import board
import digitalio
import time
import microcontroller
print(microcontroller.cpu.frequency)
pin = digitalio.DigitalInOut(board.D12)
pin.direction = digitalio.Direction.OUTPUT
while True:
pin.value = True
#time.sleep(0.1)
microcontroller.disable_interrupts()
microcontroller.delay_us(1000)
microcontroller.enable_interrupts()
pin.value = False
time.sleep(0.01)
pin.value = True
microcontroller.delay_us(1000)
pin.value = False
time.sleep(0.1)
#circuitpython-dev
ionic elk
this will obviously add a bunch of execution time for short intervals, which is why I'm not worried about those. but for big ones like 1000us I'd expect it to be more on target
- 1us -> 14.7us
- 10 -> 30.4
- 100 -> 188
- 1000 -> 1769
tulip sleet
well, when you enable interrupts, if there's a pending interrupt (like a USB tick), then a lot can happen then, and also, the background tasks are running, and they use up a lot of time (which we need to fix)
ionic elk
oh that's true.
tulip sleet
I'm suggesting you test this at the C level, by setting some volatiles that store systick or cyccnt and then just setting some breakpoints or something, or adding print statements temporarily
ionic elk
microcontroller.disable_interrupts()
pin.value = True
microcontroller.delay_us(1000)
pin.value = False
microcontroller.enable_interrupts()
still evaluates to 1765
but I'll test it in c
tulip sleet
it's still going to call the background task checker RUN_BACKGROUND_TASKS between statements
ionic elk
oh between all micropython instructions you mean
simple pulsar
@tulip sleet FYI, wrt serial blocking on bluefruit in arduino world, CircuitPython doesn't seem to suffer based on some testing with print: https://github.com/adafruit/Adafruit_nRF52_Arduino/issues/375#issuecomment-551166774
tulip sleet
right
ionic elk
Still, why would 100 -> 188 in that case? if it's additive, that doesn't really make sense as an output
tulip sleet
RUN_BACKGROUND_TASKS gets called at various times
it might take 88us to actually get to flipping the pin value
the systick timer interrupt runs at 1ms intervals and also runs background tasks, I think
i'm just saying test it in a way that cuts out all other potential overhead
ionic elk
The systick one makes the most sense to me. I don't think it can be additive pin flip execution delay if the numbers are 10 -> 30.4, 100 -> 188, 1000 -> 1769, that doesn't imply a consistent delay. But that means I'll have to disable systick
even if I do it in c
In any case this is all on my Atmel control, maybe I'll run it on stm32 and not get it
tulip sleet
@simple pulsar hmm, that's interesting
I'm just saying add stores of systick into before and after voltatiles at the beginning and end of the delay routine. That and turning off interrupts should get you an accurate idea of the delay
it may well be not that accurate, but I think Scott did test it. I thought we were using a similar technique in neopixel_write, which requires accurate timing
obsidian compass
I've a question for core circuitpython codebase. When creating a file on filesystem what API to use to write data into that file?
f_write() ?
simple pulsar
@obsidian compass I don't know if it's the best example but I know the PyPortal code writes a file to either the (previously write enabled) flash or the SD card: https://github.com/adafruit/Adafruit_CircuitPython_PyPortal/blob/master/adafruit_pyportal.py#L843 - there seem to be some precautions on write size which don't feel like they belong in application code, though
@obsidian compass It's also described in a guide with a dedicated page on it: https://learn.adafruit.com/circuitpython-essentials/circuitpython-storage
obsidian compass
@simple pulsar Thanks alot for pointers, I will look into it 🙂
For now when using f_write to write ASCII strings the result shows HEX in file, any idea?
obsidian compass
@meager fog I am actually looking for making files in core code like when building circuitpython file system and that filesystem has a file with some strings
so when we build and flash the .uf2 it has that file
obsidian compass
Trying to work on this issue here --> https://github.com/adafruit/circuitpython/issues/2149
So far able to create an empty code.py file
meager fog
are you the last person who commented on that issue?
obsidian compass
Yes I am 🙂
meager fog
ok great - a lot of people are on break this week
you may want to wait till next week
to get a faster response
meager fog
👍
i also know micropython creates files with stuff in them
you can look upstream
but thats my limit
obsidian compass
Good idea, lemme see
tulip sleet
@obsidian compass a good example is how we write to boot_out.txt in main.c. You could create code.py in a similar way
manic glacierBOT
ionic elk
@meager fog speaking of breaks I'll be in NYC the week of thanksgiving, so I'll be hacking turkeys rather than drivers that week. I'd love to say hi if anybody is around though.
ivory yew
I'm glad these boards could arrive just in time for me to not be able to assemble them because of Supercon: https://twitter.com/theavalkyrie/status/1192593723776831488
But now I have pictures so I can add the board to circuitpython.org 😉
simple pulsar
I've forgotten what needs to happen to make a new library build and go into the bundle. https://github.com/adafruit/Adafruit_CircuitPython_PyPortal/pull/39 went in on 30-Sep-2019 but the latest library (https://github.com/adafruit/Adafruit_CircuitPython_PyPortal/tree/3.1.3) does not include that.
tidal kiln
@simple pulsar just needs a release done. that will trigger the bundle to grab the latest. looks like latest release was done just one commit before that merge:
https://github.com/adafruit/Adafruit_CircuitPython_PyPortal/releases/tag/3.1.3
main meteor
@ivory yew That's a good-looking build! I like the patterned trace, that's a nifty touch.
ivory yew
Thanks! An actual artist is working on the panel for the full run but I needed something for the beta so that's what I came up with.
ivory yew
Oh rad, that got merged. 🙂
manic glacierBOT
marble hornet
how did we get qtouch working outside of atmel studios?
wind trellis
@marble hornet The "we" here is none other than @meager fog and you can watch it as it happened: https://www.youtube.com/watch?v=3vTUzvljQiU https://www.youtube.com/watch?v=01xG74COYEY
marble hornet
Thank you
wind trellis
I don't know why I got a blow-up viewer box for the first video link but not for the second, and now that will bother me all night. 😧
solar whale
@gilded cradle Is the new gizmo library supposed to be in the bundle? -- I don't see it
@raven canopy I noticed that the bundle releases don't list the updated/new modules anymore -- is that intentional?
gilded cradle
Yeah, it’s supposed to be. I’ll take a look when I get back to my computer tonight.
solar whale
OK --thanks -- no rush -- just want to make sure you were aware.
raven canopy
intentional? not that i know of... i probably broke something. i'll check into it when i can.
solar whale
Thanks!
Possibly none listed because none got added....but the last 2 releases have not listed anything
tidal kiln
oh yah, it's just brand new. still getting things all setup.
solar whale
@tulip sleet got my "ble_rover" to work with the new UARTService, very minor changes needed. just copied from the uart_echo_test example
tulip sleet
great!, that was my hope, htat it would be easy to update the code examples in the guides. I'll stash it away it if you post it here. thanks!
solar whale
Mine is a bit - modified from the original guide -- I'll go back to the original and implement the changes - I was just going to try the new CPB rover @split ocean put in the learning guides -- it will need similar changes.
tulip sleet
oh, i thought you meant JP's guide, but yes, the other will be good too
solar whale
the one I am using is on a feather nrf52840 and I have added some neopixels
split ocean
I had done this one: https://learn.adafruit.com/circuitpython-ble-crickit-rover and the new one with Circuit Playground Bluefruit is in moderation, using this code: https://github.com/adafruit/Adafruit_Learning_System_Guides/tree/master/Turtle_BLE_CPB_Crickit_Rover
solar whale
@split ocean yes -- Those were the ones I was working with and now adapting to the new bleio/BLE library. they no longer will work with the current master and BLE library.
I think the only change I made to the original ble_cricket rover was in the number of neopixels -- If you want to see -- here is the new version .
I'll try the same with your CPB version -- just need to swap boards around to try it!
solar whale
@split ocean here is a modified version of the turtle_ble rover that seems to work
solar whale
@split ocean FYI -- for the motors I am using I had to increase the speed settings .25 just caused then to whine -- I used 1.0 for FWD -.7 for REV ....
split ocean
this is for the CPB version? I was running them at 0.25 on the lastest version. This is heavily battery dependent, BTW.
big current draw at the lower speeds.
solar whale
yes for the CPB, running on 5V supply for now -- not sure where I got these motors either -- I'll experiment with other motors. Just want to let you know incase it comes up.
split ocean
thanks, great point, I'll add a note in the guide that tweaking motor speeds in the code may be required.
split ocean
ah nice! I think the CPB version of the code may win for precision control, but the Feather one on raw, reckless speed!
onyx hinge
hum I wonder why the "unix" port doesn't work right with -flto specified...
slender iron
Hi all, we're having our CircuitPython Weekly meeting at the normal time tomorrow here on Discord. It is at 11am Pacific / 2pm Eastern and everyone is welcome to attend. More details are available here in the notes doc: https://docs.google.com/document/d/1ox1-zzFvd-Os3TnWtmhD1RZQnfMb1Q3rkN_jHTZ3v48/edit?usp=sharing <@&356864093652516868>
simple pulsar
Has anyone looked at the performance of bluetooth data transfers on the Circuit Playground Bluefruit with CircuitPython? I thought I'd check the latency and it appears to be around 43ms RTT for an "echoed" ColorPacket() from one CPB to another. I don't need a lower number I was just measuring it. That number does include one packet parse operation at the moment.
gilded cradle
@solar whale, fyi, it looks like I had added it to the bundle incorrectly and just submitted a PR to fix that and a couple other libraries I added incorrectly.
pulsar python
Hi all,
need your help or advice please: the Pygamer seems to be dead, it's not showing up as drive in Win or Mac, Display not working, only CHG Led is flashing quickly (10x/sec if ON, permanenet yollow if OFF, but both with low brightness) when plugging in USB Cable. With battery only, completely dead, no LED. It was working before. No observations with regard to damage or bad treatment. USB cable is fine as well.
I have 2nd PyGamer at home so I can compare/ check if battery loaded etc.
Any thoughts or help please? Thank you:)
CircuitPython is installed on the respective pygamer, the version is also correct.
solar whale
@pulsar python Did it work previously with this battery -- verify that the battery polarity is correct.
pulsar python
@solar whale Thank you for your quick reply! Yes, battery and polarity is fine. It worked before. Also I checked the battery with my second Pygamer.
slender iron
@pastel panther this person is waiting for a reply from you, when you have a chance: https://forums.adafruit.com/viewtopic.php?f=60&t=157748
manic glacierBOT
broken hedge
OK - I "think" I've found an issue. Double-click "reset" on CPB. Drag over fresh "adafruit-circuitpython-circuitplayground_bluefruit-en_US-5.0.0-alpha.5.uf2" onto "CPLAYBTBOOT". copies, reboots. When I run this code w/"drum_cowbell.wav", no sound comes out. https://gist.github.com/gallaugher/afc0bd8213f9f1f6e5e3b0967904c0e4 BUT if I reinstall the old .uf2 (adafruit-circuitpython-circuitplayground_bluefruit-en_US-20191012-a146ce5.uf2) by double-clicking "reset", wait for green, drag "adafruit-circuitpython-circuitplayground_bluefruit-en_US-20191012-a146ce5.uf2" over on to CPLAYBTBOOT, wait for CPB to reboot, then run the code, it works fine. Is this a problem with alpha 5 on the CPB or am I doing something boneheaded? Thanks!
stuck elbow
@broken hedge you have to unmute the speaker now
it's muted by default
that was changed in 5.x to be consistent with other ports
broken hedge
Oh - thanks so much! Is this the accepted way to do this:
speaker_enable = digitalio.DigitalInOut(board.SPEAKER_ENABLE)
speaker_enable.direction = digitalio.Direction.OUTPUT
speaker_enable.value = True
Thanks!
onyx hinge
phew I'm glad @stuck elbow knew the answer!
manic glacierBOT
I can't post the entire schematic, but it is connected exaclty the same as on the Feather M4 in both cases (W25Q128JV_SQ and IS25LP128F).
I don't have a logic analzer, but the fact that the flash_info.ino recognizes a chip shows that they are extremely likley connected correctly. In fact, another board with the exact same design and a different chip works perfectly (same chip...
solar whale
@tulip sleet for CTS, in the older BLE lib and the new one (in standard/standard.py) there is a property struct_time. Did it ever get tested? It looks like it is missing the "year" argument and time.struct_time() wants a (9-tuple) input -- I think here should be two "-1" at the end for Day of Year and DST. I was getting errors about the 9 arguments until I changed it (added year and an additional -1 . I modified standard.py with these changes and fixed the imports (I think)... still having other issues but just wanted to check if I was missing something regarding this property since it came from the older code but I'm not sure it ever got used.
tulip sleet
@solar whale I only tested it in the REPL, and it's possible I wasn't very thorough
solar whale
was "year" intentionally omitted?
@tulip sleet don't spend any time on this -- I'm sure you have other priorities -- I was just curious -- happy to keep hacking....
slender iron
@solar whale I didn't actually test it because I didn't have pairing working when I tried it
solar whale
I don't have pairing working properly either, but I can connect with the Bluefruit LE app ... that's when I ran into some issues with it.
slender iron
I didn't think CTS worked without pairing
solar whale
it's not actually working .... all 0's for the time
slender iron
I did see it returning zeros to me and I "fixed" it to throw a permissions exception I thought
ah, ya. I think the old version just returned zeroes
I thought I made it throw an exception now
solar whale
I had to make mods to standard.py -- it did not like the imports using core did you fix that in yours?
slender iron
ah, I thought I had fixed all of those
solar whale
not in the current master
slender iron
maybe not. I haven't retested recently
I mainly tested advertising and uart service
solar whale
slender iron
ya, I got rid of the .cores in favor of putting them in __init__.py
I thought the lint and sphinx would catch them all
I bet sphinx isn't documenting that folder at all
solar whale
yes, I think I fixed them ok -- but still something wrong.... mostly with my understanding 😉 Do you understand my concern with time_struct not using "year" and "9-tuple"
raven canopy
yeah, you'll have to force sphinx/automodule to include __init__.py.
solar whale
There is no going back ..... 😉
river quest
i'm here will be text only (on a train)
🚋 to get that out of the way
raven canopy
🎉
solar whale
Come to New Hampshire...
ruby atlas
@river quest yay to snektrain
ivory yew
I am lurking for a bit then offline. 😶
swift arrow
lurking
fierce girder
tidal kiln
lurking
river quest
does a sommersoft make a noise in the forest if the mic is on but sommersoft does not say anything?
raven canopy
tis a mystery... 👻
river quest
amtrack train wifi is not workin great, so i'm all text it seems
we have some hotspots but it's goin' in and out
onyx hinge
@river quest oh no, we depend on you and your mellow voice
river quest
next week!
onyx hinge
you know it
inland tusk
@odd flax you should be alright. I have done it before coming up from florida
idle owl
Python powered badges at Hackaday Supercon. Bryan, JP, Melissa, and Scott will be there - if you are attending see the team to get the ML demos on your device!
https://hackaday.io/project/167255-2019-hackaday-superconference-badge
Winterbloom Sol by Alethea Flowers
https://circuitpython.org/board/winterbloom_sol/
Winterbloom Sol is a modular synthesizer (Eurorack) module, and CircuitPython powered! It is a multi-purpose, scriptable USB MIDI to CV/gate converter. Its code can be modified while in use to change how it processes MIDI data into CV and gate outputs. Sol is not yet available for purchase, however, you may contact the creator for more details.
https://thea.codes/
idle owl
Python #2 language on GitHub, read all about it:
https://octoverse.github.com/
Sponsoring Bunnie on GitHub, we did, and if you want to support bunnie's work, please do so!
https://github.com/bunnie
old smelt
Lurking
idle owl
There are now 13 entires for the Take Flight with Feather contests! Design a board to fit in the Feather ecosystem and we’ll manufacture it.
https://hackaday.io/contest/168107-take-flight-with-feather
As always, please open an issue, a PR, email, tweet, send an owl, whatever works, contribute to the newsletter:
https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2019-11-12-draft.md
Special thanks to Matt for adding a bunch of MicroPython news and links.
river quest
thanks scott!
(train wifi stopped workin for audio, so i just guessing it all worked out 🙂
onyx hinge
💯 + 💯
errant grail
late and lurking...
onyx hinge
tinyusb is hugely enabling for microcontrollers, can't imagine being without it
swift arrow
yea!! congrats @onyx hinge
timber mango
oops wrong channel.
no microphone
Hug Report: @tulip sleet Was a big help to me, in getting ARM STM32F405 Arduino IDE-based programming working.
Dan steered me to dfu-util which proved instrumental in understanding the programming of this new Adafruit target board.
Similarly, @solar whale linked to the unpublished STM32F405 Guide, in the channel, which made SPI flashROM access possible for me. Thanks so much!
slender iron
👍 will read off after siddacious
onyx hinge
oh yeah I forgot to hug report everybody who will be repping circuitpython at supercon!
swift arrow
yea! that will be an awesome episode of JP-workshop
raven canopy
3 minute build time is nice. best i've gotten on 3B+ is 6 minutes using -j2.
surprisingly, booting from an SSD didn't speed it at all
gilded cradle
That's a Catalina thing @solar whale
timber mango
ouch!
solar whale
Ouch! Feel better soon!
idle owl
Yep!
timber mango
I was able complete an Arduino project for STM32F405, using ST's Cube (programmer) or, alternatively, (Debian's distributed) dfu-util (both from a Debian Linux host PC; both via the USB interface).
Needed to erase all (in Cube, only) to upload to the F405 target, properly.
(Cube-based) upload was done only outside of the Arduino IDE.
Used the (formerly) unpublished (now published!) F405 Guide to access SPI flashROM on the F405 board (thanks, @solar whale !)
Guide:
https://learn.adafruit.com/adafruit-stm32f405-feather-express
Cube, script stuff:
https://termbin.com/je13
dfu-util CLI syntax:
dfu-util -a 0 --dfuse-address 0x08000000 -D ./this.bin
manic glacierBOT
pastel panther
The solution Dan, Limor and I came up with for defining CVs (controlled vocabularies) for drivers for things like data rate, range, modes, etc.:
https://github.com/adafruit/Adafruit_CircuitPython_LSM6DSOX/blob/master/adafruit_lsm6dsox.py#L94
timber mango
I get some good ideas after reasonable TEXTING hours, so I email them to myself.
I'd have to then transfer them to SMS media at a decent hour, to send them at all.
raven canopy
tummy rumbles. must find honey. 🍯
timber mango
Could you just send them periodically in the MIDI stream, scheduled rather than on demand?
dense pike
@tulip sleet Hi Dan, I'm trying to use the color picker on the nrf524804 using CircuitPython v5.00 and v5 library and getting the following erorr, looks like a module ( adafruit_ble.uart_server)maybe missing is the adafruit_ble library
Thanks tim
tulip sleet
which version of the library are you using? Should be https://github.com/adafruit/Adafruit_CircuitPython_BLE/releases/tag/2.0.1-alpha.2 for CPy 5.0.0-alpha.5
dense pike
@tulip sleet OK, that cleared up the error
tulip sleet
versions will change again on the next alpha (or it might be beta.0)
dense pike
@tulip sleet THanks for the help, took a while but I now have the nrf52840 talking to the iphone!!!!🙂 now on to motor contorl
tulip sleet
yay!
dense pike
@tulip sleet One more question, where you able to confirm if the white box in the control pad could be used for messaging?
tulip sleet
I started looking at the source code for the app in Xcode to find out what that box was connected to, but I didn't get very far. If I can't figure it out I'll ask someone who would know.
dense pike
@tulip sleet Thanks, Adafruit and it's staff ROCK
tulip sleet
@dense pike OK, the answer is that if you just write any old text back from the uart_server, it will appear in the text box on that page. All that box is doing is showing characters sent back from the BLE peripheral
dense pike
@tulip sleet what would be the command to do that?
tulip sleet
@dense pike like
uart_server.write("Thank you for pressing that button\n")
actually maybe need
uart_server.write(b"Thank you for pressing that button\n")
since you need to send bytes, not a string, but a regular string might work. Don't have time to try it at the moment
dense pike
@tulip sleet, Thanks IT WORKED! Ok i will experiment and let you get back to your life. Thanks for all the info and time
slender iron
@tulip sleet when do you want to chat? I'm free the rest of the day
tulip sleet
i was just going to ping you. now is fine
slender iron
kk
tidal kiln
timely comment by dan ⬆
looks like one needs to work with a very specific adafruit_ble release?
or, not release, tag
manic glacierBOT
simple pulsar
@tulip sleet Why does the build get bigger when long int is provided?
tulip sleet
because there is extra code to manage and compute with longints that is omitted without them
simple pulsar
oh, I thought there might be more to it
dense pike
Hi All, Can CircuitPython function definitions be put at the end of a program or do they have to declared before they are called? Thanks in advace tim
slender iron
@dense pike Python functions need to be defined before they are used within the same scope
tulip sleet
@dense pike Python code is executed as the .py file is read. But definitions can refer forward (there are no forward declarations)
Examples: this works:
def f():
g()
print("f")
def g():
print("g")
f()
but this does not:
f()
def f():
print("f")
getting corrupt .mpy file using CPv5.0.0 Adafruit Feather nRF52840 Express
any suggestions? thanks Tim
uf2 file adafruit-circuitpython-feather_nrf52840_express-en_US-5.0.0-alpha.5.uf2
tulip sleet
could you copy the libraries again? that error might be from a truncated file
or you may need to download again
dense pike
Ok, downloaded file again and reloaded lib files. All is working! 🙂 thanks
tulip sleet
it's unusual to have truncated files when copying on MacOS. It's pretty good about writing files to the device as soon as possible (Windows and Linux can not actually write the data for 10's of seconds, on those boxes it's recommended to do sync or the equivalent). But the nRF52840 flash is pretty slow. If you happened to start a copy and then unplugged or reset a little too quickly, you might have interrupted the copying. On the other hand, this is extremely unusual, so nothing really to wrory about
dim peak
Hi all, what is the procedure to add a board to https://circuitpython.org/downloads. I want to add boards based on SAMD21 uController. Thanks
indigo wedge
@dim peak see here for an example https://github.com/adafruit/circuitpython-org/pull/324
dim peak
Thanks @indigo wedge
tulip sleet
@slender iron while doing adafruit_ble cleanup: do you think we should just have service coders use _bleio.Attribute.NO_ACCESS and other constants, etc, or should we duplicate those into the library to hide their _bleio origin.
going out for a couple of hours or less, but hope to have a PR later today
orchid basinBOT
tulip sleet
@slender iron also have some q's re possibly making ComplexCharacteristic a subclass of Characteristic (it is not now).
orchid basinBOT
slender iron
@dim peak there is a guide for adding a board here too: https://learn.adafruit.com/how-to-add-a-new-board-to-circuitpython
@tulip sleet eating cereal and then around until noon my time
tulip sleet
@slender iron sure, ping me when ready
slender iron
kk
slender iron
ok @tulip sleet
idle owl
@tulip sleet Wrong channel. Oops.
I added the if not data: check, currently it's a RuntimeError - not sure if that's the best choice. The issue was that it was failing with TypeError: object of type 'NoneType' has no len() for obvious reasons when there was no data sent, but that's super cryptic if you're not looking at the driver. The wiring is the issue when that error is thrown.
@property
def temperature(self):
"""Return the on-chip temperature, in Celsius"""
self._uart.write(bytes([0x50]))
data = self._uart.read(1) # 1 byte return for temp
if not data:
raise RuntimeError("Sensor not found. Check your wiring!")
if len(data) != 1:
raise RuntimeError("Did not receive temperature response")
temp = data[0] - 45
return temp
also now wondering if that should be an elif on the second one now.
tulip sleet
@idle owl if the q is whether RuntimeError is a good choice, yes, I think so: indicates some problem beyond the program's control
tulip sleet
don't need elif really because the raise exits the routine
idle owl
Ok
tulip sleet
like, it would make sense to add a blank line after the raise, because that is a self-contained "paragraph" that validates data. So you can see elif is not part of that
idle owl
Ok that's a good idea thanks
ivory yew
I have a weird personal style preference that all control statements should have a newline above them, except for continuations like elif,except, and finally
tulip sleet
yeah, i use blank lines fairly liberally to indicate logical grouping, like: would this bunch of lines deserve a comment on its own, or does it do "one thing"
ivory yew
Gotta have that w h i t e s p a c e
good example of me being extreme about this: https://github.com/theacodes/Winterbloom_SmolMIDI/blob/master/winterbloom_smolmidi.py#L106
idle owl
@tulip sleet Thanks for your help.
:shakes fist at Pylint:
Naturally it didn't fail locally. Using either version of Pylint.
Ugh. Unhappy with my fix, but it worked, so eh.
main meteor
I think pep wants 2 blank lines before and after function/method definitions
ivory yew
I (personally) find PyLint infuriating. I ended up removing it from my projects about 2ish years ago?
idle owl
@ivory yew It can be infuriating, but it means we have a standards check without it all being subjective during reviews. It's important to us to keep it. But I understand where you're coming from.
idle owl
Didn't think you did 🙂
ivory yew
All of my projects use black, flake8, and some have adopted mypy.
idle owl
Fair enough.
ivory yew
I'm all about static analysis and eliminating the bikeshed.
It's just pylint haas continuously proven to me that it's the most contributor-hostile way to accomplish those goals.
idle owl
Also fair enough.
ivory yew
(that isn't an indictment of circuitpython's use of it, by any means, I'm always happy to conform to another project's standards)
tulip sleet
we did look at flake8 a bit, but pylint seemed more comprehensive. but if you have a better auto-review workflow, that would be great to know
ivory yew
flake8 is style check, pylint is borderline static analysis.
so you do give up some of that.
In projects past, we've made up for that by enforcing really high testing standards (100% coverage, etc.)
tulip sleet
the typo checking is helpfful
idle owl
I know Black was intriguing.
tulip sleet
our testing story is not good, because testing physical stuff is hard; we had a Linux box with boards connected via USB to do some testing ("rosie"), but it was not a reliable setup
ivory yew
yeah testing is hard.
So I'm writing the software library for Sol
and I want it to be 100% tested
So mostly a lot of mocks.
I don't love that.
It'd be cool to have proper stubs (Blinka but for testing) but that isn't perfect, either.
but even those things improve your confidence interval.
SmolMIDI has 100% test coverage and just uses a small Stub for usbmidi.PortIn: https://github.com/theacodes/Winterbloom_SmolMIDI/blob/master/tests/test_winterbloom_smolmidi.py#L9-L26. That plus some testing to validate the behavior on real hardware gives me a fairly good amount of confidence.
But I missed the buffer overflow thing by not having real hardware to test with.
tulip sleet
@raven canopy is working on a testing framework which I don't understand yet
ivory yew
or rather, I would have missed the buffer overflow if I wasn't testing with real hardware.
all this is to say
A project's health is determined by a lot of factors. Style, static analysis, various forms of testing, etc.
Using pylint to help hold the health up to makeup for testing is a good idea.
I'd love to see us use mypy or pytype. but that'd require a lot of work for us to create type files for the native types.
raven canopy
@tulip sleet once I can understand my creation, I'll be able to explain it better. 🤣
manic glacierBOT
ivory yew
spicy pr incoming
idle owl
@ivory yew Best kind of PR
ivory yew
Turns out I'm feeling extra spicy today
ionic elk
@tulip sleet you still online? Got a sec to talk about a merge thing?
ionic elk
want to hop in amelia?
manic glacierBOT
tulip sleet
@slender iron still testing and debugging my edits to the library, and I am out today on and off. So a library PR will be later.
manic glacierBOT
old smelt
Does CP for the Particle Argon support WiFi functionality?
solar whale
@old smelt Not directly -- you can reprogram the ESP32 on hte argon to act as a wifi co-processor (but only with the limited AT command set -- not the preferred SPI firmware) see this guide https://learn.adafruit.com/adding-a-wifi-co-processor-to-circuitpython-esp8266-esp32/overview
old smelt
Ok, great. Thanks @solar whale!
manic glacierBOT
slender iron
sounds good @tulip sleet
slender iron
@prime flower https://forums.adafruit.com/viewtopic.php?f=60&t=158597
prime flower
@slender iron thanks, that's a double-post. helping them in the original post on the AIO support forum
slender iron
@idle owl @tidal kiln https://forums.adafruit.com/viewtopic.php?f=60&t=158336&p=781639
manic glacierBOT
meager fog
@ionic elk hihi whats next for stm32 for uuu
ionic elk
@meager fog Re-forking to fix a weird merge issue, then Neopixel, then new board support, then probably clock revamps?
anything you want to push up?
meager fog
nope thats good, id fix the clock before new board support
just cause like, thats a core bug
and people will appreciate 2x speed up
meager fog
@ionic elk ill test neopixel when you are ready for me to
ionic elk
@meager fog well, it isn't hurting anything atm, and could impact other boards
tulip sleet
@meager fog we have the beginnings of this for SAMD, but not to actualy change the clock speed: https://circuitpython.readthedocs.io/en/latest/ports/atmel-samd/bindings/samd/Clock.html
ionic elk
because of min speed increases
meager fog
@ionic elk yeah but if fixing the clock breaks something, we need to find out what pretty fast
ionic elk
I'll bump up the speed and see what happens then
meager fog
@ionic elk you should be able to see the i2c clock speed
and SPI clock speed and UART speed
e.g. 100khz for i2c is defaulkt
ionic elk
I don't expect it to actually break modules in terms of functionality. My primary concern is that the divisor on SPI doesn't go high enough to guarantee really low clock speeds when the system clock is really high, so it might make some external boards unusable.
But I can see how having fast speeds and simply fixing the problems is a better approach. I'll switch it over and test things out before moving to neopixel.
meager fog
@ionic elk im not too worried about that
SPI is like, 1MHz + in general
and like ya said, lets break and fix now - cause there's only going to be more protocols/confusion later 🙂
might even want to do it before neopixel since thats is very timining specific
tidal kiln
@idle owl @slender iron i'm wiring up a TMP006 and will try a scan and report back on that thread
meager fog
@tidal kiln ok i have the next Blinka Quest if you're up for it
tidal kiln
sure. shoot.
meager fog
FT232h is great but a little $
MCP2221 is a usb to i2c/gpio/pwm/adc for $1.50
there's a devboard on DK for a few bucks
and a python library by some person in japan
idle owl
@tidal kiln Thanks for looking into that.
tidal kiln
yah. totes. looks fun.
meager fog
ok i also grabbed some of these
i was thinking it would be cute to have a USBC-MCP2221A-STEMMA adapter for like $5
so you can quickly chain connect various i2c device
i noticed that this one does not do SPI at any reasonable speed so FYI!
however it does do DAC/ADC/PWM so it would require more shimming for Blinka support on those
another fun-fact - this chip comes in DIP!
tidal kiln
DAC/ADC/PWM would be great
def looks interesting enough to play with
is that dev breakout good enough for testing?
meager fog
yes totally
if you say it works somewhat, ill design our own breakout
that is nicer/more useful
like with a STEMMA/Qwiic connector on the end
tidal kiln
@idle owl @slender iron responded:
https://forums.adafruit.com/viewtopic.php?f=60&t=158336&p=781653#p781653
manic glacierBOT
tidal kiln
@idle owl @slender iron (oops, posted with diff account, fixed):
https://forums.adafruit.com/viewtopic.php?f=60&t=158336&p=781655#p781655
idle owl
@tidal kiln Thank you!
manic glacierBOT
manic glacierBOT
bleak tiger
Got my new E-ink working with fonts and bitmaps today, trying the new CP alpha for the first time too! Thanks to the learning guides and example code I also have Airlift connected to my wifi, very excited about what I can do with this! Thanks to everyone at Adafruit but especially to those who write the guides.😃
ivory yew
I liked your test text, @onyx hinge. 🙂
onyx hinge
I worried I was being too immodest
marble hornet
@slender iron thoughts on displayio on nrf840 w/ parallel st7789s
marble hornet
possible?
slender iron
@marble hornet you mean 8-bit parallel buses or multiple displays?
marble hornet
8-bit busses
marble hornet
the docs say that parallel displays have to have the pins in order. just to be sure i am reading it correctly that means they all need to be in the same port and there have to be at least 7 more bits in the msb direction? or is it lsb?
slender iron
right. the cpu needs to be able to write a byte directly to the pins
arm is little endian so I believe its pin 0 is bit 0
marble hornet
cool! does it have to divided along one of the bytes along a port word? or could it start at bit 3?
and an aside: (writing some atmel c for my 231 class has been so cool and really given a respect for the c work all of you do (and I still probably don't see the full picture)). awesome work!
manic glacierBOT
indigo wedge
meager fog
@onyx hinge hihi
please let me know when you start spinning up workin part time on circuitpy core
and we will come up with Ideas and Plans
onyx hinge
@meager fog Hi! I'm taking this in between week off to regain a little sanity. Can we have a conversation early next week? (I'm pretty open on hours if we schedule a chat in advance, say 9AM to 9PM Monday or 9AM to 6PM Tuesday, Eastern time) If you don't have other specifics, I planned to look into one or two nRF audio bugs that have been filed, which is likely to be 1-2 hours if the bugs are obvious and 1-2 days if the bugs are subtle.
hum while looking at thta PR I merged where you can customize the string "CircuitPython" for the USB "interface" reports, I noticed that on my Linux I see no overall name for the CP boards I tested: ```Bus 002 Device 001: ID 1d6b:0003 Linux Foundation 3.0 root hub
Bus 001 Device 007: ID 239a:8021
Bus 001 Device 002: ID 0781:5571 SanDisk Corp. Cruzer Fit
taking this week off he says
solar whale
@tulip sleet I just tried to hack the old cts demo code to use the new BLE library-- I'm probably missing something fundamental
since it does not "pair" I assume there is a missing step.
tulip sleet
@onyx hinge, it's true, could be fixed, I think
@solar whale yes, that may not be done yet, I haven't tried it. we're pushing on getting a new phone app to talk to CPB, not working on pairing stuff right now
pushed ... fix
solar whale
@tulip sleet not a problem. No rush on the rest.
tulip sleet
but useful to know; you try a lot of these we forget to try; tnx!
onyx hinge
besides pearing, what other kinds of fruit can a bluefruit emulate?
maybe a grape UART or apricot neopixel
ivory yew
🍐🍇🍑
onyx hinge
in terms of the connection to the wifi, is a pyportal the same as a metro m4 with airlift? Or are they different?
solar whale
They are the same.
onyx hinge
thanks @solar whale
solar whale
Just different names for the pins
@onyx hinge are you having any problems with a it?
onyx hinge
@solar whale no, deciding whether to put an express airlift in my basket or not (I have a pyportal)
solar whale
Ah. So many toys. So little time😉
@onyx hinge there is a difference in the MCU on the airlift M4 Vs pyportal. J19 vs J20
onyx hinge
I have a non-airlift metro m4 too
onyx hinge
(it would be super useful to see on the issue page whether the commenter is already a contributor to circuitpython, it would help calibrate how much assistance to give "up front" vs waiting for a question..)
(but .. concentrating too much on a person's apparent bona fides is not always for the best either)
manic glacierBOT
river quest
manic glacierBOT
tulip sleet
@slender iron after consulting with mgmt, will make new releases for CPy and adafruit_ble. Could be beta.0, though stm32f4 is still adding features (but close)
meager fog
@onyx hinge yep lets chat when you return
onyx hinge
@meager fog hi
meager fog
hihi
onyx hinge
I can chat now if you like
meager fog
oh kk
yeah so i think if you want/can continue on squishing audio bugs
and fixing whatever supports needed
that would be rad
onyx hinge
okie
meager fog
the m4 dac is a bit of a lost cause it hink
i mean, if you get a flash of insight..
onyx hinge
I was sure not making any headway on it at the end
meager fog
but otherwise we'll lve with it
onyx hinge
I have one of those redboards with m4, I should just make sure the same problems occur there
meager fog
i pinged to see if they wanted to add it, maybe they're close
onyx hinge
so you prefer if I put items into basecamp when I'm working on an issue? helps you track things?
onyx hinge
ikr
onyx hinge
I'll try to remember that just relying on having the issue/pr on github is not best practice
meager fog
its ok to have issue/pr but then they are scattered
and they get easily forgotten
how about this one? could be an easy win https://3.basecamp.com/3732686/buckets/4356693/todos/2049516543
also with stm32 we could add audioio soon perhaps
onyx hinge
I can look for "easy to do" stuff there, tannewt seemed to want something more involved -- I think he made it a 6.x or a long term milestone in github terms
I missed the first set of stm32 feather boards for order 😦 so I'd need a different dev board or a second batch
is there more adafruit process you will want me to engage in? meetings & such?
slender iron
@tulip sleet sounds good!
tulip sleet
beta.0 sound OK? It's a breakpoint in visibility, which I think is good for BLE, etc.
onyx hinge
oh I'm wrong, that first PR is labeled 5.0. Will move it up my stack!
meager fog
@onyx hinge pardon which PR?
onyx hinge
https://github.com/adafruit/circuitpython/issues/2142 from https://3.basecamp.com/3732686/buckets/4356693/todos/2049516543
meager fog
@onyx hinge oh yeah that can go into 5.x if you feel its ready. we're still in alpha
or at least, poke at it, see how you feel
onyx hinge
yup will do
meager fog
comin' by the monday meetings here is a good place to stay on top of things
onyx hinge
Attending the monday discord meeting is a priority for me too
onyx hinge
@meager fog btw I would love it if adafruit can cover the costs of sending me to pycon at least partially
would help out with whatever, especially at sprints
meager fog
please send an email to pt/me/stella with details
onyx hinge
can do
meager fog
please include dates &cost breakdown/total
onyx hinge
okay, it'll be speculative on airfare especially
tulip sleet
@onyx hinge we can send you our prev budgets
onyx hinge
@tulip sleet that would be helpful
tulip sleet
lodging costs depend on hotel vs AirBnB-type-stuff, most other things are fixed
onyx hinge
@meager fog thanks for the time to chat. I'll get to work on some of these audio bugs on monday, and then shift over to the background tasks thing when I need a change of pace.
onyx hinge
it should keep me furnished with stuff to do for a bit
🙂
I will be sure to make noise if I run low on stuff to do, feel stuck, or I'm not sure what is a priority.
meager fog
yes thank u
manic glacierBOT
manic glacierBOT
raven canopy
finally got RosiePi's github app completely talking through Azure. the check trigger is 100%; closing the check out is just a dev stub for now. now to work on the test node handling...
demo movie (caution: file is large [107mb])
https://drive.google.com/open?id=11IqbpNI9RncSAD04sdqauepkff9zLGMf
solar whale
It's alive! ```Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 5.0.0-alpha.5-84-g4c55431bb on 2019-11-15; Feather STM32F405 Express with STM32F405RG
help('modules')
main busio math storage
_os collections microcontroller struct
_time digitalio micropython supervisor
analogio errno os sys
array gc pulseio time
board io random usb_hid
builtins json re usb_midi
Plus any modules on the filesystem
import board
dir(board)
['class', 'A0', 'A1', 'A2', 'A3', 'A4', 'A5', 'D10', 'D11', 'D12', 'D13', 'D5', 'D6', 'D9', 'I2C', 'MISO', 'MOSI', 'RX', 'SCK', 'SCL', 'SDA', 'SPI', 'TX', 'UART']
@solar whale yay. btw i tried esp32spi on it, works ifine
solar whale
Nice, I’ll try that tomorrow! Hooked up an I2C gps, worked fine!
zinc maple
Hey all! I've just setup a "Python in Education" server. Let's see how it goes! https://discord.gg/hbxP5ZC
idle owl
@tidal kiln Did you happen to test the I2C GPS code on RPi with Blinka?
idle owl
Limor may have tested it, she said it was tested in a comment.
I wasn't sure how involved with it you were.
tidal kiln
she just merged it
idle owl
The way I read it made me think you had tested it, so that was simply me misreading the comment. No worries. 🙂
I'm writing the guide for it, I'll ask her if she tested it and do it myself if she hasn't.
tidal kiln
cool. i'd guess any issues that come up will be fairly simple code tweak PRs.
if you need help with testing. let me know. i snagged one in last order. so have hw now.
idle owl
@tidal kiln Will do, thanks.
lone sandal
manic glacierBOT
manic glacierBOT
onyx hinge
hmmm the arm toolchain doesn't know how to do an atomic 64 bit operation. I guess it's probably just not directly supported by these chips.
(trying to do something about a low-probability, low-impact timekeeping bug when the milliseconds counter's 32 low bits roll over from 0xffffffff to 0x00000000, which is a total distraction from The Real Thing)
meager fog
@onyx hinge hey Q
onyx hinge
@meager fog go ahead
meager fog
@onyx hinge did i already ask you if you've done CANbus before?
meager fog
yah maybe
do you have a car with CAN connection?
not needed
but i dont so like, i def cant try CAN thing
onyx hinge
I have used one of those obd readers so I think so. 2013 Prius
onyx hinge
Not sure about how I would rig a connection though
meager fog
is it wireless?
onyx hinge
Yes if I can find it the one I have is a Bluetooth uart
meager fog
ooh ok
onyx hinge
BRB 6 minutes
ruby atlas
I have a bluetooth one around someplace that I never opened. I definitely have canbus in my 2014 santa fe. so many thingies that talk to or monitor the car. I was just wondering the other day if there was a way to monitor something about the car in realtime.
Oh I remember. I wanted to read the status of the auto headlights and warn me if they're not in automatic!
Because every time I take the car to be serviced they set them to manual/off and I forget to reset it to auto.
I wonder which box I put the ELM327 into
main meteor
Hmm, I have wired and wireless OBD-II readers, if you want me to try something out, I'm willing. I should have at least one vehicle with CAN bus.
idle owl
<@&356864093652516868> Here is the notes document for Monday’s CircuitPython Weekly meeting. Everyone is encouraged to attend! Please add your hug reports and status updates even if you’ll be attending the meeting - it’s super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and I’ll read them off during the meeting. Hope to see you there! https://docs.google.com/document/d/1MDbbC35odld_VaqHhBtGVwKkKMIYb89iIbqGFENKcJc/edit
onyx hinge
huh this is weird.
Missing message id. Please run `make translate`
{'incorrect padding',...```locally, my circuitpython.pot doesn't get 'incorrect padding' as a msgid. It is in the source!
and of course when it's not in circuitpython.pot, it doesn't get added to ko.po as untranslated
oookaay, on my system, this invokes "xgettext" twice, so strings from filenames listed in the first invocation can be lost
xgettext -L C -s --add-location=file --keyword=translate -o circuitpython.pot -p locale lib/tinyusb/hw/mcu/st/st_driver/STM32L4x...
TFW when you write a page-long commit message for a 1-line change
main meteor
Heh, reminds me of @ivory yew 's comment a few days ago "I love PRs where the description is significantly longer than the diff."
onyx hinge
@main meteor a-yup
something's still weird, I don't see where in the "checks" it built the individual board FWs. Isn't that done for PRs?
@slender iron can you glance at it if you have the chance?
tulip sleet
@onyx hinge it is just getting started
onyx hinge
or ... it's just really slow to start the jobs?
okay, face, meet egg...
I was extremely tricked by having a green step and no other steps visible
tulip sleet
it's been getting worse; parts of the system don't register that sets of actions have finished
yes, it should point out everything that's queued
this is a v1 thing, not quite ready for prime time
like see here: https://github.com/adafruit/circuitpython/actions
lotsa things spinning: most have already finished. I complained about this and they have an internal issue for it, but not fixed yet
also your korean pr is blocking the new one, probably
onyx hinge
okay thanks for the deets @tulip sleet
tulip sleet
onyx hinge
well that was a bit of a rabbit hole 🐰 goodnight
plucky flint
👋
plucky flint
For those following along at home: https://github.com/ntoll/adafruit_radio
mystic shell
hey all!
i'd like to ask about creating modules with c for micropython
ideally i'd love to mix between arduino code and micropython code, but i know that's theoretically not possible (they have different backends) but might actually be possible (most arduino implementations are wrappers for platform-specific function sets)
but mostly, i'd like to know if there are examples on how to access things like i2c from the c side
onyx hinge
A side effect of the non-finishing actions runs seems to be that the artifacts don't become available either. 😦
@tulip sleet just noticed in the GNU Tools for Arm Embedded Processors 9-2019q4-major Release notes:
manic glacierBOT
Testing performed: built locally for metro m4 express, connected from unicode-capable terminal program, provoked an error:
There are still unavailable characters in the on-board font. I don't know if this should be enough to prevent inclusion of this patch.
main meteor
@mystic shell I think what you describe is fairly straightforward. You should be able to find C I2C code easily enough (it's not a difficult protocol, you can bit-bang it fairly easily if need be). However, I don't have any examples to hand.
onyx hinge
In CircuitPython, the builtin displayio module is an example of using circuitpython's I2C from C code. However, that'll be different than in Micropython.
tulip sleet
@onyx hinge A side effect of the non-finishing actions runs seems to be that the artifacts don't become available either. 😦 Yes, we've been relying on this, and now have to pass .uf2's around for testing.
@onyx hinge re new gccthey are early! usually they don't release until December. Thanks for noticing
plucky flint
Hey... so I'm sooooo close to getting this radio module working (as in "make it work, make it work correctly, make it work correctly with tests and docs").
I'm still at the "make it work" stage. I can broadcast messages. That all works fine. I can also see incoming entries when I don't specify the AdafruitRadio subclass of Advertisement -- I can see the messages broadcast from the other device to the receiving device. However, when I pass in the AdafruitRadio advertising class into the start_scan method on BLERadio it doesn't work. It appears the start_scan method on the instance's _bleio.adapter doesn't like it when there are prefixes from my new AdafruitRadio class.
I get the feeling I'm missing something here... 😉
Any hints...?
Both the sending and receiving devices report that the message is: b'\x1e\xff"\x08\x1a\x01\x00Hello0\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00\x00'
plucky flint
Also, see module here: https://github.com/ntoll/adafruit_radio/blob/master/adafruit_radio.py (which is my attempt at just making something work in the simplest possible way).
NOTE the channel setting/feature isn't yet implemented.
😢 OK found the problem. Rubber ducking into this channel found it for me. 🙂 The culprit can be found here: https://github.com/adafruit/Adafruit_CircuitPython_BLE/pull/33/commits/7a73b104ce495c7342655547af221abbb32fe4b8
manic glacierBOT
plucky flint
@idle owl @slender iron when it comes to this morning's (damn timezones) ;-) meeting, I've a piano lesson pick-up and then I'm myself playing in a rehearsal. I'll be there but would really appreciate it if I can go first. Quite understand if not, I've put all the details in the doc for the meeting. Also, I'll email over a progress report before I finish for the day. TL;DR AFAICT progress = good and the code is v.simple. Standing on shoulders of giants etc... 👍
idle owl
@plucky flint Of course you can go first! Remind me right before the meeting please.
plucky flint
👍 Thank you!
onyx hinge
huh for some reason I thought the bluefruit would be faster than the metro m4 express but it's not in my test
idle owl
@onyx hinge I wouldn't think so, I think the Metro is a beefier version of the M4 chip because there's room for it on the board. But I'm also guessing here.
onyx hinge
OK, now that I check it's 120MHz for the Metro and 64MHz for the CPB
idle owl
Hey I knew a thing!
onyx hinge
that puts these results roughly in line
(( if it's newer it must be faster? not so! ))
I think in my mind I was comparing it to the CPX which is of course not an M4 at all
idle owl
Indeed.
onyx hinge
@idle owl I'll have to leave the meeting promptly at 2 but I don't think that should pose a problem.
that's 3PM eastern to you
idle owl
Might miss out on some In the Weeds action, but nah, it's not a problem. Turns out as long as my laptop doesn't crash, it's recorded 😉
I imagine you shouting "That's 3pm eastern to you!" like "That's MISTER JEPLER to you!"
onyx hinge
hah
idle owl
<@&356864093652516868> Weekly meeting in a little over an hour. Please add your hug reports and status updates to the notes doc even if you'll be attending the meeting - it's incredibly helpful. Thanks! https://docs.google.com/document/d/1MDbbC35odld_VaqHhBtGVwKkKMIYb89iIbqGFENKcJc/edit
plucky flint
Work in progress: https://www.youtube.com/watch?v=0tp9eBxQTyk
ionic elk
@tulip sleet can I bother you with a C question or are you setting up for the meeting
onyx hinge
@ionic elk is it worth just asking the whole channel?
idle owl
@ionic elk Currently in a meeting.
ionic elk
@onyx hinge if you're down! I'm trying to figure out the following snippet of code:
#ifdef MICROPY_HW_NEOPIXEL
const mcu_pin_obj_t* neopix = MICROPY_HW_NEOPIXEL;
//if (pin_port == MICROPY_HW_NEOPIXEL->port && pin_number == MICROPY_HW_NEOPIXEL->number) {
if (pin_port == neopix->port && pin_number == neopix->number) {
neopixel_in_use = false;
rgb_led_status_init();
return;
}
#endif
the commented line throws a compiler error: invalid type argument of '->'
which is weird because a) this works in every other port and b) even the debugger and print messages show that the neopix variable and the macro are identical
onyx hinge
@ionic elk this is in stm32 I assume, with code shuffled over from samd?
can you show the line which #defines MICROPY_HW_NEOPIXEL?
ionic elk
I'm running into it in the stm32 port, it's not strictly based off either other implementation, it's just trying to use a macro like they do
#define MICROPY_HW_NEOPIXEL &pin_PC00, which is the same as other ports
onyx hinge
ports/atmel-samd/boards/winterbloom_sol/mpconfigboard.h:#define MICROPY_HW_NEOPIXEL (&pin_PB03)
can you try adding the parens as in this random case?
ionic elk
is it the parenthesis?
onyx hinge
I am betting that &a->b is &(a->b), not (&a)->b due to operator precedence
ionic elk
yep that was it, thanks!
onyx hinge
you're welcome
ionic elk
yeah I should have spotted that. Good to remember for preprocessor use
onyx hinge
so I'd say general C advice is that a #define should be parenthesized unless there's a specific reason it shouldn't
It's easier to see when it's #define FOUR 2+2
as 2*FOUR is now 6, not 8
ionic elk
yeah it's a good point, I was probably thrown off by how many stm32 functions take &a->b as an input, but they actually want the &(a->b).
onyx hinge
@idle owl we can hear each other, you aren't hearing anybody?
idle owl
Yeah I can't hear anything. Troubleshooting now.
onyx hinge
everybody with a clicky keyboard: unmute now and type
plucky flint
@idle owl we can hear you tap dancing... 😉
cunning crypt
New work schedule means I can actually join in! Just listening today, though, so no hug report/status update
onyx hinge
is the state of CJK support in CP such that "double wide" glyphs aren't supported? and that's part of why the Chinese translation chose Pinyin?
sterile bronze
lurking
tulip sleet
i am not sure we need utf16 support, which we'd probably want to have, or if it's just lack of glyphs
new joiners: still debugging audio
turbid radish
We can hear you Kattni
onyx hinge
foley work continues
river quest
oh, while we're hangin out, hug report to @onyx hinge for startin to do more work with adafruit!
onyx hinge
@river quest right back at you
solar whale
we can skip recording and just request it from the NSA afterwards 😉
wraith tiger
Just lurking
onyx hinge
@tulip sleet "double width" refers to how things are rendered in fixed-width terminals, not to in memory representation
turbid radish
It'll be a few minutes folks
onyx hinge
pearl notch
If we’re still using it, folks could add their info to: https://docs.google.com/spreadsheets/d/1NWwiUuQnam_abdv02ugLxz9uFrvhtMfy8U306HJ4_qU/edit#gid=0
tulip sleet
@onyx hinge I didn't mean to connect double-width with utf16, but I have a vague memory that we didn't have utf16 support which we needed for the CJK support, (or it would be very helpful for space reasons). But I think the main thing was lack of Korean glyphs even for the syllabic alphabet
we don't need that many glyphs for Korean, but we didn't have the Korean glyphs merged into the terminal font
idle owl
Rebooting.
onyx hinge
oh is it time to talk about how I'm planning to build my own keyboard (cherry mx brown)? the enclosure is 3d printed.
turbid radish
I have Cherry Blues I think
plucky flint
The keyboards I most prefer have 88 keys and come in black and white... 🙂 🎹
turbid radish
I have an IBM Model M but it has the IBM original PC keyboard plug
tidal kiln
oops. was heads down in the forums. here now but lurking.
ohh. looks like maybe i'm just in time 🙂
cunning crypt
@turbid radish Just do something like this! https://www.geek.com/wp-content/uploads/2010/08/500x_chain-usb1-500x352.jpg
onyx hinge
this is the THing: https://www.thingiverse.com/thing:3478494
plucky flint
I worked at The Guardian when the Snowden revelations were in full swing. When MI5 came to the offices to destroy the hardware (laptops) containing the data, they made especially sure to destroy the chips related to the keyboard (buffers?).
turbid radish
Does that combo even work??
onyx hinge
@turbid radish my Model M has a PS/2 keyboard connector which still works on my newest desktop, happily
cunning crypt
@turbid radish Highly doubt it
plucky flint
Dvorak is a pretty awesome composer. Hated tuba players tho... I only get 14 notes in the whole of Symphony No.9 😉
turbid radish
@plucky flint - interesting......
plucky flint
The journalists took videos of the MI5 folks destroying things, and there was a LOT of speculation about why they destroyed such-and-such a bit and not some other bit.
turbid radish
I've destroyed computers for security in the distant past
onyx hinge
no, kattni, we were all replaced by robots. it is beautiful and serene. join us.
plucky flint
@idle owl I'm afraid I have to step away... youngest needs picking up in 10 minutes... 😦
river quest
that was exactly 10 mins too
wraith tiger
BTW, those of you who are into MIDI & music. There's a YouTube channel I discovered recently called Mitxela: https://www.youtube.com/channel/UCeEf90AEmmxaQs5BUkHqR3Q
plucky flint
@idle owl 👍
river quest
i was able to set that up, hah
cunning crypt
@river quest You know your stuff
plucky flint
ciao ciao folks... perhaps next time... 👋
cunning crypt
"It'll take 10 minutes" ten minutes later "It's done!"
river quest
i just need 1 more min to get back to other computer, etc
idle owl
@river quest If you're actually talking, I can't hear you
turbid radish
I cannot hear Phil either
idle owl
ok
pearl notch
This is a fun way to make electronic music with Ruby: https://sonic-pi.net/
onyx hinge
@river quest knows how long it takes to install software, but not how long it takes to walk to the other computer
pearl notch
I’m using it with my students.
idle owl
@river quest Let me know when you're ready.
pearl notch
Pointer to example of reading serial input with CircuitPython? On CPX.
meager fog
SuperCon was over the weekend, will be posting up coverage and more soon!
https://twitter.com/hashtag/supercon?src=hashtag_click&f=live
https://twitter.com/makermelissa/status/1196456972620455937
Twitter
turbid radish
meager fog
Simple byte and string based inter-device communication via BLE
https://twitter.com/ntoll/status/1196493256164610049
https://youtu.be/0tp9eBxQTyk
https://github.com/ntoll/adafruit_radio
Arm AIoT Dev Summit December 2 – 3, 2019! Python badges (and more will be there)...
http://arm.com/AIoT-Dev-Summit
Sophi Kravitz keynote speaker – 2020 Open Hardware Summit, Adafruit is a sponsor:
https://2020.oshwa.org/speakers
Explore Hardware (old and new) with CircuitPython with Scott:
https://youtu.be/NMKm5Zj31jU
Take Flight with Feather - Hackaday and Digi-Key:
https://hackaday.io/contest/168107-take-flight-with-feather
Check out the 25 entries here!
https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2019-11-19-draft.md#take-flight-with-feather---hackaday-and-digi-key
turbid radish
I am posting 2 entries per day on the Adafruit blog
meager fog
Makerspace survey: they’re looking for members and leaders of makerspaces (whether they be makerspaces, biospaces, hackerspaces, art spaces, you name it, wherever they are at) to fill out the annual survey so they can continue their work of creating a longitudinal dataset that tells them about the impacts that these spaces are having across the country and around the world:
https://makethedata.org/take-the-survey/
GitHub Archive Program - Preserving open source software for future generations. Get your code into the GitHub Arctic Code Vault by 02/02/2020
https://archiveprogram.github.com/
All this and more - https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2019-11-19-draft.md
onyx hinge
someone in 3020: we finally found that last bug in circuitpython 5!
solar whale
@pearl notch are you looking for uart example? https://learn.adafruit.com/adafruit-circuit-playground-express/circuitpython-uart-serial or just read via REPL data=input()
cunning crypt
(Lurking)
sterile bronze
lurking
trim elm
Lurking
tidal kiln
yep
swift arrow
lurking
old smelt
I just lost audio...
pearl notch
Nice, Jeff!
turbid radish
Yay Jeff!
old smelt
Ugh, sorry all. I heard kattni hand the baton to Hierophect and then lost all audio.
Have to head to a 2:00 meeting. Have a great week!
wraith tiger
lurking
ionic elk
if I drop out before or during my update it's cuz internet
turbid radish
If you're a CircuitPython fan and are not a subscriber to the Adafruit Python on Hardware newsletter, please consider joining. No spam, your email is never sold, just one newsletter post a week with all the CircuitPython/MicroPython/Python news, projects, and events.
Subscrive at https://www.adafruitdaily.com/ and click the Python on Microcontrollers Newsletter.
swift arrow
yes
pearl notch
Too close to mic now
turbid radish
You can contribute to the Python on Microcontrollers newsletter by doing a PR for the latest version on GitHub at https://github.com/adafruit/circuitpython-weekly-newsletter/tree/gh-pages/_drafts
pearl notch
We need Goldilocks
onyx hinge
👋 gotta 💨
turbid radish
Are you a fan of Reddit? We have a CircuitPython subreddit full of information updated daily.
Please join us at https://www.reddit.com/r/circuitpython/
Or are you a Twitter fan? Follow @river quest and @CircuitPython for CircuitPython goodness.
pearl notch
tulip sleet
@inland tusk, is it "sunbox" synth? not sure of spelling
pearl notch
I’d love ideas on make the physical “bars” of the bar chart.
swift arrow
@tulip sleet were you saying there is going to be a CP 5.0.0 alpha 0? That will have the BLE api changes coming soon?
tulip sleet
beta.0
swift arrow
ahhhhhhhhhhh
I was trying to figure out how we were going from Alpha 5 to 0 🙂
makes sense.
really looking forward to that and helping to beat on it once it drops
tulip sleet
@ionic elk Limor requests: Could you do urandom first, and then add all those boards?
tulip sleet
@onyx hinge You could do some quick sample builds and see if gcc9 update gives any significant space improvement on M0 builds. Otherwise we can hold off for a while.
onyx hinge
@danh ok I'll look at size and performance
solar whale
@plucky flint fired up the ble radio example on a pair of CPB -- works great!!
meager fog
@onyx hinge ok sounds good, once those two are PR'd (or abandoned :), ping me if you have more time for the week and we'll figure out whats next!
onyx hinge
Will do!
meager fog
@ionic elk ok your next todo after you're happy with neopixel is urandom
the rest are more structural, you'll want to wait till scott is back around
solar whale
@plucky flint even got a "3-way" going with 2 CPBs and an nrf52840_express -- no problems with multiple senders/receivers -- posted example to your repo
solar whale
hmm -- haven't tried moving about much -- I'll try now
several meters works fine -- at about 10m - the receive rate seems to drop off -- but still receives.
can't get much farther -- my house is not that big
that was transmitting from nrf52840 express -- receiving on CPB
over 10 m -- get nothing
very rough estimates - and walls
I can try to be more systematic later - or tomorrow,
tulip sleet
@ionic elk I can send you a movie. I'm having trouble getting the board into DFU mode. It worked once, and I loaded it, but now it's flaking out again
ionic elk
I'm not super up to date on DFU stuff! I've been meaning to spend some time on it and I'm ready to do that whenever, but I've always simply been a heavy STLink user
tulip sleet
@ionic elk top movie is when ready to enter REPL. You can see the brief flash on each cycle of the pulse. Bottom is in REPL, just very bright
ionic elk
Yeah that's visibly not the behavior I ahve
tulip sleet
i'm reloading my .bin, will try yours in a minute
ionic elk
Is it possible that it's a different edition of the neopixel, and I haven't hit the sweet spot of compatibility? I noticed there were mentions of timing differences between the WS2812 and WS2812B in the nrf port
tulip sleet
well, I think our boards were made around the same time
have to Saleae the output and check what the clock rates are
ionic elk
if you figure out a way to get a saleae hook on the neopixel please send pics of that too😆
tulip sleet
i can try external neopixels in a bit; still trying to get it into DFU mode
ionic elk
do you not have a stlink available?
tulip sleet
what I have done in the past is to redirect the neopixel pin to another external pin so I can monitor it there.
sure, I do, but I haven't soldered the SWD header on the board yet
ionic elk
not to imply we shouldn't get dfu working properly
yeah you need to use it with extension headers too since it won't fit in a breadboard after you do
tulip sleet
i have to go out in about half an hour and will try again tomw
ionic elk
k
solar whale
@tulip sleet I have had trouble getting to DFU mode. So far it has worked after a few failures. Not sure why.
tulip sleet
it's mysterious. I solder a header on (had to trim one end to make it fit, and am now seeing if my header soldering is any good
solar whale
I’ll try more systematic testing of DFU tomorrow and report.
tulip sleet
ok, GDBServer success
@ionic elk could you pass me a firmware.elf?
from your own build?
ionic elk
lemme get my urandom PR up real quick here
tulip sleet
np, i have to leave imminently, just drop it here when you have a chance
ionic elk
ok, thanks dan
tulip sleet
reloading via j-link gives the same neopixel effect, so it's not a load problem
ionic elk
hmmm
onyx hinge
@ionic elk for scoping you could redefine the neopixel to be on an exposed pin that is easy to probe
manic glacierBOT
