[wintry dome]

but on edgegap you have to set NATS_HOST etc as env vars in the application version config irrc

the matchmaker and other bits needs the env file, gameserver needs envs set in the edgegap settings

[dreamy silo]

Thanks for guiding

[wintry dome]

gl 🙂

getting a public nats instance up is probably the most annoying part tbh

[dreamy silo]

Yeah. It’s the only thing holding me back from a successful bevy deployment rn to edgegap. But it will give a good foundation for testing locally and in production

Will definitely try this

[tulip violet]

Does anyone have an example of changing the client transport once the bevy app is running (i.e. clicking a button etc to connect through steam vs local vs udp)?

[wintry dome]

dont have an example, but you'll need to get the ResMut<ClientConfig> i think, then replace or change the net field with a new NetConfig, per the steam example, or udp etc

https://docs.rs/lightyear/latest/lightyear/client/config/struct.ClientConfig.html

[stiff quiver]

hm pretty sure you would need to disconnect the old transport first

[wintry dome]

yeah step 1 is probably be disconnected.. make the change to clientconfig, then connect

never tried it myself

[stiff quiver]

should work given that connect() basically rebuilds everything needed

[digital cedar]

Hi I need help on hierarchy replication. How does the client recieve hierarchy replication, what special components do they have? and will they still be in a hierarchy? thank you :D

[pine cape]

This example does what you want https://github.com/cBournhonesque/lightyear/tree/main/examples%2Flobby. As others said you need be disconnect and reconnect for any transport changes to be applied

[pine cape]

HierarchyReplication should be enabled by default. There is an internal component ParentSync used to sync parent/child relationships

You can see more here https://github.com/cBournhonesque/lightyear/blob/main/lightyear%2Fsrc%2Fshared%2Freplication%2Fhierarchy.rs

[digital cedar]

I see, do they still have the ParentSync on the client side?

[pine cape]

Yes

[sudden tendon]

@pine cape I'm targeting bevy_remote so yeah just getting it ready for 0.15 via the RC1. Seems like you have it under control.

We can compare notes once you land next week or whenever

[pine cape]

If you already have some changes made, feel free to start a PR! It would be helpful for me as a starting point

[sudden tendon]

It will be a bit rough as there's no avian/leafwing/parry forks to refer to ATM. I will work something out with those and PR

[pine cape]

Just the lightyear changes is probably fine, for those it's probably better to just wait

Thanks a lot btw

[sudden tendon]

Agreed

No, thank you for all of your hard work on the crate. It's been a pleasure to use

I'm cooking up some editor/blueprint-esque stuff against this all. Looking forward to publishing that all but first things first with the 0.15

[unkempt sedge]

Question about this specific component in avian_2d example, Position. Where and how he gets updated? I cant seen to find it is like he magically just updates

Is he from lightyear itself? The imports are a little confusing

[inner hill]

Position is from avian unless you are talking about something else

[unkempt sedge]

Well it seens like rapier doesnt have that global rigidbody position.

It just directly apply to transform them global transform

[unkempt sedge]

oh boio this gonna be hard

[unkempt sedge]

pub(crate) fn replicate_inputs(
    mut connection: ResMut<ConnectionManager>,
    mut input_events: ResMut<Events<MessageEvent<InputMessage<CharacterAction>>>>,
) {
    for mut event in input_events.drain() {
        let client_id = *event.context();
        // Rebroadcast the input to other clients.
        connection
            .send_message_to_target::<InputChannel, _>(
                &mut event.message,
                NetworkTarget::AllExceptSingle(client_id),
            )
            .unwrap()
    }
}``` In the avian 3d example there is the replicate inputs to all other clients, I guess that is due to avian 2d example. But alas the entities in avian 3d are interpolated always not pre predicted like in 2d. Anyone know why is this here?

[pine cape]

Probably just a mistake

[unkempt sedge]

Avian 2d i think it is broken, gonna open a pr to slight fix both

[pine cape]

What is the issue with avian 2d?

[unkempt sedge]

It seens to be not be able to take input

In separate client and server mode

Might be something on my end tho

[frozen carbon]

sorry for the random question , I just don't know what I'm missing here 🥲

Resource requested by our_server::replicate_inputs does not exist: bevy_ecs::event::Events<lightyear::shared::events::components::MessageEvent<lightyear::inputs::native::input_buffer::InputMessage<shared_networking::PlayerActions>, lightyear::connection::id::ClientId>>

I added app.add_plugins(LeafwingInputPlugin::<PlayerActions>::default()); to the app, and the leafwing feature, is there something else necessary for this?

[frozen carbon]

Nvm, I just imported the wrong type for InputMessage 🥲 . Sometimes I feel like a moron.

[dreamy silo]

I havent managed to get it working with a nat yet. do you know when you get time writing a full tutorial for getting it running? i would appriciate it alot 🙂

[wintry dome]

I'll be back at it next week, when my kids are back at school 💪

[unkempt sedge]

oh god i finally manage to fully migrate my physics

Who did the spaceships example, deserves a godamm oscar

[unkempt sedge]

Well it seen when I add gravity into my game it breaks everything

oh god why

[inner hill]

did you filter for real entities

@unkempt sedge

vs confirmed from server ones

[unkempt sedge]

You mean apply the force only on entities predicted?

[inner hill]

Ya

and the ones on the server

[unkempt sedge]

oh

Yeah that does make sense

[unkempt sedge]

@pine cape Mr Peri, mutating the replicate components such as sync target and such will not adjust the type of replication? Like for example let say I change synctarget to one to all that wont automatically spawn predicted entities in all my clients if replication is default correct? I should use rooms correct?

[pine cape]

Mutating the components should work for some of them, for example the replication target. I'm not sure if it works for the sync target

[unkempt sedge]

I think it doesnt as a player join my lobby he adjusts the server player synctarget to predict in both him and the new guy client id. But alas he only spawns a replicated entity

I wonder what might cause that

fn listener_join_lobby(
    mut events: EventReader<MessageEvent<EnterLobby>>,
    mut lobbies: ResMut<Lobbies>,
    mut room_manager: ResMut<RoomManager>,
    player_entity_map: Res<PlayerEntityMap>,
    mut online_state: Query<&mut PlayerStateConnection>,
    mut connection_manager: ResMut<ConnectionManager>,
    mut commands: Commands,
) {
    for event in events.read() {
        let client_id = event.context();
        let lobby_id = lobbies.lobbies[0].lobby_id;
        info!("Inserted player {} unto lobby {}", client_id, lobby_id);
        lobbies.lobbies[0].players.push(*client_id);

        info!(
            "Added physics component in server for client id {}",
            client_id
        );
        add_physics_to_server_player(
            *client_id,
            &player_entity_map,
            &mut online_state,
            &mut commands,
        );
    }
}```

First he does this to the client that told to enter lobby

Them he does this for all client inside lobby[0]

 for client in lobbies.lobbies[0].players.iter() {
      if let Some(player) = player_entity_map.0.get(client) {
          info!("Inserted player unto room manager {}", player);
          // FOR NOW WE ONLY HAVE ONE ROOM
          let lobby_id = lobbies.lobbies[0].lobby_id.clone();
          room_manager.add_client(*client, RoomId(lobby_id));
          room_manager.add_entity(*player, RoomId(lobby_id));

          info!("Defining type of replicatinon for that player important to know he is from replication_group 1");
          let replicate = Replicate {
              sync: SyncTarget {
                  prediction: NetworkTarget::Only(lobbies.lobbies[0].players.clone()),
                  ..default()
              },
              controlled_by: ControlledBy {
                  target: NetworkTarget::Single(*client_id),
                  ..default()
              },
              group: REPLICATION_GROUP,
              ..default()
          };
          commands.entity(*player).insert(replicate);
      }
  }

Overiding replicate value to follow new logic

I think my question is, how does one. Tell server to start predicting new entities inside a lobby

[pine cape]

So the entity should be predicted by all players, not just one?

So the ReplicationTarget change takes effect (i.e. the entity gets replicated to the new player), but not the SyncTarget change?

[unkempt sedge]

Exactly

[unkempt sedge]

All player is lobby should predict him

My ideas was, first spawn the guy with a simple predict all. But when entering a room mutate his replicate so only players in that room should predict him

[unkempt sedge]

Here is a video of my agony

[pine cape]

Yes I think the way prediction/interpolation is design right now is a bit flimsy. It's purely a client concern but right now the setting is defined on the server which is a bit strange

[sonic citrus]

does lightyear support custom IO layers?

[pine cape]

Yes, anything that supports those 2 traits: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/transport/mod.rs#L84

[sonic citrus]

no world access there unfortunately

I've got some ideas anyway

[pine cape]

What do you have in mind?

[sonic citrus]

my IO layer is a component on an entity

I can probably use spsc

[pine cape]

Ah; otherwise one level up the stack, I have a ServerConnection resource: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/connection/server.rs#L175
I wanted to switch to having one entity per connection, where the ServerConnection is a component

but haven't had the time for that

also I'm waiting for relations to ship to make this kind of stuff easier

[sonic citrus]

what's your use case for relationships here?

[pine cape]

To be able to query stuff like Connected<ClientId> where maybe each ClientId would be a separate component

haven't thought it through to much

[sonic citrus]

ah right, you have a separate ClientId

[unkempt sedge]

Any ideas on how I can save it Mr Peri?

[unkempt sedge]

That is true it can cause a little bit of confusion

[pine cape]

Hm the logic here would have to change: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/server/replication.rs#L600
Right now i'm only updating replication if:

• replication target gets updated
• a new client gets connected

Maybe try updating the replication-target to only include the players in the lobby? In which case the logic in this function (which also handles prediction/interpolation) would apply.
Are you using rooms or ReplicationTarget::All currently?

[unkempt sedge]

Hmm, I think I just need to grab the ref to Sync Target

And do it

[unkempt sedge]

I will try my dandiest as this is my first direct lightyear pr, please evaluate

[pine cape]

I meant that you could try in your code to update the replication target, you wouldn't need to make a pr to lightyear

[mighty mason]

Hey I'm getting some compile errors related to leafwing?

I haven't used rust in awhile not sure what all of this is

[inner hill]

@pine cape sorry, haven't been able to make a repo for the rollback stuff yet

been busy with contract work

[digital cedar]

most probably pattern matching not fully covered

u need to make sure all of the enums are convered

[mighty mason]

is that not an error happening in the internals of the packages?

I thought it was

cause it doesn't happen while compiling my code its while compiling lightyear

[digital cedar]

oh looks like it is...

are u using a leafwing version that is different from lightyear?

[unkempt sedge]

oh sorry tired me sometime hallucinates

So what you are telling me is to change replication target from all to only lobby players? That oughta sync it

Oh my gawd

It worked

I sometimes ask myself if you are a wizard

[unkempt sedge]

But wouldnt it make sense to update whenever synctarge is changed?

this is for u

[wintry dome]

i'm writing docs for deploying bevygap - having to do a bit of extra work to support self-signed NATS server certs. got some unpublished changes coming up for that (so ENV var names changed etc in the Bevygap NATS Setup section). but the "Nats server setup" might be useful already https://www.metabrew.com/bevygap-book/installation/nats.html

@dreamy silo ^

i'm also in the middle of changing bevygap client plugin to use a websocket to talk to the matchmaker

so these docs aren't in sync with main atm

[unkempt sedge]

Is this kinda of like a setup for actual ingame server?

Like it scales up and down

According to user amount?

[wintry dome]

it's a system to automatically deploy servers in response to player demand, around the world

using Edgegap

so the flow is the game client clicks connect, the matchmaker waits while edgegap starts a new server near your players or finds an existing on, and then you pass back the server details to the client so it can make the lightyear connection

full tutorial pending..

[dreamy silo]

Thank you so much for this.

Definitely helpful

Will try setup later tonight or tomorrow

[wintry dome]

cool, see if you can get to the point where nats-cli is connecting. the bevygap nats bits in the book aren't in sync with main atm

[pine cape]

Try running cargo update and maybe use the main branch of lightyear?

[pine cape]

amazing!

[unkempt sedge]

but it is ifey

Sometimes works sometimes doenst

[pine cape]

hm, yea it's just a stopgap solution

[unkempt sedge]

Manage to make it work but hell am it is not pretty

hahahahaha

First need to set to none replication target

them change as if it is the same client it does not consider as changed

MR PERI look physics with lobby yay

NOW animations

and gravity that doesnt break everything

[pine cape]

very nice!

[mighty mason]

I am using the main branch and I just cargo updated still doesn't seem to work

I'm not sure what I'm doing

[workspace.dependencies]
bevy = "0.14"
bevy_egui = "0.30"
bevy-inspector-egui = "0.27"
serde = {version = "1.0.188", features = [ "derive" ]}
bincode = "1.3.3"
avian2d = {version =  "0.1.1", features = ["serialize"]}
lightyear = {version = "0.17" , features = [ "leafwing", "avian2d" ] }
leafwing-input-manager = "0.15"

[pine cape]

this uses the version 0.17 version of lightyear

[mighty mason]

?

what version do I change it to?

[pine cape]

you should use something like lightyear = { git = "../path/to/git/repo", branch = "main" }

[mighty mason]

oh alright

so the git would be "https://github.com/cBournhonesque/lightyear" ?

[pine cape]

yes

[mighty mason]

alright thank you

oh it works nice

[mighty mason]

I'm sorry for bothering you again but I'm getting another error

resource does not exist: lightyear::protocol::component::ComponentRegistry```

[dreamy silo]

I did take a small dive tonight. Good guide so far. I also took another look at synadia cloud’s option and that was definitely alot easier to setup in terms of stuff needed for the nats cli context. JWT based, just had to give it a .creds file. Their free tier would be nice to use now during development. I just need to tweak your crate a lil and add a optional nats async connection option using creds or creds file in bevy_shared

[pine cape]

it's hard to tell what's going on just from that error. The resource should exist, maybe you're using multiple versions of a same package?

[mighty mason]

thread 'main' panicked at C:\Users\poopn\.cargo\registry\src\index.crates.io-6f17d22bba15001f\bevy_ecs-0.14.2\src\world\mod.rs:1867:32:
resource does not exist: lightyear::protocol::component::ComponentRegistry
stack backtrace:
   0: std::panicking::begin_panic_handler
             at /rustc/f6e511eec7342f59a25f7c0534f1dbea00d01b14\library/std\src\panicking.rs:662
   1: core::panicking::panic_fmt
             at /rustc/f6e511eec7342f59a25f7c0534f1dbea00d01b14\library/core\src\panicking.rs:74
   2: bevy_ecs::world::World::resource_scope<lightyear::protocol::component::ComponentRegistry,tuple$<>,lightyear::protocol::component::impl$4::register_component::closure_env$0<common::player::PlayerId> >
             at C:\Users\poopn\.cargo\registry\src\index.crates.io-6f17d22bba15001f\bevy_ecs-0.14.2\src\world\mod.rs:1867
   3: lightyear::protocol::component::impl$4::register_component
             at C:\Users\poopn\.cargo\git\checkouts\lightyear-2cfb5e6660946fe3\12b95e7\lightyear\src\protocol\component.rs:1066
   4: common::player::register
             at .\common\src\player.rs:16
   5: common::register
             at .\common\src\lib.rs:48
   6: server::main
             at .\server\src\main.rs:34
   7: core::ops::function::FnOnce::call_once
             at /rustc/f6e511eec7342f59a25f7c0534f1dbea00d01b14\library\core\src\ops\function.rs:250

[mighty mason]

uhh so whats the clean command for rust packages again?

oh it's just cargo clean

mb

is there a new way of setting up lightyear now?

[pine cape]

no, nothing changed

[wintry dome]

sounds good, yeah a new env var to use JWT creds should be good

[mighty mason]

I cleaned it out completely and nothings changed

[unkempt sedge]

So I have the following issue with leafing input, I already have a predicted client spawned and aligned with in my server. And it tries to reproduce it is input message to my current client, even tho he doesnt even have a replicated confirmed entity. Any ideas on what might be causing this?

2024-11-06T10:27:39.002115Z ERROR lightyear::client::input::leafwing: received remote player input message for unrecognized entity The error message

Oh found the reason.

[unkempt sedge]

@wintry dome Hey Rj might I ask you something, in the spaceships example you add input staleness. What happens in live games, if you dont do that? Stutter teleportin and such?

[wintry dome]

it's so you can decide how many frames ahead you want to predict inputs from remote players. if your prediction is wrong, your client does a rollback to reposition players, which will look like a stutter in some cases

perhaps you think it's ok to assume same inputs as previous frame, for up to 5 frames, after that you assume no inputs. pretty safe to just ignore entirely to begin with i think, bit of a niche case

[unkempt sedge]

I tought lightyear had that imbued, then I noticed your comment

        // config.prediction.maximum_input_delay_before_prediction = settings.input_delay_ticks;```

[wintry dome]

i think lightyear may have changed those settings since i wrote spacehsips code, not sure though

[unkempt sedge]

Turns out it actually fixed my teleporting so thanks for doing it

[pine cape]

Only a fixed input delay currently works, the other input-config settings cause some issues

[frozen carbon]

just curious, what was the reason for this error?

[unkempt sedge]

I replicated inputs to entities in server that should be predicted by client

But client wasnt yet replicating

So basically i needed to set replication to only lobbie

[unkempt sedge]

Btw you were the guy who had weird telportatikb going on

I found out that constant collisions caused a lot of jittering

And flickering

No idea why

[frozen carbon]

Nah that wasn't me, I'm not even that far with my thing yet lol

[frozen carbon]

Ah interesting, that same error is happening in the avian 2d example, maybe I'll try creating a PR for it

[river perch]

Anyone have an example of how to use tnua-controller with lightyear and avian? The main issue I'm having is: the host player's movement is choppy for the non-host clients, while the clients' movements are fine on the host server's game. I'm wondering which components I need to replicate to the clients so they can properly interpolate the movement of the other players

[pine cape]

Try replicating GlobalTransform, i think that's what tnua uses under the hood

[river perch]

thanks I'll give it a try

in addition to avian's Position, or just GlobalTransform?

[pine cape]

Just globaltransform

[river perch]

i guess I should be replicating Transform too? seems like just replicating GlobalTransform, it gets out of sync with Transform on the Predicted entity on the client. I guess since GlobalTransform is built from Transform each frame, not the other way around

looks like tnua is just updating avian's LinearVelocity and AngularVelocity every frame, maybe it's enough to replicate those plus Position/Rotation. I will play around with that

[unkempt sedge]

god i have an stability issue that i have no idea what causes it

So annoying

man i swear to god everytime i cry in here i find the reason why it is amazing

[pine cape]

You need to replicate all the components that let you do prediction on the client. I think tnua uses GlobalTransform internally at some point. I remember an example using tnua where all the issues disappeared once GLobalTransform was replicated

[river perch]

is this the example you mentioned? https://github.com/panjeet/networked_cube_test/blob/master/src/protocol.rs. Looks like they commented out their GlobalTransform replication at some point, with the commit message:

try only syncing transform, and sync linearvelocity to the current player
https://github.com/panjeet/networked_cube_test/commit/7b43891cf45fc0d5fd51ee84f730ca58da65bc4d#diff-d8c31d407e43532e4152070bdaf92d7fff58c81b39b4308cad7c769519d31376. who knows which approached worked better 😆

[pine cape]

yes that was the one! Maybe try both then 😛

[river perch]

will do. appreciate the help!

[calm gale]

Is there any video tutorial for lightyear? The lightyear book example ain't that great to follow.

[wintry dome]

there are quite a few different examples in the repo under examples/ perhaps one of those makes more sense?

[calm gale]

They are all based on the same starter example.

[unkempt sedge]

You know what I think i am gonna do a cris and make a tutorial video on lightyear

[calm gale]

Would be lovely

[unkempt sedge]

But I can give you a short summary

[calm gale]

Might just also be, because i'm trying to split the code out more. Like separate app directory for server and client

[unkempt sedge]

Wouldnt do that I made the same mistake

Is better to follow the common examples crate

IF you are a newbee to network games

[wintry dome]

i have a version of the spaceships example split into a dedicated server (no gui) and client, and shared. if you build without default features per the readme i think the bevygap bits get out of the way. https://github.com/RJ/bevygap-spaceships it only supports webtransport.

[calm gale]

@wintry dome nice i'll take a look at that. Yeah I'm trying to go more towards a microservice setup with event driven message bus design and such

The use of nats is intresting. It's a combo of redis and kafka as far as i see

[wintry dome]

yeah, you need comms between the game servers and the matchmaker bits, and need a bit of key/val storage for config, so it made sense.

maybe i should have used redis, it's easier to deploy 🙂

[calm gale]

uhu i was thinking to use kafka, dragonfly and scylladb.

[wintry dome]

that's a lot of infrastructure

depends on your game i suppose

[calm gale]

i'm a infra kind of guy 😄

[wintry dome]

heh

no one inflicts that on themselves otherwise 😛

[calm gale]

for me it's more to learn about a high scaling infra for something like a game. Not the game itself 🧐

it's pretty easy to spin up such a thing in docker together with prometheus/grafana for data gathering

[dreamy silo]

I realize good infrastructure is incredibly important in multiplayer games, especially MMOs

[calm gale]

yeah. Also if you can split off the lobby manager. You can spin up new containers per lobby for example

that's why i like the prometheus support in bevy. Means you can monitor everything and scale on the load info of that for example

[dreamy silo]

Could you make containers per map/world too? And players could jump between them?

[calm gale]

in theory yes. That's sort of how they do it. Don't know how far lightyear supports it

[sonic citrus]

I'm looking at the Transport trait now, what are the guarantees I have to uphold for the packet sending and receiving? And how are the SocketAddrs used? (Especially on platforms like steam which don't use socketaddrs directly to identify clients)

My end goal is that network connections are represented as entities with the Session component in aeronet, and I want packet sending/receiving to go through Session::send: Vec<Bytes> and Session::recv: Vec<Bytes>. Just wanted to ask what the general process would be for enabling this. Probably would involve an mpsc/spsc somewhere?

[pine cape]

Transport is to send raw bytes to a socketaddr, and then you have the ClientConnection and ServerConnection traits to build connections.
Connections don't have to reuse the transport logic if the connection already has a way to pass bytes

For example for steam

I don't think having connections be entities is possible in the current design, you would have to make a PR to change how lightyear stores the ClientConnection and ServerConnection (which are in a resource currently)

[bronze elm]

that was based on Periwink’s suggestion at the time. Tnua does some weird stuff with the way it synchronize between the transforms. I spent like a week trying to fix it, debugging system ordering and could never get it perfected. Im not sure if its better with avian or whether the sync issues have gone away with subsequent lightyear fixes

[unkempt sedge]

Avian 3d example is also extremely vulnerable to breakage and sync issue

@pine cape mind if I refactor it adding forces like gravity and such?

Elements when ststionary try to correct even tho they are perfectly aligned in server

[sonic citrus]

I don't mean changing lightyear to have connections as entities, I mean the connection could point to a single Session connection entity somehow? I'm not entirely sure how this would work, but maybe the Transport trait isn't what I'm looking for and I need something higher level

pub enum ServerConnection {
    Netcode(Server),
    Steam(Server),
}

looks like this might not be possible, since the connection is hardcoded 😕

[river perch]

I've got working decently by replicating just Position, Rotation, LinearVelocity, and AngularVelocity. I am predicting Position and Rotation to all clients, and using visual interpolation: https://cbournhonesque.github.io/lightyear/book/concepts/advanced_replication/visual_interpolation.html

The client's controlled entity is a little bit jittery still so not perfect, but definitely working a lot better than before. Still gotta fine tune it

[dreamy silo]

Would it be possible to serve multiple worlds on the same light year server, just different ports?

[bronze elm]

yeah the jitter is a problem I got stuck on

[boreal inlet]

I just ran into https://github.com/cBournhonesque/lightyear/issues/684 when trying to use WebTransport on, well, the web 😄

Does anyone have suggestions for how to work around it?

[boreal inlet]

I was able to reproduce the issue with the first-party examples. I have offered a PR with an admittedly blunt fix for consideration: https://github.com/cBournhonesque/lightyear/pull/687

[wintry dome]

@boreal inlet i've run into the "ring breaks wasm builds" issue a couple of times, trying to remember how i solved it. i've also run into a gnarly silent linker failure that only causes issues at runtime (a js issue), which is fixed by using clang instead of gnu cc, at least on my machines. i build wasm with these flags:

TARGET_CC=/usr/bin/clang RUSTFLAGS=--cfg=web_sys_unstable_apis CARGO_BUILD_TARGET=wasm32-unknown-unknown cargo build etc..

i skimmed your pr to remove ring, and that seems helpful.

[unkempt sedge]

Avian physics example is broken the cubes dont movee

[unkempt sedge]

@wintry dome Rj I dont know if you have a better understanding than me when it comes to the visual interpolate. But from what I understand he should be attached to the visual entities that have position and rotation correct?

In my case scenario I have child entities that move based on transform, but well they are based on my rigidbody postion

Should I attach that component to them or nah?

[unkempt sedge]

goddamm

Found out what was my issue

camera following

LOL

[wintry dome]

ha.. yeah you're right, I put it on the predicted entities that get rendered, for position and rotation (see spaceships example)

[unkempt sedge]

FINALLY

Finally man

[wintry dome]

looks smooth 😎

[wintry dome]

actually not sure about child entities.. the interpolate stuff only acts on eg position and rotation, then that gets synced to transform, then it propagates down to children. I guess rendering happens after that so it all works out

[unkempt sedge]

Yeah avian physics set, is positioned before transform propagate independently of wether syncplugin is in post update or not. Therefore the smoothed out position interpolation occurs before propagate

[dreamy silo]

Wait, should a camera that follows be on visual interpolation?

[unkempt sedge]

No, it should follow transform normally, but it need to be set after physicsset sync, and before transform propagate

You can also try to make it follow the vec3 from position as that also would be interpolated

BUT

when rollback or lag spikes occur camera would teleport

@wintry dome Do you know what this guy sets? max_prediction_ticks: 100? I dont find him anywhere in config and in docs

[dreamy silo]

Yeah this I’ve fixed

[wintry dome]

hm, likely an old setting that isn't used by lightyear any more i expect

[river perch]

I've been struggling with a jittering camera on the client (for a FPS style camera). can the camera be a child of the Predicted entity with VisualInterpolateStatus<Position>? Or would the timing of the camera's GlobalTransform being synced not work? I have SyncPlugin running in PostUpdate

[unkempt sedge]

It is not ideal, because predicted entity transform will suffer corrections, although child visual would be smoothed out. The moment you have a lag spike, boom teleports and probable jitter

I would say you need to put your camera slightly upfront of your predicted entity

And follow predicted entity transform. With an offset that keeps player camera slightly ahead of model head.

[river perch]

I see, the camera transform can be set after the physics and correction has finished

im actually just not spawning a player model for the controlled player right now, so you won't see a head or anything in the way

[unkempt sedge]

hold up i have code for you, that way you can just follow along

here is a resutl of a quick change in my camera, warning my game is 3d and it is just a display of how it works

[river perch]

nice!

[unkempt sedge]

pub fn sync_player_camera(

    player_q: Query<&Transform, (With<Predicted>, With<Controlled>)>,
    mut cam_q: Query<(&mut CamInfo, &mut Transform), Without<Predicted>>,
) {
    if let Ok(player_transform) = player_q.get_single() {
        let (cam, mut cam_transform) = cam_q.get_single_mut().expect("Camera to exist");

        let rotation_matrix = Mat3::from_quat(cam_transform.rotation);

        // Offset actually
        let offset = rotation_matrix.mul_vec3(Vec3::new(0.0, 0.5, cam.zoom.radius));

        // Update the camera translation
        cam_transform.translation = offset + player_transform.translation;
    }
}

[river perch]

I just separated my camera from the player, just observing the scene from above now, and I noticed the jittering on the player is still there, so there must be some other correction issue unrelated to the camera I must solve 🙃

[river perch]

i'll give this a try too!

what does your Replicate config look like?

I've got this:

Replicate {
    sync: SyncTarget {
        prediction: NetworkTarget::All,
        ..default()
    },
    controlled_by: ControlledBy {
        target: NetworkTarget::Single(client_id),
        ..default()
    },
    hierarchy: ReplicateHierarchy { recursive: false },
    group: REPLICATION_GROUP,
    ..default()
}

[unkempt sedge]

Oh yeah zoom i think zoom needs to be upfront so probably negative

[unkempt sedge]

pretty much equal without hierarchy

[river perch]

are you using bevy_tnua for movement?

I heard that might be an issue, seems difficult to get it to work with lightyear

[unkempt sedge]

No wouldnt dare use it for me it is api is a little too confusing

[river perch]

ah okay

[unkempt sedge]

But if you are predicting all you should predict your entity input

[river perch]

that's just with

app.add_plugins(LeafwingInputPlugin::<PlayerAction>::default());

right?

[unkempt sedge]

No your server need to replicate it back to your client

Is like hey me client am being predicted take my input -> takes inputs -> okay here is your input by me so we can sray aligned server

[river perch]

Oh I see. right now just Position is being sent back to the client, not the server's account of the inputs, so it just teleports?

LeafwingInputPlugin does include

app.register_component::<ActionState<A>>(ChannelDirection::ClientToServer);

but I guess that doesn't replicate back to the client? I am a bit unsure about how this works tbh

this example doesn't seem to have anything other than just that plugin for inputs: https://github.com/cBournhonesque/lightyear/blob/main/examples/avian_3d_character/src/protocol.rs

[unkempt sedge]

No that just debugs

[unkempt sedge]

Exactly

[main grove]

is there any way to run lightyear servers on arm? or a way to disable steamworks because that is creating issues when trying to host a server from the examples on my arm server

[wintry dome]

there's a steam feature on the lightyear crate, maybe that's being enabled by something?

i think the examples in the repo enable all the transports by default including steam

[main grove]

ill try to port the example over to a new rust project then and see if that works, thank you!

[wintry dome]

i ported the spaceships example to a standalone project, and i build a headless server with a Dockerfile. might be worth a look - disable default features / delete the bevygap bits to get it working standalone https://github.com/RJ/bevygap-spaceships

(it just uses webtransport)

[fervent karma]

Hey, I'm just setting up a HostServer, and it seems to work pretty seamlessly with the existing code I have for networked clients, but I was wondering what happens when I set things like prediction for local players. Should I make sure that I don't set that, or will lightyear realize that local clients shouldn't be predicted even though I requested it?

[boreal inlet]

Thanks for that tip @wintry dome . I'll record the note about clang vs gcc in the related issue for posterity.

If ring is really only used for that one utility function (all it does is some light string decoding) it's probably for the best to remove it as a dependency anyway. It's a relatively complicated package with a lot going on internally, including a lot of non-Rust software.

[unkempt sedge]

Has anyone here even ran into the issue where if server replication send interval is low about 10 ms, we get constant rollbacks? \

I think only mr peri can solve that one

[sonic citrus]

is it possible that ClientTransport and ServerTransport could be turned into traits?

[pine cape]

Correct, the local client won't have any prediction or interpolation!

[pine cape]

Can this be reproduced in the examples?

[unkempt sedge]

Oh you are back mr peri thank the lord

[fervent karma]

Awesome, thank you so much! Loving the different types of clients, it seems like a genius way of solving the issue!

[unkempt sedge]

So I have the following struct

#[derive(Serialize, Deserialize, Clone, Debug, PartialEq, Component, Reflect)]
pub struct SunPosition(pub Quat);

impl SunPosition {
    /// Spherically interpolates between two `SunPosition`s by `t`, where `t` is a factor between 0.0 and 1.0.
    /// `t = 0.0` will yield `self`, and `t = 1.0` will yield `target`.
    pub fn slerp(&self, target: &SunPosition, t: f32) -> SunPosition {
        SunPosition(self.0.slerp(target.0, t))
    }
    pub fn default() -> SunPosition {
        return SunPosition(Quat::from_rotation_x(-std::f32::consts::PI / 4.));
    }
}```
In protocol
```app.register_component::<SunPosition>(ChannelDirection::ServerToClient)
            .add_interpolation(ComponentSyncMode::Full)
            .add_interpolation_fn(SunPosition::slerp)
            .add_correction_fn(SunPosition::slerp);```

I move them in server like this

fn tick_sun_cycle(
    mut cycle_time: ResMut<CycleTimer>,
    time: Res<Time>,
    mut suns: Query<(Entity, &mut SunPosition), With<SunMarker>>,
) {
    cycle_time.0.tick(time.delta());
    for (sun, mut sun_position) in suns.iter_mut() {
        if cycle_time.0.finished() {
            let t = time.elapsed_seconds_wrapped() / 2.0;
            info!("Sun should move");
            sun_position.0 = Quat::from_rotation_x(-t);
        }
    }
}```

Interestingly enough it feels like he is not interpolating to new sun position just going straight for it? Any ideas why is it because of my alpha

[wintry dome]

this looks like deterministic based on the elapsed time or ticks - can you do the calculation in systems on both server and client based on time? no need to constantly replicate the sun position data from the server.

[dreamy silo]

Resource requested by <ProjectName>::shared::shared_plugin::handle_hit_event does not exist: lightyear::server::connection::ConnectionManager

use lightyear::prelude::*; should get it right?

I split my .rs files into folder in src/, tying them together using pub use and mod.rs file in each folder. how do I make sure this resource is available across these folders? shared, client, server.

also struggling to read events in src/server/server_plugin.rs that is written in src/shared/shared_plugin.rs. not sure what thats all about. event has been added in shared_plugin.rs using app.add_event::<BulletHitEvent>();...and in server_plugin.rs fn handle_hit_event system is on .run_if(on_event::<BulletHitEvent>() after system process_collisions which should be working right? this exact logic is almost identical to the one found in the spaceships example.

I tested and event reader and writer works well if I put handle hit event system which is in server.rs originally , and move it to run locally inside shared.rs. But I don’t want server authoritative code to run on shared.rs. Not sure what I’m missing here.

[wintry dome]

that error reads that the resource wasn't inserted yet when the system tried to run. so perhaps lightyear setup on the server hasn't happened yet.

don't quite follow the question, but in my stand alone version of spaceships i use separarte crates for server, client, shared: https://github.com/RJ/bevygap-spaceships

[dreamy silo]

Actually the game which is working with lightyear runs just fine until i do something that triggers a system that requests connection manager. So stuff like connecting and handling new players has no issues. kinda strange if that’s all baked in and it’s not existing where I’m now requesting it. Not sure where/which part lightyear inserts the resource.

I’ll probably have to do some digging.

[dreamy silo]

ok so connectionmanager only lives on the server. cant run it anywhere else thats understood.

[dreamy silo]

BulletHitEvent triggering on_event and being consumed by handle_hit_event fine on client plugin but not server plugin. exact same implementation. following this implementation: https://github.com/search?q=repo%3AcBournhonesque%2Flightyear BulletHitEvent&type=code

know other events work on server because it handles connections fine. which are triggered on connection events. very strange. bleh

[stiff quiver]

@pine cape maybe it would make sense to use the existing easing capabilities of bevy_math for interpolation instead for 0.15?

[fervent karma]

Heyy, I'm trying send over a list of entities to the server (to update their targets), but I can't find a way to convert the client local Entity ids to the server ones, do I have to hand roll it?

I expected each replicated entity to have a component that is their Server Entity, but I can't find anything like that. I found lots of EntityMaps, but I can't figure out how to make use of any of them

[unkempt sedge]

Their network targets?

[fervent karma]

Nono, they're minions that move towards a target, and that's what I'm updating, just wanted to give a tiny bit of context, but I think I made it more confusing 😋

[dreamy silo]

Does lightyear help with replication of events?

[dreamy silo]

Like other than network related ones

[pine cape]

Yes that's a good idea!

[pine cape]

How are you sending the entities? Did you implement the MapEntities trait on your message or component? If so the conversion from client entity to server entity is done automatically!

[pine cape]

It's not handled automatically for now, you would have to create your own Message

[dreamy silo]

Then I’m not sure how BulletHitEvent is actually reaching server and every other client. Works when I run the spaceships example. Doesn’t work when I try to implement it in my own code exactly the same way. Tried reading the reader locally in the same file it’s being sent (shared.rs) and that works fine. Also works fine in client code (client.rs). Anything I’m overlooking? or any clever way I can debug this? @wintry dome

Shared event sender:

https://github.com/cBournhonesque/lightyear/blob/7d714079a540f3d0233a084de5a0603c7fc5caa9/examples/spaceships/src/shared.rs#L422

Client receiver (works both here and in my code):

https://github.com/cBournhonesque/lightyear/blob/7d714079a540f3d0233a084de5a0603c7fc5caa9/examples/spaceships/src/client.rs#L53

Server receiver (not working in my code, but works fine here):

https://github.com/cBournhonesque/lightyear/blob/7d714079a540f3d0233a084de5a0603c7fc5caa9/examples/spaceships/src/server.rs#L65

event struct (works both here and on my end):

https://github.com/cBournhonesque/lightyear/blob/7d714079a540f3d0233a084de5a0603c7fc5caa9/examples/spaceships/src/protocol.rs#L154

[fervent karma]

Ahh that's whta I'm missing, I kept searching for "EntityMap", but didn't try "MapEntities" 😅 Thank you!

[wintry dome]

in the spaceships example, shared::process_collisions runs on both server and client, emitting BulletHitEvent. then separate systems for client / server handle that event. so the event isn't transmitted over the network at all.

if you do an info! log at the point where shared::process_collisions emits the event, do you see that on both client and server? you should do

iirc the server uses that event to update the scores, and clients use it to show explosion effects

make sure you've only defined BulletHitEvent once and both client and server code are referring to the same struct

are you carving up spaceships into a new split server/client arrangement? i'll have a look if you've got a github link or something

[stiff quiver]

👍 made this for now https://github.com/cBournhonesque/lightyear/issues/691

[unkempt sedge]

Question I made a sun orbit timer, that is constantly being ticked by server should I make it so he has a unique channel for it. Would that make his ticks more continously? Avoiding slight time desyncs?

[dreamy silo]

Correct I’ve split them. Lemme add you to my repo and you can take a look. Info only goes out on clients. So not sure exactly what’s going on. Beat me silly if there’s a silly mistake. Added, invite should pop in now

[wintry dome]

searching for BulletHitEvent in your repo, can't see the "process_collisions" system that writes those events.

some system should be reading avian physics collisions and using a EventWriter<BulletHitEvent> to emit those events

in spaceships, process_collisions is in the shared plugin, so runs on server and clients.

heading out for bit, back in a couple of hours

[dreamy silo]

It’s in shared/shared_plugin.rs line 372

[stiff quiver]

You could have it based on current server tick which the client already syncs.

otherwise yes, having an ordered unreliable channel for that would make sense imo

[wintry dome]

ah yeah, github search was not showing everything. taking a look

@viva what's the easiest way to cause a collision? i just see my ship on the client

[unkempt sedge]

I did that

I made a resource that is ticked by server

replicate it to client, client moves according to resource timer

Thanks for the tip RJ avoiding the structuring in server spared me some time

[wintry dome]

your server_plugin is calling app.add_event::<BulletHitEvent>(), and so is the shared plugin. client_plugin doesn't.

[dreamy silo]

Right. I did that for testing.

[wintry dome]

server plugin shouldn't call add_event, just shared. dunno if that matters

[dreamy silo]

Shared should only do it I remember correctly

Didn’t matter for my part

[wintry dome]

also, although commented out, be careful about your debug_events, if you consume the EventReader<> in an Update system, the events will be gone before a FixedUpdate system runs

stick to only reading the events in FixedUpdate

[dreamy silo]

Agreed

[wintry dome]

what's the easiest way to cause a collision so i can test

[dreamy silo]

Run server, then two clients c0 and c1

Then shoot the other using arrows and space

From either client doesn’t matter

[wintry dome]

i noticed that you are only adding the PhysicsPlugin in the client, not the server. that's got the systems that apply movement and spawn bullets

[stiff quiver]

ok let me explain what i actually meant:
lightyear automatically tells the client the servers tick, now think of the server tick as a "seed" for the timer, if you then have the client use the same seed for its local timer you dont need to send anything (other than the server tick which the server automatically syncs).

ofc its a minor optimization at best but in prod we want to minimize bandwidth as much as possible

[stiff quiver]

actually offset is prob better word than seed

[unkempt sedge]

I have no idea how to get lightyear timer

[wintry dome]

i expect the problem is the server isn't running a system that it should be after you split things up

[stiff quiver]

iirc its this one https://docs.rs/lightyear/latest/lightyear/shared/tick_manager/struct.TickManager.html

[dreamy silo]

oh wow..

[wintry dome]

i'm not convinced the server is even spawning the bullet. add some logging to the code that processes player inputs and make sure that a bullet spawn happens on the server.

probably the fact that player inputs are rebroadcast means it looks like it's working on the other client, but the server isn't moving or spawning bullets

[dreamy silo]

thanks for the pointer

avian3d not working properly in server prob

its debugging the colliders tho

the ships are just small dots inside the box on server

[wintry dome]

but is the server spawning bullets in response to keypresses on clients?

[dreamy silo]

good question. theyre spawning on both clients at least

[wintry dome]

player inputs are replicated, which is separate from whether the srver does it

[dreamy silo]

yeah good pointers ill make sure bullets are actually spawned on server too. but not sure if relevant to the hitevent itself? since I am confirming that the event is being written to EventWriter with the event struct.

will debug some more later tn

thanks

[unkempt sedge]

@wintry dome Do you know of a way of cuptaring failure to connect?

Need to adapt my ui when occurs

[dreamy silo]

I think youre exactly right. I dont see bullet replication on server at all. will fix that. thank you!

[wintry dome]

iirc there's a client::ConnectionState, so you can run a system in OnEnter(client:ConnectionState::disconnected) or otherwise read that state somewhere

[wintry dome]

ah, no, you have to call .get_state() on the Client to get the ConnectionState. maybe there's an event or trigger too

[unkempt sedge]

I think I will just make an UI system that gets state when so, basically get stuck in main menu

And you can try to reconnect now that i have no idea how to do that

[desert saffron]

is there any plans to bump lightyear to the 0.15-rc anytime soon?

[dull lion]

I think I read that periwink is busy with life things at the moment. Maybe someone can prepare a 0.15 pr to help out

[unkempt sedge]

Yeah if noone is available I will do it, but I dont know the release candidate is just about finished perhaps just wait for 0.15

[river perch]

Hello, I copied this replicate_inputs system from avian_3d_character example:

pub(crate) fn replicate_inputs(
    mut connection: ResMut<ConnectionManager>,
    mut input_events: ResMut<Events<MessageEvent<InputMessage<CharacterAction>>>>,
) {
    for mut event in input_events.drain() {
        let client_id = *event.context();
        // Rebroadcast the input to other clients.
        connection
            .send_message_to_target::<InputChannel, _>(
                &mut event.message,
                NetworkTarget::AllExceptSingle(client_id),
            )
            .unwrap()
    }
}```
but it doesn't send messages for the `HostServer` client. For example, if I have 3 clients (1 host server + 2 more), the 2 non-hosts receive each other's inputs, but they do not receiver the host's inputs. Is there a simple way to emit the host's inputs as well?

[pine cape]

Hm it should work, that might be a bug

In general I would copy the avian_physics example, I think it's more trustworthy

But this looks like it should definitely work. Could you please open an issue?

[river perch]

Thanks. I can investigate further/open an issue later today or tomorrow

[unkempt sedge]

@pine cape Mr Peri, Avian physics seen to be having a problem with inputs

[tardy swallow]

I'm able to run a host server and 2 clients locally for the avian_3d_character example. I wrote the example so I may be able to help

[river perch]

thanks for checking. In my case, the players are moving correctly on each client, but what I'm having trouble with specifically is the ActionState on each predicted entity. The hostserver is using the replicate_inputs function to send clients' inputs to each other, but it doesn't work for the host player's inputs, if that makes sense

[river perch]

For context, what I'm trying to do is change each player model's animation based on that player's inputs. For example, walk animation if WASD are pressed, otherwise, idle animation. Originally I was just going to use things like velocity to determine the animation, but I don't want a walking animation if a player gets moved by something else for instance

[unkempt sedge]

Are you sending all except single?\

pub(crate) fn replicate_inputs(
mut connection: ResMut<ConnectionManager>,
mut input_events: ResMut<Events<MessageEvent<InputMessage<CharacterAction>>>>,
) {
for mut event in input_events.drain() {
let client_id = *event.context();
// Rebroadcast the input to other clients.
connection
.send_message_to_target::<InputChannel, _>(
&mut event.message,
NetworkTarget::AllExceptSingle(client_id),
)
.unwrap()
}
} yes you are

try just all

[unkempt sedge]

Holy schmokesy mind telling me what that visual interpolation plugin does, and why exactly you put sync config in postupdate?

[wintry dome]

check out the avian physics section here: https://cbournhonesque.github.io/lightyear/book/concepts/advanced_replication/visual_interpolation.html

[unkempt sedge]

oh

everything is clear now

[unkempt sedge]

app.add_systems(
FixedUpdate,
handle_hit_event
.run_if(on_event::<BulletHitEvent>())
.after(shared::process_collisions),
);

Might I ask why you do this, is an optimization technique?

[wintry dome]

do what, use the .after bit, or the run_if?

[unkempt sedge]

run_if

After is also interesting but i theorize is because you wanna despawn bullet first so two collisions dont do two damage

[wintry dome]

it's an optimisation to only run if there's an event to process, but also to self document so you know it's only needed for events. it was written before observers existed, perhaps observers would be more appropriate now

nowadays BulletHitEvent could be triggered instead of EventWriter'ed i think, then you could use an observer.

the /after is because process_collisions turns the avian physics collision data into BulletHitEvents, without the after you may end up processing the collision one frame later (eg if handle_hit_event ran before process_collisions)

[stiff quiver]

My rule of thumb is like if happens on avg less than once in 3 ticks then it should be an observer (at least thats what my benchmarks tell me)

[wintry dome]

interesting, thanks. was wondering about that

[stiff quiver]

tbh its just a random rule i made up for myself, microbenchmarks are never super reliable soo.. but from an intuitive standpoint smth like that makes sense too so yea

[unkempt sedge]

Wanna hear something interesting map_or for some reason was not as functional when it came to detecting if someone was hit as if let Ok and fill variable. Dont know why

[split zealot]

did you ever fix this? the same log spam issue exists for the reverse situation: when a server disconnects and the client cannot receive any packets.

for now i've forked the project and emit a new event so my user-space code can detect a connection error

[pine cape]

Fixed it now: https://github.com/cBournhonesque/lightyear/pull/698

[dreamy silo]

How lightyear doing for coming 0.15 release?

[pine cape]

I can do some of the bevy changes, but we'll have to wait for leafwing/avian to have 0.15 branches

[pine cape]

I started a PR for the upgrade: https://github.com/cBournhonesque/lightyear/pull/700

there is one test failing for some reason

[stiff quiver]

The leafwing test again maybe?

Yea seems to be the case

it never really worked soo shrug

[pine cape]

No it's another one

[digital cedar]

I have a question on spawning a scene from glb and then perform the networking ncessary for sub objects, what are the ways I can achieve this?

How do i spawn on server and client and have them both sync up afterwards?

[pine cape]

I think a scene is just an entity with some children entities, right?
I would either add Replicate to the parent of the scene, and all the children will get replicated recursively (if their components are registered)
or just add the scene on the client if some Message or Event has been received

[stiff quiver]

Oh okay, i just looked at the logs and they had some references to lwim

[unkempt sedge]

Master Peri, if I have a physical action that needs to make my player look at mouse position. How would you code it my current go to is something like capturing mouse motion via leafwing and them setting angular velocity according to it. Is not going well

[stiff quiver]

Yes

Thats exactly how

[unkempt sedge]

well fuck me

WHY in tarnation it is so strong

[unkempt sedge]

Hmm thing is my camera should also have a input map if she also is moved according to motion, I wonder if that is going to cause desyncs

[stiff quiver]

Hm possible, just try ig

[split zealot]

do the examples still work with steam?

doesn't seem to work for me, I'm trying out the lobby demo and after fixing the egui version mismatch i get this

2024-11-20T21:29:28.805964Z  INFO lightyear::connection::steam::server: Steam socket has been closed.
CreateBoundSocket: ::bind couldn't find an open port between 27016 and 27016
thread 'main' panicked at lightyear\src\connection\server.rs:162:18:
could not create steam server: SteamInitError(FailedGeneric("InitGameServer failed"))

my existing steamworks code works (i was using renet before), so i know it should be able to work, i'm not sure what i'm missing to get these examples running with steam

[dreamy silo]

Yeah that definitely makes sense. Hoping avian and leaf follows suit soon

[young prawn]

Avian's main branch is on 0.15 RC already

has been since Nov 1st

but no actual release yet

[dreamy silo]

Sweet

I didn’t actually check, sorry about that

[young prawn]

no worries :)

[dreamy silo]

Leaf seems to be too? Just not released yet either

https://github.com/Leafwing-Studios/leafwing-input-manager/milestone/15

Oh my bad that’s LW release

Not related to bevy version

[stiff quiver]

@pine cape what do u think about having custom data in connect tokens? Kinda like jwts

Or maybe the correct approach would be to associate the data with the connect token and sign that somehow

hm

like the problem is that if you dont want to / cant communicate from ur game server to your backend but still want to have verifyable data from the backend u need to somehow associate that with the session & sign/encrypt it with a shared key

[wintry dome]

i use the client_id for that. since you pick the client_id when making the connect token, and the token is signed, i associated other data with client_id in another place, then lookup.. but yeah you need some shared comms/db

there is a small user data field isn't there? or am i remembering renet instead

[stiff quiver]

yea but then u could immitate old state cuz its not directly associated with the current session, no?

[wintry dome]

256 bytes of USER_DATA i think

[stiff quiver]

Idt so, but possible

[wintry dome]

    /// Sets the user data that will be added to the token, this can be any data you want.
    pub fn user_data(mut self, user_data: [u8; USER_DATA_BYTES]) -> Self {
        self.user_data = user_data;
        self
    }

from the ConnectTokenBuilder

[stiff quiver]

ah

[wintry dome]

you could pass small stuff like a nickname or something in that maybe

[stiff quiver]

maybe instead pass a pubkey for the current session so we can sign that on the backend and can safely receive and verify any messages we get through the client from the backend

256 aint a lot

[wintry dome]

the connect tokens are already signed, so once a connection is established you can trust stuff the client sends you

[stiff quiver]

maybe im overthinking it and should just communicate with the backend from the gameserver

tho i dont really like it

[wintry dome]

oh sorry you're talking about comms from client to backend which is separate to the gameserver..

[stiff quiver]

yes

[wintry dome]

yeah i think you need your gameservers to be able to talk to your backend services somehow

i'm using NATS for that, since it's pubsub and also KV storage

[stiff quiver]

Ah okay

[wintry dome]

if you don't need to expose it to the web, redis might be a decent choice too

but whatever you choose it's a bit annoying because you probably want to talk to it async from your bevy game server, so you have to do some plumbing..

[unkempt sedge]

Rj how do you override default vec in leafwing do you know it?

[wintry dome]

what do you mean?

[stiff quiver]

Ugh..

Well alr

[unkempt sedge]

Like for example I want player to move in direction cam.forward, i need to override axis pair value

But it is weird is like as I override it resets

[wintry dome]

check this out: https://gist.github.com/RJ/e533e6f75cff3e5822a59c7972f0d5a3

that's for 2D, so the player turns towards where the mouse cursor is

[river perch]

Hey, anyone notice that the avian_physics example is a bit broken in main right now? Running in host-server mode right now. The client's box isn't moving in the client's game, but it is moving on the host server's client

the red box on the client, as far as I can tell, has PrePredicted, but not Predicted. There is also an entity on the client side with the single component Confirmed, pointing to the PrePredicted client box

If I spawn a 3rd client, both clients spam the following error message in the logs:

2024-11-21T16:22:47.572310Z ERROR lightyear::client::input::leafwing: received input message for unrecognized entity entity=Entity { index: 55, generation: 1 } diffs=[[], [], []] end_tick=Tick(32002)

And neither can see each other's box. The host-server can still receiver the clients' inputs and control the 3 player's boxes just fine though

I'll open an issue on github

[river perch]

https://github.com/cBournhonesque/lightyear/issues/701

[split zealot]

i got P2P working fine, so it does work at least 🙂

[pine cape]

Thanks, I found the issue. I recently distinguish between Replicated (an entity that is currently being replicated from the remote) and InitialReplicated (an entity that was initially spawned from a remote).
In the case of pre-prediction, the current ordering is:

• client spawns entity with PrePredicted
• server receives it and adds Replicated and InitialReplicated
• server observer notices the PrePredicted and transfer the authority from client to server, removing the Replicated component (since the entity is now owned by the server)
• the system in server.rs queries on Replicated, but the component does not exist anymore.

The solution is for now to update it to use InitialReplicated. It's a bit confusing annoying and not ideal but I don't see an easier fix right now

Some weird things are happening though.. even with the fix I can see desyncs, I wonder when these issues started happening

Like the client entity should be synced back to the Confirmed entity position in case of any desync

[pine cape]

@river perch I should have fixed your immediate problem, but it seems like there might be an issue with how inputs are handled for pre-predicted entities. They seem to be received by the remote client but not by the client that has the pre-predicted entity. I don't know how I introduced this because I thought I had tested the changes, but I probably introduced a bug while updating the PrePrediction logic .. Created this issue: https://github.com/cBournhonesque/lightyear/issues/702

[river perch]

Awesome! I appreciate the quick fix. I am noticing those desync issues now as well... at least they don't seem to be manifesting in non-pre-predicted entities as far as I can tell

[unkempt sedge]

Curiosity, is it common to have such an amount of roolbacks? Right when spawning my entity

And it just keeps getting higher and higher

[unkempt sedge]

Found out what is was I was adding physics bundle every frame hihi

@pine cape Mr Peri is it possible for a component in a entity, have a different authority? Or only entities may have different authorities

[unkempt sedge]

Ah you can filter out what components to send via target

[wintry dome]

i encountered a small footgun switching from a system to an observer relating to PreSpawnedPlayerObject for bullets.

my approach to the blueprint pattern for spawning stuff that is replicated involves spawning with a minimal bundle which includes a marker component, then a decorator system that filters on Added<MarkerComponent> to insert all the non-replicated physics (etc) components. i tried to switch that system to an observer on Trigger<OnAdd, MarkerComponent>

i'm using PreSpawnedPlayerObject::default_with_salt(client_id.to_bits()) , and spawning can happen on client or server for bullets. when i switched to an observer, the server's compute prespawned hash code runs when there are just the bundle's components on the entity, but the client sees all the decorated components too. must be an ordering issue of some sort. it makes the hashes different, so i can't use an observer for the decorator unless i calculate the hash myself.

here's my bullet plugin showing the two options: https://gist.github.com/RJ/e08f16e4953267ed6cfbde39003af817

[stiff quiver]

Observers generally run after all systems

[unkempt sedge]

It caused desyncs :?

[unkempt sedge]

I guess the correct approach is client replicate cam forward to other clients

And spin it in a shared system

[stiff quiver]

What?

how is this related to desyncs

[stiff quiver]

I have it serverauthorative

Shrug

Makes sense if u want to do serverside culling

[wintry dome]

what's the best way on my client to detect when another client disconnects? I want to get the disconnecting player's Player component to find their name.

if i use bevy's RemovedComponents<Player> it's too late to grab the Player component. seems like i can listen for lightyear's EntityDespawnEvent but 99% of those are useless for this

i suppose i should just make the server broadcast a message for joins/leaves

[stiff quiver]

Probably sending a msg from server

[stiff quiver]

Yup

[fervent karma]

Especially since there may be other valid reasons that a Player entity is despawned, obviously depending on your type of game

[wintry dome]

yeah taht's a good point

will send a msg from the server

[pine cape]

yeah the components are probably added too soon if you use an observer. Should the hash only be computed using replicated components?

[wintry dome]

i don't think only using replicated components would make a difference in this case - my decorator system / observer adds replicated components, so there would still be a mismatch

in fact i think it only uses components with a netid anyway, so maybe it already does that

[pine cape]

I see; in that case it's probably best to stick to using systems. The downside of observers is that they cannot be ordered

[wintry dome]

yeah. i'll probably use observers for that pattern for everything except stuff with PreSpawn

[pine cape]

Maybe the hash computation could be done in a ComponentHook (which runs before any observers), I would have to think about the ordering to see if it could work

[wintry dome]

hm, yes maybe that would work.. that would run instantly on insert i think

not a big deal, just wanted to flag it in case i missed an easier solution

[stiff quiver]

should work yes, component hooks would simply run right after command buffer application

[unkempt sedge]

This makes sense I am just wondering did you make sin cos implementation to your avian rotation?

[wintry dome]

that's built in to avian's rotation i think?

[unkempt sedge]

Oh it is 2d

Hahaha well at least the logic to grab input remains the same

[unkempt sedge]

So I was making this function that makes my player look at camera, via action input

fn camera_rotate_to(
    q_transform: Query<&Transform, With<MarkerMainCamera>>,
    mut player_action_state: Query<&mut ActionState<PlayerAction>, With<Predicted>>,
) {
    if let Ok(cam_transform) = q_transform.get_single() {
        let (yaw, pitch, roll) = cam_transform.rotation.to_euler(EulerRot::YXZ);
        println!("yaw {}", yaw);
        if let Ok(mut action_state) = player_action_state.get_single_mut() {
            action_state.set_axis_pair(&PlayerAction::RotateToCamera, Vec2::new(yaw, pitch));
        }
    }
}```

Weirdly my player rotate in a really weird manner no idea why

 let camera_rotation = action_state.axis_pair(&PlayerAction::RotateToCamera);

    let quat_rotation = Quat::from_euler(EulerRot::YXZ, camera_rotation.y, 0.0, 0.0);

    character.rotation.0 = character.rotation.0.slerp(quat_rotation, 0.1)

What am I doing wrong

[unkempt sedge]

ah great i put my x on the wron place ?>(

[hexed birch]

In the avian_physics example I'm trying to remove Velocity in replacement for manually changing x/y
But manually changing the position doesn't handle collisions correctly with avian2d.
Any ideas?

[wintry dome]

if you want to manually move stuff around maybe use Kinematic not Dynamic bodies

[wintry dome]

doing compute_hash in a hook on PreSpawnPlayerObject fixed my ordering issues. I don't think there are any downsides: https://github.com/cBournhonesque/lightyear/pull/710

ah those recent dependabot updates for wtransport need some minor fixes too, will sort it

there are compilation failures because now lightyear pulls in hashbrown @ 0.15.2, and bevy 0.14.2 uses hashbrown 0.14.5. bevy reexports hashbrown, so i think the safest approach might be to remove lightyear's dep on hashbrown and just say use bevy::utils::hashbrown; whereever it's needed?

[wintry dome]

also made a PR to fix issues caused by recent dependency updates

[unkempt sedge]

You can also just calculate the physics like my previou x was and my current x is and add a velocity according to it

Might be a pain in the ass and avian does that for you with kinematics but sometimes you dont wanna change your rigidbody i dont know

[dull lion]

Is there any way to replicate bevy events in lightyear? I suppose I could do it manually

[unkempt sedge]

Send message to target

Is a function that does that

You can send it from client to server client to another client and such

[dull lion]

yeah, that's what i meant by manually

it's not too bad though

[pine cape]

No direct way, but i agree that it would be nice to have

[dull lion]

made an issue

[pine cape]

Right now i'm trying to fix a bug where the avian_physics example doesn't work anymore for some reason.
The basic movement works correctly but it starts failing as soon as the player collides with a ball

[dull lion]

how did the job hunt go? still hectic with real life things?

[pine cape]

Got close a few times but didn't find anything i was willing to change for. I'm taking a break from it for a while

[pine cape]

The bug seems to be that the input components ActionState and InputBuffer end up on the Confirmed entity instead of the PrePredicted entity for some reaosn, not sure why yet

[dreamy silo]

Best way to send username and passwords from a system on client to a system/function on the server?

[pine cape]

I guess as a message with some encryption on top of it?

[pine cape]

Actually it's not that, i was looking at the wrong thing. The discrepancies only happen after a collision with the ball though

Disabling Correction completely fixes the issue, so it must be related to that. Also there are still rollbacks on collisions, which I thought had been fixed (cc @young prawn I think you had made collisions determinstic right?)

[unkempt sedge]

Oh yeah I was about to question that

[dreamy silo]

Yeah. Thinking of making a message channel with this. But how do I actually generate a message and consume it. Found this

https://github.com/cBournhonesque/lightyear/blob/989bc9006eb19b702ff106591d52fb6882701fe5/lightyear/src/server/message.rs

[unkempt sedge]

Spaceship, avian 3d, every single one flickers when collisions occura or rollbacks

[pine cape]

Ah you can find an example of messages being used here: https://github.com/cBournhonesque/lightyear/blob/989bc9006eb19b702ff106591d52fb6882701fe5/examples/simple_box/src/server.rs#L157

[dreamy silo]

Oh perfect just what I want

[young prawn]

Should be deterministic, yeah. Recently I also added a proper cross-platform determinism test using a transform hash, it can be seen here
https://github.com/Jondolf/avian/pull/555

[stiff quiver]

Oh well, good luck for the next round then :D

[young prawn]

*with the caveat that I think it's currently only deterministic without the parallel feature

[pine cape]

That's good to know, thanks

[dreamy silo]

followed this example, just reversing it from client to server instead of server to client like in the example. but having issue that messages are not arriving at server sent from client, then i printed connectionmanager just to have a look at whats in there and I see all the messages just stays in "messages_to_send". any ideas why it could be stuck?

[dreamy silo]

pub(crate) fn send_login_request(
    _trigger: Trigger<LoginToServerRequest>,
    commands: Commands,
    mut client: ResMut<ConnectionManager>,
    username_query: Query<&Text, With<UsernameInput>>,
    password_query: Query<&Text, With<PasswordInput>>,
) {
    info!("client: {:?}", client);
    info!("Sending login request");
    let username = username_query.get_single().unwrap();
    let password = password_query.get_single().unwrap();
    info!("username: {}", username.sections[0].value);
    info!("password: {}", password.sections[0].value);
    let mut message = LoginRequest{username: username.sections[0].value.to_string(), password: password.sections[0].value.to_string()};
    info!("Send login message: {:?}", message);
    client
            .send_message::<LoginChannel, LoginRequest>(&mut message)
            .unwrap_or_else(|e| {
                error!("Failed to send message: {:?}", e);
            });
    info!("Sent login request");
}````

my code on client side looks like this.

and on server its like this:

```/// System to receive messages on the server
pub(crate) fn receive_login_request(mut reader: EventReader<MessageEvent<LoginRequest>>) {
    for event in reader.read() {
        info!("Received login request message: {:?}", event.message());
    }
}```

protocol.rs has it all added like this:

```// Channels
#[derive(Channel)]
pub struct LoginChannel;

// Messages

#[derive(Serialize, Deserialize, Clone, Debug, PartialEq)]
pub struct LoginRequest{
    pub username: String,
    pub password: String,
}....

....         // messages
         app.register_message::<LoginRequest>(ChannelDirection::ClientToServer);

         //channels

        app.add_channel::<LoginChannel>(ChannelSettings {
            mode: ChannelMode::OrderedReliable(ReliableSettings::default()),
            ..Default::default()
        });````

made sure systems added to the app

[pine cape]

Are you running in host-server mode?

It's not obvious to me right now; are you sure that the client/server are connected?

Try setting the ChannelDirection to Bidirectional just to try

[dreamy silo]

running using ```cargo run -- server````

I guess its similar to a client, server acting like one.

[dreamy silo]

no success with changing to bidirectional.

ill go at it again tomorrow see if I get anywhere

[pine cape]

Did you run client.connect()?

[pine cape]

I just merged a simple change that should fix a subtle issue that was preventing PrePrediction from working correctly. The relevant examples (avian_physics, bullet_prespawn, etc.) should now be working much better!

The next thing i'd like to fix are the constant rollbacks in the avian_3d example, or the rollbacks that happen on ball-player contact in avian_physics example (which shouldn't happen if the simulation is deterministic and everything is working correctly)

[dreamy silo]

Running commands.connect_server()on server and commands.connect_client() on client

Don’t think I’m using client.connect() anywhere in my code

[wicked tulip]

Just to be sure I didn't miss anything. The best way to sync a 3d Transform is to create separate components for position, rotation and scale.

There is not a way to define for an existing component (like Transform) how it should be networked correct?

(like with quantization, interpolation etc.)

[earnest rover]

I am struggling a bit with how to organize my code again after a two month break, forgotten a lot, and trying to simplify and understand again.
I have this map with hexes (which are only local to the client there will be many more hexes), and insert Occupied and Base on them, as well as adding replicate. This works fine except for the mapping to the correct hex.
I store the hex on the Occupied and Base components and thought I could use that to look up the correct hex on the client. Attaching a picture, and some code that tries to explain it.
Ideally I would be able to lookup on receiving a message in my own maptable what entity (Hex) it belongs to.

Probably I'm going about the wrong way, but I hope intentions are somewhat clear. Any pointers?

    base: Query<&Base>,
    occupied: Query<&Occupied>
) {
    for event in reader.read() {
        if let Ok(occupied) = occupied.get(event.entity()) {
            if let Some(parent) = map.entities.get(&occupied.hex){
                if let Some(mut entity) = commands.get_entity(*parent) {
                    entity.insert(occupied.clone());
                }
            }
        }


        info!(
            "Received component Occupied insert for entity: {:?}",
            event.entity()
        );
    }
}```

[wintry dome]

broadly speaking, the client performs an action like clicking a hex to set it to occupied or whatever, the client input, eg ActionState, is sent to the server. perhaps the actionstate is an enum including ClickedToOccupy(hex_coords, etc). the server executes the logic to update the game state based on inputs, and any changes to hex entities on the server would autmatically be replicated to clients, as long as the components are in the protocol. So things like Occupied components would automatically replicate to clients. So you'd just do a query for Query<...., Added<Occupied>> or something on the client

if you're including entities in your messages/components you can implement MapEntities (iirc), check the examples for usage. that will translate the server entity to client entity for you once replicated.

[earnest rover]

A few months ago I had it like that, but I do not transmit each hex anymore. I have every command working on another branch, but the code to lookup stuff got too complex. So thats why the maps are now disconnected and not transmitted other than Base and Occupied

[earnest rover]

I looked at the MapEntities, but did not understand how I would be able to include my own mapping. But if it's the way to go, I'll try and explore som more.

[wintry dome]

the simplest approach is probably to have each hex be an entity with replicated components like Occupied, and use mapentities where needed. there may be an upper limit on scalability with that approach though..

not very lightyeary, but you could also have client/server store their own hexmap data structure and use command pattern: server broadcasts commands which mutate the map state, using an ordered reliable channel. then your map can be massive with minimal replication bandwidth, assuming commands are deterministic

[earnest rover]

This is kind of what I had before, and not very bevyish either. Trying to clean up and understand my code a bit better and "go with the bevy flow"

[pine cape]

No, you can network Transform or GlobalTransform directly. An interpolation function for Transform is provided here: https://github.com/cBournhonesque/lightyear/blob/5845699d02ee953b73fa6f341224fe0df9dfa12b/lightyear/src/utils/bevy.rs#L10-L10

MapEntities is just required if you have components that contain other Entities.
Lightyear will make sure to 'translate' the entity inside the component from the local world to the remote world when it's replicated. Apart from that you don't really need to worry about much.
Does your Occupied or Base component contain another entity?

[earnest rover]

No they don't. They just don't get attach to the hexes on the client. since they don't match up between the worlds.

And I'm not sure it's solvable either 🙂 Just something I'm trying

[pine cape]

No but I mean what does the component actually look like?
Is it

   tile: Entity
}

or

pub struct Base {
   tile_x: int,
   tile_y: int,
}

[pine cape]

and what is Hex

[earnest rover]

is just ```pub struct Hex {
/// x axial coordinate (sometimes called q or i)
pub x: i32,
/// y axial coordinate (sometimes called r or j)
pub y: i32,
}

[pine cape]

Then why does it not work? You can just use the Hex x, y to find which entity is being referred to, no?

[earnest rover]

Because when I want to show the base indicator (the red in the image), that is a transormation on child of the Hex, with an Occupied component. I run HostServer, and the image is on the server. On the client the Base and Occuped does not attach to the Hex (understandebly so)

But you are right, I am thinking about this in the wrong way again I think. I'll take a step back, make some food and start again.

[pine cape]

Sure, let me know. But this situation can definitely be handled with lightyear. Parent-child hierarchies can also be replicated

[earnest rover]

Cool. I'll check out that before I start going further.

[unkempt sedge]

Is it wise to rreplciate transform tho? As of my knowledge a lot of bevy components contains pre bundled transforms

[unkempt sedge]

Ah this would be very cash moneh

[earnest rover]

FYI; I reverted back to to keeping the in game state (related to each hex) beeing totally seperated from the visual hexgrid. If the entity ids were predictable (for the visual hexgrid, looking at Entity:from_raw) I think the approach would have worked out of the box. But since it was warned not to use it, I did not go that route. Also I could not figure out how to bend lightyear my way with regards to this, but it works pretty good as it is now, like @wintry dome described.

[dreamy silo]

Where can I see what port by bevy server/game is running on? Would it be possible to run multiple bevy worlds on different ports on the same server?

[pine cape]

You choose which port to use in the server config; and yes you should be able to have multiple bevy words on different ports

[dreamy silo]

what's a non-bevy way of accessing number of connected clients to existing lightyear server? want to try to do sequential clientid assignment and let user just do cargo run -- client and get the next available spot.

[wintry dome]

the clientid is inside the connect token. so in a production setting whatever issues connect tokens could keep track if you want sequential numbers. for dev, using Authentication::Manual, I use a random number unless it's specified with a command line arg.

[dreamy silo]

any benefits to using random number in production or is it just easy that way? with sequential I guess there is a larger risk of connect token/client id collisions.

[wintry dome]

i'm generating random clientids for prod, but i don't have it linked to a database or anything. i suppose if you have a db of user accounts you might make the clientid the same as the primary key for the user table or something like that

random is easiest unless you already have a user database i think

if you really need to know the join order of players i would insert a specific component with a sequence number for that, rather than depend on client id

[dreamy silo]

yeah thats the thing, im working on a user database rn. I dont see how client_id is related to say a userid, so i was thinking of keeping userid and clientid seperate and let only lightyear take care of client ids, and userid is database stuff. since client_id kinda is just the id to the actual device/machine thats connected? or am i misunderstanding the meaning of a clientid?

only clientid relation ill make in the user database might be a column like "last_clientid" and "current_clientid" assigned upon login and logout. incase I gotta debug and ive logged out clientid instead of userid somewhere.

[wintry dome]

i think as long as you have a way for game servers to lookup the user from a client id it'll be fine

[dreamy silo]

found where this is done. but think ill just do random client_ids for now too. will keep them short for easier reading until i figure out seq numbers. not really a big deal having them random anyways. the chance of it being assigned a identical one as a already connected client is probably pretty slim at u64.

[unkempt sedge]

@pine cape So I am refactoring a little bit of the avian_3d example, and I noticed there is a setting called max_prediction_ticks, I think now is called maximum_predicted_ticks. Also it seens that feature might be buggy, a least a few discussions mentioned it is it still? Although I am not sure is this comment still valid https://docs.rs/lightyear/latest/src/lightyear/client/prediction/plugin.rs.html#80

[pine cape]

Yep it's buggy still

I haven't figured out how to update the InputBuffer if the input delay is changing dynamic ally

That's the only missing piece

[unkempt sedge]

Kays, also in avian_3d_physics, the parallel feature is enabled might be breaking deterministic

Gonna fix it and check it out

[pine cape]

I think even without parallel there is no determinism, or there's still extra rollbacks for some reason

[unkempt sedge]

Yup you be right on that

[unkempt sedge]

@pine cape Stale inputs ...

[pine cape]

?

[unkempt sedge]

I think i figured out what it is, I will test it out and make sure

[stiff quiver]

Finally got around to working on the webrtc transport thingy :)
Its a lot more annoying to implement than ws/wt but whatever. One question tho, is there any way you know of to use env or smth with rust cuz having to hardcode turn server credentials into the app sounds kinda like a bad idea @pine cape

maybe i should just let the user handle that and just let them supply an basic/bearer auth string

its a bit awkward security wise either way since any user could just "steal" the turn server credentials no matter how we store it since they need to authenticate with them

Maybe the best option would be to generate credentials for each new connection on the fly

but again thats something the user has to do themselves

[wintry dome]

i have my server generating a new self signed cert each boot, which is fine when there's a matchmaeker that can pass the digest to the clients. would be useful to have an http server plugin that lightyear could use to serve up the connect token and cert digest. would make wasm clients much easier to play with

[stiff quiver]

http servers are pretty heavy tho, this should be a separate app / server

Maybe useful for dev but thats all i think

[dreamy silo]

I finally got time to setup my nats server up and running last night. Felt great. Will continue on the bevygap stuff later tonight

[unkempt sedge]

++

[pine cape]

One of the examples shows how the server can pass the connect token to the clients

[wintry dome]

I was thinking of wasm clients. I think the example uses a TCP socket

[unkempt sedge]

@pine cape I think the issue was correlated to input delay, i increased by 12 and now he seens to have low amount of rollbacks. Even with more clients

For some reason when he reached 3 KABOOM

Now he doesnt do that anymore

It seens the delay caused for very stale inputs to be passed to the apply_character action function causing some sort of rollback loop

[pine cape]

Well if delay is high there is no delay yea

But even if 0 delay, there shouldn't be any rollbacks with only one player

But there are

[unkempt sedge]

In my current state I only have one

But only if I eliminate the block from sample

pub(crate) fn set(&mut self, tick: Tick, value: &ActionState<T>) {
        let Some(start_tick) = self.start_tick else {
            // initialize the buffer
            self.start_tick = Some(tick);
            self.buffer.push_back(BufferItem::Data(value.clone()));
            return;
        };

        // cannot set lower values than start_tick
        if tick < start_tick {
            warn!("You set a tick lower thant the start tick in input buffer");
           return;
        }

The cause lied in this function https://github.com/cBournhonesque/lightyear/blob/5845699d02ee953b73fa6f341224fe0df9dfa12b/lightyear/src/inputs/leafwing/input_buffer.rs#L99, when he has a input delay of about 6, he tries to grab a tick that is a lower than start tick so he just returns and doesnt set tick.I added a warning but basically the entire vecdeque from buffer breaks

He goes kaboom like this

Now why dont know probably because input delay diminishes by -6 or something like that, going way before start tick

[pine cape]

Can you try adding an explanation in the PR so I can review?

[unkempt sedge]

https://github.com/cBournhonesque/lightyear/pull/716

It is not fully functional I am just trying to figure out what is causing the rollbacks. But alas you can see what I am trying to do

[unkempt sedge]

God finally figured it out

Gravity + input delay are the two main reasons

[dreamy silo]

Nice. Do you mind sharing how you fix them? I might be encouraging similar issues with my game

[unkempt sedge]

.

[fervent karma]

Hey, I finally got around to trying this, but it's not triggering automatically, and I don't understand how it would do it automatically, but it seems you have to do something extra. I put printlns in the implementation and it's not being called.
I have this for now:

#[derive(Component, Serialize, Deserialize, Clone, Debug, PartialEq)]
pub enum Inputs {
    Direction(Direction),
    Spawn,
    Target(Vec<Entity>, Vec2),
    None,
}

impl MapEntities for Inputs {
    fn map_entities<M: EntityMapper>(&mut self, entity_mapper: &mut M) {
        match self {
            Inputs::Target(entities, _) => {
                for entity in entities {
                    *entity = entity_mapper.map_entity(*entity)
                }
            }
            Inputs::Direction(_) | Inputs::Spawn | Inputs::None => todo!(),
        }
    }
}

How is this intended to work?

[pine cape]

You also have to add something like .add_map_entities() when registering the component in the protocol

[fervent karma]

Okay I figured there was something like that, I just couldn't find it when searching, thank you!

Hmm, I've run into a bit of a sang. The thing I'm trying to entity map is the inputs, as you can see, however internally when you add the input plugin it adds a message of InputMessage<Inputs>, but there's no implementation of MapEntities for lightyear::inputs::native::InputMessage. It looks like there's one for the leafwing InputMessage though, so I'm guessing this was just forgotten?
Also the user experience of mapping entities for inputs can definitely be improved, as it's not immediately obvious that you need to wrap your InputMessage.
Also I saw your comment in add_map_entities: "or should we just have add_message_map_entities and add_component_map_entities?", and to answer your question, if you split it up you can add extra bounds on the two new functions, Message and Component respectively, which would remove the issue that I just had of calling add_map_entities::<Inputs>(), which silently does nothing

For now I'll try migrating to leafwing to unblock this, but I'm happy to raise a ticket (and make a PR if want 😄) for this

[pine cape]

I didn't expect you to apply MapEntities on the inputs, I don't think this is supported. Even the MapEntities implementation for leafwing inputs is for pre-prediction and not for users

[fervent karma]

Ah, hmm

Maybe I'm using inputs for the wrong purpose. I'm trying to have an input that when you right click it'll update the target position for the currently selected minions (so it takes a list of minions and a new target position), and then in the server input handler it updates the targets, which then updates the minions (and it's then replicated and stuff), should I just be using a normal message for this?

[pine cape]

I would use normal messages for this

but I think it makes sense that inputs should try to support stuff like that

i'll open an issue

Also the update for bevy 0.15 is basically ready, I'm just waiting for new avian and leafwing versions to be released to also release a new version

[fervent karma]

Now that I look at it closer that'll make the implementation for the leafwing InputMessage really difficult, since you can't have a different implementation based on whether the inner type supports it or not 🤔

[pine cape]

yes I would have to change the way leafwing input works

[unkempt sedge]

@pine cape Question replicated entities inbound from server that are predicted should they cause rollback with one sole client?

[pine cape]

No there should never be rollbacks with one client

If client and server worlds are deterministic

That's why avian_physics shouldn't rollback on collisions

[unkempt sedge]

Perhaps sleeping is screwing things up too once I disable it they stay at 0 unto a collision occurs

[pine cape]

Btw rollback-ing resource should be supported since https://github.com/cBournhonesque/lightyear/pull/622

[unkempt sedge]

WEll hot digiity damm

How I rollback it tho i know how to replicate it

[pine cape]

stepper.client_app.add_resource_rollback::<TestResource>();

[unkempt sedge]

Lovely thanks

[pine cape]

Oh, another todo is to switch the interpolation logic to bevy's new Curve trait

[unkempt sedge]

@pine cape Yeah warm collisions was the cause of breakaage

[fervent karma]

Does anyone have good ideas for how to implement prediction ergonomically? The only way I can come up with is to implement it twice, but one adds an extra filter for Predicted, and then two systems. Ideally I would have a system that I could just add to both my server and client plugins and it would just work

[unkempt sedge]

My prefered method is spawn in server replicate with sync target, in client use added predicted. It keeps things nice and umderstandble

Also necessary when using lobbies

[fervent karma]

I do that too, I meant for like predicting the movement of an NPC (or the player) I have to implement the logic twice, since the client needs it to only affect Predicted creatures, but on the server it should affect everything

Obviously in a simple case the only change is adding a filter, but in the most complicated case you have to change the logic slightly to account for the fsct that you may need data from all of them, but only update some

[pine cape]

You can have a shared system with a Filter that works for both server and client-predicted entities: https://github.com/cBournhonesque/lightyear/blob/main/examples/bullet_prespawn/src/shared.rs#L186
I use ReplicationTarget on the server to only target entities that are replicated to the client

[pine cape]

just let me know if your PR fully fixes the rollback issue. What do you mean by warm collisions

[unkempt sedge]

Something in avian, some sort of magic that stored previous collision values to apply contact forces

After removing it the rollback loop

Stopped

[pine cape]

You disabled it via

        app.insert_resource(NarrowPhaseConfig {
            match_contacts: false,
            ..default()
        });
```?

[unkempt sedge]

Yeah

Interesting enough we still have rollbacks only when collision occurs with two clients, but I oughta to think that is expected

Also they dont seen to be uncontrollable, the remain decent so just like once in a while

[unkempt sedge]

Sincerely I disabled so much stuff that I dont even know anymore what is fixing it

[pine cape]

yes that is unavoidable, the only thing to fix is rollbacks happening with 1 client

[pine cape]

I tried running your branch but i still see constant rollbacks on collisions, with only 1 client

[unkempt sedge]

wut

[unkempt sedge]

Might I see it? On my end I only have some weird rollbacks when spawning

[pine cape]

i'm just jumping on the purple cube

[unkempt sedge]

Interesting, on my end

[unkempt sedge]

Does it occur frequently? Oh wait it sometimes occur sometimes it doesnt

[unkempt sedge]

Well at least I can say it did help

[earnest rover]

I'm tweaking my leave/enter lobby and trying to stop and start the server and connect, and I see some leaks (I think) with regards ControlledEntities which seems to remain after stopping the server in HostServer mode.

on_connect_host_server spawns it, but on_disconnect_host_server does not despawn it.

Not sure I'm looking at the correct spot in the code though, could there be a bug?

I can remove it manually, if my scenario is a bit off

[unkempt sedge]

Yeah I tried everything, removed each component that might be causing rollbacks on collision but well nothing. Interesting enough sometimes it works, sometimes it doesnt. Probably is deterministic and sometimes it isnt. When more strong collisions or multiple occur it seens determinism goes kablooei

When simple ones occur, like static rigid for example it remains okay

Perhaps advancing with deterninism test would be more efficient

[pine cape]

Good catch; this should fix it: https://github.com/cBournhonesque/lightyear/pull/722

[earnest rover]

Thanks for the quick turnaround!

[digital cedar]

when registering a component, how do I make it such that it just syncs by overriding rather than having a interpolation?

interpolation:

        app.register_component::<MaxHealth>(ChannelDirection::ServerToClient)
            .add_prediction(client::ComponentSyncMode::Full)
            .add_interpolation(client::ComponentSyncMode::Full);

is it like this?

        app.register_component::<MaxHealth>(ChannelDirection::ServerToClient)
            .add_correction_fn(|_, x, _| *x);

[wintry dome]

sounds like you want add_prediction with ComponentSyncMode of Simple

that will just replace the client's component on the predicted entity with server values as they arrive without any interp

[digital cedar]

I see

[pine cape]

You can also just completely disable prediction/interpolation and just let the replication override the value every time it's updated

[wintry dome]

so don't call add_prediction or add_i nterpolation - does that mean the client only has a confirmed entity?

[sonic citrus]

I'm curious, if I decided to send 100000 messages along a reliable ordered channel, is it guaranteed that all 100000 will make it to the other side? Or is it undefined what happens when you do that kind of extreme thing?

[unkempt sedge]

Replicated in this case, confirmed only occurs with predicted entities

[wintry dome]

good to know!

[digital cedar]

wait if the entity is interpolated and predicted at the same time, how wud it work?

cuz I have other components that are both predicted and interpolated in the same entity

[digital cedar]

has anyone tried hosting server via port forwarding? how was the process?

[unkempt sedge]

Although your entity has a replicate struct that interpolates and predicts, doesnt mean your component should necessarily follow the same replication logic

Since it is max health, i think the goto should be

app.register_component::<MaxHealth>(ChannelDirection::ServerToClient)
.add_prediction(client::ComponentSyncMode::Simple);

Simple only mutating when you tell server to mutate that component

[digital cedar]

I see so in this case, only server shud be mutating and client shud not touch it right (if we want it to be in sync that is)

[unkempt sedge]

Exactly

You can make it so client defines it but you know if competitive great chance hackers might abuse that

[digital cedar]

ok I tried, it is as simple as portforwarding then sharing yr public IP

[pine cape]

You should get the 100k messages

[pine cape]

3 entities are created: the Confirmed (is updated every time the server gets an updates), the Predicted, and the Interpolated

[stiff quiver]

Just like how u would do that usually, open the port on the firewall and then forward it trough your router

[earnest rover]

@pine cape , I would just like to give a shoutout. Once I got past not understanding anything, to understanding something, your library works GREAT! Really awesome work has been done in lightyear!

[pine cape]

Thanks! Really appreciated

[unkempt sedge]

@pine cape Mr Peri how can we buy you a cofee?

I followed the style of built you used on steam

And it was perfect

Also you should clear your stale branches

[pine cape]

No need, just appreciating the library is enough 😉

[unkempt sedge]

@pine cape Gonna be honest here, perhaps it would be best we make lifetime persistent the common usage the amount of warning I get because of entity despawn before hand errors is a biggie, just my opinion tho

[pine cape]

the easiest solution might be to have a despawn_without_warning function in bevy

Do you get this on the client?

The warnings should be fixed by https://github.com/cBournhonesque/lightyear/pull/724

[unkempt sedge]

Fire, now when I test my bullet spawn, it doesnt annoy me. Still gonna use persistent, that way I HAVE THE POWAH

Oh btw I am making a tutorial about your crate if you dont mind

[split violet]

Can you dm me or tag me the link, if this becomes available at any point? I'm new to bevy and lightyear and I don't really understand how messages are supposed to be transferred across applications (server/client). I've looked at the examples, but I can't really find out how to do it:
I looked at some of (https://github.com/search?q=repo%3AcBournhonesque%2Flightyear MessageEvent&type=code).
Here's my pretty minimal example:
I define a Message: https://github.com/phaack/troopy_bevy/blob/b2872634c470a7f7315e145a28eb5bec62100b1d/src/game/networking/messages.rs#L15
Then I send that even on the client:
https://github.com/phaack/troopy_bevy/blob/b2872634c470a7f7315e145a28eb5bec62100b1d/src/game/core/interaction/ui.rs#L151
Then (onUpdate?) I try to receive the Message on the server:
https://github.com/phaack/troopy_bevy/blob/b2872634c470a7f7315e145a28eb5bec62100b1d/src/game/networking/server.rs#L72
Where the client and server use the protocol w/ SharedPlugin:
https://github.com/phaack/troopy_bevy/blob/b2872634c470a7f7315e145a28eb5bec62100b1d/src/game/networking/protocol.rs#L50

[unkempt sedge]

You are doing it wrong here https://github.com/phaack/troopy_bevy/blob/b2872634c470a7f7315e145a28eb5bec62100b1d/src/game/core/interaction/ui.rs#L151

You are not defining the target, and you are actually using bevys, send function

Instead of lightyear send_message, this is how you send a message in lightyear

fn my_system(
  tick_manager: Res<TickManager>,
  mut connection: ResMut<ClientConnectionManager>
) {
   // send a message to the server
   connection.send_message::<MyChannel, MyMessage>("Hello, server!");
   // send a message to some other client with ClientId 2
   connection.send_message_to_target::<MyChannel, MyMessage>("Hello, server!", NetworkTarget::Single(2));
}```

@split violet https://www.youtube.com/watch?v=sJL4ClWfioE&ab_channel=altpotato Sure I am about to actually targer that theme

[split violet]

Alright, but how do I receive the events then?

fn received_send_troops_message(mut events: EventReader<MessageEvent<SendTroopsMessage>>) {
    for event in events.read() {
        println!("Received SendTroopsMessage: {:?}", event.message);
    }
}

Doesn't seem right as a system. (At least I don't seem to receive anything) when using:

let mut msg = SendTroopsMessage {
                    action: SendTroopsAction::default(&start_entity, &end_entity),
                    player: Player::new(Some(1)),
                };
let _ = connection.send_message::<GameChannel, SendTroopsMessage>(&mut msg);

(https://github.com/phaack/troopy_bevy/blob/3de52e043d44f3eff927111eb00b37eaec2b9292/src/game/networking/server.rs#L82)
Sorry, if this is somewhere in the docs, but I seriously don't see much in the docs. I guess I must be blind

I also make sure to add the channel, so that shouldn't be a problem:

app.add_channel::<GameChannel>(ChannelSettings {
            mode: ChannelMode::OrderedReliable(ReliableSettings::default()),
            ..default()
        });
``` (https://github.com/phaack/troopy_bevy/blob/3de52e043d44f3eff927111eb00b37eaec2b9292/src/game/networking/shared.rs#L34C9-L37C12)
I'll check out your linked video out now, sorry if that's already shown there.

[unkempt sedge]

https://github.com/phaack/troopy_bevy.git I dont see anywhere in your code where you do this send_message

[split violet]

I think you might need to refresh the page, if you still have it open from previously - I pushed a fix like you said from above: https://github.com/phaack/troopy_bevy/blob/3de52e043d44f3eff927111eb00b37eaec2b9292/src/game/core/interaction/ui.rs#L155
[I'm also certain that it actually gets executed]

[wintry dome]

has anyone used lightyear wasm client in firefox sucessfully, with webtransport? it never seems to work for me. (fine in chrome)

[stiff quiver]

yea but you need to use ff nightly iirc

cert hashes arent in stable release yet

or smth like that

[wintry dome]

ah, ok so hopefully not too long before it Just Works?

[stiff quiver]

i think its a bit like with safari support, not enough ppl care about WT because it only has the quite niche usecase of gamedev atm

[tardy swallow]

Setting that replication group for characters in avian_3d_character to something not used by the purple blocks appears to stop the constant rollbacks.

Now, rollbacks only trigger when a character interacts with a purple box but will constantly trigger rollbacks until the boxes stop moving despite the character no longer interacting with it before it stopped. Not sure why. There are rare occasions where the rollbacks do not stop ever. More characters results in higher chance of nonstop rollbacks

Spawning the boxes with an initial velocity (thus motion without the intervention of a client) does not trigger rollbacks.

Characters interacting with other characters does not trigger rollbacks and yet characters interacting with the purple boxes does.

[pine cape]

Hm I would expect that all predicted entities have to be in the same replication group to guarantee that rollbacks work correctly

[wintry dome]

i'd like to be able to compile the examples as dedicated servers without having to compile steam or gui stuff. although you can run them just as a --server at the mo, it's all still compiled in

i'll add suitable features to examples_common

[unkempt sedge]

Hmm what fixed constant rollback for me was increasing input delay which makes sense when you come to think about it

Constant rollbacks on dynamic bodies collision tho seens to be an issue correlated to avian determinism

I think Periwink had a test for that, interesting enough with rapier I dont get the same result as in there is no rollbacks with collisions

[unkempt sedge]

Is there an observer for connect events?

It will be pretty cool if it did

[tardy swallow]

I added some log statements before and after the physics systems execute. On the server side, a purple block will be completely stationary (it's position, rotation, & velocity are unchanging). On the client side after a rollback where a block's physics-related components sync with the server, I see that after the physic systems execute there is an incredibly small linear velocity applied to the block that de-syncs the client block's position and rotation by an incredibly small value. Before the physics systems executed, the block was sync'd and did not have any velocity, force, impulse, or angular velocity. There shouldn't be any velocity applied to the block as it should be completely stationary. My guess is that there is state information within avian that avian_3d_character isn't rollbacking.

I also tried disabling contact matching in the narrow phase:

app.insert_resource(NarrowPhaseConfig {
    match_contacts: false,
    ..default()
});

I also tried setting avian to the commit https://github.com/Jondolf/avian/pull/480 (currently lightyear uses an older version of avian that doesn't include that commit) but to no avail

[unkempt sedge]

Is client world, a new world type manipulated by you or is it just bevy native world?

[stiff quiver]

just bevys native world

[pine cape]

ConnectEvent on client side: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/client/networking.rs#L373
ConnectEvent on server side: https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/server/events.rs#L57

[pine cape]

I thought that lightyear was using a version that had https://github.com/Jondolf/avian/pull/480
It's possible that some resources that are needed are not being rolled back

It might be possible to just rollback these resources

[unkempt sedge]

You mean collisions?

[tardy swallow]

Ah you're right, my bad. I didn't do a git pull in a while and see that the dependencies were updated.

[pine cape]

There's a few resources that are used by avian to handle collisions correctly, yea

[stiff quiver]

just a thought:

• have two servers
• one gets the authority for handling all the physics and other gamelogic related systems
• the other one is the one that all clients get connected to and handles all io and replicates the world forward to the clients from the "game logic" server while preprocessing inputs for the game logic server

isnt that basically star citizens server meshing with native lightyear? :o

not sure if this actually works but if it does would be a cool poc

s1 would need good single core spd and s2 would need as many cores as possible to handle as many clients as possible

smth like that

[wintry dome]

if anyone can't build on wasm: (will fix properly in due course, down a rabbit hole atm..)

# TODO 0.3.3+ is a breaking change.. pin to 0.3.2 for now
bevy_web_keepalive = "0.3.2"

field name in WebKeepalivePlugin changed. and bevy 14->15

[stiff quiver]

oh no i totally forgot doing that

shoulda been a major version change

err minor

But not patch

[pine cape]

good to know, thanks!

[wintry dome]

it's always a painful time waiting for various deps to support the newest bevy versions after release

[pine cape]

yea

[stiff quiver]

whats wrong with having a branch that doesnt compile for a few weeks :'D

[wintry dome]

i'm adding some conditional compilation bits to the examples and refactoring cargo files in order to be able to build the examples as headless servers and/or wasm clients. will do a draft pr for more discussion once i have something legible to show

ultimate goal to conditionally compile in bevygap plugins and host all the examples on edgegap 🙂

[pine cape]

that would be so cool

[wintry dome]

would be great to provide an easy route to hosting a game on edgegap if you use lightyear. making a simple game work locally is only half the battle at the mo

[unkempt sedge]

If a user acess via the same local machine, is there a chance it is client_id would differ?

For example, in save_files I intend to use client_id as acessor to that user info. Or would I need to make some sort of unique user and password for it? If sowell fuck

[pine cape]

You can choose the client_id

[unkempt sedge]

What does that entice?

Imagine a on production environment, tho. Would I be able to choose it is client_id even so?

[wintry dome]

in production your game will contact a matchmaking service (a different app to your game server), which will give it a ConnectToken (and game server ip+port). this matchmaking service can decide what client_id to put into the connect token. sometimes this requires the user to sign in via oauth or something, so the client_id might be related to a database record for the user.

[unkempt sedge]

Ah I see

[unkempt sedge]

Bidirectional component will only mutate bidirectionally, if client is also replicating it?

[wintry dome]

can anyone help with my cargo/deps problem?

bevygap has a dependency on lightyear.
i'm currently working on a feature branch of lightyear, and i've added bevygap as a dep to lightyear.

I want bevygap's lightyear dep to use my local checkout of lightyear (ie, path = "./lightyear") but i don't know if this is possible with cargo's patch system. can't get it to work.

if i don't use the exact same version of lightyear then it fails because bevygap code can't find the lightyear resource (because bevygap has compiled a different version of lightyear so it's technically not the same resource the game has inserted)

[stiff quiver]

Hm interesting. Why wouldnt this work tho?

[patch.crates-io]
lightyear = { path = "./lightyear" }

[wintry dome]

# bevygap for deploying on Edgegap
bevygap_server_plugin = {git = "https://github.com/RJ/bevygap.git", tag = "v0.2.2"}
bevygap_client_plugin = {git = "https://github.com/RJ/bevygap.git", tag = "v0.2.2"}

# Make sure bevygap's lightyear dep is our exact version:
[patch."https://github.com/RJ/bevygap.git"]
lightyear = {path = "./lightyear" }

i tried this, since my bevygap dep is from github

[stiff quiver]

Okay maybe to clarify;
your structure is like this?:

a = lightyear depending on bevygap
b = bevygap depending on c
c = current lightyear without bevygap

now you want b to use a instead of c?

[wintry dome]

in fact, in the bevygap cargo file, it has this dep for ly:
lightyear = {git = "https://github.com/cBournhonesque/lightyear.git", rev = "5845699d02ee953b73fa6f341224fe0df9dfa12b", default-features = false}

structure at present without patches is:

lightyear (local checkout) depends on bevygap from github
bevygap from github depends on lightyear pointing to a specific github revision

i want to patch it so bevygap uses the local checkout of lightyear

[stiff quiver]

okay that should work, the other way around would be circular dependency which im pretty sure doesnt work

[wintry dome]

using cargo tree i can see that the bevygap_client_plugin (for example) is causing the wrong lightyear dep to be pulled in. ie it's pulling the one from its cargo file, not my patch to point to ./lightyear

[stiff quiver]

Pfew yea no idea why, as far as i understand thats the way you are supposed to do that

https://doc.rust-lang.org/cargo/reference/overriding-dependencies.html

[stiff quiver]

maybe its trying to pull the dep from local cache for some reason? Unlikely but i'd at least check and clear build cache

[wintry dome]

oh wait, i've committed my cargo.lock to bevygap repo, that seems like a bad idea

[wintry dome]

removing that lock file didn't help

and i nuked my local lock file and did cargo clean 🤔

[stiff quiver]

:/ im out of ideas

[wintry dome]

ah i think i've got it:

[patch."https://github.com/cBournhonesque/lightyear.git"]
lightyear = {path = "./lightyear", version = "0.17.0"}

that patches anything trying to use that github url for lightyear, which is what bevygap does. phew.

and pretty sure the version not necessary

[stiff quiver]

gg 💯

[dull lion]

I wonder how hard it would be to support https://github.com/projectharmonia/bevy_enhanced_input in lightyear. I'm guessing adding another input crate introduces a ton of edge cases, and if it lives in the main crate it introduces yet another bottleneck for keeping lightyear up to date with bevy. So probably, in order to support it you'd need to abstract away LWIM support in Lightyear behind some sort of input adapter interface

(and then implement support for LWIM/bevy_enhanced_input as separate crates implementing the interface)

[wintry dome]

https://rj.github.io/lightyear/simple_box/

in chrome^

i've got the build system for wasm and servers working, but i've only deployed spaceships and simple_box so far: https://rj.github.io/lightyear

hi whos on the german server

[dull lion]

me

seems to work!

[wintry dome]

cool

try this one? https://rj.github.io/lightyear/spaceships/

[dull lion]

seeing a little bit of stuttering/flickering

[wintry dome]

hmm your ping is ~80ms. can't remember what the input delay and settings are tbh. it's not at all tuned well

pretty smooth here, at ~67ms

[dull lion]

it is smooth like 95% of the time

[wintry dome]

i'm working on the infrastructure for deployment atm, but def want to get that buttery smooth at some point

[dull lion]

some of the flickering was purely graphical. like, the border around the arena was flickering a bit during rollbacks I think

[wintry dome]

yeah i've noticed that

[dull lion]

tbf i'm in an environment with uh... adversarial network conditions aka terrible wifi, which might explain the stuttering

[unkempt sedge]

The cause of that is rollback on physical collisions

A VERY annoying bug

[wintry dome]

some non-determinism still lurking yeah

[unkempt sedge]

The stuttering is probably non adaptable input delay, with high latency certain configs should be adjusted

[wintry dome]

i don't think the input delay is auto-adjusting based on lag, perhaps it should be. and need to review defaults / minimum value. i feel like it shouldn't drop any lower than input delay of 3 ticks for spaceships

i have a PR onto my own fork so i could trigger workflow runs. here's the changelog and todo list: https://github.com/RJ/lightyear/pull/1

[pine cape]

Awesome! simple_box works well for me, but on spaceships my inputs don't seem to do anything

[pine cape]

I have added settings to adjust the input_delay based on lags; but there are still some edgecases where it doesn't work. (for example if the input_delay increases on a given tick, then you might have two inputs sent for a given tick, or no input sent for a tick)

[pine cape]

I think it should be do-able; I would maybe first try to add support for bevy_enhanced_input directly, and then abstract it away once the similarities are better understood

[wintry dome]

I noticed this, fixed with a refresh weirdly

[pine cape]

LWIM had some careful work done to make sure that inputs work well within the FixedUpdate schedule, we would have to check if bevy_enhanced_input has the same

Yeah the re-render on rollback is a bit annoying, idk why that happens

[split zealot]

dumb question, by default there aren't any conditioners added that would cause visual jitter, right?

[dull lion]

No. Best guesses are that you are either experiencing rollbacks or you’re using the fixed schedule but not interpolating transforms

[split zealot]

i am interpolating the transforms, but badly! 😅

i really want to use avian physics but the lack of motor support is a blocker, so i'm using rapier. syncing up the transforms has been tricky fs

[split zealot]

if rapier uses transform/velocity as the source of truth, what's the best way to interpolate those values for clients? would it be adding transform/velocity to the protocol or creating a new component that copies the source transform every fixed update?

i'm confused as to whether the replication is reading the world state during the fixed update or the normal update

[pine cape]

Replication is reading the world state at a given tick t during FixedUpdate

Yes I would try adding Transform to the protocol

[wintry dome]

@pine cape the issue where spaceships occasionally ignores user input.. i'm suspicious that it's because here: https://github.com/RJ/lightyear/blob/examples/examples/spaceships/src/client.rs#L81 maybe Controlled is added too late, and the entity already got replicated to the client without Controlled, and Controlled would probably come in the next packet. does that sound plausible?

[wintry dome]

it looks like that shouldn't be possible. the spaceships server inserts the Player component and the ControlledBy all at once when spawning ships for newly connected players.

[wintry dome]

could it happen that clientside the Predicted component is inserted on a different tick to Controlled (or my Player component i suppose), causing that system not to notice our own player? i wanted to look at the "copy replicated components from confirmed to predicted" logic when an entity is received on the client, but can't find it

[unkempt sedge]

To be completely honest the added based systems tend to be a little unstable. Because of the when we replicate our other component. Of course you could ensure running them after the set responsible for replication. But I personally just make observers

[unkempt sedge]

With rapier I think it is simpler, since he directly applies changes in transform. You can just make transform itself the rollbackable. Of course you will need to ensure system ordering is okay and that he ticks according to fixed_timestep_hz.

I think you will also need to make him visual interpolate, via the visual interpolate plugin. No 100% sure on that one.

[wintry dome]

hm, well i caught it with the ignoring-inputs error but it definitely detected the controlled player and added the input map, so back to the drawing board.

[wintry dome]

it would probably be nicer as an observer now, but i have to find out what the cause is first..

[pine cape]

It's in the client/prediction folder, it's weird that this doesn't happen with fake network conditions

[stiff quiver]

@pine cape do yk if i just need to impl this myself for js val?

or should i convert this into a str?

cuz this is a js Error wrapped in jsvalue

so in theory i can just .toString() it

[stiff quiver]

this seems to work

[unkempt sedge]

@pine cape Say Mr Peri, I have a currency struct. And of course I want my server to validate if player can have that amount of currency. My currenct workflow is as follows, I change predicted entity (Player in this case) and inform server of that adjustment. Server checks and if he okays it he changes confirmed, and the resource that stores the currency amount of that client. If not he rollbacks, is that the correct approach?

[pine cape]

You just have apply the same logic on the predicted or confirmed entity. (client vs server)
It's possible that the predicted entity has a different currency amount temporarily, but eventually the server value will become the source of truth

Same with collisions; it's possible that on the client there is no collision. But on the server that actually is a collision, so the entity loses some health points on the server and the changes are applied via rollback to the client entity

[unkempt sedge]

Wait so the logic confirmed ->predicted

Oh my

well not gonna lie that lowkey kinda sucks when you want to apply local changes, and later validate them. For example, players tests skin. Can he still hold it after?

But i guess it makes sense

[unkempt sedge]

Perhhaps I shoudl try to update lobbies example to use rooms, in my view they are pretty much the same thing

[pine cape]

It already uses rooms

[wintry dome]

i wrote a cli tool to interact with the edgegap api, so now examples/ server builds can automatically update the docker tag configured in edgegap for insta-deploy https://crates.io/crates/arbctl – now i can say arbctl application patch-version simple_box v1 --patch /docker_tag '"sha-1234567890"'
i'm using it to migrate all the examples stuff into a Lightyear org within my edgegap account for now

[unkempt sedge]

oh yeah it does well i be dammed

[pine cape]

I tried upgrading to the latest leafwing version, seems to work well.
Although the examples have a bunch of changes needed + bevy-screen-diagnostics

[wintry dome]

cool. are all the other lightyear deps on 0.15 now?

[pine cape]

just need avian, which will upgrade end of this week

bevy_screen_diagnostics might need some more work though... maybe i'll switch to one of the other libraries

[wintry dome]

there's iyves something or other i wanted to try

[pine cape]

yea same

[wintry dome]

https://github.com/IyesGames/iyes_perf_ui

[pine cape]

https://github.com/IyesGames/iyes_perf_ui

lol

[wintry dome]

jinx

[pine cape]

not released 0.15, but seems to be on 0.15-rc3

[wintry dome]

quite a few changes to examples stuff in my examples branch, gonna suck to merge that after 0.15 change.. but i've only done 2.5 of the examples so far

[pine cape]

maybe merge them now?

I've only changed bullet_prespawn for now

[wintry dome]

actually should be fine to upstream what i've done, i left the default features so they would behave as it does now (building gui for everything)

could be worthwhile, because i moved some of the common ui stuff to lightyear_examples_common, so that would probably be the place to add a debug perf ui. but i don't have much free time for the next 3 weeks, and it might be a pain if you're doing 0.15 work.

did you take a look at the diff?

https://github.com/RJ/lightyear/pull/1

are you happy with the cargo file refactoring to push deps up to the top level workspace cargo file? i think it's sane, not sure if there any downsides apart from a big ugly diff.

[unkempt sedge]

Perhaps it would be wiser to just make a very simple perfui on lightyear itself

For what I know all the variables like rollback and such are easily acessible

[pine cape]

yeah i'd prefer that actually

[pine cape]

I love the changes, I think they make sense!

We can do it in whichever order you prefer, i'm fine with merging your changes before the 0.15 upgrade

Your changes are amazing btw

[wintry dome]

great. i responded to the review comments you left. i'll try and get things tidied up enough to merge, even though i've only got a couple of the examples working on wasm so far. we'll just need to disable the new workflows while i'm still working on it in my fork.

[plain charm]

looking at using lightyear for a project, and I was curious if there were any plans or context around server migrations (or w/e it’s called, voluntary switchovers or some kind of post-server-crash designated survivor)

Thing is, it’ll be a long while before I’ll ever need it, and I could contribute to a generalized lightyear implementation later on, if it’s within the crates scope

[pine cape]

What do you mean by server migrations?
A server crashes, a new one gets spawned automatically and all the clients switch to talking to that new one without loss of user data?

[plain charm]

In that general ballpark, yeah. Also, transferring to new hosting server, or between Separate and HostServer modes, etc

Plenty of complexity, naturally.

[pine cape]

It is currently possible for clients to disconnect from a server and connect to a new one; I guess most of the work would be:

• how to serialize the state of the World on the previous server
• load it in the new server
• update the entity-mappings on the client and make sure that the replication doesn't spawn new entities on the clients

[plain charm]

Right, and I’ll bet there’ll be lots of unexpected cases to resolve. At the moment though, I was planning on writing my own specialized, project-specific implementation later. But, it might be better to contribute a general implementation to lightyear instead, if the author/maintainers believe that feature to be in scope

[pine cape]

Sure that would be worthwhile; it would probably be as a separate project/plugin

Let me know if you encounter any blockers

[wintry dome]

what's the earliest schedule to render something once it's been VisualInterpolated?

right after transform propagate?

[wintry dome]

ok this is in decent shape now to merge i think. i got clippy/lints etc down to zero, but there are 4 failing tests – but i don't think they are necessarily due to my changes. https://github.com/cBournhonesque/lightyear/pull/732

i'll continue the examples refactoring in a follow-up pr later, but i switched all of them to use workspace deps so it should be easier to upgrade to bevy 0.15 in the meantime

[pine cape]

I merged it for now, can follow up on smaller PRs. I disabled the Edgegap workflow; the other two have the message "This workflow has a workflow_dispatch event trigger."

[wintry dome]

btw the Edgegap workflow isn't from my branch.. the new ones are called "Build WASM frontend" and "Build servers for examples", which will both (harmlessly) fail on your branch at the mo so can be disabled to reduce noise.

[pine cape]

Yep; there's just no button to disable them for some reason

[pine cape]

@wintry dome do you get warnings like lightyear_examples_common::renderer::handle_disconnection did not run because it requested inaccessible system parameter Res<Events<DisconnectEvent>> when you run with --server?

I imagine they go away if I run with only the feature server enabled (instead of both client and server)

but it would be nice if fiddling with features wasn't necessary at runtime

[pine cape]

I've ported the auth example, but right now it's a bit cumbersome because the user must run the examples with cargo run --features client -- client and cargo run --features server -- server which is not ideal

[wintry dome]

i put server and client in the default features, so for most people running the examples they shouldn't care about changing features and it should work like before in terms of how you launch it. feature changing only needed if you want to compile a headless server (--no-default-features -F server)

we could change the cli bit so if only server feature is on, and client disabled, assume "server" (ie, no need to pass that on the command line)

same for client. if server feature disabled we could just run the client without passing "client"

but doubt people just trying out the examples need to care about that really

[wintry dome]

i'll have to check this and get back to you. it's possible i left a system in that should be cfg'ed out (and the change to bevy 0.15 generates a new warning)

[stiff quiver]

is that even necessary? could conditionally compile in server and/or client runner in based on the feature usage, dont really see any why a -- server/client argument would even be necessary in the first place 🤔 sure it means your compile time is basically double but its still more ergonomic to not have to specify server/client as a parameter

iirc cargo has feature specific cache now too, so not even iterative builds should be a problem, otherwise having different --target-dir's might make sense, i did that for an old project

[pine cape]

Because when server and client features are enabled you could still do host-server or client-and-server

[stiff quiver]

okay but thats not really a huge issue i think? compile in both client and server feature -> specify mode with additional flag like before

[pine cape]

I don't think there's any huge issues, I just want to think about this a bit to not hurt the ergonomics of examples

[stiff quiver]

makes sense; imo having default modes might make sense, server mode if we compile in server feature only, client mode if client feature and client-and-server if we compile in both. Host server mode is in my experience less useful than client-and-server so maybe having to toggle that via a flag or an additional third feature might make sense

features are pretty much the standard way to do this kinda thing in rust after all

so i'd expect this to be much more ergonomic for the avg user instead of a cli

[pine cape]

Agreed

[unkempt sedge]

Is there an example, off a interpolatable/rollbackable transform component? I think I saw one here

[wintry dome]

https://github.com/cBournhonesque/lightyear/blob/main/lightyear/src/utils/avian2d.rs#L15 i think these 3 groups each need a .chain() after them, otherwise they ordering is undetermined. the outer chain only puts the 3 tuples in order. within each tuple it's undetermined. same in the avian3d plugin

if i'm right that would cause all kinds of weirdness 🤔

at least the 3 physics sets should be chained, anyway

yes but also with a chain at the end (second to last line)

edit your message to add?

                ).chain(),
            ).chain(),  // <---
        );

[unkempt sedge]

impl Plugin for Avian2dPlugin {
    fn build(&self, app: &mut App) {
        app.configure_sets(
            FixedPostUpdate,
            (
                // run physics after setting the PreSpawned hash to avoid any physics interaction affecting the hash
                // TODO: maybe use observers so that we don't have any ordering requirements?
                (
                    InternalReplicationSet::<ClientMarker>::SetPreSpawnedHash,
                    InternalReplicationSet::<ServerMarker>::SetPreSpawnedHash,
                ).chain(),
                (
                    PhysicsSet::Prepare,
                    PhysicsSet::StepSimulation,
                    PhysicsSet::Sync,
                ).chain(),
                // run physics before updating the prediction history
                (
                    PredictionSet::UpdateHistory,
                    PredictionSet::IncrementRollbackTick,
                    InterpolationSet::UpdateVisualInterpolationState,
                ).chain(),
            ),
        ).chain();
    }
}```

[wintry dome]

yes. that's the same as not having the three sub-tuples and just having one chain. but perhaps the InternalReplicationSet bits could run in any order. we definitely need the physics sets to be chained though. i expect your above message was the original intention of the code

@pine cape can you comment on that? could it be a source of non determinisitic stuff with physics

[unkempt sedge]

oh it seens you are right, when doing sole tuple you let them run in parallel

[wintry dome]

perhaps the avian plugin is enforcing the ordering for us, i'm not sure

seems like it should inherit the ordering from the avian plugin, although we have a few places where we still use FixedUpdate. should get all the examples over to FixedPostUpdate, the avian default. #1124043933886976171 message

what's happening in the spaceships example, is lightyear adds its Avian2dPlugin (or 3d), which configures the schedules in FixedPostUpdate without chain, which doesn't matter because the schedule ordering is setup using chain() by avian's PhysicsSchedulePlugin which also uses FixedPostUpdate. the spaceships example then does app.add_plugins( PhysicsPlugins::new(FixedUpdate)... so avian chains them in FixedUpdate.

so the sets get configured in FixedPostUpdate, and then in FixedUpdate. presumable they don't run twice.. really need to change to use FixedPostUpdate anyway, that will remove some of the confusion.

[unkempt sedge]

how are you running examples, in this new lightyear version. Keep getting some werid certificates error

Could not deserialize the settings file: SpannedError { code: MissingStructField { field: "certificate", outer: Some("WebTransport") }, position: Position { line: 39, col: 17 } }
note: run with RUST_BACKTRACE=1 environment variable to display a backtrace

[wintry dome]

the examples are being refactored a bit at the mo since the recent commit by me in main, some of them need more work.for that error, add this to your settings.ron:

        server: ServerSettings(
             ...
             transport: [
                WebTransport(
                    local_port: 5000,
                    certificate: FromFile(     <---------- this bit
                       cert: "../certificates/cert.pem",
                       key: "../certificates/key.pem",
                    )
                ),

or this:

            WebTransport(
                local_port: 5000,
                certificate: AutoSelfSigned(["localhost", "127.0.0.1"]),
            ),

in which case it will generate a self-signed cert each time the server starts

(i just made PR #734 to fix that)

[pine cape]

I thought it was fine because all these sub-groups are already ordered in different places: https://github.com/Jondolf/avian/blob/v0.1.0/src/schedule/mod.rs#L75

But yes everything should be moved to the same schedule

[pine cape]

I did what you said, I think it's not bad!

[stiff quiver]

nice 💯

[wintry dome]

working on porting some examples for 0.15. are we just getting rid of ScreenDiagnostics for now?

we also don't need FixedSet::{Main, Physics} any more, now we'll be using avian's default of FixedPostUpdate. we can simplify and just put our example systems in FixedUpdate

i like the required components change
