[fiery vapor]

I'll test with classic

oh my internet is being unhappy nice

[main wharf]

Next build will have FakeHDR Boost slider available under Effects, in games with originally no tonemapper that is.

[fiery vapor]

ah
anyways, adding saturate makes the effects less intense

this then becomes a problem because if you increase the intensity it starts to look buggy

so I feel like the solution would be to clamp the shader then ITM it

(using renodx's itm ability of course)

actually can renodx do ITM on a per shader basis?

I feel like I'm hallucinating

@desert herald does renodx have the ability to add ITM to select shaders?

[main wharf]

Well yea probably, wouldn't you just run ITM code in the one shader you want to ITM?

[fiery vapor]

huh, good point

anyways, while the rocket flames have been fixed, they're not very bright

made sure to only saturate 1 part of the equation instead of the entire equation

[desert herald]

Any of the videos shaders are inverse tm. But you shouldn't use it on rendered stuff. You should boost highlights instead. Inverse tm implies it was tonemapped at some point and you're reversing it

[fiery vapor]

boost highlights?

as long as it doesn't touch the tone mapping

[fiery vapor]

since letting this shader be unclamped breaks the colours

[delicate orchid]

@main wharf Shaders

[main wharf]

Another dx12 demo with seemingly same symptoms as previously, shaders replacement and sliders work but no FinalBlit shader.
Enabling proxy crashes on launch.
This time I checked log and... D3D11On12CreateDevice

Wait, maybe can force dx11 🤔

Yea that works, and everything good. Ugh.

[main wharf]

Even resources upgrades work on dx12, it's really just proxy...

Wait, what if the issue is dx12 proxy..? mmmh

nope, dx11 one also crashes.

[ebon mauve]

When using this addon in House flipper 2 it corrupts most in-game images, is that common?

[ebon mauve]

Like this (nvm the incorrect HDR colors). The image is just replaced by colored static

This also includes things like paintings in-game :(

I'd appreciate any help with this! <3

[main wharf]

Advanced settings: Move R8G8B8A8_Typeless slider to Output Size I think

Current pinned build is last one with Any size as default, from next will default to Output Size.

Some games will have to use Output Ratio/Any size to unclamp HDR range, but after a thought this should be preferable to visual artifacts in some games.

[ebon mauve]

The game uses dlss with a ratio below 100%, I should use output ratio then, right?

[main wharf]

Not necessarily. Modern upscalers are preferably ran in HDR before post-processing/going to SDR, so they ideally don't affect HDR mods.

A few rare games run them after post-processing, in which case Output size is needed indeed.

[ebon mauve]

no change on either output ratio nor output size 😔

[main wharf]

Mmmh that is odd, I'll have a look thanks

[ebon mauve]

these are the settings I use. Just for future reference, everything else is default

[main wharf]

Yea these should be fine. Might be something I changed in the addon

[ebon mauve]

Okay! I haven't tried any older versions or anything, so I have no idea if this worked in the past

[acoustic tendon]

does shadow tactics: blades of the shogun work with this?

[acoustic tendon]

oh and for some reason your wiki link is broken, needs to be https://github.com/clshortfuse/renodx/wiki/Mods#unity-engine- with that extra dash at the end

[main wharf]

Thanks updated

[main wharf]

Probably not, afaik they use custom shaders and there seemed to be quite a few.
Chances are they are shared across several Mimimi games, so a Mimimi addon may cover it

[last nexus]

@main wharf i think is time u replace discord link with snapshots some old timers struggle to link the discord button to the links

https://image.noelshack.com/fichiers/2017/20/1495181295-risitasvieux2.png

[main wharf]

Yea I've been meaning to have snapshot running already, got a bit busy with other stuff, and also instead of cleaning what's left to clean I added all the new fancy tonemapping/LUT stuff RenoDX has

[main wharf]

Oof, the texture corruption seems to occur with any addon, even with no resources upgrades (just swapchain). I tried generic one just to be sure, same thing.
There is one thing I can try, lemme see if I can find it...

Yaaaaay, this I believe, let's see

Omg. Seems to be good now..?

Yea, even with Any Size upgrades 🙈

[main wharf]

Here try this one. I just disabled one line of code as suggested by other modders, no idea what is going on.

[main wharf]

reshade::register_event<reshade::addon_event::copy_texture_region>(OnCopyTextureRegion); in swapchain.hpp seems to cause some missing/corrupted textures.
@desert herald

[desert herald]

anything in the log?

[main wharf]

Wut

03:41:08:748 [27700] | WARN  | [RenoDX] OnCopyTextureRegion(mismatched: 0x00000209f525baa0[0] (r32g32b32a32_typeless) => 0x00000209f525b520[0] (bc3_unorm_srgb))
03:41:30:542 [27700] | WARN  | [RenoDX] OnCopyTextureRegion(mismatched: 0x0000020aa96fe5a0[0] (r32g32b32a32_typeless) => 0x0000020aa96fca20[0] (bc3_unorm_srgb))
03:41:40:529 [27700] | WARN  | [RenoDX] OnCopyTextureRegion(mismatched: 0x0000020aa96fdaa0[0] (r32g32b32a32_typeless) => 0x0000020aa96fdd60[0] (bc3_unorm_srgb))

Nothing else, well this seems like the relevant part to me anyway 😅

That's with generic addon btw

All default, no upgrades but HDR10 swapchain (proxy)

Also happens without using proxy, and with scRGB (with Unity addon)

[desert herald]

i guess...

add case reshade::api::format::r32g32b32a32_typeless: in utils::resource::IsCompressible

case reshade::api::format::r32g32b32a32_uint:
case reshade::api::format::r32g32b32a32_sint:
+case reshade::api::format::r32g32b32a32_typeless:
  switch (compressed) {
    case reshade::api::format::bc2_unorm:
    case reshade::api::format::bc2_unorm_srgb:
    case reshade::api::format::bc2_typeless:
    case reshade::api::format::bc3_unorm:
    case reshade::api::format::bc3_unorm_srgb:

i'm going to guess there's some implicit type, shouldn't really be typeless

[main wharf]

Seems good with this

And no more mismatch in log!

[ebon mauve]

It worked! Thank you so much! :)

[storm vapor]

any idea why is this game washed out? (escape simulator 2)

[main wharf]

Not sure, could be:
-missing shader (lutbuilder)
-need to set game to borderless fullscreen or enable Swapchain Proxy
-FSR1 compatibility thing

[main wharf]

^
This build includes improvements to FSR1 compatibility and a warning for the 2nd point (borderless fullscreen/swapchain proxy), feel free to try that.

And if it's a missing lutbuilder, setting LUT Shaper to Vanilla should display correct output. Though HDR may not work in this case, shader would have to be added to the mod.

[storm vapor]

that build fixed it, thanks!
p.s. I had to delete my old ReShade.ini file as well

SDR / RenoDX

[main wharf]

Aye. FSR1/RCAS I think, pinned build still has old hacky workaround to make that work despite broken decompilation. That is fixed since, just gotta do some more testing to make sure I didn't break anything as there were some other significant changes.

[woven crag]

Why do so many of these unity games use FSR1?

[junior river]

easy to implement

(available via Unity)

[paper sandal]

what if the game clamped at 203 nits with this addon?

[main wharf]

Are sliders displayed and doing anything?
Could be a few things

[paper sandal]

yeah, sidera are working but peak brightness is not

the game is Olden era demo

[main wharf]

Mmh, I thought this worked 😒

Missing upgrade maybe?

[paper sandal]

tried all upgrades

[main wharf]

Is that with pinned build?

Well this, linked in pinned message*

[paper sandal]

yeah

[main wharf]

I'll have a look

[main wharf]

Please send ReShade.log, hopefully will hint at what's going on

Game isn't the brightest out there, but demo seems unclamped here

[main wharf]

Oh, is game set to (exclusive) fullscreen maybe?
Should be windowed or borderless

[paper sandal]

let me check

no, it was borderless windowed

maybe some setting is wrong in reno

[main wharf]

Seems to be missing some upgrades

[paper sandal]

what should I set

right now R11G11B10_float is any size

[main wharf]

Default settings should work, you can delete the [renodx] section in ReShade.ini file to reset it

[main wharf]

Default is just R8G8B8A8_TYPELESS enabled, this is the one needed/missing here.

[paper sandal]

hmm, seem like its works now

600-700 nit

[main wharf]

Yea game doesn't get quite bright, with camera being top-down or side (during fights), it's mainly the effects

[paper sandal]

yeah, overall it's not so bright

game brightness slider kinda helps

thanks anyway!

[glacial plank]

https://store.steampowered.com/app/2929250/over_the_hill/

Steam

over the hill

Explore, navigate, and uncover the vast wilderness in over the hill, the newest installation from the creator of art of rally. Ramble your way through varied biomes inspired by real-world locations, from valleys to mountains and everything in between.

Discover portals to travel to new areas, and complete objectives to unlock new vehicles, upg…

Release Date

To be announced

▶ Play video

[main wharf]

art of rally 2

[haughty dock]

I expected like, indie dirt rally but with an exploration focus. It's not that at all lol.

now I'm realizing I'd play a dirt rally roguelike

[fiery vapor]

currently looking at this hlsl

// ---- Created with 3Dmigoto v1.3.16 on Thu Oct 16 21:50:36 2025
Texture2D<float4> t0 : register(t0);

SamplerState s0_s : register(s0);

cbuffer cb0 : register(b0)
{
  float4 cb0[4];
}




// 3Dmigoto declarations
#define cmp -


void main(
  float4 v0 : SV_POSITION0,
  float2 v1 : TEXCOORD0,
  out float4 o0 : SV_Target0)
{
  float4 r0,r1,r2,r3,r4,r5;
  uint4 bitmask, uiDest;
  float4 fDest;

  r0.xyzw = cb0[3].xyxy * float4(-0.5,-0.5,0.5,-0.5) + v1.xyxy;
  r1.xyzw = t0.Sample(s0_s, r0.xy).xyzw;
  r0.xyzw = t0.Sample(s0_s, r0.zw).xyzw;
  r0.xyzw = r1.xyzw + r0.xyzw;
  r1.xyzw = cb0[3].xyxy * float4(-0.5,0.5,0.5,0.5) + v1.xyxy;
  r2.xyzw = t0.Sample(s0_s, r1.xy).xyzw;
  r1.xyzw = t0.Sample(s0_s, r1.zw).xyzw;
  r0.xyzw = r2.xyzw + r0.xyzw;
  r0.xyzw = r0.xyzw + r1.xyzw;
  r1.xy = -cb0[3].xy + v1.xy;
  r1.xyzw = t0.Sample(s0_s, r1.xy).xyzw;
  r2.xyzw = cb0[3].xyxy * float4(0,-1,1,-1) + v1.xyxy;
  r3.xyzw = t0.Sample(s0_s, r2.xy).xyzw;
  r2.xyzw = t0.Sample(s0_s, r2.zw).xyzw;
  r2.xyzw = r3.xyzw + r2.xyzw;
  r1.xyzw = r3.xyzw + r1.xyzw;
  r3.xyzw = t0.Sample(s0_s, v1.xy).xyzw;
  r1.xyzw = r3.xyzw + r1.xyzw;
  r4.xyzw = cb0[3].xyxy * float4(-1,0,1,0) + v1.xyxy;
  r5.xyzw = t0.Sample(s0_s, r4.xy).xyzw;
  r4.xyzw = t0.Sample(s0_s, r4.zw).xyzw;
  r1.xyzw = r5.xyzw + r1.xyzw;
  r5.xyzw = r5.xyzw + r3.xyzw;
  r1.xyzw = float4(0.03125,0.03125,0.03125,0.03125) * r1.xyzw;
  r0.xyzw = r0.xyzw * float4(0.125,0.125,0.125,0.125) + r1.xyzw;
  r1.xyzw = r4.xyzw + r2.xyzw;
  r2.xyzw = r4.xyzw + r3.xyzw;
  r1.xyzw = r1.xyzw + r3.xyzw;
  r0.xyzw = r1.xyzw * float4(0.03125,0.03125,0.03125,0.03125) + r0.xyzw;
  r1.xyzw = cb0[3].xyxy * float4(-1,1,0,1) + v1.xyxy;
  r3.xyzw = t0.Sample(s0_s, r1.zw).xyzw;
  r1.xyzw = t0.Sample(s0_s, r1.xy).xyzw;
  r4.xyzw = r5.xyzw + r3.xyzw;
  r1.xyzw = r4.xyzw + r1.xyzw;
  r0.xyzw = r1.xyzw * float4(0.03125,0.03125,0.03125,0.03125) + r0.xyzw;
  r1.xy = cb0[3].xy + v1.xy;
  r1.xyzw = t0.Sample(s0_s, r1.xy).xyzw;
  r1.xyzw = r2.xyzw + r1.xyzw;
  r1.xyzw = r1.xyzw + r3.xyzw;
  o0.xyzw = r1.xyzw * float4(0.03125,0.03125,0.03125,0.03125) + r0.xyzw;
  return;```
it's 0x644A670E from Beat Saber, looks to be a bloom shader?

-# I STILL need to setup renodx git on linux

[main wharf]

Could be yea, I've seen similar shaders involved in making the bloom texture

[woven crag]

Voosh, a completely random question you don't have to work on this but I'm just curious, have you ever looked at vampire survivors? What's the deal with that game? It is unity isn't it? Seems to be coded kinda weird. Just out of curiosity I tried putting the add-on on, but got very strange results. I don't need it to work, im just curious

I know it was some other engine before they ported the code but looking at game files it does look like unity

[lapis schooner]

if only there was a website that could tell you what game engine is used for a game

[main wharf]

Yea it seems I had a quick look, can't remember what came out from that tho.
Yea it is Unity. What do you mean by very strange results?

[lapis schooner]

Unity engine build: 6000.0.58f2

[main wharf]

Maybe you just have to set Swapchain Encoding manually to Gamma ?

[woven crag]

Well it changes to HDR output but it's all washed out and like 3/4 of Reno sliders don't even show up, very strange

You think that could help? I'll play around with it some more

Again it's no big deal game is totally fine in SDR I'm just messing with it for fun

[main wharf]

It would help the washed out I think, it's what Compatibility options are for.

[woven crag]

I think I tried some of it but I'll try some more

[main wharf]

Addon tries to detect and set that automatically so you shouldn't have to bother about it in most games.

[woven crag]

How do you find that?

[main wharf]

And regarding missing sliders, in theory this means game isn't supported, but that's an old "feature" I had in the very first preview builds as compatibility wasn't as wide back then. Could be broken.
I'll have a look at the game

[lapis schooner]

PCGamingWiki

[woven crag]

I was looking there too I couldn't find the info maybe I should check my eyes

[lapis schooner]

small note next to the engine bit 😛

[main wharf]

Iirc it doesn't have any kind of post-processing, just draws everything raw.

Game probably is unclamped with just resources upgrades

[main wharf]

Swapchain encoding should be set to gamma in this game indeed.
It seems it's only resource format that clamps the game, so technically you don't even need this addon to get HDR there, assuming there is any HDR/lighting to salvage, game looks pretty raw.

[woven crag]

Yes that would make a lot of sense it's "very raw" last I remember the way it was done is the dev coded it in the only code he knew but it ran poorly, so he hired someone to port over the game to unity and optimise it, while he continued to make new content in the original form and just have stuff ported over, no idea if it still works like that but it is indeed raw. But I just wanted to test if it's possible Reno could separate the UI and game even a raw game like this and could it even inject HDR properly.. again, just curiosity

[main wharf]

Sadly the methods I'm using in this addon so far are not any help in this game. There surely are ways to deal with that but that would be way beyond my technical ability.
REST addon should be able to separate game from UI if you use a ReShade.fx to scale brightness. I'm not too familiar with these, I think Lilium's suite may have one.

[woven crag]

Interesting. I'll try to play around with that. Always excited to just learn more

[rocky steppe]

Don’t know if this was answered yet but pcgamingwiki usually covers this

[lapis schooner]

i was being sarcastic

and clarified pcgw like a few lines below that

[rocky steppe]

Ait sorry wasn’t sure

[kind kernel]

Was getting some weird behavior in House Flipper 2 yesterday, where sometimes when I’d launch the game, the addon would show the Reinhard and Danielle tonemapping options, and other times Hermite-Spline

Forgot to save logs, but I’ll see if I can replicate it later tonight

[glacial plank]

might have 2 addons installed

or if loading through sk its loading one you have installed in an sk folder

[main wharf]

Mmh, this may change between title menu and actual in-game ?

As in it is possible options change depending the situation/game.
But same situation should have same settings after a reboot.

It doesn't change that default tonemapper should be the preferred option, even after it changes

For example Daniele and ACES are only offered if game originally uses ACES.
I know a game that uses ACES in title menu but then switches to no tonemapper in-game, could be that House Flipper does something like that or the opposite

[kind kernel]

It sounds like this could be the case, I’ll test and report back later

edit: yep it changes from Hermite-Spline in the intro loading screens and main menu to Daniele in-game.

[uneven sluice]

from SULFUR demo, is there anything useful in there?

Steam

SULFUR

Plan ahead, outsmart enemies and progress a world of dark creatures and cunning evil. Utilize playful and tactile weaponry in visceral and intense combat. Create unique builds by combining weapons, gear, tools, and enchantments to suit your playstyle. Whether you’re a gun-blazing risk-taker or a careful strategist, the choice is yours.…

Price

$18.49

Recommendations

5464

▶ Play video

[main wharf]

Cheers, was gonna have a look at that

Yup', lutbuilder is already in addon but output/uber shader is missing, I can add these.

They do have that weird SRGB encoding, seen it before but pretty rare, not sure why code is written that way:

  r0.w = cmp(0.00313080009 >= r0.x);
  r1.x = 12.9232101 * r0.x;
  r0.x = log2(abs(r0.x));
  r0.x = 0.416666657 * r0.x;
  r0.x = exp2(r0.x);
  r0.x = r0.x * 1.05499995 + -0.0549999997;
  o0.x = r0.w ? r1.x : r0.x;
  r0.x = cmp(0.00313080009 >= r0.y);
  r0.w = 12.9232101 * r0.y;
  r0.y = log2(abs(r0.y));
  r0.y = 0.416666657 * r0.y;
  r0.y = exp2(r0.y);
  r0.y = r0.y * 1.05499995 + -0.0549999997;
  o0.y = r0.x ? r0.w : r0.y;
  r0.x = cmp(0.00313080009 >= r0.z);
  r0.y = 12.9232101 * r0.z;
  r0.z = log2(abs(r0.z));
  r0.z = 0.416666657 * r0.z;
  r0.z = exp2(r0.z);
  r0.z = r0.z * 1.05499995 + -0.0549999997;
  o0.z = r0.x ? r0.y : r0.z;

Anyway just something I noticed, not an issue afaik it does the same thing as written the more usual way

[main wharf]

@keen lintel try this maybe.
I don't know about the upgrades, the very most common is just the one enabled by default.
If limited to bt709 even with saturation maxed up, then likely R11G11B10_float should unclamp bt2020 colors.

Game looks very flat, even fire/shots vfx.
Addon has an AutoHDR slider under Effects thanks to @haughty dock, may be helpful there.

Like, I don't think this is clipping or anything, just looks like firing shotgun is a paint blob

[keen lintel]

yeah i would assume most things to not get affected but i would expect things like these portals here to be affeccted or something

[main wharf]

Oof. Does it go above 203 if you increase Highlights, Exposure or FakeHDR effect ?

[keen lintel]

peak brightness slider does not affect it

[main wharf]

Well yea, it would only if there is something that reaches peak

[keen lintel]

ah but highlight does affect it along with skin

[main wharf]

I see. I'll download demo check if maybe they clip before post-processing and there is some more to salvage.

[main wharf]

I meant "FakeHDR Boost" in Effects btw, not AutoHDR slider sorry.
This is specifically meant for games with low dynamic range

[keen lintel]

with these settings in this area it seems not so terrible. The moon is ~750 nits while hands are not as bright around 250

[pulsar plinth]

Tried with Crime Scene Cleaner and it breaks a few core game mechanics like footprints and settings objects back into place. Anyone else tested/have settings for that game that work?

[main wharf]

Assuming these things "overlay" on top of render, originally after going to SDR, it could be that shaders break with HDR and need to be manually fixed.

I'll have a look at https://store.steampowered.com/app/2540100/Crime_Scene_Cleaner_Prologue/, seems to have been updated this year, hopefully should use same shaders as the game

[warm geyser]

@main wharf probably [flatten] in the original hlsl code

[flatten] compiles code as bools

and 3dm's decompiler uses cmp() for bools

[junior river]

https://store.steampowered.com/app/2432860/MENACE/

Steam

MENACE

Command a strike force of marines, mercenaries, and criminals in a distant system, cut off from the Core Worlds. At the lawless frontier, the Wayback system is controlled by pirate warlords, questionable corporations, and fractured planetary governments who struggle for a new order. Though you initially lead your strike force of marines from aboa…

Release Date

Feb 5, 2026

▶ Play video

By the devs that made Battle Brothers and has a demo

seems like a decent xcom like

DX12 noooo

[main wharf]

Nah not necessarily

That folder is there in a bunch of games, there's just one .dll inside and games still run dx11

[junior river]

Addon works

[main wharf]

Also regarding this, @crimson spear had a look at PEAK, one of the few dx12 unity games that was requested, and it's also d3d11on12

[junior river]

ahhh

Why does this happen

I'll ask Sac about this, maybe he knows

[main wharf]

Lemme see... I found an article regarding Unity dx12 support and it may have just been added quite recently

[junior river]

https://www.youtube.com/watch?v=oHY3n-JQCuU trailer by the guy who did Astartes

Grimdark coded

[main wharf]

As of Unity 6.1, DirectX 12 is now set as the default graphics API for new projects.
Article is from April this year, maybe from next year and beyond we get real dx12 Unity games

[junior river]

we'll see

I still want to solve Endless Space 2

and get a working addon

[main wharf]

There may already be some out there, but I couldn't find any proper documentation. I'd expect some quite niche simple "test" game maybe

Surely would be nice to find a solution for that d3d11on12 thing

Oh

I wonder if device proxy would help here

Since basically, everything works except swapchain proxy

[main wharf]

Btw I ended up realizing too late demo has a Final/Swapchain Blit shader

So maybe you can do a mod without using proxy..?

From experience, doing everything else the "dx11" way would work. As in shaders are SM4/SM5 anyway, and I didn't need to do the dx12 cbuffers specifics either, it was just working.

^ this is in fact d3d11on12, I didn't know at the time before @junior river had a look at Endless Space 2 and figured that out from a quick look in log

[junior river]

Righjt, so make a custom addon without the proxy

I'll have a look

[main wharf]

I think 🤷

[main wharf]

Maybe proxy can work with some tweaks, but I wouldn't know about that.
Maybe device proxy can help? Again just a thought, I have no idea, but since this d3d11on12 thing in log is a device iirc...

[main wharf]

Another thing is to do the dual shaders like in UE addon maybe. @warm geyser suggested this and it would do stuff, lemme try to find messages.

I guess that's just to rename shaders with ps_5_x

But then this has other implications, can't use Callback which this addon relies on so I gave up

If you don't need Shader Callbacks then maybe you can do that

This and renaming shaders to ps_5_x I believe

Ah, with ps_5_x shaders and the above, it was replacing shaders with proxy working, but no cbuffers, which could have been skill issue, I have low xp with dx12 and I never had to do this shader model upgrade thing

[desert herald]

5.x means 5.0 for dx11 and 5.1 for dx12

shared.h should have the dual setup so cb13 on dx11 and space50 on dx12

[main wharf]

Could have been what was missing, seems I didn't keep addon source so can't check.
This d3d11on12 situation is weird tho, what does happen to cbuffers in that case..?

Or maybe it doesn't matter..? I dunno really, this is obscure

[warm geyser]

yea for dx12 you need 5_1

and then you need to change shared.h to have the if statement (if sm 5 or lower X, if 5_1 and higher, Y)

you also need 2 proxy shaders

      renodx::mods::swapchain::swap_chain_proxy_shaders = {
          {
              reshade::api::device_api::d3d11,
              {
                  .vertex_shader = __swap_chain_proxy_vertex_shader_dx11,
                  .pixel_shader = __swap_chain_proxy_pixel_shader_dx11,
              },
          },
          {
              reshade::api::device_api::d3d12,
              {
                  .vertex_shader = __swap_chain_proxy_vertex_shader_dx12,
                  .pixel_shader = __swap_chain_proxy_pixel_shader_dx12,
              },
          },
      };

so one compiles as 5_0 and the other as 5_1

and the files should be named swap_chain_proxy_pixel_shader.ps_5_x.hlsl and swap_chain_proxy_vertex_shader.vs_5_x.hlsl

[warm geyser]

I was looking into shadercallback that supports 5_x, it should be doable

just add another paramater and make a new function

[main wharf]

But it's not really dx12, Forge found out Endless Space 2 and surely some other Unity games actually use d3d11on12

[warm geyser]

you sure its not just the steam overlay

or store overlays

[main wharf]

I had a demo installed, lemme check

[warm geyser]

the only time I've seen 11on12 injected is for overlays

[main wharf]

But no I don't have any overlay enabled never ever so I doubt it

[warm geyser]

MAYBE movies

[main wharf]

I dunno, it shows this in log:

| INFO  | Redirecting D3D11On12CreateDevice(pDevice = 0000020D648D1D70, Flags = 0, pFeatureLevels = 0000000000000000, FeatureLevels = 0, ppCommandQueues = 0000009D218EEAB0, NumQueues = 1, NodeMask = 0, ppDevice = 0000009D218EEAA0, ppImmediateContext = 0000000000000000, pChosenFeatureLevel = 0000000000000000) ...

[warm geyser]

does the game have like a launcher

[main wharf]

Ritsu saw that in PEAK, Forge in Endless Space 2 and I did in this:
https://store.steampowered.com/app/4002340/Hell_Maiden_Demo/

No launcher in Hell Maiden or Endless Space demo, I never got my hands on PEAK

[warm geyser]

weird

[main wharf]

yea I dunno

[warm geyser]

that game aside

no reason not to add dx12 support

sure the shader # will double, and compile times will be 2x as long

[main wharf]

But I can't test it

😒

Will try to find some real dx12 unity game/demo

It has 3 devices

[main wharf]

That's Hell Maiden demo

[main wharf]

Seems to be always like this, in menu and in-game.

Only d3d12 device shows something in Snapshot... Not sure what else to check for

Maybe renderdoc?

Or Pix I guess

[main wharf]

Any more details about this issue? What happens exactly?
I assume it has to do with the "Cleaner Sense" (binded to Q by default), which looks the same to me with or without the addon.

[main wharf]

Alright, maybe we have a snapshot very soon...

[dense thorn]

Oh I played this demo a few weeks ago, I didn’t even know it was unity

Played it in sdr because of that

Gotta say I wasn’t too impressed with the game… my favorite is HOMM V

[main wharf]

We liiiiiiiiiiiiiiiive!
64-bit: http://notvoosh.github.io/renodx-unity/renodx-unityengine.addon64
32-bit: http://notvoosh.github.io/renodx-unity/renodx-unityengine.addon32

Changes from previously pinned builds:

• added warning when Swapchain Proxy is required
• added warning when output shader is missing
• changed Unity's dithering to be done in PQ bt2020 instead of SRGB to match HDR output
• fixed FSR1/RCAS broken decompilation, removed previous workaround and improved RCAS behavior in HDR
• improved user (=baked) LUTs handling by adding max channel and gamut compression
• added HDR10 swapchain toggle
• added FakeHDR Boost slider (under Effects, currently only available in games with no tonemapper originally), thanks @haughty dock
• changed default upgrade (rgba8_typeless) to Output Size
• various other fixes
• probably some more I forgot about

[main wharf]

To do...

• code cleaning and removing useless shaders
• add shaders dumping (?)
• swapchain max_channel and gamut compression
• test dx12 support
• internal LUT resizing
• add curves scaling (internal LUT)
• attempt to fix pillar of eternity 2 bloom
• find bugs
• improve stuff

[kind kernel]

Anything here for SIGNALIS?

[main wharf]

Ugh, afaik this one game is annoying.
Custom shaders and some stuff breaks with resources upgrades

[pulsar plinth]

Sure thing. One of the issues is that you will give off bloody footprints even when not stepping in any blood. Its like the area for stepping in it is largely expanded. The second problem was that I cant correct the positions of items after cleaning them. Didn't notice any issues with Cleaner Sense. Thank you for looking into it.

[graceful wasp]

does lethal company work well hm?

I cant see it in the computability list on git

[void hollow]

Seems to have a lot of custom crt shaders and such :/

[dense thorn]

i wish, prolly need dedicated mod tho

🥀

[woven crag]

does this mean we should just always use the newest version for all games? what about specific fixes you did for cases like Starsand Island?

[main wharf]

Always use latest yea, addon includes some game specific shaders/fixes.

I'd suggest to store addon file in one common folder, then either tell ReShade to load addon from that folder in every Unity game or use symlink.
That way you only ever have to update one file in one same folder.

[main eagle]

Hey all, been trying to get the unity mod to work for Steam Warhammer 40,000 Rogue Trader. I've downloaded the ReShade from the wiki (https://reshade.me/downloads/ReShade_Setup_6.5.1_Addon.exe), I've put over the snapshot of the latest unity mod/addon. When I try to launch the game I get the loading bar but then it crashes. If I remove the unity mod, it works. I've also tried the latest version of reshade and same issue. I've added -dx11 to steam launch parameters, I've tried launching it without -dx11.

Nothing seems to be work. Wondering if I'm skipping a step or something wrong?

[woven crag]

yeah i keep storing all previous and special versions in seperate folders

oh. that seems much more advanced automation i never thought of something like that i do every game by hand

[main eagle]

Hmmm. 6.5.1?

I know theres a renodx reshade going around so wasnt sure if I should be using that one

[main wharf]

I think probably Exclusive Fullscreen mode ? Prefer Windowed or Borderless window

[main eagle]

Aaah okay I'll try that. thank you.

[main wharf]

It is in the additional notes at the top since this applies pretty much to every game.

Even if not using ReShade/RenoDX, I believe Borderless should be preferred, for performance and latency purpose. I don't think I ever encountered a game where Exclusive Fullscreen is preferable.

Oh, I should add instructions to pinned message in this thread...

[dense thorn]

borderless supremacy

[main eagle]

Advice worked great! I’ll keep that in mind for the future, thank you again everyone.

[main wharf]

By the way, I believe launch argument to force DirectX 11 in Unity games is the following, on Windows anyway:
-force-d3d11

Just for information really, since Rogue Trader already uses dx11 I doubt this changes anything here

[kind kernel]

https://schinagl.priv.at/nt/hardlinkshellext/linkshellextension.html this shell extension makes symlinking super easy

[woven crag]

try enabling windows autohdr that fixed it for me when I got this exact same error

i know it doesn't make any sense but it fixed it for me (you can turn it off later)

also as was suggested try playing around with windowed/fs modes, and also reinstalling different version of reshade and mods

i've seen that red exclamation mark before and i ussually mess around with all that until it works and last time i tried i broke the game; it completely refused to launch until i enabled autohdr+reshade+addons then it somehow worked

turned off autohdr after that it just had to go trough initial phase of just launching the damn thing

very weird makes no sense but try that

[main wharf]

It was solved, Exclusive fullscreen was the culprit

-# (it often is)

I wonder if in your case enabling AutoHDR somehow forced game to use Borderless..?

[kind kernel]

AutoHDR requires full screen optimizations so it might be Windows forcing borderless in that case

[woven crag]

must have been something like that

haha yeah sorry i didn't read further i wanted to help first

[main wharf]

All good

[main wharf]

Thanks for the dump! Added a couple shaders in this, lemme know how it goes. May not be that custom, some heavy use of Unity's lens distortion effect that I could definitely see sold as "CRT effect", along CA and bloom.
Will push to github later

AAAAAAH. Found a typo, user LUTs are broken in current git build

      float3 encoded = renodx::color::gamma::EncodeSafe(color_output.rgb, encode_gamma);
      float3 decompressed = renodx::color::correct::GamutDecompress(color_output.rgb, gamut_compression_scale);

What happens to encoded..? Spoiler: ||nothing||

[void hollow]

Seems to work, game isn't very flashy but didnt notice any major issues, thanks :)

[main wharf]

Yea it does look a bit dim on Steam page screenshots. Maybe some effects like fire or street lights may leave SDR range.

Addon now has a FakeHDR slider in Effects, could come in handy. And Color Grading uses the latest RenoDX offers, afaik Shadows and Highlights sliders were recently updated

[desert herald]

i wonder if these a clang about unused variables

[main wharf]

Mmmh, it is possible I missed a warning, I really gotta pay more attention to these

[main wharf]

No idea, I don't think game was ever mentionned here. Feel free to try, compatibility list isn't complete, games are added as people try and find out

[graceful wasp]

Ah alr

[main wharf]

Thanks. I'm not sure these are related to RenoDX, addon really only changes visuals and shouldn't change anything gameplay-wise.
Is the issue consistent? Any particular steps to reproduce it? If it only happened once, maybe it was just a game bug

[pulsar plinth]

Yeah its reproducable for me. My system is well maintained so I can largely rule that out too. Tried a bunch of different troubleshooting like verifying game files, local install, injecting Reshade with Special K, early/lazy addon load, etc etc. Same bug. Works fine vanilla or with Special K but with Reno I get those bugs.

[main wharf]

Mmh, maybe I'm misunderstanding the issue or it does not occur in the "Prologue" version of the game.
Could you share ReShade.log (after having triggered the issue) ?

[lapis schooner]

is there a auto dump shaders option yet?

[main wharf]

Nope. Still can use devkit for that purpose though

[keen lintel]

BALL x PIT Demo, seems to be working very well with just R8G8B8A8_TYPLESS upgrade. don't know if i should be doing anything else

[manic gale]

Fyi if you want a real one, Zenless Zone Zero has a real D3D12 backend and it's f2p.

Though it has some custom mihoyo shenanigans in there

I have a mod for it working at: https://github.com/MapleHinata/renodx/tree/zenless-zone-zero/src/games/zenless-zone-zero

I don't know how useful this is for you but

There was a lot of jank i never managed to fix with the d3d12 version but it mostly works

The two big remaining issues are that the game crashes if you have DLSS on (this can be worked around with OptiScaler for some reason?)

And r11g11b10_float upgrades explode the game in d3d12

(works fine in d3d11 for some reason)

The game is using URP, Unity 2019.4

[main wharf]

Nice thanks, will have a look when I get the chance

[main wharf]

d3d11on12 💀💀💀

-# not ZZZ, was looking for some smaller sized game

Uhm

LMFAOOOOOOOOO

On top of previous behavior, I realized adding this caused shader replacement to stop working:

renodx::mods::shader::expected_constant_buffer_space = 50;
renodx::mods::swapchain::expected_constant_buffer_space = 50;

While also allowing proxy to work. Solution, just keep renodx::mods::swapchain one it seems...

Everything seems to work now. I had tried everything and it was just:
renodx::mods::swapchain::expected_constant_buffer_space = 50;

Mmh, but will it break proxy in dx11 games

I guess it shouldn't

Why are shaders even affected by this 50 thing when they're sm4/sm5

Unless this renodx::mods:: thing doesn't "trigger" on shader model but API

Sigh, it's only this one game it seems

[desert herald]

expected_constant_buffer_space is supposed to be for DX12 and Vulkan only. DX11 has no spaces, but could mess up some pipeline/shader stuff i guess

[main wharf]

@junior river Do you still have Endless Legend 2? If you don't mind trying this pretty please, hopefully swapchain proxy should not crash the game anymore and everything works.
Whether it does or not ReShade.log is very welcome (for research purpose)

[main wharf]

I just added this swapchain dx12 thing ^
but without the other one (renodx::mods::shader)

[desert herald]

i guarded against it affecting anything except vulkan and dx12

so it's a safe thing to leave at 50 now

[junior river]

Wait did you add the fix to the wrong game?

I have Endless Space 2, Legend 2 is a newer game

[main wharf]

Oooh, I got confused I thought you tried to mod Legend 2.

[junior river]

[main wharf]

Oh, but Endless Space 2 isn't dx12 or d3d11on12, is it ?

[main wharf]

Could this be caused by exclusive fullscreen? Though yea I guess it doesn't really matter since it's not the game I thought, sorry

[junior river]

devkit reports d3d11 and the game uses CS_5 and PS_4 🤷‍♂️

So this whole time you confused it for Legends 2?

[main wharf]

Yes

[junior river]

Damn so the thing might not even be dx11on12

just some other bs issue

[main wharf]

Uhm

[junior river]

I remembered this

[main wharf]

Wait, there's also d3d10 in there..?

I mean, I don't speak log fluently so might be nothing, but it looks messy

[junior river]

I loaded SK in case it fixes the issue

it did

but the screen is black with reno

time to see if display commander fixes it

Nope

So SK fixes something

but combining it with reno causes problems

[main wharf]

Mmh, black screen is weird, missing upgrade? Log would tell maybe.

Titanfall 2 black screens in title menu but everything works once in-game. I think something similar happens in one unity game with this addon...

[junior river]

So the game is fully just clamped by r8g8b8_unorm

SK byitself can unclamp if set to scRGB

but HDR10 gives me a black screen (except UI shows)

scRGB on the other hand breaks the screen half shown / half black

[pulsar plinth]

Have you tried UnsafeAddOns=true in the games SpecialK.ini?

[junior river]

yep

The game is just borked

half the screen gets utterly borked

[fiery vapor]

feeling bored, might try umamusume with renodx again

while I'm at it, I might try to find what shaders are making the UI brightness affect the 3D render

the naming
https://tenor.com/view/umamusume-uma-musume-its-peak-its-so-peak-umazing-gif-3466440184519113997

this isn't the shader that's causing the issues, but I just wanted to dump it because it's a bloom shader

ok it looks like the blur shader has already been upgraded

we have a copy shader

here is the copy shader

[main wharf]

Seems to be UI? Not sure what I'm supposed to do with that

[main wharf]

aw nvm, this maybe

I had tried to have a look at that game but I'm not even sure I got to the actual gameplay part

[fiery vapor]

any part that has a 3D character is technically the "gameplay" part

[ebon stream]

a bit hard to get a screenshot of this (see white line in top of image), but in tainted grail fall of avalon, the borders freak out and flicker at max nits when youre within the menhir

especially bad within act 2 cuanatch at night

same issue with unity engine addon and the the specific tainted grail addon

here we go

[bronze galleon]

Anyone tried Syberia Remastered ?

[lapis schooner]

@main wharf some shaders for you, Egging On game

not tried unity engine in it tbf, it's dx11

[main wharf]

I noticed this issue, came with a game update. I thought I fixed it though, iirc it is some UI

Oh, can you maybe try to set UI behaviour to clamp ?

Maybe this is what fixed it and I forgot to make it automatic for the game

Iirc it was some UI shader going mad with swapchain upgrade, I'll have a look after I update game

Oh thought there was an update and there was none, lemme check

[lapis schooner]

just tried it unity engine in game and it does seem to work

[main wharf]

In case of missing output shader, addon displays a red warning in its UI (things would look weird enough that you should notice anyway)

[lapis schooner]

auto shader dump would be 👌

[fiery vapor]

oh this is new... disabling DoF in touhou dystopian causes the view to clamp

I'll have to dump whatever is causing that to happen...

[main wharf]

Yea iirc they use Beautify plugin

My bad I should have checked game settings I guess

[fiery vapor]

ah dw about it 😅
I've only now just started to try and figure out how to make the gameplay smooth for me

[main wharf]

Well I probably did, but with in mind the usual Unity post-processing stuff that changes shaders, so Bloom, Lens Dirt, Vignette, Film Grain, AA...

DoF doesn't usually cause permutation, with Unity's own post-processing that is.

But with Beautify plugin it does

v 1.0.2:

Added a Depth of Field toggle.

Ah, it wasn't there. Did they update demo

Nope

[fiery vapor]

-# I think you should buy the full game it's that good

[main wharf]

Maybe some day, but I already have a quite huge backlog of games I already own sooooooo

Also not much time to play these days, and I'm about to move/relocate. Might not even have any HDR screen for a bit until I settle

[fiery vapor]

ah

as much as I'd recommend the steam deck, the game doesn't perform that well on the steam deck sadly 😔

[fiery vapor]

damn I'm gonna have to dump that dofless shader because disabling dof makes the game feel so much smoother

[main wharf]

It should be a Beautify one, quite long, probably last of multiple Beautify shaders

[fiery vapor]

👍

do we still need to upgrade R11G11B10_FLOAT with Touhou Dystopian?

I think I only recommended it because I didn't realise a beautify shader was clamping the nits

[main wharf]

Iirc it uses ACES approximation the same as Beat Saber so you may recognize those few lines inside that Beautify shader

[main wharf]

I think so yea.
r11g11b10_float format doesn't really clamp highlights, it's only for bt2020 colors

It may also help with banding

As in, upgrading it may help with banding

[fiery vapor]

I do notice that the game mostly sticks to BT 709, but when cranking saturation to max a tiny bit of the colours go to DCI-P3

[main wharf]

And maybe improve color balance or something

[main wharf]

Look at the CIE graph, not numbers

[fiery vapor]

ah

I'll have to move the CIE graph to the right

wait

I can't move to the right can't I

[main wharf]

With very small values there can be rounding errors and such, causing analysis to display a few 0.00 something % but CIE graph when increasing saturation is more obvious when colors hit the bt709 wall

[fiery vapor]

alright yep you're right it's hitting the walls

alright I see that there's a shader that manages the chromatic aberration that isn't upgraded

[main wharf]

How do you mean? I thought I added a slider for that

[fiery vapor]

when dof is disabled

it's a separate shader that gets unloaded when DoF is enabled

is it normal for games to have a separate shader that's just a clone of another shader but with an effect removed?

[main wharf]

Yea that's what I call shader permutations, no idea if that term is like... official or something

[fiery vapor]

do you want me to decompile it

[main wharf]

I can do that ty

[main wharf]

So that one is the CA I see

[fiery vapor]

ah, uhhh
CA without DoF enabled

I need to remember how I found the other shader

it seems that the tab with the floppy disk icon is not letting me go to the draws that use the shader

so I can't quick find the draws

maybe I'll have to update devkit incase it was a bug that has been fixed

[main wharf]

There is nothing to upgrade there btw. It's just adding the slider really

[fiery vapor]

ok its this one right?

I've actually got no idea what aces approx looks like because I haven't figured out how to connect VSCodium to a docker to build renodx 😓

or it could be this one

[main wharf]

Wait I'm sorry

[main wharf]

This is all

[fiery vapor]

ah

[main wharf]

I don't know why I remembered CA was its own shader for some reason

I had not scrolled down enough lmfao

[fiery vapor]

I'll also have to get the perfect dodge / ultimate visual shader

[main wharf]

Is that different from the LUT one I had added?

[fiery vapor]

hmm

I think so?

[main wharf]

master spark

[fiery vapor]

yeah

master spark uses the dodge

hold on lemme properly explain

the perfect dodge and the character's ultimates share the same shader

master spark is Marisa's ultimate

alright found the dash / ult shader

[main wharf]

Do you have the reflection/name ?

[main wharf]

Oh I remember, the other one was SC Post Effects LUT or something

Thanks

[main wharf]

I'm not sure what code clamps in here though... 🤔

[fiery vapor]

all I know is that for some reason disabling this shader de-blurs the ult move that marisa does

unless it's the wrong shader

yeah it might be the wrong shader

no wait it seems to be the right one

@main wharf it might be harder for me to figure out until rendodx unity gets updated

[main wharf]

What update do you need

[fiery vapor]

this shader

[fiery vapor]

cheers

[main wharf]

Hope I didn't bork anything

[fiery vapor]

ok so turns out that was the only shader that needed upgrading

ok there is some mild borkness

should be fixable though, I guess now that we know that only 1 shader needs to be upgraded

[main wharf]

Yea will double check what I did there, went a bit fast over it copy-pasting what I had in other shader (dof enabled)

For test purpose that was enough, will clean and push to github

[fiery vapor]

just for the hell of it I might try cloverpit with renodx

a game that really does not need HDR

(unless the HDR makes the game more addictive, therefore adding to the slot machine gameplay)

oh this is a d3d12 game

well, it still uses shader model 4

[main wharf]

May be using d3d11on12 or something...

[fiery vapor]

yeah there's a D3D12 folder

[main wharf]

I recently pushed a change to make proxy compatible with this

[fiery vapor]

oh I just forced Dx11

[main wharf]

It doesn't seem to work in every game, but proxy is basically the only thing that seems to miss in the few "dx12" games I tried, since shaders/sliders already work

[fiery vapor]

but I might try dx12

oh

nvm it launches dx11 by default

dx12 must be optional

alright this is gonna be one of those games where you gotta reaallllyyy think about what to upgrade because of how simplistic it is

[main wharf]

Oh, this is in a bunch of dx11 games yea, I dunno, don't trust this folder to guess game's API I guess

[fiery vapor]

surprisingly some parts of the unity addon upgrade some of the shaders in this

however it does hard clamp at 202

probably from the really subtle CRT shader

and ps1 styled post processing

[main wharf]

Yea or render could be down sampled or something

[fiery vapor]

Hidden/PS1PostProcessing

Custom/CustomCrtShader

[main wharf]

I've seen a few "old-school" games render at a smaller resolution so maybe it needs "Any Size" upgrade, likely on rgba8_typeless

[fiery vapor]

looks to be natively sampled to me, with an option in the menu to downsample it

[main wharf]

Oh yea this one would clamp indeed I think

Goes into srgb to do some stuff, then saturate() and back to linear at the end

[main wharf]

Yea I dunno, maybe I'm biased because I'm so used to it but using devkit doesn't seem that bad to me.
I mentionned already I can't just copy UE addon lutbuilder auto dump as Unity and Unity addon are more complex and require more work.
For a while now, it is mostly output shaders that are missing/added to the mod, not lutbuilders.

[fiery vapor]

auto dump isn't as good as you think 😬

oh I was just about to say what voosh already said

[lapis schooner]

sure it is, anything that allows me to be lazy and not have to think about loading renodx devkit is good 🙂

[fiery vapor]

it's gonna dump everything lol

even the material shaders

[lapis schooner]

well it can be made to only dump what's needed 😉

like the unreal lut_builder_new type stuff

[fiery vapor]

https://tenor.com/view/how-do-we-tell-them-mr-krabs-squidward-spongebob-meme-gif-794152241042277714

[lapis schooner]

[fiery vapor]

uhhh
people create custom lut builder shaders with custom names
unity lets you use custom shaders
1 man's lut_builder may be another man's shitty_ass_colorinator

alright still messing around with umamusme
it has a DoF shader

Gallop/ImageEffects/Rich/PostDofBloom_Rich

alright so the UI thing...
what's weird is that the brightness is only affected when you lower the UI brightness, not raise

oh

there's also chromatic abberation awesome

Gallop/ImageEffects/ChromaticAberration

Gallop/ImageEffects/FlipScreen

only other one I can think of that could be causing the weird UI problem is
Gallop/UI/SimpleCopy

[fiery vapor]

it could be misnamed shader tho

[main wharf]

Game is f2p, I'll have a look again eventually, but I already did and iirc couldn't figure what was going on

[acoustic tendon]

i cant change those two

the scaling offset and tomemap offest cant be moved from 0, what am i doing wrong

uhhhh, for some reason it started working

after alt tabbing i think

[main wharf]

Sliders are locked if corresponding functionnality is not available, which I thought was a good idea.
I'd have to check the game, it is possible offsets only unlock after game is fully booted and are not available in title menu or something.
Once set, they are still saved and will be active whenever available so the slider lock won't mess with that. Also unlike resources upgrades, these don't require a game reboot to take effect.

[acoustic tendon]

Yeah that may have been it, loading into the full game vs being on just the main menu

yep, retested, that was it

[main wharf]

Iirc sliders should say something like "locked if unavailable" on hover. I'll try to rephrase these descriptions to make things a bit clearer

Or maybe I'll just unlock them all the time if I can find another way to indicate their availability

I feel it's important for user to know slider is not gonna do anything to avoid confusion/losing time messing with not-working sliders

But then I understand that in this case, it's a bit dumb having to fully boot the game to set these, even if it's only "set once and forget"

Ultimately, these can be automated by adding a rule for the game like there are already a few

I mean these games default settings.
Similar to Unreal Engine addon, adding a rule for pillars of eternity exe would set everything automatically on first boot (swapchain proxy and encoding, offsets, and any extra resource upgrade required)

[graceful wasp]

how do i confirm whether this addon is working properly hm

in lethal

Using liliums shader?

[main wharf]

Uh, if there's HDR and things don't look broken, I'd say it works.
Lilium's analysis shader is a great help indeed especially with stuff like bt709 clamp (usually solved by upgrading r11g11b10_float)

Using sliders is another way to find out. If they all work properly and as expected, it's usually a good sign

[graceful wasp]

alr

[graceful wasp]

I ll try n lyk

does this adon support reshade 6.5.1?

I dont want to use 6.6.X

[main wharf]

Uhm, no idea

Can always try

[graceful wasp]

my effects die but the sliders seem to work

[main wharf]

If it doesn't work ReShade.log will say that addon was not loaded because addon API version or something

[main wharf]

Effects also have ReShade version requirement. You can hover the effect that failed to compile in the list to see what the issue is

[graceful wasp]

oh

[graceful wasp]

Okay wait

[main wharf]

Oof, dunno about this.

Unless maybe if you're using REST ?

I think having REST enabled can cause some effects to fail compilation

[graceful wasp]

wats REST an effect?

[main wharf]

Well, enabled and active with a toggle group enabled

It's an addon

[graceful wasp]

iam injecting reshade addon through SK atm

[main wharf]

ReshadeEffectShaderToggler

[graceful wasp]

but everything else seems to be fine

[main wharf]

Ah

I know

Try to disable SpecialK addon in ReShade

[graceful wasp]

wouldnt tht result in SK not injecting reshade hm?

[main wharf]

No

I'm not sure what the addon does to be honest

But afaik it's not needed for SK to inject ReShade

[graceful wasp]

ok let me try

da addon didnt get injected after I unticked sk

[main wharf]

RenoDX you mean?

Oh, I guess I never used SK that way...

I just know that unless I disable SK addon in ReShade, I can't get Lilium's Analysis to work

There is https://github.com/clshortfuse/renodx/wiki/Guide:-Using-Special-K-with-RenoDX
Maybe try a different method or something I'm not sure really

[graceful wasp]

Hm ic

I can try injecting ReShade locally but it might not work cos iam using mods

[pulsar plinth]

Anyone else not able to download the pinned snapshot build?

[main wharf]

Seems to work here

What's the issue?

[woven crag]

Btw most games I tried recently work perfectly with latest builds, some need some messing around but eventually I got it all working.

You should totally try the game Slots & Daggers if you have a high nit display, the specular effect on 2000 nits hits insane in this game, it's so perfect for shiny slot machine effects, the dev probably never intended/expected to look this good in HDR

It should look good without clipping on HDR1000 mode monitors too because most of the game's UI is very dark and highlights really pop so you won't be hitting the ABL/outside EOTF curve it's perfect for it

[haughty dock]

tried using the addon in lumines, doesn't seem to work fully

lemme see if I can figure out the missing shader

[main wharf]

Sure that's Unity ? Doesn't look like it from game files list

[haughty dock]

yeah

seems like a missing lutbuilder I'd guess

[main wharf]

Oh right, I wasn't looking at "Arise" one, just Lumines

[haughty dock]

oh, yeah sorry lol

[main wharf]

All good ^.^'

Never heard of that so I got curious

[haughty dock]

this is from the same devs as tetris effect

yep, missing lutbuilder

from the devs for the game

if they're responsive on era, I may try to point them toward hdr den in the event that they change their mind

[haughty dock]

to save you a smidge of trouble lol

[main wharf]

Can give that a try

ACES

[haughty dock]

works great

[haughty dock]

@main wharf did you push a commit with this lutbuilder btw?

I want to mention that it works in this era thread

[main wharf]

Will do in a bit

[haughty dock]

game also benefits from 11 bit upgrades

would you want the application name for preconfigured settings or anything?

[main wharf]

I usually get these from steamdb, but I don't know if I wanna add all games

Well I don't know if it has any impact apart from making addon.cpp huge

If not I guess I don't mind

[haughty dock]

so if I'm at the mode selection screen in this, it shows renodrt danielle/reinhard, and when I get to the game it shows hermite spline

[main wharf]

I guess they don't use ACES in-game, only in menu..? Or you've found a bug

[haughty dock]

adding this one lutbuilder made the menu HDR as well, so it should be the same one

yeah it is

[main wharf]

It's same lutbuilder in-game?

[haughty dock]

yeah

here are the other shaders in the snapshot

[main wharf]

I don't see lutbuilder in this

[haughty dock]

I cut it off

[main wharf]

The one you sent I mean

0x1F679F37

[haughty dock]

oh, it is a different lutbuilder here

[main wharf]

Yea they're probably not always using ACES

[main wharf]

No tonemap in this one, just grading

Hence Hermite Spline I guess

[haughty dock]

a bit awkward for picking settings

[main wharf]

Thooo, they could be using a plugin or something for tonemapping here. It would be clamped

[haughty dock]

why do you use different tonemappers?

[main wharf]

Because game uses different tonemapper..?

ACES makes no sense imo if game doesn't use ACES

[haughty dock]

sorry I meant like, different renodrt configurations

[main wharf]

So it's not offered unless game uses ACES

Question is why game sometimes tonemaps and sometimes just clips

[haughty dock]

yeah lol

[main wharf]

Especially with a very not neutral tonemapper

Honestly I feel ACES is legit just picked as a color grading template somehow

Like one would pick some premade LUT or something

[haughty dock]

I guess the part of the game where it goes away makes a little bit of sense

it is a bit weird that reinhard becomes dice in a situation like this though, but I doubt this comes up much

[main wharf]

Yea that's arbitrary

I mean, I see no reason to change tonemapper in the first place

Default one will always fit whatever situation presents

Well, in theory anyway

[haughty dock]

yeah it works fine, literally only noticed cause I was looking at the menu

[main wharf]

I get your feedback tho. Didn't really face that situation as I just leave default tonemapper anyway, and would adjust grading if I need which should be consistent even when tonemapper changes

I can think of a couple ways to deal with that:

• duplicate sliders
• store sliders value when tonemapper changes, revert when it changes back or something

Duplicate sliders is lazy af but at least I should be able to make that work, which isn't sure for the other

[haughty dock]

it's really cool how robust this addon is btw

first chance I've had to really try it out

[main wharf]

Until it breaks xD

[haughty dock]

lol well

[main wharf]

Pushed, should be done in an hour or so

[woven crag]

How much work is that really? Is it a justified excuse for them or is this ignorance out of lack of knowledge? How much work was it for you guys to fix this, but considering it was built upon already established universal mod framework we're using, what if you had to do it from scratch? What would be your message to the devs?

[haughty dock]

Would be a good bit of work if they don’t know what they’re doing. A major part of why we can do things so quick is also that the renodx codebase is well designed.

But really it’s just a knowledge issue

[woven crag]

So in a way saying "were a small team" also means we don't know how to do it properly/effeciently

[haughty dock]

They had hdr in Tetris effect cause unreal engine supported it, and they don’t here cause Unity doesn’t do it for them.

[woven crag]

Right, because in unreal a lot of things like that are quite simple to "just enable" but so many unreal engine games ship with broken HDR because "they just enable it"

[main wharf]

Yea from what I gather they're using URP (Universal Pipeline).
And afaik, only HDRP (HDR Pipeline...) has "built-in/ready-to-use" HDR output support, or at least so was it last time I checked

[woven crag]

Was HDR in tetris effect even good/correct?

[haughty dock]

I think it had the usual issues?

Think it only really suffers from gamma mismatch though

I’d have to check again to be sure

[woven crag]

So they "just enabled it" and called it their game has "HDR support". But now that they can't do that in unity, it's a "small team problem". Got it

[haughty dock]

It makes sense but it’s also annoying. They can’t simply choose to do everything they could ever dream of technically.

[woven crag]

So basically they don't know how, can't blame but it's an industry wide problem

[haughty dock]

But knowing that it could be done in an afternoon 😅

[woven crag]

Yeah exactly that's what's bothering me. So its not a small team problem, it's a we don't know how to do it problem

[haughty dock]

@main wharf lumines actually is only using aces sometimes in gameplay. It seems like you're right about ACES being used almost like color grading. Baffling really

[fiery vapor]

somehow the funny communism game (Disco Elysium) pulled it off though

[main wharf]

It does feel like this sometimes... Found one game that uses ACES only if Bloom is enabled, as if they're using it to offset black raise from wide bloom. Bloom disabled? Just clips.
There are a few games that use ACES with high settings, and Unity Neutral with low settings.
'Tis what it is, I can't even judge, I had never heard of tonemapping before I started RenoDX...

Lemme know if you got more info about RenoDX sliders' behavior, or anything else I can improve

[pulsar plinth]

Sorry, I just click the link to download it and nothing happens. All other downloads on the server work fine.

all gravy though i can just grab it off of your github page. 🙂

[main wharf]

Well snapshot links are from github already. But yea I think there's a release section now, with latest and previous builds.
It's all automated and I'm not entitely familiar with how it works yet, lemme see

This I think: https://github.com/NotVoosh/renodx-unity/releases
And corresponding download links are:
https://github.com/NotVoosh/renodx-unity/releases/download/snapshot/renodx-unityengine.addon64
https://github.com/NotVoosh/renodx-unity/releases/download/snapshot/renodx-unityengine.addon32

Not sure if that's any different from the pinned snapshot links:
http://notvoosh.github.io/renodx-unity/renodx-unityengine.addon64
http://notvoosh.github.io/renodx-unity/renodx-unityengine.addon32
I think it should be the same

[woven crag]

Did you make any major changes during the last week? Im still using the Nov 3rd build

[main wharf]

Nothing I would call major change, mainly increased compatibility and bugfixes.
I still strongly advise to keep .addon file in one single place and either use symlink or tell ReShade to load addons from there.
Makes it way easier to update especially if you have multiple Unity games installed.

I'm busy with other stuff lately, so as far as addon goes I'm just slowly updating games status to ✅ on wiki after I check I did not break anything.
Also been adding stuff to the pinned to-do list as I get ideas/find issues so I can come back to that later when I get more time.

[woven crag]

Yeah it has come to the point I should start doing the linking thing

[main wharf]

Basically when installing a new game, instead of: right click addon copy, right click in game folder paste.
It's the exact same steps with "pick link source" instead of copy and "drop as..." instead of paste

I think some .bat file script would also work

[main wharf]

Symlink script (suggested, not mandatory)
To do once:

• download .addon64 and .addon32, store in some centralized folder.
• download attached script, if needed edit with text editor to replace %userprofile%\Downloads in first line with above's folder path (default is Windows' Downloads folder).
  To repeat once per game:
• (install reshade with full add-on support)
• copy script file inside game folder, run it, file self deletes after symlink is done

Benefits:

• disk space (addon is only stored once)
• easy update (only centralized folder's .addon64 and .addon32 have to be replaced with most recent)

Alternatives:

• use @haughty dock's more advanced [script](#1413695723404398674 message) that also handles ReShade install
• use https://schinagl.priv.at/nt/hardlinkshellext/linkshellextension.html instead of script to similarly symlink addon files
• or instead of symlink, set ReShade to load addons from centralized folder, either in Addons tab in-game or in ReShade.ini:

[ADDON]
AddonPath=C:\path\to\unity\addons\folder

• or instead use SpecialK/SKIF (see method 2 alternate in wiki guide)

[main wharf]

SpecialK/SKIF is probably an alternative, I have yet to use it to load ReShade and addons but afaik it also supports centralized stuff

[haughty dock]

SK is really finnicky when renodx needs to upgrade the swapchain

[main wharf]

Somehow I've had no issue, I even rely on SK for Titanfall 2's RenoDX since RenoDX alone causes a black screen in main menu.
Fwiw I do use the very oldschool local install, both SK and ReShade, dunno if that makes any difference, I'd assume so

[haughty dock]

you just gave me an idea....

I'm gonna change my renodx install script to work with a central location and symlink out

[main wharf]

Ya, symlinking renodx\build\Release\game.addon is very comfy when working on a mod and recompiling often

[haughty dock]

yeah that's what I do for dev

[main wharf]

Epic giving away another couple Unity games, yummy free modding material

Aw, online... uhm

Denuvo Anti-Cheat

Woof

Oh, makes me think, I haven't tried ReShade in The Finals since they switched their AC

Ugh doubt this'll work

Nope
8 seasons, 90 patches, no HDR

[woven crag]

Same as with Arc Raiders. Don't expect it

Thanks for the symlink guides

[true carbon]

I haven't bothered with symlinking, yet. But @surreal haven put together a guide for it as well in Ultra+ server automating copy/paste process as well, or well, less tedious with QuickPasta.

[surreal haven]

https://discord.com/channels/1296187754979528747/1437143396107026472 if you want to check it out

[haughty dock]

I spent entirely too much time on this cause bat syntax kicks my ass, but here's a pretty fully featured script that centralizes reshade and the addon file and handles updates and deployment to a specified directory. It auto elevates for symlinks and everything.

Super easy to change this for the unreal addon as well, it's just changing a couple variables at the top

@main wharf ^

can also work as a localized installer by changing a variable to false

realizing I haven't tested that yet....

works but doesn't clean up the 32 bit reshade dll lol

okay now both paths fully work

it's lacking in error handling so just don't do anything wrong

[fiery vapor]

Cloverpit is still capped at 202 nits 🤔

oh my god it's in dx12 now

luckily -force-d3d11 works

(however it doesn't fix the game still being capped at 202 nits)

I think one more effect needs to be upgraded

although I think d3d12 actually does work perfectly with renodx unity, all d3d12 seems to be doing is hiding the reflection

Custom/CustomCrtShader

[haughty dock]

as long as the addon has the cbuffer stuff setup right, it should work as long as the shaders are the same

[main wharf]

Did you grab latest snapshot..? I'm pretty sure you already sent this shader and I already added it

Or did I forget to remove saturate

Ugh, nvm, can't find it... Will add it again, probably did a oopsie

Ah, I remember now, I didn't add the CRT one, ony PS1PostProcessing

Didn't see anything clamping in Crt one

[fiery vapor]

you added the ps1 shader but not the crt shader

I just dumped whatever paused the rendering when disabled

[main wharf]

I can't see any clamping code in crt shader, I may be missing something but I don't see anything I can edit there so I don't have a reason to add it

Maybe it's clamped by resource format?

[fiery vapor]

hmm

maybe

[main wharf]

I'd have to check game

Maybe some weird resolution stuff like game renders in smaller resolution or something I'm not sure

In which case changing RGBA8_typeless to Any Size should do.
Or if game uses FSR1/RCAS, it usually comes with R10G10B10A2_typeless upgrade required

[fiery vapor]

changing it to any size doesn't work...

[main wharf]

It has a demo, lemme see if that was updated

[fiery vapor]

and I don't think it uses FSR1/RCAS either

[main wharf]

Only missing latest patch it seems... Should be fine I'll check that

[fiery vapor]

it has a copy shader

[main wharf]

Yea these are no issue

Seems it's using lutbuilder, probably uber too so that's Unity's usual post-processing

Assuming these shaders are already in addon, anything below is likely to be the issue

[fiery vapor]

okay

I just realised that what's going on is that it's just naturally dark

entering the slot machine boosts the brightness from 203 to 250

[main wharf]

Btw if you raise Highlights/contrast does it go above 203?

[fiery vapor]

yep

I'm too used to most games just becoming REALLY unlocked once they're in HDR

[main wharf]

Right, so maybe game is just dim? Kinda looks like it from the pics tbh

I'm still installing demo so I check when I get time

But yea, I may not be able to do anything here

If "FakeHDR Boost" is available in Effects you can try that, eventually combined with Highlights and/or Contrast

[fiery vapor]

yeah

I'll see what the slot machine looks like first

[main wharf]

Maybe some of the winning animations or something, but yea environment looks pretty dim

[fiery vapor]

that goes to 250 so it does work

I'll actually have to play the game a bit

[main wharf]

There seems to be some Bloom, which is likely contributing to getting above sdr/203. Maybe all highlights are fake from bloom

[fiery vapor]

I don't notice any bloom with renodx which is weird

or maybe I just don't notice the bloom

[main wharf]

Nah maybe I'm imagining that xD

[main wharf]

I see some kind of blurry halo there, it's from steam page not the game

[fiery vapor]

yeah looks like the game doesn't go brighter than 250 nits lol

I think I should've recorded this in AV1 😓

[main wharf]

There's a slight chance it's still clamped somewhere, maybe before post-processing (?). I'll have to check demo to be sure.

[fiery vapor]

super jackpot allowed the game to go up to 461 nits

[bronze galleon]

Working very nice in Egging On

Surprisingly, it's the first time I find myself wanting/needing to lower Highlights to 40 so some sunlit objects don't lose details and be too bright (like the henhouse at the beginning) but it just works ™

[main wharf]

You can try to increase clipping value in this case. Default may be too low if game gets very bright.

[fiery vapor]

ok so I just realised I've been having a wild goose chase with beat saber shaders

have I posted this one yet?
Hidden/MainEffect

disabling it freezes the render

looks like this in D3D Shader Disassembler

[main wharf]

Did you try to edit it?

[fiery vapor]

not yet

[main wharf]

Any benefit? I guess removing that saturate() towards the end maybe

[fiery vapor]

I'll give it a shot

oh, getting rid of the saturate does make the lights brighter

and allows the image to reach the maximum nits a lot quicker

[main wharf]

Ok good thanks, I can add this. Uhm, I can't remember, are game/UI brightness already working?
If not, maybe this shader can be used? Ideally it would be in the latest draws before UI (assuming UI draws last)

[fiery vapor]

the game/UI brightness doesn't work for me, even when using swapchain proxy iirc

UI brightness affects the game brightness, game brightness does nothing

[main wharf]

Yea so it's just missing, there is no game brightness application. Maybe I can add it in this shader you've just sent

[main wharf]

Can try this 🙈

[fiery vapor]

I'll give it a shot later

[fiery vapor]

eyy it works

[storm vapor]

what's this error?

also, the in-game UI becomes black now

[main wharf]

Basically what it says, one shader is missing, hence output being broken: set LUT Shaper to Vanilla for correct output.
Then it depends on the game whether Vanilla shaper supports HDR or not.
Ultimately best would be to add output shader to the addon. For now addon doesn't have shaders dumping functionnality, but you can use devkit.

If game is free-to-play or has an available demo, I (or anyone else) can also have a quick look and add missing shader

[storm vapor]

I think by "LUT Shaper", you mean "Tone Mapper"? since it's the only setting I found that kinda fixes the issue (when set to Vanilla)

[storm vapor]

it's Escape Simulator 2, it's has a demo on steam!

[main wharf]

I meant Lut Shaper, and so does the warning.
Though if Tone Mapper other than vanilla also looks broken, there may be another issue. Could be a bug, could be some shader with unsafe maths.
There's a chance it depends on game settings (FSR1 most notably).

[main wharf]

Aye will have a look

[haughty dock]

I fixed it up and added more features (that nobody will likely need)

Centralized Unity RenoDX Installation Script

I had apparently not tested the old script with a space in the path which made me realize I forgot a few quotation marks

[haughty dock]

just like tetris effect, lumines arise is a hell of an HDR experience.

shame I'm ass at lumines

[bronze galleon]

Was impressed too but damn do I suck at it lmao

[haughty dock]

stlll haven't cleared the first set of stages on normal 😭

it's my first time playing lumines but still feels bad

[graceful wasp]

Thx i should use this for unity n unreal renodx

[fiery vapor]

I don't think this will change much

[woven crag]

https://store.steampowered.com/app/2934220/Monsters_are_Coming_Rock__Road/

Steam

Monsters are Coming! Rock & Road

In Monsters are Coming! Rock & Road, gather what resources you can to defend an ever-moving city. Are you ready to take on a never-ending army of darkness in a tower-survivor, action-rogue-lite on wheels?

- Fortify: The city must endure! Choose from a selection of town halls, place towers and create your own builds to maximise destructi…

Price

$8.09

▶ Play video

Any chance someone could look into this game? (It has a demo)

UI brightness works but game is clamped

Wait I think I got it working switching to PQ Lut shaper and upgrading everything R8G8B8A8 to any size

Hmm still not perfect

And some parts of UI are seen as game, like this here;

[main wharf]

Check if offsets are available in compatibility section, maybe a different value will properly separate UI

[woven crag]

I posted my responses to #💬lounge by mistake 😭

[main wharf]

monsters something

[main wharf]

This should work

[woven crag]

Thank you so much for your work 🙏 I'll test it as soon as I can

[acoustic tendon]

did you figure this out? its on gamepass now so im playing it

[fiery vapor]

it's a naturally dark game

[woven crag]

it's perfect!!! I'm so happy i'm tearing up again 😭 😭 😭

[fiery vapor]

sigh
I am playing horse game yet again

Gallop/ImageEffects/Rich/PostBloom_Rich

this one freezes 3D rendering when disabled

currently actual gameplay is capped to 202 nits, but it looks more like an artificial cap than it naturally being 202 nits

the game has VERY subtle bloom effects, which makes me wonder if that could be added to renodx settings

[fiery vapor]

oh

OH I just realised

umamusume requires any size for resource upgrades

yeah any size also fixes the UI brightness issue

also I'd have to check if the shading highlights are fixed, I think umamusume recently updated the unity version to be the same as the JP version

so I think it uses unity 2022 now?

ok shading is still a little scuffed, and I'm wondering if it's the same scenario as audiosurf 2 where the material needs a saturate added to it

ooo there's a colour corrector in the shader that when disabled makes the backgrounds look nicer

yeah I think the hair shader will have to be modified

somehow the hair shader refuses to load unmodified wtf

[warm geyser]

sometimes (honestly not that uncommon) 3dm has a bad decomp

even if it compiles, the code is fucked

[fiery vapor]

ah

then I'll send over the cso

[calm nacelle]

do you use displaycommander

[fiery vapor]

nope

should I?

[calm nacelle]

no i saw some green artifacts from someone using it the other day

so was just checking

[fiery vapor]

if this could get decompiled properly where it doesn't break then I could modify it

I'll try doing it the long way

hmm nope, still broken

this is the D3D shader disassembler output

seems to be triggered by w1.xzz

which is only referenced once?

oh

[fiery vapor]

okay so it's line 65

alright so the shader loads...

wait, replacing w1.xzz on line 235 with r1.xzz "fixes" it

and changing line 235 to r0.xyz = saturate(r1.xzz * r0.xyz + cb0[6].xyz); fixes the hair highlights going green

ah, looks like it's all the fault of the fastbloom shader

which is... quite simple

single line fix for Gallop/ImageEffects/FastBloom

oh this promises to be good

Gallop/ImageEffects/ColorCorrectionCurvesSimple is responsible for capping the live performances to paper white

ooo, it might be multiple shaders for different concerts

yeah it seems it is

Gallop/ImageEffects/ChromaticAberration

disabling this uncaps the image sometimes

[main wharf]

Yeaaa this looks like one effect or blend doesn't like values beyond 0-1 range.
I guess Any Size upgrade makes sense since game uses weird resolution iirc, dunno if it's because it's a phone game or just the fact there's always part of the screen that's just UI, so render isn't output size nor ratio.
I'll have another look eventually, first time I checked I was stuck in long tutorial where I can basically only click where game tells me to click, super annoying, just gave up at some point as I still wasn't able to get a capture from the actual game.

[main wharf]

This shader wouldn't clamp for sure. I think I mentionned already that the "Draw" button can affect more that one shader somehow.
In this case I'd guess either ChromaticAberration shader samples the output of a clamping effect, or is followed by a clamping effect, so disabling CA draw also skips the other effect.

[main wharf]

This does clamp indeed (color grading/strip LUT), and maybe could generate bad colors as you saw with the hair, to be confirmed I can't remember right now

[haughty dock]

playing total chaos now, it works at the start, but I found a missing output shader. Haven't dumped it yet, but I can get it for you later

[haughty dock]

@main wharf uber from Total Chaos

[main wharf]

Aye thanks, here shud be gud.
Also @sweet spindle, hopefully this was the same missing shader

[velvet moth]

If anyone's curious I used Jon's script installer for Moonlighter 2 and everything seems to be working.

[radiant pagoda]

hi @main wharf, LUT dump for the new game Morsels. It would look amazing in HDR. Hopefully it can be added to the mod. Thank you.

[jaunty thorn]

can't make it works for me. renodx launches but i can't find the settings to enable hdr

[velvet moth]

Odd, I didn't have to do anything, only bug I really saw was like Hades HDR where the UI brightness slider affected everything. Not sure highlights were totally correct but I still found it looked better than SDR.

[woven crag]

I came across this odd behaviour in Dark Light: Survivor (demo), the add-on is working but some assets get crushed into black (more so with Hermite mapper than others)

It's not a big deal but I wonder what is causing this?

It is however just a very early in development demo tho

Very very cool survivor like tho I'm excited for it

not an issue during gameplay tho

you can play it both top-down and bts. atmosphere is heavy on steampunky elden ring. very cool

Probably too early to bother fixing it since it's not even in EA yet, but I'll keep an eye on it

messed around with it some more, idk what i did but it's mostly gone with frostbite mapper now

super weird why is it doing that

but eh, could be just demo build issues

ha, I got it!

interal lut strength to 0 gets rid of it

why would internal lut be doing this?

[fiery vapor]

This used to happen with umamusume pretty derby but not anymore

[main wharf]

Any warning in addon? Unless some output shader is missing,
my guess is a shader with unsafe maths after post-processing/LUT.

In linear bt709 space, WCG is represented by negative values, which are usually deleted in SDR. Some shader code doesn't work with negative input, has to be adjusted or it returns NaNs values (=> glitchy visuals).

In this case I assume internal LUT increases saturation beyond bt709 space, hence why it seems to cause the visual issues, but it's likely some other code breaking with WCG.

[woven crag]

No warnings

"unsafe math" is certainly one of the things I didn't expect to learn today

[main wharf]

I'm not sure if that's official wording lol

Some shader instructions/functions are not meant to receive negative values, and output NaN in this case (Not A Number, which can look like those black artifacts but not only)

In SDR, it is possible NaNs are generated aswell, but they are usually stripped anyway by resource format (RGBA8_UNORM, RGBA8_TYPELESS) for which stored values are also limited to 0-1 range.
RenoDX upgrades these resources to RGBA16_FLOAT to allow values beyond 0-1 range which matter in HDR (linear, not encoded). As a side effect, format also retains NaNs. To find and fix or work around things that break with resources upgrades is usually part of RenoDX making 😅

[woven crag]

I see. Had to read about 10 times but it's starting to make some sense now

How does a float value beyond 0-1... even look like?

[main wharf]

Uuuh, well negatives are below 0, and any number above 1 is... above 1

SDR is limited to 0-1, not HDR.
"Game Brightness" corresponds to the value SDR's 1 is mapped to. So with default 203 nits, the "SDR part of HDR" is 0-203 nits. Anything above 203 means value originally is above 1 (before Game Brightness scaling is applied).

[radiant pagoda]

another request to be added to the mod, new indie metroidvania "Constance". Thank you.

[main wharf]

Yup' sqrt is the culprit. "CustomBlendEffect", something they do with UI I guess. Should be easy to fix, I think
(square root)

[woven crag]

I would also have a request for another metroidvania (I can dump the missing shaders) but I'm not sure if it matters if its an in-development demo or not

As its still far from release but it's another one of those where HDR could look incredible but it's in a completely broken state atm

[main wharf]

I do add some demos shaders, I leave a comment inside with game's name so if shaders are different when game releases I can delete old ones

If you don't wanna bother with the dump, feel free to just gimme name and I'll have a look. Assuming demo is available

[woven crag]

Alright I'll make the dump if that's all you need, I'm curious how it will look because even with autohdr it looks all wrong

[main wharf]

^

[woven crag]

Oh yes of course heres the link

https://store.steampowered.com/app/3639650/Kotama_and_Academy_Citadel/

Steam

Kotama and Academy Citadel

Kotama and Academy Citadel is a 3D Metroidvania game where players embody a mysterious yet charming girl to explore the labyrinthine "Carmel Academy Citadel." Embark on a witty, vibrant, and adrenaline-fueled journey to claim the title of [Carmel Star].

…

Release Date

Coming soon

▶ Play video

Seeing this beautiful art clamped to sdr just hurts me

[main wharf]

Thank you for the dumps! Added shaders for both Constance and Morsels in this, gonna push later or tomorrow to github

[main wharf]

^ Dark Light: Survivor demo NaNs should be fixed in this

[woven crag]

Oh damn that was fast. Thanks for the update. I can't even comprehend how are you able to "squeeze" all these adjustments in the main build

[main wharf]

Done for today, gonna check that one demo later

[main wharf]

I don't quite understand most of it either to be honest. In fact if it wasn't for @crimson spear saving the addon about 3 times, it wouldn't exist 😅

[radiant pagoda]

thank you so much 🥳

[haughty dock]

@main wharf any chance you could double check if the pq encoding is right in this uber shader? Not sure what else the issue would be

uber you added on left vs the other uber shader that was already in the mod

it looks right with vanilla encoding

[spiral cargo]

@main wharf Can you help me with Tales of Xillia support?

The addon says that Missing Output Shader so I post the Uberpost

Thanks a lot 🙏

[main wharf]

Uhm, code seems fine to me. I actually took one of the old shaders as example to edit new one to be sure I didn't mess anything up

Any chance there are two uber shaders running ? I think in that case, the missing shader warning would only show if both are missing.

iirc demo had something like that going on sometimes. Usually selecting the lut resource in devkit shows 2 draws in History, eventually it becomes 4 at times. Can be twice same lutbuilder same uber, or different builder same uber, or same builder different uber or different permutations for both builder and uber... Fun stuff

[main wharf]

Here maybe

[spiral cargo]

yes its amazing!

[main wharf]

I should be able to make warning take into account multiple draws I think, will try that when I get the chance.
Until some day maybe this is all replaced by auto-dump button

[haughty dock]

I didn’t know that could happen lol. I’ll check

[haughty dock]

doesn't seem like it's 2 ubers. Idk what's goin on with it tbh

[haughty dock]

maybe check if the lutbuilder is right?

0x995B320A

already in the mod

it's oversaturated unless I switch to vanilla encoding

[main wharf]

Oh lol, that's a different one from demo 0x425A05B0

Demo was 2D, that new one is 3D

[main wharf]

I don't think there's any issue here. But I'm thinking if there is one 2D (usually 1024x32) and one 3D (maybe 33x33x33) then maybe they wouldn't use the same resource so finding them using resource History in devkit wouldn't work in this case. Theoretically speaking anyway, I haven't seen that yet

[main wharf]

Aw yea lutbuilder is arri c1000 log decoding and the uber you sent is srgb encoding, something there is dodgy

[haughty dock]

sounds like it might be some bullshit we can't really replicate....

not in a generic mod where other games/shaders may use it correctly

[main wharf]

Dunno, maybe there are two different lutbuilders and ubers drawing same time?
And addon would have 3 / 4 shaders

Eh I'm tempted to just grab the game, gonna play it at some point anyway

[main wharf]

Bcoz I doubt there is such a mismatch

[haughty dock]

There are definitely multiple Ubers I just don’t see them at the same time

Is there a demo?

Also game is pretty cool btw

[main wharf]

There was like 9 months ago, wasn't updated

Yea I enjoyed the vibe and I'm not usually much into slower-paced horror-based kind of game

[full palm]

@main wharf how do you distinguish between a notonemap and a neutral lutbuilder

[junior river]

Endfield Beta is soon out, we hab access to the main menu. Game gibs use two API choices, VK or DX11.

We can't do Vulkan for Endfield since we're doing SDR path (VK doesnt support resource upgrades and swapchain) ~~ VK is just ass~~

The other option is DX11

Game doesn't seem to be as custom as we thought looking into the shaders, Spiwar already slopped out an addon by adjusting the shaders but not LUTbuilder (we dont have access to in-game though so it might change)

Unity add-on with some custom stuff will probably work better than starting on it with generic addon

[full palm]

you saying that in the channel with no context

[junior river]

[main wharf]

Uuuuh... No tonemap builder only has grading ops.
Corresponding Neutral or ACES or Custom Tonemap would have HDR grading ops followed by tonemap followed by SDR grading if any.

In practice I just scroll down asm in devkit and recognize number/patterns

Unity Neutral is in tonemap.hlsl, looks like this

[full palm]

Right i was trying to look at your patched lutbuilder and both look kinda the same other than the end

[main wharf]

Yeaaa depends on pipeline, basically most recent builders have all HDR grading, so tonemap literally is the latest step in lutbuilder

Well if there's any, no tonemap just does max(0 after grading

[full palm]

this should be a neutral one right

[main wharf]

Nah, no tonemap in here I think

There is FastTonemap and FastTonemapInvert at the end, this is only to wrap the curves sampling that only inputs and outputs 0-1 range

Looks like... LutBuilderHdr.. ?

[full palm]

yeah

[main wharf]

Here take source

And lemme find one that has comments in Unity addon

[junior river]

We had source this entire time
