ask. If you can do that for the table cell show rule, then it makes sense that you can do the same with header.

[wary knot]

it's desirable, yes

the reason it doesn't work is that the header's cells are laid out, not the header itself

[upbeat pine]

no, I mean this

does this work

[wary knot]

probably not as you'd expect

[upbeat pine]

hm

[wary knot]

ideally you'd write #show table.cell: set table.cell(align: ...)

but that's not possible atm (it's a separate issue)

similarly for your header proposal you'd be able to write #show table.header: set table.cell(align: ...)

[upbeat pine]

oh... So both will work in the end? this and previous show-set rule?

Isn't this... too much of ways to do the same thing?

[wary knot]

#show table.cell: set table.cell(align: ...) is probably always gonna be preferred

if it's ever supported

[upbeat pine]

Don't say that!

it will, I mean at least some way should be supported

[wary knot]

lol

thats not what i meant, i meant unless we change how tables work more fundamentally

[wary knot]

the thing is, it's not the same

[upbeat pine]

Table rewrite v2 when

[upbeat pine]

If you look at a bigger picture, then yes.

[wary knot]

roughly set align applies to the cell as a whole, including stuff coming from other table.cell properties, while table.cell(align: ...) applies only to its body

thats not 100% accurate but thats more or less the idea

[upbeat pine]

stuff coming from other cell properties?

[wary knot]

like align itself and also inset

i wont remember now the exact list but it's in the show rule for cells

[upbeat pine]

I thought of: show cell: set align() will modify the alignment of all blocks inside... This doesn't make sense. I think either way everything inside will inherit the new alignment. So show cell: set cell(align) should would the same in this regard.

[wary knot]

yeah it's recursive, so the body is always affected

[upbeat pine]

Explain how setting cell alignment affects/interacts with cell inset. I'm confused.

[wary knot]

well i was trying to dig this up but it seems the behavior changed in 0.12

and it was actually writing align(x)[abc] vs table.cell(align: x)[abc]

which is different from the show-set rule

table.cell is basically shown as align(cell.align, pad(..cell.inset, body)) , and the pad would have the effect of "breaking" the alignment inside the body

so align(x)[abc] wouldnt work

but it seems to have changed as of 0.12, particularly this commit https://github.com/typst/typst/commit/34f1a232463bafeb3d8d3fa9adeae33c4bb95b23#diff-96ff5960282cc5e0779470ead3b9065e1d278ce779b66c3c7848fba15c862e1d

so there probably wont be much of a difference now, though there might be some edge case im not aware of

[random mica]

What if Typst could infer the width of a table from the array provided to table.header?

That would be so convenient and make some sense imo; I think tables are really missing an easier way to specify dimensionality without a hard coded number

[grand haven]

What exactly do you mean by this, automatically sized based on header width?

[random mica]

to clarify; I mean width as in # of columns

😅

[grand haven]

Not all tables have a header though, and I don't think it necessarily needs to have the same number of cells as the table

[random mica]

For sure, but as a default if the columns parameter of a table is auto, I think it's pretty sane to set it to the length of the header

[grand haven]

It sounds a bit magical

Not saying the current situation is ideal

[random mica]

It sounds like a pretty good way to get that information from the user 'seamlessly' and it encourages always using table.header (which as its documentation suggests is a good idea regardless)

(of course, only if the table logically has a table)

[supple eagle]

Reminds me of how for [a, b, c] in iter.array_chunks() works without explicitly setting array_chunks::<3>()

[upbeat pine]

You should make a feature request.

[random mica]

that's just normal type inference; [a, b, c] is a pattern for values of type [_; 3]

[signal breach]

I've just added a feature request for the tabulate python package https://github.com/astanin/python-tabulate/issues/358 to add Typst support.

It is a very usefult package and is frequently used with pandas dataframes to get nicely formatted tables. It supports loads of output formats (markdown flavors, html, LaTeX...) and it would be great to have there some Typst support.

[signal breach]

I've just found Pypst, which is a nice package too https://krokotsch.eu/pypst/

[upbeat pine]

Is it currently difficult to make a reactive (to page) table figure caption? For long tables.

[upbeat pine]

I'm guessing show table.cell: set table.cell is one of the rules that currently does not work? Is it supposed to work in the future?
https://forum.typst.app/t/problem-with-applying-the-show-rule/3300/2

[grand haven]

@wary knot tabularray adopted my feature request https://github.com/lvjr/tabularray/issues/381

[wary knot]

hmm, im pretty sure you sent this before? but yeah , neat

[grand haven]

Hm

Maybe the feature request itself, but it was only implemented very recently

Do you think something similar could work for typst?

[wary knot]

i think they are different models but yeah , i think something like that is possible

perhaps we could just use labels and show-set

at least this works right now...

?r ```js
#show <red-cell>: set text(red)
#table(
[a],
[#table.cell[ast] <red-cell>]
)

[wary knot]

but unfortunately it is limited, since you cant show-set on table cell properties atm, as well as on headers

also you cant label a whole row. i suppose this could be one usecase for table.row

and the fact that you have to use markup mode to attach a label is a bit annoying and even misleading, dare i say, so i guess that's another argument to support labels in code mode

[robust viper]

The issue that table input is a bit annoying (for manual tables, but also for data-generated table) because cells jump around if one is missing has come up a couple of times now. But, more generally, in my opinion, creating and styling complex tables is a bit of a hassle currently.

Aside from table.row (and possibly table.column), which were proposed before, I'd also like to throw a table.region function into the ring. This would be a rectangular subregion of a table, with the following characteristics:

• On the region, you can set parameters like stroke etc. just like on the table.
• Within the region, the x and y parameters of cells are relative to the region.
• Within a region, a table.row and table.column are local to that region.
• The region could be used in show/set rules.

The main benefit is that this makes it easy to decouple data cells from "meta" cells instead of having to stitch everything together into a single stream of cells and having complicated styling rules based on x/y.

The idea is quite fresh and untested and I haven't gotten around to experimenting with how well this would work out in practice, but I think it could be quite useful. Typically, it's not random if a table styling differs across parts of a table. It's because for the human reader, the table decomposes into different pieces with different meaning. Making this explicit could make styling quite a bit easier.

[wary knot]

Well, Ive been considering adding row groups (that aren't headers or footers) for a while, but i suppose a more general region is useful
In general, have the auto cells automatically avoid some predefined cells without having to manually position them (the predefined cells themselves can be auto)

Though I'm not sure about the positioning, having x / y be relative to the region sounds circular at first as the region in theory would inherit the position of its children, but i suppose thats a less useful behavior compared to manually setting something like top left corner + width and height

So there's some room for flexibility, but I think I'd create separate fields such as dx/dy to ensure x/y in table.cell has only one meaning

[robust viper]

In my model, the region would auto place itself like a large cell with colspan/rowspan would. Those I suppose the width/height determination of the region would require some thought to avoid cycles. Perhaps it would just need to be explicitly given. (At least the width)

[mossy rampart]

Also somewhat related to this, there is currently no way of expressing header columns, or just singular header cells (which could be regions I guess).

[vagrant pagoda]

How does region link with rows and how is it determined how big a region is? I would aim to avoid having to specify explicit column/row counts as much as possible for direct table editing. Let's say I input a region with cells (a, b, c, d)(e, f, g, h) - that's 2 x 4 and I don't need to tell the function the size of the region is 2 x 4, hopefully.
With row oriented editing, table(row[A, B], row[A, B, C]) would be a perfectly fine table and it implicitly has 2 rows and 3 columns, that's how I'm thinking about it. (Taking some syntax shortcuts here, if it's table.row[A][B] or something else is a separate issue)

[robust viper]

Note that a region could also contains rows. I think I would add all of region and row and column.

[vagrant pagoda]

aha. I was also asking because I don't have the context. I'm just trying to gather understanding - is there a model that you're thinking of how this works, maybe from a prior dicussion. For example about implicit vs explicit positions and sizes (row and column count)

Another thing. I'm also making experiments with "setrow/setcol" directives. Also a little bit inspired from tabularray (thought it is a deprecated syntax there).

It looks something like this - inserting directives to color specfic rows:

#show table: setrowrules
#rowtable(
  stroke: (x: 1pt, y: 0pt),
  [Alpha & Beta & Gamma #setrow(cyan)],
  [Epsilon & Zeta & Eta #setrow(aqua)],
  [Iota & Kappa & Lambda #setrow(violet.lighten(50%))],
)

On it's own it's a bit meh, but it has a benefit that we again put the row style physically in the row it should affect, sometimes that's good.
It's also meh because in a table.row world this could just be table.row([...], fill: cyan) but there is more.. (Also but: We can't have both table.row and table.column at the same time; but we can easily do insersecting setrow and setcol at the same time)
