viral grove
#

That's a good compromise imo. The only thing I am worried about with dynamic nodes is doing dynamic memory allocs; don't know how that is handled and they should never be done on the audio thread so I'm not sure how to do it correctly in Firewheel

slate scarab
#

So you can do arbitrary allocation during construction. Since the channels are typically provided in the Configuration structs, it wouldn't really be possible to accidentally allocate later.

viral grove
#

Oh, alright! So we also constrain channel count and max order to the construction right? Changing them after construction shouldn't be necessary?

slate scarab
#

Yeah no need to change afterwards

dusky mirage
#

I've talked to someone in an audio DSP server, and they taught me that there are two kinds of bandstop filters typically used when oversampling. Polyphase IIR filters (like what the valib library is using) have better performance, but they have the drawback of phasing issues if you want to implement a wet/dry mix parameter. The second are linear phase filters, which are more expensive but don't have the same phasing issues.

viral grove
#

I see. I guess implementing both would be best in that case

#

I have done the linear phase filters previously

oak walrus
#

lol my code in the wild getting referenced

#

Polyphase oversampling is kinda neat, because it downsamples in stages, it can really easily do 32x by upsampling 5 times (each stage oversamples by 2). The filter itself I found to have a very sharp transition, but you are limited by powers of two in terms of the amount

dusky mirage
oak walrus
#

I should also mention that this is a Rust port of the polyphase filter found on MusicDSP

#

That being said I don't expect much non-linear effects being used in typical game audio processing

#

You could oversample a compressor or limiter, but they don't need crazy oversampling, so something as simple as a 17- or 31-tap sinc filter might do the trick

dusky mirage
#

Yeah, that is a good point. It would probably make more sense to just have 3rd party node authors do their own oversampling.

oak walrus
#

or even cubic interpolation

viral grove
#

Are there any practical use cases for oversampling other than heavy distortion (and maybe intersample peak limiting)? I find aliasing to be so minimal, especially in compressors

dusky mirage
viral grove
#

I mean, I know many effects implement them but I found them to not be necessary most of the times

oak walrus
#

"sinc filter" because the sinc function is what you get from doing the Fourier Transform on a "gate" function (1 within an interval centered on 0, and 0 everywhere else)

viral grove
oak walrus
#

so you sample a sinc function with the right parameter to make it correspond to the brickwall low-pass filter (represented by the gate function in the frequency domain) and that gives you the FIR filter you need to apply

dusky mirage
#

Also, the person on that other server gave some advice on how this is usually implemented without the need for zero-stuffing:

Let's say you're upsampling by x4. With polyphase IIR, you have four different IIRs with four different states
And for each input sample, you calculate one output from each of them
And that's your four output samples.
With FIRs, it's the same thing: you'll have four different FIRs with four different kernels. Since FIRs aren't stateful, they can share the same input buffer and so on, but effectively it's four different filters.
When you work it out, your four filters end up being "delay by 1/4 sample", "delay by 2/4 sample", etc.
So depending how you design your filters, you might be able to skip one of them, since it'll be "delay by 0 samples"

oak walrus
#

The problem being (as @viral grove ninja'd me about) that sinc oscillates indefinitely, so you can't actually have a perfect sinc filter, you need a trick to get a realizable FIR filter, ie. truncating, windowing (truncating is technically a windowing method), all with their own tradeoffs, etc.

dusky mirage
viral grove
dusky mirage
viral grove
#

Ah interesting

dusky mirage
#

If you want to get fancy, you can also add a comb filter to get that "talking into a cup" sound.

viral grove
#

If the distortion is just some wave shaping then aliasing can be mitigated somewhat without explicit oversampling. There's a paper from some NI guy iirc and it works really well. Only introduces 0,5 to 1 samples of latency as well

viral grove
dusky mirage
#

Comb filters are pretty easy. You literally just mix a signal with a slightly delayed version of itself.

#

And you use an interpolator if you want to delay by sub-sample amounts.

viral grove
#

I'm guessing the quality of the interpolator dictates the quality of the comb filter in case of fractional samples

dusky mirage
#

Correct. And there are of course more advanced ways to do it (like using an allpass to delay different frequencies by different amounts).

viral grove
#

Interesting

dusky mirage
#

The world of sound design is wild.

#

Reverb algorithms also usually make use of allpass filters. You use a bunch of allpass filters to "smear" the phase of different frequencies to get a "washy" sound.

viral grove
#

Yeah, I've recently looked at some open source reverb implementations and it's very interesting

#

Btw are you okay if I add some "dynamic" nodes if people need more flexibility with channel setup and use the static nodes with const generics for the most common setups guaranteeing performance?

dusky mirage
#

It's also why cheap reverb algorithms tend to sound "metallic". It's because a bunch of allpasses literally creates a comb filter.

dusky mirage
viral grove
dusky mirage
#

Oh wait, he's using FM to get the metallic sound. I must be thinking of a different video.

#

Oh OK, he does use comb filters later in the video.

viral grove
#

Au5 is a beast

tender fiber
#

The CPU cycle is more expensive than thee expensive algorithm.

dusky mirage
drowsy dome
#

edit 3: nice actually

slate scarab
#

Could we also have samplers provide a similarly adjusted clock?

dusky mirage
celest whale
dusky mirage
#

Hmm, I'm trying to decide if the internal sample clock should account for output underflows or not.

(An output underflow occurs when the CPU takes too long to fill an audio buffer, leading to audio frames being skipped. Ideally output underflows should be rare or even nonexistant, but it still probably needs to be dealt with.)

If we don't have the sample clock account for it, then underflows will cause any scheduled events to occur later than expected and also cause any playing samples to finish later than expected.

If we do have the sample clock account for it, then we would also need to add extra logic to samplers and such to skip ahead to the correct time when an underflow occurs. That could be done, but I'm not sure we want to add that extra complexity (and to have other users deal with that complexity when making their own sampler-based nodes).

slate scarab
#

Hm yeah that’s tricky. I would be tempted to consider underflows such a degenerate state that accounting for them in timings isn’t necessary.

Then again, if audio scheduling is really important in your app, you’d potentially get a whole cascade of errors from a single underflow event.

dusky mirage
#

Though ideally you should be syncing your game to the audio clock anyway if timing is important.

slate scarab
#

Ah, right. I see.

viral grove
#

I am kind of stuck with the redesign of the filter nodes. I have it like this at the moment:

pub struct ConstChannelFilterNode<const NUM_CHANNELS: usize, const MAX_ORDER: usize = DB_OCT_24> {
    pub spec: FilterSpec,
}

pub enum FilterSpec {
    Lowpass {
        order: FilterOrder,
        cutoff_hz: f32,
        q: f32,
    },
    // snip
    Bell {
        center_hz: f32,
        q: f32,
        gain_db: f32,
    },
    // snip
}

I did it like this because

  1. ...it feels natural to tie them together.
  2. ...not all parameters make sense for all filter types. E.g. gain_db is nonsensical for Lowpass.

But now I cannot even make a UI node because I need to borrow spec twice, once for changing the type of the filter and once for modifying its parameters which makes total sense. How would one usually solve this? Sorry for the basic question, I am stumped on how to solve this.

slate scarab
#

This is for the node graph UI example right? Is there anything wrong with borrowing it twice? egui is immediate-mode, so is there any issue with multiple successive mutable borrows? (I'm probably just not understanding the issue, though.)

dusky mirage
slate scarab
#

I'd argue that's not very idiomatic Rust, personally -- I think that's a holdover from many languages that

#

can't easily represent the state fully accurately, at least not without workarounds.

viral grove
# slate scarab This is for the node graph UI example right? Is there anything wrong with borrow...

I explained it poorly, I need to borrow the enum variant as well as the fields:

GuiAudioNode::Filter { id, params } => match &mut params.spec {
    FilterSpec::Lowpass {
        order,
        cutoff_hz,
        q,
    } => {
        ui.vertical(|ui| {
            // radio button to switch filter type
            ui.radio_value(
                &mut params.spec,
                FilterSpec::Lowpass {
                    order: 1,
                    cutoff_hz: 440.,
                    q: 1.,
                },
                "Lowpass",
            );
            // snip (more radio buttons)
            // cannot mutably borrow order, since params.spec is already mutably borrowed
            ui.add(egui::Slider::new(order, 1..=16).text("Order"));
            // snip (more parameters)
        })
    }
}
dusky mirage
slate scarab
#

Lots of plugins have contextual UIs though -- the number and arrangement of parameter may change depending on other settings. Like this LFO in serum (different set of parameters on the right).

Screenshot_2025-06-21_at_10.57.46_PM.png Screenshot_2025-06-21_at_10.57.52_PM.png
viral grove
#

I agree, but for an EQ plugin for example, the labelling or number of knobs may change depending on the filter type, hiding this from the user. In our case the users will be directly interacting with the node itself. (basically what Corvus said above)

slate scarab
#

And then match on it mutably to handle the inner parameters.

viral grove
#

I can try. I honestly have no experience with egui, I just tried to make sense of it from the other examples. Couldn't find a dropdown widget when I first looked

slate scarab
viral grove
#

Thanks! Will try that!

dusky mirage
slate scarab
#

It definitely depends on if you need to persist the old values -- for example, switching between modes while still maintaining what the old values were.

#

In that case, the underlying representation in the UI definitely couldn't be an enum.

#

I think that probably doesn't apply here though -- if people want to build a front-end for a combined filter node, they can store the old values separate from what the actual variant holds.

tender fiber
#

With egui 7 million downloads, egui … why not?

wary bridge
dusky mirage
#

I've ended up being busy with other things things weekend, but I've got a bit more progress done today. The audio clock no longer tries to automatically correct for output underflows. This makes things simpler.

viral grove
# slate scarab It is a little annoying to do by hand though in this case. Could you make a dro...

I was busy but tried this approach now. If I understand correctly, I just add some additional field on my node like this:

pub struct ConstChannelFilterNode<...> {
    pub type_selector: FilterType,    // holds just the bare filter type, e.g. FilterType::Lowpass
    pub spec: FilterSpec,             // holds both the filter type and the parameters, e.g. FilterType::Lowpass { ... }
}

Then I can have a dropdown for type_selector and customized widgets for each variant of spec.

GuiAudioNode::Filter { id, params } => {
    // Dropdown menu
    ComboBox::from_label("Filter Type").show_ui(ui, |ui| {
        ui.selectable_value(&mut params.type_selector, FilterType::Lowpass, "Lowpass");
        // snip (other dropdown values)
    });
    // Custom sliders for each filter type
    match &mut params.spec {
        FilterSpec::Lowpass {
            order,
            cutoff_hz,
            q,
        } => {
            // widgets for lowpass type
        }
        // snip (other filter specs, e.g. Highpass)
    }
}

So when I get an event for type_selector in my audio node, I also need to set spec to the new type such that the UI can update.

ConstChannelFilterNodePatch::TypeSelector(type_selector) => {
    // save new type selector
    self.params.type_selector = type_selector;

    // change spec so UI understands it should render different widgets
    match type_selector {
        FilterType::Lowpass => {
            self.params.spec = FilterSpec::Lowpass {
                order: 1,
                cutoff_hz: 440.,
                q: 1.,
            };
        }
        // snip (other filter specs, e.g. Highpass)
    }
}

But the UI does not update, not sure why. Did you intend this or did I misunderstand?

#

Sorry for the wall of text

slate scarab
# viral grove I was busy but tried this approach now. If I understand correctly, I just add so...

Oh, sorry -- I might not have been super clear!

Personally, I'd just have the FilterSpec be the only field in the filter node. That way, using it in a code-driven environment maintains correctness and ease of use.

When you're working with it in an egui context, though, I'd just make a totally ad-hoc dropdown element. When it changes, you can match on the new name and construct the new FilterSpec variant however you like.

Then, beneath that, you can match on the variant itself and manage the inner parameters with egui.

#

In other words, I wouldn't adjust the structure of the filter enum or node so that you can pass it directly to egui.

#

Does that make any sense? Let me know if I'm misunderstanding.

#

As for this

So when I get an event for type_selector in my audio node, I also need to set spec to the new type such that the UI can update.

If I understand what you're suggesting correctly -- anything you do in the audio node with regards to the events or the parameter values is not bi-directional. The UI will receive no information about changes to the FilterSpec that happen in the audio node. Only changes in the UI will be communicated to the audio node.

viral grove
viral grove
viral grove
slate scarab
#

Ah, I think I see the problem. There's nothing "sticking around" to keep track of what the current variant is (except the FilterSpec itself).

Here's roughly what I would do -- a touch annoying maybe, but it should work:

let initial_variant = match params.spec {
    FilterSpec::LowPass => "Low-pass",
    // ...
};
let mut new_variant = initial_variant.to_owned();

ComboBox::from_label("Filter Type").show_ui(ui, |ui| {
        ui.selectable_value(&mut new_variant, "Low-pass".into(), "Low-pass");
        // snip (other dropdown values)
    });

if new_variant != initial_variant {
    // here's where you change the variants
    match new_variant.as_str() {
        "Low-pass" => { /* */ },
        // ...
    }
}

// THEN you can just match on the whole enum and modify the inner values
#

That is, turn the current variant into a string, create a dropdown that can select between the variants (including the current value), then update the enum if the string has changed.

faint wigeon
#

are Diff and Patch bi-directional? aka are updates to a param from a node reflected in the ecs?

slate scarab
#

To get information back, there are other mechanisms available

#

Diff, while pretty efficient, is still quite a bit slower than Patch. Diff can also allocate, so as-is it's not a great way to send events from audio nodes to the ECS.

faint wigeon
#

is there a sanctioned pattern atm?

viral grove
slate scarab
#

The reasons for this approach are mainly:

  1. In certain circumstances, we'll want to be able to store state somewhere that is !Send, like plugin types, FFI-related state, etc.

  2. It allows us to maintain separation between a node's parameters (the type that implements Diff and Patch) and any other bits of state. Parameters that are perfectly stateless, i.e. contain no shared atomics or other synchronization primitives, are very convenient. We can throw them around wherever in the ECS without worrying about its provenance, essentially. They can be constructed on the fly or cloned without concern.

faint wigeon
#

yup okay that makes sense

slate scarab
#

In a lot of cases you can just clone the state out of the audio context and insert it into the ECS, so we might set up a more convenient way to do that in bevy_seedling. In most cases it could be automatic.

faint wigeon
#

trying to get up to speed here quickly this is my first time actually digging into these apis (:

#

i guess for context i should say -- for creative tech stuff we really care much more about input than your average game. i'm happy to help contribute here. it seems like custom state is intended primarily for node local !Send stuff?

#

kinda want the opposite

#

or rather, not to have the constraint of accessing state from a non send ecs system

slate scarab
#
fn access(mut context: ResMut<AudioContext>) -> Result {
    let state = context.with(|context| {
        context.node_state::<SamplerState>(/* node id from somwhere */)
    }).ok_or("missing state!")?;

    // ...
}
#

I honestly expected the removal of !Send resources and other types to happen a bit quicker, so I borrowed the closure-sending idea from an older PR. On Wasm, this just runs in place, but in a multi-threaded environment, the closure is sent to the context's thread.

slate scarab
slate scarab
#

The dance of constructing a node, then getting its state out of the audio context is a little annoying. But it definitely helps overall correctness, at least for bevy_seedling.

faint wigeon
slate scarab
#

Awesome! Definitely let me know if you run into any problems or things are unclear.

faint wigeon
#

this all looks so incredbile and such a step up from existing bevy-audio and raw cpal

#

one thing that comes to mind is that it would be nice to have all the cpal metadata as components in the ecs. it looks like right now SeedlingPlugin constructs a AudioContext resource in it's plugin configuration but it might be nice to shift that to ecs startup so that users could dynamically query available cpal devices, etc

slate scarab
#

Yes that's probably the right move. Right now the I/O situation is not very robust.

faint wigeon
#

we have the same issue in rendering with e.g. monitor selection, etc. i'm always thinking about what a settings menu would look like. nbd for now though (:

slate scarab
#

Yeah we'll also need to think about dynamically updating I/O and potentially re-initializing the stream.

viral grove
#

It works now. Thanks so much for your help, Corvus 🙂

#

I have also added a comment on my PR, summarizing my changes

#

Maybe you have some input on better names for the two nodes (ConstChannelFilterNode and FlexibleChannelFilterNode)

#

Otherwise I am happy with the API now

slate scarab
#

Oh I do have an opinion! I always try to maximize ergonomics for the most common use cases. In this case, I think we expect people writing code by hand to use the const generics nodes more often. In that case, I would just name it FilterNode. Then, for the dynamic case, I'd personally shorten it to just DynamicFilterNode.

Maybe merely Dynamic doesn't fully communicate how it's dynamic, but it's probably enough to effectively distinguish it from const filter node.

viral grove
#

Awesome, thanks for the input!

#

I am only a bit unsure about "dynamic" because there are such things as dynamic filters that change their parameters based on the input. I don't think it's typical to call them "dynamic filters" but "dynamic eq" is definitely a thing

slate scarab
#

Hm, right

#

Maybe Runtime? Is that crazy?

viral grove
#

That could work

oak walrus
viral grove
oak walrus
#

I've been thinking and I couldn't find anything though haha

#

It's even harder because we're talking about the specific fact of being able to provide the channel count at compile-time vs. runtime, but it doesn't mean that for the latter you can necessarily change the channel count once instantiated

viral grove
#

Good point

tender fiber
#

VariableChannelFilterNode?

#

off-topic egui Sorry.

#

ModularChannelFilterNode?

viral grove
#

I think having the word "Channel" in it would make it more explicit but also longer. It feels like there doesn't exist a perfect name. I think something like FlexChannelFilterNode would at least emphasize that it is more flexible in its channels in some way. Personally, I think that using Runtime as a prefix may make it sound like FilterNode is just some compile time / const fn thing. Though it is definitely more concise.

slate scarab
#

FlexChannelFilterNode is probably fine -- people can always create an alias if they don't like it

faint wigeon
#

do we have a criteria for the mvp of upstreaming this work into bevy?

celest whale
steep dove
#

The bar for "better than current" is pretty low

celest whale
wary bridge
#

I read through all of bevy_seedling's docs the other day and I am interested in seeing it replace bevy_audio

#

might want to either update the pinned message or write a new pin btw

faint wigeon
#

the quality of the code is also very high in terms of documentation

steep dove
#

agreed, and there are a reasonable number of examples and tests

#

I'm envious of your main crate doc

tender fiber
#

This is awesome!

steep dove
#

I guess the obvius questions for @slate scarab are (a) would you want to upstream this into bevy as bevy_audio and (b) what do you think needs to happen before we do that? Can you give me a rough percentage the of bevy_audio features this supports?

faint wigeon
#

yes sorry i should have not assumed at all @slate scarab wanted to do that

dusky mirage
#

I'm currently in the process of reworking the timing system which will introduce some breaking changes, so I'd like to get that done first before merging into bevy.

#

I'll try to get that all done tomorrow.

celest whale
slate scarab
# steep dove I guess the obvius questions for <@164224139316428800> are (a) would you want to...

(a) My idea behind the bevy_seedling name was that, by the time the library sprouted into a little firewheel flower, it would be upstreamed as bevy_audio!

I suppose my only concern is the degree to which an upstreamed Bevy crate can be opinionated. I have lots of big ideas! I'd love to provide first-party support for sophisticated audio implementations similar to Fmod or Wwise. I'd also like to get a node graph editor going once Bevy's editor is off the ground. There's also a lot of little things we could add here and there.

(b) Essentially 100%. There's nothing major I'm aware of that bevy_audio has which bevy_seedling does not. bevy_audio's spatial playback does support ear positioning, which Firewheel's basic spatial node doesn't, but that's the only thing that stands out to me.

The main design challenge remaining is a robust parameter animation system. I'd like to use bevy_animation if possible, but I haven't done a deep enough dive yet to assess whether it has what we'd need for audio. I discussed a bit of that here #art-audio-animation message.

I don't feel that the crate is totally complete without parameter animation of some kind, but it doesn't necessarily block upstreaming.

celest whale
#

I suppose my only concern is the degree to which an upstreamed Bevy crate can be opinionated. I have lots of big ideas! I'd love to provide first-party support for sophisticated audio implementations similar to Fmod or Wwise.
I'm very open to this sort of thing 🙂

#

As long as the easy things are easy, I'm happy to support more complex uses

steep dove
#

The main design challenge remaining is a robust parameter animation system.

If the current audio crate can't be animated, and I don't beleive it can be, then this isn't something I'd want to block upstreaming on.

#

It seems like we should probably ping cart for an evaluation, once his workload clears up a bit.

#

Because it sounds like this is more or less ready now.

celest whale
steep dove
slate scarab
#

The demo scope is small, so I should be able to build something sufficient very soon.

viral grove
#

@dusky mirage just fyi, the filter PR would be ready from my side

dusky mirage
dusky mirage
slate scarab
# dusky mirage The new timing system is now almost done, I just need to add one more thing. Let...

This seems great! I don't think I'll be able to provide much useful feedback until I start using it, but it seems like it'll be very helpful.

I do have one request -- as you update the audio clocking stuff for sampler nodes, would it be possible to express the playback start time as an absolute time (in ClockSeconds) instead of as a delay? I'm sure that would make it more complicated in cases where the start time is actually "in the past," but it would be super helpful in the context of Bevy.

In general, when you queue a sample for playback, you don't actually know how long it'll take to load it. So the delay given to a node might become inaccurate if it takes too long to load the sample into memory. However, if it were absolute time, that would be no problem!

dusky mirage
slate scarab
#

What happens currently if the delay is back in time?

dusky mirage
#

The event just happens on the first frame in the processing block. It would actually be fairly simple to allow a sample to "play in the past". I'll work on that in another PR.

slate scarab
dusky mirage
#

Actually, it turns out using a triple buffer to do the same technique for the sampler node is a bit tricky due to the way node constructors work.

So instead, I've just added a much simpler method to FirewheelCtx that just returns the instant the audio clock was last updated. The user can use this to correct for the delay for the playhead in the sampler node using SamplerState::playhead_frames_corrected() or SamplerState::playhead_seconds_corrected().

It's not as accurate as it would be with the triple buffer technique, but it should be good enough to get a rough idea.

slate scarab
#

alas
well we can dress that up in a nice API in bevy_seedling at the very least

tender fiber
#

I like firewheel cli path

#

And sound bam

slate scarab
#

btw @dusky mirage is there a way to change input / output devices once a stream has started? if not, do you think adding it would be tricky?

dusky mirage
#

Doing that "seamlessly" is incredibly tricky, but you can stop the current stream and start a new one.

#

Practically the only way to do it seamlessly is to spin up your own audio thread that passes samples back and forth with the OS's audio threads. This will introduce extra latency.

slate scarab
#

Hm, okay I'll update bevy_seedling to support that. The processor isn't lost, right? It'll just be transferred over and the new_stream method will be called on all the nodes, right?

dusky mirage
#

Correct, the processor is reused across streams.

slate scarab
#

What do you think we should do for the sample assets if the sample rates change? Right now they're resampled on creation, so I think they'd just.... still be the old sample rate in all the sampler node processors.

#

Oh looks like you recommend reloading them in the implementation.

dusky mirage
#

Yeah, that's a tricky one to do seamlessly. Ideally you should just avoid changing the audio output device in the middle of a game.

slate scarab
#

But since bevy_seedling has full control over the process, we could just save the state of all the samplers, then change the stream, then restore that state with the newly loaded assets. Obviously that'll be noticeable, but maybe not too bad since you don't frequently change devices.

dusky mirage
#

And most modern audio devices support both 44100Hz and 48000Hz anyway, so it's very rare that changing the audio output device will change the sample rate.

slate scarab
dusky mirage
#

Yeah, things definitely would have been simpler if the industry settled on 48000Hz as a universal standard.

#

Or 44100Hz as the standard.

#

I can't remember what the history is behind those two standards. I guess it's something to look up.

#

Both have a nyquist frequency well above the human limit of hearing, so there's very little if any quality difference between them.

slate scarab
#

maybe cd folks wanted to maximize the amount of audio they could stuff on there

oak walrus
#

(I only need to do it in CoreAudio because of the way the Rust bindings are setup, other backends I can directly get it back because I own the audio thread so I can decide to stop it and return the processor back through the thread::JoinHandle)

oak walrus
#

Also didn't take 40 kHz straight because they took into account the transition band of the lowpass filter placed at 20 kHz

#

48 kHz for DVD was because all that and also the fact it's divisible by 24, which makes synchronizing with video frames easy

#

therefore video now has a standard of 48 kHz, but audio is on 44.1 kHz

slate scarab
#

Hm, @limpid river you added web_time to bevy_platform right? Or were at least involved I think?

I'm running into a bit of a problem with it:

The implementation of Instant::now() relies on the availability of the Performance object, a lack thereof will cause a panic. This can happen if called from a worklet.

With the upcoming changes to Firewheel's clocking, this is actually a huge problem! The Web Audio API backend I made for it, which runs directly inside an audio worklet using multi-threading, is now panicking whenever Instant::now is called.

I'm not sure what the best way forward is. I might be able to trick web_time by creating a JS object that looks like the global context -- not totally sure. To be honest, I'm not even sure it's possible to get any kind of system time with decent accuracy that aligns with the main browser thread. I'm fairly sure the currentTime value in the audio worklet context starts from zero when the context is created, so that can't be used to compare any kind of Duration against the main thread's Performance.now.

#

Let me know if you have any thoughts!

#

If this is not reconcilable, we might have to adjust Firewheel to use a special AudioInstant or something. In general, it could use bevy_platform::time::Instant, and in multi-threaded web contexts, we'd have to do something a little more bespoke.

#

Alternatively, @dusky mirage do you think the time fetching mechanism could be a property of the backend? If so, that would give my web audio API backend full control, which seems like a much cleaner separation. The cpal backend could simply continue using bevy_platform::time::Instant.

limpid river
dusky mirage
slate scarab
#

To expand on that -- I think, fundamentally, code running in a web audio worklet cannot acquire any meaningful Instant with respect to the main thread. The only timing information it has is relative to the audio context.

That means we can't compare anything supplied by the firewheel backend to a std::time::Instant or bevy_platform::time::Instant -- they have a different basis. However, we can always acquire the audio timing even on the main browser thread by referring to the audio context.

In practice, most backends will be able to provide a meaninful Instant in all contexts, so the status quo won't change for existing backends. We'd just have to make sure we always get the audio time, even on the main thread, from the context.

dusky mirage
#

Ok, I have an idea how to make this work. I'll work on it and you can review it.

dusky mirage
slate scarab
slate scarab
#

Hey @celest whale , I was hoping I could get a quick bit of guidance on the audio demo! As a little refresher, here's what the Rust audio group has listed as requirements:

Currently two crates are participating in this demo: `Rodio` and `Firewheel`
though everyone is very welcome. The demo will be limited to functionality that
is properly implemented by all crates.

# Demo
- audio environment playing back many sounds at the same time.
- sounds and effects are influenced by user input to make it easy to judge latency.
- the demo uses audio libraries in the same way as a game.
- pre-defined events instead of user input to keep the demo repeatable.
- no graphics to keep the demo code simple.
- sounds are all at the same sample-rate.
- implementations pre-resample before loading.

This seems to imply that they're looking for a more general/low-level demonstration. If that's the case, then such a demo might conflict with what Bevy maintainers want to see for upstreaming, since bevy_seedling's API is critical in that decision making.

Also, does it really make sense to limit bevy_seedling/Firewheel to what rodio/bevy_audio can do? A huge reason the former exist is precisely because of what the latter can't do.

In short: what is the core thing we should be demonstrating for Bevy specifically?

  • That bevy_seedling is overall better than bevy_audio (pretty easy (sorry bevy_audio))?
  • That bevy_seedling/Firewheel are better than bevy_kira_audio/kira?
    • This one's more debatable. I argue the former satisfy cart's concerns well in this comment, but in principle the latter could be brought more in line as well.
  • That Firewheel is a better foundation for all interactive Rust audio than the competition, and therefore the right choice for Bevy?
    • This is the most contentious, and potentially not really answerable. The kira folks have put a lot of good work into their engine, and there are technical trade-offs that each make. I don't think this will resolve in the short term.
#

No pressure to answer at the moment! Feel free to come back to it later. I realize now after typing all that that it's kind of a lot.

#

If the questions at the end really are important to tackle, then it may be worth spinning this out into an issue or a discussion.

#

Some things that come to mind:

  • We could have better audio now if we upstream bevy_seedling, but is that the right long-term plan?
    • I'm biased of course, but Firewheel is an up-and-comer, so going with it is in some ways a bet
  • But then.... do we try hard to coordinate with the Rust Audio group? While I think the effort is admirable, it's a very small group of people with no central authority. Are we likely to achieve consensus within reasonable time-frames?
#

I think a lot of the Rust Audio discussion has stalled, probably in part due to waiting for someone to make that demo. I could totally make that low-level, Firewheel-vs-rodio demo, but... I hope it makes sense that I'm really just more interested in bevy_seedling and Bevy!

celest whale
dusky mirage
#

Hmm, it turns out the way FilterSpec is laid out and the use of a Filter trait makes it really difficult to add parameter smoothing to the filter nodes.

#

I'm not sure there is an easy way to fix this. I'm not sure if having a "generic" filter system even makes sense at the firewheel-core level.

dusky mirage
#

Or even worse, re-computing the filter coefficients for every channel.

#

And plus I can't think of any way to process multiple channels in parallel to take advantage of auto-vectorization.

slate scarab
#

Would it be a lot of code duplication to maybe just... split up each filter into a completely separate node?

#

i.e. instead of one big Spec, you'd have parameters for each individual filter

#

That would also make the Diff and Patch traits more efficient for each individual node.

If you wanted to easily swap between filter types, maybe that's better left to higher-level tools.

dusky mirage
#

I don't think that would help that much, considering the problem is the Filter trait.

#

I'm not sure what to do, we could get rid of the filter trait, but then the user will have to keep track of filters manually.

#

Actually, I think the problem might be more the MultiChannelFilter struct.

slate scarab
#

Hm, to be honest it just seems like the whole stack would be a bit simpler (if slightly more redundant) if each filter were a different struct rather than a combined enum. I probably should have raised that thought before 😅

But I'm not in the details enough to perceive where the difficulty is coming in with smoothing, so this may be unrelated like you mentioned.

dusky mirage
#

Essentially, the psuedo code for an optimized smoothed filter would work something like this:

if self.smoothed_filter_params.is_smoothing() {
    for i in 0..frames {
        // Every 32 frames (or 16 or whatever), update the filter coefficients.
        // We avoid doing this every frame because updating filter coefficients is very
        // expensive.
        if i & 31 == 0 {
            let next_params = self.smoothed_filter_params.next_smoothed();
            self.filter.update_params(next_params);
        }

        // If `NUM_CHANNELS` is a constant, then this loop will unroll and auto-vectorize
        // leading to a huge performance improvement. If it is not constant (there are a
        // variable number of channels), then this will not unroll and auto-vectorize.
        for ch_i in 0..NUM_CHANNELS {
            buffer[ch_i][i] = self.filter.process_channel(ch_i, buffer[ch_i][i]);
        }
    }
} else {
    for i in 0..frames {
        // If `NUM_CHANNELS` is a constant, then this loop will unroll and auto-vectorize
        // leading to a huge performance improvement. If it is not constant (there are a
        // variable number of channels), then this will not unroll and auto-vectorize.
        for ch_i in 0..NUM_CHANNELS {
            buffer[ch_i][i] = self.filter.process_channel(ch_i, buffer[ch_i][i]);
        }
    }
}
#

However, another complication is that FilterCascadeUpTo has its process method defined like this:

    #[inline(always)]
    fn process(&mut self, x: f32, coeffs: &Self::Coeffs) -> f32 {
        self.svfs
            .iter_mut()
            .zip(coeffs.svfs.iter())
            .take(self.num_svfs)
            .fold(
                self.one_pole.process(x, &coeffs.one_pole),
                |acc, (svf, coeffs)| svf.process(acc, coeffs),
            )
    }

That take will prevent this from being unrolled as well, preventing auto-vectorization optimizations.

#

Hmm, I do have some ideas on how this might be fixable. I'll experiment with that.

dusky mirage
#

Dang, this is really hard to do generically.

dusky mirage
#

I'm also not sure if it's worth the extra complexity to support a mixture of both one pole filters and SVF filters in the filter cascade. I might change it to only SVF filters to make things simpler.

#

In fact, should we even support cascades at all? Considering this is mainly used for games and not for creating modular synthesizers, it might just be overkill.

#

Not having one-poles mixed in and not having cascades of SVFs would make things a lot simpler.

#

We may have veered too far into "generic DSP library" territory.

slate scarab
#

Steep slopes *can be very artistically useful, though, unless I'm misunderstanding what you're proposing.

dusky mirage
#

Yeah, I suppose.

viral grove
#

Personally I think having only 12 dB/oct slopes is a bit limiting, even for game audio. If we omit the one poles, would making the const order generic (instead of having a "maximum order") fix some issues?

pure dove
#

FMOD's EQs do support a bunch of different steepness options and algorithms, so it definitely has some precedent

#

messed around with them a lot in my own projects

#

though splitting things into separate nodes makes a lot of sense

oak walrus
#

I don't think we should aim at being as fully featured as FMOD for example, either. It makes sense to provide basic filters (with pole mixing to extend to shelves and bells) but I agree with the sentiment that we might be veering too much into generic DSP territory here. Firewheel and Seedling are modular enough hopefully that more specific use cases can be provided by third-party crates.

#

That being said, a 3 or 5-band EQ is simple enough and useful enough that it would make sense to include first party (with 12 dB/oct bands)

slate scarab
#

In principle, I think you can make that argument. But does it actually work in practice? Who's going to step up and provide the level of quality that we expect in the main Firewheel crates and maintain it over time?

Correct me if I'm wrong, but rodio does allow you to create arbitrary effects. They're just iterators. And yet (to my knowledge), we do not see a lively third-party ecosystem, and rodio is much older and much more widely used than Firewheel. Even kira doesn't have much of an ecosystem!

vocal dock
#

Could a balance be struck by having a 1st party "3rd party" extension?
Keep the base firewheel reasonably scoped, and put the more ambitious fmod-like capabilities in a second, optional crate?

slate scarab
#

haha yeah that's what I was thinking

#

From a purely "PR" perspective, I think people will be more willing to contribute to the Firewheel ecosystem (especially early on) if they're contributing to something that feels "official."

oak walrus
#

That being said, this says more about the lack of need rather than the lack of participation. People mostly don't really need advanced effects in their games, and if they do, they can provide their own implementations, as if they do know what effect they want, they're much more likely to already have some amount of knowledge in how to get an implementation going.

oak walrus
#

But there should be a balance between barebones and exhaustive

slate scarab
#

That being said, this says more about the lack of need rather than the lack of participation.

Sure, but another way to look at that is no one needs advanced audio effects for games in Rust because no one is making games that need that in Rust.

#

Even if they were making games like that in Rust, they'd probably just use FMOD or Wwise because they have no other options.

oak walrus
slate scarab
#

and if they do, they can provide their own implementations, as if they do know what effect they want, they're much more likely to already have some amount of knowledge in how to get an implementation going

I also think this isn't super artist-friendly. Most game audio people do not know how to implement almost any of the effects they use. They're implementors, or composers, or sound designers!

Sure, we're a community of people very familiar with Rust here, but my perspective (which could be totally wrong) is that most people we want to be using better audio in Bevy aren't going to know how to do any of that, especially as Bevy matures.

(I hope I'm not coming off as combative or dismissive btw! I might be talking past you.)

#

Even using bevy_seedling, which is very high-level and user friendly, will probably be a bit of a learning experience for lots of people.

oak walrus
#

(not at all, I'm all for this kind of discussion!)

pure dove
#

(i guess personally, i see "games don't use fancy effects" more as a fault & an opportunity for improvement with better tools)

oak walrus
#

The thing is that most "serious" games will already be reaching for one of the two, even when using Unity or Unreal Engine (the latter of which also has a serious audio engine platform from what I've heard). So the question is do we want to place the new Bevy audio engine as a flexible platform but lightweight (both in terms of maintenance and runtime performance), or are we aiming for a serious contender to "the big ones" by providing all sorts of tools and nodes and all that

#

And as you say, audio engines are as complicated as graphics engines, but only the latter is understood by people, and considerate effort is made to make graphics content authoring accessible. Audio engines are either "easy and simple but not expressive" or "expressive and complete but not approachable". Striking both will need a lot of work and probably innovation (the same way graphics has come to be made more approachable until now)

#

My thinking is that by focusing on the extensibility and lightweight performance part, we can provide a platform for other contributors to build on top of, and contribute back as third or even first party. Bevy is cool in that sense; the community is this project's biggest asset, and we can then focus on different things as needed, rather than spending time to provide a robust list of features that 95% of people won't use (because all they want is to play audio files with their game).

slate scarab
#

Hm, I can't speak to the maintenance angle, but I think we'd kinda eat our cake and have it too with respect to features vs performance. Or at least, I don't think there's a real dichotomy there.

Something that's really nice about Firewheel is that you only pay for what you use, often even at runtime! And it's flexible enough that I don't think you'd be pigeonholed into a bloated audio runtime. A great base set of nodes doesn't make Firewheel any less extensible, which is great!

I think the current set of Firewheel features is perfectly capable of providing a base for big-boy functionality (especially with the recent clock changes coming in). Higher-level crates can do all the curves and management and so on to provide sophisticated audio implementation. The only thing missing in my opinion are the nodes.

#

Call me crazy, but I'd love to have a Bevy-first contender to third-party audio implementation software. I think the road is long, but right now it seems doable to me.

#

Maybe that's a bit of a "miss the moon" situation, but if we land the changes we're working on into Bevy proper, then Bevy's audio capabilities will already exceed any game engine I've worked with personally by a long shot.

#

We're already doing great!

#

Side note -- the performance of Firewheel does look great in practice! I'm doing some early performance profiling for the Rust Audio demo. The timings come from core audio's client load, which should be fairly accurate.

Here's playing 20 samples simultaneously, pre-resampled, with a block size of 1024.

firewheel.png rodio.png
vocal dock
vocal dock
slate scarab
#

It might be a bit unfair to rodio? It's all the same sample, and Firewheel can share the underlying buffer, whereas rodio can't easily as far as I can tell. So maybe rodio's just getting clapped on cache misses.

Once I'm actually finished, I'll be able to get some more representative traces. But I thought it was neat!

slate scarab
#

Oop, actually that was rodio at 512 and Firewheel at 1024 (Firewheel tries to select 1024 by default). You can see in the previous plot that Firewheel has half the samples. Here it is at the default 512.

#

The delta's actually so high (~7x) that I might be doing something wrong 😅

tender fiber
#

You and Billy have done a lot right. Don’t be humble.

slate scarab
#

The performance is all @dusky mirage for sure! My main contribution is Diff/Patch, but that's not being used here.

steep dove
#

Oh wow is that literally an order of magnitude

#

How cross platform are FMod and WWise?

slate scarab
#

They're both pretty good, actually. They hit all the major platforms (including consoles). You do have to distribute their dlls/dylibs which is kinda annoying, but integrations generally take care of that for you.

steep dove
#

I need to catch up on this conversation, but I think we should not aim to be as fully featured as fmod currently.

#

What we need is a good reliable and maintainable rust-only default. The question is probably when not if a project will switch to fmod (even if we do fantastic stuff, people like what they know). The answer to that question should probably be "commercial teams".

#

The safest thing to target, for now, is beginners hobbyist and genius single-dev indies (our current core user-base).

#

If it succeeds with that user-base, then we can set our horizens a bit further out.

slate scarab
#

The transferability alone of these two necessarily puts them in a different category than anything we could do specifically for Bevy.

#

for sure

steep dove
#

There's some parts of the engine that need to be built proactively for users who are not yet here, like the editor. That's mostly not for the users we already have. There's other features that are for the people already using bevy, and this is for them. All it has to do is satisfy their needs, let's not focus on a prospective larger ecosystem just yet.

That seems to be what you are saying as well.

slate scarab
#

Yeah -- while I dream about making something feature-competitive with big audio implementations, it's probably not practical for quite a while, if it even makes sense at all. In the meantime though, it would be nice to get to a point where people with a little know-how don't feel like they have to reach for them. The flexibility/raw capability of Firewheel definitely makes that possible.

The big next steps imo are

  1. Robust parameter animation (ideally with some way to blend curves)
  2. Helpful tools for interactive audio (loop regions, layering management, transitions, etc)
  3. More effect nodes!

(1) and (2) are largely external to Firewheel. As we've discussed, (3) is up for debate depending on the node.

But with these three, anyone familiar with Bevy and just a working knowledge of audio will be equipped to handle pretty much anything (without writing everything by hand).

#

crates like fundsp can help fill the gaps anyway -- it's pretty easy to wrap fundsp processing chains in a Firewheel node

viral grove
#

@dusky mirage is there any way I can help with the redesign of the filter nodes?

dusky mirage
# steep dove Oh wow is that literally an order of magnitude

Yeah, that's the power of block-based processing vs per-sample (iterator) based processing. Block-based processing allows for many types of optimizations that are hard or not possible with per-sample processing.

One of the main reasons is branching. With per-sample processing your logic causes you to branch ever single sample, preventing the compiler from optimizing and making it much harder for CPUs to do speculative execution. With block-based processing, you only branch once per block of samples.

#

Also branching can prevent the compiler from auto-vectorizing code, which is pretty paramount to high performance audio (you can usually get a 2x-4x improvement with vectorized instructions over scalar instructions).

dusky mirage
dusky mirage
# viral grove <@714940838781911051> is there any way I can help with the redesign of the filte...

Maybe for now we should just focus on providing just a couple of very basic filters. IMO even just a simple one-pole lowpass filter node, a simple one-pole highpass filter node, and a simple one-pole bandpass filter node would already provide a lot of useful creative effects for game developers. I have already pretty much created the one-pole lowpass filter node in this example, it's just a matter of making it more official and adding the other two variants. https://github.com/BillyDM/Firewheel/blob/main/examples/custom_nodes/src/nodes/filter.rs

slate scarab
#

I actually have a basic, not-especially-optimized one-pole low-pass in bevy_seedling directly, along with a freeverb port. They're both a little.... uninsteresting artistically, so I'm personally very keen to get some real effects going.

viral grove
slate scarab
#

firewheel-extras or something

dusky mirage
viral grove
#

Ah, so using 2 one poles?

dusky mirage
#

Correct. But if it is separated out into a separate node instead of trying to make a generic "filter" node, it would be much easier to add parameter smoothing and optimize.

#

Though I agree SVF filter nodes would be useful too. We just need to think through how to best design them.

viral grove
#

Ok! I probably won't have time until the weekend but if you haven't done anything by then I can spin up a PR

dusky mirage
#

One effect that I think would be really useful for games is a convolutional reverb (a reverb where you supply a room impulse response). It gives a lot more variety and realism than freeverb. The downside is that it is pretty CPU intensive, so it's a tradeoff that the game developer would make.

But again, that's probably best if it was in a firewheel-extras crate or even a 3rd party crate.

#

Another simple thing I think I'll add is a simple noise generator node. In fact I already created it in the example, I just need to add it to the official list of nodes. Though it could be nice to also have the ability to generate pink noise. I'll have to look up how to do that.

pure dove
#

i have this bookmarked for that

dusky mirage
#

Sweet, thanks!

pure dove
#

(found it through one of your link lists, iirc)

dusky mirage
dusky mirage
#

Alright, I've added a white noise generator node and pink noise generator node!

viral grove
pure dove
#

where's the best place to ask questions about firewheel in general (not in relation to bevy specifically)?

#

i know there's a firewheel server, but there's been no activity there for a while

#

so i'm wondering if i should just ask here

slate scarab
#

either is probably fine!

dusky mirage
dusky mirage
pure dove
#

so i want to have a few nodes that share some state between them, that should be calculated on the audio thread as needed, once per block
my idea was to have them share a Rc<RefCell<Thing>> and use the ProcInfo::clock_samples to key updates, but i'm not sure how i can both construct that on the audio thread and share them between nodes
also, AudioNode::construct_processor taking &self makes me confused on how to send the Thing in the first place (given that i need to construct it on the main thread to begin with)

#

i feel like i might be going on the wrong path early on

slate scarab
#

Hm, what kind of data is in Thing?

pure dove
#

it's a timeline position, local to a couple of nodes on the same timeline (so separate to the global transport, but more shared than a single sampler's position); wrapped in double-buffering so it can be visible from other threads (so more like Writer<Data>), but otherwise just plain data

#

i'm still sketchy on the double-buffering implementation, but i'm leaving that to future luna; the main point there is that i want to construct the value on the main thread (along with a corresponding reader) and then send it over

slate scarab
pure dove
#

that's not the issue, even if it was a plain AtomicBool i would still need to share a mutable(-able) reference between nodes

#

hence the Rc<RefCell<Thing>>

#

well, i guess it could just be Rc come to think of it

#

but i still need some way to share the Rc between them all, and i don't see how i can do that

slate scarab
#

Even if you could find a way to smuggle the Rc's around, they're not the best type for sharing arbitrarily between nodes. If they're dropped anywhere on the audio thread, they may trigger realtime-unsafe (de)allocation behavior.

I'd recommend Firewheel's ArcGc type for starters.

#

(As the name implies, it's a simple, atomically reference-counted type with a barebones GC. We run a GC pass on the main thread every once-in-a-while, dropping any values that have no more references.)

slate scarab
pure dove
#

in this case, i can have the double-buffering impl handle deallocating on the non-audio thread; it's also !Sync, because it makes the assumption that there's specifically one writing thread (and another !Sync value for the reading thread), so ArcGc doesn't quite work

(though, if anyone has a better double-buffering impl lying around, feel free to throw it at me)

pure dove
slate scarab
#

in this case, i can have the double-buffering impl handle deallocating on the non-audio thread; it's also !Sync,

These two statements seem to conflict -- how can you interact with the type across threads, like reading it in one thread and dropping it in another, if it's !Sync?

pure dove
#

you use a method to get a (SharedReader<T>, SharedWriter<T>) that share the same buffers and use atomics to avoid conflict; the reader stays on the main thread, and the writer gets moved to the audio thread & is shared between relevant nodes

pure dove
#

i could wrap that in some interior mutability, but it taking &self makes me feel like that should be a bad idea

#

even though it's only called once outside of error cases (and in those cases i will want some custom handling i think)

slate scarab
#

Yes, the expectation given the signature is that construction is idempotent. If you're using Firewheel outside of bevy_seedling, you can probably get away with it fine.

pure dove
#

yeah, none of this is bevy or seedling related

#

i would like to make this all work with bevy down the line but that is not my priority

#

and moreso, i'm just trying to check some other design choices i've made, have something that produces sound that i can start whacking into shape

slate scarab
#

But all of this extra consideration is why I prompted for atomics in the first place -- an ArcGc<AtomicUsize> (or whatever) is simple, safe and decently fast.

Now of course, if you need to synchronize more fields at once (that can't all be expressed as atomics)... you don't really have a choice but to get into the weeds.

pure dove
#

yeah, there'll be more state

#

and in general i'd want a solution for "something i update on the audio thread and read from a few places"

#

my initial idea was to actually have a node in the graph that does the updating, but i think firewheel would like that even less

slate scarab
#

it's quite tricky given the problems with mutexes in audio

#

for a general solution

pure dove
#

here it's ok for other places to see stale state, and the state isn't particularly complex, hence double buffering

#

store two copies of the data, allow other threads to view one copy, mutate another copy, atomically swap which one is active when you're done with it

#

then some extra work to ensure that, if a reader thread falls asleep while in the middle of reading or accessing the data, the writer/audio thread can work around it

#

which i'm not sure i have correct in my impl, but it is a well-explored problem in general

#

i could get around it by making it sync, or clonable, or something along those lines & subsequently unsafe... i don't think i can enforce that being used correctly

slate scarab
#

making it sync
We actually have a special type for that

#

You could defer the sharing of the buffer until after the nodes are constructed and inserted into the graph. If that works for your use case, I think that would be the most natural way in Firewheel.

#

After you construct the nodes, package up your buffer into a SyncWrapper, send it to the target nodes with NodeEventType::Custom, take the value out in the node, and then you're up and running.

dusky mirage
#

Actually, it would be pretty simple to let nodes create a Box<dyn Any> that is shared across all processor instances of that node.

pure dove
# slate scarab > making it sync We actually have a special type for that

so, the benefit i'd get from making it Sync is that i'd be able to put it in an ArcGc that i share between all the nodes (replacing the outer Rc otherwise used); SyncWrapper doesn't help, because i do want to share the value within the thread, just not between the threads, and i wouldn't be able to recover exclusive access to the value on the audio thread by design

pure dove
dusky mirage
#

Although I do need to think about how to make it realtime safe (no allocations on the audio thread).

pure dove
#

yeah, hm

#

can't be static, because you can have an arbitrary number of node groups available

#

it does feel like just sending things from the main thread is a better idea, but i'm not sure what a nice API for that looks like

#

ugh, i think in this case i should just make it Sync and leave it unsafe to use a writer across threads, then call it internal and be done with it

#

at least at this point

#

because then i can just set up all the node's handles with the right buffers before anything gets sent & i don't have to think about teaching rust "it's ok once every part is sent over, but not until then"

slate scarab
#

Hm, so I've got at least a start at a demo/shootout between rodio and Firewheel going: https://github.com/CorvusPrudens/rust-audio-demo.

Depending on exactly what we're intending to evaluate with it (of which I'm still not totally sure!), we may want to change the format. It's a touch sparse at times. Luckily, changes at this point should be fairly easy -- the core sample playing and fading behavior is all in place.

Frankly, my goal was to make them sound the same. They're pretty close, but different approaches to basic spatialization between the two made it difficult to get exact results.

@celest whale, if you have a moment, feel free to take a look! Let me know if there are any adjustments I can make to help you and other maintainers properly evaluate the two.

@lean cloak let me know if there's anything we can do to better represent rodio here, or if there's anything you'd like to see from the perspective of the RustAudio group.

#

Oh there is a big difference between them now -- for some reason, the text sounds are weirdly distorted in rodio. rodio's receiving exactly the same bytes as Firewheel, so I'm not sure what's up with that.

#

Anyway, sorry for the delay on evaluating the backend timing changes @dusky mirage -- I should be able to get back to that today.

celest whale
#

The other critique I have is that we're not evaluating soundtrack-esque use cases

slate scarab
slate scarab
vocal dock
slate scarab
#

(sorry lol)

vocal dock
#

It's alright 😄 we're all grown-ups we can read the labels.

#

(but aesthetics are aesthetics)

#

The graphs look fairly interesting

#

Firewheel seems to look very gaussian, so ig it's just uncorrelated noise that you'll always have.

#

Meanwhile rodio seems to have a bunch of separated peaks (two look very visible), so there's some conditionals on the timing.

#

But maybe the statistics aren't good enough

slate scarab
#

This was just from one run to be clear -- it's not particularly careful work. But the performance delta holds pretty consistently.

There could be a number of reasons for the spiky rodio timings. In this demo, Firewheel's operation is pretty steady-state. It sets up all the nodes once, with the only thing changing being how many are active. The data that's passed around is largely just main-thread-garbage-collected Arcs.

With rodio, though, we're frequently adding and removing processors (the sinks). Unless I'm mistaken, that involves occasional mutex locking in the audio thread. I'm fairly certain rodio also drops the audio buffers (which are passed by value, not reference-counted) in the audio thread as well.

#

In other words, the audio processors are "pre-allocated" with Firewheel. You don't technically have to do this (bevy_seedling makes it easy to dynamically grow them if you want to), but that's the most natural way with the bare API.

We might be able to do something similar with rodio sinks -- basically just create a bunch of empty ones at startup, and then play sounds by grabbing an idle sink and appending to it. That's not how bevy_audio does it, so I don't know if it's even recommended.

haughty geode
#

Very cute demo! ❤️ It worked great too. The stdout gave some errors, but I don't think it influenced anything: ERROR symphonia_core::probe: probe reach EOF at 4793 bytes.

slate scarab
real mica
#

every file is an audio file if you try hard enough

haughty geode
#

Ah, as long as it doesn't try to play png's on my speakers 😎

slate scarab
#

Okay @dusky mirage those changes for the backend look great! I was worried the generics or associated instant type might get into the user-facing API for the FirewheelContext type, but it looks like that's all hidden. Very convenient for me (no special changes required for bevy_seedling itself)!

For the web audio backend, I'm just using the web context's currentTime value, which ticks up in seconds since the moment of creation. It does stop when the context is paused -- do you know if that would cause any issues?

I think it's unlikely it'll be paused in practice, but I'm just curious.

Another point is that the currentTime will only tick at the rate of processing as far as I understand, so any time in-between will not see a changing clock. Should the backend try to account for that, or does Firewheel manage that itself after getting the Instant from the backend?

dusky mirage
slate scarab
#

In the case of the web audio backend I made, it'll often be suspended for a bit at startup -- until the user actually interacts in a specific way, like pressing a key on their keyboard or clicking a button. So the Instant will just be zero for a little bit.

dusky mirage
#

This is the function that calculates the delay between when the audio clock was last updated and now. If there is a timestamp in the audio clock, then the main thread calls backend_handle.now() to get the latest timestamp from the backend, and then it calculates the difference between those two timestamps to get the estimated amount of delay.

So if the audio backend is paused, I imagine this could result in a calculated delay of zero. https://github.com/BillyDM/Firewheel/blob/3377c1461717b84332f6b0194e3f94aab3d95477/crates/firewheel-graph/src/context.rs#L813

slate scarab
#

Which, now that I think of it, kinda makes it not that useful as a timestamp 😅 since that information could just be retrieved from how many frames the firewheel processor has processed.

#

(currentTime being, again, a field on the Web Audio API context object.)

dusky mirage
#

Hmm, yeah. I wonder if it is even possible to accurately calculate that delay in the WebAudio backend then.

slate scarab
#

We do have a lead, actually

#

The getOutputTimestamp method provides an estimate for when the last frame of audio was processed in terms of the main thread's performance time.

So basically, it correlates the currentTime value to the main thread time.

#

The annoying thing is that this has to be called on the main browser thread.

#

Or, well, maybe that's fine -- that's where the backend is anyway.

But the current abstraction might not be able to capture these semantics exactly.

dusky mirage
#

Ah nevermind. That article is about accurately timing audio events, not accurately getting the current time of the audio clock from the main thread.

slate scarab
#

Hm, I might be mistaken though -- let me make sure I understand the currentTime value correctly.

dusky mirage
#

Yeah, you could probably write a test to see if the currentTime value is different on the main thread.

slate scarab
#

Ah, yeah according to the spec it looks like my understanding is correct.

This is the time in seconds of the sample frame immediately following the last sample-frame in the block of audio most recently processed by the context’s rendering graph.

Bit of a mouthful, but yeah -- only updated when the audio is processed.

Thus, for a running context, currentTime increases steadily as the system processes audio blocks, and always represents the time of the start of the next audio block to be processed.

#

Typically implemented as a shared atomic value.

#

So it's the same in all contexts, but not super useful for correlating main-thread-time with audio time on its own.

dusky mirage
slate scarab
#

Yeah if we can basically "massage" the timestamp on the main thread, we should have enough information to calculate where it's supposed to be at the moment of calculation.

dusky mirage
#

Your backend could then just ignore the timestamp parameter and just call getOutputTimestamp to get the estimated delay.

#

(Unless I'm misunderstanding how that method works.)

slate scarab
#

It basically tells you when the last processing block happened in terms of the main thread's clock. However, that's not necessarily "now" -- you'd need to then calculate how long it's been since then on the main thread.

e.g. (totally fake numbers here)

context.getOutputTimestamp():
    contextTime: 1.0 // in seconds
    performanceTime: 6000 // in milliseconds
performance.now(): 6005

So in this scenario, we called getOutputTimestamp() and performance.now() to get the above results. That means the true current value for the audio time would be roughly 1.005.

dusky mirage
#

Actually, that's kind of similar to what I'm doing for the other backends. The timestamp on the CPAL backend is just the instant the last processing block happened.

slate scarab
#

Oh okay then yeah that seems very similar.

#

but cpal can get that time within the audio processor, right?

dusky mirage
#

Correct.

slate scarab
#

I guess that's the main difference -- the Web Audio worklet where the firewheel processor runs is blissfully unaware of how it may be correlated to the main thread.

#

Only the backend on the main thread can sort it out.

#

sorry i mean context (only the main-thread context could figure out that correlation)

dusky mirage
#

So do you think a get_delay_from_last_process_block(&self, timestamp: Self::Instant) -> Duration method in the audio backend trait will work?

slate scarab
#

It's expected to be some timestamp acquired in the past, and we calculate the main-thread-time that has passed since then?

dusky mirage
#

I think in the WebAudio backend case, it would just be nothing. It's just for backends that provide a timestamp type.

#

Ultimately, the whole goal is just to get that Duration value.

slate scarab
#

Hm, well either way, I don't see any problem with it at the moment.

dusky mirage
#

Cool, when I'm back at my computer I'll add that change.

slate scarab
# celest whale Okay, very interesting. Numbers around latency or regularity would be a really h...

Okay, I did a little investigation into latency. More details in the README, but:

In short: there was no significant difference in latency between the two engines.
Through the speakers of a Macbook M3, they both exhibit latencies around 60-85ms
at a buffer size of 512. `rodio` can't adjust the buffer size, but Firewheel
saw no significant improvement after reducing it to 128.

Through my audio interface, the latency dropped noticeably, down to 40-60ms.
Again, reducing the buffer size had little noticeable impact.

There are a number of places this latency could be seeping in, but I seriously doubt it's anything Firewheel or rodio are doing on their leg of the journey. They both push information to the audio thread either as soon as possible or significantly faster than the exhibited latencies.

#

It seems a little strange that significantly lower buffer sizes (I even tested 64 with Firewheel (with no glitches :3)) have almost zero correlation with the measured latencies. My laptop in combination with my audio interface should be able to do way better.

oak walrus
#

How did you measure the latency? Is it end to end when triggered from user interaction, or is it screen-zudio latency, where an audiovisual event is supposed to happen at the same time?

#

Also is it native or web?

slate scarab
#

I did quickly test the new web backend actually, and through my speakers it had the same latency.

#

I might test it with the interface real quick though

oak walrus
#

MacBook speakers have their own processing, definitely convolution to counteract the form factor and resonance from the chassis (and probably some multiband compression, I can hear the kind of phase distortion that produces when I get clicks), so that probably adds more latency

#

There's also probably the latency from propagating the keypress to the OS to Bevy and then from the ECS to the audio engine

#

So I guess your experiments show the audio engine latency is negligible in the total end-to-end latency

slate scarab
#

Okay with the web audio backend, I'm getting a pretty consistent 50ms.

#

I think it's using a buffer of 256.

#

I definitely still have some interest in narrowing it down a bit further, if possible.

In that issue, it seems a little alarming that Godot or even PyGame could massively outstrip what we could do, even with small buffers. That's what the author's testing seems to indicate. But @rapid hedge couldn't reproduce their results.

oak walrus
slate scarab
#

Core Audio was reporting block sizes of 256 when I was running the web testing earlier.

#

40-60 milliseconds isn't bad, but if we can consistently get much better latencies with other engines or apps, it's definitely worth investigating further imo.

celest whale
celest whale
tender fiber
#

512 to 128 is great

tender fiber
#

Ooh!! 64

rapid hedge
slate scarab
dusky mirage
untold totem
#

Can I ask if we will have PitchShift effect once this comes out or if it will come later? It is quite crucial in making sounds not sound annoying when played repeatedly.

slate scarab
dusky mirage
#

Changing pitch without changing speed is very difficult.

#

Or at least difficult to get it to sound decent.

slate scarab
#

I did make a component specifically for this in bevy_seedling since it's so common. It randomizes the speed within a range that you give it.

commands.spawn((
    SamplePlayer::new(server.load("my_sample.wav")),
    // randomly select between 0.9 and 1.1 when spawned
    RandomPitch::new(0.1),
));
untold totem
#

Variation is all that matters, so if shortening/fastening is part of it then thats no problem 🙂

#

If it was such a big problem to do a proper pitch shift realtime, i can just bake it in audacity or something

rapid hedge
slate scarab
slate scarab
#

Randomizing pitch is, again, very common, so it may be worth putting a bit more work into it.

rapid hedge
#

Just to have all clients hear the same thing 🙂

#

And for replays

slate scarab
#

I think it's Apex Legends that doesn't synchronize character quips between clients, and I hate it so much.

#

(How am I supposed to riff on my character's funni????)

dusky mirage
#

@slate scarab Alright, I've updated the delay detection method for audio backends!

slate scarab
#

I might want to do some tests with some precise audio scheduling to verify correctness, but at least right now I don't see anything wrong with it.

viral grove
#

Btw sorry for not working on the barebones filter PR on the weekend, I don't have much time at the moment 😦

limpid mason
#

FYI, I'm currently working on adding better multi threading support to the Bevy CLI prototype, which will set the headers automatically and also set the required nightly flags.
But it will probably still take a bit, I have limited time for open source ATM.
I'll post here once it's done :)

slate scarab
#

That would certainly make it much easier for people to try out the web audio backend. I'm guessing few people have tried it just because of the upfront friction.

limpid mason
limpid mason
#

But I was looking for something to test the multi threading with, so it's perfect that you added support for it!

limpid mason
slate scarab
limpid mason
slate scarab
#

I’ll verify it’s working and then post a link here. I believe we activate the web audio backend with a feature, so I’ll give you that info too. (I’m away atm so I can’t check yet.)

limpid mason
slate scarab
# limpid mason Perfect, thanks a lot!

Okay here's a repo that should work out of the gate: https://github.com/void-scape/chain-reaction. I think you'll want to disabled its default features. The game is slightly busted (it will crash on the game over screen), but it works for the purposes of testing.

The --experimental-multi-threading flag actually doesn't work for me because the cross origin isolation header values include single quotes. I removed those with a header override and it seemed to work, meaning the compiler flags seem to be working as expected.

If everything works, then when you interact with the page (like clicking on the canvas), the audio should start up. If no sound starts playing, it probably didn't work, and you should see an error like this in the console.

limpid mason
limpid mason
#

I fixed the quotation and it works now!
I also verified by checking window.crossOriginIsolated in the dev console and that returns true now as well.
Also checked the repo you linked and that also runs and plays the (really nice) soundtrack :)

slate scarab
#

I was doing some more stress testing between rodio and Firewheel. For each, I played hundreds of samples at once. It's the same sound, but with some random pitch variation handled at runtime.

If we allow Firewheel to pre-allocate enough nodes to play all the sounds (otherwise it'll just drop incoming sounds when there are too many), it does quite well!

rodio can handle around 256 simultaneous sounds on my machine before it runs into underflows. This is when the sounds are played directly on the mixer, a new 0.21 feature, so it should be pretty favorable. Fairly respectable, especially since all the sounds are being live resampled due to the random pitch.

Firewheel, on the other hand, got up to 8192 before it had underflows (and in the test there was just one)! In fact, I was generating so many events to play the sounds that Bevy itself slowed way down. (I was even able to push it up to almost 16k without the pitch variation.)

Like the previous stress test, this may not be super representative, and Firewheel may benefit heavily from playing a single sample (which it shares as an Arc, likely kept in cache), but still kinda fun.

slate scarab
restive karma
#

Hello everyone, I am new to Audio-Developement, Bevy, Open-Source and Rust, but I would like to contribute to this working group anyhow 🙂
The open issues with the label A-Audio are comprehensible, but some of the C-Feature issues are not graded by difficulty.
Since both issues marked with a D-Straightforward seem to wait for continuation (#18952 & #16277),
I was wondering if someone could give me a brief overview about the current state of "Better audio" and guide me through some potential projects I could help with.

celest whale
#

User testing, refinement and feedback for #1378170094206718065 would also be very welcome 🙂

slate scarab
#

Since the work is all third-party at the moment, any progress we’ve made here is not reflected in Bevy’s issues.

slate scarab
#

bevy_seedling is my integration, and if there are no big issues with it and we like the API, it'll probably end up replacing bevy_audio completely.

restive karma
restive karma
slate scarab
slate scarab
# slate scarab Hm, so I've got at least a start at a demo/shootout between `rodio` and Firewhee...

I was interested in checking out how kira compares as well. kira was definitely the most pleasant crate to integrate from scratch given its API. In any case, it looks like Firewheel has a 2.5-2.7x performance lead over it (compared to a little over 3x with rodio).

Performance isn't necessarily the most critical aspect here, but it's cool that we stand to gain much more flexibility without any performance downsides.

wary bridge
#

For what reason specifically does Firewheel run better than kira?

#

Curious where kira has overhead that Firewheel avoids

slate scarab
#

Given the delta isn't huge, it may be something simple like better auto-vectorization in a few key places.

#

Oh, this might also be unfair to kira -- I need to double check to make sure it's not decoding on the fly.

#

No okay it does decode eagerly. Should be fair.
This sort of thing -- interpolating every value over each audio block -- may also contribute. While linear interpolation is fairly cheap, it can add up.

#

Especially if it confuses the compiler (which is easy to do) in a way that pessimizes SIMD optimizations.

#

The default nodes in Firewheel are generally pretty careful about that sort of thing, and more eagerly branch to encourage SIMD.

slate scarab
# slate scarab No okay it does decode eagerly. Should be fair. [This sort of thing](<https://gi...

For example, look at how much effort is put into the VolumeNode with regards to whether the volume is actively changing or not: https://github.com/BillyDM/Firewheel/blob/4c3abbb93d58d98e1fe56857d58bf6f94b9d5018/crates/firewheel-nodes/src/volume.rs#L122-L199. (There are also carve-outs for 1.0 (pass-through) and 0.0 (silence).)

All that compared to, effectively, the single line I linked in this message I'm replying to.

#

So it definitely doesn't come for free 😅 but pursuing the idea of auto-vectorization everywhere and aggressively avoiding unnecessary processing seems to be doing quite well for Firewheel.

slate scarab
#

If no output device has been selected (i.e. you just want the default device) and the default device changes (like when you connect headphones), should we automatically move the audio stream to the new default device?

#

I think the answer is probably yes, with the only downside being we'll have to poll the devices every once in a while to see if the default changes. If we only do it once or twice a frame, it can't be that expensive, right?

#

Oh actually it looks like cpal only surfaces an error here (and stops the stream) if you specifically select a device. It already handles the automatic switching in the default scenario. We know when an error occurs otherwise, so we don't actually have to do any polling or anything.

dusky mirage
#

Yeah. Because keep in mind even something as simple as applying a single static gain to a signal requires 44,100 * NUM_CHANNELS multiply operations per second.

slate scarab
#

Unrelated -- I'm working on restoring the playback state after the audio stream changes sample rates. It's actually... almost trivial, which is great (thank you ECS). However, it seems like the samplers actually continue playing their sequence, as if they never got their new_stream method called (or they think the sample rate hasn't changed).

Just off the top of your head, do you have an idea of where that might be coming from @dusky mirage? I'll have to do a bit more investigation here to nail it down.

#

Oh to be clear, they continue some of the time

#

not every time

dusky mirage
#

Hmm, not sure.

#

Also, having the Firewheel processor automatically schedule events efficiently is turning out to be quite complex. Nothing I can't handle, it's just I need to refactor things some more which is going to take a little while.

slate scarab
#

definitely worth the wait for me if we're able to make it work!

dusky mirage
#

(Essentially state mutation logic inside FirewheelProcessorInner has become a spaghetti mess. I need to compartmentalize it.)

slate scarab
slate scarab
#

While the above is happening, it does look like the old sample rate also isn't updated. i.e. the first switch from 44.1k to 48k correctly distinguishes the two (old rate: 44.1k, new rate: 48k), but switching back doesn't (old rate: 44.1k, new rate: 44.1k).

I'll see if I can figure out where that's coming from.

dusky mirage
slate scarab
#

The whole sequence being 44.1k -> 48k -> 44.1k

dusky mirage
#

Oh ok.

slate scarab
#

Oh yeah I think it's because prev_sample_rate isn't set anywhere except in the Default implementation (for StreamInfo).

dusky mirage
#

Ah yeah. It appears I forgot to set that value.

#

Do you need that fixed now, or can I just fix it along with the new event stuff?

slate scarab
#

I can just patch it for myself locally atm, I'll probably wait for the event stuff before publishing another bevy_seedling version

dusky mirage
#

Ok, this is what the patch will look like: ```rust
let maybe_processor = self.processor_channel.take();

stream_info.prev_sample_rate = if maybe_processor.is_some() {
self.sample_rate
} else {
stream_info.sample_rate
};

self.sample_rate = stream_info.sample_rate;
self.sample_rate_recip = stream_info.sample_rate_recip;

let schedule = self.graph.compile(&stream_info)?;

let (drop_tx, drop_rx) = ringbuf::HeapRb::<FirewheelProcessorInner<B>>::new(1).split();

let processor = if let Some((from_context_rx, to_context_tx, shared_clock_input)) =
maybe_processor
{

slate scarab
#

Great, looks like that did the trick!

#

wait I lied XD

#

gimme a sec

#

Should it be is_none maybe

stream_info.prev_sample_rate = if maybe_processor.is_none() {

since that's when we call new_stream on all the nodes?

#

(That makes it work in my case. idk if that's how it's meant to work in general.)

slate scarab
#

Okay, with a bit of a hack for the assets, it all works now. The sample states are restored after the sample rate changes, meaning there should be no issues when switching between devices, even in externally-controlled situations like disconnecting headphones. I think there are some edge cases that could cause problems, but they should be fairly unlikely.

#

@faint wigeon how much information would you want associated with each input and output device? Right now, when you query for them, the entity only provides the name, channels, and whether it's the default.

But do you think you'd want all the information associated with them, like sample rate and buffer size ranges?

#

It's a touch tricky to balance where exactly the abstraction boundaries are drawn. Technically, we could just stuff the cpal information in the entity, but Firewheel's backend abstraction doesn't expose that itself.

faint wigeon
#

i understand not just wanting to make the fire wheel api the cpal api that’s basically how we ended up with bevy window with winit

faint wigeon
slate scarab
#

Yeah so what I want to avoid is a situation where you can't easily provide arbitrary 3rd-party Firewheel backends to the seedling plugin. Right now, since Firewheel's backend trait only grabs this more limited information, that's what the entities report.

However, it's probably totally fine to update those types in Firewheel so they can report sample rates and buffer sizes. That seems pretty useful in the general case, and those concepts aren't tied to anything cpal-specific.

faint wigeon
slate scarab
#

It's not perfect yet, but it's getting better! Right now, the flow is to query the devices, grab the name from the one you want, and then update the audio backend's configuration resource with that name. Any time the resource changes, it'll attempt to restart the stream with the new config.

It would be cool if we could maybe use relationships instead (like an InputOf or something), but that's another abstraction that would require a bespoke integration of each backend, so... blobshrug

#

Oh and there's a little period in Startup before the stream is initialized where you can write to the config, allowing you to also manage the initial stream config in the ECS.

#

Maybe I'll make a trait for the backends for this though. I think in practice, not too many people will bring in their own backend, and those who do would probably have no problem authoring just a few trait methods to tie everything together.

faint wigeon
#

am happy to test drive whenever this lands

faint wigeon
slate scarab
#

Although I guess it would be easy to lose synchronization with the backend config and the ECS representation if you modify the config directly blobthink

slate scarab
dusky mirage
dusky mirage
slate scarab
dusky mirage
#

Oh and apparently a test is failing. I'll look into that tomorrow.

slate scarab
# dusky mirage <@164224139316428800> Alright, here is what I have for the new event timing syst...

Okay I just started looking into this -- definitely looking good so far. I have some things to note, but I'll put that together later.

I am running into an issue though for the audio demo. It seems like if there are too many events going on at once (not enough to overflow the buffer mind you, just a handful really), I run into a panic here for scheduled events or here for unscheduled.

That is, in both cases, it appears the sorted event buffer indices are falling out of sync with the event arena. I couldn't figure out exactly where that desync is happening, though.

If you want a quick repro, feel free to check out this branch of the repo!

dusky mirage
#

Ok. I suppose it was a bit optimistic hoping it would work first time. 😅 I'll debug it tomorrow.

dusky mirage
#

@slate scarab Those were pretty difficult logic bugs to squash but I think I fixed it. Let me know if you run into any more trouble!

#

For those who are curious, the first bug was caused by forgetting that this block can run for multiple sub-chunks, so I incorrectly assumed that the next event would always belong to the node and thinking that checking for None was unnecessary. https://github.com/BillyDM/Firewheel/blob/93d272615f3ef66c848750dde4d1d2d3a486532d/crates/firewheel-graph/src/processor/event_scheduler.rs#L458

The second bug was caused by too eagerly adding a filter to the iterator here to filter out Nones https://github.com/BillyDM/Firewheel/blob/93d272615f3ef66c848750dde4d1d2d3a486532d/crates/firewheel-graph/src/processor/event_scheduler.rs#L522. But I actually needed to do extra logic for the None case.

#

Also, nifty little demo! 😁

slate scarab
#

It's actually performing a little bit better? Might be noise, but either way it looks like the changes resulted in no appreciable regressions.

dusky mirage
#

Oh yeah, and I did do a few things to Notify, but I also wouldn't imagine that causing much of a difference.

#

Or actually, the most likely culprit might be the owned events and parameter patches along with the use of ArcGc. Before paramter patching would have caused allocations on the audio thread if the type wasn't RealtimeClone.

slate scarab
#

Oh and by "the changes" I mean in comparison to the current main if that's not clear!

dusky mirage
#

(Or wait, maybe not.)

#

When I'm back at my computer I'll figure out that clone was if there was one.

slate scarab
#

I think the only allocation that could have happened previously (specifically during patching, at least with the derived implementations) is if you had an enum with a field that allocates on clone.

#

The new trait would prevent that happening with the previous implementation, which is nice. Although since the patch is given by value, you wouldn't need to clone in the first place.

Of course, in this scenario, you'll end up calling the drop handler for the replaced value, which could result in a syscall. But we could probably carefully apply RealtimeClone to types that also happen to have real-time safe drop handlers?

dusky mirage
#

Ah yeah, nevermind, you're right.

slate scarab
#

indeed it was questionable

dusky mirage
#

Hmm, another theory for the better performance is the better cache efficiency of using a single immediate/scheduled event buffer for all nodes instead of allocating a buffer for each node.

#

(And it could just be noise)

#

The only thing I'm a bit iffy about is the performance of sort_unstable. Of course it is fine for most use cases, but if you had hundreds or even thousands of scheduled events, I'm not sure how well it would go. Ideally we would sort events off of the audio thread, but that's kind of hard to do since we are mixing musical and non-musical scheduled events together.

#

According to the docs, the unstable sort algorithm is O(n * log(n)).

#

Or wait, actually it's O(n * log(k)) where k is the number of distinct elements.

#

So I suppose if you had n distinct elements, it would be that.

slate scarab
#

Well I ran a few more tests and they're all at or below the original benchmark. The first one might have been a little exceptional (at around 10% faster). But hey, none of them were slower so that's pretty good.

slate scarab
# slate scarab indeed it was questionable

Oh and to expand on this: using the pointer of an Arc as a means of change detection is a very attractive optimization. It feels clever. However, it's not perfect. You could have false positives for example, like if you have two Arcs that happen to hold the same value.

dusky mirage
#

Yeah, that is true.

#

It's definitely helpful for large types that would be very inefficient to diff (like dyn SampleResource).

slate scarab
#

Yeah it should be fine, actually. False positives aren't too bad anyway. Just one-off extra events, really.

dusky mirage
#

Yeah, and the vast majority of plugins are probably just going to have primitive parameter types, and maybe some dyn SampleResources.

slate scarab
#

My (very rough) guess on an O(n * log(n)) sort for a thousand events is something like 50 microseconds? That's very roughly 10k operations, probably only a few nanoseconds each. Which seems fine blobshrug

#

Once I get an animation API going for bevy_seedling, it should be pretty easy to blast it and see.

crisp walrus
#

apologies if this is the wrong place to ask this... i used bevy seedling in my GMTK jam entry and it was great! It worked pretty well although a I did notice stuttering and glitching in the audio on WASM mobile builds (older devices). Probably not surprising given a lot of the particles etc were on CPU so without profiling I'd guess there was a CPU bottlneck

#

Is there a way in firewheel to play "raw" audio, i.e. audio I generate in real-time as an iter or vec of f32s?

slate scarab
#

let me link it here

oak walrus
slate scarab
#

#1236113088793677888 message

oak walrus
crisp walrus
#

Ah perfect, thanks both! I imagine that will help the audio although I think then the particles will be the problem 🙂

Being new to thinking about audio I don't know what a lot of the terms are so I was imagining nodes were for volumes / filters etc not a source. I'll take a look at the example!1

oak walrus
#

It's a bit abstract, so it's hard to wrap your head around, but the abstractness is the point, because it's what makes the audio graph versatile enough to support custom audio processing

#

Everything is a node in the audio engine, so yes, filtering and setting volume is done with nodes, but generating sound is just having a node with 0 inputs

#

You simply have to connect the output into the graph in a way that you can eventually hear it (ie. it is connected into a chain of nodes that ultimately connect to an output that then feeds your speakers), but I believe the seedling plugin takes care of that automatically (you set up connections through the ECS, and by default it goes directly to the main output AFAIK)

crisp walrus
#

ah ok, that makes sense. You've given me a place to start thank you!

rapid hedge
#

Heads-up: 0.17 uses wayland by default, so the feature list in the readme for bevy_seedling will need to be updated to use wayland instead of x11 😉

rapid hedge
#

@slate scarab finally migrating to seedling now. I'll fire some questions at you while I'm on it, hope you don't mind 😄

#

First: is there a particular reason why Sample is not in the prelude?

#

I'm storing Handle<AudioSource> rn and it seems like the seedling equivalent is Handle<Sample>

#

If so, I'm used to bevy having all asset types I might need in the prelude, so it feels like I'm not supposed to use Sample?

#

Don't think that's the intention, but that's how it feels

slate scarab
rapid hedge
#

And because I have things like convenience functions that take in a Handle<Sample> and return an impl Bundle of the effects I want

#

A bit like a UI widget, but for audio

slate scarab
#

we could definitely export it as long as it's not too overloaded of a term

#

I think it's probably okay

rapid hedge
#

yay!

#

Oh, I see you have examples for a settings menu and for spatial audio. Perfect, that's exactly the two things I was wondering about!

slate scarab
#

But I definitely wanted to avoid AudioSource because that's not really what the asset is for. I mean, yeah it is an audio source, but it's not "the way" to make an audio source in bevy_seedling. After all, you can write any kind of audio source as a node! Synthesizers, noise generators, whatever really.

rapid hedge
#

If Sample is too overloaded (I don't think it is), we could also do AudioSample

slate scarab
#

maybe that's better

slate scarab
#

so that should be convenient

#

it'll be the typical SFX/Music/Master setup by default

oak walrus
slate scarab
#

hmmm but it could be samples generated at runtime, and then packaged up into an asset

oak walrus
#

ha, I didn't think about this case, yeah

#

yeah, Sample feels the most generic actually

#

or maybe simply Audio? But that also feels too overloaded

slate scarab
#

Oh also keep in mind @rapid hedge that bevy_seedling despawns audio entities by default, unlike bevy_audio (if that's what you were using). It's maybe a little bold, but I personally think it's the correct default.

rapid hedge
#

I always assumed it did lol

#

So every time I spawned a new sound effect, I leaked a bit of memory?

slate scarab
#

it's actually worse than that -- if the handles stick around, they slow down the audio processing a little bit

rapid hedge
#

Yeah, despawning definitely seems like right call here

slate scarab
#

so when you spawn a ton of them, you can get underruns (which people have mentioned in issues from time to time)

oak walrus
#

I think most people assume audio entities despawn after finishing a one-shot audio source

rapid hedge
oak walrus
#

but then they attach audio sources to their main entities and their mesh disappears randomly

slate scarab
wary bridge
#

maybe the default could be selected based on whether the source is spawned as a fresh entity or inserted onto an existing one, or maybe that's too much cognitive overhead

slate scarab
#

right

#

Another approach that was proposed is to remove all the audio entities by default, and then despawn the entity if it's empty. However, I'm not sure I like that. If you insert any components that bevy_seedling doesn't know about, but you want and expect them all to be despawned, you'd end up with a lot of zombie entities.

oak walrus
#

yeah I think it should be taught to people to use fresh entities for audio, especially one-shot

slate scarab
oak walrus
#

tack them as children of the main entity, so that spatial audio still works as expected, but this way feels more ECS-y than just adding them as additional component to your existing entities

slate scarab
oak walrus
#

(also it feels like having a single entity with all the components on it is the ECS equivalent to a God Class in OO-based designs)

slate scarab
#

ya i think we should teach people to spawn spatial sounds as children of world-positioned entities

#

it's just a good rule of thumb

#

you would need to remember to insert a transform i suppose, but maybe we could find an ergonomic way to do that

#

One approach could be to make Transform a required component of the SpatialPool label. In the next release of bevy_seedling, the default graph configuration will have a spatial pool with that label. So the way we'll ease people into playing spatial sounds will look like:

commands.spawn((
    SpatialPool,
    SamplePlayer::new(server.load("sample.wav")),
));
oak walrus
#

Maybe SpatialPool can #[require(Transform)]?

slate scarab
#

ya

oak walrus
#

oh lol I was writing my message at the same time as yours

#

data race

#

in my Rust server?

rapid hedge
#
#[derive(Component)]
#[require(Transform = panic!("You need to provide a Transform"))]
struct Foo;
slate scarab
#

Although in this case, we'd actually want the default transform most of the time (assuming these will be children of entities with transforms)

rapid hedge
#

@slate scarab I know why I assumed that bevy_audio despawns!

#
/// A sound effect audio instance.
pub(crate) fn sound_effect(handle: Handle<AudioSource>) -> impl Bundle {
    (AudioPlayer(handle), PlaybackSettings::DESPAWN, SoundEffect)
}
#

It's my widget 😄

#

This is useless now in bevy_seedling haha

slate scarab
#

oh haha yeah that makes sense (otherwise chainboom would have borked audio after 15 min probably)

rapid hedge
#

How come volume is part of SamplePlayer but speed is part of PlaybackSettings?

#

And is it intentional that I can use a fluent API here:

SamplePlayer::new(sound_effect).with_volume(Volume::Linear(1.6))

but not here?

PlaybackSettings::default().with_speed(1.5)
slate scarab
rapid hedge
#

Aaah so it's about mutability

#

got it

slate scarab
rapid hedge
#

makes sense, thanks 🙂

slate scarab
# rapid hedge Aaah so it's about mutability

In terms of the ECS API yes, but more fundamentally, none of the parameters on the SamplePlayer can change in Firewheel after playback starts. (Not as true in the upcoming Firewheel versions, but really you should still follow the recommendations of the docs there.)

rapid hedge
#

Is there a rule of thumb how SpatialScale translates to SpatialBasicNode or do I just tweak it by ear?

#

(I always hated SpatialScale)

slate scarab
rapid hedge
# slate scarab oh really?

The docs on bevy_audio weren't clear on what the magic number meant when I first started using it haha

#

So I hold some residual bitterness to it

#

Also, I feel like my intuitive hearing does not match the numbers I use

#

Like, I think to myself how far away I want the audio to still be audible

#

But the result is almost always entirely different than what I initially wanted

#

So it always ends up with me cluelessly fiddling with constants

#

Like "oh, I want the footsteps to be audible until like 30 meters away, so I'll use SpatialScale::new(1.0 / 12.0) or something like that"

vocal dock
rapid hedge
#

After some major fiddling, I end up with SpatialScale::new(1.0 / 3.6)

#

Which is a factor 4 off from my initial guess

#

Maybe this is just a skill issue though

rapid hedge
#

A scale factor applied to the positions of audio sources and listeners for spatial audio.

#

Yes, this means nothing to me 😄

#

I think I actually learned about what SpatialScale does by reading the docs of bevy_seedling, come to think of it

#

haha

slate scarab
#

really we should allow you to choose the fall off mode

#

but do keep in mind that they are different between the two, so things may sound a little weird without different compensation right now

rapid hedge
#

Of course, I'll still tweak it later

slate scarab
#

idk 😅

rapid hedge
#

But as a starting point

slate scarab
#

it depends

rapid hedge
#

hehe

oak walrus
#

You can't get a value because it has the different law

#

Inverse square will take longer to decay, so over bigger distance bevy_audio will be louder

slate scarab
#

ya it's two different curves

rapid hedge
#

I just went by the docs of bevy_seedling while using bevy_audio hahaha

oak walrus
#

But the initial drop is faster with exponential decay so close-by, seedling is louder

rapid hedge
#

Sooo I just go by the default and completely retune everything? :/

oak walrus
#

technically you can get a conversion factor by having a set distance you want to match the two

oak walrus
slate scarab
rapid hedge
#

Just so it's not completely starting from scratch

oak walrus
#

you can change k to whatever you want, but you'll never get the two to line up

slate scarab
#

actually that's not technically what we're doing

oak walrus
#

(red is bevy_audio, blue is bevy_seedling)

slate scarab
#

I'm graphing the actual calculation used -- it's technically exponential decay but the constant is quite small

oak walrus
#

also the scale of the x-axis means nothing because there might be additional scaling factors in each implementation that I don't know

rapid hedge
oak walrus
#

k is the factor you'll multiply your old SpatialScale by to get the new constant

rapid hedge
#

And you mentioned doing this for a particular distance?

oak walrus
#

sorry scratch that, made another mistake

rapid hedge
#

😄 happens

oak walrus
rapid hedge
rapid hedge
#

Again, no need for this to be accurate

#

Just something so I don't start from literally zero 😄

oak walrus
#

the k now properly changes the distance falloff curve for the seedling attenuation

slate scarab
#

These are the precise values. bevy_seedling in green

rapid hedge
slate scarab
#

So the falloff is much more gentle compared to inverse square

rapid hedge
#

This sounds perfect

#

My issue was precisely that the falloff was extremely jarring

#

Cool!

slate scarab
rapid hedge
#

Not just for comparing the two, but for seeing what that parameter does in general 🙂

#

Maybe add that to the docs of the component 👀

rapid hedge
slate scarab
#

yes, I believe @dusky mirage wrote it with the intent of modeling 1 unit = 1 meter by default

rapid hedge
#

because that's exactly what went through my head

#

"I want the footsteps to be silent at about 30 meters, how do I tweak this to make that happen?"

slate scarab
#

maybe we should include a little curve tool in the editor for this :3

rapid hedge
slate scarab
#

I think k is exactly what the spatial scale would do

rapid hedge
slate scarab
#

no 😅 but it might help you set a good default scale to get the two to sound similar

rapid hedge
#

Okay great

#

Again, this perfect 😄

#

Please please put this in the docs

#

Well, the version in the docs probably doesn't need the blue graph

slate scarab
#

until we add inverse square back in as an option ferrisBased

rapid hedge
#

Aaah this makes me so happy right now 😄 No more struggling with SpatialScale!

#

Alright, now to port my audio menu

#

I believe @oak walrus was kind enough to write a little prototype somewhere 👀

#

We have two candidates:

const VOLUME_STOP_DB: f32 = -60.0;
const VOLUME_STOP_POS: f32 = 0.01;
let position = slider.get_position();
let volume = if position < VOLUME_STOP_POS {
    Volume::Linear(lerp(0.0, db_to_linear(VOLUME_STOP_DB), position / VOLUME_STOP_POS))
  } else {
      Volume::Decibel(lerp(VOLUME_STOP_DB, 0.0, (position - VOLUME_STOP_POS) / (1.0 - V0LUME_STOP_POS))
};

and

fn position_to_volume(t: f32) -> Volume {
    let curve = UnevenSampleAutoCurve::new([
        (0.0, f32::NEG_INFINITY),
        (0.01, -30.0),
        (0.5, -7.0),
        (1.0, 0.0),
    ]).unwrap();
    Volume::Decibels(curve.sample(t.clamp(0.0, 1.0)).unwrap())
}
#

With the caveat that the second version treats the entire range of [0.0, 0.01] as negative infinity

slate scarab
#

ya the -inf can be annoying sometimes

#

i think i like the first one

rapid hedge
#

I wish I found some reference of how other games do this

#

Like, this has to be a solved problem

#

namely, translating between some slider and a target volume

slate scarab
#

you could probably bump up the minimum to like -50 even

oak walrus
slate scarab
#

We should provide a function for this from bevy_seedling itself

rapid hedge
#

How did you find it? I tried googling but I sucked at it bavy

oak walrus
#

and it looks to be pretty close to my solution, but with an added "boost" range

slate scarab
#

i saw it in a gamedev subreddit
idek why it showed up

rapid hedge
oak walrus
#

the curve solution will simply waste the first interval because the interpolation will be stuck at -inf, but otherwise they're both close too

rapid hedge
#

Is this an accurate translation of what the library does?

pub(crate) fn apply(self, perceptual: f32) -> Volume {
    if perceptual == 0.0 {
        return Volume::Linear(0.0);
    }
    let db = if perceptual > self.normalized_max {
        ((perceptual - self.normalized_max) / self.normalized_max) * self.boost_range
    } else {
        (perceptual / self.normalized_max) * self.range - self.range
    };
    return Volume::Decibels(db);
}
#

Not sure what to do with that last normalized_max scale hmm

#

(this is for perceptual to amplitude)

#

Full code:


const DEFAULT_VOLUME_DYNAMIC_RANGE_DB: f32 = 50.0;
const DEFAULT_VOLUME_BOOST_DYNAMIC_RANGE_DB: f32 = 6.0;

/// Constructor for taking a user-presented control value and converting it to a volume
#[derive(Debug, Clone, Copy)]
pub(crate) struct PerceptualToVolume {
    /// Normalization of perceptual value, choose 1 for decimals or 100 for percentages
    pub(crate) normalized_max: f32,
    /// Dynamic range of perceptual value from 0 to [`Self::normalized_max`]
    pub(crate) range: f32,
    /// Dynamic range of perceptual value from [`Self::normalized_max`] to 2 * [`Self::normalized_max`]
    pub(crate) boost_range: f32,
}
impl Default for PerceptualToVolume {
    fn default() -> Self {
        Self {
            normalized_max: 1.0,
            range: DEFAULT_VOLUME_DYNAMIC_RANGE_DB,
            boost_range: DEFAULT_VOLUME_BOOST_DYNAMIC_RANGE_DB,
        }
    }
}

impl PerceptualToVolume {
    /// Converts a user-presented control value to a [`Volume`].
    /// The input must be in the range \[0, 2 * [`Self::normalized_max`]\].
    pub(crate) fn apply(self, perceptual: f32) -> Volume {
        if perceptual == 0.0 {
            return Volume::Linear(0.0);
        }
        let db = if perceptual > self.normalized_max {
            ((perceptual - self.normalized_max) / self.normalized_max) * self.boost_range
        } else {
            (perceptual / self.normalized_max) * self.range - self.range
        };
        return Volume::Decibels(db);
    }
}
slate scarab
#

hm, tbh I would stick with @oak walrus's first approach, since the behavior near zero will be a little more well-behaved, and usually games don't have a boost setting to worry about

rapid hedge
slate scarab
#

it could still benefit from the struct though

#

since you may want to configure the range and stop position

#

Okay I've added all these notes as issues. I should be able to implement them pretty quickly, and I can work towards another release.

I've been a little blocked on integrating animations. Initially I wanted something simple for stuff like fade ins / fade outs. However, a proper implementation is really just another animation crate, which is quite involved. And frankly, there's no point in writing another one unless it properly integrates with bevy_animation in some way, which is very difficult. So I think I'll put that aside for now.

#

(And in any case, you can animate the audio nodes like any other ECS type with any of the existing animation crates, so it's not like people have no options.)

rapid hedge
slate scarab
#

Very glad to have it! The overall feedback has been pretty sparse so far.

rapid hedge
#

I was under the impression that a few people used it so far 👀

#

But I guess they didn't have much to say

slate scarab
#

ya but mostly people have said either "ya seems nice" or nothing at all 😅

rapid hedge
#

Is there a better way to do db_to_linear than Volume::Decibels(foo).linear()?

slate scarab
rapid hedge
#

I hope I can make it justice at some point, I'm still quite the beginner in terms of audio 😄

slate scarab
rapid hedge
oak walrus
rapid hedge
#

I'm not familiar enough with the underlying maths to do so myself 😬

#

i.e. convert a volume to the perceptual control value

oak walrus
#

Not at the computer right now

#

Alternatively you can have the perceptual value as a component, have an observer that changes the volume when that component is changed using the conversion above

#

Bonus is it's easily serializable

rapid hedge
rapid hedge
#

How come that the perceptual value 1.0 corresponds to 0.0 dB, btw?

#

Is that arbitrary?

#

like, why not 3.0 dB?

slate scarab
#

generally when you work with dB (FS), the "full-scale" value is 0.0

rapid hedge
slate scarab
#

so that's why it goes negative for things quieter than full-scale

#

and the actual calculation is 10f32.powf(0.05 * db)

#

so negative values don't produce a negative amplitude or anything

#

just a smaller one

rapid hedge
rapid hedge
# slate scarab it could still benefit from the struct though

Does this look correct?


/// Constructor for taking a user-presented control value and converting it to a volume.
#[derive(Debug, Clone, Copy)]
pub(crate) struct PerceptualToVolume {
    /// When the perceptual control value is below this value, the mapping will be linear between:
    /// - 0 perceptual = 0 volume
    /// - [`Self::pivot_pos`] perceptual = [`Self::pivot_db`] volume
    ///
    /// When above this value, the mapping will be exponential between:
    /// - [`Self::pivot_pos`] perceptual = [`Self::pivot_db`] volume
    /// - 1.0 perceptual = 0 dB
    pub(crate) pivot_pos: f32,
    /// The volume to use at [`Self::volume_stop_pos`]
    pub(crate) pivot_volume: Volume,
}
impl Default for PerceptualToVolume {
    fn default() -> Self {
        Self {
            pivot_pos: 0.01,
            pivot_volume: Volume::Decibels(-50.0),
        }
    }
}

impl PerceptualToVolume {
    /// Converts a user-presented control value in \[0.0, 1.0\] to a [`Volume`].
    pub(crate) fn apply(self, perceptual: f32) -> Volume {
        if perceptual < self.pivot_pos {
            let min = 0.0_f32;
            let max = self.pivot_volume.linear();
            let t = perceptual / self.pivot_pos;
            Volume::Linear(min.lerp(max, t))
        } else {
            let min = self.pivot_volume.decibels();
            let max = 0.0;
            let t = (perceptual - self.pivot_pos) / (1.0 - self.pivot_pos);
            Volume::Decibels(min.lerp(max, t))
        }
    }
}
slate scarab
rapid hedge
slate scarab
rapid hedge
#

I'll add it to the issue in case you want to go with this version 🙂

#

I just needed something to use right now for my menu haha

#

Does this seem reasonable?

pub(crate) fn to_perceptual(self, volume: Volume) -> f32 {
    if volume.linear() <= self.pivot_volume.linear() {
        let vol = volume.linear();
        let pivot = self.pivot_volume.linear();
        let t = vol / pivot;
        t * self.pivot_pos
    } else {
        let vol = volume.decibels();
        let pivot = self.pivot_volume.decibels();
        let t = (vol - pivot) / (0.0 - pivot);
        self.pivot_pos + t * (1.0 - self.pivot_pos)
    }
}
slate scarab
#

ya this also looks correct

rapid hedge
#

@slate scarab in bevy_audio, I had tags for music and SFX. Some of my SFX (well, most of them) are spatial

#

I assume that means I need two sampler pools?

vocal dock
slate scarab
slate scarab
rapid hedge
#

Followup:
I copy-pasted the pool setup from the menu example and have this:

commands.spawn((
    Name::new("SFX audio sampler pool"),
    SamplerPool(Sfx),
    VolumeNode {
        volume: DEFAULT_VOLUME,
    },
));

But that gives me
WARN bevy_seedling::pool::queue: Queued sample "audio/sound_effects/run/Footsteps_Rock_Run_05.ogg" with effects in an effect-less pool.
So I changed my SFX pool to

commands.spawn((
    Name::new("SFX audio sampler pool"),
    SamplerPool(Sfx),
    sample_effects![SpatialBasicNode::default()],
    VolumeNode {
        volume: DEFAULT_VOLUME,
    },
));

But that gets me
ERROR bevy_seedling::pool::queue: Expected audio node in SampleEffects relationship
hmm

#

What part did I misunderstand? 😄

slate scarab
#

haha it's a good thing i made that first warning

#

idk about the second part so i'll start with the first

#

When you explicitly create a pool, like the Sfx pool, you can give it sample_effects! that act as a template for all samples played in the pool. If you try to play a sample in that pool with effects that aren't in the pool, it simply removes them (and prints the warning).

#

The second snippet should work.

slate scarab
#

i.e. the footsteps

rapid hedge
slate scarab
#

oh ya i actually did that

#

(unreleased atm)

rapid hedge
#

if you're refering to what's on main

slate scarab
#

no it's on next

rapid hedge
#

Is that on a branch?

#

Aaaah

#

the branch is called next

#

I thought you meant there's a function called next haha

#

alright

slate scarab
rapid hedge
#

That way, if the user provides the resource before the plugin, it does not get silently overwritten

slate scarab
#

oh I thought that just always inserted the Default value

rapid hedge
#

We had this conversation a while ago in the context of a new book chapter Alice was writing

rapid hedge
#

Alice corrected me

slate scarab
#

that would be much better yes

rapid hedge
#

Happy to hear I'm not the only one who didn't know that haha

rapid hedge
slate scarab
#

oh i see my in-example-comment is wrong
should be SampleEffects now
can i test my comments in my docs comments pls

rapid hedge
slate scarab
#

the linked docs also give a touch more detail

Samples played in a pool don’t need to respect the ordering or presence of effects; when a sample is queued, missing effects are inserted and the order of effects is corrected.

rapid hedge
#

But many of them are just spawn((SamplePlayer::new(handle), Sfx))

#

Here's the one from the stepping

slate scarab
rapid hedge
#
    commands.entity(entity).with_child((
        Transform::default(),
        SamplePlayer::new(sound_effect).with_volume(Volume::Linear(1.6)),
        PlaybackSettings {
            speed: 1.5,
            ..default()
        },
        sample_effects![SpatialBasicNode::default(), SpatialScale::default()],
        Sfx,
    ));
slate scarab
#

ah

#

well there it is!

#

same classic problem as children!

rapid hedge
slate scarab
#
    commands.entity(entity).with_child((
        Transform::default(),
        SamplePlayer::new(sound_effect).with_volume(Volume::Linear(1.6)),
        PlaybackSettings {
            speed: 1.5,
            ..default()
        },
        sample_effects![(SpatialBasicNode::default(), SpatialScale::default())],
        Sfx,
    ));
rapid hedge
#

Makes sense 😄

slate scarab
#

yeah so since the second entity didn't have any registered audio node, it got angy

rapid hedge
#

but hat error message is downright arcane haha

slate scarab
#

Hm, what do you think it should be?

oak walrus
#

children: famously problematic

#

What does the non-parenthesized version translate into? It feels like the macro should encapsulate the extra parentheses?

#

At least it's a first impression kind of thought

slate scarab
#

I shoe-horned in location tracking for certain things before I realized Bevy had a more integrated solution. Could we use that to help improve this?

slate scarab
rapid hedge
# slate scarab Hm, what do you think it should be?

Well, in an ideal world:
Entity {NameOrEntity} was passed a sample effect without an audio node. The offending sample effect bundle contains only a SpatialScale, but has a sibling SpatialBasicNode. Did you forget to enclose them in parenthesis?
E.g. replace sample_effects![SpatialBasicNode::default(), SpatialScale::default()] with sample_effects![(SpatialBasicNode::default(), SpatialScale::default())]

slate scarab
rapid hedge
oak walrus
slate scarab
oak walrus
#

right right right, pretty decent, nice

rapid hedge
oak walrus
#

I would have expected each effect to have all their settings within the component itself

rapid hedge
oak walrus
#

yeah that makes sense

rapid hedge
#

For an extreme example, see the Window component

#

Change detection on that is basically impossible bavy

slate scarab
#

also more importantly in this case, SpatialBasicNode is a Firewheel type -- it's the whole thing

oak walrus
#

though we do have just the thing to make granular diffing of arbitrary structures in seedling :p

slate scarab
#

and ya we could add a param to the node for overall scale, but in a way that's less elegant

rapid hedge
#

Okay, good news: Foxtrot compiles and run!
Bad news: the spatial stuff seems a bit off

#

I set panning_threshold: 1.0 to debug what's going on, and even when the fox walks to the right of me, its sound plays on my left speaker sometimes hmm

slate scarab
# oak walrus I would have expected each effect to have all their settings within the componen...

ALSO there's another thing -- every node has an associated configuration struct. This is used once when the node is created, and often sets things up like channel count (which can only be determined once when the node is created). These can be added as additional components.

sample_effects![(
    VolumeNode::default(),
    VolumeConfig {
        // add a 5-channel volume node
        channels: NonZeroChannelCount::new(5).unwrap(),
        ..Default::default(),
    },
)]

So hopefully we'll guide user's expectations towards the idea that audio nodes can have multiple meaningful components.

rapid hedge
#

I assume SpatialBasicNode uses GlobalTransform and not just Transform, right?

slate scarab
#

ya

#

I'll be honest -- I haven't tested in 3D yet. I had to adjust the coordinate system for 2D, so I'm not 100% sure it matches Bevy's coordinate system properly. Although that issue doesn't seem related to coordinate systems blobthink

rapid hedge
#

Oh, also it's not playing in my browser

slate scarab
#

Is there an error before that one?

rapid hedge
#

plenty of these

slate scarab
# rapid hedge

(I'd expect that to happen if the audio context fails to initialize.)

slate scarab
# rapid hedge

well that's symphonia for you 😅 they've since resolved that I think, but they've made no new releases

rapid hedge
#

Is there anything I can do?

#

bevy_audio uses symphonia too, right?

#

So I'm wondering why I'm not getting the same error there

slate scarab
#

well it's just a log (info), isn't it?

#

but I don't think bevy_audio uses symphonia by default for every format

rapid hedge
#

here's the actual error, sorry 😅

slate scarab
#

ya that means it either doesn't have the proper headers or it wasn't compiled with the +atomics target feature

rapid hedge
#

Oh right, headers!

#

Thanks

#

let me try again

slate scarab
#

we can mention that in the error

#

(I'll make an issue)

rapid hedge
#

Hmm still same error

#

This should be using the same compilation options as in the minimal example I did before

#

Is my browser just caching the wrong headers? hmm

#

Let me do a cargo clean too just in case

slate scarab
#

If they're present, then it's almost certainly an issue with the Wasm's target features.

rapid hedge
#

Another thing, if I do this:

    commands.spawn((
        Name::new("SFX audio sampler pool"),
        SamplerPool(Sfx),
        sample_effects![(
            SpatialBasicNode {
                panning_threshold: 1.0,
                ..default()
            },
            SpatialScale(Vec3::splat(2.0))
        )],
        VolumeNode {
            volume: DEFAULT_VOLUME,
        },
    ));
#

Does that mean that all my Sfx will "inherit" those spatial basic nodes and spatial scales?

rapid hedge
rapid hedge
#

"-Ctarget-feature=+bulk-memory,+sign-ext,+nontrapping-fptoint,+atomics"

#

(more than strictly necessary, I know)

#

and build-std = ["std", "core", "alloc", "panic_abort"]

slate scarab
rapid hedge
#

So if I don't override the effects, the scale gets cloned?

slate scarab
#

Well, it's fine if you override any other effects

#

but if you specifically override the SpatialBasicNode, that's when you need to provide stuff like that again

#

(in this case there's only one effect, so blobshrug)

rapid hedge
#

Could you take a look at my branch if you find time? My current two issues are

  • No audio on web
  • spatial audio has a weird interpretation of left and right
slate scarab
rapid hedge
slate scarab
#

Hopefully we can iron this all out so the onboarding for everyone else is very smooth

#

should be no problem

rapid hedge
#

Run it with bevy run

#

and run it in the web with bevy run web --headers="Cross-Origin-Opener-Policy:same-origin" --headers="Cross-Origin-Embedder-Policy:require-corp"

#

It uses WebGPU, so make sure you open it in a browser that supports that 😉

rapid hedge
#

At least, until the CLI is able to do additive rustflags with config.toml

slate scarab
#

btw does anyone have opinions on the name SamplerPool?

I'm specifically worried about the r in Sampler. In one sense it's a more accurate description: a SamplerPool is a pool of Sampler nodes, in which we can queue SamplePlayers.

However, I think most of the API surface surrounding samples uses Sample. SamplePlayer, SampleEffects,SamplePriority. I'm a little worried SamplerPool will be a bit of a stutter on the r. And SamplePool is honestly accurate enough imo.

rapid hedge
#

Also Sample without r happens to a verb

#

So SamplePool can wrongly be read as "Go and sample this pool"

#

Not a strong opinion tho

dusky mirage
dusky mirage
#

Hmm, now I'm second guessing my math.

Given that every doubling of distance is a 6.020599913 decrease in decibels, that means:

db = −6.020599913 * log2(distance)

And given than amplitude = 10^(db/20), that gives us:

amplitude = 10^((−6.020599913/20) * log2(distance))

converting to log base 10 gives us:

amplitude = 10^((−6.020599913/20log10(2)) * log10(distance))

and −6.020599913/20log10(2) actually equals exactly -1 so:

amplitude = 10^(-log10(distance))

using the product rule for exponents:

amplitude = (10^(log10(distance)))^-1

which simplifies nicely to:

amplitude = 1/distance

And then assuming that a distance of 1 meter is the "maximum" sound level, that gives the final answer of:

amplitude = (1/distance).min(1)

This is quite difference from my previous calculation of:

amplitude = log10(-0.03 * distance)

(which I can't quite remember exactly how I derived it).

#

I should probably just research how other game engines do it.

oak walrus
dusky mirage
#

I think the inverse square law applies to decibels, not raw amplitude. (6.02 is what you get when you apply the inverse square law for decibels).

slate scarab
#

ah so my graph might not have been taking that effect into account

oak walrus
#

The argument is over amplitude, not energy I'm pretty sure

slate scarab
#

either way, I think it would be nice to have a few models, with the most artistically useful being the default

dusky mirage
#

Yeah, we can add a parameter to switch between the different models.

dusky mirage
#

Oh, and apparently the exponential model is equivalent to the inverse model when the rolloff factor is 1.

slate scarab
#

are these the actual factor that we multiply the samples by, or do these values represent the dB?

dusky mirage
#

I think it's the actual factor that we multiply the samples by (given that the inverse model matches exactly my derivation for amplitude).

dusky mirage
rapid hedge
#

@slate scarab arrrrrrg RUSTFLAGS strikes again

#

Turns out that in Foxtrot, it comes in sneakily through one config as an env var

#

overriding my target settings in ~/.cargo/config.toml

#

Audio works in web now 🎉

slate scarab
rapid hedge
#

The only thing left is that spatial audio behaves weird

#

I'm still be very grateful if you could take a look at it 🙂

slate scarab
#

is it uh... any better? 😅 or does it need a heavier demo to cause stuttering with bevy_audio
