circuitpython-dev

[exotic pumice]

yeah, jk

anyways, good night

[raven canopy]

i know. you too! 💤

[exotic pumice]

thanks

[river quest]

@umbral dagger soon it will be matter of when, not if....

once we get some buttons and some more things going, some stacks will be possible with sound, menus, etc...

[umbral dagger]

PyCard

[river quest]

LCARS alarm clock lookin good

[umbral dagger]

PyperCard

[river quest]

haha

[umbral dagger]

I have a better pallette on it now.

Alarm works (including touch to stop it)

[river quest]

with stemma port could do something like get heart rate and not turn off alarm until it's beating more

hehe

or it donates to something each time you hit snooze

gotta use that IoT for somethin'

[umbral dagger]

It monitors the light sensor and dims the backlight when the light is low

[river quest]

that's a nice feature that not even most alarms clocks do it seems

this one can do that, set the time automatically, etc too

[umbral dagger]

Yes, time is fetched. based on the event count down demo

[river quest]

single serving countdown clocks are fun

[umbral dagger]

Thinking of using the switch connector to add a large arcade button for snooze.

[river quest]

yep 😃

[umbral dagger]

And there's a spot on the screen for a weather icon.

[river quest]

oh, we just committed the code for openweathermap

....

[umbral dagger]

Cool.. I was looking for it 😃

[river quest]

just got done testing and made new graphics

been working all night, it's really handy

[umbral dagger]

I'll add that in, then add a second mode for setting the alarm. All touchscreen based.

[river quest]

er, travis just finished, it will be up in a sec

[umbral dagger]

I'll grab it tomorrow. Callign it a night.

[river quest]

ok! https://github.com/adafruit/Adafruit_Learning_System_Guides/tree/master/PyPortal_OpenWeather

same here, time to zzzzz tooo

[simple mantle]

so a friend of mine is doing microcontrollers and hardware engineering at school. he has a project idea for his first term assignment. I would like to make this as a prototype using circuitpython (my friend is forced to use C) just to show him that it can easily be done.
The idea is to measure the ground temperature and gps location on the road and analyze this data. Im thinking featherwing + gps thing + IR temp sensor. with future option to expand into something like a gsm module to live stream the data to an iot backend. ideas of what hardware is needed? I have a featherwing datalogger hence my initial thought off using it, but that does not matter if there is other options. (already asked in the python discord)

[main meteor]

I don't know of any IR temperature sensors with CP support offhand. Here's one I2C unit that might be suitable, I doubt it would be too tough to write a module to talk to it https://www.dfrobot.com/product-1495.html

[tidal kiln]

there are CP drivers for both the TMP006 and TMP007:
https://github.com/adafruit/Adafruit_CircuitPython_TMP006
https://github.com/adafruit/Adafruit_CircuitPython_TMP007

[solar whale]

but both are discontinued 😦

[tidal kiln]

hmm. still some 006's avail:
https://www.adafruit.com/product/1296
fwiw

[prime flower]

@gilded cradle Could you ping me when you've made the change to ESP32SPI, or add me to review it so I can see if it affects the _IO library?

[gilded cradle]

Yeah, was just going to put in both PRs at the same time

[prime flower]

ok, no problem

[gilded cradle]

Just hoping to finish before my laptop dies

Since I forgot my charger

[prime flower]

Doesn't look like the .mpys for IO CircuitPython were added to the 1.0 release. Travis shows they were built (https://travis-ci.com/adafruit/Adafruit_CircuitPython_AdafruitIO/builds/102205219#L411)

[idle owl]

@prime flower Because Travis failed to deploy. Needs an API key. I don't think I got around to adding it.

Yeah, I'll do that now.

[prime flower]

Thanks kattni!

[gilded cradle]

I got both PRs in @prime flower . Laptop is at 5%, so phew.

[prime flower]

PHEW, I'll test on IO and submit PRs with the changes

oh wow you already did it, thanks

[idle owl]

API key added. Restarted the 1.0 build, should deploy. Please verify it once the build is done, I'm in the middle of a lot of things.

[prime flower]

Will do.

[gilded cradle]

Ok, down to 3%, so shutting down.

[pastel panther]

lets try this again. heya @tulip sleet what does it mean for memory in CP to be 'long lived'?

[tulip sleet]

The heap memory is divided into long and short-lived for garbage collection reasons. One is allocated from one end of the heap, one from the other. The idea is to group long-lived stuff together so it's not mixed with short-lived stuff, to reduce fragmentation. An added thing is that short-lived memory may be relocated during a gc, but long-lived is not.

[pastel panther]

excellent! Thanks

[simple pulsar]

@tulip sleet Is that duty_cycle thing a known issue, btw?

Not important, I'm just curious

[pastel panther]

@tulip sleet I feel like I've also seen a few places with malloc'd memory without an associated (or at least nearby) free. Is that some CP magic?

[simple pulsar]

Although it's an unusual kind of bug so there might be some unpleasantness going on under the covers

[tulip sleet]

no, first we heard of it. I looked at the code and maybe we're not operating the peripheral quite correctly. The code is different on samd21 and '51. We have to wait for the TC or TCC to be ready in some cases.

hold on phone call

[prime flower]

@gilded cradle I think my prev. commit to your master messed up the history (adding to remote PRs is weird..)

was trying to add an updated analogin example since it wasnt included

[gilded cradle]

Ok, I wondered if something like that might happen

[prime flower]

I think it's because I was in a detached HEAD, you can try to drop that commit by rebasing the PR

[gilded cradle]

Um, I’m not sure how to do that.

[pastel panther]

https://www.atlassian.com/git/tutorials/merging-vs-rebasing

[gilded cradle]

Thanks

Ugh, laptop won’t boot. I’ll have to do it later.

[prime flower]

@gilded cradle I reverted the incorrect merge

[tulip sleet]

@pastel panther there is no free because the garbage collector takes care of it

[prime flower]

'git pull' your 'master' before making more edits, so it doesnt encounter a merge issue

also for the future - when adding a PR, make a branch called new-features or update-examples. Create a pull request from the branch, so it doesn't effect the history of master

[pastel panther]

proceeds to malloc with abandon

[gilded cradle]

Ok, thanks @prime flower

[prime flower]

@gilded cradle changes look good, ready for me to approve and merge?

[gilded cradle]

Yeah

[prime flower]

🎉 done

[gilded cradle]

Thanks

[tulip sleet]

@pastel panther use the other peripheral calls to storage allocaters as a guide, because you may want to call malloc by a different name.

[gilded cradle]

Mind if we do a release @prime flower?

[prime flower]

I'm about to @gilded cradle

[gilded cradle]

Perfect

[prime flower]

Was waiting to see if jerryn would approve the other PR so I could do them at once, but its ok to do 2 seps.

drafting...

[gilded cradle]

Yeah, either way is fine

[prime flower]

@gilded cradle Released

[gilded cradle]

Thanks.

Can we change the semver to something like 1.1.0 so it matches the rest of the repositories @prime flower?

[idle owl]

I'm not certain you can simply change the version number. You may have to do another release, or delete the current release. But you'll have to skip the current number or you can end up with things colliding. So jump to 1.2.0 or something.

[prime flower]

@gilded cradle I could bump to 1.2.0 after the current PR is pulled in for precision if that works, otherwise I can delete and do another release jumping to 1.2.0

[crimson ferry]

Today's Adafruit_CircuitPython_ESP32SPI changes get rolled into tomorrow's Adafruit_CircuitPython_Bundle auto-release?

[meager fog]

@pastel panther hihi i have a Q about the BMP decoding

[pastel panther]

yes?

[meager fog]

is there such thing as 32-bit BMP?

[pastel panther]

I think GIMP thinks so

looks

[meager fog]

ok i mhave a 'not viewing' bmp maybe you can look

i dont know what its deal is

i have no idea what 32 bit would mean tho

[pastel panther]

gimp sez yes

[meager fog]

is there an alpha channel???

[pastel panther]

ARGB or XRGB

yes (not sure what X is)

[meager fog]

alpha i guess

can you look at if we can add support for it while you're in the 8 bit zone

[gilded cradle]

Yeah it’s alpha, was doing som bmp stuff for ra8875 yesterday

[pastel panther]

sure thing

[meager fog]

In the original OS/2 DIB, the only four legal values of color depth were 1, 4, 8, and 24 bits per pixel (bpp).[4] Contemporary DIB Headers allow pixel formats with 1, 2, 4, 8, 16, 24 and 32 bits per pixel (bpp).[17] GDI+ also permits 64 bits per pixel.[18]

ok we'll just drop alpha for now

so skip that byte

here's another one

i dont think its a big code challenge cause we'll just skip the data and treat the rest as RGB

but take a look!

i've never bumped into 32-bit but this one website seems to generate em

[pastel panther]

should be straightforward

[gilded cradle]

@prime flower that works for me

[main meteor]

Some screen grabbing programs seem to create 32 bit ones for some reason.

[gilded cradle]

@crimson ferry, that’s correct though you could just grab it right out of the repo now.

[crimson ferry]

@gilded cradle Thanks, it took me a bit to figure out where to grab it. But just tested and it works great on my ItsyBitsy-ESP32 testbed. I really appreciate the changes! Added DotStar import to my local examples + changed ESP pin names to numbers (suspect they're not defined for ItsyBitsy). Awesome! 😃

[gilded cradle]

Glad to hear. I thought it was a great suggestion.

[prime flower]

@gilded cradle bump'd https://github.com/adafruit/Adafruit_CircuitPython_AdafruitIO/releases/tag/1.2.0

[gilded cradle]

Awesome. Thanks brent

[prime flower]

@gilded cradle if you decide to do that RSSI issue, be warned that rssi returns an unpacked struct and needs to be "prettified"/cleaned up in the signal_strength method would be abstracting ._esp.rssi (I just messed with it quickly)

[umbral dagger]

Is there any reason the PyPortal splash group is set to max=5??

[main meteor]

Once I've loaded a new bitmap font, how do I use it?

[pastel panther]

@prime flower you may be entertained to know that the aforementioned mushroom farmer is now doing his own configuration of the AIO feeds and data logging

[prime flower]

@pastel panther omg..the internet of mushroom farming....Can he email [e-mail] with some pictures or at least the dashboard?

[pastel panther]

totes; I got some pix of the grow room but we'll be getting together tonight to finish out some details

[prime flower]

The IO team can't see what people are doing on/with IO, per our IOT Bill of Rights. So it's always interesting to hear/see Adafruit IO use cases

[pastel panther]

thats comforting to know 😃 I'd be happy to send pix/deets and even write a blog article when things are further along

[prime flower]

hopefully he'll figure out some features he wants, we can add blocks/build out features fairly quickly

[pastel panther]

sounds good

[umbral dagger]

@pastel panther Internet of 'shrooms

[pastel panther]

"THE INTERNET IS NOT A BIG TRUCK, IT'S A SERIES OF MYCELIUM"

[main meteor]

Medusoid mycelium? 🍄

[pastel panther]

you know, Mr. Snicket went to my highschool

[main meteor]

This is cool, but I did not expect it!

[pastel panther]

As did Stephen Breyer, Margaret Cho, William Hewlett, Rube Goldberg, and Carol Channing to name a few

[main meteor]

Hollywood Arts? 😎

[pastel panther]

Yup!

/s

[main meteor]

I put a TFT FeatherWing on a Feather M4, and when I instantiate ILI9341 (the displayio version), I get a copy of my REPL interactions on the screen. My hat's off to tannewt and the rest of the crew, that's truly spiffy.

[pastel panther]

pretty great, right?

[main meteor]

Indeed. Colour me impressed.

[prime flower]

@main meteor it's super useful 😄

[main meteor]

Now to figure out how to change the font 😃

[simple pulsar]

hello all. Is anyone aware of any code in CircuitPython which manipulates a bytearray buffer? The CP implementation is very bare bones with append() and extend() only.

I'm wondering how to (efficiently) manage a bytearray where I need to remove a little bit from the beginning

>>> del B[0]
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
TypeError: 'bytearray' object does not support item deletion

😦

[main meteor]

Use slice notation? ```python
B[1:]
bytearray(b'\x05\x06\x07\x08\t')

[simple pulsar]

I'd like to efficiently modify an existing one

[tulip sleet]

The internal storage doesn't allow trimming off the front, I believe, so you'll need to copy one way or another

[simple pulsar]

bytearray(b'\x04\x05\x06\x07\x08\t')
>>> B = B[2:]
>>> B
bytearray(b'\x06\x07\x08\t')

[tulip sleet]

is array.array of bytes more functional for you?

that's why various read and write functions take boundaries for buffers so you can do partial reads or writes

[simple pulsar]

I'm buffering up some MIDI data. I was thinking of holding a certain amount of it in the MIDI class.

What do you think is best, I've not looked at array.array. Is that going to be bigger because it's int rather than bytes?

[tulip sleet]

could you just keep start and stop indices, or do a circular buffer?

array.array is what type you say: it could be bytes, 16-bit words, or 32-bit-words

[simple pulsar]

I was pondering that but thought I'd start simple!

[tulip sleet]

you could keep a list of bytes or byte arrays and join them at the end. b''.join(...) is the "efficient" way to concatenate

(assuming that works, haven't tried it)

[simple pulsar]

ok, i'll start with just over writing with slices and leave a note to revisit it if memory/performance is grim

thanks for the ideas

[raven canopy]

@tulip sleet do you have a moment, or are you heads-down on something? have some "general" tinyUSB questions

[tulip sleet]

ga

[raven canopy]

k. first, is it more sensitive to interrupts than the AS4 stack was?

[tulip sleet]

You mean the ASF4 stack messed up? They should be similar, in the sense that it shouldn't bother them. We set USB prio fairly low. On nrf, in particular, Bluetooth gets priority over everything else, because it's very timing-sensitive

[raven canopy]

well, now that i'm compiling without error again, as soon as my one TC with an overflow interrupt is enabled, the board locks up and then the USB gets hosed.

[tulip sleet]

in other words, FrequencyIn might not work very well on nRF, if it were implemented for it.

[raven canopy]

i was on the AS4 stack for the longest...

[tulip sleet]

how often is your interrupt handler running? Is it just runnig on edge transitions? What freq are you testing with?

[raven canopy]

its a TC, in 16bit mode, interrupt occurs on overflow, and its sourced from DPLL1 @ 98.304MHz

its the "reference" TC, and has no interaction with the EIC

[tulip sleet]

so what's the overflow interval?

[raven canopy]

from my understanding: 98,304,000 / 65535 = 1500 clock periods

[tulip sleet]

so 1500 kHz? Is the count always 65535 or does it go down?

so very roughly once a msec

[raven canopy]

always 65535, which is the max counter value in 16bit mode.

[tulip sleet]

looking at your code...

[raven canopy]

let me push the current. anything on my repo is likely really stale. 😄

[tulip sleet]

i was looking at the PR

[raven canopy]

oh..yeah, REALLY stale. 😆

it might be growing penicillin at this point. 🍞

[tulip sleet]

too late to turn into croutons

[raven canopy]

https://github.com/sommersoft/circuitpython/blob/new_freq_in/ports/atmel-samd/common-hal/frequencyio/FrequencyIn.c

[tulip sleet]

@raven canopy in your test setup, have you applied a test signal to the input pin to measure? If so, what is it?

[raven canopy]

nope, no signals were applied when i ran it twice last night. couldn't stomach any more tests, since windows got seriously hiccuped forcing a restart to get the board recognized. i have not ruled out update 1809 as a culprit, either

[tulip sleet]

When it hangs, what does the stack trace show? is it always inside 'frequencyin_interrupt_handler`? It might be worth having that toggle a pin to see what the rate really is.

[raven canopy]

the ones i caught were <signal_handler>, TC4_Handler and shared_timer_handler(0x04).

0x04 being the TC index

[tulip sleet]

but shared_timer_handler calls frequencyin_interrupt_handler, so you might see that some time (it should spend more time there). So it doesn't fail until you start a frequency_in capture? So instrument frequencyin_interrupt_handler to see how often it's being called, and maybe whether bad things are happening inside there (bad ptrs, etc.) You could toggle a pin or increment a counter (and take a look after a few seconds).

[raven canopy]

yeah, i was going to jump into setting some bp's tonight and getting some closer information. just wanted to kind of check if USB would a viable direction to look as well.

thanks for the look, and the "business as usual" expectations on tinyUSB. gotta go cook & eat real quick. will let you know if i find anything interesting.

[tulip sleet]

i think losing usb is an effect, not a cause. You could see if tinyusb is involved by running not connected to USB (toggle the LED or something and see if it hangs)

[raven canopy]

oh, and i kind of blasted straight past your questions in the first part. the "capture" starts automatically, but that doesn't generate any interrupts. the reference TC interrupts, and grabs info from the capture TC(s). and i agree, it should be spending some if not more time in frequencyin_interrupt_handler. it was likely just that i wasn't catching the stack at the right time without breakpoints set.

[umbral dagger]

Added weather display.

The display dims and switches to a red pallete when ambiant light is low.

[gusty topaz]

Nice!

Guys, has anybody here tried out the NanoPi M4 SBC?. I'm wondering if CP and/or Adafruit hardware (bonnets) would work on it:

https://www.friendlyarm.com/index.php?route=product/product&path=69&product_id=234

[marble hornet]

if there is no flash storage does cp support qspi?

i'm not seeing it in the docs

@umbral dagger displayio ?

[main meteor]

Is that weather display code available?

[gilded cradle]

@main meteor maybe at https://github.com/adafruit/Adafruit_Learning_System_Guides/tree/master/PyPortal_OpenWeather

Or a similar folder

[main meteor]

Cool, thanks. Wanted some example code to see how to use fonts. Hmm, gonna have to learn about "groups"

[marble hornet]

can i have some spi sram help? if so hear or #help-with-circuitpython ?

please I'm not quite familiar with spi and cp

[gilded cradle]

Hi @marble hornet. What kind of help did you have in mind? The big RA8875 driver I made is all SPI based.

[marble hornet]

a 128 kb sram chip i have here, http://ww1.microchip.com/downloads/en/DeviceDoc/20005142C.pdf

i can read but it is refusing to write

i'm using the mcpsram lib that comes the the epd lib,

[gilded cradle]

Are you using BusDevice?

[marble hornet]

no, it just handles the spi directly

[gilded cradle]

Take a look at the guide at https://learn.adafruit.com/circuitpython-basics-i2c-and-spi. It helped me out.

Also, is it giving errors or is it just not writing?

[marble hornet]

it's just not writing

i get back the same number no matter what (funny enough not zero)

[gilded cradle]

Ok. I need to head home, but I’ll get back online as soon as I get there. I’ll see if I can come up with any ideas on the way.

Until then, maybe look at the FRAM driver. One of them is SPI based.

[marble hornet]

thank you @gilded cradle

drive safe

[gilded cradle]

Yw

Thanks

[raven canopy]

@marble hornet do you have your code posted anywhere? i can take a peek to see if i can offer any help...

[marble hornet]

yes!

https://github.com/adafruit/Adafruit_CircuitPython_EPD/blob/master/adafruit_epd/mcp_sram.py

[main meteor]

Hmm, having trouble finding out how to get the root group for a display?

[river quest]

@umbral dagger nice work

nice font

it appears to also be cold

stay warm 😃

[raven canopy]

@marble hornet k. looking...

[marble hornet]

@raven canopy i just pass it the busio.SPi object, it should be compatible since it is microchip

i did try adding ```
spi.try_lock()
spi.configure(baudrate=20000000)
spi.write(bytearray([self.SRAM_RDSR, 00000000]))
spi.unlock()

i found the 00000000 from the datasheet on page 10

and thank you

[raven canopy]

@marble hornet what read/write mode are you trying to set in __init__? i can't see 0x43 setting any of the available modes; only 0x0 (byte), 0x80 (page), and 0x40 (sequential [default]). also, there is this note for mode: Bits 0 through 5 are reserved and should always be set to '0'

[main meteor]

I'm getting closer with textareas, but I'm getting the wrong glyphs displayed for some reason.

[marble hornet]

@raven canopy i am trying to set it to bytes (just a presumption that byte mode is correct)

so i figured rdsr is the cmd and all zeros should set it it to byte mode. (i;m also guessing bito is 2^0 and bit7 is 2^7)

[meager fog]

@main meteor whats not showin'

[raven canopy]

@marble hornet ohhh....just realized that link was to the EPD. 🤦

[marble hornet]

yes

most of the infrastructure seemed to match

[raven canopy]

can you put up a gist of what your code looks like? or even just upload it here.

[marble hornet]

https://gist.github.com/TG-Techie/80890ef8ea8e9e2584605c57e906592d

i have only changed init

with underscores

[main meteor]

I set the text to '0123ABCO', and get '&-,èìòç' displayed

[gilded cradle]

Hi @marble hornet , I'm back on and am reading through the datasheet and comparing it to your code.

[meager fog]

thats interesting

wheres your code?

@main meteor

and what font are you using?

[main meteor]

Here's my code. I can upload the BDF font if that's useful

[solar whale]

@meager fog and others interested -- I wonder if it makes sense to pull the official support for the ESP_ATcontrol and move a particle_argon only version of ESP_ATcontrol over the the "Community Bundle" I'll be happy to try to maintain it but I see no reason to maintain the ESP8266 support or to maintain support for external ESP32 boards -- External ESP32's should use ESP32SPI. I think there is a good use for the particle_argon but as it is not an adafruit board, it makes sense to move its support out of the mainstream. It is a very limited use-case at this point and I'm not sure we should encourage its continuation.

[meager fog]

i dont see a need to do that quite yet

@main meteor thats odd it should work

[solar whale]

OK -- I have added the wifi-manager to ESP_ATcontrol -- and it works for the ESP32 but not for the ESP8266

[meager fog]

want to try my font?

i have lotz o f0ntz

[main meteor]

Sure, I'll give it a whirl

That should narrow down if it's a font issue

[raven canopy]

@marble hornet after hand-jamming the numbers, everything looks like it should be working. the bit work looks correct; dean knows that realm better than i do i'm sure. and CS manipulation looks correct. check pins? do you have a logic analyzer to verify the signal?

[marble hornet]

no , I don;t. the odd thing i think is i;m getting numbers back from read, unique to the addrs. i've also tried setting in in sequential. i'll check conns tho

[meager fog]

try that

[main meteor]

Ah, that works correctly, which points to some sort of issue with my font.

[meager fog]

are you using otf2bdf

cause that's a nice bit of software

[marble hornet]

i seem to be getting nonsense!

>>> chip.read(0,12)
bytearray(b'\x00___________')
>>> chip.read(0,12)[1]
95
>>> chip.read(1,12)[0]
0
>>> ```

why would they be different ?

[gilded cradle]

Another idea is to install the SRAM_23LC library for arduino and see the specific registers that it is using for that chip.

[marble hornet]

i'll give it a shot

[pastel panther]

pro tip: make sure your variables can hold the range of values you expect without overflowing 🤦

turns out zero length buffers aren't very useful

[marble hornet]

hrmmmm

interesting

let me type it up

[raven canopy]

@pastel panther nah. persistence will fix that. keep feeding that zero length! it'll grow! 😄

[main meteor]

These are some old X11 PCF fonts I found somewhere in 2001 and converted to BDF in 2002. Sure enough, it looks like they have some weird encoding I haven't seen before (it's not EBCDIC, Baudot, or Fieldata).

[raven canopy]

debating on another round of USB hosing fun... might as well. 😬

[pastel panther]

weee

[marble hornet]

so the arduino sketch write "The MattairTech MT-D21E is a development..."
so after running it i thought i would check for those bytes in the ram.

1. byte moe for read seems not to work i always gives 0,x,x,x,x,x,x,x,x,x, no mater what. sequential seems to work
2. in sequential if i read(), 12) i get bytearray(b'\x00The Mattair')

[main meteor]

A little poking around reveals they're probably from the ancient x3270-x11 package.

And sure enough, here's the encoding http://x3270.bgp.nu/Charset.html Wow.

[pastel panther]

hey @main meteor Have you ever head of 8bpp bitmaps without a palette?

[main meteor]

Other than greyscale?

[pastel panther]

yea. I mean I suppose it could be 2:2:2 or something..

[marble hornet]

I'm gonna poke around in the c code from arduino and see if i can make sense of it anymore 😉

[pastel panther]

I think some rando online converter made it:

I'm content to not support them, at least for now

[raven canopy]

@marble hornet in Byte mode, to read anything more than a single byte i'm fairly certain you'll have to toggle CS and send the address again. in sequential, the chip will just keep feeding data until CS is pulled high.

and, i think in the EPD, it is setting the mode to Sequential with 0x43. i just don't know why the 3 is at the end of that value.

[marble hornet]

in bytes wont the cs toggle if read is called again b/c it will be high form the last one ?

maybe the other chip needs 0x03 there ?

[raven canopy]

could be? i couldn't find which one is used on the EPD. but i didn't dig too deep.

[marble hornet]

IT"S WORKING !

it sent 0x40

idk why 1<<6 didn;t cut it but 🤷

but it is a little off

hrm, it is writng, now to figure out exactly how

[pastel panther]

working but off is still working! I've got the bitmaps to prove it!

[raven canopy]

@marble hornet 🎉 solving the puzzle is why we love this stuff, right? just starting on my headache for the night... 🐧

[marble hornet]

penguin?

[raven canopy]

its my spirit animal. #FightClub

[marble hornet]

and i think the chips are different, this one has some command differences in addr and addr length

[main meteor]

Tried my code with my handmade HP2647A font and it worked fine. It's weird and wonderful seeing the ancient HP characters on the TFT display.

[marble hornet]

nice! what are you settling in to tackle?

[raven canopy]

FrequencyIn, as always. hehe

[marble hornet]

best of luck

look:

>>> chip.write(0,[x + 1 for x in range(20)])
>>> chip.read(0,20)
bytearray(b'\x00\x00\x02\x03\x04\x05\x06\x07\x08\t\n\x0b\x0c\r\x0e\x0f\x10\x11\x12\x13')```

the first two are missing, interesting ...

[umbral dagger]

@marble hornet displayio, yes. Directly and through pyportal.

@river quest Thanks. Font is Anton-regular. -9C is reasonable for this time of year. The -20 cold snaps.. not so much. BTW, winter is the best time to be working at home 😃

[main meteor]

Working with the HP font: it is a thing of beauty

[pastel panther]

niiiiice

[main meteor]

I am becoming quite fond of displayio

[pastel panther]

I should see if I can scare up some TOS/GEM fonts

[umbral dagger]

‘Night’ mode. It looks way brighter than it really is.

[main meteor]

Slick! Yeah, these screens are tricky to photograph.

[pastel panther]

I have a photographer friend who makes the big bucks by taking super awesome pictures of lighting installations; blows my mind

[raven canopy]

waiting on re-build. forgot to flip that silly -flto back off when i updated

[main meteor]

My sweetie used to work at a photo lab taking pictures of difficult-to-photograph things (like chemistry glassware) for brochures. I should ask for tips.

[raven canopy]

@main meteor @umbral dagger those do look gorgeous!! 👏

[main meteor]

I'm pretty sure dastel's is running on a PyPortal, mine's running on a TFT Featherwing.

[raven canopy]

at either rate, that font is looking delicious.

[pastel panther]

if someone were to perfect green phosphor ghosting on a tft, I would give them some money

[main meteor]

It would be fun to try porting Cathode or retro-term to it 😃

[pastel panther]

well this is groovy
https://www.youtube.com/watch?v=jWx7REAQ2MY

[umbral dagger]

Looks like the Cathode app

Ah ya/... I have cool retro term, actually. Duh. Cathode on MacOS is really nice, too.

[pastel panther]

@gilded cradle you might find this useful if you're still doing bitmap stuff

[umbral dagger]

OK, it's late enough that I'm only reading half of what's in front of me. Tomorrow I'll be digging into teh touchscreen. Then the alarm setting mode.

[gilded cradle]

Thanks @pastel panther. I'll take a look. I got 16, 24, and 32-bit working great. I may try and tackle 8-bit.

Ok yeah, I see it's grabbing palette info. Thanks

[pastel panther]

The wording of the palette calcs is a little misleading but the info's there

[gilded cradle]

Yeah

Did you get the other bit formats working too?

[pastel panther]

this page was a revelation:
http://www.ece.ualberta.ca/~elliott/ee552/studentAppNotes/2003_w/misc/bmp_file_format/bmp_file_format.htm

i just got 8bpp indexed working, going to fix the 32bpp weirdos Limor was asking about then on to monochrome

[gilded cradle]

Yeah, I found that yesterday, but hadn't had a chance to read over it

[exotic pumice]

have any of you guys looked into gifs yet? I tried writing a gif loader and it kept bugging out

[pastel panther]

not yet; once BMPs are fleshed out jpegs are next in terms of images

[gilded cradle]

No, I was trying to tackle the easy ones

[pastel panther]

(jpegs are not that)

[exotic pumice]

https://github.com/sajattack/Adafruit_CircuitPython_ImageLoad/blob/master/adafruit_imageload/gif/__init__.py

if anyone's curious at some point

[gilded cradle]

I meant the bitmaps

[pastel panther]

oh right; yes,that's wise

[gilded cradle]

Nice @exotic pumice . Is it completely working now?

[exotic pumice]

no

it bombs out in the decompression

[gilded cradle]

Hmm, ok. I read a book a while back on programming in C that explained GIF compression pretty well, but it's been so long I only remember it conceptually.

[exotic pumice]

yeah I found a good tutorial

It works on the tutorial image but not on bigger ones

[gilded cradle]

I'm pretty sure it was this book: https://www.amazon.com/Gardens-Imagination-Programming-Maze-Games/dp/187873959X

[exotic pumice]

ok, I followed these docs http://giflib.sourceforge.net/whatsinagif/lzw_image_data.html

[pastel panther]

@meager fog , got 8bpp indexed working. I'll look at those 32bpp next (pyportal build)

[gilded cradle]

I just discarded the alpha channel and 32bit decoded fine

[exotic pumice]

@gilded cradle there's just something subtly wrong with my implementation that I haven't been able to track down

[gilded cradle]

@pastel panther , you can see how I just decoded it like 24bpp here: https://github.com/makermelissa/Adafruit_CircuitPython_RA8875/blob/master/examples/ra8875_bmptest.py

[exotic pumice]

it gets through 12 frames of the gif, idk what they look like, but it crashes on frame 13

[pastel panther]

thanks @gilded cradle

[gilded cradle]

@exotic pumice, I'll have to give it a try and see if another set of eyes might help

Do you have the test gif?

[exotic pumice]

this one works

this one doesn't

[gilded cradle]

Ok, so it's the animated stuff?

Have you created an animated gif before?

[exotic pumice]

I'm not sure

it could be for bigger non-animated gifs too

I have created gifs before

[gilded cradle]

I mean about the crashing

[exotic pumice]

yeah I haven't tested a large, non-animated gif

[gilded cradle]

That crashed too?

[exotic pumice]

haven't

[gilded cradle]

Ah, ok. I'm wondering if some of the gif animation control bits are throwing your code off.

[exotic pumice]

I don't think that's the case

I have animation control bits covered, and it's during decompression that it fails

I'll convert some image to gif and try though

[gilded cradle]

Ok, cool. I was just trying to think why it would get so far and then crash. Do you know how many frames that deploy rainbows one has offhand?

[exotic pumice]

16 I believe

[gilded cradle]

Ok, cool

[exotic pumice]

I just tested a large non-animated gif and it seems to have failed even earlier

[gilded cradle]

Ok, good to know.

[raven canopy]

well that explains why the proper interrupt handler never gets called. TC4 is conspicuously zeroes...

(gdb) print tc_handler
 $3 = "\000\000\002\000\000"

must have been a late night... 🤦

i need to goto bed...but, i dun wanna. 👶

[pastel panther]

it's like my buffer!

[exotic pumice]

goto beds considered non-harmful

[raven canopy]

lol. zero wins the day!

hurries up gcc-arm-embedded! i needz 💤s

[exotic pumice]

-j100000

[raven canopy]

ugh. now the jlink wants to act up. "sorry i'm late. debugging...know what i mean?"

nope. this is now a tomorrow thing. have a great night, 🦉s! 👋

[gilded cradle]

Good night

[pastel panther]

'nite! 👋

[gilded cradle]

@exotic pumice , do you have a test script for running your gif reader?

[uneven star]

Is Scott (who I talked to at PyCascades) in this channel?

[gilded cradle]

Not at the moment. He goes by @slender iron

But when he is online, he shows up under Admins

[pastel panther]

welcome @uneven star 😃

[gilded cradle]

Of course you can type something including his name with the @ and it will notify him when he logs on

But welcome none the less

[uneven star]

I tried typing @-scott... and it didn't turn up, and I tried @slender iron earlier and for some weird reason it also didn't auto-complete.

[exotic pumice]

import adafruit_imageload

adafruit_imageload.load("/home/paul/Downloads/feelsbadman.gif")

[uneven star]

Also, thanks for the welcome!

[gilded cradle]

Looks like you got it that time

[uneven star]

I played with a circuit playground express at PyCascades and now I'm thinking about how to incorporate one into the talk I'm giving about Mastodon and python-based mastodon bots at PyCon.... toot to mastodon from circuitpython, anyone? 😄

[gilded cradle]

Nice! I'm going to PyCon, so hopefully I'll see you there.

[uneven star]

@gilded cradle raaad. I'm going to see how much circuit python stuff I can get working between now and then... I already made a little binary counter for counting runs through the swag bag stuffing line at PyCon https://twitter.com/phildini/status/1100143861521731584

Philip @ Home (@phildini)

Hey #python fam. Did you know you're all receiving a Circuit Playground from @adafruit at @pycon? If you're going to be stuffing swag bags with us, here's a little #circuitpython script you can use to count (in binary!) the bags you've stuffed: https://t.co/udwa27o16n

Twitter

[gilded cradle]

Oh, great idea. You could maybe even do something with binary and different colors.

[uneven star]

So, that script changes from red to orange at 50, from orange to yellow at 100, and from yellow to green at 200.

[gilded cradle]

Oh yeah, you did do that

[uneven star]

I would love to have it be more gradual, right now it's hard jumps, but maaaathhh....

[gilded cradle]

I like the hard jumps because you can definitely tell where it is

[uneven star]

Yep. Although I need to tweak the shades between orange and yellow. They're pretty subtle right now.

[gilded cradle]

Ah, yeah

[uneven star]

Is there like a blog post I can read where someone has really dug into color math with the neopixel?

[gilded cradle]

Mmm, let me check. I always like to look through the guides at https://learn.adafruit.com/

Actually, I think I got the perfect thing...

[pastel panther]

the fancyled library is pretty great

[gilded cradle]

I did a great palette shifting example for the NeoPixel FeatherWing at: https://github.com/adafruit/Adafruit_CircuitPython_FeatherWing/blob/master/examples/featherwing_neopixel_palette_example.py

[uneven star]

Cool! I'm checking out that and https://learn.adafruit.com/fancyled-library-for-circuitpython

[gilded cradle]

It uses math to get a full rainbow palette

Well, I gotta get going. Have a good night.

[pastel panther]

nite!

[manic glacier]

nizvoo

[adafruit/circuitpython] Fork created: nizvoo/circuitpython

[slender iron]

welcome @uneven star! I made you a circuitpythonista so you'll get a few notifications a week. I'm almost entirely out this week but will be back with dedication late next week.

[solar whale]

@meager fog When I try to build my own copy of the NINA_W102 firmware -- It compiled fine with the latest version of the esp-idf but I found that the Firmware Version is still set to 1.2.1 in the adafruit/nina-fw repo https://github.com/adafruit/nina-fw/blob/master/main/CommandHandler.cpp#L28 Is this repo up to date? How did you get version 1.2.2 in the posted NINA_W102_17_FEB_2018.bin? My build seems to work but it reports version 1.2.1.

[idle owl]

@uneven star Welcome! I'm excited to see what you come up with! 😃

[manic glacier]

Franck1333

[adafruit/circuitpython] New star added

[solar whale]

@gilded cradle here is the AT firmware for an external ESP32

ATfirmware for ESP32

[gilded cradle]

Thanks

[solar whale]

flash with ```/usr/local/bin/esptool.py --chip esp32 --port /dev/ttyUSB0 --baud 115200 --before default_reset --after hard_reset write_flash -z --flash_mode dio --flash_freq 40m --flash_size detect 0 factory_WROOM-32.bin

pins - ```
VUSB - VUSB
GND - GND
RX - TX
TX -RX
D5 - ESP32 RESET
D6 - ESP32 GPIO15

GPIO is not needed

[gilded cradle]

Ok, cool. Just flashed it.

[solar whale]

we need to decide if that should go in the guide - at one point it was decided only to put the argon information in the guide.... if you have an external ESP32 it is best to use ESP32SPI so it may not be useful in general

[gilded cradle]

Yeah, but I'm testing it for the ticket, so it may not be necessary to add it, though we could just in case somebody wants to do it.

Maybe with a warning

[solar whale]

yes -- thank you for testing it! I did it with the feather_m4 so I could test the neopixel status ligt.. argon doesnt use it.

[gilded cradle]

Yeah, that's why I decided on the Metro M4

[solar whale]

should work fine...

[pastel panther]

hey @solar whale Do you know if ESP32s come with a bootloader? Like fresh off the reel ones?

[solar whale]

sorry - I don't know.

I've never had to load one so I assumed it was n ROM like the ESP8266

[pastel panther]

I'm going to assume so

[gilded cradle]

It depends on what you mean by bootloader. It comes with one in the same way an arduino does.

[pastel panther]

By bootloader I mean piece os software that will load on boot and assist with flashing new firmware

what I'm getting at is will it work with esptool out of the box

[gilded cradle]

Yes

I've only used esptool with mine

[pastel panther]

I just found the docs and they agree. Thanks!

[gilded cradle]

Yw

[pastel panther]

For those interested: https://github.com/espressif/esptool/wiki/ESP32-Boot-Mode-Selection

[umbral dagger]

pyportal touchscreen & virtual buttons working.

[teal thorn]

Why do I keep getting memory allocation failed errors? The scripts worked before.

[manic glacier]

makermelissa

[adafruit/circuitpython] Issue opened: #1602 Latest master does not compile for mini\_sam\_m4 board

The error I get is:

build-mini_sam_m4/timer_handler.o (symbol from plugin): In function `shared_timer_handler':
(.text+0x0): multiple definition of `shared_timer_handler'
build-mini_sam_m4/peripherals/samd/timers.o (symbol from plugin):(.text+0x0): first defined here
collect2: error: ld returned 1 exit status
make: *** [build-mini_sam_m4/firmware.elf] Error 1

dhalbert

[adafruit/circuitpython] New comment on issue #1602: Latest master does not compile for mini\_sam\_m4 board

Did you git submodule update --init --recursive ? That code is in a submodule that was recently updated.

makermelissa

[adafruit/circuitpython] New comment on issue #1602: Latest master does not compile for mini\_sam\_m4 board

Nope, I didn't know about that. I'll do that and try again.

makermelissa

[adafruit/circuitpython] New comment on issue #1602: Latest master does not compile for mini\_sam\_m4 board

Ok, that worked. I guess it was user error.

makermelissa

[adafruit/circuitpython] Issue closed: #1602 Latest master does not compile for mini\_sam\_m4 board

[pastel panther]

@teal thorn What board are you using? Did you change what libraries you're using ? ( or your code)

[teal thorn]

Feather M0 Express. I just updated to 4.0 beta. I am using the bus_device library and my own custom library.

[pastel panther]

What were you using before 4.0 beta? 3.x?

[teal thorn]

I was running the library on another board with 4 beta.

I think my custom lib is near the memory limits of the M0. I probably need to move to M4. Are there any tricks for freeing up memory on the M0?

[pastel panther]

Yea, there are a few things your can turn off in the mpconfigboard.mk for the board in question. Adding CIRCUITPY_I2CSLAVE = 0 can free up some space

there are other things as well that @tulip sleet can suggest

adding CFLAGS_INLINE_LIMIT = 55 is another option

[teal thorn]

That is rebuilding the circuitpython source right? That is not a problem or a surprise, I just want to be sure I understood correctly.

[pastel panther]

yes; in your case you'll need to edit ports/atmel-samd/feather_m0_express/mpconfigboard.mk

@teal thorn there's talk about the same topic going on in #help-with-circuitpython if you want to take a peek

[simple pulsar]

@split ocean I'm messing around in the adafruit_midi module at the moment, if there's any more messages you'd like it to handle, shout now

[raven canopy]

@tulip sleet figured it out last night; was setting things wrong in the constructor with set_timer_handler causing the interrupt handler to never get called. which i assume was causing endless OVF interrupts since the intflag never got cleared. 🤦

Adafruit CircuitPython 4.0.0-beta.2-149-g9d20380-dirty on 2019-02-27; Adafruit Metro M4 Express with samd51j19
>>> import board, frequencyio
>>> foo = frequencyio.FrequencyIn(board.D11)
>>> foo.value
0
>>> foo.value
2000
>>> foo.value
2000

[manic glacier]

rdiakur-enph

[adafruit/circuitpython] New star added

[tulip sleet]

@teal thorn If you're running out of memory while running a program, then the rebuild ideas above won't really help: it's that you're just using too much RAM when the program is running..

[split ocean]

@simple pulsar excellent. We just have CC, PitchBend, NoteOn, and NoteOff at the moment, right? Patch Change would be cool. I don't know if I'll make any controllers with Aftertouch or Channel Pressure, but those could be cool if someone did.

[simple pulsar]

I've got an old axiom 25 and I spotted it was sending plenty of aftertouch. I've noted your comments on the ticket i'm working on: https://github.com/adafruit/Adafruit_CircuitPython_MIDI/issues/3

[split ocean]

Nice, thanks. Ooh, I just saw on GitHub that you're working on reading incoming messages as well as building a monosynth. Awesome!

[simple pulsar]

Yep, i've got an external board driven by a CPX with some transistors on which I'm loosely refering to as 2 VCA + mixer for my two osc

where osc are PWMOut

[split ocean]

And the CPX is reading incoming MIDI from your Axiom?

[simple pulsar]

Yep

[split ocean]

So cool.

[simple pulsar]

I got a tiny number of stuck notes earlier, possibly because i'm not treating noteon vel=0 carefully

[split ocean]

Oh, interesting.

[pastel panther]

A panic command would be useful if there isn't one already

[simple pulsar]

A big red button?

[split ocean]

Huge.

Or, accelerometer on CPX so you just shake it like crazy to send MIDI panic message :)

[pastel panther]

😃

oooh, CPX tambourine! and Cowbell!

[simple pulsar]

Are you referring to the all notes off or all sound off from Channel Mode Messages?

[pastel panther]

I'm not sure how it's implemented but many of my synths and/or controllers have a "panic" button that shuts everything up when things go crazy. Both options seem plausible

[split ocean]

I think sending a message on CC 123 with a value of 0 may be the MIDI panic message, but I haven't tried it.

[simple pulsar]

ok, noted, will look into that, thanks

[raven canopy]

@tulip sleet quick Q: is del foo supposed to call __exit__? just verifying my deinit...

[tulip sleet]

I think it does on some builds but not others, depends on whether MICROPY_CPYTHON_COMPAT is set, but that's just from (my) memory.

[raven canopy]

k. i'll deep dive on it. thanks for the hint!

[umbral dagger]

Ripping apart my PyPortal alarm clock code tonight... and reassembling it as a class based state machine.

[exotic pumice]

in circuitscheme? 😛

[modern wing]

@umbral dagger Be careful not to get any borg nanoprobes in that code 😛

[tough flax]

Hi folks, I'm on the road for the next few days & just want to ask these two Qs before I go - no rush at all, and these aren't requests, just questions 😃 Please tag me if you answer them later...

1) Does the SPI slave software used on the PyPortal offer server programming?  I.e, can I export port 80 and respond to requests (ESPs can do this)
2) I know the ESP32 can also do bluetooth (peripheral and host)... and I'm sure it won't work on the PyPortal out of the box.  However :-)   Would it be possible to use the hardware for that?

[modern wing]

[you're doing the ST:TNG version of it, right?]

[umbral dagger]

@exotic pumice Just CircuitPython 😃

@exotic pumice I do want to build CircuitScheme support for the PyPortal... such an awesome piece of hardware.

@modern wing Indeed

[modern wing]

@umbral dagger Indeed? Now I want to build a Stargate SG-1 version.

[umbral dagger]

@modern wing Umm... I have a project in the works that might interest you.
Also, I'm into season 10 of my binge re-watch of SG-1

[modern wing]

Ah, the Farscape Season 😃

[umbral dagger]

You mean because of Vala?

[modern wing]

And Col. Mitchell

[umbral dagger]

Yeah.. I miss Jack.

[raven canopy]

I was glued to the actual Farscape when it was running. Have most of the seasons on DVD.

[modern wing]

Who doesn't miss MacGyver?

[umbral dagger]

Hmm... that might be binge-worthy

[modern wing]

@raven canopy Ah Scorpio, a real villain.

@umbral dagger So what's this project you have in the works, or is it hush hush?

[gilded cradle]

Yeah, Bruce McGill made a good Jack

[raven canopy]

@tulip sleet could be my total misunderstanding of the py/ core, but i can't see where del would call any context management. runtime calls delete functions in objdict, and nothing there suggests __exit__ is called. also tested against a mature module; seems standard behavior i'm observing:

Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 4.0.0-beta.2-149-g9d20380-dirty on 2019-02-27; Adafruit Metro M4 Express with samd51j19
>>> import digitalio, board, frequencyio
>>> foo = digitalio.DigitalInOut(board.D11)
>>> del foo
>>> foo = frequencyio.FrequencyIn(board.D11)
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
ValueError: D11 in use

granted: docs do not mention del in the lifetime context manager section anyway, so i don't think it's un-expected behavior

[umbral dagger]

@modern wing Other than doing some printing, I haven' really though much about it yet. But it'll be fun.

[crimson ferry]

Anyone know if it's a goal to eventually support all of the FeatherWings in CP (I don't suppose there's a public roadmap)? (e.g., TFT with Joystick, touch on the 2.4" TFT, etc.

[pastel panther]

yup

[raven canopy]

i would say its a goal to support as many as can be. but yeah, no roadmap per se.

[pastel panther]

these days @gilded cradle is the FeatherWings in CP guru

she's done great work on the FeatherWing library making it super easy to use all of them

@crimson ferry If there is one that you're particularly interested in you can always create an issue in the circuitpython github repo

[crimson ferry]

Thanks @raven canopy & @pastel panther ! Good to know, I'll give some thought to priorities.

[pastel panther]

You could also give it a go yourself 😉

[umbral dagger]

@modern wing Mitchell is no O'Neill (2 Ls) but has some good lines "This place is deader than a Texas salad bar".

[pastel panther]

I watched the original movie last week. so good

[modern wing]

@umbral dagger I always smiled when Mitchell spoke about how a stargate can be open for only 38 minutes -- "that's basic wormhole physics". Ah, classic Crichton.

And O'Neil with 1 'L' has no sense of humor.

[pastel panther]

Standoffs ftw

[umbral dagger]

Nice. I printed one of the horizontal stands. A vertical one is printing now.

[errant grail]

@pastel panther CPX tambourine and cowbell: https://learn.adafruit.com/blues-playground

[pastel panther]

nice!

[errant grail]

... and a vibra-slap

[manic glacier]

makermelissa

[adafruit/circuitpython] Issue opened: #1603 Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I was experimenting with changing from busio.I2C over to board.I2C() for another issue due to conflicts. It worked great in CP 3.1.2, but in both CP4 Beta 2 and the latest build off master, it causes the board to go into safe mode.

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I forgot to add that this was on a Feather M4 Express.

[gilded cradle]

@crimson ferry , the roadmap I'm following is pretty much here: https://github.com/adafruit/Adafruit_CircuitPython_FeatherWing/issues/4

[manic glacier]

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

The setup I had for reproduction purposes is I was using the test code Jerry had at:
https://github.com/adafruit/Adafruit_CircuitPython_FeatherWing/issues/35 as code.py, the latest master branch at: https://github.com/makermelissa/Adafruit_CircuitPython_FeatherWing, and the latest uncompressed versions of the minimal supporting libraries.

I was just doing a quick test in CP4 before merging when I discovered this.

[crimson ferry]

Thanks, @gilded cradle ! Very cool. I'm still figuring out how this all works.

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

when I try that test code with your feathewrwing library on a particle argon, I get

Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 4.0.0-alpha-1966-g3b58be9c7-dirty on 2019-02-24; Particle Argon with nRF52840
>>> import uv_temp_test
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
  File "uv_temp_test.py", line 10, in <module>
  File "/lib/adafruit_sht31d.py", line 95, in __init__
  File "/lib/adafruit_bus_device/i2c_device....

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

updated to current master CP -- same result

Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 4.0.0-beta.2-141-g2c9fbb5d4 on 2019-02-24; Particle Argon with nRF52840
>>>
>>> import uv_temp_test
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
  File "uv_temp_test.py", line 10, in <module>
  File "/lib/adafruit_sht31d.py", line 95, in __init__
  File "/lib/adafruit_bus_device/i2c_device.py", line 66, in __init__
AttributeErr...

dhalbert

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

Is someone calling board.I2C instead of board.I2C() ?

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

yup! @makermelissa has

import board
try:
    I2C_BUS = board.I2C()
except AttributeError:
    import busio
    I2C_BUS = busio.I2C(board.SCL, board.SDA)

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

and the failure is on the sht31d device, not on the featherwing

[solar whale]

@tulip sleet sorry for the erroneous report -- I misread the code -- ithe call looks OK

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

if I change the test code to this -- it works with

import time
import board
import busio
import adafruit_sht31d
import adafruit_veml6070

from adafruit_featherwing import alphanum_featherwing,shared

display = alphanum_featherwing.AlphaNumFeatherWing()
sensor = adafruit_sht31d.SHT31D(shared.I2C_BUS)
uv = adafruit_veml6070.VEML6070(shared.I2C_BUS)



loopcount = 0
while True:
    uv_raw = uv.read
    risk_level = uv.get_index(uv_raw)
    print('Reading: {0} | Risk Leve...

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

Ran both version on a feather_m4_ express -- the original version reproduces the safe mode crash
the modified version above work normally.

[solar whale]

@tulip sleet so once the shared.py library module creates shared.I2C_BUS = board.I2c() - does it make sence way calling board.I2C() would fail but calling shared.I2C_BUS works

this is why I want to get rid of shared.py !

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

FYI -- the safe mode crash on the SAMD51 is

Auto-reload is on. Simply save files over USB to run them or enter REPL to disable.

You are running in safe mode which means something unanticipated happened.
Looks like our core CircuitPython code crashed hard. Whoops!
Please file an issue at https://github.com/adafruit/circuitpython/issues
 with the contents of your CIRCUITPY drive and this message:
Crash into the HardFault_Handler.

Press any key to enter the REPL. Use CTRL-D to r...

[prime flower]

mornin' @solar whale - noticed the PR for ATControl wifi manager has been merged, want me to open a PR in CircuitPython_IO for supporting it? (I'll add an example/dep for the AT library and do some comments to reference it)

[solar whale]

Sure. Only the examples need to be added. No changes to the library are needed. There are some issues with the ESP8266. Weather example fails. The ESP32 works fine....

[prime flower]

AIO CircuitPython doesn't officially support ESP8266 anyway, not too worried about that.

[solar whale]

As a coprocessor it does not know the difference.

This is where it gets complicated. Only the argon really makes sense for atcontrol , but I don’t think it is officially supported

@prime flower are you testing on an argon?

[prime flower]

I dont have an argon with me, I'll tag you on a PR with a test example (modified data example with the esp atcontrol wifimanager)

[solar whale]

what are you using for AT control testing?

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

No, it shouldn't crash.

[tulip sleet]

@solar whale board.I2C() is supposed to return a singleton, so you should be able to call it as many times as you want. Shouldn't matter if it's assigned to something else or not.

[solar whale]

odd -- clearly makes a difference when done as it is in the featherwing lib. woks fine if just board.I2C() is used everywhere

[tulip sleet]

@raven canopy Are we mixed up: Not sure why del should call __exit__, but __exit_ can call __del__ (but it might not ever do so).
https://docs.python.org/3/reference/datamodel.html?highlight=del#object.__del__
https://stackoverflow.com/questions/40536821/python-enter-exit-vs-init-or-new-del
What was your thinking about del calling __exit__ ?

[umbral dagger]

OK.. touch interaction is good, state machine is good, switching between screens/modes is good. next up is allarm setting mode/screen.

[raven canopy]

@tulip sleet it could very well be me expecting the wrong stuff to happen. Was just testing my deinit...

[tulip sleet]

__exit__ is meant to be called due towith, so I realized that may not be what you need. We call deinit() explicitly because there's no guarantee that del ever does call anything, because a gc might never happen.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I'm trying to reproduce this in the simplest way possible, and not succeeding. Are you saying that your shared.py has:

import board
try:import board
try:
    I2C_BUS = board.I2C()
except AttributeError:
    import busio
    I2C_BUS = busio.I2C(board.SCL, board.SDA)
    I2C_BUS = board.I2C()
except AttributeError:
    import busio
    I2C_BUS = busio.I2C(board.SCL, board.SDA)

And then you get a crash when referencing board.I2C() in other code?
The simple REPL version...

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I couldn't get it to happen in the REPL either and I wondered if it might have something to do with calling it in different files or through an import or something. Also, the entire contents of shared.py is basically what @jerryneedell posted above.

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I also tried commenting out everything except this in shared and it still crashed.

import board
I2C_BUS = board.I2C()

dhalbert

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

This might have to do with class and global dictionaries or something like that. I'm not sure it's related to I2C at all, really. If you can give me the simplest test case you can muster that would be really helpful. Thanks.

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

Ok, I'll keep playing with it and see what I can come up with.

[meager fog]

@pastel panther hihi im around if u need testing

[pastel panther]

@meager fog (PP)

@meager fog gotta 🏃 ; send over any bmps that don't work

[meager fog]

ok is that monochrome too

[pastel panther]

ya

[meager fog]

rad

[obsidian compass]

Hello Everyone, wanted to share a small update. I'll be giving a talk at FOSSASIA Summit - 2019(Singapore) on Embedded programming for Everyone using MicroPython & CircuitPython. If there's anything specific CP community likes me add feel free to let me know 😃

I was wondering If there's anyway I could get some CircuitPython stickers to distribute during the conference..

[solar whale]

@meager fog I accidentally included the NINA_W102.bin file in that PR so it is now in the repo -- do you want it there -- or should I do a PR to remove it?

[stuck elbow]

or a force push to also remove it from the history

[solar whale]

good to know -- It may be OK for it to be there -- just let me know.

[umbral dagger]

So... the PyPortal screen update. It's not as bad as eInk.. but are there plans to make it faster?

Or are there things I can do to make it more efficient?

[meager fog]

@solar whale doesnt matter

@umbral dagger there will be partial updates after 4.0 is out, current version draws entire screen each time. its something scott wants to do for next big update once eveything is working

[solar whale]

I put in a new PR -- i had already deleted the branch -- it could easily get confused if it is there

[meager fog]

all good

[river quest]

hi @obsidian compass please email me when ya can and we'll see what we can do. [e-mail]

[umbral dagger]

@meager fog Cool. I remember him talking about that at one point.

[celest zenith]

I'm curious why was ESP8266 support dropped in 4.0?

[meager fog]

poor experience, no USB

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

I have reproduced this on a Metro M0 with this test program:

import board, pulseio

d9_pwm = pulseio.PWMOut(board.D9, duty_cycle = 2**15, frequency = 2*1000*1000, variable_frequency=True)

while True:
    prev_read_dc = -1
    prev_dc = -1
    for dc in range(0, 60000, 10000):
        d9_pwm.duty_cycle = dc
        read_dc = d9_pwm.duty_cycle
        if read_dc == prev_read_dc:
            print('requested: {}, prev requested: {}, read: {}, prev read: {}'.format(
           ...

[umbral dagger]

PyPortal alarm clock

[river quest]

good work @umbral dagger

[meager fog]

🖖

@pastel panther ok im around and ready to BMPtest

[pastel panther]

coolio

[umbral dagger]

Once my Mugsy arrives (and is assembled and runnign) the mugsy button will ask it to start my morning mug of coffee brewing.

[pastel panther]

@meager fog do you need anything from me?

[meager fog]

nope

just FYI - grabbed your uf2 above

[umbral dagger]

That way I can start the coffee before getting out of bed, and have it ready by the time I get up & going and have the cat fed.

But it can do anything.

[prime flower]

@umbral dagger mugsy?

[umbral dagger]

@prime flower https://www.heymugsy.com/

[meager fog]

@pastel panther ok

lemme know whne yr read for DEETS

[pastel panther]

I can take some deets but probably can't act on them until I'm home

[meager fog]

ok imageready generated images: 24-bit (GOOD!), 32-bit (GOOD!), 16-bit 565 (GOOD!), 8 bit and 16-bit 555 not displaying

[pastel panther]

hmmm

regressions, yay

[meager fog]

probably some exciting header thing

[pastel panther]

That 8bpp one is like another I ran into where it doesn't have palette info

what errs did you get for the 555?

[meager fog]

just nothing displays

hows it display without a pallette

[pastel panther]

Only thing I can thing is it's actually bit compressed? 🤷

can you put this in the same format as both of the above?

[meager fog]

oki

one moment

testing gray

this photoshop 8-bit gray isnt working either - but yorick-gray does

ok for testr - you want it in 8bit and in 16-bit 555?

[pastel panther]

yes please

[pastel panther]

ya the gray is the same format as the color 8 bit so it makes sense that it wouldn't work either

[meager fog]

ok this time i got the 8bit graphic to display by nudging it in photoshop to indexed color

[pastel panther]

did PS say anything before you nudged it?

if you can send over the funky 8bpp testr I should be able to get it going later

[meager fog]

@pastel panther ok i got 555 working

you need to select X1 mode

[pastel panther]

🤔

[ruby lake]

omg grand centralzeses...ordered

[meager fog]

here's another @pastel panther

[pastel panther]

doggo!

I think that image-formatter is RLE

[meager fog]

yeah ironically our online image converter is probably the easiest way to get images!

yeah i think so too

[pastel panther]

that would take some time to make work

[opal forge]

hello

[meager fog]

nonono need

[opal forge]

yeah we'll figure out how to stop image-formatter from outputting RLE if possible.

[pastel panther]

@meager fog can you send API infoz for the converter?

[meager fog]

yep one moment

IMAGE_CONVERTER_SERVICE = "https://io.adafruit.com/api/v2/schmarty/integrations/image-formatter?width=320&height=240&output=BMP" + BMP_DEPTH + "&x-aio-key=" + secrets['adafruitio_key'] + "&url="```

we use adafruit io to handle rate limiting

oops change schmarty to your name too

ill update my pyportal

[opal forge]

oops yeah that should be coming from secrets.py i guess.

[meager fog]

np ill push in a moment

ironically the best source of bonkers format images is the hackster project viewer

it would give all SORTS of weird bit depths

[pastel panther]

hah

@opal forge what lib backs that service?

[opal forge]

@pastel panther it's imagemagick

[pastel panther]

ok, thanks

[opal forge]

we're not 100% what version. it's whatever Amazon ships on their lambda containers. 6.X we think.

[meager fog]

every project expands until it uses imagemagick

[opal forge]

and the UI becomes excel

[pastel panther]

lol

It's like the Kardashev scale of Orgs

I'm becoming a 🎃 ; I'll check back in later.

[meager fog]

@pastel panther ok well i think 8 bit is going to be hairy so if you want you can take another look but im ok also saying '8 bit not supported'

[pastel panther]

I've got some time left so I'll take a gander

[idle owl]

sigh NeoPixels work in super complicated code, not with simple NeoPixel demo examples. I don't get it. (yes @tidal kiln, I tried calling show())

oi nm. sorted it. have to pull enable high. Forgot about that.

[meager fog]

@pastel panther 1 bit looks great. 16 doesnt' exist for imagemagick for some reason but we'll do more testing once thats resolved (whee)

[stuck elbow]

anybody knows why mp_arg_check_num suddenly takes a pointer as its second argument instead of an integer?

urgh, looks like the whole signature of *_make_new has changed

[tidal kiln]

@idle owl have you run into SlideShow / 4.x / board.TFT_BACKLIGHT issue yet?

[idle owl]

Haven't been doing much with displays, so no

[tidal kiln]

looks like that pin gets pwn'd by 4.x

Press any key to enter the REPL. Use CTRL-D to reload.
Adafruit CircuitPython 4.0.0-beta.2 on 2019-02-05; HalloWing M0 Express with samd21g18
>>> import board
>>> import pulseio
>>> backlight = pulseio.PWMOut(board.TFT_BACKLIGHT)
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
ValueError: TFT_BACKLIGHT in use
>>>

the change is mentioned in the beta notes, but it does break some current guides and examples

[pastel panther]

I was going to do a PR to fix the Sprite references so I can update the backlight stuff in the displayio examples

Unless someone beats me to it

[meager fog]

sure go for it 'sidd

[raven canopy]

@stuck elbow i ran into that one too. 😦

[tulip sleet]

@timber mango we changed it so we could subclass native classes that take keyword args: see https://github.com/adafruit/circuitpython/pull/1472. Scott discussed it with Damien. Damien liked the idea, but didn't want to change that function signature for backwards compat reasons: he would have added yet another arg or something. But we didn't have that constraint. This is cleaner.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

@kevinjwalters Could you please test this uf2? It seems to fix the above problem. But I have not actually looked at the output waveforms, and you're in a better position to do that. I tested on a Metro M0, but I believe I replicated the test conditions you set up (I used the same physical chip pin, etc.). Thanks.

cpx-fix-pwmout-tcc-2019-02-28.uf2.zip

[umbral dagger]

Added a snooze button to the PyPortal alarm clock.

[raven canopy]

hehe. snooze is the dangerous button. but...also my favorite. 😄

[pastel panther]

@meager fog wrong channel, sorry

[meager fog]

hi

@pastel panther either way 😃

these are great - we'll def use these low bit depths for icons/buttons

[pastel panther]

shweet. I'm just gonna give it a quick refactor so it doesn't look like it was written by a 3 year old, then PR

[tough flax]

For those playing with a PyPortal (mine comes tomorrow & I'll be in NYC :-/) here's a thought. This service transcodes images on the fly. So, in theory you can take the URLs in <img> tags and URLEncode them and then make the request here with a parameter of &output=bmp -- just a thought

https://images.weserv.nl/

[umbral dagger]

@raven canopy Now I need a "snoozing" indicator

[tough flax]

Ugh - Ignore me - BMP is not on the list (not sure why I thought it was:

Output&output=
Encodes the image to a specific format. Accepts jpg, png, gif, tiff or webp. If none is given, it will honor the origin image format.

[dry axle]

Hey y’all. What’s the circuitpython snake’s name?

[pastel panther]

Blinka!

@tough flax Limor's pyportal demo code comes with an API call you can use to convert stuff to BMPs 😃

[meager fog]

@tough flax hiya we already have that

https://github.com/adafruit/Adafruit_CircuitPython_PyPortal/blob/master/adafruit_pyportal.py#L646

[manic glacier]

dhalbert

[adafruit/circuitpython] Pull request opened: #1604 Don't wait for display frame if interrupt pending

common_hal_displayio_display_wait_for_frame() would call the background tasks over and over. If a reload was pending, displayio_refresh_displays() would stop refreshing, but common_hal_displayio_display_wait_for_frame() didn't know that.

The effect was that writes to CIRCUITPY would cause the board to apparently freeze (because the display was frozen). It was really cycling in the background task, never to return.

Details:

• Check for pending interrupts in `common_hal_displayio...

dhalbert

[adafruit/circuitpython] Pull request opened: #1605 Use TCC LUPD lock when updating CCB

Should be a fix for #1597.

• When PWMOut used a TCC, it did not use the TCC CTRLB LUPD lock mechanism to lock out the double-buffering while writing CCB. This seemed to cause the CCB to CC automatic write on UPDATE not to happen sometimes. The Arduino code does use LUPD, so I copied the way they did it.
• There were also some places where some SYNCBUSY clock domain synchronization was not done.
• A couple of SYNCBUSY loops called MICROPY_VM_HOOK_LOOP, which I don't believe was neede...

dhalbert

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

This may the most incomprehensibly jargon-filled PR description I have ever written.

[tough flax]

@meager fog Sweet! BTW am I missing a bit quite public doc repository on this board?

[manic glacier]

sommersoft

[adafruit/circuitpython] New comment on pull request #1144: Add pulseio\.FrequencyIn

Seeing as how this PR is REALLY stale, would it be better to close this and open a new PR for my current iteration? I'm close (hopefully this weekend), but have been thinking about this...

dhalbert

[adafruit/circuitpython] New comment on pull request #1144: Add pulseio\.FrequencyIn

Sure, no need to ask permission.

sommersoft

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

Leftover closing bracket from previous while SYNCBUSY. Fairly certain this is causing the Travis fails.

sommersoft

[adafruit/circuitpython] New comment on pull request #1144: Add pulseio\.FrequencyIn

Thanks @dhalbert. Only concern was obfuscating the history. I was planning to reference this PR in the new one at any rate. Will close once the new one is up.

[umbral dagger]

Snooze working well, with an onscreen indicator. Now to tidy up the code and write a guide.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

Thanks for catching that! I did an edit after a test compile, and didn't repeat it :(

[manic glacier]

siddacious

[adafruit/circuitpython] Pull request opened: #1606 added monochrome, 8bpp index, and 32bpp ARGB BMPs

More bitdepths! Tested on PyPortal.

[manic glacier]

ladyada

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp index, and 32bpp ARGB BMPs

ive tested this, works gr8

[manic glacier]

kevinjwalters

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Sure, I can give it a test today or tomorrow on my CPX. The explanation in #1605 fits the type of bug I was expecting particularly wrt sporadic occurrence.

Does that uf2 need to re rebuillt due to the absent bit that @sommersoft noted in #1605?

kevinjwalters

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

Will this fix end up in 4.0.0?

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I kept trying to boil this down and even just removing a little of the SHT31D module made it behave as expected. It seems to be some kind of bad combination of things. I can go ahead and close this is you want or leave it open for later.

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

Nevermind, I got it to crash again, so I'll keep working on it.

[lone sandal]

wwj718

[adafruit/awesome-circuitpython] New star added

[lone sandal]

xavierchan

[adafruit/awesome-circuitpython] New star added

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

Will this fix end up in 4.0.0?
Definitely!

dhalbert

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Does that uf2 need to re rebuillt due to the absent bit that @sommersoft noted in #1605?
No, that just broke the M4 builds (syntax error). The CPX build I gave you above is fine.

dhalbert

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

I can go ahead and close this is you want or leave it open for later.\

No, please leave it open. A crash is a crash, and needs to be fixed.

deshipu

[adafruit/circuitpython] Pull request opened: #1607 Add support for PewPew 10\.x boards

This is an initial pull request to start the discussion about how to best incorporate this into the main repository. For the PewPew boards to work, there needs to be the _pew module added, which handles the LED matrix display and the buttons on those boards. There is also the pew Python library frozen to give easy access to all that.

dhalbert

[adafruit/circuitpython] Pull request opened: #1608 Update PyPortal pins to rev C

Red LED now on PB23.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

I'd suggest not including this Python code in the adafruit/circuitpython repo, but instead in a separate submodule repo as a library like we do the other frozen modules. Then it can be modified experimentally by changing the library repo code and changing `sys.path. If it needs to be updated, it's a very simple PR to just update the submodule commit.

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

:+1: CIRCUITPY_PEW was exactly what I was going to suggest before I even saw this code.

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Fix formatting style.

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Can this repository live outside of adafruit's github?

dhalbert

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

Add space before {.

dhalbert

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

Not sure what you mean by stale.

dhalbert

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

Add space after } and before {.

kevinjwalters

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Ran my previous test, then ran it again with upping the iterations from 9 to 99 - all tiptop - fix looks good on my CPX, ta.

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Sure, we depend on plenty of submodule repos that are outside the adafruit organization (though no libraries yet).

dhalbert

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Great, are you getting the waveforms out that you want?

[plucky flint]

Just wondering if folks have seen this... https://blog.littlevgl.com/2019-02-20/micropython-bindings

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Those errors can only happen when the object is created, and that only happens in the pew.py library that is frozen — the users should never see any of those errors, unless they are creating their own version of the board and compiling their own firmware for it. Because of that, and because I have struggled hard to fit all the required modules inside the firmware, I decided to remove error messages to save space. I will change it to ValueError as suggested, though.

[plucky flint]

"GL" means "GUI library" AFAICT

Rather than GL as in 3d OpenGL graphics (where, er... GL stands for "graphics library" too). #confusing

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

There is no dependency. CIRCUITPYTHON_PEW is completely independent from the others.

dhalbert

[adafruit/circuitpython] Pull request closed: #1608 Update PyPortal pins to rev C

dhalbert

[circuitpython:master] 2 new commits

fb027f2 Update PyPortal pins to rev C - dhalbert
5af2c7f Merge pull request #1608 from dhalbert/pyportal... - dhalbert

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

I will look into it but I basically copied the code that is right now in pwmout.c.

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Sorry, no idea how that sneaked in.

dhalbert

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

Remove "this name is stale".

siddacious

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

🤦‍♂️

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

By the way, that timer.c file has some ^Ms in it...

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Feel free to clean that up. We appreciate it!

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

@dhalbert thank you for your review!

[simple pulsar]

@tulip sleet For that testing I was previously running really close to the memory limits of the CPX and that new uf2 pushed me over the edge. Will I save a lot from mpy'ing the adafruit_midi.py additions I'm working on?

[tulip sleet]

@simple pulsar it can't hurt. In general making an .mpy fixes two things: 1. failure to compile on import due to not enough RAM. 2. Less fragmentation of RAM due to compilation. An .mpy still uses up RAM at run-time unless it's frozen in. If you are just running out of RAM period at run-time due to data and program size, then the .mpy will not ultimately help.

[simple pulsar]

I think it's mainly program size as the approach I'm using is class heavy but I'll have a look any also play with the commands that show the memory footprint

[tulip sleet]

🔮 I see an M4 in your future.

[manic glacier]

makermelissa

[adafruit/circuitpython] New comment on issue #1603: Initializing with board\.I2C\(\) multiple times causing crash into safe mode

Ok, thanks Danh. I'll leave it be.

[simple pulsar]

I have got an M4 but my friends have a lot of M0 hardware like Gemma and CPX so I don't want to exclude them

[gilded cradle]

USPS changed my delivery date on me. I found out I'm getting my PyPortal today instead of tomorrow. I'm very excited.

[pastel panther]

whoo!

[prime flower]

@gilded cradle Whoo! :pyportal emojiiii:

[gilded cradle]

😃

[prime flower]

I'm excited to see your projects with it

[gilded cradle]

Thanks!

I have a few ideas

[prime flower]

rc-car controller

[gilded cradle]

Maybe

I was thinking more along the lines of making a framework to play games or something, but that might be a little ambitious.

[pastel panther]

hey @prime flower any thoughts/plans about exporting AIO dashboards for use on PyPortal or similar devices? I assume it would need some more supporting code in CP but I think the idea has merit

[prime flower]

@pastel panther as in, mirroring an IO dashboard?

[pastel panther]

Yea. I was thinking there could be some CP side code that knows how to render a subset of the dashboard blocks.

I was thinking "export" because I was imagining AIO could generate assets, if that was needed

[prime flower]

@pastel panther I'd wait until displayio becomes finalized before moving forwards with that idea. Adafruit IO's API supports dashboard and block generation, and you could also GET block information if you wanted to pull the block data and mirror it on a display (https://io.adafruit.com/api/docs/#operation/getBlock).

I think the IO blocks, for instance the gauge block, wouldn't render quickly enough on the PyPortal (as of now) for visualizing real-time data.

[pastel panther]

ya displayio needs to be fleshed out a bit and optimized and even then probably wouldn't be fast enough for some use cases, but even if screen updates were rate limited it could be useful.

For example a temp/humidity histogram that updated every 5-15 seconds could be cool, depending on how fast data was coming in

[prime flower]

a mini histogram for pyportal would be really neat, even if the refresh is a minute

[pastel panther]

heck, you could have AIO render it to BMP at that speed

probably a better way but that would be quick to get going

(sez the guy not working on AIO)

[prime flower]

yeah - a hacky way of doing it would be multiple BMPs for a gauge block to display levels

for example

[pastel panther]

...stored as a sprite map/table thing? 🤔

[manic glacier]

dhalbert

[adafruit/circuitpython] Pull request closed: #1605 Use TCC LUPD lock when updating CCB

dhalbert

[circuitpython:master] 3 new commits

808304e Use TCC LUPD lock when updating CCB - dhalbert
3c24e89 Fix SYNCBUSY loop typo. - dhalbert
7535326 Merge pull request #1605 from dhalbert/pwmout-t... - dhalbert

dhalbert

[adafruit/circuitpython] New comment on pull request #1605: Use TCC LUPD lock when updating CCB

Saleae'd a PWMOut pin. Looks OK.

dhalbert

[adafruit/circuitpython] Pull request closed: #1606 added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

dhalbert

[circuitpython:master] 5 new commits

398c706 added monochrome, 8bpp indexed, and 32bpp ARGB ... - siddacious
014595b fixed whitespace, clarified variable name, and ... - siddacious
e9f1812 Merge branch 'master' into bmp_bitdepths - siddacious
76dc8e1 fixed typo - siddacious
1ba7610 Merge pull request #1606 from siddacious/bmp_bi... - dhalbert

dhalbert

[adafruit/circuitpython] New comment on pull request #1606: added monochrome, 8bpp indexed, and 32bpp ARGB BMPs

Thank you!

dhalbert

[adafruit/circuitpython] New comment on pull request #1600: Add basic Pybadge board definition

We'll wait for your word that it's working before merging.

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Travis is reporting failures like this:

/tmp/ccmPl5TW.ltrans16.ltrans.o: In function `shared_timer_handler.part.0':
<artificial>:(.text.shared_timer_handler.part.0+0x82): undefined reference to `pewpew_interrupt_handler'
/tmp/ccmPl5TW.ltrans29.ltrans.o: In function `reset_port':
<artificial>:(.text.reset_port+0x190): undefined reference to `pew_reset'
collect2: error: ld returned 1 exit status
Makefile:308: recipe for target 'build-circuitplayground_express/firmware.elf' failed

dhalbert

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Fixed by #1605

dhalbert

[adafruit/circuitpython] Issue closed: #1597 pulseio\.PWMOut duty\_cycle assignment fails infrequently

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

That is strange, because it does compile on my computer, obviously. I wonder what does that <artificial> mean?

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

I cloned your repo and get the same errors locally. So maybe something local not committed or pushed?

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

nothing to commit, working tree clean

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

Ah, on boards that do not have CIRCUITPY_PEW = 1, the .c file for those functions is not compiled. So I think you need to #if CIRCUITPY_PEW guard the uses of those pew functions in timer_handler.c and somewhere if

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

doh!

dhalbert

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

This is a side effect of the build refactoring I did. The build used compiled nearly everything, or remove stuff in a coarse way. It left -flto to prune out unused stuff. -flto didn't always do the greatest job, so it included unneeded things, and it also hid some places that should have been conditionally compiled.

deshipu

[adafruit/circuitpython] New comment on pull request #1607: Add support for PewPew 10\.x boards

I like the new way a lot, it's much cleaner and less magical too. Good job!

[crimson ferry]

Is there an official pyportal_startup.wav somewhere?

[river quest]

@crimson ferry yah, there is! we'll have a spot for it as we get everything in one spot during the launch

some odds and ends and art is also located here: https://www.dropbox.com/sh/zvjyb25312dv3t6/AACioQ0sk756hIdhchgRCIyla?dl=0

[simple pulsar]

@tulip sleet Whilst on the topic of PWM and CPX, do you know if there's any way to squeeze an extra PWM out of a CPX, perhaps by disabling something? I put a question on forums about this: https://forums.adafruit.com/viewtopic.php?f=60&t=148017

[tulip sleet]

@simple pulsar The order in which you create the PWM's may make a difference, since only certain TC's or TCC's are on certain pins. Have you tried this? https://learn.adafruit.com/circuitpython-essentials/circuitpython-pwm#wheres-my-pwm-8-21

[simple pulsar]

@tulip sleet No, hadn't seen that but it's similar to my loop. I could write a combination checker if that deinit() does a full cleanp-up. Thanks. I was just wondering if there was someway to sacrifice something like on-board NeoPixels which I presume must use some sort of clock

[tulip sleet]

the on-board peripherals including the neopixels use up a lot of pins which are not exposed on the outside. You could solder jumpers to them. But getting another board with more pins may make more sense. If there are features of the CPX board you're using (like touch) or the accelerometer, then you can duplicate that with offboard stuff.

[simple pulsar]

@tulip sleet ah, of course, I sometimes forget there are other pins not exposed in use. A7 shows up in use even when no code has run, is there someway I can hijack that? ```Adafruit CircuitPython 4.0.0-beta.2-141-g2c9fbb5d4-dirty on 2019-02-28; Adafruit CircuitPlayground Express with samd21g18

import board
import pulseio
a7first = pulseio.PWMOut(board.A7, duty_cycle=2**15, frequency=880, variable_frequency=False)
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
ValueError: All timers for this pin are in use

[tulip sleet]

A7, aka TX and D1, is PB08. See https://github.com/adafruit/circuitpython/blob/master/ports/atmel-samd/boards/circuitplayground_express/pins.c and then also see the big table at http://ww1.microchip.com/downloads/en/DeviceDoc/SAMD21-Family-DataSheet-DS40001882D.pdf, starting on page 28, which describes which TC's and TCC's are available for which pins (see columns E and F. That will tell you what the conflicts are. It's "pin sudoku", as Limor says.

[simple pulsar]

@tulip sleet thanks for the pointers

[tulip sleet]

The nRF chips are much simpler: most pins can be used for most purposes, but the peripherals are not as capable.

[manic glacier]

jreese

[adafruit/circuitpython] New comment on pull request #1600: Add basic Pybadge board definition

This was done during the PyCascades sprint, using a board borrowed from @tannewt that I no longer have access to.

dhalbert

[adafruit/circuitpython] Pull request closed: #1607 Add support for PewPew 10\.x boards

dhalbert

[circuitpython:master] 21 new commits

a41ea27 Add pewpew70 board - deshipu
5a1e69f Correct a typo in the pin name - deshipu
7ac11ed Enlarge the usb disk - deshipu
88e4019 Add a _pew module - deshipu
55b511a Use a dedicated timer - deshipu

[simple pulsar]

@tulip sleet there's talk of single slope PWM in them and the diagrams suggest this is a sawtooth wave output. Can it really do that? Is there a way to select that from CircuitPython? I don't see a way to select the waveform in https://circuitpython.readthedocs.io/en/latest/shared-bindings/pulseio/PWMOut.html

[umbral dagger]

I'm starting on a PyPortal alarm clock guide . Came out to 525 lines of CircutiPython (plus a bunch of library modules). Almost 140K of ram left after everything is loaded and allocated. This is a sweet, sweet chip/board.

[uneven star]

Does the PyPortal have a speaker? What's the "alarm" portion?

[idle owl]

It does have a speaker, and a speaker connector 😃

[simple pulsar]

Speaker mentioned on https://www.adafruit.com/product/4116 but no power details. I'd assumed it's a 500W affair.

[tulip sleet]

@simple pulsar I think the sawtooth patterns you are seeing are not the output waveforms, but are representations of the TC/TCC counter register values: they increment up and then hit a limit and start over. Any specific page reference?

tiny speaker on the back (same speaker as CPX) and also has audio amp with speaker connector, as @idle owl mentioned

https://learn.adafruit.com/adafruit-pyportal/pinouts#speaker-and-speaker-connector-2-15

[manic glacier]

jreese

[adafruit/circuitpython] New star added

[simple pulsar]

@tulip sleet Ah, yes, i was getting prematurely excited by spotting some ramping waveforms but the wo[x] at bottom of page 715 still looks very square 😦 https://www.adafruit.com/product/4116

@tulip sleet Wrong paste: http://ww1.microchip.com/downloads/en/DeviceDoc/SAMD21-Family-DataSheet-DS40001882D.pdf

[tulip sleet]

yep, that shows the COUNT register value

[main meteor]

You can get a sawtooth out, however (on some chips): https://learn.adafruit.com/waveform-generator

[crimson ferry]

@uneven star schematic shows a PAM8301 1.5W class D amp driving the 7.5mm speaker, with a molex picoblade connector to attach an optional external speaker

[simple pulsar]

@main meteor Thanks, for my particular use I'd like something hardware driven and I'm already using A0 output on CPX for an analogue out. The M4 stuff is more capable in many ways but I'd like to see what I can get out the humble CPX for now.

[idle owl]

@umbral dagger Hey. You wrote the Prop-Maker Lightsaber code, right?

[stuck elbow]

hmm, I'm not sure if I'm seeing things, but every time I disconnect pewpew with the new cp 4 firmware, it mutes my sound

[idle owl]

@tulip sleet^^

You said something about Spotify earlier...

[stuck elbow]

I need to test it with an official board

[main meteor]

If you're already using the only analogue output, and you want an analogue signal, you'll need some external hardware. I'm thinking a ramp generator (op-amp integrator or constant-current source), or an outboard DAC, but there may be other options.

[tulip sleet]

@timber mango that happened to me too, it turns down the volume on spotify. Something to do with HID Consumer Control, maybe? I don't know what changed to cause this

I thought it was on boot-up, not disconnect, but I was doing a lot of restarting

[simple pulsar]

@carmine hornetni There's an animated image of a CPX in this PyPortal guide, is that intentional? https://learn.adafruit.com/adafruit-pyportal/uninstalling-circuitpython#moving-to-makecode-18-3

[tulip sleet]

@timber mango one of us should file an issue on this to remember it

[simple pulsar]

Ooops, last message I meant @idle owl

[solar whale]

@idle owl just curious -- have you tried connecting any I2C sensors to your pyportal via the I2C (4 pin JST) connector?

[idle owl]

@simple pulsar Yeah it's in all the guides. It's meant to show how to reset the board. That movement is the same for all boards.

@solar whale I have not, why?

[tulip sleet]

limor said the hallowing was also 5v stemma

[solar whale]

I have a concern about the votlage on one of the pins -- not sure if it is an issue -- I asked about in the #help-with-circuitpython channel earler and @tulip sleet is looking into it. Just wanted to see if you had actually done it .

[idle owl]

I hadn't. But I added a note to the guide based on your question. There's a jumper that you can use to change it to 3.3V. But it defaults to 5.

[simple pulsar]

@idle owl ok, just checking! What's the typical range for power consumption for the PyPortal? I haven't read much about this.

[idle owl]

@simple pulsar No idea! 😃 Others will know better than I.

[stuck elbow]

@tulip sleet okiedokie

[solar whale]

@tulip sleet so is is safe to leave it at 5V and connect -- I dont want to damage the onboard ADT temperature sensor

[idle owl]

@solar whale "The sensor is good from 2.7V to 5.5V power and logic, for easy integration."

From the ADT7410 breakout product page.

[solar whale]

ah -- thanks.

I guess I'll stop worrying ....

[umbral dagger]

@idle owl Wasn't me. I did the New Years Eve ball drop code.

[idle owl]

Oh hmm. Fair enough, thanks.

Bummer. Was hoping for help with it 😄

[tulip sleet]

@solar whale just checked Hallowing STEMMA connector with a meter. It's also 5V from the factory.

[umbral dagger]

@idle owl I don't know who did it, but I'm happy to have a look and help as I can.

[tulip sleet]

STEMMA is compatible with Grove, which also could be 5V or 3.3V

[simple pulsar]

@main meteor Yep, I thought about external hardware but difficult to know where to stop on that one plus still need some way to control it.

[tulip sleet]

@simple pulsar I have a USB breakout and can measure this in a minute

[simple pulsar]

@tulip sleet not urgent, I was just curious how feasible battery powering was

BTW, i just added to a STEMMA discussion on here: https://forums.adafruit.com/viewtopic.php?f=19&t=123991

[pastel panther]

@simple pulsar The Ruiz's have a guide on battery powering the PP, I think

[solar whale]

@idle owl Do you know who is doing the OpenWeather guide for the PyPortal?

[idle owl]

@umbral dagger I'm trying to adapt it and I'm seriously struggling. I'm about 5 minutes from trying to redo a whole new program myself. Noe and Pedro did another build (an axe) that they want similar functionality for, but not similar enough to simply change a couple of things. I'm trying to make it so it pulses when it's idle. I can't figure out making NeoPixels pulse in a way that isn't blocking. Also trying to make it do a particular thing on swing, which I think might be working, but it's tough to tell with not being able to figure out adapting the rest of the code.

@solar whale No idea.

[pastel panther]

@simple pulsar https://learn.adafruit.com/portable-pyportal

[idle owl]

@umbral dagger long story short, I feel like I'm out of my depth. I thought it would be a simple modification of code to do a couple of other things, but it's turning out to not be simple at all. At least to me.

[pastel panther]

dunno if it actually needs the boost converter

[solar whale]

@simple pulsar thanks for the STEMMA link

[idle owl]

@pastel panther You can't power it directly from a battery.

[pastel panther]

Yea but it's got a regulator, right? I'm just sayin' I don't know that it needs to go up to 5v then back down

[idle owl]

Ah

I don't know either then.

[simple pulsar]

@solar whale I came across it and had no idea what it was hence I started looking around for the spec and eventually realised it was an Adafruit thing

[umbral dagger]

@idle owl OK.. Want to move this to a side channel?

[idle owl]

Sure.

[tulip sleet]

@simple pulsar starting up, looks like 150mA, but when the slideshow demo starts running (which varies the backlight), runs like 60-90mA. So the backlight is the big hog.

[solar whale]

@simple pulsar I feel better about being confused now 😉

[manic glacier]

deshipu

[adafruit/circuitpython] Issue opened: #1609 USB disconnect or reset mutes sound on the computer

For some reason with the 4.0 code, even with CIRCUITPYTHON_USB_HID=0 and CIRCUITPYTHON_USB_MIDI=0, disconnecting or hard-resetting the board results in my sound getting muted. I tested that initially with PewPew (which is pretty much a Trinket M0), but confirmed it now with a Hallowing M0 Express.

Interestingly enough, nothing is appearing in xev when that happens.

dhalbert

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

This is on Ubuntu, right? We should test on other OS's.

siddacious

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

I've been plugging/unplugging, resetting etc. ad nauseam the last few days with master+ and haven't noticed anything getting muted on my Mac (Mojave)

[prime flower]

@solar whale I have 2 sensors connected to my pyportal using that connector rn

[manic glacier]

waako

[adafruit/circuitpython] New star added

[prime flower]

VEML7065 and BME680 using a 4-pin stemma i2c

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

Yes, more precisely Linux Mint with XFCE4. It doesn't happen on Fedora 28, also with XFCE4.

[pastel panther]

@simple pulsar As has been covered the positive pin of the JST goes to 'VCC' which is a jumper that defaults to the 5V from vbus after the PTC. This means that jumper is basically chosing between upstream and downstream of the regulator

[solar whale]

@prime flower no smoke ?? -- I have one more question about this -- at least -- The ADT7410 data sheet says SCL/SDA absoute rating is VDD+ .3 but they are powered by 3.3V so taht is 3.6V -- is it OK an I2C device is putting 5V on SDA?

[prime flower]

No smoke , no. It's been running logging data to IO for the past hour or so

[tulip sleet]

The I2C device is open collector and doesn't apply voltage directly. It is just open or grounded.

the voltage is provided by the pullups

[solar whale]

so there is 3.3v pullup connected to a 5V pullup correct?

[tulip sleet]

there are 3.3V pullups on the PyPortal. I measured teh SDA and SCL pins on the connector and they are 3.3V

but yeah if you connected an external device there could be 5V on its pullups

[solar whale]

right - and if I connect to an I2C device with VCC = 5V it will use 5V on its pullups

is that OK?

[tulip sleet]

good q, not sure. hold on

[solar whale]

sure -- that is really what has been troubling me.

[tidal kiln]

it would depend on the device - what it does with the actual VCC line

[solar whale]

right -- most seem to imply that the SCL/SDA follow VCC.. The external devices will be OK but I am worried about violating the maximum voltage on the ADT7410 onboard

[tulip sleet]

an example is an SHT31D breakout which doesn't need a regulator cause it's 2.4V-5.5V

[pastel panther]

@solar whale from the ADT7410 datasheet:

Wide operating ranges
Temperature range: −55°C to +150°C
Voltage range: 2.7 V to 5.5 V

[tulip sleet]

then that is OK

[tidal kiln]

but is safe v-logic set by actual VCC used?

[solar whale]

see Table 3 of the data sheet -- absolute ratings -- VDD + .3

VDD can be 2.7 - 5.5 -- but SDA must be < VDD + .3

at least that is how I read it.

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

I think that it is not keyboard — I disabled keyboard shortcuts for volume control, and it still happens.

dhalbert

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

are they regular keyboard shortcuts or Consumer Control shortcuts?

[solar whale]

and regarding the SHT31D -- SCL/SDA are pulled up to VDD -- exactly my concern. What will the SDA on the ADT7410 see if I connect an SHT31D

[pastel panther]

@solar whale that's how I read it as well (under absolute maximum ratings?)

[solar whale]

so is it a problem?

clearly not a catastrophic one - as @prime flower is seeing -- but is it a good state to put it in?

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

How do I tell?

I just checked that it doesn't happen with 4.0.0-alpha.5

[tulip sleet]

limor says not a big deal; the pullups are very weak

[solar whale]

@tulip sleet OK -- I'll take that as a clean bill of health. As my EE colleagues at work are fond of pointing out -- I'm just the "software guy" so I'm way out of my comfort zone. this caught my attention and I wanted to clarify it before I started connecting things.

I have to go offline for a bit -- the dog is desperate for a walk! Thanks for the discussion.

[tulip sleet]

@solar whale given https://forums.adafruit.com/viewtopic.php?f=8&t=128512&p=639992 I'd suggest asking in the forums so that Bill or Mike or someone with EE background would answer. Don't ask in CircuitPython subforum, ask in Electronics or Other Products

they leave the CircuitPython forum to us

[solar whale]

Ok. I’ll post something when I get back.

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

Looks like commit b5e40f52c2b1c2890c866d7305e0e99b4811b7f5 is the problem.

dhalbert

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

Thanks for the bisect or equivalent. That's a big commit: USB MIDI and a lot of tinyusb changes. I'll put a sniffer on the USB traffic and see what's up.

[tulip sleet]

@solar whale - limor says (paraphrasing) : the current is so low, and also there's a 3.3V pullup on the pyportal; it won't have a bad effect

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

Another thing that may be relevant: the board shows up in alsamixer in the list of sound cards. My current working theory is that Ubuntu does something weird when a sound card is disconnected — perhaps the same mechanism that switches volume when headphones are connected/disconnected.

deshipu

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

I wonder how hard it would be for the board not to appear as a MIDI device when CIRCUITPYTHON_USB_MIDI is disabled, and also not appear as a keyboard when CIRCUITPYTHON_USB_HID is disabled.

dhalbert

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

Then it's the MIDI. USB MIDI is a subclass of audio device (from https://github.com/adafruit/circuitpython/blob/master/tools/gen_usb_descriptor.py)

audio_midi_interface = standard.InterfaceDescriptor(
    description="Midi goodness",
    bInterfaceClass=audio.AUDIO_CLASS_DEVICE,
    bInterfaceSubClass=audio.AUDIO_SUBCLASS_MIDI_STREAMING,
    bInterfaceProtocol=audio.AUDIO_PROTOCOL_V1,
    iInterface=StringIndex.index("CircuitPython MIDI"),

I wonder how hard it would be for...

[manic glacier]

kevinjwalters

[adafruit/circuitpython] New comment on issue #1609: USB disconnect or reset mutes sound on the computer

I found the CPX didn't work as a keyboard when I plugged it into a school's computer. It made me wonder if there was something about the other usb devices that it was showing up as which made it block the port. It's alluded to in https://forums.adafruit.com/viewtopic.php?f=48&t=146648#p725650

I'd tweaked the CPX dice project (https://github.com/kevinjwalters/circuitpython-examples/blob/master/cpx/cpx-dice-typer.py) and it was supposed to type the numbers. Worked at home but not at the scho...

[crimson ferry]

Just a note to PyPortal users (as you'd soon discover anyway)... temp readings tend to be higher than ambient due to other bits on the board. Flipping it from slanted on standoffs to upside-down straight vertical drops the temp by 2°F, but still above ambient. Could calibrate that away in a stable environment.

[umbral dagger]

@crimson ferry IMO it's best for monitoring the temp of the board. I.e. insode the case if using one.

[crimson ferry]

gotcha... I've been letting the (notoriously wrong) CPU temp and the 7410 temp run all day, just to see what shakes out

[manic glacier]

siddacious

[adafruit/circuitpython] New comment on issue #703: Ethernet FeatherWing Library

Just chiming in to voice my support for this. I'd be happy to test once the feathers are back in stock.

[manic glacier]

kevinjwalters

[adafruit/circuitpython] New comment on issue #1597: pulseio\.PWMOut duty\_cycle assignment fails infrequently

Waveforms are good, just been playing with those.

[solar whale]

Had a blast with the PyPortal today -- Congratulations all who made it available!

[pallid garnet]

Hi

I cant get the circuit playground express thermistor temp plotter to work in MU. Does anyone know why this isnt working?

I have circuit python, lib and ex files. code copied to mu and playground...

the light sensor worked but the temp is not loading

[tulip sleet]

@pallid garnet what code are you using, and what do you mean it isn't loading?

[pallid garnet]

import time

import adafruit_thermistor
import board

thermistor = adafruit_thermistor.Thermistor(
board.TEMPERATURE, 10000, 10000, 25, 3950)

while True:
print((thermistor.temperature,))
# print(((thermistor.temperature * 9 / 5 + 32),)) # Fahrenheit
time.sleep(0.25)
this worked for Celcius

im trying to get it to convert to F

[tulip sleet]

This is working for me:

import board

thermistor = adafruit_thermistor.Thermistor(
    board.TEMPERATURE, 10000, 10000, 25, 3950)

while True:
    #print((thermistor.temperature,))
    print(((thermistor.temperature * 9 / 5 + 32),))  # Fahrenheit
    time.sleep(0.25)

@pallid garnet I just commented the Celsius line and uncommented your Fahrenheit line. I thought perhaps there was a parens problem but it looks fine.

[pallid garnet]

I was able to get this to show me C and F

import time
from adafruit_circuitplayground.express import cpx

while True:
print("Temperature C:", cpx.temperature)
print("Temperature F:", cpx.temperature * 1.8 + 32)
print((cpx.temperature, cpx.temperature * 1.8 + 32))
time.sleep(1)

https://learn.adafruit.com/circuitpython-made-easy-on-circuit-playground-express/temperature

[tulip sleet]

cpu.temperature may be somewhat less accurate than thermistor.temperature because it's measuring the temperature inside the CPU package (which is slightly warm). But since I got your original code to work, what was the problem you had with it?

[raven canopy]

@stuck elbow got a timer_handler PR in before me, so i got bumped on the #define list. 😦 however, good call on the switch vs if! i've already forgotten switch/case exists (i'm looking at you Python!). 😄

[pallid garnet]

Awesome it's working. Thank You

import time

import adafruit_thermistor
import board

thermistor = adafruit_thermistor.Thermistor(
board.TEMPERATURE, 10000, 10000, 25, 3950)

while True:
#print((thermistor.temperature,))
print(((thermistor.temperature * 9 / 5 + 32),)) # Fahrenheit
time.sleep(0.25)

[tulip sleet]

you can put your code in triple backquotes in discord and it will format it nicely (backquote is to the left of the "1" key)

But I didn't do anything! You did it yourself! Maybe there was just a simple indentation error or something like that.

[pallid garnet]

import time import adafruit_thermistor import board thermistor = adafruit_thermistor.Thermistor( board.TEMPERATURE, 10000, 10000, 25, 3950) while True: #print((thermistor.temperature,)) print(((thermistor.temperature * 9 / 5 + 32),)) # Fahrenheit time.sleep(0.25)

.......likethat

cool

[crimson ferry]

Would it make any sense to put in an issue to add identical ESP32SPI pin constants from the M4 and PyPortal, to defaults for the ItsyBitsy M4? (ESP_BUSY=D10 ESP_RESET=D5 ESP_CS=D9) I think all of the other Express boards are covered. afaict GPIO0 isn't exposed on the ESP32 Huzzah, but I suppose someone could tie a bare module to a ESP_GPIO0 pin on ItsyBitsy. Just a matter of more consistent examples I think.

[pastel panther]

@crimson ferry I'm not sure I follow. You want to add pin aliases for use with ESP32SPI to the itsybitsy M4?

[crimson ferry]

@pastel panther Right. Minor issue perhaps, but since any Express board can be used with ESP32SPI, wiring instructions and example code can work w/o modification. Right now, I know those pins are defined as above for Feather M4 (though I've scoured and I'm not sure where), so I'm proposing those ESP32SPI pin names get applied consistently across the Express family.

[pastel panther]

Pin names in board files are meant to be labels specific to the features of that board, not general purpose labels for what they can be used for. If someone were to look at the pins for a board and see something like ESP_CS on a board that didn't have an ESP32 attached, it would be confusing.

The feather M4 does not have ESP... pins defined; you might have heard someone suggest which pins to use, or share example code but I just checked ports/atmel-samd/boards/feather_m4_express/pins.c and they're not there

It's expected that sample code will need to be modified to fit the specific requirements of the board or use case that it's being used for.

[lone sandal]

pingf

[adafruit/awesome-circuitpython] New star added

[manic glacier]

nickzoic

[adafruit/circuitpython] New comment on issue #1042: nrf: implement nvm\.ByteArray

OK I completely forgot about this but I think it is okay ... now i've just got to rebase it!

jonatasbaldin

[adafruit/circuitpython] New star added

[manic glacier]

nickzoic

[adafruit/circuitpython] Pull request opened: #1610 Circuitpython nickzoic 1042 nrf nvm bytearray

An implementation for #1042 for non-volatile memory.

Some example code:

import microcontroller

def dump(n = microcontroller.nvm):
    for i in range(0,len(n)):
        print ("%02X " % n[i], end="")
        if i % 16 == 15: print('')

microcontroller.nvm[0:4096] = bytes([1,2,3,4,5,6,7,8]) * 512
microcontroller.nvm[107:120] = b"hello, world!"
dump()

nickzoic

[adafruit/circuitpython] New comment on pull request #1610: Circuitpython nickzoic 1042 nrf nvm bytearray

PS: I had build errors in lib/tinyusb/src/class/msc/msc_device.c when building master with compiler version gcc-arm-none-eabi-8-2018-q4-major & ended up having to build with -Wno-error=stringop-truncation

[manic glacier]

nickzoic

[adafruit/circuitpython] New comment on pull request #1534: Circuitpython nickzoic 1046 nrf rtc

OK so I've rebased it and sadly, no change. I've just changed one of the messages for now and provided translations as best I can approximate for the new message.

[solar whale]

@stuck elbow FYI -- I just updated a pewpew v10.2 to the current CP Master build -- seems to be working fine!

[stuck elbow]

@solar whale awesome, thanks for testing!

@solar whale it has more features now, as more modules fit in there

I need to try some example code that turns it into a gamepad

[solar whale]

I have not done much with it yet, but hope to explore. Let me know if you want something tested.

It's nice to have it as part of the CP repository now - thanks for getting it merged

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #1610: Circuitpython nickzoic 1042 nrf nvm bytearray

PS: I had build errors in lib/tinyusb/src/class/msc/msc_device.c when building master with compiler version gcc-arm-none-eabi-8-2018-q4-major & ended up having to build with -Wno-error=stringop-truncation

I told @hathach about this when testing out gcc8, so he's aware: https://github.com/hathach/tinyusb/issues/33

[solar whale]

@tulip sleet have you ever actually read images from an SD Card with displayio and the 2.4 inch TFT -- I am finding that somthing clobbers the SD card in the slideshow if I try to use it.. Just curious if you've ever tried it?

I can read the "directory" of images, but then get an I/O error when trying to display.

[tulip sleet]

Limor reported that, and the the PR I submitted was trying to address that indirectly. Are you using the version from my PR (which hasn't been merged yet)?

i'm waiting for her to test it this weekend.

[solar whale]

ah - no -- I missed that -- I'll try it

[tulip sleet]

there are a bunch of parallel PR's, so that includes certain fixes, and others include other fixes. They are all branched from the latest master instead of being stacked.

[solar whale]

is it 1604 for this issue

[tulip sleet]

My fix is not SD-specific: it fixes a bug in the redisplay logic that causes CPy to hang in the background-task loop, never to return to actually executing code. The symptom is that the slideshow hangs. I don't see I/O errors. That may be a different problem or it may be partially due to the problem I'm fixing.
