patent bobcat Oct 30, 2021, 12:49 AM

#

#

#

grand stone Oct 30, 2021, 12:51 AM

#

Are you using a level shifter for the data line ?

patent bobcat Oct 30, 2021, 12:51 AM

#

No not at all!

grand stone Oct 30, 2021, 12:52 AM

#

Some neopixel strips use a version of neopixels are want 5V data signals

patent bobcat Oct 30, 2021, 12:52 AM

#

Yes I've read something like this in documentation but don't understand how to implement.

#

Also super appreciate your attention!!

grand stone Oct 30, 2021, 12:53 AM

#

So like ws2812b or the RGBW versions of them which I think is ws2813 would need to shift the logic level from 3.3V of the CPX and the strip

#

https://www.adafruit.com/product/395

8-channel Bi-directional Logic Level Converter

Because the Arduino (and Basic Stamp) are 5V devices, and most modern sensors, displays, flashcards, and modes are 3.3V-only, many makers find that they need to perform level ...

#

Something like this would work perfect

#

John Park has a few good videos on level shifting neopixels

patent bobcat Oct 30, 2021, 12:54 AM

#

Hmm how does this incorporate with a CPX?

grand stone Oct 30, 2021, 12:55 AM

#

So what you do is put 3V to the low voltage side, 5V from the neopixel strip to the high voltage side

#

Then take your data line from the CPX to the low voltage side, and then take the high voltage data signal and put it to the neopixel strip with a 330ohm or 470ohm resistor

#

Let me find the video from John park. He explains it very well

patent bobcat Oct 30, 2021, 12:56 AM

#

Thank you!!

#

I was in paint trying to draw a schematic

grand stone Oct 30, 2021, 12:57 AM

#

https://youtu.be/y6HiDnyhRa0

YouTube

Adafruit Industries

John Park's NeoPixel Level Shifter @adafruit @johnedgarpark #adafruit

Solve microcontroller-to-NeoPixel mismatches with a level shifter. 3v3 micros can talk with 5V NeoPixels, they just need a translator. That translator is the ever handy logic level shifter. Often, a mismatch of logic levels can cause strange behavior, such as dim or wrong-colored pixels -- especially on longer wire runs or in projects that use l...

▶ Play video

patent bobcat Oct 30, 2021, 12:57 AM

#

Also if I'm understanding correctly, my issue boils down to powering the strip, is that right?

grand stone Oct 30, 2021, 12:58 AM

#

Well, the strip will need 5V, preferably from a separate source than the CPX

#

Connect the ground of the CPX to the ground of the 5V neopixel source. Then use that level shifter to shift your data signal to the neopixel strip

#

The video explains everything:)

patent bobcat Oct 30, 2021, 12:59 AM

#

Okay lemme watch this 5 min vid then bother you with more questions! Bless you for being online!!

grand stone Oct 30, 2021, 1:00 AM

#

You’re very welcome! I do a lot with neopixels anymore so I’ve found and revisit these videos frequently 🙂

patent bobcat Oct 30, 2021, 1:18 AM

#

Okay this video was helpful in terms of demystifying the process. And it looks like no additional code necessary, just be mindful of where you plug things in. I realize now that I'm going to need a breadboard to hold the level shifter in place and solder my CPX leads into place, so something new I hadn't expected but doable.

I made a circuit diagram on paper, do you mind looking it over?

grand stone Oct 30, 2021, 1:24 AM

#

Looks right

patent bobcat Oct 30, 2021, 1:26 AM

#

Awesome, thanks so much!!!
