worthy swan May 8, 2023, 7:04 PM

#

I'm trying to write some code that would read a bbmodel file to extract the vertices and faces data to reconstruct the model in my own game, using my own format. I have it mostly working, but I cannot figure out the order of the vertices listed in the "faces" property. I need to re-order them so that they are ordered clock-wise.

worthy swan May 8, 2023, 10:50 PM

#

hum, I think i found the answer in the code base

#

https://github.com/JannisX11/blockbench/blob/master/js/outliner/mesh.js#L166

GitHub

blockbench/mesh.js at master · JannisX11/blockbench

Blockbench - A low poly 3D model editor. Contribute to JannisX11/blockbench development by creating an account on GitHub.

#

they seem to compute the order, instead of storing it in the file in some way

worthy swan May 9, 2023, 9:42 AM

#

It worked \o/

#

I doubt it'll ever help someone, but just in case, here's the code translated to C#, that will order the vertices in the bbmodel file properly:
