#Blursed ECS (Entity-Component System)

1 messages · Page 1 of 1 (latest)

kind elm
#

I am incredibly unconfident in the viability of this concept, especially for a production codebase. It seems useful, but my instincts are tingling.

I would love feedback and discussion on if this is a good/bad idea, and what potential pitfalls there are in my implementation. Or, any alternative solutions that already exist.

I will continue to develop it regardless, for my own use and especially if there is interest from others.

#

There is the v0.1.0-alpha version, should be fully working, but mostly untested and limited features.

marsh fossil
#

hmm... this could be just a "me" thing, but i'm very much Not A Fan of using macros to create custom syntax

#

here some if it seems to be for the purpose of ensuring the system is created properly, which is... fine, i guess, but the bulk of it just seems to be for the purpose of... letting the user ignore invoking the constructor themselves?

kind elm
#

That is entirely fair. I don't like it either.
In this case yeah it's just for the setup stuff, and might be overkill.

marsh fossil
#

this is 99.99% identical to "function example() constructor {" at the cost of forcing the user to deal with red feather pen on every line, and learning a custom syntax

modern harbor
#

I agree I am also not a fan of that kind of thing

#

it is confusing and introduces a learning curve that isn't justified

kind elm
#

I was going through hoops to avoid the user needing to define components across more than one file.

#

But the Component itself is simple and provided by the constructor, so a less macromagic syntax is probably possible.

modern harbor
#

It is more readable though if they are organized into separate files

#

and they are more intentional

kind elm
#

Yes yes.

#

I want each Component in a separate file, yes. I don't want to have to also go to the "define_all_components" function and list it in there so it can be defined when the game starts.

#

This is partly only an issue because I like them having a "namespace" provided by COMPONENT.

#

Mmmm, actually I think I can do that inside the constructor too. Let me grab lunch then I'll try to rewrite it.

#

Final syntax might be better as:
(name would have to be a string instead, but can still make a variable out of that internally to avoid lookup after initialization)js with (new Component("example")) { INIT = function() { } //etc }Still in a script?

#

Or a helper function like:

define_component("example",
function() { /*INIT...*/ },
function() { /*STEP...*/ },
//etc```
marsh fossil
#

that could work jsut as well

kind elm
#

I will make adjustments.
Any thoughts about the concept itself, syntax aside?

modern harbor
#

hmm

kind elm
#

Okay syntax looks like this now:```js
with (new Component("example"))
{
INIT = function()
{
my_string = "Hello world!";
is_activated = false;
}

STEP = function()
{
    if (!is_activated)
    {
        show_debug_message(my_string);
        is_activated = true;
    }
}

DRAW = function()
{
    draw_text(x, y, my_string);
}

}``` (Or any sensible variation on it).
I will probably add a helper function too.

#

I also changed the COMPONENT namespace instance for a macro COMPONENT that references a global variable struct instead.

#

I have a concern though, is it not possible that depending on the order the scripts are compiled the Component definition might happen before the Component constructor is defined? I seem to remember running into that before, which is part of where those magic macros originated from.

#

If I'm right, then the only safe way I know without using magic macros is wrapping it up in a second function and manually calling it at the start of the game, like ```js
function init_component_example()
{
with (new Component("example")) { ... }
}

//Then later...
function init_game()
{
init_component_example();
}

#

This I am trying to avoid, but maybe it's better to have users write their own magic macros if they care. Is there a better solution, or am I imaginging this issue?

#

Ah wait, I can do the same thing I do for COMPONENT with Component() constructor.
EDIT: No, that just introduces the same bug w/ one more layer.

kind elm
#

Can now do this in an initialization function. js define_component("example", function() { my_string = "Hello world!"; is_activated = false; }, function() { if (!is_activated) { show_debug_message(my_string); is_activated = true; } }, function() { draw_text(x, y, my_string); });
Or alternatively, use ECS_DEFINE and ECS_DEFINE_END macros to define the Components within a global script instead. I added an error message in case the user attempts to do an unsafe definition without the macros.

ECS_DEFINE
define_component("example", ...);
ECS_DEFINE_END
#

But the macros are optional now, and even if you use the macros it's much simpler than before.

modern harbor
#

I think I like that approach far better

kind elm
#

Me too. 👍

#

Thanks for the feedback.

#

Here is updated version.
I will update the documentation for new syntax, then I'll continue to work on more features until it's properly completed.

📎 Blursed_ECS_v0_2_0.yymps
kind elm
#

The Blursed ECS is no longer cursed.
I got everything narrowed down to a single constructor, you don't even need to call an initialization script.

#

Still working out methods and documentation, but a sort-of-final release will be ready soon (this weekend hopefully). Then I will use it for a while in my new project (which is what I made it for) and fix issues for a while until I'm confident it's good.

#
new Component("SayHello")
.add_event("INIT",    function()
{
    my_message = "Hello!";
    is_activated = false;
})
.add_event("STEP", function()
{
    if (!is_activated)
    {
        show_debug_message(my_message);
        is_activated = true;
    }
});```
#

Newest syntax

kind elm
#

Alpha v0.3.0 release done with finished definition syntax (which boils down to: use the constructor provided). Also added a few helper functions, most notably component_remove so you can add and remove Components at runtime. README has updated documentation but it's a bit lazy since I wrote it fast.

I will be using this system in my newest project, as a stress test (and because that is the reason I made this in the first place). There will possibly be future updates once I figure out what changes need to be made for that project.

📎 Blursed_ECS_v0_3_0.yymps
