Avian Physics

[severe urchin]

wasn't sure how to make a collider from a torus

[low storm]

How to create new SharedShape from old SharedShape ? My system receive event include &SharedShape to create Collider, but I could not clone Arc object from it.

[low storm]

I guess this is right Collider::from(shape.clone())🥲

[rough nebula]

Is there any difference between setting physics speed and setting physics time step?

Like id assume they do the same thing right?

[vestal minnow]

Physics time step controls how frequently physics runs. Like the refresh rate on your monitor. Simulation speed controls how fast the actual simulation looks, allowing slow-mo or fast forward (fast-mo?)

Running physics more frequently is more expensive but can improve simulation quality

[rough nebula]

Oh right i thought step made the simulation go faster lol

[clever quail]

Fair

Instead of using hollow shapes or an approximation I just used joints which did a good enough job, other solution would have have taken too long to load

[glossy holly]

in avian 2d, do both of these conditions have to be met or just one?
https://docs.rs/avian2d/latest/avian2d/collision/struct.CollisionLayers.html

[glacial nebula]

@vestal minnow do you plan on yoinking the avian picking backend for 0.15? bevy_mod_picking is on track for deprecation.

[vestal minnow]

Both

Docs should probably be clarified though

[vestal minnow]

Yup, I intend to yoink it and put it behind a bevy_picking feature flag (probably enabled by default)

[fiery mortar]

I have some general design questions on how to implement a kinematic character controller in avian3d. My plan is to update the linear velocity of my character using shape-casting before the phsics step. Is this the right approach? Won't this mean my character could end up colliding with other moving kinematic rigidbodies at the end of the physics step?

[fiery mortar]

Or maybe I'm confused on how avian works. The kinematic character controller example here https://github.com/Jondolf/avian/blob/main/crates/avian3d/examples/kinematic_character_3d/plugin.rs#L295 says "speculative collision". What does this mean, exactly?

[clever quail]

Is there a bundle for removing all physics stuff, I spawn an object with a bundle containing

    pub rigid_body: RigidBody,
    pub collider: Collider,
    pub collider_density: ColliderDensity,
    pub dominance: Dominance

Is there a bundle of all physics components that may be generated so I can remove them all as I only do physics on gamestart and rather not run it after its done

[crimson crest]

As far as I'm aware, Avian will always allow all bodies to "collide" kinematics just lack built in response behavior, so its up to you to handle the response. There shouldn't be any issue with two entities running collide and slide hitting eachother as long as they're both working with linearvelocity

[clever quail]

the list of removables

physics_stuff.remove::<(
                ColliderParent,
                ColliderMassProperties,
                Mass,
                InverseMass,
                Inertia,
                InverseInertia,
                CenterOfMass,
                ColliderTransform,
                LinearVelocity,
                AngularVelocity,
                ExternalForce,
                ExternalTorque,
                ExternalImpulse,
                ExternalAngularImpulse,
                Restitution,
            )>();

rest I cannot remove

[lunar bluff]

is there a cleaner way to get the normal of the contact manifold depending on whether the queried entity is entity 1 or 2?

let normal = if entity == event.0.entity1 {
    event
        .0
        .manifolds
        .iter()
        .next()
        .and_then(|m| Some(m.normal1))
} else if entity == event.0.entity2 {
    event
        .0
        .manifolds
        .iter()
        .next()
        .and_then(|m| Some(m.normal2))
} else {
    None
};

it seems that entity is consistently equal to entity1, but I'm not sure if I can depend on this, there seems to be no distinction between 1 and 2 in any documentation, so I have to write code like the above

would be good to be able to convert the Collision event into one that is relative to a given entity, so 1 and 2 become "this" and "other" for example. Something like event.relative_to(entity), returning Option<RelativeCollision>, where None is returned if it doesn't match entity1 or entity2

[fiery mortar]

I don't understand the example. If I set the velocity in the collision response behavior, is that velocity used in the current step?

[fiery mortar]

If I understand the example correctly, then velocity set in the collision response will be applied in the next physics update, right? At the end of the physics step, my kinematic rigidbodies will still be colliding, right?

[obsidian maple]

Curious why PhysicsLayer requires implementing Default - shouldn't the default just be the empty mask?

Btw @vestal minnow, I noticed that the PhysicsDebugPlugin emits a ton of validation errors each frame on main:

        Validation Error: [ SYNC-HAZARD-READ-AFTER-WRITE ] Object 0: handle = 0x555559a1ba80, type = VK_OBJECT_TYPE_QUEUE; | MessageID = 0xe4d96472 | vkQueueSubmit():  Hazard READ_AFTER_WRITE for entry 3, VkCommandBuffer 0x7ffee80ccfa0[main_transparent_pass_2d], Submitted access info (submitted_usage: SYNC_VERTEX_ATTRIBUTE_INPUT_VERTEX_ATTRIBUTE_READ, command: vkCmdDraw, seq_no: 3, reset_no: 37, debug_region: main_transparent_pass_2d). Access info (prior_usage: SYNC_COPY_TRANSFER_WRITE, write_barriers: SYNC_FRAGMENT_SHADER_COLOR_ATTACHMENT_READ|SYNC_FRAGMENT_SHADER_DEPTH_STENCIL_ATTACHMENT_READ|SYNC_FRAGMENT_SHADER_INPUT_ATTACHMENT_READ|SYNC_EARLY_FRAGMENT_TESTS_DEPTH_STENCIL_ATTACHMENT_READ|SYNC_EARLY_FRAGMENT_TESTS_DEPTH_STENCIL_ATTACHMENT_WRITE|SYNC_LATE_FRAGMENT_TESTS_DEPTH_STENCIL_ATTACHMENT_READ|SYNC_LATE_FRAGMENT_TESTS_DEPTH_STENCIL_ATTACHMENT_WRITE|SYNC_COLOR_ATTACHMENT_OUTPUT_COLOR_ATTACHMENT_READ|SYNC_COLOR_ATTACHMENT_OUTPUT_COLOR_ATTACHMENT_WRITE|SYNC_SUBPASS_SHADER_HUAWEI_INPUT_ATTACHMENT_READ, queue: VkQueue 0x555559a1ba80[], submit: 7, batch: 0, batch_tag: 192, command: vkCmdCopyBuffer, command_buffer: VkCommandBuffer 0x555559c53550[(wgpu internal) PendingWrites], seq_no: 8, reset_no: 1).
2024-10-29T20:59:18.770377Z ERROR wgpu_hal::vulkan::instance:       objects: (type: QUEUE, hndl: 0x555559a1ba80, name: ?)

[vestal minnow]

TLDR: PhysicsLayer is a trait you can derive for enums to make each of their variants represent a collision layer. On the main branch, the first bit is reserved for the default layer. We added the Default restriction to make this default layer explicit and prevent footguns.

Long explanation, starting with some background: Collision layers in Avian are specified for colliders with the CollisionLayers component (similar to bevy_rapier's CollisionGroups). Previously, the default was that every collider belongs on every layer, and can interact with every layer, meaning that all bits in the bitmasks are set to 1. I originally just copied this from Rapier.

However, we realized that this is very impractical and doesn't make sense in practice. It means that you can't e.g. perform ray casts targeting a specific layer without overriding everything, since all colliders belong to all layers by default. So, we changed the defaults on the main branch in #476 such that colliders only have one membership and all filters by default. The first bit in the bitmask is reserved for this default layer. This is the same as what the Box2D physics engine does.

To clarify what PhysicsLayer is for: it's a trait you can derive for an enum to use it for CollisionLayers. It's not something you're intended to manually implement for anything. Using it on the main branch looks like this:

#[derive(PhysicsLayer, Default)]
enum GameLayer {
    #[default]
    Default, // Layer 0 - the default layer that objects are assigned to
    Player,  // Layer 1
    Enemy,   // Layer 2
    Ground,  // Layer 3
}

// ...

// Player collides with enemies and the ground, but not with other players.
let layers = CollisionLayers::new(
    GameLayer::Player,
    [GameLayer::Default, GameLayer::Enemy, GameLayer::Ground],
);

If you have an enum value that is a PhysicsLayer, it must obviously represent some layer. You can't have an enum value that doesn't represent any of its variants. You can have empty CollisionLayers though, but it wouldn't make sense as a default, since then nothing would collide by default.

Now, finally the reason PhysicsLayer requires Default. Since the first bit is now reserved for the default layer, it means that one of the enum variants (typically the first one) is also the default layer. This is implicit and could be very confusing if you are not aware of this. So, we added the Default restriction in #494 to force users to explicitly specify "this variant represents the default layer", i.e. the first bit.

(wow, that became long 😅)

[obsidian maple]

got it thanks 🙂

[vague pebble]

Is there an easy way to see your colliders, like a debug mode in aviann?

[vague pebble]

Or make like a semi visible capsule

[vestal minnow]

Yup, you can add the PhysicsDebugPlugin

[vague pebble]

oh wee

[fiery mortar]

what does LinearVelocity mean when running the physics simulation in FixedUpdate? is LinearVelocity not units per step?

[vestal minnow]

It is

or no, I mean units per second

misread

So, for example LinearVelocity(Vec3::new(5.0, 0.0, 0,0)) would move towards positive X at 5 units/s

[fiery mortar]

thanks. Followup question, is there a way to configure the plugin so that it represents velocity per step? Otherwise, what's the most reliable way to convert from velocity per step to velocity per second?

[vestal minnow]

I'm not exactly sure what you mean by velocity per step, but if you mean converting "units per fixed delta time" to "units per second", then I think it's velocity_per_step / time.delta_seconds(), where time in your case is Time<Fixed>

[vague pebble]

So I was trying to setup my server to be able to handle avian physics. I got this error related to the debug plugin I think.

impl Plugin for SharedPhysicsPlugin {
    fn build(&self, app: &mut App) {
        // Leafwing input plugin handles the whole leafwing shenanigans
        app.add_plugins(LeafwingInputPlugin::<CharacterAction>::default());

        // SETUP FOR MAKING OUR PHYSICS WORK
        app.add_plugins(
            PhysicsPlugins::new(FixedUpdate)
                .build()
                .disable::<SyncPlugin>(),
        );
        app.add_plugins(PhysicsDebugPlugin::default());
        // We change SyncPlugin to PostUpdate, because we want the visually
        // interpreted values synced to transform every time, not just when
        // Fixed schedule runs.
        app.add_plugins(SyncPlugin::new(PostUpdate));
        // Position and Rotation are the primary source of truth so no need to
        // sync changes from Transform to Position.
        app.insert_resource(SyncConfig {
            transform_to_position: false,
            position_to_transform: true,
        });
        // Setting timestep to same rate as fixed timestep hz
        app.insert_resource(Time::new_with(Physics::fixed_once_hz(FIXED_TIMESTEP_HZ)));
        // Setting up gravity
        app.insert_resource(Gravity(Vec3::ZERO));

        // Make sure that any physics simulation happens after the input
        // SystemSet (i.e. where we apply user's actions).
        app.configure_sets(
            FixedUpdate,
            (
                (
                    PhysicsSet::Prepare,
                    PhysicsSet::StepSimulation,
                    PhysicsSet::Sync,
                )
                    .in_set(InputPhysicsSet::Physics),
                (InputPhysicsSet::Input, InputPhysicsSet::Physics).chain(),
            ),
        );
    }
}

I encountered this panic
Resource requested by bevy_gizmos::update_gizmo_meshesavian3d::debug_render::configuration::PhysicsGizmos does not exist: bevy_asset::assets::Assets<bevy_gizmos::LineGizmo>
note: run with RUST_BACKTRACE=1 environment variable to display a backtrace
Encountered a panic in system bevy_gizmos::update_gizmo_meshes<avian3d::debug_render::configuration::PhysicsGizmos>!
Encountered a panic in system bevy_app::main_schedule::Main::run_main!

Any ideas on what type of adjustment i need to do to my physics debug plugin gizmos to avoid this?

[vague pebble]

FIgured it out

app.configure_sets( FixedUpdate, ( ( PhysicsSet::Prepare, PhysicsSet::StepSimulation, PhysicsSet::Sync, ) .in_set(InputPhysicsSet::Physics), (InputPhysicsSet::Input, InputPhysicsSet::Physics).chain(), ), ); this is nono

[bold garnet]

there's an avian backend in bevy_mod_picking @vestal minnow

are you interested in taking ownership/splitting that out at some point?

[vestal minnow]

Yes #1124043933886976171 message

[bold garnet]

Great. Heads up, I'm going to try to do an end-of-life update to the existing avian backend, moving it to 0.15 but still using the legacy bevy_mod_picking version. We'll leave it to you to publish a version for the upstreamed picking version.

[vestal minnow]

FYI Avian isn't using the 0.15 RC yet, but I intend to finish the migration today/tomorrow. I also can't do a release yet since I'm blocked on some other dependencies

[bold garnet]

no worries, we are also blocked on a release

[obsidian maple]

@vestal minnow Is the correct way to "pause" physics to set the timestep to zero in Time<Physics>?

[vestal minnow]

Time<Physics> should have a pause method (through an extension trait)

[obsidian maple]

Great thanks, found it

[obsidian maple]

I think Physics::fixed_hz doesn't exist anymore?

Oh, maybe I'm to use with_relative_speed now to force the resource to be created

Er no, that can't be right

oh, I can use default

[vestal minnow]

Since physics on the main branch runs in FixedPostUpdate by default, you can just use Bevy's own Time::<Fixed>::from_hz now (the generic is optional there)

[obsidian maple]

if you don't set the resource, what happens?

Basically that resource must exist to do pause / unpause

[vestal minnow]

It's initialized by the physics plugins

Or you can just .init_resource::<Time<Physics>>() if for some reason you need it before that

(or insert_resource)

[obsidian maple]

Does it use the value of the current fixed timestep by default? (btw, it works, I had an unrelated bug)

in other words, I'm doing this:

app.insert_resource(Time::<Fixed>::from_seconds(FIXED_TIMESTEP));

curious if it'll use that under the hood, or if i need to explicitly set it

[vestal minnow]

Yes, it just uses Time::delta_seconds, and Time depends on the clock of the schedule that physics is running in

In fixed schedules, Time<Fixed>

[obsidian maple]

Awesome thanks 🙂

[vestal minnow]

Np 🙂

[pseudo prairie]

Hi! I am using spatial_query.cast_shape(...) and I need the point where the other collider is hit by the shape in local coordinates of said collider. I kind of thought that point1 of ShapeHitData is in local space of the collider but it seems to be in global space. At least that's what I think because when I subtract the Position/Transform of the collider from point1 I get the correct value.

That seems to be counter intuitive because ContactData works different where point1 and point2 are in their respective local coordinates. Is that intended or am I misunderstanding something? 🙂

[vestal minnow]

Yep I believe it's actually in world space. The docs in Parry (the collision detection lib Avian is currently using) say that it's in local space, but it doesn't seem like it when I've tested. I agree it's a bit inconsistent though

Avian's docs are also wrong here atm but I have a PR open that fixes them

I might also rename point1 and point2 for contact data to local_point1 and local_point2 to be more explicit

I finally made the initial 0.15 migration PR for y'all who are early adopters
https://github.com/Jondolf/avian/pull/540

I'll probably merge this tomorrow so people can use the main branch for the RC

I'll migrate internals to required components and add that picking backend in follow-ups

[willow rune]

I have to wonder why this is like this

[vestal minnow]

This is Parry Capsule right? Not Bevy's Capsule

[willow rune]

yeah

[vestal minnow]

Parry represents capsules with two endpoints and a radius rather than just a half-height and radius

So the half_height getter is just a helper to compute the distance between those points

*half of the distance

[willow rune]

yeah ok it is just a getter cool ty

[vestal minnow]

So I'm now porting things to required components, and I feel like it'd be a good time to rework some of our defaults as well. Any opposition to making these components optional?

For RigidBody:

• Friction
• Restitution
• ExternalForce
• ExternalTorque
• ExternalImpulse
• ExternalAngularImpulse

For Collider:

• CollidingEntities

I think the force-related components definitely shouldn't be required. They're not used by anything internally, and you rarely need them on too many entities. CollidingEntities also makes sense as something you need to add manually, although people might then have the issue of forgetting to add it, at least at the start. Either way, I don't think any of these should be "required". If people want to insert them automatically anyway, it'll be easy in 0.15 with runtime required components.

Friction and Restitution I'm least sure about, but I think instead of inserting them for every rigid body automatically, we should treat them as extra configuration, and default to globally defined default material properties (see #119). This would let each app specify its own defaults.

Later on I'd also like to split the RigidBody enum in some way to only require velocity and mass components for dynamic bodies

[regal kindle]

@vestal minnow Hi, hope you are doing great!
I am making rts game on bevy using Avian 3d. And at the moment I am facing one issue:

I cannot pinpoint a time when I need to run observer or system so that it run after certain collider has been initialised.

I need to run series of raycasts on level collider to determine buildable and not buildable positions, if ray hits level then its buildable, if it doesn't then its not buildable position.

Since its quite compute heavy task I need to run it only once - when the level collider has been fully initialized and ready to be detected by raycasts.

I have difficulty getting system/observer run in this point in time. So far I have tried both observer Trigger<OnAdd, ColliderMarker> and system Query<Entity, Added<ColliderMarker>> , with system I have tried to run it on different schedules like Last, PostProcessCollisions and others.

If you have time I will be very grateful if you could give me advise on how to approach this problem.
Thank you!

[vestal minnow]

You could try running it in the PhysicsSchedule, using .in_set(PhysicsStepSet::Last), with an Added<Collider> or Added<ColliderMarker> filter

Running anywhere after physics should also work, but it might be some issue where physics doesn't happen to run during the frame you added the collider and some values aren't initialized properly

[regal kindle]

It works with PhysicsSchedule .in_set(PhysicsStepSet::Last), thank you so much!!!! ❤️

[elder creek]

So if I'm following this right, if you make CollidingEntities optional without making it a required component using the new 0.15 feature, it'll never be added even by ContactReportingPlugin ?

[vestal minnow]

Yes, it'd mean you need to add it manually to query for it

That's how it is in bevy_rapier too

Adding it to every collider is mainly just unnecessary memory usage for entities you don't need it for, which usually is most of your entities

[elder creek]

Right, I get the motivation now!

[elder creek]

Then it wouldn't make sense to make it a required component?

[vestal minnow]

Yeah. Like, you probably don't need CollidingEntities on all random objects in the environment, but just on specific entities

[elder creek]

Yep that makes sense

[gaunt niche]

#1302253308010037309 message
This is such a strange thing, maybe someone can advise something?
in short, the joints behave strangely when the parent is turned

[alpine oak]

hey i was wondering what your thoughts are on this
https://github.com/Jondolf/avian/pull/527
@vestal minnow

[cinder summit]

Is the idea behind the context being able to query for other components or resources, or is there something else to it?

[vestal minnow]

I don't love that you'd now need to pass a context (typically unused) to a bunch of user-facing methods. Conceptually it also doesn't make much sense that computing an AABB or mass properties for colliders requires access to outside information

[alpine oak]

yea pretty much

[alpine oak]

yea I get that, i agree. however, my usecase does seem to require it

[vestal minnow]

IIRC the motivation was that this makes it easier to implement a custom voxel collider, right? Let's you access voxel data

[cinder summit]

If I think of context as Res<Assets<Sdf>> that makes sense to me tbh 🤔

[alpine oak]

however, as i'm typing this out I think that I can just use observers

to update data inside collider components

or smth

[alpine oak]

yea

[cinder summit]

There's also that thing where avian probably needs to start using Assets at some point rather than having a big enum with weird Arc types from parry

[vestal minnow]

So you have a shared structure that stores voxel data, and need to access that in the collider methods

[alpine oak]

yea

[vestal minnow]

yeah, makes sense... I think it might require something context-like then

[cinder summit]

I don't think that PR can handle per-component vs world resource data correctly tho can it? 🤔

Also wonder if there's some rust magic that can be done to remove that context arg entirely when the generics are ()

[vestal minnow]

Probably not, but we could technically have separate _with_context variants of the methods

[cinder summit]

Maybe make impl only for types with empty context that add the non-context version, then make it non-optional

Because empty context would probably always be wrong on colliders that need it

[vestal minnow]

Right, that'd probably be fine

[alpine oak]

yea

this was more of a proof of concept

to get it working for my use case

i'd be happy to clean it up further if it'd be useful

[vestal minnow]

If it works for your use case, and you can't think of nice alternatives that'd work, I think I'd be fine adding something like this

I'd preferably like to keep the non-context versions for colliders that have an empty context, and also have the non-optional context versions, like Nise suggested

I wonder if something like the Fetchable collider idea from a while back could also work here somehow #1124043933886976171 message

[alpine oak]

probably?

[spiral nymph]

Set gravity scale to 0 and add an external force to entities in a query with filter ?

[vague pebble]

Yeah i could do that

I was just thinking how the gravity resource works

but it seens he directly affect velocity

Not entities with impulse as I expected

[pulsar bone]

Restitution::new(0.).with_combine_rule(CoefficientCombine::Min) Doesn't seem to be having any effect 🤔
I'm dropping a rotation locked dynamic cube on a static cube, both with 0 restitution

This is caused by friction

Setting friction to 0 prevents any bouncing

[vestal minnow]

I get this 🤔

[vestal minnow]

Okay yeah with a high friction of about 0.75 it gets a bit wack

but not with default friction in this basic test

[pulsar bone]

Interesting, I've left the friction at the default. It does get worse if I raise the friction further

[vestal minnow]

Ahhh sorry I missed "rotation locked", yeah it's worse with that

[pulsar bone]

Let me test without locking the rotation

[vestal minnow]

I'm aware of the 3D friction implementation being a bit wrong (see #489) so I wouldn't be surprised if this is related

[pulsar bone]

With this setup I get some bounce

[vestal minnow]

Yeah I get a small corner bounce with that too

[fiery mortar]

I have two questions:

• what is the order of AngularVelocity?
• why is AngularVelocity euler angles instead of quaternions?

[vestal minnow]

It's just a vector pointing along the rotation axis, and the length of the vector is the rotation speed in radians per second

2D would be equivalent to Vec3::Z * rotation_speed

i.e. you're only rotating about the Z axis, the other axes project to zero

using a scaled axis makes computations much simpler / more efficient than having to deal with quats everywhere

I'm not aware of any engine using quats for angular velocity

Glam's Quat is also intended to be normalized

So it doesn't make sense to use for angular velocity. It's primarily for representing orientation

[fiery mortar]

Okay, that makes sense. I thought they were eulers cause I missed the comments on the AngularVelocity. 🙇‍♂️

[vestal minnow]

The contact tangent directions for friction seem to be very wrong for the initial contact in a spinning case at least 🤔 lemme investigate

okay there's actually no way this fixes it

- let tangent_velocity =
-     relative_velocity + force_direction * force_direction.dot(relative_velocity);
+ let tangent_velocity =
+     relative_velocity - force_direction * force_direction.dot(relative_velocity);

god I love programming

I've tried debugging this friction bug on like five separate occasions and of course it ends up being a sign issue

FYI @pulsar bone ^ fixed it

I'll make a PR

[pulsar bone]

Nice!

[vestal minnow]

I'll run some more examples to test things though, this changes behavior quite a bit

since friction is now actually... like friction

[pulsar bone]

Yes, that would affect things 😄

[vestal minnow]

https://github.com/Jondolf/avian/pull/542

(the diff is misleading there because of snapshots, really it's a +2/-2 change)

I should really change our determinism tests to just produce a single hash that is compared between platforms instead of using these large snapshots

[pulsar bone]

I noticed something about how the cubes bounce when it lands flat on a side. Its biased to rotate towards the positive axes after it bounces
I.E. Dropping a cube flat with the default gravity makes the top of the cube turn diagonally, towards positive Z and X(Towards the camera and to the right)

Same for dropping it in the other gravity directions I've tested(X, -X, and -Z ), it always turns toward the positive axes

[vestal minnow]

Probably some bias in the order that Parry returns contact points for contact manifolds

For a cube landing flat, there can be 4 contact points, and they are solved sequentially

The order matters there, though more iterations can help make it less apparent

[pulsar bone]

That makes a lot of sense 👍

[vestal minnow]

It's possible to make a block solver that solves multiple contact point at once without bias, but I've only seen it for two contact points, for more than that it quickly gets very complicated and expensive afaik

[ocean monolith]

Hello,
I am trying to switch away from rapier and made a test implementation
for top down car physics. I removed gravity, calculate the all
acting forces according to current energy. And then set the fixed
external force & torque each frame. No impulses. This works butter smooth
in rapier, but in avian I have these 'impuls' stutters. Besides the gravity, both
plugins run in default config. (1/60 step). Any idea, what could be the cause?

[vestal minnow]

Looks like it could be a scheduling issue in camera following logic. Does this system ordering help?
https://docs.rs/avian2d/latest/avian2d/#why-does-my-camera-following-jitter

[ocean monolith]

Its not a camera follow issue. The logic is the same in both test. Your suggested changes did improve the overall follow by a tiny bit. But the stutter still remains.

[pulsar bone]

@vestal minnow Could it be a lack of transform interpolation + the fixed timestep being one frame ahead/behind sometimes? IIRC avian actually does properly run in fixed timestep unlike rapier

[cinder summit]

If the FPS isn't exactly 60, or it only happens sometimes then it would be because of the fixed timestep yes

[ocean monolith]

You are right, that is the cause of the problem. On 60fps the stutter is gone. Demo runs on 164fps (vsync). I have to
look into avians schedule system. Thx alot, I was about to go nuts. 😅

[vestal minnow]

Yeah Rapier defaults to a weird variable timestep with a capped delta iirc, so it's less of an issue there

I'm adding built-in interpolation for Avian 0.2 though

[pulsar bone]

Thoughts on making collision started/ended events be observable 🥺

[vestal minnow]

I'd like to do this yeah, it just ideally should be opt in instead of triggering for both entities for every single collision

[pulsar bone]

A performant way to check whether there is an observer present would be nice

I'm wondering whether you could observe an observer being created for the collision events and then add a marker component automagically

[vestal minnow]

The tricky thing is that each observer is its own entity, and they don't live on the target entity. But IIRC there is a way to get observers targeting an entity, and I think I managed to get something scuffed like that working a while ago

Lemme see if I can find it

[pulsar bone]

Hmm, Observer is type erased now :u

[vestal minnow]

Mm I found old code related to this but it's not doing the thing I was thinking about

Right, Bevy has this ObservedBy component but it's private 🙃

It sure would be nice

Oh and there's still the issue that you need to figure out if there's an observer with the correct event

[vestal minnow]

I feel like this would be ideal here, but it's type-erased now like you said...

lemme ask in #ecs-dev

[cinder summit]

Should the next release include something like

if rb1.is_added() || rb2.is_added() {
+    if !contacts
+        .manifolds
+        .iter()
+        .any(|m| m.contacts.iter().any(|c| c.penetration >= 0.01))
+    {
+        continue;
+    }
```or just finally ![yeet](https://cdn.discordapp.com/emojis/941199111422627891.webp?size=128 "yeet") the overlap warnings? 🤔

[vestal minnow]

I'd probably be in favor of just removing the warning, but this could be fine too

might need to scale by PhysicsLengthUnit?

[cinder summit]

Made a PR for each option, you previously mentioned 0.05 * PhysicsLengthUnit, so that's what the check version does

[vestal minnow]

Ah I see you made a bunch of PRs, thanks

I think I'll merge the version, I don't really see a need for the warning anymore and it's easy enough to add on the user's side too if someone really wants it

the threshold is also kinda arbitrary

[cinder summit]

Yea, was planning to make just these two options, but then I realized I had some some fixes for {:?} locally too, and I ran into failing doctests and by the time I fixed them I realize they were unrelated to my change 😂

At least in 0.15 the {:?} for Entity is a bit less awful, but it still looks a lot worse than {}

[vestal minnow]

Weird how CI is fine with the doc tests

[cinder summit]

Maybe it doesn't run them? 🤔

If you pass something like --lib to cargo test it won't run doc tests for example

[vestal minnow]

It does look like it's running them

[cinder summit]

Oh ... Yea, that's very strange then 🤔

Does it pull avian from crates and use that? 😂

[vestal minnow]

I don't think so, it should be using the workspace's crates

The command it's using is currently

cargo test --no-default-features --features enhanced-determinism,collider-from-mesh,serialize,debug-plugin,avian2d/2d,avian3d/3d,avian2d/f64,avian3d/f64,default-collider,parry-f64,bevy_scene

I've also run it locally and tests pass fine

[cinder summit]

In my case I just ran cargo test -p avian3d -j 2 -- --test-threads=2

The -j and --test-threads is so doc tests and examples don't crash everything

Might be a rust version thing tho, but I don't thinkg Type::default() should've ever been valid as a reference 🤔

[rich gazelle]

Is there a commonly accpeted workaround to not having motor joints at the moment? Even a way to just set a joint angle manually by moving around entities?

Alternatively what's in the way of motor joints currently? I've love to contribute so if it's more a matter of getting it done I'd be happy to take a crack at it. But if it's requires changing the entire engine or knowing the deep magic I'd leave it to the main devs.

[calm meteor]

Hi everyone, I need some help 🙂
Long story short, I made a custom schedule to run Avian on it because I need it to keep looping while the visual frames are rendering, because I need to communicate with an external controller in real time. I run that custom schedule in a loop in a world exclusive system until it gets a signal that rendering is done.

The problem with this approach is that the physics simulation suddenly became insanely fast. I assume this is because every time I run the schedule, Avian will advance the physics clock it uses internally by the delta of the real clock, which would be equivalent to the delta time of the full app loop instead of my internal real time loop.

How should one get around this issue? Should I try to replace the real clock with my own and then restore the original at the end of my system?

[vestal minnow]

A hacky way that might somewhat work is to dynamically change the min and max angle limits to force the joint to adjust the angle. Or you could maybe manually apply some torques to try to emulate a joint motor. I'm not sure how well these approaches would work though, I don't think I've tried them or seen other people have nice workarounds

[vestal minnow]

So, Avian's joints currently still use Extended Position-Based Dynamics (XPBD). There's an XPBD rigid body simulation paper that describes the "proper" way to handle joint motors with it. For revolute joints (i.e. hinges, see section 3.4.1), you essentially just have a target angle that you update at every substep based on a target velocity, and the joint applies a correction that attempts to match this target angle. I have a very old branch that largely implements this.

The main blocker though is that I'm in the process of overhauling joints to use a completely different impulse-based approach instead of XPBD. I'd be a bit hesitant to spend time or effort adding proper XPBD-based joint motors right now, when it'll likely need to be entirely rewritten for the joint rework. The rework is still pretty WIP, but I hope to have it ready for Avian 0.3 (not the upcoming release coming with Bevy 0.15, but the one after that)

For impulse-based joints, motors should be relatively straightforward to implement, but the joints themselves are quite complicated and a lot of work

[rich gazelle]

And the idea is that the release with impulse based joints will include motors or they'll be coming some time after that? If that's the case what the current timeline on that rewrite (days, weeks, months, or years). If it's more than a year away I might just try anyways since it could be nice to have an established interface when doing the rewrite so it wouldn't be completely wasted work.

[vestal minnow]

I intend to include joint motors in that release, yeah, along with some other improvements to joints. Accurate estimates are always hard, but I would hope to have the rework ready in anywhere from 1-3 months. I have revolute joints in 2D and 3D mostly working locally already, and once they're fully done I expect the rest of the joints to be a bit easier

[rich gazelle]

gotcha that's pretty soon so I think I'll leave you to it

thanks for your work!

[vestal minnow]

(I'm assuming you're using 0.1 and not the main branch)
You should probably set the physics timestep to Time::new_with(Physics::fixed_once_hz(my_internal_timestep_hz))

On the main branch you'd probably do what you're describing and replace the clock for the duration of physics, since physics uses the current schedule's active Time clock

[vestal minnow]

Basically this just says "every time the physics schedule is run, advance physics time by 1.0 / my_internal_timestep_hz"

Which is a bit confusing, but... It's simpler on the main branch

You could also make your own scheduling by pausing the Time<Physics> clock (or rewriting PhysicsSchedulePlgin), and creating a system that manually advances time and runs the PhysicsSchedule

[calm meteor]

Ah that's interesting, so basically I could just replace the Time<Physics> resource every time I run my custom schedule with the true delta?

Yes I'm on 0.1.2

What I did now was replacing Time<Real> with a fake version and advance it on each interal cycle with the delta calculated in the system. I guess this has the added benefit that it works for other plugins as well, not just Avian, however it is a lot more complicated then basically setting the physics delta.

I noticed that my dynamic bodies randomly jump around, could that happen if the delta is very close to 0 perhaps?

[rich gazelle]

I'm working on a robot simulator and I'm trying to use Avian but I'm having some difficult behavior. I'm constructing the robot from a URDF and I know I'm assembling it correctly but the moment I try to actually simulate anything it gets hairy fast. There's lots of stuttering and shaking and jumping around and it eventually just folds up. This might be a larger challenge of robotics simulation in general. I really should look into hoe Gazebo handles intersection and joints.

If anyone has the time my code is here: https://github.com/RunnersNum40/bevy_robotics

Things I have tried to fix this:

1. Ignore collisions between links using collisions.retain

• This doesn't seem to do much

2. Turning the dampening on the joints up really high

• Going from nothing to a lot makes a difference but it doesn't solve it

3. Setting restitution to zero

• Might make a difference but it's hard to say

4. Increasing the substep count

• This helped a bit but didn't solve it

5. Removing gravity

• No change

6. Slightly scaling down the meshes

• Bad idea for obvious reasons and it didn't work

7. Increasing the resolution of the VHACD convex decomposition

• Not much effect

8. Locking all the joints be setting the angle limits to a small range or a single value

• I don't think it did anything

9. Many combinations of the above

If anyone has some advice I'd greatly appreciate it.

Okay update. When I remove the colliders entirely and keep the joints everything works fine (except collision detection of course). This is confusing to me because I assumed that 1. Ignoring collisions between links using collisions.retain would have made them a non-factor. Is it possible I'm misinterpreting what the function does?

This is the system that's supposed to prevent small intersections from mattering:

fn ignore_collision(mut collisions: ResMut<Collisions>, query: Query<&URDFCollider>) {
    collisions.retain(|contacts| {
        let entity1_is_urdf = query.get(contacts.entity1).is_ok();
        let entity2_is_urdf = query.get(contacts.entity2).is_ok();

        if entity1_is_urdf && entity2_is_urdf {
            collision_below_threshold(contacts, 0.01)
        } else {
            true
        }
    });
}

fn collision_below_threshold(contacts: &mut Contacts, ignore_threshold: f32) -> bool {
    contacts.manifolds.iter().all(|manifold| {
        manifold
            .contacts
            .iter()
            .all(|contact| contact.penetration >= ignore_threshold)
    })
}

Okay so one things that I wasn't doing that's made a big difference was having the ignore_collision system on the PostProcessCollisions schedule. I had it on Update so it basically didn't do anything.

That's solved a lot of my problem but I'm still a bit confused about how contact penetration works. I'm having a difficult time selecting a value that makes ignoring small intersections work correctly. They seem to vary in the 0.01 +- 0.005 range no matter what's happening. Does anyone have any insight into what the values mean? Should I consider a completely different metric?

[calm meteor]

@rich gazelle I have no answer to your questions, just wanted to say it looks really cool. I'm a robotics engineer and I'm trying to make a drone simulator. I think in case of Gazebo it doesn't actually simulate joints and joint motors, I'm pretty sure it just applies position or velocity updates to the "joints". Basically they can be treated as static bodies. Of course if you want "real" simulation which would allow collisions of the arm with itself or even ragdolling the arm that would be cool but yeah I'm not sure how to avoid this janky behaviour.

[rich gazelle]

So it doesn't actually deal with link intersection it just is based on the joint limits?

[calm meteor]

Well I wouldn't swear on it but that's my understanding. There are joint limits in the URDF but you can still easily get the robot into a self collision. Honestly I used gazebo mostly for drones and robwork for industrial arms so I'm not fully sure. You could do manual collision checking in a test configuration to determine if that pose is valid for example.

if I were you I would try to make the collision mesh smaller around the joints so they are clearly not touching. Two links will not move closer to each other anyway since they are rigit bodies rotating around each other over just one axis.

But it depends on what your end goal is with this project.

[rich gazelle]

Damn that makes me reconsider some choices here. I really like the idea of doing a proper simulation to get more accurate dynamics but I think it gets farther from real once things start exploding like this

My end goal is to be able to not use ROS but still have Gazebo

it's be nice to improve on it on the way

[calm meteor]

There are collaborative robots out there which go into a handmanouverable safety mode when they collide with something. That would be hard to do without modelling the dynamics

[calm meteor]

sorry that's confusing, I thought you're basically making a Gazebo replacement? Otherwise I think you can use Gazebo without ROS you just need to do some messaging

[rich gazelle]

I tried making the meshes smaller but the naive approach leads to more intersections since you start pulling some of them into each other if they aren't perfectly convex

I am making a Gazebo replacement, sorry for any confusing language

mostly for personal use but I just want to try doing an entire robotics project in plain Rust

[calm meteor]

Yeah that's funny we're doing very similar things. Alright I feel a bit bad about hijacking this thread 🙂

[rich gazelle]

nah that's okay I stole yours

[vague pebble]

is there something similar to collision groups in avian?

[elder creek]

https://docs.rs/avian2d/latest/avian2d/collision/struct.CollisionLayers.html ?

[vague pebble]

Does avisn intend to make softbodies?

[cinder summit]

Jondolf has posted a soft body showcase in the past usin bevy_xpbd, haven't seen any soft bodies since however ... I think in theory it might be possible to add them manually on top too 🤔

[vestal minnow]

There's a third party bevy_silk crate for cloth, but actual deformable solids are not on the near-future roadmap for first party features. Hopefully some day once everything on the rigid body simulation side is good enough

It's not too hard to make very basic soft bodies with just a mass-spring-damper model using joints though

[dire cape]

I remember there was some talk about adding a AnyCollider::Context associated type so that you can pass arbitrary world context down to colliders from the world. Previously this was implemented by @alpine oak (#1124043933886976171 message) where the context was a single extra component that may be included in the collider query. I've built on this and turned Context into a full ReadOnlySystemParam which you can access, and also give the AnyCollider access to its own entity ID, so it can read its own components from queries within that param.

Implementation here: https://github.com/oxkitsune/avian/pull/1
@vestal minnow Do you think this approach is suitable to be upstreamed into avian?

there's 1 safety comment which I think is actually safe, but I need to confirm with ecs folks

I think this resolves your concerns with having non-context versions though, since in that case colliders will just take () as context, which means nothing extra is queried

[vague pebble]

@vestal minnow Imagine the following, I have gravity setted up manually in my game, because it is networked. If my player is on ground, should I keep applying gravity in your opinion or nah? If the whole limitations of messages and such.

[cinder summit]

If you stop applying gravity when on the ground it's trivially easy to stop being on the ground, but not necessarily impossible when an object is stationary

[vague pebble]

well fudge

[hexed veldt]

What might caused the following error/panic?

thread 'main' panicked at ...\.cargo\registry\src\index.crates.io-6f17d22bba15001f\avian3d-0.1.2\src\collision\collider\mod.rs:327:9:
assertion failed: b.min.cmple(b.max).all()
note: run with `RUST_BACKTRACE=1` environment variable to display a backtrace
Encountered a panic in system `avian3d::collision::collider::backend::update_aabb<avian3d::collision::collider::parry::Collider>`!
Encountered a panic in system `avian3d::schedule::run_physics_schedule`!
Encountered a panic in system `bevy_app::main_schedule::Main::run_main`!

[hexed veldt]

I can re-prduce the above panic consistently. Since the setup has many objects/colliders running the same time, I wonder if there is anyway for me to debug which entity is causing the panic?

[cinder summit]

NaN

NaN in turn is usually caused by things rotating at very high speeds, denormalizing the rotation and making things quickly spiral out of control

[hexed veldt]

After some debugging, I noticed the object I spawned into the game has the following initial transformation (without angular rotation)

--------- pos Vec3(5.0, 0.0, 0.0) rot Quat(0.0, -0.0, 0.22975293, 0.97324896) s Vec3(0.6, 0.6, 0.6)

in the avian3d system avian3d-0.1.2/src/collision/collider/backend.rs#L495 update_aabb both Position and Rotation for the collider is NaN

Position(Vec3(NaN, NaN, NaN)) rot Rotation(Quat(NaN, NaN, NaN, NaN))

Then I removed the debug_assert! from the grow method and notice the game seems to be running fine, with the object colliding with other objects correctly. I wonder if this NaN only exist for the object after the initial setup, but then gets auto corrected into valid numbers?

Ok. Here is my question:

Where is the logic that added the initial Position component for the newly initialized Collider. I can dig into that deeper to understand why it is NaN

[hexed veldt]

I think I found the fix. I have a auto aim system that update the object orientation towards a moving target. The system was executed under Update schedule. When I change that system to use FixedUpdate schedule, now I no longer see the NaN in avian's update_aabb system.

Anyone knows why changing the schedule to FixedUpdate solves the issue?

[cinder summit]

Does avian run in FixedPostUpdate in your setup or in PostUpdate?

[hexed veldt]

I don't know. What is the difference and how to configure it? Any best practice here?

[cinder summit]

It's configured based on the schedule passed to PhysicsPlugin, on 0.1.2 it's still PostUpdate, but if you'r on a newer git version it's FixedPostUpdate

The best practice is generally to use FixedUpdate so things aren't tied to FPS, but there are still some issues (which the default in 0.1.2 also has because it runs its own loop in PostUpdate, rather than just once per frame at a variable delta) like getting jittery movement when your frames and updates don't align perfectly. Which could be fixed with some interpolation, and there is a plugin for interpolation with avian, it's just not something you have by default iirc

[hexed veldt]

I noticed the objects move slightly slower on my macbook (120FPS) versus my windows (60FPS). The configuration on the objects are the same, with LinearVelocity applied. I'm using FixedPostUpdate schedule to run physics. Suppose Fixed schedule would make the movement the same on different frame rate right?

[hexed veldt]

BTW, I'm using avian 0.12. When I switch to PostUpdate for the Physics schedule, everything seems to work fine now. The movement looks exactly the same between 60 and 120 FPS.

The only issue I had with PostUpdate physics update is that when FPS drops lower (like 30FPS) things start moving slower again.

[cinder summit]

I think on 0.1.2 you also need to set Time<Physics> to match with how it runs. It should work as expected out-of-the-box in FixedPostUpdate in the next release

By default it currently is set up to run its own loop in PostUpdate, so the physics theirselves should run the same, but your own code might not run in-sync with physics, which can cause the results to be off

[hexed veldt]

Here is what I did, and it seems everything is working well now, for 30/60/120 FPS consistently.

  app.insert_resource(Time::new_with(Physics::fixed_once_hz(60.0)))
     .add_plugins(PhysicsPlugins::new(FixedPostUpdate),...
     ...
     .add_systems(FixedUpdate, keyboard_handle)

I learned bevy's FixedUpdate schedule is running at 64HZ instead of 60. I wonder if the above setup of 60.0 hz for physics would cause any issues? Does it need to match 64HZ?

[cinder summit]

Ideally it would match yes, you can either set FixedUpdate to 60Hz too, or set both to 64Hz

[vestal minnow]

Yeah in this case, if it doesn't match, I think the simulation would be slower/faster than real time

like if fixed_once_hz was configured to 10 Hz and Bevy's fixed update uses 64 Hz, it'd run physics whenever the fixed update runs, but advance physics time by the equivalent of 10 Hz every time

(which is 1 / 10 Hz = 0.1 s)

but yeah on the main branch it's different and simpler, stuff like fixed_once_hz doesn't exist, you'd just configure Time<Fixed>

[rich gazelle]

I'm doing my best to approximate joint motors with external forces and torques. Can anyone suggest the best schedule to run updates on? I've been using FixedUpdate but it would be nice if it could match the substeps so I can increase the accuracy if needed. I tried using avian3d::schedule::SubstepSchedule and avian3d::schedule::PhysicsSchedule but both cause a panic.

[rich gazelle]

Working revolute joint motor

[rich gazelle]

If anyone wants to take a look at a working implementation of motor joints I've made this plugin which allows velocity control of revolute joints

[hot osprey]

Hey, sorry, got a stupid question

I'm doing an rts selection system. Basic click on a unit and highlight it. I'm drawing boxes around units ala Starcraft.

Problem I have is I can't figure out the correct way to do it

The way I'm doing it atm is this

I decided to cache the mouse pointer info in a resource for reuse in multiple systems later on. I know events are probably a smarter way to do it but I just want something simple whilst I learn and mess around with things

I then get a point intersection using avian, with a collidable box

The problem I'm having after that is that I don't really know what to do with the entities themselves

Entities are set up like this. The idea is, click the entity, flag it as selected or unselected in some buffer somewhere, flip the visibility state of the child

Under normal circumstances in a game engine you'd just grab the entity and go to town finding its child. All I can think of is tagging the entity with a tag component of some sort and flipping it next frame

Any advice on how to deal with this and other similar problems coming out of SpatialQuery?

[vestal minnow]

If I understood your setup correctly, you should just get the Children of the selected entities, query for the ones that are selection boxes, and toggle their visibility. I think it's something like this

fn flip_selection_box_visibility(
    mouse_info: Res<MouseInfo>,
    mouse_buttons: Res<ButtonInput<MouseButton>>,
    mut q_selection_box: Query<&mut Visibility, With<SelectionBoxTag>>,
    children: Query<&Children>,
    mut commands: Commands,
) {
    if mouse_buttons.just_pressed(MouseButton::Left) {
        for &entity in mouse_info.selectable_entities.iter() {
            // Get child entities.
            let Ok(children) = children.get(entity) else {
                continue;
            };

            // Iterate over children that are selection boxes.
            // We can't use a for loop for `iter_many_mut` (I forget why)
            let mut iter = q_selection_box.iter_many_mut(children);
            while let Some(mut visibility) = iter.next() {
                visibility.toggle_inherited_hidden();
            }
        }
    }
}

[vestal minnow]

So I was looking at defaults for friction and restitution coefficients and combine rules across physics engines

• Jolt: 0 restitution (max), 0.2 friction (geometric mean)
• Box2D: 0 restitution (max), 0.6 friction (geometric mean)
• PhysX: 0 restitution (average), 0 friction (average)
• Rapier: 0 restitution (average), 0.5 friction (average)
• Godot: 0 restitution (?), 1.0 friction ("rough" boolean)
• Unity 2D: 0 restitution (max), 0.4 friction (geometric mean)
• Unity 3D: 0 restitution (average), 0.6 friction (average)
• Avian: 0.3 restitution (average), 0.3 friction (average)

(gotta love how Unity is inconsistent between 2D and 3D)

I think we should at least change the default restitution to zero, making bounciness opt-in

I think it might be good to increase the default friction too, maybe to 0.6 or 0.5

[glacial nebula]

probably good for default stability too, I imagine?

[rich gazelle]

In almost everything I do I add in the Restitution::ZERO

[vestal minnow]

Yeah, might help a bit

[rich gazelle]

so I'd like that default

[peak timber]

agreed

[vestal minnow]

Then for combine rules, I'm not sure; the geometric mean sqrt(a * b) for friction is kinda nice since it means that the mixed friction is zero if either coefficient is zero, so e.g. everything can slide on "ice"

but it's still somewhat averaged otherwise

you can get that by just using CoefficientCombine::Min on the ice though... so I'm not sure if it's worth it

the current arithmetic average (a + b) / 2.0 is easier to reason about and think about in your head, so it might make sense to keep it as the default

especially for consistency with restitution, if we keep that the same

So I think the only thing left to figure out is what the default coefficient for friction should be, that's a bit more arbitrary

The current default of 0.3 feels way too slidey, and 0.6 feels like it's slightly too much

0.5 like in Rapier might be the sweet spot...

[cinder summit]

Wait are these used when the component is missing too?

[vestal minnow]

Yes

[cinder summit]

Yea restitution probably should be 0 then, because having things bounce by default is kind of odd 🤔

[vestal minnow]

Yeah I think I'll change default restitution to 0 and default friction to 0.5, but keep the combine rules the same for now

and Restitution will be optional (currently it's added automatically)

Now I'm not sure if I should make Friction required or not. Conceptually yes, but I'd like to have DefaultRestitution and DefaultFriction resources that let you configure the global defaults

Similar to Unity's default physics material

(side note, I love how in Unity it's "Physic material" in 3D but "Physics material 2D" in 2D)

Technically we could do physics materials as assets, which would let us require a physics material component with the default handle for every rigid body, and you'd be able to modify the default material's asset... But I've felt like it'd be more annoying to work with (without an editor) since you'd need to define assets just to specify friction and restitution for things

The other benefit would be that you can just change one material and have that change affect every entity using that material, but you could also just define constants for friction and restitution values atm, so changing it in code is pretty straightforward

[cinder summit]

Physics material as assets does sound nice but yes it does also sound kind of painful 😂

[thin hare]

What is the best way to alter a colliders size at run time? Is it just updating the collider shape or is there a better way I'm not aware of?

[vestal minnow]

You could change the Transform scale

If you have other things like a mesh on the entity and you don't want to scale those, you can put the collider on a child entity and only scale that

Otherwise, yeah updating the collider shape would be the way

[thin hare]

I'll give that a go, thanks!

[proven ice]

what kind of physics body should i use for players?

[cinder summit]

There's no single correct answer, but at the very least static is probably the wrong choice 😂

Kinematic bodies are used for kinematic character controllers, while dynamic bodies are used for physics-based character controllers like the common floating capsule character controllers

[proven ice]

thanks!

[proven ice]

no pls, i used to try to use static physics bodies in physics engines for players thinking "well i dont want anything to act upon it, why is it making things bug out when i update the position?? why isnt the velocity being calculated??" 😭

[vestal minnow]

https://github.com/Jondolf/avian/pull/551

[rich gazelle]

What is the correct schedule to run systems that modify the physics on? Things that modify the torques, velocities, or positions.

[vestal minnow]

On the main branch, physics runs in FixedPostUpdate by default, and the intended place to run most logic like that would be before that, in FixedUpdate. Same as running things in _physics_process in Godot or FixedUpdate in Unity

In 0.1 physics is in PostUpdate by default, so it's a bit more annoying to run things at the same fixed timestep

There you'd run in PhysicsSchedule, with .before(PhysicsStepSet::Prepare) IIRC

Or, move physics scheduling to FixedPostUpdate kinda like the main branch

You can also run things inside the physics schedules or even the substepping loop if you really need to, but avoiding scheduling conflicts there is more annoying, and scheduling internals are prone to changes

[cinder summit]

values greater than 1.0 should be allowed, though not recommended
Finally we can model perpetual motion machines in avian that generate energy!

[rich gazelle]

Thanks I'll have to consider that

[rich gazelle]

If anyone's interested I've implemented really really basic motors for revolute joints https://github.com/RunnersNum40/avian_motors. The interface and naming is a bit rough because I've been prototyping a lot and changing things. I might work on cleaning it all up but if actual motors are coming soon I don't want to spend too much time on it.

It has PID based position and velocity control for revolute joint angles

I'd super appreciate if anyone has any suggestions for improvements

I'm also pretty new to rust so I've no clue how to setup the Cargo.toml so it's a usable library.

[vague pebble]

Question how can I acess the physics debug plugins gizmos, I need to insert a little bit of visual interpolation into them in my networked game

[cinder summit]

Doesn't modifying them to not match up with what physics actually did make them kind of useless?

[vague pebble]

hmm true, I wonder how I can make them less figety tho

Once there are corrections and rollbaccks

[cinder summit]

With my rollback it's pretty easy, I just clear all the gizmos before new simulations so I get exactly just one set of gizmos matching the newest tick

[vague pebble]

Mind if I see how you do it, I dont even know how to acess the gizmmo itself

[cinder summit]

Ah it looks like I slightly changed what I do.
I run this system after any resimulation so only events from the real simulations get picked up

fn clear_collision_events(
    mut col_events: ResMut<Events<Collision>>,
    mut start_events: ResMut<Events<CollisionStarted>>,
    mut end_events: ResMut<Events<CollisionEnded>>,
) {
    col_events.clear();
    start_events.clear();
    end_events.clear();
}

I'd assume you otherwise access them trough the Gizmos<PhysicsGizmos> system param

[bronze bronze]

What is the/is there a recommended way of changing a collider's size at runtime? I'm trying to use it for collision detection on a basic 2d rts-style unit selection (rectangle that gets bigger with a mouse drag).

I tried using the ColliderConstructor, but it seems disappear upon the collider creation and adding a new one doesn't overwrite the previous collider.

[sharp dew]

is it ok to use CollisionLayers along with Sensors? i cant seem to get my player to collide with event triggers, but tile collisions ive set up with CollisionLayers in the same way work just fine

for reference, this (save for irrelevant bits) is how im spawning the triggers

commands.spawn((
    RigidBody::Static,
    Collider::rectangle(rect.width(), rect.height()),
    CollisionLayers::new([Layer::Portal], [Layer::Player]),
    Sensor,
    /* trigger components */
));

and the player:

commands
    .spawn((
        RigidBody::Dynamic,
        LockedAxes::ROTATION_LOCKED,
        Collider::capsule(4.0, 8.0),
        ShapeCaster::new(caster_shape, Vector::ZERO, 0.0, Dir2::NEG_Y)
            .with_max_time_of_impact(1.0),
        Friction::ZERO.with_combine_rule(CoefficientCombine::Min),
        Restitution::ZERO.with_combine_rule(CoefficientCombine::Min),
        ColliderDensity(2.0),
        GravityScale(2.5),
        CollisionLayers::new([Layer::Player], [Layer::Wall, Layer::Portal]),
    ))

I can detect every other collision with EventReader<CollisionStarted> just fine

[sleek thicket]

it should work. i just double-checked, and i didn't even need rigidbody. not sure if it's added automatically though.

[sharp dew]

if you have a minute that'd be appreciated! i went through the sensors example and i'm still at a loss

[sleek thicket]

the main things that are different for me: TransformBundle and const CollisionLayers... and using Collider::Sphere

@sharp dew how are you checking that it's getting hit? maybe you just forgot to use the system D;

[sharp dew]

hideous but here it is

fn portal_detection(
    mut reader: EventReader<CollisionStarted>,
    player_query: Query<Entity, With<Player>>,
    portal_query: Query<Entity, With<Portal>>,
) {
    for CollisionStarted(e1, e2) in reader.read() {
        for portal in portal_query.iter() {
            if let Ok(player) = player_query.get_single() {
                warn!("collision detected between entities {e1} and {e2}");
                // if one of the entities is the player and the other one a portal
                if (*e1 == player || *e2 == player) && (*e1 == portal || *e2 == portal) {
                    warn!("portal collision detected");
                }
            }
        }
    }
}

the first warn! between the player and collision tiles works just fine, but nothing appears when i should be colliding with the triggers

just found out about CollidingEntities but that didn't give me any results either

[sleek thicket]

^ this is basically what i have

[sleek thicket]

i can't see what's wrong, but i cleaned it up a little

fn portal_detection(
    mut reader: EventReader<CollisionStarted>,
    player_query: Query<Entity, With<Player>>,
    portal_query: Query<Entity, With<Portal>>,
) { let Ok(player) = player_query.get_single() else { error!("no player?"); }
    for CollisionStarted(e1, e2) in reader.read() {
        let (player_e, other_e) = if *e1 == player { (*e1, *e2) }
                             else if *e2 == player { (*e2, *e1) }
                                else { continue; }

        for portal in portal_query.iter() {
            if other_e == portal { warn!("success"); }
        }
    }
}

[sharp dew]

oh my god.

i just. forgot to add a transform to the portal spawn. groaaaaan.

the examples are still super useful to me, tysm!

[sleek thicket]

doesn't it just spawn at 0 without transform?

[sharp dew]

guess so but i had no way to collide with it with the layout i have

[vestal minnow]

Spent most of today trying to set up a testbed that would allow running all the 2D or 3D examples at once, and also added a way to reset examples. Only implemented it for two examples so far to just get it working

The goal is to have a similar thing as Box2D's demos, with a bunch of samples you can run, with UI for lots of configuration options

The tricky part is that I still want the examples to be useful for demonstration purposes and showing off APIs too, and you kinda have to set things up in a specific way so the tesbed can also run them

Right now I just create a struct for each example that defines the system configurations and the name of the example

pub fn main() {
    App::new()
        .add_plugins((
            DefaultPlugins,
            ExampleCommonPlugin,
            PhysicsPlugins::default(),
            MoveMarblesExample.plugin(),
        ))
        .run();
}

pub struct MoveMarblesExample;

impl PhysicsExample for MoveMarblesExample {
    fn name(&self) -> &str {
        "Move Marbles"
    }

    fn setup(&self) -> SystemConfigs {
        setup.into_configs()
    }

    fn fixed_update(&self) -> SystemConfigs {
        movement.into_configs()
    }
}

Ideally you could just use a plugin directly, but the testbed needs to add additional run conditions (or swap/reset worlds and schedules somehow, which I don't think is possible)

I think it's probably fine like this, the scheduling is rarely the focus in examples anyway, and in cases where it is, we can just have those be "normal" examples that aren't available in the testbed

[vestal minnow]

Typically, just changing Transform scale #1124043933886976171 message

[cinder summit]

Unify dimensions so you can have 2D and 3D in the same app 😈

[vestal minnow]

I think technically you could just have the examples in a separate crate that uses both crates... you'll have all the type names duplicated tho

[rough nebula]

Is there a way to exclude an entity from collisions?

[cinder summit]

I think your options would be collision post processing and making the collision layers not match

[vestal minnow]

bevy_picking support!
https://github.com/Jondolf/avian/pull/554

I'll go over it again tomorrow and probably add a 2D example, it's getting really late here

(FYI @glacial nebula @bold garnet 🙂)

[cinder summit]

Why do you do this bevy_picking thing instead of enabling bevy/bevy_picking trough a bevy_picking feature? 🤔

[vestal minnow]

...good point lol

lemme change that

[cinder summit]

It's also around for bevy_math for some reason

[vestal minnow]

I think that one is for bevy_math/libm

Doesn't seem like it's exposed for bevy directly

[vestal minnow]

Finally removed our insta snapshot stuff in favor of a transform hash for cross-platform determinism tests. Made the test much better too and added an example to visualize it
https://github.com/Jondolf/avian/pull/555

Begone unnecessary huge PR diffs and manual snapshot generation!

let's see if CI passes

also fixed some pretty nasty and obscure bugs I found

[cinder summit]

I wish my rollback was as deterministic as that example, it's somehow always just slightly off causing things to start moving at just the wrong angle creating tiny mispredictions which look less like mispredictions and more like jitter

[vestal minnow]

Some contact data helpers (for #552) to end off the day

• https://github.com/Jondolf/avian/pull/556
• https://github.com/Jondolf/avian/pull/557

[rich gazelle]

Is it possible to apply an external torque around a specific point?

[glacial nebula]

the former is generally better for compile times, if I understand what you mean

if you rely on bevy + features, your plugin can't start building until bevy and all transitive deps have finished building, even if your plugin only uses one tiny part of bevy

[cinder summit]

In this case avian did bevy and bevy_picking so it had both the annoying patch.crates-ioability of individual crates and blocking on bevy 🙃

[fleet field]

hey all, wondering if anyone has experienced little "hops" with dynamic character controllers in avian3d. basically, whenever my character moves horizontally when standing on flat ground, it gets some upward force. I don't have anything fancy setup, basically just the dynamic character controller example. I thought I'd ask here in case this is a known quick that is easily solved

[sleek thicket]

probably ghost collision with triangle edge
hovering collider automatically solved it for me, so i don't remember if there was a proper fix

[fleet field]

I see. I am just stepping away from using bevy_tnua's floating character controller as it wasn't playing well with lightyear... Is a hovering collider builtin to avian directly which I can use?

[sleek thicket]

nah it's braindead simple to make it yourself
https://youtu.be/qdskE8PJy6Q
https://youtu.be/CdPYlj5uZeI

[fleet field]

ah okay, thanks. I'll look into that!

[sleek thicket]

and man, those 2 videos overshadow their actual game so hard it's strange that they didn't just convert into a tutorial channel 🤣

[fleet field]

haha. their tutorials seem very well done

[rough nebula]

What exactly is the heightfield collider?

[vestal minnow]

A grid with a given height for each cell, useful for things like terrain

Also known as a heightmap, basically a collider for this
https://en.wikipedia.org/wiki/Heightmap

[rough nebula]

Oh i knew what a heightmap is, didnt know you could just do that

[little maple]

I'm working on optimizing my game a bit. I did a profile and am just wondering as this isn't something I've looked at to deeply before..

assuming I have several dynamic rigid bodies with cuboid colliders that I'm applying impulses to, is there anything I can do in "user code" to optimize this (it's a screenshot of the physics part of one frame) or is this pretty typical?

[vestal minnow]

Yeah narrow phase collision detection (the blue block) and the contact solver are the main bottlenecks. There's not too much you can do on the user side, outside of things like avoiding complicated geometry (e.g. large/dense trimeshes)

Reducing the SubstepCount down from 6 can also help, but at some point it'll hurt stability

[little maple]

does making more granular collision layers help? Like, if I have a cube type that I only want to interact with one other type of cube, does setting up the layers that way reduce the collision checking?

[vestal minnow]

It could maybe help slightly, but the broad phase already filters out entities whose AABBs aren't intersecting, so if they're far away they already shouldn't have collision checks

Optimizations for the solver are planned, but I keep getting other important (or more fun) things to work on :/

[little maple]

no worries and understandable. just wanted to see if there were any "low hanging fruit" I could look out for

[rough nebula]

Second stupid question, do physics work for entities in different plugins?

[vestal minnow]

What do you mean by entities in different plugins? Entities don't belong to plugins, they just belong to... the ECS

[rough nebula]

Spawned in a different plugin*
I figuered it wouldnt but i am noticing it wasnt working so maybe i did something wrong

[slim ledge]

I have a stupid question too: can I define the rotation of a fixed joint between 2 dynamic bodies? I changed their Transform rotation but they keep sticking to each other with default rotation

[vestal minnow]

Not really supported yet, though there's a PR to add this: #507

Haven't merged it yet since I need to verify that it works in 3D, and this also kinda overlaps with the joint overhaul I'm working on (among many other things, it should support proper "local frames" for joints, i.e. anchor offset + rotation offset)

A simple workaround that could maybe work depending on the use case is to instead use a child entity for the thing you want to rotate, and keep the parent rigid body as is

Made a quick proposal for reworking how we handle external forces and impulses. Not a very thought out or thorough design yet, but I do think we should rework things in some way
https://github.com/Jondolf/avian/discussions/558

Ideas and feedback welcome!

[slim ledge]

Thanks. For my use case I'll use a ball collider that doesn't need to be rotated

[sleek thicket]

you can think of plugins as bundles, they're used just to group up stuff for convenience and don't really do anything special

[rough nebula]

Ok but wtf, i can see the colliders exist through the debug wireframe, run into them, no collision

Although only for trimesh, other shapes seem to work just fine

[opal moth]

Hello, is avian2d have only event but not really collision collider?

[rough nebula]

Compount doesnt either, only basic shapes do

Genuinely have no idea what could be causing this

[blazing sluice]

Hey guys, glad to see the Avian project is going well. I've just upgraded my codebase from 0.13 to 0.14, and xbpd still works great, so thanks for at least supporting it into 0.14. What's the transition like from xbpd to avian? Any big changes I should be aware of going in?

[little maple]

are you using CollisionLayers? What are the rigidbody types of the colliders involved?

[vestal minnow]

There's a migration guide from bevy_xpbd to Avian here

I also have a blog post covering the biggest changes
https://joonaa.dev/blog/06/avian-0-1

The next release (coming after Bevy 0.15) also has a decent amount of changes, there'll be a migration guide and post for those too

[rough nebula]

No, static and dynamic
The normal colliders work fine, but the moment i switch to compound/trimesh i am able to clip right through, even if i am using the same points

[opal moth]

Hello, is avian2d have only event but not really collision collider?

I create a bullet for attack detection but it really collision.

[vestal minnow]

I'm not sure if I understood exactly what you mean, but:

• A Collider on its own currently only detects collisions and sends collision events like CollisionStarted. Objects can go through colliders with no "collision response".
• To enable "collision response" for a Collider, make it a RigidBody. That way, dynamic rigid bodies can bump into it.
• If you want a RigidBody that has a Collider but does not have collision response, you can add the Sensor component. This makes it behave like a standalone Collider again, but with the other features of rigid bodies.

[opal moth]

Thanks for reply, Sensor works for me.

But i got tons of message

Dynamic rigid body Entity { index: 0, generation: 2 } has no mass or inertia. This can cause NaN values. Consider adding a `MassPropertiesBundle` or a `Collider` with mass.

It's really a Collider:

.insert(RigidBody::Dynamic)
.insert(Collider::circle(4.))
.insert(CollisionLayers::from_bits(
    ATTACK_DUMMY_GROUP,
    NORMAL_COLLIDER_GROUP & !ATTACK_DUMMY_GROUP,
))
.insert(Lifetime(5.))
.insert(YSort::default())
.insert(Sensor)
.insert(LinearVelocity(
    fire_direction.truncate().normalize() * bullet_speed,
));

What I did wrong?

[vestal minnow]

Unlike normal colliders, sensors currently don't get mass automatically since they're not really physical "things", just shapes for detecting intersections in some area. A common use case could be detecting when the player enters some area, or is close to a door, which doesn't need mass.

Dynamic rigid bodies do need mass though. You could add it manually like this:

.insert(MassPropertiesBundle::new_computed(&Collider::circle(4.), 1.0))

which basically computes the collider's mass based on the shape with a density of 1. For colliders that aren't sensors, you don't need this

Also FYI, if the bullet is moving very fast, it could be better to use ray casts or shape casts than colliders. Depends on what kind of bullets they are though, and what behavior you need

[opal moth]

Thank you very much, this knowledge will be very helpful for me to develop other kinds of skills.

[cinder summit]

Wait what does RigidBody + Sensor get that just Collider + Senssor doesn't?

[vestal minnow]

You can have a dynamic RigidBody that moves around and responds to velocity, external forces, and joints, but doesn't have collision response, only sensor-based collision detection

[cinder summit]

Oh, so it's like a kinematic body that also doesn't push thing?

[vestal minnow]

not kinematic since it's still controlled by physics, but it just passes through things

Sensor just disables the contact solver essentially (and automatic mass computation)

and in the future it likely wouldn't compute actual contact data, but just do cheaper intersection tests

[hot osprey]

Hey, sorry it took me so long to get back to you as I've been hellishly busy at work. I'll give this a shout and work out how it works 🙂

[hot osprey]

It works! Took me a little while to figure out how Rust wanted me to do the function for toggling inherited visibility (because I'm a Python/R data monkey at work and every day spent in R saps your will to program), but it works 🙂

I didn't even think to try using queries with simple lists of entities

Now that I think about it, it's stupid I never even considered how the engine itself would be doing the selection of entities 🙂

Thanks so much

[last forge]

Hey again! things are (almost) working to get my balloon simulation off the ground. I'm having trouble with external forces though.

1. If I have my systems force.set_force(my_vec3) on the ExternalForce every physics tick, the force accumulates over time.
2. If I add additional ExternalForce components to the entity, the magnitudes are correct but the object does not move.

It's not exactly clear to me when I should set_force vs apply_force. If I understand it right I'd want to apply_force to make it act in world space, and set_force to change the vector thereafter.

Driving me crazy. Attached a snippet similar to what im working with if you're curious.

I put in logs to show that when the new ExternalForce is added it is indeed running the apply_force and then running set_force each physics tick after that. The main ExternalForce component on the plugin is still zero but I thought that additional forces would be summed to the dynamic body

2024-11-14T02:27:53.430373Z  INFO yahs::simulator::forces: applied new buoyant force: Vec3(0.0, 0.0, 0.0)
2024-11-14T02:27:53.430394Z  INFO yahs::simulator::forces: applied new weight force: Vec3(0.0, 0.0, 0.0)
2024-11-14T02:27:53.457624Z  INFO yahs::simulator::forces: updated weight force: Vec3(0.0, -53.10969, 0.0)
2024-11-14T02:27:53.457619Z  INFO yahs::simulator::forces: updated buoyant force: Vec3(0.0, 50.412033, 0.0)

[rough nebula]

Is impulse and force impersistent practically the same thing?

[vestal minnow]

Mostly, but force is in Newtons, impulse is in Newton seconds. Applying an impulse of 1 Ns for a frame will be "stronger" than a force of 1 N, because the force equivalent to the impulse will be force = impulse / delta_secs, and delta_secs is typically 1.0 / 60.0 or some other value smaller than 1.0

I want to rework how forces and impulses work though. Imo it doesn't make sense to have "persistent impulses", and no other engines have them

(I have a rough proposal for a new approach here)

[vestal minnow]

Here it looks like you're not updating the actual ExternalForce component of the body, just values stored in your own components

apply_force adds a new force on top of the existing forces, set_force sets the total force to a specific value

IIRC the forces are currently persistent by default, so you need to manually clear them, but you can also set persistence to false, and they'll be cleared automatically every frame

[vestal minnow]

And like I mentioned ^ I'd like to rework the force stuff, it's not ideal currently imo

[little maple]

I was about to ask this exact question and make almost the exact same video

is the solution "use vsync and lock the game in at 60fps"? Is there an alternative? (Might be a question for Jondolf / NiseVoid / Tim too since they were part of this conversation)

[ocean monolith]

That's pretty much what I did. Increased the physics step to 100 fps (close to my dev V-sync), called it a day / pushed
the problem into the future. It reduced the issue to a minimum, but not entirely gone. I just know the basics about
physics simulation, would be very happy if someone could explain the correct solution.

To me it looks like a interpolation error. The stutter does not feel linear. But that's just a wild guess.

[little maple]

I thought it was related to schedule ordering + fluctuating frame rate

[last forge]

Okay, so the only way to move the body is to update the external force component created with the rigid body and other external forces are ignored? I thought avian would sum all external forces attached to a rigid body. I'm coming from an engineering background so I drew the force diagram and added all the force vectors.

Not to hard to add a system to do that myself. Feels like I am doing the Shrek walking through the velvet rope thing though. https://makeagif.com/i/yI54VY

What is the "avian" way to handle summing a bunch of independent forces like this? I guess the answer is to have only one system that sets the net force, not one system for each contributing force.

[glacial nebula]

I thought avian would sum all external forces attached to a rigid body
If you are adding your own custom components (weight, buoyant) how is avian supposed to know they exist to sum them?

I guess the answer is to have only one system that sets the net force, not one system for each contributing force.
Forces can be summed, you could reset the external force on your entity at the start of every update, then add forces to it from multiple systems throughout the update.

[little maple]

it does look like here you're using set_force in the update rather than apply_force?

[little maple]

actually, I should add that I notice this stutter in one of my games but not another one which also made me think it was due to scheduling and fluctuating fps

[ocean monolith]

I really hope so. If its a bug on our end, that would be great. The interpolating thing is was just a wild guess. I do not know, how the physics internal work.

[last forge]

Good point. I did this so I know which force is which when querying later. I didn't consider that wrapping the external force component doesn't actually add the component itself.

Awesome thanks all this got me out of my thought spiral! Hopefully I'll have a cool demo to share when I get it working

[noble pier]

Did you every figure out the cause? Noticing the same issue with half-space and non-half-spaces.

[vestal minnow]

FYI that warning has been ed on the main branch

[vestal minnow]

Most likely it's mainly just what Tim and Nise said. Since physics uses a fixed timestep (60 Hz in 0.1, and Bevy's 64 Hz on the main branch), it can sometimes run once per frame, and sometimes skip frames depending on the screen refresh rate. The solution is to use transform interpolation to visually smooth out the movement between fixed timesteps, but this isn't built-in yet. It should be in the next release though, and I also have a bevy_transform_interpolation crate (somewhat experimental)

You can also (1) increase the fixed timestep rate to match the refresh rate, or (2) use a variable timestep, but (1) can be more expensive at high refresh rates, and also makes behavior dependent on the frame rate, and (2) is even worse in terms of determinism, and can make behavior wonky if FPS is inconsistent

[little maple]

no rush/pressure, totally just curious, when would the next release be?

I may go with 2 after checking out that crate because what in life is determined anyway amirite

[vestal minnow]

after Bevy 0.15 releases

or the main branch is already 0.15-compatible

[little maple]

oh so the fix is already in avian main?

[vestal minnow]

No, interpolation isn't on main yet, but main uses the Bevy 0.15 RC so it's "ready" in that sense. I want to add a few more things though before release (like the interpolation)

[little maple]

got it 👍 cool

[vestal minnow]

I might also make a release just for the 0.15 migration without the other changes to ease migration but I'm not sure yet... It's a bit of a pain to do lol

[little maple]

I noticed this change that made FixedPostUpdate the default

https://github.com/Jondolf/avian/pull/457

does that mean this should use FixedPostUpdate instead of PostUpdate?

https://docs.rs/avian3d/latest/avian3d/#why-does-my-camera-following-jitter

[vestal minnow]

I think camera following logic can just be in Update on main. You generally don't want it to use a fixed timestep since you want camera movement to be smooth and run every frame with some lerp

PostUpdate is also fine still, as long as it's before transform propagation

[cinder summit]

I tend to use PostUpdate for purely visual stuff, which cameras often are not, since pointing the camera at something usually has some non-simulation impacts like highlighting things or whatever

Also lerp in a variable delta context is wrong, but iirc 0.15 should have that thing mweatherley added

[vestal minnow]

yeah stable interpolation with smooth_nudge would be what you actually want

[little maple]

hmm, maybe I should upgrade and then come back to this. Does there happen to be example code of like.. even an opinionated way to avoid the stuttering?

[cinder summit]

The opinionated way is using the interpolation

And a pretty popular opinion at that

[vestal minnow]

I've been chewing on the interpolation stuff for a couple of days again, and experimenting with making bevy_transform_interpolation work nicely for it (e.g. support alternative component sources for start and end states, like PreviousRotation and Rotation in our case). For now, I think I won't use it for Avian though; making things properly generic is kinda tricky, and my approach there doesn't work well for transform extrapolation.

Instead, I'll probably just add PhysicsInterpolation and maybe PhysicsExtrapolation components to Avian, and tailor it just to physics entities. It's simpler and likely more efficient, and technically we could also take e.g. velocity into account for more accurate interpolation, which requires physics integration anyway

Of course people could still use bevy_transform_interpolation for general interpolation too if they wanted, since it works for any entity with a Transform

[slim ledge]

Considering Avian doesn't support motors and supposing I set a joint-based car up (1 chassis, 4 axle joints each with 1 wheel joint), how should I propel my car? Should I just add some ExternalForce (not torque) to each wheel? Or to the chassis? Other approaches? Or should I just drop it all...

[grizzled depot]

I was eyeing on bevy_transform_interpolation to see if we could have a similar approach to bevy_rapier 🙈 ; I’ll take this approach with a grain of salt then 👌

[vestal minnow]

It works fine, it just duplicates some data for storing the start and end of the interpolation (like what bevy_rapier's TransformInterpolation already does). For physics, you have the separate physics position stored already, so ideally you can just use that, and only store the previous position and rotation as extra

And yeah extrapolation needs velocity so that needs physics integration anyway

In practice I would also expect at least 95% of things that really need to move at a fixed timestep to be physics entities, so I'm not sure how useful fully general transform interpolation would be

That being said, I've seen interest in adding more general interpolation support to Bevy itself eventually (not just for transforms afaik), and if/when that's a thing, we can consider if we can make use of it too. Though I'd still expect physics to want some of its own logic

[sleek thicket]

even if it's not useful, it just makes sense to have
like if you eventually run into a case where you want something without physics in fixed update and then realize that you have to deal with transform being choppy, just using the usual approach is just nice

[void dragon]

Quick question, because I swear I have seen it somewhere. Can I create a collision mesh from an imported mesh? If so how?

[vestal minnow]

You can add ColliderConstructorHierarchy to the scene, it generates a collider for each mesh in that scene once it's loaded

[void dragon]

Yes that was it! Thank you!

[vestal minnow]

Do you have an example of something that changes transforms and must be in fixed update (for determinism or something else) but doesn't use physics?

I agree it'd be nice to have in theory though

[sleek thicket]

does the netcode count?

physics or movement could be done server-side and clients would just receive positions with regular intervals

[vestal minnow]

I feel like you might want something more custom for that, and it's something that the networking library would handle instead of the user (like lightyear iirc), but I know close to nothing about netcode so idk

[sleek thicket]

i guess games without any physics in the first place would also benefit from that a lot

[vestal minnow]

built-in transform interpolation is a physics-only thing in both Godot and Unity fwiw

and if you want it otherwise, just manually lerp/slerp where necessary

[sleek thicket]

hmmm... yeah, maybe it's worth adding that question and link to discussion right in the docs

but intuitively it just seems like a good idea to have a common way to interpolate transforms with movement systems stuck in fixedupdate for any reason

[rocky seal]

i just dropped TransformationInterpolationPlugin into my app and it works great, thanks @vestal minnow

[glacial nebula]

this would get extra tricky for floating origins

[vestal minnow]

I have a thing where you can still modify Transform outside of fixed schedules (e.g. in Update or PostUpdate) and it'll be treated as "teleporting" the entity

So, only transform changes in fixed schedules get interpolated, and only if you don't also change transforms in non-fixed schedules

[glacial nebula]

Wouldn't that mean that when crossing from one cell to the next, the object would jump/not interpolate?

i.e. when the object teleports its Transform

[vestal minnow]

Possibly, yeah

It's only for the remainder of that one fixed timestep but might still be a bit annoying, hmm

[glacial nebula]

what approach were you planning on taking for integrating with big_space?

iirc we had very different approaches in mind

[vestal minnow]

I'd probably try your idea of physics islands

I'm not sure how well it'll work with the current architecture in terms of running physics in parallel for different islands, but we'll need to rework things anyway to do that for actual simulation islands

Also need to consider how this will work together with simulation islands

I guess technically these physics islands would already be a simpler form of simulation islands :p just based on proximity (I think?) and not constraints

Hmm you could probably parallelize simulation island building based on these proximity-based Islands

[vague pebble]

@vestal minnow A funny thing is ocurring with my collision layers when inside a collider that you can collide with, and I add a impulse force my character just jumps way higher

Here is a sample

Any ideas on what causes this 🙂

[vestal minnow]

How do you determine if the character can jump, and apply the jump impulse? It's hard to tell what the problem is, but it kinda looks like the impulse strength is doubled, so intuitively I would guess that maybe it detects both the ground and the other character as entities you can jump on, and then tries to jump on both of them for some reason

which would add the jump impulse twice

I'm just guessing based on what it looks like though

[vague pebble]

I think I already see the mistake

// Handle jumping.
    if action_state.pressed(&CharacterAction::Jump) {
        let ray_cast_origin = character.position.0
            + Vec3::new(
                0.0,
                -CHARACTER_CAPSULE_HEIGHT / 2.0 - CHARACTER_CAPSULE_RADIUS,
                0.0,
            );

        // Only jump if the character is on the ground.
        //
        // Check if we are touching the ground by sending a ray from the bottom
        // of the character downwards.
        if spatial_query
            .cast_ray(
                ray_cast_origin,
                Dir3::NEG_Y,
                0.01,
                true,
                SpatialQueryFilter::from_excluded_entities([character.entity]),
            )
            .is_some()
        {
            character
                .external_impulse
                .apply_impulse(Vec3::new(0.0, 5.0, 0.0));
        }
    }

I forgot the spatial query filter

[vestal minnow]

Might also want to use just_pressed to only apply the impulse once? I believe pressed is true for every frame the button is held down

[vague pebble]

Turn out yeah it laster for 4 frames

[void dragon]

https://docs.rs/avian3d/latest/avian3d/spatial_query/struct.ShapeHitData.html
Here the how should I interpret the TOI?

I am trying to create a kinematic character controller, and for the collide and slide algorithm I need the distance between the projection and hit.

[vestal minnow]

It's essentially just the distance the shape traveled before the first hit

It's most likely getting renamed to just distance soon

[void dragon]

that is much more intuitive. thank you

is it 1:1 to vec3 distances? so a distance of 1.0 is the same as vec3(0.0, 0.0, 1.0).length()?

[vestal minnow]

Yep

[void dragon]

May I ask if this is something that you come home from work and do? Did you have another big project in a physics engine before bevy?

[vestal minnow]

I don't currently have a job, but I'm a first-year university student, and yeah I do this mainly as a hobby

[void dragon]

No way. How old are you?

[vestal minnow]

I didn't have prior experience with physics simulations before I started making physics stuff for Bevy, I mostly did web dev, some mobile development, tinkered with several languages and technologies, and occasionally did some stuff in Unity and Godot

[vestal minnow]

I'm 19

[void dragon]

Man I am 20, you make me feel obsolete. What are you studying in uni?

Dont take it the wrong way but I thought you are some 30 year old guy with 2 bachelors in computer science and a master in physics just cuz its fun.

(2 bscs of course I am joking)

[vestal minnow]

It's basically just computer science (not that exact study programme, but largely equivalent)

(I'm from Finland)

[void dragon]

I am from Hungary

[vestal minnow]

haha no worries 😄

I'll take that as a compliment

[void dragon]

This is so crazy. You will have the easiest time finding an internship.

[fiery mortar]

Hey, I wanted to circle back on this. I tried this and it didn't work. Closest I could get was dividing by TimestepMode::FixedOnce::delta, but this caused some weird jitter with angular velocity.

My goal is something like a kinematic position-based rigidbody for use in a character controller. I'm considering forgoing use of velocity and using Position and Rotation directly.

[vestal minnow]

So are you trying to implement a kinematic position-based character that has Position and NextPosition components, and derives the velocity based on them such that the body will end up at NextPosition by the end of the frame?

[gritty estuary]

no way! 😳 you're too talented lol

[vestal minnow]

haha thanks 😅

[gritty estuary]

I'm the same age as you but I'm very far from making a physics engine 😅

[vestal minnow]

Eh, I started by just copying a tutorial, and it took a long time and struggling with papers and math before I actually understood how things generally worked (and I still don't fully understand a lot). It's a ton of incremental learning and researching into what other engines do, and I feel like I'm still in the lower end of the learning curve

I've technically been working on this stuff for over two years now, though actively about one and a half years probably

the first commit in the repo is from May 29, 2022, although I remember playing around with Verlet integration and watching YT videos on physics simulation stuff before that

[gritty estuary]

It's literally impossible for me to work on my project and study at the same time. I can only work efficiently on my project during the vacations...

[gritty estuary]

it's impressive what you've done in ~2 years

learning physics is tough so making an engine sure is

[vestal minnow]

development through the last year of high school with matriculation exams going on was pretty rough 😅

[void dragon]

nah the impressive stuff the understanding papers at 19

that's a highly appreciated skill

[vestal minnow]

The paper I was mainly using for bevy_xpbd (what Avian was before it was rebranded) is this one on XPBD
https://matthias-research.github.io/pages/publications/PBDBodies.pdf

As far as papers go, it's not too crazy, the algorithm is outlined pretty clearly, everything is in pretty self-contained sections, and the formulas are relatively simple (though I didn't understand a lot of them at first)

I've definitely seen some papers that are a lot more unreadable with my math knowledge though lol

[void dragon]

this is what I am saying. You say eh it's hard but doable.

at 19 years old.

[proven ice]

is there any way i can toggle physics simulation of entities and then resume them?

i'd like to make a system for volumes where physics is allowed; if anything is outside a physics zone, it will pause that entity until physics in that area is permitted.

[vestal minnow]

For now, you could probably just add/remove the RigidBody component, or make the paused bodies kinematic or static. I also have a PR (#536) to add a RigidBodyDisabled component, which I'll most likely merge for the upcoming release

[proven ice]

alright, i see! i should probably explain why i want this - i'm doing a minecraft clone (bc there aren't enough already) and want to generate a small mesh around physics bodies for collision (from the world geometry / voxel data).

could i just make the system for updating these collision meshes run before physics systems to ensure simulated objects don't go too fast, leave their calculated collision zone, and fall through / clip into the world?

[vestal minnow]

Not sure if I quite understood what you mean by collision zones 🤔 Do you mean that you generate colliders only for "active" chunks, and want to disable physics for "inactive" chunks to prevent bodies from falling through? But yeah you can probably update them before physics

[proven ice]

yeah basically what youre describing

can avian efficiently handle collisions with larger collision meshes? does parry spatially partition collision meshes?

[vestal minnow]

Yeah, it uses a Bounding Volume Hierarchy (BVH) for each trimesh to partition the triangles. Not super fast but pretty decent afaik. I think it's mainly slow if you have a ton of small triangles densely packed together, since then you might be intersecting all of them at once and get way more hit tests than normal

[proven ice]

oh, okay! thats great, because i can just generate the collision mesh for entire chunks at once.

there's a problem in many physics engines (including avian) where things sliding along touching / flush (but separate) faces will hitch. to solve this, i would probably merge contiguous chunk meshes. but how would i unmerge when the chunk unloads? do i need to store all the chunk meshes and the combined mesh so i can recombine them upon chunk unloads (without having to remesh everything)? i cant think of a way to solve this without doing really hacky stuff with caching and tagging regions of mesh data to specific chunks and then deleting those regions when chunks unload. there's gotta be a better way.

so ig my question is: do you know of a solution to the hitching problem?

(btw im talking about collision meshes here)

[little maple]

I had that problem in a car game I'm making and the "solution" I ended up going with was to make a floating car controller using raycasts and impulses to "float" the collider rather than having it slide along the face.

it's a bit of work, but in the end I don't have to worry about the world meshes as much

[little maple]

Edit: I think I'm just going crazy over frame rate inconsistency so ignore this

I'm trying to get to the bottom of this stutter in my game. This is a really simplified example where I have a cube spawned with a linear velocity, zero gravity, a camera following it with an offset on after(PhysicsSet::Sync).before(TransformSystem::TransformPropagate). I'm using the bevy_transform_interpolation crate and have time set with Time::from_hz(120.0) and running in release mode.

and to me, I still see these random stutters... do y'all see it too? Is this enough to rule out that it's caused by the physics engine?

[fiery mortar]

Basically, yes. I've got this working perfectly fine in an minimal example, but in my actual game the angular velocity is not applied in full.

pub fn log_system(
  physics_time_r: Res<Time<Physics>>,
  mut player_character_q: Query<
    (&Transform, &AngularVelocity, &Rotation),
    With<PhaseTagComponent>,
  >,
) {
  for (transform, angular_velocity, rotation) in player_character_q.iter_mut() {
    debug!(
      "{:?}+{}={}?",
      transform.rotation.to_euler(EulerRot::YXZ).0,
      (angular_velocity.0 * physics_time_r.delta_seconds()).y,
      rotation.0.to_euler(EulerRot::YXZ).0
    );
  }
}

This gives me outputs like -0.7853124+3.1415927=2.2909148? and then 2.2909148+0.06528074=2.3562312? . It seems to simply not being applied in full and takes two steps to apply the velocity.

Which is strange, because I have a minimal app with the same implemetnation and it works just fine.

[void dragon]

Did you write the character controller yourself?

[void dragon]

You can merge them, and then save the merged vertices indexes.

I do not have an example, because I have never seen anything like this, but I think it could be done.

[little maple]

yes, although the clip there is not using it at all. That's literally just spawning a collider with zero gravity and giving it a linear velocity of Vec3::Z. I think what I'm seeing there is related to framerate and not avian

[void dragon]

So this is a dynamic controller and not a kinematic?

[little maple]

the one I made is dynamic

[void dragon]

Ah okay I hoped that it is kinematic :D

[little maple]

have you seen bevy_tnua? I really like it for character controllers

[void dragon]

I want to create my own, and I have tried understanding tnua but I just couldn't.

I am having some weird behaviour currently. I will probably fix it sooner or later. It would have been faster if I could ask someone.

[little maple]

have you seen the toyful games youtube video on character controllers?

[void dragon]

Yeah but it is not what I am looking for.

[wide oar]

hey how do I get rid of these messages if I am juz spawning a bunch of static colliders that is closesly together (they are not overlapping actually)

WARN avian2d::boom::narrow_phase: Entity { index: 451, generation: 1 } and Entity { index: 502, generation: 1 } are overlapping at spawn, which can result in explosive behavior.

[sleek thicket]

for now just spread them apart further D;

[wide oar]

well I can't really do that haha, cuz it's a terrain map and the visuals and collisions would be off 🤣

[sleek thicket]

huh, iirc static colliders aren't supposed to have that message

[cinder summit]

Yea, static-static doesn't even get to the plugin that produces that message, there were some bugs that made them show up with kinematics tho, despite the fact that kinematic bodies can't produce explosive behavior because they have no collision responses

Idk if the fix for that ever got merged

[wide oar]

I am still in version 0.1 tho, not sure if I should upgrade? but I am using also leafwing 0.14 and bevy 0.14

[sleek thicket]

i'd wait for 0.15 first, it shouldn't be that long now

but i don't think version matters

[wide oar]

I see, I will dig into the source code I guess 🤣

[sleek thicket]

just remove rigidbody from terrain and see if it still shows messages

[wide oar]

alright lemme test

[wide oar]

it doesn't show warnings anymore

tho does it still collide

[sleek thicket]

yeah, you only need RB on the thing that moves

[wide oar]

oh yeah I will do that

so the colliders doesn't need one?

[sleek thicket]

if they're static, and not sensors, no

[wide oar]

I see, that' s neat

ill try it out!

[sleek thicket]

should be same, but sensor instead of trigger

[wide oar]

oh alright, didn't know it follows that

[little maple]

is it possible for avian to skip applying impulses for a frame?

I have an Update system "A" that applies an impulse to an entity
and a PostUpdate after PhysicsSet before TransformPropagate system B that reads the transform

and sometimes I'll get a frame where the transform in those two systems is the same and it's also the same when system A runs on the next frame

Edit: I believe what might be happening is since System A is on Update, if a frame takes longer than the fixed update, the impulses get made too late.

[wide oar]

seems like I still need the RigidBody::Static for collision to work 🤣

[hidden girder]

Yup, can confirm on 0.1.2. At least when using a trimesh collider for the ground.
Everything just falls through if terrain entity does not have RigidBody::Static.

I also noted a large performance issue for trimesh collision.
When not adding CollisionMargin to the terrain entity, rigid bodies seem to be unable to enter sleep/are woken up by something(maybe speculative collision?).
Fps start to drop very noticably when >1.5k capsules with locked rotation are falling onto the terrain.
Note:
The drop only starts to happen when they start colliding with the terrain.
While all are falling the fps are fine.
Adding the CollisionMargin to the trimesh collider entity reduces the severity of the fps drop but it is not prevented entirely.

[hidden girder]

Does anyone have any idea what can cause this behaviour?

The duck is moving forward by updating its LinearVelocity component.
The update happens in the Update schedule of bevy.

It looks like its position is reset if it starts moving.
Furthermore, it starts to look jumpy/shaky and starts to bounce after a few seconds of moving forwards.
It has a capsule collider component, and the ground is a trimesh collider.

Sidenote: Previously, i have been using rapier and there it was just sliding along the ground without the resetting/bounciness.
I am sure I am doing something wrong/missing something but for now I am not exactly sure what.

[little maple]

I've seen similar behaviors caused by different things.. might be helpful to know exactly what LinearVelocity you're setting it to and using the PhysicsDebugPlugin to see all the colliders visually to start with

[hidden girder]

When using PhysicsDebugPlugin it looks like this:

[little maple]

are you using LockedAxes to lock translation?

[hidden girder]

like this when its standing still, i guess the lines are overlapping with the mesh so sometimes they are not visible.

Linear Velocity change is just z axis but once it starts moving linear velocity changes on x and y too.

I am just using LockedAxes::ROTATION_LOCKED

Restitution is set to Restitution::PERFECTLY_INELASTIC

[silk mauve]

I know the kinematic character controller example isn't really intended for use, so I'm not trying to be critical with this but I thought it was interesting. I'm using the kinematic_controller_collisions from the kinematic character example, and when I walk my character over the edges of the triangles in my custom terrain they seem to bounce like I might expect them to do if the character went over a small ramp:

[fleet field]

I had the same issue. You can follow the conversation starting with my message on how to fix it with a floating capsule: #1124043933886976171 message

It worked for me

[silk mauve]

Thanks!

I am curious if this would be fixed with a proper collide-and-slide implementation. I just don't know enough about this

[fleet field]

Perhaps. I quite like the floating collider approach as it can give you slopes and stairs basically for free if you float high enough

[silk mauve]

That's fair

[sleek thicket]

yeah, for 3d the floating collider will be good even if edge ghost collision bug gets fixed

[finite blaze]

HL-2 anniversary doc, and how they used a string comparsion scale for object masses when debugging ("mass of a food can", "racehorse", "space station"): https://youtu.be/YCjNT9qGjh4?t=2138

[sleek thicket]

lmao

[finite blaze]

there's several tricks the comment about, for example increasing the friction of the player when closer to edges

[vague pebble]

I am curious if I want my collider to rotate so he stares at mouse direction should I try applying force or just apply directly into angvel?

[wide oar]

depends on how u want it, but u cud also use angular velocity as well

btw is there a concept of physics world in avian? let's say I want to have world 1 and world 2 so that they do not collide/interact with each other, is it possible?

[wide oar]

from my research it seems like it's not supported yet, tho would it help if I use separate bevy Worlds?

[hidden girder]

I have not used multiple worlds in one bevy app yet.
However, if systems are run on each world separately, it should work as avian uses bevy systems for the physics calculations.

[hidden girder]

If you just want a few entity collision kinds to completely ignore each other you could also use CollisionLayers (Note there are only 32 layers available)

[wide oar]

I did some experimentations, and it seems really hard to get it working 😢

[wide oar]

yeah that's the thing, ideally the server should be able to support as much game sessions as the server can handle haha

the only "easier" solution I came up with is to put them in different locations and simulate them altogether 😭 , for now precision isn't the issue yet...

[vague pebble]

I dont know what is usually the go tofor character controllers

[wide oar]

if it's kinematic, just rotate it

[vague pebble]

nope dynamic

[wide oar]

then maybe consider using some sort of physics, but I really don't think it will matter that much since avian won't just explode if you accidentally clip into another collider due to rotation

it really depends on your use case, if you want snappy rotation, then rotate the Rotation component, if you want physics based, then use AngularVelocity or force

[wide oar]

wanna ask, does CollisionLayer also affect sensors?

[hidden girder]

yes, afaik sensors only prevent collision entities from being affected by physics.
Otherwise, they should behave like regular colliders.

[wide oar]

I see, thanks!

[sleek thicket]

if it's for the head, then it sounds like a job for inverse kinematics

[cloud jasper]

I think it's not that important for rotation.

It's crucial for linear velocity/acceleration, because even the slight differences between working with the velocity and working with the acceleration can have big effects on where the character ends up. Also, changing the velocity directly makes it possible for the character to slightly phase into solid walls - something that doesn't happen with acceleration (ExternalForce really). On the other hand, using acceleration makes it easier to overshoot - especially if you are not using fixed timestep. With velocity it's much easier to stop exactly when you want to. Because of that, for Tnua's linear movement part I'm using acceleration in general but when the character stops, during the last frame, I switch velocity to guarantee it won't change the direction before stopping completely (especially important if some other system is looking at the direction of the velocity to decide where the character should be facing)

But for rotation? The difference will be quite minor. It will affect how quickly the character turns, but the difference will not be noticeable - and either way the character will end up facing the same direction.

I do suggest though that you use angular velocity, which makes the calculations simpler. Additionally, phasing into walls is not a problem with rotation - but overshooting is.

[vestal minnow]

Okay, I've kept working on this for the past few days, and I might take back what I said; currently, I think I will use bevy_transform_interpolation for Avian as well.

I've reworked the structure a ton and made it more extensible, and in #4 I managed to implement decent transform extrapolation, and also added support for some shiny (optional) Hermite interpolation to produce more accurate motion by taking velocities into account for the interpolation. The velocity components aren't defined in the crate itself, but passed in using generics implementing a VelocitySource trait. For Avian, this means that the interpolation can just use LinearVelocity and AngularVelocity instead of storing duplicates.

As for my concern re: duplicate position components instead of using the physics position directly, I think I'm actually fine with it for now. It means that we don't have to worry about hierarchies (Position and Rotation in Avian are in global space, but the interpolated Transform isn't!), and it might make big_space support more straightforward.

I'm still working on this though, so of course I could change my mind for the millionth time 🙃

Things I still need to do for bevy_transform_interpolation:

• Try to integrate it with big_space
• Test camera following scenarios
• Maybe move the actual easing from PostUpdate to RunFixedMainLoop, in RunFixedMainLoopSystem::AfterFixedMainLoop? (#2)
• Rework module structure some more
• Add a 3D example or two
• Finally, add a PhysicsInterpolationPlugin or similar to Avian using it

[vestal minnow]

Not currently possible, other than using separate Worlds (pain), collision layers (limited to 32 layers), or filtering collisions manually (relatively slow).

It's a bit tricky to support more than one physics instance since Avian uses the ECS directly, and the ECS doesn't really have proper multi-world support or partitioning. In the future, we will probably do a limited version of "multiple physics worlds" where you can just assign physics entities to worlds/groups using some PhysicsWorldId, and each world has its own acceleration structures and constraints, making them fully separate in terms of physics entities interacting with one another

[little maple]

I think I've narrowed down the source of the stuttering in my game

I have the camera follow in PostUpdate, impulses applied in FixedUpdate and every couple seconds I get a frame where the physics isn't run before PostUpdate runs (which updates the smooth camera)

so everything stays still but the camera moves which makes it stutter.

I think I can work around that now that I know it's happening.. I guess it makes sense, just an update that doesn't align with the physics fixed update

[vague pebble]

Ah yes problem is I have no idea how to conver mouse motion into angular velocity

[cloud jasper]

But you know how to convert mouse motion to torque?

[vague pebble]

No

Hahhaa

[wide oar]

actually I have a questions, how does one filter collisions manually?

[wide oar]

this can be solved using transform interpolation: https://github.com/Jondolf/bevy_transform_interpolation

[wide oar]

let movement = action
    .clamped_axis_pair(&PlayerAction::Move)
    .map(|axis| axis.xy())
    .unwrap_or_default()
    .normalize_or_zero();
let desired_angle = movement.to_angle();

angular.0 += rotation.angle_between(Rotation::radians(desired_angle))
    * spaceship.angular_acceleration
    * time.delta_seconds();

here, movement is a Vec2 direction, and rotation is the Rotation component from the entity

this is juz one way, u cud formulize other ways to do it hahaha

[cloud jasper]

I find it easier to keep a persistent representation of the direction you want your character to face, and use mouse positions to rotate that direction. This is easier than doing it with velocity, because you can just convert mouse movement units into radians with a simple multiplication. Unless your character is a plane/spaceship - keep the spinning and elevation separate to make the updates easier.

Once you have that, calculate the angular velocity required to rotate to that direction in a single frame - and clamp it by the maximum rotation speed you want to allow (you'll probably want to have separate limits for spinning and pitching). That's the angular velocity for that frame.

This does mean that the character will keep turning for a bit after the player stops moving the mouse. But:

• Unless you use very slow rotation limits, this will hardly be noticeable.
• If you use a third person camera, you can move the camera separately from the character so that the camera will respond immediately to the mouse motion, even if the character takes a bit more time to get there.
• If none of these solutions are applicable - you can just have that forward direction slowly "diminish" (using a weighted average) toward the actual direction every frame.

[little maple]

I am actually using that. I think the problem is that during that frame where the physics doesn't update nothing in the physics world moves but my camera is lerping closer to its target (which hasn't moved) and then on the next frame it kinda over compensates. My solution is to just not move the camera if the target's translation hasn't changed

[little maple]

that crate is good though, it definitely helped smooth everything out

[wide oar]

im controling a spaceship haha, but yes I agree, rmb to use deltatime too!

[wide oar]

ah I have similar issues as well, it's when my bullets are telelporting from one position to another due to object pooling

my current solution is to not interpolate it at the start haha, maybe you can remove interpolate when it's not moving?

[little maple]

ah, that's interesting, I may run into that at some point. I guess for now I just have to "pause" the camera for a frame which is easy enough without having to add/remove components

[void dragon]

Hi! How do I show the collision shape in Avian in the 3D space for debug reasons?

https://docs.rs/avian3d/latest/avian3d/debug_render/struct.PhysicsDebugPlugin.html
found it

This is actually getting funny. Quick description: I am currently trying to implement a collide and slide algorithm. I am using the cast_shape function to manually check collision. If I press forward or/and left it works as expected, if however I press backward/right it for some what reason makes a collision at a distance of 0.0. I cannot debug it. The blue line - velocity - touches the ground everywhere. Everything shown in the visual is the same as in the cast_shape function.

The object is not moving in any direction. It has no LinearVelocity set.

[void dragon]

Could this be a bug?

[void dragon]

(please)

[vestal minnow]

Hard to tell what's happening there, I'd probably log the shape cast directions and make sure they look correct for each input direction

Also FYI there's a few existing collide and slide implementations for Avian floating around, like this one in vidar by UB

aceeri also has one, but I can't find it rn with Discord's search

[void dragon]

Oh wow thank you so much!

[void dragon]

They do! Also the blue line that is shown is the direction times the max distance.

[rocky seal]

@vestal minnow using bevy_transformation_interpolation i experience a regression between HEAD and the previous commit. interpolation works great on the previous, but when i use the latest:

2024-11-21T22:52:18.270855Z  INFO bevy_diagnostic::system_information_diagnostics_plugin::internal: SystemInfo { os: "Linux 21.3 Linux Mint", kernel: "6.8.0-49-generic", cpu: "12th Gen Intel(R) Core(TM) i9-12900K", core_count: "16", memory: "62.6 GiB" }
2024-11-21T22:52:18.371795Z  INFO bevy_render::renderer: AdapterInfo { name: "NVIDIA GeForce RTX 3090", vendor: 4318, device: 8708, device_type: DiscreteGpu, driver: "NVIDIA", driver_info: "535.183.01", backend: Vulkan }
2024-11-21T22:52:18.749330Z  INFO bevy_winit::system: Creating new window "App" (0v1#4294967296)
2024-11-21T22:52:18.749486Z  INFO winit::platform_impl::linux::x11::window: Guessed window scale factor: 1
thread '<unnamed>' panicked at /home/ty/.cargo/git/checkouts/bevy_transform_interpolation-06af9eb63201b40c/1ee1c33/src/lib.rs:321:75:
called `Option::unwrap()` on a `None` value
note: run with `RUST_BACKTRACE=1` environment variable to display a backtrace
Encountered a panic in system `bevy_transform_interpolation::reset_easing_states_on_transform_change`!
Encountered a panic in system `bevy_app::main_schedule::FixedMain::run_fixed_main`!
Encountered a panic in system `bevy_time::fixed::run_fixed_main_schedule`!
Encountered a panic in system `bevy_app::main_schedule::Main::run_main`!
Segmentation fault (core dumped)
error: Recipe `local` failed on line 5 with exit code 139

[vestal minnow]

Thanks for reporting, should hopefully be fixed now

[rocky seal]

nice! thanks

[golden python]

Anyone know how mass is handled when not explicitly set ?

[rocky seal]

from the collider: https://docs.rs/avian3d/latest/avian3d/dynamics/rigid_body/struct.ColliderMassProperties.html

[golden python]

Thanks

[hidden girder]

https://docs.rs/avian3d/latest/avian3d/collision/struct.Collisions.html

Maybe this can help you.

[hidden girder]

Looking back at your original question and what is written in the docs.

You can probably create a CollisionWorld component with an id and attach this to your colliding entities.
Then retain only those collisions where both share the same CollisionWorld id in manual collision filtering.

[wide oar]

ohhh that sounds like a plausible idea!

[last forge]

I got my force systems working with bevy_trait_query! My force components impl the Force trait. Each one gets updated in a system set just before the physics updates. In the prepare phase, a system gathers all components that implement Force sets the external force to the sum. I am approximating drag by using the bounding sphere as the thing making drag. Still working on a system that does differential drag based on the mesh. Some experiments showed it could work if I'm clever.

It's not much but it's there. I think I'm finally getting the hang of Bevy and Avian. Thanks yall for answering my noob questions lately. Next thing is to add force debug vector gizmos and attach a dangly tether to the bottom for fun

[vague pebble]

Hmm, weird why would i map a mouse to x.y if he already is 2d?

[vague pebble]

Hmm yours make more sense that way I always have the go to

[wide oar]

that's juz leafwing semantics xd, u can juz think of movement as a Vec2 direction

[sleek thicket]

@vestal minnow did "Block" come up as a name for a collision library before?

[vestal minnow]

I don't think so

[sleek thicket]

i was working on adding block and parry to the game and thought it'd be a good name xD

[vestal minnow]

repel 🤔

[sleek thicket]

i mean, you could think of minecraft/building blocks which kinda also relate to collisions a lot better

[vestal minnow]

yeah

repel is kinda funny because "avian repellent"

i.e. bird repellent

[sleek thicket]

if you wanna pair meme with avian then i'll have to think harder D:

[vestal minnow]

nah I don't actually want that haha

[sleek thicket]

"avian uses ### collision library"

fuck, it has to be glass or cage

[edgy light]

"angry". it's a well known fact that angry avians like to collide into stuff

[sleek thicket]

there are so many names that are super effective in that context xD

[vestal minnow]

Fixed a scheduling issue in bevy_transform_interpolation btw, it was causing problems for camera following logic in Update
https://github.com/Jondolf/bevy_transform_interpolation/pull/5

It's pretty nice how Avian's new default scheduling setup (FixedPostUpdate) and this interpolation stuff simplify the camera ordering shenanigans you used to need for camera following logic

// Before
app.add_systems(
    PostUpdate,
    camera_follow_player
        .after(PhysicsSet::Sync)
        .before(TransformSystem::TransformPropagate),
);

// Now
app.add_systems(Update, camera_follow_player);

of course you could still use PostUpdate too for camera following, but either way you don't need to order things relative to physics

[sleek thicket]

is it 0-lag though

[vestal minnow]

define 0-lag, interpolation can never not be behind true positions

Or you mean the camera following? It shouldn't lag behind the rendered transforms of the entities

[sleek thicket]

i mean if the game is at 60 fps, is that still the case?

[vestal minnow]

If the fixed timestep matches the screen refresh rate then you're just running fixed update every frame, and the interpolation shouldn't have an effect

[sleek thicket]

wasn't it 64 though

[vestal minnow]

yes

just means that for some frames, it'll run fixed update twice or zero times, and when it's zero times, it should get interpolated

or no it should always run once or twice I think

I'm confusing myself, it's late

[sleek thicket]

at 60 fps each frame is 16ms, so i really don't want any delay there 😅

i was planning on just not using interpolation for now, but if there's no cost then i'll have to try it

[vestal minnow]

it's at least super easy to just try and see if it helps, just add the dep and plugin, and enable it for everything or for specific entities

Or for Avian 0.2 I'll add a PhysicsInterpolationPlugin or similar that just uses bevy_transform_interpolation and sets things up nicer for physics

[river moat]

It is really strange, but my game (with default PhysicsPlugins) always crashes after adding mesh colliders. This is my system for adding mesh collider (during Update stage):

pub fn add_mesh_colliders(
    mut commands: Commands,
    query: Query<
        (Entity, &Handle<Mesh>),
        (
            With<RequireMeshCollider>,
            Without<MeshColliderAdded>,
            Without<MeshColliderError>,
        ),
    >,
    meshes: Res<Assets<Mesh>>,
) {
    for (entity, mesh_handle) in query.iter() {
        let Some(mesh) = meshes.get(mesh_handle) else {
            continue;
        };
        let Some(collider) = Collider::convex_decomposition_from_mesh(mesh) else {
            error!("Invalid collider mesh");
            commands.entity(entity).insert(MeshColliderError);
            continue;
        };
        debug!("Adding mesh collider");
        commands
            .entity(entity)
            .insert((collider, RigidBody::Static, MeshColliderAdded));
    }
}

And this is error message:

thread 'Compute Task Pool (7)' panicked at /home/artushak/.cargo/registry/src/index.crates.io-6f17d22bba15001f/glam-0.27.0/src/f32/mat3.rs:458:9:
assertion failed: det != 0.0
note: run with `RUST_BACKTRACE=1` environment variable to display a backtrace
Encountered a panic in system `avian3d::collision::collider::backend::update_collider_mass_properties<avian3d::collision::collider::parry::Collider>`!

[river moat]

Can it happen due to static rigid body entity having parent entities without any physics-related components?

Very interesting, adding capsule collider instead of the mesh one causes the same crash

[river moat]

Even when I simply spawn:

let cube_mesh = Capsule3dMeshBuilder::new(0.35, 1.1, 10, 10).build();
let collider = Collider::capsule(0.35, 1.5);
let cube_mesh_handle = meshes.add(cube_mesh);
commands.spawn((
    PbrBundle {
        mesh: cube_mesh_handle,
        transform: Transform::from_xyz(0.0, 2.0, 10.0),
        ..default()
    },
    RigidBody::Static,
    collider,
));

game crashes, but if I spawn

let cube_mesh = Capsule3dMeshBuilder::new(0.35, 1.1, 10, 10).build();
let collider = Collider::capsule(0.35, 1.5);
let cube_mesh_handle = meshes.add(cube_mesh);
commands.spawn((
    PbrBundle {
        mesh: cube_mesh_handle,
        transform: Transform::from_xyz(0.0, 2.0, 10.0),
        ..default()
    },
    collider,
));

it does not

[brittle pilot]

Hi!
Is there a way to find the closest collider to a point?
I'm trying to implement basic obstacle avoidance, but i don't want to just on random raycasts.

[north kindle]

Hi, I am new to avian, is there any way to visually debug collisions et forces applied on rigid bodies ?

[river moat]

Here comes the minimal reproducible example™:

use avian3d::prelude::*;
use bevy::{prelude::*, render::mesh::Capsule3dMeshBuilder};

pub fn test_spawn1(
    mut commands: Commands,
    mut meshes: ResMut<Assets<Mesh>>,
    mut local_flag: Local<u8>,
) {
    debug!("Local counter is {}", *local_flag);
    if *local_flag == 128 {
        debug!("Spawning debug capsule collider");
        let cube_mesh = Capsule3dMeshBuilder::new(0.35, 1.1, 10, 10).build();
        let collider = Collider::capsule(0.35, 1.5);
        let cube_mesh_handle = meshes.add(cube_mesh);
        commands.spawn((
            PbrBundle {
                mesh: cube_mesh_handle,
                transform: Transform::from_xyz(0.0, 2.0, 10.0),
                ..default()
            },
            RigidBody::Static,
            collider,
        ));
        *local_flag += 1;
    } else if *local_flag < 128 {
        *local_flag += 1;
    }
}

fn main() {
    let mut app = App::new();
    app.add_plugins(DefaultPlugins);
    app.add_plugins(PhysicsPlugins::default());
    app.add_systems(Startup, move |mut commands: Commands| {
        commands.spawn(Camera3dBundle {
            transform: Transform::from_xyz(0.0, 40.0, 0.0).looking_at(Vec3::ZERO, Vec3::Z),
            ..default()
        });
    });
    app.add_systems(Update, test_spawn1);
    app.run();
}

And, alas, it crashes.

Alright, I'll try to remove most of my dependencies and run this example again.

[river moat]

I have figured it out: the reason was this dependency in my game's Cargo.toml:

glam = { version = "^0.27.0", features = ["std", "glam-assert", "rand"] }

[vestal minnow]

yeah the issue is most likely glam-assert in that case

it can panic for a ton of pretty small things

and physics code is quite math-heavy so it's not uncommon to hit those assertions

[vestal minnow]

Yup, there is SpatialQuery::project_point
https://docs.rs/avian3d/0.1.2/avian3d/spatial_query/struct.SpatialQuery.html#method.project_point

[vestal minnow]

You can add the PhysicsDebugPlugin to enable debug rendering for physics. Collisions won't be visualized by default, but you can configure the PhysicsGizmos like this:

app.insert_gizmo_config(
    PhysicsGizmos::default().with_contact_normal_color(foo_color),
    GizmoConfig::default(),
);

IIRC the contact normal should be scaled by the contact force or impulse by default, and you can also adjust the scale using with_contact_normal_scale

[north kindle]

Thx, I will try this!

[wide oar]

hi, in which schedule shud I be checking for collisions?

[grizzled depot]

https://github.com/Vrixyz/bevy_rapier/pull/28 fyi ; a (wip) proof of concept example to use bevy_transform_interpolation with bevy_rapier ; I'd love to strip interpolation-specific code from bevy_rapier and benefit from shared codebase 🤩

[peak marsh]

Is it possible to make a capsule collider, but rotated by 90 degrees? I'm making a top-down view game, so my player entity points to the right by default. I could make it so that my character points up instead, but it will make the rotation logic in other systems more annoying.

Basically my situation:

Oh this works:

Collider::compound(vec![(
    vec2(0.0, 0.0),
    Rotation::degrees(90.0),
    Collider::capsule(12.0, 24.0),
)])

[peak marsh]

Does it make sense to mutate Rotation directly for kinematic bodies? I need it to point to a specific angle, so AngularVelocity won't work for my case.

[north kindle]

Sometimes my RevoluteJoint snap on the other side of the angle limits set by with_angle_limits, how can I prevent that ?

[cinder summit]

Alternatively try the capsule_endpoints constructor, it takes the points that make up the line at the center if you fully remove the radius, should be slightly faster as it's not a compound collider

[vestal minnow]

Cool! I also just made a PR to add built-in physics interpolation support for Avian, powered by bevy_transform_interpolation

(also see #showcase message)

Worth noting that I have a PR ready for bevy_transform_interpolation that adds support for extrapolation and Hermite interpolation, renames some types, and reworks a bunch of docs. My PR for Avian uses that branch, but it can't be merged yet since it depends on a fix on Bevy's main branch that isn't in the RC

[peak marsh]

Thanks, I'll try that too.

[vestal minnow]

Changing Rotation or Transform rotation is generally fine, but collisions with other objects while rotating might not work quite as well since the rotation won't be substepped, and CCD (continuous collision detection) also won't account for the rotational motion

[cinder summit]

If correct collision responses are desired, setting angular velocity so that it results in the desired rotation in a known amount of time (say 1 full tick) would be the way to go

[peak marsh]

Ok makes sense. Also, if you want to tween/animate kinematic rigid bodies (is this a good idea in the first place?), does it matter when the system runs? I'm currently using PostUpdate + .before(PhysicsSet::StepSimulation), but I'm not sure if this is right.

[vestal minnow]

Anywhere before physics should be fine I think

[cinder summit]

If it runs after physics that's fine too, it just runs for the next frame ... As long as it doesn't run in the same schedule with no ordering relative to physics, since that would cause inconsistent ordering

[peak marsh]

Ok thanks for the advice!

[peak marsh]

Also, are these issues also relevant if you're just using kinematic bodies? Since they're not moved by the engine, I'd assume there'd be less potential issues.

[vestal minnow]

Kinematic bodies are still moved by the velocity components like dynamic bodies, in the substepping loop. I believe they do also support sweep-based CCD (which is opt-in). They just don't react to any forces, collisions, or joints

[peak marsh]

Oh yeah forgot about that.

[vestal minnow]

Oh and FYI a third approach would be to just make the collider a child entity, and rotate that by 90 degrees independently of the rest of the player. But yeah capsule_endpoints should be good

[vague pebble]

@vestal minnow A quick questioneriino is there a problem in changing rotation directly I know it is not supposed to be the go to, but do you think that is gonna cause some weird things to occur with a dynamic body.

[vestal minnow]

#1124043933886976171 message

[vague pebble]

Lol

So it is nono

[vestal minnow]

It's fine for some things, but for continuous rotation I would generally recommend changing velocity or applying a torque instead

you can always try it and see if you get problems for your use case, if not then it's probably fine

[vague pebble]


let target_rotation = Quat::from_euler(EulerRot::YXZ, camera_rotation.y, 0.0, 0.0);

    let current_rotation = character.rotation.0;

    let delta_quat = target_rotation * current_rotation.conjugate();

    let (axis, angle) = delta_quat.to_axis_angle();

    let angular_velocity = axis * (angle / time.delta_seconds());

    if angle > 1e-5 {
        // Avoid numerical instability for very small angles
        character.angular_velocity.0 = angular_velocity;
    } else {
        return;
    }``` is this how you would convert the difference between rotations into  angular velocity?

[vestal minnow]

but yeah as a general rule of thumb, use velocity or forces unless you explicitly want to "teleport" the body to a specific position/orientation

[vague pebble]

Yeah I noticed he sometimes just passed through floor

And then went up again

Thing is I cant balance out it is angular velocity, when I do via it.

It goes cucko

It works

But it goes cucko I wonder why

[vestal minnow]

Is camera_rotation a quaternion? The y component isn't exactly an angle I think

[vague pebble]

It is a vec2 giving me the yaw and pitch from camera rotation

fn camera_rotate_to(
    q_transform: Query<&Transform, With<MarkerMainCamera>>,
    mut player_action_state: Query<&mut ActionState<PlayerAction>, With<Predicted>>,
) {
    if let Ok(cam_transform) = q_transform.get_single() {
        let (yaw, pitch, _) = cam_transform.rotation.to_euler(EulerRot::YXZ);
        if let Ok(mut action_state) = player_action_state.get_single_mut() {
            action_state.set_axis_pair(&PlayerAction::RotateToCamera, Vec2::new(pitch, yaw));
        }
    }
}```

This guy

[vestal minnow]

right, makes sense

[vague pebble]

Agh I am guessing i would need a pid to ensure he stabilizes

[peak marsh]

Is there a way to turn off overlap warnings for kinematic bodies? I don't have any dynamic bodies in my game, so it's not an issue. It looks like that it still prints a warning even if you have attached a Sensor.

[peak marsh]

Ah, it looks like it was fixed: https://github.com/Jondolf/avian/commit/571dcc668a5fa27537a33c0d1810f42d41a39894, but missed the 0.1.2 window by 5 days 😩. Could it be backported, since most people is going to be stuck with 0.14 for a while?
Also, it looks like that this logging system is no longer a thing in main, or at least I can't find it. Was it just removed or replaced by something else?

[vestal minnow]

It was removed, since it's not nearly as relevant in Avian as it was in bevy_xpbd, and I've only seen people be annoyed by the spam :P It's also pretty straightforward for users to add the warnings manually in app code if they want
https://github.com/Jondolf/avian/pull/547

I'm not sure if I want to make a cherry picked patch release this late in the cycle just to remove a warning 🤔

if people really want it then I could, it's just pretty small and also technically removing existing behavior

[peak marsh]

Would really appreciate this if it's not too much churn 🙏
I'll probably be stuck with 0.14 for like 1-2 months while waiting my plugins to update. I need to spawn a bunch of bodies really close together (bullethell-ish thing) and my console is basically constantly filled with the warnings.

[paper maple]

It seems that ConvexHullFromMesh doesn't do any sort of internal caching of a generated collider for a Mesh, meaning that it seems to be recalculating the collider for each copy of that mesh that I add. Is that right ? If so, how can I cache the generated colliders in a nice way ?

[vestal minnow]

Hmm, I don't think there's a very nice way to do this with automatic collider generation right now 🤔

If you can generate one Collider in some way, you can just clone that without cloning the actual data, since internally it stores an Arc<dyn Shape> which is cheap to clone.

You could create the collider manually with Collider::convex_hull_from_mesh, you just need access to the Mesh for that

[formal galleon]

hey folks, i think i have a silly question, but i don't know how to proceed. in my game there's a Dir3 that keeps getting denormalized over time - it starts with length 1 and keeps increasing until it panics within a few seconds. here are the last log entries. any ideas how to best debug something like this?

Warning: The vector given to `Dir3::new_unchecked` is not normalized. The length is 1.0099094.
   0: bevy_ecs::system::function_system::system
           with name="avian3d::spatial_query::update_ray_caster_positions"
             at /Users/mario/.cargo/registry/src/index.crates.io-6f17d22bba15001f/bevy_ecs-0.15.0-rc.3/src/system/function_system.rs:65
thread 'main' panicked at /Users/mario/.cargo/registry/src/index.crates.io-6f17d22bba15001f/bevy_math-0.15.0-rc.3/src/direction.rs:63:9:
Error: The vector given to `Dir3::new_unchecked` is not normalized. The length is 1.0099764.
note: run with `RUST_BACKTRACE=1` environment variable to display a backtrace
Encountered a panic in system `avian3d::spatial_query::update_ray_caster_positions`!
Encountered a panic in system `avian3d::schedule::run_physics_schedule`!
Encountered a panic in system `bevy_app::main_schedule::FixedMain::run_fixed_main`!
Encountered a panic in system `bevy_time::fixed::run_fixed_main_schedule`!
Encountered a panic in system `bevy_app::main_schedule::Main::run_main`!

or should I post it in another channel? 😶

[paper maple]

Oh boy

That means messing with loading events and stuff

Any idea on how to streamline this so it's more convenient for users ?

Maybe the component could include a cache_name: Option<String> field that will store it in a Resource CachedColliders(HashMap<String, Collider>), then subsequent calls with the same cache_name can check that resource for a collider if there is one, and use that ?

I'm not convinced of my design pattern, but just a basic idea of how something like that could work ?

[vestal minnow]

We've had the idea of "colliders as assets" for larger shapes like trimeshes and convex polyhedra, and using asset preprocessing to generate colliders for scenes at build-time to reduce startup times. Then you could just pass those collider asset handles around. Afaik there are still some blockers here though, and Bevy's asset preprocessing functionality is pretty half-baked, so it probably isn't very viable just yet

[vestal minnow]

Something like this could probably work

[vestal minnow]

I've seen this a couple of times but haven't been able to reproduce it properly

Is the RayCaster on a dynamic or kinematic rigid body? Or something else

[formal galleon]

its a kinematic body

[vestal minnow]

It should be normalizing rotation every frame for kinematic bodies too so I'm not sure why it'd become denormalized over time

(btw the panic should only happen with debug_assertions enabled, so it shouldn't happen in release mode at least)

[formal galleon]

i cant debug the assertion in new_unchecked, but i could clone the source and insert an if and set a breakpoint 🤔 i will give it a try

[cinder summit]

You can also set up a rule to just hide the warning I think 🤔

[peak marsh]

Just for the overlap warning? Not really seeing anything, at least in 0.1.2. It's only gated behind debug_assertions.

[cinder summit]

I think I've seen other people disable it trough a rule on bevy's LogPlugin

[north kindle]

Hi, I'll ask again with more details. I have been trying to make landing legs for my spaceship, currently the code for them looks like this :

let leg_normal = position.cross(Vec3::Y).normalize();

let leg_entity = parent.spawn((
    PbrBundle {
        transform: Transform {
            translation: position,
            rotation: Quat::from_axis_angle(leg_normal, 0.5),
            ..default()
        },
        mesh: meshes.add(Cylinder::new(0.15, 1.0)),
        material: materials.add(Color::WHITE),
        ..default()
    },
    LandingLeg,
    Collider::cylinder(0.15, 1.0),
    CollisionMargin(0.2),
    RigidBody::Dynamic,
    ExternalTorque::new(-2.0 * leg_normal),
    SweptCcd::default()
)).id();

parent.spawn(RevoluteJoint::new(ship_entity, leg_entity)
    .with_aligned_axis(leg_normal)
    .with_angular_velocity_damping(0.5)
    .with_angle_limits(0.2, 0.6)
    .with_local_anchor_1(position)
    .with_local_anchor_2(Vec3::Y * 0.5)
);

They have a RevoluteJoint that link them to the ship with angle limits and external torque to act like a spring that put them back in position
However, when they hit something, they go off the limits (below 0.2 and above 0.6) as you can see here :

.

[paper maple]

https://discord.com/channels/691052431525675048/1311093318922534973

[vestal minnow]

Hmm, hard to tell 🤔 It kinda looks like the joint stiffness is too low, but I don't think that should be an issue here

I did find one bug related to joint limits recently, which could maybe be related, not sure. That one should be fixed on the main branch

[north kindle]

I will try to rebuild with the main branch and update you about that

Also, ive seen this issue that is similar : https://github.com/Jondolf/avian/issues/553
The workaround is kind of working but it makes my ship shaking

[vestal minnow]

I'm trying to work on finishing the mass rework again, it's such a pain

give me back my Jacobians and Lagrange multipliers

Current issue is that idk how I would detect if the components were added manually or through required components

i.e. in this case

• RigidBody + Collider + Mass(5.0)
  the manually specified mass should probably override the initial value

but if Mass isn't provided, it should be computed from the collider

but Mass is required for RigidBody, so it exists in both cases

[bold garnet]

Seems like you should make mass an enum with an Auto variant, and have a system that calculates the value for components set to Auto.

Much like Val::Px vs Val::Auto

[vestal minnow]

Yeah I kinda had something like that at one point, I've gone through a billion designs

[bold garnet]

You could even have a private ComputedMass component

[vestal minnow]

I also had that design :P

[bold garnet]

Otherwise I don’t think it should be required

[vestal minnow]

The current design idea is roughly this, after several iterations
https://github.com/Jondolf/avian/discussions/499#discussioncomment-10922998

I don't really want a "manual mass vs. computed mass" split, or enums

I'm largely going for how Box2D's mass properties work, but in an ECS context with a bit more flexibility

I.e.

• Mass is established from attached colliders based on their densities by default
• Adding, removing, and modifying colliders affects the body's mass properties
• Mass properties can be set manually at runtime
• Automatic mass computation can be explicitly disabled (with marker components)
  And in our case also
• If a collider entity has Mass, AngularInertia, or CenterOfMass specified at spawn, they override the initial values
• A MassHelper system param can be used to do mass computations and updates that require access to hierarchies or several different components

[rocky seal]

would it be easier if you did not use required components and instead used a builder?

that way, you would know which components the user has provided and which they want computed

[vestal minnow]

I don't see how a builder would necessarily help, I think the same could be done by not having the mass components be required components and just checking if they were added

Just semantically, Mass should 1000% be a required component for dynamic rigid bodies

(not necessarily for static or kinematic)

[bold garnet]

there's a proposal to give the custom constructor access to the components that require it

[rocky seal]

fair enough. it just sounded above like you were having trouble checking whether they were added manually

[bold garnet]

so if A requires B, it can give it a constructor fn(A) -> B

[vestal minnow]

I'd like if Ref<Mass> had an .is_explicit_component() method

[bold garnet]

go review that pr i guess

[vestal minnow]

i.e. "not inserted as required component"

that information is already stored in the bundle info

but not exposed for the component

I'll look into adding that

[vestal minnow]

Do you have a link? I can't seem to find it

Or do you mean this? #general message

I think that'd mainly be useful for me if it can return None to skip insertion depending on some predicate

which might be contentious

[river perch]

Is it possible to run avian3d on a headless server app? When I add minimal plugins I get complaints that avian collision collider need mesh resource from bevy_render

[junior flower]

https://github.com/Jondolf/avian/issues/505

Sounds like this issue. Does the change I commented on this issue solve it?

[river perch]

This is exactly the problem I’m encountering. I do think your comment is gonna solve my issue. I’ll report back when I’ve tried it

[formal galleon]

@vestal minnow I debugged it. It always happens here: https://github.com/Jondolf/avian/blob/f951ed38ed4e03d00b61d772ae21b8c953dd5ba3/src/spatial_query/mod.rs#L273
The rotation Quaternion keeps getting denormalized over time until it crashes. Any clue why it happens? 🤔 I don't exactly understand whats going on in this function with the global und parent stuff, right now.

[river perch]

thank you, this fixed it!

[paper maple]

Is there a provided method to apply an impulse to the Ancestor of Colliders, and have that propogate sensibly through the Hierarchy ?

[paper maple]

Or just some way of determining the "primary" rigidbody in a hierarchy or something ?

Basically it's just really awkward to apply an impulse to an object in my scene :/

[paper maple]

How do I maintain a non-collider Entity's Transform constant relative to another Collider Entity's Transform ?

[formal galleon]

I fixed it. I used to update the rotation in the Update schedule by setting the Transform componenent. I thought they will be in sync after one frame. However, now I also update the Rotation component and it works. I have some strange behavior with my character since updating to the main branch of avian (and bevy 0.15-rc.3). Do we have a changelog or migration guide or something for avian? It would be cool to review the changes for possible incompatibilities with my code.

[vestal minnow]

These are probably the biggest breaking changes so far in this cycle, the PR descriptions should have migration guides.
https://github.com/Jondolf/avian/pulls?q=is%3Apr+is%3Aclosed+merged%3A>2024-08-09+label%3AC-Breaking-Change+

For the actual release I will write a proper migration guide, and a blog post covering the changes, like I did for 0.1 (see the GitHub release and blog post)

[vestal minnow]

I'm not sure what you mean by propagating impulses 🤔 Impulses are only for dynamic rigid bodies, they need to take mass into account

You can apply an impulse to the rigid body entity with the ExternalImpulse component

I intend to rework the force and impulse API at some point though, I'm not entirely satisfied with it

[vestal minnow]

What do you mean by primary rigid body?

You generally shouldn't nest rigid bodies in hierarchies

[paper maple]

Well it's like for example a car that has a parent entity, then all of its rigid bodies as children. The parent thing doesn't have a rigid body

I don't know how best to deal with that kind of situation. Maybe I have a marker component. But I'm importing a car from Blender, so it means some modifying of the loaded scene to give it a marker component. idk, i'm just not sure what to do

[vestal minnow]

Do you need them to be separate rigid bodies? Typically if you load a model from Blender like that, you'd have just one rigid body with several child colliders

[paper maple]

Oh I didn't know that

So parent car container entity would be a rigid body, then children of it would just be colliders, but not rigid bodies ?

[vestal minnow]

If you want stuff like physically simulated wheels attached to the car with joints, they'd need to be separate rigid bodies since they're simulated separately, but if you want just one physics object with many shapes rigidly attached to it, then yeah they'd just be child collider entities

There's also the ColliderConstructorHierarchy component for automatically generating colliders for child entities in a scene, but that of course doesn't have the caching thing either if you had many instances of the same scene

[paper maple]

So the issue I have now is that I'm getting warnings about it having no mass

Cus the Entity with the RigidBody doesn't have a collider itself. The children have colliders and mass, but it doesn't seem be getting respected ?

[vestal minnow]

It should have mass, but not before the scene is loaded and the colliders are actually inserted. The warning is just sent before this, though it probably should be changed to wait somehow

[paper maple]

The parent has less mass than one of the child colliders

[vestal minnow]

Hmm, that's strange

[paper maple]

Might be something to do with the order that things are getting added

idk

Cus maybe im adding things later than expected because I'm caching stuff first, idk

[vestal minnow]

You should probably use ColliderDensity for the collider, and not use MassPropertiesBundle there

[paper maple]

Okay

How does that work if MassPropertiesBundle::new_computed(&collider, 5.), needs to be pre-computed ?

[vestal minnow]

I think the way it currently works is that the components in MassPropertiesBundle only work for rigid bodies, and do nothing on a standalone collider entity. Colliders use ColliderMassProperties instead, and that is computed at runtime based on the shape and ColliderDensity. The Mass of the rigid body is the sum of the masses of all attached colliders

Afaik you can't really precompute mass properties for colliders currently

[paper maple]

Gotcha

[vestal minnow]

The way mass works currently is confusing and kinda footgunny, which is why I've been working on trying to redesign it

With my new designs I think your code would work, i.e. you can set the mass of a collider with MassPropertiesBundle or its individual components

[paper maple]

No problem I don't really mind either way atm - I just couldn't get it to work cus I didn't understand. ColliderDensity worked for me, thanks

[paper maple]

How does Friction behave ? Does friction need to be in Entities with Collider ? Or can I have them in just the parent Entity (with the RigidBody) ?

[vestal minnow]

Currently you can have it just on the rigid body and it'll be used for all attached colliders, unless they have their own Friction explicitly specified

[urban flume]

do heightfield colliders always have to be square?

when I try to add less rows than columns it doesn't look like I expect

this looks right

but if I remove a row it looks like it expects the missing row to be there

[peak marsh]

Will collision reporting become triggers one day? I wonder what's the overhead of just running commands.trigger on every collision by default.

[void dragon]

Remember me? It was a bug, for some reason the ignore_origin_penetration did not work, I filtered out the entity at the beginning, now it works fine.

More context: I cast_shape to query for hits along the velocity to implement the collide_and_slide. I checked the source code of vidar - awesome thanks again! - and I copied the part that filters out the entity itself, now it does not collide with itself. All the math checks out so it is a bug in Avian itself.

[weak gorge]

Greetings. Thanks for the great crate. I noticed when I clone the repo and run the examples they are locked to 144 hz. However, if I copy and paste the example into a new project it is NOT locked to any framerate. Can you share how you were able to lock the framerate? Cheers.

[river perch]

I think inserting resource like this should fix it when you build the bevy app:

app.insert_resource(Time::new_with(Physics::fixed_once_hz(FIXED_TIMESTEP_HZ)));

Actually nvm don’t think that’s it

You can try it

Also don’t think avian physics is related to frame rate itself, you can just define how many times physics run per frame. Fixed frame rate is set by the schedulerunner.

Like this:

    App::new()
        .add_plugins(
            DefaultPlugins
                .set(ScheduleRunnerPlugin::run_loop(Duration::from_secs_f64(
                    1.0 / 60.0,
                )))```

[vestal minnow]

Hmm I think this is a bug, I made a PR with a fix here

It's kinda confusing though, I'm not 100% sure if the inner vectors should represent rows or columns. It's mainly a matter of choice

I think Glam's matrices use a column-major order, and input vectors are the columns, even though visually they look like rows when laid out table-like

But especially for heightfields, that representation might just be confusing

[vestal minnow]

There will be some form of per-entity collision event listeners, either with observers, or with some custom component that registers a one-shot system and runs that.

I've tried the observer route a couple of times, but I'd like the events to be opt-in at the entity-level, and I don't really want the observer events to be sent globally (the buffered events already exist for that) so I haven't been entirely satisfied with that approach

[vestal minnow]

I don't think the examples do anything special here, most of them are just using DefaultPlugins with the default configuration. FPS should be capped to the display refresh rate with PresentMode::Fifo (configurable through the primary_window of WindowPlugin), and that is the default for apps

For example I'm currently on a 60 Hz monitor, and the examples are capped to 60 FPS for me

[cinder badger]

What kind of error is this

[vestal minnow]

Bevy version mismatch?

[cinder badger]

whats supposed to be the bevy version

0.14

yeah its 0.14

[vestal minnow]

If you're using Avian 0.1 and not the main branch, then yeah 0.14

[cinder badger]

so i still have that error

[vestal minnow]

any other dependencies that could be using a different Bevy version?

might also want to run cargo update and/or cargo clean just in case if not

[cinder badger]

Also on the bevy screen it just shows all black, are all collider shapes automatically colored black?

[vestal minnow]

colliders aren't rendered unless you have debug rendering for physics enabled

[cinder badger]

how do you enable this

[vestal minnow]

for a game you'd use meshes and/or sprites to render your entities, but if you specifically want physics debug rendering, you can add the PhysicsDebugPlugin

[cinder badger]

gosh the error is bothering me

i have no idea why its acting like that

it's really frustrating because errors like these pop up, then i'd have to make a whole bug report about it with the chance of being ignored by Jetbrains teams because it's not a severe issue, it would've been nicer for RustRover to not be closed source so it'd be easier to contribute through there to fix stupid errors like these which would be ignored anyway

[vestal minnow]

If the game compiles and runs fine but you still get the error in your editor, you might need to restart Rust Analyzer? (or that looks like RustRover, iirc it has its own thing)

[cinder badger]

yeah i restarted everything, nothing works

[vestal minnow]

hmm I'm not sure then, I haven't used RustRover so I can't help there unfortunately

[vestal minnow]

Okay I have yet another revised version of the mass rework proposal, separating Mass and ComputedMass. I was against it at one point, but I think it does make things much simpler and allows the user-facing API and overall behavior to be nicer.
https://github.com/Jondolf/avian/discussions/499#discussioncomment-11410922

[bold garnet]

I think the public api component / private computed components is going to be an increasingly common pattern.

[peak marsh]

and I don't really want the observer events to be sent globally
fwiw, this is how bevy_picking is implemented right now. The pointer event is triggered using commands.trigger_targets for the affected entities, then cloned and sent to the normal event writer.

[silk mauve]

Is there any situation in which changing the translation of an entity won't move it in Avian?

fn threat_collector_follow_system(
    character_query: Query<(&ThreatCollector, &Target, &Transform)>,
    mut threat_collector_query: Query<&mut Transform, Without<ThreatCollector>>,
) {
    for (threat_collector, target, character_transform) in character_query.iter() {
        if let Ok(mut threat_collector_transform) = threat_collector_query.get_mut(threat_collector.0) {

            let direction = (target.0 - character_transform.translation).normalize_or_zero();

            println!("pos before: {:?}", threat_collector_transform.translation);
            threat_collector_transform.translation = target.0; //threat_collector_transform.translation + direction * 10.0;
            println!("pos after : {:?}", threat_collector_transform.translation);
            continue;
        }
    }
}

The translation changes, and the ThreatCollector has the correct entity reference.

    let threat_detector = commands.spawn((
        Collider::cylinder(10.0, 10.0),
        Transform::default(),
        ThreatCollectorOwner(player_id),
        Sensor,
        CollisionLayers::new([Layer::Sensor], [Layer::Character]),
        OwnerBundle::new(),
    )).id();

... the threat collector if that helps.

[vestal minnow]

Hmm, I might just make a minimal 0.15 migration release tomorrow, and do the full feature release (0.3 I guess?) in a week or two. I really want to land the mass property rework properly, and need some more time to finish it, clean up and merge a few other open PRs, and do all the release prep

[vestal minnow]

Make sure you have a GlobalTransform too. In Bevy 0.15 it's required by Transform, so it should get added automatically, but not in 0.14

[vestal minnow]

This just becomes messy and I'd need to redo the core 0.15 migration to not have the new stuff :/

I'd also like to just call the new release 0.2 and not do a tiny release followed by a huge 0.3

I could also just have a bevy-0.15 branch with the minimal migration path and not do a crates.io release before the full release, idk

[boreal tendon]

is this zed?

[vestal minnow]

RustRover

[rocky seal]

what's the rush? folks that can't wait for the proper release can use main

[vague pebble]

@vestal minnow Mr Jondolf question, besides sleeping is there any other state based logic envolving components?

[silk mauve]

I'm building a boid system in my game that already uses Avian and I'm curious if it's even worth building a specialized spatial partitioning system? I don't know how physics works but I assume there's some sort of spatial partitioning going on to avoid unnecessary collision checks. If that's the case, couldn't I just do a sphere cast for anything on with "Layer::Boid"?

I feel like this is the exact problem a physics engine solves but maybe I'm missing something

[sleek thicket]

yeah, that's something it should solve
