Download map as a PNG file | xyflow | Page 1

candid laurel Jun 9, 2023, 10:21 AM

#

Hello everyone, I'm using an example from the documentation that describes downloading a map as a PNG image. My problem is that the map sizes will dynamically expand based on user actions. The map will also grow to very large dimensions, causing not all nodes on the map to fit within it. Is there a way to modify the example in the documentation to make it more scalable?

https://reactflow.dev/docs/examples/misc/download-image/

Download Image Example - React Flow

This example shows how to download a flow as an image with html-to-image.

flint cloud Jun 12, 2023, 7:50 AM

#

you can make a screenshot of ".react-flow__viewport" and use the style option https://github.com/bubkoo/html-to-image#style to reset the transform (style: transform: "translate(0,0) scale(1)")

GitHub

GitHub - bubkoo/html-to-image: ✂️ Generates an image from a DOM nod...

✂️ Generates an image from a DOM node using HTML5 canvas and SVG. - GitHub - bubkoo/html-to-image: ✂️ Generates an image from a DOM node using HTML5 canvas and SVG.

candid laurel Jun 13, 2023, 10:44 AM

#

Not sure if I've got that one right but with this code: ``` import { toPng } from 'html-to-image';
import { ReactComponent as PrinterIcon } from '@/assets/icons/print.svg';
import styles from '@/components/Header/PrintButton/PrintButton.module.scss';

const downloadImage = (dataUrl: string) => {
const a = document.createElement('a');
a.setAttribute('download', 'relationship-map.png');
a.setAttribute('href', dataUrl);
a.click();
};

const PrintButton = () => {
const handleOnClick = () => {
toPng(document.querySelector('.react-flow__viewport') as HTMLElement, {
backgroundColor: '#ebedf1',
style: {
transform: 'translate(0,0) scale(1)',
},
}).then(downloadImage);
};

return (
<button onClick={handleOnClick} className={styles.button}>
<PrinterIcon className={styles.icon} />
</button>
);
};

export default PrintButton;

flint cloud Jun 16, 2023, 6:35 AM

#

ah, maybe you need to zoom out a bit

#

getRectOfNodes -> getTransformForBounds -> use the returned transform for the passed style.transform value

candid laurel Jun 16, 2023, 2:47 PM

#

It seems to me that you did the same thing as in the example in the documentation? Did I miss any differences? When implementing the code from the documentation, the situation was very similar, and it also trimmed some of the nodes.

#

So I did something like this: ``` import { toPng } from 'html-to-image';
import { getRectOfNodes, getTransformForBounds, useReactFlow } from 'reactflow';
import { ReactComponent as PrinterIcon } from '@/assets/icons/print.svg';
import styles from '@/components/Header/PrintButton/PrintButton.module.scss';

const downloadImage = (dataUrl: string) => {
const a = document.createElement('a');
a.setAttribute('download', 'relationship-map.png');
a.setAttribute('href', dataUrl);
a.click();
};

const PrintButton = () => {
const { getNodes } = useReactFlow();

const handleOnClick = () => {
const imageWidth = window.innerWidth;
const imageHeight = window.innerHeight;
const nodesBounds = getRectOfNodes(getNodes());
const transform = getTransformForBounds(nodesBounds, imageWidth, imageHeight, 0.5, 1);

toPng(document.querySelector('.react-flow__viewport') as HTMLElement, {
  backgroundColor: '#ebedf1',
  style: {
    transform: `translate(${transform[0]}px, ${transform[1]}px) scale(${transform[2]})`,
  },
}).then(downloadImage);

};

return (
<button onClick={handleOnClick} className={styles.button}>
<PrinterIcon className={styles.icon} />
</button>
);
};

export default PrintButton;

flint cloud Jun 16, 2023, 3:15 PM

#

Maybe you need to set minZoom to 0.1 instead of 0.5

#

getTransformForBounds(nodesBounds, imageWidth, imageHeight, 0.1, 1);

candid laurel Jun 19, 2023, 9:08 AM

#

But with setting it to 0.1 the image will come out very blurry.

flint cloud Jun 19, 2023, 9:10 AM

#

then you need to increase width and height https://github.com/bubkoo/html-to-image#width-height

candid laurel Jun 19, 2023, 9:11 AM

#

Is there a way to increase it by the value which is dependent on flow viewport dimensions?

#

So basically, the image width and image height would scale based on the dimensions of the map itself.

flint cloud Jun 19, 2023, 9:14 AM

#

you can get the dimensions from the viewport and multiply it with 2, 4 ,8 whatever works for you

#

const domRect = document.querySelector('.react-flow').getBoundingClientRect();

candid laurel Jun 19, 2023, 12:26 PM

#

We are getting somewhere with this. 😄

#

import { getRectOfNodes, getTransformForBounds, useReactFlow } from 'reactflow';
import { ReactComponent as PrinterIcon } from '@/assets/icons/print.svg';
import styles from '@/components/Header/PrintButton/PrintButton.module.scss';

const downloadImage = (dataUrl: string) => {
  const a = document.createElement('a');
  a.setAttribute('download', 'relationship-map.png');
  a.setAttribute('href', dataUrl);
  a.click();
};

const multipler = 4;
const PrintButton = () => {
  const { getNodes } = useReactFlow();

  const handleOnClick = () => {
    const domRect = document.querySelector('.react-flow')!.getBoundingClientRect();
    const nodesBounds = getRectOfNodes(getNodes());

    const imageWidth = domRect.width * multipler;
    const imageHeight = domRect.height * multipler;
    const transform = getTransformForBounds(nodesBounds, imageWidth, imageHeight, 0.2, 1);

    toPng(document.querySelector('.react-flow__viewport') as HTMLElement, {
      backgroundColor: '#ebedf1',
      width: domRect.width * multipler,
      height: domRect.height * multipler,
      style: {
        transform: `translate(${transform[0]}px, ${transform[1]}px) scale(${transform[2]})`,
      },
    }).then(downloadImage);
  };

  return (
    <button onClick={handleOnClick} className={styles.button}>
      <PrinterIcon className={styles.icon} />
    </button>
  );
};

export default PrintButton;
