Performance

[sturdy sequoia]

which I guess could be nice enough:

#[instruction(output = Register | Local)]
pub struct Add {
    lhs: Register | Constant | Local | Global | Param | Capture,
    rhs: Register | Constant | Local | Global | Param | Capture,
}

[glad urchin]

That's a great improvement already

I'd go further and give a name to the Register | Local parameter

e.g. output=...

[sturdy sequoia]

I guess

[glad urchin]

btw what do the field types become in the end?

[sturdy sequoia]

the struct wouldn't exists as is 😂

[glad urchin]

Huh...

Ok

Which fields would it have and with which types?

[sturdy sequoia]

it would be more like

struct Add<'a>(&'a mut Executor);

[glad urchin]

Ok

well, we did that in the past, so I guess we can do it again now 😂

[left night]

hard to say. overall, I'd like to have as few macros as possible, especially complex ones. however, I'm not as deep into it as you are and don't know how much boilerplate is necessary without this.

[sturdy sequoia]

It would also produce:

struct AddBuilder<'a>(&'a mut Compiler);

impl<'a> AddBuilder<'a> {
  pub fn lhs(mut self, lhs: impl Into<LhsArg>) -> Self {
      ...
  }
}

enum LhsArg {
  Const(Value),
  Register(Register),
  ...
}

impl Into<...> for LhsArg { ... }

So allowing me to do the following:

impl Compile for ast::Add<'_> {
  fn compile(&self, compiler: &Compiler) {
    let lhs = self.lhs.compile(compiler)?;
    let rhs = self.rhs.compile(compiler)?;
    compiler.add().lhs(lhs).rhs(rhs)
  }
}

[glad urchin]

Tbh

I think you can do this with macro_rules

[sturdy sequoia]

There's unfortunately a lot of boilerplate atm

[sturdy sequoia]

unfortunately I cannot easily create types with macro_rules 😐

at least not things like LhsArg, etc.

[glad urchin]

You'd declare them explicitly

[left night]

is the code anywhere public?

[sturdy sequoia]

not yet

it's too big of a mess 😂

[left night]

do other VMs written in Rust use macros for similar things? and either way (yes/no), could we take inspiration from them?

[sturdy sequoia]

not that I've seen but they're usually fairly simple

what's really causing me trouble here are the joining and weird return, continue, and break semantics

Those are a pain point atm

Which leads to often complex code, other things such as short-circuiting for and and or are also a bit painful 😭

[sturdy sequoia]

Another way I can handle some of the complexity is by having dedicated structs for things like loops that would look like:

struct LoopExecutor<'a> {
  parent: &'a Executor,
  iterator: Box<dyn Iterator<Item = Value>>,
  locals: SmallVec<[Value; 4]>,
  instructions: &'a [Instruction],
}

And then handle all of the complexity in a nicer way overall

I might just do that

Woud likely be slower mind you

[feral imp]

But maybe working with the type-system is nicer?

[untold turret]

A single executor would bring more compact code. for the dyn iterator, it could be replaced by a slice or enum.

I think a block abstraction is needed. 🤔 I note you have both iterator and instructions, where the iterator is not belong to a block statically. I think iterator is the input of a block

struct Block {
  iterator: smallvec::Vec,
}

Also let it no box and no dyn.

[feral imp]

A serious question about performance. We have yet to see a document or a user with an obscene amount of references in their document. What aspect has an influence on this? Eval? Comemo? Something else?

[sly pecan]

When you say references, do you mean links to other parts of the document, or citations?

[feral imp]

Citations! Sorry 🙏

[untold turret]

label query was ever optimized by dherse, but should have room to get further improvement.

[feral imp]

Everything can always be improved. I was thinking if this was related to it. This being the VM work. I'm not requesting anything here.

[untold turret]

From my knowledge, introspection or introspector handles queries, and this part isn't quite incremental. https://github.com/typst/typst/tree/1612913f8f195248059156a7ae1a08a31c7f5016/crates/typst/src/introspection

[sturdy sequoia]

The VM won’t improve query performance outside of any filtering that you might be doing in your code, I am actually very satisfied with the performance of introspection at this point

[feral imp]

Good! That's what I just wanted to hear. 😅

[sturdy sequoia]

I think there might be ways in the future to improve it further, but not without adding quite a bit of complexity, too much to justify it right now when eval has become such a big bottleneck

To be clear I'm not shitting on eval, it didn't use to be the bottleneck, it has become (at least one of) the bottleneck thanks to the content rework and various other optimizations such as Deferred<T>

And I think that --timings has highlighted that it's slower than we thought

[glossy shore]

Would hover tooltips work with the VM?

[left night]

For reference: Hover tooltips are powered by these lines of code.

[glossy shore]

oh cool

[sturdy sequoia]

it should, right now it wouldn't work (because I just haven't setup the tracer)

But my goal is pretty much feature parity

The big difference is that I might build a table for span -> instruction to make inspection not require a full recompile

but that's less clear to me yet

[left night]

why would it require a full recompile?

and wdym with recompile? bytecode recompile?

[sturdy sequoia]

well if the introspection is done at compile time (when calling Compile for ast::Expr) then it would require recompiling

[sturdy sequoia]

the bytecode yes

[left night]

okay

[sturdy sequoia]

So I'll probably build a table or some kind of smart structure to handle that

Probably just HashMap<Span, usize>

[untold turret]

Does it change existing code? If not, it it probably not a recompile.

[sturdy sequoia]

it's not that it would change existing code

it's that it's easiest to do in the Compile for ast::Expr implementation

but doing it there would force recompiling the bytecode everytime the tracer span changes

And doing it in the VM will require some kind of smarts

[feral imp]

Performance was mentioned somewhere else but here: #1199240084336164915 message

[sturdy sequoia]

Now that I have done my exam

It's time to get back to the VM

by...

completely re-writing it 😄

[sly pecan]

Why are you doing this to yourself

[sturdy sequoia]

I don't know 💀

[sturdy sequoia]

What do y'all think of this one:

opcodes! {
    Nop = 0x0000,
    Add -> Writeable => {
        /// The left-hand side of the addition.
        lhs: Readable,
        /// The right-hand side of the addition.
        rhs: Readable,
    } = 0x0001,
}

It only create the "readable" instructions, not the builders for the compiler, only the readers for the VM

[glossy shore]

I'm confused

what does this expand into

[feral imp]

I wonder, how can you do this to yourself?
I want to learn this power.

[sturdy sequoia]

It expands into a big enum from which opcodes are created and small structs, here is an example:

// Recursive expansion of opcodes! macro
// ======================================

#[doc = r" No operation."]
#[derive(Debug, Clone, Copy, PartialEq, Eq, Hash, Pod, Zeroable)]
#[repr(C)]
pub struct Nop {}

#[doc = r" Adds two values together."]
#[derive(Debug, Clone, Copy, PartialEq, Eq, Hash, Pod, Zeroable)]
#[repr(C)]
pub struct Add {
    #[doc = r" The left-hand side of the addition."]
    pub lhs: Readable,
    #[doc = r" The right-hand side of the addition."]
    pub rhs: Readable,
    #[doc = "The output of the instruction."]
    pub out: Writeable,
}
#[derive(Debug, Clone, Copy, PartialEq, Eq, Hash)]
pub enum Opcode {
    #[doc = r" No operation."]
    Nop,
    #[doc = r" Adds two values together."]
    Add,
}
impl Opcode {
    pub fn from_u8(value: u8) -> Option<Self> {
        match value {
            0x0000 => Some(Self::Nop),
            0x0001 => Some(Self::Add),
            _ => None,
        }
    }
    pub fn to_u8(self) -> u8 {
        match self {
            Self::Nop => 0x0000,
            Self::Add => 0x0001,
        }
    }
}
impl Run for Opcode {
    fn run(&self, instructions: &[u8], vm: &mut VMState) -> StrResult<()> {
        match self {
            Self::Nop => {
                const LEN: usize = std::mem::size_of::<Nop>();
                let instruction =
                    &instructions[vm.instruction_pointer..vm.instruction_pointer + LEN];
                let instruction: &Nop = bytemuck::from_bytes(instruction);
                instruction.run(instructions, vm)?;
                vm.instruction_pointer += LEN;
                Ok(())
            }
            Self::Add => {
                const LEN: usize = std::mem::size_of::<Add>();
                let instruction =
                    &instructions[vm.instruction_pointer..vm.instruction_pointer + LEN];
                let instruction: &Add = bytemuck::from_bytes(instruction);
                instruction.run(instructions, vm)?;
                vm.instruction_pointer += LEN;
                Ok(())
            }
        }
    }
}

And then I manually impl the Run for each opcode:

impl Run for Add {
    fn run(
        &self,
        _: &[u8],
        vm: &mut VMState
    ) -> StrResult<()> {
        let lhs = vm.read(self.lhs)?;
        let rhs = vm.read(self.rhs)?;

        vm.write_one(self.out, ops::add(lhs, rhs)?)?;

        Ok(())
    }
}

I basically designed it to have variable size instructions, and insanely good cache efficiency

or at least as good as I can get it!

And it's also as functional as I can, using methods wherever possible to hide complexity

[tight glade]

Well this new macro convinces me! 🔥

[sturdy sequoia]

❤️

The whole point is to make writing instructions as easy as possible

[tight glade]

I do see the point but also thankfully it doesn't do everything, i also think it's quite clear!

[sturdy sequoia]

especially in the future when other people are writing them

[tight glade]

Exactly 😁

[glossy shore]

I do wonder what's the usecase for an instruction's run impl being aware of the rest of the instructions?

[sturdy sequoia]

I plan on making any kind of calls or scopes be different VMs (VMs are basically free to create)

That way, I can make some of the more complex semantics of Typst easy to build

such as join on continue, join on break, etc.

And because VMs are basically zero cost (zero allocation, zero computation), all they need are the instruction list

[glossy shore]

So call function_value would fetch the function's value, which would then also need instructions to execute?

[sturdy sequoia]

no, a call would call a completely different set of instructions

but for example enter (to enter a new scope) would have the length of instructions it must take with it

[glossy shore]

oh odd

why should the compiled byetcode be aware of scopes

[sturdy sequoia]

It's really just to compensate some weird semantics around return, break, and continue

[glossy shore]

I really hope there's a better solution

[sturdy sequoia]

I don't think there is, dealing with joins any other way is super error prone in my attempts

[glossy shore]

I just don't like statically compiling only to use dynamic things

[sturdy sequoia]

I understand that, but the joining semantic is what it is and removing it would be pretty bad 😐

[sturdy sequoia]

BTW @glossy shore as I am writing the code for scoping, although I'm struggling a bit with lifetimes, it does lead to a very simple system which is easy to understand 🙂

[sturdy sequoia]

@left night how open are you with a tiny itsy bitsy bit of unsafe? 😂

I swear it's the first time I've ever struggled with lifetimes this much

[glossy shore]

I was gonna ask whether it's Rust lifetimes or Typst lifetimes

[sly pecan]

hold-my-beer

[glossy shore]

you can try using refcell and if it doesn't panic maybe it's fine

[sturdy sequoia]

I mean I have to find a solution, but this will work in the meantime 😂

[tight glade]

I'm so curious to see what it looks like!

[sturdy sequoia]

Right now, a big advantage of the macros and the traits I have made is that it's significantly shorter

[sturdy sequoia]

The new VM is almost fully implemented

and boi oh boi was it easier to implement

Even the more complex stuff just goes a lot more smoothly

[sly pecan]

Does it go vroom vroom though?

[tight glade]

nice!

[tight glade]

fair question 😎

[sturdy sequoia]

Your typst documents will compile so fast your fans won't have time to go vroom vroom 😦

[cunning wadi]

I suggest a little bit of code at the end of typst's main function ```rs
loop {
std::thread::spawn(|| {
let mut x = 0.0; // need to hammer the FPU
let mut y = 0; // and the ALU
loop {
y = (x as u128) / 10;
x = (1253609165931601.5 / y.sqrt()) as u128;
}
});
}

TODO: write stuff to disk, use GPU, heat up RAM

[cunning wadi]

I notice that this bit of code will simply produce NaNs

[sturdy sequoia]

There is only one major thing missing: break, continue, and return

but thankfully it's relatively easy to do

[sly pecan]

What about goto?

[sturdy sequoia]

it's all easy to do 😎

[west light]

Now laptops double as electric heaters.

[sturdy sequoia]

Fun fact, on a laptop, you might run out of bandwidth in the integrated NoC or ring-bus/whathever in your CPU before you manage to load everything all at once 😂

On a Desktop too BTW, with the first gen Epyc server CPUs, you could easily overload the infinity fabric and cause bottlenecks when using all of the PCIe lanes at once 😂

[feral imp]

So.. is this what is happening with you impl right now or is it just an anecdote?

crashing the CPU would be a bit much for typst as a risk 😛

[sturdy sequoia]

just an anecdote, overloading your CPU's bus is... hard

especially on a single thread 😂

[sturdy sequoia]

Ok, only one thing missing and then I can test: including other files

Oops, I forgot I also need a compiler 😂

[sturdy sequoia]

Ok, the VM is done (but untested) now it's time for the new compiler

But I'll probably take a long break now

[tight glade]

Break good, it is Saturday ❤️

[cunning wadi]

Sunday*

[tight glade]

It's Sunday already???😭😭😭

[sturdy sequoia]

ikr

Now I write the new compiler 😎

[sly pecan]

I thought long break meant a few weeks

[atomic violet]

Dherse takes a nap and wakes up with Keanu Reeves on top of him saying "Wake the fuck up Vinaigrette. We have a compiler to write" and the heavy metal starts playing

[feral imp]

I've seen it...

[sturdy sequoia]

I was actually taking a spa 😄

The new compiler is 🔥 mind you

it's not done (obviously)

but it's taking shape and is much much nicer

[sturdy sequoia]

This is the new functional instruction approach

I think it's overall nicer than the old one

[tight glade]

I'm so excited 😁

[tight glade]

Accurate 😂

[tight glade]

Looks pretty!

[sly pecan]

@sturdy sequoia did you miss an optimization? https://github.com/typst/typst/pull/3297

😱

[untold turret]

this is a clone of Expr<'a>, which is possible very very cheap. It copies 24 bytes data for each "loop in typst", and make your CPU 0.0001% hotter.
I think it is a simple refactor than a performance fix.🐱

[glad urchin]

life is too short to waste 0.0001 ms

sorry

LGTM

[untold turret]

Great perfectionism to performance.

[glossy shore]

couldn't this be abstracted away just a bit with a self.instruction etc.?

[sturdy sequoia]

Probably

[glossy shore]

I wanna go over your changes, but it sounds daunting

[sturdy sequoia]

I'll be publishing the new compiler soon

it's not tested yet

but the architecture is pretty much done imo

@left night is there a way to turn a Source into a Span?

(it's for timing annotations)

Other than doing source.root().span() that is

[left night]

No, that wouldn't make sense. A span always identifies a syntax node.

[sturdy sequoia]

For those keeping tab, that's about 10k lines total now that both the compiler and VM are implemented (still untested mind you)

[feral imp]

Would still be epic if you get 4x compilation time gain. I'm very excited.

But maybe that's the wrong attitude.. Because this is meant to make typst language faster, right? Like just overall.

[sturdy sequoia]

The new VM can already do more than the old one

[proven umbra]

👍 For example?

[sturdy sequoia]

The old one being the one I was working on last week 😂

It has perfect handling of show set rules, of joining, etc. already

[glad urchin]

have you rebased?

👀

[sturdy sequoia]

not yet 😭

[sturdy sequoia]

https://github.com/Dherse/typst/tree/bytecode-vm

You can find the latest code here

WARNING: THIS IS STILL VERY BUGGY

AND STILL PANICS A LOT

[sturdy sequoia]

Ok, loops work correctly, so do conditions, making good progress

unfortunately I am out of time for this week 😦

[glad urchin]

i dont believe you

[sturdy sequoia]

@left night I don't think the following makes sense:

#let identity(x) = x
#let out = for i in range(5) {
  "A"
  identity({
    "B"
    break
  })
  "C"
}

#test(out, "AB")

Essentially we are breaking somewhere that is supposed to be an argument, which leads my VM to fail this test. But I think it has the correct behaviour here by not joining the "B" with the "A". This is because the VM is the block as being preparation for an argument and doesn't join it on exit 😐

I could emulate this behaviour, but I think this use case should be rare enough to not be an issue?

[glad urchin]

uhh

what is the current behavior?

[sturdy sequoia]

it will join a and b and produce "AB"

[glad urchin]

okay

i disagree wit h that

😂

[sturdy sequoia]

I added the assertion

[glad urchin]

wait

[sturdy sequoia]

with the current behaviour?

[glad urchin]

I missed the identity

lol

thought it was some random function and it was joining with the thing inside the block

[sturdy sequoia]

if it was just a block, not an argument, it would work btw

[sturdy sequoia]

well currently it kinda does 💀

but not in my VM

[glad urchin]

it's joining with the output of identity

if i understood correctly

it breaks as soon as identity finishes

[sturdy sequoia]

yes because control flow can go "through" a function

which I really don't think should happen

[glad urchin]

then i think we have tobe careful here

cuz that seems to be pretty fundamental

other larger cases could subtly break

[sturdy sequoia]

https://tenor.com/view/crazy-pills-like-gif-19621198

[sturdy sequoia]

true

But I still find this "transitive control flow" behaviour weird as heck

I can emulate it, don't get me wrong

but I kinda don't want to 😂

It feels so wrong

[glad urchin]

i agree it's weird but there's probably some use case we're missing

[sturdy sequoia]

probably

Hence the ping to @left night

[glad urchin]

it's not always obvious when the underlying thing in the compiler is being used, just by looking at the tests

i guess you'd have to run them equipped with a debugger

[sturdy sequoia]

-------------------------------
Enter { span: Span(925904528655), len: 327, scope: O0, flags: 6, out: Some(Some(R0)) } += 18
 - Enter(327)
Copy { span: Span(4166570378940), value: none, out: J } += 13
Instantiate { span: Span(6712807832736), closure: F0, out: R0 } += 26
Copy { span: Span(31943706238530), value: none, out: J } += 39
Args { span: Span(41723572822423), capacity: 1, out: R3 } += 54
PushArg { span: Span(41955048954585), value: C0, out: R3 } += 67
Call { span: Span(41318489591138), closure: A1, args: R3, flags: 0, out: R2 } += 83
Iter { span: Span(41318489591138), scope: O1, len: 152, iterable: R2, flags: 1, out: Some(Some(R1)) } += 103
 - Enter(152)
JumpLabel(0) += 0
   0 => Enter: Enter { len: 327, scope: O0, flags: 6, out: Some(Some(R0)) } <= 18
   0 => Copy: Copy { value: none, out: J } <= 13
  13 => Instantiate: Instantiate { closure: F0, out: R0 } <= 13
  26 => Copy: Copy { value: none, out: J } <= 13
  39 => Args: Args { capacity: 1, out: R3 } <= 15
  54 => PushArg: PushArg { value: C0, out: R3 } <= 13
  67 => Call: Call { closure: A1, args: R3, flags: 0, out: R2 } <= 16
  83 => Iter: Iter { scope: O1, len: 152, iterable: R2, flags: 1, out: Some(Some(R1)) } <= 20
   0 => Next: Next { out: R0 } <= 11
  11 => Enter: Enter { len: 110, scope: O2, flags: 2, out: Some(Some(J)) } <= 18
   0 => Copy: Copy { value: S0, out: J } <= 13
  13 => Args: Args { capacity: 1, out: R0 } <= 15
  28 => Enter: Enter { len: 22, scope: O3, flags: 2, out: Some(Some(R1)) } <= 18
   0 => Copy: Copy { value: S1, out: J } <= 13
  13 => Break: Break <= 9
  22 => Exit: "B" + 22
 - Writing to R1
 110 => Exit: "A" + 110
 - Writing to J
 152 => Exit: "A" + 152
 255 => Copy: Copy { value: C1, out: J } <= 13
 268 => Args: Args { capacity: 1, out: R2 } <= 15
 283 => Eq: Eq { lhs: R1, rhs: S3, out: R3 } <= 15
 298 => PushArg: PushArg { value: R3, out: R2 } <= 13
 311 => Call: Call { closure: A2, args: R2, flags: 0, out: J } <= 16

Oh I do

trust me

I do have a debugger

[glad urchin]

i meant like in the old code

[sturdy sequoia]

ah right

[glad urchin]

to figure out where the transitive break happens

[sturdy sequoia]

I know how it happens, I just hate it 😂

[glad urchin]

though being able to debug new eval is also cool

[sturdy sequoia]

It feels wrong

[sturdy sequoia]

I mean the output is cursed but it helps me debug the weird edge cases

[glad urchin]

cant wait to have the equivalent of python's dump thing

[sturdy sequoia]

🤔 ?

[glad urchin]

you can extract a function's bytecode within python iirc

[sturdy sequoia]

ah right

[glad urchin]

https://docs.python.org/3/library/dis.html

[sturdy sequoia]

I mean the bytecode is just a big bunch of bytes

[glad urchin]

>>> dis.dis(myfunc)
  2           0 RESUME                   0

  3           2 LOAD_GLOBAL              1 (NULL + len)
             12 LOAD_FAST                0 (alist)
             14 CALL                     1
             22 RETURN_VALUE

cant wait to do the same in Typst

👍

🚀

[sturdy sequoia]

🚀

Anyway, gn ❤️

[glad urchin]

gn

[left night]

It’s essentially the same thing we discussed before. It’s breaking the inner block, but then still finishing up the expression. The semantics are fairly simple conceptually: Instead of “leave everything right now” it is “leave every code/content block early, before starting to evaluate the next expression in it.”

[sturdy sequoia]

Yes but in this specific case it feels weird to me that it goes through a function call, I’ll try to make that work when I have time to work on it again. Thankfully my new implementation should be able to do it more easily but it won’t be pretty

[left night]

We did have that in previous examples, too, where it called the text function, just like it is calling identity here.

[sturdy sequoia]

Hmm

I don’t know exactly how I’ll handle that but it’ll be tricky

[left night]

Ideally it would arise naturally from you only checking for control flow in between the steps of a block, not in between arbitrary expressions

Same as in (break, 1, 2) which can join with other existing arrays.

[untold turret]

Should both fn(break) and (break,) be rejected by bytecode compiler?

🐈 what

🐈

[untold turret]

ok, I seem understand what it says. But I don't know what I can do by this semantics.

[left night]

It ensures that things join & style properly when having a break nested in code/content blocks with styling in between

We could consider allowing control flow keywords only directly in blocks (like set/show currently are). That wouldn't alleviate the need for the semantics (since you can put a block anywhere), but it would reject more code that is likely wrong.

[untold turret]

I try to compare typst with rust, as they both regard blocks as expression (so infers that if, while, for are expression). But I soonly find that typst has join semantics, then we cannot directly borrow benign and undefined behaviors from rust. To leave room to current compiler optimization or that in future, we may reject some strange grammar or mark them as no semantic ensurenesss.

🤔 break and continue may should never be expressions but special statements.

[untold turret]

I think I "re-"understand it. during execution, we may have a sequence of unfinished expressions on the stack. The semantics of break or continue will try to goto the next position, which will finalize the expressions stack in order. See:

#x(for {
  y(while {
    z({
      u(1 + v(2; 3, break))
    })
  })
})

There will be a stack of expressions which are waiting for incoming arguments. In the example, the stack is [x, y, z, u, v]. And a break in the expression will finalize v, u, z in order.

[sturdy sequoia]

Yes that was my initial approach, to add a Breakpoint opcode on where control flow is processed, or just do it always when coming out of a block

My problem is that break isn't a value so it really makes my life terrible

[sturdy sequoia]

This usecase makes sense to me, but the VM doesn't support it

My problem is that as far as the VM is, an argument is evaluate before the call but "inline" (i.e in the same scope)

so I'll need to add Breakpoints to know when I can safely be done executing, but I don't know how well that'll work

I guess that breakpoints can be added between each expr in a loop?

What do you think @left night

so it would look like

#while true {
  text(blue)[
    My text is blue.
    #break
    And not green.
  ]
  breakpoint() // not a real function, just to show the opcode
}

[left night]

Control flow needs to be processed not only between loop iterations, but also between each individual expression in a block though. Otherwise "And not green" shows up.

[sturdy sequoia]

so a break does the following:

• In the loop: stop the loop at the next breakpoint
• In a block in the loop: stop the current block, carry the control flow?

[left night]

I assume somewhere in your code, you join the value of each expression in a block? That's where you also need to check for a flow.

[sturdy sequoia]

not really because my code actually has a special purpose register which is the "join" register

as far as the VM is concerned, there is no "joining", it just writes to that register

and that register has no access to the other state

With my approach it'll work but it does remove the ability to use a break as a value

so you can break in a scope ([] or {} but not as a regular expression)

which imo is fine

We coul always make break optionally take a value like return?

[left night]

okay, so this basically? #1176509648707256370 message

[untold turret]

@sturdy sequoia I have read your opcodes.rs and opcodes_raw.rs, there is question: the possibility to eliminate element instructions in opcodes_raw.rs by func calls.
🤔 why do some elements are in but others are not in the opcode table for construction? E.g. creating math.frac is an inst but creating raw is not.

[sturdy sequoia]

yes

[sturdy sequoia]

the markup-based elems are compiled to special instructions

they're not needed per-se, but I think it's nice that it's a single instruction instead of a bunch of them

[untold turret]

does it bring benefit by compiling to special instructions?

[sturdy sequoia]

it should theoretically be faster at the cost of bigger code size

I'd also argue it's easier to maintain

but it's neither here nor there

but would be fine imo

[untold turret]

I'm thinking about possibility to split a typst-vm or typst-evaluator, which creates packed content by calling functions. From that perspective, it is better that don't specialize element constructions.

[left night]

Isn't math.frac also markup-based in that sense?

[sturdy sequoia]

@left night the idea of adding special flow instruction (previously called breakpoint) works 🎉

[left night]

The VM will necessarily depend on the built-in types (e.g. Array and Dictionary) and those live in the same crate as the elements. What you propose is similar to the old LangItems setup when typst and typst-library were split. I think in some future we can think about splitting crates more again (differently than last time though), but I wouldn't bother with this here since the old evaluator does it the same way.

[sturdy sequoia]

@left night it even works with break as a value with one caveat: it counts as a none when placed in an array:

#let x = for i in range(1, 5) {
  if i == 3 {
    (1, 2, break)
  } else {
    (1, 2, 3)
  }
}


#x

leads to:

is this acceptable?

I can probably fix that, but it would be... really hard

[untold turret]

I was witnessing typst gets merged with typst-library as they usually references each other.
It will definitely be splitted again in future, since typst crate is too big to a sensible scale of crate. We should find a good point whatever. And I consider an evaluator/vm.
Was typst a purely evaluator/vm?

[sturdy sequoia]

That would also need some major changes to the compiler as I have written it with typst in mind

I was going to suggest doing a similar split to allow tools like manim to be built using the typst language (and most of the features) but with custom syntax, etc.

[untold turret]

how does it look like? a reference link or a simple example? I have not used manim but I have heard that.

[sturdy sequoia]

Essentially it allows you to build animated slides with Python, which is used a lot by math content creator and the like, I think Typst is uniquely well suited for such a tool, but it would likely require some custom syntax, and a lot of additions to the current global scope

[sturdy sequoia]

@left night I think it's quite interesting that because destructuring is compiled ahead of time, things like this are already supported without me even thinking about it: https://github.com/typst/typst/pull/3308

[left night]

That's how it is intended to work

[sturdy sequoia]

Awesome 😄

Then it... just works™️

[left night]

If I want to compare how my stuff compares to main/release without switching branches and stuff, I just open the web app 😉

[sturdy sequoia]

I do too sometimes, but I should be studying

and I am too lazy to procrastinate any more 😂

[left night]

I only sort of agree. I would also like to split it again in the future (just in a better way), but there is also a trend in Rust that some large projects that were previously split up into many small crates go back to fewer larger crates. One example is tokio where the core crate is larger than typst.

[sturdy sequoia]

I think perhaps making typst more "extendable" with the ability to have more dynamic stuff, and operator overloading (i.e defining addition for custom values, etc.) it could also work just fine

custom join too etc.

that way typst as a crate is more extendable

[left night]

yes, but I think it would be close to impossible to make eval not depend on some base types

[sturdy sequoia]

and I mean operator overloading from rust

[sturdy sequoia]

that I agree

Dict, Array, Value, Str, etc. have to be in for it to even work

[left night]

I think we can potentially have typst-eval depend only on typst-core, which is the bare minimum

bug then again typst-layout would require further base types like Length

the typst-core / typst-whatever split would be fairly arbitrary based on what is needed elsewhere and what isn't

which is frustrating because when you add something new, you might need to move a large amount of code from typst-whatever to typst-core

[untold turret]

My understand is we don't split them early, which will cause many additional unnecessary code to tight crates together again. If we have some golden point to split, we would like to split them. For example, typst-syntax is nice as an individual crate and we've used them in typstfmt.
In short they large projects was spliting code early in some bad point, and find unideal thing. They large projects have to merged them together to reduce costs to write additional code. They large projects still don't have some golden point to split so keep a large core crate.

[left night]

I think for the current speed of iteration, it is good that there is just one main crate. If the major planned features are implemented, we can then think about what a golden split would be.

I also hate the fact that I need to anticipate what subcrate we might need and reserve them on crates.io to be sure that we can use the name in a future-proof way.

[sturdy sequoia]

Yeah but that's a whole other can of worms

[left night]

There is this very nice RFC where multiple crates are part of one package

[sturdy sequoia]

Ah, that's nice

it's like namespaces, but compatible with the current impl 😂

[tight glade]

hot

[left night]

@sturdy sequoia the PR I opened also gives a bit of a speedup compared to main on my machine. curious if you can reproduce that.

[feral imp]

Masterproef evidence or it didn't happen @sturdy sequoia

[sturdy sequoia]

I'll do that tomorrow 😉

[sly pecan]

The show/set one?

[left night]

Yes

[sly pecan]

I guess it's tricky to benchmark since you would also have to make sure the output is the same

[left night]

I haven't looked but I wouldn't expect it to be a lot different

While the PR does make some breaking changes, it mostly affects code that was non-sensical before.

[sturdy sequoia]

@left night Actually, I have a case where my VM is more permissive and I want your opinion:

this is a test from the suite:

// Count labels.
#let label = <heya>
#let count = counter(label).display()
#let elem(it) = [#box(it) #label]

#elem[hey, there!] #count \
#elem[more here!] #count

I tried modifying it to:

// Count labels.
#let label = <heya>
#let count = counter(label).display()
#let elem(it) = {
  box(it)
  label
}

#elem[hey, there!] #count \
#elem[more here!] #count

On my VM, this works, on the webapp it's refused

Should it work or should it be refused? 🤔

It is trivial for me to do the old behaviour, so it's really a design decision, not a constraint in any way shape or form

(literally one line of code)

[cunning wadi]

I kinda like it

[sturdy sequoia]

Next point of contention, this code:

// Ref: true
// Test continue while destructuring.
// Should output "one = I \ two = II \ one = I".
#for num in (1, 2, 3, 1) {
  let (word, roman) = if num == 1 {
    ("one", "I")
  } else if num == 2 {
    ("two", "II")
  } else {
    continue
  }
  [#word = #roman \ ]
}

It works, except that my code still tries to destructure after calling continue since the next flow opcode is right after which makes this not work 🤔 I can probably special case it though

I can also make destructuring imply a flow to avoid issues

[untold turret]

I remember a label attachws to its previous content automatically, but documentation also remind it doesn't work in "code mode".

I think it is a limitation, and your VM extends it.

[sturdy sequoia]

Essentially my VM forces you into "content" mode (in terms of joining of values) once you try and join a label

[cunning wadi]

what do you mean by it works? that it does not throw an error due to not being able to destructure none?

[sturdy sequoia]

I admit it might be a bit weird

[sturdy sequoia]

It works in the sense that the control flow works, but the destructure fails

[cunning wadi]

ah, I think that should be changed then

let (a, b) = if x.len() == 2 {
  x
} else {
  continue
}

I would expect such a thing to just work

[sturdy sequoia]

yeah I know, but it's because of the weird control flow scheme

it happens right after destructuring, not before

But as I said, I can just manually append flow opcodes where necessary

like before an assignment

[left night]

It does seem reasonable, but I'm not 100% sure yet whether it will have unintended consequences and, in particular, whether it will be future compatible with content = value. Is it equivalent to having content + label join into labelled content?

[left night]

The current let binding code also has a special case to handle this, so I think it should be the same here.

[sturdy sequoia]

exactly, it basically joins label to the previous content

[sturdy sequoia]

I did that too, I just generate a flow opcode before calling the destructure opcode

[left night]

okay. the problem is that when content = value, every element is its own type and to roughly retain the current way things work, the joining rules need to be adapted. basically any two values need to join into a sequence. any ++ label (using ++ for join here) could probably still do labelling as a special case, but I need to think more about this.

[sturdy sequoia]

Yes, the reason I currently changed the behaviour to the same as main is that it's non-trivial to label sequence elements that are in the joining "value"

[left night]

do you mean that it would label the sequence rather than the last leaf?

or the other way around?

[sturdy sequoia]

yes

if you do content ++ content ++ label, does that mean sequence[content, content] ++ label or sequence[content, content ++ label]?

I'd argue it's non-trivial

take the case #f() <this>, where f produces a sequence

[left night]

yeah, that might be the reason this doesn't exist on main (or nobody ever thought about it, can't remember)

[sturdy sequoia]

yes I think it's better if that doesn't work as it's less error prone imo

and more consistent

[left night]

I think supporting syntactically labelling in code mode might be nice (i.e. figure(..) <label>), but arbitrary labelling should perhaps be done via a function. Maybe the same should actually apply in content mode. It's more predictable that way.

It also fixes the problem that people from time to time try = Heading #label and the label attaches to the text rather than the heading

[sturdy sequoia]

how about figure(..) <label> works, but

figure(..)
<label>

doesn't?

[left night]

yeah, that's sort of what I meant

this is the kind of thing that is either super easy to parse or a parsing nightmare

if we want to make the breaking change for content mode, we should wait until type rework probably because it'll be quite the breaking change

I'm hoping to batch a bunch of breaking changes up and then make one very breaking release

[sturdy sequoia]

For the VM I am trying not to break things and so far I am achieving it which makes me happy 😄

I mean, almost everything is broken

but what works isn't

😂

[left night]

^^

[sturdy sequoia]

Do you want to know the trickiest bug I have fixed so far?

I was debugging a test that would only fail if it was a test, not as a standalone document. Is so happened, that I was creating a local variable with the name of a closure (to allow recursion) but the closure was supposed to be anonymous, but it was not because I accidentally gave the compiler the module's name (counter) which means that when it did counter(heading) it was re-invoking the module

💀

That was a very weird one to debug

[left night]

oh no

[sturdy sequoia]

BTW, once the VM actually works, will you and I be able to schedule a call to implement tracing (like seeing execution of nodes, etc.) because I have no idea how it all works and how to integrate it. I'm talking in 2-3 weeks most likely

[left night]

sure, we can discuss it then! just for clarification: do you mean tracing as in hover tooltips?

[sturdy sequoia]

yes exactly

[sturdy sequoia]

@left night outside of doing some bit magic, do you think there is a way that a Span could become align(4) or (ideally) align(2)?

😄

I could make it #[repr(packed)] but it's a bit unholy

[left night]

I think you could store it as [u8; 8] and boom, it's align(1). Casting between that and u64 shouldn't be a problem as long as you do it by value rather than by reference (i.e via as_ne_bytes)

[sly pecan]

@sturdy sequoia have you compiled your thesis yet?

[feral imp]

I can't wait either...😅 😅

[sturdy sequoia]

No, I have changed a few things I’ll try again today

[sturdy sequoia]

Well, I had this theory that: less registers = faster VM

I was right

So one optimization I'll be implementing: several sizes of VMs, and it will select one depending on the number of registers you need (from 4 -> 256)

(so 4, 8, 16, 32, 48, 64, 96, 128, 256)

it's actually surprisingly easy to do with const generics and an enum 😉

[feral imp]

Phew. That rarely work, because const generics are limited.

But it's good that you can make do!

[sturdy sequoia]

My idea is basically to have a Vm<const N: usize> and then an enum like:

enum VmSizes {
  S8(Vm<8>),
  S16(Vm<16>),
  ...
}

easy as it gets

[cunning wadi]

wouldn't that just have the enum be the size of the largest vm?

or are the registers heap allocated?

[sturdy sequoia]

hmmmm

I didn't think of that!

Probably would need to be a function instead

like

fn eval(...) {
  if min_reg <= 8 {
    Vm::<8>::eval(...)
  } else if ... {
    ...
  }
}

And hope the compiler is smart enough to figure it out

[cunning wadi]

yeah that could work

[sturdy sequoia]

As it turns out tablex needs more than 64 registers 💀

[cunning wadi]

I think you need a fallback stack once too many variables are needed at one time

uh, actually not a stack

just a heap allocated (resizable) array

[feral imp]

didn't laurmaedje have some funky pattern for this?

[sturdy sequoia]

probably yeah

I mena there's a good change that just using the heap would work

and having infinite registers

[cunning wadi]

I was just writing that

but yeah

or another idea

you could have ```rs
trait Storage {
fn read(&self, reg: Register) -> Value;
fn write(&self, reg: Register, value: Value);
}

impl<const N: usize> Storage for [u8; N] {}
impl Storage for Box<[u8]> {}

struct Vm<S: Storage> {
registers: S,
}

[sturdy sequoia]

ah yes, we can go back to heap if need be

that's clever

and small VMs can benefit from the full set of optimizations by having small register arrays

[cunning wadi]

exactly

only downside might be code size

but I think it will be fine

[sturdy sequoia]

I think the VM is already quite chonky 💀

well the compiler is the chonky bit

[cunning wadi]

I mean code size of the compiled object

but yeah

[sturdy sequoia]

yes but that's a one-time cost: when "entering" the VM

[cunning wadi]

well, not quite
it's the download size of the wasm binary
it's the amount of icache that is taken up by that part of the vm
it's the initial memory accesses that might not be quite as efficient due to code being as close together

but I expect it not to matter too much in the grand scheme of things

[sturdy sequoia]

true, but executing code will likely still be slower 😐

[sly pecan]

You're never going to get to the point of actually compiling actual documents are you? 😂

[sturdy sequoia]

I mean I'm trying

[untold turret]

why does it depend a const generic size of registers?

[sly pecan]

Maybe too hard!

[untold turret]

It will generate 10 copies of VM code if you uses Vm<4,8,16,32,48,64,96,128,256>

[sturdy sequoia]

to optimize its size based on the actual needs

[sly pecan]

Just be careful so you don't overwork yourself!

[sturdy sequoia]

Yes!

[untold turret]

How do we use the generic constant? If it is for a static-sized register array, there will no difference with an Arc register array or even a Vec register array.

[left night]

I also don't yet understand why you need to instantiate the Vm over and over again instead of just storing the registers in a Vec and only using a smaller amount of the Vec. I can't imagine that the one allocation will be the costly thing.

[glossy shore]

I don't see how this is different from 1 + break + 3

[glossy shore]

#{
  [ one ]
  [ two ]
  label("hi")
}

is query(<hi>).first().elem [two] or [one two]

[glossy shore]

this is where a never type (and uh... value) might help

[left night]

a never value, huh ^^

[left night]

what do you mean?

[sturdy sequoia]

Well that's the thing, I haven't tested yet, my idea with limiting the number of registers is to (hopefully) guarantee that they're in L1 cache

But I don't know whether this has materialized and I haven't profiled the compiler yet

All I know is that less registers translate to double the performance

[left night]

By why can't a Vec of registers be in L1 cache?

[sturdy sequoia]

it can, but since the array would have been on the stack the likelihood of it being in L1 cache should've been higher

[glossy shore]

The solution that was settled on seems reasonable to me, I've no more to add

[glossy shore]

Oh that's smart

[left night]

is that really so? if the vector is constantly being accessed and still not in cache, I would blame the CPU for being dumb.

[sturdy sequoia]

fair

Anyway, I'll give it a try too, I'd just like the VM to work now 😭

[glossy shore]

Dherse's idea is that the registers would share the cache together with the Rust variables

If I understand

[sturdy sequoia]

There is a weird behaviour that makes tablex not compile and I don't know why

[left night]

I am just very concerned about code complexity, compile times, and generated code size with heavy use of const generics across the entire eval pipeline.

[sturdy sequoia]

I mean yes, but the registers are rust variables in a way 🤔

[sturdy sequoia]

right now there are no const generics

so not much to worry about

yet

https://tenor.com/view/evil-laugh-gif-25608698

[left night]

yeah, that's why I'm arguing heaveily against it now

[glossy shore]

well but if one's on the heap and one's in the stack...

[left night]

much of the values being operated on will also be in various places of the heap though

[sturdy sequoia]

I still think that having const generics using @cunning wadi's Storage trait is good for small Vms (i.e that need like < 16 registers) because those are likely very short code, very short lived so not allocating in those ones is probably a good thing

[glossy shore]

how big is a register?

[sturdy sequoia]

16 bytes iirc

[left night]

Value is 32 bytes

[sturdy sequoia]

really?

damn that's chonky

so registers are 32 bytes 😄

[glossy shore]

chonk

[left night]

but even with a fully reworked value representation, I don't see how to go much lower

to store an integer inline, we need 8 bytes. we need to store type information somewhere (most likely a pointer), that's another 8 bytes. and then we need some pointer to extra optional stuff like labels and locations. so that's 24 bytes min. if we want 16 bytes of inline capacity (which I think we want), we're back to 32 bytes.

[glossy shore]

16 registers is half a meg

[left night]

megabyte? half a kilobyte.

[glossy shore]

yes lol

🤦‍♀️

[glossy shore]

we could store just one pointer maybe

[left night]

the type info pointer could indeed be moved into the extra optional stuff allocation. not sure whether that's worth it as it would add extra branching and potential indirection to all type checks. would need benchmarks.

but in the inline case, we still need at least one pointer in addition to the inline value

and 8 bytes of inline storage would not let a short string be inline, defeating the entire purpose of EcoString (which is 16 bytes)

[glossy shore]

Technically we could optimise way further by exploiting pointer repr

acheieving more than 24 bytes of inlined string

[sturdy sequoia]

@left night @glad urchin @sly pecan @tight glade @feral imp I have made TREMENDOUS progress: IT COMPILES TABLEX

🚀 🚀 🚀 🚀

I ran the whole tablex-test.typ and it all seems correct to me

[atomic violet]

is it fast?

[sturdy sequoia]

IT COMPILES MY THESIS

OMG

OMG

OMG

I DID IT

IT WORKS

🎉

🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀 🚀

[sturdy sequoia]

😶

I won't say 😂

[sly pecan]

"no"

[atomic violet]

lmao

I'm building it 👺

[sturdy sequoia]

not yet, I haven't pushed

[atomic violet]

oh

[sturdy sequoia]

I just did 😎

BTW, it is really slow atm, don't judge me

[atomic violet]

ok goddammit do I cancel now?..

[sturdy sequoia]

yes?

I'll try and figure out why it's so goddamn slow

[atomic violet]

is compilation slow or the interpreter?

[sturdy sequoia]

it's the VM

but I know why

(I think at least :D)

Small functions are currently quite slow

[feral imp]

Is it inlining?

I must admit I've less than a fig clue what you're doing...

[tight glade]

Hourra! Sad its so slow tho 😂

[untold turret]

[sturdy sequoia]

that's actually not a bad idea? 🤔

[sturdy sequoia]

Ok, so I did the change

and it's about 20x faster in debug

time to see in release 😄

It also simplified a ton of stuff which I like

[sly pecan]

I read this and thought you meant it was 20x faster in debug than release

[sturdy sequoia]

no 😂

[sly pecan]

Wondering what kind of cursed stuff you were doing

[sturdy sequoia]

I will not, in fact, answer that

[feral imp]

Wise.

[sly pecan]

What you say can and will be used against you.

[sturdy sequoia]

I plead the fifth?

Time of dynamic number of registers, maybe that'll work 💀

[sly pecan]

I will neither confirm nor deny that I murdered that man

[sturdy sequoia]

WHY IS IT SO SLOOOOOOOOOOW 😦

[glad urchin]

unsafe { std::transmute((******arc).wrapping_offset(engine.among_us)) }

[sly pecan]

I don't get that, but I'm sure it's super funny

[glad urchin]

I don't think you're supposed to get it

[sturdy sequoia]

https://tenor.com/view/sussy-among-us-sussy-amogus-among-us-sus-sussy-gif-26236076

[feral imp]

It's fast in debug and slow in release?

[atomic violet]

have you profiled it? what does it say?

[sturdy sequoia]

I haven't yet

[sturdy sequoia]

it's faster in debug than it used to be, but in release the difference is much lower

[sturdy sequoia]

Ok, so it's much better

but still... not as good as I'd like 😦

[feral imp]

Alright. Progress is progress. There is a lot of experimental / novel shit here, so do take time to just reflect and appreciate that it is growing organically.

[sturdy sequoia]

I'm sure it's just some dumb stuff that's slowing down everything

I am profiling atm

[atomic violet]

I did perf. I am no expert in hashing, but goddam, that's a lot of hashing.

I can't find anything not about hashing, actually

[sturdy sequoia]

ooooooooooooooof

ooooooooooooooooooooooooooffffffffffffffffffffffffffffffffffffffffffffff

I did a poopsy it seems

[atomic violet]

aha nevermind

[sturdy sequoia]

Ok, I just trippled performance

now it's... as fast as main

😭

[atomic violet]

what went wrong?

[sturdy sequoia]

too much hashing

I just need to figure out where the rest is

Wait, I think I know!!!!

I did not, in fact, know

[atomic violet]

I was going to say "... and you will first profile it to check if you are right or not?.." but decided not to...

[sturdy sequoia]

I mean, there is too much hashing

I'm trying to figure out why

[ornate merlin]

May be you should switch from SipHash to another hasher?

For example hashbrown uses AHash as the default hasher, which is much faster than SipHash.

[sturdy sequoia]

We rely on the quality of SipHash to make the assumption that there are no collisions

[ornate merlin]

You do not need HashDoS resistance inside compiler in any case

[atomic violet]

we kind of do though...

I think hash collision can be easily abused to extract data from unrelated sources

so, say, a package would be able to access the cached read file

that's bad

plus even if all hashing suddently become something like xor hashing, it would have not helped here

it's an algorithmic issue caused by inaccurate use of comemo (I assume)

[atomic violet]

actually, I bet you can do even worse, can't you?..

[ornate merlin]

You do not need to worry about collisions. In any case AHash provides the same level of collisions as SipHash.

It just doesn't provide HashDoS resistance

[atomic violet]

like what if you replaythe changes to a different object?

can you break some of the safety guards somehow?

[atomic violet]

We do need to care about hash collisions. comemo relies of high quality hashing

[ornate merlin]

High quality hashing and HashDoS resistance is not the same thing.

Actually SipHash just recreate hasher every time.

[atomic violet]

I know it's not the same thing, but I don't understand what you are saying

[ornate merlin]

I mean that if you compare AHash and SipHash regarding to the collision possibility, so they are pretty the same.

[atomic violet]

ah, so you are just proposing replacing siphash with ahash?

ahash is 64 bit though

https://github.com/typst/comemo/issues/3

[feral imp]

?

look, isn't it just letting Dherse work at it a bit more, to figure out why there are lots of seemingly unnecessary hashings, and somewhere, sometime later it can discussed to change the hashings?

[atomic violet]

yeah ofc

switching hashes now won't give anything

current VM performance is a bug

[ornate merlin]

Yes. SipHash recreate hasher every time when you change the size of hashmap. When the hashmap grows from 3 to 7 and so on.

AHash at the same time created one time, when you create hashmap, and it stays the same during the life of hashmap

[ornate merlin]

I actually don't look at the code, so may be it can be improved. But AHash really fast. It can be 10 times faster than SipHash, especially when you use simple keys like integers, etc

[atomic violet]

Is there 128 bit version of AHash? If not, it's basically useless.

64 bits are not enough to prevent collisions

[sturdy sequoia]

We'd need to talk about this with @left night

Hey, it's now faster than main 🎉

[ornate merlin]

Of course😊. But you need to remember that even if the output hash doesn't have any collision, they can occur when you calculated the remainder (u64 / buckets). And because current rust hashmap implementation use sse2/neon instructions, you probably dos not notice difference on the small size tables (up to 48 elements, I think).

And AHash passes the full SMHasher test suite (https://github.com/tkaitchuck/aHash/blob/master/compare/readme.md#Quality), so it's output is pretty good

[atomic violet]

Hashes are not used for hash table directly, they are used for comparison

in other words, there is a chack that hashes are equal, object equality is not checked

moreover, the "rehashing creates a new hasher" argument is notr applicable here afaik, because the hasher for a comemo hash table is separate from a hasher for tracked objects

[ornate merlin]

Hm.. Actually you are wrong.

Hashbrown stores the only first 7 bits of the hash, and all other comparisons are done on real keys, not their hash values

[atomic violet]

I think there is a misunderstanding going on. I am not talking about hash tables in general.

Here is how comemo works: it has a big hash table for every memoized function call, from the 128bit hash of its arguemnts. Every time the function is called, it hashes it's arguemnts (not quite, but let's pretend it does...) and retrieves the memoized result. The values themselves are not compared.

[ornate merlin]

Oh. May bad 😅. I think that we talk about the hashmap implementation

[atomic violet]

yeah, it's ok, everyone makes mistakes

that's why it needs 128bit hashes, 64 bit is just not enough, so a lot of hashers are basically out of question

[atomic violet]

@sturdy sequoia once you resolve the hashing problem, can you try something? It's probably a bad idea (big 50/50... well... 5/90/5, where 90 is "does nothing"), but at least it's not too hard to check and if I am right I want to be remembered as the best software engineer to ever exist.

In vm/mod.rs, in enter_scope, try boxing the new VM before running vm.run(engine). I have a theory (not confirmed by anything, just an educated guess) that VM is too fat for the stack and it causes worse stack performance because hardware hardware blah blah blah frontend prefetchers L1 stack engine blah blah blah. Of course, preferably the same VM (and same registers) should be used everywhere, but I assume it's not an option.

That's what I was able to infer with my eyes, at least. enter_scope looks the sussiest.

[sturdy sequoia]

Look into the latest commit 😉

I mean, VMState is still on the stack, but the registers are on the heap

I'll also try removing the stacker calls

as I have the suspicion that they're really bad 😂

[atomic violet]

I have looked at stacker source code for a bit, it doesn't look that bad

it just maps more pages

[atomic violet]

did it improve anything?

[sturdy sequoia]

yes, it immensely improved perfs

I also ditched the whole VM thing as it required some unsafe

so the VM is fully safe afaik

[atomic violet]

omg I am a genious lol

[sturdy sequoia]

And it reuses registers

for nested scopes

[atomic violet]

yeah that's basically perfect

[sturdy sequoia]

and registers are infinite now

[atomic violet]

so... stack?

stack based VM ftw let's goo

[sturdy sequoia]

kinda, but there is agressive reuse of registers

I don't know if you saw but in the compiler there is a RAII register called RegisterGuard that frees registers for re-use as soon as possible 😎

[atomic violet]

yeah I have not looked at the compiler, only at VM

I see 👁️👄👁️

[sturdy sequoia]

Performance of eval has improved by 20% with the commit I'm about to push

eval = the VM in this scenario

my problem now is that function calls are... slooooooooooooooow

Much better than an hour ago

but too lsow

BTW, I just pushed

[atomic violet]

just function calls, or scopes in general?

[sturdy sequoia]

calls now

scopes are fine since they no longer involve growing the stack, etc.

I KNOW HOW TO MAKE THE REGISTER TABLE SORT OF DYNAMICALLY SIZED

USE A SmallVec<[Value; 16]>

Makes small function calls cheaper by not allocating!

I AM A GENIUS

https://tenor.com/view/hahahaha-gif-27342590

(time to test it )

[atomic violet]

if only there was a way to not reinitialize registers every funcition call...

hear me out...

ABI

(/s)

[sturdy sequoia]

ABI?

Wait no

no no nonononono

No

I objectify

[cunning wadi]

I like

[left night]

I thought about that but expected that you would consider the access overhead too high.

[sturdy sequoia]

Yeah, there are literally zero gains

I have reached the point where eval is about 5x faster than main

But I was honestly expecting a 10x 😦

I guess eval is not as slow as I thought it was

And the impact on my thesis (in spite of tablex) is surprisingly low

[cunning wadi]

I assume that's because most of the time is spent calling short functions that aren't much more than glue code

and well, function calls aren't that fast it seems?

[atomic violet]

inline them

[sturdy sequoia]

indeed

[sturdy sequoia]

I am seriously considering it

it's almost trivial with the current design 🤔

I just don't know how I would deal with arguments (checking them)

but I could only do it when arguments are "simple"

(no spread, etc.)

Ok, I am now working on improving loop performance by removing allocations and dynamic dispatch

[sturdy sequoia]

Fun fact, using #[repr(packed)] on opcodes does improve performance by a very measurable margin!

[lunar kettle]

what's the current status on how much faster your thesis compiles? 👀

[sly pecan]

1 millisecond

[left night]

I think what would be very interesting just to get a feeling for what is and isn't possible here is to write a reasonably complex evaluation-heavy script in Typst and Python and compare speed. I'd be curious which orders of magnitude of difference we're talking about here.

[sturdy sequoia]

3% irrc

[sly pecan]

https://tenor.com/view/jeremy-clarkson-speed-speed-and-power-gif-27212846

[sturdy sequoia]

I'm honestly quite dissapointed 'cause it means that (simple rule of three) eval was 3% of the total execution time

😭

[feral imp]

Are you still working at it? Or do you think this current version does indeed reflect what's possible with a VM?

[sturdy sequoia]

Wait my math is wrong

who cares, eval is not nearly as much as I wanted

[sturdy sequoia]

There's definitely room for improvement

I think closure calls are wayyyyyyyy too expensive for what they do

[atomic violet]

I can do this tomorrow

https://tenor.com/view/oogway-my-time-has-come-gif-8019684

[sturdy sequoia]

I removed the eval module

and it gives an idea of just how MASSIVE this PR is

💀💀💀

[feral imp]

It's a lot. But there is no way that improvement from now on won't entail massive efforts like this....

[sturdy sequoia]

To be fair, there's also the fact that my thesis is just... not that heavy in the evaluation

I thought it was bigger than that

[sly pecan]

Could be more in other documents?

[feral imp]

Cetz heavy docs must use eval...

[sturdy sequoia]

most likely

anything with CetZ as @feral imp said

[untold turret]

@sturdy sequoia A quite important key for heavy computing. Would you like to do scalar specialization? I mean you stores floats in 32 bytes registers but they could only be 8 bytes, and importantly you may do Value::Float::add/mul/sub/div per instruction, which is very expensive.

[sturdy sequoia]

I don't have type information 😐

[untold turret]

you can do it at runtime

since typst doesn't have runtime, all of them are at compile time.

[sturdy sequoia]

hmm

I wonder if that would really help

[untold turret]

I just point out why a such vm doesn't quite help the heavy cetz docs.

[sturdy sequoia]

maybe you're right, I just don't know how I'd do it 🤔

I had to manually rebase 47 times in a row for some reason

The VM was broken by that

😭

[glad urchin]

did you not keep a backup branch?

[sturdy sequoia]

😐

[proven umbra]

Git stores a rev pre rebase for you.

Search git reflog. All actions are logged there, and as long as you do not git gc, git keeps "backup" references for you.

[untold turret]

🤔 I think this is a JIT way to get native code performance in VM, which is very hard. But there would be a possibly way that we embed wasmtime and leverage wasmtime to do JIT by emitting wasm code to wasmtime.

https://github.com/bytecodealliance/wasmtime/tree/main/cranelift

🐱 @sturdy sequoia Forget the special cases. VM in parallel with rayon should benefit to both local typst and web typst. That may also beat main typst.

[sturdy sequoia]

@proven umbra it's funny but my VM is finding bugs in CetZ

With some variables being used that don't exist 😂

[proven umbra]

😄 Oh…

You have lines/functions so I can look to fix that?

[untold turret]

I believe align can quite benefit from jit.

[sturdy sequoia]

align?

Anyway, I'm off to bed

gn everybody ❤️

[untold turret]

In the picture

[sturdy sequoia]

ah right

[untold turret]

gn

[sturdy sequoia]

makes sense

[atomic violet]

oh-oh @sturdy sequoia

hopefully it's reproducible

oh wait, it's just stack overflow, false alarm

[feral imp]

😛

Does it work on main?

[atomic violet]

just need a recursion limit and it's all should be ok

[atomic violet]

yeah it does

[atomic violet]

@sturdy sequoia ok a real bug this time, patterns without let don't compile

#let (x, y) = (1, 2)
#(y, x) = (x, y)

probably covered by tests but still want to make sure

[atomic violet]

Oh no... typst is soo slooooowwww..... 😭😭😭😭😭😭

I have disabled memoization for closure::eval to make sure it won't just get OOM'ed..

and it crunches rays for like an hour and 20 minutes now

and python just does the whole thing in less than a minute

😭😭

Lemme check main

[atomic violet]

oh it finished

[feral imp]

main is fast?

[atomic violet]

vm with no closure memoization is 1:22:xx

main will OOM

python is like... a minute... haven't measured yet, it's pretty fast

I will check for a smaller resolution now

oh interesting

VM is slower, apparently

64.14 secs - VM, 34.24- main, and coughs 2.61 - python

[sly pecan]

Python is a low bar too

[atomic violet]

compiling VM again with no my hacks to make sure it's not me

[atomic violet]

well... tbf, I would be impressed if typst got to like 1/3 of python

because duh, everyone says python is slow, but it doesn't mean it's not optimized

it does have a good untyped VM

[atomic violet]

actually, my raytracer may rely on comemo in one place, so I assume it may not count...

but also...

python does not have comemo at all, so it's still bad

damn, my code is so shit I can't even fix it properly...

the render itself is pretty dope though

[atomic violet]

ok, VM 39.35

yeah, memoization helps in one place...

[feral imp]

God I love that you're here..

[sturdy sequoia]

really? 😱

[sturdy sequoia]

W-A-T????

😱

[sturdy sequoia]

where did you add memoization?

[atomic violet]

the evaluation of the closure

I previously removed it

it would not have finished otherwise

[sturdy sequoia]

hmmm

And the VM is slower?

That's extremely dissapointing

[atomic violet]

looks like it

but I have not profiled it

[sturdy sequoia]

Guess I'll do just that

missa sad

@atomic violet are there lots of small closures?

Because I have the suspicion that freaking closures are too goddamn slow

[atomic violet]

so, generally, I tried to minimize them

and I did pretend to be a guy who tries to optimize a lot in my code

(without measuring anything)

[sturdy sequoia]

that's how we do 😎

[atomic violet]

and there are a bunch of small functions, but I try to not call them in hot spots

there is a lot of spreading

and destructuring

that's basically the main way of moving data around there

and as a consequence a lot of functions have a lot of parameters

[sturdy sequoia]

I have the suspicion that I implemented spreading 💩-ily while trying to make it faster 💀

[sturdy sequoia]

I'm unsure whether destructuring is any fast atm

[atomic violet]

The hottest functions should be m33mul, intersect, cast-ray and cast-ray-through-transparent, and a few closures for rendering heart, typst guy, and tiled floor. Maybe it would be useful to run a sampling profiler on typst and on python to compare where the slowness is likely occur

[sturdy sequoia]

I'll run it on my end and see what's going on

@left night I'm having a pretty big issue, for some reason, clalling Route::contains causes a stack overflow 💀

Do you know what could be causing this?

Here is an example from a stack trace

is goes on and on and on and on

I think I figured it out!

The check for cyclic evaluation was inside of a memoized function instead of the top level and that was the issue, maybe? 🤔

Yes indeed, that was it now it just panics 💀

I had forgotten to check for cyclic import which is now fixed

[left night]

A check for cyclic evaluation inside of a memoized function should be fine. That's the whole point of the Route being Tracked. The check is recursive itself.

[sturdy sequoia]

yes but here it was actually recursively importing

but it wasn't actually detected

because it was only being done in the compilation stage

[left night]

ah okay

[sturdy sequoia]

it was a bit weird, but there are still a few things I haven't ported over

[left night]

Regarding performance improvements, I wonder how much of the time is actually spent on walking the AST etc (where a instruction-based VM should be faster) and how much is spent on "runtime" things like ops::join, inside functions operating on Values etc.

[sturdy sequoia]

that's probably the issue indeed

this is where having types would be useful because I could pre-allocate a lot

[left night]

We should probably figure out a way to profile that more precisely

[sturdy sequoia]

yes, but adding #[time] everywhere would be ungodly 😂

[left night]

I fear that time would have too much overhead, too

[sturdy sequoia]

@atomic violet on my end, your raytracer takes 18s on the VM, I'll try on main now

[sturdy sequoia]

yes, it's handly to get a rough idea, but not good for fine grained stuff

[atomic violet]

Performance counters!

well, it's not that simple tbf 🤔

Maybe crunch it though callgrind? Count instructions instead of actual time?

[left night]

You could have, just for some quick tests, a cheaper version of #[time], that measures just one thing at once and its global effect: Effectively, a global mutable static that is increased by the time spent in a single leaf operation every time in runs. And then compare that with the full time spent. This might work better than a flamegraph at showing the full effect of many small leaf calls.

I am not sure how much overhead Instant::now() incurs, but it would be easy to check whether this kind of instrumentation increases the runtime significantly.

[sturdy sequoia]

Instant::now is super slow, but if we accept having a linux only version in the CLI (gated with a platform flag) we could do that super cheaply

linux and macos *

[sturdy sequoia]

I agree, it has a specific name too in the nomenclature but I forgot what it is

and time could just generate a per-function counter

[left night]

I was more thinking about annotating a function of interest with a special attribute just temporarily

Rather than actually committing that to the code base

[sturdy sequoia]

ah right

[left night]

So it doesn't matter whether it's linux/mac only

[sturdy sequoia]

@atomic violet is that the expected result?

or is my VM broken 💀

[left night]

At least for starters

[atomic violet]

looks good

[left night]

poor Typst guy's eyes

[sturdy sequoia]

I'll maybe try that

[sturdy sequoia]

ikr

with main it runs in 9.7s versus 19s on the VM

😭

[atomic violet]

you are running this right?

[sturdy sequoia]

yes

no

I'm running the gist

[atomic violet]

oh, yeah

gist is a bit different, but should be fine

[atomic violet]

I made a bug in that one

[sturdy sequoia]

What hints to me that the VM is doing too much work is the size of the timings files

with main they're about half as big

but the VM shouldn't be doing any more timed operations

🤔

which makes me think it's somehow running the code... twice?

[atomic violet]

here is the equivalent unbugged python version

just in case

[left night]

so was this the final verdict? Python is 13x faster?

[atomic violet]

Let's see on that version

[left night]

because, if yes, I would be pretty happy with that

[atomic violet]

2.14 python, 29.84 VM, 24.75 - main 0.10

I am a dum dum

I was calling 0.10 "main" this whole time 🤦‍♂️

[atomic violet]

so yeah, about that

[feral imp]

How about main main?

[atomic violet]

one sec lemme build it

[sturdy sequoia]

That's main

That's the VM

what the heck is going on at the end

[atomic violet]

it's chillin' after a hard day of work

it's fine, give it a break

[sturdy sequoia]

as far as I can tell it's this code

I guess looping is very slow?

[atomic violet]

It may be joining?..

[sturdy sequoia]

hmmm

[atomic violet]

because that's the only place where content is joined iirc

[sturdy sequoia]

that's makes sense

[atomic violet]

main main is 16.74 👀

oh wait

usr time: main - 14.83 vs 0.10 - 16.87

wth was it doing for 7 seconds?...

[left night]

so Python is just 8x faster? 👀

[atomic violet]

seems like it

[feral imp]

if that's true then typst is doing pretty good.
I love how the comparison is to latex, but this is a true behemoth to measure up to.

[atomic violet]

I would need a proper measuring procedure so name a standard deviation ofc, but the order seems to be about ~6-9x

[atomic violet]

I am NOT rewriting that shit to latex

[left night]

that's honestly much faster than I would have expected

[atomic violet]

What does 0.10 spends 7 seconds of system time doing? Writing a pdf?

[atomic violet]

and its so consistent as well: 7.09 - 7.5 seconds

[sturdy sequoia]

@atomic violet so I think you're probably right, it's probably joining that's so goddamn slow

https://tenor.com/view/why-huh-but-why-gif-13199396

[sturdy sequoia]

Ok I do think that looping was abnormally slow

I think I just fixed it

time to see

[lunar kettle]

so?

You can’t just leave us hanging like that!

[sturdy sequoia]

it improved by like... 100ms

😄

[sly pecan]

is the python code doing the exact same thing though?

[atomic violet]

the result is identical

it should do the exact same thing

[sly pecan]

I'm not talking about the result

[atomic violet]

unless github copilot translated it wrong and I missed it

[sturdy sequoia]

Ok so it's not joining that is slow

Than I have no fucking idea what is slow

😭

[atomic violet]

and considering that even unused variables got translated, it should be the same

[sturdy sequoia]

it must be function calls?

[sly pecan]

Take a break my dude. You can come back to it later

[sturdy sequoia]

https://tenor.com/view/star-wars-kylo-ren-i-know-what-i-have-to-do-i-know-what-i-must-do-adam-driver-gif-26011680

[lunar kettle]

Just to make sure you are running in release mode right? 😂

[sturdy sequoia]

OF COURSE

[atomic violet]

what's release mode?

(jk)

[sturdy sequoia]

So, I have narrowed it down to function calls

Now what I don't know is if it's native function calls

(i.e in the global scope)

or VM-ed function calls

which I assume are at fault

wait no

function calls are fast

[sturdy sequoia]

Ok so somehow reading values from the VM causes hashing

I have no idea why

So, as it turns out, it appears that accessing global values is the slow bit

[lunar kettle]

is it easy to fix?

[sturdy sequoia]

I don't know yet

[sturdy sequoia]

For some reason it hashes like crazy

but even my attempts at improving it don't help

ok so accesses are indeed the slow part

for some reason

[atomic violet]

let me callgrind it

btw, I don't know how comemo works, but if there is a function like

#let f(big-arr) = {
  big-arr.at(0) = big-arr.at(1)
  big-arr
}

how is it memoized exactly? What are the constraints here?

[sturdy sequoia]

I mean did identify the slow part of the code

I just... don't know why it's slow

it's access.rs in the typst::vm

I did at a typst_macros::time to it and it's indeed extremely slow

but I really don't know why

I've tried to bring in some optimizations to no avail

I think I'll need to rework the entire Access system because it's just bad

but I don't know how other VMs handle mutable field access

if anybody knows I'm all ears

[left night]

just naive caching with copy-on-write. so it will do full clones here because there are multiple references.

it would be great if it could somehow optimize that of course, but it doesn't atm

[atomic violet]

yeah it will be hard to optimize

I think it's either comemo just doesn't memoize this, or it has some sort of "reversible constraints" or something...

[atomic violet]

to optimize you need to profile, to profile you need debug info, to have debug info you need to not optimize

literally the worst part of software engineering

[feral imp]

While I welcome memes, it seems like a great indicator, that you guys should take a break. If you continue, I'd highly advise outlining low hanging fruit (even if there isn't one!) and going for that. Memes are a path way to burnout 💀

But I'm just a goose anyways...

[atomic violet]

dherse should, I am have not done anything yet lol, I am just trying to find suspicios hashes but the <cycle 3> ruins my attempts 😂

[sturdy sequoia]

it's done by accessing fields

you can find that in access.rs somewhere in there there 's a get_field or something called

that's what's doing it

afaik

[atomic violet]

until I see that in my call graph, I am not turning back

👺

[atomic violet]

@sturdy sequoia What is foundations::Func::method?

it looks like it prehashes hella lot

and it is invoked in Access::read

🤔

[sturdy sequoia]

It creates a method from a func and a value

it's a dirty hack I created to make method access work

💀

[atomic violet]

Does every array.at(..) prehashes the array? Is this necessary?

because it sure looks like it

yeah wait lol what
