lusty terrace
Hello, I've tried following the instructions to add RGB underglow to my shield, the firmware compiles fine, but I can't get the LED to light up. What am I doing wrong?
Here my github repo: https://github.com/oOJoshOo/zmk-config-poldkey/actions/runs/7837358100
wicked notch
First, remove space after comma in https://github.com/oOJoshOo/zmk-config-poldkey/blob/master/config/boards/shields/PoldKey/Kconfig.shield#L2
Second, these CONFIG_* need to go in PoldKey.conf, not this file https://github.com/oOJoshOo/zmk-config-poldkey/blob/master/config/boards/shields/PoldKey/Kconfig.defconfig#L8
<NRF_PSEL(SPIM_MOSI, 3, 2)>; doesn't make any sense here https://github.com/oOJoshOo/zmk-config-poldkey/blob/master/config/boards/shields/PoldKey/boards/nice_nano_v2.overlay#L6
What pin are you connecting to?
lusty terrace
0.32
i know that thats a slow one wich is not good for BT Performance but i dont use BT
wicked notch
I don't see it here https://nicekeyboards.com/docs/nice-nano/pinout-schematic/
Do you mean p1.00?
lusty terrace
uff jeah its actually 0.31 it was late yesterday 😄
lusty terrace
ok is that all should i try now?
wicked notch
This and the other two at the top, yeah
lusty terrace
ok thank you very much i will try
