Product ID: 0x2812
Vendor ID: 0x2109 (VIA Labs, Inc.)
Version: b.e0
Speed: Up to 480 Mb/s
Manufacturer: VIA Labs, Inc.
Location ID: 0x14240000 / 12
Current Available (mA): 500
Current Required (mA): 0
Extra Operating Current (mA): 0
Saola 1 w/WROVER:
Product ID: 0x80a6
Vendor ID: 0x239a
Version: 1.00
Serial Number: 0000000000000000160000000CFCDF
Speed: Up to 12 Mb/s
Manufacturer: Espressif
Location ID: 0x14244000 / 24
Current Available (mA): 500
Current Required (mA): 100
Extra Operating Current (mA): 0
Media:
Saola 1 w/WROVER:
Capacity: 2.1 MB (2,097,664 bytes)
Removable Media: Yes
BSD Name: disk9
Logical Unit: 0
Partition Map Type: MBR (Master Boot Record)
S.M.A.R.T. status: Verified
USB Interface: 2
Volumes:
CIRCUITPY:
Capacity: 2.1 MB (2,097,152 bytes)
Free: 2 MB (1,954,816 bytes)
Writable: Yes
File System: MS-DOS FAT12
BSD Name: disk9s1
Mount Point: /Volumes/CIRCUITPY
Content: DOS_FAT_12
Volume UUID: 2015F2C7-4C99-3402-9C9C-147B7AEDFE6F
#circuitpython-dev
solar whale
that is with a build from a few days ago
onyx hinge
maybe the code to get the serial number is simply not functioning as expected, like @main meteor says
solar whale
I don't want to try it on my Linux box because it usually kills it...
onyx hinge
oh ... ```void common_hal_mcu_processor_get_uid(uint8_t raw_id[]) {
}
bytearray(b't\t\n@\x02\x00\x00\x00\x01\x00\x00\x00e\x00\x00')
>>> ```['0xc5', '0x4e', '0x8', '0x80', '0x1', '0xcd', '0xfd', '0x3f', '0x0', '0x0', '0x0', '0x0', '0xd0', '0x60', '0xfc']
>>>
hmmm iit is not constant ```>>> [hex(x) for x in microcontroller.cpu.uid]
['0x74', '0x9', '0xa', '0x40', '0x1', '0x0', '0x0', '0x0', '0x1', '0x0', '0x0', '0x0', '0x63', '0x0', '0x0']
[hex(x) for x in microcontroller.cpu.uid]
['0x74', '0x9', '0xa', '0x40', '0x1', '0x0', '0x0', '0x0', '0x1', '0x0', '0x0', '0x0', '0x30', '0x0', '0x0']
solar whale
ruh roh...
stuck elbow
''.join('%x' % x for x in microcontroller.cpu.uid) btw.
hey, found even shorter way: ('{:x}' * 15).format(*microcontroller.cpu.uid)
crimson ferry
I like the first one, different CPUs have different lengths
solar whale
just to check -- just rebuilt from main ```Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 6.0.0-alpha.1-83-ga6c20208b on 2020-07-15; Saola 1 w/Wrover with ESP32S2
import microcontroller
''.join('%x' % x for x in microcontroller.cpu.uid)
'92f000000e4300400'
''.join('%x' % x for x in microcontroller.cpu.uid)
'91f000000e4300400'
''.join('%x' % x for x in microcontroller.cpu.uid)
'90f000000e3300400'
silver tapir
@lone axle It looks like the commit is now in the pr, and it's trying to do the checks but I guess the system is still recovering and has stuff on queue.
@stuck elbow Where did you get the pcbs for fluff m0?
stuck elbow
@silver tapir elecrow
silver tapir
I'm thinking of making a video series in spanish about how to load cpy on one, and the fluff m0 seems like the correct board for that.
silver tapir
Oh that would be very nice, thank you.
stuck elbow
do you want it flashed, with just bootloader, or empty?
I guess you can always erase the chip
silver tapir
Yes, whatever is simpler for you.
idle owl
@slender iron You updated the bundles, but not circuitpython.org. I'll submit a PR today.
tulip sleet
@solar whale @onyx hinge The serial number code is different for different chips. Maybe it is just wrong for ESP32S2 (wrong address or length).
uncut nexus
@tulip sleet - do you have a couple of minutes to chat?
slender iron
@idle owl thanks! I looked on the downloads page but didnβt look elsewhere.
idle owl
@slender iron Looks like this at the moment π
silver tapir
Oh yeah, py bundle. That is useful.
slender iron
Oops! Now I know
onyx hinge
@slender iron thanks for your work on esp32s2 so far -- the issues I've been filing don't mean that most of it isn't AWESOME and ready to build on
slender iron
@onyx hinge just means you are ready to help on it π
manic glacierBOT
ionic elk
@slender iron I thought I had a USB breakout but I don't π¦ I've got one coming in express but I won't be able to get drive access until Friday. I can read up on the timer API and even start coding but I won't have a PulseIO PR until next week.
onyx hinge
@ionic elk You might be able to sacrifice a whole cable to get access to the individual wires, splicing them to some nice jumper wires
ionic elk
True! I'll dig around and see if I have a junk cable I could use for that.
onyx hinge
80+% the wiring color inside will be accurate. Verifying GND and VCC is easy, then you can try both orientations of D- and D+ without damaging anything
but yeah it assumes you have a cable you don't mind ruining for science π§
ionic elk
I've got tons of junk cables that come with chargers and things, but I don't know if they contain the data lines (which is the reason they're junk)
onyx hinge
yeah that probably won't work, I'd start with one that is known good for data
ionic elk
They ought to have a mandatory marking for power only cables
so much irritation in my early debugging days
ionic elk
A tiny dunce cap attached with a zip tie
onyx hinge
lunchtime! π
ionic elk
π
ionic elk
@onyx hinge when you get back, if you have a sec, could you check out https://github.com/adafruit/Adafruit_Protomatter/pull/14 and see if it looks ready to you? When submitted it'll allow my timer PR to pass CI.
lone axle
@silver tapir looks like the actions system never did notice the commit even though it's now showing on the PR page. If you end up having a moment it might be worth trying one more push of something innocuous to see if a new commit/push will get it to retry the actions run.
silver tapir
@lone axle For some minutes it, for me, it is showing the new commit, and it did ran the new checks as it now does not have the failure, so your suggestion was correct.
lone axle
Hmm, maybe the front end is still being weird on my end. I see the commit now, but it seems like it didn't run the actions check. I am seeing 0 checks and still a grey circle instead of red or green for the status symbol thing:
onyx hinge
@ionic elk done
lone axle
Oh, thank you. That is encouraging. Earlier it seemed they were having issues but the status page was still green.
idle owl
@slender iron https://circuitpython.org/libraries
ionic elk
@onyx hinge does only PaintYourDragon have merge permissions?
Thanks for taking a look
onyx hinge
yup; or at any rate, I don't.
idle owl
@onyx hinge @ionic elk I do... Is it good to go?
onyx hinge
I didn't run the code but I read it and it looks fine. so assuming @ionic elk has run it π
idle owl
Or does it make sense to leave it for Dragon?
ionic elk
I mean it'll only run once the timer code is in, and that hasn't been approved yet.
onyx hinge
I don't know them well enough to anticipate if it will feel like stepping on toes or stepping up
ionic elk
I'm not sure what your preference is for this kind of thing
idle owl
@ionic elk Hmm. Does the timer code rely on anything?
ionic elk
It'd be nice for my testing if it was on some kind of branch so that I can check it out in my timer code, so the timer code can pass CI
idle owl
Typically we wait to merge things dependent on other things until the other thing is in.
onyx hinge
this is the part that needs to go first
ionic elk
The timer code relies on this protomatter code to compile, because otherwise it has conflicts in the IRQ definitions
idle owl
Ah!
ionic elk
but at the same time, this protomatter code won't work until the timer code is reviewed and merged
onyx hinge
it's the submodule, and it needs this change before circuitpython can be improved
idle owl
Then if you're both happy with it, I'll merge it.
onyx hinge
thank you
ionic elk
Ideally I would think that the best thing would be to put this change on a branch of protomatter that I can check out
is that possible?
idle owl
Jeff would know, I have no idea.
onyx hinge
you mean for yourself locally or for the github CI?
ionic elk
I mean we actually make a branch in the protomatter repo and have this change on that branch
so this change doesn't impact the main performance of protomatter? But it's not my workflow, if that's too weird than don't do it
Am I making any sense at all?
onyx hinge
let me ask you a different question .. in your pull request https://github.com/adafruit/circuitpython/pull/3099/files did you actually add and push the submodule change?
ionic elk
I just don't want to break protomatter if the timer code runs into some other issue and needs further fixes
onyx hinge
(is that the right pr?)
ionic elk
Yeah that's the right PR. I don't have any changes to protomatter in that, because what would I even be checking out?
my changes aren't in yet
ionic elk
So it's failing CI on most STM32 chips because there's a build conflict with the IRQ callback definitions
Sorry if I'm missing something and just being an idiot that happens sometimes π
onyx hinge
In my experience, if my PR in CircuitPython makes a submodule point to a ref that has been added to a PR in that github repo, the CI is able to chew on it and give useful results
onyx hinge
You will always have my sympathy when it is submodules or merge conflicts that confound you
ionic elk
ok awesome I'll just do that then
idle owl
Submodules are jerks at times.
ionic elk
And we shouldn't submit it until both of them are ready
onyx hinge
you just commit the submodule ref the same way you would if it was merged somewhere else already
ionic elk
nice, ok, learned a new thing today. That's handy
onyx hinge
now, this thing I said about github CI being fine with it and doing the right thing .. I'm surprised at it each time, but it really does seem to work. Now watch me be a liar.
solar whale
@idle owl tell us how you really feel...;-)
onyx hinge
@idle owl that's a pretty @vapid mango thing to say
onyx hinge
I'm gonna step away for a bit thanks @idle owl @ionic elk and if it doesn't work out do @ me
idle owl
Thanks @onyx hinge. Have a good one.
Jeff's git fu is strong. He's the reason I'm able to check out other people's PRs and push back to them.
idle owl
@slender iron Am I seeing correctly there's no way to use board.I2C() if you want to set frequency? I tried a couple of things and it's all failing.
idle owl
Ok thanks.
slender iron
reason is that all devices on the bus need to agree
idle owl
Wasn't sure if I was missing something.
idle owl
Fair enough.
idle owl
@tulip sleet Hah! Fair enough.
tulip sleet
I feel like my life is sometimes "There's an issue for that!"
idle owl
I'd be annoyed about that memory sector being dedicated to issues that could be being used for something else. π
onyx hinge
"you've got issues" turned out to be a bad slogan for bug tracking software
idle owl
@gilded cradle You have a BNO055, correct? There's an open PR on it that you might be able to test if you have the cycles. https://github.com/adafruit/Adafruit_CircuitPython_BNO055/pull/51 If not, no worries.
gilded cradle
Yes @idle owl, I do have one. I might have the cycles tomorrow for that.
idle owl
@gilded cradle That would be perfect. Thanks!
thorny jay
@idle owl When you said in the weekly meeting "PM2.5 Air Quality sensor" do you mean the old UART PMS5003 or the new I2C PMSA003I ?
idle owl
@thorny jay I'm currently working with the PMSA300I, but will be updating the guide for the UART PM2.5 sensor as well, they use the same library. I have both. That is, if the PMS5003 is the UART PM2.5 sensor we sell.
thorny jay
idle owl
Yes, that's up next for updates. And what I plan to use to test your code.
idle owl
I am perhaps wrong. I thought you submitted a PR to update the example code?
idle owl
Yes, it was you π - I checked. Anyway, I'll be testing it in the next couple of days and merging it once done.
thorny jay
I shared my "analysis" of the piece of code around that UART sensor. The code in Python and the code in CircuitPython.
I think I need to put some "recovery" logic on the serial part. Either my hardware/cable is faulty (and that can be usefull to make the library more reliable) or this is a general problem. But with a single board, it is hard to tell.
idle owl
What faults are you experiencing? I ran into an issue with the PMSA300I doing I2C scan. Example code works fine, but it was iffy with the scan.
Which I just realised has nothing to do with the lib, so it's not the same thing.
thorny jay
Within one or two minutes, I get a "bad packet" either because the signature is not what is expected, or the checksum is wrong.
Depending on the library or demo code, I can survive that, or it never recover.
idle owl
Ah, fair enough.
thorny jay
So I think I need to embed some of the logic to find the next packet into the library.
idle owl
Sounds like an ideal thing to add
thorny jay
Right now it might just read one byte, maybe generate an exception.
But I need to figure out the best way to do that in the library... I have a long week-end ahead, so I might spend more time on this.
idle owl
I'm working with it in the next couple of days, so I may be able to test things for you, but not over the weekend.
thorny jay
My ultimate goal is to have something "fail proof" that I can run four hours and record on an SD card the readings. Then keep in running at the office, or at home and get a clue about the air quality. If that works, then see if I can advertise that in BLE or push to AdafruitIO. But right now it will fail quickly.
My long week-end start on Friday. π And I am maybe 6 hours ahead of you in daylight/timezone.
I'll try to write simple test code and if you can run that for 5 minutes without a glitch then my hardware is the problem. If you have the same problem, then you would be able to review a PR if I do one.
Speaking of timezone, it is sleeping time here. Let's stay in touch.
idle owl
Sounds good! Have a lovely sleep!
silver tapir
@lone axle Do the checks on the pr look ok to you now? Githubstatus says it's all ok.
lone axle
Will take a look in one minute.
@silver tapir I still am seeing 0 checks on my end:
I think if you push another small change to something it may do them correctly now though that the status is looking better.
silver tapir
That is were it used to show the error, I think.
lone axle
yep, and to clarify a bit. I do think the previous error is now gone. But it doesn't seem like it ran successfully either. It looks like it just didn't try this time (likely due to the issues with github)
ordinarily this page should have something green and indicating success on it
and the "Checks 0" in the tab near the top should show "Checks 1"
And toward the bottom of the PR page it should have this thing:
silver tapir
Ok. I'm looking for a typo in the comments or something :)...
Yeah, it's in build ci now, it worked. Thanks for the suggestion.
lone axle
Nice looks good now. I will test it out tonight
silver tapir
@slender iron BTW, I was testing the new json on my pyportal and found a bug but not with your code but on the pyportal lib. (already fixed in a pr)
slender iron
k, great!
silver tapir
I'm also processing a local.txt, and there I am running out of memory. Tomorrow I'll probably add mm to it to see if I can process it better.
manic glacierBOT
manic glacierBOT
Adafruit CircuitPython 5.3.1 on 2020-07-13; Adafruit Feather M4 Express with samd51j19
The VL53L0X does not appear to return from shutdown mode. When SHDN has been brought low, and then high, the next read of the sensor will hang. See wiring here:
Code is:
Documentation at:
...
thorny jay
I have a suggestion of change for https://io.adafruit.com/ when you ask to see your "Adafruit IO Key", it show you code sample for Arduino, Linux Shell and Scripting. But maybe it should show the syntax for CircuitPython secret.py file.
I cross posted that on #help-with-wippersnapper-and-adafruitio channel
ionic elk
@onyx hinge are you online
Trying to figure out how to do this submodule PR trick, but I'm not finding anything online about it, and it won't compile locally either
tulip sleet
did you want to make a change in a submodule and then PR that?
ionic elk
No, my issue is that my current Circuitpython PR (for timer module) relies on a change to a submodule (protomatter) that is still in the PR stages
so it is impossible for my PR to pass CI, but I'm reluctant to just ask for the submodule to be merged, because my protomatter PR might also need further changes
@onyx hinge said I could actually make the submodule in Circuitpython point to a reference within a PR, so I could essentially link the version of protomatter I'm suggesting in my timer PR
tulip sleet
there's a commit for your PR in the adafruit repo for protomatter; if you git fetch the submodule, and then check out the PR commit, you should be sync'd up with your proposed change.
ionic elk
fatal: reference is not a tree: 4c8bed230392573a7104ebb11d77d8e895a71943
tulip sleet
did you pull down the latest commits for protomatter into the submodule
ionic elk
with git fetch? yeah
I also moved to the master branch and pulled, still can't check out PR commits
tulip sleet
ionic elk
But do you mean to imply that I can check out an unmerged commit on github? Because I thought you could only do that with git CI
Oh, I guess it's the same thing, with a new branch and all that
so I guess when the protomatter request does get merged, it'll break my Circuitpython PR
tulip sleet
Alternatively what I have done is to add my own fork as a remote in the submodule, and then check out my pr branch there
i find that easier to understand; i haven't done it from the PR
so the clone of the submodule repo inside circuitpython becomes my development area for the PR
ionic elk
I'll just use gh pr checkout ###
tulip sleet
i didn't know about gh; i've been using hub
ionic elk
@onyx hinge Looks like the merge of master into protomatter is causing all of the nrf boards to fail?
../../lib/protomatter/arch.h:1234 :11: error: unused variable 'clockMask' [-Werror=unused-variable] 1234 | uint8_t clockMask = core->clockMask >> (core->portOffset * 8);
onyx hinge
@ionic elk filing an issue at the protomatter repo is my recommendation
ionic elk
Ok, no problem. Wanted to make sure it wasn't something I had messed up
onyx hinge
possible change needed is something like ```-#if defined(_PM_portToggleRegister) && !defined(_PM_STRICT_32BIT_IO)
+#if defined(_PM_portToggleRegister)
+#if !defined(_PM_STRICT_32BIT_IO)
// core->clockMask mask is already an 8-bit value
uint8_t clockMask = core->clockMask;
#else
// core->clockMask mask is 32-bit, shift down to 8-bit for this func.
uint8_t clockMask = core->clockMask >> (core->portOffset * 8);
+#endif
#endif
as we experience more of these libs that are maintained externally to circuitpython devs, we will need to investigate technical aides to keeping up to date. For instance, we don't get warnings when the upstream repo has a new tagged release; and nobody is testing whether the releases build against CircuitPython... there's CI for microlab, mp3, and protomatter; but they only build against micropython (in the first case) and arduino (in the other cases), so we don't find these problems until late unless we go looking
circuitpython uses MUCH more strict compiler diagnostic flags than arduino
if you didn't MIND rolling this fix into your PR it'll probably make things come to a successful conclusion sooner
ionic elk
Yeah, no problem
lunar crown
@indigo wedge Are you still moving ahead with the iMXRT 1011 and/or 1062 projects, or have they been set aside?
indigo wedge
half and half, I want to move forward but I'm blocked by another board I wanna put on sale first to get funds to produce the Feathers
otherwise the 1011 design is done and verified, just need to produce and document
slender iron
@tulip sleet how quickly should I expect you to get back on PR reviews? aka, when can I bug you about it. re: https://github.com/adafruit/circuitpython/pull/3143
tulip sleet
@slender iron Sorry! I confused this with another PR that had seen very recent commits, and thought you were still working on it.
or was it failing the build before the force-push? Anyway, will review right now.
slender iron
I pushed to that branch last night. I forgot I made a PR for it already
and ya, those commits did fail
tulip sleet
@slender iron I thought this was the PR where you saw a big increase in small allocations instead of a few large ones, and that you still wanted to work on it. I'm confused, where is the allocations one?
slender iron
I haven't made one for the allocations yet
it's all esp32spi and requests. not core cp
tulip sleet
ok, I got those mixed up. I thought you were still going to revise the json PR because it was doing too many small allocations, but I wasn't paying attention enough. sorry
trim elm
@solar whale Is there any advantage for the DHT library to use pulseio instead of just bitbanging on the raspberry pi? It seems like it's causing a bunch of issues and bitbanging seems to work fine (at least from what I've seen from a few minutes of testing).
Pretty much every issue currently open on the DHT library doesn't present itself when bitbanging but does when using pulsio
solar whale
I thought it did use bitbanging on the Pi. Isn't that why it was added to the library?
trim elm
it can use bitbanging, but if pulseio can be imported, it uses pulseio, and since pulseio is in blinka, it always uses it
solar whale
ah -- OK -- I guess pulseio was added to blinka after that was set up. Is the problem only with the DHT or is there a bigger issue with blinka and pulseio? FYI -- I can't get bitbanging to work on an M0 board -- if I remove Pulseio.
In any case, I have no objection to using bitbang on the Pi, especially if it works better π
trim elm
So I think the issue is that we're not using it as a context manager and the process never gets exited, which I don't think causes any issues on circuitpython, but does cause issues on the pi
I'll add a check so it only tries importing pulseio on CircuitPython
solar whale
No objection from me but I still wonder if there is something with the pulseio implementation that needs to be looked into.
manic glacierBOT
solar whale
I would still leave it to use bitbang if pulseio does not exist -- even in CP
you can just ignore pulseio on the Pi if you want to.
tulip sleet
is something running as a separate process that hangs around after the main script is running? It could possibly be made dependent. This is a stretch, but the Python threading stuff can prevent a process from exiting, but if you set the thread to be a "daemon", then it exits quietly when the parent process tries to exit. Maybe there is something similar that could be done here? (I assume it's not a thread.)
solar whale
@trim elm in regards to your original question, I think there IS an advantage to to using Pulseio, but only if it works...
trim elm
@tulip sleet Yeah, that's what some people in github think the issue is, and I'm pretty sure they're right. Do you know how I would go about doing that? I know that atexit isn't in circuitpython, and having __exit__ run would require it to be run in a context manager.
tulip sleet
you call call __exit__ explicitly
trim elm
Ok
tulip sleet
you might need to catch any exceptions it throws, but I think that might work
trim elm
Yeah, that's what I'm thinking would be the best way
And the example already has a try/except, so it wouldn't be that big a deal
solar whale
good -- better to fix the root cause than to implement a workaround!
lapis hemlock
@onyx hinge Jeff, in case you want to comment: https://github.com/v923z/micropython-ulab/issues/137
Once the code itself is accepted, I will add the stubs, so you won't have to trouble yourself with the documentation.
ionic elk
@onyx hinge so, what's the target frequency on the RGBMatrix again? I see there's no prescaler set, so it's running at 168MHz, and you have the period set to 1000 so I'm guessing it's at 168kHz unless you set it again elsewhere?
onyx hinge
@ionic elk the arduino code from long ago shows an overall refresh rate of either 150Hz or 250Hz, but that's displaying multiple planes. Each plane is shown a different length of time, based on powers of 2 I think
and then there's the scanning of the rows of which there are 8 or 16 row-pairs
ionic elk
Oh nevermind, it's because TIM6 maxes out at 42MHz
onyx hinge
different timers have different capabilities?
ionic elk
Dang I probably do need to program that in somewhere
yeah it all kind of depends, as is typical for ST
every chip has a different frequency, buses have different max frequencies, different timers land on different buses depending on the chip line
onyx hinge
you'd have to double check my math but to get an overall refresh rate of 250Hz with a depth of 5 (= 32 brightness levels) and 16 line-pairs your interrupt will need to be something like 250HzΓ32Γ16 = 128kHz
ionic elk
I might need some kind of minimum frequency parameter in my timer setting system
onyx hinge
this is for sure an "Ask Dragon" question, my answers are only what I can infer
or maybe that's a depth of 4, so 64kHz ? I don't know. I know the examples/protomatter/protomatter.ino printed a number close to either 150 or 250 when I ran it on M4 at the very beginning
// around 250 Hz is where things firm up. And while this could proceed higher
// in some situations, the tradeoff is that faster rates use progressively
// more CPU time (because it's timer interrupt based and not using DMA or
``` in the Arduino codealso not every interrupt is the same period of time .. successive color planes each are given twice as much time, so you might have one interrupt that is 7.8us, one that's twice that so 15.6us, and so forth.
A 48MHz clock should be plenty to count at if you need to measure out 7.8us, your counter top/bottom/max/preload/whateveritis-in-stm32 would be 374 or something
ionic elk
@onyx hinge Ok, I think my timer PR is basically done! I tested the RGBMatrix and it's still kind of broken and fuzzy, but not anymore than it was already for me. I just got my USB cable in for the ESP32S2 so I might push the fix for RGBMatrix behind ESP32 PulseIO for now.
trim elm
@solar whale If you'd like to, and if you have time, it'd be really great if you could test my branch of DHT. For the life of me, I can't figure out why pulseio can't find libgpiod, so I can't test the pulseio version, but the bitbanging approach seems like it's still working fine. Just note that I did add a parameter where you can disable using pulseio when you initialize the DHT22 object, so you will have to change that to test the simpletest with pulseio. https://github.com/adafruit/Adafruit_CircuitPython_DHT/pull/46
solar whale
@trim elm I should be able to try it tomorrow.
trim elm
Awesome. Thanks
onyx hinge
@ionic elk excellent .. still wish we knew what was going on with your setup. I should test again over here... but don't seem to find the time.
idle owl
@lone axle You working on any library code at the moment?
lone axle
No, not at the moment.
idle owl
Fair enough. Thanks. I'm trying to decide which library to move to main first, and figured if I'm going to rock somebody's git world, it might as well be yours. π
I figured you'd be up for following instructions to make sure I'm clear on explaining how to update.
lone axle
Heh, yep I am up for that.
I will be out for a bit this evening but I'd be happy to try it out when I can.
idle owl
@lone axle I more meant if I changed a lib you were working on out from under you, you could see if my instructions are clear enough for updating. But I'll let you know if/when I need someone to test things.
lone axle
Ah, I see.
onyx hinge
I don't know what that is but I like it when you speed things up ποΈ
lone axle
@idle owl as fate would have it I did end up working on the display_text library a bit tonight. I have a draft PR that needs to be finished up and have some more testing still before it's ready. I can try out your instructions on that if you want.
I'll be getting back to it tomorrow night.
manic glacierBOT
trim elm
In the latest versions of chrome 83 and 84, files with .uf2 extensions appear to be blocked from being downloaded. Hopefully this will be resolved soon, but in the meantime, you can get around it by going to settings -> Privacy and Security -> security, and turn on 'No protection' while you download the files.
idle owl
@lone axle It would need to be pre-PR. Coincidentally, I was going to do Display Text, it turns out, but held off, and now in your process wouldn't be a good time. Thank you for letting me know though.
idle owl
@tulip sleet @onyx hinge Ok, so how did things go when you moved CircuitPython from master to main? I was thinking about it this morning, and realised that all existing forks will have to be updated, right? I don't need to know how to move to main, I want to know what miscellaneous steps you had to follow once CP was moved, if you remember.
onyx hinge
Scott did all the legwork on github. It doesn't do anything to existing forks, but that didn't affect me as I don't use the branch called "master" in my own fork; I think other people may work differently.
idle owl
Hmm fair enough.
onyx hinge
One thing Scott did that I wondered whether it was automated: fixing pull requests so that they were to the new "main" branch
idle owl
That one I think I know how to do, I think it's part of the instructions I have. But I'm uncertain.
onyx hinge
yeah I am sure it can be done manually at any rate
if there's a script for updating PRs I'd love to run on some repos for software I maintain
idle owl
I'll have to ping Scott then. I thought I had everything he did, but it sound like I don't.
onyx hinge
He may have done it manally, the number of PRs is relatively small
idle owl
Seems likely.
And not feasible in my case long term.
@slender iron When you're around, I have some questions about moving from master to main.
slender iron
@idle owl I'm around now
idle owl
Hello. I'm following Scott Hanselman's post, but I feel like there's more to it than that. What else did you have to do?
slender iron
change the default branch in github settings
idle owl
Right.
slender iron
update all pending PRs to be against main and not master
idle owl
Ah ok
slender iron
I copied the branch protections from master to main
and set master to requiring 5+ approvals after we accidentally merged to it π
slender iron
also need to check any CI stuff that may have a branch restriction
idle owl
@slender iron Hmm do we have a lot of that?
slender iron
not sure, lemme grep
slender iron
@idle owl looks like readme.rst has a link to the CoC in master
slender iron
np, just grepped the bundle for master
idle owl
That's good, didn't think there would be an issue, but good to check.
slender iron
π
manic glacierBOT
idle owl
@slender iron Remembered my other question - what happened with your fork? Or because you made the change from your local setup, you didn't run into issues with your fork not being updated?
I mean, what will happen to others who don't know to update and try to PR to a lib with main
slender iron
I don't keep my main branch of my fork updated
idle owl
Jeff doesn't either. You're no help! π
idle owl
Yeah that's what all my research said
Or rather, indicated. Nothing said it explicitly.
slender iron
people do need to know to start from main rather than master
otherwise they may need to rebase
idle owl
The guide is being updated. But that doesn't mean people will read it.
manic glacierBOT
slender iron
yup
we could delete the master branch which should cause an error if they try and update it
but I left it for core
idle owl
Any reason not to delete it? I mean, I did the -m so it kept things into the main branch. Might be worth throwing the error. Either that or we'll spend the next year pointing people's PRs to main and pointing folks to the guide. Which is also a viable solution.
There will be growing pains regardless.
slender iron
I'm fine trying it
only one way to find out how it'll work π
we can always add it back
idle owl
Yep. I have Dylan working with a open PR right now, so I guess we'll find out how that goes down.
I was going to wait, but better to have something fail hard on Dylan than someone new.
slender iron
haha, ya π
orchid basinBOT
idle owl
@slender iron Did you run this? git symbolic-ref refs/remotes/adafruit/HEAD refs/remotes/adafruit/main
slender iron
I didn't
idle owl
Ok, neither did I. I'm not entirely sure what it's doing. The explanation is "update the default branch to be (adafruit)/main" but I don't follow entirely.
slender iron
ah hrm
idle owl
It's for updating your "local clones".
orchid basinBOT
slender iron
it must not be part of my workflow
idle owl
I'll have Dylan run through things and see if he needs it.
slender iron
kk
when I start a new branch I always checkout git checkout adafruit/main first and then create the branch
idle owl
That's what I said to do in the guide. And what I do as well.
Adding instructions on moving your local clone from master to main though, in the guide, and am not sure about that last one.
About to find out! π
slender iron
ya, I'm not sure what that means. does it mean updating your own github fork?
slender iron
ya, I think I okayed it
idle owl
Ok.
slender iron
similar things happen when folks rebase
idle owl
Ah fair enough.
onyx hinge
@slender iron did you get your json "readinto" to work?
tulip sleet
i merged it yesterday
onyx hinge
There was a problem where sockets didn't actually have "readinto"; that's what I'm wondering about
tulip sleet
That I don't know, but sockets are being Pythonized, so it could be added? But Scott can answer authoritatively.
onyx hinge
looks like esp32spi sockets are a bit of distance from that at the moment, I don't know if the work scott's been doing is with esp32s2 or esp32spi
I added support for "objects with readinto" to mp3 playback but it also can't work with current esp32spi
onyx hinge
https://github.com/jepler/circuitpython/tree/mp3decoder-readinto I'll leave this as a branch without a PR since it's untestable
tulip sleet
or make it a draft PR?
onyx hinge
If I understood right, Scott prefers I don't do that, so that draft PRs don't clutter up the pull request tracker.
tulip sleet
I didn't know that; I think a draft is good because it's easy to find. If we are counting them wrong we can change the counting code. But I'll leave it to thim.
tulip sleet
@onyx hinge In the background PR, the intention is that the whole callback list be gc'd, right?
onyx hinge
yeah I think the problem scott pointed out is real
every pointer on the list should have its "data" pointer included as a valid GC pointer
I got bogged down thinking about how/whether to use the critical section macro in this list traversal
tulip sleet
I agree, makes sense. At first I though you only wanted to gc the head of the list, and I knew it would walk the whole list. btw, do you use the prev ptr? I don't know why it's a two-way list
so you can remove a middle easily?
onyx hinge
hm originally I did have a "remove callback" call but I didn't end up using it
+ // We don't enter the callback critical section here. We rely on
+ // gc_collect_ptr _NOT_ entering background callbacks, so it is not
+ // possible for the list to be cleared.
+ //
+ // However, it is possible for the list to be extended. We make the
+ // minor assumption that no newly added callback is for a
+ // collectable object. That is, we only plug the hole where an
+ // object becomes collectable AFTER it is added but before the
+ // callback is run, not the hole where an object was ALREADY
+ // collectable but adds a background task for itself.
+ //
+ // It's necessary to traverse the whole list here, as the callbacks
+ // themselves can be in non-gc memory, and some of the cb->data
+ // objects themselves might be in non-gc memory.
background_callback_t *cb = (background_callback_t*)callback_head;
- gc_collect_ptr(cb);
+ while(cb) {
+ gc_collect_ptr(cb->data);
+ cb = cb->next;
+ }
}
here's what I've got at the moment that I'm ruminating on
I do end up using prev, only to detect whether an item is inserted in a list. A bit weird. ```void background_callback_add_core(background_callback_t *cb) {
CALLBACK_CRITICAL_BEGIN;
if (cb->prev || callback_head == cb) {
CALLBACK_CRITICAL_END;
return;
("cb" is an interior pointer within an allocation, never it own allocation; so directly gc_collect_ptr()ing it doesn't really make sense)
tulip sleet
The gc will walk the next and prev pointers if they point into heap space, but are the objects not in heap space?
onyx hinge
I think for the most part the objects are in the GC heap but not always.
and some of the data pointers are NULL
supervisor/shared/usb/usb.c: background_callback_add(&callback, usb_background_do, NULL);
``` these don't really have objects that they act on per seI asked the q above because I was writing up a comment about this very thing, thinking that you might unintentionally gc the non-head, but that's what you want
so the code above makes sense to me
onyx hinge
``` this one is non-heap data, it's global static datait is okay to pass such pointers to gc_collect_ptr, or not?
calls gc_mark, which ```// Mark can handle NULL pointers because it verifies the pointer is within the heap bounds.
STATIC void gc_mark(void* ptr) {
if (VERIFY_PTR(ptr)) {
yes, we pass statically allocated ptrs to gc all the time, to gc the things those objects hold
onyx hinge
gc_collect_root would scan for pointers within a block
but head->next->next->data wouldn't get scanned just by gc_collect_ptr(head) would it?
specifically if head->next is NOT itself heap memory
tulip sleet
that's right, you're right, I was thinking they were on the heap
onyx hinge
``` is the example where the data pointer `dma` and the callback itself `dma->callback` are both static data@onyx hinge esp32spi.socket will have recv_into
requests will create a file-like wrapper for it to pass to json
I'll try and push all my changes today during my stream
onyx hinge
@slender iron cool, I'll revisit that code when esp32spi.socket is upgraded.
onyx hinge
dunno if it'll work out, vis a vis the speed of esp32 at transferring data, it'll be fun to see though
do you think I should write the core code to check recv_into and readinto both, then?
slender iron
I chose not to because recv_into isn't standard
and it's not hard to wrap
socket is just an old api I think
onyx hinge
Thanks for the reviews and help @tulip sleet @slender iron
idle owl
@lone axle There's not a lot that changes if I move to main in the middle of your PR, but it borked another PR so I'd rather not risk breaking your PR. I'll consider moving the lib once your PR is merged.
Thanks for offering to be a test subject - Dylan ended up there today. π
lone axle
Okay sounds good. I'll be working on that here in a bit tonight. I'll try to get it finished and ready for review tonight. But might not make it until tommorrow. soon(tm) either way.
idle owl
No worries. Nothing will be happening until at least next week. And then I'm uncertain what our overall plans are.
We're doing this slowly. Which has its own challenges, but it is what it is.
@lone axle I will still appreciate you looking at the updated guide - it's not finished yet because I realised the GitHub UI update and our move to Actions rendered a bunch of it out of date. So I need to decide what to do there. And document one more thing about the move from master to main before that bit is done as well. I'll let you know when I'd like another set of eyes on it
Anyway, heading out for now. Cheers!
lone axle
okay sounds good to me. See ya! have a nice night.
manic glacierBOT
manic glacierBOT
lone sandalBOT
low sentinel
Anyone object to removing displayio.Shape in 6.0.0? I don't think anyone uses it.
vectorio is probably better anyway
@slender iron It's used for bitmaps right? I think it might could be collapsed together?vectoriois better than Shape for most cases, and for simple shapes like rectangle and circle it is basically as fast as a bitmap; but for things like theadafruit_display_shapeslibrary there is some tradeoff to consider betweenO(n*m)memory and computing pixel winding numbers (for polygons). Butvectoriois not available everywheredisplayiois on account of small controllers' memory running out.
Tangentially related, I had thought about reimplementing RoundRect as 4 circles and 2 rectangles. Due to the draw masking that displayio does, I think it would be almost indistinguishable speed-wise from the bitmap and require O(1) memory for any sized RoundRect.
Your allocation optimization work is β€οΈ. I can't wait to use the new stuff, but my next foray into cpy c code will probably be getting async/await up to CircuitPython acceptance standards.
manic glacierBOT
onyx hinge
@low sentinel thanks for sticking with async. Consider attending a weekly meeting so we can discuss what Tannewt wants to see. If we have general agreement (about how the user code will look, for instance) before you do a lot more coding, that helps when we get to the PR review step. It's up to you but voice chat can often help conclude these discussions faster.
(wow a lot of activity overnight!)
lone axle
is vectorio new-ish? I don't think I've seen that before. Also not sure that I have ever run across displayio.Shape before is there code somewhere that shows how that could be used?
onyx hinge
@lone axle yeah I think vectorio is new in main and not in 5.3.x.
lone axle
Is this behavior expected?
>>> i = 0.0
>>> while i < 1.0:
... i += 0.05
... print(i)
it outputs as expected up to 0.5 and then seems to get off somehow:
0.45
0.5
0.549999
0.599999
Without the loop it doesn't seem to have the same issue:
>>> p = 0.5
>>> p += 0.05
>>> print(p)
0.55
same in CPython -- just the nature of floating point, I think ```IndentationError: unexpected indent
while i<1.0:
... i = i +.05
... print(i)
...
0.05
0.1
0.15000000000000002
0.2
0.25
0.3
0.35
0.39999999999999997
0.44999999999999996
0.49999999999999994
0.5499999999999999
0.6
0.65
0.7000000000000001
0.7500000000000001
0.8000000000000002
0.8500000000000002
0.9000000000000002
0.9500000000000003
1.0000000000000002
I see, interesting. I will play with it some, maybe counting with ints and then dividing could be better
solar whale
There is no loss of precision,, just some numbers cannot be represented exactly in Floating point
never test floats with ==
honest dust
The way to avoid things getting out-of-whack because of this is to do: value = i * 0.05 and let i go from 0 to 20.
So don't add small float values up in a loop, but always compute the value based on the current loop index.
lone axle
Thank you matthijs
onyx hinge
That's a very good suggestion @honest dust !
onyx hinge
Usually with these kinds of loops, you can convert it from thinking about fractions instead of decimal numbers. Loop over integers which give the numerators and divide by the denominator. Then you'll get equally spaced values and a minimum of floating point misery. You still can't have exactly 1/3 or 11/20 but you'll get the right number of values within the range you want, and they'll be as accurately spaced as possible
(i / 20 and i * .05 being approximately the same)
solar whale
approximately ??
honest dust
The general formula is x = start + (end - start)*step_size*i where i is your counter.
There is no 0.05 in floating point math, @solar whale
Only an approximation π
solar whale
as shown above
honest dust
Only integers are exact in floating point math (up to 2^54 or something).
Maybe I should write the formula as x = start + (end - start)*i/num_steps where i goes from 0 to num_steps.
main meteor
Some specific fractions are exact in floating point math, but many are not.
solar whale
and fractional powers of 2 (.5,.25...)
honest dust
Fair enough π
lone axle
Is there a "proper" place for examples of things that are builtin to the system like vectorio? if it were a library there would be simpletest and perhaps some others in the examples folder, but as part of the system I'm not sure where those would be.
lone axle
Is there a particular folder inside of tests that would make the most sense for vectorio? or would creating a new one be the right thing to do? https://github.com/adafruit/circuitpython/tree/main/tests
crimson ferry
I'd anticipate a vectorio Learn guide at some point
lone axle
I look forward to it! having no luck figuring out how to use it and I couldn't find example code anywhere
crimson ferry
https://learn.adafruit.com/circuitpython-essentials/circuitpython-essentials has many of the widely used core modules, but not all (e.g., not displayio)
lone axle
In an older newsletter I found this blurb:
The vectorio library builds on an Feather M4 Express and draws concrete shapes are composed into a VectorShape, which is put into a displayio Group for display
But if I create a Rectangle and try to add it to a group I get this error:
ValueError: Layer must be a Group or TileGrid subclass.
crimson ferry
circle, polygon, and rectangle don't have (x, y), so I wonder if you have to have a vectorio.VectorShape to anchor them
lone axle
Ah, I got it packed inside of a VectorShape now and It did draw something to the screen. But it's only two sides of the rectangle.
This code: https://gist.github.com/FoamyGuy/e80df20ec7d2061b9d8b8be5660351b0 results in this
If I add a second color to the rect palette I see more get drawn:
rect_palette = displayio.Palette(2)
rect_palette[0] = 0x0000FF
rect_palette[1] = 0xFF0000
vector_shape = VectorShape(shape=rect, x=10, y=10, pixel_shader=rect_palette)
hm what if you
palette = displayio.Palette(2)
palette.make_transparent(0)
color_palette[1] = 0xFFFFFF
oh, Circle and Rectangle are polygons, some mathematicians might disagree π
low sentinel
What makes you think they are polygons?
lone axle
@low sentinel is palette index 0 of the shapes palette (rect_palette in my example) supposed to be the outline of the shape? or is it meant to only be on the top and left sides?
low sentinel
no, what's happening there is the shape's invalidation box is supposed to be filled with transparency. If the pixel shader expects to return a color for index 0 I believe it's drawing a strip of bounding box (rather than transparency)
that is too subtle a sharp edge and needs to be rounded off.
lone axle
Ah.
low sentinel
I had some ideas about extending color utilities in vectorio so I left this a little raw to not design the api into a corner
tragically, a corner is all you drew
crimson ferry
so to speak π
lone axle
I was able to get a red rectangle showing like this:
rect = Rectangle(319, 239)
rect_palette = displayio.Palette(2)
rect_palette.make_transparent(0)
rect_palette[0] = 0x0000FF
rect_palette[1] = 0xFF0000
vector_shape = VectorShape(shape=rect, x=0, y=0, pixel_shader=rect_palette)
splash.append(vector_shape)
rect_palette.make_transparent(0)
rect_palette[0] = 0x0000FF
is surprising
but π€· if it works
crimson ferry
Circle and Rectangle are accepted as polygons in class vectorio.VectorShape(shape: vectorio.Polygon, pixel_shader: displayio.Palette, x: int = 0, y: int = 0)
lone axle
Interestingly the blue outline on the top and left is outside of the shape. If I put the shape at 0,0 I don't see the blue line
@low sentinel do you have any sample code that shows usage of the module?
low sentinel
@crimson ferry then I did a bad in the documentation. They're absolutely not vectorio.Polygons
crimson ferry
This is cool. Need to grok the paradigm, just like starting with displayio, but then pretty powerful!
low sentinel
@lone axle give me a few minutes and I'll clean up an old example I used for testing. It kind of showcases the strengths and weaknesses of vectorio and drawing dynamic vector shapes on microcontrollers without graphics hardware (like EVE2 or whatever)
crimson ferry
a lot faster too than the display-shapes library I'm guessing
low sentinel
Faster was a non-goal. I hoped to match the bitmap implementation's speed only.
Memory usage is where vectorio shines
lone axle
My intention is to ultimately see if it would make a better solution for the ProgressBar library. Currently it's using a bitmap and filling pixels with x,y for loops.
low sentinel
and, well I guess initialization speed and mutation speed
oh you'll probably have a better time with a vectorio.Rectangle and just adjust its width property.
or you could use polygon and adjust its right side. That way you don't have to compute positioning on update, only width.
in either case you would not need a fixed 2d array of pixels allocated.
lone axle
How do you change the width of rectangle?
I tried like this:
rect.width = 100
but got this error:
AttributeError: 'Rectangle' object cannot assign attribute 'width'
Looking at the docs here: https://circuitpython.readthedocs.io/en/latest/shared-bindings/vectorio/index.html it doesn't list width or height property under Rectangle
low sentinel
welp looks like another bad. I spent more effort on polygon and circle than rectangle tbh; I faintly remember a reason for keeping rectangles of fixed size but that reason (if it exists) is lost to me now.
lone axle
Okay. Thank you. I really appreciate your help and insight! I'll tinker around with Polygon. I would love to see a repo of examples or a learn guide for this module get created.
or maybe a new page within the displayio guide
low sentinel
this old vectorio test uses async/await and a whole bunch of debug tooling I made. It's going to take me a few minutes yet π
lone axle
No worries, no rush on my end. With what you've given me so far I was able to get it drawing as expected so I can do quite a bit more tinkering on my own now as well.
Thank you for creating this module btw as well. I somehow missed this when it first got merged in.
crimson ferry
It is faster and better memory use... display_shapes circles in similar code only gets a few hundred and there's remaining memory but it's too fragmented to allocate; vectorio gets to 1600+ with 0 memory remaining https://gist.github.com/anecdata/767d29f287110828dbd33707ee85bb59
interestingly, hitting 0 free memory gets an exception, but no error text MemoryError:
stuck elbow
@crimson ferry that's intentional, there is no room to format the message
low sentinel
@lone axle here's a complete animated example https://github.com/WarriorOfWire/circuitpython-utilities/blob/master/examples/vectorio_example.py
lone axle
Thank you!
fringe ginkgo
Specifically, can't get past the adafruit_bme280 import. Is this a known problem?
lone axle
@fringe ginkgo I believe it is a known problem. The non-express M0 devices like the M0 RFM9x's have very little memory. Over time the core system and libraries have grown a bit and I think they no longer fit. I believe jerryn is working on optimizing the size to try to get it to fit, or perhaps looking into different sensors with smaller libraries.
fringe ginkgo
ok. Suspected this was the problem.
lone axle
In general though those M0 devices are going to have very little left over after the radio library. Its probably best to try to get an M4 if you can. I don't think there is a "all in one" feather M4 but there are Lora breakouts by themselves or on featherwings that can work with a variety of M4 devices.
fringe ginkgo
Thanks @lone axle I do have an M4 and an RFM95 to attach to it. Had hoped to use the combined M0+RFM9x to drive a simple sensor network. Not clear if I can do anything now with the M0+RFM9x.
solar whale
@fringe ginkgo I am working on a build for the feather_m0_rfm9x that has the rfm9x library βfrozenβ into the build. That greatly reduces the RAM needed. It is still a βwork in progressβ some other modules have to be removed and I am struggling to make it fit. I donβt have an ETA. I would recommend using Arduino for the M0_rfm9x board. The RadioHead library works well and there is plenty of RAM under Arduino.
solar whale
@stuck elbow yes - I also need to take out pulseio but then the DHT sensors donβt work and they are popular....
I was hoping to use bitbang for the DHT, but it is not working....
solar whale
Iβd be happy to just give up the DHTβs many better choices.
stuck elbow
I assume you already removed usb_midi, touchio, pixelbug, neopixel_write, apa102, audioio and samd?
solar whale
I was hoping to preserve neopixel_write, but it may have to go and keep pulseio.
stuck elbow
also audiomixer
solar whale
I think that is gone already. Will check tomorrow.
lone axle
I've run into a really strange situation that I do not understand. I am working on converting the progress bar library to make use of vectorio polygons instead of holding a bitmap. I mostly had to change the constructor and the progress property. The constructor seems to be working properly. Here is the code for the progress property: https://github.com/FoamyGuy/Adafruit_CircuitPython_ProgressBar/blob/a531e9e55cab0aa62a5d5f35f4e9a5c11d10e336/adafruit_progressbar.py#L148
using this version of the library If i set the progress like this:
progress_bar.progress = 0.5
progress_bar.progress = 0.85
progress_bar.progress = 0.35
time.sleep(0.02)
progress_bar.progress = 0.1
The last change will not have any visual effect. The bar is stuck at 35%. There is a debugging print statement inside of progress property and it does print out the proper points of the polygon, but visually it doesn't change on the screen. If I change the sleep time like this: time.sleep(0.01) then I will see the last progress change take effect. The bar will properly go back down to 10% visually on the screen.
How could sleeping 0.02 vs. sleeping 0.01 before a particular action affect whether the action is working successfully?
Interestingly if I remove the ProgressBar class from the equation and just use a vectorio Polygon directly I am able to update the points while utilzing sleep:
for i in range(50, 150):
rect.points = [(0,0), (i,0), (i, 30), (0,30)]
time.sleep(0.1)
This is the same basic approach that I am trying to use inside the progress property but for some reason it's behaving differently
fringe ginkgo
Thanks @solar whale Will go with Arduino but keep an eye out for your frozen lib solution.
onyx hinge
@lone axle 5.3.1 or main? If it's main-only then it may be a problem I created with recent changes. If it is newly broken, for sure file an issue.
probably file an issue either way. I guess we discussed that vectorio wasn't in 5.3 so maybe it's not easy to determine whether it's new or not
ivory yew
hmmm I want to change how CircuitPython talks to the ADC just for Big Honking Button. I'm trying to figure out how to do this with the least amount of surgery to anything outside of the boards/winterbloom_big_honking_button.
I thought of making common_hal_analogio_analogin_get_value weak so that I can create a new implementation in board.c.
Or maybe exposing a custom get_value function defined in board.c.
lone axle
@onyx hinge its on 6.0.0 i believe. I will try a few other versions in the morning and create an issue
manic glacierBOT
solar whale
@fringe ginkgo If you are interested in it, I do have an experimental build and you are welcome to try it with the caveats that it is totally unsupported (Adafruit has not endorsed or approved it). Several modules have been removed (analogio, pulseio (no DHT sensors), neopixel_write, hid, midi and more) It does work with the bme280 sensor and should be OK with most I2C devices. Let me know if you want to try it and I can post a .uf2 file here. It's also fine if you prefer to wait for something more final ... this version will most likely not be released.
adafruit_rfm9x and adafruit_busdevice are "frozen" into the build so they should not be loaded onto the file system
lone axle
@low sentinel I found some strange behavior with Polygons β¬οΈ I'm not really certain if this is an issue inside of vectorio or something larger within Circuit Python. If you have a second to take a look some time I am curious if anything jumps out to you as immediately problematic about the way I've attempted to use Polygons in the example from that issue.
manic glacierBOT
thorny jay
Remember that I have issue of creating up to date set of file for specific board or learn guide. I want a quick way to update the library I use in a consistent way. Here is a python script I use on Windows to copy the file and folder I want from lib to PyPortal/lib : https://gist.github.com/dglaude/f5f3423288861bc44fe758212dbaac61
Now what I need is a format and place to store the list of file/folder needed. Maybe some json file per project that I would read from.
wooden nest
Cool snippet!
Have you tried using pathlib before? It makes path handling much easier
thorny jay
Thanks, did not knew about pathlib. I'll have a look.
wooden nest
I find this article on RealPython really helpful: https://realpython.com/python-pathlib/
Hello, world!
If you are bored, have a PyGamer/PyBadge (Both types should work)/EdgeBadge, and have CircuitPython (recent version) loaded on it, you can try out my program.
It's a text editor.
Make sure that you have a text file on the FS called text.txt (It should have some text on it so that you can write to it - I think)
Also make sure that you can someone enable write access to the FS from CircuitPython (I use this program - press any key within 2 seconds and the FS will be writeable from CircuitPython)
boot.py
import storage
import time
import ugame
print("Press any key to enable writing to the file system from CircuitPython!")
time.sleep(2)
buttons_pressed = ugame.buttons.get_pressed()
if buttons_pressed:
storage.remount("/", False)
print("File system is now >>>writeable<<< from CircuitPython (Exposed drive is read only now)!")
else:
print("File system is now >>>read-only<<< from CircuitPython (Exposed drive has write access)!")
time.sleep(1)
And here's the text editor, put it in code.py:
CircuitPython Text Editor for PyGamer/PyBadge/EdgeBadge
(Sorry, I have to put it in a file. There is over 6.6K characters in it!)
Alternativly, heres a link: http://txt.do/1geg3
You should not need to install any modules in lib.
It's kinda similar to nano, where you have a block cursor, and move around with the d-pad/joystick if you are in read mode. Press B if you are in write mode to go to read mode. To go to write mode, press A. You will see at the bottom, you can use the up/down buttons/joystick to select a character. Press A (in write mode) to write that character. You can still move left/right in both modes. (It's a little glitchy) Press Start for a newline and Select for backspace. You will need some practice if you want to achieve 1WPM ;)
I'd appreciate any feedback! (I hope this is the correct channel to post this in!)
manic glacierBOT
low sentinel
@lone axle if you can produce a more focused repro example for the other issue that would be ideal. I'm setting up my development environment for circuitpython core again.
lone axle
Okay thank you. I will see how far break down the other
low sentinel
I can't believe I did vectorio entirely in vim. VS Code + WSL2 is the only way to develop on windows. (i have to have windows because of my day job)
lone axle
The thought of using only vim for something like this makes me dizzy π₯΄
I stick to Mu and PyCharm mostly. "One of these days" I intend to try to replicate some of the neat tools that have been made for VSCode over to Pycharm.
I do think that on the other issue I am conflating a few things together. I'm going to close that and I think I can make a much more focused one shortly on at least one of the actual things that was the root of my trouble.
lone axle
@low sentinel While playing with this a bit more I noticed the docs for VectorShape https://circuitpython.readthedocs.io/en/latest/shared-bindings/vectorio/#vectorio.VectorShape say that x/y position is center point of the shape within it's parent. But it behavior is top left point instead of center I think.
low sentinel
it depends on the shape actually.
a polygon's axis is at (0, 0), which lets you get really creative with positioning and orientation.
lone axle
Ah, Circle is probably in the center then? I haven't played with that one as much yet.
low sentinel
A circle's x/y position is its center yes
>>> from vectorio import Polygon
>>> rect = Polygon(points=[(0,0), (100,0), (100, 30), (0,30)])
20002f00 polygon_construct
polygon_points_list len: 4
>>> rect.points
20002f00 vectorio_polygon_obj_get_points: len: 1393, items: 571
this is a cool bug.
i'm embarrassed to have missed it tbh.
manic glacierBOT
low sentinel
#define c(f) compile_##f
π
manic glacierBOT
turbid radish
?serverinfo
digital shoreBOT
adafruit
onyx hinge
@lone axle thanks for setting me on the trail of this, I did find a problem that would have vexed a lot of users as a result of investigating it
lone axle
! happy to catch it, I figured somehow my PyPortal had gotten weird. It also started doing the "Find and Fix Errors on this drive" pop-up in windows recently.
FWIW I was noticing the freezes happening when I went to REPL. I would spam ctrl-C several times and would get about 3 or 4 instances of >>> before it became unresponsive.
lone axle
Is there a relatively easy way via git magic to bring in some remote changes from a different repo in order to make a build of Circuit Python, but do it inside of my existing workspace that already has submodules sync'd and updated etc...?
or is it best to just clone the whole new one and start fresh with everything in it?
stuck elbow
@lone axle check out the cherry-pick command
lone axle
Will do thank you!
drowsy geyser
@ionic elk I closed the issue about the heap error when using Airlift on the STM32. 5.4.0-beta.1 fixed it. Should I be going to 6-alpha yet?
manic glacierBOT
slender iron
@slender iron It's used for bitmaps right? I think it might could be collapsed together?
vectoriois better than Shape for most cases, and for simple shapes like rectangle and circle it is basically as fast as a bitmap; but for things like theadafruit_display_shapeslibrary there is some tradeoff to consider betweenO(n*m)memory and computing pixel winding numbers (for polygons). Butvectoriois not available everywheredisplayiois on account of small controllers' memory running out.Tangentially related, I had thought about reimplementing RoundRect as 4 circles and 2 rectangles. Due to the draw masking that
displayiodoes, I think it would be almost indistinguishable speed-wise from the bitmap and requireO(1)memory for any sized RoundRect.
@low sentinel I think the shape library just uses bitmap and never displayio.shape. displayio.shape is weird because it's two values per pixel row plus mirroring
manic glacierBOT
slender iron
@ionic elk I closed the issue about the heap error when using Airlift on the STM32. 5.4.0-beta.1 fixed it. Should I be going to 6-alpha yet?
@drowsy geyser Ya, use the alpha. It's only alpha so we can break APIs. It should be stable
we'll pretty quick through beta to rc
onyx hinge
I hope so! The background task list stuff could sure use some testing. foamyguy ran into an issue and it was super helpful to have his feedback.
@slender iron do we need to talk about whether the next release is alpha or beta In The Weeds?
or if you think "alpha" then I don't have anything to talk about π
slender iron
Β―_(γ)_/Β―
I don't usually take it too seriously
I'd say alpha if we think APIs will change
tulip sleet
alpha usually means feature-incompelte
slender iron
beta otherwise
tulip sleet
what scott said
onyx hinge
Fair enough, I'm convinced
slender iron
(I could go straight to rc if you are confident about background stuff)
onyx hinge
haha no
slender iron
kk π
let's plan on doing a release of some sort this week
so it can soak in an unstable release
onyx hinge
@slender iron if you want to 3-2-1 me for meeting recording that would be nice
modern wing
Good afternoon all you wonderful CircuitPythonistas -- happily lurking for today's meeting. The doc has been updated to reflect that.
lapis hemlock
I am also lurking today.
turbid radish
Lurking but here
onyx hinge
<@&356864093652516868> We're coming up on the meeting in just a few minutes. If you will be "lurking", please let us know. If you can add your info to the notes doc that's super helpful
idle owl
onyx hinge
brb
solar whale
Is there a known issue with using the SD card (or SDCardio) driver on the STM32f405 -- it's come ups a few times in discussion but I don't see an issue for it. SHould I recheck and open one?
solar whale
no not the built in -- I mean a breakout
onyx hinge
a wild Mr. Certainly speaks
then no, there's no issue because it should just work π
solar whale
OK -- last I tried, it did not. will retry and open if reproducible.
onyx hinge
Thank you!
idle owl
@timber mango Are you lurking (listening in) today?
onyx hinge
I haven't tried it myself but I have some adaloggers so I should
solar whale
It was an adalogger I tried. And a breakout IIRC.
onyx hinge
https://www.adafruit.com/product/2922 I'll try with this one assuming you repro the problem
errant grail
Just listening today.
onyx hinge
a separate computer for each USB device
stuck elbow
ze cloud
ivory yew
"screaming" button
ivory yew
π "beep, boop"
old smelt
Lurking
tidal kiln
lurking
thorny jay
Not even lurking... I don't get any sound from Discord... trying another computer. π
inland tusk
@thorny jay understood
solar whale
@onyx hinge yup -reproduced -- keeps reporting"no SD Card" -- I'll open an issue later today.
onyx hinge
https://blog.europython.eu/post/614102095419850752/europython-2020-online-conference-from-july-23-26
https://twitter.com/PlusPlusInt/status/1283004659913957376?s=09 https://drive.google.com/file/d/1sJsW3r12_vnLUIJXL_1vZ0xPcK2UlQ62/edit
gilded cradle
π
onyx hinge
https://careers.microsoft.com/us/en/job/788078/Senior-Program-Manager https://twitter.com/qubitron/status/1283791148687880192
modern wing
That sign is so cool π
gilded cradle
Thanks
onyx hinge
onyx hinge
circuitpythonday@adafruit.com
idle owl
You can host events locally, do projects, all kinds of things!
turbid radish
Send a tweet to @anne_engineer for Python/CircuitPython tips and projects or email anneb@adafruit.com
uncut nexus
not lurkng today π
slender iron
kk
manic glacierBOT
thorny jay
Yes I do.
gilded cradle
Just a tiny bit
ionic elk
un petit peu
onyx hinge
I don't know the french for "meeting". rendez-vous is probably not right.
blissful pollen
I remember just a little from school, kinda funny what does come back at times
ionic elk
c'est la rencontre
inland tusk
lurking for updates
thorny jay
"rΓ©union"
prime flower
oo yeah - bonus hug report to @lone axle for tackling a progressbar issue
old smelt
π― <- for Scott, not for me...
onyx hinge
(and I know I'm forgetting another name who has helped with text for displayio .. curses)
lone axle
kmatch98
onyx hinge
belated hug to kmatch98
tidal kiln
@solar whale thank YOU for all your help in the various outlets. it is much appreciated.
inland tusk
@gilded cradle can you supply the URL for the guide on your large sign
ivory yew
oooo that sounds awesome
gilded cradle
@inland tusk, I don't have an Adafruit guide, but you can check the documentation at https://opensign.readthedocs.io/en/latest/ and view the video at https://youtu.be/WP-MhQo5OLw.
Part 1 is available at: https://www.youtube.com/watch?v=iUOKnKkuhis
prime flower
lets see if mic works
dang!
@ionic elk I now understand your frustration a few weeks ago
uncut nexus
here
slender iron
kk
onyx hinge
(sorry, I should have added Dave P to the notes:)
slender iron
np
mental nexus
Sorry I canβt join today. Hereβs my βnon CP work from last weekβ, video with audio if you like to hear the clickety-clackety bits.
ivory yew
dat click
tidal kiln
i'm still "gitting" π used to that new UI
onyx hinge
I need to step away so I'll miss In the Weeds. I'll lurk so the backup recording can complete.
slender iron
kk
thorny jay
I have seen a 7 color eInk display... but costing a lot!
errant grail
@ivory yew Excellent blog posting!
ivory yew
ty!
low sentinel
(done with my day job Monday meeting, lurking now in the chat)
ivory yew
that blog post is one of the longest and definitely involved more math and javascript than any other
low sentinel
oh cool thanks! β₯οΈ
slender iron
talking about updating https://learn.adafruit.com/circuitpython-display-support-using-displayio/text
tidal kiln
sounds like wanting to update that page?
slender iron
yup
tidal kiln
ok, what kattni said then. π
gilded cradle
Maybe this one too, which is mirrored from another guide: https://learn.adafruit.com/circuitpython-display-support-using-displayio/ui-quickstart
tidal kiln
(and thanks for updating)
inland tusk
@gilded cradle thanks
thorny jay
that blog post is one of the longest and definitely involved more math and javascript than any other :mood:
@ivory yew Yes that was too much for me. But I found your other blog post "Lessons learned from building a custom CircuitPython board" and that was the kind of thing I like.
inland tusk
thats a package instead of a module
ivory yew
@thorny jay if you have any specific areas that were too much I'd love to know- I always want my posts to be pretty approachable.
gilded cradle
PulseIn?
tidal kiln
@lone axle you can ping me if you have a question about that displayio guide page, but in general, feel free to update it as you want. it hasn't been updated in a long time (if ever).
gilded cradle
I've used PulseIn on the Grand Central.
idle owl
@lone axle Do you know if kmatch98 is in the Learn system? e.g. have they written a guide?
gilded cradle
Ah, ok
lone axle
Thank you Cater.
thorny jay
@ivory yew Maybe it was the math, or ADC is not my thing, or it was not the right time to try to understand that (I had the link parked to read it since I saw that on Twitter). I may need to rewatch https://www.youtube.com/watch?v=UAJMLTzrM9Q to better understand ADC, and then read your thing.
lone axle
@idle owl I don't think so, but I am not sure to be honest.
idle owl
@lone axle No worries. Include them in the email you send me, when you get around to it, and we'll find out.
lone axle
Will do.
ivory yew
@thorny jay cool, well, if you do come back to it all feedback is welcome. π
crimson ferry
Could we auto-generate more than one build per unique board? We'd probably want to keep this to a minimum (if at all) to avoid confusion, but it could help with distinctly different use cases for resource-limited hardware.
lone axle
Pie in the sky idea: maybe there could be a build server with a front end interface that gives you a nice clean way to select which modules you want to include and it will create a build on the fly.
that could lower the barrier to entry for customizing builds based on indivudual project needs.
crimson ferry
@lone axle that sounds awesome
ivory yew
that's an awesome pie in the sky idea
ionic elk
The default right now is basically just that we have a default but if you want more build options you have to clone and custom build, right?
thorny jay
Well, I wanted to see if I could put ps2io back into M0.
ionic elk
So this is basically an interface for adjusting build flags online?
lone axle
yep
ionic elk
That'd be pretty neat for STM32 boards, we have a lot of flags like that which impact flash size
lone axle
check boxes or side by side lists or something like that. Just choose which ones to include or exclude.
ivory yew
Not build flags as much as the board makefile, right?
ionic elk
Whether or not you want a bootloader, etc
ivory yew
or I guess you can pass those in through make arguments.
thorny jay
I can now compile CircuitPython on my Pi4 "server" so maybe I should just give it a try.
lone axle
(my terminology about flags vs. board make files etc. is probably off. I don't have much actual experience with custom builds yet)
ionic elk
I mean like setting environmental variables or whatever as you build that get processed in the makefile. My vocab might be bad
I'm not amazing at makefile terms
onyx hinge
(I'm back)
ivory yew
I know just enough make to be dangerous
ionic elk
I say things and people understand what I mean so I learn it's ok and then never change
π
ivory yew
ninja builds when @slender iron π
ionic elk
π€ βοΈ
onyx hinge
I have some code which helped generate uf2s that update just the filesystem area with new content. doesn't work on express boards of course.
ivory yew
oh that's cool
stuck elbow
@onyx hinge is it published anywhere?
low sentinel
@slender iron I can hop in voice if you want to talk async however I suspect we've already reached an understanding on what you expect; and I'm still unsure the upsides of the changes are worth furthering the divergence from micropython - so it's probably not something I'll try to do in the immediate future.
I tried to increase async compatibility with cpython and found mpy/py compilation differences that seem surprising so I aborted it for now.
onyx hinge
@stuck elbow I don't think so, if you're interested I'll try to dig it up.
stuck elbow
that would be great, thank you!
onyx hinge
ah I overestimated how far I got in the project π It creates a FAT filesystem image but doesn't convert it to uf2. https://github.com/jepler/mkfatimg
stuck elbow
thanks, I think I can go from there
onyx hinge
./mkfatimg .o/img.bin IMAGE 512 --circuitpython=boot.py
``` it's a commandline program, works something like this.@uncut nexus we have some examples of calculation speed in the ulab learn guide
uncut nexus
ok, thanks!
idle owl
@onyx hinge I have feedback on the addition of translations to the Contributing page. Actually.... I'll probably make a PR and tag you instead.
onyx hinge
@idle owl that is awesome of you, thanks
manic glacierBOT
stuck elbow
there are versions of python 3 that would run that code
manic glacierBOT
stuck elbow
the errors were added later on
thorny jay
Contrary to micropython... there is no "unix" version of CircuitPython? Or only for testing?
tulip sleet
right, there's no unix CircuitPython. It hasn't been worth doing.
onyx hinge
In a slightly alternate version of history we might have gotten that instead of blinka
I think we're in the better timeline
ionic elk
Will we get the dynamic C modules if we merge in Micropython?
onyx hinge
in that respect
ionic elk
because that would be spicy
thorny jay
Is this the longest meeting we have had?
ionic elk
Big in the weeds, 45m
thorny jay
I don't complain. I love when it goes over my head (like a joke you don't understand).
ivory yew
yeah we'd get a ton of new stuff if we merged with upstream: https://github.com/adafruit/circuitpython/issues/2999#issuecomment-653989721
ionic elk
I think it's still probably worth thinking about breaking in the weeds into a separate meeting
thorny jay
Everybody is free to exit.
modern wing
Thanks for a good meeting everyone!
onyx hinge
circuitpythonday@adafruit.com
gilded cradle
Bye, thanks
tiny oriole
i suspect Discord tries to do a bit of its own echo suppression as well
modern wing
The more the merrier π
I was just paranoid, seeing the indicator light up -- thinking "oh no, am I causing a stadium effect?"
idle owl
@modern wing Understandable and worth checking.
solar whale
Have a good week --- dog walk time π
idle owl
My mic goes through an audio interface and it picks up EVERYTHING, but not enough to be caught on the other end of the most part. But still I get concerned.
slender iron
@onyx hinge how much of the video work flow do you want to do?
idle owl
I can see the green light blinking along to the background noise π
tulip sleet
@low sentinel if you have time to talk more async stuff, i would be happy to now. I am interested in your use cases.
onyx hinge
I have a 1:46:09 mkv file that I'm uploading to youtube now (my personal account) .. I know it has some "mistakes" in it, accidentally switching discord servers via hotkey, and of course I was typing in it and such. URL will be https://www.youtube.com/watch?v=EgYYntCzSOc but I assume there's no reason to use it
slender iron
kk
modern wing
@idle owl If I'm using my USB mic (AT2020usb), it picks up the speakers so easily -- no choice but to use headphones.
If I use the built-in mic, the macbook does a fair amount of cancellation from what I've seen -- the laptop mic was about a foot away from my speakers a few moments ago.
And this new MBP has some stellar mic technology, almost as good as my external (from early tests I've been doing).
onyx hinge
so if you and/or kattni take a look at it and tell me what I did wrong that's great; if it's okay, I'd think doing one where I record and the emcee does the backup recording would be a good next step. Once I've also done a video then maybe I can do the whole thing
idle owl
@modern wing My AT4040 is carefully positioned, though I only have my MBP speakers or the speakers built into the display (ew), and I haven't tried them with the mic. I have tried the bluetooth speakers on my partner's desk which is 4 feet to the right, and it worked fine without feedback afaik, but it's not convenient (did it when we were both on show and tell - have a headphone splitter in the monitor now for future use in that scenario).
@onyx hinge Switching servers, maybe try to avoid that π But typing into it, not a big deal. I'm sure the video is fine.
slender iron
ya, I'm sure it's fine too. the one thing that I'm unhappy with is when I only get my audio and not obs
onyx hinge
my audio & scott's (discord's) audio are both good in the recording. hooray
idle owl
Then you're 98% there.
onyx hinge
do you ever get used to that "hearing yourself" thing?!
mental nexus
@idle owl sorry I had to disappear halfway through the meeting today. I have never done anything with learn guides. Iβll listen to the call and then connect with foamyguy to define next steps for display_text.
idle owl
@onyx hinge I am told you do. I have not.
low sentinel
@low sentinel if you have time to talk more async stuff, i would be happy to now. I am interested in your use cases.
@tulip sleet sure, you want a DM or do you want to hop in a voice channel?
tulip sleet
how about Amelia Earhart?
modern wing
@onyx hinge I'm self-conscious of it. Folks say it's fine, but I go, "Wait, I sound like...that?"
onyx hinge
I mean, I sound fine but at the same time I sound like somebody else
idle owl
@mental nexus Perfect! I simply wanted to know whether you were in the system already. Depending on how involved you'd like to be with the update, we can get you added and show you the ropes of the system. Foamyguy has done a guide and such so he'll be of a lot of assistance there.
@onyx hinge Imagine doing the newsletter video. I have to listen to myself repeatedly.
mental nexus
Ok sounds cool. Iβll talk with him and figure how we divvy up the work. Will let you know if I need access there.
onyx hinge
@idle owl yeah ....
modern wing
@idle owl I was wondering, do you do that in one or several long-ish takes, or do you do cuts for each line item then splice them together in an audio editor?
idle owl
@modern wing Oh noes, you want to know my sekrets! π
modern wing
Hahaha, guilty as charged π
idle owl
@modern wing It's one long take, and then I cut out the borks, breaks and silences in Premiere while adding the image/video assets.
modern wing
That's impressive. Doing that much effort, week after week, especially with such a short turnaround time is pretty amazing.
idle owl
Still takes me all day Tuesday. It gets shipped around 8:30-9pm pretty consistently, no matter how hard I try.
onyx hinge
you can twitch-stream the next recording, your audience will love it. see the human side of the circuitpython weekly video.
the f-bombs and raspberries just bring you and your audience closer
idle owl
Except for the marking it as "for mature audiences" part, because the fourth time I screw something up... yeah that.
ivory yew
I'm frankly astonished that I haven't said bad words during the meeting yet
modern wing
And when a loud muffler car drives past your place, you jump out of your chair screaming: "Oh for cryin' out loud, do you need to do that four times in an HOUR?!"
idle owl
@ivory yew It'll happen. π
@modern wing Or the fire alarm goes off.... etc etc.
Apartment building, so it's one alarm system. Some idiot microwaves a potato in foil, and we're all subjected to it until the fire dept shows up to verify and shut it off.
(There may be a couple of layers of gaffers tape over the speaker. MAY BE.)
ivory yew
my building has independent alarm systems
modern wing
We know nothing, we hear nothing π
