lightyear

[pine cape]

Did you add VisualInterpolation for the predicted projectiles?

The hashes are based on the tick + the type of all the components present on the entity when PreSpawnedPlayerObject is added

[dreamy silo]

If I assign/insert/spawn a session id to an entity as a component with a string inside containing said id, is it somehow readable by another clever user?

Any tips on how I could store session ids on clients without exposing them to the game itself? Perhaps only give the game client itself a client id, which then on the server can be associated to a session id on a db lookup. And versa.

[fervent karma]

Okay, there may actually be some types I left out, I know I forgot at least one component previously, so there may be more

[pine cape]

You can also manually compute the hash by providing a hash inside the PreSpawnedPlayerObject component, if that's easier

[pine cape]

What does that mean, without exposing to the game itself?

[fervent karma]

If the session id is on the client's computer they can read it. If you don't want them to read it, don't give it to them

[fervent karma]

I was toying with the idea of just using a monotonically increasing counter for minions and using that as the biggest source of data for the hash, but I'll try to get the proper way working first

[long marsh]

what is the intended api through which i enable visual interpolation for something? my player is definitely visually interpolated just from registering interpolation_fns for the appropriate components it seems like. so i lean towards saying, "yes, they are visually interpolated" (edit: might be a frame-pacing or camera issue instead of netcode, holup)

[dreamy silo]

Not sure what I mean but if someone had world inspector on a game in release mode, could they see the session id string by looking at a entity’s component?

[dreamy silo]

True, but could another player read it? Not that it matters I could easily secure game transactions using a session key and session id system. If key isn’t provided at attempts for exchange, the tx is denied. Not sure how complex I’d like it yet but I guess multiplayer games with should have some security bottom line and that no one can just read the key and do things on their behalf.

I could be overthinking stuff for a multiplayer game lol. Perhaps the client id associated with the correct user alone is sufficient. Just need to make the db reducer code right, where all the user’s data gets read and written from.

[fervent karma]

If you only replicate it to the one user (or maybe easier to send a message to the specific user to be sure it only goes there) it can't be read by anyone else no

But most clients will know of client ids from other players I think, so you shouldn't use that for authentication without some form of token that you only send to the specific user it belongs to

[pine cape]

Interpolation interpolates (using your registered interpolation functions) Interpolated entities by interpolating between 2 replication updates received from the server.
VisualInterpolation interpolates Predicted entities (also using your registered interpolation functions) to interpolate the FixedUpdate components across the PostUpdate schedule. So yes it's a framepacing issue. Maybe there should be a way to do this automatically for all Predicted entities by setting .add_visual_interpolation() on the registry.

This will 100% fix your jittering artifacts

For now you have to add this plugin: https://github.com/cBournhonesque/lightyear/blob/main/examples/fps/src/renderer.rs#L25
and then add this component on the entity: https://github.com/cBournhonesque/lightyear/blob/main/examples/fps/src/renderer.rs#L144

[fervent karma]

But I wouldn't really bother with considering security to begin with honestly

[dreamy silo]

Absolutely agree, I’ll boil it down to just client ids first. Just wanna make sure I don’t make it too hard to implement later if I need to

I don’t know how hackable netcode is lol

[fervent karma]

In theory it should be pretty simple to tack on a token system at a later stage, but security is also notoriously complicated, so who knows

[dreamy silo]

Will probably never get to that point unless game actually is fun and people wanna get ahead. I’ll just have it in mind if I think it could happen in any case

[pine cape]

lightyear uses the netcode protocol for connections which is already 100% secure. You just need a secure way (for example https) to send a private ConnectToken to a user

This example (https://github.com/cBournhonesque/lightyear/tree/main/examples/auth) shows how to do that

[dreamy silo]

Im currently writing my database columns together with their reducers. Just tryna think if there’s anything obvious I’m missing in regards to security

[dreamy silo]

You’re right. Netcode makes it pretty secure already.

[dreamy silo]

Nice, exactly what I need

[long marsh]

huh. i turned my tickrate down so i could see better. setting this up doesn't appear to fix the jitter. visual interp is definitely enabled, because it looks / feels different when i toggle the plugin on/off.

some kind of ordering issue maybe?

[pine cape]

Maybe you also have avian interpolation enabled which is messing it up?
Also is your pos/rot -> transform enabled? Otherwise I don't really know what it is

[long marsh]

already had both of those things correct. darn. i'll keep spinning on it

seems like it works great on the character example and that's where i stole half my setup from so

oh the answer is literally explained in a comment in that example
trigger_change_detection: true,

[long marsh]

now enabling VisualInterpolation causes some duplicating / smearing during rollbacks, especially at a lower tickrate. hrm

butter smooth in the happy case tho, very lovely

[pine cape]

are you running VisualInterpolation on Position or on Transform?

[long marsh]

Transform

[pine cape]

I wonder why you need trigger_change_detection; I guess because you need to somehow propagate the transform to GlobalTransform?

[pine cape]

also that's weird; the rollback should leave the Time<Fixed>.overstep() exactly the same, so the visual interpolation shouldn't affect anything

[long marsh]

it could technically be from prespawns instead of rollbacks, those two things just happen to be one in the same for me right now lol

[tropic jackal]

Is this the correct syntax for receiving a message (server-side)?

pub fn foo(
    mut message: EventReader<MessageEvent<MyMessage>>,
) {
    for _ in message.read() {
        // Do something...
    }
}

[long marsh]

hmm i can't even get vis interp for remote players working in the avian character example

[pine cape]

in lightyear 0.19, yes

[pine cape]

that's not visual interpolation issue; looks like there's constant rollbacks

[long marsh]

was a bad example for me to use to debug anyway, that example's predicting remote players

[pine cape]

yeah it only works with enough input delay to cover the RTT

at which point it might be worth simply interpolating everything (including current player)

hm even with a lot of input delay there's some jitter, i'm not sure why...

[unkempt sedge]

Constant ccollision with static floor collider perhaps?

[long marsh]

hmm, by default, on main, when do the avian position to transform sync systems run relative to the (network) interp systems?

seems like the former in PostUpdate, the latter in Update, which would make sense... edit: ohh, no avian sync uses the same schedule as PhysicsPlugins by default. so it's only syncing on fixed possibly

[pine cape]

You don't need to run physics for interpolated entities

And visual interpolation should already be ordered correctly with respect to avian systems

[long marsh]

yeah but i am syncing position and rotation over the network. so network interpolation gets applied to those values. when do the interpolated positions get sync'd to the transform for display?

[pine cape]

Ah yes I made a custom sync system that is a copy of avians but also works for entities that are not rigid body

[long marsh]

yeah that did it. thanks. (edit: should such a system be built in?)

i did hit one other snag. the real thing that fixed my problem was manually setting an InterpolationConfig. the default one has send_interval_ratio: 2.0 - that means it buffers two ticks, yeah? seems to...not do that. i can only get something working with min_delay

[dreamy silo]

same issue here when trying to run a second client on my windows 11 machine after spinning up the server. its def because the exe that cargo run builds and runs is already occupied by the first client/server. classic case of windows not allowing two programs with the exact same filepath, name and file extension to run at the same time?

not really a concern, server wont run on the same machine as the client anyways.

[fervent karma]

Is there a way to receive messages from the client to the server on that same client? My use-case is trying to avoid having to duplicate implementation, so I would love to be able to run the same logic on the server and client (one example is that I use a message for spawning minions, and currently I send a message to the server, but on the client I just create it immediately). This is probably causing them to be created on different ticks (which is probably why I'm struggling to get PreSpawning to work actually), but maybe if there was a way to combine the message logic it would be easier to get them running in the same tick on both the server and client?

[pine cape]

No it buffers components for 2 * send_interval; if your server sends updates every 100ms, it will buffer for 200ms to guarantee that we have 2 components to interpolate against. Now that I think 2 * send_interval is not required, something like 1.1 might work.
Are you sure you have send_interval set to something?

[pine cape]

I think you can specify a --target so that the exe has a different path

[pine cape]

Yes messages between client/server within the same App should work fine

[fervent karma]

I mean like a remote Client sends a message to the Server to spawn a "minion", but now I want the client to prespawn the minion, so I need to somehow capture that message on the client that sent it.
Also just to confirm, but messages arrive on the server in the same tick as they are sent from the Client, right?

[pine cape]

Normally you would have some game Event that runs in both the client and the server that you would react to in order to spawn a PreSpawn entity

how come the client knows to spawn a minion but not the server?

[fervent karma]

I guess I can test this by printing out the tick that the minions are spawned actually. But my true goal is to have a single system that I can run on both the server and client that accepts my Message struct and handles it

Oooh I just realized my minions don't work with PreSpawning because to make it easy for myself I didn't add a Name in the client one, so the components are indeed different...

Actually I think I confused myself, because spawning minions is handled with the Input, so that's already good I guess. But I have some other logic that is handled through Messages, specifically updating the target location for minions to move to, that's a good chunk of logic I'd want to consolidate, and it'll obviously grow as the game grows

[pine cape]

I think the tools you can use are:

• PreSpawn: spawn an entity on the server and on the predicted timeline on the client. You need to run the same system in both client and server.
• PrePredicted: spawn an entity on the predicted timeline on the client, and give the authority to the server. This is used when only the client knows about the entity that needs to be spawned, i.e. you cannot run the same system in both client and server

In your case of the client 'spawning' a minion, I think you need PrePredicted, not PreSpawn

(the naming is confusing but I don't have any better ideas)

[fervent karma]

So I should make my message hold the event and then just emit the event on the server-side's message reading system? And then both client&server will have the same system that reacts to the event? That does seem easy to implement and easier to reason about

Ooh, I hadn't heard of PrePredicted before, I'll give that a shot

[pine cape]

It's not super straightforward:

• the client spawns a PrePredicted entity: https://github.com/cBournhonesque/lightyear/blob/main/examples/avian_physics/src/protocol.rs#L52
• the server reacts on receiving the entity replicated from the client and adds its own Replication component: https://github.com/cBournhonesque/lightyear/blob/main/examples/avian_physics/src/server.rs#L114
  • maybe the query could filter based on PrePredicted instead of InitialReplicated

[long marsh]

setting server_replication_send_interval explicitly makes send_interval_ratio work, yep.

this means the combination of the default SharedConfig (send_interval = 0) and the default InterpolationConfig (min_delay = 0, send_interval_ratio = 2) will always result in a configuration that can't interpolate effectively? confusing

[pine cape]

you're right that's pretty bad...

[unkempt sedge]

wow

such a cool bug check it out

My bullet logic only gets rollbacks when we add player base velocity into it

[long marsh]

on a single entity, can i take a component that has add_prediction(ComponentSyncMode::Full), but then stop syncing it? for example with a projectile, i can deterministically predict it's position perfectly once the server confirms its location once, i don't need the confirmed entity's position sync'd after that

ComponentSyncMode::Once is basically the behavior i want, but i want it at the entity level. i thought e.g. ReplicateOnceComponent::<Position> might do it, but it seems like the client is still trying to sync the confirmed entity's Position that is no longer being updated by the server when i do that

[pine cape]

I don't think that's possible right now; would being able to override the ComponentSyncMode on the entity level work?

[long marsh]

yeah i think that's sufficient

[pine cape]

And how are you stopping the replication btw? Are you just removing Replicating

[long marsh]

mmm mostly trying to get it working with ReplicateOnce because i need it to be per-component; i still want the replication (server-issued despawn, for example)

[long marsh]

it’s kinda awkward in the case of remote clients. i really don’t want to replicate position data for projectiles, but if if the remote clients’ projectiles are in the predicted timeline and the remote players are in the interpolated one, it is gonna look bad. like they are shot from positions the shooter hasn’t reached yet

i can’t just stop replicating projectile position data and then set predicted to true for all projectiles for all clients. remote clients’ projectiles need to be correctly fired in the interpolated timeline. their position data, however, still needs to be extrapolated from that point on

[pine cape]

But if the projectile's trajectory is deterministic, why not PreSpawn it on both client and server then?

• then the projectile moves via physics (or just linear velocity) on the client, and gets despawned on collision, etc.
• damage computation are still done exclusively on the server
  that's what i do

[long marsh]

struggling to reason about prespawning something from a remote player. you already have the confirmed entity; what sense does it make to do prespawning and entity matching at that point?

and that still puts the projectile in the predicted timeline but i am displaying enemy players in the interpolated one, which is gonna look disjointed

[unkempt sedge]

I tought that what you usually did was transfer the ownership of prespawned client entities to server?

[unkempt sedge]

is your game fast paced? Or more slow paced just curious

[pine cape]

ah i thought your remote players were also predicted. Prespawning would only make sense if your remote players are predicted

Why does ReplicateOnceComponent::<Position> not work? Does your confirmed entity's Position still get updated somehow?

[long marsh]

it DOESNT get updated which causes infinite rollbacks for the shooter

the other clients are fine when i do that, minus the projectile not being visually interpolated because it’s neither predicted or network interpolated now

[long marsh]

well, neither really. i am limit testing the design space to see what i can get away with. but probably slower paced overall / i will make the tradeoffs that slower paced games do

very concerned about bandwidth primarily

[pine cape]

You're predicting your own player and interpolating other players?

[long marsh]

correct

[pine cape]

Option 1

• client 1 presses Fire and spawns a local bullet
• server receives the input and spawns a non-replicated bullet
  • The client/server bullets should be fired from exactly the same spot thanks to prediction on the client 1's player
• server sends a message to other clients saying that C1 fired a bullet, and those clients fire a bullet upon receipt of the message.

The issue is that there's no guarantee that the remote player will fire the bullet from the interpolated character's position.

Option 2:

• client 1 presses Fire and spawns a prespawned bullet.
• server spawns prespawned bullet at the same time and adds Replicate with Predicted = C1, Interpolated = AllExceptC1. Also ReplicateOnceComponent::<Position>
• You add ComponentSyncMode::<Position> = Once on the client 1 (either on the Confirmed or Predicted entity, to be determined)
• the Position is only replicated once to C1, but since you have ComponentSyncMode::<Position> on the C1's entity we don't check for rollbacks based on Position.
• the bullet is spawned at the right interpolated position on the remote client C1, but it doesn't receive any more updates. You run a system on clients that still moves interpolated bullets so that you can keep moving bullets without any server updates

Option 3:

• same as option 2 but you write every predicted position in the PredictedHistory to avoid rollbacks?
• Theoretically this is not required because the way rollback works is that we only check for rollback if we received any update for any entity in the ReplicationGroup. So even if you don't send any more replication update for a bullet we would not check for rollback at all anymore.

So it looks like a combination of:

• ReplicateOnce<Position> on the server
• on the client, run movement systems for interpolated entities too

I will still open an issue for this because the current solutions are definitely not ideal, it would be great to have more flexibility on how Prediction/Interpolation works

[long marsh]

i had considered option 1, the biggest problems being

1. i am sending a message to do replication which is a primary feature of lightyear, pretty dirty
2. projectile should be in the interpolated timeline (message should say what tick to fire on) but since it’s not network interpolated via lightyear it doesn’t get visually interpolated

option 2 is my preference right now just because i know sync mode: once works. but again, i can’t use lightyear’s visual interpolation here without faking the network updates, because the objects aren’t in the predicted timeline (despite their positions being extrapolated)

option 3 makes me wonder if i have a bug, though? when i do that, the shooter’s projectiles are fine until the prespawned entity confirms. then the location of the projectile forever bounces back and forth between the first confirmed location and the first predicted one after that. constantly trying to roll back to the position where the prespawned entity was confirmed

the history faking is non trivial too, seemingly. i need to dissect some lightyear code to figure out what order of operations i have to do.

[pine cape]

For option 1: you would then move the remote-client bullet yourself on the client, you don't need Interpolation. VisualInterpolation is independent from replication, it can be applied to any component that gets updated in FixedUpdate. You can totally use visual interpolation without receiving network updates

I think option 3 should work in your use case, i would need more details to see why it doesn't work. Do you have a branch?

[long marsh]

idk why i thought Predicted was a requirement for vis interp, great if i can just add it to whatever

i'll set something up in a sec

[long marsh]

once branch in my repo

i am guessing based on your wording that i am causing problems by having one replication group per client / that client's entities? so that group still gets updates, even if that individual object does not.

so i tried giving each projectile a dedicated replication group, which has the hilarious behavior of all future projectiles shooting an additional projectile from the spawn location of every past projectile that hasn't despawned yet.

[pine cape]

That's a possibility, but why are any of your projectiles receiving a replication update? What other component besides Position is receiving updates?

[long marsh]

well im saying they were in the same group as the player thus the problem, but giving them their own group causes rollbacks

because of prespawn maybe?

[pine cape]

Maybe, if you enable debug logs it could tell you which component is causing the rollback

[long marsh]

ooh okay i was on the wrong track at first, here's something i think

i am getting rollbacks when the spawn command for my projectile is split into two messages.

here is an example of where the spawn message fit in one message

EntityActionsMessage { sequence_id: MessageId(0), group_id:
ReplicationGroupId(12114142938702618892), actions: [(34v1#4294967330,
EntityActions { spawn: Spawn, insert: [b"\r", b"\n",
b"\x05\xc6\x17\xebA\0\0\0\x80\xd8\"\xc1\xc0", b"\x04d\0\x9a\x99\xcdA",
b"\x06\xd0\xeb\x89?gff@e\t%@", b"\x07\0\0\0\0\0\0\0\0\0\0\0\0\0\0\x80?",
b"\x08\x01\xfd\x0c!\xad\xbb\xd1\x14\x1e\xa8"], remove: [], updates: [] })] }

all good. no rollback. there is no other message for tha treplication group.

here is an example of where the spawn message was split into two:

EntityActionsMessage { sequence_id: MessageId(0), group_id:
ReplicationGroupId(12114142938702618943), actions: [(35v1#4294967331,
EntityActions { spawn: Spawn, insert: [b"\r", b"\n",
b"\x05\x17\x17\x94\xc1\0\0\0\x80\xf8\xdc\xbc\xc1", b"\x04d\0\x8f\xc2\xd5A",
b"\x06\x7f\xf6\x9d\xbefff@V\xb4IA", b"\x08\x01\xfd?!\xad\xbb\xd1\x14\x1e\xa8"],
remove: [], updates: [] })] }

// The prespawned entity’s predicted entity is created and sync'd here, before this next message comes in.

EntityActionsMessage { sequence_id: MessageId(1), group_id:
ReplicationGroupId(12114142938702618943), actions: [(35v1#4294967331,
EntityActions { spawn: None, insert: [b"\x07\0\0\0\0\0\0\0\0\0\0\0\0\0\0\x80?"],
remove: [], updates: [] })] }

THAT causes a rollback. the insert, which is really just completing the original spawn command, is causing the rollback.

[pine cape]

Do you know what that extra component is?

[long marsh]

golly. yes it is because of that specific component. i wasn't explicitly specifying a Rotation on the server-spawned entity, merely relying on it to be passively added from required components of the other physics components

need to add it explicitly right when i spawn the entity

i might be good now 👀

[pine cape]

Hm normally required components should add it at thr same time

But avian doesn't use required components for rotation I believe

I think they have specific systems to add missing components

[long marsh]

does rolling back to correct one object roll back the entire client simulation? seems like my primary problem now is that if any rollback happens (from a natural cause like cpu lag, packet loss, switching too quick between windows, etc), any projectile in flight gets reset to its starting position

[unkempt sedge]

Question, why we disable the colliderhierarchyplugin, when utilizing avian? Just curious, I guess is something with how the propagation works

[pine cape]

You don't need to disable it; i just disabled it because i didn't need the plugin

[pine cape]

it rollsback only Predicted entities. Maybe your solution would be to:

• spawn bullet for the Predicted client (non-prespawn)
• spawn replicated bullet with interpolation AllExceptSingle(client) on the server

Sorry that this hasn't been straightforward!

[long marsh]

equally sorry i’m causing so much trouble 😅

so if i spawn the predicted bullet and don’t replicate it to the shooter at all, it LOOKS fine, but the projectile can’t get server-sent despawn updates because i don’t replicate it

if i do replicate it, but don’t use prespawn, i just get projectile duplication. or if i don’t fire it on the client at all, i get firing lag

maybe per-entity sync mode is still gonna be the way 🤔 just using ReplicateOnce (now that i fixed all my other bugs) is good enough for me to move forward with experimenting though.

[pine cape]

but the projectile can’t get server-sent despawn updates because i don’t replicate it
that might be fine, because i assume you would still run collision detection on the client for projectile VFXs

Another solution might be to remove the Predicted component on the pre-spawned bullet to stop it from being affected by rollbacks, but that's not super straightforward either.. Maybe a DisableRollback component could work?

Per-entity sync mode is not super straightforward because currently I add systems based on the component sync mode.
So the rollback systems are only added for the ComponentSyncMode::FULL components.
Being able to change syncmode means that I would have to add rollback systems for all replicated components, and then apply runtime filtering inside the system based on the OverrideSyncMode component.
Maybe just allowing overriding from Full->Simple or Full->Once but not the other directions would work

[long marsh]

DisableRollback would be sufficient for me, yes. on the server side this is fully handled by ReplicateOnce already

i don’t want to run fully predicted hit confirms on the client like that. with the interpolated other players it’s gonna feel bad. could replicate the impact independently and treat it as an event from which to manually despawn the projectile on the client i guess

or i suppose i could lag comp

[pine cape]

If you use interpolated enemies, you would lag comp on the server for accurate hit detection; but on the client you wouldn't do any lag comp, you would show VFX on actual collisions between predicted/interpolated

[long marsh]

yeah that’s what i’m saying. realistically since comp isn’t perfect i’d probably do a small local vfx and then a big confirmed vfx+sfx

but i am hoping to avoid lag comp entirely (or to have very generous / lazy comp) with big slow projectiles with generous hit boxes and a decent connection. but i truly don’t know if that is tunable into something that feels good or not. that’s part of the whole exercise im doing here i guess

[unkempt sedge]

Has anyone ever encountered an issue where sometimes when a client connect, one gets a massive amount of rollbacks? It seens to be correlated to system ordering, as it sometimes occurs and it doesnt. The issue is truly very crazy, as the cause is totally a mistery to me dont even know how to start debuggin

It give me this panic from time to time no idea why
overflow when subtracting durations
Encountered a panic in system lightyear::client::prediction::rollback::run_rollback!

[stone osprey]

Does this crate expose an abstraction to connect to sockets over either normal TCP or websockets (I want to use the former for native builds and the latter for web builds)? I added auth based on the auth example, but tokio's net feature doesn't compile for wasm.

Oh, I think PacketSender and PacketReceiver is what I need

[stone osprey]

Is there a way to get a WebSocketClientSocket? WebSocketClientSocketBuild is pub(crate)

[pine cape]

You can take a look at https://github.com/cBournhonesque/lightyear/blob/bevy-main-simplify-replicate/examples/common/src/settings.rs#L404-L404 for how to use the various transports, including websockets

WebTransport doesn't fix your usecase?

[pine cape]

do you have the exact line of the panic?

[unkempt sedge]

Unfortunately closed the terminal. I was just wondering, how would one go about fixing rollback loops issues? Like what metric can give me the component that is the root cause of those rollbacks. Perhaps them I can at least know where to start

[pine cape]

If you have visualizer feature enabled, type 'rollback' to find graphs that will tell you which components are the cause of the rollback

[unkempt sedge]

great thanks

hmm it seens the rollback loop overcharges my machine, any diagnostics info that may be usefull here?

the visualizer becomes very stale

[long marsh]

did you try just turning on debug logging and writing everything to a file then searching for “rollback”? that’s how i debugged mine, going step by step through exactly what happened. default debug logs seemed sufficient to suss it out

[pine cape]

yep, or lightyear::client::prediction::rollback=debug

[lyric badge]

hi im having some trouble connecting with the client when the host is in a different machine
im connecting using Netcode, and the server is set to localhost on the port 5000

pub fn get_server_net(config_data: &ConfigData) -> lightyear::prelude::server::NetConfig {
    NetConfig::Netcode {
        config: server::config::NetcodeConfig {
            private_key: config_data.private_key,
            protocol_id: PROTOCOL_ID,
            ..default()
        },
        io: IoConfig::from_transport(ServerTransport::UdpSocket(SocketAddr::new(IpAddr::V4(config_data.server_ip), config_data.server_port))),
    }
}

pub fn get_client_net(config_data: &ConfigData) -> lightyear::prelude::client::NetConfig {
    lightyear::prelude::client::NetConfig::Netcode {
        auth: Authentication::Manual {
            server_addr: SocketAddr::new(IpAddr::V4(config_data.server_ip), config_data.server_port),
            client_id: config_data.client_id,
            private_key: config_data.private_key,
            protocol_id: PROTOCOL_ID,
        },
    io: lightyear::prelude::client::IoConfig::from_transport(ClientTransport::UdpSocket(SocketAddr::new(IpAddr::V4(config_data.server_ip), config_data.server_port))),
        config: NetcodeConfig::default(),
    }
}

to connect from the client i use the actual ip and the same port
is that configuration correct?

[pine cape]

Set the server to 0.0.0.0 instead of localhost

[lyric badge]

how come?

im guessing that sets it to its actual ip?

hm

didnt know that

[pine cape]

It makes the kernel choose an IP address for routing

i'm not too clear on the details

[lyric badge]

okok

regardless, thank you

[fervent karma]

The general gist is that picking the ip for the socket is a local OS concept completely unrelated to your public ip

[long marsh]

when you choose an ip you are implicitly chosing a network interface. when you choose 127.0.0.1 you are choosing the loopback interface which only accepts connections originating from the same machine.

[stone osprey]

This is for configuring what lightyear uses, though. My problem is getting a token from the server on web, so this is before lightyear connects. Since lightyear already abstracts over socket types, I want to just use the same abstractions that it uses.

[pine cape]

Ah i see; no lightyear doesn't provide this; you can make a PR to make WebSocketClientSocketBuilder pub, but the Transports currently have some extra stuff that is only needed by lightyear

[lyric badge]

so i tried some things with 0.0.0.0, couldnt get it to work, im pretty sure my config is just wrong though, i cant connect on 127.0.0.1 after i made some changes to test it on different machines, could someone confirm if its correct?

[stone osprey]

Ok, I will soon, thanks

[long marsh]

is your client listening on 0.0.0.0 too?

[lyric badge]

yes, i tried it with both the server and client on my machine

[long marsh]

youre on LAN?

like not remote over the internet, just local network

[lyric badge]

yes

[long marsh]

ok so the true correct setup is

1. client listen address is the client host’s local IP as assigned by the router
2. server address (on the client) and server listen address are both the server host’s local IP as assigned by the router

you can usually cheat both listen addresses by choosing 0.0.0.0, which is why you’re getting that advice. it accepts connections on all network interfaces

[lyric badge]

is the local ip the same as the public ip?

[long marsh]

nope it’s distinct

if you list network interfaces for your OS it should be listed in there

[lyric badge]

and this setup wouldnt work when doing it over the internet, right?

[long marsh]

over the internet you need the public IP, right

but you’ll still listen on the local IPs, the router uses those IPs to know which computer to forward to

that’s why you have to set up port forwarding in your router when you expose something to the internet from home. the router has to know, when a connection comes in on a certain port, which computer on the local network do i send it to?

once you are production deployed in some cloud it’ll be different again probably, depending on your setup

[lyric badge]

ok i think i understand

well, i understand the local ip and public ip + port forwarding

[lyric badge]

just want to make sure on this one, the host can do 0.0.0.0, but the client has to use their public ip
but if i wanted to test it locally i can do 0.0.0.0 on both?

[pine cape]

The server specifies 0.0.0.0 for its own server_addr, but the client needs to use the server's public ip as server_addr.
Same for client

[lyric badge]

sorry what do you mean when you say "Same for the client"?

i understand the first part, i think
in lightyear it would translate to the server NetConfig io using 0.0.0.0 and the client NetConfig auth using the server's public ip
do you mean that the client NetConfig should also be 0.0.0.0?

[pine cape]

I think the client should specify their own address as 0.0.0.0, but the server would specify the client-addr as public_ip:port

[long marsh]

this is right yeah. the address of the UdpSocket you pass to client_config.net.io is the address upon which the client will listen. that's the one that should be 0.0.0.0, because you want to listen on all network interfaces

[lyric badge]

okok

thank you guys for your patience

ill try it out tomorrow

🫡

[stone osprey]

I migrated to main and the player can't move anymore. There aren't any new warnings/errors in the logs

[pine cape]

are you using leafwing inputs or native?

[stone osprey]

native

I'm checking to see if the same issue happens in the examples, but I have to figure out why steamworks isn't compiling

[pine cape]

simple_box works fine in main

[unkempt sedge]

our building system is being held back because version 0.19, does not support avian 0.2.1. I saw it had something to do with "issues" what they might be? Perhaps we can help

[stone osprey]

Ok, sometimes when I run my game, the player can move. Attacking causes the player to despawn, though, which I suspect is an issue with hierarchy stuff, bc that spawns an attack that's a child of the player

I think I'll just make my changes off 0.19 for now

[pine cape]

hm i'm unsure of what could be wrong

[pine cape]

Here's the issue I created: https://github.com/Jondolf/avian/issues/643
there seems to be a problem with how the ColliderAABB is computed

The way you can test it is use avian 0.2.1 and run the fps example. The ColliderAABB for lag compensation are in the wrong position

[sly ibex]

Super dumb question, but what crates do I need to import to make the simple startup work? Downloading the full repo works fine, but recreating it throws six or so errors

Sorry if this is a dumb question 😓

[unkempt sedge]

no such thingy as dumb questions

[unkempt sedge]

https://github.com/Sirmadeira/mre_scene/blob/main/Cargo.toml

Just chec my mre cargo should be more than enough to get you starrted

[sly ibex]

trust i got thousands of them 😭

also it worked, tyvm king!

[unkempt sedge]

oh my jebus

[pine cape]

that's fine, you just have higher jitter so you're receiving old updates

[wet kelp]

i'm beeing stupid right now. havent had this problem on an older version:
When running in HostServer mode, the client connection needs to be of type Local

i'm using the build_client_plugin() and build_server_plugin() from the simple box example.

alright, discordd was eating parts of my message, the when running in hostServer mode.... is the panic message i'm getting when trygin to connect to the server i started before in the same app

[stone osprey]

I'm having to make a lot of internals public, and it's kind of contrived to make this work for my use case, so I think I'll just write my own websocket stuff for auth

[primal cargo]

What's the best way to let a server send replication updates to a client, for the purposes of spawning an entity, but give the client authority such that it can despawn the entity and replicate that update to the server? I tried giving the entity client authority on the server side (on initial spawn), but then the client never receives the spawn replication update from the server

[pine cape]

I don't think that's possible. You could have the client send a message to the server to despawn the entity

[primal cargo]

Hmm, okay. I'm thinking of attaching some sort of ID to each of these entities through the server to solve this. Is there a better way of telling the server which entity to despawn?

[long marsh]

implement MapEntities for the message type and send the Entity directly

[primal cargo]

Thanks!

[unique plover]

I'm currently splitting off my complex sim systems so they're not running in rollback and I noticed that gizmos are cleared out during rollback and are not rendered when set during the regular FixedUpdate. It results in gizmos flickering when some rollbacks occur. I can definitely set the gizmos during rollback too to fix this issue, or swap so I'm not using gizmos for these systems (since they'll be actual rendered models in the future), but this does point to a complex issue of Bevy and library provided FixedUpdate interactions with the rollback of the entirety of FixedMain. I'm wondering if a configurable rollback schedule might be better, but I think that would have to happen during one of the fixed schedules and would have to ignore Bevy's fixed loop when more than one FixedMain needs to happen in a frame.

Ideally for me rollback systems are "opt in"

[unique plover]

I could probably solve this with my own implementation of a fixed sim schedule, but that seems like overkill.

[unique plover]

Make sure you use .add_map_enitites() in your protocol when you .register_message

[sonic citrus]

I'm using 0.19.0, and I get this error when sending a message. This seems like an oversight, since lightyear now uses varints for encoding fragments?

[pine cape]

Yes it probably is, there might be an old check on the number of fragments that I forgot to remove

[sonic citrus]

looks like it

also thinking about it

if FragmentIndex is a u64, how does this work on platforms where usize is 32 bit?

[pine cape]

I still think that FixedUpdate should be used for rollback. A user would use fixed update when they need their system to react precisely to inputs or when they need to correctly match the simulation time. In my experience most fixedUpdate systems need to be rolled back.
Ah I experienced the flickering as well and was wondering what was causing it, you think it's due to gizmos?

[sonic citrus]

would it be possible to release a 0.19.1 to fix this?

[unique plover]

Definitley FixedMain should remain the default for rollbacks, but I'm thinking a configurable option at plugin build time would help.

Gizmos clear during FixedFirst and then collected during FixedLast, so during a rollback if you are not setting a gizmo then it will be cleared. I don't know why, but the final FixedUpdate after rollback doesn't refresh the gizmo for me.
https://github.com/bevyengine/bevy/blob/main/crates/bevy_gizmos/src/lib.rs#L273

[pine cape]

Sure can you make a PR? I won't have time immediately but I can do it by sunday

[pine cape]

Ah, yes I can try to make it configurable. But then the update_tick system would also have to be part of the new configurable scheduke

[unique plover]

I can try a PR early next week if you have other priorities.

Should I target main or bevy-main?

[pine cape]

Maybe a Rollback schedule could be added which runs roughly at the same time as FixedUpdate?

Main should work

[unique plover]

I think letting the user decide (optionally) where to put the schedule is the best setup personally, but yeah parallelizing the rollback while FixedMain goes through its own loop could be a solid architecture for me.

[unkempt sedge]

This is used to filter out excessive tracing correct?

[unkempt sedge]

Well according to the logs, when my client disconnects and quickly reconnects it seens server didnt have the time to despawn it is old entities. Which causes rollbacks right on the get go. Because he still tries to replicate his previous entitties to client itself, this was my bug I wonder how I could fix it, guess I just need to wait or make despawn more immediate as server despawn seens very slow for some reason

the bug might also occur when one, has network-relevance manager enabled with replicate target and sync target all entities. As it seen that the sync target component applies it is logic before the room manager (sometimes, system order non defined) actually applies, causing rollback as he will receive replicate from entitites in other rooms yet he has no information on them

Guess the "get started" system from sync target is a little faster than network relevance manager, which makes sense when I come to think of it

The fix make replication targers unique to client id, as room manager logic self increases both sync target and replication target

Which is appreciated

[pine cape]

Can you open an issue?

[unkempt sedge]

I will first refactor my mre to check my theory and a continous sample, but from what I see yes it occurs first, in my bullet logic, when you make them consider rooms. You get constant "trying to despawn entity error" even tho that bullet shouldnt even be on that room.

[pine cape]

Ah I see, yes a mre would be helpful!

[long marsh]

i have some non-sync’d predicted projectiles with VisualInterpolation<Transform>.

when those projectiles undergo a Position misprediction as they spawn (since they were not prespawned), the correction function is properly applying the correction to Position.

i cannot, however figure out when to extract that corrected Position to Transform in a way that does not break the Visual Interp somehow. any thoughts? it’d be easy if corrections were applied in the fixed schedule, but looks like they get updated in PostUpdate

like, in the normal, non-corrected scenario, i don’t need to extract those positions manually at all, it just works. but the corrections are getting swallowed by vis interp somewhere if i don’t manually copy them over

[pine cape]

You're right

you might have to run a sync system (from pos to transform) again in PostUpdate, after correction

https://github.com/cBournhonesque/lightyear/blob/main/lightyear%2Fsrc%2Fclient%2Fprediction%2Fplugin.rs#L450

And i guess we could either disable visual interpolation if the component is being corrected

Or order correction to happen after visual interpolation

[wet kelp]

how can i change the netcode to be local? i'm trying to understand the lobby example, but having a hard time following the "common" folder 🙂

[wet kelp]

alright, i got it.... lol

[wicked tulip]

vast improvements on current main compared to the 0.19 release.

A lot less jitter, even with cubes and jumping it feels really good when predicted.

Still the interpolated other player seems to be jittery when changing direction under the provided networking conditions:

latency_ms: 50,
jitter_ms: 1,
packet_loss: 0.03,

Is there a way to modify how the interpolation of other controlled entities work?

Like adding a little bit more lag but having it smoother for the interpolation?

[long marsh]

there is an InterpolationConfig https://github.com/cBournhonesque/lightyear/blob/d7ff0b0ead980b0ef4b6cb69ec80f1b3fdc3c5c2/lightyear/src/client/interpolation/plugin.rs#L60

personally i am using a min_delay of the length of 1 tick + my max expected jitter, and that works well. i set send_interval_ratio to 0. worth playing around with tho

[long marsh]

turns out i was already doing this, and it was working, before i asked. i just had a different bug that made it look like it wasn't 🥲 awkward little gotcha there though

hm

when the predicted projectile fires on the remote player's screen (right player shoots on the top screen), a rollback happens since there was no prespawned projectile. this (correct) rollback causes the predicted player (top screen, left) to jitter even though they were correctly predicted.

the addional jitter is there even when i disable all my interpolation and correction copying. it's like the rollback of the predicted timeline is spitting out a slightly different result for the player. struggling to understand how it could be different though..

[pine cape]

Can you open issues for this? I'm at a ski trip now so I might forget about them when I come back if they're not on the github

[pine cape]

Yes I think in most cases you would to limit your bandwidth by sending updates less frequently

[long marsh]

oh yes i just wanted your intuition to see where i should look before i went to the trouble of making a proper repro

realize it's a pretty vague ask

[pine cape]

But yes that's strange. It's expected that all predicted entities are rolled back when a rollback happens, but I don't know why they would jitter if they were correctly predicted

You would need to log the values for each tick to see if they are really diverging

[long marsh]

that's the thing, i did, they are. lol

it's by 2 ticks, but i think my logging has a system ordering issue and it's actually by one tick

ill fiddle with an example and see if i can repro

[pine cape]

Do you use gizmos? Someone was saying that rollbacks can cause them to flicker

[long marsh]

not in this case but i definitely have that issue when i do. is that why the box that encloses the spaceships example constantly flickers while a remote player is moving?

[pine cape]

I think so yes

[unkempt sedge]

Hmm I believe in that case it is correlated to collisions rollbacks

As in sole clients that doesnt occur

Hmm interesting just found out that if a bullet has a different rigidbody definition than my player rigidbody. When I have a bullet rollback it expects lineardamping on it, something solely applied on my character physical rigid body

man debug has truly unlocked some good shit

[molten socket]

I'm trying to add a singleplayer mode in my game. I chose to use the LocalChannel client transport with Netcode.
But when I simulate a crash from the internal server app or even when I stop the server normally (commands.stop_server();), the client spams error in the console (even after exceeding client_timeout_secs):

2025-02-16T21:23:24.153303Z ERROR lightyear::connection::netcode::client::connection: error updating netcode client: Transport(Io(Custom { kind: Other, error: "error receiving packet: Disconnected" }))
2025-02-16T21:23:24.153407Z ERROR lightyear::client::networking: Error updating netcode: netcode error: error receiving packet: Disconnected
2025-02-16T21:23:24.153958Z ERROR lightyear::client::networking: Error sending packet: netcode error: error sending packet

Switching to UdpSocket transport don't cause these problems (even after a crash from the server)

[pine cape]

LocalChannel, so 2 apps in the same process? Could you please open an issue?

[molten socket]

Yes 2 apps in the same process. The internal server app is launched in a seperate thread

https://github.com/cBournhonesque/lightyear/issues/905

[long marsh]

i think client error handling might just need some love in general

[long marsh]

it was disguised by other bugs, but this ultimately was due to my correction-copying system. idk why the player is getting corrected tho. logs are fine, rollback simulation sync is fine with previous frames.

excluding the player from the position_to_transforms_after_correction system fixes it, so that must be the problem. but if there weren't any mispredictions, why was there a correction?

overall it is fine because i am treating "predicted and fully replicated" differently from "predicted and fully extrapolated", so i'll just only extract corrections for the latter...just can't clock why the player is getting corrected at all

[long marsh]

we are in business tho. with all of my known bugs fixed this feels great and doesn't need me to do lag comp. 🙂 maybe a little silly looking with the sped-up projectiles on the target

[unique plover]

For me it was only when I was rendering gizmos in FixedUpdate and not(is_in_rollback)

Gizmos are cleared in FixedFirst

[wicked tulip]

looking smooth, how much lag and jitter did you use?

[long marsh]

both clients are 100ms, jitter 5ms (my settings technically cover up to like, idk, 9?), but packet loss 0%. i think i need to give up a whole extra tick of latency to cover dropping a single packet cleanly, but just haven't tried yet

[long marsh]

also dropped a comment on https://github.com/cBournhonesque/lightyear/issues/894

predicted projectiles resetting during rollbacks is my last real game-ruiner

[pine cape]

Awesome, so the problem is that during rollbacks some things are corrected even though they don't need to be? Yes I think that's the current behaviour, currently I rollback everything without tracking which entities didn't need to be rollbacked. Great find, thanks!
I would appreciate if you could send me your test repo
It would also be nice if we could just rollback the prepawned entity and nothing else.. maybe during check rollback I can add a ToBeRollbacked marker on the Predicted entities that are mispredicted, and leave the rest. That's a bit risky though

This sounds like the same issue maybe? You see them being rollbacked visually because of correction, if we disabled correction for correctly predicted entities your projectiles would not move even during rollback

[long marsh]

i am sitting here trying to decide if my entities are considered “correctly predicted” by lightyears systems if the confirmed entity only gets updated once

probably not, right, because the confirmed tick will be way too old relative to the prediction window of “when projectile spawned until now”

[pine cape]

Also can you tell me more about your approach? If I understand correctly your enemies are interpolated, and you replicate a bullet with both Interpolated and Predicted? Or are you using prespawning? I saw something about spawning a bullet on the interpolated timeline, and then fast-forwarding it to the predicted timeline. How do you achieve that?

[pine cape]

They should, I only check rollback if the Confirmed entity receives an update. However if any entity rollbacks, I rollback all predicted entities

[long marsh]

my repo is up to date if you wanna go poke around. you can repro just by lowering the shoot cooldown and spamming shots with two clients open (cooldown is above my player component declaration)

enemies are interpolated but enemy projectiles are predicted. i don’t prespawn them, i just let them rollback into the predicted timeline from the confirmed one. this makes them “fast forward” kinda via the correction function.

the idea is to have enemy projectiles be more in the interpolated timeline when they are close to the enemy (so it looks like they shot from the right position) but more in the predicted timeline when close to you (so you can dodge it). since the local player is predicted you want to be able to dodge things in that same timeline

[long marsh]

then yeah only rolling back the things that were actually mispredicfed seems like it would work

but uh. say i fire a projectile on tick 100. on tick 120 i fire another one, causing a rollback of, say, 5 ticks. when all my systems run for tick 115-120, where during those executions is the original tick 100 projectile in the simulation? just at its historical predicted location?

bc otherwise how could you resimulate its position starting from 115 when your confirmed data is stale from tick 100

[long marsh]

oh even better i made this earlier, here, snag my branch of the 3d character example. here's the diff. just stand still and press q to fire, then fire again whenever to see the incorrect rollback. character movement is rollbacky w my changes but not required for this

https://github.com/Piefayth/lightyear/pull/2

[pine cape]

Yea but what about your own shots trying to hit an interpolated enemy?

[long marsh]

shooters shots are in the interpolated timeline - they lag when they fire. i am going for “moba” gameplay not for “fps”

[pine cape]

Ah I see, you could interpolate everything including the current player, then

[long marsh]

gotta predict player movement or it feels like crap, which causes all the downstream problems haha

less bad in a click to move game; with wasd it’s truly unplayable to have unpredicted movement

i’ve been using a lag injector to check how some games work so i can steal it, and this setup seems to be the consensus

[unkempt sedge]

Well that is actually the rollback ocurring perhaps visual interpolations is not working as expected?

[wicked tulip]

Technically the components are there to trigger it (as it’s the example from the repository), but it does look like something isn’t working properly.

[pine cape]

I see , cuz league of legends doesn't do prediction for instance, if you lag your own actions are delayed

[long marsh]

iirc league has a movement prediction option that’s on by default, but yeah, everything else is delayed

[pine cape]

Nope it's off by default

But you're right that they have it as an option

I never thought of having prediction on just for the movement, but not for sprlls

[long marsh]

i rejected it the first time i came across the solution and didn’t revisit it until i studied Battlerite with my lag simulator, hah

i think some mmos pull the same trick

[pine cape]

battlerite does this?

But also you said that other players shoot projectiles which are sped up into the predicted timeline

but that doesn't work for projectiles from interpolated player 1 to interpolated player 2

in that case you want the projectile to remain interpolated no?

[long marsh]

well ideally sure but if you’re gonna give up visual consistency, rather it be between two players you are not interacting with

i think ideally the way the projectile might work is to have it be more predicted the closer it is to you (the dodger), and more interpolated the further it is away. sounds tricky

[long marsh]

idk about the projectile fast forwarding, just the predictive movement with lagged abilities

their melee is crazy, the visual is just a lie. attacker’s visual in predicted timeline, but the hitbox in confirmed 😬

[pine cape]

that's good to know, i'd love to have a resource that lists examples of how other games do this kind of stuff

it's funny that your predicted players shoots projects in interpolated timeline, and interpolated players shoot projectiles in predicted timeline

[long marsh]

if only! that would’ve saved me some time

[unkempt sedge]

Question, what would be the ideal use, of a pseudo client?

My case scenario -We have a tower space, which is basically a room. That has it is own kinda lobby/room. we ideally always want that room to exist but for a room to exist it must have a client id connected to it

[pine cape]

Ok i ran this. When I press q again, the first bullet gets rolledbacked. How come it doesn't get corrected back to the initial position?

[long marsh]

as in, why is it snapping instead of correcting when we have corrections enabled?

[pine cape]

I didn't check the settings carefully; but I think correction is enabled?

[pine cape]

I think you should be able to create a room even if no client-ids are connected to it

[long marsh]

i think i disabled it to make it obvious it was snapping

yeah i did

[long marsh]

oh no youre right - i enabled it. turn it up? lol

[unkempt sedge]

I believe there is no add room function in room manager.

[long marsh]

ahhh, remember my issue where i said visual interp was blowing out corrections? it's that

i didn't port my fix for that

[pine cape]

i thought this would fix it

https://github.com/cBournhonesque/lightyear/pull/908/files

but for some reason it doesn't seem to work

ah maybe that's it

Could you make a PR with your fix to lightyear? Is it just a system ordering? or is it an avian-sync issue

[long marsh]

i wonder if that PR you just linked fixes the problem i am about to describe (edit: it doesnt) but, i don't have a general solution atm. what i'm doing...

app.add_systems(
    PostUpdate,
    (
        position_to_transform_for_corrections
            .before(TransformSystem::TransformPropagate)
            .after(InterpolationSet::VisualInterpolation),
    ),
);

pub fn position_to_transform_for_corrections(
    mut query: Query<(&mut Transform, &Position), (With<Correction<Position>>, Without<PlayerId>)>,
) {
    for (mut transform, pos) in &mut query {
        transform.translation = pos.f32();
    }
}

but since i keep getting inaccurate (?) corrections put on my player i need to explicitly except them, so upstreaming would break me

[long marsh]

it also makes the assumption that you want lightyear to be responsible for the pos <- -> transform flow everywhere, which means we should upstream the 3d and 2d versions of this too

https://github.com/Piefayth/lightyear/blob/4033c09dea02984d90405377134e5197bc140b5a/examples/avian_3d_character/src/renderer.rs#L76-L104

but idk to the extent that different games / users want to configure that differently. although i do believe there should be one "blessed" avian setup out of the box without the workarounds

[long marsh]

refactored my protocol into it's own crate. incremental compilation time to the common crate 33s -> 7s. 🎉

can't tell you how much time ive wasted compiling

[wicked tulip]

I know there is Host mode, but it’s more challenging to reason about compared to server/client mode.

Is it possible to run an android app with client/server?

Or would you need to spin up a server for an android app if you don’t want to use Host Mode?

[pine cape]

I have no idea, are android apps single threaded?

[wicked tulip]

No, they could run multi threaded, there are not many threads available, but nowadays I think most of them should have multiple.

Small request for docus update on the

    /// Percentage of packet loss
    pub packet_loss: f32,

For the package loss, I think adding that the value is between [0,1] would make it clearer, as I though 1.0 would mean 1% package loss, and got confused why I couldn't connect to the server...

[unkempt sedge]

Hmm the hashsets keys, inside entity to rooms. Never get cleared is that an expected behaviour?

Ought to think just repopping the entities would be the same time, and wouldnt cause excessive memory storage here

[unkempt sedge]

Btw if you dont clear client from a room and he reconnects to that same room some very weird shit happens

[wicked tulip]

Just to confirm, if a pre-spawned entity, then receives the server confirmed entity, both will still exist (one makred with Predicted the other with Confirmed, but they will not merge. is that correct?

[pine cape]

Feel free to open a PR, I'll approve it 👍

[wicked tulip]

done

I tested main and the new skip-correction branch, but I still have very visible stuttering for physics objects.

I am doing the same as is done in the 2d spaceship example, but in 3d something seems to be different.

[pine cape]

Stuttering like that can be due to one of 2 things:

• visual interpolation is not setup properly so your objects move in FixedUpdate, but not in Update schedule
• you have constant rollbacks
  I think you should first try to see which one it is

[unkempt sedge]

Since gravity is enabled avian_3d character it has constant collision. Try disabling gravity and go inside your egui. Check prediction metrics

If that little guy is going banana, well it is gonna look like shit

[wicked tulip]

ClientInterpolation is added through the ClientPlugin (also If I try to add it on the client, I get an error that is has already been added).

I also tried to modify the parameters to see if that would improve the stutter but not really any success.

What is a good way to check for rollbacks?

Comparing the confirmed and predicted positions per tick, or is there another way to check if a rollback occured?

[wicked tulip]

Disabling gravity makes it look a lot less jittery. But as gravity is applied on both server and client, that should not real to rollback?

[unkempt sedge]

this is how

Go to your egui, and open this guy

Another way is enabling rollbacks debug on log plugin

I dont know how to do that tho using the setting setup? Mayber overriding but seens unecessary

[wicked tulip]

I have thousands

[unkempt sedge]

Yes as you can see not good

[wicked tulip]

You can say that indeed...

Its basically every tick

[unkempt sedge]

yes it is

I think I will refactor that sample.

@pine cape Is it necessary, for all samples to follow the "low-code" approach utilized with the predispose settings file?

I believe it would be a good idea to split them into portions. For example: Avian 3d character makes a character that moves physically.

Not a character that moves physically both in host mode and in separate mode. And is friendly with edgegap

[pine cape]

it's convenient for me to be able to test all examples in all modes

[pine cape]

Yes exactly. The pre-spawned entity on the client becomes the Predicted entity after the merge, and the server sends replication updates to the Confirmed entity

[pine cape]

No, things should be cleared

[unkempt sedge]

Hmm I see, but alas It seen maintenance will become overbearing at same point (my impression is that most sample are already unstable). Also most games just follow one "style", never heard of a game that transitions, between host mode to separate mode according to servers. Perhaps we can make most samples using the common separate mode and one general testing one, instead of multiple different scenarios and codes.

[pine cape]

I think most examples are working fine, it's mostly just the avian samples that are having issues since I changed a lot of rollback related stuff recently

[wicked tulip]

Yes it seems, that he Avian example suffers from constant rollbacks on current main. (basically every tick).

Even without anything else except the two characters.

[pine cape]

that's unfortunate, the rollbacks were completely gone when removing the cubes. You mean the avian_3d example right?

[wicked tulip]

the avian_3d_character example

by using the following conditioner:

conditioner: Some(Conditioner {
        latency_ms: 100,
        jitter_ms: 20,
        packet_loss: 0.01,
    }),

[wicked tulip]

Ah they are gone unless you bump once into the other character

It looks like as soon as there is any collision there are continous roolbacks afterwards (every tick)

[unkempt sedge]

I give u 100 buck if you fix promise on my mother, this godamm collision shenanigans hohoho

[wicked tulip]

@pine cape the fact that we have continuous rollbacks, does that mean we have a simulation that never converges again?

Would that mean the predicted and the confirmed entities have differences every frame?

[peak ice]

Hello everyone! I am looking for someone to possibly play a game demo and then have a conversation about what kind of networking shenanigans I need to use for it to feel right. Right now my code is heavly based on the starship example, I just don't think things feel right on the client side, and when there is large amounts of latency (100ms) the client side is unplayable. I'm looking for a recommended networking setup for a PvE game that you play with friends where one friend is the hostserver.

[unkempt sedge]

Spaceships utilize avian, and recently avian + lightyear has been really unstable with dynamic bodies.

Perhaps you can try using kinematic bodies (that has worked out for me) with sensor colliders as hitboxes.. Or just dont use physics at all

[peak ice]

I am using kinematic bodies, that isn't the issue right now. Its more along the lines of, do I predict? do I interpolate? have input lag? who has authorty over what?

[unkempt sedge]

Depend on your game, is it fast paced, is it slow paced? Input lag is generally utilized with predicted entities and mostly used with high ping conditions. Server most of the time should be the authority figure, he should tell who spawns, when replication occur and so on. But sometimes you can use client_replication, to avoid over using server example: Read cursor movement

[peak ice]

yeah the game is kinda fast paced, It intended for friends playing together so I don't care about cheating which opens up client side authority. I have a demo on steam I could share with anyone trying to get a better idea on the style of game.

[unkempt sedge]

fast paced, should have predicted entities. For player, and interpolated for npcs. You can make all interpolated and one sole client predicted (specially if there is no pvp) for the player scenario

[peak ice]

ok, so fast paced games should have predicted players. Im noticing input lag kinda ruins the feel on the client side, can you do predicted entities without input lag?

[unkempt sedge]

you can

it usually should be 0

[wicked tulip]

Once we figure out what is causing the rollbacks, prediction should feel really good.

We are about to release a fully networked experience in VR where we use the prediction/client/server tech (similar to what lightyear is using) it it feels very responsive.

So if it feels unresponsive its more likely related to some issue in lightyear (either on your implementation or the framework itself) rather than the networking model.

[pine cape]

I would have to check debug logs to see, it could be some avian non-determinism

[pine cape]

The simplest version would probably to interpolate everything. You would have a delay on your own inputs but it could be acceptable

Then you could predict your own actions and interpolate everything else, which would make your own actions feel responsive but you might have to use lag compensation

If your game has a lot of physics-based interactions (collisions, etc) you could try to predict everything, but as you have seen in the spaceships example it mostly feels good only when there are no mispredictions. I think for things to feel good even with mispredictions you would need more tuning: maybe extrapolation using velocity/acceleration, tweak the correction parameters, etc.

[long marsh]

for the pve with friends i would just give up server authority tbh

[pine cape]

Or you could use client-authority instead of lag compensation in some cases. For example battlefield has the client tell the server that the player hit an enemy

[wicked tulip]

So it seems the controlled entity is not the issue but the other entity is (without any boxes).

From the log I don't fully understand the meaning:

Correction { original_prediction: Position(Vec3(2.1028938, 1.2499865, 0.11440856)), original_tick: Tick(3642), final_correction_tick: Tick(3657), current_visual: Some(Position(Vec3(2.1028936, 1.2499865, 0.11440855))), current_correction: None }

It seems to be off by a very small amount, and the current_correction is None,

Is there a way to define quantization for the synced values?

[wicked tulip]

So it seems to be related to collisions, when Gravity is set to 0, the rollbacks stop after a while.

But even then there are rollbacks as soon as the other player is moved.

(but only when stoppind and starting the movement, when moving continously the rollbacks stop without gravity)

[unkempt sedge]

to be expected. It is extrapoloting, your user input the only way to not have those rollbacks is input delay

[wicked tulip]

But the current_correction is None

[unkempt sedge]

oh yeah it is

oh now it isnt

check the prediciton value and currentt value

thei have a 0.00001 difference

So a rollback yotu shall have

[wicked tulip]

I added input delay

input_delay_ticks: 16,
correction_ticks_factor: 15.0,

but it seems not to make any difference

[wicked tulip]

Yes there is a small difference, but shouldn't the current_correction be Some instead of None?

[unkempt sedge]

You still get rollback when starting to move?

HMM

[wicked tulip]

yes

The part which I can't find up to now is why the current_visual is Some and the current_correction is None, from what I can see is that the current_correction is only None if its a new correction (but then the current_visual should be None as well.

[unkempt sedge]

My my that explains a lot of my rollback loops

I have no idea why it occurs my guess is it thinks it should rollbacks, but it doesnt return the correction component

Therefore he keeps rollbacking

And maybe sometimes he gets the component

[wicked tulip]

I checked the collisions, and they appear to be reported with the same values and the same order

After analyzing some more logs, it seems that they collisions re not identical, different point data, normal_impulse etc.

So it seems the collisions diverge between the client 2 and the client 1.

values are close but diverge slightly, like -0.029934 vs -0.029934008

[fervent karma]

Are you sure you're using the correct clock? I.e. Time<Fixed>

[wicked tulip]

Not sure what you mean? I'm currently using the avian_3d_character example of the repo.

[fervent karma]

I'm sorry, I missed the context, ignore me 😅

Actually that example does use Res<Time>, it would be worth checking if Res<Time<Fixed>> makes a difference. It did cause desyncs for me, but that was also on 0.14, so maybe the behaviour is different for 0.15

[wicked tulip]

even when replacing all Res<Time> with Res<Time<Fixed>> I get continuous rollbacks.

So it still is an issue. What I'm not sure about if the corrections aren't properly applied (and we get different collisions every frame).

Or if the collisions are inherently diverging.

It looks like at the start the collisions are identical, but after I bump into the other character they diverge (ever so slightly).

I couldn't really find a place where the correction functions are used in the lightyear source, but I might just be missing it.

(I checked, and the functions are called which are provided in the protocol, but even when returning the target value withour interpolating I get continous rollbacks)

[unkempt sedge]

That is lack of determinism with avian itself

[wicked tulip]

But contact pairs seems to be in the same order now (I think)

[unkempt sedge]

that doesnt make sense, if they have the same order why would they diverge between clients?

[unkempt sedge]

Btw where are you getting all those logs from?

is it prediction::rollback tralalal =debug?

[wicked tulip]

Simply logging all collisions for each tick and comparing all contact pairs and forces.

Randomly sampling a few ticks

[unkempt sedge]

Perhaps it would be a good idea to leave such logs on debug and pr that

I would appreciate it

[wicked tulip]

There are in the example but for the boxes, I just added them for the characters, as I disabled the boxes.

[sly ibex]

Could I ask for some file management / module advice in here kings? Like where explicitly what kind of functions would go in which file (main.rs, client.rs, shared.rs and server.rs etc)

I read through the cheatbook and it was p good-- but I dont got the game development knowledge to extrapolate much from that

Doing something of a very basic 2d rpg if that helps any

[peak ice]

The game has a lot of colliders, sensors, but very minimal dynamic bodies in terms of how I'm using the physics engine. The main reason I'm even here is this problem:
On the server side the client player moves smooth, on the client side the server player (and other client players) seem to overcorrect for inputs and they jump around, but only when there is latency (set to 100ms, similar value to live testing with a friend).

I'm not sure why this is happening. The code is based on the spaceship example so I know its server authoritive were everything is predicted, which is something I could give up on because of PvE. But why does the server side's client player still look smooth? I feel like I should be able to get better results without moving from prediction to interpolation or changing who's the authority of the player.

[peak ice]

I think that up to you, and depends on what kind of game you're making. Is there a dedicated server? Hostserver? etc?

[sly ibex]

Dedicated, yeah. Trying to avoid crossing everything up and making a MESS without knowing the whys n wheres

Something simple, tile based, probably simpler than a roguelike even

[peak ice]

lol i might be in that situation haha

I would maybe check out https://github.com/cBournhonesque/sixdof, he made lightyear and all the server code is in the server folder, and all the client code is in the client folder

[sly ibex]

I will take a look, ty homie
When I last looked at this guys stuff I found it very uh, daunting 😅

[peak ice]

yeah it took me like 2 weeks just to get a main menu with a hostserver and client button working lol

I personally found getting an example "working" without his lightyear_example_common library was a good place to start. It abstracts a lot of the setup of lightyear making the examples easier to read and harder to copy.

[sly ibex]

That may be the shout homie, Ill see if I can pull it off 😭

[peak ice]

Also here's a menu example for hostserver/client setups including steam networking options https://github.com/SueHeir/lightyear-menu

[fervent karma]

That link 404s for me

[peak ice]

it was private my bad, is it working now?

[fervent karma]

Yess thank you, I've been wanting to get something like this set up

Especially the part about connecting to steam friends seems awesome

[peak ice]

Just a warning, I only tested steam connections with my actual steam game app id, I'm pretty sure it will still work with the default 480 app id but it wasn't tested.

[wintry dome]

regarding the constant rollbacks with prediction and avian integration.. presumably values are nearly correct, are we talking tiny floating point discrepencies causing rollbacks? wondering if anyone has tried quantizing the physics values (position, rotation, linvel, etc) before and after the physics step, on client and server?

gaffer suggests this so you can transmit the values using fewer bits, but it would also maybe hide any minor desync issues (See the Quantize both sides section)

i never got to properly testing this to see what the side effects are, but i just rediscovered it and put it in a gist in case anyone wants to experiment: https://gist.github.com/RJ/74e598b84dd81feb40f72407dee4ad79

it quantizes stuff before physics runs, and after physics but before physics syncs transforms etc. so the game/networking should only ever see quantized values for physics states (client & server). in this case i'm using a scale factor of 1/8192, which means ~ 0.0012 is the smallest difference in values you can represent.

[unkempt sedge]

It feels a lot like stardew

[peak ice]

lol the artwork for the actual game is also pixel art

[pine cape]

@long marsh this should help improve the correction logic; https://github.com/cBournhonesque/lightyear/pull/913
i'll also merge the other PR

[wicked tulip]

That was my next plan. I talked to Jondolf, and we tested with the deterministic2d sample, and when no joints are involved, even if the entity id's are different, the result should be deterministic.

Testing with quantization is the next thing to try, but I only have time later in the day to see if it helps.

[wicked tulip]

What schedule would you use for the quantization? Would you run it twice?

[wintry dome]

i'd use the same schedule as avian, which by default is fixedpostupdate iirc

i'm not sure it needs to be run twice.. i'd test by running it before physics and after physics but before avian's sync set for starters i think

to make sure none of your code or lightyears code ever sees a non-quantized physics value

[pine cape]

not if you change the order of entities. You can change the order that the entities are spawned and the results will be different

What do you mean by quantization? Which library is introducing quantization?

[wintry dome]

like rounding to a multiple of some small fixed amount, to reduce the accuracy of the floats but in a deterministic way. i think this is often done by multiplying by a scale factor, rounding to an i32, and then converting back. it limits the available accuracy for physics values, so you could transmit them as a type of integer. but i was mainly thinking of using it to paper over any small floating point disrepencies

from the gaffer article "In the cube simulation I found it necessary to have 4096 position values per-meter" so he's tuned the quantization so he can represent 1000mm in 4096 integers, ie 1000/4096 = 0.25mm accuracy

[unkempt sedge]

Question, does replicateoncecomponent needs to be registered in the protocol?

[wintry dome]

doesn't need to be baked into avian for an experiment. just write systems that mutates all the postion, rotation, linvel, etc. and run it before physics set and before physics sync.

you probably only need to quantize any physics values that are in the protocol and being replicated, ie position, rotation, linearvelocity, maybe mass or angular velocity or some others depending on the game

in the case of Position, instead of operating on a 2d or 3d plane represented by float coords, operates on a snap-to-grid of distinct values where the quantization scale defines the grid spacing. values after quantization will be very similar to before, but snapped to the nearest grid position.

[pine cape]

yes

Ah you mean you want to add quantization to fix the issue?
I'm pretty sure avian is mostly deterministic, there's just loss of determinism due to:

• entity ordering (in hashmaps, etc.)
• ordering of contact points

[wintry dome]

yes, quantization having the added benefit of maybe making it easier to save bits on the wire, but really just to hide any small differences due to non deterministic avian shenanigans and make stuff work without constant rollbacks

obviously fixing the root cause would be ideal 🙂

[unkempt sedge]

Them replicate once component should be used, when you want to add a component after some server logic?

Intead of being right on build time like in protocol

[pine cape]

You register component C in the protocol, then you add ReplicateOnce<C> on your entity to make sure that no updates are sent after the initial update

[unkempt sedge]

Okay so it ceases the replication good to know

[wicked tulip]

Ok testing with the quantization doesn't stop the rollbacks (if I add the cubes again) in the example.

[wintry dome]

too bad... which example are you using?

[wicked tulip]

avian_3d_character

[pine cape]

I caught up on the determinism discussion

the issue is definitely in avian

were you able to run the avian_determinism test with randomly ordered entities and multiple contact points and get a passing test?

[young prawn]

yeah determinism_2d is fully deterministic with shuffled entity spawning order (but without joints)

[pine cape]

The server is a dedicated server? or are you running in host-server mode?

[young prawn]

with joints it's not deterministic with shuffled entities atm because of query iteration order

[pine cape]

good to know, thanks!

[unkempt sedge]

2025-02-19T15:55:21.572718Z DEBUG lightyear::client::prediction::rollback:247: Rollback check: mismatch for component between predicted 77v1#4294967373 and confirmed 72v1#4294967368 on tick Tick(161) for component "avian3d::dynamics::rigid_body::LinearVelocity". Current tick: Tick(267) predicted_exist=false confirmed_exist=true
I believe there is a condition missing that should check, if predicted history exist before rollback on current main

oh just saw the todo

[wicked tulip]

that is not what I could observe.

if I schuffle the columns (as suggested):

    let mut cols = (0..COLUMNS).collect::<Vec<u32>>();
    cols.shuffle(&mut rand::thread_rng());

    for col in cols {
        let x = x_root + col as f32 * delta_x;

The results produce different hashes every time.

[pine cape]

No that's expected. Whenever a entity gets replicated with prediction it triggers a new rollback to fill the PredictionHistory with initial values

[young prawn]

(answered here #1124043933886976171 message)

[wicked tulip]

So I could reproduce it when sorting the entities which produce the hash (as Jondolf suggested).

So it seems the rollback are not triggered by avian, so that means lightyear is the source of the rollbacks somehow?

(and I also tested with latest main, which has the replication changes merged in, but with the same results)

[long marsh]

this does correct the interaction between corrections and vis interp, but there's something funky going on with corrections now

i just confirmed with the logs, that sometimes i see the (visual) correction being applied a tick late. the object will spend 1 tick at its final predicted position, then the correction kicks in and it teleports back to get corrected the rest of the way.

when it works, this log is showing up on the same tick that the predicted object is created (https://github.com/cBournhonesque/lightyear/blob/3748543999b82f9bd74e8ae9b9f27e4404da9ed5/lightyear/src/client/prediction/correction.rs#L72)

when it doesn't work, that log shows up a tick late

[long marsh]

the actual Correction component is there on the first tick in both cases and seems to be in the same state 🤔

[pine cape]

Hm, the sync plugin needs to run after Correction, that might be why

So that visual interpolation has the correct Transform values to interpolate between

When there's 2 FixedUpdate in one frame (which is most of the time), then the sync plugin gets applied

but if there's only 1 FixedUpdate in one frame, then Position is corrected but Transform isn't

I'll try to move it to FixedPostUpdate instead of FixedLast, and add the required orderings

[peak ice]

This video is of a hostserver and client but the issue is still there if i run a server and two clients

[unkempt sedge]

guys despite the rollbacks we be having check out this character

[wicked tulip]

At least I have the simplest sample now:

• 1 cube (dynamic rigidbody)
• 1 Floor (static rigidbody)

even without player inputs produces continous rollbacks and never gets to rest.

The server also has continous movement (due to no sleeping), but for some reason, even without any player input we have continous rollbacks.

[wicked tulip]

One think I don't understand is why:

correction=Correction { original_prediction: Position(Vec3(-1.0952371, 0.99995565, -0.17343313)), original_tick: Tick(19399), final_correction_tick: Tick(19400), current_visual: None, current_correction: None }

the current_correction is always None. Its as if the correction is never applied?

as inside the get_visually_corrected_state system, the value should always be Some...

[unkempt sedge]

They are colliding?

I expect so

[wicked tulip]

With the floor yes

[unkempt sedge]

Perhaps you should try circumventing that issue

He is quite troublesome

[wicked tulip]

The goal is to find out what causes the rollbacks, so this is a very good setup

[unkempt sedge]

Oh okay

[wicked tulip]

Can’t make a game with lightyear if you can’t use physics 😅

[wicked tulip]

when I enable debug for lightyear I get the following outputs for the rollbacks:

2025-02-19T21:49:44.012479Z DEBUG lightyear::client::prediction::rollback: Rollback check: mismatch for component between predicted 66v1#4294967362 and confirmed 64v1#4294967360 on tick Tick(896) for component "avian3d::dynamics::rigid_body::LinearVelocity". Current tick: Tick(897) predicted_exist=true confirmed_exist=true
2025-02-19T21:49:44.012496Z DEBUG lightyear::client::prediction::rollback: Rollback check: mismatch for component between predicted 66v1#4294967362 and confirmed 64v1#4294967360 on tick Tick(896) for component "bevy_transform::components::transform::Transform". Current tick: Tick(897) predicted_exist=true confirmed_exist=true
2025-02-19T21:49:44.012578Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012585Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012586Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012625Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012628Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012603Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012656Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.012650Z DEBUG lightyear::client::prediction::rollback: in prepare rollback
2025-02-19T21:49:44.013438Z DEBUG lightyear::client::prediction::rollback: Rollback between Tick(897) and Tick(897)
2025-02-19T21:49:44.013454Z DEBUG lightyear::client::prediction::rollback: Rollback tick: Tick(897)

is it expected that the rollback happens between the same ticks? (897)

[pine cape]

Nope; are you testing with very little latency?

[pine cape]

but with the capsule there are no rollbacks right? So isn't it the multiple points of contacts between the cube and the floor that are not deterministic?

[wicked tulip]

100ms

[wicked tulip]

From the avian deterministic test (with multiple colliding cubes) it seems that avian itself is deterministic independent of entity id orders

(Unless you use joints, but that will be solved at a later point)

[wicked tulip]

With the capsules I also have rollbacks, especially once the bump into each other, but I tried to get to the simplest case where rollbacks happen every frame (floor + 1 cube)

So it seems from the experiments I ran that avian (and the contact points or entity ID order) is not the cause of indeterminism.

[unkempt sedge]

Question what is the difference between server conditioner and client conditioner?

[pine cape]

do you still get those when you disable correction? correction_factor = 0.0

[pine cape]

client conditioner = applied to packets received by the client, server conditioner = applied to packets received by the server

[wicked tulip]

I only used server conditioner

[wicked tulip]

I set correction_ticks_factor: 0.0,, and still receive these rollbacks (and same tick)

server conditioner is:

Conditioner {
    latency_ms: 100,
    jitter_ms: 20,
    packet_loss: 0.01,
},

[unkempt sedge]

@pine cape Check this out Mr peri chompi boi, made a construction system with lightyear

[unkempt sedge]

Hmm there should bbe a check for that

I believe

If prediction extrapolates what shall occur why would it is extrapolation tick ever be equal to cureent tick

[pine cape]

We take away he current_correction value in PreUpdate to update the component to have the correct value instead of the visually interpolated value.
If you print Correction in FixedUpdate the current_correction will be None because of this

[sly ibex]

hello bros, i have another foolish question;
coming from the setup in the cheatbook i believe i have made an error, not entirely certain why but this is what im getting with a copy of what's in the cheatbook protocol.rs

[unkempt sedge]

Question when using the simple setup, where is the field in each I can disable confirmed entities

I have just so many of them my egui is bvecoming clustered

[pine cape]

To be able to use the linear interpolation function, your component must implement Mul and Add , like so: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/tests/protocol.rs#L44

[unkempt sedge]

when using interpolated entities, who are predicted in their client but interpolated in others into whon should i station the collider? In the interpolated i assume

[pine cape]

You should probably put physics components like colliders in the predicted entity

[unkempt sedge]

but them my other client wouldnt have the collider if they share a room would him

[unkempt sedge]

fn add_physics_to_player(
    physical_entities: Query<
        (
            Entity,
            Has<Predicted>,
            Has<Interpolated>,
            Has<ReplicationTarget>,
        ),
        (Added<PlayerMarker>, Without<Confirmed>),
    >,
    mut commands: Commands,
) {
    for (entity, is_predicted, is_interpolated, is_replicated) in physical_entities.iter() {
        if is_predicted || is_replicated {
            commands.entity(entity).insert(CharacterPhysics::default());
        }
        if is_interpolated {
            commands
                .entity(entity)
                .insert(RigidBody::Kinematic)
                .insert(Collider::cuboid(1.0, 1.0, 1.0));
        }
    }
}```

Shoudl i do something like this?

Another question, how would a client know, the action my interpolated entity is making. It seens there is no input buffer in interpolated entities?

[fervent karma]

Instead of the if checks you use Or<(With<Predicted>, With<Interpolated>, ...)> I made one in my own repo called Relevant: https://github.com/OleStrohm/bevy_aoe/blob/43dc7ca41907ccb964e5f60ed7af89c399f42917/src/game.rs#L18-L23 which isn't necessarily finished, but something similar might work for your usecase

[unkempt sedge]

There is no direct message to client if separate mode correct? One cannot send a message from one client to another

If they are not hosts I mean

[pine cape]

Correct, all messages go through the server

[hexed ruin]

Is it a good idea to mix TCP and UDP? One of the features of my games is modding and I’d like players to be able to download the files through a TCP connection. But I’d like them to actually play the game through a UDP connection when going against players. Is such a thing a good idea?

[pine cape]

Yes I think that's fine! The "auth" example mixes TCP and UDP

[wintry dome]

I'd use http for downloading files, it's good at that and you can easily add caches/CDNs/hosting services etc later if needed.

[sonic citrus]

is it possible to unit test code which uses ConnectionManager?

[pine cape]

Yes, depending on what you mean. You can check some of the unit tests in the repo

[fervent karma]

How do you get logs that show the PreSpawnedPlayerObject hash and stuff? I tried the vizualiser, but that doesn't seem to have the logs

[pine cape]

Bevy_inspector_egui should be able to show the component value, right?

[fervent karma]

But the object disappears once the replication comes through, so it's gone in an instant

I'm trying to debug a prespawned object not being replaced as I'd expect, I check that I'm using all the same components, but I might be missing something

[unkempt sedge]

@pine cape Mr Peri when it comes to ai, what would your approach be? I want to make it both for player and npc. As if a player ragequits the other at least have a bot to play with them. Would you make it entirely server side?

[fervent karma]

Hmm, turns out the issue with PreSpawnedPlayerObject was just because I was still using Time instead of Time<Fixed> in some places 😅

[pine cape]

Time is equivalent to Time<Fixed> in FixedUpdate. PreSpawnedPlayerObject should only be used in FixedMain schedule

[pine cape]

You can turn on the logs using the LogPlugin, then

[pine cape]

Yes I think so, server side

[fervent karma]

I know, and yet... Is FixedUpdate different to FixedMain? I seem to be using FixedUpdate

[pine cape]

FixedMain contains FixedPreUpdate, FixedUpdate, FixedPostUpdate, etc.

[peak ice]

Hello again! I'm trying to create a menu system that runs a server in a separate thread. So far I'm trying to spawn the server thread using https://github.com/EkardNT/bevy-tokio-tasks, in a bevy system. I have the code here https://github.com/SueHeir/lightyear-menu. I believe the issue is that the crossbeams channels aren't working with bevy-tokio-tasks, but im not confident on that. The setup should start the server when you click the button and stop the server when you exit, not sure how else to accomplish this without the bevy-tokio-tasks plugin.

maybe the server needs spawned at the beginning, and then somehow told to start when you click the button, not sure

[pine cape]

Maybe a simpler option would be to start the other thread with the server and leave it always running, but then use a run-condition/state to enable/disable it

[peak ice]

so the thread would be spawned in main, and the server would always be running, but wouldn't let people connect until the host client is connected?

This might be a option, but then if I run two instances of the game on the same computer while testing it we'd have servers trying to use the same ports

[pine cape]

The server wouldn't always be running; the thread would.
You could use a channel to let the thread know to call server.start() and server.stop()

[peak ice]

oh snap I messed up the server address, should have been LOCAL_SOCKET!!

[pine cape]

@wicked tulip @young prawn I have 0 rollbacks without collisions. I believe the main issue with rollbacks when collisions are involved is that
I need to rollback the Collisions resource to the server-state at tick T. Currently I do a non-networked rollback, meaning that I rollback the resource to its state at rollback_tick in the client-history. This doesn't necessarily match the state of the resource on the server at rollback_tick, which is why we see a discrepancy. This would mean that to completely avoid constant rollbacks we would need to replicate the Collision resource through the network, which might be expensive. I wonder if there is a way in avian to compute collisions from scratch from a given tick using all Positions, etc. without requiring the Collisions resource?

[peak ice]

So https://github.com/SueHeir/lightyear-menu should be working for separate mode, hostserver mode, client mode, and just server mode, im very excited about it lol

[pine cape]

Awesome, I'll try it!

[peak ice]

some of my fixes are questionable, but its just a first pass, a minimally viable menu if you will... Looks at handle_disconnections system

[peak ice]

just tested this on windows and it doesn't work soo.. yeah nevermind

works on mac os, no idea why

[peak ice]

switch it to spawn the server thread at the start seems to fix my windows issues, the only problem is when I try to control it with a channel message my server doesn't work. I've pinned it down to having a system request a resource that is the channel receiver. Everything is working until I add this one system https://github.com/SueHeir/lightyear-menu/commit/df6e72dc7ef62fce78a1c50c30026b3091037f77

[peak ice]

I think i got it fixed now:)

[wintry dome]

seems like Collisions uses a sorted map with (Entity, Entity) as the key, so since local entities differ from remote, the ordering could be different. i wonder if that's enough to cause non determinism.

and i suppose when a client joins, they don't have the collisions from the previous frame stored in Collisions, which the comments suggest it would be on the server version "..contains collisions from both the current frame and the previous frame". perhaps that has a subtle knock-on effect too.

[unkempt sedge]

Saw your behaviour tree

Impl very nice, from the ai crate i saw yours is the most intuitive one just wanted to let you know

[wintry dome]

thanks, yeah I am happy with the API, it ended up nice and simple to use

[wintry dome]

could you ask in #game-ai don't want to go too offtopic in here

[wicked oak]

i have two workspace server and client, does lightyear support dedicated server?what i want rn is on main from server workspace start the server and on client main workspace connect to the server

[wicked tulip]

You can have a server only application in lighyear.

(also headless server)

[peak ice]

I'd recommend having most of you're project if not all of it in the same workspace, and then use feature flags to control if its a client or sever. It's probably the simplest way to have a shared protocol, check out the lightyear examples!

[long marsh]

i ended up with one crate for server, one for client, then additional shared crates, all in one workspace. client and server each their own binary. that was good for pure dedicated server

then when i wanted client host, i just also made the server crate a lib and made it an optional / feature flagged dependency on the client

[wicked oak]

no i prefer have two workspaces

[wicked oak]

me to

can i see your examples?

like how do i start the server

[long marsh]

i don't have anything of mine public

but there is a command extension to start it https://github.com/cBournhonesque/lightyear/blob/main/examples/simple_setup/src/server.rs#L71

[wicked oak]

thanks piefayth

[wicked oak]

yeah no, the example is old @long marsh

[long marsh]

either missing serde dependency or missing bevy serialize feature

[wicked oak]

wydm

i need add serde dependecy

i see

..

this seens not a dedicated server example

i mean i just think lightyear doenst support different workspaces

[pine cape]

But maybe there could be a (potentially more expensive way) to just not use Collisions from the previous frame and recompute contacts from scratch?

[unkempt sedge]

It does

I think periwink made a few games that are subidivided in workspaces

[wicked oak]

well iam trying but i cant somehow

[unkempt sedge]

I think brianh was developing a shooter of sort in conjunction with mr peri.

I am not sure tho, perhaps you could take a look into it

[long marsh]

i don't know if that's gonna be any simpler https://github.com/cBournhonesque/sixdof

[wintry dome]

yes, that would be handy. does it work if you just nuke Collisions every frame?

[wicked oak]

the bad thing about examples are the unecessary thing they put on example

like the example also build players and bots, why bro, i just want connect, they should make simple examples

guess i will do via https

with rust api

[long marsh]

make sure you are looking at the same version of the example as the version of lightyear you are using

your error before looks like it thought it was in HostServer mode but there was no client. in main branch lightyear i’m pretty sure that gets detected correctly automatically, but in 0.19 you need to manually specify the mode

[wicked oak]

'ou need to manually specify the mode'

but i did

welll

i will try use https rust protocol

since there is not a reliable plugin for bevy rn for it

[long marsh]

wrong mode

[wicked oak]

Separate mode works

cool, hwo do i check when a player connected on server? @long marsh

nvm

i saw the tutorial

[wicked oak]

questions guys, how do i generated the private_key and protocol_id?

[wicked oak]

guys why the event is not firing ?

impl Plugin for ServerConnectionPlugin {
    fn build(&self, app: &mut App) {
        app.add_plugins(setup_server_connection()).add_systems(Startup,start_server).add_systems(Update, handle_connections);
    }
}

and yes i start the server / client workspaces

hmmmm

i see

wich can be the cause?

nvm

i fixed

the api is very clear now

[young prawn]

In theory you could just nuke all the collisions, but this would break collision events (every collision is a "new" collision) and make things pretty expensive. Especially the upcoming improved contact pair management relies a lot on persisting contact pairs to optimize things.

I'm pretty sure disabling warm starting should be enough to prevent contacts from previous frames from affecting the simulation though

[wicked oak]

Iam curious ,what is the problem he is facing? Since iam using lightyear and avian too @young prawn

[young prawn]

rollbacks when objects collide

[wicked oak]

I wanted to know how the replication works for players controlling a character and how safe its, iam making a battlegrounds game,open map everyone vs everyone, will have powers and movement abilities and even teleport skills, usually how i do is:

1-Player move on client instantly
2-it tells the server the movement and the reason of the movement
3-Server checks if he can move on that position taking in consideration the reason of movement, Example: If he is just walking it will take the player speed as consideration, if he used a teleport skill it will check if the teleport position distance is correctly basead on the max distance of the skill, etc etc
4-if the serve thinks its invalid so it will teleport the player back, or where the player should be

So how does lightyear handle the replication, is similar ?

@pine cape since you are th owner i wanted to know

[wet kelp]

@wicked oak there is the avian3d example in the repo which pretty much should explain your questions

[wicked oak]

the example show how setupt it, doenst explain how it works

[wet kelp]

it implemented the movement and server client logic. isnt that what you asked for ?

sry if i misinterpreted your question

[wicked oak]

well try read again

xd

[wet kelp]

you wanted to know how lightyear handles the character movement and replication,right?

[wicked oak]

yes

[wet kelp]

in that case, you have the answer in the avian3d example. it implements a simple scene with 3d character movement. You have leafwing as inputmanager wich gets reprocessed by the server and transported back to the clients

hang on, i'll link it to you

https://github.com/cBournhonesque/lightyear/tree/main/examples/avian_3d_character

its the one i started with and its working pretty well so far. sometimes soemthing breakes, but thats normal for an engine/lib in this state

clone the repo and start the example, this way you shoud see if its what you need to start with

from there, just build up on it

if you have any specific question, don't hesitate to aks, i'm happy to help you with it since i was having some trouble at first too 🙂

so i know the feeling and struggles

[wicked oak]

@wet kelp hm

look i created a plataform on server for example

how would i replicate for client

this

its becuase i make a plataform on server and its not replicated when the player join aftr

yes it doenst get replicated for the client

 commands.spawn((
            RigidBody::Static,
            Collider::cylinder(50.0, 0.1),
            Mesh3d(meshes.add(Cylinder::new(50.0, 0.1))),
            MeshMaterial3d(materials.add(Color::WHITE)),
            Replicate::default()
        ));

just appear on server

there is no clear simple examples of how do it

[wet kelp]

have you tried to do it the same way the example handles floors, boxes and the player?
it should work the same way, create a marker, and call a function if it got added

give me a sec

i'll give you an example

[wicked oak]

bet

thaks

[wicked oak]

so? @wet kelp

[wicked oak]

the examples are messy

they are not going straight to point

it calls a lot of others mods to do a simple stuff, making it messy

[wet kelp]

sry, i'm at work right now, will do it as soon as i have a bit of time. got surprised with a meeting, sry for that, the examples are fine tho. look in the example i linked you how they do it with the floor and just follow that

[wicked oak]

i did but they are messy, i would need copy all others 4 rust files it calls for just spawn one part? lol

it should be straight to point

like just here is 3 new rust files, like why, make it simple bro

FloorMarker

FloorPhysicsBundle::default(),

REPLICATION_GROUP

like lmao

[wet kelp]

if you don't need physics, just dont add it. its just components

the marker is fort the query

[wicked oak]

wich query, where

[wet kelp]

did you follow the marker?

[wicked oak]

what do you mean by follow the marker?

iam brazilian

[wet kelp]

hello from Berlin ❤️

the marker is really just a component, if you look into the renderer.rs you have the add_floor_comsetics function which gets triggerd by the added floormarker and adds the meshes

it really is that easy

sry, have to go afk again for a bit

[wicked oak]

like this ProtocolPlugin i cant even find where its begin added

nvm

let me try

[wicked oak]

yeah bro, i tryed, no sucess

protocol plugin

the renderer

= nothing

it just dont replicate

this info never prints

[wet kelp]

i know it can be frustrating, don't give up, we will figure out whats going wrong.
as soon as i finished work, i can help you better

[wicked oak]

that is it, nothing works

xd

gonna use the whole day to figure out, if the examples were straight to point .

[unkempt sedge]

what a zen approach penguin

congratulations

[long marsh]

are you using bevy_inspector_egui? it might help to use that look at the state of the components on the server and client. especially making sure that

• The FloorMarker actually exists on the server
• The ReplicationTarget component on the floor on the server is set to All
• FloorMarker for sure isn't on the client at all

etc

i would also verify you are actually registering the ProtocolPlugin

[wicked oak]

ReplicationTarget

let me check

[wicked oak]

FloorMarker is on shared workspace, both client and server have acess

the ReplicationTarget is all as you can see

floormarket is on client yes

and yes protocol is registering

on client too

all checks out

[wet kelp]

did you add the Protocolplugin to your shared or main plugin, wherever you call them?

[wicked oak]

Protocolplugin is called on server and on client

[wet kelp]

alright....

[long marsh]

yeah this looks good to me

do you know how to set your log level to debug and write those logs to a file?

[wicked oak]

look let me add a print on it

here is supposed to floor appea

on client

let me play

[long marsh]

so i’m asking because lightyear has a TON of additional logging hidden behind the debug log level. it would give you more information about what is happening from WITHIN lightyear

[wicked oak]

idk

seens all correctly but doenst work

[wicked oak]

no

my server / net config

fn net_config() -> NetConfig{
    let io_config = IoConfig{
        transport: ServerTransport::UdpSocket(SERVER_ADDR),
        ..default()
    };

    let netcode_config = NetcodeConfig::default()
        .with_protocol_id(PROTOCOL_ID)
        .with_key(PRIVATE_KEY);

    NetConfig::Netcode{
        config: netcode_config,
        io: io_config,
    }
}

fn setup_server_connection() -> ServerPlugins{
    ServerPlugins::new(ServerConfig {
        shared: shared_config(),
        net: vec![net_config()],
        ..default()
    })
}

client / net config

fn net_config() -> NetConfig{
    let io_config = IoConfig{
        transport: ClientTransport::UdpSocket(CLIENT_ADDR),
        ..default()
    };

    let auth = Authentication::Manual {
        server_addr: SERVER_ADDR,
        client_id: 1,
        private_key: PRIVATE_KEY,
        protocol_id: PROTOCOL_ID,
    };

    NetConfig::Netcode {
        auth,
        config: Default::default(),
        io: io_config
    }
}

fn setup_client_connection() -> ClientPlugins {
    ClientPlugins::new(ClientConfig {
        shared: shared_config(),
        net: net_config(),
        ..default()
    })
}

[long marsh]

assuming you are in PowerShell or Terminal run this: $env:RUST_LOG="debug"

then do cargo run *> server_out.txt but replace cargo run with your normal command for server/client. (and for client, change it to client_out.txt)

then just start both, close them, and look at the output filefs

you can get your logs back to normal with $env:RUST_LOG="info"

[wicked oak]

shared config

pub fn shared_config() -> SharedConfig {
    SharedConfig {
       server_replication_send_interval: Duration::from_millis(0),
        tick: TickConfig { tick_duration: Duration::from_secs_f64(1.0 / 64.0)},
        mode: Mode::Separate,
    }
}

[wet kelp]

i may have an idea,. have you tried running lightyear with the main branch yet?

[wicked oak]

?

there is one main rust file per workspace

just on shared that is a lib

this is my workspace

[wet kelp]

sry for beeing unclear, still at work ^^

lightyear = { git = "https://github.com/cBournhonesque/lightyear.git", branch = "main", features = [
"avian3d",
"bevy_egui",
"leafwing",
"lz4",
"mock_time",
"steam",
"trace",
"track_change_detection",
"visualizer",
"websocket",
"webtransport",
"zstd",
] }
put this into your Cargo.toml and comment out your version

[wicked oak]

is this a problem?

[wet kelp]

i had some issues with the non main version

[wicked oak]

but i need add the features list?

or it will add all features if i dont use it?

i prefer not need to list all lol

let me try

this?

[wet kelp]

you just need to add the features you need.
after updating it, you also need to change your shared_config. i think you need to remove the Mode:Separate part.

[wicked oak]

? there is no mode now

[wicked oak]

yes

why

mode is not necessary anymorew

[wet kelp]

exactly

[wicked oak]

nothing changes

still no replication

wait bro i noticed something

[wet kelp]

can you push your stuff to git and give me the link, i would love to debug it

[wicked oak]

that may be import

let me show

this on client have this entity

i removed the floor on server to test, and when i do this entity is not created on client

so seens something is getting replicated but

this never triggers

making not possible to add the collider

this also doenst trigger

[long marsh]

oh so the entity IS getting replicated but FloorMarker isn't, that helps

all you should have to do to replicate FloorMarker is

• add it to your protocol
• put the component on the entity on the server

that's...the whole thing

[wicked oak]

this is odne already

[long marsh]

right

[wicked oak]

use bevy::prelude::{App, Component, Plugin};
use lightyear::prelude::{AppComponentExt, ChannelDirection, ReplicationGroup};
use lightyear::prelude::client::ComponentSyncMode;
use serde::{Deserialize, Serialize};

pub const REPLICATION_GROUP: ReplicationGroup = ReplicationGroup::new_id(1);

#[derive(Component, Serialize, Deserialize, Clone, Debug, PartialEq)]
pub struct FloorMarker;

pub struct ProtocolPlugin;

impl Plugin for ProtocolPlugin {
    fn build(&self, app: &mut App) {
        app.register_component::<FloorMarker>(ChannelDirection::ServerToClient)
            .add_prediction(ComponentSyncMode::Once);
    }
}

protocol

commands.spawn((
        RigidBody::Static,
        Collider::cylinder(50.0, 0.1),
        //Mesh3d(meshes.add(Cylinder::new(50.0, 0.1))),
        //MeshMaterial3d(materials.add(Color::WHITE)),
        FloorMarker,
        Replicate{
            group: REPLICATION_GROUP,
            target: ReplicationTarget {
                target: NetworkTarget::All,
            },
            ..default()
        }
    ));

server spwaning

[long marsh]

that's kinda why i was trying to get your debug logs, cause i agree everything looks right

[wicked oak]

iam using rust over can i add the server_out.txt here?

server_out.txt

on the execute commands

[long marsh]

oh that's a great question, try it

but it has to be *> server_out.txt

idk if they execute that command in a powershell context or not, will just have to try

if not you can just open powershell and do it that way

honestly you might even have to set the log level environment variable in that menu too

the RUST_LOG="debug"

[wicked oak]

how

[long marsh]

idk but definitely with this box somehow

OR you can modify LogPlugin https://docs.rs/bevy/latest/bevy/log/struct.LogPlugin.html

i just do it with environment var so i can switch without recompiling

[long marsh]

yeah ok i kinda figured

[wicked oak]

nothing gets created

[long marsh]

you will have to do it in Terminal or PowerShell, or like, forget the file thing and just write it all to the console

if you dont mind scrolling through a million miles of logs

[wicked oak]

write wht?

[long marsh]

the debug logs

[wicked oak]

this?

[long marsh]

yeah

like verbatim what i do is

[wicked oak]

that is it?

[long marsh]

yeah but need the logs from a time where the client succesfully connected

looks like they have some connection error there

client might not have had debug logging on either, that looks like just info and error

[wicked oak]

no, this is because i closed server beforre client

so the last sutff is client disconnecting

[long marsh]

oh ok in that case you didnt have debug logs on the clinet

make sure you set the env in both terminal instances

[wicked oak]

$env:RUST_LOG="debug"

[long marsh]

yeah you had it right for the server logs

was just client that was missing them

[wicked oak]

this time i closed client first

[long marsh]

weird. FloorMarker is definitely in both protocols, but it looks like the server just isn't sending it

remote_tick=Tick(2799) EntityActionsMessage { sequence_id: MessageId(0), group_id: ReplicationGroupId(1), actions: [(20v1#4294967316,
EntityActions { spawn: Spawn, insert: [], remove: [], updates: [] })] }

that's the message the client gets; no components listed to insert

[wicked oak]

the system hates me

[long marsh]

do you have something on your server that removes floor marker?

like code that finds all floor markers, does something to them, then removes it?

[wicked oak]

https://github.com/Kevenpvp/PowerProject

take a look

[long marsh]

you have FloorMarker defined twice, im guessing the one in your protocol isn't the one you're actually putting on the entity

https://github.com/Kevenpvp/PowerProject/blob/master/shared/src/lib.rs#L19C1-L22C24
https://github.com/Kevenpvp/PowerProject/blob/master/shared/src/protocol.rs#L9

[wicked oak]

ooo

bro is the goat

bro thanks it f works

you are goat

[long marsh]

happy to help

[wicked oak]

iam happy that you exist bro

[peak ice]

So I've been pretty happy with how my lightyear project is coming along, runs very well most of the time. I've noticed that when the person I'm testing it with is using wifi I get incredible lag spikes when they're hosting the server. (its happened with two different people now). The person claims they never have any issues when they play multiplayer games, league, wow, overwatch, etc.

Question: Do PvP - all predicted style games need a dedicated server running from a server provider to compensate for people's bad internet?
Is there anyway to debug this issue? Or does everyone playing this game just need to buy an ethernet cord? Could it be a bandwidth issue?

[unkempt sedge]

If the host has bad internet, there is really not much too do. Except reconnect mechanics. Perhaps you can transfer host to someone with less latency, but I am not sure if lightyear provides the infra.

Could be a compression issue, tho? Perhaps you are just sending too much information. Via server and so on

[peak ice]

yeah the issue always happens when I spawn in a bunch of enemies (like 10, not a lot), but sometimes it happens when we're just standing there

so how do I check the bandwidth usage? what is a resonable amount for a game?

[pine cape]

You can check the bandwidth usage via the visualizer feature

How often are you sending replication updates

[peak ice]

ok sick I'll look into that, and 20 ms

[unkempt sedge]

I know that by sampling, that lightyear handles "acceptably" massive amounts of server replicated entities. At least with simple behaviour trees and transform adjustments. You just need to be carefull to no use events, as they tend to die out before doing your code logic

[peak ice]

yeah if the person is connected with ethernet then spawning enemies is never an issue, 100's of them is fine.

[misty wyvern]

Hmm ya could just be the bandwidth limitations but ideally the host is never on WiFi. The games mentioned your friend would have never hosted, and would have only ever experienced internet traffic from a client's perspective, as those games have dedicated servers ran only by the developers AFAIK. So I don't think they're a good benchmark for this.

If you get stuck on this, is it feasible to scatter these spawns out over time?

Could they be saturating the WiFi itself? Does lightyear have a way to customize the MTU per packet?

[digital cedar]

hey wanna ask if prespawning can work in this scenario, I have a scene (which have multiple hierarchies in it) i wanted to spawn in both server and the client. I want most of the things to be in sync with the server, can this work using prespawning? and how rould that work? (or is this a bad idea?)

[long marsh]

is there a reason you want to use pre spawning over replicating the object normally? what kind of “thing” is your scene?

[digital cedar]

it's a blenvy scene, but yeah replicating can work as well, just need extra work to each of the object in the scene..

[long marsh]

if the scene isn’t dynamic i would just replicate a marker and use the marker to indicate to the client to load the scene

but if you want to pick and choose specific objects that do or do not get replicated dynamically, you can’t escape having to identify them programmatically somehow

[digital cedar]

truee, the scene is partially static and partially dynamic, which means i need to mark those that are dynamic

[long marsh]

i get why you’re asking about prespawning though, you want to match those dynamic entities up? so you just load the scene normally on both ends and it all syncs?

that might actually work if you went through the hierarchy and put the prespawn component with an appropriate id on every dynamic entity on both the client and server

but i do NOT know how prespawning works with hierarchies; never tried that

[digital cedar]

yeah, that's what i'm attempting haha, so that i wouldn't need to rely on replication for the spawning to happen, and instead locally spawned then synced up

i still think the most straightforward way is still replicating..

[long marsh]

agree 👍

[wicked oak]

hey guys, how could i replicate this component to client, so client can know the combatant type

#[derive(Component)]
pub enum Type{
    Player,
    Npc
}

[sly ibex]

Is the lightyear cheatbook now out of date? I get errors using the example code / some from the github

[pine cape]

Yes it is

[sly ibex]

Ah, gotcha homie 🙏

[copper laurel]

If someone tried both approaches, why would you pick lightyear over bevy_replicon? I'm familiar with the overview of both, but in practical terms what's "better"?

[pine cape]

Replicon has better performance and tries to provide an abstraction for messaging/replication can build upon.

Lightyear has more features (prediction, interpolation, input handling, authority, etc.)

[sly ibex]

Would you say a bevy project can be adapted to lightyear later in development, or would doing so be significantly more difficult out of interest

[wicked oak]

couls i have some answer?

[pine cape]

It's not impossible but in general I would strongly suggest to start from scratch with multiplayer in mind

You would just load the asset on the client no?

[pine cape]

Does Prespawning for the scene not work? If you add Replicate it should propagate recursively to all children

[unkempt sedge]

2025-02-27T20:41:41.771954Z DEBUG lightyear::client::prediction::prespawn: PreSpawnedPlayerObject hook, setting the hash on the component entity=456v5#21474836936 tick=Tick(983) hash=2984040181942278987 2025-02-27T20:41:41.973191Z DEBUG lightyear::client::prediction::prespawn: found a client pre-spawned entity corresponding to server pre-spawned entity! Spawning/finding a Predicted entity for it 2984040181942278987 2025-02-27T20:41:41.973207Z DEBUG lightyear::client::prediction::prespawn: re-using existing entity 2025-02-27T20:41:41.973218Z DEBUG lightyear::client::prediction::prespawn: Added/Spawned the Predicted entity: 456v5#21474836936 for the confirmed entity: 457v1#4294967753 2025-02-27T20:41:41.974191Z DEBUG lightyear::client::prediction::rollback: Rollback check: mismatch for component between predicted 456v5#21474836936 and confirmed 457v1#4294967753 on tick Tick(983) for component "bevy_transform::components::transform::Transform". Current tick: Tick(996) predicted_exist=false confirmed_exist=true. Why? It is weird that even tho my pre spawned predicted entity gets spawed with a transform it says there isnt any

[unkempt sedge]

Oh found the origin

[unkempt sedge]

commands.spawn((bullet, prespawned)) it was literally this line of code, the reason I have no idea, but I believe is correlated to bad syncing

[digital cedar]

I haven’t tried haha. Abit hesitant to try (also with my project deadline nearing soon 🤣)

[pine cape]

Also prespawning wouldn't reduce the bandwidth, if that's what you're interested in. The component still needs to be replicated

[misty wyvern]

Just my two cents after finally getting a more serious look at lightyear:

I love the fact that you're mostly not (or maybe none at all?) relying off macros, this makes things more clear when looking at a protocols.rs (which I recommend having), not a fan of magic, so bravo!

However, there's a flip side to that. When I'm looking at a component's definition, for example:

#[derive(Component, Clone, Debug, PartialEq, Serialize, Deserialize)]
pub struct Moveable {
    pub velocity: Vec3,
    pub angular_velocity: Vec3,
    pub collision_shape: ShapecastMoveableShape,
    pub collision_mask: LayerMask,
}

There's no clear way to know if this is a replicated component or not without looking at protocols.rs

I don't know what the solution is to this, is it really a problem? ehhhh at the end of the day probably not, but just food for thought

[wicked tulip]

Better performance due to less features or why is the performance better in replicon?

[wicked tulip]

You can replicate it the same way as any other component, or why would this component require specific treatment?

[wicked oak]

? I Already fixed

[unkempt sedge]

I guess one could make a derivable trait. That marks that is specified for protocol

Even go further and auto insert it for you, but seens a little overreachy

[misty wyvern]

Yeah definitely overreachy

[pine cape]

A mix of

• I'm less focused on perf and more on adding new features
• I have some features (e.g. ReplicationGroup) which prevent some optimization
• skill?

[wicked oak]

Xd skill

[wicked oak]

This is a Nice point

Iam Also worried about bevy update and peri abandon the project you know

But i made a plugin that call the others functions so If i need implement a New network i just need Deal with this plugins and not modify the wholeeee system

[unkempt sedge]

God lord, finally found out the cause of my rollback on spawn bug

Animation component require transform...

He inserted it before the prediction set could dot it is thing

Got rollback

[wicked tulip]

There are certainly many optimizations still possible, but adding features is a good thing to focus on (along with bufixes).

Would be really nice to have an ICE compatible transport (for natpunching similar to matchbox).

[misty wyvern]

Does anyone know if there is a way to explicitly exclude an entity from rollback, I'm trying to find the source of extreme jitter/corrections on a non-replicated entity, kinda shooting in the dark here

sorry, to be clear, it looks like they're being corrected

because they should be moving about 1/4 of that speed, sometimes it looks fine but its really rare

Or better yet, how do I know I'm currently being corrected/in the middle of a rollback? is there a resource or something I can access

[long marsh]

on main there is a DisableRollback component

[misty wyvern]

nice, also I just found the Rollback resource

[long marsh]

perfect was typing that

[misty wyvern]

yeaaaaa this fixed it:

    let rolling_back = rollback.map_or(false, |r| r.is_rollback());

    for (entity, mut simulation, mut transform) in simulations.iter_mut() {
        // If we're in a rollback AND the moveable is not predicted, skip it
        // otherwise it will move multiple times in a frame and we dont want
        // that for non-predicted moveables
        if rolling_back && !predicted.contains(entity) {
            continue;
        }

[misty wyvern]

Wellllll now its acting up again, oof im tired lol

I think its a separate issue, ignore me

yeah ok similar issue, timers were being ticked in rollback too, so thats fixed now

[wicked tulip]

Just to confirm the Visual Interpolation section of the cheatbook is outdate, and to get visual interpolation the setup is not needed anymore (with avian physics)

https://cbournhonesque.github.io/lightyear/book/concepts/advanced_replication/visual_interpolation.html

[long marsh]

you're on main? the stuff about changing which schedule the sync plugin is in is out of date, yeah. you still need to add the vis interp component to predicted stuff

[wicked tulip]

What is it called now? VisualInterpolateState I can't find

[long marsh]

sorry not the component still waking up

app.add_plugins(VisualInterpolationPlugin::<Transform>::default());

[long marsh]

oh also the component though VisualInterpolateStatus::<Transform>

i thought so

the status postfix on that name is not my favorite for something that has to be user-added

[wicked tulip]

Thank you, was hoping that would fix the jitteriness of my predicted pysics based bullets, but they are still very jittery

[long marsh]

are they rolling back?

or just jittery

[wicked tulip]

its continously rolling back, as the collision resource is not synced yet.

Its strange on the client side it looks like no interpolation is applied at all

(or rollback correction)

[long marsh]

yeah it just looks that way when it's constantly rolling back. i think if correction was 100% perfect and the rollbacks were due to very small differences, it would look seamless still, but i think there's some goofiness somewhere that makes it jittery in the perpetual rollback case

i would focus on fixing the rollbacks

or if you aren't prespawning the projectile, you will always get rollbacks when you spawn a predicted one

[wicked tulip]

rollbacks are due to the collisions (most likely) not beeing rolled back.

[wicked tulip]

I use prepsawning

Do you mean you always get rollbacks if you prespawn the bullet?

[long marsh]

if you dont prespawn it (because the history needs backfilled)

[wicked tulip]

yeah I prespawn...

[long marsh]

o if this is that avian collision resource problem i can't help you, but uh, that's interesting. are there actual collisions happening when it rolls back or just perpetually rolling back as soon as it exists?

[wicked tulip]

perpetual roolsback, even if it doesn't collide

[long marsh]

what do the logs say about what component is causing the rollback

[wicked tulip]

how can you log the component that causes the rollback?

[long marsh]

either set the LogPlugin to have a log level of debug or set the RUST_LOG environment variable to debug

might pipe that output to a file too, there will be a lot 😅

[wicked tulip]

Ok I get an output I don't fully understand:

Predicted entity Some(85v1#4294967381) was not found when preparing rollback for "lightyear_experiment_main::protocol::Weapon"

(the weapon is spawned on the player, and I would expect it would be simply synced to the client?)

[long marsh]

haven't encountered that! are you getting rollbacks before you spawn the projectile? or is it fine

that's confusing because, looking at the code, it implies there is a Confirmed entity with a reference to a predicted Entity that doesn't exist lol

[wicked tulip]

no, before bullet spawn all is fine

pretty sure I did something wrong, but not sure what yet

[long marsh]

is Weapon the only component the logs suggest need rolled back? or is it trying to roll back like everything that is sync'd?

could be as simple as the state of your prespawned entity just isn't the same as the state on the server

[wicked tulip]

I resgistered the component in the protocol, and then add it when I spawn the player character.

The weapon is spawned on the server (so not prespawned)

when the player connects I spawn the player and add the Weapon Component to it.

app.register_component::<Weapon>(ChannelDirection::ServerToClient)
        .add_prediction(ComponentSyncMode::Full);

thats how it registered in the protocol.

Its also not just at the beginning but constantly

Is there anything else needed?

[long marsh]

you get that error without spawning a projectile?

like it's happening as soon as you spawn your player

and then happens forever?

[wicked tulip]

Only once the first bullet gets spawned

[long marsh]

just to be clear then... so after you fire your first projectile, the predicted entity for your Weapon goes missing? lol

[wicked tulip]

https://github.com/Occuros/lightyear_rollback_investigation

Yes, its very confusing, here is the repo if that might help.

Feels like something obvious is missing, but I just can't find it

[long marsh]

are you using main branch lightyear?

cargo has your local one

[wicked tulip]

Yes sorry, just for getting more debug info, you can replace it with main of lightyear

Let me know if you can spot anything obviously wrong

[long marsh]

spent some time looking through the logs. the initial rollbacks were getting triggered by ComputedMass being different, so i just took it out of the protocol (which, makes sense to me, it's computed!) and they stopped rolling back

i didn't test it too much tho; can you try / what do you think about that?

you are also rendering your confirmed bullets btw

which might be adding to the confusion here

[wicked tulip]

Yes just noticed... how could the mass be such a problem?

and THANK YOU!

[long marsh]

yeah i am not sure why replicating that is an issue since it should end up the same anyway

no problem

[wicked tulip]

I agree that its computed and doesn't need to be synced (unless you plan to change it freequently) but still confusing

Its also in the example @pine cape, probably a good idea to remove it:

https://github.com/cBournhonesque/lightyear/blob/main/examples/avian_3d_character/src/protocol.rs

Ok this is creating more questions in my head than answers, but that is really good news

It is finnally SMOOOTH

[wicked tulip]

Ok there is one last issue remains is that as soon as there are any collisions there are continuous rollbacks.

And when that happens everything is jittery again, as it seems rollback on every frame brake it again 😭 (no matter what I use for the correction_ticks_factor).

No idea why it creates also issues with the physics mass sync, but will be interesting to see if that persists once we have resource syncing.

[unkempt sedge]

We already have rollbackable resources i think

[misty wyvern]

How can you check how often you're rolling back?

Curious about this

[wicked tulip]

We do? I thought the implementation is not yet finished?

[wicked tulip]

There is a resource (prediction metrics I think it’s called) it shows you how often a rollback occurred.

[misty wyvern]

Thank you, and does lightyear have a way of displaying ping anywhere?

you know what, i should dig at the examples first lol

Hmm ok so it seems like I get rollbacks every frame whenever I move

despite it being very smooth

I take it that's not intended?

Oh maybe it is:

Sync the component from the confirmed to the interpolated/predicted entity with the most precision Predicted: we will check for rollback every tick Interpolated: we will run interpolation between the last 2 confirmed states

[misty wyvern]

Could I get a better idea of what you're seeing? So collisions are causing jitter?

[wicked tulip]

It’s not very easy to see in the video, but the bullet is not flying smooth after the rollbacks start happening:

#1189344685546811564 message

[misty wyvern]

It looks like its not being visually interpolated

not saying thats what it is, but definitely looks like FixedUpdate jitter

[misty wyvern]

But yeah from my understanding I think continous rollbacks are supposed to happen based on this comment for ComponentSyncMode::Full

[wicked tulip]

Certainly looks like that indeed.

But in theory there is the correction smoothing function which should interpolate from the rollback.

[pine cape]

You can use the visualizer feature to get useful plots about lightyear internals; or just check the PredictionMetrics resource via inspector-egui

[pine cape]

Nope, if the client and server simulation are deterministic and give the same results, you shouldn't have any rollbacks

[misty wyvern]

iiiiinteresting, ok I can look into whats going on then

[misty wyvern]

I dont think I understand whats going on here, this should be sending updates to the client, right?

app.register_component::<CurrentWeaponIndex>(ChannelDirection::ServerToClient);

Then I have this query:

    mut query: Query<(
        Entity,
        &UniqueIdentity,
        &Transform,
        &mut WeaponInventory,
        &CurrentWeaponIndex,
        &ActionState<PlayerInput>,
    ),
    Or<(With<Predicted>, With<Replicating>)>>,

But it doesn't seem to find anything when CurrentWeaponIndex is in there

Is it because of the Predicted component?

I'm seeing two player entities 🤔 one has the CurrentWeaponIndex, the other doesnt, but both are Controlled, and one is Predicted. hmmm ok

ok so that means I basically need to predict everything, at least in the context of what im trying to do. Interesting

oh ok I know what to do

I get it

brain expanding noises

[misty wyvern]

@pine cape there's something really funky going on, so check this out, its working fine here (note the rollback count top left)

But sometimes its constantly rolling back (trying to get a video)

Ok I restarted the client several times and it was fine, then I restarted the server and now its not fine:

important to note that the link conditioner is on

It's like as if the server sometimes boots into a bad state, usually its continuously rolling back, but every once in a while it appears to boot into a good state

I've checked everything, I've gone back to what I know is a more deterministic movement and yet its still doing it

And also note it does not appear to be collision related

I have pushed these changes to sixdof in main (Use TAB if you want to toggle the mouse on and off @pine cape )
