Avian Physics

[valid fog]

Even tho they are angular momentum constrained

And I have angular dampening at 10000

[drifting marsh]

if you'd like Jondolf, I'm trying to make a kinematic character controller again in my spare time if you want to collaborate

[vestal minnow]

I need to make a patch release to fix a few things first, and ideally take a few days off so I don't burn out, but in a week or two I'd probably be interested

[valid fog]

Wait

#1259011159663579186 message

I think this might be related

🤔

[vestal minnow]

If it's a collision thing then maybe

[royal helm]

I've hit some really bad performance with shapecasting when 2 objects are ontop of eachother directly

will try to look into it more in the future

when I'm at my desktop and can profile it effectively lol

[shrewd wharf]

so, any news about my code? @vestal minnow

[shrewd wharf]

btw i wanted to ask two things:
what is making this so hard to do?
and you said that it worked before because it did in substeps, but it doesnt do anymore. but substep of what? the physics used to step two times per frame and now it does only once per frame?

[royal helm]

controllers are just really hard in general to make fully correct

[vestal minnow]

Which part specifically? The changes I mentioned fix getting stuck in the ceiling and being able to jump on walls, I think the main remaining issue might be that jitter when pushing against walls

[shrewd wharf]

yep

this is what im talking about

[vestal minnow]

Also FYI if all you need is collisions for axis-aligned boxes, then I feel like some fully custom physics and collision logic with something like swept AABB collisions could be more performant and robust. But I haven't implemented that myself, and you'd lose some other nice things provided by the engine if you went the route of custom physics

[vestal minnow]

didn't fix it properly yet, I keep getting pulled in a billion directions

[shrewd wharf]

ah yes

[vestal minnow]

So a very rough outline of the old simulation loop is like this, leaving out a bunch of details

loop {
    // Collect potential collision pairs
    broad_phase();

    let substep_dt = delta_time / substep_count;

    for _ in 0..substep_count {
        // Apply gravity, move bodies
        integrate_velocities_and_positions(substep_dt);

        // Compute contacts between broad phase collision pairs
        narrow_phase();

        // Solve contacts and joints
        solve_constraints(substep_dt);
    }
}

Substepping means that each frame is divided into several smaller steps, which makes solving contacts more accurate, and makes the simulation converge faster for more complex setups, meaning that it reaches the desired result more effectively. With very few substeps, things like cloth would stretch a lot, and stacks of objects wouldn't be stable.

As you can see, the narrow phase used to be in the substepping loop, which made sure the contact data was always up to date, but it was super expensive.

In Avian, the relevant parts look like this:

loop {
    // Collect potential collision pairs
    broad_phase();

    // Compute contacts between broad phase collision pairs
    narrow_phase();

    let substep_dt = delta_time / substep_count;

    for _ in 0..substep_count {
        // Apply gravity
        integrate_velocities(substep_dt);

        // Solve contacts and joints (with bias)
        solve_constraints_with_bias(substep_dt);

        // Move bodies
        integrate_positions(substep_dt);

        // Solve contacts and joints without bias to relax velocities
        solve_constraints_without_bias(substep_dt);
    }
}

Here the narrow phase is outside of the substepping loop (like in 99% of engines that have substepping), and the updated contact data must be approximated at each substep like I described. Note that the solver uses impulses instead of position corrections, unlike before.

If we're handling collisions outside the substepping loop, like the KCC collision logic now does, it means that the bodies can move into the wall at every substep without issue and it is only solved the next frame, which is the reason for the jitter. The velocity corrections in the collision logic aim to cancel out that velocity so the character doesn't go inside the blocks

[shrewd wharf]

yeah, i mean, the reason why i chose to use a physics engine is because i really didnt wanted to write my own, and i would probably spend hours and days trying to do it and then ending up giving up on it. but also because i might want to add beach balls into my game lol

and btw

since its a 2d minecraft clone

perhaps the collision checks could be done on the blocks themselves rather than spawning collider entities for the blocks

i tried to do this once but failed

because i couldnt figure out how to do it.

but in theory, it is basically a AABB collision with a tilemap

[vestal minnow]

Yeah if you just know what tile the character is in, you could only check collisions against the tiles that its AABB intersects

[shrewd wharf]

in order to try to write anything collision related in this library, i need to understand everything and how it works

actually

i dont need it if im gonna write from scratch

the physics library will handle the LinearVelocity component, basically

[cinder summit]

Clearly this calls for a customAabbCollider, the most disappointing alternative collider out of all of them

[vestal minnow]

Well, all LinearVelocity really does is

position += linear_velocity * delta_seconds;

So that would be super easy to do even without the physics engine lol

[shrewd wharf]

actually

i need like uhh

i first need a way of calculating the penetration amount on a block

[shrewd wharf]

how can i get the corners or sides of a collider idk

[vestal minnow]

if you need an AABB-AABB penetration depth and normal then I think this should work (probably not optimized)

fn aabb_aabb_collision(aabb1: Aabb2d, aabb2: Aabb2d) -> Option<(Dir2, f32)> {
    let normals = [Dir2::NEG_X, Dir2::X, Dir2::NEG_Y, Dir2::Y];

    let penetrations = [
        aabb2.max.x - aabb1.min.x,
        aabb1.max.x - aabb2.min.x,
        aabb2.max.y - aabb1.min.y,
        aabb1.max.y - aabb2.min.y,
    ];

    let (min_i, min_penetration) = penetrations
        .into_iter()
        .enumerate()
        .min_by(|(_, dist1), (_, dist2)| dist1.total_cmp(dist2))?;

    (min_penetration > 0.0).then_some((normals[min_i], min_penetration))
}

returns the normal and penetration, if penetrating

[shrewd wharf]

but what about the blocks on the chunk

[vestal minnow]

haven't tested much

[vestal minnow]

wdym

[shrewd wharf]

i'm currently trying to calculate the penetration depth on a block

by the player

[vestal minnow]

you can just get their AABBs and use that function

[shrewd wharf]

i guess

oh wait

i just remembered of something

i remember i used a technique where every frame the player would predict where it would be on the next frame based on the current velocity value

and then, if it detected that it would be inside a block

it would add to the position the velocity minus the penetration

[vestal minnow]

yeah that'd be closer to a swept AABB algo

[shrewd wharf]

so it snaps perfectly

but the problem is

to do that i would literally have to ditch the physics library

because it is already doing that

of adding the velocity to the position

[vestal minnow]

there's at least this article on it
https://www.gamedev.net/tutorials/programming/general-and-gameplay-programming/swept-aabb-collision-detection-and-response-r3084/

[royal helm]

got a basic collide & slide movement KCC working 🙂

[vestal minnow]

Ooh nice!

[royal helm]

isn't too complicated, but probably some simplifications that can be made here, you'd probably want to split out Y axis sliding from X/Z (since you might want to scale slopes at the same speed you walk on flat ground)

[shrewd wharf]

i guess i could get my player working if i knew how to implement collide and slide in bevy

[royal helm]

fairly simple actually

added some documentation for it, but this works well

[shrewd wharf]

huh

i want for 2D though...

[royal helm]

should work regardless, just have to change the types

although idk if 2d bevy has dot product for Vec2?

or no it should

[shrewd wharf]

there is

[royal helm]

i was thinking of cross product not usually being implemented in 2d

[shrewd wharf]

theres a tutorial for collide and slide but uhh

theres stuff like project on plane

which i dont think thats for 2D

in that case you would want to project on a vector

which is the dot product!

[royal helm]

project onto is a concept slightly further from dot product

but ya

[vestal minnow]

yeah vector projection != dot product

[royal helm]

vector projection typically uses dot product to do so though

[vestal minnow]

yeah

[royal helm]

honestly is there even another method to do so...?

[vestal minnow]

trigonometry to get the magnitude

and scale the unit vector

[royal helm]

ya but thats essentially dot product no?

I guess thats the problem with math, what really is "different" between two things lol

[vestal minnow]

I think it can be done like length(a) * cos(theta) * normalize(b) unless I'm misremembering

[royal helm]

ah true

although that seems just be a derivation of dot product too

[vestal minnow]

but yea using dot(a, b) / dot(b, b) * b is of course more efficient

[royal helm]

since in normalize you'd be using length too I'm assuming

its just moving the division around a little

[vestal minnow]

yeah I mean you could write length as both sqrt(x^2 + y^2) or sqrt(dot(a, a))

but yeah anyways it's equivalent to using a dot product lol

[royal helm]

we gotta be fancy and start saying stuff like "This is isomorphic to the previous derivation"

[vestal minnow]

that can be left to #math-dev

[royal helm]

haha

[shrewd wharf]

yeah man i dont know if i have the patience for coding my own physics solution

you know what

i'm reverting back to xpbd

sorry

[hexed veldt]

Need some help on a bug I encountered with bevy 0.13 and xpbd 0.4. To detect two meshes collision and then use the contact manifolds to determine the average points for both meshes. The issue I'm seeing is that the caculated average point1 and point2 are far from each other: One of them actually looks correct (align with the mesh), but the other one is far from the colliding mesh. I've attached a video file to show how far those average points are from the colliding point.

[vestal minnow]

If the objects have scaling applied, I think you should transform the points like transform.translation + transform.rotation * point instead of using transform.transform_point(point), because the contact data should already include the scale

Not sure if that's the issue, but it could be related

Btw is it possible to get reactions removed from these #1034543904478998539 topics? 🤔

The ❌ 🇵 🅱️ 🇩 might not be as relevant now 😂

[zinc talon]

time to ping aNamee to correct this oversight /s

[shrewd wharf]

i had to go back to xpbd...

i wont go to avian until i figure out a player controller that actually works. i have other stuff to work on my game so i dont want to waste too much time with that

[hexed veldt]

Thank you @vestal minnow ! You are right. The objects have scale applied. I've tried your approach and now the issue is gone. I can understand why translation was not applied but scale was applied to the colliders; but it isn't obvious to me why rotation wasn't applied here?

[vestal minnow]

The contact data is in local space, because the contact solver needs them in that format, and it's also the output of the collision detection algorithms. We should probably rename the properties to local_point1 and local_point2 to make this clearer though

[hexed veldt]

Quick question: Does avian (and xpbd) skip colliders that are out of the camera view (off screen)? If not, is there a way to customize the engine to skip them?

[vestal minnow]

It doesn't skip them, that would generally cause a lot of weirdness and issues

Like time isn't meant to just stop behind you

I guess you could technically cull all the off-screen colliders and change their collision layers or something so that they don't collide

[glacial nebula]

Thought the convo was happening in here, oops. #1260054020005953618 message
(Was responding to Jondolf there)

[glacial geyser]

Does anyone have a good generic move_and_slide function for avian2d?

[shrewd wharf]

i also want the same thing lol

[glacial geyser]

Hmm I think I just need to take a look at the most recent kinematic controller example and adapt it.

Oh, I just needed to scroll up x.x

[glacial nebula]

FYI, just released the new avian bevy_mod_picking backend thanks to a community contribution https://github.com/aevyrie/bevy_mod_picking/pull/346

[royal helm]

just note that this might not be what you want exactly for 2d depending on what kind of game you are making

if its side view you probably dont want to scale at all with sliding/slopes

if its top down you probably do

might also be some bugs i havent teased out yet

but mainly if you are going to use it, mess around with the alignment_scaling variable calculation a bit to make it either not scale or only scale a certain axis

i also havent really tested ceilings but they should work?

[glacial geyser]

Yeah I've been playing with it a bit -- one question is what you do with your velocity

[royal helm]

how to turn your character velocity into the collide & slide stuff?

[glacial geyser]

No I mean -- after the collide and slide, you have the new position, but you'll want to update velocity based on the collisions as well right?

[royal helm]

oh yeah, i guess 2 options there that I'm not entirely sure about

probably just taking the last direction

[glacial geyser]

yeah that makes sense

I guess it's not to be confused with godot's move_and_slide which manages velocity for you -- though I always found myself steering clear of it anyways, too magical.

I'm also wondering how this approach compares to the kinematic controller example using collision manifolds instead of the shapecast.. I guess it's harder to get sliding over multiple bounces with that approach?

[royal helm]

The collision manifold stuff might tunnel if you go fast enough? but it does have some benefits I think

it'd technically hug walls slightly closer on a turn (at least at the same given timestep I believe), since what could happen with a move and slide is overshooting the sliding

[royal helm]

also note you need to put in a time.delta_seconds() for your velocity here

otherwise you'll be goin ultra fast

[dreamy raft]

question, I have this player bundle which has a rigidbody

pub struct PlayerBundle
{
    player: Player,
    movement: components::Movement,
    stats: components::Stats,
    input_vector: components::InputVector,
    input_manager: InputManagerBundle<input::Action>,
    rigidbody: RigidBody,
    collider: Collider,
    mesh: PbrBundle
}```
but when I query for the linear velocity it returns the second statement here meaning the player doesn't have it, why is that, the examples imply that it's part of the rigidbody by default?
```fn player_move(time: Res<Time>, mut query: Query<(&components::InputVector , &components::Movement, &mut LinearVelocity),With<Player>>)
{
    if let Ok((input, movement, mut linear_velocity)) = query.get_single_mut()
    {

        let direction: Vec3 = input_to_isometric(Vec3{x: input.0.x, y:0.0, z: input.0.y});
        println!("we're in the if statement");
        linear_velocity.x += direction.x * movement.speed as f32 * time.delta_seconds();
        linear_velocity.z -= direction.z  * movement.speed as f32 * time.delta_seconds();

    }
    else
    {
        println!("we're out of the if statement")
    }```

and when I go into the code there's nothing for rigidbody implying that it is

so what am I doing wrong

[sleek thicket]

you need a LinearVelocity component on the player too

[dreamy raft]

Oh okay

[true hearth]

how it works in godot, and how I have also implemented it myself from time to time, is essentially this: (this is using godot-rust)

fn process_movement(&mut self, delta: f64) {
        let mut last_collision = None;
        let mut velocity = self.velocity;
        {
            let mut base = self.base_mut();
            let mut remainder = velocity * delta as f32;
            for _ in 0..16 {
                let Some(coll) = base.move_and_collide(remainder) else {
                    break;
                };

                let normal = coll.get_normal();
                let this_remainder = coll.get_remainder();
                remainder = this_remainder - normal * this_remainder.dot(normal);
                velocity = velocity - normal * velocity.dot(normal);
                last_collision = Some(coll);
            }
        }
        self.velocity = velocity;
        self.last_collision = last_collision;
    }

In avian, the move_and_collide part can probably be replaced by a shapecast + manual application of the partial movement, and the coll.get_remainder() is something like (cast_length - time_of_impact) * cast_direction

in this case, I'm allowing a max of 16 collisions per physics update (this is not substepping)

So what it does is, at each collision, the part of the velocity along the normal is removed

physically, this just assumes that each collision just absorbs all momentum that pushes the body into the collision

[little maple]

I'm making this truck with a bed that can move independently and my first attempt was making the kinematic bed a child of the dynamic truck (which I asked about in help here: #1259697959793332305 message)

HOWEVER, I realized that's a flawed approach but am wondering what is the right way to handle something like this. I am experimenting with joints at the moment (spherical joint seems most like what I want?) but if the bed is kinematic then nothing moves.. and if it's dynamic then it starts affecting the truck. Is there a way to setup joints to behave the way I'm wanting? Or.. should I instead move the truck bed by changing its velocity so it looks attached to the truck at the end of each frame?

[vestal minnow]

Have you tried making the bed just a child collider attached to the dynamic truck, not its own kinematic body?

I think that way it would use the truck's actual velocity, and speculative collision might work too

also fixed another regression
https://github.com/Jondolf/avian/pull/409

then there's this one which I can't reproduce
https://github.com/Jondolf/avian/issues/408

I'm still trying to fix this as well https://discord.com/channels/691052431525675048/1259011159663579186

[little maple]

duuuuuuude, this works perfectly

[vestal minnow]

Alright, nice 😄

Rigid bodies as children are generally kinda weird and might often have some issues like this

[little maple]

yeah, after making that example it clicked why that approach would have problems

[vestal minnow]

Thinking of reworking mass properties, can't decide if I should do this:

pub struct Mass {
    inverse: f32,
    effective_inverse: f32,
}

// Note: 2D versions left out for brevity
pub struct AngularInertia {
    inverse: Mat3,
    // Effective here means that it takes axis locking
    // into account and is in world-space.
    effective_inverse: Mat3,
}

pub struct CenterOfMass(pub Vec3);

Or

pub struct Mass {
    inverse: f32,
}
pub struct EffectiveMass {
    inverse: f32,
}

pub struct AngularInertia {
    inverse: Mat3,
}
pub struct EffectiveAngularInertia {
    inverse: Mat3,
}

pub struct CenterOfMass(pub Vec3);

Or

pub struct MassProperties {
    inverse_mass: f32,
    effective_inverse_mass: f32,
    inverse_angular_inertia: Mat3,
    effective_inverse_angular_inertia: Mat3,
    center_of_mass: Vec3,
}

They all have their pros and cons... It's kind of weird to have Mass but have it actually represent the inverse, but InverseMass wouldn't be as user-friendly

And then with MassProperties its not as composable and all the method names have to be longer

[sleek thicket]

is all of that actually always used?

[vestal minnow]

Yes?

the sim loop needs the inverse mass, angular inertia, and center of mass

both local and world space

world space should be cached, but right now it's not

recomputing it every time is expensive

Rapier and Bepu have it cached, for example

Rapier's setup is even more complicated

pub struct RigidBodyMassProps {
    /// Flags for locking rotation and translation.
    pub flags: LockedAxes,
    /// The local mass properties of the rigid-body.
    pub local_mprops: MassProperties,
    /// Mass-properties of this rigid-bodies, added to the contributions of its attached colliders.
    pub additional_local_mprops: Option<Box<RigidBodyAdditionalMassProps>>,
    /// The world-space center of mass of the rigid-body.
    pub world_com: Point<Real>,
    /// The inverse mass taking into account translation locking.
    pub effective_inv_mass: Vector<Real>,
    /// The square-root of the world-space inverse angular inertia tensor of the rigid-body,
    /// taking into account rotation locking.
    pub effective_world_inv_inertia_sqrt: AngularInertia<Real>,
}

[sleek thicket]

and what does effective mass stand for? weight?

[vestal minnow]

Mass, taking into account locked translational axes

For angular inertia, you need the world-space version, and for that you need to compute a rotation matrix, do some matrix multiplication and a transpose

I guess technically we could do this, there would just need to be logic in place to automatically add angular inertia back when you unlock any of the rotational axes

And you need to compute it by traversing all the child colliders

[sleek thicket]

all i know is that memory is often a bottleneck and minimizing the bloat might be a huge optimization

[vestal minnow]

If e.g. AngularInertia doesn't exist, it should probably mean that rotation is completely locked. A static body shouldn't need mass properties, for example

If a body has any angular inertia, it requires the world-space version regardless of axis locking

*in 3D

the angular inertia tensor depends on the body orientation

[sleek thicket]

then you've ruled out 1 thing from the list of what you need to decide

[vestal minnow]

I think the minimum we need is

pub struct Mass {
    inverse: f32,
}

pub struct AngularInertia {
    inverse: Mat3,
    world_effective_inverse: Mat3,
}

pub struct CenterOfMass(pub Vec3);

and have all of them be technically optional

effective inverse mass is super cheap to compute so we probably don't need it cached

it's just Vec3::splat(inverse_mass)

and then set locked axes to 0

Well the solver logic would need to handle that case separately but technically it isn't needed

Hmm maybe we should use Mat3A instead of Mat3 as well

[sleek thicket]

either way i think the best decision for effective mass is to hide it from user, you can figure out the rest later

[vestal minnow]

The insertion logic will just become a bit confusing

• Add Mass/AngularInertia only if the object is dynamic and it has at least one unlocked translational/rotational axis
• Add CenterOfMass only if it wouldn't be the origin of the body
• Update all of this as colliders or LockedAxes change
  Presumably we shouldn't do automatic cleanup and remove the components automatically either since users might want them to exist, but idk

I mean you kinda need it if you have even a single collider that is off-center and has non-zero density

Would you prefer if you spawned a dynamic body with a collider computed from a mesh, and it behaved all wonky and unstable by default? You need the center of mass for these things to behave correctly. We could add a component for disabling auto-cómputation from attached colliders though

They probably don't need it

although the center of mass affects what point the object rotates around

so it will have an effect on kinematic objects too

No we can't do that lol, RigidBody is an enum and that would break all composability

we could do MassPropertyComputation::Auto/Manual or something though

Or CenterOfMass::Auto/CenterOfMass::Custom(Vector) like what Godot and Unity have GUI-wise

[sleek thicket]

auto/custom/origin

[vestal minnow]

Unity defaults to auto for center of mass and angular inertia fwiw

and every other engine I know

[sleek thicket]

i didn't have bugs because everything i have is either static or primitive, but i can easily imagine spending a week in frustration because of unexpected behaviour caused by auto 🥲

[vestal minnow]

In Godot, Inertia::ZERO means auto

(and is the default)

no, auto-compute angular inertia from attached colliders

[sleek thicket]

and i can only speak for unity, but you can often see that their physics are one of the main points of frustration

so at least that one is a bad reference to copy from

there are good parts that make sense too though

but it's easier to notice the sharp edges

[dark nexus]

I updated bevy_xpbd_3d to avian3d and I'm getting jitter that I didn't get before with my third person camera following a moving target, am I correct to run the system that moves the camera in PostUpdate?

[vestal minnow]

Yeah, the same ordering as before should work... I can't think of anything that would've changed it 🤔
https://docs.rs/avian3d/latest/avian3d/#why-does-my-camera-following-jitter

Yeah I definitely wouldn't want to use bundles, especially considering they would likely be discouraged if/when required components land

And again center of mass is also used by kinematic, at least currently

[dark nexus]

Thanks, I was missing the .after(PhysicsSet::Sync).before(TransformSystem::TransformPropagate) bits because I previously used bevy_xpbd_3d_interp with its in_set(InterpolationSet::PostInterpolation) and removed it with the update to avian and forgot to put this in there instead

[vestal minnow]

Ah, gotcha 🙂

[dark nexus]

btw I noticed that the author of bevy_xpbd_3d_interp already started working on interpolation for avian which is very cool: https://github.com/rubengrim/avian_smooth

[vestal minnow]

Cool! Wasn't aware of that

[sleek thicket]

ok, i collected my thoughts for a bit, different genres just have different priorities
for a game with focus on physics it makes more sense to sacrifice performance for accuracy,
for a game with hordes of enemies it makes more sense to cut all corners to improve performance

i expected origin because of the latter, for the former auto makes more sense, but auto is less likely to break when expecting origin than the other way around

[vestal minnow]

Yeah I prefer correctness and stability over hyper-optimization by default, but to allow that optimization for those who need it

And a center of mass at the origin when the collider is offset just leads to highly unphysical behavior

[sleek thicket]

it's just that for an ecs engine performance appears much more important than for unity/godot

[vestal minnow]

The performance effect of having center of mass specified is very negligible

and again we could just not add it for bodies with no off-center colliders

although then we'll need Option spam everywhere

[sleek thicket]

it's still at least 3 wasted floats per enemy, but yeah at this point it's just premature optimization

but at least keeping everything in 1 struct can be ruled out

[vestal minnow]

It would have a few API benefits, but at least some of them can also be handled with MassPropertyBundle and MassPropertyQuery

[dreamy raft]

I added that and it's still not moving

the component is being detected now though

[sleek thicket]

maybe something with input itself?

[dreamy raft]

no I know the input works since it was working no problem before I switched to using avian

yes when I was moving it on transform.translation I have made no modifications to the input and direction variables since

[sleek thicket]

input, direction, and speed are the only moving parts then

[dreamy raft]

direction is a rotated version of the input, the player movement system looks like this right now

{
    if let Ok((input, movement, mut linear_velocity)) = query.get_single_mut()
    {

        let direction: Vec3 = input_to_isometric(Vec3{x: input.0.x, y:0.0, z: input.0.y});
        linear_velocity.x += direction.x * movement.speed as f32 * time.delta_seconds();
        linear_velocity.z -= direction.z  * movement.speed as f32 * time.delta_seconds();

    }

}```

[sleek thicket]

what does it say if you print input and direction?

[dreamy raft]

(When pressing W) Input: [0, -1] Direction: [-0.7071068, 0, -0.7071067]

linearvelocity isn't 0 either so I don't know why it's not moving

[sleek thicket]

try turning up the speed?

[dreamy raft]

still no movement

do I need to sync my linearvelocity up with the transform?

[vestal minnow]

No

Maybe double-check that

• You have added PhysicsPlugins (if you have any physics already then you probably have)
• Your player's rigid body is dynamic or kinematic
• Your player has a Transform and GlobalTransform (included in many bundles already)
• You aren't resetting the velocity in some other system

And if it doesn't work, try to reduce it into the most minimal reproduction, and build up from there

Like try if just this moves

commands.spawn((
    RigidBody::Kinematic,
    Collider::sphere(1.0),
    LinearVelocity(Vec3::X),
    PbrBundle {
        mesh: meshes.add(Sphere::new(1.0)),
        ..default(),
    },
));

[dreamy raft]

okay the issue was my dumbass forgot to add the physics plugin

[vestal minnow]

Yeah, I was suspecting that 😅 You shouldn't need to add LinearVelocity manually, it's inserted automatically for rigid bodies

[dreamy raft]

now I get to steal study the code from the kinematic player controller 3d example to make collisions work

[vestal minnow]

It's currently a bit scuffed and might have some edge cases, I'd like to implement a proper built-in collide-and-slide implementation soon-ish (similar to what Godot has)

[sleek thicket]

is that new in avian?

[vestal minnow]

but it should hopefully work alright for most cases

[dreamy raft]

that would be nice, but for now, scuffed use case it is

[vestal minnow]

No, it has always been like that. The physics engine can't simulate anything without velocity

Unlike Rapier, the ECS is the source of truth here

[vestal minnow]

(or static bodies don't need it, but I haven't handled that separately yet)

[sleek thicket]

query for LV component + player with single_mut results in error for me though

[vestal minnow]

That's because it's added at the start at the physics schedule in PostUpdate currently

[dreamy raft]

I'm guessing the hope is for avian to one day be merged into bevy as the main physics engine?

[vestal minnow]

We could use lifecycle hooks now in 0.14 though

Or maybe required components if/when they land

[sleek thicket]

even if it doesn't, they can upstream stable parts of it

[vestal minnow]

That's my hope of course, but there's still a long road before that 🙂 And of course Rapier is still a valid option, although it has several things that would (in my personal opinion) be blockers for official adoption

[dreamy raft]

isn't bevy rapier just a wrapper of normal rapier but made to work with bevy?

[vestal minnow]

yep

[dreamy raft]

yeah I'm gonna stick with avian lol, at least I can get some idea of how it works outside of the physics and collision stuff I'm too smooth brained to understand

since it's made for bevy

right turns out clamping linearvelocity is a bad idea

at least clamping it like this is

        linear_velocity.x = clamp(linear_velocity.x, -(movement.speed as f32), movement.speed as f32);
        linear_velocity.z += direction.z  * movement.speed as f32 * time.delta_seconds();
        linear_velocity.z = clamp(linear_velocity.z, -(movement.speed as f32), movement.speed as f32);```

[fair fractal]

Yeah lol I took one look at the rapier create and I did not understand it at all lol.

Probably because I'm not very used to rust language but still

Every function and type comes with like 5 nested generic args

[vestal minnow]

I can say that a lot of Rapier's internals are very unreadable, especially the solver

the solver is black magic with like zero helpful comments

[fair fractal]

Well you managed to work with parry pretty well

[vestal minnow]

Parry's internals are generally a bit more understandable and there's less moving pieces... although from a user perspective it's still not exactly great, and the docs are pretty nonexistent

for learning how to do more advanced things with it, the best bet is often to look at how Rapier uses it lol

[dreamy raft]

the lack of documentation is why I started using bevy instead of using Godot's GDExtension + Flecs since I wanted performance (plus components are going to make a turn based RPG a lot easier)

anyways is there a good way to cap the speed of linearvelocity

[vestal minnow]

Hmm... There isn't a good built-in way at the moment, but I think you could do it in a system in this very specific part of the schedule

app.add_systems(
    SubstepSchedule,
    clamp_velocities
        .after(SubstepSolverSet::SolveConstraints)
        .before(IntegrationSet::Position)
);

That way it clamps velocities right before updating positions with it. We could add a MaxLinearVelocity component for this though

(I haven't tried this so lmk if it has system order conflicts or other issues)

I'll open an issue about capping velocity

[visual sparrow]

Completely off-topic: I recently contributed a fixed-timestep example to Bevy and that got me wondering how Avian does things. I know Avian uses fixed-timesteps as well, but not in the FixedTimestep schedule. The relevant issue says this is due to RemovedComponents, but now that could be handled with a lifecycle hook. Should Avian try to move to FixedTimestep? Furthermore, is Transform the for-real-for-real Transform according to the physics simulation? If so, I know that the visual representation should do some inter- or extrapolation instead of showing the real physics updates because those might have very heterogenous updates. Is there a best practice for this in Avian? I know I could cache the last Transform manually and then setup a visual object that "follows" the real physics object by lerping between the last Transform and the current one, but I'm wondering if there's anything built-in in Avian for that.

[vestal minnow]

Yeah I think nowadays we could probably switch to using FixedUpdate instead of PostUpdate by default. Historically it has had several usability issues, and IIRC there might still be some issues with input handling in FixedUpdate, but overall I believe it should be pretty usable now. Not entirely sure on the current state of things though

@cinder summit I recall you mentioning problems with Bevy's FixedUpdate a few times in the past, do you know if it still has many issues?

[cinder summit]

Compared to Update with variable deltas it still has some issues like the lack of first-party interpolation and of course inputs

I've seen some efforts to at least make LWIM behave as reasonable as possible in FixedUpdate, if that ends up working well it would probably be a lot better than using a custom loop for fixed rate physics at least 🤔

[vestal minnow]

Yeah, makes sense

Doesn't FixedUpdate run before Update? I'd imagine that input systems would currently need to run in PreUpdate or something to avoid a frame delay

(if you ran physics in FixedUpdate)

[cinder summit]

Yea, it's PreUpdate -> StateTransitions -> FixedUpdate -> Update

Realistically you should also do input stuff for FixedUpdate inside of it tho, generating inputs in PreUpdate has a lot of weird flaws

[vestal minnow]

mm yeah

so I think we could probably switch to FixedUpdate for physics at least once input handling there is better

[cinder summit]

We already run a fixed loop by default right? 🤔

[vestal minnow]

yea

[cinder summit]

We could probably already switch then. It should at least behave better than a custom loop

[vestal minnow]

Fair, it'd probably be better. And the old scheduling would probably be available still, since you can choose where you run physics

[vestal minnow]

For the second question, the actual simulation doesn't use Transform or GlobalTransform at all and can function without them. Instead, it uses its own Position and Rotation components which are two-way synced with transforms by the SyncPlugin.

Transforms are used for hierarchies and as a user-facing way of moving and positioning objects, since that's what people are used to using in Bevy and other engines.

I believe we could technically handle Transform interpolation in the engine without touching the physics positions or requiring separate entities for the visual and physics representation, but I haven't tried that yet. The workaround so far has been to use something like bevy_xpbd_interp (now avian_smooth)

[vestal minnow]

Issue for capping velocity 🧢
https://github.com/Jondolf/avian/issues/410

[edgy nacelle]

I think I might be having some nans (in the rotation I think) on avian 0.1 when a cylinder spinning really fast collides with a trimesh. I’m trying to narrow it down. Is it already a known issue though?

[vestal minnow]

Not sure. It could potentially be related to this https://discord.com/channels/691052431525675048/1259011159663579186
(associated issue)

A minimal reproducible example could be useful, at least that issue is being a bit annoying to debug

[edgy nacelle]

Okay, lemme open an issue once I find it 👍

Basically whenever my wheels lose grip and spin up they turn into nans haha

[dreamy raft]

oh cool glad to know that this will be added as a feature of avian in the future then

[dreamy raft]

I'm confused, whenever I do this it just says these two don't exist

IntegrationSet::Position```

[vestal minnow]

Make sure you add the system after you've added PhysicsPlugins, and that you're adding the system to SubstepSchedule

like my example

// After adding PhysicsPlugins
app.add_systems(
    SubstepSchedule,
    clamp_velocities
        .after(SubstepSolverSet::SolveConstraints)
        .before(IntegrationSet::Position)
);

[royal helm]

I'm not sure this is a great idea though

Actually hmm nvm I was misundersfanding

[vestal minnow]

Or do you mean the types don't exist? They're in

use avian3d::dynamics::{integrator::IntegrationSet, solver::SubstepSolverSet}

tested myself and it seems to work fine

[dreamy raft]

okay after implementing this all works, now I can add even more polish to my player controller as well as playing around with values

only issue now is movement can be a little glitchy and I think that's a hardware thing more than anything

[little maple]

what is meant by this? (from the Avian 0.1 blog post)

Another thing to note is that CCD does not prevent bodies from being pushed through other objects due to contact softness

[vestal minnow]

If you push an object into a wall hard enough, it will overlap that wall, and with enough force you could push it through. Contacts aren't perfectly hard, and if they were, it would typically lead to instability and explosiveness, like with XPBD. This contact softness disclaimer is also in Box2D and Rapier, for example

It's often more important that bodies don't phase through static objects like walls than dynamic objects though, which is why static contacts currently have double the contact frequency (kinda like stiffness). It could further be improved by only solving dynamic-static contacts after all dynamic-dynamic contacts have been solved, but I haven't done that yet

[dusky brook]

i'm migrating from rapier2d to avian2d, and wondering if there's an equivalent to rapier's DebugRenderContext::enabled flag to toggle debug rendering on the fly?

[visual sparrow]

Yes! You take ResMut<GizmoConfigStore>, then do the following

let config = config_store.config_mut::<PhysicsGizmos>().0;
config.enabled = true_or_false;

This is the general way in which gizmos in Bevy are enabled or disabled.

[little maple]

that makes sense. That explains some of the behaviors I was seeing. I'm guessing that there isn't a current way to reduce those effects?

also, I asked chatgpt the same question and it referenced your avian 0.1 blog post which was kinda funny

[vestal minnow]

Wait actually? That's pretty insane lol

[vestal minnow]

There's a SolverConfig resource that has configuration for contact behaviour, mainly contact_damping_ratio and contact_frequency_factor. Making them too high or low can cause other stability issues though

I asked ChatGPT what solver Avian uses and it could actually kinda answer

It said it uses sequential impulses, which is mostly accurate... although TGS Soft is of course substepped and uses soft constraints

[little maple]

I tend not to trust it for anything specific

[cinder summit]

Don't trust it at all ... The only good use I've seen for it is pointing you to things that you might not have found with a simple search because search ranking can be pretty biased 🤔

[vestal minnow]

Yeah I mean it's definitely getting a lot of details very wrong lol

At least it specifically said to refer to the implementation for more accurate details and that it can change

[vestal minnow]

I'm potentially able to reproduce by just dropping a fast spinning trimesh onto ground (see the rotation of the torus and the cylinder that touches it become invalid)

[edgy nacelle]

Ah interesting! Although it's weird that the torus gets an invalid rotation only a little while after the ground collision

[visual sparrow]

Beyblade game when 👀

[finite blaze]

*Bevyblade

[vestal minnow]

I have made Bevyblades already lol

https://discord.com/channels/691052431525675048/1152991839314513940

See later videos in the thread for more fast-paced versions

Would be interesting to try again with Avian

[finite blaze]

😄 this is amazing

[vestal minnow]

this one in particular
#1152991839314513940 message

[visual sparrow]

Oh my god I love this 😄

You could make something like that for the jam

I'm sure it will somehow fit the theme

[vestal minnow]

huh, that demo was apparently before we even had child colliders or async colliders... time flies

I distinctly remember making it, feels more recent than it is

although it's only like 10 months ago anyway lol

[visual sparrow]

Time flies like arrow, fruitflies like banana

[vestal minnow]

wise words

[visual sparrow]

[vestal minnow]

In Finnish, fruit flies are just banana flies (banaanikärpänen)

[visual sparrow]

That’s kinda cute 🙂

[violet lava]

same in the scandinavian languages

[dreamy raft]

question, what would be a good way to add deceleration in a kinematic player controller, since I didn't see it in the 3D example for it

[sleek thicket]

if you don't want to use LinearDamping component then you can multiply LV by anything less than 1
you can use LV length or dot to decide how strong deceleration should be, very very valet devs have a video on that but in context of car movement

[snow urchin]

How do I check for collision via query?

[thin hare]

There is a Collisions resource that you can add as asystem param

[vestal minnow]

• If you want to get a list of the entities currently colliding with an entity, there is a CollidingEntities component
• If you want to iterate over collision events, there is a Collision event (also CollisionStarted and CollisionEnded)
• If you want even more control, there is the Collisions resource

[thin hare]

Here's a simplified example of a system I use to check collisions with the player

fn colisions_with_player(
    mut player_query: Query<(Entity, &mut Transform), With<Player>>,
    collisions: Res<Collisions>,
) {
    if let Ok((player_entity, mut player_transform)) = player_query.get_single_mut() {
        for collision in collisions.collisions_with_entity(player_entity) {
        // ... Collision logic here
        }
    }
}

[snow urchin]

What about for when a collision starts?

[dreamy raft]

lineardamping feels like it's doing nothing

[vestal minnow]

I think it currently only affects dynamic bodies, but we could probably change it to also affect kinematic bodies 🤔

What it does is this

lin_vel.0 *= 1.0 / (1.0 + delta_secs * lin_damping.0);

So you could pretty easily implement it yourself too

(for those curious on the math, Box2D has a brief derivation)

[vestal minnow]

I linked CollisionStarted earlier

[snow urchin]

I meant for his example

I'd like to do started_collisions_with_entity

if that exists

[sleek thicket]

so basically the classic OOP approach

it might actually be possible now that hooks and observers are here, right?

[vestal minnow]

Hmm I haven't tested if this works, but you might be able to filter based on collision.during_previous_frame

fn colisions_with_player(
    mut player_query: Query<(Entity, &mut Transform), With<Player>>,
    collisions: Res<Collisions>,
) {
    if let Ok((player_entity, mut player_transform)) = player_query.get_single_mut() {
        for collision in collisions
            .collisions_with_entity(player_entity)
            .filter(|collision| !collision.during_previous_frame)
        {
            // ... Collision logic here
        }
    }
}

We should probably expose a dedicated API for this though

Otherwise you'd iterate through CollisionStarted events and find the one(s) that match your entity

[snow urchin]

which is cumbersome

It would probably be way more performant in scenarios if there was just a started version of it

[vestal minnow]

Yes I'd like to do entity events, and in theory we could do that with observers already

[sleek thicket]

OOP approach probably can't be performant either way

observers for rare events would be neat though

[snow urchin]

It's iterating over collisions vs seeing if an entity collided

indexing vs finding

[sleek thicket]

DOD shouldn't care about any specific entity in the first place

[vestal minnow]

I just need to figure out the details; I'm not sure if we can nicely reuse the existing event types since those have both entities participating in the collision and in no particular order, so you'd need to figure out which entity is the one you're targeting, which would be annoying. Ideally the type would store only one entity (since the trigger stores the target entity)

And we should also only trigger events if an observer is actually targeting the rigid body or collider to avoid lots of unnecessary data cloning

[snow urchin]

I think there should be an option for gravity for kinematic bodies

[sleek thicket]

i'm still a bit concerned that if you add it in, everyone coming over from unity/godot will immediately start using it even if it tanks the performance

[sleek thicket]

kinematic usually implies everything about it is DIY, but other rigidbodies can hit it

[vestal minnow]

Observers would be much better for performance for the cases where you do want to target specific entities. For typical ECS systems the buffered events can be more efficient of course

that's more of a general observers vs. buffered events issue though, not necessarily specific to Avian

[snow urchin]

yeah, but really no reason to not make non-rotating gravity an option

[vestal minnow]

*Or at least currently, since many queries on Collisions are very unoptimal since it's not a contact graph yet

(I want to address that soon)

[sleek thicket]

i use dynamic player controller and have it turned off 🤷‍♂️

[snow urchin]

ah, I didn't think about collision handling, nvm

either way I think started_collisions_with_entity should be implemented soon for performance concerns

[sleek thicket]

i just sort all collisions by tag into appropriate events for now, need to try more stuff to see if it breaks

[snow urchin]

how do you do that

[sleek thicket]

#1124043933886976171 message

[snow urchin]

Don't understand your code, i'll figure it out later

for now the code jon sent is good enough

[sleek thicket]

tag is an enum, you just check how 2 entities interact based on that

so e.g. 1 is player, other is damage or player-only-trigger, etc and so on

[snow urchin]

wait, the one jon sent is also just a for loop

whatever

[sleek thicket]

the only problem with it is if you want 2 things to happen at the same time

and damage can hit multiple targets at the same time, so it needs to be accounted for outside of collision sorting for projectiles

[snow urchin]

Is there a way to get the normal of the collision?

[vestal minnow]

Each collision between two objects can have multiple different contact surfaces, think a table on uneven ground. Each table leg could potentially have a different contact normal with the ground.

These contact surfaces are essentially what is stored in the manifolds list in the collision data. You can iterate that to get the normals of each contact surface. A lot of collisions might have just one contact surface/manifold, in which case the list will only have one element

(further, each manifold can have more than one contact point, like one for each corner of the bottom face of a table leg, but that's unrelated to the question)

[snow urchin]

so like collisions.manifolds?

or for each collision?

[vestal minnow]

Yeah, assuming you're using the method from earlier to get the collision, it should return a Contacts type that has a manifolds property

[snow urchin]

this?

I'd like example code

[vestal minnow]

yes

for collision in collisions
    .collisions_with_entity(player_entity)
    .filter(|collision| !collision.during_previous_frame)
{
    for manifold in collision.manifolds.iter() {
        // ...
    }
}

[snow urchin]

ah, for loop black hole

Is manifold a vec3?

[vestal minnow]

No, it's this
https://docs.rs/avian3d/latest/avian3d/collision/struct.ContactManifold.html

[snow urchin]

How do I use it?

[vestal minnow]

Another important note is that manifold.normal1 (outward normal on first entity) and manifold.normal2 (outward normal on second entity) are in local space. This is for a bunch of physics engine reasons, and also the output of the collision detection library we're using. Although we could maybe change this now with the new solver in Avian.

For the global normal, you need to transform the normal using the rotation of the entity whose normal you want to compute

[snow urchin]

Just make another code example, I understand that best

[vestal minnow]

And yes I'm aware this is currently very cumbersome. I would like to make it nicer, but there are lots of performance and memory reasons for the current setup in terms of contact data. We can hopefully make it much nicer with the new solver and the planned contact graph though

[vestal minnow]

okay wait a moment I'll make one

[snow urchin]

ty

[vestal minnow]

I think it'd be something like this. (I also changed if-let to let-else to reduce indentation)

fn colisions_with_player(
    mut player_query: Query<(Entity, &mut Transform), With<Player>>,
    collisions: Res<Collisions>,
) {
    let Ok((player_entity, mut player_transform)) = player_query.get_single_mut() else {
        return;
    };

    for collision in collisions
        .collisions_with_entity(player_entity)
        .filter(|collision| !collision.during_previous_frame)
    {
        let is_player_first = player_entity == collision.entity1;
        for manifold in collision.manifolds.iter() {
            let local_normal = if is_player_first {
                manifold.normal1
            } else {
                manifold.normal2
            };
            // Compute global contact normal pointing away from the player
            let normal = player_transform.rotation * local_normal;
            // ...
        }
    }
}

There's no guarantee on which entity in the contact data is the player entity, so we have to check it annoyingly. But if you don't care whether the normal is pointing away from the player or towards it, you don't need that

[thin hare]

Was PhysicsSetupPlugin renamed in avian3d or was it deprecated in the re-architecture?

[vestal minnow]

It was split into PhysicsTypeRegistrationPlugin and PhysicsSchedulePlugin

PhysicsSchedulePlugin is effectively what PhysicsSetupPlugin was, I just extracted type registration (for inspectors etc.) out since it's a completely separate concern

and Bevy has a similar plugin setup

[dreamy raft]

well now the player can stop so I can play around with both damping and acceleration values so this actually feels good to control

[snow urchin]

Y is up right?

In your engine

[vestal minnow]

Yes, in Bevy and in Avian

[snow urchin]

Alright.

Well in bevy it seems to be Z unless you specify in the lookat matrix function

[vestal minnow]

info on Bevy's coordinate system
https://github.com/bevyengine/bevy/discussions/10488

[snow urchin]

Ah, nvm, mb, I guess z is up for only the camera?

Cause I just looked at my code and there is no lookat

[vestal minnow]

Not sure, I don't remember what the 3D camera defaults to

I would expect it to be looking in -Z by default

-Z being forward

[snow urchin]

I must have dementia cause you're right

[snow urchin]

Is this correct gravity code?

if let Ok((ent,mut vel)) = query.get_single_mut() {
        let mut colli:bool = false;
        for coll in col.collisions_with_entity(ent).filter(|colle|!colle.during_previous_frame) {
            let is_p_first = ent == coll.entity1;
            for man in coll.manifolds.iter() {
                let norm = if is_p_first {man.normal1} else {man.normal2};
                colli = norm.y > 0.84 && norm.y < 1.01;
            }
        }
        if !colli {
            vel.y -= 0.05;
        }
    } else {
        return;
    }

[sleek thicket]

look_at/look_to are in transform
-Z forward is confusing as hell, so i switched to Z-up Y-forward and regret nothing so far

[severe urchin]

i'm doing the 0.13->0.14 + xpbd->avian upgrade, and i get this panic now: Resource requested by avian2d::collision::collider::backend::init_collider_constructors does not exist: bevy_asset::assets::Assets<bevy_render::mesh::mesh::Mesh>

(i have bevy's default features enabled)

[vestal minnow]

If you're not using the collider-from-mesh feature and are using e.g. MinimalPlugins, that's probably this issue
https://github.com/Jondolf/avian/pull/405

should be fixed on main

[severe urchin]

ah, i was staring at the code wondering why it didn't work, but was looking at main on github. i'm using 0.1 locally... thanks! i'll switch to main

[vestal minnow]

I plan on releasing a 0.1.1 patch soon-ish to fix a few of these regressions

[severe urchin]

big upgrade, congrats on shipping it 🙂

[vestal minnow]

Thanks 😄

[severe urchin]

hm, i switched to using avian2d = { git = "https://github.com/Jondolf/avian.git", branch = "main", features = ["serialize", "default-collider"] } and i get compile_error!("either feature \"f32\" or \"f64\" must be enabled"); (and "2d"/"3d") shouldn't those features be enabled automatically?

[vestal minnow]

Yes, and they are 🤔
https://github.com/Jondolf/avian/blob/main/crates/avian2d/Cargo.toml

It's weird if you get that without default-features = false

[cinder summit]

default-collider should also be enabled by default 🤔

[severe urchin]

i also have lightyear as a dep, which includes avian2d with default-features=false, but my own dep should supercede that, so a bit stumped

[cinder summit]

It doesn't really work trough one crate superceding another, if default features are on anywhere it includes default features, and it just creates a sum of all features 🤔

[severe urchin]

yeah since i don't disable default features lightyear's avian2d should get ["2d", "f32", "parry-f32", "debug-plugin", "parallel", "bevy_scene"] too

[cinder summit]

Oh wait

Is that in your dependencies?

git = "https://github.com/Jondolf/avian.git" is a different version from version = "0.1" according to cargo's rules, so you'll get two different avian2ds if it's in dependencies instead of patch.crates-io

[severe urchin]

my top level cargo.toml contains this:

[workspace.dependencies]
avian2d   = { git = "https://github.com/Jondolf/avian.git", branch = "main", features = ["serialize", "default-collider"] }
lightyear = {git = "https://github.com/cBournhonesque/lightyear.git", branch = "main", features = ["webtransport", "leafwing", "avian2d"]}

and then my game server cargo toml contains:

[dependencies]
avian2d.workspace = true

ah so lightyear is asking for 0.1 of avian2d.. so i need to patch so that lightyear's avian2d matches my own?

[cinder summit]

Yea, both your crate and lightyear need to ask for the same version, and then in patch.crates-io you can change what it actually uses

[severe urchin]

thanks

switching my dep back to 0.1 to match lightyear then using patch to ask for main did the trick, thanks

[cinder summit]

Hey @vestal minnow did anything major change in bevy_xpbd 0.4 -> 0.5? I'm getting spammed with these warnings:

Dynamic rigid body Entity { index: 125, generation: 1 } has no mass or inertia. This can cause NaN values. Consider adding a `MassPropertiesBundle` or a `Collider` with mass.

and I assume that's related to my dynamic bodies not being affected by gravity

[vestal minnow]

Hmm... at least sensors don't contribute to mass properties now

and then some transform propagation changes but they shouldn't be breaking really

[cinder summit]

I don't even have transform propagation enabled I think 🤔

[vestal minnow]

Mm do you have ColliderHierarchyPlugin? It should be added by PhysicsPlugins though

It might be needed atm, although I'll probably make it optional in the Avian 0.1.1 patch

[cinder summit]

Ah yes, after adding ColliderHierarchyPlugin and the bevy::hierarchy::HierarchyPlugin it depends on it works

[vestal minnow]

ya that's currently because ColliderHierarchyPlugin is the plugin that adds ColliderParent for colliders, and it's needed even without hierarchies atm

I'll try to make it so it works even without ColliderHierarchyPlugin though

[little maple]

so, I have this truck bed and these cubes and the cubes only can interact with the bed (not each other). When the truck moves, the bed moves and the cubes stay in. But, when rotating the bed the cubes eventually get inside the truck walls and then fall through.

It doesn't happen as much if I increase the size of the cubes, but just wondering what other approaches should I try? I messed with SolverConfig a bit but it didn't seem to have an effect.

[vestal minnow]

Is the truck using trimesh colliders somewhere?

[sleek thicket]

the bed itself seems to be a trimesh

[little maple]

the bed is trimesh collider. The truck is convex hull but it's layered to not interact with the cubes or the bed

[vestal minnow]

Ideally the bed would probably either use convex decomposition or (more efficient) be a compound collider created from five cuboid colliders, one for each side and one for the bottom.

I think configuring TrimeshFlags::FIX_INTERNAL_EDGES might also help a bit in some cases, but that might mainly just be for trimesh-trimesh collisions, not sure

Then there is also CollisionMargin to make the trimesh collider "thicker", which can help, but then it might look like the cubes aren't visually touching it anymore unless you change the mesh again

The main issue here is that trimesh colliders are essentially hollow, and the triangles are infinitely thin by default

So it's easier to tunnel and get stuck in them

[sleek thicket]

it's kind of a useful shape, i think it might be a good idea to add function to generate it from primitives

i'm just not sure how to make it without ghost collisions

[little maple]

ah, these are great suggestions. Thanks!

[edgy nacelle]

Are all of the non trimesh shapes non-hollow for collisions? e.g. the standard convex geometric shapes, convex hulls, convex decompositions?

[vestal minnow]

All convex shapes and shapes formed from convex pieces (through convex decomposition) are non-hollow

Trimeshes, heightfields, polylines, and line segments are hollow and/or infinitely thin (and heightfields of course aren't closed anyway so they can't have an interior)

Basically every shape that can exist without being watertight/closed is treated as infinitely thin

[willow ice]

...
let mut deepest_penetration: Scalar = Scalar::MIN;

// Solve each penetrating contact in the manifold.
for contact in manifold.contacts.iter() { // Empty sometimes
    if contact.penetration > 0.0 {
        position.0 += normal * contact.penetration;
    }
    deepest_penetration = deepest_penetration.max(contact.penetration);
}

...

Following the kinematic 3d character example is there any reason why this iterator might be empty?https://github.com/Jondolf/avian/blob/main/crates/avian3d/examples/kinematic_character_3d/plugin.rs#L362

It seems like this sometimes doesn't run then propagates the large magnitude deepest penetration and causes NaN and inf down the line

Context:
My character collider is a cuboid and the thing I am colliding with is a Collider::compound of many cuboids (like a minecraft chunk)
I can reproduce this when sliding from one block to another and when impacting a block on its top at high speed

[dreamy raft]

so for some reason my collisions aren't working, I copied it directly from the kinematicbody3d player controller example (only changing the character_controller component for my own player_components::player component), both the player and the floor but the player just goes right through the floor
these are the parts involved in all this
physis/mod.rs

impl Plugin for Physics
{
    fn build(&self, app: &mut bevy::prelude::App)
    {
        app
        .add_plugins(PhysicsPlugins::default())
        .add_systems(PostProcessCollisions, physics_collision::kinematic_controller_collisions)
        .add_systems(FixedUpdate, dampen_velocity)
        .add_systems(
            SubstepSchedule,
            clamp_velocities
                .after(SubstepSolverSet::SolveConstraints)
                .before(IntegrationSet::Position)
        )
                ;
    }
}```

the physics_collision script

the player bundle spawn

{
    commands.spawn
    (
        PlayerBundle
    {
        movement: player_components::Acceleration(50),
        stats: battle_components::Stats
        {
            name: "Valeria".to_string(),
            health: 100,
            mana: 50,
            speed: 10,
            attack: 10,
            evasion: 10,

        },
        input_vector: player_components::InputVector(Vec2{x:0.0,y:0.0}),
        input_manager: InputManagerBundle::with_map(player_input::Action::mkb_input_map()),
        mesh:PbrBundle{
            mesh: meshes.add(Capsule3d{..Default::default()}
            ),
            material: materials.add(Color::WHITE),
            transform: Transform{ translation: Vec3{x:0.0, y:1.0, z:0.0}, ..Default::default()},
            ..Default::default()
         },
        rigidbody: RigidBody::Kinematic,
        collider: Collider::capsule(1.0, 2.0),
        player: player_components::Player,
        linear_damping: LinearDamping(2.5),
        max_linear_velocity: physics_components::MaxLinearVelocity(Vec3{x:4.0,y:0.0,z:4.0})
    }
    );```

and the floor spawn script

{
    let color = Color::srgb(0.0, 0.5, 0.0);
    let floor = PbrBundle
    {
        mesh: meshes.add(Plane3d{..Default::default()}),
        transform: Transform{scale: Vec3{x:100.0,y:100.0,z:100.0}, ..Default::default()},
        material: materials.add(color),
        ..default()
    };
    commands.spawn(floor).insert(avian3d::collision::Collider::cuboid(100.0, 0.1, 100.0));```

[vestal minnow]

you probably need a RigidBody::Static for the floor

the collision system has

// Get the rigid body entities of the colliders
let Ok([collider_parent1, collider_parent2]) =
    collider_parents.get_many([contacts.entity1, contacts.entity2])
else {
    continue;
};

but if the other entity has no rigid body, this just returns early

[dreamy raft]

well that was the problem, now it sends the player extremely far away when I spawn the player, but collision works

oh and also the collision is a bit glitchy

[true hearth]

pretty happy with this so far:
https://www.youtube.com/watch?v=KC_tI8k1WF0
Still using xpbd 0.13, waiting for the blevy 0.14 update

[vestal minnow]

Ooh, cool! That looks fun, although a bit motion sickness inducing in first person mode 😅

[true hearth]

ah yeah, definitely 😛 will need a lot of tweaking, that mode

do love that "gopro" vibe though, so in a game I would probably leave something similar as an option

[dreamy raft]

looks cool, i'm jealous how non-jittery yours is lol

[true hearth]

there's a lot of springs involved 😛

[dreamy raft]

mine has no springs involved since I just need something that works lol

[true hearth]

if you're talking about camera jitter, that was fixed once I just set the camera position during the substepschedule (probably not the recommended solution though, but I'm doing lots of things during the substep schedule anyways)

[dreamy raft]

unfortunately it's not all Camera jitter, some of it is just collision jitter

[true hearth]

like this maybe? luckily this is absorbed by my spring, but yeah I'm noticing this jittery shape cast on some of the trimesh colliders in this level

[severe urchin]

will it cause issues if i spawn my level and some static colliders overlap?

walls, for example

[vestal minnow]

No, that's fine

[sleek thicket]

basic spring is super simple though

#1124043933886976171 message

[vestal minnow]

For "something that works", there is also tnua which supports Avian

That is a floating character controller though, and uses a dynamic body instead of a kinematic one

[sleek thicket]

the one i sent is not that far off from kinematic though, just need to resolve velocity manually

[dreamy raft]

I don't really need springs though, mine is meant to be a character controller for an RPG

[sleek thicket]

RPG doesn't say much 😅

[dreamy raft]

it's a turn based RPG lol, I'm already more concerned about movement than most turn based RPG devs (I blame SMTV)

[sleek thicket]

if you're working alone then it's better not to compare

[severe urchin]

is it ok to change a body from kinematic to dynamic? eg i have a moon in orbit (kinematic) and decide to let it deorbit by changing it from kinematic to dynamic on a certain trigger?

[vestal minnow]

That should be fine

[severe urchin]

cool

[vestal minnow]

(lmk if it's not lol)

[sleek thicket]

if it's not fine then it'd be a huge problem, turning kinematic chars into ragdolls is really common 😅

[severe urchin]

good to know. physics/gamedev noob so just making this up as i go 🙂

[dreamy raft]

okay, point is, I don't think a spring is going to fix my jittering problem

[hexed veldt]

Is it generally a good idea to do collision checks in PostUpdate schedule? I'm running into errors like

Could not insert a bundle (of type `game::collider::CollisionInfo`) for entity 360v138 because it doesn't exist in this World.

when running the collision checks in the Update schedule.

[vestal minnow]

Yeah physics currently runs in PostUpdate by default, so the contact data in Update is technically from the previous frame.

You could run your system in PostUpdate right after physics, or to just avoid the error you could also use try_insert instead of the panicking insert. try_insert only inserts the bundle if the entity exists.

[hexed veldt]

Thanks! How to do this "You could run your system in PostUpdate right after physics"? I mean how to specify it to run after physics?

[edgy nacelle]

Ooh how do you implement springs? I tried applying ExternalImpulse (-k * x * dt), but it’s either too weak against gravity, or things get explodey

[gilded fox]

I am following the docs here: https://docs.rs/avian3d/latest/avian3d/dynamics/rigid_body/enum.RigidBody.html#mass-properties and setting the ColliderDensity(0.0) and as soon as I do that on my dynamic rigidbody it stops colliding with the static ground. Am I doing something wrong? If I comment out the ColliderDensity then it works again.```
const GROUND_SIZE: f32 = 20.0;
commands.spawn((
PbrBundle {
mesh: meshes.add(Cuboid::new(GROUND_SIZE, 1.0, GROUND_SIZE)),
material: materials.add(Color::srgb(0.8, 0.2, 0.4)),
..default()
},
Collider::cuboid(GROUND_SIZE, 1.0, GROUND_SIZE),
RigidBody::Static,
));

commands.spawn((
    PbrBundle {
        mesh: meshes.add(Cuboid::new(1.0, 1.0, 2.0)),
        material: materials.add(Color::srgb(0.8, 0.7, 0.6)),
        transform: Transform::from_xyz(0.0, 5.0, 0.0),
        ..default()
    },
    RigidBody::Dynamic,
    Collider::cuboid(1.0, 1.0, 2.0),
    ColliderDensity(0.0),
    Mass(20.0),
    InverseMass(1.0/20.0),
    CenterOfMass(Vec3::ZERO),
));```

[gilded fox]

I made the dynamic object into Collider::sphere(1.0) and it works as expected.. I guess just a missing implementation for cuboid.

[snow urchin]

Am I stupid cause I genuinely don't know why this floor code won't work

let mut hitfloor = false;
        'a: for coll in col.collisions_with_entity(ent).filter(|colle|!colle.during_previous_frame) {
            let is_p_first = ent == coll.entity1;
            for man in coll.manifolds.iter() {
                let norm = if is_p_first {man.normal1} else {man.normal2}.y.abs();
                if norm > 0.84 && norm < 1.01 {
                    hitfloor = true;
                    break 'a
                }
            }
        }
        if !hitfloor {
            vel.y -= 0.05;
        }

Or rather I don't know what the solution would be

[snow urchin]

I tried adding the same amount to y when hitfloor isn't true and no change

But add too much and it just bounces up and down

Ik it's probably textbook physics but i'm afraid I don't know what that would look like

[vestal minnow]

My guess is that you need non-zero Inertia

[vestal minnow]

Is the intention that this would apply gravity whenever the object is not in contact with ground? It looks like you're iterating through started collisions, not just active collisions, so hitfloor is only true for the frame where you first hit the floor

[snow urchin]

tried that, still goes right through

whether it's started or continous

[vestal minnow]

What are you using for stopping the object's vertical velocity when it hits the ground? So it doesn't just keep going

[snow urchin]

A static cuboid

I tried println on everything and it works as intended

[vestal minnow]

Is the object you're moving kinematic?

[snow urchin]

by conclusion is that it's just adding more than it stops

[snow urchin]

no

static

[snow urchin]

It stops for a few frames and keeps going

[vestal minnow]

If it's moving with LinearVelocity then it can't be RigidBody::Static though because they by definition can't be moved, except teleported with position changes

[snow urchin]

The object that the player is colliding with is static

the floor is static

the player is kinematic

[vestal minnow]

Do you have collision logic for the kinematic body though? To actually prevent it from going through the static ground

[snow urchin]

The code I sent is my current logic

it passes the print statements

[vestal minnow]

So the whole thing with kinematic bodies is that they're fully user-controlled, and can be moved with velocity, but they don't respond to collisions or forces. You need to manually handle all collision logic for kinematic bodies

[snow urchin]

I did

let mut hitfloor = false;
        'a: for coll in col.collisions_with_entity(ent).filter(|colle|!colle.during_previous_frame) {
            let is_p_first = ent == coll.entity1;
            for man in coll.manifolds.iter() {
                let norm = if is_p_first {man.normal1} else {man.normal2}.y.abs();
                if norm > 0.84 && norm < 1.01 {
                    hitfloor = true;
                    break 'a
                }
            }
        }
        if !hitfloor {
            vel.y -= 0.05;
        }

[vestal minnow]

You're moving the body downwards with gravity, but not reacting to the collision by actually stopping the player at the ground

[true hearth]

it needs to be a force, not an impulse. The ExternalForce component

and damping is also a game changer when using springs

so the force should be something like stiffness * (target - position) - damping * velocity

[vestal minnow]

Kinematic collisions are most commonly handled with collide-and-slide, which isn't currently built-in but likely will be in the future. There are also some simple implementations of it on this Discord

[true hearth]

oh, but you're transforming to an impulse via dt, so not sure why that doesn't work. Maybe you just need to add damping

[snow urchin]

how

[vestal minnow]

like this one (I haven't tested)
#math-and-physics message

and this one
#1124043933886976171 message

both for Avian

[snow urchin]

Don't understand any of that currently

I'm aware of a gamemaker tutorial I followed though where the players position would incremently go backwards by half the position each time

Otherwise the player would get stuck inside the object

Forgot the code though

[gilded fox]

Thank you, makes sense in retrospect! That fixed it.

[royal helm]

sometimes I wish I had a little vector sandbox lol

make it easier to visualize and understand the operations taking place

[snow urchin]

The benefit to making an engine yourself isn't you don't have to learn the engine, at the cost of all your time

I chose bevy because it's like a scene editor in the form of code, the most efficient way of manufacturing a game.

[royal helm]

I mean I could make this inside of bevy, I just mean I'd like a little graph with a bunch of vectors based off some code

[snow urchin]

wdym

[royal helm]

honestly just using the gizmos to make it would be fairly easy

I just want a visualization of certain operations, like I do:

let velocity = velocity - normal * velocity.dot(normal);`

I can make sense of it eventually in my head, but it just takes a bit longer

[vestal minnow]

Proper collisions for kinematic characters are just not a simple thing to implement, and require decent understanding of vector math (or just copy an existing solution I guess). There is a kinematic_character_2d example with an example collision system, but it also has some issues and is relatively complicated and unorthodox.

In general, I would really recommend that you either implement collide and slide (see the video I linked) or use a dynamic character controller like tnua (or a custom one). We had a long discussion on this a few days already, and this summarizes my recommendation pretty well #1124043933886976171 message

Unless you're going for something very simple for collisions or really want to implement them from scratch

[snow urchin]

I guess i'll just figure out then.

[royal helm]

FWIW I'm thinking of just using a dynamic controller even though I've implemented this basic KCC

[snow urchin]

I was in a thinking mode of efficient learning but if it's ineffiency for quality i'll take it.

[royal helm]

I'd say these are possibly the most important things to learn in terms of game feel, your character controller is going to be vital to 99% of games

[gilded fox]

I really appreciate being able to plug and play my own plugins! and bumping substep count seems essential for my simulation. It's nice being able to fully customize it... porting my own physics code in the next week, so hoping it fixes some of my hand-made issues 🙂

[royal helm]

(with the exception of things like rts's or floating camera games)

[hexed veldt]

@vestal minnow how do I specify a system to run after the collision events being sent out? https://docs.rs/bevy_xpbd_3d/latest/bevy_xpbd_3d/enum.PhysicsStepSet.html

[vestal minnow]

If you're running in PostUpdate, then I'd probably do .after(PhysicsSet::Sync)
https://docs.rs/bevy_xpbd_3d/latest/bevy_xpbd_3d/enum.PhysicsSet.html

If running in PhysicsSchedule, then .after(PhysicsStepSet::SpatialQuery) would run after all physics in bevy_xpbd. In Avian there's also a PhysicsStepSet::Last to make it clearer though

[snow urchin]

Ofc. Gameplay is the most important thing in a game.

[royal helm]

Ya, but I mean this in the way that this is why Celeste was so popular. The controller feels amazing to play around with even without interacting with anything else in the game

If it is fun to just move around in your game, it multiplies the fun of everything else

conversely if the controller is slow or clunky it makes everything else feel like shit even if those parts are well designed

[snow urchin]

Yeah. Everyone should try to achieve perfection in a certain regard in every aspect even if you fail to. Quality is an important separation from other games.

Speaking of such, @vestal minnow , if you can, you should implement a fix to a common problem I see in physics engines if possible, that when something collides with dynamic bodies, it bounces back like it has moon physics.

[vestal minnow]

I'm not sure if I understand exactly what issue you mean

Bounces back in what way?

[snow urchin]

Well, I guess what i'm trying to say is that in real life it bouncing back is more logorithmically and takes more force, then suddenly increases rapidly

Where as in common practice it feels like it's one way in one way out uniformly

[royal helm]

I don't think the physics engine should really be trying to solve that since there isn't really a single solution for it

like how do you tell which way is the "way out"?

[snow urchin]

realism

[snow urchin]

I mean that semantically, in terms of the way an object accels and decels

[royal helm]

Physics engines are realistic in that way, it's usually a problem of scale that the developer messed up

if you have your objects be 200 meters in diameter, it's going to look moon jumpy

[snow urchin]

I guess what i'm trying to say is in real life it takes more force to get something going, but once it's going it goes up a lot faster, same way the opposite for decel

Where as in normal ones it takes a little to push it, and it accels just as fast, same for decel

[royal helm]

what's the scenario you are thinking of here? because I'm confused as to whether this is objects grinding against eachother or if you are throwing something in the air

[snow urchin]

well I guess an analogy I could use is when pushing a leg press

It's hard to push at first but when you get past the threshold it's way easier

at the end I mean

Similar to how in martial arts breaking a board feels better on your limbs than hitting and not breaking it

[royal helm]

human muscles probably aren't the best analogy, they are really complex and tend to have zones of more or less strength

[snow urchin]

I'm aware, I was just using it for example

As a parable of sorts

[vestal minnow]

In real life objects have non-uniform material properties, objects are never perfectly rigid, there is air resistance, contact surfaces are uneven, different materials behave very differently against each other... Physics engines do approximately produce the correct results for the given coefficient of restitution, but that assumes the objects are perfectly rigid and the system has no imperfections, disturbances, etc. (outside of limitations imposed by simulation methods)

[snow urchin]

That's what I meant by it seems like floaty moon physics in a way

[snow urchin]

I'm aware, but semantically speaking, they always follow that rule even at smaller weights in smaller scales.

Other physics components are of course always applied ontop of each other.

[vestal minnow]

I feel like you're basically describing momentum

if I'm understanding correctly

[snow urchin]

Yes, but in the way I believe to be in real life

[vestal minnow]

like for example it's hard to push something heavy, but once it's already moving, it feels easier to keep it moving and even accelerate

[snow urchin]

Whenever I add mass to an object, it feels like it only decreases the bounce, and speeds up the interaction

That of course isn't how it is in real life

[snow urchin]

yeah

[vestal minnow]

Momentum is definitely handled by physics engines, but things like large mass ratios are something that most (dual) solvers struggle with, and restitution is also pretty challenging to handle accurately (especially with continuous collision detection)

(or with speculative collision at least)

[snow urchin]

Well, to put in perspective, let me draw a graph real quick

[vestal minnow]

(as a side note, I have a section on simulation accuracy in the docs here, inspired by Box2D)

[snow urchin]

Well as a rule of thumb, physics towards a static object should never be a thing when a heavier object is on top of a lighter one, but i'm just saying that just in case.

I believe this is what i'm trying to express.

the starting velocity of course increases faster with force

and end decreases faster with weight that it hits

[snow urchin]

Anyways, should an "about to collide" function group be added?

[royal helm]

narrow phase is fairly similar, but not guaranteed to collide

[snow urchin]

wdym

Depends on how you detect collision

[dreamy raft]

is there a plane collider(3d), because I can't find it if there is

[wanton forge]

Hello, the game I'm working on has recently switched from rapier2d to avian2d, and it has been an overall smooth switch, aside from one thing. Is there a way to set the default resitution for all objects to 0? We've been encountering issues where the player character still bounces after doing certain actions, despite the collider being set to zero restitution and combine mode zero.

[snow urchin]

@wanton forge

[wanton forge]

I see. So is there a recommended thing to do to reduce the bounciness of high speed collisions?

[snow urchin]

idk

[wanton forge]

In my googling I’ve found damping, which seems not fun, increasing the iteration steps, which we will probably use till performance becomes an issue, and manually setting the linvel to 0 after the collision, which will probably be our go to method.

[edgy nacelle]

What makes large mass ratios challenging (and what's a dual solver)? Trying to understand physics engines better

[vestal minnow]

Here's an explanation for one of the issues with large mass ratios, taken from Erin Catto's slides

I'm not too knowledgeable on the details of primal vs. dual methods, but primal methods correspond to Projective Dynamics, while dual methods AFAIK correspond to typical constraint-based dynamics, which are the standard for game physics.

Primal methods have issues with stiffness ratios, so mixing different constraint stiffnesses will behave poorly and lead to error and stretching, while dual methods have issues with mass ratios, like the above heavy ball on top of a lighter one, or a heavy object at the end of a chain.

There's a paper on primal vs. dual methods by Macklin et al.
https://mmacklin.com/primaldual.pdf

[snow urchin]

Did you see this jondolf?

Also, for anyone here, how do you check if a position collides with something?

[little maple]

do you mean like.. aside from looking at EventReader<Collision>?

[visual sparrow]

You mean an arbitrary position? You can do a spatial query

[snow urchin]

example?

[little maple]

is this what you want?
https://docs.rs/avian3d/latest/avian3d/spatial_query/struct.SpatialQuery.html#method.point_intersections

[snow urchin]

What function would I use? point_intersections?

[visual sparrow]

Maybe you should first read through https://docs.rs/avian3d/latest/avian3d/spatial_query/index.html

It’s a very nice overview of what is possible

Then, you take a SpatialQuery in your system and do the operation you need

[edgy nacelle]

@vestal minnow The slides are super helpful, thanks! That probably explains why my car suspension was so jiggly -- I suspect the constraint solver for joints (XPBD?) was having trouble transferring the weight of the car (200kg) via a prismatic joint's distance limit, through a tiny part (1kg), via a revolute joint, through the wheels, to the ground.

[edgy nacelle]

From your experience with the prototypes you mentioned in your blog, does TGS handle chains of joints with high mass ratios better than XPBD?

[vestal minnow]

There are lots of implementation details that can affect things, but in general, XPBD can actually handle chains with less stretch than TGS Soft, but it has more high-frequency oscillation and is perhaps more prone to instability in more complex cases.

Erin's video on Solver2D results has a chain test around 28:00
https://youtu.be/sKHf_o_UCzI?si=DIZpbA3349k2Yf85&t=1677

For joints, there are also some direct solvers that could be used to get exact results, and articulated bodies (what Rapier calls multi-body joints) could even be handled with forward dynamics using something like Featherstone's algorithm, but those are typically more complex and expensive

[edgy nacelle]

Interesting, thanks! It's really hard to get an intuitive understanding of why a certain solver behaves a certain way in a certain case 🥲

[vestal minnow]

A rough guess for why XPBD and TGS NGS do well in that particular test is that they do position corrections instead of only doing velocity corrections like e.g. TGS Soft, so in a way, the error gets corrected quicker and overall convergence is better. But position updates have their own issues

I believe NGS also kinda does two separate solves, a velocity solve followed by a position solve, so I'm not entirely sure how comparable the test is since it could be more expensive. Depends on how the test was configured

And substepped solvers (all the TGS solvers and XPBD) do better than non-TGS solvers since substeps are more effective than iterations

[edgy nacelle]

I see. I'm trying to come up with a story that explains the jiggly car. For avian's joints is the solver the one described here? https://mmacklin.com/smallsteps.pdf (Algorithm 1: Substep XPBD simulation loop)

[vestal minnow]

this is mainly what was used
https://matthias-research.github.io/pages/publications/PBDBodies.pdf

Hmm fixing https://discord.com/channels/691052431525675048/1259011159663579186, I think we need an implicit gyroscopic torque solver 🤔 because the semi-implicit Euler version extrapolates velocity and blows up

either that or drop the term completely (done by e.g. Rapier and Bepu), but that makes some rolling and spinning behavior look worse

or we could do a hybrid, where we only use the implicit version when the semi-implicit one fails 🤔

not sure how reliable the condition for choosing which one to use would be

[edgy nacelle]

How about always solving for the gyroscopic term implicitly? (too expensive?)

Erin Catto talks about implicit for gyroscopic Δω (1 iteration of Newton-Raphson is apparently enough for a capsule) + explicit for torques, starting slide 71 of https://box2d.org/files/ErinCatto_NumericalMethods_GDC2015.pdf

[vestal minnow]

Yeah that's what I'm using as reference here

I was wondering if I could default to semi-implicit Euler, and only fall back to implicit Euler when the gyroscopic term computed with semi-implicit is too large (indicating that it probably blew up)

The semi-implicit approach works in general, but it fails for e.g. this quickly spinning torus #1124043933886976171 message and in some instances some of the small objects in https://discord.com/channels/691052431525675048/1259011159663579186

[vestal minnow]

It could also potentially be the reason why your cylinder collider blew up (unless that's a joint issue)

[edgy nacelle]

I'll put some nan checks before and after the angular velocity integration -- maybe around dynamics/integrator/semi_implicit_euler.rs: integrate_velocity ?

[vestal minnow]

It doesn't produce NaNs at least directly, it mostly just makes angular velocity increase rapidly into infinity in some instances (which can potentially lead to NaN elsewhere).

If it is this issue, removing the gyroscopic term from angular_acceleration should fix it:

// Change this:
inv_inertia * (torque - ang_vel.cross(inv_inertia.inverse() * ang_vel))
// To this:
inv_inertia * torque

(at least it fixed the other two cases of explosiveness or other weirdness)

I'm trying to implement the implicit solver now

[edgy nacelle]

Hah, that fixed it! (RIP Dzhanibekov)

and indeed at the last step before ang_vel became non-finite, it was
Vec3(-7.157498e20, 6.6739575e20, -1.1932445e21)

[vestal minnow]

Hmm, it'd be interesting to have an example of a literal tennis racket flip 🤔
https://en.wikipedia.org/wiki/Tennis_racket_theorem

and see if it's actually simulated correctly

[visual sparrow]

Woah that's cool, TIL!

[vestal minnow]

It's funny how I literally saw some YT short on this theorem earlier today, and it ended up being related to the stability issue I've been struggling with for the last week 😂

the universe wanted to give a subtle nudge in the right direction I guess

[edgy nacelle]

hm sorta!

Could probably optimize the shape to maximize the effect

commands.spawn((
    RigidBody::Dynamic,
    Transform::IDENTITY,
    AngularVelocity(Vec3::new(0.1, 10.0, 0.0)),
    Collider::compound(vec![
        (Position(Vec3::new(0.0, 0.0, 0.0)), Rotation(Quat::IDENTITY), Collider::cylinder(2.5, 0.6)),
        (Position(Vec3::new(0.0, 0.0, 4.5)), Rotation(Quat::from_rotation_x(90.0_f32.to_radians())), Collider::cylinder(0.4, 5.0)),
    ]),
    ColliderDensity(100.0),
));

@vestal minnow Joint limits are not predictive currently right?

[vestal minnow]

Currently they're not

Hmm I assume this ^-2 is a mistake for the angular inertia in the first formula here 🤔 I'd think it's meant to be ^-1

[edgy nacelle]

Units work out for ^-1: 1/s = s * 1/(kg m^2) * (kg m^2/s^2) = s / s^2

Is there anything we can do against ghost collisions on trimesh colliders currently? The wheels sink a tiny bit into the icosphere trimesh, so whenever it hits an edge it's like eating a road bump at high speed 🫨

[vestal minnow]

Does using TrimeshFlags::FIX_INTERNAL_EDGES help?

can be configured through ColliderConstructor::TrimeshFromMeshWithConfig or Collider::trimesh_from_mesh_with_config depending on what you're using for constructing the collider

[sleek thicket]

@vestal minnow #math-and-physics message
i think a step-by-step tutorial/explanation would be better after all, people just copy the examples without learning anything, so they can't even debug simple problems

[vestal minnow]

yeah, true

something on kinematic character collisions would probably be good too, I don't want to rehash the same conversations with people struggling with them a million times... although it wouldn't be nearly as bad if we just had built-in collide-and-slide

[sleek thicket]

but doing the work for them will just end up with questions about how to customize it instead

catlikecoding shows how he arrived to the end result, pointing out every problem before showing the workaround so there are no questions left by the end of each chapter.
each finished step could work as a standalone controller or plugin, but i think it'd be better to use an external crate for it to reduce the bloat

first chapter doesn't even use physics engine to teach about physics

[visual sparrow]

As an onlooker, I think you spent way more time than can be expected from anyone teaching people about KCCs

[vestal minnow]

Got stable gyroscopic motion working with the hybrid approach I was proposing; bodies with low angular momentum use the cheaper semi-implicit Euler approach, while bodies with high angular momentum use the much more accurate but slightly more expensive implicit Euler approach

Old behavior:

Haven't seen any other engines do this 🤔

Most seem to skip gyroscopic motion entirely

[edgy nacelle]

That looks amaaazing

[edgy nacelle]

Looks like FIX_INTERNAL_EDGES was added in parry 0.19 (avian is on 0.15)?

[cinder summit]

"slightly more expensive" how slightly are we talking here? Is it at least worth branching when it isn't necessary? 🤔

[vestal minnow]

0.16 is the most recent version though

[edgy nacelle]

Oops... wait where tf did I read that?

Damn it I was reading rapier 0.19 changelog 😅

Hm so avian 0.1 redefines parry's TriMeshFlags as TrimeshFlags, but is missing FIX_INTERNAL_EDGES

[sleek thicket]

not just about KCC though

[vestal minnow]

This

-delta_seconds * world_inv_inertia * ang_vel.cross(world_inertia * ang_vel)

vs.

// Convert angular velocity to body coordinates so that we can use the local angular inertia.
let local_ang_vel = rotation.inverse() * ang_vel;

// Residual vector
let f = delta_seconds * local_ang_vel.cross(local_inertia.0 * local_ang_vel);

// Compute Jacobian
let jacobian = local_inertia.0
    + delta_seconds
        * (skew_symmetric_mat3(local_ang_vel) * local_inertia.0
            - skew_symmetric_mat3(local_inertia.0 * local_ang_vel));

// Do one Newton-Raphson iteration
let delta_ang_vel = -jacobian.inverse() * f;

// Convert back to world coordinates
rotation * delta_ang_vel

[vestal minnow]

Whoops, I think that was just missed when we added our own version of the type (for Reflect), I can put it in the 0.1.1 patch since adding it isn't a breaking change

It seems to be equivalent to 1 << 7 | ORIENTED.bits() | MERGE_DUPLICATE_VERTICES.bits() though

[edgy nacelle]

@vestal minnow Thanks, that did the trick 🙂 PR to add it to avian here: https://github.com/Jondolf/avian/pull/418

[vestal minnow]

Thanks 😄

Tbh maybe we could enable that flag by default for trimesh colliders if it's not too expensive

(but not for this patch release probably)

[royal helm]

I just realized I had re-invented collide & slide in wanderlust a while ago lol

silly stuff

[vestal minnow]

Eh, I'll just do implicit Euler regardless of angular velocity for now, it's not actually that expensive and it just gives better results (and it was Erin's recommendation)

we can benchmark later to see if the adaptive approach would actually have any benefits

(also this only affects 3D since 2D has no gyroscopic motion ofc)

making spinning tops out of things is satisfying

[sleek thicket]

try making spinning tops with curved gravity and you'll lose all productivity for the foreseeable future 👍

[vestal minnow]

yay
https://github.com/Jondolf/avian/pull/420

[cinder summit]

I think the expensive part there is probably the inverses, and maybe the skew functions (since I have no clue what they do). Might also be possible to optimize some of the inversions out, or share some more math across the frame

[edgy nacelle]

The skew symmetric matrices should be pretty cheap, it’s just like a swizzle that copies stuff from a vec3 into a 3x3 matrix

[vestal minnow]

yeah that and the quat inverse should be cheap, the matrix inverse is probably a bit more expensive but not too bad

[cinder summit]

For quats it just seems to flip some signs so that's pretty cheap yes. Matrix inversions are more expensive

Well unless they're pure rotation matrices, then you transpose them which is pretty cheap too

But it's probably one of the less expensive things ... I don't see dozens of normalizes for example

[vestal minnow]

the integration is also trivial to parallelize, although the overhead seemed to just regress things when I last tried... Could probably configure the batching strategy

[cinder summit]

Main thing for this kind of stuff is that you need big enough batches for dispatching tasks to be worth it

Which probably means a really big simulation

And to support simulations that big there's probably optimizations to be made elsewhere first 🤔

[sleek thicket]

dogfooding would be better, just to point out what devs actually need from the physics engines

[vestal minnow]

Lmao, just noticed this

I wonder what that spike is

[cinder summit]

Must be from a trivial bug fix

[valid fog]

YOOO YOUFIXED IT

LETS GO

[fringe mango]

has any done any performance comparisons between avian and rapier? would be curious to see how they stack up against each other now that avian uses the new solver

[sleek thicket]

i'd be surprised if it's faster even after that

[vestal minnow]

Most likely the final fix for 0.1.1 patch, fixing #1260582666617618442 message
https://github.com/Jondolf/avian/pull/425

[fringe mango]

damn really? i thought avian would have at least a small advantage given its directly built for bevy

also i heard somewhere that rapier keeps its own physics world and does applies it to the bevy world so that it is synced, which i thought would cause at least some overhead

[sleek thicket]

it might get better in future, but for now it's just more comfortable to use

[fringe mango]

i see

im currently upgrading to 0.14 and thought that i might as well switch to avian as well

[sleek thicket]

wait for the bugfix patch first

[fringe mango]

does that bug have a big impact on performance?

also I don't mind these little bugs currently because my game probably wont be affected by them

[sleek thicket]

@vestal minnow when is it coming btw

[vestal minnow]

Within an hour or two unless I find any critical issues

[sleek thicket]

then yeah better wait for it first 😄

@fringe mango just back up your code before switching and write an essay about what you think if you end up switching back to rapier

[vestal minnow]

bevy_rapier does have extra overhead there, but there's a lot of optimizations we need to work on to beat Rapier. So far the focus has been more on features and usability, and we just haven't had as much time to optimize yet. Although the focus has shifted a bit more in that direction with the solver rework and plans to implement things like simulation islands and a better broad phase.

(For reference, Rapier has existed for 4 years and its predecessor NPhysics was released over 8 years ago. bevy_xpbd 0.1 was only released about 1 year ago and Avian 0.1 only 8 days ago, so there has been much less time for things to mature)

I listed some optimizations we should implement here
https://github.com/Jondolf/avian/issues/319#issuecomment-2108949253

My next things in that list would probably be simulation islands (most likely also involves some joint reworks), a better broad phase, and one-body constraints

and a contact graph

Proper SIMD constraints would require wide math types, which we don't have for Glam yet

Rapier can use Nalgebra and Simba for that

[sleek thicket]

shouldn't there just be a single page for all of that as a FaQ

i think i've even seen something like it

[fringe mango]

probably dont need to back up cus I just have to switch some syntax (for example, Velocity to LinearVelocity, etc)

[sleek thicket]

it'll probably be more than that

[fringe mango]

yeah that does makes sense 😅 , thanks for clarifying about the optimizations

[snow urchin]

What's the math avian3d uses to calculate what distance something goes in a frame based on the velocity?

[fringe mango]

im basically only using collisions and velocity in my project right now, so it really isn't a lot (hence why I want to switch sooner than later)

[sleek thicket]

ah, yeah, then it should be fine

[vestal minnow]

It uses semi-implicit Euler integration (the standard in game physics), there's an explanation and formulas in this module, see the docs at the top
https://github.com/Jondolf/avian/blob/main/src/dynamics/integrator/semi_implicit_euler.rs

or the docs.rs version, but the code has some more comments
https://docs.rs/avian3d/latest/avian3d/dynamics/integrator/semi_implicit_euler/index.html

[snow urchin]

so vel + acc * dt, ty

[vestal minnow]

that's for computing the new velocity based on applied forces

[snow urchin]

I'm just making a kinematic body, so that's all I need

[wanton forge]

For us the upgrade to bevy 14 was a lot easier than from rapier to avian, just updating the path for the css colors. We switched to avian since we were having an impossible to track down bug with rapier, but now we also have one with avian :). It looks solver related, so I’m hoping this new update will solve it.

[vestal minnow]

the position change is just the standard delta_x = lin_vel * delta_time

[snow urchin]

yeah

[vestal minnow]

What kind of bug is it?

[snow urchin]

Right now i'm going to try a raycasting solution that's distance is based on the distance the object travels in a frame, so I need that

To prevent it from sinking into the floor

[wanton forge]

For some reason, our simulation slowly becomes more bouncy over time, even though every collider is restitution 0 combine min. I’ve been slowly digging into it, and my suspicion is that there is some instability when the player’s collider (dynamic) hits the walls (static), so the more collisions happen the more everything becomes less rigid, and thus bouncy. I can’t currently check anything, away from computer, and the repo we use is in massive disorder, but if the update doesn’t fix it and I can’t track it down I plan to make a minimal reproduction and open an issue.

[vestal minnow]

There was one issue related to static bodies and mass that was fixed, but I don't see how it would be related to bounciness... The simulation also shouldn't maintain state related to collisions after the collision ends, so I'm not sure why the behavior would change over time like that

Either way let's see if the patch changes anything, and if not, we can try to debug further

(currently doing final tests before releasing the patch)

[wanton forge]

Yep. We do plan on sticking with avian since the interface is so much nicer than rapier. It will be a few hours until I’ll be able to test the new update, I’ll report back once I’ve seen how it goes.

[snow urchin]

I'm assuming it still bounces because the function still runs even if the restitution is 0.

Maybe your code has it to bounce, and it is assumed to not bounce at 0.

But infact, it bounces with the 0 input value.

Just a thought.

[vestal minnow]

it does not run when restitution is 0

if restitution == 0.0 {
    continue;
}

[snow urchin]

I see. I thought that would be the case.

This maybe stupid, but try using return instead

[vestal minnow]

small bounce is inevitable for solver reasons, but the strength of the bounce should not increase over time

[vestal minnow]

Then it would stop applying bounce for any contact when even a single non-bouncy contact is encountered.

I also have this restitution test that works
#showcase message

[snow urchin]

I see. i'll think of a way this can be solved.

Although from retrospect, it would be hard not to make it bounce just to be safe.

Have you fixed the teleporting bug yet?

[vestal minnow]

What teleporting bug? This?
#math-and-physics message

[snow urchin]

yep

[vestal minnow]

yes
#math-and-physics message

[snow urchin]

Great to see 👍

Also, I appreciate your constant help with the community.

Thank you

I'm sure it takes a lot of time out of your day.

[vestal minnow]

Thanks <3 I like helping people, the project wouldn't be what it is without you all

It also helps identify what to improve on and what's actually important for users

dogfood indeed

[sleek thicket]

dogfooding is only when dev does it

a couple games i play had problems that people kept talking about for years until dev decided to play, immediately stumbled into the got completely burned by that problem and fixed it the next day

[snow urchin]

Tarkov devs

[sleek thicket]

not that but yeah, dogfooding is great.

[snow urchin]

Idk what dogfooding is

[sleek thicket]

dev using their own creation

[snow urchin]

Hard to believe that it's uncommon but it is lol

[vestal minnow]

I guess it's not dogfooding in the traditional sense (like making a game with it), but I do often set up test scenes and so on to debug peoples' issues, or even debug their actual projects

(I do also try to randomly make small projects with the engine)

[sleek thicket]

no, it applies to everything as long as you're actually using it as intended

[snow urchin]

I think the issue with most game studios isn't the lack of dogfooding, but the perceived lack of dogfooding when in reality, megacorps are trying to push an agenda by keeping bad changes

example being tarkov pretending to not know how to fix their ai

bad enough to where ai programming difficulty isn't the issue

The only time where it was a genuine mishap was when the machine gun ai would shoot at you when you were hundreds of meters out of the zone where they should shoot you

in a specific area

Well scavs would increase their accuracy when you looked at them

No matter where or why

At that point, they would have a random chance of headshotting you even when you were in the middle of jumping midair

rogues won't aim primarily at the head but won't miss you unless you peak them at angles you haven't already peaked them at

And if you peak them at slightly canted angles (not full Q or E) then they most likely won't even notice you

These features all seem very unnaturally aligned

My completely unfounded opinion is that it's to stimulate the cheater market

Yeah lol, to have very functional gunplay and dogwater ai programming seems impossible

Oh sorry, you meant that the gameplay is too complicated to make good ai?

wdym

yeah

no

Oh...

That's bad

Yeah, but still makes the gameplay dishonest

Anyway,

It's more complicated than the average fps, so I don't understand

And there are fps games with functional-ish ai

I mean, you see people achieving movement feats in tarkov daily, but the difference is night and day between them and the ai

There are even SPT mods to make the ai standard quality

That's just my opinion, and why I think the ai is intentionally bad

[snow urchin]

Look up sain's ai mod and you'll see what I mean by this

Idk how that makes tarkov's ai good for it's gameplay

I was arguing that tarkov's gameplay is far more complicated than what ai will do

Can you tell me?

[vestal minnow]

Nice, we reached 19k messages

[snow urchin]

peak

Well i'm talking about the ai

[vestal minnow]

That link from the first message is outdated now though

Nah

[snow urchin]

Just get on topic when someone needs help, don't worry

So that's why I think the ai is intentionally bad

That's what I always think when some guy comes out with a mod fixing someone's game

That the lack of fixing was an industry plant

[vestal minnow]

No need to delete messages, but ideally try to stay roughly on topic here (i.e. physics or Avian) for longer convos

[snow urchin]

Cause if a few guys can do it in their free time, surely a company can do it if they want to

[snow urchin]

I understand

[sleek thicket]

well, i did it anyways >:3
how's 0.1.1 coming along?

[vestal minnow]

Released #crates message

[snow urchin]

Is big_space added yet?

[sleek thicket]

oh i completely missed it :0

[snow urchin]

Good thing I have the git in the toml lol

Will rust recompile made DLLs if there's a version change, but not a small git change?

Cause I didn't notice any compile slow down

[vestal minnow]

If you have the version specified like 0.1, it'll update to patches like 0.1.1, 0.1.2 and so on when you run cargo update, or when it has to recompile the crate again for some other reason (like if you removed target)

[snow urchin]

So not on git changes?

[vestal minnow]

you need to run cargo update for that as well

[snow urchin]

oh, didn't know, ty

it won't update libraries that toml libraries require will it?

I doubt it, but just incase

[vestal minnow]

It updates all the crates in your Cargo.toml to whatever version you have specified, if new versions are available

[snow urchin]

I see

[vestal minnow]

So it'll pull git updates for dependencies that you depend on via a git path

and patch releases, unless you've specified a specific version

[snow urchin]

ty

Should I consider a library for 3d audio or does bevy already support that?

[vestal minnow]

Bevy does have spatial audio (see example) but idk how capable it is

that's off-topic here tho and I'm not the best person to ask about audio stuff :P

[snow urchin]

Not really, physics is usually required to make good audio

[sleek thicket]

i keep seeing people use https://github.com/NiklasEi/bevy_kira_audio
there's also this #showcase message

[snow urchin]

the asset_loader guy lol

[sleek thicket]

https://tenor.com/view/this-is-fine-gif-25423531

[vestal minnow]

This is fine 🙂
-# This is not in fact fine. Send help.

[vapid monolith]

160 of those are unused imports i bet 😂

[sleek thicket]

direction3d -> dir3, xpbd -> avian, and color changes are the main chunk

[sleek thicket]

0 errors, the rest is just pointless warnings 🙂

[wanton forge]

I can’t wait for lint reasons to come to stable so I can finally silence dumb warnings without forgetting to enable them once I’m done

[snow urchin]

ermm, this variable isn't being used, you should label as dead code 🤓

[wanton forge]

#[expect(dead_code, reason = "TODO: shut up I’m still working on this part of the code >:(")]

[snow urchin]

btw, How should I go about making the distance of a shape cast just enough to catch an object before it sinks into the floor?

I'm using a cuboid to detect collisions below the player, and the distance should be just enough to stop the player at the right time based on the velocity

[wanton forge]

It sounds like you want ccd (continuous collision detection)
Otherwise, the size would be the distance the player will move, so just the velocity, maybe plus the player height depending on where you measure from.

You’d basically be checking the area of space from the player’s current position to the next position for any collision.

[snow urchin]

this is what the distance should be?

also the velocity is 10.0, so that's a big no

[thin hare]

Hey all, I'm trying to check for grabable items in a radius only when a key is pressed, is doing a large sphere with 0.0 TOI via the system param SpatialQuery be the cleanest way to handle that?

[snow urchin]

Not really, more like Res<Collisions> as a resource, then using https://docs.rs/avian3d/latest/avian3d/collision/struct.Collisions.html#method.collisions_with_entity

As far as the sphere collider that's ok

Unless you prefer for things not to be picked up at a certain height

[sleek thicket]

@vestal minnow both entities are static, one is sensor ಠ_ಠ

[vestal minnow]

I'd probably use shape_intersections

[thin hare]

I'm not actually going to be colliding with these items in this case though, it's more like: When the pickup key is pressed, check for items within a certain radius

[snow urchin]

You could use it for that

[thin hare]

Perfect that's exactaly what I'm looking for, thanks!

[snow urchin]

Technically the one I sent is more explicit

But if you don't care about that it's ok

[vestal minnow]

it's much less convenient and very likely less efficient

[snow urchin]

yeah

well yes and no really

hard to explain

[thin hare]

effeciency is my main concern here, That's why I'm looking for a solution that essentially just looks for items within a certain distance without having to do a bunch of sqrt operations based on transform.translation.distance(item_transform.translation) or adding an additional large sensor collider to the player

[snow urchin]

for 1 it's easier to track collisions with a pickup since you're only looking for 1 collider

So I guess that's more performant

[sleek thicket]

you'll probably want to add some kind of pick up/use indicator as soon as you're in range, so checking every frame is probably better
and the collider can just have a filter that only includes those things

[snow urchin]

they both check every frame

[vestal minnow]

With collisions you'd need to spawn an actual collider, have the simulation manage that and potentially run lots of unnecessary logic on it even when you don't need the collider active, and you have no control over when the collision checks are done. And Collisions::intersections_with_entity is currently very sub-optimal.

[snow urchin]

collisions_with_entity only loops through the total collisions with a single object

[thin hare]

The spatial query will only be casting the shape on button press in this instance

[snow urchin]

You could use this function only if a button is pressed

[thin hare]

I've though about that and may go back and take a check every frame approach, but atm I'm essentially creating a mechanical clone of SM64 to start with this prototype

[snow urchin]

so it's the same use case

[vestal minnow]

It's currently an O(n) iteration over all collisions because we don't have a contact graph yet.

[snow urchin]

wait so you would be adding the same performance impact with this function?

[thin hare]

Yeah, but I would still have to worry about adding a new larger collider just for finding items

[snow urchin]

oooh that's what you mean

I get it, you just want to check if the distance between the pickup is low enough

well then that makes sense

You don't really need collision for that

[thin hare]

true, but doing one shape cast that only hit's the layer that objects are already on seems like it will be fine enough for the time being

[sleek thicket]

is that same for ontriggerenter with filter?

[vestal minnow]

Wdym by ontriggerenter here?

[sleek thicket]

ah ehh uhh

collisionstarted

[snow urchin]

why? Just out of curiosity

[snow urchin]

bro thinkin unreal

[sleek thicket]

i unitybrainfarted

[snow urchin]

me when textbook game dev function names

https://tenor.com/view/fnaf-gangnam-style-puppet-gif-6072627091288167460

[thin hare]

My thinking so far is that I already need the Entity for an observer I have handling item pickup events, and querying every item that can be picked up and doing a distance calculation seems a little messier than I need

[wanton forge]

Ooh shape_intersections looks so useful.
Me when it’s impossible to find info since the docs haven’t been indexed on google yet.

[snow urchin]

Then you could just do a capsule collider with a low height

[vestal minnow]

Currently there's a system that iterates through all collisions once every frame and sends the appropriate collision events. So yes, but the other events are handled in the same loop

we could probably handle it in the narrow phase directly though

[snow urchin]

And yeah I agree shape_intersections is a lot less complicated than having to check which entity is the entity you want

Wait, you would still have to make sure the position is at the edge of the collider

[vestal minnow]

These docs have an overview of all the spatial queries
https://docs.rs/avian3d/latest/avian3d/spatial_query/index.html

I want to add some visual diagrams and stuff too

[wanton forge]

For getting the things with colliders in an area that moves/is parented to another object, should I use something with shape_intersections, or a collider with Sensor?

[sleek thicket]

no, the enter iter is fine, i mean does filtering happen before or after collisions? because unity optimized layers and you can gain performance by using them

[vestal minnow]

If you want to detect things enter and exit the area every frame, probably a sensor, and if it's something you do on-demand (like when a button was pressed), probably shape_intersections

[snow urchin]

Yeah i'd rather use collisions_with_entity than having to code my own collider from scratch in terms of pickups unless you don't want your pickups to have colliders

[vestal minnow]

Collisions are filtered based on things like layers in the broad phase, so before the expensive part

[snow urchin]

what are "layers"?

[vestal minnow]

https://docs.rs/avian3d/latest/avian3d/collision/struct.CollisionLayers.html

[snow urchin]

Is that like SpatialQueryFilter?

what are masks for?

or how do they work I mean

[vestal minnow]

CollisionLayers is a component that defines the layers that a collider belongs to (and can interact with), and SpatialQueryFilter can have a LayerMask that determines which collision layers are included in the spatial query

[snow urchin]

I get that, I was just asking about masks in queryfilter

[vestal minnow]

So you could for example perform a ray cast against just colliders on the environment layer, skipping all enemies

[snow urchin]

oh, that's nice

[vestal minnow]

It's basically equivalent to layer masks in Unity
https://docs.unity3d.com/ScriptReference/Physics.Raycast.html

[snow urchin]

I see, so with_mask just requires the id of the mask?

don't get it then

[vestal minnow]

Layer masks are bitmasks, like 0b0001 is the first layer, 0b0010 is the second layer, 0b0011 is the first and second layer, and so on

But you can also use an enum-based abstraction

https://docs.rs/avian3d/latest/avian3d/collision/struct.LayerMask.html

or define your own constants

[snow urchin]

cool

[wanton forge]

Speaking of layers, I see there’s a method for checking if a layer mask includes a layer, but is there one for checking if it doesn’t contain a set?

[wanton forge]

On further thinking this was a silly question, it’s just !contains, brain no work.

[charred arch]

I just want to say that the docs.rs documentation for Avian is excellent

[timber cape]

is there a relatively simple way to get collision events between two entities with specified components? eg get only events between a ball and a brick entity
currently i need to check if entity1 has ball and entity2 has brick OR entity1 has brick and entity2 has ball

[peak timber]

Hey I've been out for quite a while but want to chime in and say thanks for all the ongoing hard work on Avian

Is it still XPBD-based and just a new name or are you transitioning away from that design entirely?

[peak timber]

I'm running into a bug where if you set Friction & Restitution to zero on both the static ground and a dynamic object, they don't bounce but slide with no resistance (like you'd expect).

However with Friction at one and Restitution at zero for both, I would expect them to still not bounce at all. But they seem to bounce as if Restitution wasn't zero.

So for some reason Friction is affecting bounce and even at PERFECTLY_INELASTIC, things are bouncing off each other

[wanton forge]

0.1.1 seems to have fixed the inexplicable bounciness I was running into :)
