circuitpython-dev

[charred blaze]

mhmmm

[tidal kiln]

and you can double reset into bootloader on that one?

[charred blaze]

mhmmm

[tidal kiln]

yeah, sorry then, i'd guess something's up with the wiring on the green perf board

the bootloader is protected, it's pretty hard to accidentally mess it up with just code

[stuck elbow]

or something was shorted for a moment and one of the shottky leds burned

@tidal kiln I think it wasn't protected in some early ones

shottky diodes

[charred blaze]

huh.... i think one of the traces on the bottom is messed up

[stuck elbow]

not leds

photo?

[tidal kiln]

@stuck elbow early m0's?

[stuck elbow]

early uf2 bootloaders

now the update_bootloader.uf2 sets the protect bit back, but it didn't

[tidal kiln]

oops

[charred blaze]

bottom right pin. its the usb pin

[stuck elbow]

ok, that's probably it, you must had a short of some kind, and something burned and now it's shorting the whole thing

RIP

[charred blaze]

dang

[stuck elbow]

I wonder why the green led shines

[charred blaze]

#sparky right there lol

well now when i plug it in nothing happens

[tidal kiln]

i'm not following. what's the last photo?

[stuck elbow]

a desoldered trinket m0 with a burned trace

[tidal kiln]

oh wow, you desoldered it fast

so that's the one that was on the green proto?

[charred blaze]

if i connect the usb pin to either the 3v or bat pin the green light comes on. if i connect the usb to 3v pin though the dotstar comes on as well as a solid white but it is not recognised by the computer. plus plugging into either 3v or bat pins makes it get really hot really fast

@tidal kiln yes, that was the one on the perf board

[tidal kiln]

"if i connect the usb pin to either the 3v or bat pin the green light comes on"
what do you mean by usb pin ?

[charred blaze]

One of the pins on the trinket is a usb pin, its the voltage directly coming from the usb

huh. so i used the voltmeter to check the voltage
usb pin (usb voltage) to gnd- 4.9 volts
bat pin to gnd - 0 volts (because its not being powered an alternate power source)
3v pin to gnd - 0 volts

[tidal kiln]

diode on usb 😦 @stuck elbow called it

[charred blaze]

dang.

well the traces on the bottom are still messed up too.

[tidal kiln]

or the trace

[charred blaze]

I checked the backup trinket m0 and there is voltage on the bat pin/gnd.

[stuck elbow]

let me look at the schematic

[charred blaze]

The trace on the bat pin also looks messed up too

[tidal kiln]

lets all look!

[stuck elbow]

no way that green led could be shining with any part of the power broken

[charred blaze]

huh

[tidal kiln]

why not?

[stuck elbow]

because it's on the 3.3V side of the LDO

so pretty much same place as the MCU

if it got power, mcu got power too

[tidal kiln]

"if i connect the usb pin to either the 3v or bat pin the green light comes on"

@charred blaze connect usb to bat and measure voltage on 3v

[stuck elbow]

oh, right, so either D2 or the trace to it

[tidal kiln]

yep

applying usb to 3v basically direct injected 5v to the other side of the LDO

lit the LED and probably blue smoked the mcu

[charred blaze]

its coming up as 3v

well 3.3

[tidal kiln]

so the voltage reg works

[charred blaze]

yup

[stuck elbow]

I have a whole strip of those MBR120 shottky diodes

[charred blaze]

nice

[stuck elbow]

but it might just be the trace

could be simply bodged to fix it

[charred blaze]

i think its the trace. theres actually 2 of them that are messed up

[tidal kiln]

samd21 vdd absolute max = 3.8v

it probably didn't like seeing 5v

[charred blaze]

the pinouts page says i can apply 3-6v to the bat pin: https://learn.adafruit.com/adafruit-trinket-m0-circuitpython-arduino/pinouts

[tidal kiln]

it's when you applied usb to 3v

[stuck elbow]

yeah, that's before the regulator

[charred blaze]

ah

[tidal kiln]

see schematic. usb and bat are before votlage reg. 3v is after.

and 3v goes straight to the mcu

[charred blaze]

ahhhhhhh i think i get it now.

still a little new to some of this stuff

[stuck elbow]

don't worry, we all started at some point

hopefully you won't burn more expensive things 😃

[tidal kiln]

no worries. good #sparky story. 😃

[charred blaze]

i mean, ive been playing with some of these things for a year now. but I slowly learn some of it as I go.

[stuck elbow]

I love how the schematics are available for almost everything, it helps you debugging a lot

[charred blaze]

Hahaha i burned up a Flora a year ago. couldnt figure out what the heck happened other than i went to plug it in and a part of it got red hot (literally) and puffed blue smoke at me

[stuck elbow]

and also, I can prototype with modules, and when it's ready, move it all on my own pcb by copying those schematics

by the way, spent whole day adding text layer support to this:

[charred blaze]

So basically make sure the 3v pin isnt connected to the usb pin or the bat pin

[stuck elbow]

make sure the usb/bat pin is not connected to any other pin

[charred blaze]

ok. can those 2 be connected at all?

[stuck elbow]

because all other pins are 3.3V and, usb is 5V and bat can be anyting

you can connect it to things that have a separate pin for power, such as hobby servos or motor drivers

or neopixels, I think

[charred blaze]

ok

I made sure to double check all of my connections on my perfboard on last time before soldering the new trinket in place

[stuck elbow]

if you have a mac, make sure to not place the board on the metal case

I've seen people do that

[charred blaze]

Nope, im a windows guy :3

[stuck elbow]

I think some surfaces are metal too

[meager fog]

~leeks~ time

[charred blaze]

ALL THE IO!!!!!!!!!!

[meager fog]

yep all io are used!

[charred blaze]

Sweet!

[meager fog]

kinda a replacement for pro trinket

[charred blaze]

ooooohhhhhhhh

[meager fog]

step up from trinket, but not as chunky as a feather

[idle owl]

Good place to be.

[glacial bronze]

I love it

[charred blaze]

Awesome!!

not exactly circuit python related i guess i cant use FastLED on my trinket m0 programmed with arduino (for now). something about the FastLED code isnt like by the compiler

[meager fog]

hmm it should! we tried fastLED

make sure you have the latest version!

[charred blaze]

huh. yeah i just recently updated.

its giving me something about an "invalid pin specified"

[charred blaze]

Ohhhhhhh I got it now @meager fog . I had the version of fastLED from their git. I didnt have the version of it you guys modified

[meager fog]

oops was in another window

yah we did submit a PR

so it should have been merged to theirs :/

[idle owl]

I found a quirk with CPX. I have one I purchased in at the end of June, and a friend has one she got in the end of September. I'm teaching her with MakeCode and they don't communicate consistently via IR. We thought it was the code, but I have a second one I got in the middle of September, and they communicates perfectly. I don't know if there's anything to be done about it, but it seems like something worth noting somewhere in the event that anyone is using two boards purchased that far apart.

[charred blaze]

@meager fog ahhhh. well it hasnt yet. but hey! i got it working for now!! now i gotta get a second trinket m0 so i can work on circuit python for it. Since I had a sparky moment with it.

[meager fog]

yay nice

@idle owl the only difference is the xmitter LED may have changed. the receiver

is the same for sure

the makecode IR stuff isnt super tested :/

[idle owl]

I noticed the hardware looked a little different

[meager fog]

IR is not great for communication. that's why remotes 'spam' the transmission

[idle owl]

Right

[meager fog]

we do test IR rx/tx in manufacture. so it works, just maybe not as noise-free

[idle owl]

hmm. Yeah it worked once or twice, which is what made me think it was a code issue. It was a last minute idea to try the newer board.

[meager fog]

(we only use it for like, IR remotes n stuff, which are very simple)

[idle owl]

So sending color suggestions is getting more complicated

I wanted to include simple IR communication in the CPX API eventually. Might not be so simple. 😄

[meager fog]

yah

i do too! 😃 its just a very gruesome protocol. BTLE is nice because it manages retransmissions for ya

also people have a lot of lighting that gets in the way

flickery dimmed LEDs and flourescents

[idle owl]

I try to think in terms of using it for teaching, and what would be super awesome to learn as a beginner. And if you're paired with someone, being able to send a simple string to your partner's board seemed like it fit the bill of awesome.

Yeah! I had to tell Carter what stray light looked like in the remoteIR code you had us test. He thought at first it wasn't working right.

[meager fog]

hmm i think your best bet is to try and transmit like a maybe 4 bytes max per messgea?

and put in CRC

and just spam the tx

[stuck elbow]

@meager fog you know about https://1bitsquared.com/collections/embedded-hardware/products/1bitsy ?

[charred blaze]

And you could maybe put a line in the code that once they have a first contact then it kinda sinks them up. if you are automating it that is

that way you arent always open to new signals, only when you need to be

[idle owl]

@meager fog The other idea was to bake it in to only send a specific message, like MakeCode sending a signal to change the NeoPixels. I don't know how many bytes it actually is to control the NeoPixels though. I know they're 3-4 per LED, but I imagine it's more complicated than that in actually sending the code to change them.

I don't know much about coding for IR though. So I'll be learning that as I go with this one.

[charred blaze]

Thats how my past year has been since picking up arduinos/hobby electronics in general

[tidal kiln]

@idle owl instead of trying to have full control of neopixels over ir, could make it where the 4 bytes (or similar small packet) just indicates a desired mode

[idle owl]

@charred blaze Nice! My first Adafruit order was at the end of June. I knew about them before that but hadn't ever ordered for myself. Mostly ordered Raspberry Pi related stuff, and the Circuit Playground Express.

[charred blaze]

I agree with @tidal kiln do kinda like code words sorta thing.

[idle owl]

@tidal kiln So you write code for both of them, waiting to hear mode info, and waiting to execute mode.

I like it

[charred blaze]

so like, Sender could send something simple like "blue" and they would all change to blue. or you could even do it in RGB where 120255030 would translate to setting the color to R-120 G-255 B-030 on the Receiver

[meager fog]

@stuck elbow yep! we'll carry the 1bitsy swd as soon as they are available

[stuck elbow]

I just thought the name and the shape are very similar, are you not afraid of them being confused?

[tidal kiln]

@idle owl main idea is to just reduce the amount of info you need to tx (full control might required too much)

[idle owl]

@tidal kiln Right. And agreed.

[meager fog]

nope - all hardware is similarly shaped 😃

[stuck elbow]

trinket and cpx are kinda special 😃

[charred blaze]

Dang, if i hadnt messed up my other trinket m0 i could've used it to make some leds for my Mavic Pro and controlled them with circuit python

[meager fog]

@charred blaze what happened to it?

[tidal kiln]

(scroll up)

[charred blaze]

lol Cater.

[stuck elbow]

3.3V connected to 5V basically

[charred blaze]

yeah what they said

personal mistake there

[tidal kiln]

@charred blaze thought you said you had a backup?

[charred blaze]

I do! but one was going to be for personal learning and the other for a simple project for a buddy.

[meager fog]

lol woops - did it go poof?

[charred blaze]

no it didnt! it just stopped working. And Cater and Deshipu deduced that was what happened. Though when i desoldered it and went to pop it off 2 of the traces got pulled off because apparently the solder pads on the bottom werent fully desoldered.

[meager fog]

ahh it happens!

[charred blaze]

oh well! wonder if fastLED would be ok on a regular trinket. Im not doing anything too fancy.

[meager fog]

it should!

we use it lots

[charred blaze]

maybe not. i need 4 pins total so one of those would have to share with pin 3/4 as either output to the leds or as input for a button

[idle owl]

I replicated the code that ships with the Circuit Playground Express in Circuit Python.

[charred blaze]

nice!

[idle owl]

People keep asking for the demo it ships with. It ships with MakeCode. But it seems like posting this somewhere might be a good idea. Need to find out where though.

[tidal kiln]

@idle owl the cpx guide, cp section

[idle owl]

@tidal kiln lol I was just typing something close to that.

Your idea is better. I was about to say write up a quick guide on it.

[umbral dagger]

I finished the post on my Trinket/CircuitPython humidity monitor: https://daveastels.com/2017/11/04/humidity-monitor/

[idle owl]

@umbral dagger Nice!

[umbral dagger]

@idle owl Thanks. For the next batch I’ll try it without trimming the edges... maybe I can just have solder wick through the holes. It’d be a lot faster to do the build and I’m contemplating trying to sell them ... next summer (here in Canada).

[idle owl]

That would be handy.

Nice use of the power breakout too.

[umbral dagger]

Maybe using a toggle clamp to hold the Trinket/breakout firmly in place while soldering.

Yes, it perfect for this. Makes the code simple AND makes, the whole thing very low power.

[idle owl]

Yeah something would be needed. Trying to get it to wick through without it moving would be a challenge.

[umbral dagger]

Yeah, a clamp would give me two hands to work with. I could go with a fully custom board, but There would still be through-hole components.

It was a fun project to go from need to final solution.

As mentioned, I need a 3D printer now to really complete it.

[idle owl]

Yeah!

We have a humidity sensor setup in the basement, with four zones. We're tracking the data remotely though, so they're running off of Pi0W's.

I think it is the same humidity sensor you used.

[meager grove]

Neat project idea. I should make something like that to scream and shout if my mandolin case is too dry.

[umbral dagger]

@meager grove The whole thing could be packaged in a well ventallated shell.

@meager grove You'd also need to be able to hear it, so something based on e.g. esp8266 that can post to IFTTT or such might be a better approach.

The one thing It's missing is a low battery indication. I have to give that some thought (or just recharge them regularly.

[cunning crypt]

@umbral dagger Diode of voltage reducig to 3.3 tops. Run that to analog in. You'll be able to detect when the battery is just about deadn but it's only one component

Or the ever-useful voltage divider to read full battery status

[umbral dagger]

@cunning crypt I just need a "recharge now!" alarm.

[manic glacier]

ladyada

[adafruit/circuitpython] Issue opened: #407 reading value from output pin not always reflective

was testing a feather m0 basic on adafruit-circuitpython-feather_m0_basic-20171104-5ff6417 and bumped into this odd issue while testing pin toggling.

on some pins, reading the value does not return the right value?

e.g this code does not toggle:

led = digitalio.DigitalInOut(board.MOSI)
led.direction = digitalio.Direction.OUTPUT
while True:
    led.value = not led.value
    time.sleep(0.1)

but this works:

led = digitalio.DigitalInOut(board.MOSI)
led.direction...

[errant grail]

Beginning to test the next generation of the autonomous string car racer using the Trinket M0 and CircuitPython. Initial tests are working perfectly! The plan is to make it pin compatible with the existing controller board. Using CP simplified the code significantly -- and no more IDE! The previous gen car (Trinket 5v-based) is shown on the right.

[idle owl]

@errant grail That's great!

[meager fog]

@umbral dagger wow thats great!

you too @errant grail

(i am taking a little break from routing boards 😄

[idle owl]

@errant grail What does the autonomous part do for a string racer?

Breaks are good!

[errant grail]

... Thanks @idle owl. I have 6 of these "in the field." Upgrading to CP simplifies support tremendously!

[idle owl]

@errant grail For sure!

[meager fog]

yay thats the point of circuitpyhon so im glad 😄

funny story circuitpython is borne from about 10 yrs ago

i used to go to burningman and do projects there and haul my pickit around

[errant grail]

I'm a happy camper. Was itching to do this ever since watching you working on the prototype, @meager fog .

[meager fog]

and thought "omg i cannot deal with how hard it is to tweak firmware in the field. this sux. i hope i come up with something better in 10 years" 😃

[umbral dagger]

@meager fog The original physical prototype (hand wired on prototyping board) and one PCB based unit are “deployed” and running nicely.

[idle owl]

@meager fog Nailed it.

[errant grail]

Yeah, this will help with the makerspace classes, too.

[meager fog]

yah! easy to share code, save backups

ok back to pcb routing

[errant grail]

@idle owl : here's a discussion of the autonomous version in the learning guide I wrote.

https://learn.adafruit.com/basic-string-car-racer/string-car-history?view=all#string-car-history

[idle owl]

Oh! I've seen this guide before! I recognise the photo. Thanks for the link!

[meager fog]

@umbral dagger s'ok for us to blog your project?

[umbral dagger]

@meager fog Looking at it one way a SAMD21 is way overkill for this. Previously I would have used an Arduino ProMini. But for not significantly more $ I can work in Python instead of C, and dropping files onto the usb drive instead of AVRdude. I really need to write a post about the qualitative difference working in CP provides.

@meager fog Of course. Feel free. Any feedback on improving it would always be gratefully received.

[meager fog]

yah its definitely a "distruptive" tech - its not more powerful, its much less complex which is not usually what engineers go for. we like to compare it to how people-who-normally-would-have-run-a-nfs-server experience dropbox

its like "oh dropbox just...works. its not as complex but...thats ok!"

[idle owl]

@errant grail That's so cool! Makes a lot of sense.

[meager fog]

you saw i designed a trinket m0 express for u right? 😄

[umbral dagger]

@meager fog haha

[drowsy geyser]

Oh, hey, hi @meager fog ! I was off configuring my OctoCam kit and didn't see you come in. 😃

[errant grail]

@meager fog Yes! The express version will be great for the more advanced models.

[meager fog]

hihi! im taking a short break from routing a few complex older designs

[umbral dagger]

@meager fog I think I mentioned that I was uninterested in Python until I discovered CP.The language is good, but it’s the CP/MP experience that’s the real win.

[meager fog]

yah yah - i think m4 will be a huge upgrade. the m0 is underpowered, but its all we had

i think at the m4 python level its usable for 'real projects'

[drowsy geyser]

Yes, but the M0 was a huge leap forward over the 32u4...

[meager fog]

true, but as a py board it feels like a step back, like an attiny. m4 will make it 'feel' more like a > m328 board

[drowsy geyser]

Good point

[umbral dagger]

I like the move M0->M4, leapfrogging the M3 core. Hardware floating point will be a significant upgrade.

[meager fog]

M3 is older than M0, ironically 😄

[errant grail]

The M4 will be perfect for upgrading a couple of data analysis and music synth projects.

[meager fog]

M3 came first but is now quite old, which is why you dont see new M3 chips

[umbral dagger]

Yup. We did some cool things with M3 based chips at SteelSeries.

STM and Freescale mainly.

It was at a fairly good price/performance point... especially as it starting getting older.

[drowsy geyser]

I think the M4 will be an excellent platform. With the M0 I couldn't get my robotics to work since there wasn't enough memory left over after loading the packages I needed....

[meager fog]

you can try mp3 decoding right now on the M4 in arduino https://github.com/adafruit/Adafruit_MP3

ironically, its fixed point. but does use the DSP commands in the M4

[errant grail]

nice -- that opens up some multitrack possibilities for feeding the synth from my DAW.

[meager fog]

yah at some point we will look at porting the PJRC audio lib to the samd51

it will be 'fun' and 'enjoyable'

[drowsy geyser]

<sarcasem></sarcasm>? 😃

[idle owl]

Of course not. 😉

[meager fog]

(it will not be fun and enjoyable)

(it is a lot of very low level stuff to make it fast)

[drowsy geyser]

I can think of a few of the CircuitPython core team who would probably like the very low level programming.

[errant grail]

okay, thanks @meager fog ! I'm going afk for a bit to redesign a couple of projects. 😃

[meager fog]

yep later me too

ciao!

[drowsy geyser]

See ya!

[umbral dagger]

Ya... that audio lib does actually sound fun & enjoyable 😃

[cunning crypt]

Truly a sound idea

[candid sun]

I've been playing around with the IR stuff for Circuit Python and got it working to control an Apple TV tonight. Did a quick stream if anyone is interested. Big thanks to everyone working on Circuit Python, I really love working with it 😄 https://www.youtube.com/watch?v=mm82UZDHuSU

[umbral dagger]

Ok, humidity monitor distraction done for now. Time to get back to M4/CP3. First step is to catch up on the state of SPI/I2C support. I want to hook an AMG8833 and the 8x8 dotstar board to it and do some neural net stuff.

[idle owl]

@candid sun That's fantastic!

[candid sun]

@idle owl thank you!

[glacial bronze]

I should get one of those 8x8 dotstar boards and a trinket M0 and make a Conway's Game of Life miniature desk widget

I could have it do both random starts and stable and metastable starts

[stuck elbow]

@glacial bronze get a led matrix backpack

[umbral dagger]

The CP/MP simple debugger is making some progress... mostly in terms of my understanding of the VM. Code to follow.

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

I'll be happy to submit a PR to enable frambuf - Should I submit PRs both the 2.x and 3.0 branches?

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

@jerryneedell Since it's already turned on in the atmel-samd express builds, sounds fine, assuming it fits. Do you have a way to test it for esp8266?

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

yes - I will test it with an ssd1306 on an esp8266 before submitting the PR. Likely tonight or tomorrow.

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

I have built it under both master and 2.x branches - no problem with she or import framebuf. Just need to hook up the oled display to verify operation.

[umbral dagger]

@meager fog I have a meetup Wed night, but I'll think about ducking out early to make an appearance on Show & Tell.

[umbral dagger]

OK, this is getting real... Running MP in GDB. This place looks familiar 😃

[hollow tartan]

Hello Everyone! ampy is giving me grief. windows 7 running python 2.7 esp8266

  File "c:\python27\lib\site-packages\ampy\pyboard.py", line 143, in __init__
    raise PyboardError('failed to access ' + device)
ampy.pyboard.PyboardError: failed to access COM5

[stuck elbow]

access rights?

no idea how windows handles access to com ports

[hollow tartan]

RE: ampy it works if I disconnect the terminal (TeraTerm or Putty)

[stuck elbow]

Ah, that makes sense.

[hollow tartan]

So , to be completely direct. I want to determine the workflow (methods and steps) for debugging micropython. If anyone has or knows a resource for THAT. I would happily follow their lead.

[manic glacier]

jerryneedell

[adafruit/circuitpython] Pull request opened: #408 esp8266 enable framebuf

enable framebuf for ESP8266 in mpconfigport.h

[slender iron]

@hollow tartan what are you trying to debug? ampy uses the serial connection so you can't use both at once

[hollow tartan]

@slender iron So, I have discovered. I am getting myself ready to attack the problem you asked me to work on. "ignored arguments"

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

submitted PR for 2.x - Do you want one for master - I need to rebuild the .mpy files for master since the format is different. IS it useful to do that at this time. I was surprised that 3.0 even builds for esp8266, but it looks OK - I assume it is really the 2.x code. Let me know if you want me to test the .mpy builds and if you want a PR to master.

[slender iron]

awesome! sounds like you are close!

[bronze geyser]

i want to read from a sensor every 15 secs forever. So circuitpython/Huzzah I have a while True: ....the challenge is when i run w/ ampy - just hangs there. If I remove the while True: code, rest works fine...any ideas why while True: hangs ...does there have to be a break? hmm.

[slender iron]

@bronze geyser ampy tries to ctrl-c the main.py but its possible there aren't enough ctrc-c for it to get to the repl

[hollow tartan]

ampy run -n is an option ?

[bronze geyser]

thanks i think @slender iron...i apologize i don't understand what ampy is doing ...you're saying it's running the while loop before repl? Wow...i am clueless.

[slender iron]

ampy uses the serial connection and if your main is already running it tries to stop it just like you would

[bronze geyser]

@slender iron - again, apologize for my ignorance. I do an ampy ls ... there is boot.py and my lib directory on the Huzzah. Where then is main.py?

[slender iron]

I thought that was your while loop. are you using ampy run instead?

[bronze geyser]

yah. ampy run.

[slender iron]

(I don't use ampy much)

ah ok

[bronze geyser]

what do you do on a Huzzah? (stay away from using it 😃 )

[slender iron]

yeah, I don't use it much

ampy hangs because it waits for the program to finish

I think @hollow tartan was right

[bronze geyser]

oh...that's unfortunate....

[slender iron]

-n will tell ampy not to wait for it to finish

[bronze geyser]

i use -n ... it exits, but then the stuff i'm printing doesn't print. Real quick...so i assume nothing is running?

[slender iron]

I'd assume it is runing

try blinking an led instead

[bronze geyser]

ampy says run "Run a script and print its output" ...oh, yah...right when in doubt blink (so not Dr. Whoish)

[slender iron]

its tricky with a while loop

I'd suggest removing the loop for testing and using ampy run

long term ampy put the file so it runs even when not connected

[bronze geyser]

@slender iron ... oh yah...contextually that makes sense. Test lines of code = ampy .... endlessly read the sensor data = load on boot and either blink LED or send messages to know what state firmware is in. Thank you.

[slender iron]

yup yup

no problem!

[hollow tartan]

@slender iron Am I to assume that ampy is the only tool available to use in testing micropython. I did see a statement the there are others. Is it the only tool you think I will need?

[slender iron]

@hollow tartan for the esp8266 yes

[bronze geyser]

@slender iron while you're at it...how about radiopython to complement circuitpython? Then us folks connecting to whatever won't feel marginalized 😃

[slender iron]

we

er, we'll do radios at some point. just gotta pick our priorities

@hollow tartan for the issue I pointed you to, do a simple test script that triggers the bug that you can run with ampy

then, when you change the circuitpython code you can confirm its behavior is fixed

[hollow tartan]

@slender iron Hey, that should be helpful. How do you want to share it with me?

[slender iron]

share what with you?

[hollow tartan]

whoa,, micro or circuit python? the test script I am not sure what to write in the script.

Oh sorry misread

[slender iron]

I figured you could write the test script 😃 I think the issue has enough detail in it for it

[hollow tartan]

Ok I will try.

[slender iron]

👍

[hollow tartan]

but my focus will be running it from ampy or from repl? I have loaded a test.py to the file space on micropython. I am also , by the way, reading a short book about Vagrant.

[slender iron]

whichever way works best for you is fine

[hollow tartan]

the problem is in micropython , circuit python, or both?

[slender iron]

circuitpython only

[hollow tartan]

got it,, thanks.

[manic glacier]

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

I am ready to release all the library changes. Should I wait or start 12 pull requests? Since these changes are incompatible with 2.x of circuitpython . I assume we have a way to build/maintain library bundle 2.x and library bundle 3.0 separately.

tannewt

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

Can we try: except it for now? That way it could be used on any version.

[hollow tartan]

FYI just in case you need to know: http://stackoverflow.com/questions/14016761/python-turn-list-values-into-string

works in micropython 😃

why? because >>> os.listdir() # returns a list! Can I assume that ```b = country[0].encode("ascii")

[manic glacier]

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

here is a possible way to detect a missing method:

def _read_register(self, register, length):
    self._buffer[0] = register & 0xFF
    with self._i2c as i2c:
        i2c.write(self._buffer, start=0, end=1)
        try:
            i2c.readinto(self._buffer, start=0, end=length)
        except AttributeError:
            i2c.read_into(self._buffer, start=0, end=length)
        return self._buffer

[tulip sleet]

@hollow tartan encode doesn't exist for all builds, but you can use str(b'abc', 'ascii') for now. See https://github.com/adafruit/circuitpython/issues/384. There is also an issue filed about os.listdir() returning bytes instead of strings sometimes: https://github.com/adafruit/circuitpython/issues/249

[manic glacier]

siddacious

[adafruit/circuitpython] New comment on issue #383: double file extensions

So I'm so close to being done with this except for the part where it's totally broken. When I take one of the generated double extension file names and run it (blinky in this case) with pyexec_file(double_extension_filename, exec_result); I see my led blink but I loose the CDC serial in /dev/tty* and CIRCUITPY doesn't show up. I assume it's running the blinky that I had previously uploaded and tested with master (5ff6) successfully since I don't have MSC to upload a new file with.

I'm ...

jerryneedell

[adafruit/circuitpython] Pull request opened: #409 enable framebuf for ESP8266

enable inclusion of framebuf in mpconfigport.h for esp8266

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

submitted PR for master as well - I was able to generate the necessary .mpy's to test this in the master branch build using an ssd1306 OLED display.

[hollow tartan]

@tulip sleet Thanks for that. I just tested on my Circuit Python and got a good result. Adafruit CircuitPython 2.0.0 on 2017-09-12; ESP module with ESP8266

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #407: reading value from output pin not always reflective

I've been staring at https://github.com/adafruit/circuitpython/blob/2.x/atmel-samd/common-hal/digitalio/DigitalInOut.c and I am wondering if switch_to_output() is not called then how is self->open_drain initialized? If it is not initialized, then will it behave differently for some pins?

If you just set the direction as in the example, I don't think switch_to_output() is ever called.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #407: reading value from output pin not always reflective

common_hal_digitalio_digitalinout_switch_to_output() is called here: https://github.com/adafruit/circuitpython/blob/2.x/shared-bindings/digitalio/DigitalInOut.c#L202, in the layer above. When you set the .direction property it calls either common_hal_digitalio_digitalinout_switch_to_input() or common_hal_digitalio_digitalinout_switch_to_output().

[tulip sleet]

@slender iron just a progress report: The I2C freq calculations in ASF4 are wrong, and there appears to be a SAMD51 hardware bug: you must set both the SERCOM's BAUD and BAUDLOW to get the right-shape waveform. On the D21 if BAUDLOW is zero BAUD is used to set the length of both for the low and high parts of the SCL clock pulse. The D51 is documented to do that, but it actually doesn't. The baudrate calculations in the hpl_sercom_config.h know this, but the ASF4 I2C library does not. Also, it seems to calculate the wrong value as well (bad algebra or something).

good night

[umbral dagger]

@tulip sleet Nice mike drop.

[slender iron]

good work @tulip sleet! The errata sheet is always handy though its still missing things: http://ww1.microchip.com/downloads/en/DeviceDoc/80000748B.pdf

<@&356864093652516868> Normal time for the CircuitPython weekly tomorrow (Monday) everyone in #circuitpython-dev and the CircuitPython voice channel. Thats 2pm ET and 11am PT. For those outside the US double check the time because we just switched daylight savings this weekend.

[hollow tartan]

Hi, everyone. I just compiled .bin code for esp8266 that includes SSD1306 OLED support! https://www.youtube.com/watch?v=OOIO3oiC3lM&t=62

Gotta wait weeks to get my OLED parts though.

It was so fast and easy since vagrant is installed and working. Wowzers!

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #383: double file extensions

Is your branch based on 5ff6 as well? I'd be happy to take a look tomorrow.

[manic glacier]

siddacious

[adafruit/circuitpython] New comment on issue #383: double file extensions

I found the bug; I had not noticed that the two calls to maybe_run had different arguments and treated them as the same. I simplified how it works and addressed that oversight in doing so. Now I'm just trying to remember how to pointer.

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

I would rather put something like:

self.i2c_read_into = getattr(i2c, "readinto", getattr(i2c, "read_into"))

somewhere at the beginning (in the __init__), so that we don't have to check every time.

[plucky flint]

Morning... now PyCon UK is over I'll try to be more active on here... except that I won't be able to make this evening's chat because I'm giving a talk about MicroPython here in London. 😃 cc/ @slender iron

[solar whale]

@tulip sleet think of it as "alternative" algebra 😉 Nice work!

[manic glacier]

microbuilder

[adafruit/circuitpython] Fork created: microbuilder/circuitpython

[manic glacier]

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

I like that idea @deshipu . Thanks.

class LIS3DH_I2C(LIS3DH):

def __init__(self, i2c, address=0x18):
    import adafruit_bus_device.i2c_device as i2c_device
    self._i2c = i2c_device.I2CDevice(i2c, address)
    # handle name change of method readinto; backward compatible
    self._i2c_readinto = getattr(self._i2c, "readinto", getattr(self._i2c, "read_into", None))
    self._buffer = bytearray(6)
    super().__init__()

def _read_register(sel...

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

I would drop that None from there — it should never get to that part, but when it does, and AttributeError is the right exception to throw.

[manic glacier]

bygreencn

[adafruit/circuitpython] New star added

[stuck elbow]

@plucky flint good to aee you here!

[plucky flint]

@stuck elbow 👋

[stuck elbow]

I mean "see". Tablet on-screen keyboard, sorry.

[tulip sleet]

@slender iron my diagnosis last night about the I2C BAUD and BAUDLOW issues may be wrong. It seems to have to do with the clock values being wrong. I'll contact you.

[manic glacier]

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

@deshipu Python 3.5 evaluates both getattr() functions, so when we finally remove the redundant read_into method, the None ensures that the getattr(i2c,"read_into") does not throw an Attribute exception. Maybe we need to add

self.i2c_readinto = getattr(i2c,"readinto",getattr(ic2,"read_into",None))

if both readinto and read_into are not present, then throw exception

if self.i2c_readinto == None: raise AttributeError

your thoughts?

deshipu

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

Argh, you are right, I'm sorry, I didn't thought it through. In that case maybe:

try:
    self.i2c_readinto = i2c.read_into
except AttributeError:
    self.i2c_readinto = i2c.readinto

would be clearer.

[stuck elbow]

when is the meeting?

in 1 hour?

oh, 2 hours

[tidal kiln]

yep. in ~2. currently 9:17am local.

[tidal kiln]

@slender iron has there been any recent activity on this?
https://github.com/adafruit/circuitpython/issues/296
asking because:
https://forums.adafruit.com/viewtopic.php?f=19&t=114536#p629139

[slender iron]

@tulip sleet ready when you are

[tidal kiln]

@idle owl does your cpx lib have a way to change lis3dh range?

[idle owl]

@tidal kiln No. We chose one to use. I think it would be trivial to add if you think there's a need for it.

[tidal kiln]

was/is there a desire to keep the cpx lib as simple as possible? any reasons for not adding it?

[hollow tartan]

OMG I just had the most strange thought. What if adafruit started promising to give away 1 m4 metro to educational projects around the world just like rPi folks are supposed to have been doing.

[slender iron]

@tidal kiln I doubt it. I think EinsteinUnicorn is back in school

feel free to ping the issue and offer to take it up

@hollow tartan we're kinda doing that already with the trinket, gemma and circuitplayground givewaways with orders

[tidal kiln]

@slender iron k. thanks.

[hollow tartan]

I am aware of the adafruit big order free products incentives. I like that.

@slender iron HA Ha. Here is another idea: AdaFruit could offer an trade-in program: Send in a rPi and get a Metro for half price. LOL.

[floral dagger]

Hey folks. Looks you all are having loads of "fun" with the new hardware. 😃
Wish I could be more active here, but life, man...you know.
Still working on adafruit.io and MQTT. I also just got a INA219 DC current sensing module that I want to get working with my ESP board as well. I found a few things for micropython. Is there anything for that in CP yet?

[hollow tartan]

Maybe, I should get a Sparky Pin. The 3 OLEDs I ordered for my esp8266 have I2C interfaces for which bit banging will be needed on GPIO pins. I could have and should have ordered SPI interface OLEDs.

LOL

😃

[tidal kiln]

@floral dagger not seeing an entry for it (INA219):
https://github.com/adafruit/circuitpython/issues/269

[floral dagger]

awesome, thanks @tidal kiln Figured I'd double check before doing too much with it.

[idle owl]

@tidal kiln There is a desire to keep it simple. However, if it will work like I think it will, we can have it set to a default that doesn't have to be set unless you want to change it. I don't think it'll alter the simplicity much.

[hollow tartan]

@idle owl What is the strategy in the Educational arena for keeping the students from earning their Sparky badges with the Adafruit boards?

[tidal kiln]

@idle owl do you think the desire to keep it simple is strong enough that you want to minimize the amount of functions you add?

[stuck elbow]

@hollow tartan the bit-banged i2c on the esp8266 is as fast as standard i2c

I mean, 100kHz is not hard to reach on a 80MHz mcu 😃

[hollow tartan]

That's good. The refresh rate on the OLEDs is about 80 ms which is only 12.5 Hz. Did you know that they can have "8 bit high SCAN line artifacts" if updated too quickly using u8g2lib driver? LOL

[stuck elbow]

@floral dagger it should be rather easy to write a driver for that

@glacial schooner if you send 128x64 pixels, you still get about 50Hz in theory

[floral dagger]

thanks @stuck elbow I may give that a try then.

[stuck elbow]

@hollow tartan sorry, that was meant to you

[floral dagger]

never actually wrote a driver before 😃

[stuck elbow]

@floral dagger we can help

[idle owl]

@tidal kiln I think it depends what it looks like once it's added. If it's just a matter of an optional parameter in the current function, I think it would be fine. If it means adding more than that, then maybe not. Memory is also a significant concern, though I'm not sure it'll affect that.

[slender iron]

@floral dagger I think @bronze geyser was doing current sensing from a ESP8266. It was a different chip though I believe

[floral dagger]

oh, good to know @slender iron thanks

[idle owl]

@hollow tartan I think a huge part of avoiding Sparky is in the design and function of the Circuit Playground Express, as you can do quite a lot without soldering or having the option to cross wires that would smoke something.

[tidal kiln]

@floral dagger seen scott's guide? (on writing lib)

[floral dagger]

@stuck elbow I'd imagine it's a lot like most other things. I usually learn about 800 ways that it DOESN'T work, before accidentally stumbling backwards into one that does. 😃

[idle owl]

@hollow tartan Past that, I think we all earn Sparky badges while learning. It's part of the process in and out of an education-specific environment.

[floral dagger]

@tidal kiln The one on learn.adafruit.com?

[hollow tartan]

@idle owl thanks for you thoughts. I gotta go eat a little bite. see you all at 1 pm CT

[idle owl]

@hollow tartan You're welcome. See you in a bit!

[stuck elbow]

@floral dagger yes, that's pretty much how it works for all of us

[tidal kiln]

@floral dagger yes: https://learn.adafruit.com/creating-and-sharing-a-circuitpython-library/overview

[stuck elbow]

the trick is to be more patient than the computer is

[tidal kiln]

is round supported in cp? i'm getting this:

>>> round(3.14)
0

[stuck elbow]

>>> round(3.14)
3

what version do you have?

[tidal kiln]

2.1

[stuck elbow]

mine was 2.0

[tidal kiln]

Adafruit CircuitPython 2.1.0 on 2017-10-17; Adafruit CircuitPlayground Express with samd21g18
>>> round(2.1)
0

[stuck elbow]

maybe that math functions removal took the round() too

[idle owl]

@tidal kiln I get the same thing as you with the same version.

[stuck elbow]

you can always do int(3.14)

that does the floor

[tidal kiln]

@stuck elbow that truncs, want round

[stuck elbow]

int(3.14 + 0.5) maybe? 😄

[tulip sleet]

@tidal kiln that looks like a bug! Could you file an issue?

[tidal kiln]

@tulip sleet sure. in cp repo, right?

[tulip sleet]

yes, tnx

[tidal kiln]

will do

@idle owl thanks for sanity checking

[idle owl]

@tidal kiln Absolutely!

[manic glacier]

caternuson

[adafruit/circuitpython] Issue opened: #410 round function not working

Adafruit CircuitPython 2.1.0 on 2017-10-17; Adafruit CircuitPlayground Express with samd21g18
>>> round(3)
3
>>> round(3.0)
0
>>> round(3.8)
0

[tidal kiln]

related to a more general question - how to convert float to int in cp? i was trying to use:

int(round(3.14))

[stuck elbow]

that should work

[cunning crypt]

The CircuitPython weekly chat is in about 5 minutes, right?

[slender iron]

yup!

[cunning crypt]

I'm actually home for one of these things

[slender iron]

👍

[idle owl]

@cunning crypt Hah! You're one of us now!

[cunning crypt]

One of us!

[tidal kiln]

@stuck elbow works, but wondering if that's the accepted way?

[stuck elbow]

that's the obvious way, and python is usually all about the obvious ways

[manic glacier]

tannewt

[adafruit/circuitpython] Pull request closed: #408 esp8266 enable framebuf

tannewt

[circuitpython:2\.x] 1 new commit

3c1486a esp8266 enable framebuf (#408) - jerryneedell

[stuck elbow]

I'm in a browser and it works

Chromium, if that helps

[hollow tartan]

hello

now I can hear

[cunning crypt]

Negative, not at the moment

Also, fiddling with mic...

[floral dagger]

none for me

[cunning crypt]

Discord does not enjoy my mic having its own self mute...

[idle owl]

@cunning crypt I find it eventually gets over it. I mute my mic, not Discord.

[hollow tartan]

ditto ... Group Hug!

[pastel panther]

HRs to @slender iron and @solar whale for testing the metrowing, RC2 coming soon!. Also thanks to @umbral dagger for helping me with some C questions. Also thanks to @meager fog, @tulip sleet and @tannwet for encouraging me to work on my first CP commit.

💒 🏰 💒

hmm @meager fog "stole" my extremly obvious QSPI upgrade idea 😛

[floral dagger]

just got an INA219 breakout, and want to start working on my first Circuit Python library for it. I will probably have loads of silly questions for you all.

[cunning crypt]

Silly questions are the best questions.

[floral dagger]

awesome!

[stuck elbow]

@cunning crypt can you switch the mike off?

[cunning crypt]

@stuck elbow My mic's muted.

[idle owl]

It's not Andon's.

[hollow tartan]

FYI I found a really good Python book on O'Reilly Safari: Python Crash Course By: Eric Matthes Publisher: No Starch Press Pub. Date: November 20, 2015 Print ISBN-13: 978-1-59327-603-4 Pages in Print Edition: 560

[stuck elbow]

@cunning crypt it doesn't show you muted

[cunning crypt]

@stuck elbow Physical mute button.

[idle owl]

@stuck elbow It won't if you physically mute your mic, and don't click mute in Discord.

[cunning crypt]

There.

[stuck elbow]

thanks!

[idle owl]

My mic is also physically muted, Discord is not.

I'm typing on a cherry mx keyboard, and you're not hearing endless clicking 😄

[cunning crypt]

clicky clicky

[timber lion]

phew i think discord is loading for me now

but it's really slows for some reason

[stuck elbow]

@idle owl I was thinking the echo might be coming from the client, not necessarily thourgh the physical microphone

[timber lion]

can't hear audio either :/

[cunning crypt]

@timber lion It doesn't show you as in the audio channel... Oh, wait, there you are

[timber lion]

yeah it's kinda coming and going

[stuck elbow]

I can only hear Scott

not the other half of the conversation

[tidal kiln]

@stuck elbow hang up and reconnect

[stuck elbow]

@tidal kiln thanks, that helped

[tidal kiln]

@stuck elbow it's a "feature", i have to do same

[hollow tartan]

This book seems to offer explanations to get me prepped (as I am new to Python) to help out with Circuit Python. Would someone care to thumbs up this book or point out a superior one or other resource? Python Crash Course By: Eric Matthes Publisher: No Starch Press Pub. Date: November 20, 2015 Print ISBN-13: 978-1-59327-603-4 Pages in Print Edition: 560 😃

thanks

[pastel panther]

I should have a PR tonight to support double file extensions. I don’t have it working quite how I would like but I think it’s good enough to be useful. I’m slowly relearn everything I’ve forgotten in the last 10+ years since I’ve touched any C code which ends up being just about everything useful :)
If anyone has good C for programmers books let me know
As far as I can tell CDC and MSC are working fine in master. My most recent issues were self-imposed code issues that have since been fixed.

Lastly I just finished hand soldering headers to my JD-T1800 TFT so hopefully I can test with it soon. Pro tip: probably just buy the breakout? Also they’re delicate so don’t solder on it upside down and crack your screen 😦

[timber lion]

check out the hitchhiker's guide to python: http://docs.python-guide.org/en/latest/intro/learning/

great list of resources there

there are nice video courses free online you might check out

also has some book recs

zed shaw's C book is my current favorite

[stuck elbow]

I just got my copy of the "Programming with MicroPython" by @plucky flint

[timber lion]

https://learncodethehardway.org/c/

i can't get audio, it's super choppy

[slender iron]

any other updates besides what you hipchatted me?

[timber lion]

but yeah nothing new from hipchat, working on guide updates to have circuitpython code

[tidal kiln]

yes

[pastel panther]

tuesday is fine

[timber lion]

yeah tuesday is good

[cunning crypt]

Don't think Tuesday will be any different than Monday for me - Probably will be working

[pastel panther]

back to the salt mine for me. Enjoy the rest of your day! 👋

[idle owl]

@pastel panther Have a good one

[tulip sleet]

@stuck elbow issue for that: https://github.com/adafruit/circuitpython/issues/335

[stuck elbow]

@tulip sleet awesome, thank you!

[floral dagger]

have a good one everyone

[hollow tartan]

[cunning crypt]

@timber lion Are you using Comcast? Looks like there's a big bunch of issues with them: http://outage.report/xfinity

[timber lion]

drivers aren't working without busio first though

yep i totally am @cunning crypt ahhh that must be my problem

it's written in the .travis.yml file

read the comments there

[cunning crypt]

I've been having some intermittent issues today as well. Ran across a tweet with that link a few minutes ago.

[timber lion]

@tulip sleet @granite oak check the comments in the .travis.yml files

let me know if they don't show enough details

it explains you need to add the GITHUB_TOKEN

yeah it's a separate config to add GITHUB_TOKEN unfortunately

it's state travis stores separately by design

because it has to be secure, you can't store the token in the repo

anyone with that token has your full control to github

[tidal kiln]

🐱 - mew!

(looked behind me, thought a cat walked in)

[idle owl]

@tidal kiln I always check to make sure it's not mine we're hearing 😄

[timber lion]

nope unfortunately not, travis needs each repo to have an individual .travis.yml

[solar whale]

that was my cat - beating down my door...

[timber lion]

it could first step clone a yaml but it can't produce release artifacts without an explicit list

the list of release artifacts to attach has to be in the repo's .travis.yml unfortunately

the outputs

the "adafruit_vs1053.mpy" etc in it

its ability to attach to releases is limited to just whats' in the travis yml

i broke the script out as much as i could otherwise, it actually does download a shell script

for building the zips

yep

one for single files and one for multiples

the multiple builds a zip, excludes init.py from mpy generation (old bug)

etc

https://github.com/adafruit/MicroPython_TravisCI_Deploy

no unfortunately not it has to have an explicit list of release artifacts

it could maybe replace the 2-3 commands

but there isnt much to the files

yep :/

[hollow tartan]

@timber lion I do have free access to Zed Shaw's books and Videos. thank you for pointing them out! I said to Tony: "Tony, please be more careful on those trails. okay?"

[timber lion]

oh nice, yeah i like his stuff a lot.. it's opinionated but in a good way IMHO

his python books are good too

oh wow yeah safety is actually #1, i haven't had any trouble yet but am always on the lookout 😃

[stuck elbow]

Is there a meaning for the different charcters? I know Sparky is for the blue smoke, but the others?

[tidal kiln]

@stuck elbow not really meaning, like blue smoke, but they all have their own personalities.

[manic glacier]

stevector

[adafruit/circuitpython] New star added

[tidal kiln]

@slender iron this is what needs some eyes on: https://github.com/adafruit/circuitpython/issues/312
also, let me know if that idea of creating a new branch wasn't a good one

[solar whale]

@cunning crypt thanks for the xfinity link - I was having trouble for the past hour or so as well - perhaps that is why....

[cunning crypt]

Yeah, it seems to be pretty widespread.

I was having issues with some sites earlier this morning, but it seems to be resolved for me

[solar whale]

me too.

[umbral dagger]

@hollow tartan @timber lion Ya, Zed is a bit of a jerk sometimes, but an awesome guy.

[tidal kiln]

@idle owl i think this has been discussed, not sure where it stands - how to get a value from a single axis of the accelo? (using cpx)

this syntax works cpx.acceleration[2] to get Z for example. maybe good enough?

[tidal kiln]

@idle owl also, what about analog in?

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

Since the update is in 2.x and pending for master, I thing this can be closed. It won't let me close it.

jerryneedell

[adafruit/circuitpython] New comment on issue #410: round function not working

odd - FYI - you do have access to several functions in the math module. ```import math
math.floor()
math.ceil()
math.trunc()

jerryneedell

[adafruit/circuitpython] New comment on issue #410: round function not working

round also fails the same in the master 3.0 build.

[tidal kiln]

is this expected behavior? why 0 for third case?

Adafruit CircuitPython 2.1.0 on 2017-10-17; Adafruit CircuitPlayground Express with samd21g18
>>> import time
>>> t1=time.monotonic(); time.sleep(0.1); t2=time.monotonic(); print(t2-t1)
0.0976563
>>> t1=time.monotonic(); time.sleep(0.01); t2=time.monotonic(); print(t2-t1)
0.0078125
>>> t1=time.monotonic(); time.sleep(0.001); t2=time.monotonic(); print(t2-t1)
0.0

[cunning crypt]

Looks like time.sleep() isn't ultra-precise, and 0.001 falls underneath that precision.

If I were to guess, at least.

[tidal kiln]

@cunning crypt my guess also, esp. given the values for the other two

[cunning crypt]

Yeah. 0.097whatever is pretty close to 0.01, but 0.0078ish is significantly less close to 0.01

@tidal kiln I'm assuming M4?

[tidal kiln]

no. m0. good point. i'll edit and add banner for context.

[cunning crypt]

I get similar results.

On CircuitPlayground Express

[tidal kiln]

yeah, but that shouldn't matter

[cunning crypt]

>>> import time
>>> t1=time.monotonic(); time.sleep(0.1); t2=time.monotonic(); print(t2-t1)
0.098999
>>> t1=time.monotonic(); time.sleep(0.01); t2=time.monotonic(); print(t2-t1)
0.00900269
>>> t1=time.monotonic(); time.sleep(0.001); t2=time.monotonic(); print(t2-t1)
0.0```

[tidal kiln]

looks a little better, but still 0 on last

similar on trinket m0

[cunning crypt]

Running the 0.01 sleep a few times, and it's often 0.0090332

Lowest is 0.00891113, highest is 0.0100098

Definitely looks like 0.001 is outside of its range

Or not. Just got 0.000976563

[split ocean]

@idle owl or anyone w ideas on this, I've got a quick (I hope) question on a simplio module error

[cunning crypt]

It hits 0.0 very often, but it does occasionally hit real numbers.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #410: round function not working

There is apparently a bug in https://github.com/adafruit/circuitpython/blob/master/lib/libm/nearbyintf.c in the builtin libm.

[tidal kiln]

@split ocean go for it, ask away...

[floral dagger]

time.monotonic is not purely time based. It relies on clock cycles in some cases iirc, so can sometimes be ever so slightly off.

[tidal kiln]

that's probably it, first time i've tried to crank things down this low

[floral dagger]

it returns a fractional representation of time passed, so it could also be in the math

[split ocean]

thanks @tidal kiln I've got a pretty simple bit of code started and as soon as add importing of simpleio I'm getting a memory allocation error

[tidal kiln]

also noting that not much has been implemented in the the cp time module:
http://circuitpython.readthedocs.io/en/2.x/shared-bindings/time/__init__.html

[split ocean]

Traceback (most recent call last):
File "main.py", line 5, in <module>
File "libraries/helpers/simpleio/simpleio.py", line 225, in <module>
MemoryError: memory allocation failed, allocating 136 bytes

here's the code:

https://gist.github.com/jedgarpark/0aada831d70a8919efee1ec714eec03d

I'm going to use servo, btw

I'm on CircuitPython 2.1 on a CPX w latest bundle

[tidal kiln]

one thing right off - you can access the neopixels via the CPX library

line 15 coudl be cpx.pixels[i] = ((R, G, B))

[idle owl]

@tidal kiln Re: accel, I think that syntax might be good enough. But it might be better to have something clearer. Analog in is not included, I hadn't thought about it until trying to write up examples using the CPX library for all the code in the Intro to CPX guide.

[slender iron]

Hi all and <@&356864093652516868> here is the video from today's meeting https://youtu.be/VuDyCgx4ZRk . Next week will be on Tuesday instead of the normal MOnday because I'm travelling Monday. Thanks!

[idle owl]

@split ocean Checking out your code now.

[tidal kiln]

Adafruit CircuitPython 2.1.0 on 2017-10-17; Adafruit CircuitPlayground Express with samd21g18
>>> import time
>>> from adafruit_circuitplayground.express import cpx
>>> import neopixel
>>> import board
>>> import simpleio
Traceback (most recent call last):
  File "<stdin>", line 1, in <module>
ImportError: no module named 'simpleio'
>>>

recreated, at least

oh wait.

[idle owl]

Is simpleio not built in?

[tidal kiln]

it's in bundle:
https://github.com/adafruit/Adafruit_CircuitPython_Bundle/tree/master/libraries/helpers

forgot i had a paired down set of stuff on my CPX

@split ocean did you just drag over all the bundle contents as is? or have you deleted and/or mpy-cross'd anything?

ok...that's the error droid i was looking for:

Auto-reload is on. Simply save files over USB to run them or enter REPL to disable.
main.py output:
Traceback (most recent call last):
  File "main.py", line 5, in <module>
  File "libraries/helpers/simpleio/simpleio.py", line 225, in <module>
MemoryError: memory allocation failed, allocating 136 bytes

[split ocean]

I dragged over the unzipped bundle lib directory without any changes

[idle owl]

Does it help to mpy-cross it?

[split ocean]

FWIW, simpleio worked when I ran just the servo code and nothing else as I was working on this

[pastel panther]

New toys, wew! Hope to have one of these puppies choochin' some CP before too long:

[tidal kiln]

can get away with it in REPL:

Adafruit CircuitPython 2.1.0 on 2017-10-17; Adafruit CircuitPlayground Express with samd21g18
>>> import time
>>> from adafruit_circuitplayground.express import cpx
>>> import neopixel
>>> import board
>>> import simpleio
>>>

@split ocean "just the servo code" probably had fewer imports?

[split ocean]

yes, many fewer

[idle owl]

I've tried uncommenting a lot of what looked like commented out code... I'm not having memory allocation issues. But I don't know if I've added all the code you're trying to run.

[split ocean]

oh, of course, I'm eating up ram w cute ascii art ;)

[idle owl]

Also, I have 2 micro servos, will one of them work to try to replicate your setup?

One is continuous, the other is not.

[split ocean]

yes, I'm not doing anything proper w it yet in that code though

[slender iron]

@tulip sleet get the clock going?

[tidal kiln]

@idle owl so you deleted code comments from the gist?

[idle owl]

I pasted the entire thing in, and uncommented what looked like code. I didn't delete anything.

[split ocean]

was just getting to that. but for now, if you had the servo move to one position when the CPX is rotated CW 90 degrees and another when rotated CCW 90 degrees that would be a good test. Orientation of CPX is like a clock on a wall

[tulip sleet]

@slender iron yeah, but the I2C is twice as fast on the SAMD51, despite the constants being the same. I should double-check gclk1 on both. For a requested 400 kHz clock, '21 is 350-ish, '51 is 735-ish

oh wait, maybe a typo

[tidal kiln]

@idle owl i'm getting same memory error as @split ocean if i just paste as is and use the bundle as is. are you doing something different?

[idle owl]

I only copied simpleio.mpy out of the library bundle into my lib folder. So all that's in there is adafruitcircuitplayground/ and simpleio.mpy

Let me copy the rest of the bundle in

[manic glacier]

tannewt

[adafruit/circuitpython] Pull request closed: #409 enable framebuf for ESP8266

tannewt

[circuitpython:master] 1 new commit

e2867eb enable framebuf for ESP8266 - jerryneedell

[tulip sleet]

@slender iron all better - I forgot to change the clock source in one place. Identical clocks on both now. Now to test a fancier device like the accelerometer

[slender iron]

w00t!

[tulip sleet]

maybe a pull request soon! can you do the asf4 pull I have on tap?

[idle owl]

Memory allocation error.

Wait!

[tulip sleet]

take two mpy-cross's and call me in the morning

[slender iron]

@tulip sleet yup, will look now

[manic glacier]

tannewt

[adafruit/circuitpython] Issue opened: #411 APDS9960 Driver

Driver for the gesture sensor.

https://www.adafruit.com/product/3595

[idle owl]

@tidal kiln If the bundle is there as-is, it means that lis3dh is included, and it's already frozen into the firmware for the CPX.

If I delete ONLY that from the bundle, it works fine.

You can't have it duplicated. It was frozen in because the acceleration module was too much to be run from the lib folder.

[tulip sleet]

@idle owl the frozen one is last on sys.path. If there's one in lib it will take that one first

[idle owl]

@tulip sleet So it seems!

[tidal kiln]

hey. wasn't this discussed today? board specific bundles?

[idle owl]

@split ocean You have to delete lis3dh from the bundle for it to work.

[split ocean]

got it.

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #395: ESP8266 \- turn on framebuf in mpconfigport\.h

I pulled the master version as well. Thanks @jerryneedell !

[idle owl]

It's been discussed previously as well 😃

[manic glacier]

tannewt

[adafruit/circuitpython] Issue closed: #395 ESP8266 \- turn on framebuf in mpconfigport\.h

[tidal kiln]

is there a good decoder ring for what to remove from the full menu for each board? or is cpx the only outlier?

[split ocean]

this is for an AdaBox 006 project guide -- is the current thinking that there won't be board specific bundles? in that case, I'll include a step where people remove that module.

[idle owl]

I think it's the only outlier for included libs. The trinket and gemma issue is just space and only importing what you need vs. having a board "specific" bundle for them.

@split ocean I would include the step for now. We talked about doing board specific bundles but there are a number of reasons why it's still up in the air.

[split ocean]

roger that

Thanks @tidal kiln and @idle owl that worked!

[idle owl]

Yay!

[tidal kiln]

np @split ocean , good job @idle owl

[tulip sleet]

@slender iron thanks on asf4! lis3dh returns acceleration on CPX! That's a good exercise. I'll look at your clock fixes, merge that in, retest, and submit a PR.

[slender iron]

👍

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

The last option looks good! Also keep in mind that switching a driver to adafruit_bus_device.I2CDevice might be the easiest way going forwards.

[tidal kiln]

@idle owl the CP classic just used arduino libs to do analog and digital io. so in that same style, maybe no need for anything in the CPX lib. just use core modules.

[idle owl]

@tidal kiln Ok keen. I wasn't sure whether it was something worth looking into. In my mind, the CPX lib uses in some way everything built into the board and once you're past that, you're to a point that using core modules is easier to understand.

[split ocean]

on that note, do we have a debounce built into the cpx.button_a check?

[idle owl]

So the lib works with the board stand-alone and as you start adding external sensors an so on, you start using core modules.

[slender iron]

@tidal kiln I can voice or video chat with you about the ADC in the next couple hours if you like.

[idle owl]

@split ocean I don't know. I didn't write the button code, so I'm not as familiar with it. @slender iron do you remember?

[split ocean]

it seems to work really well, but just want to make sure I show best practices in this

[slender iron]

@split ocean it doesn't debounce. it just runs slowly. let me know if you see weirdness with it

[split ocean]

cool. no weirdness thusfar ;)

[slender iron]

k, then its ok as is 😃

@stuck elbow introduced gamepad with debouncing if you want to track button presses that happen between checks

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #406: release should include bin files for the uf2 based releases

Hi zencuke! Which documentation are you looking at? It should be updated.

I'd rather not include bins in the release list because its already long as is. However, they are always built and available here: https://adafruit-circuit-python.s3.amazonaws.com/index.html?prefix=bin/

[split ocean]

@idle owl @slender iron on that topic of how much simplification is introduced w the adafruit_circuitplayground.express import cpx action:

do I still need to import DigitalInOut, Direction, Pull if I'm using cpx.button_a?

or is that implicit

[idle owl]

Nope. Implicit.

[split ocean]

SNAZZY

Oh, I see same goes for neopixel, as well. excellent.

[idle owl]

@split ocean Yep, and brightness works. You can set it before your while loop or in it.

[tulip sleet]

@slender iron another asf4 PR before the circuitpython PR

[slender iron]

needs a rebase

[tulip sleet]

@slender iron the CONTAINER_OF changes are redundant

[split ocean]

got it. and you were saying earlier that simplio is still a separate module to import because it's not based on sensors that are physically on the cpx?

[tidal kiln]

and just so you know, this x = int(xF) truncates

>>> print(int(3.99999) )
3

[slender iron]

@tulip sleet merge it as you like I just approved

[idle owl]

@split ocean Not exactly. It just hasn't been frozen into the firmware. The reason for including or not including something in the CPX lib is in design discussions, I was simply explaining how I think about the library. I feel like we could expand it to include the options available with the Educator's pack, which I believe includes a servo, but we haven't gotten to that point yet.

[split ocean]

Cool.

[tidal kiln]

@split ocean you probably want int(round(3.999)), but not right now:
https://github.com/adafruit/circuitpython/issues/410

[idle owl]

As time passes, we'll definitely expand it to include new things as we find that there are new use cases for it. The more people use it, the more we learn what types of things people want to do with it.

[tidal kiln]

@split ocean some of what @idle owl was saying may have been related to the discussion about analog in and how to use it with CPX

[idle owl]

@tidal kiln Looping back to earlier, what was your reason for needing access to the lis3dh range?

[tidal kiln]

so it could be changed for different applications

for example, wanted to crank it down to 2G for better accuracy

or up to 16G for something super shaky

[slender iron]

@tidal kiln for the ads change I'd just suggest documenting ADC_Channel

[tidal kiln]

@idle owl something like this: https://github.com/adafruit/Adafruit_CircuitPlayground/blob/master/Adafruit_Circuit_Playground.h#L120

[slender iron]

and removing the stuff thats commented out because it moved

[tidal kiln]

@slender iron want to talk?

[slender iron]

I can if you like

[idle owl]

I don't think it will be as simple as exposing the parameter. So I wanted to know whether it was a general thing or whether you'd come up with a specific use case.

Yeah we picked one of the range levels in the middle.

[tidal kiln]

@slender iron need to set mic up....one sec...

[slender iron]

kk

it just shows as connecting for me

[tidal kiln]

same

[manic glacier]

dhalbert

[adafruit/circuitpython] Pull request opened: #412 Implement busio\.I2C

• Added asf4_conf/samd*/hpl_sercom_config.h
• Adjusted clocks in peripheral_clk_config.h.
• Put some frozen libs back in CPX for testing.
• Implement common-hal I2C.
• Re-enable resetting SERCOMs in port_init(), so SERCOM's get reset on soft reboot.
• Add samd*_peripherals.h in parallel with samd*_pins.h for common
  functions and data.
• Store SERCOM index in pins table for convenience.
• Canonicalize some #include guard names in various .h files.

[slender iron]

@tidal kiln https://github.com/adafruit/Adafruit_CircuitPython_ADS1x15

[cunning crypt]

Does CircuitPython have any sort of sleep functionality? IE, all-but-shutoff the M0?

[idle owl]

Not at the moment.

@cunning crypt There's an issue started for it. https://github.com/adafruit/circuitpython/issues/119

[cunning crypt]

Not surprised.

[slender iron]

@cunning crypt I glanced at it a bit but it didn't seem easy

I'd love it if time.sleep() was smart enough to manage it

[cunning crypt]

That'd be cool

[idle owl]

@slender iron Send me the neopixel update.

[slender iron]

😃

1 sec, updating everything first

[idle owl]

Np

[slender iron]

need a uf2 or bin?

[idle owl]

uf2 please

@errant grail Congrats!!

[slender iron]

building now @idle owl. you'll be the first to test

[idle owl]

@slender iron Nice!

[slender iron]

-Os compilation

[idle owl]

@slender iron Woah! That's noticably faster!

Already had rainbow animation code and a neopixel strip wired up.

REPL working fine.

[slender iron]

oooh perfect!

I expected it to crash 😃

[idle owl]

It's not mounting on reset though.

[slender iron]

what do you mean by reset?

[umbral dagger]

Update time. Here's the file running that's loaded/running: acc = 0 for i in range(10): acc = acc + i debugger() and here's a trace: MicroPython Debugger DD> acc acc 0 DD> i i 0 DD> :c :c CONTINUE MicroPython Debugger DD> acc acc 1 DD> i i 1 DD> :c :c CONTINUE MicroPython Debugger DD> :c :c CONTINUE MicroPython Debugger DD> i i 3 DD> acc acc 6 DD> :c :c CONTINUE MicroPython Debugger DD> :c :c CONTINUE MicroPython Debugger DD> i i 5 DD> acc acc 15 DD>

[idle owl]

If I eject it, and either press reset or unplug it and plug it back in, it doesn't show up in Finder. It took 2 resets once to get it to show up, but after that it's not showing up again. I can get to it via serial, but it's not mounting circuitpy drive

[slender iron]

@idle owl master does this too right?

[idle owl]

It had stopped doing this I thought.

[slender iron]

its based on the latest master

[idle owl]

Ok this time it popped up. Hmm.

Now it's mounting consistently.

Except when Finder crashes, lol. Wondering if it's something odd on my end.

I can reboot, but this is what it was doing before the last USB fix. Finder just crashed again. I'll reboot.

[slender iron]

a bug is totally possible

please file an issue with instructions to reproduce

I don't think resets on the USB side are handled well

[idle owl]

Ok repro'd after reboot.

Ejecting and physically removing was working until it popped up as NO_NAME and my code stopped running. And apparently erased the board.

[slender iron]

hrmmm, crazy!

[idle owl]

Ooh. So it let me get to the bootloader and drag the firmware you sent me to it, rebooted it like it worked, and came back up as no_name.

Even with no_name mounted, I can at least temporarily get to and interact with the REPL

[slender iron]

thats weird its no_name

when it updates it won't rewrite the file systems

[idle owl]

I was able to copy main.py and neopixel.py to no_name and have it run, at least while I'm connected via serial.

And I can import main.py inside the REPL and it runs.

[slender iron]

ok, so the name of the disk just got corrupted

[idle owl]

It erased my code and module files, I had to copy them back.

But they're working now.

[manic glacier]

dhalbert

[adafruit/circuitpython] Pull request opened: #413 Fix round\(\)\.

Don't split a statement with a #pragma. It breaks the compiled output. Fixes #410.

[idle owl]

Hmm.

Also a file called _NEOPi~1.PY was on the cleared drive when it mounted again as no_name. Containing somewhat jibberish. That acted really weird when I tried to paste it in here, so I'll include the file if you want, but I don't want to crash anything with weird non-code.
.

[slender iron]

yeah, I think the filename is stored in the same place as the disk name

[idle owl]

So... jlink? And try to repro?

Because reflashing the firmware.uf2 isn't resolving the issue.

[slender iron]

yeah, you need something to erase the file system flash for you

do you all know how to erase with jlink? I don't actually

[idle owl]

No. I know how to reflash. I was going to reflash the bootloader, and then reload the uf2.

[slender iron]

the bootloader isn't working?

[idle owl]

It is. But that's the only way I know to clear everything would be to reflash the bootloader.

I guess I could try using the jlink and a .bin firmware

[tidal kiln]

erase spi flash?

via jlink?

[idle owl]

We have flash eraser files for the M0 boards, I don't know how they work or whether they'd work on the M4 though.

Those work through the bootloader.

I mean they're uf2 files, I assume that's how they work.

[vague monolith]

They're available on readthedocs page under troubleshooting for circuitpython

[tidal kiln]

cause i don't know either. theres erase but that's just for on chip

[idle owl]

I know but I don't know if they'd work on the M4 board. They're designed for the M0 boards.

[tidal kiln]

afaik

[slender iron]

all filesystems are on chip now

[tidal kiln]

oh. then erase

[idle owl]

How does that work

[tidal kiln]

run JLinkExe

connect

[slender iron]

that will erase the bootloader if you've never updated via the self-updater uf2

[tidal kiln]

then erase

[slender iron]

the self-updater sets the protection bits

[idle owl]

@slender iron I didn't because you said it made doing things with the jlink more difficult.

[slender iron]

it does a little

it might be easier than reloading the bootloader though to do a chip erase

[vague monolith]

What is jlink?

[tidal kiln]

@vague monolith https://www.adafruit.com/product/3571

@vague monolith or similar https://www.adafruit.com/product/1369

[idle owl]

Well, I've always got the jlink to reload something if I break it, lol. So I'll do erase

[tidal kiln]

@vague monolith a programmer for ARM core chips

@slender iron you can get around any protection bits using the jlink, correct?

[slender iron]

yeah

[vague monolith]

Nice

[slender iron]

its just one command you have to remember to run

[idle owl]

It's been a while, how am I connecting to it again?

Not jlink, connecting to the M4

[tidal kiln]

command wise?

[idle owl]

Yeah

[slender iron]

https://github.com/adafruit/uf2-samd21#samd51

[idle owl]

connect -somethingspecific

[tidal kiln]

try just running JLinkExe

should get a prompt?

[idle owl]

Yep

[tidal kiln]

connect

[idle owl]

Oh. I thought I had to tell it things.... oh wait, it asks inside JLinkExe doesn't it

I had forgotten

[tidal kiln]

you do, but this way you do so interactively

[idle owl]

speed is 1000 right?

[tidal kiln]

i've gotten away with 4000, so dunno

[idle owl]

hmm ok

[tidal kiln]

SWD

[idle owl]

I remembered that one

I.. think it worked?

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

This looks like a hangover from spi. I doubt its needed.

tannewt

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

The reliance of these new _init methods on arrays of _configuration structs is really annoying. Is the compiler smart enough to inline the values from the arrays or does it always take code space? I'd be tempted to init them ourselves to avoid the configuration structs and the need for the CONF values at all.

tannewt

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

I don't think you need these three things. SPI.CTRLA.bit.SWRST is the same memory location as I2CM.CTRLA.bit.SWRST because SPI and I2CM are members of a union. Instead, I think you had "in use" errors because the reset takes time and the M4 is faster than the M0. You can wait on the state of SYNCBUSY.bit.SWRST. It'll be 0 when the reset is finished.

[tidal kiln]

when you're back to the prompt, then do erase

[idle owl]

So just type erase?

ok

Done.

[tidal kiln]

loadbin foo.bin, 0

[idle owl]

foo being the bootloader?

[tidal kiln]

yep

[idle owl]

@slender iron Other than the self-updater one, is the bootloader.bin I have from 24 October still the most up to date? Or should I just load the self-updater.

[slender iron]

I think so

I haven't changed anything recently

[tidal kiln]

INFO_UF2.TXT:

UF2 Bootloader v1.23.0-14-g3db9182 SFHR
Model: Metro M4
Board-ID: SAMD21G19A-Metro-v0

^^ thats whats on my M4 fwiw

@slender iron i think i remember i did this:

chan0 = adc[0]
chan0.value

so that you could then show how one could pass chan0 to something else

and it would work the same as analogio

[slender iron]

right, maybe use it in a loop after that instead with an analogio example commented out?

[tidal kiln]

yeah. i can make a stab at something. and can always comment once pr is made.

[slender iron]

sounds good!

[tidal kiln]

gotta run. @idle owl , you set?

[idle owl]

@tidal kiln Yeah looks like it! Thanks!

[tidal kiln]

cool. you can do all the interactive stuff via command line to expedite if you want.

i've just been running in that interactive mode for now

[idle owl]

Makes sense. I had forgotten it did that.

[tidal kiln]

but now you're back to bootloader goodness and can move forward from there (without jlink)

[idle owl]

Yep! Firmware loaded happily. Now I'm back to ejecting and reseting. 😃

[slender iron]

aka back to breaking it again 😛

[idle owl]

Exactly!

Isn't that the point? I thought it was the point.

[tidal kiln]

but can pwn and fix with jlink, so no worries.

[idle owl]

Yep!

[slender iron]

sure 😃 I do wish you had usb logs to go with it

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on pull request #398: Add a \_stage module

I'm super excited about this! It reminds me of this talk: https://www.youtube.com/watch?v=HyzD8pNlpwI

It looks good to me. The one thing I wonder is if its worth thinking about how it work if the display was QSPI instead of SPI because the SAMD51 has a QSPI peripheral. Would it be worth delegating the actual write back to Python to gain flexibility on where the frame is written to after its rendered?

[idle owl]

Doesn't that require another piece of HW? Or am I hoping to get that from dmesg

[slender iron]

dmesg error would help

I use a beagle to get it. If you have a linux box it could get close too

[idle owl]

It's mostly not returning dmesg errors. Every so many times I get this: USB device 239A802114130002 - fConsecutiveResetCount = 1. SmartBattery: finished polling type 4 disk3s1: device/channel is not attached. disk3s1: device/channel is not attached. disk3s1: device/channel is not attached. disk3s1: media is not present. USB device 239A802114130002 - fConsecutiveResetCount = 2. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. disk3s1: media is not present. USBMSC Identifier (non-unique): AF8C5FF815E47535020202D473C480FF 0x239a 0x8021 0x100, 1

There's a lot of other messages, but I guess I'm not entirely sure what all would be related.

[slender iron]

I think the disk3s1 messages are ok

[idle owl]

There aren't really any errors. I have an older linux laptop I can fire up.

[slender iron]

wireshark can be used to capture usb on linux

I gotta go do a few chores before dinner with tony

thanks for the help and testing!

[idle owl]

For sure!

[manic glacier]

tannewt

[adafruit/circuitpython] Pull request opened: #414 Turn on \-Os and tweak neopixel for new code output\.

microbuilder

[adafruit/circuitpython] New comment on pull request #398: Add a \_stage module

@tannewt Feel free to correct me, but I've never seen a QSPI display ... it's normally only used for very high speed flash memory access, such as an MCU with external flash where you want to execute code directly off the SPI flash device. As such, for anything display related I don't think it's worth waiting or reworking anything around QSPI.

dhalbert

[adafruit/circuitpython] New comment on issue #407: reading value from output pin not always reflective

This works fine on 2.x, but is a problem on 3.0.

Tested partially on Feather M0 basic and Metro M0:
MOSI, A1, A2, A5, value is False even after set to True.
MISO, A0: works fine.

Then, while trying to use A3, I got a "Pin PB09" in use, even though I hadn't used A3 before. So this might be a pin mapping problem.

tannewt

[adafruit/circuitpython] New comment on pull request #398: Add a \_stage module

Thanks for the info! I didn’t look just thought there might be.
On Mon, Nov 6, 2017 at 5:49 PM Kevin Townsend [e-mail]
wrote:

@tannewt https://github.com/tannewt Feel free to correct me, but I've
never seen a QSPI display ... it's normally only used for very high speed
flash memory access, such as an MCU with external flash where you want to
execute code directly off the SPI flash device. As such, for anything
display related I don't think it's worth waiting or ...

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

Union thing understood. I didn't read the register defns carefully enough.
The weird thing about the ENABLE and SWRST is that I got "pin in use" errors after a soft reboot when lines 183 and 184 were reversed. These errors were many seconds after the reboot: I was testing in the REPL. I'll test this again.

dhalbert

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

I'll delete.

dhalbert

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

sercom_clock_init is new by me (it's in samd*1_periphals.c). I do need the clock lookup table (maybe not the SLOW), because the numbers are random.

I think we could get rid of the _i2cms configuration table in hp_sercom.c, but it means changing the semantics of the library somewhat. I was trying to make minimal code changes to ASF4 aside from fixing bugs, so that we could merge more easily later.

The compiler can't inline the values because they're looked up by an index computed...

dhalbert

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

I thought maybe SWRST was ENABLE-protected. It says it isn't.

dhalbert

[adafruit/circuitpython] New comment on pull request #413: Fix round\(\)\.

Test failure was the the usual "lock_3" failure.

dhalbert

[adafruit/circuitpython] New comment on pull request #413: Fix round\(\)\.

I will merge more 2.x fixes into master on a batch basis, unless you would like separate master PR's for each.

dhalbert

[adafruit/circuitpython] Pull request closed: #413 Fix round\(\)\.

dhalbert

[circuitpython:2\.x] 2 new commits

ddc8570 Fix round(). Don't split a statement with a #pr... - dhalbert
d9a19c4 Merge pull request #413 from dhalbert/fix_round - dhalbert

dhalbert

[adafruit/circuitpython] Pull request closed: #414 Turn on \-Os and tweak neopixel for new code output\.

dhalbert

[circuitpython:master] 3 new commits

a8ee001 atmel-samd: Enable -Os for SAMD51 and update ne... - tannewt
182a946 atmel-samd: Tweak mass storage code to finish r... - tannewt
048f0f0 Merge pull request #414 from tannewt/new_opt - dhalbert

[manic glacier]

siddacious

[adafruit/circuitpython] Pull request opened: #415 support for doubled file extensions ala issue \#383

Here's my fix. It's the first C I've written in quite a long time so by all mean suggest any improvements that are warranted.

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on pull request #413: Fix round\(\)\.

Batch basis is fine with me!

On Mon, Nov 6, 2017 at 6:39 PM Dan Halbert [e-mail] wrote:

Merged #413 https://github.com/adafruit/circuitpython/pull/413.

—
You are receiving this because your review was requested.

Reply to this email directly, view it on GitHub
https://github.com/adafruit/circuitpython/pull/413#event-1328873287, or mute
the thread
https://github.com/notifications/unsubscribe-auth/AADNqZD3XyAcMQJEmLF_NiG0SeLPlhbDks5sz8LHgaJpZM4QUHiF
...

[manic glacier]

deshipu

[adafruit/circuitpython] New comment on pull request #398: Add a \_stage module

This is a great talk, and GameBoy is certainly a very well engineered system — though they drove their LCD display directly, not with a luxurious chip that we have nowadays, so the timings had the be exactly right.
I haven't heard about quad-spi displays — I think at that point you would simply use a parallel 8-bit or 16-bit interface, that most such displays support. We might add support for that at some point, but it will have to be in the C module. I did try to make it just fill the buffe...

[manic glacier]

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

@tannewt I am not understanding your point about "switching a driver to". Every one of the libraries I will be changing already are using adafruit_bus_device.I2CDevice. What am i missing?

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on pull request #412: Implement busio\.I2C

I fixed the unnecessary SERCOM reset and removed the unused routine. I have some ideas for getting rid of the configuration tables. But are you willing to defer that for a little while and take the current implementation so people can start testing with I2C devices? I'll come back to the configuration stuff when I start implementing the next part of busio.

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #410: round function not working

Fixed by #413.

dhalbert

[adafruit/circuitpython] Issue closed: #410 round function not working

[manic glacier]

dhalbert

[adafruit/circuitpython] Pull request opened: #416 DigitalInOut: Use pin value % 32 to accomodate PORTB and up\.

Fixes #407 (get pin.value not correct for certain pins)

[cunning crypt]

I mean no offense, guys, it's a great problem to have... but I think I need to set up an email strictly for GitHub

[floral dagger]

good afternoon everyone. I am running through the library example on learn. When I try to run this line:
cookiecutter gh:adafruit/cookiecutter-adafruit-circuitpython
I get this error:
subprocess.CalledProcessError: Command '['git', 'clone', 'https://github.com/adafruit/cookiecutter-adafruit-circuitpython.git']' returned non-zero exit status 128.

Anyone have any insights on what could be thecause?

[tulip sleet]

@floral dagger can you run git clone https://github.com/adafruit/cookiecutter-adafruit-circuitpython.git from the command line? That's all the above is doing.

[floral dagger]

@tulip sleet yeah, that works without a hitch

Is that all I need to do, or does the cookiecutter command do more?

[tulip sleet]

no, that's just the first part; it asks you a bunch of questions and then fills in some slots in the cookiecutter template. what os is this on, and how do you have git installed?

[floral dagger]

windows 10. I installed git from the command line, and I have the windows gui program installed too

[tulip sleet]

I don't know if the script works on windows. If you just type git in a CMD window, does it do anything?

it may not be in your path

gotta leave for an appt - sorry

[floral dagger]

Yeah, git seems to work fine. It shows all the commands

[tulip sleet]

consider using WSL (windows subsystem for Linux), which will let you do all this inside a real Linux env in Windows

[floral dagger]

I'd really prefer to not do that if possible. Any other options @tulip sleet ?

[tidal kiln]

i've run into a use case issue with using _FOO = const(99)

since _FOO becomes hidden, it limits how you can break things up into multiple files

which is my use case:
base_class.py contains the base class and all the consts
some_class.py imports above and derives, but can't access the consts

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

@mrmcwethy yeah, I was confused thinking we were changing CircuitPython's methods.

I think that we should just switch the libraries over to readinto. Lets leave read_into in the I2CDevice class for a little while for any other libraries to catch up.

I want people to grab libraries out of the bundle instead of separately because we can then verify bundled libraries always work with each other.

tannewt

[adafruit/circuitpython] New comment on pull request #415: support for doubled file extensions ala issue \#383

How about adding a macro to do this initialization? That way it can add the empty string.

STRING_LIST("code.txt", "code.py", "main.py", "main.txt")

tannewt

[adafruit/circuitpython] New comment on pull request #415: support for doubled file extensions ala issue \#383

Implicit C int -> bool confuses my C++ and python brain. Mind making this filenames[i] != ""?

tannewt

[adafruit/circuitpython] Pull request closed: #412 Implement busio\.I2C

tannewt

[circuitpython:master] 1 new commit

7292984 Implement busio.I2c. - dhalbert

siddacious

[adafruit/circuitpython] New comment on pull request #415: support for doubled file extensions ala issue \#383

Will do.

siddacious

[adafruit/circuitpython] New comment on pull request #415: support for doubled file extensions ala issue \#383

I agree, that would be easier to read.

tannewt

[adafruit/circuitpython] Pull request closed: #398 Add a \_stage module

tannewt

[circuitpython:2\.x] 1 new commit

216fced Add a _stage module (#398) - deshipu

tannewt

[adafruit/circuitpython] Issue closed: #407 reading value from output pin not always reflective

tannewt

[circuitpython:master] 1 new commit

9060df5 DigitalInOut: Use pin value % 32 to accomodate ... - dhalbert

tannewt

[adafruit/circuitpython] Pull request closed: #416 DigitalInOut: Use pin value % 32 to accomodate PORTB and up\.

siddacious

[adafruit/circuitpython] New comment on pull request #415: support for doubled file extensions ala issue \#383

I don't see a place for similar macros like supervisor/default/messages.h is for message strings. Should I put it in main.c or somewhere else?

tannewt

[adafruit/circuitpython] New comment on issue #401: 2017\-11\-02 3\.0beta build REPL won't exit \(M4\)

Can you test against latest master again? 4140b3b9443c47b8eda05de60b312b7df65ff5e0 fixed a usb issue and may have fixed this.

[stuck elbow]

the issue is that git is a special animal and returns non-zero exit status on success

because Linus said so

[tidal kiln]

multiple flavors of success?

[stuck elbow]

yeah, I think the commands that modify something return 2

or something like that

[floral dagger]

The text returned:

  File "path\runpy.py", line 193, in _run_module_as_main "__main__", mod_spec)
  File "path\runpy.py", line 85, in _run_code exec(code, run_globals)
  File "path\cookiecutter.exe\__main__.py", line 9, in <module>
  File "path\core.py", line 722, in __call__ return self.main(*args, **kwargs)
  File "path\core.py", line 697, in main rv = self.invoke(ctx)
  File "path\core.py", line 895, in invoke return ctx.invoke(self.callback, **ctx.params)
  File "path\core.py", line 535, in invoke return callback(*args, **kwargs)
  File "path\cli.py", line 120, in main password=os.environ.get('COOKIECUTTER_REPO_PASSWORD')
  File "path\main.py", line 63, in cookiecutter password=password
  File "path\repository.py", line 103, in determine_repo_dir no_input=no_input,
  File "path\vcs.py", line 99, in clone stderr=subprocess.STDOUT,
  File "path\subprocess.py", line 336, in check_output **kwargs).stdout
  File "path\subprocess.py", line 418, in run output=stdout, stderr=stderr) subprocess.CalledProcessError: Command '['git', 'clone', 'https://github.com/adafruit/cookiecutter-adafruit-circuitpython.git']' returned non-zero exit status 128.```

had to replace the actual path with "path" to get under the discord character limit

it looks like the git command completes as expected, but it fails in other places

(all files are present in the destination folder)

[manic glacier]

caternuson

[adafruit/circuitpython] New comment on issue #312: Add driver for ADS1x15 ADCs

PR made:
https://github.com/adafruit/Adafruit_CircuitPython_ADS1x15/pull/1

[opaque patrol]

FYI, I test the cookiecutter using the git bash and got the same errors

[tidal kiln]

just to sanity check, ran on linux, all ok:

~/test$ cookiecutter gh:adafruit/cookiecutter-adafruit-circuitpython
You've cloned /home/foo/.cookiecutters/cookiecutter-adafruit-circuitpython before. Is it okay to delete and re-clone it? [yes]: yes
library_name: test_library
depends_on_bus_device []: y
depends_on_register []: n
author: Foo Bar
company [Adafruit Industries]:
~/test$ cd test_library/
~/test/test_library$ ls
adafruit_test_library.py  CODE_OF_CONDUCT.md  LICENSE     readthedocs.yml
api.rst                   conf.py             README.rst  requirements.txt

[solar whale]

well - there you go - problem soved 😉

[glad hazel]

Is it possible to record some audio from the on board mic on the Circuit Playground express using circuit python? I'm having trouble getting the right API to record audio 😕

[manic glacier]

dhalbert

[adafruit/circuitpython] New comment on issue #358: i2c read\_into hardfaults if given bytearray of size zero

Fixed by #404. Thanks @deshipu

dhalbert

[adafruit/circuitpython] Issue closed: #358 i2c read\_into hardfaults if given bytearray of size zero

zencuke

[adafruit/circuitpython] New comment on issue #406: release should include bin files for the uf2 based releases

I was looking at the Circuit Playground Express tutorial. It is obviously not done. It is huge with lots of useful info but it looks like a lot of cut and paste was done. It needs some editing for things that need to be changed for inclusion in this specific tutorial. I try to give feedback when I notice things. It would work if the tutorial pointed to the bin files. It said "this is how to recover with a bin file" but no pointer to bin files. I went to the release area and no bin file.

mrmcwethy

[adafruit/circuitpython] New comment on issue #364: I2C & SPI BusDevice readinto/read\_into

I like that decision. I will act on it.

[tulip sleet]

@glad hazel there is some rough microphone code here: https://github.com/adafruit/circuitpython/issues/156; we are working on better support

[glad hazel]

@tulip sleet Thank you! Do you think switching to C++ would work more reliably, or will this be enough for a simple record and playback?

[tulip sleet]

@glad hazel You'll probably have to do some experimenting. As that issue discusses, there is some signal processing you may want to do on the result. Here is some more doc for CircuitPython: https://circuitpython.readthedocs.io/en/2.x/shared-bindings/audiobusio/PDMIn.html. And here is a tutorial for a similar mic with Arduino and Rpi info: https://learn.adafruit.com/adafruit-i2s-mems-microphone-breakout/arduino-wiring-and-test. Also note that the CPX is supported by MakeCode, which has microphone support: https://learn.adafruit.com/adafruit-circuit-playground-express/makecode

[bronze geyser]

anyone recovered from this w/o reinstalling circuitpython? ampy.pyboard.PyboardError: could not enter raw repl

I thought I could ctl-d or something...but so far not successful.

[stuck elbow]

can you enter repl normally?

[bronze geyser]

yah. I just (seems slowly) thought to go to a screen.

[stuck elbow]

raw mode is ctrl+b iirc

[floral dagger]

Ok, well since I can't use cookiecutter in windows apparently. Is there another reference I can use?

[manic glacier]

zencuke

[adafruit/circuitpython] New comment on issue #406: release should include bin files for the uf2 based releases

This is off point for the issue but there was a bigger problem in the tutorial. I probably didn't need bossa. I tried to load circuitPython and the behavior didn't match the tutorial. Bright lights flashed, two popups appeared indicating that both CIRCUITPY and CPLAYBOOT had been improperly removed and CIRCUITPY was not on the desktop as promised.

It turns out that in spite of the weird behavior circuitPython was actually running. CIRCUITPY was mounted (according to 'df' and 'ls /Volumes/*...

[bronze geyser]

@stuck elbow ok. I can get into raw then repl using screen.... but ampy can't get to raw repl?

[stuck elbow]

your don't have your screen running at the same time, do you?

[bronze geyser]

no.

if i did, it would be access error instead of could not enter raw repl....

[stuck elbow]

true, just making sure

do you have anything running there? any main.py?

or boot.py?

[bronze geyser]

yes indeedy. i have main.py....i stupidly put a While True: so I assume this is choking access...

[stuck elbow]

can you rename it with os.rename()?

[bronze geyser]

ooh. clever. i will try this. thanks.

[stuck elbow]

use os.listdit() to see if it worked

listdir()

[manic glacier]

dhalbert

[adafruit/circuitpython] Issue opened: #417 3\.\.0: can only paste 128 chars into REPL

Pasting from the clipboard or middle-click (Linux) into the REPL in 3.0 only allows 128 characters. In 2.x, much larger blocks can be pasted (I couldn't get it to break).

[bronze geyser]

@stuck elbow THANKS! Brilliant. I shoulda but didn't think of that! I appreciate and am grateful for your cleverness.

[stuck elbow]

it's more like I just had all those problems before and someone told me the solution, but you are welcome

[bronze geyser]

i dunno...in some ways i love bumbling into these kind of challenges because it makes me happy knowing there are very clever people all around us.

[manic glacier]

zencuke

[adafruit/circuitpython] New comment on issue #406: release should include bin files for the uf2 based releases

I just tried the uf2 boot process again and much of the weirdness is gone. I only got a single unmount warning popup for CPLAYBOOT. None for CIRCUITPY this time. Even better CIRCUITPY was on the desktop. And the finder sidebar CIRCUITPY worked. I was able to drag the uf2 file to it. If it had been doing this Saturday I wouldn't have been fiddling with bossa. I think I rebooted the Mac in there somewhere. OSX must have been in a bad state.

[stuck elbow]

as long as they don't take too long to resolve — I just fixed a bug I was working 2 weeks on 😦

[manic glacier]

jerryneedell

[adafruit/circuitpython] New comment on issue #417: 3\.\.0: can only paste 128 chars into REPL

I'm glad you posted this - I had a cut/paste truncated recently on 3.0 and I was meaning to go back and explore it!

[fading solstice]

@tulip sleet Have you had the following problem builid cpxcleanmake?

Generating build-circuitplayground_express/genhdr/mpversion.h
GEN build-circuitplayground_express/genhdr/qstr.i.last
QSTR updated
GEN build-circuitplayground_express/genhdr/qstrdefs.generated.h
Traceback (most recent call last):
File "../../tools/mpy-tool.py", line 593, in <module>
main()
File "../../tools/mpy-tool.py", line 581, in main
raw_codes = [read_mpy(file) for file in args.files]
File "../../tools/mpy-tool.py", line 448, in read_mpy
raise Exception('incompatible .mpy version')
Exception: incompatible .mpy version
../../py/mkrules.mk:132: recipe for target 'build-circuitplayground_express/frozen_mpy.c' failed
make: *** [build-circuitplayground_express/frozen_mpy.c] Error 1
make: *** Deleting file 'build-circuitplayground_express/frozen_mpy.c'
make: *** Waiting for unfinished jobs....

[tulip sleet]

@fading solstice you need to build mpy-cross explicitly. You're using a previously built version that's old. Just cd mpy-cross;make

[fading solstice]

ok

[tulip sleet]

we should probably fix it so that it rebuilds automatically; there was a reason once upon a time...

[fading solstice]

yep, that worked!

[fading solstice]

@tulip sleet or @slender iron After building and loading CPS .uf2 onto a CPX board. the number of byte left on the drive is super low. 10K byte free. Do i need a new bootloader for CPX board?

[tulip sleet]

@fading solstice do you mean in CIRCUITPY? That size is not affected by the size of the .uf2.

or do you mean the size left as reported by the build process

[fading solstice]

Yes the CIRCUITPY: drive has total byte of 47k and 10K left free. i thought the drive used to be bigger

[tulip sleet]

For 3.0, we're not yet using the SPI flash chip on the CPX. We have to write the code to do that. So for now, the 256k flash is divided into 192k for the firmware and 64k for the filesystem. That's how it is on Gemma/Trinket M0, Feather M0 basic, etc.

(boards without SPI flash)

[fading solstice]

ok, thanks

[meager grove]

If the brown truck doesn't arrive soon...

I just want to play with CircuitPython.

[idle owl]

@glad hazel Did you get sorted with your audio recording? I have a slightly modified version of the CircuitPython code that Dan linked from GitHub that works to record a few seconds of sound and play it back using the Circuit Playground Express. I don't know whether this would help or not - you may have already found a solution to your need.

[meager grove]

I was punished for my impatience by a summons to jury duty.

[solar whale]

@tulip sleet Is there any magic to be done to test i2c for M4? I built master and created new adafruit_bus_device and adafruit_register .mpys - so far i2c.scan() is not fiinding anthing. ```>>> import board

import digitalio
import busio
import time
i2c = busio.I2C(board.SCL, board.SDA)
i2c.scan()
Traceback (most recent call last):
File "<stdin>", line 1, in <module>
RuntimeError: Function requires lock.
i2c.try_lock()
True
i2c.scan()
[]

this was on
Adafruit CircuitPython 3.0.0-alpha.0-1151-g9060df5 on 2017-11-07; Metro M4 Express with samd51j19

[tulip sleet]

@solar whale no that's exactly how I tested. Let me try again with an M4. The default I2C freq is 400kHz, not 100 KHz. I was testing with an SHT31 humidity sensor and with the accelerometer on the CPX.

[solar whale]

I am trying a BMP280

I can try it on an M0 as well - just went for broke 😉

[tulip sleet]

i did try both

[solar whale]

I need to go off for a bit - be back in an hour or so - no rush - just though I't try some tests.

[tulip sleet]

I don't have a BMP280 - should get one, since it's so popular. I have to leave in 5 mins also, back about 8:30pm

i will try once

>>> import busio
>>> i2c = busio.I2C(board.SCL, board.SDA)
>>> i2c.try_lock()
True
>>> i2c.scan()
[68]
>>>

68 ix 0x44, the SHT31

I don't have many other I2C devices except output-only ones like HTK1633, etc.

[solar whale]

I hookedi up a mcp9008and it sees it!```>>> import board

import digitalio
import busio
import time
i2c = busio.I2C(board.SCL, board.SDA)
i2c.try_lock()
True
i2c.scan()
[24]

i'll test more devices - and check my wires!

[tulip sleet]

Try i2c = busio.I2C(board.SCL, board.SDA, frequency=100000) if you think it might be too fast. I don't know what the BMP280 is spec'd for, but if it worked before on 2.x, it's probably OK.

ttyl

[solar whale]

thanks - will do

[manic glacier]

tannewt

[adafruit/circuitpython] New comment on issue #406: release should include bin files for the uf2 based releases

Cool cool! I've added a bin link to the guide here: https://learn.adafruit.com/adafruit-circuit-playground-express/circuitpython-detailed-install#flashing-with-bossac

What version of OSX are you on?

tannewt

[adafruit/circuitpython] Pull request opened: #418 atmel\-samd: Update Feather M0 Express USB PID

This makes it different from the bootloaders and Arduino.

tannewt

[adafruit/circuitpython] New comment on pull request #418: atmel\-samd: Update Feather M0 Express USB PID

This is part of the fix for #324.
