#circuitpython-dev
meager fog
ionic elk
@meager fog sure thing. Are you still getting that I2C display error? rigging that up now
meager fog
@ionic elk yah i have moved on to test other sensors
ionic elk
oh darn it I don't have an I2C one, just the SPI version. And the little one doesn't have the I2C jumpers
meager fog
@ionic elk ok plz get....
yeah thats a good range
one of each, then you can test i2c/spi very well
ionic elk
You want me to stick to 1 or 2? With 2 I can have a parallel control with a SAMD. But either is fine
I'll stick to 1 that's a lot of boards
timber mango
Is anyone else playing with the Serpente CircuitPython boards?
tawny creek
@timber mango got an inquiry?
timber mango
Mine don't seem to be functioning like other CP boards I've used in the past. The serial port isn't responding, and the reset button doesn't respond either, but they show up as drives OK in Windows 10
tawny creek
how are you trying to connect via serial? Mu? Terminal?
timber mango
serial, the port shows up, but nothing comes across
Putty with 9600 baud to be specific
tawny creek
I haven't actually tried Putty for Cp stuff.. imma try
timber mango
Wait
What's it called when you try several times before asking for help, then it starts working?
Serial is responding ๐
tawny creek
haha walkiing the duck? or something
Next time, try Ctrl+D or C ... maybe it was running some code? with no output
timber mango
It's my sample code so it's likely all me ๐
ionic elk
@meager fog you know what? I bet it's a timeout error
All hal functions have timeouts. If it takes a super duper long time, maybe it exceeded my timeout value
I'm going to throw in a cheap cheaty fix for it, could you try the I2C one again and let me know if it works?
Also, I'm sorry to ask this but could you throw in another feather in the RMA if you have one? I didn't have those stacking headers for the existing one, and I won't be able to plug in any of those nice wings ๐
ionic elk
Yep I just put one in, can you pop the F405 in there?
meager fog
its an assembled f405 feather
ionic elk
you and PT are forwarded
meager fog
gr8
ionic elk
Commit with my I2C fix is also live in branch
Let me know if it fixes the problem. Otherwise I'll probably revert it to avoid breaking anything else accidentally
meager fog
ok one moment
im testing airlift which is intense
ok there's also some max-buffer issue in SPI
meager fog
code.py output:
ESP32 SPI webclient test
ESP32 found and in idle mode
Firmware vers. bytearray(b'1.2.2\x00')
MAC addr: ['0xa0', '0x7c', '0x12', '0x12', '0xcf', '0xa4']
Adafruit RSSI: -53
Adafruit RSSI: -58
embedded RSSI: -63
consulatewireless RSSI: -64
Consulate Guest RSSI: -64
Adafruit RSSI: -65
Consulate Guest RSSI: -66
consulatewireless RSSI: -67
consulatewireless RSSI: -72
Consulate Guest RSSI: -72
Connecting to AP...
Connected to Adafruit RSSI: -58
My IP address is 10.0.1.191
IP lookup adafruit.com: 104.20.38.240
Ping google.com: 10 ms
Fetching text from http://wifitest.adafruit.com/testwifi/index.html
----------------------------------------
This is a test of Adafruit WiFi!
If you can read this, its working :)
so that can't be it
meager fog
but...
----------------------------------------
Fetching json from http://api.coindesk.com/v1/bpi/currentprice/USD.json
Traceback (most recent call last):
File "code.py", line 54, in <module>
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/helpers/requests/adafruit_requests.py", line 270, in get
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/helpers/requests/adafruit_requests.py", line 236, in request
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/helpers/requests/adafruit_requests.py", line 220, in request
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi_socket.py", line 106, in readline
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi.py", line 679, in socket_read
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi.py", line 315, in _send_command_get_response
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi.py", line 304, in _wait_response_cmd
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi.py", line 302, in _wait_response_cmd
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/esp32spi/adafruit_esp32spi/adafruit_esp32spi.py", line 254, in _read_bytes
OSError: [Errno 5] Input/output error```so like, when we fetch a big-ass file, it fails ๐
we need to split up the SPI transactions, so when we request like, 1024 bytes
it will chunk em into smaller bits
still, very impressive it got that far ๐
ionic elk
Is that something the other ports can do?
meager fog
i dont know for sure but i assume so
there's usually a limit to how much a HAL can transfer in i2c/spi
for example the ft232h can only do max 16KB
that's a question scott/dan can help with more
ionic elk
I'm not using DMA for my current implementation
its possible it could do more with that
meager fog
that makes it easier
try transmitting/receiving larger and larger buffers
until you hit the ioerror
ionic elk
I'll make a project out ofit
meager fog
ok for now im ok with merging what we got
meager fog
and make an issue to investigate - you can test the i2c buffer stuff with the OLED, and the spi buffer stuff you'll hit with the airlift
ionic elk
I'll make it a new issue
meager fog
nice!
ionic elk
yeah that
meager fog
featherwings make it easy to test, at least. pop em on
ionic elk
It's my first time using them, definitely looking forward to the handyness
Still want to make an Omnitester with Circuitpython with my crosspoint switch, but it's a bit slow going
ionic elk
A board that'd let me plug any breakout in and test it
meager fog
intense!
ok i gotta get ready for shows
much success, we can now really test those peripherals
good work today!
ionic elk
Thanks! Did you get a chance to run that last I2C test before you head out?
ionic elk
oooh is travis no good
meager fog
it only generates files on success
ionic elk
I don't know what it's deal is it's griping about a file I made no changes to ๐
Anyway we can put it off to tomorrow or whenever I know show and tell is coming up
meager fog
i think when you added the new SPI chip
maybe some entry is missing from the table
so its included but then causes some parsing error
ionic elk
yep just fixed it
meager fog
@ionic elk ok we can check later
raven canopy
AWS administration is way more involved than i imagined... ๐ฌ
ruby atlas
@raven canopy depends what you're doing, but... ya...it is. "cloud" is not the magic panacea of simplicity that people claim it is.
raven canopy
hehe. i just wanted an S3 bucket to test deployments on, instead of just "pushing to prod".
though i will say, Azure isn't that much easier in the little experience i have there too.
errant grail
StringCar M0 Express: It's alive and running CircuitPython 5.0.0-alpha.4-127-g25232cc5b with just two PCB bodges. I'll submit it as a CircuitPython board after the revised PCB is tested.
(A scrap from the Blinka sticker was used to diffuse the 5050 DotStar.)
tawny creek
That's a nice tip @errant grail !
meager fog
@ionic elk the SSD1306 / I2C issue is now fixed, good debugigng!
meager fog
@ionic elk i dont see issues you've made for the bugs we've found today
please put in bug/issues asap when we find them because otherwise they can be forgotten
ionic elk
I will first thing tomorrow, sorry! I have them all down on various post-its, I'll make sure they all go up
manic glacierBOT
manic glacierBOT
orchid basinBOT
broken hedge
Hi. Iโve got about 100 CPXbfs enroute and hope to start intro exercises with new-to-code uni students. Where is the best place to share issues with CircuitPython 5a4? Will an express lib be available? When I include from adafruit_circuitplayground.express import cpx I get an error โhome/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/drivers/circuitplayground/adafruit_circuitplayground/express.py", line 53, in <module>
ImportError: no module named 'audioio'โ. Was going to use Bluetooth so I have been assuming sticking with v5 makes sense, but advice is appreciated. Thx
stuck elbow
@broken hedge I think the adafruit_circuitplayground.express library doesn't have support for the bluefruit boards yet
ionic elk
@meager fog if you have a minute today, you could check out my commit to #2186 and see if it solves the SPI data cap issue
manic glacierBOT
meager fog
@ionic elk will do!
i got the feather working with micropython last nite, was fun!
today will try arduino
@ionic elk solved!
----------------------------------------
{'time': {'updated': 'Oct 3, 2019 16:32:00 UTC', 'updatedISO': '2019-10-03T16:32:00+00:00', 'updateduk': 'Oct 3, 2019 at 17:32 BST'}, 'disclaimer': 'This data was produced from the CoinDesk Bitcoin Price Index (USD). Non-USD currency data converted using hourly conversion rate from openexchangerates.org', 'bpi': {'USD': {'code': 'USD', 'description': 'United States Dollar', 'rate_float': 8177.78, 'rate': '8,177.7767'}}}
----------------------------------------
Done!```is that the SPI block?
ionic elk
Yay!
meager fog
ill try an eink next
manic glacierBOT
ionic elk
Ok yeah so it sounds like it was just the timeout triggering on really big transfers
I took it up from like 2ms to 500 so that should cover everything... right?
No 1 second long single I2C transfers I should be worrying about?
meager fog
500ms is plenty for now
lets see, if we have 100khz that would be...
10 kbps
5KB - yeah i think thats ok
is there a way to know if it was a timeout from the HAL
or a general failure?
meager fog
@ionic elk ok with that PR done, whats next?
ionic elk
Cleanup or UART/DAC?
I put up a bunch of issues this morning
Some higher priority than others
meager fog
ok lets look!
alright dont forget to add an issue for the missing 'random' module
thats not os.random its different
ionic elk
That's fine. Let me do that one right now, I think this is a pretty high priority/low effort issue
meager fog
okidoke
ionic elk
For the others, anything in particular you'd like me to tackle right now, or should I just skip right to UART?
And do them after DAC?
meager fog
@ionic elk nah skip em, go to UART
ionic elk
Sounds good, I'll get right to work then.
meager fog
add an issue to remind yourself to add the default I2C/SPI/UART busses
so you can call board.I2C()
ionic elk
yeh it's up there
meager fog
there's RX/TX uart pins
meager fog
nah not necessary
might as well wait till uart is done
then do it after, so its easy to test completely
ionic elk
reasonable
meager fog
uart will likely be a fairly straightforward peripheral
ionic elk
here's hoping, I said that about I2C, and then I ran into the eratta x_x
ionic elk
@meager fog should I wait on @slender iron to submit the SPI PR or do it now?
meager fog
@tidal kiln ok when ya hav ea moment lets archive that max library
and then i hvae a QUEST
@ionic elk leave the PR as is - when he's available he'll review it. you can work on UART in a separate branch/PR
yay
tidal kiln
@meager fog ok. gotta go deal with a water/house thing. want me to ping you later?
tidal kiln
w0rd
meager fog
its optional side quest but i think fun
slender iron
@prime flower https://forums.adafruit.com/viewtopic.php?f=60&t=157080
prime flower
@slender iron Thx, replying after lunch. I know the issue, libs arent up to date (new version of mmqt needs to match up with latest esp32spi)...shouldnt have broke though
lone sandal
pearl notch
@idle owl , @slender iron , @errant grail Hi again. I added some timings to the note playing code and discovered that, as I originally thoughtโthough as a result of a faulty reading of the codeโa new sample is generated for each pair of start_tone/stop_tone. Take a look: ```
def stop_tone(self):
โฎ
self._sample = None
Without regenerating, things are much faster.
Generate sample: 0.092773 Start (including generating): 0.0947266 Stop:0.0107422
Start: 0.000976563 Stop:0.0332031
Start: 0.000976563 Stop:0.0458984
Perhaps I should create an issue for this, where I can document everything in one place, and get advice.
tough flax
Great new on the XAC support changes! Thanks @tulip sleet and @slender iron!
meager fog
@slender iron we need to have pulseio for stm before we can enable displayio rite?
slender iron
@meager fog ya, for backlight I think
@pearl notch interesting! Ya, an issue would be good
pearl notch
Listen to the before and after
pearl notch
Thatโ s a simple, compatible change to stop_tone, adding a clear_sample keyword parameter:
def stop_tone(self, clear_sample=True):
if self._sample is not None and self._sample.playing:
self._sample.stop()
if clear_sample:
self._sample.deinit()
self._sample = None
But perhaps the sample never needs to be cleared. Iโll create an issue.
meager fog
@ionic elk ๐ ok how is UART looking
ionic elk
I've gotten my control setup done, and then took a quick diversion to get that random PR up
Moving on to reading the HAL docs now
meager fog
@ionic elk kool thanx
tidal kiln
@meager fog ping. ok. im back.
meager fog
@tidal kiln hihi ok i archived the max31855 repo so thats done
quest is - make a subclass or new class of https://github.com/adafruit/Adafruit_CircuitPython_NeoPixel/blob/master/neopixel.py that uses an SPI port to send neopixel data, instead of neopixel_write
so if you have, say, an FT232H, you can control neopixels with it
tidal kiln
side quest accepted
meager fog
first thing you have to verify is that bytes are sent in perfect sequence
start with making a simple SPI writing test that writes 3 bytes, look at the clock pin, it should be a contiguous square wave
tidal kiln
for the neopixel timing requirements
meager fog
@tidal kiln yes
tidal kiln
@meager fog ok. added a basecamp. so can add progress updates there, etc.
meager fog
@tidal kiln nice!
tidal kiln
and thanks for doing the housekeeping on the old MAX repo
meager fog
@tidal kiln yep! next is LSM303
but ya can take a break to do this more-fun-hacking quest ๐
@tidal kiln do you have an LSM303 sensor? if not plz order
tidal kiln
yep. have a PID1120.
pearl notch
I havenโt yet clearly explained what Iโve done, but perhaps some of @slender iron , @idle owl , @tulip sleet , and @errant grail will take an early look. https://github.com/adafruit/Adafruit_CircuitPython_CircuitPlayground/pull/71
ionic elk
@meager fog should I be using ST's UART or USART drivers for the module? They're distinct on the F4. USART is a superset with the synchronous option but is higher power than the UART.
meager fog
@ionic elk higher power is ok
raven canopy
New GitHub review feature. ๐ GitHub!
amber bronze
Hopefully multi-line suggestions is soon to follow ๐
ruby atlas
it's odd to click in here and see recent activity be mine...
crimson ferry
@sly falcon I'll be afk again this w/e, but Discord mention will get my attention ๐
sly falcon
@crimson ferry sounds good. I didn't have time this week to do more than read some code...I'm planning on actually doing some coding this weekend ๐ค hope you have a good weekend!
crimson ferry
@sly falcon Thanks. You too. I'll be around more after this one for awhile.
pearl notch
Back on the CPX audio fun: A square wave requires just two points per sample (vs. 100 currently used for the sine wave), and itโs much louder. @idle owl, did you consider other waveforms than sine?
meager fog
@pearl notch doesnt sound as nice ๐
stuck elbow
actually I like square wave sound more, it's more like computer games
pearl notch
Hi @meager fog. Are you speaking generally, about the sound of square waves vs. sine waves, or after hearing the sound from this program running on a CPX? I can see the sine and square waves on ground and A0 on the oscilloscope (thanks @errant grail , for that suggestion), but when I record the sound coming from the speaker and look at that wav file in Audacity, the waveforms look very different. I assume itโs because of resonance or something.
errant grail
@pearl notch In my experience, square waves are harmonically rich and can pierce through the spectral bandwidth limitations of some speakers. Depending on the output device, the fundamental musical tone of a square wave can occasionally be obscured, depending on frequency. A triangle or sawtooth waveform may be a way to compromise, preserving more of the root tone (that a sine wave naturally produces) while maintaining enough harmonic content to help with listenability.
pearl notch
Interesting, @errant grail , thanks!
slender iron
@tulip sleet I realized that scan() should return an iterator in the shower this morning
that way you can read results as they come in
meager fog
@ionic elk hihi lemme know if yr workin today and how UART is going
ionic elk
@meager fog workin, punchin in pin defines and excessive macro ifdefs
meager fog
@ionic elk okidoke!
let me know when you want me to test a PR and ill toss it onto my feather
ionic elk
@slender iron I'm getting weird non-ascii stuff in my terminal instead of my messages. It didn't happen with the atmel feather. Do you have any ideas what that could be? Stuff like "hัช(Ajm&--hัช(Ajm"
slender iron
is that over usb or uart?
ionic elk
UART
slender iron
with uart it's likely a baudrate mismatch
ionic elk
that's what I thought but everything is lined up
ionic elk
I tried moving it to ASCII, but I just get different garbage
slender iron
what is producing the uart data?
ionic elk
It's the HAL_UART_Transmit() function, which transmits an array of uint8_t, running on the F405
It produces the same characters if I pass in a b"string" in my python code, or if I declare a const char array "string" in c right before the transmit function and pass that instead. So at least it's consistent.
slender iron
and then you read it back in on rx?
ionic elk
I'm reading it with an ft232. But that's a good idea, I should try a linked transfer and see what that looks like
oh, hmmm. We don't have a uart transfer function
slender iron
maybe the transmit is the incorrect baudrate
a logic analyzer can usually guess the baudrate
ionic elk
Yeah I can try that next
I notice the UART management is very different from the I2C and SPI systems across both ports. NRF uses interrupts, and atmel also seems to have an unusual buffering system.
Whereas ST just handles it the exact same way as the other two. So I'm struggling a little bit to make it fit, because there's no way of knowing in ST land how many characters you received, for instance.
I might have to go LL again for this one
slender iron
that seems weird it doesn't tell you character count
slender iron
what function are you using for it?
ionic elk
HAL_UART_Transmit()
just to get things up and running - there are IRQ and DMA options as well, as with all STM32 peripherals
Seems that micropython goes the raw register route, and just cycles waits on the TXEmpty and RXNotEmpty flags to read things one at a time.
slender iron
ah, and always reads the full length?
slender iron
@ionic elk you can always read one byte at a time
ionic elk
That's true, I could have a blocking loop for it. That won't play nice with reading from itself, though I guess that's not a huge priority
slender iron
write blocks anyway
ionic elk
So if I tried to write to myself, it would never complete, right? Because the write would be waiting on read? (I can read through the whole documentation of it again, just trying to get a sense)
I should just look at the HAL transmit_recieve function, see how that does it
slender iron
I wouldn't worry about it. in practice you'll never do that
whether it works depends on the implementation and if it buffers the read
raven canopy
first time i've even looked at STM HAL: can you not access the UART_HandleTypeDef->RxXferSize/Count? https://github.com/adafruit/stm32f4/blob/master/STM32F4xx_HAL_Driver/Inc/stm32f4xx_hal_uart.h#L141
raven canopy
nope. nevermind. it just returns the status.
manic glacierBOT
timber mango
Do you wait for the tx buffer to clear? Don't know how big it is, may e 1 byte? This definitely works on STM32F407:
ionic elk
Yeah checking the flags is no problem. I'll simply have to loop and increment how many bytes have been read.
swift arrow
If we are using the new CPX bluefruit with CP 5.0 Alpha 4.. can we use the libraries from https://circuitpython.org/libraries for CP 5? or do we still need to pull the Adafruit_CircuitPython_Ble from https://github.com/adafruit/Adafruit_Circuitpython_ble?
idle owl
@swift arrow For the BLE lib right now, you want the pre-release which is only available at the link you included.
tulip sleet
@slender iron I started pulling the thread on moving vfs from extmod, and it continues to unravel, because most of the file reading/writing code in various native modules is oofatfs-specific. Looks like I really should make all that code be filesystem-agnostic, so I'll start to do that. If you have any comments let me know.
OnDiskBitmap and AudioFile and main.c are using oofats calls, but probably should be using stream objects, to generalize the reads.
raven canopy
@gilded cradle we're were both ๐ like a hawk i'm sure. this is a good sign:
creating circup-0.0.3/circup.egg-info
copying files to circup-0.0.3...
copying CHANGES.rst -> circup-0.0.3
copying MANIFEST.in -> circup-0.0.3
copying README.rst -> circup-0.0.3
copying circup.py -> circup-0.0.3
copying setup.py -> circup-0.0.3
๐ค
gilded cradle
It worked
raven canopy
๐
swift arrow
@idle owl I got it working. I am doing the Blog tie thing from John Gallaugher.. except only using the CPX bluefruit's Neopixels. It's very cool.. I have gotten it to lock up, so I'm curious if that happens to others.
Traceback (most recent call last):
File "code.py", line 241, in <module>
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/helpers/bluefruitconnect/adafruit_bluefruit_connect/packet.py", line 128, in from_stream
File "/home/travis/build/adafruit/Adafruit_CircuitPython_Bundle/libraries/helpers/bluefruitconnect/adafruit_bluefruit_connect/packet.py", line 89, in from_bytes
ValueError: Bad checksum
That is from https://pastebin.com/KEfHiqW3 running on my CPX Bluefruit Alpha.. with CP5 Alpha 4 (from today) and a mix of the CP lib for 5.x and the adafruit_bluefruit_ble from github.
raven canopy
@swift arrow /home/travis/build/adafruit has me rather confused... leads me to believe that its due to how the bundle is being created. looking at the code though, nothing is jumping out at me that would cause a namespace to look like that. i'll dig more over the weekend (but i have no hardware to test with)
swift arrow
@raven canopy it's the adafruit_circuitpython_ble that we have to get from outside the regular lib bundle.
raven canopy
right. but it runs through the same bundler script as the "big bundle" when its released. all of which happens on TravisCI.
swift arrow
ah
I have not looked at the source.. but what if it did get a bad packet.. should it error out or just drop it and wait for the next?
since it is in a library.. there is nothing a user can do
raven canopy
it may have to do with the fact the library is labelled as a "pre-release", which is handled a little differently.
looking at the code, it does in fact raise the exception if the packet checksum fails: https://github.com/adafruit/Adafruit_CircuitPython_BluefruitConnect/blob/master/adafruit_bluefruit_connect/packet.py#L89
swift arrow
if a bad packet was to come in
raven canopy
on the user side, you could wrap it in a try and catch the ValueError.
swift arrow
hmmm.. maybe I will "try" and modify the test code I am using to use a try.. and see if that helps
raven canopy
try:
packet = Packet.from_stream(uart_server)
except ValueError:
continue # or pass or however you want to handle it
gotta run. ๐ฅ time...
swift arrow
thanks for the ideas!
so far so good.. just had to change one part of the code.
if this keeps working I'll let John know for his guide that is on the Adafruit Blog
upbeat plover
will that new I2C security chip be able to store secrets.py for wifi logins?
manic glacierBOT
quasi fjord
@upbeat plover maybe, but it wouldn't gain you much because you'd still have to read it into python and send it to the esp in the clear. If your WiFi is a complicated enterprise setup that uses certificates you could probably extend the ESP firmware to request that python ask the security chip to do the certificate authentication magic, but ain't nobody got time fo that.
pearl notch
Trying 50 different volume levels now, with the square waveform. The waveformโs amplitude keeps increasing, but the measured volume caps around 50%. Why? https://youtu.be/1hEdERoDkVY @errant grail
quasi fjord
you're probably hitting the mechanical limits of the buzzer. It's probably incapable of moving any more air
pearl notch
Thanks, @quasi fjord . An experiment comes to mind: try again in warmer air, or helium.
pearl notch
Iโm hoping that Monday we can get into the weeds with this: https://www.youtube.com/watch?v=j1VUJFcSD30
errant grail
@pearl notch Interesting experiment but not too surprising given the increased spectral energy of the square wave as compared to sine and triangle waveforms.
broken hedge
@swift arrow thanks for improving the Python tie with the try. Just merged. I was noticing too many presses from Bluefruit crashed things. This is helpful. Cheers!
swift arrow
@raven canopy and I were discussing if it was an issue with the library and he was just like "why not try a try" ๐
I learn a lot hanging around here. That is a great project/Guide you made. Kudo's!
I changed it to just use the neopixels on the CPX Bluefruit as I really wanted to learn about BLE. Very cool stuff
idle owl
<@&356864093652516868> Here is the notes document for Mondayโs CircuitPython Weekly meeting. Everyone is encouraged to attend! Please add your hug reports and status updates even if youโll be attending the meeting - itโs super helpful! If you are unable to attend but would still like to include updates, feel free to include them in the notes and Iโll read them off during the meeting. Hope to see you there! https://docs.google.com/document/d/1suvCpQSY2tuw4wjyZ9G-BFId2iovcZSiA07r3W7gmrs/edit
gilded pewter
which microcontroller supports cicruitpython and has the capability of wireless programming like ble?
exotic pumice
nrf52840 has ble
ruby atlas
@slender iron I've managed to make subclassing mostly work for pixelbuf. The one thing left is figuring out how to call a python override from the native class? I've tried mp_load_method then mp_call_method* and mp_call_function_1 but feel like mp_load_method is the wrong thing here. I'm spending some time in the debugger hoping to figure out the right calling convention ๐
slender iron
@ruby atlas I've not done it before myself. I think it's something like that
ruby atlas
@slender iron any tips for debugging what object instance self_in refers to in gdb? ๐
raven canopy
@ruby atlas i've used display pointing at the object struct indexes...
ruby atlas
@raven canopy what file should I look at? (I'm working on making _pixelbuf subclassable, and i'm having issues calling the python show() method from the native PixelBuf class. Specifically, from non-subclassed methods on the native, I'm trying to call the .show() during auto_write=True)
raven canopy
my best guess would be pixelbuf_pixelbuf_type. so with an instance of pixelbuf created, and the board halted, i'd try:
display pixelbuf_pixelbuf_type[0]->auto_write
gdb will save the display entry, and auto show it on every break. (iirc, this is automatic..)
gilded pewter
can u upload code through bluetooth for nrf52840?
raven canopy
@gilded pewter do you mean upload a file (code.py)?
gilded pewter
yes? (just to know i never worked with circuit python)
for some ble controller, u can upload code through arduino sketch without wire, some thing like that
raven canopy
i was more trying to get to a clearer question, as i am not all that up-to-date on the BLE stuff.
i think your arduino reference would be more of an over-the-air firmware update. i'm almost 100% sure we can't do that (yet). there is a mobile app under development to remotely update the program to run (code.py or main.py).
ruby atlas
@raven canopy i'll try display. i'm used to using print
raven canopy
@gilded pewter yes, code.py or main.py. i don't think there is a current way to update either over BLE. i'm not seeing anything on either of these guides:
https://learn.adafruit.com/introducing-the-adafruit-nrf52840-feather/overview
https://learn.adafruit.com/circuitpython-nrf52840
@ruby atlas print would probably work too... ๐คท
ruby atlas
@raven canopy 4: *self = {base = {type = 0x3fa7c <pixelbuf_pixelbuf_type>}, pixels = 32, bytes = 96, pixel_step = 3, byteorder = { bpp = 3 '\003', byteorder = {r = 2 '\002', g = 1 '\001', b = 0 '\000', w = 0 '\000'}, has_white = false, is_dotstar = false, order = 0x376}, bytearray = 0x20002cd0, rawbytearray = 0x20002d00, brightness = 0.049999997, two_buffers = true, offset = 0, rawbuf = 0x20002e70 "", buf = 0x20002e10 "", write_function = 0x0, write_function_args = 0x0, auto_write = true} now the question is - is that the subclass or is that the native? ๐ Or are they the same?
ruby atlas
llol
@idle owl can attest to the llol
at least i no longer feel bad about poking around in the dark here
raven canopy
thought: i don't expect it to work, but maybe just try print pixelbuf_pixelbuf_type without the index? it might just print the whole kit-n-kaboodle.
and yeah, if Scott hasn't seen it...i definitely haven't. ๐
ruby atlas
I think I'm going to need to set breakpoints within the bytecode executor...
#1 0x0002293a in pixelbuf_pixelbuf_subscr (self_in=0x20002ef0, index_in=<optimized out>, value=0x20002d50)
at ../../shared-bindings/_pixelbuf/PixelBuf.c:430
#2 0x00015778 in mp_obj_subscr (base=0x20002ef0, index=<optimized out>, value=0x20002d50) at ../../py/obj.c:493
#3 0x0002688a in instance_subscr (self_in=0x20002c20, index=0x20002d60, value=0x20002d50) at ../../py/objtype.c:853
#4 0x00015778 in mp_obj_subscr (base=0x20002c20, index=<optimized out>, value=0x20002d50) at ../../py/obj.c:493
#5 0x00035ae8 in mp_execute_bytecode (code_state=code_state@entry=0x2002fe88, inject_exc=<optimized out>, inject_exc@entry=0x0)
at ../../py/vm.c:467
#6 0x00036d28 in fun_bc_call (self_in=0x20029980, n_args=<optimized out>, n_kw=1, args=0x0) at ../../py/objfun.c:284
...```I feel like self_in=0x20002c20 might be what I want, not self_in=0x20002ef0 but not sure yet
raven canopy
need a good canary...
raven canopy
well, it might help. Balmer thought so.. ๐ป
onyx hinge
@idle owl still on vaycay, will miss a couple more weekly meetings. Hug reports to all!
idle owl
@onyx hinge Sounds good! Keep having an amazing time!
slender iron
@ruby atlas the first member of all object instances should be a pointer to the type
if it says pixelbuf then it's native already
@gilded pewter Updating over ble is not currently possible but I'm working on adding it alongside some refactoring
ruby atlas
@slender iron hmm... i'm actually trying to call a non-native subclass method from the native method. When I invoke a helper (see below) from pixelbuf_pixelbuf_subscr (on the native), it seems to call the native method, not the python subclass method.
mp_obj_t call_show(mp_obj_t self_in) {
mp_obj_t dest[2];
mp_load_method(self_in, MP_QSTR_show, dest);
return mp_call_method_n_kw(0, 0, dest);
}
specifically, what I wanted to be able to do is have
class NeoPixel(_pixelbuf.PixelBuf):
def show(self):
neopixel_write(self.pin, self.buf)
as the glue to write pixels in neopixel.py
gilded pewter
@slender iron sounds good.. please give update when u guys are done!!
I have seen some companies doing with at command
umbral abyss
Can CircuitPython be used to generate a 2MHz toggling IO on a SAMD21 (aka Trinket M0)?... I've used the simpleio.tone library to generate kilohertz signals. Is there a library for MHz outputs?
raven canopy
@umbral abyss 2MHz is about the max i ever got out of the M0 using pulseio.PWMOut
quasi fjord
I don't think 2MHz is unreasonable, because the hard work is done by the TCC module not python anyway
slender iron
@ruby atlas seems like that should work to me. I'd expect self in to have the subclass type.
@gilded pewter I'd suggest following the circuitpython release notes. my plan is to have a custom ble service for circuitpython that enables it
ruby atlas
@slender iron i'll spend more time in the debugger tomorrow evening ๐ Unfortunately, i'm pretty sure I won't make tomorrow's weekly.
slender iron
kk, feel free to add notes though! I'm excited to hear how things are coming along
ionic elk
@tulip sleet the new tinyusb/dcd update has broken usb for the F412 - was there a piece of upkeep I was supposed to do but missed?
plucky flint
@idle owl @slender iron alas (again!), the combination of my son, Tae Kwon Do and my ability to drive him places has misaligned so I won't be able to make today's meeting. However, I've added stuff to the doc linked to above. Thanks!
ionic elk
^it isn't the ST definition, my bad
does have something to do with endpoint count though.
idle owl
@plucky flint No worries! Thanks for adding updates to the notes!
ionic elk
@tulip sleet how would I go about making the autogen of the usb descriptor a prerequisite for make? Having to make clean and recompile everything just to get the usb descriptor seems like it ought to be fixed, but I'm not sure how python stuff is triggered via the makefile.
tulip sleet
@ionic elk it already is, but maybe there are some missing dependencies (like, it should be dependent on the script)
i'll look
@ionic elk it's in supervisor/supervisor.mk
ionic elk
does make just not recognize changes to it because it's a py file?
tulip sleet
the depedencies look ok; are you saying it doesn't get rebuilt properly if you change the script?
tulip sleet
# autogen_usb_descriptor.intermediate: ../../tools/gen_usb_descriptor.py Makefile | $(HEADER_BUILD)
does it have to do with the .intermediate? I'm not sure what that does
ionic elk
also, I found the usb issue - Audio is taking 2 endpoint slots
I was under the impression it was supposed to take 1
and that only CDC was supposed to take 2
tulip sleet
there is some weirdness i had to add re intermediate; I don't remember why I did that
i'll try to reconstruct why it's the way it is
ionic elk
@tulip sleet sorry, on the USB-audio issue or the regen issue?
tulip sleet
| $(HEADER_BUILD) means it's an "order-only" prerequisite
ionic elk
Gotcha. Would I just activate that via an ENV flag HEADER_BUILD=1?
tulip sleet
@slender iron did the MIDI stuff; usb-audio needs two endpoints for MIDI
ionic elk
Oh. Well crap then yeah we can't support that on basically any ST chip
tulip sleet
well, if someone needs it they can drop HID
slender iron
I don't remember
tulip sleet
i think you saw the same two-endpoint thing with all the USB-to-MIDI adapters you tried?
i have an elderly USB MIDI device I can extract the desciptor from, but I'm not sure we'll discover anything we don't already know.
ionic elk
I don't know what's up in the python, I only see a single endpoint address described
tulip sleet
@ionic elk yeah, that's why I put in the compile-time choice, and we would like to have a run-time choice
of HID devices
ionic elk
And the debugger is slightly weird about it. It doesn't increment through them the way it does with CDC, the assert for the endpoint pops up only once, but it's at 2 already
@tulip sleet oh sure I meant that I don't see how audio is taking 2 endpoints
I don't see the descriptor for the second one, unless it runs it twice?
tulip sleet
there's an audio midi interface and an audio control interface; you need both. this is vaguely like why CDC needs two
ionic elk
Ok. I feel weird that I didn't pick that up when we talked about this before, I could have sworn it was only CDC that needed 2. Did this only come up recently?
But in any case, mystery solved, etc.
it was old man MIDI all along
tulip sleet
yeah, I just plugged in my ancient MIDI USB dongle, and it asks for two interfaces, according to wireshark
idle owl
@gilded cradle Have a minute to test my audio setup with me for the meeting?
ionic elk
Ok, so the official baseline for Circuitpython's endpoints is 7 including control. To clarify, this will exclude all STM32 chips except the F446/69/79
gilded cradle
Sure @idle owl
ionic elk
@gentle bronze I notice that tusb is capping out for the F405 at 4 endpoints, which implies it's stuck in FS mode and not touching HS, which has 6 endpoints - is this changeable by a setting?
tulip sleet
@ionic elk I think we don't have to say that's the "baseline". We have been able to have MIDI in the past due to lotsa endpoints. We can say in the doc (and set in the makefiles) that MIDI is not included in the STM builds by default.
i thought F405 had no PHY for the HS endpoints
i think hathach tried some tricks on that, but failed to get it to work
ionic elk
We might have covered that and I forgot. What's the PHY? I don't think I ever asked.
tulip sleet
the electrical driver circuit that you'd connect the socket to
ionic elk
Oh so as in "Physical"?
tulip sleet
right
ionic elk
Weird, why even have the HS at all then? In any case, not a big deal.
gentle bronze
@ionic elk hs usb on f405 has more endpoints, but require external PHY to operate at highspeed mode.
tulip sleet
it has data lines, but they need some circuitry to actually talk to a USB cable
ionic elk
Ah, gotcha. So it's an additional circuitry thing
gentle bronze
Though many people mentions that it is possible to have the hs usb work with builtin PHY (full speed), but I failed when giving a try
tulip sleet
why they left it off, I dunno, since it's a pain otherwise. It might have been a chip design issue
i certainly wouldn't set out to spec a chip that needed off-chip PHY
gentle bronze
It probably need external rc or something but I am not sure. I am not an hw expert ๐
ionic elk
Well, if you have the time @gentle bronze it might be a nice feature, since it'll let us get HID on there alongside CDC and MSC. But it's not too big a deal.
I can look into the guts as well
gentle bronze
I tried but I really need an board that physically work first though.
ionic elk
Some Discovery boards might support the PHY, I'll look into that
This probably occurs on the F407 and F427 too, so I'm sure it's not the first time anyone's run into it.
tulip sleet
the pyboard has this problem, and there are ways to specify which combo of HID devices
gentle bronze
@ionic elk I will check to see if there is any dev board that we can test with the hs core
Though it is up to @meager fog to decide on the pcb hw
pastel panther
modern wing
Good afternoon all you wonderful people! I'll be lurking today, nothing to share other than a desire to listen in and catch up on what's going on. ๐
gilded cradle
If anybody else is lurking please let me know so I can update it in the meeting notes. Thanks!
river quest
@gilded cradle have the notes link handy? need to add mine
gilded cradle
or feel free to put it in the docs yourself. ๐
trim elm
It's pinned
gilded cradle
modern wing
Loud and clear @idle owl
stuck elbow
good evening
river quest
i'll be a couple mins late but there in a few mins
idle owl
@river quest No worries
modern wing
๐ต
stuck elbow
"no one listens to my lyrics, they just want to see me dance"
modern wing
Former high school & college musician here -- did bass clarinet & bari sax (along with other clarinets and saxes) in concert, ensembles, musicals, etc. Some of the most fun I've had.
tidal kiln
lurking
trim elm
Lurking
modern wing
๐ @gilded cradle
errant grail
^ "You're never more than a half-step away from the right note."
modern wing
@errant grail And if you are, call it "jazz" ๐
river quest
hi
ivory yew
I'm gonna lurk as well.
slender iron
yay!!
ivory yew
Also, hi!
slender iron
๐
turbid radish
Lurking
river quest
hi @ivory yew !
turbid radish
Hi Thea!
river quest
added the post in our newsletter, great work! Lessons learned from building a custom CircuitPython board by Thea Flowers
https://blog.thea.codes/lessons-learned-from-building-a-circuitpython-board/
DRAFT here - https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2019-10-08-draft.md
ivory yew
Oh rad. ๐ Thank you so much.
river quest
stories about cats are good too
turbid radish
Equal Dog and other pets lovers too
river quest
Happy Ada Lovelace Day! TOMORROW!
Ada Lovelace Day (ALD) is October 8, 2019, it is an international celebration of the achievements of women in science, technology, engineering and maths (STEM). It aims to increase the profile of women in STEM and, in doing so, create new role models who will encourage more girls into STEM careers and support women already working in STEM - findingada.com.
Thank you Mitsuharu Aoyama, CircuitPython book is out
https://ameblo.jp/steamtokyo/
turbid radish
Would love if Adafruit carried the shirt
river quest
Lessons learned from building a custom CircuitPython board by Thea Flowers
https://blog.thea.codes/lessons-learned-from-building-a-circuitpython-board/
turbid radish
I did too
river quest
CircuitPython slithers onto a new board, but this board looks a bit familiar!
https://bigl.es/microcontroller-monday-serpente/
EuroPython 2019 videos posted
https://www.youtube.com/user/PythonItalia/videos
Talks include: Radomir Dopieralski โ Game Development with CircuitPython, Nicholas Tollervey โ Tools of the Trade: The Making of a Code Editor, Florian Wahl โ Building logistics applications with MicroPython and ESP32 MCUs, and Ben Nuttall โ Astro Pi: Python on the International Space Station.
Open-source hardware month is here!
https://ohm.oshwa.org/
https://blog.adafruit.com/?s=%23ohm2019
Have an open-source hardware (or software) success story? A person, company, or project to celebrate? An open-source challenge? Email opensource@adafruit.com, we'll be looking for, and using the tag #OHM2019 online as well!
All this and more, shipping out Tues AM!
https://github.com/adafruit/circuitpython-weekly-newsletter/blob/gh-pages/_drafts/2019-10-08-draft.md
modern wing
๐ฐ ๐
river quest
thankya!
ivory yew
alpha worked really well for my project. ๐คท I'm almost sad I haven't found bugs.
pearl notch
Reminder: Our community directory: https://docs.google.com/spreadsheets/d/1NWwiUuQnam_abdv02ugLxz9uFrvhtMfy8U306HJ4_qU/edit
pearl notch
Amazing how many accomplishments people have.
modern wing
It's a side effect of gathering a group of talented, caring people and setting them loose on a worthwhile project ๐
tidal kiln
oh yah. thanks for testing neopixel spi @gilded cradle
gilded cradle
yw
raven canopy
now, breathe.... thanks for speaking for all us no-shows/no-mics, @idle owl!
pearl notch
The BLE work sounds fun
prime flower
@pearl notch I've seen the bubblesort dance video during a lecture, it stuck with me ๐
stuck elbow
yes
gilded cradle
No
ionic elk
Hang on bad discord
turbid radish
no
slender iron
I can't
slender iron
yes! that'd be cool
old smelt
raven canopy
SysTick is already highest priority on the NVIC, iirc.
errant grail
Yes, an external speaker sounds quite nice.
slender iron
raven canopy
Right, but pewpew13 isn't a defined board.
stuck elbow
what does it compile?
I see, should I make a PR for removing it?
I'm fine with just one version
and it takes up resources
slender iron
stuck elbow
thanks
raven canopy
๐ thanks everyone!
errant grail
Thanks!
gilded cradle
Thanks everyone
pearl notch
Thanks! So long.
modern wing
Thanks!
ionic elk
cheers !
idle owl
@pearl notch Can you hop back in for a moment
pearl notch
One sec
modern wing
๐ฅ ?
modern wing
I'm gonna drop -- ya'll have a nice one, thanks again. Stay safe @slender iron
idle owl
@gilded cradle Thank you again for taking notes!
slender iron
@modern wing it's 8 blocks away and lots of fire folks are on it
pearl notch
Done. Thanks.
idle owl
@pearl notch Thanks so much for doing that!
pearl notch
Quality. ๐
manic glacierBOT
marble hornet
@idle owl I though cirpy gfx development was ceased when displayio was released?
idle owl
@marble hornet What is the context you're referring to
marble hornet
The recent issues filed on the gfx repo
idle owl
I'll need to look into it, but you may be right. In which case we need to at least update the README to reflect that, or deprecate the library.
@slender iron The Adafruit_CircuitPython_GFX lib - is that deprecated by displayio?
slender iron
it won't be deprecated until blinka has displayio as well
idle owl
@slender iron Ok thanks.
tulip sleet
@slender iron re the BLE scanning iterator: I think it might be good to have a timeout specified so that if no advertisement is received within the timeout, it either terminates, or it returns None. It also doesn't necessarily have to be a real iterator (though that's elegant): it could be a function that takes a timeout value (optional) and returns either the next scan entry or None.
slender iron
ya, it's still possible to provide the timeout when starting the scanning
tough flax
3 BLE CPX's on the way! (Yay! AT w/iOS just got lots simpler!)
slender iron
it'll just return STOP_ITERATION in that case
ionic elk
@slender iron I thought I could figure this out from the other ports but I guess I'm stumped. What exactly is the expected behavior of busio_uart_read? I thought it was to attempt to read anything off the UART line and return 0 if it didn't find anything. But it's causing all kinds of weird behavior even when returning 0. How do I get it to just be inert if there's nothing on the UART line to read?
slender iron
lemme look
slender iron
@ionic elk https://github.com/adafruit/circuitpython/blob/master/ports/atmel-samd/common-hal/busio/UART.c#L306
slender iron
what is the behavior you are seeing?
ionic elk
It's constantly acting as though empty material has been sent,
so a lot of spaces, etc
is that the expected behavior, though? It should just ignore the return if it has that error attached, right?
slender iron
are you returning MP_STREAM_ERROR?
idle owl
Alright, https://circuitpython.org/libraries/contributing is now updating daily! We now have a central place for keeping up with everything Library related. Thanks again to @raven canopy and Justin for all the great work on this!
I am unreasonably excited about this.
onyx hinge
I bet all my tests construct the audio object just once...
@ivory yew great blog post and welcome to the discord community!
ivory yew
Thank you. :3
timber mango
MP_STREAM_ERROR is not 0 though, it's -1 (but as unsigned)
onyx hinge
http://media.unpythonic.net/emergent-files/sandbox/report-3d3d49.html#LN954 hm clang's static analysis says there's a null pointer dereference here, and I can't see the flaw in its logic. That assignment must not be reached (much) in practice?
I think it would be reached after 4 never-free objects were listed, but it looks like only displayio is using this feature, so it doesn't happen in practice
onyx hinge
OK now it won't be forgotten
onyx hinge
hm except a number of tests fail.
๐
wait, they fail at adafruit master as well
pass micropython/viper_binop_multi_comp.py
b"(<class 'ZeroDivisionError'>, ZeroDivisionError('division by zero'))\n(<class 'ZeroDivisionError'>, ZeroDivisionError('division by zero'))\n(None, None)\n"
### Actual
b"(<class 'ZeroDivisionError'>, ZeroDivisionError('division by zero',))\n(<class 'ZeroDivisionError'>, ZeroDivisionError('division by zero',))\n(None, None)\n"
FAIL misc/sys_exc_info.py
``` this ring any bells?the difference is an extra comma in the repr of ZeroDIvisionError, I think
oh it's a python3 incompatibility
3.7: ```>>> ZeroDivisionError("test")
ZeroDivisionError('test')
3.5: ```>>> ZeroDivisionError("test")
ZeroDivisionError('test',)
pyenv to the rescue... ๐
raven canopy
look! i'm on a train. well, my words are... ๐
onyx hinge
too bad that the station where I decided to stage my photo was kinda ugly
raven canopy
i still haven't been to Japan. def need to get there some day.
onyx hinge
I recomend it for anyone who enjoys travel, it has been pretty amazing. there are streets clogged by western and chinese tourists, but there are also neighborhoods that look exactly like what you see in 20th/21st century movies and anime. I'm even learning enough to appreciate the shrines and temples.
and you can absolutely do it without more japanese than "please/thank you/excuse me/1/2/3"
and did I mention the food?
raven canopy
Japanese presentation of anything is always so appealing.
onyx hinge
In an American restaurant, all the plates would be the same boring style. Here, you get 9 things in 9 bowls that don't match and it's beautiful
train's arriving soon, ttyl!
raven canopy
๐
and coincidently, i just hit a Python 3.7 syntax error with something. async is now a keyword, so using it as a function kwarg is apparently frowned upon.
manic glacierBOT
gentle bronze
@ionic elk I will order a couple of stm32f7 board with USB HS to test with, couldn't find an f4 discovery board with HS USB. I will update its status in this github issue https://github.com/hathach/tinyusb/issues/198
timber mango
I'm running into an error building ports/unix
../../py/sequence.c: In function โmp_seq_multiply_lenโ: ../../py/sequence.c:40:5: error: implicit declaration of function โ__builtin_mul_overflowโ [-Werror=implicit-function-declaration] if (__builtin_mul_overflow(item_sz, len, &new_len)) {
onyx hinge
@timber mango first guess would be gcc version incompatibility. What compiler are you using?
timber mango
@onyx hinge clang version 3.4.2 under centos 7.7
I was able to compile micropython with it but not circuitpython.
onyx hinge
@timber mango it's possible that circuitpython is using gcc extensions not in clang, but I don't know the specifics about __builtin_mul_overflow. patches to build on more compilers would make great pull requessts.
wind trellis
@timber mango I ran into that using GCC but not a super recent version. Looks like __builtin_mul_overflow() premiered with GCC 5 and is also reported to be in newer Clang releases. Wikipedia says 9.0.0 is the current stable so updating probably fixes it. Or you can do what I did, because I'm naughty, and make this change in circuitpython/py/sequence.c:// Detect when a multiply causes an overflow. size_t mp_seq_multiply_len(size_t item_sz, size_t len) { #if 0 size_t new_len; if (__builtin_mul_overflow(item_sz, len, &new_len)) { mp_raise_msg(&mp_type_OverflowError, translate("small int overflow")); } return new_len; #endif return item_sz * len; }
tough flax
So, the STM32F405 has "Two USB OTG Ports" - will they be exposed on the Feather? I'd love to have a way to make [WIERDUSB]->HID adapters without the hacks https://www.adafruit.com/product/4382
solar whale
@tulip sleet I assume it is expected the the Bootlader File system is not visible to an IOS13 (ipad pro) but the CIRCUITPY drive is. Is that correct? see this forum question https://forums.adafruit.com/viewtopic.php?f=58&t=157270&p=775429#p775429
tulip sleet
We've seen ...BOOT visible - gotta go out in a minute but I believe it's visible. There are issues with the .Trashes file on iOS. We use a .Trashes file (not dir) to suppress having a trash can on iOS, but it's confusing iOS.
solar whale
OK -- I have to go as well -- will try again later
prime flower
CircuitPython 5 poster added to the "poster pole" near my desk at Adafruit HQ.
We're going to need a larger ceiling...
tulip sleet
@solar whale there is an issue with the USB descriptor asking for too much power, we need to fix the bootloader
manic glacierBOT
ionic elk
@tulip sleet @slender iron could I talk to one of you about UART on a call today? I've got a basic UART system working ok, but the existing port code makes it seem like a LOT more is going to be required. Would like to go over priorities.
slender iron
@errant grail mind replying with a uart midi example here: https://forums.adafruit.com/viewtopic.php?f=60&t=157287 ? We should add one to the examples directory of the library
@ionic elk I can chat in 10 minutes or so
tulip sleet
@ionic elk i'm also avail
ionic elk
Ok let me chat with @slender iron first if that's ok Dan, your code is a lot more complex due to the IRQ and buffer structure.
tulip sleet
np
manic glacierBOT
slender iron
@ionic elk ok, at my desk
ionic elk
Ok I'm around, should we just do the discord call thing?
or actually let's just hop in circuitpython
slender iron
๐
ionic elk
@tulip sleet Ok chatted with Scott and it looks like we definitely should talk! Can you hop in CircuitPython?
(chat channel)
timber mango
@wind trellis That was my temporary fix as well.
slender iron
@swift arrow voice channel in the list on the left
tulip sleet
this is not a meeting chat ; we are talking development
idle owl
@gilded cradle Blinka question. Do you know if we have the following working yet: USB HID, pulseio, analogio. (I know we don't have displayio yet)
timber mango
The 'better' fix to compile circuitpython's port/unix on Centos 7.7 turned out simply using a newer compiler the the default.
yum install centos-release-scl yum install devtoolset-8 scl enable devtoolset-8 -- bash source /opt/rh/devtoolset-8/enable
And compile as usual.
gilded cradle
@idle owl, sorry. Discord didn't ping me. I think pulseio is present for some boards, but I don't think the other stuff is working yet.
idle owl
Ok, I'll call it a no across the board for now.
gilded cradle
Ok then
idle owl
I went through the PyPI spreadsheet from that project, and there are a few libs that are marked as on hold waiting on Blinka support for the things I listed, so I wanted to check whether it was worth adding them yet. It is not if it isn't consistently supported.
gilded cradle
Yeah, the main problem is that so many boards/os combos support things differently.
idle owl
Understandable
gilded cradle
Just getting the basics like I2C/SPI, and UART working can be a challenge, so we've had to mark some boards as not supporting it if the steps to get it working were way too complicated for the average user.
idle owl
Ah. That makes sense.
solar whale
@tidal kiln just hooked up an ft232h to my Linux box and tried "blinka"
So far just blinking and LED and read from an adt7410 temperature sensor. Works great!!
errant grail
@slender iron I replied to the forum post a few minutes ago: https://forums.adafruit.com/viewtopic.php?f=60&t=157287&p=775506#p775506
manic glacierBOT
slender iron
thanks @errant grail !
solar whale
@prime flower Is there an "official" place to grab the 1.4.0 version of the nina firmware?
In fact, I don't see it in the nina-fw repository to build.
ah -- found it PR-11 -- not yet merged -- I'll try to test this tomorrow.
manic glacierBOT
prime flower
@solar whale it will be merged tomorrow, binary will be released under Releases for now until we have a travis script to build it
not sure how many nina-fw build's we'll actively be releasing so that's where they'll be for now
solar whale
working so far -- have not tried new stuff, just making sure nothing broken....
prime flower
I checked a bunch of pre-existing tests, but please break things if you can ๐
manic glacierBOT
torpid osprey
I could use some feedback on my project was thinking of going with the SAMD51 But anyone else have any thoughts. Does anyone know if circuit python would work with this. I have no experience with it
manic glacierBOT
meager fog
@tidal kiln hiya not sure if yr around, i was just testing my USB C FT232H and all is good - was gonna try neopixels next
stuck elbow
@torpid osprey does it have an USB port?
onyx hinge
Seems like the latest prototype schematic shows the USB data pins as no connects
onyx hinge
#almostontopic spotted some Python being used to set up an art exhibit at the 21st Century Museum of Contemporary Art in Kanazawa Japan
torpid osprey
@stuck elbow Yes it is on the bottom though
stuck elbow
as long as you can connect your computer to the usb, you should be able to run circuitpython on it
trim elm
Does anyone have an ili3940 screen that would be willing to test an example from the circuitpython_gfx library?
manic glacierBOT
trim elm
sorry, I meant ili9341
prime flower
@trim elm did you find one?
trim elm
@prime flower no
solar whale
@prime flower Just FYI -- I seem to get fewer "failed to find SSID" errors with IDF3.3 than with 3.2. I often have seen those when connection to my AP -- When I build nina 1.4 with 3.3 I just accepted all the default changes to the sdconfig. seems to be working well. Not a big deal and no reson to rush to 3.3, but it does seem to help with that one issue I have seen.
@prime flower do you have an example of how to use the new certificate feature in 1.4 ?
prime flower
@solar whale I do in MiniMQTT
Didnt release yet but it's merged, you'll need latest ESP32SPI. I'm assembling an AWS IoT library the next two days for CircuitPython
How are you building nina with 3.3, btw?
solar whale
great -- thanks -- I'll take a look
just downloaded the IDF 3.3 (as the repo says but use 3.3 instead of 3.2) and did make clean/make firmware -- accept all the default changes to sdconfig.
prime flower
I may have been building nina-fw 1.4 with 3.3 in that case...
solar whale
as here -- jsut used 3.3 where it says 3.2 https://github.com/adafruit/nina-fw
prime flower
Yeah, I have been. I'm going to release fw 1.4 with ESP-IDF 3.3
solar whale
cool!
prime flower
We're not "shipping" (as in physically shipping from the factory) fw 1.3.1, so I'll release 1.4 for those who want it and see if people hit issues with 3.3. I noticed the increase in AP-connection-stability as well
solar whale
I have it running on sevreal boards -- Airlift breakout, airlif featherwing, Airlift shield , metro_m4_airlift and a huzzah esp32.
prime flower
I do want to add pre-shared-keys (PSK) to WiFiClientSSL, though.
Mosquitto uses it, but it seems that's one of the only brokers so far. Most commercial IoT brokers use a root CA cert and device cert/key pair.
solar whale
I have to do some reading re:certs -- all a black box to me.... looking forward to learning....
prime flower
It's a black box I've been trying to make more transparent ๐
solar whale
I have to go off for a while - more time to play later...
@trim elm I have a tft featherwing (ili9341) and can do some testing this afternoon.
tidal kiln
@solar whale cool. thanks for trying out ft232h.
prime flower
@solar whale Going to do a fresh install of esp-idf 3.3 so I can get these instructions correct for everyone ๐
crimson ferry
@prime flower I'd like the NINA pin read changes we're working on to use 3.3 as well. I haven't built NINA before, can beta test the new instructions.
prime flower
@crimson ferry I'm about to PR a 3.3. sdkconfig and readme update.
running tests to ensure I dont break things first, one of the new sdkconfig options will free up 10k of IRAM which is great for us.
@crimson ferry I'll have build instructions in the PR, I've made it easier with the makefile that's currently within master (make firmware, make load-passthrough, make load-nina, make load-circuitpython), keep in mind you'll need a UF2 for the USB/Serial passthrough and CircuitPython UF2
crimson ferry
Ah yes, I used to have some standalone ESP32s wired up as Airlifts, but they've all been repurposed now (I'm setting up an array of wi-fi station probe request detectors to triangulate on where some unknown probe requests are coming from ๐
prime flower
@crimson ferry @solar whale ๐
https://github.com/adafruit/nina-fw/pull/13
prime flower
๐
crimson ferry
@prime flower Process question... The version shows 1.4.0 in CommandHandler.cpp, but I didn't see CommandHandler.cpp in the files changed. Should we update version number when code or build changes, since either will result in a unique binary whose version can be queried by CircuitPython? Or does the build process change that version number in CommandHandler.cpp?
prime flower
@crimson ferry Commandhandler changed from 1.3.1 to 1.4.0.. (https://github.com/adafruit/nina-fw/commits/master/main/CommandHandler.cpp)
Do you have the latest master?
I manually set the version number in CommandHandler.cpp and Partitions.csv before bumping the version
crimson ferry
I'm referring to this: https://github.com/adafruit/nina-fw/pull/13/files build process changed (new unique binary) but same 1.4.0 version as yesterday's cert stuff.
Maybe I'm mising something, I'm a bit of a n00b still at github.
prime flower
I didn't update to 1.4.1 or something similar since no code changed, just the build environment
crimson ferry
Right, that's my point... even a build change will result in a unique binary (different hash), and could affect functionality, even if no core code changes... shouldn't it deserve a new version number?
prime flower
It should, I didn't release a binary of 1.4.0 yet, though
crimson ferry
ah, gotcha
prime flower
You are correct, I just didnt want to release firmware (it's manual rn for nina-fw) until I had a binary built with 3.3 for the wifi patches
crimson ferry
cool, much ado about nothing... thanks!
prime flower
@sly falcon @crimson ferry We'll release nina-fw binaries on the Releases page for now, I've pointed the upgrading guide to this page -> https://github.com/adafruit/nina-fw/releases/latest
crimson ferry
Cool! Would it make sense to put the shipping binary there too? (1.2.2, I think)
@prime flower If I read all of that right, there are three procedures to upgrade NINA firmware... one for all-in-ones (e.g., *passthru.UF2 on PyPortal), second using SerialESPPassthrough.ino and esptool onto a separate Airlift co-processor board, and third (implicitly) using esptool directly on a standalone ESP32 board like ESP32 Huzzah Feather or ESP32 Huzzah Breakout.
idle owl
@hexed pawn Thank you for writing a driver for the MCP9600. It is my understanding the updated board will be in the store this week. Until then, I can work with you to get a PR in for the driver. You'll submit it to this GitHub repo: https://github.com/adafruit/Adafruit_CircuitPython_MCP9600 There are step to follow to get it set up for a PR involving using a tool called cookiecutter to create the base set of files we include, and then you'll have to go through and update those files. We have a guide that covers a lot of it, but I am also available to discuss it if you run into issues or if you learn better that way. Let me know when you're around and ready, and I can point you to the right places to get started.
crimson ferry
@prime flower How are the separate co-processor boards wired differently to the all-in-ones such that the *passthru.UF2 process wouldn't work?
meager fog
@ionic elk hiya are ya hackin today
ionic elk
@meager fog hiya I'm hacking away
Just about done with DAC, had to put UART on hold until I get the GPS
prime flower
@crimson ferry the passthrough process works, with those too - the uf2 file can be obtained by loading the Serialpassthrough ino file via arduino onto the board, then double clicking RESET to launch into BOOT. Then use that CURRENT.UF2
solar whale
@prime flower Nice job on the new commit/release -- just built and loaded to an Airlift shield - on a GCM4 - no problems.
prime flower
The all-in-one-boards have fixed pinouts, compared to how someone might wire up a shield or wing so it's easier to provide a Uf2 for them.
slender iron
catalina hates arm gcc ๐ฆ
prime flower
@solar whale thanks!
solar whale
@slender iron glad I waited ....
solar whale
was going to try it later today -- I have a spare system to test on -- it has catalina on it now but I need to do a full install of the build tools -- will give it a try later today or tomorrow,
@prime flower serailpassthrough.ino worked fine on the GCM4
crimson ferry
@prime flower Pin differences could be a bear, but I was just thinking that someone who does CP but not Arduino may want to easily update their Airlift FeatherWing on a Feather M4, or their Bitsy Add-On.
solar whale
just had to set pins
prime flower
Yeah, I have a UF2 for the FeatherWing that I reuse during building nina-fw (see the Makefile in nina-fw for how it's used)
crimson ferry
Since those pinouts are fixed for the wings, I wonder if there could be standard UF2s for those, so CP people don't have to install and learn Arduino.
prime flower
There could be, I'll a TODO. The shield gets reused btween diff form factors (uno/gc)
some people use the wings with female-to-male headers, to breadboard
crimson ferry
True, there are tons of variations. Before all the airlift stuff, I had a Feather M4 + Feather ESP32. I don't recomment it.
prime flower
You can use miniesptool, the guide doesnt list it bc it's a lot slower than esptool
crimson ferry
Nice! Speed probably less of an issue for someone who doesn't have an Arduino env.
idle owl
@tidal kiln This is probably a dumb question, but will this work with RPi 4? https://www.adafruit.com/product/2028
tidal kiln
yep. should. header pins are common on all pis.
idle owl
Ok thanks.
tidal kiln
except for some very early ones, but doubt you'll ever run into those, they're rare, museum pieces
idle owl
Right. We still sell the tinier version of that too.
stuck elbow
I have one of those, only a little burned
(I didn't understand why using 5V signal on a 3.3V device is bad back then)
idle owl
Now you know!
stuck elbow
it worked fine for a year!
tidal kiln
"tinier" = for the 2x13 header?
idle owl
Yah.. I thought it was shorter.
tidal kiln
yep. even those pins are common.
the newer models with 2x20 header simply added additional pins
idle owl
Ah. explains the "downgrade cable".
tidal kiln
but there are some super early revs where a few pins on the 2x13 changed
idle owl
Do you mind testing it with Blinka and a fritzing diagram I did?
I don't have a Pi set up here yet. Ordering it now, but would rather not wait.
tidal kiln
yep. have 006 and 007.
idle owl
Updating the 006 guide with CircuitPython/Python usage.
tidal kiln
are you putting together a Pi set up for general testing?
idle owl
I will be, yes.
Well to continue the PyPI project we started and never finished.
Which means testing sensors on Pi with Blinka.
@tidal kiln
manic glacierBOT
tidal kiln
the t cobbler is good. and then also get one of these:
https://www.adafruit.com/product/942
makes for a nice tidy pi testing setup
idle owl
ahhhhh ok
ionic elk
@meager fog DAC PR ready to test as soon as CI is done
idle owl
@tidal kiln Kind of like the plate like that for the Metros?
idle owl
No. Simply tested in general.
Can you still mount a Pi 4 on that plate? Have you tried?
tidal kiln
yep. they also standardized the mounting hole pattern. somewhere around B+?
idle owl
Ah nice ok
tidal kiln
what's the code to test with TMP006?
idle owl
or hold on
Here's the guide page: https://learn.adafruit.com/infrared-thermopile-sensor-breakout/python-circuitpython?preview_token=pMqVehZfPPzrMDYA2gHjFA
I made the REPL test simpler
But the simpletest.py is probably best
meager fog
@ionic elk nice, the 405 has 2 dacs
@ionic elk did you get storage included as a module?
ionic elk
Yes, I sorted out all the modules that should be included with every board last week
meager fog
awesome! plz ping me whe its ready to test
im gonna send the feather 405 out for fab soon
did you find anything you want fixed/adjusted?
ionic elk
I don't think I have any input besides moving the SWD header slightly. It's pretty nice the way it is
tidal kiln
@idle owl sorta worked. got a few random i2c comm errors on temperature read:
OSError: [Errno 121] Remote I/O error
investigating...
tidal kiln
yay. must've just been wiring and/or breadboard.
re-did the setup and it's working fine now
pi@raspberrypi:~ $ python3 tmp006_simpletest.py
Object temperature: 26.025*C / 78.845*F
Object temperature: 26.139*C / 79.051*F
Object temperature: 26.390*C / 79.502*F
Object temperature: 26.958*C / 80.524*F
and via REPL:
pi@raspberrypi:~ $ python3
Python 3.7.3 (default, Apr 3 2019, 05:39:12)
[GCC 8.2.0] on linux
Type "help", "copyright", "credits" or "license" for more information.
>>> import board
>>> import busio
>>> import adafruit_tmp006
>>> i2c = busio.I2C(board.SCL, board.SDA)
>>> sensor = adafruit_tmp006.TMP006(i2c)
>>> sensor.temperature
26.47104378525455
>>> sensor.temperature
26.402765856877352
>>> sensor.temperature
26.266072340923756
>>> sensor.temperature
26.2762707720172
>>> sensor.temperature
26.25347433579782
>>> sensor.temperature
26.116588253247926
>>> sensor.temperature
26.207866122041878
@idle owl โฌ
idle owl
@tidal kiln Thank you so much!
tidal kiln
np
manic glacierBOT
ionic elk
@meager fog give that attached binary a shot when you have a minute.
meager fog
@ionic elk will do, gotta get a TFT going ๐
hexed pawn
Thanks @idle owl I'll look at the learning guide and let you know if I get stuck along the way.
idle owl
@hexed pawn Do you need the link? Also let me take a look at it quickly and make sure there aren't any caveats. It has been updated piecemeal along the way but we may have missed something.
@hexed pawn This is the most important page at the moment for you and it appears to be updated. https://learn.adafruit.com/creating-and-sharing-a-circuitpython-library/creating-a-library
ivory yew
Heh I was just looking for this guide myself.
manic glacierBOT
meager fog
@ionic elk ok i am floating back to this now
so
should i wait for a new bin
or use the one u attached
meager fog
okidoke
@ionic elk hmm testing ...
isnt working?
oh wait no it is
ignore me
lol
@ionic elk tested!
from analogio import AnalogOut
analog0 = AnalogOut(board.A0)
analog1 = AnalogOut(board.A1)
while True:
# Count up from 0 to 65535, with 64 increment
# which ends up corresponding to the DAC's 10-bit range
for i in range(0, 65535, 64):
analog0.value = i
analog1.value = 65535-i
Welcome @ivory yew and @swift arrow to CircuitPythonistas! We're super happy to have you!
ivory yew
swift arrow
lol @ivory yew that's awesome
ivory yew
I'm just super stoked that it comes with a purple username.
idle owl
Right?
swift arrow
@tidal kiln and @ivory yew it worked!!!! my new PR worked in one try!
swift arrow
So much time and energy wasted doing it the wrong way.. gitdesktop for the win!
